Nokia 5800 XpressMusic User Guide
FCC Draft
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-356 product is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at www.nokia.com/phones/
declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Original Enhancements logos, Nokia Care, and XpressMusic are trademarks or registered trademarks of Nokia Corporation. Nokia
tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document
without prior notice.
This product includes software licensed from Symbian Software Ltd ©1998-2009. Symbian and Symbian OS are trademarks of Symbian Ltd.
This software is based in part of the work of the FreeType Team. This product is covered by one or more of the following patents: United States Patent 5,155,805,
United States Patent 5,325,479, United States Patent 5,159,668, United States Patent 2232861 and France Patent 9005712.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
Portions of the Nokia Maps software are ©1996-2009 The FreeType Project. All rights reserved.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been
encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4
video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional,
internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR
INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Reverse engineering of software in the device is prohibited to the extent permitted by applicable law. Insofar as this user guide contains any limitations on Nokia's
representations, warranties, damages and liabilities, such limitations shall likewise limit any representations, warranties, damages and liabilities of Nokia's licensors.
The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia
does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user support,
functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party applications. BY
USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE
ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details and availability
of language options. This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion
contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require
you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part
15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's
authority to operate this equipment.
Model number: 5800d-1
FCC Draft/Issue 1 EN
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Contents
Safety...................................................................7
About your device......................................................................7
Network services.......................................................................8
1. Get started........................................................9
Keys and parts............................................................................9
Insert the SIM card...................................................................10
Insert battery ..........................................................................10
Charge the battery...................................................................11
Switch the device on...............................................................12
Stylus.........................................................................................12
Lock the keys and touch screen.............................................12
Home screen............................................................................12
Access the menu......................................................................13
Touch screen actions...............................................................13
Media key..................................................................................14
Change the ringing tone.........................................................15
Support.....................................................................................15
Open Ovi...................................................................................15
2. Find help.........................................................15
In-device help..........................................................................15
Accessibility solutions.............................................................16
Extended user guide................................................................16
Access codes.............................................................................16
3. Your device.....................................................17
Memory card............................................................................17
Shortcuts..................................................................................18
Antenna locations....................................................................18
Contacts bar.............................................................................18
Offline profile...........................................................................19
Sensor settings and display rotation.....................................19
Headset.....................................................................................20
Remove the SIM card...............................................................20
Attach a wrist strap.................................................................21
4. Make calls.......................................................21
Proximity sensor......................................................................21
Voice calls ................................................................................21
5. Write text.......................................................22
On-screen keyboard................................................................22
Handwriting.............................................................................23
Alphanumeric keypad.............................................................23
Touch input settings...............................................................25
6. Messaging......................................................25
Messaging main view..............................................................25
Write and send messages.......................................................26
Set up e-mail............................................................................27
Mail for Exchange.....................................................................27
7. Music player....................................................28
Play a song or a podcast.........................................................28
Playlists.....................................................................................29
Transfer music from a computer...........................................30
Nokia Music..............................................................................30
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
8. Gallery............................................................30
View and organise files...........................................................30
View images and videos.........................................................31
9. Camera...........................................................32
Activate the camera................................................................31
Image capture..........................................................................32
Video recording.......................................................................34
10. Positioning (GPS)..........................................35
About GPS.................................................................................35
Assisted GPS (A-GPS)................................................................36
Hold your device correctly......................................................36
11. Connectivity..................................................37
Wi-Fi/WLAN connection .........................................................37
12. Share online.................................................38
About Share online..................................................................38
Subscribe to services...............................................................38
Manage your accounts............................................................39
Create a post............................................................................39
Post files from Gallery.............................................................39
13. Nokia Video Centre.......................................39
View and download video clips.............................................40
Video feeds...............................................................................41
My videos..................................................................................41
Transfer videos from your PC.................................................41
Video centre settings..............................................................42
14. Web browser................................................42
Browse the web.......................................................................42
Browser toolbar.......................................................................43
Bookmarks...............................................................................44
Empty the cache.......................................................................44
Connection security.................................................................44
15. Green tips.....................................................45
Save energy..............................................................................45
Recycle......................................................................................45
Save paper................................................................................45
Learn more...............................................................................46
Accessories.........................................................47
Battery................................................................47
Battery and charger information...........................................47
Nokia battery authentication guidelines..............................48
Taking care of your device.................................48
Recycle......................................................................................49
Additional safety information...........................50
Small children..........................................................................49
Operating environment..........................................................50
Medical devices........................................................................50
Vehicles.....................................................................................51
Potentially explosive environments......................................51
Emergency calls.......................................................................51
Certification information (SAR)..............................................52
Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for further
information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone
use is prohibited or when it may cause interference
or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to
operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel, chemicals,
or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this
product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
About your device
The wireless device described in this guide is approved for
use on the GSM 850, 900, 1800, 1900 and UMTS 900, 2100
networks. Contact your service provider for more information
about networks.
When using the features in this device, obey all laws and
respect local customs, privacy and legitimate rights of others,
including copyrights.
Copyright protections may prevent some images, music
(including ringing tones), and other content from being
copied, modified, or transferred.
Your device supports several methods of connectivity. Like
computers, your device may be exposed to viruses and other
harmful content. Exercise caution with messages,
connectivity requests, browsing, and downloads. Only install
and use services and other software from trustworthy
sources that offer adequate security and protection against
harmful software, such as applications that are Symbian
Signed or have passed the Java Verified™ testing. Consider
installing antivirus and other security software on your
device and any connected computer.
Your device may have preinstalled bookmarks and links for
third-party internet sites. You may also access other third-
www.nokia.com/support 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
party sites through your device. Third-party sites are not
affiliated with Nokia, and Nokia does not endorse or assume
liability for them. If you choose to access such sites, you
should take precautions for security or content.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on. Do not
switch the device on when wireless device use may cause
interference or danger.
Remember to make back-up copies or keep a written record
of all important information stored in your device.
When connecting to any other device, read its user guide for
detailed safety instructions. Do not connect incompatible
products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about
your device.
Network services
To use the device you must have service from a wireless
service provider. Many of the features require special network
features. These features are not available on all networks;
other networks may require that you make specific
arrangements with your service provider before you can use
the network services. Using network services involves
transmission of data. Check with your service provider for
details about fees in your home network and when roaming
on other networks. Your service provider can give you
instructions and explain what charges will apply. Some
networks may have limitations that affect how you can use
network services. For instance, some networks may not
support all language-dependent characters and services.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have a special configuration such as changes
in menu names, menu order, and icons. Contact your service
provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that
run on TCP/IP protocols. Some features of this device, such as
MMS, browsing, and e-mail, require network support for
these technologies.
Safety
8www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
1. Get started
Keys and parts
1 – Micro USB connector to
connect to a compatible PC
2 – Nokia AV Connector (3.5
mm) for compatible
headsets, headphones, and
TV-out connectors
3 – Charger connector
4 – Power key
5 – Earpiece
6 – Light sensor
7 – Proximity sensor
8 – Touch screen
9 – Secondary camera
10 – Volume/Zoom key
11 – Media key
12 – Screen and key lock
switch
13 – Capture key 15 – Menu key
14 – End key 16 – Call key
17 – Pen stylus
18 – Camera lens
19 – Camera flash
20 – Loudspeakers
21 – Cover of the SIM card slot
22 – Cover of the memory
card slot
23 – Wrist strap opening
24 – Microphone
During extended operation such as an active video call and a
high speed data connection, the device may feel warm. In
most cases, this condition is normal. If you suspect the device
is not working properly, take it to the nearest authorised
service facility.
Do not cover the area above the touch
screen, for example, with protective
film or tape.
www.nokia.com/support 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Insert the SIM card
Important: To prevent damage to the SIM card,
always remove the battery before you insert or remove the
card.
A SIM card may be already inserted in the device. If not, do
the following:
1. Open the cover of the
SIM card slot.
2. Insert a SIM card in
the slot. Ensure that
the contact area on
the card is facing up
and the bevelled
corner is facing
toward the device.
Push the card in.
3. Close the cover of the SIM card slot.
Ensure that the cover is properly
closed.
If the SIM card is not properly in place,
the device can only be used in the
offline profile.
Insert battery
Always switch the device off and disconnect the charger
before removing the battery.
1. Remove the back cover by
lifting it from the bottom end
of the device.
2. Insert the battery.
Get started
10 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
3. To replace the cover, direct the
top locking catches toward their
slots first and then press down
until the cover locks into place.
Charge the battery
Your battery has been partially charged at the factory. If the
device indicates a low charge, do the following:
1. Connect the charger to a wall outlet.
2. Connect the charger to the device.
3. When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length of
time, and you can use the device while it is charging. If the
battery is completely discharged, it may take several minutes
before the charging indicator appears on the display or
before any calls can be made.
Tip: Disconnect the charger from the wall outlet when
the charger is not in use. A charger that is connected
to the outlet consumes power even when it is not
connected to the device.
Get started
www.nokia.com/support 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Switch the device on
1. Press and hold the power key.
2. If the device asks for a PIN code or
lock code, enter it, and select OK.
To delete a number, select
. The factory setting for the
lock code is 12345.
3. Select your location. If you
accidentally select the wrong
location, select Back.
4. Enter the date and time. When
using the 12-hour time format, to
switch between a.m. and p.m.,
select any number.
