Microsoft RM-497 GSM 850/900/1800/1900 Cellular Phone w/BT User Manual Manual
Microsoft Mobile Oy GSM 850/900/1800/1900 Cellular Phone w/BT Manual
Manual
User Guide
Issue FCC Draft 7 July 2009
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-497 product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the
Declaration of Conformity can be found at www.nokia.com/phones/
declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People and Navi are trademarks or registered trademarks of Nokia Corporation. Nokia tune
is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or
tradenames of their respective owners.
Portions of the Nokia Maps software are ©1996-2009 The FreeType Project. All rights reserved.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without
the prior written permission of Nokia is prohibited. Nokia operates a policy of continuous development. Nokia
reserves the right to make changes and improvements to any of the products described in this document without
prior notice.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in
connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer
engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a
licensed video provider. No license is granted or shall be implied for any other use. Additional information, including
that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://
www.mpegla.com.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS
LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT
DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF
ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS
DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR
NOTICE.
The availability of particular products and applications and services for these products may vary by region. Please
check with your Nokia dealer for details and availability of language options. This device may contain commodities,
technology or software subject to export laws and regulations from the US and other countries. Diversion contrary
to law is prohibited.
FCC NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving
equipment). The FCC can require you to stop using your telephone if such interference cannot be eliminated. If you
require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation. Any changes or
modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
0434
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Model number: 7020a-2
/Issue FCC Draft 7 July 2009 EN
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Contents
Safety...........................................6
1. Get started...............................7
Keys and parts............................................7
Remove battery.........................................8
Install SIM card...........................................8
Insert a memory card................................9
Insert battery.............................................9
Charge the battery.....................................9
GSM antenna............................................10
Accessories...............................................10
Magnets and magnetic fields.................10
2. Switch it on............................11
About your device...................................11
Network services.....................................11
Access codes.............................................11
Switch the device on and off..................12
Home screen ...........................................12
Navigate the menus................................14
Functions without a SIM card ................15
Applications running in background.....15
Flight profile............................................15
Tapping....................................................15
3. Make it your device...............16
Basic settings...........................................16
Personalise your device..........................17
Connect.....................................................19
Network provider services......................21
4. Stay in touch..........................22
Make calls.................................................22
Text and messages..................................25
5. Image and video...................28
Capture images........................................28
Record video clips....................................28
Camera and video settings.....................28
Gallery.......................................................29
Print images.............................................30
Memory card............................................30
6. Entertainment.......................30
Listen to music.........................................30
Web ..........................................................32
Games and applications..........................34
7. Maps......................................35
Download maps.......................................35
Maps and GPS...........................................36
Extra services...........................................36
8. Organise................................36
Manage contacts......................................36
Business cards..........................................37
Date and time..........................................38
Alarm clock...............................................38
Calendar....................................................38
To-do list..................................................38
Notes.........................................................39
Nokia PC Suite..........................................39
Calculator.................................................39
Countdown timer....................................39
Stopwatch................................................40
9. Green tips..............................40
Save energy..............................................40
Recycle......................................................40
Learn more...............................................40
Digital rights management.......41
Third-party applications...........41
Accessories................................42
Battery.......................................42
Battery and charger information...........42
Nokia battery authentication
guidelines.................................................43
Care and maintenance..............44
Recycle......................................................45
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Additional safety
information...............................45
Magnets and magnetic fields.................45
Small children..........................................45
Operating environment..........................45
Medical devices........................................45
Vehicles.....................................................46
Potentially explosive environments......47
Emergency calls.......................................47
Certification information (SAR)..............47
Index.........................................49
Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when
it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
6 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
1. Get started
Get to know your device, insert the battery, SIM card, and memory card, and learn some
important information about your device.
