Connections
Your device offers several options to connect to the
internet or to another compatible device or PC.
Wireless LAN
Your device supports wireless local area network
(WLAN). With WLAN, you can connect your device to
the internet and compatible devices that have
WLAN.
About WLAN
To use WLAN, it must be available in the location,
and your device must be connected to the WLAN.
Some places, like France, have restrictions on the
use of wireless LAN. Check with your local
authorities for more information.
Features that use WLAN, or that are allowed to run
in the background while using other features,
increase the demand on battery power and reduce
the battery life.
Your device supports the following WLAN features:
●IEEE 802.11b/g standard
●Operation at 2.4 GHz
●Wired equivalent privacy (WEP) with keys up to
128 bits, Wi-Fi protected access (WPA), and
802.1x encryption methods. These functions can
be used only if they are supported by the
network.
WLAN connections
To use WLAN, you must create an internet access
point (IAP) in a wireless LAN. Use the access point
for applications that need to connect to the
internet. See "WLAN internet access
points", p. 102.
Important: Always enable one of the
available encryption methods to increase the
security of your wireless LAN connection. Using
encryption reduces the risk of unauthorized access
to your data.
A WLAN connection is established when you create
a data connection using a WLAN internet access
point. The active WLAN connection ends when you
end the data connection.
You can use WLAN during a voice call or when packet
data is active. You can only be connected to one
101
Connections
WLAN access point device at a time, but several
applications can use the same internet access point.
When the device is in the offline profile, you can still
use WLAN (if available). Remember to comply with
any applicable safety requirements when
establishing and using a WLAN connection.
Tip: To check the unique media access control
(MAC) address that identifies your device,
enter *#62209526# in the standby mode.
WLAN wizard
The WLAN wizard helps you to connect to a WLAN
and manage your WLAN connections.
The WLAN wizard shows the status of your WLAN
connections in the active standby mode. To view the
available options, scroll to the row showing the
status, and select it.
If the search finds WLANs, for example, WLAN
network found is displayed, to create an internet
access point (IAP) and start the web browser using
this IAP, select the status and Start Web
browsing.
If you select a secured WLAN network, you are asked
to enter the relevant passcodes. To connect to a
hidden network, you must enter the correct
network name (service set identifier, SSID). To
create a new access point for a hidden WLAN, select
New WLAN.
If you are connected to a WLAN, the IAP name is
displayed. To start the web browser using this IAP,
select the status and Continue Web browsing. To
end the connection in the WLAN, select the status
and Disconnect WLAN.
If WLAN scanning is off and you are not connected
to any WLAN, WLAN scanning off is displayed. To
set scanning on and search for available WLANs,
select the status and press the scroll key.
To start a search for available WLANs, select the
status and Search for WLAN. To set WLAN scanning
off, select the status and select WLAN scanning
off.
To access the WLAN wizard application in the menu,
press , and select Tools > WLAN wiz..
WLAN internet access points
Press , and select Tools > WLAN wiz.
Select Options and from the following:
●Filter WLAN networks — Filter out WLANs in
the list of found networks. The selected networks
are filtered out the next time the application
searches for WLANs.
●Details — View the details of a network shown
in the list. If you select an active connection, the
connection details are displayed.
●Define access point — Create an internet access
point (IAP) in a WLAN.
102
Connections
●Edit access point — Edit the details of an
existing IAP.
You can also use connection manager to create
internet access points. See "Active data
connections", p. 103.
Operating modes
There are two operating modes in WLAN:
infrastructure and ad hoc.
The infrastructure operating mode allows two
kinds of communication: wireless devices are
connected to each other through a WLAN access
point device, or wireless devices are connected to a
wired LAN through a WLAN access point device.
In the ad hoc operating mode, devices can send and
receive data directly with each other.
Connection manager
Active data connections
Press , and select Tools > Connectivity >
Conn. mgr. > Active data connections.
In the active data connections view, you can see the
open data connections:
data calls
packet data connections
WLAN connections
Note: The actual time invoiced for calls by
your service provider may vary, depending on
network features, rounding off for billing, and so
forth.
To end a connection, select Options >
Disconnect. To close all open connections, select
Options > Disconnect all.
To view the details of a connection, select
Options > Details. The details shown depend on
the connection type.
Available WLAN networks
Press , and select Tools > Connectivity >
Conn. mgr. > Available WLAN networks.
The available WLAN view shows a list of WLANs
within range, their network mode (infrastructure or
ad hoc), and signal strength indicator. is shown
for networks with encryption, and if your device
has an active connection in the network.
To view the details of a network, select Options >
Details.
To create an internet access point in a network,
select Options > Define access point.
103
Connections
Bluetooth connectivity
About Bluetooth connectivity
You can make a wireless connection to other
compatible devices with Bluetooth connectivity.
Compatible devices may include mobile phones,
computers, and enhancements such as headsets
and car kits. You can use Bluetooth connectivity to
send images, video clips, music and sound clips, and
notes; make a wireless connection to your
compatible PC (for example, to transfer files); and
connect to a compatible printer to print images
with Image print.
Since devices with Bluetooth wireless technology
communicate using radio waves, they do not need
to be in direct line-of-sight. However, they must be
within 10 metres (33 feet) of each other, although
the connection may be subject to interference from
obstructions such as walls or from other electronic
devices.
This device is compliant with Bluetooth
Specification 2.0 supporting the following profiles:
Generic Audio/Video Distribution Profile, Advanced
Audio Distribution Profile, Audio/Video Remote
Control Profile, Basic Imaging Profile, Basic Printing
Profile, Dial-up Networking Profile, File Transfer
Profile, Hands-Free Profile, Headset Profile, Human
Interface Device Profile, Object Push Profile, SIM
Access Profile, Synchronization Profile, Serial Port
Profile, and Phonebook Access Profile. To ensure
interoperability between other devices supporting
Bluetooth technology, use Nokia approved
enhancements for this model. Check with the
manufacturers of other devices to determine their
compatibility with this device.
There may be restrictions on using Bluetooth
technology in some locations. Check with your local
authorities or service provider.
Features using Bluetooth technology, or allowing
such features to run in the background while using
other features, increase the demand on battery
power and reduce the battery life.
When the device is locked, you cannot use Bluetooth
connectivity.
Settings
Press , and select Tools > Bluetooth.
When you open the application for the first time,
you are asked to define a name for your device. You
can change the name later on.
Select from the following:
●Bluetooth — To make a wireless connection to
another compatible device, first set Bluetooth
connectivity On, then establish a connection. To
switch off Bluetooth connectivity, select Off.
●My phone's visibility — To allow your device to
be found by other devices with Bluetooth
104
Connections
wireless technology, select Shown to all. To set
a time after which the visibility is set from shown
to hidden, select Define period. To hide your
device from other devices, select Hidden.
●My phone's name — Edit the name shown to
other devices with Bluetooth wireless
technology.
●Remote SmartChip mode — To enable another
device, such as a compatible car kit
enhancement, to use the SIM card in your device
to connect to the network, select On. See
"Remote SIM mode", p. 107.
Security tips
Press , and select Tools > Bluetooth.
When you are not using Bluetooth connectivity, to
control who can find your device and connect to it,
select Bluetooth > Off or My phone's visibility >
Hidden.
Do not pair with or accept connection requests from
an unknown device. This protects your device from
harmful content.
Send data using Bluetooth
connectivity
Several Bluetooth connections can be active at a
time. For example, if you are connected to a
compatible headset, you can also transfer files to
another compatible device at the same time.
1. Open the application where the item you want
to send is stored. For example, to send an image
to another compatible device, open Photos.
2. Select the item and Options > Send > Via
Bluetooth.
Devices with Bluetooth wireless technology that
are within range are displayed. Device icons are
as follows:
computer
phone
audio or video device
other device
To interrupt the search, select Stop.
3. Select the device with which you want to
connect.
4. If the other device requires pairing before data
can be transmitted, a tone sounds, and you are
asked to enter a passcode. See "Pair
devices", p. 106.
When the connection is established, Sending
data is displayed.
Tip: When searching for devices, some
devices may show only the unique address
(device address). To find the unique address
105
Connections
of your device, enter *#2820# in the standby
mode.
Pair devices
To pair with compatible devices and view your
paired devices, in the main view of Bluetooth
connectivity, scroll right.
Before pairing, create your own passcode (1 to 16
digits), and agree with the owner of the other
device to use the same code. Devices that do not
have a user interface have a factory-set passcode.
The passcode is used only once.
1. To pair with a device, select Options > New
paired device. Devices that are within range are
displayed.
2. Select the device, and enter the passcode. The
same passcode must be entered on the other
device as well.
3. Some audio enhancements connect
automatically to your device after pairing.
Otherwise, scroll to the enhancement, and select
Options > Connect to audio device.
Paired devices are indicated by in the device
search.
To set a device as authorised or unauthorised, scroll
to the device, and select from the following options:
●Set as authorized — Connections between your
device and the authorised device can be made
without your knowledge. No separate
acceptance or authorisation is needed. Use this
status for your own devices, such as your
compatible headset or PC or devices that belong
to someone you trust. indicates authorised
devices in the paired devices view.
●Set as unauthorized — Connection requests
from this device must be accepted separately
every time.
To cancel a pairing, scroll to the device, and select
Options > Delete.
If you want to cancel all pairings, select Options >
Delete all.
Receive data using Bluetooth
connectivity
When you receive data through Bluetooth
connectivity, a tone sounds, and you are asked if
you want to accept the message. If you accept,
is displayed, and the item is placed in the
Inbox folder in Messaging. Messages received
through Bluetooth connectivity are indicated by
.
106
Connections
Block devices
Press , and select Tools > Bluetooth.
To block a device from establishing a Bluetooth
connection to your device, scroll right to open
Paired devices. Select a device you want to block
and Options > Block.
To unblock a device, scroll right to Blocked
devices, select a device, and Options > Delete. To
unblock all blocked devices, select Options >
Delete all.
If you reject a pairing request from another device,
you are asked if you want to block all future
connection requests from this device. If you accept
the query, the remote device is added to the list of
blocked devices.
Remote SIM mode
Before the remote SIM mode can be activated, the
two devices must be paired and the pairing initiated
from the other device. When pairing, use a 16-digit
passcode, and set the other device as authorised.
To use the remote SIM mode with a compatible car
kit enhancement, activate Bluetooth connectivity,
and enable the use of the remote SIM mode with
your device. Activate the remote SIM mode from the
other device.
When the remote SIM mode is on in your device,
Remote SmartChip mode is displayed in the
standby mode. The connection to the wireless
network is turned off, as indicated by in the
signal strength indicator area, and you cannot use
SIM card services or features requiring cellular
network coverage.
When the wireless device is in the remote SIM mode,
you can only use a compatible connected
enhancement, such as a car kit, to make or receive
calls. Your wireless device will not make any calls
while in this mode, except to the emergency
numbers programmed into your device. To make
calls from your device, you must leave the remote
SIM mode. If the device is locked, enter the lock code
to unlock it.
To leave the remote SIM mode, press the power key,
and select Exit remote SChip mode.
USB
Press , and select Tools > Connectivity >
USB.
To have the device ask the purpose of the
connection each time a compatible data cable is
connected, select Ask on connection > Yes.
If Ask on connection is set to off or you want to
change the mode during an active connection,
107
Connections
select USB connection mode and from the
following:
●PC Suite — Use Nokia PC applications such as
Nokia Nseries PC suite, and Nokia Software
Updater.
●Mass storage — Transfer data between your
device and a compatible PC. Use this mode also
for downloading maps with the Nokia Map
Loader PC application.
●Image transfer — Print images on a compatible
printer.
●Media transfer — Synchronise music with
Windows Media Player.
●Multimedia — Synchronise your images, videos,
and messages and their properties between your
Nokia device and a compatible PC.
PC connections
You can use your device with a variety of compatible
PC connectivity and data communications
applications. With Nokia Nseries PC Suite you can,
for example, transfer images between your device
and a compatible PC.
For information on Apple Macintosh support and
connecting your device to an Apple Macintosh
device, visit www.nseries.com/mac.
108
Connections
Media folder
RealPlayer
With RealPlayer, you can play video clips or stream
media files over the air without saving them to the
device first.
RealPlayer supports files with extensions such as .
3gp, .mp4, or .rm. However, RealPlayer does not
necessarily support all file formats or all the
variations of file formats.
Play video clips
Press , and select Applications > Media >
RealPlayer.
To play a saved media file, select Video clips, a clip,
and Play.
To list previously played files, in the application
main view, select Recently played.
To adjust the volume, use the volume key.
After you select a media file, select Options and
from the following:
●Send — Send a file using a multimedia message,
e-mail, or other connection methods, such as
Bluetooth connectivity.
●Use video — Assign a video to a contact or set
it as a ringing tone.
●Mark/Unmark — Mark items in the list to send
or delete multiple items at the same time.
●View details — View details of the selected
item, such as format, resolution, and duration.
●Settings — Edit the settings for video playback
and streaming.
Stream content over the air
Many service providers require you to use an
internet access point (IAP) for your default access
point. Other service providers allow you to use a
WAP access point.
In RealPlayer, you can only open an rtsp:// URL
address. However, RealPlayer plays a .ram file if you
open an HTTP link to it in a browser.
To stream content over the air (network service), in
RealPlayer or Photos, select a streaming link saved
in the Streaming links folder. You can also receive
a streaming link in a text message or multimedia
message, or open a link on a web page. Before live
content begins streaming, your device connects to
109
Media folder
the site and starts loading the content. The content
is not saved in your device.
RealPlayer settings
Press , and select Applications > Media >
RealPlayer.
You may receive RealPlayer settings in a special
message from the service provider. For more
information, contact your service provider.
Select Options > Settings and from the following:
●Video — Select whether video clips are played
in full screen or in the normal view, and whether
the clips are automatically repeated after they
finish playing.
●Streaming — Select whether to use a proxy
server, change the default access point, and set
the port range used when connecting. Contact
your service provider for the correct settings.
Advanced settings
To edit the advanced settings, in the settings view,
select Streaming > Network > Options >
Advanced settings.
To select the bandwidth used for a network, select
the network setting and the desired value.
To edit the bandwidth yourself, select User
defined.
Adobe Flash Player
Press , and select Applications > Media >
Flash Player.
Use Adobe Flash Player to view, play, and interact
with compatible flash files made for mobile devices.
To open a flash file, select it, and Open.
Licences
To view digital rights licences, press , and select
Applications > Media > Licenses.
Digital rights management
Content owners may use different types of digital
rights management (DRM) technologies to protect
their intellectual property, including copyrights.