Stylus
Some functions, such as
handwriting recognition,
are designed to be used
with a stylus. The pen
stylus is located in the
back cover of the device.
Important: Use
only a stylus approved by Nokia for use with this device. Using
any other stylus may invalidate any warranty applying to the
device and may damage the touch screen. Avoid scratching
the touch screen. Never use an actual pen or pencil or other
sharp objects to write on the touch screen.
Lock the keys and touch screen
To lock or unlock the touch screen and the keys, slide the lock
switch on the side of the device.
When the touch screen and keys are locked, the touch screen
is switched off and the keys are inactive.
The screen and keys may be locked automatically after a
period of inactivity. To change settings for automatic screen
and key locking, select Menu > Settings and Phone >
Phone mgmt. > Auto. keyguard > Keypad autolock
period.
Home screen
Home screen is your starting point where you can collect all
your important contacts or application shortcuts.
Get started
12 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Interactive display elements
To open the clock application, tap the clock (1).
To open calendar or change
profiles in the home screen,
tap the date or the profile
name (2).
To view or change
connectivity settings ( ), to
see the available wireless
LANs if WLAN scanning is
enabled, or to view the
missed events, tap the top
right corner (3).
To make a phone call, select
(4).
To open Contacts, select
(5).
To open the main menu, press
the menu key (6).
Start using the contacts
bar
To start using the contacts bar
and add your contacts to the
home screen, in the home
screen, select > Add contact to Home screen, and follow
the instructions.
Change the home screen theme
To change the home screen theme or the shortcuts, select
Menu > Settings and Personal > Home screen.
Access the menu
To access the menu, press the menu key.
To open an application or folder in the menu, tap it.
Touch screen actions
Tap and double-tap
To open an application or other element on the touch screen,
you normally tap it with your finger or the stylus. However,
to open the following items, you must tap them twice.
●List items in an application, such as the Drafts folder in the
folder list in Messaging
Tip: When you open a list view, the first item is
already highlighted. To open the highlighted item,
tap it once.
●Applications and folders in the menu when using the list
view type
●Files in a file list, for example, an image in the images and
videos view in Gallery.
If you tap a file or similar item once, it is not opened, it
becomes highlighted. To see the options available for the
item, select Options or, if available, select an icon from a
toolbar.
Get started
www.nokia.com/support 13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Select
In this user documentation, opening applications or items by
tapping them once or twice is called "selecting". If you need
to select several items in a sequence, the display texts to
select are separated by arrows.
Example: To select Options > Help, tap Options, and
then tap Help.
Drag
To drag, place your finger or the stylus on the screen, and
slide it across the screen.
Example: To scroll up or down on a web page, drag
the page with your finger or stylus.
Swipe
To swipe, slide your finger quickly left or right on the screen.
Example: When
viewing an image, to
view the next or
previous image, swipe
the image left or right,
respectively.
Scroll
To scroll up or down in lists that have a scroll bar, drag the
slider of the scroll bar.
In some list views, you can scroll by placing your finger or
stylus on a list item and dragging up or down.
Example: To scroll through contacts, place your finger
or stylus on a contact, and drag up or down.
Tip: To view a brief description of icons and buttons,
place your finger or stylus on the icon or button.
Descriptions are not available for all icons and buttons.
Touch screen light
The touch screen light is turned off after a period of inactivity.
To turn the screen light on, tap it.
If the touch screen and keys are locked, tapping the screen
does not turn the screen light on. To unlock the screen and
keys, slide the lock switch.
Media key
To access applications such as the
music player or browser, tap the
media key ( ) to open the media
bar, and select the application.
Tip: Hold your finger or the
stylus on the icon to see the
name of the application.
Get started
14 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Change the ringing tone
Select Menu > Settings and Personal > Profiles.
You can use profiles to set and customise the ringing tones,
message alert tones, and other tones for different events,
environments, or caller groups. To personalise a profile, scroll
to the profile, and select Options > Personalise.
Support
When you want to learn more about how to use your product
or you are unsure how your device should function, see the
support pages at www.nokia.com/support or your local
Nokia website, www.nokia.mobi/support (with a mobile
device), the Help application in the device, or the user guide.
If this does not resolve your issue, do one of the following:
●Restart the device: switch off the device, and remove the
battery. After about a minute, replace the battery, and
switch on the device.
●Restore the original factory settings as explained in the
user guide. Your documents and files will be deleted in the
reset, so back up your data first.
●Update your device software regularly for optimum
performance and possible new features, as explained in
the user guide.
If your issue remains unsolved, contact Nokia for repair
options. See www.nokia.com/repair, or in Latin America,
www.nokia-latinoamerica.com/centrosdeservicio. Before
sending your device for repair, always back up the data in
your device.
Open Ovi
Ovi is your door to different Nokia services.
For a tour and more information, see www.ovi.com.
2. Find help
For local services and warranty information, see the separate
booklet.
In-device help
Your device contains instructions to help to use the
applications in your device.
To open help texts from the main menu, select Menu >
Help and the application for which you want to read
instructions.
When an application is open, to access the help text for the
current view, select Options > Help.
When you are reading the instructions, to change the size of
the help text, select Options > Decrease font size or
Increase font size.
Find help
www.nokia.com/support 15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
You can find links to related topics at the end of the help text.
If you select an underlined word, a short explanation is
displayed. Help texts use the following indicators: shows
a link to a related help topic. shows a link to the
application being discussed.
When you are reading the instructions, to switch between
help texts and the application that is open in the background,
press and hold the menu key, and select from the list of open
applications.
Accessibility solutions
Nokia is committed to making mobile phones easy to use for
all individuals, including those with disabilities. For more
information, visit the Nokia website at
www.nokiaaccessibility.com.
Extended user guide
An extended version of this user guide is available on the
product support pages of the Nokia website. Some
applications or functions are explained only in the extended
user guide.
Access codes
If you forget any of the access codes, contact your service
provider.
●Personal identification number (PIN) code — This code
protects your SIM card against unauthorised use. The PIN
code (4 to 8 digits) is usually supplied with the SIM card.
After three consecutive incorrect PIN code entries, the
code is blocked, and you need the PUK code to unblock it.
●UPIN code — This code may be supplied with the USIM
card. The USIM card is an enhanced version of the SIM card
and is supported by UMTS mobile phones.
●PIN2 code — This code (4 to 8 digits) is supplied with some
SIM cards, and is required to access some functions in your
device.
●Lock code (also known as security code) — The lock code
helps you to protect your device against unauthorised use.
The preset code is 12345. You can create and change the
code, and set the device to request the code. Keep the new
code secret and in a safe place separate from your device.
If you forget the code and your device is locked, your
device will require service and additional charges may
apply. For more information, contact a Nokia Care point or
your device dealer.
●Personal Unblocking Key (PUK) code and PUK2
code — These codes (8 digits) are required to change a
blocked PIN code or PIN2 code, respectively. If the codes
are not supplied with the SIM card, contact the operator
whose SIM card is in your device.
●UPUK code — This code (8 digits) is required to change a
blocked UPIN code. If the code is not supplied with the
USIM card, contact the operator whose USIM card is in your
device.
Find help
16 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
3. Your device
Memory card
Use only compatible microSD and microSDHC cards approved
by Nokia for use with this device. Nokia uses approved
industry standards for memory cards, but some brands may
not be fully compatible with this device. Incompatible cards
may damage the card and the device and corrupt data stored
on the card.
Insert the memory card
A memory card may be already inserted in the device. If not,
do the following:
1. Open the cover of the
memory card slot.
2. Insert a compatible memory card in
the slot. Ensure that the contact area
is facing up. Push the card in. You can
hear a click when the card locks into
place.
3. Close the cover of the memory card
slot. Ensure that the cover is properly
closed.
Remove the memory card
Important: Do not remove the memory card during
an operation when the card is being accessed. Doing so may
damage the memory card and the device, and corrupt data
stored on the card.
1. If the device is switched on, before you remove the card,
press the power key, and select Remove memory card.
2. When Remove memory card? Some applications will
be closed. is displayed, select Yes.
Your device
www.nokia.com/support 17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
3. When Remove memory card and press 'OK' is
displayed, open the cover of the memory card slot.
4. Press the memory card to release it from the slot.
5. Pull out the memory card. If the device is switched on,
select OK.
Shortcuts
To switch between open applications, press and hold the
menu key. Leaving applications running in the background
increases the demand on battery power and reduces the
battery life.
To start a web connection (network service), in the dialler,
tap and hold 0.
To access applications available in the media bar, such as the
music player and web browser, in any view, press the media
key.
To change the profile, press the power key, and select a
profile.
To call your voice mailbox (network service), in the dialler,
tap and hold 1.
To open a list of last dialled numbers, in the home screen,
press the call key.
To use voice commands, in the home screen, press and hold
the call key.
Antenna locations
Your device may have internal and external antennas. Avoid
touching the antenna area unnecessarily while the antenna
is transmitting or receiving. Contact with antennas affects the
communication quality and may cause a higher power level
during operation and may reduce the battery life.
Cellular antenna
Bluetooth and
WLAN antenna GPS antenna
Contacts bar
Start using the contacts bar
To start using the contacts bar and add your contacts to the
home screen, in the home screen, select > Add contact
to Home screen, and follow the instructions.
To add a contact to the home screen in contacts bar mode,
select and either select a contact from your contacts, or
Your device
18 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
create a new contact, and add a photo to the contact
information.
