Nokia 6600 Slide User Guide

5555555

Issue 1

Cyan

Magenta

Yellow

Black

Contents

3Safety

4 Make it your phone

4 Start up

12 Personalise your phone

14 Connect

17 Network provider services

18 Stay in touch

18 Make calls

21 Text and messages

26 Image and video

26 Capture an image

26 Record a video clip

26 Camera and video options

27 Gallery

28 Entertainment

28 Listen to music

31 Web

33 Games and applications

34 Maps

34 Download maps

34 Maps and GPS

35 Extra services

36 Organise

36 Manage contacts

37 Business cards

37 Date and time

37 Alarm clock

37 Calendar

38 To-do list

38 Notes

38 Nokia PC Suite

38 Calculator

38 Countdown timer

39 Stopwatch

39 Support and phone software

updates

39 Helpful hints

39 Nokia support

40 My Nokia

40 Download content

40 Software updates

41 Software updates over the air

41 Configuration setting service

41 Restore factory settings

43 Digital rights management

43 Enhancements

43 Battery

43 Battery and charger information

44 Nokia battery authentication

guidelines

44 Authenticate hologram

44 What if your battery is not authentic?

44 Care and maintenance

44 Disposal

45 Additional safety information

45 Small children

45 Operating environment

45 Medical devices

45 Vehicles

45 Potentially explosive environments

46 Emergency calls

46 CERTIFICATION INFORMATION (SAR)

47 Index

2Contents

Cyan

Magenta

Yellow

Black

Safety

Read these simple guidelines. Not

following them may be dangerous or

illegal. Read the complete user guide for

further information.

SWITCH ON SAFELY

Do not switch the device on

when wireless phone use is

prohibited or when it may

cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep

your hands free to operate the

vehicle while driving. Your first

consideration while driving

should be road safety.

INTERFERENCE

All wireless devices may be

susceptible to interference,

which could affect

performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch

the device off in aircraft, near

medical equipment, fuel,

chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may

install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved

enhancements and batteries.

Do not connect incompatible

products.

ENHANCEMENTS

Use only approved

enhancements. Do not connect

incompatible products.

WATER-RESISTANCE

Your device is not water-

resistant. Keep it dry.

Safety 3

Cyan

Magenta

Yellow

Black

Looking for a little self-

expression? Give your

phone its own look and feel

by choosing your own

ringtones, display

background and theme.

Make it your phone

Start up

Get to know your phone, insert the

battery, SIM card, and memory card, and

learn some important information about

your phone.

Keys and parts

1Earpiece

2Display

3Navi™ key (scroll key)

4Left selection key

5Call key

6Keypad

7End/Power key

8Right selection key

9Light sensor

10 Front camera

11 Charger connector

12 Strap eyelet

13 Back cover release button

14 USB cable connector

15 Camera flash

16 Main camera

17 Loudspeaker

Install SIM card and battery

Always switch the device off and

disconnect the charger before removing

the battery.

This phone is intended for use with a

BL-4U battery. Always use original Nokia

batteries. See "Nokia battery

authentication guidelines", p. 44.

The SIM card and its contacts can be easily

damaged by scratches or bending, so be

careful when handling, inserting, or

removing the card.

1 Push the release button, and open the

back cover. Remove the battery.

2 Open the SIM card holder. Insert the

SIM card into the holder with the

contact surface facing down. Close the

SIM card holder.

4Make it your phone

Cyan

Magenta

Yellow

Black

3 Observe the battery contacts, and

insert the battery. Replace the back

cover.

Insert a memory card

Use only compatible microSD cards

approved by Nokia for use with this

device. Nokia uses approved industry

standards for memory cards, but some

brands may not be fully compatible with

this device. Incompatible cards may

damage the card and the device and

corrupt data stored on the card.

You phone supports microSD cards of up

to 4 GB.

1 Switch the device off, and remove the

back cover and battery.

2 Slide the memory card holder to

unlock.

3 Open the card holder, and insert the

memory card into the holder with the

contact surface facing inwards.

4 Close the card holder, and slide it to

lock.

5 Replace the battery and back cover.

Charge the battery

Your battery has been precharged, but the

charging levels may vary.

1 Connect the charger to a wall outlet.

2 Connect the charger to the device.

3 When the battery is fully charged,

disconnect the charger from the

device, then from the wall outlet.

You also may charge the battery with a

USB cable with power from a computer.

1 Connect the USB cable to the USB port

of a computer and to your device.

2 When the battery is full charged,

disconnect the USB cable.

If the battery is completely discharged, it

may take a few minutes before the

charging indicator appears on the display

or before any calls can be made.

The charging time depends on the charger

used. Charging a BL-4U battery with the

AC-8 charger takes approximately 1 hour

30 minutes while the phone is in the

standby mode.

Make it your phone 5

Cyan

Magenta

Yellow

Black

Antenna

Your device may have internal and

external antennas. As with any radio

transmitting device, avoid touching the

antenna area unnecessarily while the

antenna is transmitting or receiving.

Contact with such an antenna affects the

communication quality and may cause the

device to operate at a higher power level

than otherwise needed and may reduce

the battery life.

The figure shows the antenna area

marked in grey.

Headset

Warning: Listen to music at a

moderate level. Continuous exposure to

high volume may damage your hearing.

Warning: When you use the headset,

your ability to hear outside sounds may be

affected. Do not use the headset where it

can endanger your safety.

When connecting any external device or

any headset, other than those approved

by Nokia for use with this device, to the

USB connector, pay special attention to

volume levels.

Strap

1Open the back cover.

2 Hook a strap behind the clamp, and

close the back cover.

About your phone

The wireless device described in this guide

is approved for use on the WCDMA 850 and

2100 and GSM 850, 900, 1800, and 1900.

Contact your service provider for more

information about networks.

When using the features in this device,

obey all laws and respect local customs,

privacy and legitimate rights of others,

including copyrights.

images, music, and other content from

being copied, modified, or transferred.

Your device may have preinstalled

bookmarks and links for third-party

internet sites. You may also access other

third-party sites through your device.

Third-party sites are not affiliated with

Nokia, and Nokia does not endorse or

assume liability for them. If you choose to

access such sites, you should take

precautions for security or content.

6Make it your phone

Cyan

Magenta

Yellow

Black

Warning: To use any features in this

device, other than the alarm clock, the

device must be switched on. Do not switch

the device on when wireless device use

may cause interference or danger.

Remember to make back-up copies or

keep a written record of all important

information stored in your device.

When connecting to any other device,

read its user guide for detailed safety

instructions. Do not connect incompatible

products.

Important: Use only services that you

trust and that offer adequate security and

protection against harmful software.

Network services

To use the phone you must have service

from a wireless service provider. Many of

the features require special network

features. These features are not available

on all networks; other networks may

require that you make specific

arrangements with your service provider

before you can use the network services.

Your service provider can give you

instructions and explain what charges will

apply. Some networks may have

limitations that affect how you can use

network services. For instance, some

networks may not support all language-

dependent characters and services.

Your service provider may have requested

that certain features be disabled or not

activated in your device. If so, these

features will not appear on your device

menu. Your device may also have a special

configuration such as changes in menu

names, menu order, and icons. Contact

your service provider for more

information.

Functions without a SIM card

Some functions of your phone may be

used without inserting a SIM card, such as

Organiser functions and games. Some

functions appear dimmed in the menus

and cannot be used.

Keypad lock

•To lock the keypad to prevent

accidental keypresses, select Menu,

and press * within 3 seconds.

•To unlock the keypad, select Unlock,

and press * within 1.5 seconds. If

requested, enter the lock code.

•To answer a call when the keypad is

locked, press the call key. When you

end or reject the call, the keypad locks

automatically.

Further features are Automatic

keyguard and Security keyguard. See

"Phone settings", p. 10.

When the device or keypad is locked, calls

may be possible to the official emergency

number programmed into your device.

Access codes

To set how your phone uses the access

codes and security settings, select

Menu > Settings > Security > Access

codes.

•The PIN (UPIN) code, supplied with the

SIM (USIM) card, helps to protect the

card against unauthorised use.

•The PIN2 (UPIN2) code, supplied with

some SIM (USIM) cards, is required to

access certain services.

Make it your phone 7

Cyan

Magenta

Yellow

Black

•PUK (UPUK) and PUK2 (UPUK2) codes

may be supplied with the SIM (USIM)

card. If you enter the PIN code

incorrectly three times in succession,

you are asked for the PUK code. If the

codes are not supplied, contact your

service provider.

•The security code helps to protect

your phone against unauthorised use.

You can create and change the code,

and set the phone to request the code.

Keep the code secret and in a safe

place separate from your phone. If

you forget the code and your phone is

locked, your phone will require

service and additional charges may

apply. For more information, contact

a Nokia Care point or your phone

dealer.

•The barring password is required

when using the call barring service to

restrict calls to and from your phone

(network service).

•To view or change the security

module settings for the web browser,

select Menu > Settings >

Security > Security module sett..

Switch the phone on and off

•To switch the phone on or off, press

and hold the power key.

•If the phone prompts for a PIN code,

enter the code (displayed as ****).

•If the phone prompts you for the time

and date, enter the local time, select

the time zone of your location in

terms of the time difference with

respect to Greenwich Mean Time

(GMT), and enter the date. See "Date

and time", p. 37.

When you switch on your phone for the

first time, you may be prompted to get the

configuration settings from your service

provider (network service). For more

information, refer to Connect to

support. See "Configuration", p. 17, and

"Configuration setting service", p. 41.

Standby mode

When the phone is ready for use, and you

have not entered any characters, the

phone is in the standby mode.

Display

1Network type indicator and signal

strength of the cellular network

2Battery charge status

3Indicators

4Name of the network or the operator

logo

5Clock

6Display

7Function of the left selection key

8Function of the scroll key

9Function of the right selection key

You can change the function of the left and

right selection key. See "Left and right

selection keys", p. 13.

8Make it your phone

Cyan

Magenta

Yellow

Black

Power saving

Your phone has a Power saver and a

Sleep mode feature in order to save

battery power in the standby mode when

no keys are pressed. These features may

be activated. See "Display", p. 13.

Active standby

The active standby mode displays a list of

selected phone features and information

that you can access directly.

•To activate or deactivate the active

standby mode, select Menu >

Settings > Display > Active

standby > Active standby mode.

•In the active standby mode, scroll up

or down to navigate in the list, and

select Select or View. The arrows

indicate that further information is

available. To stop navigation, select

Exit.

•To organise and change the active

standby mode, select Options and

from the available options.

