Nokia 6170

User Guide

Note: Spanish translation of this user guide begins on page 101.

6170.ENESv1_BIL_9236732.book Page 1 Tuesday, November 16, 2004 1:30 PM

Quick guide

Make a call Enter a phone number, and press Call.

Answer a call Press Call, or open the fold.

Answer call

during call Select Options > Answer call.

End a call Press End.

Decline a call Press End.

Mute a call Select Mute during a call.

Redial Press Call.

Adjust call volume Press the Volume keys on the left side of the phone

during a call.

Use the in-call menu Select Options during a call.

Save a name

and number Enter a number, select Save, enter a name, and select

OK.

Use 1-touch dialing Press and hold a key (2–8). You must assign a key to a

number in Contacts.

Look up a name Select Contacts > Find.

Check voice mail Press and hold the 1 (contact your service provider for

details).

Write and send

text messages Select Menu > Messages > Text messages > Create

message. Enter the message, and select Send. Enter the

number, and select OK.

Send a

picture message Select Menu > Messages > Text messages > Create

message > Options > Insert picture. Scroll to the

picture you want, and select View > Insert. Enter the

text message, and select Send. Enter the number, and

select OK.

Read a new message If New Message appears, select Read, highlight the

message, and select Read again.

Press Press a key briefly and release it.

Press and hold Press and hold a key for 2 to 3 seconds and release it.

6170.ENESv1_BIL_9236732.book Page 2 Tuesday, November 16, 2004 1:30 PM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that

the products RM-47 and RM-48 are in conformity with the provisions

of the following Council Directive: 1999/5/EC.

A copy of the Declaration of Conformity can be found at

http://www.nokia.com/phones/declaration_of_conformity/.

LEGAL INFORMATION

PART NO. 9235535 ISSUE NO. 1

Nokia, Nokia Connecting People, Pop-Port, Xpress-on, Nokia Original Enhancements, Nokia

6170, and the Nokia Original Enhancements logos are trademarks or registered trademarks

of Nokia Corporation. Other company and product names mentioned herein may be

trademarks or trade names of their respective owners.

Printed in Canada 10/2004

US Patent No 5818437 and other pending patents. T9 text input software

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java is a trademark of Sun Microsystems, Inc.

USE OF THIS PRODUCT IN ANY MANNER THAT COMPLIES WITH THE MPEG-4 VISUAL

STANDARD IS PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO (A) DATA OR

INFORMATION (i) GENERATED BY AND OBTAINED WITHOUT CHARGE FROM A CONSUMER

NOT THEREBY ENGAGED IN A BUSINESS ENTERPRISE, AND (ii) FOR PERSONAL USE ONLY;

AND (B) OTHER USES SPECIFICALLY AND SEPARATELY LICENSED BY MPEG LA, L.L.C.

The information contained in this user guide was written for the Nokia 6170 product. Nokia

operates a policy of ongoing development. Nokia reserves the right to make changes to any

of the products described in this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR

INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES

HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS." EXCEPT

AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR

IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY

AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO

REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS

This device may contain commodities, technology or software subject to export laws and

regulations from the US and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close

proximity to receiving equipment). The FCC or Industry Canada can require you to stop using

your telephone if such interference cannot be eliminated. If you require assistance, contact

your local service facility. This device complies with part 15 of the FCC rules. Operation is

subject to the condition that this device does not cause harmful interference.

6170.ENESv1_BIL_9236732.book Page 3 Tuesday, November 16, 2004 1:30 PM

Manufactured or sold under one or more following US Patents.

Asterisk (*) indicates design patents pending.

4868846 5519885 5827082 5966378 6112099 6266330

4969192 5526366 5835889 5970059 6115617 6282436

5001372 5553125 5839101 5987137 6118775 6285888

5045973 5557639 584884 5991716 6121846 6292668

5101175 5565821 5845219 5991857 6122498 6295286

5212834 5570369 5857151 5999523 6128322 6308084

5230091 5581244 5862178 6005857 6128509 6310609

5233634 5597102 5870683 6011853 6138091 6311054

5241284 5625274 5887266 6014573 6140966 6314166

5241583 5640395 5889770 6018277 6144243 6324412

5266782 5664004 5892475 6026161 6144676 6347218

5311151 5664053 5898925 6028567 6148209 6356759

5311179 5669069 5907823 6029128 6151485 6359904

5317283 5677620 5914690 6038238 6151507 6363259

5331638 5678224 5914796 6043760 6163609 6370362

5335362 5692032 5915440 6047196 6164547 6370390

5353328 5699406 5917868 6049796 6167248 6377803

5378935 5699482 5920826 6050415 6170073 6393121

5384782 5701392 5926138 6055439 6178535 6430721

5390223 5729534 5926769 6060193 6185295 6434133

5396657 5729541 5930233 6069923 6188909 *29/170210

5400949 5734683 5946651 6072787 6195338 *29/170229

5416435 5754976 5956332 6081534 6199035 *29/170245

5442521 5760568 5956625 6084962 6201876 *29/170246

5444816 5782646 5956633 6088746 6219560

5446364 5794142 5960354 6094587 6240076

5479476 5802465 5960389 6097964 6240079

5487084 5805084 5963901 6105784 6249584

5493255 5805301 5966374 6108553 6259312

6170.ENESv1_BIL_9236732.book Page 4 Tuesday, November 16, 2004 1:30 PM

Contents

Quick guide. . . . . . . . . . . . . 2

1. For your safety. . . . . . . . . . . 7

About your device. . . . . . . . . . . 8

Network Services . . . . . . . . . . . 8

Shared memory. . . . . . . . . . . . . 9

2. About your phone . . . . . . . 10

Terms . . . . . . . . . . . . . . . . . . . . 10

Find information about

your phone . . . . . . . . . . . . . . . 10

Get help. . . . . . . . . . . . . . . . . . .11

Phone introduction—

fold closed. . . . . . . . . . . . . . . . 12

Phone introduction—

fold open . . . . . . . . . . . . . . . . . 13

Start screen. . . . . . . . . . . . . . . 14

Accessibility solutions . . . . . . 17

Nokia PC Suite . . . . . . . . . . . . 17

Connection settings service . . 17

Phone menus. . . . . . . . . . . . . . 18

3. Basic operations. . . . . . . . . 19

Open the fold . . . . . . . . . . . . . 19

Install the battery

and SIM card. . . . . . . . . . . . . . 19

Charge the battery . . . . . . . . . 21

Attach the wrist strap . . . . . . 21

Switch the phone on and off. . 22

Antenna. . . . . . . . . . . . . . . . . . 22

Keyguard . . . . . . . . . . . . . . . . . 23

Make calls . . . . . . . . . . . . . . . . 23

Answer calls . . . . . . . . . . . . . . 24

Loudspeaker. . . . . . . . . . . . . . . 24

Options during a call . . . . . . . 25

4. Text entry . . . . . . . . . . . . . .26

Traditional text entry . . . . . . . .26

Predictive text entry . . . . . . . .26

Tips for writing text . . . . . . . . .27

5. Messages . . . . . . . . . . . . . . .28

Linked messages. . . . . . . . . . . .28

Font size . . . . . . . . . . . . . . . . . .28

Text and picture messages . . .29

Multimedia messages . . . . . . . 31

Instant messaging . . . . . . . . . .33

Voice messages. . . . . . . . . . . . .38

Info message service . . . . . . . .38

Service commands . . . . . . . . . .39

Message counter . . . . . . . . . . .39

6. Contacts . . . . . . . . . . . . . . .40

Menu. . . . . . . . . . . . . . . . . . . . .40

Save information . . . . . . . . . . .40

Change the primary number . .41

Search for an entry . . . . . . . . .42

Make a call . . . . . . . . . . . . . . . .42

Add an image to a contact . . .42

Edit an entry. . . . . . . . . . . . . . .42

Delete names and numbers. . .42

Copy entries . . . . . . . . . . . . . . .43

Business cards . . . . . . . . . . . . .43

1-touch dialing . . . . . . . . . . . .44

Voice dialing. . . . . . . . . . . . . . .44

Caller groups . . . . . . . . . . . . . .45

Contacts view and memory. . .46

7. Call log . . . . . . . . . . . . . . . .47

Missed, received,

and dialed calls . . . . . . . . . . . .47

Location information . . . . . . . .47

6170.ENESv1_BIL_9236732.book Page 5 Tuesday, November 16, 2004 1:30 PM

8. Settings . . . . . . . . . . . . . . . 48

Profiles . . . . . . . . . . . . . . . . . . .48

Themes . . . . . . . . . . . . . . . . . . .49

Tone settings . . . . . . . . . . . . . .49

Main display settings. . . . . . . . 49

Mini display settings . . . . . . . .49

Time and date settings . . . . . .49

Personal shortcuts . . . . . . . . . .50

Connectivity . . . . . . . . . . . . . . . 51

Call settings . . . . . . . . . . . . . . .53

Phone settings . . . . . . . . . . . . .55

Enhancement settings . . . . . . . 56

Configuration settings. . . . . . .57

Security settings . . . . . . . . . . .57

Restore factory settings . . . . . 61

9. Gallery . . . . . . . . . . . . . . . . 62

Folders. . . . . . . . . . . . . . . . . . . .62

Edit an image . . . . . . . . . . . . . .62

10. Media. . . . . . . . . . . . . . . . . 63

Camera . . . . . . . . . . . . . . . . . . .63

Media player. . . . . . . . . . . . . . .64

Voice recorder. . . . . . . . . . . . . .65

11. Organizer . . . . . . . . . . . . . . 66

Alarm clock. . . . . . . . . . . . . . . .66

Calendar . . . . . . . . . . . . . . . . . .67

To-do list. . . . . . . . . . . . . . . . . .69

Notes. . . . . . . . . . . . . . . . . . . . .69

Synchronization . . . . . . . . . . . . 70

Wallet . . . . . . . . . . . . . . . . . . . .72

Calculator . . . . . . . . . . . . . . . . .75

Stopwatch . . . . . . . . . . . . . . . .76

Countdown timer. . . . . . . . . . .77

12. Applications . . . . . . . . . . . . 78

Games . . . . . . . . . . . . . . . . . . . 78

Collection. . . . . . . . . . . . . . . . . 79

13. Mobile Internet services . . . 81

Set up for browsing. . . . . . . . . 81

Service inbox . . . . . . . . . . . . . . 83

File download . . . . . . . . . . . . . 84

Disconnect from the

mobile Internet . . . . . . . . . . . . 84

Emergency call while online. . 84

Options while online. . . . . . . . 85

Security . . . . . . . . . . . . . . . . . . 85

14. SIM services . . . . . . . . . . . . 88

15. Hardware and

enhancements . . . . . . . . . . 89

Hardware . . . . . . . . . . . . . . . . . 89

Enhancements . . . . . . . . . . . . . 89

16. Reference Information . . . . 90

Battery information . . . . . . . . 90

Enhancements . . . . . . . . . . . . . 90

Enhancements, batteries,

and chargers . . . . . . . . . . . . . . 91

Care and maintenance . . . . . . 91

Additional safety

information . . . . . . . . . . . . . . . 92

Certification information

(SAR). . . . . . . . . . . . . . . . . . . . . 95

Technical information . . . . . . . 96

Index . . . . . . . . . . . . . . . . . 97

6170.ENESv1_BIL_9236732.book Page 6 Tuesday, November 16, 2004 1:30 PM

For your safety

1 For your safety

Read these simple guidelines. Not following them may be dangerous or illegal.

Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the phone on when wireless phone use is prohibited

or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the

vehicle while driving. Your first consideration while driving should

be road safety.

INTERFERENCE

All wireless phones may be susceptible to interference, which could

affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference

in aircraft.

SWITCH OFF WHEN REFUELING

Don't use the phone at a refueling point. Don't use near fuel

or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Don't use the phone where blasting is

in progress.

USE SENSIBLY

Use only in the normal position as explained in the product

documentation. Don't touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect

incompatible products.

6170.ENESv1_BIL_9236732.book Page 7 Tuesday, November 16, 2004 1:30 PM

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all

important information stored in your phone.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for

detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press End as many

times as needed to clear the display and return to the main screen.

Enter the emergency number, then press Call. Give your location. Do

not end the call until given permission to do so.

• About your device

The wireless device described in this guide is approved for use on the GSM 850/

1800/1900 and GSM 900/1800/1900 networks. Contact your service provider

for more information about networks.

When using the features in this device, obey all laws and respect the privacy

and legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock,

the phone must be switched on. Do not switch the device on when

wireless phone use may cause interference or danger.

• Network Services

To use the phone you must have service from a wireless service provider. Many

of the features in this device depend on features in the wireless network to

function. These Network Services may not be available on all networks or you

may have to make specific arrangements with your service provider before you

can utilize Network Services. Your service provider may need to give you

additional instructions for their use and explain what charges will apply. Some

networks may have limitations that affect how you can use Network Services.

For instance, some networks may not support all language-dependent

characters and services.

Your service provider may have requested that certain features be disabled or

not activated in your device. If so, they will not appear on your device menu.

Contact your service provider for more information.

6170.ENESv1_BIL_9236732.book Page 8 Tuesday, November 16, 2004 1:30 PM

For your safety

• Shared memory

The following features in this device may share memory: contacts, text and

multimedia messages, instant messaging, voice tags, images, ringing tones,

video clips, sound clips, camera, calendar, to-do notes, notes, and Java™ games

and applications. Use of one or more of these features may reduce the memory

available for the remaining features sharing memory. For example, saving many

gallery items may use all of the available memory. Your phone may display a

message that the memory is full when you try to use a shared memory feature.

In this case, delete some of the information or entries stored in the shared

memory features before continuing. Some of the features may have a certain

amount of memory specially allotted to them in addition to the memory shared

with other features.

Refer to the appropriate area of this User Guide for information on how to

manage the features and data in your device.

6170.ENESv1_BIL_9236732.book Page 9 Tuesday, November 16, 2004 1:30 PM

2 About your phone

Congratulations on your purchase of the Nokia 6170 mobile phone.

• Register your phone

Be sure to register your phone at www.warranty.nokiausa.com or call

1-888-NOKIA-2U (1-888-665-4228) so that we can serve you better if you

need to call a customer center or to have your phone repaired.

•Terms

This guide uses certain terms for the parts of the phone and the steps that you

are asked to perform.

•Highlighted options on the screen are enclosed within a bar. The selection

keys are used to act on the highlighted option.

• Left selection key and Right selection key are used to select the options

on the left and right bottom corners of the screen.

•Four-way scroll and selection key is used to navigate through names,

phone numbers, menus, and settings. It is also used to move the cursor up,

down, left, and right when writing text, using the calendar, and in some

game applications. Pressing the key briefly in the middle selects the item in

the bottom center of the screen. The middle of the Four-way scroll and

selection key is also called the Middle selection key. The top, bottom, left,

and right edges of the Four-way scroll and selection key are also called

the Scroll up, Scroll down, Scroll left, and Scroll right keys.

•Select means to press the Left selection key or the Right selection key,

or to press the center of the Four-way scroll and selection key (the

Middle selection key). To select an option, press the selection key below

the menu item on the phone screen.

•Call key. Press Call to place a call or to answer an incoming call.

•End key. Press End to end a call or to return to the start screen.

• Find information about your phone

An information label under the battery contains the following information:

• Model number

• Phone type and FCC ID

• International mobile equipment identity (IMEI)

6170.ENESv1_BIL_9236732.book Page 10 Tuesday, November 16, 2004 1:30 PM

About your phone

•Get help

If you need help, Nokia Customer Care is available for assistance. We recommend

that you write down the following information and have it available if you call.

• The IMEI printed on the back of the phone, beneath the battery

• Your zip code

Contact Nokia

Please have your phone or enhancement with you when contacting the

numbers below.

Contact your service provider

To use the network services available in your phone, you will need to sign up

with a service provider. In many cases, the service provider will make available

descriptions of their services and instructions for using certain features.

Service providers may differ in their support of features. Before you sign up,

make sure a service provider supports the features that you need.

Guide updates

From time to time, Nokia updates this guide to reflect changes. The latest

version may be available at www.nokia.com/us.

Online tutorials

An interactive tutorial for this product may be available at the Web site

www.nokiahowto.com.

Nokia Customer Care Center, USA Customer Care, Canada

Nokia Inc.

7725 Woodland Center Boulevard

Suite 150

Tampa, Florida 33614

Tel: 1-888-NOKIA-2U

(1-888-665-4228)

Fax: 1-813-249-9619

TTY: 1-800-24-NOKIA

(1-800-246-6542)

(for TTY users only)

Nokia Products Ltd.

601 Westney Road South

Ajax, Ontario L1S 4N7

Tel: 1-888-22-NOKIA

(1-888-226-6542)

Fax: 1-905-619-4360

6170.ENESv1_BIL_9236732.book Page 11 Tuesday, November 16, 2004 1:30 PM

In-phone help

Many features have brief descriptions (help text) that can be viewed on the

display. To view help text, scroll to a feature and wait for about 15 seconds for

the help text to appear.

The default setting for help text is On. To activate or deactivate help text:

Select Menu > Settings > Phone settings > Help text activation > On or Off.

• Phone introduction—fold closed

• Mini display (1)

• Loudspeaker (2)

• Charger

connector (3)

• Microphone (4)

• Pop-Port™

connector (5)

used for

headsets and

the data cable.

• Camera lens (6)

•Power key (7)

switches the

phone on and off.

When the keypad is locked, press the Power key briefly to turn the display

lights on for approximately 15 seconds.

• Infrared (IR) port (8)

6170.ENESv1_BIL_9236732.book Page 12 Tuesday, November 16, 2004 1:30 PM

About your phone

• Phone introduction—fold open

• Ear piece (1)

• Main display (2)

•Left, middle, and right

selection keys (3)

The function of these keys

depends on the guiding text

shown on the display above the

keys. See “Main display” on

page 14.

•End key (4) ends an active call,

and exits from any function.

Press and hold to exit from

any function.

•Number keys (5) enter numbers

and characters; * and # keys

are used for various purposes

depending on the function.

Press and hold to open

the web start page, if mobile

Internet services are available

and configured. Mobile Internet

services are

network-dependent. Contact

your service provider for more

information.

•Up, down, left, and right

scroll keys (6)

Use to scroll through contacts,

menus, settings, calendar

dates, and feature options, or

to move the cursor when

writing text.

•Call key (7) dials a phone

number, and answers a call.

•Volume keys (8) adjust the earpiece, the loudspeaker, or the headset

volume (it is connected).

When the fold is closed, use the volume keys to mute the ringing tone of

an incoming call, to switch the alarm clock to snooze, or to mute.