To communicate with your contact, select the contact and
from the following:
● — Make a phone call.
● — Send a message.
● — Modify contact information.
● — Refresh the contact's web feeds.
To view past communication events with a contact, select a
contact. Select a communication event to view event details.
To close the view, select .
Offline profile
To activate the Offline profile, press the power key briefly,
and select Offline.
The Offline profile lets you use the device without connecting
to the wireless network. When you activate the Offline
profile, the connection to the wireless network is turned off,
as indicated by in the signal strength indicator area. All
wireless RF signals to and from the device are prevented. If
you try to send messages, they are placed in the Outbox folder
to be sent later.
When the Offline profile is active, you can use your device
without a SIM card.
If the SIM card is not properly in place, the device starts in the
Offline profile.
Important: In the Offline profile you cannot make or
receive any calls, or use other features that require cellular
network coverage. Calls may still be possible to the official
emergency number programmed into your device. To make
calls, you must first activate the phone function by changing
profiles. If the device has been locked, enter the lock code.
When you have activated the offline profile, you can still use
the wireless LAN, for example, to read your e-mail or browse
on the internet. Remember to comply with any applicable
safety requirements when establishing and using a wireless
LAN connection. You can also use Bluetooth connectivity
while in the offline profile.
To switch to another profile, press the power key briefly, and
select another profile. The device re-enables wireless
transmissions (providing there is sufficient signal strength).
Sensor settings and display rotation
When you activate the sensors in your device, you can control
certain functions by turning the device.
Select Menu > Settings and Phone > Sensor settings.
Select from the following:
●Sensors — Activate the sensors.
●Turning control — Select Silencing calls and Snoozing
alarms to mute calls and snooze alarms by turning your
device so that the display faces down. SelectAuto-rotate
display to rotate the display content automatically when
you turn the device on its left side or back to a vertical
Your device
www.nokia.com/support 19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
position. Some applications and features may not support
rotating the display content.
Headset
You can connect a compatible headset or compatible
headphones to your device. You may need to select the cable
mode.
Warning: When you use the
headset, your ability to hear outside
sounds may be affected. Do not use
the headset where it can endanger
your safety.
Do not connect products that create an
output signal as this may cause
damage to the device. Do not connect
any voltage source to the Nokia AV
Connector.
When connecting any external device
or any headset, other than those
approved by Nokia for use with this
device, to the Nokia AV Connector, pay
special attention to volume levels.
Remove the SIM card
1. Remove
the back
cover by
lifting it
from the
bottom
end of the
device.
2. Remove the battery.
3. Open the cover of the SIM
card slot. Place the tip of the
stylus in the opening under
the battery, and push the SIM
card sideways to slide it out
of the slot. Pull the SIM card
out.
4. Replace the battery and the
back cover.
Your device
20 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Attach a wrist strap
Tip: Attach the
plectrum stylus to
the device like a
wrist strap.
4. Make calls
Proximity sensor
Your device has a proximity sensor. To prevent accidental
selections, the touch screen is disabled automatically during
calls when you place the device next to your ear.
Do not cover the proximity sensor, for example, with
protective film or tape.
Voice calls
1. In the home screen, select to open the dialler, and
enter the phone number, including the area code. To
remove a number, select C.
For international calls, select * twice for the + character
(which replaces the international access code), and enter
the country code, area code (omit the leading zero if
necessary), and phone number. The + character as a
replacement for the international access code may not
work in all regions. In this case, enter the international
access code directly.
2. To make the call, press the call key.
3. To end the call (or to cancel the call attempt), press the
end key.
Pressing the end key always ends a call, even if another
application is active.
To make a call from the contacts list, select Menu >
Contacts. Scroll to the desired name. Or, tap the search field
to enter the first letters of the name, and scroll to the name.
To call the contact, press the call key. If you have saved several
Make calls
www.nokia.com/support 21
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
numbers for a contact, select the desired number from the
list, and press the call key.
5. Write text
You can enter letters, numbers, and special characters in
several different ways. The on-screen keyboards allow you to
enter characters by tapping them with your fingers or the
stylus. Handwriting recognition allows you to write
characters directly onto the screen using the stylus as a pen.
Tap any text input field to enter letters, numbers, and special
characters.
Your device can complete words based on the built-in
dictionary for the selected text input language. The device
also learns new words from your input.
On-screen keyboard
To activate the on-screen keyboard in portrait mode, select
and Mini QWERTY keyboard.
To activate the on-screen keyboard in landscape mode, select
and Full screen QWERTY.
When using the on-screen keyboard in portrait mode, tap the
keys of the keyboard with the stylus. When using the on-
screen keyboard in landscape mode and in full-screen, you
can tap the keys with your fingers.
For an explanation of each key and its function, see the
following figure.
1 — Close - Closes the on-screen keyboard view.
2 — Input menu - Opens the touch input options menu, which
includes commands such as Writing language.
3 — On-screen keyboard
4 — Shift and Caps Lock - Allows you to enter an uppercase
character when you write in lowercase using the on-screen
keyboard. When you tap this key in handwriting recognition
mode, the last lowercase character switches to uppercase,
and vice versa. To turn Caps Lock on, tap the key twice. The
key will have a line under it.
5 — Numbers and symbols - Switches between numbers,
most commonly used special characters, and alphabet
characters in the on-screen keyboard.
6 — Character accents - Opens a pop-up window, in which
you can select language character accents.
7 — Space bar - Inserts a space.
Write text
22 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
8 — Enter - Moves the cursor to the next row or text input
field. Additional functions are based on the current context
(for example, in the web address field of the web browser, it
acts as a Go button).
9 — Move - Moves the touch input window. Drag the key to
move the touch input window around the screen.
10 — Backspace - Deletes the previously entered character.
11 — Input mode - Opens a pop-up window, in which you can
select from the available input methods. When you tap an
item, the current input method view closes, and the selected
one opens.
Handwriting
To activate handwriting mode, tap and Handwriting.
You can use the stylus as a pen to write as you would write
text on paper. Write legible, upright characters on the text
input area, and leave a space between each character.
To teach the device your handwriting style, tap and
Handwriting training.
To enter letters and numbers (default mode), write words as
you would normally. To select number mode, tap in the
right pane of the input area. To enter non-Latin characters,
tap the corresponding icon, if available.
To write special characters, write
them as you would normally. You
can also tap in the right pane of
the input area, and select a desired
character from the pop-up table.
To delete characters or move the
cursor back, swipe backwards (see Figure 1). To insert a
space, swipe forwards (see Figure 2).
Alphanumeric keypad
Icons and functions
Use the on-screen keypad (Alphanumeric keypad) to enter
characters like you would with a traditional phone keypad
with numbers on the keys. For an explanation of each icon
and its function, see the following figure.
Write text
www.nokia.com/support 23
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
1 — Close - Closes on-screen keypad (Alphanumeric
keypad).
2 — Input menu - Opens the touch input menu, which
includes commands such as Activate predictive text and
Writing language.
3 — Text input indicator - Opens a pop-up window, in which
you can turn predictive text input modes on or off, change
the character case, and switch between letter and number
mode.
4 — Input mode - Opens a pop-up window, in which you can
select from the available input modes. When you tap an item,
the current input method view closes, and the selected one
opens.
5 — Arrow keys - Moves the cursor left or right.
6 — Backspace - Deletes the previously entered character.
7 — Number keys - Enters the desired numbers or characters
according to the current case and input mode.
8 — Star - Opens a special characters table.
9 — Shift - Changes the character case, turns predictive text
input modes on or off, and switches between the alphabet
and number modes.
Traditional text input
Tap a number key (1-9) repeatedly until the desired character
appears. There are more characters available for a number
key than are visible on the key.
If the next letter is located on the same key as the present
one, wait until the cursor appears (or move the cursor
forward to end the time-out period), and enter the letter.
To insert a space, tap 0. To move the cursor to the next line,
tap 0 three times.
Predictive text input
With predictive text input, you can enter any letter with a
single tap of a key. Predictive text input is based on a built-
in dictionary to which you can add new words.
1. To activate predictive text input for all editors on the
device, tap , and select Activate prediction, or
Write text
24 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
quickly tap # twice. You can also tap , and select
Activate predictive text.
2. To write the desired word, tap the keys 2-9. Tap each key
only once for one letter. For example, to write "Nokia"
when the English dictionary is selected, tap 6 for N, 6 for
o, 5 for k, 4 for i, and 2 for a.
The word suggestion changes after each tap of a key.
3. When you finish writing the word correctly, move the
cursor right to confirm it, or tap 0 to add a space.
If the word is not correct, tap * repeatedly to view the
matching words the dictionary has found one by one.
If the ? character is shown after the word, the word is not
in the dictionary. To add a word to the dictionary, select
Spell, enter the word using traditional text input, and
select OK. The word is added to the dictionary. When the
dictionary is full, a new word replaces the oldest added
word.
4. Start writing the next word.
Switch between text modes
To turn predictive text input off for all editors in your device,
tap , and select Deactivate prediction or quickly
double-tap#. Alternatively, you can tap , and select
Predictive text > Off.
Touch input settings
Select Menu > Settings and Phone > Touch input.
To configure text input settings for the touch screen, select
from the following:
●Handwriting training — Open the handwriting training
application. Train the device to recognise your
handwriting better. This option is not available in all
languages.