Shortcuts in the standby mode

List of dialled numbers

Press the call key once. To make a call,

scroll to the number or name, and press

the call key.

Start the web browser

Press and hold 0.

Call the voice mailbox

Press and hold 1.

Use other keys as shortcuts

See "Dialling shortcuts", p. 19.

Indicators

You have unread messages.

You have unsent, cancelled, or

failed messages.

You have missed calls.

The keypad is locked.

The phone does not ring for

incoming calls or text messages.

An alarm is set.

/The phone is registered to the

GPRS or EGPRS network.

/The phone has an open GPRS or

EGPRS connection.

/The GPRS or EGPRS connection is

suspended (on hold).

Bluetooth connectivity is turned

on.

If you have two phone lines, the

second phone line is selected.

All incoming calls are diverted to

another number.

Calls are limited to a closed user

group.

The currently active profile is

timed.

Flight mode

Use the flight mode in radio sensitive

environments — on board aircraft or in

hospitals — to deactivate all radio

frequency functions. You can still access

your calendar, phone numbers, and

offline games. When the flight mode is

active, is displayed.

•To activate or set up the flight mode,

select Menu > Settings > Profiles >

Flight > Activate or Personalise.

Make it your phone 9

Cyan

Magenta

Yellow

Black

•To deactivate the flight mode, select

any other profile.

Emergency call in flight mode

•Enter the emergency number, press

the call key, and when Exit flight

profile? is displayed, select Yes.

Warning: With the flight profile you

cannot make or receive any calls,

including emergency calls, or use other

features that require network coverage.

To make calls, you must first activate the

phone function by changing profiles. If the

device has been locked, enter the lock

code. If you need to make an emergency

call while the device is locked and in the

flight profile, you may be also able to

enter an official emergency number

programmed in your device in the lock

code field and select 'Call'. The device will

confirm that you are about to exit flight

profile to start an emergency call.

Tapping

The tap function allows you to quickly

mute and reject calls and alarm tones, and

to display a clock just by double-tapping

the back or front of the phone when the

slide is closed.

Select Menu > Settings > Phone >

Sensor settings to activate the tap

function and vibration feedback.

Mute calls or alarms

Double-tap the phone.

Reject a call or snooze an alarm after

muting it

Double-tap the phone again.

Display the clock

Double-tap the phone.

If you have missed calls or received new

messages, you must view them before you

can see the clock.

Phone settings

Select Menu > Settings > Phone and

from the following:

Language settings

•to set the display language of your

phone, select Phone language. . To

set a language for the voice

commands, select Recognition

lang..

Memory status

•to check the memory consumption

Automatic keyguard

•to lock the keypad automatically after

a preset time when the phone is in the

standby mode and no function has

been used.

Security keyguard

•to ask for the security code when you

unlock the keyguard

Sensor settings

•to activate and adjust the tapping

function

Voice recognition

•See "Voice commands", p. 14.

Flight query

•to be asked whether to use the flight

mode when you switch the phone on.

10 Make it your phone

Cyan

Magenta

Yellow

Black

With the flight mode, all radio

connections are switched off.

Phone updates

•to receive software updates from your

service provider (network service).

This option may not be available,

depending on your phone. See

"Software updates over the

air", p. 41.

Network mode

•to use both the UMTS and the GSM

network. You cannot access this

option during an active call.

Operator selection

•to set a cellular network available in

your area

Help text activation

•to select whether the phone shows

help texts

Start-up tone

•to play a tone when you switch the

phone on

Confirm SIM actions

•See "SIM services", p. 17.

Security settings

When security features that restrict calls

are in use (such as call barring, closed user

group, and fixed dialling), calls may be

possible to the official emergency number

programmed into your device.

Select Menu > Settings > Security and

from the following:

PIN code request or UPIN code request

•to request for your PIN or UPIN code

every time the phone is switched on.

Some SIM cards do not allow the code

request to be turned off.

PIN2 code request

•to select whether the PIN2 code is

required when using a specific phone

feature which is protected by the PIN2

code. Some SIM cards do not allow the

code request to be turned off.

Call barring service

•to restrict incoming calls to and

outgoing calls from your phone

(network service). A barring password

is required.

Fixed dialling

•to restrict your outgoing calls to

selected phone numbers if supported

by your SIM card. When the fixed

dialling is on, GPRS connections are

not possible except while sending

text messages over a GPRS

connection. In this case, the

recipient’s phone number and the

message centre number must be

included in the fixed dialling list.

Closed user group

•to specify a group of people whom

you can call and who can call you

(network service)

Security level

•To request the security code when a

new SIM card is inserted, select

Phone. To request the security code

when the SIM card memory is

Make it your phone 11

Cyan

Magenta

Yellow

Black

selected, and you want to change the

memory in use, select Memory.

Access codes

•to change the security code, PIN code,

UPIN code, PIN2 code, or barring

password

Code in use

•to select whether the PIN code or UPIN

code should be active

Authority certificates or User

certificates

•to view the list of the authority or user

certificates downloaded into your

phone. See "Browser

security", p. 32.

Security module sett.

•to view security module details,

activate the module PIN request, or

change the module PIN and signing

PIN. See "Access codes", p. 7.

Personalise your phone

Give your phone a personal touch with

ringing tones, display backgrounds, and

themes. Add shortcuts for your preferred

features, and attach enhancements.

Profiles

Your phone has various setting groups

called profiles, which you can customise

with ringing tones for different events

and environments.

Select Menu > Settings > Profiles, the

desired profile, and from the following

options:

Activate

•to activate the selected profile

Personalise

•to change the profile settings

Timed

•to set the profile to be active for a

certain time. When the time set for

the profile expires, the previous

profile that was not timed becomes

active.

Themes

A theme contains elements for

personalising your phone.

Select Menu > Settings > Themes and

from the following options:

Select theme

•Open the Themes folder, and select a

theme.

Theme downloads

•Open a list of links to download more

themes.

Tones

You can change the tone settings of the

selected active profile.

Select Menu > Settings > Tones. You can

find the same settings in the Profiles

menu.

If you select the highest ringing tone level,

the ringing tone reaches its highest level

after a few seconds.

12 Make it your phone

Cyan

Magenta

Yellow

Black

Lights

To activate or deactivate light effects

associated with different phone

functions, select Menu > Settings >

Lights.

Display

Select Menu > Settings > Display and

from the available options:

Wallpaper

•to add a background image for the

standby mode

Active standby

•to activate, organise, and personalise

the active standby mode

Standby font colour

•to select the font colour for the

standby mode

Navigation key icons

•to display the icons of the scroll key

shortcuts in the standby mode when

active standby is off

Notification details

•to display details in missed call and

message notifications

Transition effects

•to activate a smoother and more

organic navigation experience

Slide animation

•to display an animation and sound a

tone when you open or close the slide

Screen saver

•to create and set a screen saver

Power saver

•to dim the display automatically and

to display a clock when the phone is

not used for a certain time

Sleep mode

•to switch off the display automatically

when the phone is not used for a

certain time

Font size

•to set the font size for messaging,

contacts, and web pages

Operator logo

•to display the operator logo

Cell info display

•to display the cell identity, if available

from the network

My shortcuts

With personal shortcuts, you get quick

access to frequently used functions of

your phone.

Left and right selection keys

•To change the function assigned to

the left or right selection key, select

Menu > Settings > My shortcuts >

Left selection key or Right selection

key and the function.

In the standby mode, if the left selection

key is Go to, to activate a function, select

Go to > Options and from the following:

Select options

•to add or remove a function

Make it your phone 13

Cyan

Magenta

Yellow

Black

Organise

•to rearrange the functions

Other shortcuts

Select Menu > Settings > My shortcuts

and from the following options:

Navigation key

•to assign other functions from a

predefined list to the navigation key

(scroll key).

Active standby key

•to select the movement of the

navigation key to activate the active

standby mode

Assign dialling shortcuts

Create shortcuts by assigning phone

numbers to the number keys 3-9.

1 Select Menu > Contacts > Speed

dials, and scroll to a number key.

2 Select Assign, or, if a number has

already been assigned to the key,

select Options > Change.

3 Enter a number or search for a

contact.

Voice commands

Call contacts and use your phone by

speaking a voice command.

Voice commands are language-

dependent.

•To set the language, select Menu >

Settings > Phone > Language

settings > Recognition lang. and

your language.

•To train the voice recognition to your

voice, select Menu > Settings >

Phone > Voice recognition > Voice

recog. training.

•To activate a voice command for a

function, select Menu > Settings >

Phone > Voice recognition > Voice

commands, a feature, and the

function. indicates that the voice

command is activated.

•To activate the voice command, select

Add.

•To play the activated voice command,

select Play.

To use voice commands, see "Voice

dialling", p. 19.

To manage the voice commands, scroll to

a function, select Options and from the

following:

Edit or Remove

•to rename or deactivate the voice

command

Add all or Remove all

•to activate or deactivate voice

commands for all functions in the

voice commands list

Connect

Your phone provides several features to

connect to other devices to transmit and

receive data.

Bluetooth wireless technology

Bluetooth technology allows you to

connect your phone, using radio waves, to

14 Make it your phone

Cyan

Magenta

Yellow

Black

a compatible Bluetooth device within 10

metres (32 feet).

This device is compliant with Bluetooth

Specification 2.0 + EDR supporting the

following profiles: 2.0 + EDRgeneric

access, network access, generic object

exchange, advanced audio distribution,

audio video remote control, handsfree,

headset, object push, file transfer, dial-up

networking, service discovery application,

SIM access, and serial port. To ensure

interoperability between other devices

supporting Bluetooth technology, use

Nokia approved enhancements for this

model. Check with the manufacturers of

other devices to determine their

compatibility with this device.

Features using Bluetooth technology

increase the demand on battery power

and reduce the battery life.

Set up a Bluetooth connection

Select Menu > Settings >

Connectivity > Bluetooth and take the

following steps:

1 Select My phone's name and enter a

name for your phone.

2 To activate Bluetooth connectivity

select Bluetooth > On. indicates

that Bluetooth is active.

3 To connect your phone with an audio

enhancement, select Connect audio

enhan. and the device that you want

to connect to.

4 To pair your phone with any

Bluetooth device in range, select

Paired devices > Add new device.

Scroll to a found device, and select

Add.

Enter a passcode (up to 16 characters)

on your phone and allow the

connection on the other Bluetooth

device.

If you are concerned about security, turn

off the Bluetooth function, or set My

phone's visibility to Hidden. Accept

Bluetooth communication only from

those you trust.

PC connection to the internet

Use Bluetooth technology to connect your

compatible PC to the internet without PC

Suite software. Your phone must have

activated a service provider that supports

internet access, and your PC has to support

Bluetooth personal area network (PAN).