This device uses various types of DRM software to
access DRM-protected content. With this device you
can access content protected with WMDRM 10, OMA
DRM 1.0, and OMA DRM 2.0. If certain DRM software
fails to protect the content, content owners may ask
that such DRM software's ability to access new DRM-
protected content be revoked. Revocation may also
prevent renewal of such DRM-protected content
already in your device. Revocation of such DRM
software does not affect the use of content
protected with other types of DRM or the use of non-
DRM-protected content.
110
Media folder
Digital rights management (DRM) protected content
comes with an associated activation key that
defines your rights to use the content.
If your device has OMA DRM protected content, to
back up both the activation keys and the content,
use the backup feature of Nokia Nseries PC Suite.
Other transfer methods may not transfer the
activation keys which need to be restored with the
content for you to be able to continue the use of
OMA DRM-protected content after the device
memory is formatted. You may also need to restore
the activation keys in case the files on your device
get corrupted.
If your device has WMDRM protected content, both
the activation keys and the content will be lost if the
device memory is formatted. You may also lose the
activation keys and the content in case the files on
your device get corrupted. Losing the activation
keys or the content may limit your ability to use the
same content on your device again. For more
information, contact your service provider.
Some licences may be connected to a specific SIM
card, and the protected content can be accessed
only if the SIM card is inserted in the device.
In the main view, select from the following:
●Valid licenses — View licences that are
connected to media files or whose validity period
has not begun.
●Invalid licenses — View licences that are not
valid; the time period for using the media file is
exceeded or there is a protected media file in the
device but no connected activation key.
●Not in use — View licences that have no media
files connected to them in the device.
To buy more usage time for a media file, select an
invalid licence and Options > Get new license
(web service messages must be enabled). See "Web
service message settings", p. 123.
To view detailed information, such as the validity
status and ability to send the file, scroll to an
activation key, and press the scroll key.
Recorder
Press , and select Applications > Media >
Recorder.
With Recorder, you can record voice memos and
telephone conversations.
To record a telephone conversation, open Recorder
during a voice call. Both parties hear a tone every 5
seconds during recording.
111
Media folder
Messaging
Only devices that have compatible features can
receive and display multimedia messages. The
appearance of a message may vary depending on
the receiving device.
Messaging main view
Press , and select Messaging (network service).
To create a new message, select New message.
Messaging contains the following folders:
● Inbox — Received messages, except e-mail
and cell broadcast messages, are stored here.
● My folders — Organise your messages into
folders.
Tip: To avoid rewriting messages that you
send often, use texts in the Templates folder
in My folders. You can also create and save
your own templates.
● New mailbox — Connect to your remote
mailbox to retrieve your new e-mail messages,
or view your previously retrieved e-mail
messages offline.
● Drafts — Draft messages that have not been
sent are stored here.
● Sent — The last messages that have been
sent, excluding messages sent using Bluetooth
connectivity, are stored here. You can change the
number of messages to save in this folder.
● Outbox — Messages waiting to be sent are
temporarily stored in the outbox, for example,
when your device is outside network coverage.
● Reports — You can request the network to
send you a delivery report of the text messages
and multimedia messages you have sent
(network service).
To enter and send service requests (also known as
USSD commands), such as activation commands for
network services, to your service provider, select
Options > Service commands in the Messaging
main view.
Cell broadcast (network service) allows you to
receive messages on various topics, such as
weather or traffic conditions, from your service
provider. For available topics and relevant topic
numbers, contact your service provider. In the
Messaging main view, select Options > Cell
broadcast.
112
Messaging
Cell broadcast messages cannot be received in UMTS
networks. A packet data connection may prevent
cell broadcast reception.
Write text
Your device supports traditional text input and
predictive text input. With predictive text, you can
enter any letter with a single keypress. Predictive
text input is based on a built-in dictionary to which
you can add new words.
When you write text, is displayed when you
write text using traditional text input and
when using predictive text input.
Traditional text input
Press a number key (1–9) repeatedly until the
desired character appears. There are more
characters available for a number key than are
printed on the key.
If the next letter is located on the same key as the
present one, wait until the cursor appears (or scroll
right to end the time-out period), and enter the
letter.
To insert a space, press 0. To move the cursor to the
next line, press 0 three times.
Predictive text input
With predictive input, you can enter any letter with
a single keypress. Predictive text input is based on
a built-in dictionary to which you can add new
words.
1. To turn predictive text input on or off in the
general settings, press , and select Tools >
Settings > General > Personalization >
Language > Predictive text.
2. To write the desired word, press the keys 2–9.
Press each key only once for one letter. For
example, to write "Nokia" when the English
dictionary is selected, press 6 for N, 6 for o, 5 for
k, 4 for i, and 2 for a.
The word suggestion changes after each
keypress.
3. When you finish writing the word correctly,
scroll right to confirm it, or press 0 to add a
space.
If the word is not correct, press * repeatedly to
view the matching words the dictionary has
found one by one.
If the ? character is shown after the word, the
word is not in the dictionary. To add a word to
the dictionary, select Spell, enter the word using
traditional text input, and select OK. The word is
added to the dictionary. When the dictionary is
full, a new word replaces the oldest added word.
113
Messaging
4. Start writing the next word.
Tips on text input
To insert a number in the letter mode, press and
hold the desired number key.
To switch between the different character modes,
press #.
To delete a character, press C. To delete more than
one character, press and hold C.
The most common punctuation marks are available
under 1. To scroll them through one by one, if you
use traditional text input, press 1 repeatedly. If you
use predictive text input, press 1, and then *
repeatedly.
To open a list of special characters, press and hold
*.
Tip: To select several special characters from
the special characters list, press 5 after each
highlighted character.
Change the writing language
When you are writing text, you can change the
writing language. For example, if you are writing
text using a non-Latin alphabet and want to write
Latin characters, such as e-mail or web addresses,
you may need to change the writing language.
To change the writing language, select Options >
Writing language and a writing language that
uses Latin characters.
After changing the writing language, for example,
if you press 6 repeatedly to reach a specific
character, changing the writing language gives you
access to characters in a different order.
Edit text and lists
To copy and paste text, while pressing and holding
#, scroll left or right to highlight text. To copy the
text to the clipboard, while still holding #, select
Copy. To insert the text into a document, press and
hold #, and select Paste.
To mark an item in a list, scroll to it, and press #.
To mark multiple items in a list, press and hold #
while you scroll up or down. To end the selection,
stop scrolling, and release #.
Write and send messages
Press , and select Messaging.
Before you can create a multimedia message or
write an e-mail, you must have the correct
connection settings in place. See "Define the e-mail
settings", p. 117.
114
Messaging
The wireless network may
limit the size of MMS
messages. If the inserted
picture exceeds this limit,
the device may make it
smaller so that it can be
sent by MMS.
Check the size limit of e-
mail messages with your
service provider. If you
attempt to send an e-mail
message that exceeds the
size limit of the e-mail server, the message is left in
the Outbox folder, and the device attempts to
resend it periodically. Sending an e-mail requires a
data connection, and continuous attempts to
resend the e-mail may increase your phone bill. In
the Outbox folder, you can delete such a message
or move it to the Drafts folder.
1. Select New message > Message to send a text
message or a multimedia message (MMS), Audio
message to send an audio message (a
multimedia message that includes one sound
clip), or E-mail to send an e-mail.
2. In the To field, press the scroll key to select
recipients or groups from contacts, or enter the
recipient’s phone number or e-mail address. To
add a semicolon (;) that separates the recipients,
press *. You can also copy and paste the number
or address from the clipboard.
3. In the Subject field, enter the subject of the e-
mail. To change the fields that are visible, select
Options > Message header fields.
4. In the message field, write the message. To
insert a template or note, select Options >
Insert > Insert text > Template or Note.
5. To add a media object to a multimedia message,
select Options > Insert, the object type or
source, and the desired object. To insert a
business card, slide, note, or some other file to
the message, select Options > Insert > Insert
other.
6. To capture an image or record video or sound for
a multimedia message, select Options >
Insert > Insert image > New, Insert video
clip > New, or Insert audio clip > New .
7. To add an attachment to an e-mail, select
Options > Insert > Image, Audio clip, Video
clip, Note, or Other for other file types. E-mail
attachments are indicated by .
8. To send the message, select Options > Send,
or press the call key.
Note: Your device may indicate that your
message was sent to the message center number
programmed into your device. Your device may not
115
Messaging
indicate whether the message is received at the
intended destination. For more details about
messaging services, contact your service provider.
Your device supports the sending of text messages
beyond the character limit for a single message.
Longer messages are sent as a series of two or more
messages. Your service provider may charge
accordingly. Characters that use accents or other
marks, and characters from some language options,
take up more space, limiting the number of
characters that can be sent in a single message.
You may not be able to send video clips that are
saved in the .mp4 format or that exceed the size
limit of the wireless network in a multimedia
message.
Tip: You can combine images, video, sound,
and text to a presentation and send it in a
multimedia message. Start to create a
multimedia message, and select Options >
Insert > Insert presentation. The option is
shown only if MMS creation mode is set to
Guided or Free. See "Multimedia message
settings", p. 120.
Messaging inbox
Receive messages
Press , and select Messaging > Inbox.
In the Inbox folder, indicates an unread text
message, an unread multimedia message, an
unread audio message, and data received
through Bluetooth connectivity.
When you receive a message, and 1 new
message are shown in the standby mode. To open
the message, select Show. To open a message in
Inbox, scroll to it, and press the scroll key. To reply
to a received message, select Options > Reply.
Multimedia messages
Important: Exercise caution when opening
messages. Multimedia message objects may
contain malicious software or otherwise be harmful
to your device or PC.
You may receive a notification that a multimedia
message is waiting in the multimedia message
centre. To start a packet data connection to retrieve
the message to your device, select Options >
Retrieve.
When you open a multimedia message ( ), you
may see an image and a message. is shown if
sound is included, or if video is included. To play
the sound or the video, select the indicator.
To see the media objects that have been included
in the multimedia message, select Options >
Objects.
116
Messaging
If the message includes a multimedia presentation,
is displayed. To play the presentation, select the
indicator.
Data, settings, and web service
messages
Your device can receive many kinds of messages
that contain data, such as business cards, ringing
tones, operator logos, calendar entries, and e-mail
notifications. You may also receive settings from
your service provider or company information
management department in a configuration
message.
To save the data from the message, select
Options and the corresponding option.
Web service messages are notifications (for
example, news headlines) and may contain a text
message or a link. For availability and subscription,
contact your service provider.
Message reader
With Message reader you can listen to text,
multimedia, and audio messages and e-mail.
To change the message reading settings in the
Speech application, select Options > Speech. See
"Speech ", p. 150.
To listen to new messages or e-mail, in the standby
mode, press and hold the left selection key until
Message reader starts.
To listen to messages from your Inbox or e-mail
from your Mailbox, select a message and Options >
Listen. To stop the reading, press the end key.
To pause and continue the reading, press the scroll
key. To skip to the next message, scroll right. To
replay the current message or e-mail, scroll left. To
skip to the previous message, scroll left in the
beginning of the message. To adjust the volume,
scroll up or down.
To view the current message or e-mail in text
format without the sound, select Options >
View.
Mailbox
Define the e-mail settings
Tip: To define your mailbox settings, press
, and select Messaging > Mailboxes.
To use e-mail, you must have a valid internet access
point (IAP) in the device and define your e-mail
settings correctly. See "Access points", p. 160. See
"E-mail settings", p. 121.
117
Messaging
You must have a separate e-mail account. Follow
the instructions given by your remote mailbox and
internet service provider (ISP).
If you select New mailbox in the Messaging main
view and have not set up your e-mail account, you
are prompted to do so. To start creating the e-mail
settings with the mailbox guide, select Start.
When you create a new mailbox, the name you give
to the mailbox replaces New mailbox in the
Messaging main view. You can have up to six
mailboxes.
Open the mailbox
Press , and select Messaging and a mailbox.
When you open the mailbox, the device asks if you
want to connect to the mailbox (Connect to
mailbox?).
To connect to your mailbox and retrieve new e-mail
headings or messages, select Yes. When you view
messages online, you are continuously connected
to a remote mailbox using a data connection.
To view previously retrieved e-mail messages
offline, select No.
To create a new e-mail message, select New
message > E-mail in the Messaging main view or
Options > Create message > E-mail in your
mailbox. See "Write and send messages", p. 114.
Retrieve e-mail messages
Press , and select Messaging and a mailbox.
If you are offline, select Options > Connect to start
a connection to the remote mailbox.
Important: Exercise caution when opening
messages. E-mail messages may contain malicious
software or otherwise be harmful to your device or
PC.
1. When you have an open connection to a remote
mailbox, select Options > Retrieve e-mail >
New to retrieve all new messages, Selected to
retrieve only the messages that have been
marked, or All to retrieve all messages from the
mailbox.
To stop retrieving messages, select Cancel.
2. To close the connection and view the e-mail
messages offline, select Options >
Disconnect.
3. To open an e-mail message, press the scroll key.
If the e-mail message has not been retrieved and
you are offline, you are asked if you want to
retrieve this message from the mailbox.
To view e-mail attachments, open the message, and
select the attachment field indicated by . If the
attachment has a dimmed indicator, it has not been
118
Messaging
retrieved to the device; select Options >
Retrieve.
To retrieve e-mail messages automatically, select
Options > E-mail settings > Automatic
retrieval. See "Automatic retrieval
settings", p. 123.
Setting the device to retrieve e-mail automatically
may involve the transmission of large amounts of
data through your service provider's network.
Contact your service provider for information about
data transmission charges.
Delete e-mail messages
Press , and select Messaging and a mailbox.
To delete the contents of an e-mail message from
the device while still retaining it in the remote
mailbox, select Options > Delete. In Delete e-
mail from:, select Phone only.
The device mirrors the e-mail headings in the
remote mailbox. Although you delete the message
content, the e-mail heading stays in your device. If
you want to remove the heading as well, you must
first delete the e-mail message from your remote
mailbox, then make a connection from your device
to the remote mailbox again to update the status.
To delete an e-mail from the device and the remote
mailbox, select Options > Delete > Phone and
server.
To cancel deleting an e-mail from the device and
server, scroll to an e-mail that has been marked to
be deleted during the next connection , and
select Options > Restore.
Disconnect from the mailbox
When you are online, to end the data connection to
the remote mailbox, select Options >
Disconnect.
View messages on a SIM card
Press , and select Messaging.
Before you can view SIM messages, you must copy
them to a folder in your device.
1. In the Messaging main view, select Options >
SmartChip messages.
2. Select Options > Mark/Unmark > Mark or
Mark all to mark messages.
3. Select Options > Copy. A list of folders opens.
4. To start copying, select a folder and OK. To view
the messages, open the folder.