6170.ENESv1_BIL_9236732.book Page 13 Tuesday, November 16, 2004 1:30 PM

• Start screen

When the phone is ready for use, and you have not keyed in any characters, the

phone is in the start screen.

Mini display

When the fold is closed, the mini display may show the following information:

• The signal strength of the cellular network at your current location, and

the battery charge level

• The name of the network or a text note indicating that the phone is not

in service

• The time and date, the active profile, and the alarm clock or calendar

note alerts

• The caller’s name or number of an incoming call and the caller, if identified

Main display

• Name of the network or the operator logo

to indicate in which cellular network the

phone is currently being used (1)

• Signal strength of the cellular network

at your current location (2). The higher

the bar, the stronger the signal.

• Battery charge level (3). The higher the

bar, the more charge in the battery.

• The Left selection key (4) in the start

screen is Go to.

Select Go to to view the list of functions

that are in your personal shortcut list.

Select any function to activate it, or select

Options to access the following options:

Select options—View the list of all available functions. Scroll to a function,

and select Mark to add it to the shortcut list. To remove a function from

the shortcut list, select Unmark. If there are no functions on the shortcut

list, select Add to add a function.

Organize—Rearrange the functions on the list. Scroll to the function that

you want to move, select Move and one of the moving options.

• The Middle selection key (5) in the start screen is Menu.

• The Right selection key (6) in the start screen may be:

Names—to access the Contacts menu

The operator-specific key—to access an operator’s homepage

Personal shortcut—a specific function for the Right selection key menu.

See “Personal shortcuts” on page 50.

6170.ENESv1_BIL_9236732.book Page 14 Tuesday, November 16, 2004 1:30 PM

About your phone

Screen saver

You can select an image for the screen saver on the mini display, and set the

phone to activate it after a certain length of time if no phone function is used.

See “Mini display settings” on page 49.

The phone automatically activates the digital clock screen saver on the main

display in the start screen, and also on the mini display if you have not selected

a screen saver for it. If you have not set the time, 00:00 is displayed.

Shortcuts in the start screen

• To access the list of dialed numbers, press Call. Scroll to the desired number,

and press Call to dial the number.

• To call your voice mailbox when you have saved your voice mailbox

number in the phone, press and hold 1.

• To connect to a browser service, press and hold 0.

• To find a name in the contacts list, scroll down.

• To write a text message, scroll left.

• To open the camera viewfinder in standard photo view, scroll up. To change

to video, scroll left. To change to portrait photo, scroll right.

• To select a profile when the keypad is unlocked, briefly press the Power key,

scroll to the desired profile, and press and hold the Power key.

Indicators and icons

Icon Indicates...

You have one or more text or picture messages. See “Read a

message” on page 30.

You have one or more multimedia messages. See “Read and reply”

on page 33.

You have one or more voice messages. See “Voice messages” on

page 38.

You have a delivery note, sent by your network, in the inbox. See

“Settings” on page 29.

or Your phone is connected to an instant message service, and the

availability status is online or offline. See “Instant messaging” on

page 33.

Your phone is connected to an instant message service, and you

have received one or more instant messages. See “Instant

messaging” on page 33.

The phone has registered a missed call. See “Call log” on page 47.

6170.ENESv1_BIL_9236732.book Page 15 Tuesday, November 16, 2004 1:30 PM

Your phone keypad is locked. See “Keyguard” on page 23.

Your phone does not ring for an incoming call or text message

when Incoming call alert is set to Off or none of the caller groups

has been set to alert in the Alert for setting, and Message alert

tone is set to Off. See “Customize a profile” on page 48.

The alarm clock is set to On. See “Alarm clock” on page 66.

The timer is running. See “Countdown timer” on page 77.

The stopwatch is running in the background. See “Stopwatch” on

page 76.

The GPRS connection mode Always online is selected, and the

GPRS service is available. The indicator is shown on the top left of

the display. See “GPRS modem settings” on page 52.

A GPRS dial-up connection is established. The indicator is shown on

the top left of the display. See “GPRS modem settings” on page 52.

The GPRS dial-up connection is suspended. For example, you have

an incoming or outgoing call during a GPRS connection. The

indicator is shown on the top right of the display.

IR connection indicator is shown continuously when the IR

connection is activated. See “Infrared” on page 51.

Forward all voice calls. All calls are forwarded to another number.

If you have two phone lines, the indicator for line 1 is and

for line 2 .

or If you have two phone lines, this indicator displays the selected

phone line. See “Phone settings” on page 55.

Loudspeaker is active. See “Loudspeaker” on page 24.

Calls are limited to a closed user group. See “Closed user groups”

on page 59.

The timed profile is selected. See “Profiles” on page 48.

A headset, hands-free, loopset, or music stand enhancement is

connected to the phone.

Icon Indicates...

6170.ENESv1_BIL_9236732.book Page 16 Tuesday, November 16, 2004 1:30 PM

About your phone

• Copyright protection

content from being copied, modified, transferred, or forwarded.

• Accessibility solutions

Nokia is committed to making mobile phones easy to use for all individuals,

including those with disabilities. For more information, visit

www.nokiaaccessibility.com.

• Nokia PC Suite

Nokia PC Suite is a collection of powerful software tools that let your phone work

with a compatible PC to manage phone features and data. For more information,

consult the Nokia PC Suite online help. Nokia PC Suite software and documentation

can be downloaded from www.nokia.com/us.

• Connection settings service

To use browsers, MMS, GPRS, and other wireless services, you must have the

proper connection settings on your phone. Your service provider may be able to

send the settings directly to you as a connection settings message. You only need

to save the settings on your phone. For more information about the availability

of the settings, contact your service provider or nearest authorized Nokia dealer.

You may be able to receive the connection settings for multimedia messages,

IM, synchronization, streaming, and the browser.

If you receive the connection settings as a message and the settings are not

automatically saved and activated, Connection settings received is displayed.

You can do one of the following:

• To save the received settings, select Save. If Enter settings’ PIN is displayed,

enter the PIN code for the settings, and select OK. For the PIN code,

contact the service provider that supplies the settings.

If no settings have been saved yet, the settings are saved and set as default

configuration settings. Otherwise, the phone asks Set as default settings?.

• To discard the received settings, select Discard.

You may need to activate the settings as described in the section for that service.

You can also find the settings in the support section of www.nokia.com/us.

6170.ENESv1_BIL_9236732.book Page 17 Tuesday, November 16, 2004 1:30 PM

• Phone menus

Phone features are grouped according to function and are accessed through the

main menus of your phone. Each main menu contains submenus and lists from

which you can select or view items and customize phone features.

Note: Some features may not be available, depending on your network.

For more information, contact your service provider.

You can choose from two types of menu style: List and Grid. See “Main display

settings” on page 49 or “Scroll method” on page 18 to switch between styles.

In the List style, the menu names are listed in the conventional way. In the Grid

style, multiple menu icons appear on a single display.

To use menus and submenus, scroll or use a shortcut.

Scroll method

1At the start screen, use the Middle selection key to select Menu.

2In the List view, scroll through the main menus one at a time using the

Scroll up and Scroll down keys.

3As you scroll through the menus, the menu number (1) appears in the upper

right corner of the display. Below the menu number is a scroll bar with a tab

(2). The tab moves up or down as you scroll through the menus, providing a

visual representation of your current position in the menu structure.

4To change between the List and Grid view, select Settings > Main display

settings > Menu view > List or Grid.

5In the Grid view, use all four scroll keys to navigate through the menu icons.

The icon for the selected menu is highlighted (1), and the name (2) of the

menu appears at the top of the display.

6When the desired menu is highlighted, press the Middle selection key.

7If the menu contains submenus, use the scroll keys to highlight the desired

menu; then press the Middle selection key.

•Select Back (press the Right selection key) to return to the previous menu

or submenu.

• Press End to return to the start screen from any main menu.

Shortcuts

Menus and options are numbered so that you can quickly key–press your way

to an option. The numbers appear in the top right corner of the screen and show

your location in the menu.

Select Menu and, quickly, enter the first number of the menu function you want

to access. Repeat until you have entered all the numbers.

6170.ENESv1_BIL_9236732.book Page 18 Tuesday, November 16, 2004 1:30 PM

Basic operations

3 Basic operations

• Open the fold

When you open the fold of the

phone, it automatically opens

to about 150 degrees. Do not try

to force the fold open further.

• Install the battery and SIM card

Keep all SIM cards out of the reach of small children. For availability and

information on using SIM card services, contact your SIM card vendor. This may

be the service provider, network operator, or other vendor.

The SIM card and its contacts can easily be damaged by scratches or bending,

so be careful when handling, inserting, or removing the card.

Note: Before installing or removing the battery or SIM card, always verify

that the phone is switched off and disconnected from any enhancement.

Note: Avoid touching electronic

components while changing cover.

Store and use your device with its

covers attached.

1With the phone closed and the back

of the phone facing you, press the

release button and lift the cover to

remove it from the phone.

6170.ENESv1_BIL_9236732.book Page 19 Tuesday, November 16, 2004 1:30 PM

2Remove the battery.

3To open the SIM card holder, gently

pull up on the locking clip.

4Insert the SIM card into the SIM card

holder so that the gold-colored

contact area on the card is facing

downwards. Ensure that the SIM card is properly inserted.

5Close the cover of the SIM card holder, and press it gently to snap into place.

6Replace the battery. Ensure that

the battery terminals are in the

proper position.

6170.ENESv1_BIL_9236732.book Page 20 Tuesday, November 16, 2004 1:30 PM

Basic operations

7Slip the locking catches of the

cover into the corresponding

catches on the phone.

8Press the opposite end of the cover

down onto the cover release button

until it snaps into place.

• Charge the battery

Warning: Use only batteries, chargers, and enhancements approved by

Nokia for use with this particular model. The use of any other types may

invalidate any approval or warranty and may be dangerous. Check the

model number of any charger before use with this device. This device is

intended for use when supplied with power from ACP-12, ACP-7, AC-1,

and LCH-12.

1Connect the charger to a wall socket.

2Connect the plug from the charger to

the jack on the bottom of your phone.

On the main display, the battery

indicator scrolls during charging. If

the power is on, Charging appears

briefly when the charger is first

attached. If the battery is completely

discharged, it may take a few minutes

before the charging indicator appears

on the display or before any calls can

be made.

You can use the phone while the charger is connected.

The charging time depends on the charger and the battery used. For example,

charging a fully discharged BL-4C battery with a ACP-7 charger takes

approximately 3 hours, and with a ACP-12 charger, approximately 1 hour and

30 minutes while the phone is in the standby mode.

• Attach the wrist strap

Wrist strap is available as an accessory. Check availability with your local

Nokia dealer.

1Remove the cover from the phone. See “Install the battery and SIM card”

on page 19.

6170.ENESv1_BIL_9236732.book Page 21 Tuesday, November 16, 2004 1:30 PM

2Thread the strap.

3Close the cover.

See “Install the

battery and SIM

card” on

page 19.

• Switch the phone on and off

Warning: Do not switch the phone on when wireless phone use is

prohibited or when it may cause interference or danger.

To switch the phone on or off, press and

hold the Power key.

If the phone displays Insert SIM card

or SIM card not supported, even

though the SIM card is properly

inserted, contact your network

operator or service provider. Your

phone does not support 5-V SIM cards.

If the phone requests a PIN code or a

security code, enter the code, and

select OK. See also “Access codes” on

page 60.

• Antenna

Hold the phone as you would any other telephone.

Your phone has an internal antenna.

6170.ENESv1_BIL_9236732.book Page 22 Tuesday, November 16, 2004 1:30 PM

Basic operations

Note: As with any other radio transmitting

device, do not touch the antenna area

unnecessarily when the device is switched

on. Contact with the antenna area affects

call quality and may cause the phone to

operate at a higher power level than

otherwise needed. Avoiding contact with the

antenna area when operating the phone

optimizes the antenna performance and the

battery life.

•Keyguard

With keyguard, you can lock the keypad to prevent keys from being pressed

accidentally. See “Security keyguard” on page 55.

If the keypad is locked, it unlocks when you receive a call. After a call, the lock

automatically reactivates.

To lock the keypad, at the start screen, select Menu > *.

To unlock the keypad, at the start screen, select Unlock > *, and enter the

security code if required.

Note: When keyguard is on, calls may be possible to the emergency

number programmed into your phone (for example, 911). Key in the

emergency number, and press Call. The number is displayed only after

you have keyed in its last digit.

• Make calls

Use the keypad

1Open the fold, enter the phone number (including the area code), and

press Call.

To delete a character to the left of the cursor, select Clear.

2To end the call or to cancel the call attempt, press End.

Use contacts

1At the start screen, scroll down; then scroll to the entry you wish to view.

To search the list of entries quickly, press the key with the letter that

matches the first letter of the contact name.

2Press Call to make the call, or select Details to view details of the entry.

6170.ENESv1_BIL_9236732.book Page 23 Tuesday, November 16, 2004 1:30 PM

Use 1-touch dialing

Before using 1-touch dialing, you must assign a phone number to a key (2–9).

See “1-touch dialing” on page 44.

If 1-touch dialing is set to On in the call settings, press and hold the assigned

1-touch dialing key until the call is started.

• Answer calls

When you receive a call, the phone shows the caller’s name, phone number, or

displays Private number or Call. The information appears in the mini display if

the phone is closed, or in the main display if the phone is open.

To answer a call, press Call.

To decline a call, open the fold and quickly close it again. If the fold is already

open, press End to decline the call. If Forward if busy is activated on your voice

mailbox, the call is forwarded to your voice mail. If not, the call is declined.

If you select Silence, only the ringing tone is muted. You can still answer or

decline the incoming call.

If a compatible headset with a headset key is connected to the phone, you can

answer or end a call by pressing the headset key.

Call waiting

During a call, press Call to answer the waiting call. The first call is put on hold.

Press End to end the active call.

To activate call waiting, see “Call waiting” on page 55.

Answer with the keys locked

To answer a call with keyguard on, open the fold or press Call. During the call,

all features function as normal. When you end or decline the call, the keypad

automatically relocks.

• Loudspeaker

You can use your phone as a loudspeaker during a call.

Warning: Do not hold the device near your ear when the loudspeaker

is in use because the volume may be extremely loud.

To activate the loudspeaker, select Loudsp; to deactivate it, select Normal.

To activate a headset, if attached, select Loudsp > Heads..

The loudspeaker is deactivated automatically when a call (or a call attempt)

ends or when certain enhancements are connected.

6170.ENESv1_BIL_9236732.book Page 24 Tuesday, November 16, 2004 1:30 PM

Basic operations

• Options during a call

Many of the options that you can use during a call are network services. To

check availability, contact your network operator or service provider.

During a call, you can select Options to access the available options. Some of

the options are as follows:

Hold—Put a call on hold.

Mute—The caller will hear silence.

Contacts—Access your contacts list.

New call—Place a new call; the first call is put on hold (network service).

Menu—Display the main menus.

Lock keypad—Lock the keypad to prevent an accidental key press.

Record—Record the call. See “Record a phone call” on page 65.

End call—End a call.

Touch tones—Send touch tones generated by your phone keypad. Enter the

touch tone string or search for it in contacts, and select Tones.

Loudspeaker—Listen to the call on the loudspeaker.

6170.ENESv1_BIL_9236732.book Page 25 Tuesday, November 16, 2004 1:30 PM

4 Text entry

Use two methods to enter text and numbers.

• Traditional text entry

Traditional text entry (predictive text off) is the only way to enter names into

contacts and to rename caller groups. In standard mode, the icon appears

in the upper left corner of the display.

Press a key once to insert the first letter on the key, twice for the second letter,

etc. If you pause briefly, the last letter in the display is accepted, and your

phone waits for the next entry.

To insert a name from contacts, select Options > Add new contact, and search

for the name. To insert a phone number or text item attached to the selected

name, select Options > View details.

• Predictive text entry

Predictive text entry (predictive text on) is a quick and easy method for

writing messages. When predictive text is on, the icon appears in the

upper left corner of the display.

Press # to switch between traditional text entry, predictive text entry, uppercase,

lowercase, and sentence case. , , and appear in the upper left of

the display, indicating uppercase, lowercase, and sentence case.

To switch to numeric entry, press and hold # and select Number mode. To switch

back to text entry, press and hold #, and select Writing language.

Activate predictive text

At a text entry screen, select Options > Predictive text and the desired language.

The selection of a writing language does not affect the language used in the

phone menus, displays, and messages.

Enter text

• For each letter of the word that you want to spell, press the corresponding

key once, even if the letter you want is not the first letter on the key. The

phone guesses the word you are trying to spell.

• If a displayed word is not correct, press * repeatedly to see other matches.

• Press 0 to accept the word and enter a space. Then begin writing the

next word.

• To insert a word, select Options > Insert word, write the word using

traditional text input, and select Save. The word is also added to the dictionary.

•If ? appears after a word, select Spell to add the word to the dictionary.

See “Add new words to the dictionary” on page 27.

6170.ENESv1_BIL_9236732.book Page 26 Tuesday, November 16, 2004 1:30 PM

Text entry

Compound words

Enter the first part of the word and scroll right to confirm it. Enter the last part

of the word and confirm it by pressing 0.

Add new words to the dictionary

If you encounter a word that predictive text does not recognize, ? follows the

word, and Spell appears in the bottom center of the display.

Select Spell, enter your new word using the keypad, and select Save. The word

is added to the dictionary and to the message that you are writing. When the

dictionary is full, the most recent addition replaces the first.

• Tips for writing text

• Press 0 to enter a space, and press 1 to enter a period (.).

• To move the cursor left or right, scroll left or right.

• To delete a character, select Clear. Select and hold Clear to continuously

delete characters. Select Options > Clear text to delete all of the characters

at once when writing a message.

• To switch between upper and lower case, or between traditional and predictive

text, press # repeatedly, and check the indicator at the top of the display.

• To switch between letters and numbers, press and hold #.

• To enter a number, press and hold the desired key.

• To display special characters, press *. (Press and hold * in predictive text.)

Press * again to display smileys. Scroll to the character you want, and

select Insert. In traditional text entry, to enter punctuation marks and

other special characters, press 1 repeatedly.

6170.ENESv1_BIL_9236732.book Page 27 Tuesday, November 16, 2004 1:30 PM

5 Messages

If you have subscribed to a message network service, you can send

messages to and receive messages from compatible phones that are also

subscribed to compatible message services. You can also send and receive

picture messages and multimedia messages, if supported by your service

provider. To send and receive messages, you need a messaging service through

your service provider, and a message center number saved in your phone. See

“Text entry” on page 26 for more information.

Note: When sending messages, your device may display Message Sent.