After connecting to the network access

point (NAP) service of the phone, and

pairing with your PC, your phone

automatically opens a packet data

connection to the internet.

Packet data

General packet radio service (GPRS) is a

network service that allows mobile

phones to send and receive data over an

internet protocol (IP)-based network.

To define how to use the service, select

Menu > Settings > Connectivity >

Packet data > Packet data conn. and

from the following options:

When needed

•to set the packet data connection to

established when required by an

application. The connection will be

cut when the application is closed.

Make it your phone 15

Cyan

Magenta

Yellow

Black

Always online

•to automatically connect to a packet

data network when you switch the

phone on

You can use your phone as a modem by

connecting it to a compatible PC using

Bluetooth technology or a USB data cable.

For details, see Nokia PC Suite

documentation. See "Nokia

support", p. 39.

USB data cable

You can use the USB data cable to transfer

data between the phone and a compatible

PC or a printer supporting PictBridge.

To activate the phone for data transfer or

image printing, connect the data cable

and select the mode:

PC Suite

•to use the cable for Nokia PC Suite

Printing & media

•to use the phone with a PictBridge

compatible printer or with a

compatible PC

Data storage

•to connect to a PC that does not have

Nokia software and use the phone as

data storage

•To change the USB mode, select

Menu > Settings > Connectivity >

USB data cable and the desired USB

mode.

Synchronisation and backup

Select Menu > Settings > Sync and

backup and from the following:

Phone switch

•Synchronise or copy selected data

between your phone and another

phone using Bluetooth technology.

Create backup

•Create a backup of selected data to the

memory card or to an external device.

Restore backup

•Select a backup file stored on the

memory card or on an external device

and restore it to the phone. Select

Options > Details for information

about the selected backup file.

Data transfer

•Synchronise or copy selected data

between your phone and another

device, PC, or network server

(network service).

Connect a USB device

You can connect a USB storage (for

example, a memory stick) to your device

and browse in the file system and transfer

files.

1 Connect a compatible adapter cable to

the USB port of your device.

2 Connect the USB storage to the

adapter cable.

3 Select Menu > Gallery and the USB

device to browse.

Note: Not all USB storage devices are

supported, depending on their power

consumption.

16 Make it your phone

Cyan

Magenta

Yellow

Black

Network provider services

Your network provider provides several

additional services you may want to use.

For some of these services, charges may

apply.

Operator menu

Access a portal to services provided by

your network operator. For more

information, contact your network

operator. The operator can update this

menu with a service message.

SIM services

Your SIM card may provide additional

services. You can access this menu only if

it is supported by your SIM card. The name

and contents of the menu depend on the

available services.

•To show the confirmation messages

sent between your phone and the

network when you are using the SIM

services, select Menu > Settings >

Phone > Confirm SIM actions.

Accessing these services may involve

sending messages or making a phone call

for which you may be charged.

Position log

The network may send you a position

request (network service). To subscribe

and agree upon the delivery of

positioning information, contact your

service provider.

•To accept or reject the position

request, select Accept or Reject. If

you miss the request, the phone

automatically accepts or rejects it

according to what you have agreed

with your network operator or service

provider.

•To view the information on the 10

most recent privacy notifications and

requests, select Menu > Log >

Positioning > Position log.

Info messages, SIM messages, and

service commands

Info messages

You can receive messages on various

topics from your service provider

(network service). For more information,

contact your service provider.

•Select Menu > Messaging > Info

messages and from the available

options.

Service commands

Service commands allow you to write and

send service requests (USSD commands)

to your service provider, such as activation

commands for network services.

•To write and send the service request,

select Menu > Messaging > Serv.

commands. For details, contact your

service provider.

SIM messages

SIM messages are specific text messages

that are saved to your SIM card. You can

copy or move those messages from the

SIM to the phone memory, but not vice

versa.

•To read SIM messages, select Menu >

Messaging > Options > SIM

messages.

Configuration

You can configure your phone with

settings that are required for certain

services. You may receive these settings as

Make it your phone 17

Cyan

Magenta

Yellow

Black

a configuration message from your

service provider.See "Configuration

setting service", p. 41.

Select Menu > Settings >

Configuration and from the following:

Default config. sett.

•to view the service providers saved in

the phone, and to set a default service

provider

Act. def. in all apps.

•to activate the default configuration

settings for supported applications

Preferred access pt.

•to view the saved access points

Connect to support

•to download the configuration

settings from your service provider

Device manager sett.

•to allow or prevent the phone from

receiving software updates. This

option may not be available,

depending on your phone. See

"Software updates over the

air", p. 41.

Personal config. sett.

•to manually add new personal

accounts for various services, and to

activate or delete them. To add a new

personal account, select Add, or

Options > Add new. Select the

service type, and enter the required

parameters. To activate a personal

account, scroll to it, and select

Options > Activate.

Want to talk, chat or send

messages? Making calls and

sending messages is at the

heart of what a phone's all

about.

Stay in touch

Make calls

Make a voice call

You can start a call in several ways:

Manual dialling

Enter the phone number, including the

area code, and press the call key.

For international calls, press * twice for

the international prefix (the + character

replaces the international access code),

enter the country code, the area code

without the leading 0, if necessary, and

the phone number.

Repeat a call

To access the list of dialled numbers, press

the call key once in the standby mode.

Select a number or name, and press the

call key.

Select a number from Contacts

Search for a name or phone number that

you saved in Contacts.

Select Menu > Settings > Call > Slide

call handling to handle calls with the

slide.

18 Stay in touch

Cyan

Magenta

Yellow

Black

Answer an incoming call

Press the call key, or open the slide.

End a call

Press the end key, or close the slide.

Mute the ringing tone

Select Silence.

Reject an incoming call

Press the end key.

Adjust the volume in a call

Scroll left or right.

Make a video call

In a video call, the video recorded with the

front camera on your phone is shown to

the video call recipient. To make a video

call, you must have a USIM card and be

connected to a WCDMA network. For

availability and subscription to video call

services, contact your service provider.

The video call can be made to a

compatible phone or an ISDN client

between two parties. Video calls cannot

be made while another voice, video, or

data call is active.

1 To start a video call, enter the phone

number, including the area code.

2 Press and hold the call key, or select

Options > Video call.

Starting a video call may take a while.

If the call is not successful, you are

asked to try a voice call or send a

message instead.

3 To end the call, press the end key.

Dialling shortcuts

First assign a phone number to one of the

number keys, 2 to 9. See "Assign dialling

shortcuts", p. 14.

Use a dialling shortcut to make a call in

one of the following ways:

•Press a number key, then the call key.

•If Menu > Settings > Call > Speed

dialling > On is selected, press and

hold a number key.

Voice dialling

Make a phone call by saying the name that

is saved in Contacts.

As voice commands are language-

dependent, before voice dialling, you

must select Menu > Settings > Phone >

Language settings > Recognition

lang. and your language.

Note: Using voice tags may be difficult

in a noisy environment or during an

emergency, so you should not rely solely

upon voice dialling in all circumstances.

1 In the standby mode, press and hold

the right selection key. A short tone

sounds, and Speak now is displayed.

2 Say the name of the contact you want

to dial. If the voice recognition is

successful, a list with matches is

shown. The phone plays the voice

command of the first match on the

list. If it is not the correct command,

scroll to another entry.

Options during a call

Many of the options that you can use

during a call are network services. For

availability, contact your service provider.

Stay in touch 19

Cyan

Magenta

Yellow

Black

During a call, select Options and from the

available options.

Some of the network options are Hold,

New call, Add to conference, End all

calls, and the following:

Send DTMF

•to send tone strings

Swap

•to switch between the active call and

the call on hold

Transfer

•to connect a call on hold to an active

call and disconnect yourself

Conference

•to make a conference call

Private call

•to have a private discussion in a

conference call

Warning: Do not hold the device near

your ear when the loudspeaker is in use,

because the volume may be extremely

loud.

Voice messages

The voice mailbox is a network service to

which you may need to subscribe. For

more information, contact your service

provider.

Call your voice mailbox

Press and hold 1.

Edit your voice mailbox number

Select Menu > Messaging > Voice

messages > Voice mailbox no..

Video messages

The video mailbox is a network service to

which you may need to subscribe. For

more information, contact your service

provider.

Call your video mailbox

Press and hold 2.

Edit your video mailbox number

Select Menu > Messaging > Video

messages > Voice mailbox no..

Call log

To view the information on your calls,

messages, data, and synchronisation,

select Menu > Log and from the available

options.

Note: The actual invoice for calls and

services from your service provider may

vary, depending on network features,

rounding off for billing, taxes, and so

forth.

Call settings

Select Menu > Settings > Call and from

the following:

Call divert

•to forward your incoming calls

(network service). You may not be

able to forward your calls if some call

barring functions are active.

20 Stay in touch

Cyan

Magenta

Yellow

Black

Anykey answer

•to answer an incoming call by briefly

pressing any key, except the power

key, the left and right selection keys,

or the end key

Automatic redial

•to automatically redial the number if

a call fails. The phone tries to call the

number 10 times.

Video-voice redial

•the phone automatically repeats a

voice call to the same number to

which a video call has failed

Voice clarity

•to enhance speech intelligibility,

especially in noisy environments

Speed dialling

•to dial the names and phone numbers

assigned to the number keys (2 to 9)

by pressing and holding the

corresponding number key

Call waiting

•to have the network notify you of an

incoming call while you have a call in

progress (network service)

Summary after call

•to briefly display the approximate

duration after each call

Send my caller ID

•to show your phone number to the

person you are calling (network

service). To use the setting agreed

upon with your service provider,

select Set by network.

Slide call handling

•to set the phone to answer calls when

you open the slide and to end calls

when you close the slide

Outgoing call line

•to select the phone line for making

calls, if your SIM card supports

multiple phone lines (network

service)

Video sharing

•to define video sharing settings

Text and messages

Write text, and create messages, e-mail,

and notes.

Write text

Text modes

To enter text (for example, when writing

messages) you can use traditional or

predictive text input.

•When you write text, press and hold

Options to switch between

traditional text input, indicated by

, and predictive text input,

indicated by . Not all languages

are supported by predictive text

input.

The character cases are indicated by ,

, and .

•To change the character case, press

#. To change from the letter to

number mode, indicated by ,

press and hold #, and select Number

mode. To change from the number to

the letter mode, press and hold #.

Stay in touch 21

Cyan

Magenta

Yellow

Black

•To set the writing language, select

Options > Writing language.

Traditional text input

•Press a number key, 2-9, repeatedly

until the desired character appears.