Messaging settings
The settings may be preconfigured in your device,
or you may receive them in a message. To enter
119
Messaging
settings manually, fill in all fields marked with Must
be defined or an asterisk.
Some or all message centres or access points may
be preset for your device by your service provider,
and you may not be able to change, create, edit, or
remove them.
Text message settings
Press , and select Messaging > Options >
Settings > Text message.
Select from the following:
●Message centers — View a list of all text
message centres that have been defined.
●Message center in use — Select which message
centre to use to deliver text messages.
●Character encoding — To use character
conversion to another encoding system when
available, select Reduced support.
●Receive report — Select whether the network
sends delivery reports on your messages
(network service).
●Message validity — Select how long the
message centre resends your message if the first
attempt fails (network service). If the message
cannot be sent within the validity period, the
message is deleted from the message centre.
●Message sent as — Contact your service
provider to learn if your message centre is able
to convert text messages into these other
formats.
●Preferred connection — Select the connection
to use.
●Reply via same center — Select whether you
want the reply message to be sent using the
same text message centre number (network
service).
Multimedia message settings
Press , and select Messaging > Options >
Settings > Multimedia message.
Select from the following:
●Image size — Define the size of the image in a
multimedia message.
●MMS creation mode — If you select Guided, the
device informs you if you try to send a message
that may not be supported by the recipient. If you
select Restricted, the device prevents you from
sending messages that may not be supported. To
include content in your messages without
notifications, select Free.
●Access point in use — Select which access point
is used as the preferred connection.
●Multimedia retrieval — Select how you want
to receive messages. To receive messages
automatically in your home cellular network,
select Auto in home netw.. Outside your home
cellular network, you receive a notification that
120
Messaging
there is a message to retrieve in the multimedia
message centre.
Outside your home cellular network, sending and
receiving multimedia messages may cost you more.
If you select Multimedia retrieval > Always
automatic, your device automatically makes an
active packet data connection to retrieve the
message both in and outside your home cellular
network.
●Allow anonymous msgs. — Select whether you
want to reject messages from an anonymous
sender.
●Receive ads — Define whether you want to
receive multimedia message advertisements.
●Receive reports — Select whether you want the
status of the sent message to be shown in the log
(network service).
●Deny report sending — Select whether you
want to prevent your device from sending
delivery reports of received messages.
●Message validity — Select for how long the
message centre resends your message if the first
attempt fails (network service). If the message
cannot be sent within this time period, the
message is deleted from the message centre.
E-mail settings
Manage mailboxes
Press , and select Messaging > Options >
Settings > E-mail.
To select which mailbox you want to use to send e-
mail, select Mailbox in use and a mailbox.
To remove a mailbox and its messages from your
device, select Mailboxes, scroll to the desired
mailbox, and press C.
To create a new mailbox, in Mailboxes, select
Options > New mailbox. The name you give to
the new mailbox replaces New mailbox in the
Messaging main view. You can have up to six
mailboxes.
Select Mailboxes and a mailbox to change the
connection settings, user settings, retrieval
settings, and automatic retrieval settings.
Connection settings
Press , and select Messaging > Options >
Settings > E-mail > Mailboxes, a mailbox, and
Connection settings.
To edit the settings for the e-mail you receive, select
Incoming e-mail, and from the following:
●User name — Enter your user name given to you
by your service provider.
121
Messaging
●Password — Enter your password. If you leave
this field blank, you are prompted for the
password when you try to connect to your
remote mailbox.
●Incoming mail server — Enter the IP address
or host name of the mail server that receives your
e-mail.
●Access point in use — Select an internet access
point (IAP). See "Access points", p. 160.
●Mailbox name — Enter a name for the mailbox.
●Mailbox type — Defines the e-mail protocol that
your remote mailbox service provider
recommends. The options are POP3 and IMAP4.
This setting cannot be changed.
●Security — Select the security option used to
secure the connection to the remote mailbox.
●Port — Define a port for the connection.
●APOP secure login (for POP3 only) — Use with
the POP3 protocol to encrypt the sending of
passwords to the remote e-mail server while
connecting to the mailbox.
To edit the settings for the e-mail you send, select
Outgoing e-mail and from the following:
●My e-mail address — Enter the e-mail address
given to you by your service provider.
●Outgoing mail server — Enter the IP address or
host name of the mail server that sends your e-
mail. You may only be able to use the outgoing
server of your service provider. Contact your
service provider for more information.
The settings for User name, Password, Access
point in use, Security, and Port are similar to the
ones in Incoming e-mail.
User settings
Press , and select Messaging > Options >
Settings > E-mail > Mailboxes, a mailbox, and
User settings.
Select from the following:
●My name — Enter your own name. Your name
replaces your e-mail address in the recipient’s
device when the recipient’s device supports this
function.
●Send message — Define how e-mail is sent from
your device. Select Immediately for the device
to connect to the mailbox when you select Send
message. If you select During next conn., e-
mail is sent when the connection to the remote
mailbox is available.
●Send copy to self — Select whether you want
to send a copy of the e-mail to your own mailbox.
●Include signature — Select whether you want
to attach a signature to your e-mail messages.
●New e-mail alerts — Select whether you want
to receive the new e-mail indications (a tone, a
note, and a mail indicator) when new mail is
received.
122
Messaging
Retrieval settings
Press , and select Messaging > Options >
Settings > E-mail > Mailboxes, a mailbox, and
Retrieval settings.
Select from the following:
●E-mail retrieval — Define which parts of the e-
mail are retrieved: Headers only, Size limit
(POP3), or Msgs. & attachs. (POP3).
●Retrieval amount — Define how many new e-
mail messages are retrieved to the mailbox.
●IMAP4 folder path (for IMAP4 only) — Define
the folder path for folders to be subscribed.
●Folder subscriptions (for IMAP4 only)
— Subscribe to other folders in the remote
mailbox, and retrieve content from those folders.
Automatic retrieval settings
Press , and select Messaging > Options >
Settings > E-mail > Mailboxes, a mailbox, and
Automatic retrieval.
Select from the following:
●E-mail notifications — To automatically
retrieve the headings to your device when you
receive new e-mail in your remote mailbox,
select Auto-update or Only in home netw..
●E-mail retrieval — To automatically retrieve the
headings of new e-mail messages from your
remote mailbox at defined times, select
Enabled or Only in home netw.. Define when
and how often the messages are retrieved.
E-mail notifications and E-mail retrieval cannot
be active at the same time.
Setting the device to retrieve e-mail automatically
may involve the transmission of large amounts of
data through your service provider's network.
Contact your service provider for information about
data transmission charges.
Web service message settings
Press , and select Messaging > Options >
Settings > Service message.
Select whether you want to receive service
messages. If you want to set the device to
automatically activate the browser and start a
network connection to retrieve content when you
receive a service message, select Download
messages > Automatically.
Cell broadcast settings
Check the available topics and related topic
numbers with your service provider.
Press , and select Messaging > Options >
Settings > Cell broadcast.
Select from the following:
123
Messaging
●Reception — Select whether you want to
receive cell broadcast messages.
●Language — Select the languages in which you
want to receive messages: All, Selected, or
Other.
●Topic detection — Select whether the device
automatically searches for new topic numbers,
and saves the new numbers without a name to
the topic list.
Other settings
Press , and select Messaging > Options >
Settings > Other.
Select from the following:
●Save sent messages — Select whether you
want to save a copy of the text messages,
multimedia messages, or e-mail that you send to
the Sent folder.
●Number of saved msgs. — Define how many
sent messages are saved to the sent folder at a
time. When the limit is reached, the oldest
message is deleted.
●Memory in use — Select the memory where you
want to save your messages.
124
Messaging
Make calls
Voice calls
1. In the standby mode, enter the phone number,
including the area code. To remove a number,
press C.
For international calls, press * twice for the +
character (which replaces the international
access code), and enter the country code, area
code (omit the leading zero if necessary), and
phone number. The character + as a replacement
for the international access code may not work
in all regions. In this case, enter the international
access code directly.
2. To end the call, press the call key.
3. To end the call (or to cancel the call attempt),
press the end key.
Pressing the end key always ends a call, even if
another application is active.
To make a call from Contacts, press , and select
Addr. Book. Scroll to the desired name, or enter the
first letters of the name to the search field. Matching
contacts are listed. To call, press the call key. If you
have saved several numbers for a contact, select the
desired number from the list, and press the call key.
Options during a call
To adjust the volume during a call, use the volume
key on the side of your device. You can also use the
scroll key. If you have set the volume to Mute, select
Unmute first.
To send an image or a video clip in a multimedia
message to the other participant of the call, select
Options > Send MMS (in UMTS networks only). You
can edit the message and change the recipient
before sending. Press the call key to send the file to
a compatible device (network service).
To put an active voice call on hold while answering
another incoming call, select Options > Hold. To
switch between the active and the held call, select
Options > Swap.
To send DTMF tone strings (for example, a
password), select Options > Send touch tones.
Enter the DTMF string or search for it in Contacts. To
enter a wait character (w) or a pause character (p),
press * repeatedly. To send the tone, select OK. You
can add DTMF tones to the phone number or DTMF
fields in a contact card.
125
Make calls
Tip: When you have only one active voice call,
to put the call on hold, press the call key. To
activate the call, press the call key again.
During an active call, to route the sound from the
handset to the loudspeaker, select Options >
Activate loudspeaker. If you have attached a
compatible headset with Bluetooth connectivity, to
route the sound to the headset, select Options >
Activate handsfree. To switch back to the handset,
select Options > Activate handset.
To end an active call and replace it by answering the
waiting call, select Options > Replace.
If you have several calls active, to end them all,
select Options > End all calls.
Many of the options that you can use during a voice
call are network services.
Voice and video mailboxes
To call your voice or video mailbox (network
services, video mailbox available only in the UMTS
network), press and hold 1 in the standby mode,
and select Voice mailbox or Video mailbox.
To change the phone number of your voice or video
mailbox, press , and select Tools > Utilities >
Call mailbox, a mailbox, and Options > Change
number. Enter the number (obtained from your
network service provider), and select OK.
Answer or decline a call
To answer the call, press the call key.
To mute the ringing tone of an incoming call, select
Silence.
If you do not want to answer a call, press the end
key. If you activate the Call forwarding > Voice
calls > If busy function in phone settings to
forward calls, declining an incoming call also
forwards the call.
When you select Silence to mute the ringing tone
of an incoming call, you can send a text message
without rejecting the call, informing the caller that
you cannot answer the call. Select Options > Send
message. To set up this option and write a standard
text message, select Tools > Settings > Phone >
Call > Reject call with message.
Make a conference call
1. Make a call to the first participant.
2. To make a call to another participant, select
Options > New call. The first call is
automatically put on hold.
3. When the new call is answered, to join the first
participant in the conference call, select
Options > Conference.
126
Make calls
To add a new person to the call, repeat step 2,
and select Options > Conference > Add to
conference. Your device supports conference
calls between a maximum of six participants,
including yourself.
To have a private conversation with one of the
participants, select Options > Conference >
Private. Select a participant, and select
Private. The conference call is put on hold on
your device. The other participants can still
continue the conference call. After you finish the
private conversation, select Options >
Conference to return to the conference call.
To drop a participant, select Options >
Conference > Drop participant, scroll to the
participant, and select Drop.
4. To end the active conference call, press the end
key.
1-touch dial a phone number
To activate the feature, press , and select Tools >
Settings > Phone > Call > Speed dialing.
To assign a phone number to one of the number
keys (2-9), press , and select Tools > Utilities >
Speed dial. Scroll to the key to which you want to
assign the phone number, and select Options >
Assign. 1 is reserved for the voice or video mailbox,
and for starting the web browser.
To call in the standby mode, press the assigned key
and the call key.
Call waiting
You can answer a call while you have another call in
progress if you have activated call waiting in
Settings > Phone > Call > Call waiting
(network service).
To answer the waiting call, press the call key. The
first call is put on hold.
To switch between the two calls, select Swap. To
connect an incoming call or a call on hold with an
active call and to disconnect yourself from the calls,
select Options > Transfer. To end the active call,
press the end key. To end both calls, select
Options > End all calls.
Voice dialling
Your device supports enhanced voice commands.
Enhanced voice commands are not dependent on
the speaker’s voice, so the user does not record
voice tags in advance. Instead, the device creates a
voice tag for the entries in contacts, and compares
the spoken voice tag to it. The voice recognition in
127
Make calls
the device adapts to the main user’s voice to
recognise the voice commands better.
The voice tag for a contact is the name or nickname
that is saved on the contact card. To listen to the
synthesised voice tag, open a contact card, and
select Options > Play voice tag.
Make a call with a voice tag
Note: Using voice tags may be difficult in a
noisy environment or during an emergency, so you
should not rely solely upon voice dialing in all
circumstances.
When you use voice dialling, the loudspeaker is in
use. Hold the device at a short distance away when
you say the voice tag.
1. To start voice dialling, in the standby mode,
press and hold the right selection key. If a
compatible headset with the headset key is
attached, press and hold the headset key to start
voice dialling.
2. A short tone is played, and Speak now is
displayed. Say clearly the name or nickname that
is saved on the contact card.
3. The device plays a synthesised voice tag for the
recognised contact in the selected device
language, and displays the name and number.
After a time-out of 2.5 seconds, the device dials
the number. If the recognised contact was not
correct, select Next to view a list of other
matches or Quit to cancel voice dialling.
If several numbers are saved under the name, the
device selects the default number if it has been set.
If not, the device selects the first available number
in a contact card.
Make a video call
When you make a video call (network service), you
can see a real-time, two-way video between you
and the recipient of the call. The live video image,
or video image captured by the camera in your
device is shown to the video call recipient.
To be able to make a video call, you must have a
USIM card and be in the coverage of a UMTS network.
For availability of and subscription to video call
services, contact your network service provider.
A video call can only be made between two parties.
The video call can be made to a compatible mobile
device or an ISDN client. Video calls cannot be made
while another voice, video, or data call is active.
Icons
You are not receiving video (the recipient is not
sending video or the network is not transmitting it).
You have denied video sending from your
device. To send a still image instead, select Tools >
128
Make calls
Settings > Phone > Call > Image in video
call.
Even if you denied video sending during a video call,
the call is still charged as a video call. Check the
pricing with your service provider.
1. To start a video call, enter the phone number in
the standby mode, or select Addr. Book and a
contact.
2. Select Options > Call > Video call.
The secondary camera on the front is used by
default for video calls. Starting a video call may
take a while. Waiting for video image is
shown. If the call is not successful (for example,
video calls are not supported by the network, or
the receiving device is not compatible), you are
asked if you want to try a normal call or send a
text or multimedia message instead.