This is an indication that the message has been sent by your device to

the message center number programmed into your device. This is not

an indication that the message has been received at the intended

destination. For more details about messaging services, check with your

service provider.

Important: Exercise caution when opening messages. Messages may

contain malicious software or otherwise be harmful to your device or PC.

• Linked messages

Your phone can send and receive long text messages. Long text messages are

automatically split into multiple messages and sent as a series. For this feature

to work properly, the receiving phone must also support linked messages.

While you write a message, the number of available characters and the current

part number of linked message (for example, 120/2) are shown.

While receiving linked messages, you can start reading the first part before the

phone has received the entire message. If you may see *some text missing* on

the display, the message content will be updated as soon as the missing

sequence arrives.

If the memory is full, you may have to delete a message from your inbox or

outbox before your phone can update the missing text. See “Delete messages”

on page 31 for more information.

• Font size

Select Menu > Messages > Message settings > Other settings > Font size >

Small font or Large font.

6170.ENESv1_BIL_9236732.book Page 28 Tuesday, November 16, 2004 1:30 PM

Messages

• Text and picture messages

Settings

1Select Menu > Messages > Message Settings > Text messages >

Sending profile.

2If more than one message profile set is supported by your SIM card, select

the set you want to change and select one of the following:

Message center number—Save the phone number of the message center,

which is necessary for sending text messages; obtain this number from

your service provider.

Messages sent via—Select the message type Text, Page, or Fax.

Message validity—Define how long the network attempts to send your

messages before it gives up.

Default recipient number—For text messages, the default number used to

send messages.

Delivery reports—Request the network to send delivery reports on

your messages. When a delivery report is received, it goes to the inbox,

and displays.

Use GPRS—Set GPRS as the preferred method of sending text messages.

Reply via same center—Allow the recipient of your message to send you

a reply message using your message center (network service).

Rename sending profile—Change the name of the selected profile. This

option is available only if your SIM card supports multiple sending profiles.

It is not available for the default profile.

Folders

You can use folders to organize text and picture messages.

Select Menu > Messages and one of the following folders:

Inbox—Messages are automatically stored in the inbox after they have been

read or if you select Exit when Message received appears on the start screen.

Outbox—Contains messages you have sent and are waiting to be transmitted.

Sent items—Messages that you have sent are automatically stored in this folder

if Save sent messages is set to On in the message settings for text messages and

multimedia messages.

Saved items—You can store messages in this folder that you have read or that

you want to send later.

6170.ENESv1_BIL_9236732.book Page 29 Tuesday, November 16, 2004 1:30 PM

Write and send a message

indicates the message you composed has not been sent. indicates

the message you composed has been sent.

1Select Menu > Messages > Create message > Text messages, or scroll

left at the start screen.

2Compose a message using the keypad.

3To list available options while composing the message, select Options and

one of the listed options.

To save the message in the Saved items folder, select Save message > Saved

text msgs. or Templates, to save the message as a predefined template. If you

have defined any folders under My folders, they also appear in the list, and

you can save the message to one of them.

4To send the text message to a single address, select Send; enter the recipient’s

phone number, and select OK; or select Find to retrieve a number from

contacts, and press Select.

5For other sending options, select Options > Sending options and one of

the options, and follow the prompts.

Read a message

When you receive a text or picture message or SMS e-mail, and n Message(s)

received appear in the display, where n is the number of new messages.

indicates a message that has been read.

The blinking indicates that the message memory is full. Before you can

receive new messages, delete some of your old messages. See “Delete messages”

on page 31 for more information.

1To view the message immediately, select Show.

2To save the message to the inbox for later viewing, select Exit.

3To view a saved message, select Menu > Messages > Inbox.

4If more than one message is received, select the message you want to read.

indicates unread messages.

5While viewing the message, select Options and one of the listed options.

To extract numbers and Web site addresses from the current message,

select Use detail.

To copy text from the message to the phone calendar as a reminder note

for the current day, select Copy to calendar.

Reply to a message

1While viewing a message, select Reply > Text message.

2Compose your reply and send the message as described in “Write and send

a message” on page 30.

6170.ENESv1_BIL_9236732.book Page 30 Tuesday, November 16, 2004 1:30 PM

Messages

Forward a message

AS A TEXT MESSAGE

1While viewing a message, select Options > Forward > Via text message.

2Edit the message if desired, and select Send.

3Enter the recipient’s phone number, or select Find to retrieve it from

contacts, and select OK.

Delete messages

If your message memory is full and you have more messages waiting at the

network, blinks in on the start screen. You must read and delete unread

messages, or delete messages from some of your folders.

To delete a single message, select Menu > Messages, the folder, the message

you want to delete, and Options > Delete > Yes.

To delete all messages in a folder, select Menu > Messages > Delete messages,

the folder, and Yes.

• Multimedia messages

A multimedia message is indicated by and can contain text, sound, and a

picture. Your phone supports multimedia messages that are up to 100 KB. Only

compatible devices can receive and display multimedia messages.

The default setting of the multimedia message service is On. The appearance of

a multimedia message may vary depending on the receiving device.

Multimedia messaging supports the following formats:

• Picture: JPEG, GIF, WBMP, BMP, OTA-BMP, and PNG

• Sound: SP-MIDI, AMR audio, and monophonic ringing tones

• Video: 3GP format (H.263 baseline and MPEG-4 simple profile)

If a received message contains unsupported elements, these elements may be

replaced with the file name.

You cannot receive multimedia messages if you have a call in progress, a game

or other Java application running, or an active browsing session over GSM.

Because delivery of multimedia messages can fail for several reasons, do not

rely solely upon them for essential communications.

MMS settings

CONNECTION SETTINGS MESSAGE

You may be able to receive multimedia connection settings as a connection

settings message from your service provider. For more information, contact

your service provider.

6170.ENESv1_BIL_9236732.book Page 31 Tuesday, November 16, 2004 1:30 PM

MANUAL ENTRY

Contact your service provider for the settings.

Select Menu > Messages > Message settings > Multimedia msgs. >

Configuration settings > Edit active multimedia settings and each of the

settings in turn, and enter the required information.

OTHER MMS SETTINGS

Select Menu > Messages > Message settings > Multimedia msgs. and one

of the following:

Save sent messages—Select Yes to save sent multimedia messages to the Sent

items folder or No to discard.

Delivery reports—Select On for the network to send reports about your messages

(network service).

Scale image down—Select Yes to scale images to a smaller size when inserted

into a message or No to keep the original size.

Default slide timing—Set the default time in mm:ss format for each slide in an

MMS to remain on the screen.

Allow multimedia reception—Select Yes, No, or In home network for your

multimedia service. In home network cannot receive multimedia messages

outside the home network.

Incoming multimedia messages—Select Retrieve to receive multimedia

messages or Decline to not receive multimedia messages.

Configuration settings—Select Configuration > Default or Personal config.

according to which configuration settings support the multimedia messaging.

See “Configuration settings” on page 57.

Allow advertisements—Select Yes to enable reception of automatic multimedia

advertisements or No to disable.

Write and send

1Select Menu > Messages > Create message > Multimedia msg., and

enter the text of your message.

2To insert an image, sound or video clip, select Options > Insert and the type.

3Open the desired Gallery folder, scroll to the file, and select Options > Insert.

content from being copied, modified, transferred, or forwarded.

4To add a new page (also called a slide) to the message, select Options >

Insert > Slide.

Each slide can contain text, one image, a calendar note, a business card,

and one sound clip. If the message contains several slides, to open the

desired slide, select Previous slide, Next slide, or Slide list.

6170.ENESv1_BIL_9236732.book Page 32 Tuesday, November 16, 2004 1:30 PM

Messages

5To set other message properties, follow the prompts.

It takes more time to send a multimedia message than to send a text message.

While the multimedia message is being sent, is displayed, and you can use

other functions on the phone. If sending fails, the message remains in the

Outbox folder, and you can try to resend it later. Check your Outbox folder for

unsent messages. Messages that you have sent are saved in the Sent items

folder if the setting Save sent messages is set to Yes. See “Other MMS settings”

on page 32. This is not an indication that the message has been received at the

intended destination.

Read and reply

When a multimedia message is being received, blinks in the display. Once

the message has been fully downloaded, and Multimedia message received

appear in the display.

1To view the message immediately, select Show.

2To save the message to the inbox for later viewing, select Exit.

3To view a saved message, select Menu > Messages > Inbox, and scroll to

view the message. Unread messages are indicated by .

4While viewing the message, select Play to view the entire MMS, or select

Options and the desired action.

If blinks and Multimedia memory full, view waiting msg. appears, memory

for multimedia messages is full. To view the waiting message, select Show. Before

you can save the message, you need to delete some of your old messages. See

“Delete messages” on page 31 for more information.

• Instant messaging

Take text messaging to the next level by experiencing instant messaging (IM)

in a wireless environment. Engage in instant messaging with friends and family,

regardless of the mobile system or platform they are using (like the Internet),

as long as you all use the same IM service. Check with your wireless service

provider for availability.

Before you can start using IM on your phone, you must first subscribe to your

wireless service provider’s text messaging service. GPRS network service is required

to use instant messaging. You must also register with the IM service you want to

use. See “Register with an IM service” on page 34 for more information.

Note: Depending on both your IM service provider and your wireless

service provider, you may not have access to all of the features

described in this guide.

6170.ENESv1_BIL_9236732.book Page 33 Tuesday, November 16, 2004 1:30 PM

Before you can use IM, you must register with an IM service to obtain an IM

user name and password. You can obtain an IM user name and password by

registering over the Internet (using your computer) with the IM service provider

you have selected. During the registration process, you will have the opportunity

to create the user name and password of your choice. For more information

about signing up for IM services, contact your wireless service provider.

IM icons and menu items

Each IM service provider has its own unique interface, so the IM menu items, screen

display text, and icons on your phone may appear differently for each IM service. If

you have questions about the differences in the various IM service providers’ screen

text and icons, contact your wireless service provider for more information.

IM menus

OFFLINE

When you select IM from your phone menu, a list of available IM services is

displayed. Select the desired IM service to access the IM offline menu options:

are using, these may not be the exact menu items displayed. See “IM icons and

menu items” on page 34.

ONLINE

After you log into IM, the following IM online menu options appear: Conversations,

IM contacts, Add contact, Create group, Saved convers., IM availability,

Settings, Blocked list, and Logout. Depending on the IM service provider you

are using, these may not be the exact menu items displayed. See “IM icons and

menu items” on page 34.

1Select Menu > IM.

2Select the IM service you want to log into.

You must select the IM service every time you log in.

3Select Login.

4At the prompt, enter your user name if it is not already displayed, and

select OK.

5At the prompt, enter your password, and select OK.

Depending on your IM service, you may not need to enter your user name and

password manually every time you log in.

After you have logged into IM the first time, you can choose to log in automatically

or you can continue logging in manually. See the Automatic login option under

“IM settings” on page 37.

6170.ENESv1_BIL_9236732.book Page 34 Tuesday, November 16, 2004 1:30 PM

Messages

Begin an IM session

You can send instant messages to anyone if you have the person’s user name

and you use the same IM service. As the conversation progresses, the most

recent message appears at the top of the screen, causing the previous messages

to move down one level (some IM services may do this in the opposite direction).

If you want to chat with a person, you must first add that person to IM Contacts.

See “IM contacts” on page 36.

To begin an IM session with one contact:

1From the IM online menu, select IM contacts.

2Scroll to a contact who is online, and press Select > Open.

A conversation screen is opened, and the contact’s name is displayed at

the top.

3Select Write, and enter a message. See “Text entry” on page 26.

4When you finish the message, select Send.

Begin a group chat

You can create your own private chat groups. The participants must be entered

into IM contacts. See “IM contacts” on page 36.

1From the IM online menu, select Create group.

2Enter the group name (up to 10 characters), and select OK.

3After your screen name appears, select OK.

The group chat screen is displayed.

4To add group members, select Options > Group members.

5Select the contact whom you want to invite to the group chat.

6Enter the invitation text, and select Send.

Receive and reply to messages

If you have an active chat open and receive an instant message from the contact

or group member with whom you are chatting, the new message is displayed

on the conversation screen in the sequence in which they are received. Select

Write to reply.

If you receive an instant message when you have the IM application open but do

not have an active chat open, a screen appears showing you have a new instant

message with the name of the sender. Select Open to open the conversation

screen with that contact’s new message displayed. To reply, select Write, enter

a message, and select Send.

If you receive an instant message when you are logged in to the IM service but

do not have the IM application open on your phone, a message is displayed

telling you that a new IM message has been received. Select Start to open the

IM application and view the new message.

6170.ENESv1_BIL_9236732.book Page 35 Tuesday, November 16, 2004 1:30 PM

Return to chat session

From the IM online menu, select Conversations. This list displays all IM

conversations and group chats in which you are currently participating. To view

a conversation or continue chatting, scroll to a group name or contact name,

and press Select.

IM contacts

You can add the names of contacts with whom you interact frequently by

instant messaging to the IM contacts list.

ADD A NEW CONTACT

To add a person to IM Contacts during an instant messaging session, select

Options > Add.

To add a new contact from the IM online menu, select Add contact. Enter the

contact’s user name for the IM service, and select OK. Enter a nickname for the

contact, and select OK. The contact is added to your IM contacts list.

To add a new contact from the IM contacts list, select any contact to open the

IM contacts menu. Select Add contact, enter the contact’s user name for the

IM service, and select OK. Enter a nickname for the contact, and select OK. The

contact is added to your IM contacts list.

REMOVE A CONTACT

From the IM online menu, select IM contacts and the contact you want to

remove; then select Remove contact > OK.

BLOCK OR UNBLOCK CONTACTS

To block or unblock instant messages from a contact, select IM Contacts from

the IM online menu, the contact name, and Block contact or Unblock > OK.

To view a list of the contacts you have blocked, select Blocked list from the IM

online menu.

Save chat session

You can save a chat session while you have the conversation open. Select

Options > Save, edit the name if desired, and select Save.

To view a saved chat session, go to the IM online menu, select Saved convers.

and the desired conversation name to open it for viewing. While viewing the

saved conversation, you can select Delete or Options > Rename.

Set your availability

You can determine if other users can tell whether you are available or not. From

the IM online menu, select IM Availability > Available for all, Available for

contacts, or Appear offline.

6170.ENESv1_BIL_9236732.book Page 36 Tuesday, November 16, 2004 1:30 PM

Messages

IM settings

You can customize your IM settings, depending upon the IM service you have

selected. From the IM online menu, select Settings and one of the following:

Screen name—Enter a screen name (also called an alias or a nickname) that is

1–20 characters in length. This name is shown in front of the messages that

you send to your contacts. It is also your default screen name when you join a

group chat.

Automatic login—You can use automatic login after you have logged in at

least once to an IM service with your user name and password. When you select

IM from the phone main menu and then select the same IM service provider,

you are then logged in automatically and do not have to enter your user name

and password.

Sort contacts—Specify whether you want your IM contacts to be displayed

Alphabetically or By status.

Status updates—Select On if you want your IM contacts list to be updated when

a contact’s availability changes. If you set this feature to Off, you can select

Refresh list from the IM contacts menu to update your contacts’ status manually.

Network—Modify network connection settings for the IM service.

Log off service

EXIT INSTANT MESSAGING

From the IM online menu, you can exit the IM application but still be connected

to the IM service. Select Back until the IM online menu appears; then select

Exit. If you open IM again, you do not need to log in again.

You can then receive instant messages and chat invitations from your contacts

when using your phone for other purposes, such as playing a game. If you are

connected to your IM service, but you have not used your IM application for

some time, you may be automatically disconnected from the IM service. The

next time you open the IM application, Not connected is displayed, and you

are taken to the offline menu where you have to log in again.

LOG OUT OF INSTANT MESSAGING

To disconnect from the IM service, you must log out from the online menu.

You will be taken to the IM service provider list, where you can exit the IM

application or select an IM service and log in again.

From the IM online menu, select Logout > OK.

6170.ENESv1_BIL_9236732.book Page 37 Tuesday, November 16, 2004 1:30 PM

• Voice messages

If you subscribe to voice mail, your service provider will furnish you with a voice

mailbox number. You must save this number to your phone to use voice mail.

When you receive a voice message, your phone lets you know by beeping,

displaying a message, or both. If you receive more than one message, your phone

shows the number of messages received. If supported by the network,

indicates new voice messages.

Save your voice mailbox number

Your service provider may have already saved your voice mailbox number to

your phone. If so, the number will appear in the display in step 2. Select OK to

leave the number unchanged.

1Select Menu > Messages > Voice messages > Voice mailbox number.

2If the Mailbox number box is empty, enter the voice mailbox area code

and number, and select OK.

Call and set up your voice mail

1Once you have saved the voice mailbox number, press and hold 1.

2When you connect to voice mail and the prerecorded greeting begins,

follow the service’s automated instructions to setup your voice mail.

Listen to your voice messages

Once you have set up voice mail, you can dial the number in the following ways:

• Enter the voice mailbox number.

• Press and hold 1.

•Select Listen if there is a notification message in the display.

After a brief pause, your phone dials the voice mail number. Once you connect

and the prerecorded greeting begins, follow the automated instructions to

listen to your voice messages.

• Info message service

With the info message network service, you can receive short text messages

from your service provider on various topics, such as weather and traffic

conditions. Contact your service provider for more information.

Select Menu > Messages > Info messages and follow the prompts to

configure your service.

Info service—Select On or Off to activate or deactivate the service, or Topic

index to activate index reception.

6170.ENESv1_BIL_9236732.book Page 38 Tuesday, November 16, 2004 1:30 PM

Messages

Note: If the GPRS connection is set to Always online, info messages

may not be received. In that case, set the GPRS connection to When

needed. See “GPRS, EDGE, CSD, HSCSD” on page 51 for more information.

• Service commands

Use the Service commands editor to enter and send service requests (also known

as USSD commands) to your service provider. Contact your service provider for

information about specific service commands.

1Select Menu > Messages > Service commands.

2Enter a service request, such as an activation command for a specific

network service, and select Send.

• Message counter

To view the number of text and multimedia messages you have sent and

received, select Menu > Messages > Message counter > Sent messages or

Received messages.

To clear the counters, select Clear counters.

6170.ENESv1_BIL_9236732.book Page 39 Tuesday, November 16, 2004 1:30 PM

6 Contacts

Contacts can be saved in the phone memory and on the SIM card.

The phone memory can save up to 500 entries. You can also save

an image with some of the names. The amount of names, numbers and text

entries that you can save varies, depending on their length and the total

number of entries in contacts. indicates contacts saved on the SIM card.

•Menu

Select Menu > Contacts and one of the following:

Find—Find a name or select from a list.