Keys and parts
1Earpiece
2Display
3Selection keys
4Call key
5Navi™ key; hereafter referred to as scroll key
6Microphone
7Middle selection key
8End/Power key
9Keypad
10 USB port
11 Charger connector
12 Secondary display
13 Wrist strap eyelet
14 2-megapixel
camera
15 Headset connector
Note: Avoid touching this connector as it is intended for use by authorised service
personnel only.
www.nokia.com/support 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Remove battery
Always switch the device off and disconnect the charger before removing the battery.
1. With the back of the phone facing you, remove the back cover.
2. If the battery is inserted, remove the battery.
Install SIM card
The SIM card and its contacts can be easily damaged by scratches or bending, so be
careful when handling, inserting, or removing the card.
1. Remove the battery if inserted, and slide the SIM card holder to unlock.
2. Open the card holder.
3. Insert the SIM card into the holder with the contact surface facing down.
4. Close the card holder.
5. Slide the card holder to lock.
Get started
8 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Insert a memory card
Use only compatible MicroSD cards approved by Nokia for use with this
device. Nokia uses approved industry standards for memory cards, but some
brands may not be fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored on the card.
Your device supports microSD cards with a capacity of up to 16 GB. The size of a single
file must not exceed 2 GB.
Insert a memory card
1. Remove the battery if inserted, and slide
the memory card holder to unlock.
2. Swing the card holder open.
3. Insert the memory card into the card
holder with the contact surface facing
down.
4. Close the card holder.
5. Slide the card holder to lock.
Insert battery
1. Remove the back cover if in place, observe the battery contacts, and
insert the battery
2. Replace the back cover.
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low
charge, do the following:
1. Connect the charger to a wall outlet.
2. Connect the charger to the device.
3. When the device indicates a full charge, disconnect the charger
from the device, then from the wall outlet.
You do not need to charge the battery for a specific length of time,
and you can use the device while it is charging. If the battery is
completely discharged, it may take several minutes before the
charging indicator appears on the display or before any calls can be made.
Charging the device while listening to the radio may affect the quality of reception.
Get started
www.nokia.com/support 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
GSM antenna
Your device may have internal and external antennas. Avoid touching the
antenna area unnecessarily while the antenna is transmitting or receiving.
Contact with antennas affects the communication quality and may cause a
higher power level during operation and may reduce the battery life.
The figure shows the GSM antenna area marked in grey.
Accessories
Connect a USB cable
Headset
Warning: When you use the headset, your ability to hear outside sounds may
be affected. Do not use the headset where it can endanger your safety.
When connecting any external device or any headset, other than those approved by
Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume
levels.
Do not connect products that create an output signal as this may cause damage to the
device. Do not connect any voltage source to the Nokia AV Connector.
Strap
Thread the strap, and tighten it.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
Get started
10 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
2. Switch it on
Learn how to switch on your device, and how to use the basic functions.
About your device
The wireless device described in this guide is approved for use on the GSM 900, 1800,
850, 1900 MHz networks. Contact your service provider for more information about
networks.
When using the features in this device, obey all laws and respect local customs, privacy
and legitimate rights of others, including copyrights.
Copyright protection may prevent some images, music, and other content from being
copied, modified, or transferred.
Your device may have preinstalled bookmarks and links for third-party internet sites.
You may also access other third-party sites through your device. Third-party sites are
not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If
you choose to access such sites, you should take precautions for security or content.
Warning: To use any features in this device, other than the alarm clock, the device
must be switched on. Do not switch the device on when wireless device use may cause
interference or danger.
Remember to make back-up copies or keep a written record of all important information
stored in your device.
When connecting to any other device, read its user guide for detailed safety instructions.
Do not connect incompatible products.
The images in this guide may differ from your device display.
Network services
To use the device you must have service from a wireless service provider. Some features
are not available on all networks; other features may require that you make specific
arrangements with your service provider to use them. Network services involve
transmission of data. Check with your service provider for details about fees in your
home network and when roaming on other networks. Your service provider can explain
what charges will apply.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device menu. Your
device may also have customized items such as menu names, menu order, and icons.
Access codes
To set how your device uses the access codes and security settings, select Menu >
Settings and Security > Access codes.