The video call is active when you see two video
images, and hear the sound through the
loudspeaker. The call recipient may deny video
sending ( ), in which case you only hear the
sound and may see a still image or a grey
background graphic.
3. To end the video call, press the end key.
Options during a video call
To change between showing video or hearing only
sound, select Options > Enable, or Disable and
the desired option.
To use the main camera to send video, select
Options > Use main camera. To switch back to
the secondary camera, select Options > Use
secondary camera.
To take a snapshot of the video you are sending,
select Options > Send snapshot. Video sending is
paused and the snapshot is shown to the recipient.
The snapshot is not saved. Press Cancel to resume
sending video.
To zoom your image in or out, select Options >
Zoom.
To route the audio to a compatible headset with
Bluetooth connectivity attached to your device,
select Options > Activate handsfree. To route the
audio back to the loudspeaker of your device, select
Options > Activate handset.
To change the video quality, select Options >
Video preference. Normal quality is framerate 10
fps. Use Clearer detail is lower framerate for small,
static details. Use Smoother motion for moving
image that requires a higher framerate.
To adjust the volume during a video call, use the
volume key on the side of the device.
129
Make calls
Answer or decline a video
call
When a video call arrives, is displayed.
To answer the video call, press the call key. Allow
video image to be sent to caller? is displayed. To
start sending live video image, select Yes.
If you do not activate the video call, video sending
is not activated, and you only hear the sound of the
caller. A grey screen replaces the video image. To
replace the grey screen with a still image captured
by the camera in your device, select Tools >
Settings > Phone > Call > Image in video
call.
To end the video call, press the end key.
Video sharing
Use video sharing (network service) to send live
video or a video clip from your mobile device to
another compatible mobile device during a voice
call.
The loudspeaker is active when you activate Video
sharing. If you do not want to use the loudspeaker
for the voice call while you share video, you can also
use a compatible headset.
Requirements
Video sharing requires a UMTS connection. Your
ability to use video sharing depends on the
availability of the UMTS network. Contact your
service provider for more information on the service
and network availability and fees associated with
using this service.
To use video sharing you must do the following:
●Ensure that your device is set up for person-to-
person connections.
●Ensure you have an active UMTS connection and
are within UMTS network coverage. If you start
the sharing session while you are within UMTS
network coverage and a hand over to GSM occurs,
the sharing session is discontinued, but your
voice call continues. You cannot start video
sharing if you are not within UMTS network
coverage.
●Ensure that both the sender and recipient are
registered to the UMTS network. If you invite
someone to a sharing session and the recipient’s
device is not within UMTS network coverage,
does not have video sharing installed, or person-
to-person connections set up, the recipient does
not know that you are sending an invitation. You
receive an error message that indicates that the
recipient cannot accept the invitation.
130
Make calls
Settings
To set up video sharing, you need person-to-person
and UMTS connection settings.
Person-to-person connection settings
A person-to-person connection is also known as a
Session Initiation Protocol (SIP) connection. The SIP
profile settings must be configured in your device
before you can use video sharing. Ask your service
provider for the SIP profile settings, and save them
in your device. Your service provider may send you
the settings over the air or give you a list of the
needed parameters.
To add a SIP address to a contact card, do the
following:
1. Press , and select Addr. Book.
2. Open the contact card (or start a new card for
that person).
3. Select Options > Add detail > Share video.
4. Enter the SIP address in the format
username@domainname (you can use an IP
address instead of a domain name).
If you do not know the SIP address for the
contact, you can use the phone number of the
recipient, including the country code, to share
video (if supported by the network service
provider).
UMTS connection settings
To set up your UMTS connection, do the following:
●Contact your service provider to establish an
agreement for you to use the UMTS network.
●Ensure that your device UMTS access point
connection settings are configured properly.
Share live video or video clips
During an active voice call, select Options > Share
video :
1. To share live video during the call, select Live
video.
To share a video clip, select Recorded clip.
Select a clip you want to share.
You may need to convert the video clip into a
suitable format to be able to share it. Clip must
be converted for sharing. Continue? appears.
Select OK.
2. To share the video, select Options > Invite.
If you share live video, your device sends the
invitation to the SIP address you have added to
the recipient's contact card. If the contact
information of the recipient is saved in Contacts,
and the contact has several SIP addresses or
phone numbers including the country code,
select the desired address or number. If the SIP
address or phone number of the recipient is not
available, enter the SIP address or the phone
131
Make calls
number of the recipient including the country
code, and select OK to send the invitation.
Sharing begins automatically when the recipient
accepts the invitation.
Options during video sharing
to zoom the video (available for sender only)
to adjust the brightness (available for sender
only)
or to mute or unmute the microphone
or to switch the loudspeaker on and off
to switch to full screen mode (available for
receiver only)
3. To end the sharing session, select Stop. To end
the voice call, press the end key. When you end
the call, video sharing also ends.
To save the live video you shared, select Save when
prompted. The shared video is saved in Photos.
If you access other applications while you are
sharing a video clip, the sharing is paused. To return
to the video sharing view and to continue sharing,
in the active standby mode, select Options >
Continue.
Accept an invitation
When someone sends you a video sharing
invitation, the invitation message displays the
sender’s name or SIP address. If your device is not
set to silent, it rings when you receive an invitation.
If someone sends you a share invitation and you are
not within UMTS network coverage, you will not
know that you received an invitation.
When you receive an invitation, select from the
following:
●Accept — Activates the sharing session.
●Reject — Declines the invitation. The sender
receives a message that you rejected the
invitation. You can also press the end key to
decline the sharing session and disconnect the
voice call.
When you receive a video clip, to mute the sound of
the clip, select Mute.
To end video sharing, select Stop. Video sharing
also ends if the active voice call ends.
Log
The log stores information about the
communication history of the device. The device
registers missed and received calls only if the
network supports these functions, the device is
switched on, and within the network service area.
132
Make calls
Recent calls
Press , and select Tools > Recent Calls.
To monitor the phone numbers of missed, received,
and dialled voice calls, select Recent calls. The
device registers missed and received calls only if the
network supports these functions, the device is
switched on, and within the network service area.
To clear all recent call lists, select Options > Delete
recent calls in the recent calls main view. To clear
one of the call registers, open the register you want
to erase, and select Options > Clear list. To clear
an individual event, open a register, scroll to the
event, and press C.
Call duration
Press , and select Tools > Recent Calls.
To monitor the approximate duration of your
incoming and outgoing calls, select Call time.
Note: The actual time invoiced for calls by
your service provider may vary, depending on
network features, rounding off for billing, and so
forth.
To clear call duration timers, select Options >
Clear timers. For this you need the lock code.
Packet data
Press , and select Tools > Recent Calls.
To check the amount of data sent and received
during packet data connections, select Data
counter. For example, you may be charged for your
packet data connections by the amount of data sent
and received.
Monitor all communication
events
Press , and select Tools > Recent Calls >
Recent calls.
Icons in the log are as follows:
Incoming
Outgoing
Missed communication events
To open the general log where you can monitor all
voice calls, text messages, or data and WLAN
connections registered by the device, scroll right.
Subevents, such as a text message sent in more than
one part and packet data connections, are logged
as one communication event. Connections to your
mailbox, multimedia messaging centre, or web
pages are shown as packet data connections.
133
Make calls
To add an unknown phone number from the log to
your contacts, select Options > Save to Address
Book.
To filter the log, select Options > Filter and a filter.
To erase the contents of the log, recent calls
register, and messaging delivery reports
permanently, select Options > Clear log. Select
Yes to confirm. To remove a single event from one
of the recent calls logs, press C.
To set the log duration, select Options >
Settings > Log duration. If you select No log, all
the log contents, recent calls register, and
messaging delivery reports are permanently
deleted.
Tip: In the details view, you can copy a phone
number to the clipboard, and paste it into a
text message, for example. Select Options >
Copy number.
To view from the packet data counter how much
data is transferred and how long a certain packet
data connection lasts, scroll to an incoming or
outgoing event indicated by Pack., and select
Options > View details.
134
Make calls
Contacts (phonebook)
In Contacts, you can save and update contact
information, such as phone numbers, home
addresses, or e-mail addresses of your contacts. You
can add a personal ringing tone or a thumbnail
image to a contact card. You can also create contact
groups, which allow you to send text messages or
e-mail to many recipients at the same time.
Save and edit names and
numbers
1. Press , and select Addr. Book > Options >
New contact.
2. Fill in the fields that you want, and select Done.
To edit contact cards, scroll to a contact, and select
Options > Edit. You can also search for the desired
contact by entering the first letters of the name to
the search field.
To attach a small thumbnail image to a contact card,
open the contact card, and select Options > Edit >
Options > Add thumbnail. The thumbnail image
is shown when the contact calls.
Manage names and numbers
To add a contact to a group, select Options > Add
to group (shown only if you have created a group).
To check to which groups a contact belongs, select
the contact and Options > Belongs to groups.
To delete a contact card, select a card, and press C.
To delete several contact cards at the same time,
select Options > Mark/Unmark to mark the
desired contact cards, and press C to delete.
To send contact information, select the card you
want to send, Options > Send, and the desired
option.
To listen to the voice tag assigned to the contact,
select a contact card and Options > Play voice
tag.
Default numbers and
addresses
Press , and select Addr. Book.
You can assign default numbers or addresses to a
contact card. In this way if a contact has several
135
Contacts (phonebook)
numbers or addresses, you can easily call or send a
message to the contact to a certain number or
address. The default number is also used in voice
dialling.
1. In the contacts list, select a contact.
2. Select Options > Defaults.
3. Select a default to which you want to add a
number or an address, and select Assign.
4. Select a number or an address you want to set
as a default.
The default number or address is underlined in the
contact card.
Add ringing tones for
contacts
Press , and select Addr. Book.
To define a ringing tone for a contact or a contact
group, do the following:
1. Press the scroll key to open a contact card or go
to the groups list, and select a contact group.
2. Select Options > Ringing tone. A list of ringing
tones opens.
3. Select the ringing tone you want to use for the
individual contact or the members of the
selected group.
When a contact or group member calls you, the
device plays the chosen ringing tone (if the caller’s
telephone number is sent with the call and your
device recognises it).
To remove the ringing tone, select Default tone
from the list of ringing tones.
Copy contacts
When you open Addr. Book for the first time, you
can choose to copy SIM contacts to the device
memory or to view SIM contacts in the contacts
directory. The device asks you if you want to copy
names and numbers from a SIM card to your device.
To start copying, press OK.
Press Cancel if you do not want to copy the SIM
contacts to the device memory. The device asks you
if you want to view the SIM contacts in the contacts
directory. Press OK, Contacts opens and you can see
names stored on your SIM card marked with .
SIM directory and other SIM
services
For availability and information on using SIM card
services, contact your SIM card vendor. This may be
the service provider or other vendor.
136
Contacts (phonebook)
To see the names and numbers stored on the SIM
card, select Options > My numbers. In the SIM
directory you can add and edit contacts, and you can
make calls.
To view the list of fixed dialling numbers, select
Options > SmartChip numbers. This setting is
only shown if supported by your SIM card.
To restrict calls from your device to selected phone
numbers, select Options > Fixed dial contacts.
You need your PIN2 code to activate and deactivate
fixed dialling or edit your fixed dialling contacts.
Contact your service provider if you do not have the
code. To add new numbers to the fixed dialling list,
select Options > New SmartChip contact.
When you use fixed dialling, packet data
connections are not possible, except when sending
text messages over a packet data connection. In this
case, the message centre number and the
recipient’s phone number must be included on the
fixed dialling list.
When fixed dialling is activated, calls may be
possible to the official emergency number
programmed into your device.
Manage contact groups
Create contact groups
1. In Contacts, scroll right to open the groups list.
2. Select Options > New group.
3. Write a name for the group or use the default
name, and select OK.
4. Select the group and Options > Add
members.
5. Scroll to a contact, and press the scroll key to
mark it. To add multiple members at a time,
repeat this action on all the contacts you want
to add.
6. To add the contacts to the group, select OK.
To rename a group, select Options > Rename,
enter the new name, and select OK.
Remove members from a group
1. In the groups list, select the group you want to
modify.
2. Scroll to the contact, and select Options >
Remove from group.
3. To remove the contact from the group, select
Yes.
137
Contacts (phonebook)
Time management
Clock
Alarm clock
Press , and select Applications > Clock.
To set a new quick alarm, select Options > New
quick alarm. Quick alarms are set for the next 24
hours and they cannot be repeated.
To view your active and inactive alarms, scroll right
to the alarm tab. To set a new alarm, select
Options > New alarm. Define the repetition, if
needed. When an alarm is active, is shown.
To turn off the sounding alarm, select Stop. To stop
the alarm for a certain time period, select Snooze.
If your device is switched off when an alarm is due,
your device switches itself on and starts sounding
the alarm tone.
Tip: To define the time period after which the
clock alarm sounds again when you set it to
snooze, select Options > Settings > Alarm
snooze time.
To cancel an alarm, select Options > Remove
alarm.
To change the time, date, and clock type settings,
select Options > Settings.
To allow the mobile phone network to update the
time, date, and time zone information to your
device (network service), in the settings, select
Automatic time update > On.
World clock
Press , and select Applications > Clock.
To open the world clock view, scroll right to the
world clock tab. In the world clock view, you can
view the time in different cities. To add cities to the
list, select Options > Add city. You can add a
maximum of 15 cities to the list.
To set your current city, scroll to a city, and select
Options > Set as current city. The city is displayed
in the clock main view, and the time in your device
is changed according to the city selected. Ensure
that the time is correct and matches your time zone.
138
Time management
Calendar
Create a calendar entry
Press , and select Applications > Calendar.
1. To add a new calendar
entry, scroll to the
desired date, and select
Options > New
entry and one of the
following:
●Meeting — to
remind you of an
appointment that
has a specific date
and time
●Meeting
request — to create and send a new meeting
request. You must have a mailbox set up for
sending requests. See "Manage
mailboxes", p. 121.
●Memo — to write a general entry for a day
●Anniversary — to remind you of birthdays or
special dates (entries are repeated annually)
●To-do — to remind you of a task that must be
done by a specific date
2. Fill in the fields. To set an alarm, select Alarm >
On, and enter the alarm time and date.
To add a description for an entry, select
Options > Add description.
3. To save the entry, select Done.
Tip: In the day, week, or month calendar
view, press any key (1-0). An appointment
entry opens, and the characters you enter are
added to the subject field. In the to-do view,
a to-do note entry opens.
When the calendar alarm sounds for a note, select
Silence to turn off the calendar alarm tone. The
reminder text stays on the screen. To stop the
calendar alarm, select Stop. To set the alarm to
snooze, select Snooze.