●Writing language — Define which language-specific
characters in your handwriting are recognised and how
your on-screen keyboard is laid out.
●Writing speed — Adjust the speed at which handwriting
is recognised.
●Guiding line — Show or hide the guiding line in the
writing area. The guiding line helps you write in a straight
line, and it also helps the device recognise your writing.
This option may not be available in all languages.
●Pen trail width — Change the thickness of the text.
●Writing colour — Change the colour of the text.
6. Messaging
Only devices that have compatible features can receive and
display multimedia messages. The appearance of a message
may vary depending on the receiving device.
Messaging main view
Select Menu > Messaging (network service).
Messaging
www.nokia.com/support 25
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To create a new message, select New message.
Tip: To avoid rewriting messages that you send often,
use texts in the Templates folder in My folders. You can
also create and save your own templates.
Messaging contains the following folders:
● Inbox — Received messages, except e-mail and cell
broadcast messages, are stored here.
● My folders — Organise your messages into folders.
● Mailbox — Connect to your remote mailbox to
retrieve your new e-mail messages, or view your
previously retrieved e-mail messages offline.
● Drafts — Draft messages that have not been sent are
stored here.
● Sent — The last messages that have been sent,
excluding messages sent using Bluetooth connectivity, are
stored here. You can change the number of messages to
save in this folder.
● Outbox — Messages waiting to be sent are
temporarily stored in the outbox, for example, when your
device is outside network coverage.
● Delivery reports — You can request the network to
send you a delivery report of the text messages and
multimedia messages you have sent (network service).
Write and send messages
Select Menu > Messaging.
Important: Exercise caution when opening messages.
Messages may contain malicious software or otherwise be
harmful to your device or PC.
Before you can create a multimedia message or write an e-
mail, you must have the correct connection settings defined.
The wireless network may limit the size of MMS messages. If
the inserted picture exceeds this limit, the device may make
it smaller so that it can be sent by MMS.
Check the size limit of e-mail messages with your service
provider. If you attempt to send an e-mail message that
exceeds the size limit of the e-mail server, the message is left
in the Outbox folder, and the device attempts to resend it
periodically. Sending an e-mail requires a data connection,
and continuous attempts to resend the e-mail may incur
charges from your service provider. In the Outbox folder, you
can delete such a message or move it to the Drafts folder.
1. To send a message, select New message.
To send an audio or e-mail message, select Options >
Create message, and the relevant option.
2. To select recipients or groups from the contacts list, select
To. To enter the number or e-mail address manually, tap
the To field.
3. In the Subject field, enter the subject of the e-mail. To
change the fields that are visible, select Options >
Message header fields.
4. To write the message, tap the message field.
Messaging
26 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
5. To add an object to a message, select and the relevant
type of content.
The message type may change to multimedia message
based on the inserted content.
6. To capture an image or record a video or sound clip for a
multimedia message, select Options > Insert content
and New image, New video clip, or New sound clip.
7. To add an attachment to an e-mail, select Options >
Insert content and the relevant type of content. E-mail
attachments are indicated by .
8. To send the message, select , or press the call key.
Your device supports text messages beyond the limit for a
single message. Longer messages are sent as two or more
messages. Your service provider may charge accordingly.
Characters with accents, other marks, or some language
options take more space, and limit the number of characters
that can be sent in a single message.
You may not be able to send video clips that are saved in the
MP4 file format or that exceed the size limit of the wireless
network in a multimedia message.
Set up e-mail
To set up e-mail, select Menu > Messaging and Mailbox.
You can set up several e-mail accounts, for example, a
personal e-mail account and a corporate e-mail account.
To set up e-mail from your home screen, select the relevant
plug-in. Alternatively, to set up an e-mail account, select
Menu > Applications > Sett. wizard.
Mail for Exchange
With Mail for Exchange, you can receive your work e-mail to
your device. You can read and reply to your e-mails, view and
edit compatible attachments, view calendar information,
receive and reply to meeting requests, schedule meetings,
and view, add, and edit contact information.
ActiveSync
Use of the Mail for Exchange is limited to over-the-air
synchronisation of PIM information between the Nokia
device and the authorised Microsoft Exchange server.
Mail for Exchange can be set up only if your company has
Microsoft Exchange Server. In addition, your company's IT
administrator must have activated Mail for Exchange for your
account.
Before starting to set up Mail for Exchange, ensure that you
have the following:
●A corporate e-mail ID
●Your office network user name
●Your office network password
●Your network domain name (contact your company's IT
department)
●Your Mail for Exchange server name (contact your
company's IT department)
Messaging
www.nokia.com/support 27
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Depending on your company's Mail for Exchange server
configuration, you may need to enter other information in
addition to those listed. If you do not know the correct
information, contact your company's IT department.
With Mail for Exchange, the use of the lock code may be
mandatory. The default lock code of your device is 12345, but
your company's IT administrator may have set a different one
for you to use.
You can access and modify the Mail for Exchange profile and
settings in the Messaging settings.
7. Music player
Music player supports file formats such as AAC, AAC+, eAAC+,
MP3, and WMA. Music player does not necessarily support all
features of a file format or all the variations of file formats.
You can also use Music player to listen to podcasts. Podcasting
is a method for delivering audio or video content over the
internet using either RSS or Atom technologies for playback
on mobile devices and computers.
You can transfer music from other compatible devices to your
device.
Play a song or a podcast
To open Music player, select Menu > Music > Music
player.
You may have to refresh the music and podcast libraries after
you have updated the song or podcast selection in your
device. To add all available items to the library, select
Options > Refresh library.
To play a song or a podcast:
1. Select categories to navigate to the song or podcasts you
want to hear.
2. To play an item, select the item from the list.
To pause playback, tap ; to resume, tap .
Music player
28 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To fast-forward or rewind, tap and hold or .
To go to the next item, tap .
To return to the beginning of the
item, tap . To skip to the
previous item, tap again
within 2 seconds after a song or
podcast has started.
To turn random play ( ) on or
off, select Options > Shuffle
play.
To repeat the current item ( ),
all items ( ), or to turn repeat
off, select Options > Repeat.
If you play podcasts, shuffle and
repeat are automatically turned off.
To adjust the volume, press the volume key.
To modify the tone of the music playback, select Options >
Equaliser.
To modify the balance and stereo image or to enhance the
bass, select Options > Settings.
To return to the home screen and leave the player playing in
the background, press the end key.
To close the player, select Options > Exit.
Playlists
Select Menu > Music > Music player and Playlists.
To view details of the playlist, select Options > Playlist
details.
Create a playlist
1. Select Options > New playlist.
2. Enter a name for the playlist, and select OK.
3. To add songs now, select Yes; or to add the songs later,
select No.
4. If you select Yes, select artists to find the songs you want
to add to the playlist. Select Add to add items.
To show the song list under an artist title, select
Expand. To hide the song list, select Collapse.
5. When you have made your selections, select Done.
If a compatible memory card is inserted, the playlist is
saved to the memory card.
To add more songs later, when viewing the playlist, select
Options > Add songs.
To add songs, albums, artists, genres, and composers to a
playlist from the different views of the music menu, select an
item and Options > Add to playlist > Saved playlist or
New playlist.
To remove a song from a playlist, select Options >
Remove. This does not delete the song from the device; it
only removes it from the playlist.
Music player
www.nokia.com/support 29
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To reorder songs in a playlist, select the song you want to
move, and Options > Reorder playlist. To grab a song and
drop it to a new position, select the song in the desired
position and Drop. To finish reordering the playlist, select
Done.
Transfer music from a computer
You can use the following methods to transfer music:
●To view your device on a computer as a mass memory
device where you can transfer any data files, make the
connection with a compatible USB data cable or Bluetooth
connectivity. If you are using a USB data cable, select Mass
storage as the connection mode. A compatible memory
card must be inserted in the device.
●To synchronise music with Windows Media Player, connect
a compatible USB data cable, and select Media transfer as
the connection mode. A compatible memory card must be
inserted in the device.
●To install Nokia Music to manage and organise your music
files, download the PC software from
www.music.nokia.com/download, and follow the
instructions.
To change the default USB connection mode, select Menu >
Settings and Connectivity > USB > USB connection
mode.
Nokia Music
With the Nokia Music PC software, you can transfer music to
your device from your computer, and manage and organise
your music files.
To manage your music in Nokia Music, do the following:
1. Open the Nokia Music software on your PC, and register
or sign in to Nokia Music Store.
2. Connect your device to your PC with a compatible USB data
cable.
3. To select the connection mode on your device, select
Media transfer.
8. Gallery
To store and organise your images, video clips, sound clips,
and streaming links, select Menu > Gallery.
Tip: To access the images and video clips view quickly,
tap the media key ( ) to open the media bar, and
select .
View and organise files
Select Menu > Gallery and from the following:
● Images & videos — View images in the image viewer
and videos in Video centre.
Gallery
30 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
● Songs — Open Music player.
● Sound clips — Listen to sound clips.
● Other media — View presentations.
You can browse, open, and create folders; and mark, copy,
move, and add items to folders.
Files stored on your compatible memory card (if inserted) are
indicated with .
To open a file, select a file from the list. Video clips and files
with the .ram file extension open and play in Video centre,
and music and sound clips in Music player.
To copy or move files to the memory card (if inserted) or
device memory, select a file, Options > Organise > Copy
or Move, and from the available options.