Switch it on
www.nokia.com/support 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
●The security code helps to protect your device against unauthorised use. The preset
code is 12345. You can change the code and set the device to request the code. Some
operations require the security code regardless of the settings, for example, if you
want to restore the factory settings. Keep the code secret and in a safe place separate
from your device. If you forget the code and your device is locked, your device will
require service and additional charges may apply. For more information, contact a
Nokia Care point or your device dealer.
●The PIN (UPIN) code, supplied with the SIM (USIM) card, helps to protect the card
against unauthorised use.
●The PIN2 (UPIN2) code, supplied with some SIM (USIM) cards, is required to access
certain services.
●PUK (UPUK) and PUK2 (UPUK2) codes may be supplied with the SIM (USIM) card. If you
enter the PIN code incorrectly three times in succession, you are asked for the PUK
code. If the codes are not supplied, contact your service provider.
●The barring password is required when using the call barring service to restrict calls
to and from your device (network service).
●To view or change the security module settings for the browser, select Menu >
Settings and Security > Security module.
Switch the device on and off
Switch on and off — Press and hold the power key.
Enter the PIN code — If requested , enter the code PIN code (displayed as
****).
Set the time and date — If requested, enter the time and date.
When you switch on your device for the first time, you may be prompted to get the
configuration settings from your service provider (network service). For more
information, contact your service provider.
Home screen
When the device is ready for use, and you have not entered any characters, the device
is in the home screen.
Switch it on
12 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Display
7
6
10
1 — Signal strength of the cellular network
2 — Battery charge status
3 — Indicators
4 — Name of the network or the operator logo
5 — Clock
6 — Date (only if the enhanced home screen is deactivated)
7 — Display
8 — Function of the left selection key
9 — Function of the scroll key
10 — Function of the right selection key
You can change the function of the left and right selection key. See " Left and right
selection keys ", p. 18.
Enhanced home screen
With the enhanced home screen, you can display a list of selected information and
features that you can directly access.
Select Menu > Settings and Display > Home screen.
Activate the enhanced home screen — Select Home screen mode > On.
Organise and personalise the enhanced home screen — Select Personalise view.
Select the key used to activate the enhanced home screen — Select Home screen
key.
Navigate in the home screen — Scroll up or down to navigate the list, and select
Select, View, or Edit. The arrows indicate that further information is available.
Stop navigating — Select Exit.
Switch it on
www.nokia.com/support 13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Shortcuts
When your device is in the home screen, you can use shortcuts.
List missed, received, and dialled calls — Press the call key. To make a call, scroll to
the number or name, and press the call key.
Open the web browser — Press and hold 0.
Call the voice mailbox — Press and hold 1.
Use other keys as shortcuts — See "Dialling shortcuts", p. 23.
Indicators
You have unread messages.
You have unsent, cancelled, or failed messages.
The keypad is locked.
The device does not ring for incoming calls or text messages.
An alarm is set.
/ The device is registered to the GPRS or EGPRS network.
/ A GPRS or EGPRS connection is open.
/ The GPRS or EGPRS connection is suspended (on hold).
Bluetooth connectivity is activated.
All incoming calls are diverted to another number.
Calls are limited to a closed user group.
The currently active profile is timed.
A headset is connected to the device.
The device is connected to another device, using a USB cable.
Navigate the menus
The device offers a range of functions that are grouped into menus.
1. To access the menu, select Menu.
2. Scroll through the menu, and select an option (for example, Settings).
3. If the selected menu contains further submenus, select one (for example, Call).
4. Select the setting of your choice.
5. To return to the previous menu level, select Back.
To exit the menu, select Exit.
Change the menu view — Select Options > Main menu view. Scroll right, and select
from the available options.
Switch it on
14 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Rearrange the menu — Select Options > Organise. Scroll to the menu item to be
moved, and select Move. Scroll to where you want to move the menu item, and select
OK. To save the change, select Done > Yes.