Tip: To define the time period after which the
calendar alarm sounds again when you set it
to snooze, press , and select
Applications > Calendar > Options >
Settings > Alarm snooze time.
Calendar views
To change the starting day of the week or the view
that is shown when you open the calendar, select
Options > Settings. In the settings, you can also
modify the calendar alarm tone, alarm snooze time,
and the title for the week view.
To go to a certain date, select Options > Go to
date. To jump to today, press #.
139
Time management
To switch between the month view, week view, day
view, and to-do view, press *.
To send a calendar note to a compatible device,
select Options > Send.
If the other device is not compatible with
Coordinated Universal Time (UTC), the time
information of received calendar entries may not be
displayed correctly.
Manage calendar entries
To delete several events at a time, go to the month
view, and select Options > Delete entry > Before
date or All entries.
To mark a task as completed, scroll to it in the to-do
view, and select Options > Mark as done.
You can synchronise your calendar with a
compatible PC using Nokia Nseries PC Suite. When
creating a calendar entry, set the desired
synchronisation option.
140
Time management
Office folder
Quickoffice
With the Quickoffice applications, you can
view .doc, .xls, .ppt, .pps, and .txt documents and
download software. Not all file formats or features
are supported. Apple Macintosh is not supported.
To view a file, press , and select Applications >
Office > Quickoffice. Select the location from
which you want to view files, browse to the desired
folder, and select a file.
The files open in the respective applications
depending on the file format.
To download software using Quickmanager, in the
main view, select Quickmanager; or, when
browsing files, scroll to the Quickmanager tab.
If you experience problems with the Quickoffice
applications, visit www.quickoffice.com, or send e-
mail to supportS60@quickoffice.com.
Quickword
With Quickword, you can view native Microsoft
Word documents with your device.
Quickword supports the viewing of documents
saved in .doc and .txt formats created with Microsoft
Word 97, 2000, XP, and 2003. Not all variations or
features of the mentioned file formats are
supported.
To upgrade to a version of Quickword that supports
editing, when you have a file open, select
Options > Updates and upgrades. The upgrade
is chargeable.
Quicksheet
With Quicksheet, you can view native Microsoft
Excel files with your device.
Quicksheet supports the viewing of spreadsheet
files saved in .xls format created with Microsoft
Excel 97, 2000, XP, or 2003. Not all variations or
features of the mentioned file formats are
supported.
To upgrade to a version of Quicksheet that supports
editing, when you have a file open, select
Options > Updates and upgrades. The upgrade
is chargeable.
141
Office folder
Quickpoint
With Quickpoint, you can view native Microsoft
PowerPoint presentations with your device.
Quickpoint supports the viewing of presentations
saved in .ppt and .pps formats created with
Microsoft PowerPoint 2000, XP, and 2003. Not all
variations or features of the mentioned file formats
are supported.
To upgrade to a version of Quickpoint that supports
editing, when you have a file open, select
Options > Updates and upgrades. The upgrade
is chargeable.
Quickmanager
With Quickmanager, you can download software,
including updates, upgrades, and other useful
applications. You can pay for the downloads by
phone bill or credit card.
Notes
Press , and select Applications > Office >
Notes.
To write a note, start entering the text. The note
editor opens automatically.
To open a note, scroll to it, and select Open.
To send a note to other compatible devices, select
Options > Send.
To delete a note, press C.
Tip: To delete several notes, select Options >
Mark/Unmark to mark the notes, and press
C.
To synchronise or to define synchronisation
settings for a note, select Options >
Synchronization. Select Start to start
synchronisation or Settings to define the
synchronisation settings for the note.
Adobe PDF reader
Press , and select Applications > Office >
Adobe PDF.
With the PDF reader you can read PDF documents
on the display of your device; search for text in the
documents; modify settings, such as zoom level and
page views; and send PDF files using e-mail.
Converter
Press , and select Applications > Office >
Converter.
With Converter, you can convert measures from one
unit to another.
142
Office folder
The converter has limited accuracy, and rounding
errors may occur.
1. In the Type field, select the measure you want to
use.
2. In first Unit field, select the unit from which you
want to convert.
3. In the next Unit field, select th e unit to which you
want to convert.
4. In the first Amount field, enter the value you
want to convert. The other Amount field changes
automatically to show the converted value.
Convert currency
Select Type > Currency. Before you can make
currency conversions, you must select a base
currency and add exchange rates. The default base
currency is Home. The rate of the base currency is
always 1.
1. Select Options > Currency rates.
2. The default name for the currency items is
Foreign. To rename a currency, select
Options > Rename currency.
3. Add the exchange rates for the currencies, and
press Done.
4. In the second Unit field, select the currency to
which you want to convert.
5. In the first Amount field, enter the value you
want to convert. The other Amount field changes
automatically to show the converted value.
To change the base currency, select Options >
Currency rates, a currency and Options > Set as
base currency.
Note: When you change base currency, you
must enter new exchange rates because all
previously set exchange rates are cleared.
143
Office folder
Applications folder
Calculator
Press , and select Applications > Calculator.
Note: This calculator has limited accuracy
and is designed for simple calculations.
To make a calculation, enter the first number of the
calculation. Select a function such as add or subtract
from the function map. Enter the second number of
the calculation, and select =.
The calculator performs operations in the order
they are entered. The result of the calculation
remains in the editor field and can be used as the
first number of a new calculation.
To save the results of a calculation, select Options >
Memory > Save. The saved result replaces the
previously stored result in the memory.
To retrieve the results of a calculation from the
memory and use them in a calculation, select
Options > Memory > Recall.
To view the last saved result, select Options > Last
result. Exiting the Calculator application or
switching off the device does not clear the memory.
You can recall the last saved result the next time you
open the Calculator application.
Application manager
With Application manager, you can see the software
packages installed in your device. You can view
details of installed applications, remove
applications, and define installation settings.
Press , and select Applications > App. mgr..
You can install two types of applications and
software to your device:
●J2ME applications based on Java technology with
the extension .jad or .jar
●Other applications and software suitable for the
Symbian operating system with the
extension .sis or .sisx
Only install software specifically designed for your
device: Nokia N78. Software providers will often
refer to the official model number of this product:
Nokia N78-3.
144
Applications folder
Install applications and software
Installation files may be transferred to your device
from a compatible computer, downloaded during
browsing, or sent to you in a multimedia message
as an e-mail attachment or using other connectivity
methods, such as Bluetooth connectivity. You can
use Nokia Application Installer in Nokia Nseries PC
Suite to install an application to your device. If you
use Microsoft Windows Explorer to transfer a file,
save the file to a compatible memory card (local
disk).
indicates a .sis or .sisx application, a Java
application, that the application is not fully
installed, and that the application is installed on
the memory card.
Important: Only install and use applications
and other software from trusted sources, such as
applications that are Symbian Signed or have
passed the Java Verified
TM
testing.
Before installation, note the following:
●To view the application type, version number,
and the supplier or manufacturer of the
application, select Options > View details.
To display the security certificate details of the
application, in Details:, scroll to Certificates:,
and select View details. See "Certificate
management", p. 154.
●If you install a file that contains an update or
repair to an existing application, you can only
restore the original application if you have the
original installation file or a full backup copy of
the removed software package. To restore the
original application, remove the application, and
install the application again from the original
installation file or the backup copy.
The .jar file is required for installing Java
applications. If it is missing, the device may ask
you to download it. If there is no access point
defined for the application, you are asked to
select one. When you are downloading the .jar
file, you may need to enter a user name and
password to access the server. You obtain these
from the supplier or manufacturer of the
application.
To install an application or software, do the
following:
1. To locate an installation file, press , and select
Applications > App. mgr.. Alternatively,
search the device memory or a compatible
memory card (if inserted) in File manager, or
open a message in Messaging > Inbox that
contains an installation file.
2. In Application manager, select Options >
Install. In other applications, scroll to the
installation file, and select it to start the
installation.
145
Applications folder
During installation, the device shows
information about the progress of the
installation. If you install an application without
a digital signature or certification, the device
displays a warning. Continue installation only if
you are sure of the origin and contents of the
application.
To start an installed application, locate it in the
menu, and select it. If the application does not have
a default folder defined, it is installed in the
Applications folder in the main menu.
To see which software packages are installed or
removed and when, select Options > View log.
Important: Your device can only support one
antivirus application. Having more than one
application with antivirus functionality could affect
performance and operation or cause the device to
stop functioning.
After you install applications to a compatible
memory card, installation files (.sis) remain in the
device memory. The files may use large amounts of
memory and prevent you from storing other files.
To maintain sufficient memory, use Nokia PC Suite
to back up installation files to a compatible PC, then
use the file manager to remove the installation files
from the device memory. If the .sis file is a message
attachment, delete the message from the
Messaging inbox.
See "File manager", p. 148.
Remove applications and
software
Press , and select Applications > App. mgr..
Scroll to a software package, and select Options >
Remove. Select Yes to confirm.
If you remove software, you can only reinstall it if
you have the original software package or a full
backup of the removed software package. If you
remove a software package, you may no longer be
able to open documents created with that software.
If another software package depends on the
software package that you removed, the other
software package may stop working. Refer to the
documentation of the installed software package
for details.
Settings
Press , and select Applications > App. mgr..
Select Options > Settings and from the following:
●Software installation — Select whether
Symbian software that has no verified digital
signature can be installed.
●Online certificate check — Select to check the
online certificates before installing an
application.
146
Applications folder
●Default web address — Set the default address
used when checking online certificates.
Some Java applications may require that a message
be sent or a network connection be made to a
specific access point to download extra data or
components. In the Application manager main
view, scroll to an application, and select Options >
Open to change settings related to that specific
application.
147
Applications folder
Tools folder
File manager
Press , and select Tools > File mgr..
With File manager, you can browse, manage, and
open files on your device, memory card, or a
compatible external drive.
File manager main view
The available options depend on the memory you
highlight. Select Options and from the following:
●Remove memory card — Remove the memory
card safely from the device without any loss of
data.
●Back up phone memory — Create a backup of
the device memory to a memory card.
●Restore from mem. card — Restore a backup
of the device memory saved on a compatible
memory card. This option is only available if you
have created a backup of the device memory.
●Remote drives — Define settings for a
compatible remote drive connected to your
device, or map or delete drives.
●Find — Find a file in the memory. Enter a search
text that matches the file name.
Phone memory and memory card views
The available options depend on the memory you
select. Select Options and from the following:
●Send — Send a file using available connection
methods.
●Organize — Move and copy files and folders, or
create new folders in the memory.
●Mark/Unmark — Mark files or folders to delete
multiple items at the same time.
●Rename — Rename a file or a folder.
●Details — View the details of the memory or the
selected item.
●Memory card options — Rename or format a
memory card.
●Memory card password — Password protect a
memory card.
Voice commands
Press , and select Tools > Utilities > Voice
comm..
You can use enhanced voice commands to control
your device. See "Voice dialling", p. 127.
148
Tools folder
To activate enhanced voice commands to start
applications and profiles, press and hold the right
selection key in the standby mode.
To use enhanced voice commands, press and hold
the right selection key in the standby mode, and
speak a voice command. The voice command is the
name of the application or profile displayed in the
list.
To edit the voice commands, in the Voice commands
application, select an item, such as an application
or a profile, and Edit.
To listen to the synthesised voice tag, select
Options > Playback.
To remove a voice command that you added
manually, select Options > Remove voice
command.
Select Options > Settings and from the following:
●Synthesizer — to switch on or off the
synthesiser that plays recognised voice tags and
commands in the selected device language
●Playback volume — to adjust the playback
volume for the voice commands
●Recognition sensitivity — to adjust how easily
the synthesiser recognises speech. If the
sensitivity is set too high, it may not accept
commands because of background noise.
●Command verification — to select whether the
spoken command is accepted manually, by voice,
or automatically
●Remove voice adapts. — to reset voice
recognition learning, for example, when the
main user of the device has changed
Sync
Press , and select Tools > Sync.
Sync enables you to synchronise your notes,
calendar entries, text and multimedia messages,
browser bookmarks, or contacts with various
compatible applications on a compatible computer
or on the internet.
You may receive synchronisation settings in a
special message from your service provider.
A synchronisation profile contains the necessary
settings for synchronisation.
When you open the application, the default or
previously used sync profile is displayed. To modify
the profile, scroll to a sync item and select Mark to
include it in the profile or Unmark to leave it out.
To manage sync profiles, select Options and the
desired option.
To synchronise data, select Options >
Synchronize. To cancel synchronisation before it
finishes, select Cancel.
149
Tools folder
Device manager
Press , and select Tools > Utilities > Device
mgr..
Use Device manager to connect to a server and
receive configuration settings for your device, to
create new server profiles, or to view and manage
existing server profiles.
You may receive server profiles and different
configuration settings from your service providers
and company information management
department. These configuration settings may
include connection and other settings used by
different applications in your device.
Scroll to a server profile, and select Options and
from the following:
●Start configuration — Connect to the server
and receive configuration settings for your
device.
●New server profile — Create a server profile.
To delete a server profile, scroll to it, and press C.
Speech
With Speech, you can set the language, voice, and
voice properties for the message reader.
Press , and select Tools > Utilities > Speech.
To set the language for the message reader, select
Language. To download additional languages to
your device, select Options > Download
languages.
Tip: When you download a new language,
you must download at least one voice for that
language.
To set the speaking voice, select Voice. The voice
depends on the selected language.
To set the speaking rate, select Speed.
To set the speaking volume, select Volume.
To view details of a voice, scroll right to the voice
tab, scroll to the voice, and select Options > Voice
details. To listen to a voice, scroll to the voice, and
select Options > Play voice.
To delete languages or voices, scroll to the item and
select Options > Delete.
Message reader settings
To change the message reader settings, scroll to the
Settings tab, and define the following:
●Language detection — turn automatic reading
language detection on or off.
●Continuous reading — turn continuous
reading of all selected messages on or off.
●Speech prompts — select whether the message
reader inserts prompts in messages.
150
Tools folder
●Audio source — select whether you want to
listen to the message through the loudspeaker
or the device.
151
Tools folder
Settings
Some settings may be preset for the device by your
service provider, and you may not be able to change
them.
General settings
In general settings, you can edit the general
settings of your device or restore the device to
original default settings.
You can adjust time and date settings also in the
clock. See "Clock ", p. 138.
Personalisation settings
Press , and select Tools > Settings >
General > Personalization.
You can edit settings related to the display, standby
mode, and general functions of your device.
Themes allows you to change the look of the
display. See "Change the look of your
device", p. 34.