Add new contact—Add a name to contacts.

Delete—Delete a name and its associated numbers.

Copy—Copy entries from phone memory to SIM and vice versa.

Settings—Set memory in use (phone or SIM), change contacts view, and check

the memory status of your phone and SIM card.

1-touch dialing—Display the list of 1-touch dialing numbers saved to memory.

Voice tags—Display and manage voice tags. See “Voice dialing” on page 44.

My numbers—View the numbers (line 1, line 2, data) in use by your SIM card.

Caller groups—View and edit the properties (such as the ringing tone) for any

of the caller groups.

• Save information

You can save names and numbers to phone memory or to SIM memory. See

“Contacts view and memory” on page 46.

Quickly save a name and number

1At the start screen, enter the phone number you wish to save, and select Save.

2Enter a name for the number, and select OK.

Save an entry

1Select Menu > Contacts > Add new contact.

2Enter a contact name, and select OK.

3Enter a phone number, and select OK > Done.

6170.ENESv1_BIL_9236732.book Page 40 Tuesday, November 16, 2004 1:30 PM

Contacts

Save multiple numbers and text items

For each entry in phone memory, you can save different types of phone numbers

and short text items. The first number you save for any entry is automatically

set as the default, or primary number. It is indicated with a frame around the

number type indicator. If you save multiple numbers, you can designate another

number as the primary number if desired. See “Change the primary number” on

page 41.

1Select Menu > Contacts > Settings.

2Make sure that the memory in use is either Phone or Phone and SIM.

See “Contacts view and memory” on page 46.

3At the start screen, scroll down; then scroll to the contact entry to which

you want to add a number or text item.

4Select Details > Options > Add number or Add detail and the desired

information category.

5Select an information category, enter the information, and select OK.

6To change the number or text type, with a number or text item highlighted,

select Options > Change type and the desired type.

You cannot change the type of an instant messaging user ID if it is in the

Subscribed names list or in the contact list for group chat.

7Press End to return to the start screen.

Save addresses and notes

To save an address or note, you need to add it to an existing entry (name).

1At the start screen, scroll down; then scroll to the entry to which you want

to add an address or note.

2With the entry highlighted, select Details > Options > Add detail > Web

address, Street address, or Note.

3Enter the text for the note or address, and select OK.

• Change the primary number

In a contact with more than one phone number, you can select which number

should be the primary number. When you highlight the contact and press Call,

the phone automatically dials the primary number.

1At the start screen, scroll down; then scroll to the entry you want to change,

and select Details.

2Scroll to the number you want to set as default, and select Options > Set

as default.

6170.ENESv1_BIL_9236732.book Page 41 Tuesday, November 16, 2004 1:30 PM

• Search for an entry

1At the start screen, scroll down to display the contents of Contacts.

2Press the key that corresponds to the first letter of the name for which you

are searching.

3Select Details to view the details of the selected entry.

4Scroll up and down through the details of the entry, if necessary.

• Make a call

At the start screen, scroll down; then scroll to the entry for the person you want

to call.

To dial the primary number, press Call.

To dial one of the other numbers for that contact, select Details, scroll to the

desired number, and press Call.

• Add an image to a contact

You can add an image to a name or number saved in phone memory. That image

is displayed when you receive a call from that phone number.

1At the start screen, scroll down.

2Scroll to the name or number, and select Details > Options > Add image.

The display shows the list of folders in the Gallery.

3Scroll to the folder that contains the image, and select Open.

4Scroll to the desired image, and select Options > Save to contacts.

A copy of the image is added to the contact.

You can use the phone to take a photo and attach it to the contact. See “Take

a photo” on page 63 for more information.

• Edit an entry

1At the start screen, scroll down; then scroll to the entry that you want to

edit, and select Details.

2Scroll to the item you want to edit, and select Options.

The list of available options varies according to the type of item selected.

3Select an option, and follow the prompts to edit the item.

• Delete names and numbers

1Select Menu > Contacts > Delete.

2To delete individual names and numbers, select One by one.

3Scroll to the entry you wish to delete, and select Delete > Yes to confirm

the deletion.

6170.ENESv1_BIL_9236732.book Page 42 Tuesday, November 16, 2004 1:30 PM

Contacts

4To delete the entire contents of contacts, select Delete all > Phone or SIM

card > Delete > Yes.

5At the prompt, enter your security code, and select OK.

• Copy entries

Text entries that are saved in the phone memory are not copied to the SIM card.

1Select Menu > Contacts > Copy > From phone to SIM card or

From SIM card to phone and one of the following:

One by one—Selects and copies entries one by one. Go to step 2.

All—Copies all entries from the SIM card or phone. Go to step 3.

Primary numbers—Copies only primary numbers. This appears only if you

selected From phone to SIM card. Go to step 3.

2Scroll to the entry you wish to copy, and select Copy > Keep original or

Move original.

Select Keep original if you are unsure of which copy method to use. This

ensures original entries are merely copied to the new location. Move original

deletes files at their former location after copying.

The entry is copied and you are returned to the list of contact entries.

3If you selected All or Primary numbers in step 1, select Keep original or

Move original > Yes to confirm your choice.

All entries are copied to the selected destination.

4Press End to return to the start screen.

• Business cards

You can send and receive an entry in Contacts to a compatible phone or other

handheld device using IR or a text or multimedia message, if supported by your

service provider.

Receive a business card using IR

1Select Menu > Settings > Connectivity > Infrared to ensure IR is activated.

When you receive the business card, your phone beeps, and a message

appears in the display.

2Select Show > Save to save the business card in phone memory or Exit >

OK to discard the business card.

Send a business card

1Highlight an entry from Contacts that you wish to send, and select

Details > Options > Send bus. card > Via infrared, Via text message,

or Via multimedia.

2Follow the prompts to finish sending the business card.

6170.ENESv1_BIL_9236732.book Page 43 Tuesday, November 16, 2004 1:30 PM

•1-touch dialing

You can assign any phone number to any key from 2–9, and dial the number by

pressing and holding the assigned key. If you assign a number that is not

already in your contact list, the number is added to the list.

Assign a key

1Select Menu > Contacts > 1-touch dialing.

2Scroll to any empty slot, and select Assign.

3Enter the number (including the area code), and select OK.

4Enter a name for the number, and select OK.

Make a call

Press and hold the key to which an entry has been assigned. Your phone dials

the entry assigned to the key.

Change numbers

1Select Menu > Contacts > 1-touch dialing.

2Scroll to the 1-touch dialing entry you wish to change, and select

Options > Change.

3Enter the number (including the area code), and select OK.

4Enter a name for the number, and select OK.

Delete numbers

1Select Menu > Contacts > 1-touch dialing.

2Scroll to the 1-touch dialing location you wish to delete, and select

Options > Delete > Yes.

• Voice dialing

You can make a phone call by saying a voice tag that has been added to a phone

number in contacts. Any spoken word, such as a name, can be a voice tag.

Before using voice tags, note that:

• Voice tags are not language-dependent. They are dependent on the

speaker's voice.

• You must say the name exactly as you said it when you recorded it.

• Voice tags are sensitive to background noise. Record them and make calls

in a quiet environment.

• Very short names are not accepted. Use longer, unique names (for example,

“John Smith, work”)

• When recording a voice tag or making a call using a voice tag, hold the

phone in the normal position at your ear.

6170.ENESv1_BIL_9236732.book Page 44 Tuesday, November 16, 2004 1:30 PM

Contacts

Note: Using voice tags may be difficult in a noisy environment or during

an emergency, so you should not rely solely upon voice dialing in all

circumstances.

Assign a voice tag

1At the start screen, scroll down to display the entry you would like to

assign a voice tag, and select Details.

2If the entry has multiple numbers, scroll to the number you wish to tag.

3Select Options > Add voice tag > Start.

4After the phone beeps, pronounce the voice tag clearly into the microphone.

After the voice tag is recorded, it is replayed through the earpiece, and a

confirmation note appears in the display. The icon is displayed next to

the number in the contact list.

Voice dial a number

1At the start screen, press and hold the Volume down key or the Right

selection key; or if you are using a compatible headset with a headset key,

press and hold the headset key.

The phone beeps, and Speak now appears in the display.

2Within 3 seconds, speak the tag into the microphone.

Once the voice tag is recognized, the tagged entry appears in the display,

replays through the earpiece, and the number is dialed.

Edit voice tags

1Select Menu > Contacts > Voice tags.

2Scroll to view the voice tags, select a voice tag, and Playback, Change,

or Delete.

• Caller groups

You can add contacts entries to any of five caller groups and assign a unique ringing

tone or graphic to that group. This enables you to identify callers from the group by

their unique ringing tone or graphic. A caller group can be as small as one person

or as large as the contacts list. You can rename caller groups to suit your preference.

To set the phone to ring only for calls from members of a selected caller group,

see the Alert for option in “Customize a profile” on page 48.

Set caller group options

1Select Menu > Contacts > Caller groups > Family, VIP, Friends,

Business, or Other > Rename group, Group ringing tone, Group logo,

or Group members.

2Follow the prompts to set the option according to your preference.

6170.ENESv1_BIL_9236732.book Page 45 Tuesday, November 16, 2004 1:30 PM

Add a name to a caller group

1Recall a name from contacts, and select Details > Options > Caller groups.

2Select the caller group to which you want to add the name.

Remove a name from a caller group

1Select Menu > Contacts > Caller groups > Family, VIP, Friends,

Business, or Other > Group members.

2Scroll to the name you want to remove, and select Options >

Remove contact.

•Contacts view and memory

At the start screen, select Contacts > Settings and one of the following:

Memory in use—Select the memory you wish to use. Options are Phone, SIM

card, or Phone and SIM combined. With Phone and SIM selected, when you

save a new contact entry, it is saved to phone memory only. However, when you

display the contact list you can see the entries in both phone memory and the

SIM card.

Contacts view—Select the Name list, Name and number, Name only, or Name

and image.

Memory status—View the amount of phone or SIM memory used and available.

6170.ENESv1_BIL_9236732.book Page 46 Tuesday, November 16, 2004 1:30 PM

Call log

7 Call log

Call log stores information about the last 20 missed, 20 received, and

20 dialed calls. It also adds the total duration of all calls. When the number of

calls exceeds the maximum, the most recent call replaces the oldest. For Call

log to work properly:

• Your service provider must support caller ID, and it must be enabled.

• Your calls cannot be blocked.

• Your phone must be on and within the service area.

• Missed, received, and dialed calls

1Select Menu > Call log > Missed calls, Received calls, or Dialed numbers.

2Scroll to a name or number of interest, select Options, and one of the

listed options.

• Location information

The network may deliver location information of your phone if you approve it

(network service). Contact your network operator or service provider to subscribe

and to agree upon the delivery of location information.

The network may send you a location request.

To accept or reject the location request, select Accept or Reject. If you miss the

request, the phone automatically accepts or rejects it according to what you

have agreed with your network operator or service provider. The phone displays

1 missed position request. To view the missed location request, select Show.

To view the information on the 10 most recent position requests, or to delete

them, select Menu > Call log > Positioning > Position log > Open folder or

Delete all.

6170.ENESv1_BIL_9236732.book Page 47 Tuesday, November 16, 2004 1:30 PM

8 Settings

Use this menu to set or change your personal shortcuts, time and

date settings, call settings, phone settings, display settings, tone

settings, enhancement settings, security settings, and to restore factory settings.

• Profiles

Profiles define how your phone reacts when you receive a call or a message, how

your keypad sounds when you press a key, and more. Ringing options, keypad

tones, and other settings can be left at their default setting, or customized to

suit your needs. Select and customize the most suitable profile for your situation,

such as when you are in a meeting or outdoors. The profiles available are

Normal, Silent, Meeting, Outdoor, and Pager.

Profiles are also available for enhancements such as a headset and car kit.

See “Enhancement settings” on page 56 for more information about

enhancement profiles.

Select a profile

Select Menu > Settings > Profiles, a profile from the list, and Activate; or in

the start screen, briefly press the Power key, scroll to the desired profile, and

press and hold the Power key.

Customize a profile

You can customize any of the profiles a variety of ways.

1Select Menu > Settings > Profiles.

2Select the profile you want to customize; select Customize and one of the

listed options.

For Alert for, define which caller groups the selected profile will accept or

decline. See “Caller groups” on page 45 for more information.

Set a timed profile

Timed profiles can be used to prevent missed calls. For example, suppose you

attend an event that requires your phone be set to Silent before the event

starts, but you forget to return it to Normal until long after the event. During

this time, you have missed several calls because the ringing tone was silent.

With the timed profile feature, you can set a profile to expire after any length of

time up to 24 hours. When the profile expires, your phone automatically returns

to the default profile.

1Select Menu > Settings > Profiles, a profile, and Timed.

2Enter the time for the profile to expire, and select OK.

The profile you have set for expiration is now active and appears in the

start screen along with a small clock icon.

6170.ENESv1_BIL_9236732.book Page 48 Tuesday, November 16, 2004 1:30 PM

Settings

•Themes

A theme contains many elements for personalizing your phone, such as

wallpaper, screen saver, color scheme, and a ringing tone.

Select Menu > Settings > Themes and follow the prompts.

• Tone settings

You can adjust the ringing volume, keypad tones, and more for the active profile.

Select Settings > Tone settings.

• Main display settings

Select Menu > Settings > Main display settings, and one of the listed options.

• Mini display settings

Images on the mini display may not be as bright as those on the main display.

Select Menu > Settings > Mini display settings, and one of the listed options.

• Time and date settings

Set the clock

1Select Menu > Settings > Time and date settings > Clock > Set the time.

2Enter the time in hh:mm format, and select OK.

3If required, select am or pm.

Show or hide the clock

Select Menu > Settings > Time and date settings > Clock > Hide clock or

Show clock.

Change the time format

You can set the time format for am, pm, or 24-hour format (military time).

Select Menu > Settings > Time and date settings > Clock > Time format >

24-hour or 12-hour.

Set the date

1Select Menu > Settings > Time and date settings > Date > Set the date.

2Enter the date, and select OK.

Show or hide the date

Select Menu > Settings > Time and date settings > Date > Show date or

Hide date.

6170.ENESv1_BIL_9236732.book Page 49 Tuesday, November 16, 2004 1:30 PM

Set or change the date format

1Select Menu > Settings > Time and date settings > Date > Date

separator and the separator of your choice (period, slash, hyphen, or space).

2Select Date > Date format and the format of your choice.

Automatic update of date and time

This is a network service. You can set the phone to update the date and time

from the network when you turn the phone on. Automatic update of the date

and time does not change the time you have set for the alarm clock, calendar,

or alarm notes. They are in local time. Updating may cause some alarms that

you have set to expire.

Select Menu > Settings > Time and date settings > Auto-update of

date & time and one of the following:

On—Update the time automatically

Confirm first—Request confirmation before updating the time. You can accept

or decline the update.

Off—Do not automatically update the time.

• Personal shortcuts

Right selection key

You can set the Right selection key to go directly to a specific function from

the start screen.

Select Menu > Settings > Personal shortcuts > Right selection key and one

of the functions in the list.

The selected name or function appears over the Right selection key in the

start screen.

Voice commands

Some phone functions can be voice-activated.

1Select Menu > Settings > Personal shortcuts > Voice commands, the

desired feature, Select, the function, and select Add.

2Select Start and speak after the tone.

See “Voice dialing” on page 44.

You cannot activate or add a voice command during a call or while sending or

receiving data over a GPRS connection.

6170.ENESv1_BIL_9236732.book Page 50 Tuesday, November 16, 2004 1:30 PM

Settings

• Connectivity

You can connect the phone to a compatible device or PC using an IR connection

or a data cable. You can also use the phone as a wireless modem to enable GPRS

mobile link from a compatible PC.

For information on using a data communication application, refer to the

documentation provided with the application.

For more information on Nokia PC Suite applications, see the Nokia PC Suite

online help. Nokia PC Suite and all related software can be downloaded from

www.nokia.com/us.

Infrared

You can send or receive data such as business cards, graphics, images, sound

clips, videos, and calendar notes to or from a compatible phone or data device

(such as a computer) using the IR port of your phone.

For better performance during an IR connection, place the phone on a stationary

surface. Do not move the phone while the IR connection is active. The preferable

distance between the two devices in an IR connection is from 3 inches to 3 feet.

Do not point the IR beam at anyone's eye or allow it to interfere with other IR

devices. This device is a Class 1 laser product.

SEND AND RECEIVE DATA

1Verify that the IR ports of the sending and receiving devices are pointing

at each other and that there are no obstructions between the devices.

2To activate IR in your phone, select Menu > Settings > Connectivity >

Infrared from the menus.

3The user of the other device should activate IR as well.

If data transfer is not started within 2 minutes after the activation of the IR

port, the connection is canceled and must be restarted.

CONNECTION INDICATOR

• When is shown continuously, the IR connection is activated and your

phone is ready to send or receive data using its IR port.

• When blinks, your phone is trying to connect to the other device or a

connection has been lost.

GPRS, EDGE, CSD, HSCSD

With your phone you can use general packet radio service (GPRS), high-speed

circuit switched data (HSCSD), and circuit switched data (CSD). The use of

HSCSD services uses the battery faster than normal voice or data calls. You may

need to connect the phone to a charger during HSCSD data transfer.

6170.ENESv1_BIL_9236732.book Page 51 Tuesday, November 16, 2004 1:30 PM

With GPRS, you can stay connected to the mobile Internet and allow faster

downloads without completing a dial-up connection. Applications using GPRS

include MMS, SMS messaging, browsing sessions, remote synchronization, Java

application downloading, and the PC dial-up. Your phone can support three

simultaneous GPRS connections.

Enhanced GPRS (EGPRS, or EDGE) is similar to GPRS but the connection is faster.

To use the EDGE service, subscribe to it from your service provider, and save the

GPRS settings for the functions that you want to use over the EDGE network.

For information on pricing, availability, and data transfer speed, contact your

service provider.

When you have selected GPRS as a data bearer, the phone uses EDGE instead

of GPRS if this is available in the network. You cannot choose between EDGE

and GPRS, but for some applications, such as browsing mobile Internet pages,

you may be able to select either GPRS or CSD.

The phone can support three simultaneous GPRS connections.

DEFINE GPRS CONNECTION

Depending on your service, you may be able to define when the phone connects

to the GPRS or EDGE network.

Select Menu > Settings > Connectivity > GPRS > GPRS Connection and one

of the following:

When needed—The phone registers and connects to the GPRS or EDGE network

only if you use a function that needs the GPRS service. The connection closes

when you exit the application. Establishing a connection may take longer than

when Always online is selected.

Always online—The phone automatically registers to a GPRS or EDGE network

when you switch the phone on, if the network is available in your location.