The available characters depend on

the selected writing language.

•If the next letter you want is located

on the same key as the present one,

wait until the cursor appears, and

enter the letter.

•To access the most common

punctuation marks and special

characters, press 1 repeatedly. To

access the list of special characters,

press *.

Predictive text input

Predictive text input is based on a built-in

dictionary to which you can also add new

words.

1 Start writing a word, using the keys

2 to 9. Press each key only once for

one letter.

2 To confirm a word, scroll right or add

a space.

•If the word is not correct, press *

repeatedly, and select the word

from the list.

•If the ? character is displayed after

the word, the word you intended

to write is not in the dictionary.

To add the word to the dictionary,

select Spell. Enter the word using

traditional text input, and select

Save.

•To write compound words, enter

the first part of the word, and

scroll right to confirm it. Write the

last part of the word, and confirm

the word.

3 Start writing the next word.

Text and multimedia messages

You can create a message and optionally

attach, for example, a picture. Your phone

automatically changes a text message to

a multimedia message when a file is

attached.

Text messages

Your device supports text messages

beyond the limit for a single message.

Longer messages are sent as two or more

messages. Your service provider may

charge accordingly. Characters with

accents or other marks, and characters

from some language options, take up

more space, and limit the number of

characters that can be sent in a single

message.

An indicator at the top of the display

shows the total number of characters left

and the number of messages needed for

sending.

Before you can send any text or SMS e-mail

messages, you must save your message

centre number. Select Menu >

Messaging > Message settings > Text

messages > Message centres > Add

centre, enter a name, and the number

from the service provider.

Multimedia messages

A multimedia message can contain text,

pictures, and sound or video clips.

Only devices that have compatible

features can receive and display

multimedia messages. The appearance of

22 Stay in touch

Cyan

Magenta

Yellow

Black

a message may vary depending on the

receiving device.

The wireless network may limit the size of

MMS messages. If the inserted picture

exceeds this limit the device may make it

smaller so that it can be sent by MMS.

Important: Exercise caution when

opening messages. Messages may contain

malicious software or otherwise be

harmful to your device or PC.

For availability and subscription to the

multimedia messaging service (MMS),

contact your service provider. You may

also download the configuration settings.

See "Nokia support", p. 39.

Create a text or multimedia message

1 Select Menu > Messaging > Create

message > Message.

2 To add recipients, scroll to the To:

field, and enter the recipient’s

number or e-mail address, or select

Add to select recipients from the

available options. Select Options to

add recipients and subjects and to set

sending options.

3 Scroll to the Text: field, and enter the

message text.

4 To attach content to the message,

scroll to the attachment bar at the

bottom of the display and select the

desired type of content.

5 To send the message, press Send.

The message type is indicated at the top

of the display and changes automatically

depending on the content of the message.

Service providers may charge differently

depending on the message type. Check

with your service provider for details.

Read a message and reply

Important: Exercise caution when

opening messages. Messages may contain

malicious software or otherwise be

harmful to your device or PC.

Your phone issues a notification when you

receive a message. Select View to display

the message. If more than one message

was received, to display a message, select

the message from the Inbox and Open.

Use the scroll key to view all parts of the

message.

To create an answer message, select

Reply.

Send and organise messages

•To send a message, select Send. The

phone saves the message in the

Outbox folder, and the sending starts.

Note: The message sent icon or text

on your device screen does not indicate

that the message is received at the

intended destination.

If message sending is interrupted, the

phone tries to resend the message a few

times. If these attempts fail, the message

remains in the Outbox folder. To cancel

message sending, in the Outbox folder,

select Options > Cancel sending.

•To save the sent messages in the Sent

items folder, select Menu >

Messaging > Message settings >

General settings > Save sent

messages.

The phone saves received messages in the

Inbox folder. Organise your messages in

the Saved items folder.

Stay in touch 23

Cyan

Magenta

Yellow

Black

•To add, rename, or delete a folder,

select Menu > Messaging > Saved

items > Options.

E-mail

Access your POP3 or IMAP4 e-mail account

with your phone to read, write, and send

e-mail. This e-mail application is different

from the SMS e-mail function.

Before you can use e-mail, you must have

an e-mail account and the correct settings.

For availability and the correct settings,

contact your e-mail service provider. You

may receive the e-mail configuration

settings as a configuration message. See

"Configuration setting service", p. 41.

E-mail setup wizard

The e-mail setup wizard starts

automatically if no e-mail settings are

defined in the phone. To start the setup

wizard for an additional e-mail account,

select Menu > Messaging and the

existing e-mail account. Select Options >

Add mailbox to start the e-mail setup

wizard. Follow the instructions on the

display.

Write and send an e-mail

You may write your e-mail before

connecting to the e-mail service.

1 Select Menu > Messaging > Create

message > E-mail message.

2 If more than one e-mail account is

defined, select the account from

which you want to send the e-mail.

3 Enter the recipient’s e-mail address,

the subject, and the e-mail message.

To attach a file, select Options >

Insert and from the available options.

4 To send the e-mail, select Send.

Read an e-mail and reply

Important: Exercise caution when

opening messages. Messages may contain

malicious software or otherwise be

harmful to your device or PC.

1 To download e-mail message

headers, select Menu > Messaging

and your e-mail account.

2 To download an e-mail and its

attachments, select the e-mail and

Open or Retrieve.

3 To reply to or forward the e-mail,

select Options and from the available

options.

4 To disconnect from your e-mail

account, select Options >

Disconnect. The connection to the e-

mail account automatically ends after

some time without activity.

New e-mail notifications

Your phone can automatically check your

e-mail account in time intervals and issue

a notification when new e-mail is

received.

1 Select Menu > Messaging >

Message settings > E-mail

messages > Edit mailboxes.

2 Select your e-mail account,

Downloading sett., and the

following options:

Mailbox upd. interval

•to set how often your phone

checks your e-mail account for

new e-mail

24 Stay in touch

Cyan

Magenta

Yellow

Black

Automatic retrieval

•to retrieve new e-mail

automatically from your e-mail

account

3 To enable the new e-mail notification,

select Menu > Messaging >

Message settings > E-mail

messages > New e-mail notif. >

On.

Flash messages

Flash messages are text messages that are

instantly displayed upon reception.

1 To write a flash message, select

Menu > Messaging > Create

message > Flash message.

2 Enter the recipient’s phone number,

write your message (maximum 70

characters), and select Send.

Instant messaging

With instant messaging (IM, network

service) you can send short text messages

to online users. You must subscribe to a

service and register with the IM service

you want to use. Check the availability of

this service, pricing, and instructions with

your service provider. The menus may

vary depending on your IM provider.

To connect to the service, select Menu >

I M and follow the instructions on the

display.

Nokia Xpress audio messages

Create and send an audio message using

MMS in a convenient way.

1 Select Menu > Messaging > Create

message > Audio message. The

voice recorder opens.

2 Record your message. See "Voice

recorder", p. 31.

3 Enter one or more phone numbers in

the To: field, or select Add to retrieve

a number.

4 To send the message, select Send.

Message settings

Select Menu > Messaging > Message

settings and from the following:

General settings

•to save copies of sent messages in

your phone, to overwrite old

messages if the message memory

becomes full, and to set up other

preferences related to messages

Text messages

•to allow delivery reports, to set up

message centres for SMS and SMS e-

mail, to select the type of character

support, and to set up other

preferences related to text messages

Multimedia messages

•to allow delivery reports, to set up the

appearance of multimedia messages,

to allow the reception of multimedia

messages and advertisements, and to

set up other preferences related to

multimedia messages

Service messages

•to activate service messages and to

set up preferences related to service

messages

Stay in touch 25

Cyan

Magenta

Yellow

Black

Where’s that picture? Store

your high-resolution

pictures and video clips in

the phone’s gallery, or share

them via the new image

upload service.

Image and video

Capture an image

Activate the still camera

Select Menu > Media > Camera; or, if the

video function is on, scroll left or right.

Zooming

In the camera mode, scroll up and down.

Capture an image

Select Capture. The phone saves the

images on the memory card, if available,

or in the phone memory.

•Select Options > Flash on to capture

all images with camera flash, or

Automatic to activate the flash

automatically when the light

conditions are dim.

Keep a safe distance when using the

flash. Do not use the flash on people

or animals at close range. Do not cover

the flash while taking a picture.

•To display an image immediately

after you take it, select Options >

Settings > Image preview time and

the preview time. During the preview

time, select Back to capture another

image, or Send to send the image as

a multimedia message.

Your device supports an image capture

resolution of 2048x1536 pixels .

Record a video clip

Activate video function

Select Menu > Media > Video, or, if the

camera function is on, scroll left or right.

Video recording

To start recording, select Record; to pause

recording, select Pause; to resume

recording, select Continue; to stop

recording, select Stop.

The phone saves the video clips on the

memory card, if available, or in the phone

memory.

Camera and video options

In the camera or video mode, select

Options and from the following:

Effects

•Apply different effects (for example,

greyscale and false colour) to the

captured image.

White balance

•Adapt the camera to the current light

conditions.

Settings

•Change other camera and video

settings, and select the image and

video storage.

26 Image and video

Cyan

Magenta

Yellow

Black

Gallery

Manage images, video clips, music files,

themes, graphics, tones, recordings, and

received files. These files are stored in the

phone memory or an attached memory

card and may be arranged in folders.

Your phone supports an activation key

system to protect acquired content.

Always check the delivery terms of any

content and activation key before

acquiring them, because they may be

subject to a fee.

Folders and files

•To view the list of folders, select

Menu > Gallery.

•To view the list of files in a folder,

select a folder and Open.

•To view the folders of the memory

card when moving a file, scroll to the

memory card, and press the scroll key

right.

Memory card

Use a memory card to store your

multimedia files, such as video clips,

music tracks, sound files, images, and

messaging data.

Some of the folders in Gallery with

content that the phone uses (for example,

Themes) may be stored on the memory

card.

Format the memory card

Some supplied memory cards are

preformatted; others require formatting.

When you format a memory card, all data

on the card is permanently lost.

1 To format a memory card, select

Menu > Gallery or Applications, the

memory card folder , and

Options > Format mem. card >

Yes.

2 When formatting is complete, enter a

name for the memory card.

Lock the memory card

•To set a password (maximum 8

characters) to lock your memory card

against unauthorised use, select the

memory card folder and

Options > Set password.

The password is stored in your phone, and

you do not have to enter it again while you

are using the memory card on the same

phone. If you want to use the memory

card on another device, you are asked for

the password.

•To remove the password, select

Options > Delete password.