Voice commands opens the settings for the Voice
commands application. See "Voice
commands", p. 148.
Tones allows you to change the tones of the
calendar, clock, and currently active profile.
Display
●Brightness — Scroll left or right to adjust the
brightness of the display.
●Font size — Adjust the size of the text and icons
on the display.
●Power saver time-out — Select the time-out
period after which the power saver is activated.
●Welcome note / logo — The welcome note or
logo is displayed briefly each time you switch on
the device. Select Default to use the default
image, Text to write a welcome note, or Image
to select an image from Photos.
●Light time-out — Select a time-out after which
the backlight of the display is switched off.
Standby mode
●Shortcuts — Assign shortcuts to the selection
keys to be used in the standby mode and select
which applications are shown in the active
toolbar.
If the active standby is set off, you can assign
keypad shortcuts for the different presses of the
scroll key.
152
Settings
●Change Menu view — Select Horizontal icon
bar to view a horizontal toolbar and the content
from different applications on the screen. Select
Vertical icon bar to view a vertical toolbar on
the screen. The content from different
applications is hidden. To display the content,
select a shortcut and press the scroll key left.
Select Basic to switch off active toolbar.
●Operator logo — This setting is only available
if you have received and saved an operator logo.
Select Off if you do not want the logo to be
shown.
Language
Changing the settings for the phone language or
writing language affects every application in your
device until you change these settings again.
●Phone language — Change the language of the
display text in your device. This also affects the
format used for date and time and the separators
used, for example, in calculations. Automatic
selects the language according to the
information on your SIM card. After you change
the display text language, the device restarts.
●Writing language — Change the writing
language. This affects the characters available
when writing text and the predictive text
dictionary used.
●Predictive text — Set predictive text input on
or off for all editors in the device. The predictive
text dictionary is not available for all languages.
Enhancement settings
Press , and select Tools > Settings >
General > Enhancement.
Some enhancement connectors indicate which type
of enhancement is connected to the device. See
"Display indicators", p. 26.
The available settings depend on the type of
enhancement. Select an enhancement and from the
following:
●Default profile — Set the profile that you want
activated each time you connect a certain
compatible enhancement to your device.
●Automatic answer — Select whether you want
the device to answer an incoming call
automatically after 5 seconds. If the ringing type
is set to Beep once or Silent, automatic answer
is disabled.
●Lights — Set whether lights remain on or are
switched off after the time-out. This setting is not
available for all enhancements.
153
Settings
Security settings
Phone and SIM
Press , and select Tools > Settings >
General > Security > Phone and SmartChip.
●PIN code request — When active, the code is
requested each time the device is switched on.
Deactivating the PIN code request may not be
allowed by some SIM cards.
●PIN code, PIN2 code, and Lock code — You can
change the lock code, PIN code, and PIN2 code.
These codes can only include the numbers from
0 to 9.
If you forget the PIN or the PIN2 code, contact
your service provider. If you forget the lock code,
contact a Nokia Care point or your service
provider.See "Access codes", p. 20.
Avoid using access codes similar to the
emergency numbers to prevent accidental
dialling of the emergency number.
●Keypad autolock period — Select whether the
keypad is locked when your device has been idle
for a certain period of time.
Tip: To lock or unlock the keypad manually,
press the left selection key, then *.
●Phone autolock period — To avoid
unauthorised use, you can set a time-out after
which the device automatically locks. A locked
device cannot be used until the correct lock code
is entered. To turn off the autolock period, select
None.
Tip: To lock the device manually, press the
power key. A list of commands opens.
Select Lock phone.
●Lock if SChip changed — You can set the device
to ask for the lock code when an unknown SIM
card is inserted into your device. The device
maintains a list of SIM cards that are recognised
as the owner’s cards.
●Closed user group — You can specify a group of
people to whom you can call and who can call
you (network service).
●Confirm SChip services — You can set the device
to display confirmation messages when you are
using a SIM card service (network service).
Certificate management
Press , and select Tools > Settings >
General > Security > Certificate management.
Digital certificates do not guarantee safety; they are
used to verify the origin of software.
In the certificate management main view, you can
see a list of authority certificates that are stored in
your device. Scroll right to see a list of personal
certificates, if available.
Digital certificates should be used if you want to
connect to an online bank or another site or remote
server for actions that involve transferring
154
Settings
confidential information. They should also be used
if you want to reduce the risk of viruses or other
malicious software and be sure of the authenticity
of software when downloading and installing
software.
Important: Even if the use of certificates
makes the risks involved in remote connections and
software installation considerably smaller, they
must be used correctly in order to benefit from
increased security. The existence of a certificate
does not offer any protection by itself; the
certificate manager must contain correct,
authentic, or trusted certificates for increased
security to be available. Certificates have a
restricted lifetime. If "Expired certificate" or
"Certificate not valid yet" is shown even if the
certificate should be valid, check that the current
date and time in your device are correct.
Before changing any certificate settings, you must
make sure that you really trust the owner of the
certificate and that the certificate really belongs to
the listed owner.
View certificate details—check authenticity
You can only be sure of the correct identity of a
server when the signature and the period of validity
of a server certificate have been checked.
You are notified if the identity of the server is not
authentic or if you do not have the correct security
certificate in your device.
To check certificate details, scroll to a certificate,
and select Options > Certificate details. When
you open certificate details, the validity of the
certificate is checked, and one of the following
notes may be displayed:
●Certificate not trusted — You have not set any
application to use the certificate.
●Expired certificate — The period of validity has
ended for the selected certificate.
●Certificate not valid yet — The period of validity
has not yet begun for the selected certificate.
●Certificate corrupted — The certificate cannot
be used. Contact the certificate issuer.
Change the trust settings
Before changing any certificate settings, you must
make sure that you really trust the owner of the
certificate and that the certificate really belongs to
the listed owner.
Scroll to an authority certificate, and select
Options > Trust settings. Depending on the
certificate, a list of the applications that can use the
selected certificate is shown. For example:
●Symbian installation: Yes — The certificate is
able to certify the origin of a new Symbian
operating system application.
155
Settings
●Internet: Yes — The certificate is able to certify
servers.
●App. installation: Yes — The certificate is able
to certify the origin of a new Java™ application.
Select Options > Edit trust setting to change the
value.
Security module
Press , and select Tools > Settings >
General > Security > Security module.
To view or ed it a sec uri ty mo dule (i f avai lable ), scr oll
to it, and press the scroll key.
To view detailed information about a security
module, scroll to it, and select Options > Security
details.
Restore original settings
Press , and select Tools > Settings >
General > Factory config..
You can reset some of the settings to their original
values. To do this, you need the lock code.
After resetting, the device may take a longer time
to power on. Documents and files are unaffected.
Navi wheel settings
Press , and select Tools > Settings >
General > Navi wheel.
Navi wheel
When the Navi wheel setting is set on, you can
browse through files and lists in certain
applications by sliding your finger on the rim of the
scroll key. See "Navi wheel", p. 28. When the Navi
wheel setting is set off, to move up, down, left, or
right, press the scroll key in the desired direction.
Breathing
The rim around the Navi wheel illuminates slowly
when the device is in sleep mode and quickly when
there are missed calls or received messages. To
switch off the illumination, select Tools >
Settings > General > Navi wheel.
Positioning settings
Press , and select Tools > Settings >
General > Positioning.
Positioning methods
●Integrated GPS — Use the integrated GPS
receiver of your device.
●Assisted GPS — Use Assisted GPS (A-GPS) to
receive assistance data from an assistance data
server. See "Assisted GPS (A-GPS)", p. 38.
●Bluetooth GPS — Use a compatible external GPS
receiver with Bluetooth connectivity.
●Network based — Use information from the
cellular network (network service).
156
Settings
Positioning server
To define an access point, and positioning server for
A-GPS, select Positioning server. The positioning
server may be preset by your service provider, and
you may not be able to edit the settings.
Notation settings
To select which measurement system you want to
use for speeds and distances, select Measurement
system > Metric or Imperial.
To define in which format the coordinate
information is shown in your device, select
Coordinate format, and the desired format.
Phone settings
In phone settings, you can edit settings related to
phone calls and network.
Call settings
Press , and select Tools > Settings > Phone >
Call.
●Send my caller ID — You can set your phone
number to be displayed to (Yes) or hidden from
(No) the person to whom you are calling, or the
value may be set by your service provider when
you make a subscription (Set by network)
(network service).
●Send my internet call ID — You can set your
internet caller ID to be displayed to or hidden
from the person to whom you are calling.
●Call waiting — To be alerted for incoming calls
(network service) while you are in a call, select
Activate. To check whether the function is
activated, select Check status.
●Reject call with message — To send a text
message to a caller informing why you could not
answer the call, select Yes.
●Message text — Write a text to be sent in a text
message when you reject a call.
●Image in video call — If video is not sent during
a video call, you can select a still image to be
displayed instead.
●Automatic redial — Select On, and your device
makes a maximum of 10 attempts to connect the
call after an unsuccessful call attempt. To stop
automatic redialling, press the end key.
●Show call time — Activate this setting if you
want the length of a call to be displayed during
the call.
●Summary after call — Activate this setting if
you want the length of a call to be displayed after
the call.
●Speed dial — Select On, and the numbers
assigned to the number keys (2 to 9) can be
dialled by pressing and holding the key. See "1-
touch dial a phone number", p. 127.
157
Settings
●Anykey answer — Select On, and you can
answer an incoming call by briefly pressing any
keypad key, except the power key.
●Line in use — This setting (network service) is
shown only if the SIM card supports two
subscriber numbers, that is, two phone lines.
Select which phone line you want to use for
making calls and sending text messages. Calls on
both lines can be answered irrespective of the
selected line. If you select Line 2 and have not
subscribed to this network service, you are not
able to make calls. When line 2 is selected, is
shown in the standby mode.
Tip: To switch between the phone lines,
press and hold # in the standby mode.
●Line change — To prevent line selection
(network service), select Disable if supported by
your SIM card. To change this setting, you need
the PIN2 code.
Call divert
Press , and select Tools > Settings > Phone >
Call forwarding.
Call divert allows you to divert your incoming calls
to your voice mailbox or another phone number. For
details, contact your service provider.
Select which calls you want to divert and the desired
diverting option. Set the option on (Activate) or off
(Deactivate), or check whether the option is
activated (Check status).
Several diverting options can be active at the same
time. When all calls are diverted, is shown in
the standby mode.
Call barring and call diverting cannot be active at
the same time.
Call barring
Press , and select Tools > Settings > Phone >
Call restriction.
Call barring (network service) allows you to restrict
the calls that you make or receive with the device.
To change the settings, you need the barring
password from your service provider.
Call barring and call diverting cannot be active at
the same time.
When calls are barred, calls may be possible to
certain official emergency numbers.
Voice call barring
Select the desired barring option, and set it on
(Activate) or off (Deactivate), or check whether the
option is active (Check status). Call barring affects
all calls, including data calls.
158
Settings
Network settings
Press , and select Tools > Settings > Phone >
Network.
Your device can automatically switch between the
GSM and UMTS networks. The GSM network is
indicated with in the standby mode. The UMTS
network is indicated with .
●Network mode — Select which network to use.
If you select Dual mode, the device uses the GSM
or UMTS network automatically, according to the
network parameters and the roaming
agreements between the wireless service
providers. Contact your network service provider
for details and roaming costs. This option is
shown only if supported by the wireless service
provider.
●Operator selection — Select Automatic to set
the device to search for and select one of the
available networks, or Manual to manually
select the network from a list. If the connection
to the manually selected network is lost, the
device sounds an error tone and asks you to
reselect a network. The selected network must
have a roaming agreement with your home
cellular network.
A roaming agreement is an agreement between
two or more service providers to enable the users
of one service provider to use the services of
other service providers.
●Cell info display — Select On to set the device
to indicate when it is used in a cellular network
based on microcellular network (MCN)
technology and to activate cell info reception.
Connection settings
In connection settings, you can edit access points
and other connectivity settings.
You can also edit settings for Bluetooth connectivity
in the Bluetooth connectivity application. See
"Settings", p. 104.
You can also edit settings for data cable connections
in the USB application. See "USB", p. 107.
Data connections and access
points
Your device supports packet data connections
(network service), such as GPRS in the GSM network.
When you use your device in GSM and UMTS
networks, multiple data connections can be active
at the same time, and access points can share a data
connection. In the UMTS network, data connections
remain active during voice calls.
You can also use a WLAN data connection. Only one
connection in one wireless LAN can be active at a
159
Settings
time, but several applications can use the same
internet access point.
To establish a data connection, an access point is
required. You can define different kinds of access
points, such as the following:
●MMS access point to send and receive multimedia
messages
●Internet access point (IAP) to send and receive e-
mail and connect to the internet
Check the type of access point you need with your
service provider for the service you want to access.
For availability and subscription to packet data
connection services, contact your service provider.
Access points
Create a new access point
Press , and select Tools > Settings >
Connection > Destinations.
You may receive access point settings in a message
from a service provider. Some or all access points
may be preset for your device by your service
provider, and you may not be able to change, create,
edit, or remove them.
When you open one of the access point groups ( ,
, , ), you can see the access point types:
indicates a protected access point.
indicates a packet data access point.
indicates a WLAN access point.
Tip: You can create internet access points in
a wireless LAN with the WLAN wizard.
To create a new access point, select New access
point. The device asks to check for available
connections. After the search, connections that are
already available are shown and can be shared by a
new access point. If you skip this step, you are asked
to select a connection method and to define the
settings needed.
To edit the settings of an access point, open one of
the access point groups, select an access point and
Edit. Follow the instructions from your service
provider.
●Connection name — Enter a descriptive name
for the connection.
●Data bearer — Select the data connection type.
Depending on the data connection you select, only
certain setting fields are available. Fill in all fields
marked with Must be defined or with a red *. Other
fields can be left empty, unless your service provider
has instructed otherwise.
To use a data connection, your service provider
must support this feature, and if necessary, activate
it for your SIM card.
160
Settings
Packet data access points
Press , and select Tools > Settings >
Connection > Destinations > New access
point, and follow the instructions on the screen. Or,
open one of the access point groups, select an
access point marked with , and select Edit.
Follow the instructions from your service provider.
●Access point name — You obtain the access
point name from your service provider.
●User name — The user name may be needed to
make a data connection, and is usually provided
by the service provider.
●Prompt password — If you must enter the
password every time you log in to a server, or if
you do not want to save your password in the
device, select Yes.
●Password — A password may be needed to
make a data connection and is usually provided
by the service provider.
●Authentication — Select Secure to always send
your password encrypted or Normal to send
your password encrypted when possible.
●Homepage — Depending on the access point
you are setting up, enter the web address or the
address of the multimedia messaging centre.