When you start an application using GPRS, the connection between the phone

and the network is established. When you exit the application, the connection

ends, but the phone is still registered to the network.

GPRS MODEM SETTINGS

When you use your Nokia phone as a wireless modem, you can enable a GPRS

mobile link from your PC or laptop computer.

Before you can use GPRS technology, you must save the GPRS settings for each

of the applications used over GPRS. Some service providers may have already

set up information for your GPRS dial-up connection.

In order to use GPRS, you must first subscribe to the network service. Contact

your service provider for details.

1Select Menu > Settings > Connectivity > GPRS > GPRS modem settings >

Active access point and the access point that you want to activate.

6170.ENESv1_BIL_9236732.book Page 52 Tuesday, November 16, 2004 1:30 PM

Settings

2Select Edit active access point to change the access point settings.

Contact your service provider for the access point name.

You can also set the GPRS dial-up service settings (access point name) on your

PC using the Nokia Modem Options software. See the Nokia PC Suite online

help for more information. If you set the settings on both the phone and the

PC, the PC settings will be used.

GPRS ICONS

The following icons appear in the upper left corner of the screen to show you

the status of your GPRS connection.

Data cable

1Connect the DKU-2 data cable to the USB port on your computer and to

the Pop-Port™ connector on your phone.

2Start using the data communications application on the computer.

Making or answering phone calls during a computer connection is not

recommended as it might disrupt the operation.

• Call settings

Call forwarding

Call forwarding tells your network to redirect incoming calls to another number.

Call forwarding is a network service and may not work the same in all networks.

Contact your service provider for more information.

ACTIVATE CALL FORWARDING

1Select Menu > Settings > Call settings > Call forwarding and one of

the following:

Forward all voice calls—Forward all calls to the number you specify.

Forward if busy—Forward all calls when you are in a call.

Forward if not answered—Forward all calls to another number if you do

not answer. You can also set a delay before forwarding takes place.

Forward if out of reach—Forward all calls when your phone is turned off

or out of the coverage area.

Forward if not available—Forward all calls when you do not answer, your

phone is busy or turned off, or out of the coverage area. You can also set

a delay before forwarding takes place.

Indicates an active GPRS connection (for example, when you are using

the browser).

Indicates that the GPRS connection has been interrupted by a voice call

or text message.

6170.ENESv1_BIL_9236732.book Page 53 Tuesday, November 16, 2004 1:30 PM

Forward all fax calls—Forward all fax calls to an alternate fax number.

Forward all data calls—Forward all data calls to a data mailbox.

Cancel all call forwarding—Cancel any call forwarding options you have set.

2Select Activate; then select the destination to which your calls will

be forwarded.

3Enter the number to which your calls, data, or other information will be

forwarded, and select OK; or select Find to retrieve a number from contacts.

4If required, select the delay time before the call is forwarded.

Your phone calls the network to activate the feature you have requested.

The network sends a confirmation note when the feature has been

activated successfully.

CANCEL CALL FORWARDING

1Select Menu > Settings > Call settings > Call forwarding.

2 Select Cancel all call forwarding; or one of the call forwarding options,

and select Cancel.

Canceling all call forwarding may affect your ability to receive voice mail

messages. Contact your service provider for specific details.

Anykey answer

Anykey answer allows you to answer an incoming call by briefly pressing any

key except the Power key, the selection keys, and the End key.

Select Menu > Settings > Call settings > Anykey answer > On or Off.

Answer when fold is open

You can determine whether opening the fold automatically answers an

incoming call.

Select Menu > Settings > Call settings > Answer when fold is open > On or Off.

Automatic redial

Occasionally, your network may experience heavy traffic, resulting in a fast

busy signal when you dial. With automatic redial activated, your phone redials

the number up to 10 times, and notifies you once the network is available.

Select Menu > Settings > Call settings > Automatic redial > On or Off.

1-touch dialing

You can turn the 1-touch dialing feature on and off. For more information, see

“1-touch dialing” on page 44.

Select Menu > Settings > Call settings > 1-touch dialing > On or Off.

6170.ENESv1_BIL_9236732.book Page 54 Tuesday, November 16, 2004 1:30 PM

Settings

Call waiting

If supported by your service provider, call waiting notifies you of an incoming call

even while you are in a call. You can accept, decline, or ignore the incoming call.

ACTIVATE OR DEACTIVATE

Select Menu > Settings > Call settings > Call waiting > Activate or Cancel.

CHECK STATUS

You can see whether call waiting is active, and for which type of calls.

Select Menu > Settings > Call settings > Call waiting > Check status.

USE CALL WAITING

1During a call, press Call to answer the waiting call.

The first call is put on hold.

2Press End to end the active call.

Summary after call

You can display the time spent on a call when you hang up (network service).

Select Menu > Settings > Call settings > Summary after call > On or Off.

Send my caller identity

You can prevent your number from being displayed on the receiving party’s

caller ID. This feature is a network service and works on a call-by-call basis.

Contact your service provider for more information.

Select Menu > Settings > Call settings > Send my caller ID > Set by

network, Yes, or No.

• Phone settings

Language

To set the language for the display texts, select Menu > Settings > Phone

settings > Language settings. If you select Automatic, the phone selects the

language according to the data in the SIM card.

Phone memory

You can check the amount of memory available in the phone. For more

information, see “Shared memory” on page 9.

Select Menu > Settings > Phone settings > Memory status, and scroll

through the list to view the memory associated with each item.

Security keyguard

You can set the phone to ask for the security code when you unlock the keyguard.

1Select Menu > Settings > Phone settings > Security keyguard.

2Enter the security code, and select OK > On or Off.

6170.ENESv1_BIL_9236732.book Page 55 Tuesday, November 16, 2004 1:30 PM

Welcome note

You can write a welcome note which shows up briefly on your display whenever you

power up your phone. You must use standard text input for entering welcome note

text. Press * to display and select from available special characters and smileys.

1Select Menu > Settings > Phone settings > Welcome note.

2Enter a note (up to 44 characters), and select Save.

System selection

You may be able to manually search for another network which has a roaming

agreement with your home service provider.

Select Menu > Settings > Phone settings > Operator selection and one of

the following:

Automatic—Your phone defaults to those settings which have been preset by

your service provider.

Manual—Your phone searches for a network which has a roaming agreement

with your service provider.

If No system access appears in the display, you need to switch to Automatic

mode, or insert another SIM card into the phone.

Confirm SIM service actions

This option allows you to request notification when your service provider makes

changes to SIM-related services (such as activating GPRS service).

Select Menu > Settings > Phone settings > Confirm SIM service actions >

Yes or No.

Help text

For information about help text, see “In-phone help” on page 12.

• Enhancement settings

The Enhancement settings menu is shown only if the phone is or has been

connected to one of the compatible enhancements such as the headset. Each

compatible enhancement appears in the Enhancement settings menu only

after it has been connected to the phone.

Select Menu > Settings > Enhancement settings and one of the available

enhancements; then select the option of your choice and follow the prompts.

6170.ENESv1_BIL_9236732.book Page 56 Tuesday, November 16, 2004 1:30 PM

Settings

• Configuration settings

You can configure your phone with settings that are required for certain services

to function correctly. The supported services are multimedia messaging, instant

messaging, synchronization, streaming, and browser. Your service provider may

also send you these settings. See “Connection settings service” on page 17.

For information on availability and the appropriate configuration settings,

contact your network operator or service provider.

Select Menu > Settings > Configuration settings and one of the following:

Default configuration sett.—Scroll to a service provider, and select Details to

view the services that the configuration settings of this service provider

supports, or select Options and one of the following:

•Set as default—Set the configuration settings of the service provider as

default settings.

•Delete—Delete the configuration settings.

Activate default in all applications—Activate the default configuration settings

in all services.

Preferred access point—Scroll to an access point, and select Options > Details

to view the name of the service provider, data bearer, and GPRS access point or

GSM dial-up number.

Personal configuration settings—Add new personal accounts for various services,

and activate or delete them. To add new configuration settings if you have not

added any, select Add new; otherwise, select Options > Add new. Select the

service type, and one by one select and key in all the required parameters. The

parameters differ according to the selected service type. To delete or activate a

personal account, scroll to it, and select Options > Delete or Activate.

• Security settings

Security features help to prevent accidental calls, allow you to restrict the calls

your phone can make and receive, and keep your stored information safe.

PIN code request

The PIN code (4–8 digits) provides extra security in case your phone is lost or

stolen. The PIN code must be obtained from your service provider. It is typically

provided with your SIM card.

You can set your phone to request the PIN code upon power-up. After three

successive incorrect entries the PIN code is blocked and you are asked to enter

the personal unblocking key (PUK) code. Some SIM cards do not allow you to

turn the PIN code request off.

1Select Menu > Settings > Security settings > PIN code request.

2At the prompt, enter the PIN code, and select OK > On > OK.

6170.ENESv1_BIL_9236732.book Page 57 Tuesday, November 16, 2004 1:30 PM

Call restrictions

This network service lets you restrict the calls your phone can make and receive.

Check with your service provider for details.

When calls are restricted, calls may be possible to emergency numbers programmed

into your phone (for example, 911). Enter the emergency number and press Call.

The number appears in the display after you have keyed in the last digit.

TURN ON CALL RESTRICTIONS

1Select Menu > Settings > Security settings > Call restrictions and one

of the following:

Outgoing calls—Calls cannot be made.

International calls—Calls cannot be made to foreign countries.

Int. calls except to home country—When abroad, calls can be made only

within the current country and to your home country (that is, the country

where your home network operator is located).

Incoming calls—Calls cannot be received.

Incoming calls if roaming—Calls cannot be received outside your home area.

Cancel all call restrictions—Turns off all call restrictions. Calls can be

made and received in the usual way. If you select this option, steps 2 and

3 are not available.

2Scroll to one of the following options:

Activate—Enter the restriction password, and select OK.

Cancel—Enter the restriction password, and select OK. This option allows

you to cancel one type of call restriction and leave others in force.

Check status—The phone lists the call types with call restriction active.

CHANGE YOUR RESTRICTION PASSWORD

Contact your service provider for your original restriction password.

1From the menus, select Settings > Security settings > Access codes >

Change restriction password.

2Enter your current password, and select OK.

3Enter your new password, and select OK.

4Re-enter your new password for verification, and select OK.

Fixed dialing

Once you set up and activate a fixed dialing list, your phone can make calls only

to those numbers that you have defined in the fixed dialing list. Fixed dialing is

a network feature and must be supported by your service provider.

If you activate fixed dialing and the number list is empty, all outgoing calls,

except for emergency numbers such as 911, require entry of the PIN2 code.

6170.ENESv1_BIL_9236732.book Page 58 Tuesday, November 16, 2004 1:30 PM

Settings

When fixed dialing is on, calls may be possible to emergency numbers programmed

into your phone (for example, 911). Enter the emergency number and press Call.

The number appears in the display after you have keyed in the last digit.

SET UP AND ACTIVATE A FIXED DIALING LIST

1Select Menu > Settings > Security Settings > Fixed dialing > Number list.

Fixed dialing not active appears in the display followed by

Fixed dialing list empty.

2At the prompt, enter the PIN2 code, and select OK.

3Enter the fixed dialing number, or select Find to retrieve a number from

contacts, and select OK.

4Enter a name for the number, and select OK.

5Select Back > On to activate fixed dialing.

VIEW OR EDIT THE FIXED DIALING LIST

1Select Menu > Settings > Security Settings > Fixed dialing > Number list.

2At the prompt, enter the PIN2 code, and select OK.

3Scroll to a number, and select Options, and an option from the list.

NOTES ABOUT FIXED DIALING

• If a SIM card with fixed dialing that is activated is inserted into a phone

that does not support fixed dialing, the SIM card is rejected.

• When fixed dialing is on, GPRS connections are not possible except while

sending text messages over a GPRS connection. In this case, the recipient’s

phone number and the message center number must be included in the

fixed dialing list.

• You cannot access SIM memory manually (view or copy numbers on the

SIM card) while fixed dialing is active.

Closed user groups

A closed user group is a network service that specifies the group of people

whom you can call and who can call you. For more information, contact your

service provider.

When calls are limited to closed user groups, calls may be possible to emergency

numbers programmed into your phone (for example, 911). Enter the emergency

number and press Call. The number appears in the display after you have keyed

in the last digit.

1Select Menu > Settings > Security settings > Closed user group > On,

Off, or Default.

2If you selected On, enter the group number provided by your service

provider, and select OK.

6170.ENESv1_BIL_9236732.book Page 59 Tuesday, November 16, 2004 1:30 PM

Security levels

The security level determines your access to features when a non-owner SIM card

is used. A non-owner SIM card is one (other than the original) that is inserted

after you power off the phone. There are three security levels:

Off—Owner and non-owner cards are treated the same.

Memory—The phone will ask for the security code when the SIM card memory

is selected and you want to change the memory in use or copy from one

memory to another.

Phone—The security code is required whenever a new SIM card is inserted.

Use the following to set your security level.

1Select Menu > Settings > Security settings > Security level.

2At the prompt, enter the security code (default 12345), and select OK >

Off, Memory, or Phone.

Access codes

SECURITY CODE

The security code (5–10 digits) controls access to features such as the security

level and is supplied with the phone. The preset code is 12345.

If you enter the wrong security code five times in succession, you will not be able

to enter a code for 5 minutes, even if you power off the phone between

incorrect entries.

Once you change the security code from its preset of 12345, keep the new code

secret and in a safe place separate from your phone. Use this procedure to change

your security code.

1Select Menu > Settings > Security settings > Access codes > Change

security code.

2At the prompt, enter the current security code (default 12345), and follow

the prompts.

PIN CODE

Before you can change your PIN code (4–8 digits), you need to enable PIN code

request. See “PIN code request” on page 57.

1Select Menu > Settings > Security settings > Access codes >

Change PIN code.

2At the prompt, enter the current PIN code, and follow the prompts.

6170.ENESv1_BIL_9236732.book Page 60 Tuesday, November 16, 2004 1:30 PM

Settings

PIN2 CODE

The PIN2 code (4–8 digits) is required for features such as fixed dialing. If you

enter an incorrect PIN2 code three times in succession, the PIN2 code is blocked

and you will have to enter the PUK2 code.

The original PIN2 code must be obtained from your service provider.

Use this procedure to change your PIN2 code.

1Select Menu > Settings > Security settings > Access codes >

Change PIN2 code.

2At the prompt, enter the current PIN2 code, and select OK.

3At the prompt, enter the new PIN2 code, and select OK.

4At the prompt, enter the new PIN2 code again, and select OK.

PUK AND PUK2 CODE

The PUK code is required to change a blocked PIN code. The PUK2 code is

required to change a blocked PIN2 code. If the codes are not supplied with the

SIM card, contact your service provider.

• Restore factory settings

You can reset some of the menu settings to their original values. However, data

that you have entered or downloaded is not deleted. For example, names and

numbers in contacts are not affected.

1Select Menu > Settings > Restore factory settings.

2Enter the security code (the default is 12345), and select OK.

A message confirms the original settings have been restored.

6170.ENESv1_BIL_9236732.book Page 61 Tuesday, November 16, 2004 1:30 PM

9 Gallery

You can save pictures, video clips, recordings, and ringing tones to

folders in the gallery, and add new folders to the ones already there.

You can download images and tones using MMS, mobile Internet sites,

or Nokia PC Suite.

Your phone supports a digital rights management system to protect content that

you have acquired. A piece of content, such as a ringing tone, can be protected

and associated with certain usage rules, for example, the number of usage times

or a certain usage period. The rules are defined in the content activation key that

can be delivered with the content or separately, depending on the service provider.

You may be able to update these activation keys. Always check the delivery terms

of any content and activation key before acquiring them, as they may be subject

to a fee.

from being copied, modified, transferred, or forwarded.

If the phone displays a message that the gallery memory is full, delete some

gallery files before proceeding.

•Folders

1Select Menu > Gallery.

A list of folders is displayed. Images, Video clips, Themes, Graphics, Tones,

and Recordings are preset in the phone.

2Scroll to a folder, and select Open to view a list of the files in the folder.

3Select Options to view the available options.

Select Activation key list to list available activation keys. You can delete

expired activation keys if desired.

Select Downloads to connect to the mobile Internet using your browser

and the currently active set of gallery downloads. If the connection fails,

you may need to activate another set or change the current settings. See

“Set up for browsing” on page 81 for more information.

• Edit an image

1Select Menu > Gallery, a folder that contains images, and Open.

2Scroll to an image, and select Options > Edit image > Options.

Options include Insert text, Insert frame, Insert clip-art, and Crop image.

6170.ENESv1_BIL_9236732.book Page 62 Tuesday, November 16, 2004 1:30 PM

Media

10 Media

•Camera

You can take photos and record video clips with the built-in camera, and adjust

its settings. The camera lens is on the back of the phone, and the color display

of the phone works as a viewfinder. The camera produces photos in JPEG format

and video clips in H.263 (SubQCIF) format. After you have taken a picture or

video, you can attach it to a multimedia message, and send it with MMS, save

it as wallpaper in the start screen, save it in a compatible PC using Nokia PC Suite

software, and upload it to a Web address with the content image uploader.

When you attach a picture to an entry in your list of contacts, the picture is

displayed when your contact calls you.

If there is not enough memory to take a new photo, free some by deleting old

photos or other files in the gallery.

Take a photo

1To open the camera from the start screen, scroll up; then scroll right and

left to switch to portrait photo, night mode, or video

Standard photo—Lets you take a photo in landscape orientation under

normal lighting conditions.

Portrait photo—Lets you take a photo in portrait orientation that can be

added to a name or phone number saved in contacts.

Night mode—Lets you take a photo in landscape orientation in dim lighting.

The live image appears on the display, and you can use the display

as a viewfinder.

2To use the self-timer, select Options > Self-timer > Start.

3To take a photo immediately, select Capture.

The phone saves the photo in the Images folder of the Gallery menu.

4Select Back to take another photo, Delete to delete the photo, or Options

to access the options.

Record a video clip

1Select Menu > Media > Camera > Options > Change mode > Video.

The live image appears in the display.

2To start the video, select Record.

While you are recording, and the remaining recording time are shown

at the top of the display.

3Select Pause to pause the recording and Continue to resume the recording.

6170.ENESv1_BIL_9236732.book Page 63 Tuesday, November 16, 2004 1:30 PM

4Select Stop to stop the recording.

The phone saves the recording in the Video clips folder of the Gallery menu.

5Select Back to record another video, Play to view the video, or Options to

access the options.

Settings

You can select the level of image quality, turn camera sounds on and off, and

define a default title to be used when you save a photo.