Check memory consumption

•To check the memory consumption of

different data groups and the

available memory to install new

software on your memory card, select

the memory card and Options >

Details.

Print images

Your phone supports Nokia XpressPrint to

print images that are in the JPEG format.

1 Connect your phone with a USB data

cable to a compatible printer.

2 Select the image you want to print

and Options > Print.

Image and video 27

Cyan

Magenta

Yellow

Black

Share images and videos online

Share images and video clips in

compatible online sharing services on the

web.

To use online sharing, you must subscribe

to an online sharing service.

To upload an image or a video clip to an

online sharing service, select the file from

Gallery and Options > Send > Upload to

web.

For more information on online sharing

and compatible service providers, see the

Nokia product support pages or your local

Nokia website.

Want a little relaxation at

the end of the day? Simply

transfer your favourite

music and MP3 files to your

phone’s music player.

Entertainment

Listen to music

Listen to music with the music player or

radio, and record sounds or voice with the

voice recorder. Download music from the

internet, or transfer music from your PC.

Music player

Your phone includes a music player for

listening to songs or other MP3 or AAC

sound files that you have downloaded

from the web or transferred to the phone

with Nokia PC Suite. See "Nokia PC

Suite", p. 38. You can also view your

recorded or downloaded video clips.

Music and video files stored in the music

folder in the phone memory or on the

memory card are automatically detected

and added to the music library.

To open the music player, select Menu >

Media > Music player.

Music menu

Access your music and video files stored in

the phone or on the memory card,

download songs or video clips from the

web, or view compatible video streams

from a network server (network service).

•To listen to music or play a video clip,

select a file from a folder and Play.

28 Entertainment

Cyan

Magenta

Yellow

Black

•To download files from the web,

select Options > Downloads and a

download site.

•To update the music library after you

have added songs, select Options >

Update library.

Create a playlist

To create a playlist with your selection of

music:

1 Select Playlists > Create playlist,

and enter the name of the playlist.

2 Add songs or video clips from the

displayed lists.

3 Select Done to store the playlist.

Configure a streaming service

You may receive the streaming settings as

a configuration message from the service

provider.See "Configuration setting

service", p. 41. You can also enter the

settings manually. See

"Configuration", p. 17.

To activate the settings:

1 Select Options > Downloads >

Streaming settings >

Configuration.

2 Select a service provider, Default, or

Personal config. for streaming.

3 Select Account and a streaming

service account from the active

configuration settings.

Play songs

Warning: Listen to music at a

moderate level. Continuous exposure to

high volume may damage your hearing.

Do not hold the device near your ear when

the loudspeaker is in use, because the

volume may be extremely loud.

Operate the music player with the virtual

keys on the display.

Start playing

Select .

Pause playing

Select .

Adjust the volume

Press the scroll key up or down.

Skip to the next song

Select .

Skip to the beginning of the previous

song

Select twice

Fast-forward

Select and hold .

Rewind

Select and hold .

Close the music player menu

Press the end key. The music continues

playing.

Stop the music player

Press and hold the end key.

Entertainment 29

Cyan

Magenta

Yellow

Black

Change the music player look

Your phone provides several themes to

change the look of the music player.

Select Menu > Media > Music player >

Go to Music player > Options >

Settings > Music player theme and one

of the listed themes. The virtual keys may

change depending on the theme.

Radio

The FM radio depends on an antenna other

than the wireless device antenna. A

compatible headset or enhancement

needs to be attached to the device for the

FM radio to function properly.

Warning: Listen to music at a

moderate level. Continuous exposure to

high volume may damage your hearing.

Do not hold the device near your ear when

the loudspeaker is in use, because the

volume may be extremely loud.

Select Menu > Media > Radio.

To adjust the volume, select Options >

Volume.

To use the graphical keys , , , or

on the display, scroll up, down, left, or

right.

Tune radio stations

1 To start the search, select and hold

or . To change the radio

frequency in 0.05 MHz steps, briefly

select or .

2 To save a station to a memory

location, select Options > Save

station.

3 To enter the name of the radio

station, select Options > Stations >

Options > Rename.

Select Options and from the following:

Search all stations

•to automatically search for the

available stations at your location

Set frequency

•to enter the frequency of the desired

radio station

Stations

•to list and rename or delete saved

stations

•To change stations, select or , or

press the number keys corresponding

to the number of the station in the

station list.

Radio features

To switch off the radio, swap between

headset and loudspeaker, and switch

between stereo and mono output, select

Options > Settings. To display

information from the radio data system of

the tuned in station, select RDS on. To

enable the automatic switch to a

frequency with the best reception of the

tuned in station, select Auto-freq.

change on.

Equaliser

Adjust the sound when using the music

player.

Select Menu > Media > Equaliser.

30 Entertainment

Cyan

Magenta

Yellow

Black

•To activate a predefined equaliser set,

scroll to one of the sets, and select

Activate.

Create a new equaliser set

1 Select one of the last two sets in the

list and Options > Edit.

2 Scroll left or right to access the virtual

sliders and up or down to adjust the

slider.

3 To save the settings and create a

name for the set, select Save and

Options > Rename.

Stereo widening

Stereo widening creates a wider stereo

sound effect when you are using a stereo

headset.

•To activate, select Menu > Media >

Stereo widening.

Voice recorder

Record speech, sound, or an active call,

and save them in Gallery.

Select Menu > Media > Voice recorder.

To use the graphical keys , , or

on the display, scroll left or right.

Record sound

1 Select , or, during a call, select

Options > Record. While recording a

call, all parties to the call hear a faint

beeping. To pause the recording,

select .

2 To end the recording, select . The

recording is saved in the Recordings

folder in Gallery.

Select Options to play or send the last

recording, to access the list of recordings,

or to select the memory and the folder to

store the recordings.

Web

You can access various internet services

with your phone browser. The appearance

of the internet pages may vary due to

screen size. You may not be able to see all

the details on the internet pages.

Important: Use only services that you

trust and that offer adequate security and

protection against harmful software.

For the availability of these services,

pricing, and instructions, contact your

service provider.

You may receive the configuration

settings required for browsing as a

configuration message from your service

provider.

To set up the service, select Menu >

Web > Web settings > Configuration

sett., a configuration, and an account.

Connect to a service

Connect to the web service

Select Menu > Web > Home; or in the

standby mode, press and hold 0.

Show list of bookmarks

Select Menu > Web > Bookmarks.

Connect to the web address used the

last time

Select Menu > Web > Last web addr..

Entertainment 31

Cyan

Magenta

Yellow

Black

Enter a web address and connect to it

Select Menu > Web > Go to address.

Enter the address, and select OK.

After you make a connection to the

service, you can start browsing its pages.

The function of the phone keys may vary

in different services. Follow the text

guides on the phone display. For more

information, contact your service

provider.

Appearance settings

While browsing the web, select

Options > Settings. The available

options may include the following:

Display

•Select the font size, whether images

are shown, and how the text is

displayed.

General

•Select whether web addresses are

sent as Unicode (UTF-8), the encoding

type for the contents, and whether

JavaScript is enabled.

Cache memory

A cache is a memory location that is used

to store data temporarily. If you have tried

to access or have accessed confidential

information requiring passwords, empty

the cache after each use. The information

or services you have accessed are stored

in the cache.

A cookie is data that a site saves in the

cache memory of your phone. Cookies are

saved until you clear the cache memory.

1 To clear the cache while browsing,

select Options > Tools > Clear the

cache.

2 To allow or prevent the phone from

receiving cookies, select Menu >

Web > Web settings > Security >

Cookies; or, while browsing, select

Options > Settings > Security >

Cookies.

Browser security

Security features may be required for

some services, such as banking services or

online shopping. For such connections

you need security certificates and possibly

a security module which may be available

on your SIM card. For more information,

contact your service provider.

To view or change the security module

settings, or to view a list of authority or

user certificates downloaded to your

phone, select Menu > Settings >

Security > Security module sett.,

Authority certificates, or User

certificates.

Important: Even if the use of

certificates makes the risks involved in

remote connections and software

installation considerably smaller, they

must be used correctly in order to benefit

from increased security. The existence of

a certificate does not offer any protection

by itself; the certificate manager must

contain correct, authentic, or trusted

certificates for increased security to be

available. Certificates have a restricted

lifetime. If "Expired certificate" or

"Certificate not valid yet" is shown, even if

the certificate should be valid, check that

the current date and time in your device

are correct.

32 Entertainment

Cyan

Magenta

Yellow

Black

Games and applications

You can manage applications and games.

Your phone may have some games or

applications installed. These files are

stored in the phone memory or an

attached memory card and may be

arranged in folders.

Launch an application

Select Menu > Applications > Games,

Memory card, or Collection. Scroll to a

game or an application, and select Open.

To set sounds, lights, and shakes for a

game, select Menu > Applications >

Options > Application settings.

Other available options may include the

following:

Update version

•to verify that a new version of the

application is available for download

from the web (network service)

Web page

•to provide further information or

additional data for the application

from an internet page (network

service), if available

Application access

•to restrict the application from

accessing the network

Download an application

Your phone supports J2ME Java

applications. Ensure that the application

is compatible with your phone before

downloading it.

Important: Only install and use

applications and other software from

trusted sources, such as applications that

are Symbian Signed or have passed the

Java Verified™ testing.

You can download new applications and

games in different ways.

•Select Menu > Applications >

Options > Downloads > App.

downloads or Game downloads;

the list of available bookmarks is

shown.

•Use the Nokia Application Installer

from PC Suite to download the

applications to your phone.

For the availability of different services

and pricing, contact your service provider.

Entertainment 33

Cyan

Magenta

Yellow

Black

Looking up a route? Check

out points of interest along

the way, and select 2D or 3D

display.

Maps

You can browse maps for different cities

and countries, search for addresses and

points of interest, plan routes from one

location to another, save locations as

landmarks, and send them to compatible

devices.

Almost all digital cartography is

inaccurate and incomplete to some

extent. Never rely solely on the

cartography that you download for use in

this device.

To use the Maps application, select

Menu > Maps and from the available

options.

For detailed information about Maps, see

maps.nokia.com

Download maps

Your phone may contain pre-installed

maps on the memory card. You can

download a new set of maps through the

internet using Nokia Map Loader PC

software.

Nokia Map Loader

To download the Nokia Map Loader on

your PC and for further instructions, see

www.maps.nokia.com.

Before you download new maps for the

first time, ensure that you have a memory

card inserted in the phone,

•Select Menu > Maps to do an initial

configuration.

•To change the selection of maps on

your memory card, use the Nokia Map

Loader to delete all maps on the

memory card and download a new

selection, to ensure that all maps are

from the same release.