Select Options > Advanced settings to change
the following settings:
●Network type — Select the internet protocol
type to transfer data to and from your device. The
other settings depend on the selected network
type.
●Phone IP address (for IPV4 only) — Enter the IP
address of your device.
●DNS addresses — Enter the IP addresses of the
primary and secondary DNS servers, if required
by your service provider. Contact your internet
service provider to obtain these addresses.
●Proxy server address — Enter the address of
the proxy server.
●Proxy port number — Enter the port number
of the proxy server.
WLAN internet access points
Press , and select Tools > Settings >
Connection > Destinations > New access
point, and follow the instructions on the screen. Or,
open one of the access point groups, select an
access point marked with , and select Edit.
Follow the instructions from your WLAN service
provider.
●WLAN network name — Select Enter
manually or Search for networks. If you select
an existing network, WLAN network mode and
WLAN security mode are determined by the
settings of its access point device.
161
Settings
●Network status — Define whether the network
name is displayed.
●WLAN network mode — Select Ad-hoc to
create an ad hoc network and to allow devices to
send and receive data directly; a WLAN access
point device is not needed. In an ad hoc network,
all devices must use the same WLAN network
name.
●WLAN security mode — Select the encryption
used: WEP, 802.1x (not for ad hoc networks), or
WPA/WPA2. If you select Open network, no
encryption is used. The WEP, 802.1x, and WPA
functions can be used only if the network
supports them.
To enter the settings for the selected security mode,
select WLAN security config..
Security settings for WEP
●WEP key in use — Select the wired equivalent
privacy (WEP) key number. You can create up to
four WEP keys. The same settings must be
entered on the WLAN access point device.
●Authentication type — Select Open or
Shared for the authentication type between
your device and the WLAN access point device.
●WEP key settings — Enter WEP encryption
(length of the key), WEP key format (ASCII or
Hexadecimal), and WEP key (the WEP key data
in the selected format).
Security settings for 802.1x and WPA/WPA2
●WPA/WPA2 — Select the means of
authentication: EAP to use an extensible
authentication protocol (EAP) plug-in, or Pre-
shared key to use a password. Complete the
appropriate settings:
●EAP plug-in settings — Enter the settings as
your service provider instructs.
●Pre-shared key — Enter a password. The
same password must be entered on the WLAN
access point device.
●WPA2 only mode — Only WPA2 enabled devices
are allowed to establish a connection in this
mode.
Advanced WLAN settings
Select Options > Advanced settings and from the
following:
●IPv4 settings — Enter the IP address of your
device, the subnet IP address, the default
gateway, and the IP addresses of the primary and
secondary DNS servers. Contact your internet
service provider for these addresses.
●IPv6 settings — Define the type of DNS address.
●Ad-hoc channel (only for Ad-hoc) — To enter a
channel number (1-11) manually, select User
defined.
●Proxy server address — Enter the address for
the proxy server.
162
Settings
●Proxy port number — Enter the proxy port
number.
Packet data settings
Press , and select Tools > Settings >
Connection > Data counter.
The packet data settings affect all access points
using a packet data connection.
●Data counter connection — If you select When
available and you are in a network that supports
packet data, the device registers to the packet
data network. Starting an active packet data
connection (for example, to send and receive e-
mail) is quicker. If there is no packet data
coverage, the device periodically tries to
establish a packet data connection. If you select
When needed, the device uses a packet data
connection only if you start an application or
action that needs it.
●Access point — The access point name is needed
to use your device as a packet data modem to a
compatible computer.
●High speed packet access — Enable or disable
the use of HSDPA (network service) in UMTS
networks.
Wireless LAN settings
Press , and select Tools > Settings >
Connection > Wireless LAN.
●Show WLAN availability — Select whether
is displayed in the standby mode when a wireless
LAN is available.
●Scan for networks — If you set Show WLAN
availability to Yes, select how often the device
searches for available wireless LANs and updates
the indicator.
To view advanced settings, select Options >
Advanced settings. Changing wireless LAN
advanced settings is not recommended.
SIP settings
Press , and select Tools > Settings >
Connection > SIP configuration.
Session Initiation Protocol (SIP) settings are needed
for certain network services using SIP. You may
receive the settings in a special text message from
your service provider. You can view, delete, or
create these setting profiles in SIP settings.
Configurations
Press , and select Tools > Settings >
Connection > Configurations.
163
Settings
You may receive trusted server settings from your
service provider in a configuration message. You
can save view or delete these settings in
configurations.
Access point name control
Press , and select Tools > Settings >
Connection > APN control.
With the access point name control service, you can
restrict packet data connections and allow your
device to use only certain packet data access points.
This setting is only available if your SIM card
supports the access point control service.
To set the control service on or off or to change the
allowed access points, select Options and the
corresponding option. To change the options, you
need your PIN2 code. Contact your service provider
for the code.
Application settings
To edit the settings of some of the applications in
your device, press , and select Tools >
Settings > Applications.
To edit the settings, you can also select Options >
Settings in each application.
164
Settings
Troubleshooting
Q: What is my password for the lock, PIN, or
PUK codes?
A: The default lock code is 12345. If you forget or
lose the lock code, contact your device dealer. If you
forget or lose a PIN or PUK code, or if you have not
received such a code, contact your network service
provider. For information about passwords, contact
your access point provider, for example, a
commercial internet service provider (ISP) or
network service provider.
Q: How do I close an application that is not
responding?
A: Press and hold . To close an application, scroll
to it, and press C . Pressing C does not close Music
player. To close Music player, select it from the list,
and Options > Exit.
Q: Why do images look smudgy?
A: Ensure that the camera lens protection windows
are clean.
Q: Why do missing, discoloured, or bright
dots appear on the screen every time I turn
on my device?
A: This is a characteristic of this type of display.
Some displays may contain pixels or dots that
remain on or off. This is normal, not a fault.
Q: Why can't my device establish a GPS
connection?
A: Find more information about GPS, GPS receiver,
satellite signals, and location information in this
user guide. See "Positioning (GPS)", p. 38.
Q: Why can’t I find my friend’s device while
using Bluetooth connectivity?
A: Check that both devices are compatible, have
activated Bluetooth connectivity, and are not in
hidden mode. Check also that the distance between
the two devices is not over 10 metres (33 feet) and
that there are no walls or other obstructions
between the devices.
Q: Why can’t I end a Bluetooth connection?
A: If another device is connected to your device, you
can either end the connection using the other
device or by deactivating Bluetooth connectivity.
165
Troubleshooting
Press , and select Tools > Bluetooth >
Bluetooth > Off.
Q: Why can’t the other device see the files
stored on my device in the home network?
A: Make sure that you have configured the home
network settings, content sharing is turned on in
your device, and the other device is UPnP
compatible.
Q: What can I do if my home network
connection stops working?
A: Switch off the wireless LAN (WLAN) connection
from your compatible PC and your device, and
switch it on again. If this does not help, restart your
compatible PC and your device. If the connection
still does not work, reconfigure the WLAN settings
in both your compatible PC and device. See
"Wireless LAN", p. 101. See "Connection
settings", p. 159.
Q: Why can't I see my compatible PC in my
device in the home network?
A: If you are using a firewall application in your
compatible PC, check that it allows home media
server to use the external connection (you can add
Home media server to the firewall application's
exceptions list). Check from the firewall settings
that the firewall application allows traffic to the
following ports: 1900, 49152, 49153, and 49154.
Some WLAN access point devices have a built-in
firewall. In such cases, check that the firewall in the
access point device does not block traffic to the
following ports: 1900, 49152, 49153, and 49154.
Check that the WLAN settings are the same in your
device and compatible PC.
Q: Why can't I see a wireless LAN (WLAN)
access point even though I know I'm within
its range?
A: The WLAN access point may use a hidden service
set identifier (SSID). You can only access networks
that use a hidden SSID if you know the correct SSID,
and have created a WLAN Internet access point for
the network on your Nokia device.
Q: How do I switch wireless LAN (WLAN) off
on my Nokia device?
A: The WLAN on your Nokia device switches off
when you are not trying to connect, not connected
to another access point, or not scanning for
available networks. To further reduce battery
consumption, you can specify that your Nokia
device does not scan, or scans less often, for
available networks in the background. WLAN
switches off in between background scans.
To change the background scan settings:
1. Press , and select Tools > Settings >
Connection > Wireless LAN.
166
Troubleshooting
2. To increase the background scan time interval,
adjust the time in Scan for networks. To stop
background scans, select Show WLAN
availability > Never.
3. To save your changes, press Back.
When Show WLAN availability is set to
Never, the WLAN availability icon is not shown
in the standby mode. However, you can still
manually scan for available WLAN networks, and
connect to WLAN networks as usual.
Q: How can I save my data before deleting it?
A: To save data, use Nokia Nseries PC Suite to make
a back-up copy of all data to a compatible computer;
send images to your e-mail address, then save the
images to your computer; or send data using
Bluetooth connectivity to a compatible device. You
can also store data on a compatible memory card.
Q: Why can’t I select a contact for my
message?
A: The contact card does not have a phone number,
an address, or an e-mail address. Press , select
Addr. Book, and edit the contact card.
Q: How can I end the data connection when
the device starts a data connection again and
again?
A: The device may be trying to retrieve a multimedia
message from the multimedia message centre. To
stop the device from making a data connection,
press , and select Messaging > Options >
Settings > Multimedia message > Multimedia
retrieval and Manual to have the multimedia
messaging centre save messages to be retrieved
later, or Off to ignore all incoming multimedia
messages. If you select Manual, you receive a
notification when there is a new multimedia
message that you can retrieve in the multimedia
message centre. If you select Off, the device does
not make any network connections related to
multimedia messaging. To set the device to use a
packet data connection only if you start an
application or action that needs it, press , and
select Tools > Settings > Connection > Data
counter > Data counter connection > When
needed. If this does not help, switch the device off,
and switch it on again.
Q: Why do I have problems connecting the
device to my PC?
A: Ensure that you have the latest version of Nokia
Nseries PC Suite and that it is installed and running
on your compatible PC. For further information on
how to use Nokia Nseries PC Suite, see the help
function on Nokia Nseries PC Suite or visit the Nokia
support pages.
167
Troubleshooting
Q: Can I use my device as a fax modem with
a compatible PC?
A: You cannot use your device as a fax modem.
However, with call diverting (network service), you
can divert incoming fax calls to another phone
number.
168
Troubleshooting
Battery information
Charging and discharging
Your device is powered by a rechargeable battery.
The battery can be charged and discharged
hundreds of times, but it will eventually wear out.
When the talk and standby times are noticeably
shorter than normal, replace the battery. Use only
Nokia approved batteries, and recharge your
battery only with Nokia approved chargers
designated for this device.
If a replacement battery is being used for the first
time or if the battery has not been used for a
prolonged period, it may be necessary to connect
the charger, then disconnect and reconnect it to
begin charging the battery.
Unplug the charger from the electrical plug and the
device when not in use. Do not leave a fully charged
battery connected to a charger, since overcharging
may shorten its lifetime. If left unused, a fully
charged battery will lose its charge over time.
If the battery is completely discharged, it may take
several minutes before the charging indicator
appears on the display or before any calls can be
made.
Use the battery only for its intended purpose. Never
use any charger or battery that is damaged.
Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object such as
a coin, clip, or pen causes direct connection of the
positive (+) and negative (-) terminals of the
battery. (These look like metal strips on the
battery.) This might happen, for example, when you
carry a spare battery in your pocket or purse. Short-
circuiting the terminals may damage the battery or
the connecting object.
Leaving the battery in hot or cold places, such as in
a closed car in summer or winter conditions, will
reduce the capacity and lifetime of the battery.
Always try to keep the battery between 15°C and
25°C (59°F and 77°F). A device with a hot or cold
battery may not work temporarily, even when the
battery is fully charged. Battery performance is
particularly limited in temperatures well below
freezing.
Do not dispose of batteries in a fire as they may
explode. Batteries may also explode if damaged.
Dispose of batteries according to local regulations.
Please recycle when possible. Do not dispose as
household waste.
169
Battery information
Do not dismantle or shred cells or batteries. In the
event of a battery leak, do not allow the liquid to
come in contact with the skin or eyes. In the event
of such a leak, flush your skin or eyes immediately
with water, or seek medical help.
Nokia battery
authentication guidelines
Always use original Nokia batteries for your safety.
To check that you are getting an original Nokia
battery, purchase it from an authorised Nokia
dealer, and inspect the hologram label using the
following steps:
Successful completion of the steps is not a total
assurance of the authenticity of the battery. If you
have any reason to believe that your battery is not
an authentic, original Nokia battery, you should
refrain from using it, and take it to the nearest
authorised Nokia service point or dealer for
assistance. Your authorised Nokia service point or
dealer will inspect the battery for authenticity. If
authenticity cannot be verified, return the battery
to the place of purchase.
Authenticate hologram
1. When you look at the
hologram on the label, you
should see the Nokia
connecting hands symbol
from one angle and the
Nokia Original
Enhancements logo when
looking from another angle.
2. When you angle the
hologram left, right, down
and up, you should see 1, 2,
3 and 4 dots on each side
respectively.
What if your battery is not
authentic?
If you cannot confirm that your Nokia battery with
the hologram on the label is an authentic Nokia
battery, please do not use the battery. Take it to the
nearest authorised Nokia service point or dealer for
assistance. The use of a battery that is not approved
by the manufacturer may be dangerous and may
result in poor performance and damage to your
device and its enhancements. It may also invalidate
any approval or warranty applying to the device.
170
Battery information
Care and maintenance
Your device is a product of superior design and
craftsmanship and should be treated with care. The
following suggestions will help you protect your
warranty coverage.
●Keep the device dry. Precipitation, humidity, and
all types of liquids or moisture can contain
minerals that will corrode electronic circuits. If
your device does get wet, remove the battery,
and allow the device to dry completely before
replacing it.
●Do not use or store the device in dusty, dirty
areas. Its moving parts and electronic
components can be damaged.
●Do not store the device in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
●Do not store the device in cold areas. When the
device returns to its normal temperature,
moisture can form inside the device and damage
electronic circuit boards.
●Do not attempt to open the device other than as
instructed in this guide.
●Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and
fine mechanics.
●Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean the device.
●Do not paint the device. Paint can clog the
moving parts and prevent proper operation.
●Use a soft, clean, dry cloth to clean any lenses,
such as camera, proximity sensor, and light
sensor lenses.
●Use only the supplied or an approved
replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the
device and may violate regulations governing
radio devices.
●Use chargers indoors.
●Always create a backup of data you want to keep,
such as contacts and calendar notes.