View images and videos
Select Menu > Gallery and Images & videos.
The images, video clips, and folders are displayed in a loop
and ordered by date and time. To browse the files one by one,
swipe left or right. To browse files in groups, swipe up or
down.
To open a file, select a file from the list. To zoom in an image,
use the volume key in your device.
Select Options and from the following:
●Edit — Edit a video clip or an image.
●Use file — To use the image as wallpaper in the home
screen, select Set as wallpaper.
To set the image as a generic call image, select Set as call
image.
To set the image as a call image for a contact, select Assign
to contact.
To set the video clip as a ringing tone, select As ringing
tone.
To assign the video clip as a ringing tone for a contact,
select Assign to contact.
The toolbar helps you select frequently used functions with
images, video clips, and folders.
From the toolbar, select from the following:
● Send — Send the selected image or video clip.
● Edit — Edit the selected image or video clip.
● Delete — Delete the selected image or video clip.
Gallery
www.nokia.com/support 31
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
9. Camera
Your device supports an image capture resolution of
2048x1536 pixels. The image resolution in this guide may
appear different.
Activate the camera
To activate the camera, press the capture key.
Image capture
On-screen controls and indicators for still
image capture
The still image viewfinder displays the following:
1 — Capture mode indicator
2 — Zoom slider. To turn the zoom slider on and off, tap the
screen.
3 — Capture icon. Tap to capture an image.
4 — Flash mode. Tap to change settings.
5 — Capture settings. Tap to change settings.
6 — Battery charge level indicator
7 — Image resolution indicator
8 — Image counter (the estimated number of images you can
capture using the current image quality setting and available
memory)
9 — Memory in use. Depending on the setup of your device,
there are the following options: device memory ( ), or
memory card ( ).
10 — GPS signal indicator
Capture and recording settings
To open the capture and recording settings view before
capturing an image or recording a video clip, select Menu >
Applications > Camera and .
The capture and recording settings view provides you with
shortcuts to different items and settings before capturing an
image or recording a video clip.
The capture and recording settings return to the default
settings after you close the camera.
Select from the following:
— Select the scene.
or — Switch between video and image mode.
or — Show or hide the viewfinder grid (images only).
— Activate the self-timer (images only).
— Open Gallery.
Camera
32 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Image settings:
— Select a colour effect.
— Adjust the white balance. Select the current lighting
conditions. This allows the camera to reproduce colours more
accurately.
— Adjust the exposure compensation (images only). If
you are shooting a dark subject against a very light
background, such as snow, adjust the exposure to +1 or +2
to compensate for the background brightness. For light
subjects against a dark background, use -1 or -2.
Adjust light sensitivity (images only). Increase the light
sensitivity in low light conditions to avoid too dark images
and blurry images. Increasing the light sensitivity may also
increase the image noise.
Adjust contrast (images only). Adjust the difference
between the lightest and darkest parts of the image.
Adjust sharpness (images only).
The screen display changes to match the settings you define.
The capture settings are shooting-mode specific. Switching
between the modes does not reset the defined settings.
If you select a new scene, the capture settings are replaced
by the selected scene. You can change the capture settings
after selecting a scene if needed. For more information on
the scenes, see the extended user guide on the product
support pages of the Nokia website.
Saving the captured image may take longer if you change the
zoom, lighting, or colour settings.
Capture images
When capturing an image, note the following:
●Use both hands to keep the camera still.
●The quality of a digitally zoomed image is lower than that
of a non-zoomed image.
●The camera goes into battery saving mode if there are no
actions for about a minute. To continue capturing images,
slide the lock switch on the side of the device.
To capture an image:
1. To switch from video mode to image mode, if necessary,
select > .
2. To lock the focus on an object, press the capture key
halfway down (not available in landscape or sport scene
modes). A green locked focus indicator is displayed. If the
focus was not locked, a yellow focus indicator is displayed.
Release the capture key, and press it halfway down again.
You can also capture an image without locking the focus.
3. To capture an image, press the capture key. Do not move
the device before the image is saved and the final image
displayed.
To zoom in or out when capturing an image, use the zoom
key in your device.
After capturing an image
After you capture an image, select from the following options
(available only if you have selected Options > Settings >
Show captured image > Yes):
Camera
www.nokia.com/support 33
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
● Send — Send the image in a multimedia or e-mail
message, or through connection methods such as
Bluetooth connectivity.
To send the image to the person you are talking to, select
Send to caller during a call.
● Delete — Delete the image.
● — Open Gallery.
To use the image as wallpaper in the home screen, select
Options > Use image > Set as wallpaper.
To set the image as a default call image to be used for every
call situation, select Options > Use image > Set as call
image.
To assign the image to a contact, Options > Use image >
Assign to contact.
To return to the viewfinder to capture a new image, press the
capture key.
Flash and video light
Keep a safe distance when using the flash. Do not use the
flash on people or animals at close range. Do not cover the
flash while taking a picture.
The camera of your device has a dual LED flash for low light
conditions.
To select the desired flash mode, tap the current flash mode
indicator, which is one of the following: Automatic,
Reduce red, On, and Off.
Avoid touching the flash LEDs when the back cover has been
removed. The LEDs may get hot after prolonged usage.
Video light
To increase light levels when recording video in low light,
select
Video recording
Record videos
1. To switch from image mode to video mode, if necessary,
select and the video mode .
2. To start recording, press the capture key or tap . A red
record icon is displayed, and a tone sounds.
3. To pause recording at any time, select Pause. To resume,
select Continue. If you pause recording and do not press
any key within one minute, the recording stops.
To zoom in or out of the subject, use the zoom key in your
device.
4. To stop recording, press the capture key. The video clip is
automatically saved in Gallery. The maximum length of a
video clip is approximately 30 seconds with sharing
quality and 90 minutes with other quality settings.
Video recording on-screen controls and
indicators
The video viewfinder displays the following:
Camera
34 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
1 — Capture mode indicator
2 — Audio mute on indicator
3 — Capture icon. Tap to record video.
4 — Video light on/off.
5 — Recording settings. Tap to change settings.
6 — Battery charge level indicator
7 — Video quality indicator. To change this setting, select
Options > Settings > Video quality.
8 — Video clip file type
9 — Available recording time. When you are recording, the
current video length indicator also shows the elapsed and
remaining time.
10 — The location to which the video clip is saved.
After recording a video clip
After you record a video clip, select from the following
options (available only if you have selected Options >
Settings > Show last captured video > Yes):
● Play — Play the video clip you just recorded.
● Delete — Delete the video clip.
●Send or press the call key — Send the video clip in a
multimedia or e-mail message, or through connection
methods such as Bluetooth connectivity. You may not be
able to send video clips saved in the MPEG4 file format in
a multimedia message.
To send the video clip to the person you are talking to,
select (Send to caller) during a call.
To return to the viewfinder to record a new video clip, press
the capture key.
10. Positioning (GPS)
You can use applications such as GPS data to calculate your
location or measure distances. These applications require a
GPS connection.
About GPS
The coordinates in the GPS are expressed using the
international WGS-84 coordinate system. The availability of
the coordinates may vary by region.
Positioning (GPS)
www.nokia.com/support 35
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
The Global Positioning System (GPS) is operated by the
government of the United States, which is solely responsible
for its accuracy and maintenance. The accuracy of location
data can be affected by adjustments to GPS satellites made
by the United States government and is subject to change
with the United States Department of Defense civil GPS policy
and the Federal Radionavigation Plan. Accuracy can also be
affected by poor satellite geometry. Availability and quality
of GPS signals may be affected by your location, buildings,
natural obstacles, and weather conditions. GPS signals may
not be available inside buildings or underground and may be
impaired by materials such as concrete and metal.
GPS should not be used for precise location measurement,
and you should never rely solely on location data from the
GPS receiver and cellular radio networks for positioning or
navigation.
The trip meter has limited accuracy, and rounding errors may
occur. Accuracy can also be affected by availability and quality
of GPS signals.
Different positioning methods can be enabled or disabled in
positioning settings.
Assisted GPS (A-GPS)
Your device also supports Assisted GPS (A-GPS).
A-GPS is a network service.
Assisted GPS (A-GPS) is used to retrieve assistance data over
a packet data connection, which assists in calculating the
coordinates of your current location when your device is
receiving signals from satellites.
When you activate A-GPS, your device receives useful satellite
information from an assistance data server over the cellular
network. With the help of assisted data, your device can
obtain the GPS position faster.
Your device is preconfigured to use the Nokia A-GPS service,
if no service provider-specific A-GPS settings are available.
The assistance data is retrieved from the Nokia A-GPS service
server only when needed.
You must have an internet access point defined in the device
to retrieve assistance data from the Nokia A-GPS service over
a packet data connection. To define an access point for A-GPS,
select Menu > Applications > Location and
Positioning > Positioning server > Access point. A
wireless LAN (WLAN) access point cannot be used for this
service. Only a packet data internet access point can be used.
Your device asks for the internet access point when GPS is
used for the first time.
Hold your device correctly
When using the GPS receiver, ensure you do not cover the
antenna with your hand.
Positioning (GPS)
36 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Establishing a GPS connection may take from
a couple of seconds to several minutes.
Establishing a GPS connection in a vehicle
may take longer.
The GPS receiver draws its power from the
device battery. Using the GPS receiver may drain the battery
faster.
11. Connectivity
Your device offers several options to connect to the internet
or to another compatible device or PC.