Functions without a SIM card
Some functions of your device may be used without inserting a SIM card, such as
Organiser functions and games. Some functions appear dimmed in the menus and
cannot be used.
Applications running in background
Leaving applications running in the background increases the demand on battery power
and reduces the battery life.
Flight profile
In radio sensitive environments, where you are asked not to use your device, you can
still access your calendar, contacts list, and offline games by activating the flight profile.
indicates that the flight profile is active.
Activate the flight profile — Select Menu > Settings > Profiles and Flight >
Activate or Personalise.
Deactivate the flight profile — Select any other profile.
Warning: With the Flight profile you cannot make or receive any calls, including
emergency calls, or use other features that require network coverage. To make calls,
you must first activate the phone function by changing profiles. If the device has been
locked, enter the lock code.
If you need to make an emergency call while the device is locked and in the Flight profile,
you may be also able to enter an official emergency number programmed in your device
in the lock code field and select 'Call'. The device will confirm that you are about to exit
Flight profile to start an emergency call.
Tapping
Select Menu > Settings > Phone > Sensor settings to activate the tapping function
and vibration feedback.
Mute calls or alarms — Double-tap the phone.
Reject a call or snooze an alarm after muting it — Double-tap the phone again.
Display the clock — Double-tap the phone.
If you have missed calls or received new messages, you must view them before you can
see the clock.
Switch it on
www.nokia.com/support 15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
3. Make it your device
Set up your device, personalise it, and connect it in several ways.
Basic settings
Phone settings
Select Menu > Settings and Phone.
Select from the following:
●Language settings — To set the language of your device, select Phone
language and a language. To set the language of your device according to the
information on the SIM card, select Phone language > Automatic.
●Touch music keys — Activate the touch music keys..
●Memory status — View the memory consumption.
●Automatic keyguard — The keypad is locked automatically after a preset time delay
when the device is in the standby or home screen and no function has been used.
●Security keyguard — Request the security code to unlock the keypad.
●Voice recognition — Set up voice commands, or start voice recognition training.
●Flight query — Set the device to prompt for the Flight profile when you switch the
device on. In the Flight profile, all radio connections are closed.
●Phone updates — Allow software updates from your service provider (network
service). The available options may vary.
●Operator selection — Manually select which network to use.
●Help text activation — Set the device to display help text.
●Start-up tone — Play a tone when you switch the device on.
Security settings
SelectMenu > Settings and Security .
When security features that restrict calls are in use (such as call barring, closed user
group, and fixed dialling), calls may be possible to the official emergency number
programmed into your device. Call barring and call diverting cannot be active at the
same time.
●PIN code request or UPIN code request — Set the device to request for the PIN or
UPIN code every time the device is switched on. Some SIM cards do not allow the
code request to be deactivated.
●Call barring service — Restrict incoming calls to and outgoing calls from your device
(network service). A barring password is required.
●Fixed dialling — Restrict your outgoing calls to selected phone numbers if
supported by your SIM card. When fixed dialling is activated, GPRS connections are
not possible except while sending text messages over a GPRS connection. In this case,
the recipient’s phone number and the message centre number must be included in
the fixed dialling list.
Make it your device
16 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
●Closed user group — Define a group of people whom you can call and who can call
you (network service).
●Security level — To request the security code whenever a new SIM card is inserted
into the device, select Phone.
●Access codes — Change the security code, PIN code, UPIN code, PIN2 code, or barring
password.
●PIN2 code request — Select whether to request the PIN2 code when using a specific
device feature protected by the PIN2 code. Some SIM cards do not allow the code
request to be deactivated. This option may not be available depending on your SIM
card. For details, contact your service provider.
●Code in use — Display and select the type of PIN code to be used.
●Auth. certificates or User certificates — View the list of the authority or user
certificates available on your device.
●Security module — View Sec. module details, activate Module PIN request, or
change the module PIN and signing PIN.
Personalise your device
Give your device a personal touch with ringing tones, display backgrounds, and themes.