●To reset the device from time to time for
optimum performance, power off the device and
remove the battery.
These suggestions apply equally to your device,
battery, charger, or any enhancement. If any device
172
Care and maintenance
is not working properly, take it to the nearest
authorized service facility for service.
Disposal
The crossed-out wheeled-bin symbol on your
product, literature, or packaging reminds you
that in the European Union all electrical and
electronic products, batteries, and
accumulators must be taken to separate collection
at the end of their working life. Do not dispose of
these products as unsorted municipal waste.
Return the products to collection to prevent
possible harm to the environment or human health
from uncontrolled waste disposal and to promote
the sustainable reuse of material resources.
Collection information is available from the product
retailer, local waste authorities, national producer
responsibility organizations, or your local Nokia
representative. For more information, see product
Eco-Declaration or country-specific information at
www.nokia.com.
173
Care and maintenance
Additional safety information
Small children
Your device and its enhancements may contain
small parts. Keep them out of the reach of small
children.
Operating environment
This device meets RF exposure guidelines when
used either in the normal use position against the
ear or when positioned at least 1.5 centimeters (5/8
inch) away from the body. When a carry case, belt
clip, or holder is used for body-worn operation, it
should not contain metal and should position the
device the above-stated distance from your body.
To transmit data files or messages, this device
requires a quality connection to the network. In
some cases, transmission of data files or messages
may be delayed until such a connection is available.
Ensure the above separation distance instructions
are followed until the transmission is completed.
Parts of the device are magnetic. Metallic materials
may be attracted to the device. Do not place credit
cards or other magnetic storage media near the
device, because information stored on them may be
erased.
Medical devices
Operation of any radio transmitting equipment,
including wireless phones, may interfere with the
functionality of inadequately protected medical
devices. Consult a physician or the manufacturer of
the medical device to determine if they are
adequately shielded from external RF energy or if
you have any questions. Switch off your device in
health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that
could be sensitive to external RF energy.
Implanted medical devices
Manufacturers of medical devices recommend that
a minimum separation of 15.3 centimeters (6
inches) should be maintained between a wireless
device and an implanted medical device, such as a
pacemaker or implanted cardioverter defibrillator,
to avoid potential interference with the medical
device. Persons who have such devices should:
174
Additional safety information
●Always keep the wireless device more than 15.3
centimeters (6 inches) from the medical device
when the wireless device is turned on.
●Not carry the wireless device in a breast pocket.
●Hold the wireless device to the ear opposite the
medical device to minimize the potential for
interference.
●Turn the wireless device off immediately if there
is any reason to suspect that interference is
taking place.
●Read and follow the directions from the
manufacturer of their implanted medical device.
If you have any questions about using your wireless
device with an implanted medical device, consult
your health care provider.
Hearing aids
Some digital wireless devices may interfere with
some hearing aids. If interference occurs, consult
your service provider.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles such as electronic fuel injection systems,
electronic antiskid (antilock) braking systems,
electronic speed control systems, and air bag
systems. For more information, check with the
manufacturer, or its representative, of your vehicle
or any equipment that has been added.
Only qualified personnel should service the device
or install the device in a vehicle. Faulty installation
or service may be dangerous and may invalidate any
warranty that may apply to the device. Check
regularly that all wireless device equipment in your
vehicle is mounted and operating properly. Do not
store or carry flammable liquids, gases, or explosive
materials in the same compartment as the device,
its parts, or enhancements. For vehicles equipped
with an air bag, remember that air bags inflate with
great force. Do not place objects, including installed
or portable wireless equipment in the area over the
air bag or in the air bag deployment area. If in-
vehicle wireless equipment is improperly installed
and the air bag inflates, serious injury could result.
Using your device while flying in aircraft is
prohibited. Switch off your device before boarding
an aircraft. The use of wireless teledevices in an
aircraft may be dangerous to the operation of the
aircraft, disrupt the wireless telephone network,
and may be illegal.
175
Additional safety information
Potentially explosive
environments
Switch off your device when in any area with a
potentially explosive atmosphere, and obey all
signs and instructions. Potentially explosive
atmospheres include areas where you would
normally be advised to turn off your vehicle engine.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death. Switch off
the device at refuelling points such as near gas
pumps at service stations. Observe restrictions on
the use of radio equipment in fuel depots, storage,
and distribution areas; chemical plants; or where
blasting operations are in progress. Areas with a
potentially explosive atmosphere are often, but not
always, clearly marked. They include below deck on
boats, chemical transfer or storage facilities and
areas where the air contains chemicals or particles
such as grain, dust, or metal powders. You should
check with the manufacturers of vehicles using
liquefied petroleum gas (such as propane or
butane) to determine if this device can be safely
used in their vicinity.
Certification information
(SAR)
This mobile device meets guidelines for
exposure to radio waves.
Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits for
exposure to radio waves recommended by
international guidelines. These guidelines were
developed by the independent scientific
organization ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.
The exposure guidelines for mobile devices employ
a unit of measurement known as the Specific
Absorption Rate or SAR. The SAR limit stated in the
ICNIRP guidelines is 2.0 watts/kilogram (W/kg)
averaged over 10 grams of tissue. Tests for SAR are
conducted using standard operating positions with
the device transmitting at its highest certified
power level in all tested frequency bands. The actual
SAR level of an operating device can be below the
maximum value because the device is designed to
use only the power required to reach the network.
That amount changes depending on a number of
factors such as how close you are to a network base
station. The highest SAR value under the ICNIRP
guidelines for use of the device at the ear is 1.00 W/
kg.
176
Additional safety information
Use of device accessories and enhancements may
result in different SAR values. SAR values may vary
depending on national reporting and testing
requirements and the network band. Additional SAR
information may be provided under product
information at www.nokia.com.
Your mobile device is also designed to meet the
requirements for exposure to radio waves
established by the Federal Communications
Commission (USA) and Industry Canada. These
requirements set a SAR limit of 1.6 W/kg averaged
over one gram of tissue. The highest SAR value
reported under this standard during product
certification for use at the ear is 1.26 W/kg and
when properly worn on the body is 1.04 W/kg.
Information about this device model can be found
at http://www.fcc.gov/oet/fccid by searching the
equipment authorization system using FCC ID:
QFXRM-342.
Emergency calls
Important: Wireless phones, including this
device, operate using radio signals, wireless
networks, landline networks, and user-
programmed functions. Because of this,
connections in all conditions cannot be guaranteed.
You should never rely solely on any wireless device
for essential communications like medical
emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for
adequate signal strength.
Some networks may require that a valid SIM card
is properly inserted in the device.
2. Press the end key as many times as needed to
clear the display and ready the device for calls.
3. Enter the official emergency number for your
present location. Emergency numbers vary by
location.
4. Press the call key.
If certain features are in use, you may first need to
turn those features off before you can make an
emergency call. If the device is in the offline or flight
profile mode, you may need to change the profile
to activate the phone function before you can make
an emergency call. Consult this guide or your service
provider for more information.
When making an emergency call, give all the
necessary information as accurately as possible.
Your wireless device may be the only means of
communication at the scene of an accident. Do not
end the call until given permission to do so.
177
Additional safety information
Index
Symbols/Numerics
1-touch dialing 127
A
access codes 20
access points 102, 160
accessories
See
enhancements
active standby mode 36,
152
active toolbar 67
in camera 65
in Photos 77
address book
See
contacts
alarm clock 138
alarm, calendar note 139
albums, media 77
anniversary notes 139
answering calls 126
antennas 24
application manager 144
applications 144
assisted GPS (A-GPS) 38
attachments 116, 119
audio messages 114
audio themes 35
auto-update for time/
date 138
B
backing up device
memory 148
backlight time-out 152
battery
power saver setting 152
saving power 21
birthday notes 139
blogs 96
Bluetooth connectivity
blocking devices 107
device address 106
device visibility 105
pairing devices 106
receiving data 106
security 105
sending data 105
settings 104
switching on/off 104
bookmarks 97
browser
bookmarks 97
browsing pages 94, 96
cache memory 98
downloads 97
security 99
settings 99
widgets 96
C
cable connection 107
cache memory 98
calculator 144
calendar 139
call waiting 127
calls 125
answering 126
conference 126
duration of 133
log for 133
options during 125
recording 111
rejecting 126
settings 157
camera
colour 73
flash 68
image quality 72
imaging mode 66
indicators 64
178
Index
lighting 73
location information 67
options 67
scenes 68
self-timer 69
sequence mode 68
settings 72
video mode 71
video quality 74
cell broadcast messages 112
certificates 154
character encoding 114
charts, spreadsheet 141
clipboard, copying to 114
clock 37, 138
computer connections 108
See also
data connections
conference calls 126
configuration
See
settings
connection manager 103
contacts
copying 136
default information 135
deleting 135
editing 135
groups 137
images in 135
ringing tones 136
saving 135
sending 135
synchronising 149
voice tags 135
converter 142
copying text to
clipboard 114
copyright protection 110
currency
converter 142
D
data connections
cable 107
device manager 150
PC connectivity 108
synchronisation 149
date and time 138
declining calls 126
device manager 150
dialled numbers 133
dismissing calls 126
display settings 152
document applications 141
downloads 97
DRM (digital rights
management) 110
duration of calls 133
E
e-mail messages 117
end all calls option 127
enhancements settings 153
Excel, Microsoft 141
F
factory settings,
restoring 156
feeds, news 96
file manager 148
Flash Player 110
FM radio 60
FM transmitter 55
playing songs 56
settings 56
font settings 152
G
gallery
sounds 84
streaming links 84
general information 19
GPS (Global Positioning
System) 38
grid view of menus 37
H
headset 31
help application 19
home network 52, 85
copying files 88
179
Index
sharing content 87
home synchronisation
incoming files 89
log 90
setting up 88
settings 89
HSDPA (high-speed downlink
packet access) 32
I
IAPs (internet access
points) 102
images
editing 78
printing 81, 82
sharing online 82
inbox, message 116
indicators and icons 26
installation of
applications 145
internet connection 94
See also
browser
internet radio
favourites 62
listening 62
settings 63
station directory 63
J
J2ME Java application
support 144
Java scripts/
applications 144
K
keyguard 28, 154
keypad 28, 154
L
landmarks 41
language settings 153
licences 110
light settings 152
list view of menus 37
location information 38
lock code 20
locking
keypad 28, 154
loudspeaker 31
M
mailbox
e-mail 117
video 126
voice 126
main menu 37
Maps 44
media
Flash Player 110
music player 50
radio 60
RealPlayer 109
streaming 109
voice recorder 111
meeting notes 139
meetings, setting up 139
memo notes 139, 142
memory
clearing 22
web cache 98
message reader 117
selecting voice 150
messages
e-mail 117
folders for 112
icon for incoming 116
multimedia 116
settings 119
voice 126
Mini Map 96
MMS (multimedia message
service) 114, 116
multimedia menu 29
multimedia messages 114,
116
music player 50
playlists 51
180
Index
transferring music 53
muting sound 126
my numbers 135
N
Navi wheel 28
navigation tools 38
network settings 159
news feeds 96
notes 142
O
offline mode 32
one-touch dialing 127
operator logo 153
options menu for calls 125
outbox, message 112
P
packet data connection
access point settings 161
counters 133
settings 163
page overview 96
PDF reader 142
personal certificates 154
personalisation 34, 152
phonebook
See
contacts
photographs
See
camera
Photos
active toolbar 71
organising files 76
photos
editing 78
file details 76
red-eye 79
tags 77
viewing 75
PictBridge 81
PIN code 20
PIN2 code 20
playing
messages 117
podcasting
directories 58
downloads 58
playing 59
searching 57
settings 56
positioning information 38
positioning settings 156
power saver 152
PowerPoint, Microsoft 142
predictive text entry
mode 113
presentations,
multimedia 84, 117, 142
printing
images 81
profiles
offline restrictions 32
proxy settings 161
PUK codes 20
punctuation, text entry 114
Q
Quickmanager 142
Quickpoint 142
Quicksheet 141
Quickword 141
R
radio 60
RBDS (Radio Broadcast Data
System) 60
RDS (Radio Data System) 60
RealPlayer 109
recording
calls 111
sounds 111
recording video clips 71
red-eye removal 79
redial feature 157
rejecting calls 126
remote mailbox 117
remote SIM mode 107
ringing tones 35, 36
181
Index
roaming 159
S
scenes, image and video 68
screen settings 152
scroll key 28
security
certificates 154
web browser 99
WEP 162
WPA 162
security code 20
security module 156
self-timer, camera 69
sent messages folder 112
service commands 112
service messages 117
setting wizard 24
settings
access point name
control 164
access points 160
applications 164
Bluetooth connectivity 104
call barring 158
call divert 158
calls 157
camera 72
certificates 154
configuration 163
display 152
enhancements 153
FM transmitter 56
home network 86
internet radio 63
language 153
Navi wheel 156
network 159
packet data 163
packet data access
points 161
personalisation 152
podcasting 56
positioning 156
RealPlayer 110
SIP 163
standby 152
Video Centre 93
video sharing 131
Visual Radio 61
web browser 99
WLAN 162, 163
WLAN internet access
points 161
shared video 130
shooting modes, camera 68
signature, digital 155
SIM card
contacts 136
messages 119
SIM card security 154
SIP 163
slide show 78
SMS (short message
service) 114
software applications 144
software update 20
songs 50
sounds 35
speaker phone 31
special characters, text
entry 114
Speech 150
standby mode 36, 152
streaming links 84
streaming media 109
Symbian applications 144
synchronisation
settings 89
synchronisation of data 149
T
text entry 113
text messages
receiving and reading 116
replying to 116
sending 114
settings 120
SIM messages 119
themes 34
182
Index
time and date 138
time zone settings 138
time-out for backlight 152
tones
ring settings 35, 36
settings 152
toolbar 65, 77
transferring data 24
transferring music 53
troubleshooting 165
trust settings 155
U
unlocking keypad 28, 154
UPIN code 20
UPnP (Universal Plug and Play
architecture) 85
UPUK code 20
USB cable connection 107
useful information 19
V
video calls 128, 130
options during 129
Video Centre 91
downloading 91
viewing 91
video clips
editing 79
effects 80
sending 80
shared 130
sound clips in 80
transitions 80
video settings 74
Visual Radio 60
settings 61
voice applications 148
voice calls
See
calls
voice commands 127, 148
voice recorder 111
volume controls 31
W
wallpaper 34
web connection 94
web logs 96
week settings, calendar 139
welcome 24
welcome note 152
WEP 162
widgets 96
wireless LAN (WLAN) 101
wireless LAN settings 163
Word, Microsoft 141
world clock 138
WPA 162
Z
zooming 66, 71
183
Index