Wi-Fi/WLAN connection
Your device can detect and connect to wireless local area
networks (WLAN). Using a WLAN, you can connect your device
to the internet and compatible devices that have WLAN
support.
About WLAN
Your device can detect and connect to WLANs. Using a WLAN,
you can connect your device to the internet and compatible
devices that support WLAN.
To use a WLAN connection, you need the following:
●WLAN must be available in your location.
●Your device must be connected to the WLAN. Some WLANs
are protected, and you need an access key from the service
provider to connect to them.
●An internet access point created for WLAN. Use the access
point for applications that need to connect to the internet.
A WLAN connection is established when you create a data
connection using a WLAN internet access point. The active
WLAN connection ends when you end the data connection.
You can use WLAN during a voice call or when packet data is
active. You can only be connected to one WLAN access point
device at a time, but several applications can use the same
access point.
Features that use WLAN, or that are allowed to run in the
background while using other features, increase the demand
on battery power and reduce the battery life.
Your device supports the following WLAN features:
Connectivity
www.nokia.com/support 37
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
●IEEE 802.11b/g standard
●Operation at 2.4 GHz
●Wired equivalent privacy (WEP), Wi-Fi protected access
(WPA/WPA2), and 802.1x authentication methods. These
functions can be used only if they are supported by the
network.
Important: Always enable one of the available
encryption methods to increase the security of your wireless
LAN connection. Using encryption reduces the risk of
unauthorised access to your data.
When the device is in the offline profile, you can still use
WLAN, if available. Remember to comply with any applicable
safety requirements when establishing and using a WLAN
connection.
Tip: To check the unique media access control (MAC)
address that identifies your device, open the dialler
and enter *#62209526#.
WLAN wizard
Select Menu > Settings and Connectivity > Wireless
LAN.
The WLAN wizard helps you to connect to a wireless LAN
(WLAN) and manage your WLAN connections.
If the search finds WLANs, to create an internet access point
(IAP) for a connection and start the web browser using this
IAP, select the connection and Start web browsing.
If you select a secured WLAN, you are asked to enter the
relevant password. To connect to a hidden network, you must
enter the correct network name (service set identifier, SSID).
If you already have the web browser running using the
currently active WLAN connection, to return to the web
browser, select Continue web browsing. To end the active
connection, select the connection and Disconnect WLAN.
12. Share online
About Share online
Select Menu > Internet > Share online.
With Share online (network service), you can post your
images, video clips, and sound clips from your device to
compatible online sharing services, such as albums and
blogs. You can also view and send comments to the posts in
these services, and download content to your compatible
Nokia device.
The supported content types and the availability of the Share
online service may vary.
Subscribe to services
Select Menu > Internet > Share online.
Share online
38 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To subscribe to an online sharing service, go to the service
provider's website, and check that your Nokia device is
compatible with the service. Create an account as instructed
on the website. You receive a user name and password
needed to set up your device with the account.
1. To activate a service, open the Share online application in
your device, select a service and Options > Activate.
2. Allow the device to create a network connection. If you
are prompted for an internet access point, select one from
the list.
3. Sign in to your account as instructed on the service
provider’s website.
For the availability and cost of the third party services and
data transfer costs, contact your service provider or the
relevant third party.
Manage your accounts
To view your accounts, select Options > Settings > My
accounts.
To create a new account, select Options > Add new
account.
To change your user name or password for an account, select
the account and Options > Open.
To set the account as the default when sending posts from
your device, select Options > Set as default.
To remove an account, select the account and Options >
Delete.
Create a post
Select Menu > Internet > Share online.
To post multimedia files to a service, select a service and
Options > New post. If the online sharing service provides
channels for posting files, select the desired channel.
To add an image, video clip, or sound clip to the post, select
Options > Insert.
To add a title or description to the post, enter text directly to
the fields, if available.
To add tags to the post, select Tags:.
To select whether to enable the posting of location
information contained in the file, select Location:.
To set the level of privacy for a file, select Privacy:. To allow
everyone to view your file, select Public. To restrict others
from seeing your files, select Private. You can define the
Default setting on the service provider's website.
To send the post to the service, select Options > Upload.
Post files from Gallery
You can post files from Gallery to an online sharing service.
1. Open Gallery, and select the files you want to post.
2. Select Options > Send > Upload and the desired
account.
3. Edit your post as required.
4. Select Options > Post to web.
Share online
www.nokia.com/support 39
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
13. Nokia Video Centre
With Nokia Video Centre (network service), you can download
and stream video clips over the air from compatible internet
video services using a packet data or WLAN connection. You
can also transfer video clips from a compatible PC to your
device and view them in Video centre.
Using packet data access points to download videos may
involve the transmission of large amounts of data through
your service provider's network. Contact your service
provider for information about data transmission charges.
Your device may have predefined services.
Service providers may provide free content or charge a fee.
Check the pricing in the service or from the service provider.
View and download video clips
Connect to video services
1. Select Menu > Applications > Video centre.
2. To connect to a service to install video services, select Add
new services and the desired video service from the
service catalogue.
View a video clip
To browse the content of installed video services, select
Video feeds.
The content of some video services is divided into categories.
To browse video clips, select a category.
To search for a video clip in the service, select Video
search. Search may not be available in all services.
Some video clips can be streamed over the air, but others
must be first downloaded to your device. To download a
video clip, select Options > Download. Downloads
continue in the background if you exit the application. The
downloaded video clips are saved in My videos.
To stream a video clip or view a downloaded one, select
Options > Play. When the video clip is playing, to use the
control keys for controlling the player, tap the screen. To
adjust the volume, use the volume key.
Warning: Continuous exposure to high volume may
damage your hearing. Listen to music at a moderate level,
and do not hold the device near your ear when the
loudspeaker is in use.
Select Options and from the following:
●Resume download — Resume a paused or failed
download.
●Cancel download — Cancel a download.
●Preview — Preview a video clip. This option is available
if supported by the service.
●Feed details — View information about a video clip.
●Refresh list — Refresh the list of video clips.
●Open link in browser — Open a link in the web browser.
Nokia Video Centre
40 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Schedule downloads
Setting the application to download video clips automatically
may involve the transmission of large amounts of data
through your service provider's network. For information
about data transmission charges, contact your service
provider. To schedule an automatic download for video clips
in a service, select Options > Schedule downloads. Video
centre automatically downloads new video clips daily at the
time you define.
To cancel scheduled downloads, select Manual download as
the download method.
Video feeds
Select Menu > Applications > Video centre.
The content of the installed video services is distributed using
RSS feeds. To view and manage your feeds, select Video
feeds.
Select Options and from the following:
●Feed subscriptions — Check your current feed
subscriptions.
●Feed details — View information about a video.
●Add feed — Subscribe to new feeds. Select Via Video
directory to select a feed from the services in the video
directory.
●Refresh feeds — Refresh the content of all feeds.
●Manage account — Manage your account options for a
particular feed, if available.
●Move — Move video clips to a desired location.
To view the videos available in a feed, select a feed from the
list.
My videos
My videos is a storage place for all videos in the Video centre
application. You can list downloaded videos and video clips
recorded with the device camera in separate views.
1. To open a folder and view video clips, select the folder.
When a video clip is playing, to use the control keys for
controlling the player, tap the screen.
2. To adjust the volume, press the volume key.
Select Options and from the following:
●Mute or Unmute — Turn sound on or off.
●Resume download — Resume a paused or failed
download.
●Cancel download — Cancel a download.
●Video details — View file details.
●Change aspect ratio — Select the aspect ratio of the
video clip. Select Natural, Stretch, or Zoom.
●Memory status — View the amount of free and used
memory.
To move or copy video clips to a compatible memory card,
select Options > Move and copy > Copy or Move and the
memory card.
Transfer videos from your PC
Transfer your own video clips to Video centre from
compatible devices using a compatible USB data cable. Video
Nokia Video Centre
www.nokia.com/support 41
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
centre displays only the video clips which are in a format
supported by your device.
1. To view your device on a PC as a mass memory device
where you can transfer any data files, make the
connection with a USB data cable.
2. Select Mass storage as the connection mode. A
compatible memory card needs to be inserted in the
device.
3. Select the video clips you want to copy from your PC.
4. Transfer the video clips to E:\My Videos in the memory
card.
The transferred video clips appear in the My videos folder
in Video centre. Video files in other folders of your device
are not displayed.
Video centre settings
In the Video centre main view, select Options > Settings
and from the following:
●Video service selection — Select the video services that
you want to appear in Video centre. You can also add,
remove, edit, and view the details of a video service. You
cannot edit preinstalled video services.
●Connection settings — To define the network
destination used for the network connection, select
Network connection. To select the connection manually
each time Video centre opens a network connection, select
Always ask.
To set GPRS connection on or off, select Confirm GPRS
usage.
To set roaming on or off, select Confirm roaming.
●Parental control — Set an age limit to videos. The
required password is the same as the device lock code. The
factory setting for the lock code is 12345. In video-on-
demand services, videos which have the same or a higher
age limit than you have set, are hidden.
●Preferred memory — Select whether downloaded
videos are saved in the device memory or on a compatible
memory card.
●Thumbnails — Select whether to download and view
thumbnail images in video feeds.
14. Web browser
To browse the web, you need to have an internet access point
defined in your device.
Tip: To access the browser, tap the media key ( ) to
open the media bar, and select .