Network map service

You can set your phone to automatically

download maps that you do not have in

your phone when needed.

•Select Menu > Maps > Settings >

Network settings > Allow network

usage > Yes or In home network.

•To prevent automatic download of

maps, select No.

Downloading maps may involve the

transmission of large amounts of data

through your service provider’s network.

Contact your service provider for

information about data transmission

charges.

Maps and GPS

You can use the global positioning system

(GPS) to support the Maps application.

Find out your location, or measure

distances and coordinates.

Before you can use the GPS function with

your phone, you must pair your phone

with a compatible external GPS receiver

using Bluetooth wireless technology. For

34 Maps

Cyan

Magenta

Yellow

Black

more information, see the user guide for

your GPS device.

After pairing the Bluetooth GPS device

with the phone, it may take several

minutes for the phone to display the

current location. Subsequent connections

should be faster, but if you have not used

GPS for several days, or are very far away

from the last place you used it, it may take

several minutes to detect and display your

location.

The Global Positioning System (GPS) is

operated by the government of the United

States, which is solely responsible for its

accuracy and maintenance. The accuracy

of location data can be affected by

adjustments to GPS satellites made by the

United States government and is subject

to change with the United States

Department of Defense civil GPS policy and

the Federal Radionavigation Plan.

Accuracy can also be affected by poor

satellite geometry. Availability and

quality of GPS signals may be affected by

your location, buildings, natural

obstacles, and weather conditions. The

GPS receiver should only be used outdoors

to allow reception of GPS signals.

Any GPS should not be used for precise

location measurement, and you should

never rely solely on location data from the

GPS receiver and cellular radio networks

for positioning or navigation.

Extra services

You can upgrade Maps with a full voice-

guided navigation, which requires a

regional licence. To use this service, you

need a compatible external GPS device

that supports Bluetooth wireless

technology.

To purchase a navigation service with

voice guidance, select Menu > Maps >

Extra services > Purchase navigation,

and follow the instructions.

To use navigation with voice guidance,

you must allow the Maps application to

use a network connection.

The navigation licence is connected to

your SIM card. If you insert another SIM

card in your phone, you are asked to

purchase a licence when starting

navigation. During the purchase

procedure, you are offered to transfer the

existing navigation licence to the new SIM

card without extra charge.

Maps 35

Cyan

Magenta

Yellow

Black

Did you know that you can

manage your music,

contacts and calendars

between your phone and

your PC with Nokia PC Suite?

Organise

Let your phone help you to organise your

life.

Manage contacts

Save names, phone numbers, and

addresses as contacts in the phone and

SIM card memory.

•Select Menu > Contacts.

Select the memory for contacts

The phone memory can save contacts with

additional details, such as various phone

numbers and text items. You can also save

an image, a tone, or a video clip for a

limited number of contacts.

The SIM card memory can save names with

one phone number attached to them. The

contacts saved in the SIM card memory are

indicated by .

1 Select Settings > Memory in use to

select the SIM card, the phone

memory, or both for your contacts.

2 Select Phone and SIM to recall

contacts from both memories. When

you save contacts, they are saved in

the phone memory.

Handle contacts

Search for a contact

Menu > Contacts > Names

Scroll through the list of contacts, or enter

the first characters of the contact's name.

Save a name and phone number

Names > Options > Add new contact

Add and edit details

Select a contact, Details > Options >

Add detail and from the available

options.

Delete a detail

Select a contact and Details. Select a

detail and Options > Delete.

Delete a contact

Select a contact and Options > Delete

contact.

Delete all contacts

Menu > Contacts > Del. all contacts >

From phone memory or From SIM card.

Copy or move contacts between the

phone and SIM card memory

Single contact

Select the contact to copy or move and

Options > Copy contact or Move

contact.

Several contacts

Select Options > Mark.

36 Organise

Cyan

Magenta

Yellow

Black

Mark the contacts, and select Options >

Copy marked or Move marked.

All contacts

Select Menu > Contacts > Copy

contacts or Move contacts.

Create a contact group

Arrange contacts into caller groups with

different ringing tones and group images.

1 Select Menu > Contacts > Groups.

2 Select Add or Options > Add new

group to create a new group.

3 Enter the group name, optionally

select an image and a ringing tone,

and select Save.

4 Select the group and View > Add to

add contacts to the group.

Business cards

You can send and receive a person’s

contact information from a compatible

device that supports the vCard standard.

•To send a business card, search for the

contact, and select Details >

Options > Send business card.

•When you receive a business card,

select Show > Save to save the

business card in the phone memory.

Date and time

•To change the clock type, time, time

zone, or date, select Menu >

Settings > Date and time.

•When travelling to a different time

zone, select Menu > Settings > Date

and time > Date & time settings >

Time zone:, and scroll left or right to

select the time zone of your location.

The time and date are set according

to the time zone and enable your

phone to display the correct sending

time of received text or multimedia

messages.

For example, GMT -5 denotes the time

zone for New York (USA), 5 hours west of

Greenwich, London (UK).

Alarm clock

To sound an alarm at a desired time.

Set the alarm

1 Select Menu > Organiser > Alarm

clock.

2 Set the alarm on, and enter the alarm

time.

3 To issue an alarm on selected days of

the week, select Repeat: > On and

the days.

4 Select the alarm tone. If you select the

radio as the alarm tone, connect the

headset to the phone.

5 Set the snooze time-out, and select

Save.

Stop the alarm

•To stop the sounding alarm, select

Stop. If you let the alarm sound for a

minute or select Snooze, the alarm

stops for the snooze time-out, then

resumes.

Calendar

Select Menu > Organiser > Calendar.

The current day is framed. If there are any

notes set for the day, the day is in bold

type. To view the day notes, select View.

To view a week, select Options > Week

Organise 37

Cyan

Magenta

Yellow

Black

view. To delete all notes in the calendar,

select Options > Delete notes > All

notes.

To edit settings related to date and time,

select Options > Settings and from the

available options. To delete old notes

automatically after a specified time, select

Options > Settings > Auto-delete

notes and from the available options.

Make a calendar note

•Scroll to the date, and select

Options > Make a note. Select the

note type, and fill in the fields.

To-do list

To create a note for a task that you must

do, select Menu > Organiser > To-do

list.

•To create a note if no note is added,

select Add; otherwise, select

Options > Add. Fill in the fields, and

select Save.

•To view a note, scroll to it, and select

View.

Notes

To write and send notes, select Menu >

Organiser > Notes.

To make a note if no note is added, select

Add; otherwise, select Options > Make a

note. Write the note, and select Save.

Nokia PC Suite

With Nokia PC Suite, you can manage your

music, synchronise contacts, calendar,

notes, and to-do notes between your

phone and a compatible PC or a remote

internet server (network service). You may

find more information and PC Suite on the

Nokia website. See "Nokia

support", p. 39.

Calculator

Your phone provides a standard, a

scientific, and a loan calculator.

Select Menu > Organiser > Calculator

and, from the available options, the

calculator type and the operating

instructions.

This calculator has limited accuracy and is

designed for simple calculations.

Countdown timer

Normal timer

1 To activate the timer, select Menu >

Organiser > Countd. timer >

Normal timer, enter a time, and

write a note that is displayed when

the time expires. To change the time,

select Change time.

2 To start the timer, select Start.

3 To stop the timer, select Stop timer.

Interval timer

1 To have an interval timer with up to

10 intervals started, first enter the

intervals.

2 Select Menu > Organiser > Countd.

timer > Interval timer.

3 To start the timer, select Start

timer > Start.

To select how the interval timer should

start the next period, select Menu >

Organiser > Countd. timer >

Settings > Contin. to next period and

from the available options.

38 Organise

Cyan

Magenta

Yellow

Black

Stopwatch

You can measure time, take intermediate

times, or take lap times using the

stopwatch.

Select Menu > Organiser > Stopwatch

and from the following options:

Split timing

•to take intermediate times. To reset

the time without saving it, select

Options > Reset.

Lap timing

•to take lap times

Continue

•to view the timing that you have set

in the background

Show last

•to view the most recently measured

time if the stopwatch is not reset

View times or Delete times

•to view or delete the saved times

To set the stopwatch timing in the

background, press the end key.

Support and phone software

updates

Nokia helps you in many ways to gain the

most benefit from your phone.

Helpful hints

If you have queries about your phone, or

you are unsure how your phone should

function, see the user guide. If this does

not help, try the following:

Reset the phone

Switch off the phone, and remove the

battery.

After a few seconds, insert the battery,

and switch on the phone.

Restore the factory settings

See "Restore factory settings", p. 41.

Update your phone software

See "Software updates", p. 40.

Get more information

See a Nokia website, or contact Nokia

Care. See "Nokia support", p. 39.

If a query remains unresolved, contact

your local Nokia Care point for repair

options. Before sending your phone for

repair, always back up or make a record of

data in your phone.

Nokia support

•Check www.nokia.com/support or

your local Nokia website for the latest

version of this guide, additional

information, downloads, and services

related to your Nokia product.

Support and phone software updates 39

Cyan

Magenta

Yellow

Black

Configuration settings service

•Download free configuration settings

such as MMS, GPRS, e-mail, and other

services for your phone model at

www.nokia.com/support.

Nokia PC Suite

•You may find PC Suite and related

information on the Nokia website at

www.nokia.com/support.

Nokia Care services

•If you need to contact Nokia Care

services, check the list of local Nokia

Care contact centres at

www.nokia.com/customerservice.

Maintenance

•For maintenance services, check your

nearest Nokia Care point at

www.nokia.com/repair.

My Nokia

Receive free tips, tricks, and support for

your Nokia phone, plus free trial content,

interactive demonstrations, a

personalised web page, and news about

the latest Nokia products and services.

Get the most out of your Nokia phone and

information and availability in your

region, see www.nokia.com/mynokia.

Download content

You may be able to download new content

(for example, themes) to your phone

(network service).

Important: Use only services that you

trust and that offer adequate security and

protection against harmful software.

For the availability of different services

and pricing, contact your service provider.

Software updates

Nokia may produce software updates that

may offer new features, enhanced

functions, or improved performance. You

may be able to request these updates

through the Nokia Software Updater PC

application. To update the device

software, you need the Nokia Software

Updater application and a compatible PC

with Microsoft Windows 2000, XP or Vista

operating system, broadband internet

access, and a compatible data cable to

connect your device to the PC.

To get more information and to download

the Nokia Software Updater application,

visit www.nokia.com/softwareupdate or

your local Nokia website.

If software updates over the air are

supported by your network, you may also

be able to request updates through the

phone. See "Software updates over the

air", p. 41.