Add shortcuts for your preferred features, and attach enhancements.
Profiles
Your device has several profiles, which you can customise.
Select Menu > Settings and Profiles.
Select the desired profile and from the following:
●Activate — Activate the profile.
●Personalise — Modify profile settings.
●Timed — Set the profile to be active for a certain period of time. When the time set
for the profile expires, the previous profile that was not timed becomes active.
Themes
With themes, you can personalise your device.
Select Menu > Settings and Themes.
Select a theme — Select Select theme > Themes and a theme.
Download more themes — Select Theme downloads.
Tones
You can modify the tone settings of the currently active profile.
Select Menu > Settings and Tones. You can find the same settings in the Profiles menu.
Make it your device
www.nokia.com/support 17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Display
Select Menu > Settings and Display.
Select from the following:
●Wallpaper — Add a background image to the home screen.
●Home screen — Activate, organise, and personalise the home screen.
●Home scr. font col. — Select the font colour for the home screen.
●Navigat. key icons — Display the scroll key icons in the home screen.
●Notification details — Display details in missed call and message notifications.
●Main menu view — Select the layout of the main menu.
●Font size — Set the font size for messaging, contacts, and web pages.
●Operator logo — Display the logo of the currently selected operator.
●Cell info display — Display the cell identity, if available from the network.
My shortcuts
With personal shortcuts, you get quick access to frequently used functions of your
device. Select Menu > Settings and My shortcuts.
Left and right selection keys
To change the function assigned to the left or right selection key, select Left selection
key or Right selection key, and the desired function.
In the home screen , if the left selection key is Go to, to add, remove, or reorganise
functions, select Go to > Options > Select options or Organise.
Other shortcuts
Select from the following:
●Navigation key — Assign other functions from a predefined list to the scroll key.
●Home screen key — Select the movement of the scroll key to activate the home
screen.
Assign dialling shortcuts
1. Select Menu > Contacts > Speed dials, and scroll to a number key.
2. Select Assign, or, if a number has already been assigned to the key, select
Options > Change.
3. Enter a number or search for a contact.
Voice commands
You can use voice commands to make phone calls, launch applications, and activate
profiles. Voice commands are language-dependent.
Select Menu > Settings and Phone.
Set the language — Select Language settings > Phone language and the language.
Make it your device
18 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Train voice recognition to your voice — Select Voice recognition > Voice
training.
Activate a voice command for a function — Select Menu > Settings > Phone >
Voice recognition > Voice commands, a feature, and the function. indicates that
the voice command is activated. If is not displayed, select Add.
Play an activated voice command — Select Play.
Use voice commands — See "Voice dialling", p. 23.
Rename or deactivate a voice command — Scroll to a function, and select Options >
Edit or Remove.
Activate or deactivate all voice commands — Select Options > Add all or Remove
all.
Connect
Your device provides several features to connect to other devices to transmit and receive
data.
Bluetooth wireless technology
With Bluetooth wireless technology, you can connect your device, using radio waves,
to a compatible Bluetooth device within 10 metres (32 feet).
Select Menu > Settings > Connectivity > Bluetooth.
This device is compliant with Bluetooth Specification 2.1 + EDR supporting the following
profiles: Advanced Audio Distribution Profile (A2DP) Audio Video Remote Control Profile
(AVRCP) Device ID (DID) Dial-up Networking Profile (DUN) FileTransfer Profile (FTP)
General Access Profile (GAP) Generic Audio/Video Distribution Profile (GAVDP) Generic
Object Exchange Profile (GOEP) Handsfree Profile (HFP) Headset Profile (HSP) Object Push
Profile (OPP) Phonebook Access Profile (PBAP) Serial Port Profile (SPP) Service Discovery
Application Profile (SDAP) SIM Access Profile (SAP) SIM access, and serial port. To ensure
interoperability between other devices supporting Bluetooth technology, use Nokia
approved accessories for this model. Check with the manufacturers of other devices to
determine their compatibility with this device.