Browse the web
Select Menu > Internet > Web.
Web browser
42 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Important: Use only services that you trust and that
offer adequate security and protection against harmful
software.
Important: Only install and use applications and
other software from trusted sources, such as applications
that are Symbian Signed or have passed the Java Verified™
testing.
To browse a web page, in the bookmarks view, select a
bookmark, or enter the address in the field ( ), and select
Go to.
Some web pages may contain material, such as graphics and
sounds, that requires a large amount of memory to view. If
your device runs out of memory while loading such a web
page, the graphics on the page are not shown.
To browse web pages without graphics to save memory,
select Options > Settings > Page > Load content > Text
only.
To enter a new web address you want to visit, select
Options > Go to > New web page.
To refresh the content of the web page, select Options >
Web page options > Reload.
To save the current web page as a bookmark, select
Options > Web page options > Save as bookmark.
To view snapshots of the web pages you have visited during
the current browsing session, select Back (available if
History list is set on in the browser settings and the current
web page is not the first web page you visit). Select the web
page you want.
To open a sublist of commands or actions for the current web
page, select Options > Service options (if supported by the
web page).
To prevent or allow the automatic opening of multiple
windows, select Options > Web page options > Block
pop-ups or Allow pop-ups.
Tip: To take the browser to the background, press the
end key once. To end the connection, press and hold
the end key.
Browser toolbar
The browser toolbar helps you select frequently used
functions of the browser.
From the toolbar, select from the following:
● Expand toolbar — Expand the toolbar to access more
toolbar functions.
● Go to web address — Enter a new web address.
● Show zoom — Zoom in or out on the web page.
To use the expanded toolbar, select Expand toolbar and
from the following:
● Go to feeds — View your current feed subscriptions.
● Full screen — Switch to the full screen view.
● Subsc. feeds — View a list of available web feeds on
the current web page, and subscribe to a web feed.
Web browser
www.nokia.com/support 43
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
● Settings — Edit the settings.
● Save bkmrk. — Save the current web page as a
bookmark.
● Reload — Refresh the web page.
● Overview — View an overview of the current web
page.
● Homepage — Go to the homepage (if defined in the
settings).
● Bookmarks — Open the bookmarks view.
● Find keywd. — Search on the current web page.
Bookmarks
The bookmarks view opens when you open the Web
application. You can select web addresses from a list or from
a collection of bookmarks in the Recently visited pages
folder.
The toolbar helps you select frequently used functions of the
browser.
On the toolbar, select from the following:
● Add bookmark — Add a new bookmark.
● Go to web address — Enter a new web address.
● Delete — Delete a bookmark.
Select Options and from the following:
●Go to — Enter a new web address, go to the previous web
page, or view saved links to web feeds and blogs.
●Bookmark options — Send and add bookmarks, and set
bookmarks as a homepage.
●Bookmark manager — Edit, move, and delete
bookmarks.
Web also keeps track of the web pages you visit during
browsing. In the Recently visited pages folder, you can view
the list of the visited web pages.
Empty the cache
The information or services you have accessed are stored in
the cache memory of the device.
A cache is a memory location that is used to store data
temporarily. If you have tried to access or have accessed
confidential information requiring passwords, empty the
cache after each use.
To empty the cache, select Options > Clear privacy data >
Cache.
Connection security
If the security indicator ( ) is displayed during a connection,
the data transmission between the device and the internet
gateway or server is encrypted.
The security icon does not indicate that the data transmission
between the gateway and the content server (where the data
is stored) is secure. The service provider secures the data
transmission between the gateway and the content server.
Security certificates may be required for some services, such
as banking services. You are notified if the identity of the
server is not authentic or if you do not have the correct
Web browser
44 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
security certificate in your device. For more information,
contact your service provider.
Important: Even if the use of certificates makes the
risks involved in remote connections and software
installation considerably smaller, they must be used correctly
in order to benefit from increased security. The existence of
a certificate does not offer any protection by itself; the
certificate manager must contain correct, authentic, or
trusted certificates for increased security to be available.
Certificates have a restricted lifetime. If "Expired certificate"
or "Certificate not valid yet" is shown, even if the certificate
should be valid, check that the current date and time in your
device are correct.
Before changing any certificate settings, you must make sure
that you really trust the owner of the certificate and that the
certificate really belongs to the listed owner.
15. Green tips
Here are tips on how you can contribute to
protecting the environment.
Save energy
When you have fully charged the battery and disconnected
the charger from the device, unplug the charger from the wall
outlet.
You do not need to charge your battery so often if you do the
following:
●Close and disable applications, services, and connections
when not in use.
●Decrease the brightness of the screen.
●Set the device to enter the power saver mode after the
minimum period of inactivity, if available in your device.
●Disable unnecessary sounds, such as keypad and ringing
tones.
Recycle
Most of the materials in a Nokia phone are recyclable. Check
how to recycle your Nokia products at www.nokia.com/
werecycle, or with a mobile device, www.nokia.mobi/
werecycle.
Recycle packaging and user guides at your local recycling
scheme.
Save paper
This user guide helps you get started with your device. For
more detailed instructions, open the in-device help (in most
applications, select Options > Help). For further support,
see www.nokia.com/support.
Green tips
www.nokia.com/support 45
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Learn more
For more information on the environmental attributes of
your device, see www.nokia.com/ecodeclaration.
Green tips
46 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Accessories
Warning: Use only batteries, chargers, and
accessories approved by Nokia for use with this particular
model. The use of any other types may invalidate any
approval or warranty, and may be dangerous. In particular,
use of unapproved chargers or batteries may present a risk
of fire, explosion, leakage, or other hazard.
For availability of approved accessories, please check with
your dealer. When you disconnect the power cord of any
accessory, grasp and pull the plug, not the cord.
Battery
Battery and charger information
Your device is powered by a rechargeable battery. The battery
intended for use with this device is BL-5J. Nokia may make
additional battery models available for this device. This
device is intended for use when supplied with power from
the following chargers: AC-8, AC-5. The exact charger model
number may vary depending on the type of plug. The plug
variant is identified by one of the following: E, EB, X, AR, U, A,
C, K, or UB.
The battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, replace
the battery. Use only Nokia approved batteries, and recharge
your battery only with Nokia approved chargers designated
for this device.
If a battery is being used for the first time or if the battery
has not been used for a prolonged period, it may be necessary
to connect the charger, then disconnect and reconnect it to
begin charging the battery. If the battery is completely
discharged, it may take several minutes before the charging
indicator appears on the display or before any calls can be
made.
Safe removal. Always switch the device off and disconnect the
charger before removing the battery.
Proper charging. Unplug the charger from the electrical plug
and the device when not in use. Do not leave a fully charged
battery connected to a charger, since overcharging may
shorten its lifetime. If left unused, a fully charged battery will
lose its charge over time.
Avoid extreme temperatures. Always try to keep the battery
between 15°C and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and lifetime of the battery.
A device with a hot or cold battery may not work temporarily.
Battery performance is particularly limited in temperatures
well below freezing.
www.nokia.com/support 47
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Do not short-circuit. Accidental short-circuiting can occur
when a metallic object such as a coin, clip, or pen causes
direct connection of the positive (+) and negative (-)
terminals of the battery. (These look like metal strips on the
battery.) This might happen, for example, when you carry a
spare battery in your pocket or purse. Short-circuiting the
terminals may damage the battery or the connecting object.
Disposal. Do not dispose of batteries in a fire as they may
explode. Dispose of batteries according to local regulations.
Please recycle when possible. Do not dispose as household
waste.
Leak. Do not dismantle, cut, open, crush, bend, puncture, or
shred cells or batteries. In the event of a battery leak, prevent
battery liquid contact with skin or eyes. If this happens, flush
the affected areas immediately with water, or seek medical
help.
Damage. Do not modify, remanufacture, attempt to insert
foreign objects into the battery, or immerse or expose it to
water or other liquids. Batteries may explode if damaged.
Correct use. Use the battery only for its intended purpose.
Improper battery use may result in a fire, explosion, or other
hazard. If the device or battery is dropped, especially on a
hard surface, and you believe the battery has been damaged,
take it to a service centre for inspection before continuing to
use it. Never use any charger or battery that is damaged. Keep
your battery out of the reach of small children.
Nokia battery authentication
guidelines
Always use original Nokia batteries for your safety. To check
that you are getting an original Nokia battery, purchase it
from a Nokia authorised service centre or dealer, and inspect
the hologram label using the following steps:
Authenticate hologram
1. When you look at the hologram on
the label, you should see the Nokia
connecting hands symbol from one
angle and the Nokia Original
Enhancements logo when looking
from another angle.
2. When you angle the hologram left,
right, down and up, you should see 1,
2, 3 and 4 dots on each side
respectively.
Successful completion of the steps is not
a total assurance of the authenticity of
the battery. If you cannot confirm
authenticity or if you have any reason to
believe that your Nokia battery with the
hologram on the label is not an authentic
Nokia battery, you should refrain from
using it, and take it to the nearest Nokia authorised service
centre or dealer for assistance.
For additional information, refer to the warranty and
reference leaflet included with your Nokia device.
Battery
48 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Taking care of your device
Your device is a product of superior design and craftsmanship
and should be treated with care. The following suggestions
will help you protect your warranty coverage.