Select Menu > Media > Camera > Options > Settings and one of the following:

Image quality—Define file compression when saving the image. Select High,

Normal, or Basic. High has the least file compression and provides the best

image quality, but takes more memory.

Video clip length—Select Default or Maximum. The maximum is approximately

4 minutes depending on conditions. Only video clips that are default length or

shorter can be sent in a multimedia message.

Camera sounds—Set the shutter and self-timer sounds to On or Off.

• Media player

With the media player you can download, view, and play compatible images,

audio and video files, and animated images from a variety of sources.

The media player allows you to play streaming videos and streaming audio from

a network server. Streaming functionality is a network service and requires

network support. Check the availability of these services, pricing, and tariffs with

your network operator or the service provider whose service you wish to use.

Service providers will also give you instructions on how to use their services.

Select Menu > Media > Media player and one of the following:

Open Gallery—Open the gallery. From the gallery, you can play stored audio and

video files. See “Gallery” on page 62.

Bookmarks—Open the list of bookmarks in the Web menu. See “Bookmarks” on

page 83.

Go to address—Enter the address of a mobile Internet service, and select OK.

Media downloads—Download more graphics, tones, or videos to your phone.

Download content only from sources you trust.

Streaming sett.—Set the connection settings for the media service.

Set up for a streaming service

For more information and for the appropriate settings, contact the network

operator or service provider that offers the service that you want to use. You

may receive the streaming settings as a connection settings message from the

network operator or service provider that offers the service that you want to

use. See “Connection settings service” on page 17.

6170.ENESv1_BIL_9236732.book Page 64 Tuesday, November 16, 2004 1:30 PM

Media

To add and edit the settings with Nokia PC Suite, see the Nokia PC Suite online help.

To enter the settings manually, select Menu > Media > Media player >

Streaming sett. and each of the following:

Configuration—Select Default or Personal config. according to which

configuration settings support streaming. See “Configuration settings” on page 57.

Account—Select a streaming account contained in the active configuration

settings.

• Voice recorder

You can make a short recording (up to 3 minutes) and save it to the Recordings

folder or another folder in the Gallery. You can set a recording as a ringing tone.

You can also record your phone calls.

You cannot use the voice recorder when a data call or GPRS connection is active.

Make a recording

1Select Menu > Media > Voice recorder.

2To start the recording, select Record.

3Hold the phone in the normal position near your ear, and record your message.

4To stop the recording, select Stop.

The recording is saved in the Recordings folder of the Gallery.

5To replay the latest recording, select Play last recorded.

6To send the latest recording as a multimedia message or by IR mobile link

to a compatible phone, select Send last recorded.

Record a phone call

During a call, select Options > Record. To stop recording, select Stop.

While the call is being recorded, all parties to the call can hear a faint beeping

sound about every 5 seconds.

The recording is saved in the Recordings folder of the Gallery.

Manage recordings

1Select Menu > Media > Voice recorder > Recordings list.

2Scroll to the Recordings folder or the folder that you have defined for

storing recordings, and select Open.

3Use the options available in the Gallery.

6170.ENESv1_BIL_9236732.book Page 65 Tuesday, November 16, 2004 1:30 PM

11 Organizer

•Alarm clock

The alarm clock is based on the internal clock of your phone. It sounds an alert at

the time you specify. The alarm works even if the fold is closed or if the phone is off,

as long as there is enough power in the battery. When the alarm is triggered, the

alarm stays on until it is turned off.

Select an alarm tone

Select Menu > Organizer > Alarm clock > Alarm tone and one of the following:

Standard—Select the default alarm tone.

Ringing tone—Select an alarm tone from the ringing tone list.

Open Gallery—Select a sound clip from a gallery folder to use as an alarm. Open a

folder that contains tones, scroll to the tone you want, and select Options > Select.

Set an alarm

1Select Menu > Organizer > Alarm clock > Alarm time.

2If the alarm is already set, select On.

3Enter the time for the alarm in hh:mm format, and select OK > am or pm.

Alarm on appears briefly in the display, and appears on the start screen.

Repeat alarm

You can set the alarm clock to alert you on selected days of the week.

1Select Menu > Organizer > Alarm clock > Repeat alarm > Repetition days.

2Scroll to each desired day, and select Mark; or to mark all days, select

Options > Mark all.

3When you are finished, select Done.

Turn off an alarm setting

Select Menu > Organizer > Alarm clock > Alarm time > Off.

When the alarm sounds

WITH THE PHONE ON

The phone sounds an alert tone, flashes Alarm!, and shows the current time.

Select Stop to shut the alarm off, or select Snooze to stop the alarm for 10 minutes.

If the fold is closed, press either of the volume keys to set the alarm to snooze.

6170.ENESv1_BIL_9236732.book Page 66 Tuesday, November 16, 2004 1:30 PM

Organizer

WITH THE PHONE OFF

If the alarm time is reached while the device is switched off, the device switches

itself on and starts sounding the alarm tone. If you select Stop, the device asks

whether you want to activate the device for calls. Select No to turn off the

device or Yes to make and receive calls. Do not select Yes when wireless phone

use may cause interference or danger.

•Calendar

The calendar keeps track of reminders, calls you need to make, meetings, and

birthdays. It can even sound an alarm for any of these events.

Open the calendar

Select Menu > Organizer > Calendar.

The month view of the calendar appears in the display with the current date

highlighted. You can move to another date by using the four-way scroll keys

like a joystick.

The month view provides an overview of the selected month and weeks. It also

allows you to jump to a specific date. Any days or dates that appear in bold font

contain calendar notes such as a meeting or reminder.

While in the month view, to display the week view, select Options > Week view.

Settings

In either the month view or the week view, select Options > Settings, and one

of the listed options, and follow the prompts.

You can set the phone to delete calendar notes automatically after a day, a

week, or a month, or to never delete notes. Even if you set the phone for

automatic deletion, repeating notes such as birthdays are not deleted.

Go to a date

1In either the month view or the week view, select Options > Go to date.

2Enter the date (for example, 01/05/2004), and select OK.

The month or week view appears in the display with the jump date highlighted.

Make a note

You can choose from five types of notes: Meeting, Call, Birthday, Memo, and

Reminder. Your phone asks for further information depending on which note you

choose. You can also set an alarm, with or without an alarm tone, for any note.

1Go to the date for which you want to make a note, and select Options >

Make a note and one of the listed types of notes.

2Enter the information requested by the prompts.

6170.ENESv1_BIL_9236732.book Page 67 Tuesday, November 16, 2004 1:30 PM

View notes

Any dates that contain calendar notes are in bold (in the month view) or display

a note icon (in the week view).

1Go to the date containing the note, and select View.

The headers of any notes you have for the day appear in a list format.

2Scroll to the desired note, and select View.

The body of the note appears in the display.

Note options

While viewing the header or the body of a note, select Options and one of

the following:

Make a note, Delete, Edit, Move, Go to date, Copy, Go to to-do list

Repeat—Make the note recur on a regular basis (daily, weekly, biweekly,

monthly, and yearly).

Send note—Send the note to another device using IR mobile link, as a text or

multimedia message or as a note to another compatible phone calendar.

Settings—Set the date and time, date and time format, the day each week starts,

and whether you want your notes to autodelete after a specified time.

Note alarms

The phone beeps and displays the note. When a call note is displayed, you can

call the displayed number by pressing Call.

To stop the alarm without viewing the note, select Exit.

To stop the alarm and view the note, select View. Select Snooze; the phone

returns to the start screen and sounds an alarm again after 10 minutes.

If the fold is closed, press either of the volume keys to mute the note alarm.

Send a note

1Go to the date with the note you want to send, select View, and the note.

2Select Options > Send note > Via calendar, Via multimedia, Via text

message, or Via Infrared.

3Follow the prompts to send the note.

Receive notes

When you receive a calendar note, your phone displays Calendar note received.

You can then save the note in your calendar if desired, and set an alarm for any

date and time.

1When your phone displays Calendar note received, select Show; then use

the scroll keys to view the entire message, if necessary.

2To save the calendar note, select Options > Save, or to discard the

calendar note, select Options > Discard.

6170.ENESv1_BIL_9236732.book Page 68 Tuesday, November 16, 2004 1:30 PM

Organizer

•To-do list

Use the to-do list feature to keep track of your tasks. You can save a note for a

task, select a priority level for the note, and mark it as done when you have

completed it. You can sort the notes by priority or by date.

Add a note

1Select Menu > Organizer > To-do list.

2If there are no notes, select Add note; if there are notes, select Options > Add.

3Enter the subject of the to-do note, and select Save.

4Select either High, Medium, or Low priority.

The to-do note is saved. The phone automatically sets the deadline without

an alarm.

View a note

Select Menu > Organizer > To-do list, scroll to a to-do note, and select View.

Options while viewing notes

Select Options while viewing the header or body of a particular note and the

following options appear:

Add, Deadline, Delete, Sort by deadline, Go to calendar, Save to calendar,

Delete all notes.

Mark note as done—Mark a note or task as complete; no more reminders

will follow.

Send—Send the note to another device using IR, as a text or multimedia

message, or as a calendar note to another compatible phone.

Edit priority—Change the priority to high, medium, or low (available only in

body view).

•Notes

You can use the notes application to write and send notes to compatible

devices using IR or as a text message or multimedia message.

Make a note

1Select Menu > Organizer > Notes.

2If there are no notes, select Add note; or if there are notes, select

Options > Make a note.

3Enter the text of the note.

4While entering text, select Options, and follow the prompts.

6170.ENESv1_BIL_9236732.book Page 69 Tuesday, November 16, 2004 1:30 PM

Send a note

1Highlight the note you want to send, and select Options > Send note >

Via infrared, Via text message, or Via multimedia.

2Follow the prompts to send the note.

•Synchronization

The phone synchronization feature is a network service that allows you to

synchronize the calendar and contacts in your phone with a remote Internet

server or a compatible PC. If you have saved data in the remote Internet server,

you can synchronize your phone by starting the synchronization from the phone.

You can also synchronize your phone contacts and calendar to correspond with

the data of a compatible PC by starting the synchronization from the PC. You

must install Nokia PC Suite on your PC to use this feature. See “Nokia PC Suite”

on page 17 for more information.

Contacts in your SIM card will not be synchronized.

Answering an incoming call during synchronization will end synchronization

and you will need to restart it.

This feature must be supported by your service provider. For more information on

availability and synchronization service settings, contact your service provider.

Save settings

You may receive the synchronization settings as a settings message or you may

need to enter the synchronization settings manually.

SAVE SETTINGS RECEIVED AS A SETTINGS MESSAGE

When you receive the synchronization settings as a settings message,

Synchronization settings received is displayed.

Select Options > Details, Save, or Discard.

SAVE SETTINGS MANUALLY

You need to activate the set where you want to save the synchronization settings.

A set is a collection of settings required to make a connection to a service.

Contact your service provider for the settings.

1Select Menu > Organizer > Synchronization > Server sync > Sync

settings and the following:

Configuration—Select Default or Personal config. depending on which

configuration settings support the synchronization. See “Configuration

settings” on page 57.

Account—Select a service account contained in the active

configuration settings.

6170.ENESv1_BIL_9236732.book Page 70 Tuesday, November 16, 2004 1:30 PM

Organizer

2Select PC sync. settings and the following:

User name—Enter the user name, and select OK. (Contact your service

provider, if necessary, for this information.)

Password—Enter the password, and select OK. (Contact your service

provider, if necessary, for this information.)

The user name and password must be the same in the phone and in the PC.

With a remote Internet server

If you have saved data in the remote Internet server, you can synchronize your

phone by starting the synchronization from your phone. Once you have customized

and selected the appropriate synchronization settings, you are ready to synchronize

data. (See “Save settings” on page 70 or “Save settings manually” on page 70 for

more information.)

SYNCHRONIZE DATA

1Select Menu > Organizer > Synchronization > Server sync > Data to

be synchronized.

2Mark the data to be synchronized.

3Select Menu > Organizer > Synchronization > Server sync > Synchronize.

Synchronization begins.

Depending on the type of connection you are using to synchronize data,

connecting or initializing messages may appear.

Synchronizing for the first time or after an interrupted synchronization may

take up to 30 minutes, if contacts or calendar are full.

STOP SYNCHRONIZATION

1To stop synchronization, select End call, or press End.

2At the Quit synchronization? prompt, select OK.

HANDLE CALLS DURING SYNCHRONIZATION

During synchronization, outgoing calls are not possible. Incoming calls can still

be received, and can be handled in one of the following ways:

• To decline the incoming call, press End. Synchronization continues.

• To answer the incoming call, press Call. Synchronization is interrupted and

a Synchronization suspended message appears.

Once the incoming call is ended, a Start synchronization again? message appears.

Select Yes to start synchronization again from the beginning.

With your PC

You can synchronize the data in contacts and calendar to correspond with the

data of your PC by starting the synchronization from your PC. To synchronize

data from your PC, use either an IR connection or a data cable. You also need

the Nokia PC Suite software installed on your PC.

6170.ENESv1_BIL_9236732.book Page 71 Tuesday, November 16, 2004 1:30 PM

Start the synchronization from your PC using Nokia PC suite. For more information,

see the Nokia PC Suite online help. After synchronizing, the data in the phone

and in the PC are the same.

•Wallet

The wallet feature allows you to store personal information like debit and credit

card information to an encrypted area of phone memory. This information can

then be used to make secure online purchases. Wallet purchases can also use

digital signatures enabled by a security module in the SIM card (if present) for

signing and verifying transactions. Online purchases and digital signature

capabilities depend on your service provider.

You can also store personal information such as PIN codes and other sensitive

data in a wallet personal note.

You must enter a wallet code each time you access wallet. If you do not use

wallet for 5 minutes, it is automatically closed.

Create a code

The first time you access wallet, you must create a personalized wallet code.

1Select Menu > Organizer > Wallet.

2At the prompt, enter the 4–10 digit code of your choice, and select OK.

3Enter the same code again for verification, and select OK.

Create a code that is unique, yet easy to remember. This will be your key to

using wallet features in the future. Also, keep your wallet code in a secret place,

separate from your phone.

If you enter an incorrect wallet code three times in succession, you cannot

access wallet for 5 minutes.

Change the code

1Select Menu > Organizer > Wallet.

2At the prompt, enter your wallet code, and select OK > Settings >

Change code.

3Enter the original wallet code, and select OK.

4Enter the new wallet code, and select OK.

5Enter the new wallet code again for verification, and select OK.

Reset the code

If you forget your wallet code, you can reset the code and to erase all the

information stored in wallet.

Once you reset the wallet code and clear the contents of wallet, all of the

information is deleted. You must manually enter the information to restore it.

1At the start screen, enter *#7370925538# (*#res wallet#).

6170.ENESv1_BIL_9236732.book Page 72 Tuesday, November 16, 2004 1:30 PM

Organizer

2At the prompt, select Yes.

3Enter your security code, and select OK.

Wallet menu

1Select Menu > Organizer > Wallet.

2At the prompt, enter your wallet code, and select OK and one of the following:

Wallet profiles—Create card combinations for different services.

Cards—Save personal card information. See “Create a card” on page 73.

Tickets—Save notifications of e-tickets that you have bought through a

mobile service.

Receipts—Save receipts for mobile purchases.

Personal notes—Save any personal information that you want to protect

with the wallet code.

Settings—Set and change the wallet settings.

•Change code—Change the wallet code.

•RFID—Set the radio frequency identification (RFID) code. The RFID

technology helps to securely conduct commerce transactions with

your phone. You can enter the RFID code and the RFID type.

Create a card

Wallet supports several categories of cards.

1Access the wallet, and select Cards and one of the following:

Payment cards—Credit and debit cards

Loyalty cards—Membership cards

Access cards—Personal user names and passwords to online services

User info cards—Customized personal preferences for online services

Address cards—Contact information such as delivery and billing addresses

2If there are no cards in that category, select Add new; if there are cards,

select Options > Add new and follow the prompts.

3When you are finished, select Done.

If supported by your service provider, you can also receive card information as

a message. You are notified which category the card belongs to. Save or discard

the received card. You can view and rename the saved card, but you cannot edit

it. Contact your service provider for more information.

Compose a personal note

Wallet can store up to 30 personal notes, such as passcodes or other sensitive

data. Your notes are protected by the wallet security feature.

1Access the wallet, and select Personal notes.

6170.ENESv1_BIL_9236732.book Page 73 Tuesday, November 16, 2004 1:30 PM

2If there are no notes in the list, select Add new; if there are notes in the

list, select Options > Add new.

3Compose your note, and select OK.

4Enter a title for the note, and select OK.

Note options

While viewing note headers, select View to view the contents of the selected

note, or select Options > Edit, Add new, Sort, Delete, or Delete all.

While viewing the contents of a note, select Edit to edit the note, or select

Options > Send via text msg., Copy to calendar, Use detail, or Delete.

Create a wallet profile

When you have saved your personal card details, you can combine them into a

wallet profile. You can use the profile to retrieve wallet data from different

cards while browsing.

1Access the wallet, and select Wallet profiles.

2If there are no wallet profiles, select Add new; if there are wallet profiles,

select Options > Add new.

3Follow the prompts to select a payment card, a loyalty card list, an access

card, a user info card, a billing address, a shipping address, a receipt delivery

address, and a receipt delivery method (either To phone number or To

e-mail address).

4At the Wallet profile name prompt, enter a name for the profile, and

select OK.

Purchase guidelines

To shop, access the desired service site that supports wallet. See “Mobile Internet

services” on page 81. The service must support the Electronic Commerce Modeling

Language specification.

Choose the product you want to buy and read all information carefully.

When you indicate that you want to buy an item, the phone asks whether you

want to use wallet, and asks for your wallet code.

Select the card you want to use from the payment cards list. The phone

automatically fills in the credit card information or the wallet profile.

Approve the purchase, and the information is forwarded. You may receive an

acknowledgement or a digital receipt.

To close the wallet, select Close wallet.

If you have accessed or tried to access confidential information requiring

passwords, such as a bank account, empty the phone cache after each use. See

“Cache memory” on page 86.

6170.ENESv1_BIL_9236732.book Page 74 Tuesday, November 16, 2004 1:30 PM

Organizer

•Calculator

Basic calculations

The calculator adds, subtracts, multiplies, divides, calculates the square and the

square root, and converts currency values.

Note: This calculator has limited accuracy and is designed for simple

calculations.

1Select Menu > Organizer > Calculator.

2In the calculator screen, enter the first number in the calculation.

Press # for a decimal point if necessary.

3To perform an arithmetic calculation, press * to cycle through the add (+),

subtract (-), multiply (*), and divide (/) characters, and pause briefly to

select the displayed character; then enter the second number in your

calculation, and select Equals.