Important: Use only services that you

trust and that offer adequate security and

protection against harmful software.

40 Support and phone software updates

Cyan

Magenta

Yellow

Black

Software updates over the air

Your service provider may send phone

software updates over the air directly to

your phone (network service). This option

may not be available, depending on your

phone.

Downloading software updates may

involve the transmission of large amounts

of data through your service provider's

network. Contact your service provider for

information about data transmission

charges.

Make sure that the device battery has

enough power, or connect the charger

before starting the update.

Warning: If you install a software

update, you cannot use the device, even

to make emergency calls, until the

installation is completed and the device is

restarted. Be sure to back up data before

accepting installation of an update.

Software update settings

This option may not be available,

depending on your phone.

•To allow or disallow software and

configuration updates, select

Menu > Settings >

Configuration > Device manager

sett. > Serv. softw. updates.

Request a software update

1 Select Menu > Settings > Phone >

Phone updates to request available

software updates from your service

provider.

2 Select Current softw. details to

display the current software version

and check whether an update is

needed.

3 Select Downl. phone softw. to

download and install a software

update. Follow the instructions on the

display.

4 If the installation was cancelled after

the download, select Install softw.

update to start the installation.

The software update may take several

minutes. If there are problems with the

installation, contact your service provider.

Configuration setting service

To use some of the network services, such

as mobile internet services, the

multimedia messaging service (MMS),

Nokia Xpress audio messaging, or remote

internet server synchronisation, your

phone needs the correct configuration

settings. For more information on

availability, contact your service provider

or the nearest authorised Nokia dealer, or

see the support pages on the Nokia

website. See "Nokia support", p. 39.

When you have received the settings as a

configuration message and the settings

are not automatically saved and activated,

Configuration settings received is

displayed.

•To save the settings, select Show >

Save. If required, enter the PIN code

supplied by the service provider.

Restore factory settings

To restore the phone back to factory

conditions, select Menu > Settings >

Rest. factory sett. and from the

following:

Support and phone software updates 41

Cyan

Magenta

Yellow

Black

Restore settings only

•Reset all preference settings without

deleting any personal data.

Restore all

•Reset all preference settings and

delete all personal data, such as

contacts, messages, media files, and

activation keys.

42 Support and phone software updates

Cyan

Magenta

Yellow

Black

Digital rights management

Content owners may use different types of digital rights

management (DRM) technologies to protect their intellectual

property, including copyrights. This device uses various types

of DRM software to access DRM-protected content. With this

device you can access content protected with WMDRM 10,

OMA DRM 1.0, OMA DRM 1.0 forward lock, and OMA DRM 2.0. If

certain DRM software fails to protect the content, content

owners may ask that such DRM software's ability to access

new DRM-protected content be revoked. Revocation may also

prevent renewal of such DRM-protected content already in

your device. Revocation of such DRM software does not affect

the use of content protected with other types of DRM or the

use of non-DRM-protected content.

Digital rights management (DRM) protected content comes

with an associated activation key that defines your rights to

use the content.

If your device has OMA DRM-protected content, to back up

both the activation keys and the content, use the backup

feature of Nokia PC Suite. Other transfer methods may not

transfer the activation keys which need to be restored with

the content for you to be able to continue the use of OMA DRM-

protected content after the device memory is formatted. You

may also need to restore the activation keys in case the files

on your device get corrupted.

If your device has WMDRM-protected content, both the

activation keys and the content will be lost if the device

memory is formatted. You may also lose the activation keys

and the content if the files on your device get corrupted.

Losing the activation keys or the content may limit your

ability to use the same content on your device again. For more

information, contact your service provider.

Enhancements

Warning: Use only batteries, chargers, and

enhancements approved by Nokia for use with this particular

model. The use of any other types may invalidate any

approval or warranty, and may be dangerous.

For availability of approved enhancements, please check with

your dealer. When you disconnect the power cord of any

enhancement, grasp and pull the plug, not the cord.

Battery

Battery and charger information

Your device is powered by a rechargeable battery. The battery

intended for use with this device is BL-4U. This device is

intended for use when supplied with power from the

following chargers: AC-8. The battery can be charged and

discharged hundreds of times, but it will eventually wear out.

When the talk and standby times are noticeably shorter than

normal, replace the battery. Use only Nokia approved

batteries, and recharge your battery only with Nokia

approved chargers designated for this device. Use of an

unapproved battery or charger may present a risk of fire,

explosion, leakage, or other hazard.

The exact charger model number may vary depending on the

type of plug. The plug variant is identified by one of the

following: E, EB, X, AR, U, A, C, or UB.

If a battery is being used for the first time or if the battery has

not been used for a prolonged period, it may be necessary to

connect the charger, then disconnect and reconnect it to

begin charging the battery. If the battery is completely

discharged, it may take several minutes before the charging

indicator appears on the display or before any calls can be

made.

Always switch the device off and disconnect the charger

before removing the battery.

Unplug the charger from the electrical plug and the device

when not in use. Do not leave a fully charged battery

connected to a charger, since overcharging may shorten its

lifetime. If left unused, a fully charged battery will lose its

charge over time.

Always try to keep the battery between 15°C and 25°C (59°F

and 77°F). Extreme temperatures reduce the capacity and

lifetime of the battery. A device with a hot or cold battery may

not work temporarily. Battery performance is particularly

limited in temperatures well below freezing.

Do not short-circuit the battery. Accidental short-circuiting

can occur when a metallic object such as a coin, clip, or pen

causes direct connection of the positive (+) and negative (-)

terminals of the battery. (These look like metal strips on the

battery.) This might happen, for example, when you carry a

spare battery in your pocket or purse. Short-circuiting the

terminals may damage the battery or the connecting object.

Do not dispose of batteries in a fire as they may explode.

Batteries may also explode if damaged. Dispose of batteries

according to local regulations. Please recycle when possible.

Do not dispose as household waste.

Do not dismantle, cut, open, crush, bend, deform, puncture,

or shred cells or batteries. In the event of a battery leak, do

not allow the liquid to come in contact with the skin or eyes.

In the event of such a leak, flush your skin or eyes immediately

with water, or seek medical help.

Do not modify, remanufacture, attempt to insert foreign

objects into the battery, or immerse or expose it to water or

other liquids.

Digital rights management 43

Cyan

Magenta

Yellow

Black

Improper battery use may result in a fire, explosion, or other

hazard. If the device or battery is dropped, especially on a

hard surface, and you believe the battery has been damaged,

take it to a service centre for inspection before continuing to

use it.

Use the battery only for its intended purpose. Never use any

charger or battery that is damaged. Keep your battery out of

the reach of small children.

Nokia battery authentication guidelines

Always use original Nokia batteries for your safety. To check

that you are getting an original Nokia battery, purchase it

from a Nokia authorised service centre or dealer, and inspect

the hologram label using the following steps:

Successful completion of the steps is not a total assurance of

the authenticity of the battery. If you have any reason to

believe that your battery is not an authentic, original Nokia

battery, you should refrain from using it, and take it to the

nearest Nokia authorised service centre or dealer for

assistance. If authenticity cannot be verified, return the

battery to the place of purchase.

Authenticate hologram

1 When you look at the hologram on the label, you should

see the Nokia connecting hands symbol from one angle

and the Nokia Original Enhancements logo when

looking from another angle.

2 When you angle the hologram left, right, down and up,

you should see 1, 2, 3 and 4 dots on each side

respectively.

What if your battery is not authentic?

If you cannot confirm that your Nokia battery with the

hologram on the label is an authentic Nokia battery, please

do not use the battery. Take it to the nearest Nokia authorised

service centre or dealer for assistance. The use of a battery

that is not approved by Nokia may be dangerous and may

result in poor performance and damage to your device and

its enhancements. It may also invalidate any approval or

warranty applying to the device.

For additional information, refer to the warranty and

reference leaflet included with your Nokia device.

Care and maintenance

Your device is a product of superior design and craftsmanship

and should be treated with care. The following suggestions

will help you protect your warranty coverage.

•Keep the device dry. Precipitation, humidity, and all

types of liquids or moisture can contain minerals that

will corrode electronic circuits. If your device does get

wet, remove the battery, and allow the device to dry

completely before replacing it.

•Do not use or store the device in dusty, dirty areas. Its

moving parts and electronic components can be

damaged.

•Do not store the device in hot areas. High temperatures

can shorten the life of electronic devices, damage

batteries, and warp or melt certain plastics.

•Do not store the device in cold areas. When the device

returns to its normal temperature, moisture can form

inside the device and damage electronic circuit boards.

•Do not attempt to open the device other than as

instructed in this guide.

•Do not drop, knock, or shake the device. Rough

handling can break internal circuit boards and fine

mechanics.

•Do not use harsh chemicals, cleaning solvents, or strong

detergents to clean the device.

•Do not paint the device. Paint can clog the moving parts

and prevent proper operation.

•Use a soft, clean, dry cloth to clean any lenses, such as

camera, proximity sensor, and light sensor lenses.

•Use only the supplied or an approved replacement

antenna. Unauthorised antennas, modifications, or

attachments could damage the device and may violate

regulations governing radio devices.

•Use chargers indoors.

•Always create a backup of data you want to keep, such

as contacts and calendar notes.

•To reset the device from time to time for optimum

performance, power off the device and remove the

battery.

These suggestions apply equally to your device, battery,

charger, or any enhancement. If any device is not working

properly, take it to the nearest authorised service facility for

service.

Disposal

The crossed-out wheeled-bin symbol on your product,

literature, or packaging reminds you that all electrical and

44 Nokia battery authentication guidelines

Cyan

Magenta

Yellow

Black

electronic products, batteries, and accumulators must be

taken to separate collection at the end of their working life.

This requirement applies to the European Union and other

locations where separate collection systems are available. Do

not dispose of these products as unsorted municipal waste.

By returning the products to collection you help prevent

uncontrolled waste disposal and promote the reuse of

material resources. More detailed information is available

from the product retailer, local waste authorities, national

producer responsibility organizations, or your local Nokia

representative. For the product Eco-Declaration or

instructions for returning your obsolete product, go to

country-specific information at www.nokia.com.

Additional safety information

Small children

Your device and its enhancements may contain small parts.

Keep them out of the reach of small children.

Operating environment

This device meets RF exposure guidelines when used either

in the normal use position against the ear or when positioned

at least 1.5 centimetres (5/8 inch) away from the body. When

a carry case, belt clip, or holder is used for body-worn

operation, it should not contain metal and should position

the device the above-stated distance from your body.