●Keep the device dry. Precipitation, humidity, and all types
of liquids or moisture can contain minerals that will
corrode electronic circuits. If your device does get wet,
remove the battery, and allow the device to dry completely
before replacing it.
●Do not use or store the device in dusty, dirty areas. Its
moving parts and electronic components can be damaged.
●Do not store the device in high or cold temperature. High
temperatures can shorten the life of electronic devices,
damage batteries, and warp or melt certain plastics. When
the device warms to its normal temperature from a cold
temperature, moisture can form inside the device and
damage electronic circuit boards.
●Do not attempt to open the device other than as instructed
in this guide.
●Do not drop, knock, or shake the device. Rough handling
can break internal circuit boards and fine mechanics.
●Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the device. Only use a soft, clean, dry
cloth to clean the surface of the device.
●Do not paint the device. Paint can clog the moving parts
and prevent proper operation.
●Use only the supplied or an approved replacement
antenna. Unauthorised antennas, modifications, or
attachments could damage the device and may violate
regulations governing radio devices.
●Use chargers indoors.
●Backup all data you want to keep, such as contacts and
calendar notes.
●To reset the device from time to time for optimum
performance, power off the device and remove the
battery.
These suggestions apply equally to your device, battery,
charger, or any accessory.
Recycle
Always return your used electronic products, batteries, and
packaging materials to dedicated collection points. This way
you help prevent uncontrolled waste disposal and promote
the recycling of materials. Check product environmental
information and how to recycle your Nokia products at
www.nokia.com/werecycle, or nokia.mobi/werecycle.
Taking care of your device
www.nokia.com/support 49
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Additional safety information
Small children
Your device and its accessories are not toys. They may contain
small parts. Keep them out of the reach of small children.
Operating environment
This device meets RF exposure guidelines in the normal use
position at the ear or at least 1.5 centimetres (5/8 inch) away
from the body. Any carry case, belt clip, or holder for body-
worn operation should not contain metal and should position
the device the above-stated distance from your body.
To send data files or messages requires a quality connection
to the network. Data files or messages may be delayed until
such a connection is available. Follow the separation distance
instructions until the transmission is completed.
Parts of the device are magnetic. Metallic materials may be
attracted to the device. Do not place credit cards or other
magnetic storage media near the device, because
information stored on them may be erased.
Medical devices
Operation of radio transmitting equipment, including
wireless phones, may interfere with the function of
inadequately protected medical devices. Consult a physician
or the manufacturer of the medical device to determine
whether they are adequately shielded from external RF
energy. Switch off your device when regulations posted
instruct you to do so. Hospitals or health care facilities may
use equipment sensitive to external RF energy.
Implanted medical devices
Manufacturers of medical devices recommend a minimum
separation of 15.3 centimetres (6 inches) between a wireless
device and an implanted medical device, such as a pacemaker
or implanted cardioverter defibrillator, to avoid potential
interference with the medical device. Persons who have such
devices should:
●Always keep the wireless device more than 15.3
centimetres (6 inches) from the medical device.
●Not carry the wireless device in a breast pocket.
●Hold the wireless device to the ear opposite the medical
device.
●Turn the wireless device off if there is any reason to
suspect that interference is taking place.
●Follow the manufacturer directions for the implanted
medical device.
If you have any questions about using your wireless device
with an implanted medical device, consult your health care
provider.
Hearing aids
Some digital wireless devices may interfere with some
hearing aids.
Additional safety information
50 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles such as
electronic fuel injection, electronic antilock braking,
electronic speed control, and air bag systems. For more
information, check with the manufacturer of your vehicle or
its equipment.
Only qualified personnel should service the device or install
the device in a vehicle. Faulty installation or service may be
dangerous and may invalidate your warranty. Check regularly
that all wireless device equipment in your vehicle is mounted
and operating properly. Do not store or carry flammable
liquids, gases, or explosive materials in the same
compartment as the device, its parts, or accessories.
Remember that air bags inflate with great force. Do not place
your device or accessories in the air bag deployment area.
Switch off your device before boarding an aircraft. The use of
wireless teledevices in an aircraft may be dangerous to the
operation of the aircraft and may be illegal.
Potentially explosive environments
Switch off your device in any area with a potentially explosive
atmosphere. Obey all posted instructions. Sparks in such
areas could cause an explosion or fire resulting in bodily
injury or death. Switch off the device at refuelling points such
as near gas pumps at service stations. Observe restrictions in
fuel depots, storage, and distribution areas; chemical plants;
or where blasting operations are in progress. Areas with a
potentially explosive atmosphere are often, but not always,
clearly marked. They include areas where you would be
advised to turn off your vehicle engine, below deck on boats,
chemical transfer or storage facilities and where the air
contains chemicals or particles such as grain, dust, or metal
powders. You should check with the manufacturers of
vehicles using liquefied petroleum gas (such as propane or
butane) to determine if this device can be safely used in their
vicinity.
Emergency calls
Important: This device operates using radio signals,
wireless networks, landline networks, and user-programmed
functions. If your device supports voice calls over the internet
(internet calls), activate both the internet calls and the
cellular phone. The device will attempt to make emergency
calls over both the cellular networks and through your
internet call provider if both are activated. Connections in all
conditions cannot be guaranteed. You should never rely
solely on any wireless device for essential communications
like medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for adequate
signal strength. Depending on your device, you may also
need to complete the following:
●Insert a SIM card if your device uses one.
●Remove certain call restrictions you have activated in
your device.
Additional safety information
www.nokia.com/support 51
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
●Change your profile from offline profile mode to an
active profile.
●If the screen and keys are locked, slide the lock switch
on the side of the device to unlock them.
2. Press the end key as many times as needed to clear the
display and ready the device for calls.
3. Open the dialler by selecting the dialler icon ( ).
4. Enter the official emergency number for your present
location. Emergency numbers vary by location.
5. Press the call key.
When making an emergency call, give all the necessary
information as accurately as possible. Your wireless device
may be the only means of communication at the scene of an
accident. Do not end the call until given permission to do so.
Certification information (SAR)
This mobile device meets guidelines for exposure to
radio waves.
Your mobile device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines
were developed by the independent scientific organisation
ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The exposure guidelines for mobile devices employ a unit of
measurement known as the Specific Absorption Rate or SAR.
The SAR limit stated in the ICNIRP guidelines is 2.0 watts/
kilogram (W/kg) averaged over 10 grams of tissue. Tests for
SAR are conducted using standard operating positions with
the device transmitting at its highest certified power level in
all tested frequency bands. The actual SAR level of an
operating device can be below the maximum value because
the device is designed to use only the power required to reach
the network. That amount changes depending on a number
of factors such as how close you are to a network base station.
The highest SAR value under the ICNIRP guidelines for use of
the device at the ear is 1.01 W/kg.
Use of device accessories may result in different SAR values.
SAR values may vary depending on national reporting and
testing requirements and the network band. Additional SAR
information may be provided under product information at
www.nokia.com.
Your mobile device is also designed to meet the requirements
for exposure to radio waves established by the Federal
Communications Commission (USA) and Industry Canada.
These requirements set a SAR limit of 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported under this
standard during product certification for use at the ear is 1.29
W/kg and when properly worn on the body is 0.81 W/kg.
Additional safety information
52 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Index
A
A-GPS (assisted GPS) 36
access codes 16
antennas 18
assisted GPS (A-GPS) 35
audio messages 26
B
bookmarks 44
browser
bookmarks 44
browsing pages 42
cache memory 44
security 44
toolbar 43
C
cache memory 44
calls 21
camera
flash 34
image mode 33
indicators 32
options 33
recording 35
video mode 34
capture settings
in camera 32
D
data connections
wireless 37
display rotation 19
double-tap 13
drag 13
E
e-mail 27
G
gallery 30
organising 30
viewing 30
viewing images 31
viewing videos 31
general information 15
GPS (Global Positioning
System) 35
H
headset 20
help application 15
I
internet connection 42
See also
browser
K
keypad lock 12
keys and parts 9
L
location information 35
lock code 16
lock switch 12
locking the keys 12
M
Mail for Exchange 27
media
music player 28
media bar 14
media key 14
memory
web cache 44
menu 13
messages
folders for 25
MMS (multimedia message
service) 26
multimedia messages 26
music player 28
playlists 29
transferring music 30
www.nokia.com/support 53
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
N
navigation tools 35
Nokia Music 30
Nokia support information 15
O
offline profile 19
outbox, message 26
P
photos
See
camera
PIN code 16
PIN2 code 16
positioning information 35
profiles
offline restrictions 19
proximity sensor 21
PUK codes 16
R
recording settings
in camera 32
recording video clips 34
removing SIM card 20
S
security
web browser 44
security code 16
select 13
sensors 19
sent messages folder 26
settings 32
video centre 42
Share online 38
accounts 39
activating services 38
creating posts 39
posting 39
subscribing 38
sharing media files online 38
SIM card 20
inserting 10
SMS (short message service) 26
songs 28
stylus 12
support resources 15
swipe 13
T
tap 13
text messages
sending 26
U
UPIN code 16
uploading media files 38
UPUK code 16
useful information 15
V
Video Centre 40
video centre
downloading 40
my videos 41
transferring videos 41
video feeds 41
viewing 40
voice calls
See
calls
W
web connection 42
wireless LAN (WLAN) 37
WLAN (wireless local area
network) 37
wrist strap 21
Z
zooming 33, 34
Index
54 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