4To perform a square or square root calculation, select Options > Square

or Square root.

The completed calculation appears in the display.

Currency conversion

You can convert foreign currency to home currency, or vice versa.

CREATE OR EDIT THE EXCHANGE RATE

1Select Menu > Organizer > Calculator > Options > Exchange rate and

one of the following:

Foreign units in home units—Enter the number of home units it takes to

make one unit of foreign currency.

Home units in foreign units—Enter the number of foreign units it takes

to make one unit of your home currency.

2Enter the exchange rate, and select OK.

CONVERT CURRENCY

1Perform the currency conversion directly from the start screen, or select

Menu > Organizer > Calculator.

2Enter amount of currency to convert, select Options, and one of the following:

To home—Converts foreign currency to domestic currency.

To foreign—Converts domestic currency to foreign currency.

The converted amount appears in the display.

6170.ENESv1_BIL_9236732.book Page 75 Tuesday, November 16, 2004 1:30 PM

•Stopwatch

Your phone has a stopwatch that can be used to track time at sporting events

or other occasions. While the stopwatch is running, if you press End and return

to the start screen, the clock continues to run in the background, and

appears in the upper left corner of the screen.

Using the stopwatch consumes the battery and reduces the operating time of

the phone. Be careful not to let it run in the background when performing other

operations with your phone.

Measure split time

You can use the split time function for such things as a long distance race when

you need to pace yourself.

1Select Menu > Organizer > Stopwatch > Split timing > Start.

2To take an intermediate time, select Split.

The timer continues to run. The split time appears below the running time.

If you split the time more than once, the new measured time appears at

the beginning of the list. You can scroll to see previous measured times.

3To stop timing, select Stop.

The total time appears at the top of the display.

Measure lap time

You can use the lap time function when you want to track how long it takes to

complete each cycle or lap.

1Select Menu > Organizer > Stopwatch > Lap timing > Start.

The running time appears on the screen.

2Select Lap to measure lap time.

The clock stops, then starts immediately from zero. The lap time appears

below the running time.

If you take more than one lap time, the new measured time appears at the

beginning of the list. You can scroll to see previous measured times.

3To stop timing, select Stop.

The total time appears at the top of the display.

Save the time

1While the clock is running, select Stop > Save.

2Enter a name for the measurement, and select OK.

If you do not enter a name, the total time is used as the default title for

the lap time.

6170.ENESv1_BIL_9236732.book Page 76 Tuesday, November 16, 2004 1:30 PM

Organizer

• Countdown timer

The countdown timer is like an egg-timer or the timer on your microwave oven.

You can enter a specified time (up to 99 hours and 59 minutes), and when the

time runs out, your phone sounds an alarm. The countdown timer only works

when the phone is on. Once you turn off your phone, the countdown timer is

no longer active.

Set the countdown timer

1Select Menu > Organizer > Countdown timer.

2At the prompt, enter the time in hh:mm:ss format, and select OK.

3Enter a note for the countdown timer, and select Start.

The countdown timer begins running. The icon appears in the upper

left corner of the start screen.

Change the time

After you have set the countdown timer, you can change the time.

1Select Menu > Organizer > Countdown timer > Change time.

2Enter the new time in hh:mm:ss format, and select OK.

The countdown timer begins running.

Countdown timer alarm

When the time runs out, your phone sounds an alarm and displays the timer

note or Countdown completed.

To stop the countdown timer, press any key during the alarm. To stop the alarm

and delete the text note, select Exit.

If you do not respond to the countdown timer alert, it expires automatically

after 30 seconds.

Stop the countdown timer

Select Menu > Organizer > Countdown timer > Stop timer.

Timer stopped appears in the display.

6170.ENESv1_BIL_9236732.book Page 77 Tuesday, November 16, 2004 1:30 PM

12 Applications

Your phone supports J2ME™ Java applications. You will find some Java

applications and games pre-installed on your phone. Also, you can

manage and download new applications and games from your service provider.

Running some applications and games may consume the battery faster. You

may need to connect the phone to the charger.

•Games

Start a game

1Select Menu > Applications > Games > Select game, a game, and Open.

2To begin a new game, select New game.

3To read the games rules, select Instructions.

Options

While viewing the games list, select Options to display the following options:

Delete—Delete the game.

Details—Display details of the game.

Update version—Check if a new version of the game is available for download.

Web page—Get more information or additional data from a mobile Internet

page. This feature is shown only if it is supported by the network and a mobile

Internet address has been provided by the game.

App. access—Choose whether the game should be allowed to access the

network. You can require that the game ask every time it tries to access the

network, ask only the first time, always access the network without asking, or

never access the network.

Downloads

Your phone supports J2ME Java applications. During downloading the compatibility

is checked, and the downloading is interrupted if the phone does not support

the application.

1Select Menu > Applications > Games > Game downloads and one of the

bookmarks displayed.

To access the list of bookmarks in the Web menu, select More bookmarks.

2Select Select.

The phone connects to the Web pages using the currently active set of

browser settings. If the connection fails, you may enter the Web menu and

activate another set of service settings. See “Set up for browsing” on page 81.

When downloading a game, it may be saved in the Collection menu instead of

the Games menu.

6170.ENESv1_BIL_9236732.book Page 78 Tuesday, November 16, 2004 1:30 PM

Applications

Settings

You can turn game sounds, lights, and vibration on or off.

1Select Menu > Applications > Games > App. settings.

2Select Application sounds or Application shakes > On or Off; or select

Application lights > App. defined or Default.

• Collection

Start an application

1Select Menu > Applications > Collection > Select application.

2Scroll to an application or an application set, and select Open.

If the selection is a single application, the application starts. Otherwise, a list

of applications within the selected application set appears in the display.

3To start a single application, scroll to the desired application, and select Open.

Options

While viewing the application list, select Options to display the following options.

Delete—Delete the application or application set from your phone. If you delete

a pre-installed application or application set, you may be able to download it

again from www.nokia.com/us.

Details—Shows additional information about the application.

Update version—Check if a new version of the application is available

for download.

Web page—Get further information or additional data for the application from a

mobile Internet page. This feature must be supported by a service provider. It is

only shown if a mobile Internet address has been provided with the application.

App. access—Choose whether the application should be allowed to access the

network. You can require that the application ask every time it tries to access

the network, ask only the first time, always access the network without asking,

or never access the network.

Downloads

Note: Only install sources that offer adequate protection against

harmful software. Downloading applications is a network service.

Contact your service provider for more information

Your phone supports J2ME Java applications. During downloading the

compatibility is checked, and the downloading is interrupted if the phone does

not support the application.

When you download games or applications, games may be saved in the

Collection menu and applications may be saved in the Games menu.

6170.ENESv1_BIL_9236732.book Page 79 Tuesday, November 16, 2004 1:30 PM

APPLICATIONS

1Select Menu > Applications > Collection > App. downloads.

A list of available browser bookmarks appears in the display.

2Select More bookmarks to access the list of browser bookmarks in your

Web menu.

3Select the bookmark that contains the application you wish to download.

The phone connects to the Web page. See “Navigate the mobile Internet”

on page 82 for information on browsing Web pages. If the connection fails,

you may enter the Web menu and activate another set of service settings.

See “Set up for browsing” on page 81.

LINKS

Select Menu > Web > Download links > App. downloads and one of the sites

from the list.

6170.ENESv1_BIL_9236732.book Page 80 Tuesday, November 16, 2004 1:30 PM

Mobile Internet services

13 Mobile Internet services

The browser on your phone can display content that uses wireless

mark-up language (WML) or extensible hypertext mark-up language

(XHTML). The browser supports WAP 2.0 protocols (HTTP and SSL) that run on

TCP and IP protocols.

This feature is a network service. Contact your service provider for more information.

Because mobile Internet content is designed to be viewed from your phone,

your service provider is now your mobile Internet service provider as well.

It is likely that your service provider has created a home page and set up your

browser to go to this page when you log on to the mobile Internet. Once at your

service provider’s home page, you may find links to a number of other sites.

• Set up for browsing

It may not be necessary to manually configure the browser on your phone if

this was done by your service provider when you subscribed to the feature.

You may receive the service settings as a connection settings message from

your service provider. See “Connection settings service” on page 17.

You can enter the settings manually or add and edit the settings with

Nokia PC Suite.

To enter the settings manually, select Menu > Web > Settings >

Configuration settings and each of the following:

Configuration—Select Default or Personal config. depending on which

configuration settings support the service. See “Configuration settings” on page 57.

Account—Select a service account contained in the active configuration settings.

Display terminal window—Select Yes to perform manual user authentication

for intranet connections.

Contact your service provider if you have problems using the browser.

Activate service settings

Select Menu > Web > Settings > Configuration settings >

Active service settings, scroll to the desired service, and select Activate.

Connect to the web

To open the web start page, at the start screen, press and hold 0 (the Internet

icon ).

To select a bookmark, select Menu > Web > Bookmarks, and a bookmark from

the list. If the bookmark does not work with the current active service settings,

activate another set of service settings and try again.

After a brief pause, the phone attempts to connect to your service provider’s

home page or to the address that you selected.

6170.ENESv1_BIL_9236732.book Page 81 Tuesday, November 16, 2004 1:30 PM

If you see Check service settings, the phone may not be set up for browsing.

Contact your service provider to make sure that your phone is configured properly.

If GPRS is selected as the data bearer, is shown in the upper left corner of the

display during browsing. If you make a call or receive a call or text message, the

GPRS connection is suspended and is shown in the upper right corner of the

display. After the call, the phone tries to reestablish the GPRS connection.

Navigate the mobile Internet

Since your phone screen is much smaller than a computer screen, mobile Internet

content is displayed differently from content displayed on a computer. This section

contains guidelines for using phone keys to navigate a mobile Internet site.

• To browse the site, use any of the scroll keys.

• To select a highlighted item, press Call or select Open.

• To enter letters and numbers, press a key from 0–9.

• To enter special characters, press *.

Examples of elements you may find on a mobile Internet site are as follows:

Header line. Shows the current mobile Internet site.

Active link. Appears as a highlighted word.

Inactive link. Appears as an underlined word.

Scroll up and down through the list of links.

Options. Select Options to go to the list of service options. See “Options while

online” on page 85.

Select. Select Select to go to the active link.

Back. Select Back to return to the previous page.

Appearance settings

You can determine how pages appear on the phone display.

1Select Menu > Web > Settings > Appearance settings; or while

browsing, select Options > Other options > Appear. settings.

2Select one of the following options:

Text wrapping—Text on the Web page continues on the next line if it

cannot be shown on only one line. Select On to allow text wrapping, or Off

to prevent text wrapping.

Font size—Select Small, Normal, or Large.

Show images—Select Yes to display pictures from the page or No to hide

pictures. When pictures are displayed, pages load more slowly.

Alerts—The phone can alert you to unsecure connections and to unsecure

items on secure pages. However, these alerts do not guarantee a

secure connection.

6170.ENESv1_BIL_9236732.book Page 82 Tuesday, November 16, 2004 1:30 PM

Mobile Internet services

•Alert for unsecure connection—Select Yes to set the phone to alert

you when a secure connection changes to an unsecure connection

during browsing.

•Alert for unsecure items—Select Yes to set the phone to alert you

when a secure page contains an unsecure item.

Character encoding—Select encoding methods for Web content and

Web addresses.

•Content encoding—Select the character set that the phone uses to

display browser pages that do not include that information.

•Unicode (UTF-8) web addresses—Determine whether to always use

UTF-8 encoding when sending a Web address to a compatible phone.

Select On or Off.

Bookmarks

You can save addresses for your favorite sites as bookmarks.

Your device may have some bookmarks loaded for sites not affiliated with Nokia.

Nokia does not warrant or endorse these sites. If you choose to access them, you

should take the same precautions, for security or content, as you would with any

mobile Internet site.

SET MANUALLY

1Select Menu > Web > Bookmarks.

2If there are no bookmarks in the list, select Add new; or if there are

bookmarks in the list, select Options > New bookmark.

3Enter an address for the bookmark, and select OK.

4Enter a title for the bookmark, and select OK.

SET WHILE ONLINE

While you are connected to the site that you want to bookmark, select

Options > Add bookmark.

RECEIVE

When you receive a bookmark, 1 bookmark received is displayed. Select

Show > Save to save the bookmark, or Options > View or Delete to view or

delete it.

• Service inbox

You can receive service messages (pushed messages) from your service provider.

Message settings

Select Menu > Web > Settings > Service inbox settings and one of the following:

Service messages—Select On to receive service messages, or Off to reject them.

6170.ENESv1_BIL_9236732.book Page 83 Tuesday, November 16, 2004 1:30 PM

Message filter—Select On to set the phone to receive messages only from

content authors approved by the service provider. Select Trusted channels to

view the list of approved content authors.

Automatic connection—Select On to automatically activate the browser from

the start screen when a service message is received; or Off to activate the

browser only when you select Retrieve after a service message is received.

View a message

When you receive a service message, a note appears in the display. To view

the message:

1At the start screen, select Show to view the message immediately, or Exit

to save it to the service inbox for later viewing.

2While browsing, select Options > Other options > Service inbox.

To view a saved service message:

1Select Menu > Web > Service inbox.

2Scroll to the desired message, and select Options and one of the following:

Retrieve—Activate the browser, and download the content indicated in

the message.

Details—View the details of the message.

Delete—Delete the message.

• File download

You can download tones, images, games, and applications from the mobile Internet.

1Select Menu > Web > Download links; or while browsing, select

Options > Download links.

2Select a download option; then select one of the sites from the list and

follow the prompts.

• Disconnect from the mobile Internet

To close your connection, press and hold End.

• Emergency call while online

If you are using GPRS to connect to the mobile Internet, you can end your data

connection and then make an emergency call.

1To close your mobile Internet connection, press End twice.

2Enter the emergency number (for example, 911), and press Call.

6170.ENESv1_BIL_9236732.book Page 84 Tuesday, November 16, 2004 1:30 PM

Mobile Internet services

• Options while online

While you are connected to the mobile Internet, select Options to access the

following options. Some service providers may have customized these options.

Contact your service provider for more information if any of the following

options are not available.

Use wallet info—Use the wallet card information from the wallet application,

if the service page supports wallet. See “Wallet” on page 72.

Shortcuts—Open a new list of options, such as options specific to the current page.

Home—Go to the service home page.

Add bookmark—Saves the current page as a bookmark.

Bookmarks—Shows a list of all saved bookmarks. Bookmarks help you find a

mobile Internet site quickly.

Download links—Show the list of bookmarks for downloading tones, graphics,

games, or applications.

Save to folder—Add a bookmark for the current site to the list of bookmarks

for downloading tones, graphics, games, videos, or applications. The bookmark

then appears in the appropriate folder in the Download links submenu.

Other options—Show a list of other options, such as appearance and

security options.

Reload—Reload and update the current page.

End call—Disconnect from a service.

The browser supports functions that you can access while browsing. You can

make a voice call, send touch tones while a voice call is in progress, and save a

name and phone number from a page.

•Security

Security features may be required for some services, such as banking or shopping.

For such connections you need security certificates and possibly a security module

which may be available on your SIM card. For more information, contact your

service provider.

Security module

The security module improves security services and allows you to use a digital

signature. It can contain certificates and public and private keys. Your service

provider saves the certificates in the security module.

Select Menu > Web > Settings > Security settings > Security module

settings and one of the following:

Security module details—View the security module title, status, manufacturer,

and serial number.

Module PIN request—Select On to set the phone to ask for the module PIN

when using services provided by the security module.

6170.ENESv1_BIL_9236732.book Page 85 Tuesday, November 16, 2004 1:30 PM

Change module PIN—Change the module PIN, if allowed by the security module.

Change signing PIN—Select and change a signing PIN.

Digital signature

You can make digital signatures with your phone if your SIM card has a security

module. The signature can be traced back to you through the private key on the

security module and the user certificate that was used to perform the signature.

Using the digital signature can be the same as signing your name to a paper

bill, contract, or other document.

1While browsing, select a link on a page, such as the title of the book you

want to buy and its price.

The text to sign (possibly including amount, date, etc.) is shown.

2Check that the header text is Read and that the digital signature icon

is shown.

If the digital signature icon does not appear, there is a security breach. Do

not enter any personal data such as your signing PIN.

3Scroll through and read all of the text before signing.

4To sign the text, select Sign.

5Select the user certificate you want to use, enter the signing PIN (provided

with the SIM card if the SIM card has a security module), and select OK.

The digital signature icon disappears, and the service may display a

confirmation of your purchase.

Cache memory

The information or services you access with the browser are temporarily saved in

the cache memory of the phone.

If you tried to access or have accessed confidential information requiring

passwords (for example, your bank account), clear the cache after each use.

To clear the cache from the menu, select Web > Clear the cache.

To clear the cache while browsing, select Options > Other options >

Clear the cache.

Certificates

There are three kinds of certificates: server, authority, and user.

Certificates have a restricted lifetime. If Expired certificate or Certificate not

valid yet is shown even though the certificate should be valid, check that the

current date and time settings in your phone are correct. Before changing these

settings, make sure that you really trust the owner of the certificate and that

the certificate really belongs to the listed owner.

6170.ENESv1_BIL_9236732.book Page 86 Tuesday, November 16, 2004 1:30 PM

Mobile Internet services

SERVER CERTIFICATES

The phone uses a server certificate to create a connection with improved

security between the phone and the content server. The phone receives the

server certificate from the service provider before the connection is established.

The validity of the server certificate is checked using the authority certificates

saved in the phone. Server certificates are not saved.

AUTHORITY CERTIFICATES

Authority certificates are used by some services, such as banking, for checking

the validity of other certificates. Authority certificates can be saved in the

security module by the service provider, or they can be downloaded from the

network if the service supports the use of authority certificates.

To view authority certificates, select Web > Settings > Security settings >

Authority certificates > Certificate list, scroll to the desired certificate, and

select View.

USER CERTIFICATES

User certificates are issued to users by a certifying authority. User certificates

are required to make a digital signature. They associate the user with a specific

private key in a security module.

To view user certificates, select Web > Settings > Security settings > User

certificates > Certificate list, scroll to the desired certificate, and select View.

A cookie is data that a Web site saves in your phone browser cache memory. The

data can be, for example, your user information or your browsing preferences.

Cookies will be saved until you clear the cache memory.

1Select Menu > Web > Settings > Security settings > Cookies; or while

browsing, select Options > Other options > Security > Cookie settings.

2Select Allow to accept cookies or Reject to reject cookies.

Scripts over secure connection

To allow scripts from a secure page to be run, do one of the following:

• In the start screen, select Menu > Web > Settings > Security settings >

Scripts over secure connection > Allow.