To transmit data files or messages, this device requires a

quality connection to the network. In some cases,

transmission of data files or messages may be delayed until

such a connection is available. Ensure the above separation

distance instructions are followed until the transmission is

completed.

Medical devices

Operation of any radio transmitting equipment, including

wireless phones, may interfere with the functionality of

inadequately protected medical devices. Consult a physician

or the manufacturer of the medical device to determine if

they are adequately shielded from external RF energy or if

you have any questions. Switch off your device in health care

facilities when any regulations posted in these areas instruct

you to do so. Hospitals or health care facilities may be using

equipment that could be sensitive to external RF energy.

Implanted medical devices

Manufacturers of medical devices recommend that a

minimum separation of 15.3 centimetres (6 inch) should be

maintained between a wireless device and an implanted

medical device, such as a pacemaker or implanted

cardioverter defibrillator, to avoid potential interference

with the medical device. Persons who have such devices

should:

•Always keep the wireless device more than 15.3

centimetres (6 inch) from the medical device when the

wireless device is turned on.

•Not carry the wireless device in a breast pocket.

•Hold the wireless device to the ear opposite the medical

device to minimise the potential for interference.

•Turn the wireless device off immediately if there is any

reason to suspect that interference is taking place.

•Read and follow the directions from the manufacturer

of their implanted medical device.

If you have any questions about using your wireless device

with an implanted medical device, consult your health care

provider.

Hearing aids

Some digital wireless devices may interfere with some

hearing aids. If interference occurs, consult your service

provider.

Vehicles

RF signals may affect improperly installed or inadequately

shielded electronic systems in motor vehicles such as

electronic fuel injection systems, electronic antiskid

(antilock) braking systems, electronic speed control systems,

and air bag systems. For more information, check with the

manufacturer, or its representative, of your vehicle or any

equipment that has been added.

Only qualified personnel should service the device or install

the device in a vehicle. Faulty installation or service may be

dangerous and may invalidate any warranty that may apply

to the device. Check regularly that all wireless device

equipment in your vehicle is mounted and operating

properly. Do not store or carry flammable liquids, gases, or

explosive materials in the same compartment as the device,

its parts, or enhancements. For vehicles equipped with an air

bag, remember that air bags inflate with great force. Do not

place objects, including installed or portable wireless

equipment in the area over the air bag or in the air bag

deployment area. If in-vehicle wireless equipment is

improperly installed and the air bag inflates, serious injury

could result.

Using your device while flying in aircraft is prohibited. Switch

off your device before boarding an aircraft. The use of

wireless teledevices in an aircraft may be dangerous to the

operation of the aircraft, disrupt the wireless telephone

network, and may be illegal.

Potentially explosive environments

Switch off your device when in any area with a potentially

explosive atmosphere, and obey all signs and instructions.

Potentially explosive atmospheres include areas where you

would normally be advised to turn off your vehicle engine.

Sparks in such areas could cause an explosion or fire resulting

Additional safety information 45

Cyan

Magenta

Yellow

Black

in bodily injury or even death. Switch off the device at

refuelling points such as near gas pumps at service stations.

Observe restrictions on the use of radio equipment in fuel

depots, storage, and distribution areas; chemical plants; or

where blasting operations are in progress. Areas with a

potentially explosive atmosphere are often, but not always,

clearly marked. They include below deck on boats, chemical

transfer or storage facilities and areas where the air contains

chemicals or particles such as grain, dust, or metal powders.

You should check with the manufacturers of vehicles using

liquefied petroleum gas (such as propane or butane) to

determine if this device can be safely used in their vicinity.

Emergency calls

Important: This device operates using radio signals,

wireless networks, landline networks, and user-programmed

functions. If your device supports voice calls over the internet

(internet calls), activate both the internet calls and the

cellular phone. The device will attempt to make emergency

calls over both the cellular networks and through your

internet call provider if both are activated. Connections in all

conditions cannot be guaranteed. You should never rely

solely on any wireless device for essential communications

like medical emergencies.

To make an emergency call:

1 If the device is not on, switch it on. Check for adequate

signal strength. Depending on your device, you may

also need to complete the following:

•Insert a SIM card if your device uses one

•Remove certain call restrictions you have

activated in your device.

•Change your profile from offline or flight profile

mode to an active profile.

2 Press the end key as many times as needed to clear the

display and ready the device for calls.

3 Enter the official emergency number for your present

location. Emergency numbers vary by location.

4Press the call key.

When making an emergency call, give all the necessary

information as accurately as possible. Your wireless device

may be the only means of communication at the scene of an

accident. Do not end the call until given permission to do so.

CERTIFICATION INFORMATION (SAR)

This mobile device meets guidelines for exposure to

radio waves.

Your mobile device is a radio transmitter and receiver. It is

designed not to exceed the limits for exposure to radio waves

recommended by international guidelines. These guidelines

were developed by the independent scientific organisation

ICNIRP and include safety margins designed to assure the

protection of all persons, regardless of age and health.

The exposure guidelines for mobile devices employ a unit of

measurement known as the Specific Absorption Rate or SAR.

The SAR limit stated in the ICNIRP guidelines is 2.0 watts/

kilogram (W/kg) averaged over 10 grams of tissue. Tests for

SAR are conducted using standard operating positions with

the device transmitting at its highest certified power level in

all tested frequency bands. The actual SAR level of an

operating device can be below the maximum value because

the device is designed to use only the power required to reach

the network. That amount changes depending on a number

of factors such as how close you are to a network base station.

The highest SAR value under the ICNIRP guidelines for use of

the device at the ear is 0.44 W/kg.

Use of device accessories and enhancements may result in

different SAR values. SAR values may vary depending on

national reporting and testing requirements and the network

band. Additional SAR information may be provided under

product information at www.nokia.com.

Your mobile device is also designed to meet the requirements

for exposure to radio waves established by the Federal

Communications Commission (USA) and Industry Canada.

These requirements set a SAR limit of 1.6 W/kg averaged over

one gram of tissue. The highest SAR value reported under this

standard during product certification for use at the ear is 0.61

W/kg and when properly worn on the body is 0.44 W/kg.

46 Additional safety information

Cyan

Magenta

Yellow

Black

Index

access codes 7

active standby 9, 13

anykey answer 21

applications 33

barring password 7

battery 5

battery charge status 8

browser 31

business cards 37

cache memory 32

calculator 38

call divert 20

call log 20

call waiting 21

caller id 21

camera 26

capture an image 26

configuration 17

configuration setting service 41

contacts

— memory 36

cookies 32

data cable 16

dialling 19

dialling shortcuts 14, 19

digital rights 43

display 8, 13

downloads 40

e-mail 24

equaliser 30

factory settings 41

flash messages 25

flight mode 9

flight query 11

font size 13

gallery 27

games 33

general packet radio service 15

GPRS 15

GPS 34

handsfree 19

headset 6

help text 11

helpful hints 39

IM 25

image 26

indicators 9

info messages 17

instant messaging 25

internet 31

keyguard 10

keypad lock 7

keys 4

language 10

lights 13

location information 17

loudspeaker 19

Index 47

Cyan

Magenta

Yellow

Black

Maps 34

memory card 5, 27

message centre number 22

message sending 23

music player 28

My Nokia 40

Nokia Care 39

notes 38

number mode 21

offline mode 7

operator menu 17

packet data 15

parts 4

PC Suite 38

phone software updates 11

PictBridge 16

picture 26

PIN 7

position log 17

power saver 13

power saving 9

predictive text input 22

print images 27

profiles 12

PUK 7

radio 30

recorder 31

redial 21

screen saver 13

security code 7

security module 7

service commands 17

shortcuts 9, 13

signal strength 8

SIM

— services 17

SIM card 4, 7

SIM messages 17

sleep mode 13

software update 40, 41

speed dialling 14, 19, 21

start up tone 11

status indicators 8

stereo widening 31

stopwatch 39

strap 6

text modes 21

themes 12

tones 12

traditional text input 22

UPIN 7

USB data cable 16

video call 19

video clips 26

voice clarity 21

voice commands 14

voice dialling 19

voice recognition 14

voice recorder 31

wallpaper 13

web 31

write text 21

48 Index

Cyan

Magenta

Yellow

Black

DECLARATION OF CONFORMITY

0434

Hereby, NOKIA CORPORATION declares that this RM-414

product is in compliance with the essential requirements and

other relevant provisions of Directive 1999/5/EC. A copy of the

Declaration of Conformity can be found at www.nokia.com/

phones/declaration_of_conformity/.

Nokia, Nokia Connecting People, and Navi are trademarks or

registered trademarks of Nokia Corporation. Nokia tune is a

sound mark of Nokia Corporation. Other product and

company names mentioned herein may be trademarks or

tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all

of the contents in this document in any form without the prior

written permission of Nokia is prohibited.

US Patent No 5818437 and other pending patents. T9 text

Includes RSA BSAFE cryptographic or security protocol

software from RSA Security.

Java and all Java-based marks are trademarks or registered

trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent

Portfolio License (i) for personal and noncommercial use in

connection with information which has been encoded in

compliance with the MPEG-4 Visual Standard by a consumer

engaged in a personal and noncommercial activity and (ii) for

use in connection with MPEG-4 video provided by a licensed

video provider. No license is granted or shall be implied for

any other use. Additional information, including that related

to promotional, internal, and commercial uses, may be

obtained from MPEG LA, LLC. See http://www.mpegla.com

Nokia operates a policy of ongoing development. Nokia

reserves the right to make changes and improvements to any

of the products described in this document without prior

notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,

UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS

LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME

OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT

DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS".

EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF

ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT

LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN

RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS

DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS

DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR

NOTICE.

The availability of particular products and applications and

services for these products may vary by region. Please check

with your Nokia dealer for details, and availability of

language options.

Export controls

This device may contain commodities, technology or

software subject to export laws and regulations from the US

and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example,

when using a telephone in close proximity to receiving

equipment). The FCC or Industry Canada can require you to

stop using your telephone if such interference cannot be

eliminated. If you require assistance, contact your local

service facility. This device complies with part 15 of the FCC

rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including

interference that may cause undesired operation. Any

changes or modifications not expressly approved by Nokia

could void the user's authority to operate this equipment.

Model number: 6600s-1c

5555555/Issue 1

Cyan

Magenta

Yellow

Black

Cyan

Magenta

Yellow

Black

Microsoft RM-414 GSM 850/900/1800/1900 WCDMA FDD I/V Cellular Phone w/BT User Manual Manual

Microsoft Mobile Oy GSM 850/900/1800/1900 WCDMA FDD I/V Cellular Phone w/BT Manual

Manual

Navigation menu

Namespaces

Views

Navigation