• While browsing, select Options > Other options > Security > Script

settings > Allow.

6170.ENESv1_BIL_9236732.book Page 87 Tuesday, November 16, 2004 1:30 PM

14 SIM services

In addition to the functions available on the phone, your SIM card

may provide additional services that you can access through the SIM

services menu. This menu is shown only if it is supported by your SIM card.

The name and contents of the menu depend entirely on the service available.

For availability, rates, and information on using SIM services, contact your

service provider.

To see the messages sent between the phone and the network when you are

using the SIM services, select Menu > Settings > Phone settings > Confirm

SIM service actions > Yes.

Accessing these services may involve sending a text message or making a phone

call for which you may be charged.

6170.ENESv1_BIL_9236732.book Page 88 Tuesday, November 16, 2004 1:30 PM

Hardware and enhancements

15 Hardware and enhancements

• Hardware

Connection ports and other features

For the location of ports and other features of your phone, refer to “Phone

introduction—fold closed” on page 12, and “Phone introduction—fold open” on

page 13.

The BL-4C battery provides up to 4 hours of talk time and up to 270 hours of

standby time. Operation times are estimates and may vary depending on

network conditions, charging, and use of various features.

• Enhancements

Your phone is compatible with the following Nokia mobile enhancements:

Power

• 760-mAh Li-Ion battery (BL-4C)

• Retractable travel charger

(AC-1)

• Travel charger (ACP-12)

• Mobile charger (ACP-7)

• Mobile charger (LCH-12)

Data

• Data cable (DKU-2)

Audio

• Music stand (MD-1)

• Boom headset (HDB-4)

• Earbud headset (HS-5)

Accessibility

• Loopset (LPS-4)

• Phone adapter (HDA-10)

Car

• Plug-In Car Handsfree (HF-3)

• Headrest handsfree (BHF-3)

Body

• Image album (PD-1)

• Kaleidoscope (RX-11)

6170.ENESv1_BIL_9236732.book Page 89 Tuesday, November 16, 2004 1:30 PM

16 Reference Information

• Battery information

Charging and discharging

Your device is powered by a rechargeable battery. The full performance of a new

battery is achieved only after two or three complete charge and discharge

cycles. The battery can be charged and discharged hundreds of times but it will

eventually wear out. When the talk and standby times are noticeably shorter than

normal, buy a new battery. Use only Nokia approved batteries, and recharge your

battery only with Nokia approved chargers designated for this device.

Unplug the charger from the electrical plug and the device when not in use. Do

not leave the battery connected to a charger. Overcharging may shorten its

lifetime. If left unused, a fully charged battery will lose its charge over time.

Temperature extremes can affect the ability of your battery to charge.

Use the battery only for its intended purpose. Never use any charger or battery

that is damaged.

Do not short-circuit the battery. Accidental short-circuiting can occur when a

metallic object such as a coin, clip, or pen causes direct connection of the

positive (+) and negative (-) terminals of the battery. (These look like metal

strips on the battery.) This might happen, for example, when you carry a spare

battery in your pocket or purse. Short-circuiting the terminals may damage the

battery or the connecting object.

Leaving the battery in hot or cold places, such as in a closed car in summer or

winter conditions, will reduce the capacity and lifetime of the battery. Always try

to keep the battery between 59°F and 77°F (15°C and 25°C). A device with a hot

or cold battery may not work temporarily, even when the battery is fully charged.

Battery performance is particularly limited in temperatures well below freezing.

Do not dispose of batteries in a fire! Dispose of batteries according to local

regulations. Please recycle when possible. Do not dispose as household waste.

• Enhancements

A few practical rules about accessories and enhancements:

• Keep all accessories and enhancements out of the reach of small children.

• When you disconnect the power cord of any accessory or enhancement,

grasp and pull the plug, not the cord.

• Check regularly that enhancements installed in a vehicle are mounted and

are operating properly.

• Installation of any complex car enhancements must be made by qualified

personnel only.

6170.ENESv1_BIL_9236732.book Page 90 Tuesday, November 16, 2004 1:30 PM

Reference Information

• Enhancements, batteries, and chargers

Check the model number of any charger before use with this device. This device

is intended for use when supplied with power from AC-1, ACP-12, ACP-7, or

LCH-12 chargers.

Warning: Use only batteries, chargers, and enhancements approved by

Nokia for use with this particular model. The use of any other types may

invalidate any approval or warranty, and may be dangerous.

For availability of approved enhancements, please check with your dealer.

When you disconnect the power cord of any enhancement, grasp and pull the

plug, not the cord.

Your device and its enhancements may contain small parts. Keep them out of

reach of small children.

• Care and maintenance

Your device is a product of superior design and craftsmanship and should be

treated with care. The suggestions below will help you protect your warranty

coverage and enjoy your device for many years.

• Keep the device dry. Precipitation, humidity, and all types of liquids or moisture

can contain minerals that will corrode electronic circuits. If your device does

get wet, remove the battery and allow the device to dry completely before

replacing it.

• Do not use or store the device in dusty, dirty areas. Its moving parts and

electronic components can be damaged.

• Do not store the device in hot areas. High temperatures can shorten the life

of electronic devices, damage batteries, and warp or melt certain plastics.

• Do not store the device in cold areas. When the device returns to its normal

temperature, moisture can form inside the device and damage electronic

circuit boards.

• Do not attempt to open the device other than as instructed in this guide.

• Do not drop, knock, or shake the device. Rough handling can break internal

circuit boards and fine mechanics.

• Do not use harsh chemicals, cleaning solvents, or strong detergents to

clean the device.

• Do not paint the device. Paint can clog the moving parts and prevent

proper operation.

• Use a soft, clean, dry cloth to clean any lenses (such as camera, proximity

sensor, and light sensor lenses).

• Use only the supplied or an approved replacement antenna. Unauthorized

antennas, modifications, or attachments could damage the device and

may violate regulations governing radio devices.

6170.ENESv1_BIL_9236732.book Page 91 Tuesday, November 16, 2004 1:30 PM

All of the above suggestions apply equally to your device, battery, charger, or

any enhancement. If any device is not working properly, take it to the nearest

authorized service facility for service.

• Additional safety information

Operating environment

Remember to follow any special regulations in force in any area and always switch

off your device when its use is prohibited or when it may cause interference or

danger. Use the device only in its normal operating positions. This device meets

RF exposure guidelines when used either in the normal use position against the

ear or when positioned at least 5/8 inch (1.5 cm) away from the body. When a

carry case, belt clip, or holder is used for body-worn operation, it should not

contain metal and should position the device at least 5/8 inch (1.5 cm) away

from your body.

In order to transmit data files or messages, this device requires a quality connection

to the network. In some cases, transmission of data files or messages may be

delayed until such a connection is available. Ensure the above separation distance

instructions are followed until the transmission is completed.

Medical devices

Operation of any radio transmitting equipment, including wireless phones, may

interfere with the functionality of inadequately protected medical devices. Consult

a physician or the manufacturer of the medical device to determine if they are

adequately shielded from external RF energy or if you have any questions. Switch

off your phone in health care facilities when any regulations posted in these

areas instruct you to do so. Hospitals or health care facilities may be using

equipment that could be sensitive to external RF energy.

PACEMAKERS

Pacemaker manufacturers recommend that a minimum separation of 6 in (15.3 cm)

be maintained between a wireless phone and a pacemaker to avoid potential

interference with the pacemaker. These recommendations are consistent with the

independent research by and recommendations of Wireless Technology Research.

To minimize the potential for interference, persons with pacemakers should

• Always keep the device more than 6 in (15.3 cm) from their pacemaker

when the device is switched on

• Not carry the device in a breast pocket

• Hold the device to the ear opposite the pacemaker

If you have any reason to suspect that interference is taking place, switch off

your device immediately.

6170.ENESv1_BIL_9236732.book Page 92 Tuesday, November 16, 2004 1:30 PM

Reference Information

HEARING AID

Some digital wireless devices may interfere with some hearing aids. If interference

occurs, consult your service provider.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic

systems in motor vehicles such as electronic fuel injection systems, electronic

antiskid (antilock) braking systems, electronic speed control systems, air bag

systems. For more information, check with the manufacturer or its representative

of your vehicle or any equipment that has been added.

Only qualified personnel should service the device, or install the device in a vehicle.

Faulty installation or service may be dangerous and may invalidate any warranty

that may apply to the device. Check regularly that all wireless device equipment in

your vehicle is mounted and operating properly. Do not store or carry flammable

liquids, gases, or explosive materials in the same compartment as the device,

its parts, or enhancements. For vehicles equipped with an air bag, remember

that an air bags inflate with great force. Do not place objects, including installed

or portable wireless equipment in the area over the air bag or in the air bag

deployment area. If in-vehicle wireless equipment is improperly installed and

the air bag inflates, serious injury could result.

Potentially explosive environments

Switch off your device when in any area with a potentially explosive atmosphere

and obey all signs and instructions. Potentially explosive atmospheres include

areas where you would normally be advised to turn off your vehicle engine.

Sparks in such areas could cause an explosion or fire resulting in bodily injury

or even death. Switch off the device at refuelling points such as near gas pumps

at service stations. Observe restrictions on the use of radio equipment in fuel

depots, storage, and distribution areas, chemical plants or where blasting

operations are in progress. Areas with a potentially explosive atmosphere are

often but not always clearly marked. They include below deck on boats, chemical

transfer or storage facilities, vehicles using liquefied petroleum gas (such as

propane or butane), and areas where the air contains chemicals or particles

such as grain, dust or metal powders.

FCC regulations prohibit using your wireless device while in the air. The use of

wireless telephones in an aircraft may be dangerous to the operation of the

aircraft, disrupt the wireless telephone network, and may be illegal.

Failure to observe these instructions may lead to suspension or denial of

telephone services to the offender, legal action, or both.

6170.ENESv1_BIL_9236732.book Page 93 Tuesday, November 16, 2004 1:30 PM

EMERGENCY CALLS

Important: Wireless phones, including this phone, operate using radio

signals, wireless networks, landline networks, and user-programmed

functions. Because of this, connections in all conditions cannot be

guaranteed. You should never rely solely on any wireless phone for

essential communications like medical emergencies.

To make an emergency call:

1If the phone is not on, switch it on. Check for adequate signal strength. Some

networks may require that a valid SIM card is properly inserted in the phone.

2Press End as many times as needed to clear the display and ready the

phone for calls.

3Key in the official emergency number for your present location. Emergency

numbers vary by location.

4Press Call.

If certain features are in use, you may first need to turn those features off before

you can make an emergency call. Consult this guide or your service provider.

When making an emergency call, give all the necessary information as accurately

as possible. Your wireless phone may be the only means of communication at the

scene of an accident. Do not end the call until given permission to do so.

6170.ENESv1_BIL_9236732.book Page 94 Tuesday, November 16, 2004 1:30 PM

Reference Information

• Certification information (SAR)

THE NOKIA 6170 DEVICE MEETS GUIDELINES FOR EXPOSURE TO RADIO WAVES.

Your mobile device is a radio transmitter and receiver. It is designed and

manufactured not to exceed the limits for exposure to radio frequency (RF) energy

recommended by international guidelines (ICNIRP). These limits establish

permitted levels of RF energy for the general population. The guidelines are based

on standards that were developed by independent scientific organizations through

periodic and thorough evaluation of scientific studies. The standards and guidelines

include a substantial safety margin designed to assure the safety of the public,

regardless of age and health and to account for any variations in measurements.

The exposure guidelines for mobile devices employ a unit of measurement known

as the Specific Absorption Rate or SAR. The SAR limit stated in the international

guidelines is 2.0 watts/kilogram (W/kg) averaged over ten grams of tissue. Tests

for SAR are conducted using standard operating positions with the device

transmitting at its highest certified power level in all tested frequency bands.

The actual SAR level of an operating device can be well below the maximum

value because the device is designed to use only the power required to reach

the network. That amount changes depending on a number of factors such as

how close you are to a network base station. The highest SAR value when tested

according to international testing procedures for use at the ear for device type

RM-47 is 0.22 W/kg and for device type RM-48 is 0.61 W/kg. Your phone’s

device type is listed on the label located under the battery.

SAR values may vary depending on national reporting and testing requirements

and the network band. Use of device accessories and enhancements may result

in different SAR values. Additional SAR information may be provided under

product information at www.nokia.com.

USA and Canada: The SAR limit of USA (FCC) and Canada (IC) is 1.6 W/kg averaged

over one gram of tissue. Device types RM-47 and RM-48 have also been tested

against this SAR limit. The highest SAR value reported under this standard during

product certification for device type RM-47 when used at the ear is 0.43 W/kg

and when properly worn on the body is 0.11 W/kg. The highest SAR value reported

under this standard during product certification for device type RM-48 when

used at the ear is 1.12 W/kg and when properly worn on the body is 1.09 W/kg.

Information about this device can be found on the FCC's website at

http://www.fcc.gov/oet/fccid by searching the equipment authorization

system using FCC IDs: LJPRM-47 and LJPRM-48.

6170.ENESv1_BIL_9236732.book Page 95 Tuesday, November 16, 2004 1:30 PM

• Technical information

Feature Specification

Weight With 760-mAh BL-4C battery:

4.27 oz (121 g) 900/1800/1900 version

4.34 oz (123 g) 850/1800/1900 version

Size Volume:

4.8 in3 (79 cm3) 900/1800/1900 version

5.2 in3 (85 cm3) 850/1800/1900 version

Length: 3.5 in (88 mm)

Width: 1.81 in (46 mm )

Thickness: (with fold closed)

0.87 in (22 mm)

0.94 in (24 mm)

Frequency range GSM 850

824—849 MHz (TX)

869—894 Mhz (TX)

GSM 900

880.2—914.8 MHz (TX)

925.2—959.8 MHz (RX)

GSM 1800

1710.2—1784.8 MHz (TX)

1805.2—1879.8 MHz (RX)

GSM 1900

1850.2—1909.8 MHz (TX)

1930.2—1989.8 MHz (RX)

Transmitter output power Up to 2 W

Battery voltage 3.7 V nominal

Operating temperature 14°F to + 131°F (-10°C to + 55°C)

aTalk time,

Standby time

Talk time: up to 4 hours

Standby time: up to 270 hours (11 days)

a. Battery talk and standby times are estimates only and depend on signal

strength, network conditions, features used, battery age and condition

(including the effect of charging habits), temperatures to which battery is

exposed, use in digital mode, and many other factors. Please note that the

amount of time a phone is used for calls will affect its standby time.

Likewise, the amount of time that the phone is turned on and in the start

screen will affect its talk time.

6170.ENESv1_BIL_9236732.book Page 96 Tuesday, November 16, 2004 1:30 PM

Index

Numerics

1-touch dialing 44, 54

accessibility 17

activate call forwarding 53

alarm clock 66

answer a call 24

anykey answer 54

applications menu 78

battery 89

bookmarks 83

business cards 43

calculator 75

calendar 67

call

answer 24

forwarding 53

log 47

make 23

record 65

reject 24

restriction 58

waiting 55

caller

groups 45

ID 55

camera 63

clock radio 66

closed user groups 59

connection ports 89

connectivity

infrared 51

contacts 40

1-touch dialing 44

add image 42

business cards 43

call from 42

caller groups 45

copy 43

delete 42

find entry 42

menu options 40

save 40

search 42

currency conversion 75

customer care 11

customize profile 48

data communication 53

date settings 49

definition of terms 96

delete

1-touch dialing entry 44

contact entry 42

fixed dialing entry 59

messages 31

voice tags 45

dialed numbers, view 47

dialing

1-touch 44

fixed 58

dictionary 27

display

language 55

settings 49

download

applications 79

games 78

emergency calls

while online 84

with keys locked 23

enhancements 89

fixed dialing 58

folders

gallery 62

message 29

6170.ENESv1_BIL_9236732.book Page 97 Tuesday, November 16, 2004 1:30 PM

forward messages 31

gallery 62

games 78

glossary 96

GPRS mobile link 51

help text 56

chat 35

contacts 36

offline menu 34

online menu 34

settings 37

images

add to contacts 42

edit in gallery 62

info

message service 38

infrared connectivity 51

install SIM card 19

instant messaging, see IM

Internet

options 85

security 85

service 81

keyguard 23

language 55

lap timer 76

make a call 23

media 63

camera 63

player 64

voice recorder 65

menus 18

message alert tone 48

messages

delete 31

folders 29

forward 31

info message service 38

instant 33

linked 28

multimedia 31

reply 30

send 29, 32

service commands 39

settings 29, 31

text 29

voice 38

missed calls, view 47

mobile link 51

GPRS 51

multimedia messages 31

Nokia PC Suite 17

notes

calendar 67

to-do 69

organizer 66

alarm clock 66

calendar 67

to-do list 69

over the air settings 17

PC Suite 17

personal shortcuts 50

phone

memory 55

PIN code 57, 60

private groups 35

profiles 48

PUK codes 61

6170.ENESv1_BIL_9236732.book Page 98 Tuesday, November 16, 2004 1:30 PM

quick guide 2

read messages 30

received calls, view 47

record

calls 65

video clip 63

voice tags 45

redial 54

registration 10

reject a call 24

reply to messages 30

restore factory settings 61

ringing tone 48

ringing volume 48

safety 7

security

code 60

mobile Internet 85

select profile 48

send

business card 43

caller ID 55

multimedia messages 32

text messages 29

service

commands 39

set

alarm clock 66

time and date 49

settings 48

call 53

camera 64

display 49

enhancements 56

IM 37

OTA 17

personal shortcuts 50

phone 55

restore factory settings 61

security 57

time and date 49

tone 49

shortcuts

menu 18

personal 50

SIM card 19

speed dialing 44

stopwatch 76

summary after call 55

synchronization 70

text

entry 26

messages 29

time settings 49

timed profile 48

timer 77

to-do list 69

tones 48

turn off alarm clock 66

vibrating alert 48

video recorder 63

view

call lists 47

voice

dialing 44

messages 38

recorder 65

voice tags 45

change 45

volume, ringing tone 48

wallet 72

welcome note 56

6170.ENESv1_BIL_9236732.book Page 99 Tuesday, November 16, 2004 1:30 PM

NOTES

6170.ENESv1_BIL_9236732.book Page 100 Tuesday, November 16, 2004 1:30 PM

Microsoft RM-48 GSM850/1800/1900 Cellular Telephone User Manual 6170 ENESv1 BIL 9236732

Microsoft Mobile Oy GSM850/1800/1900 Cellular Telephone 6170 ENESv1 BIL 9236732

Manual

Navigation menu

Namespaces

Views

Navigation