Features using Bluetooth technology increase the demand on battery power and reduce
the battery life.
Set up a Bluetooth connection
1. Select My phone's name, and enter a name for your device.
2. To activate Bluetooth connectivity, select Bluetooth > On. indicates that
Bluetooth connectivity is active.
3. To connect your device to an audio accessory, select Conn. to audio acc. and the
accessory.
Make it your device
www.nokia.com/support 19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
4. To pair your device with any Bluetooth device in range, select Paired devices >
Add new device.
5. Scroll to a found device, and select Add.
6. Agree on a passcode (up to 16 characters) with the user of the other device and enter
the passcode on your device. To establish the connection, enter the passcode on the
other device, when requested.
Operating the device in hidden mode is a safer way to avoid malicious software. Do not
accept Bluetooth connectivity from sources you do not trust. Alternatively, switch off
the Bluetooth function. This does not affect other functions of the device.
Connect your PC to the internet — You can use Bluetooth technology to connect your
compatible PC to the internet without the PC Suite software. Your device must be able
to connect to the internet (network service), and your PC must support Bluetooth
technology. After connecting to the network access point (NAP) service of the device,
and pairing with your PC, your device automatically opens a packet data connection to
the internet.
Packet data
General packet radio service (GPRS) is a network service that allows mobile devices to
send and receive data over an internet protocol (IP) based network.
Select Menu > Settings and Connectivity > Packet data > Packet data conn..
Select from following:
●When needed — Establish the packet data connection only when an application
needs it. The connection is closed when the application is closed.
●Always online — Automatically connect to a packet data network when you switch
the device on.
You can use your device as a modem by connecting it to a compatible PC. For details,
see the Nokia PC Suite documentation.
USB data cable
You can use the USB data cable to transfer data between your device and a compatible
PC or a printer supporting PictBridge.
Select USB mode
To activate the device for data transfer or image printing, connect the USB data cable,
and select from the following:
●PC Suite — Use Nokia PC Suite on your PC.
●Printing & media — Use your device with a PictBridge compatible printer or with
a compatible PC.
●Data storage — Connect to a PC that does not have Nokia software, and use your
device as data storage
Change USB mode — Select Menu > Settings > Connectivity > USB data cable
and the desired USB mode.
Make it your device
20 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Synchronisation and backup
Select Menu > Settings > Sync & backup > Synchronisation and from the
following:
●
●Create backup — Create a backup of selected data.
●Restore backup — Select a stored backup file, and restore data to the device. Select
Options > Details for information about the selected backup file.
●Data transfer — Synchronise or copy selected data between your device and another
device, PC, or network server (network service).
Connect a USB device
You can connect a USB storage device (for example, a memory stick) to your device and
browse the file system and transfer files.
1. Connect a compatible adapter cable to the USB port of your device.
2. Connect the USB storage to the adapter cable.
3. Select Menu > Gallery and the USB device.
Not all USB storage devices are supported, depending on their power consumption.
Network provider services
Your network provider provides several additional services you may want to use. For
some of these services, charges may apply.
Operator menu
Access a portal to services provided by your network operator. The operator can update
this menu with a service message. For more information, contact your network
operator.
SIM services
Your SIM card may provide additional services. You can access this menu only if it is
supported by your SIM card. The name and contents of the menu depend on the available
services.
Accessing these services may involve sending messages or making a phone call for which
you may be charged.
Info messages, SIM messages, and service commands
Select Menu > Messaging and More.
Info messages
View info messages — Select Info messages. You can receive messages on various
topics from your service provider (network service). For more information, contact your
service provider.
Make it your device
www.nokia.com/support 21
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Service commands
Send service commands — Select Serv. commands. Service commands allow you to
write and send service requests (USSD commands) to your service provider, such as
activation commands for network services. For details, contact your service provider.
SIM messages
View SIM messages — Select Menu > Messaging and Options > SIM messages.
SIM messages are specific text messages that are saved to your SIM card. You can copy
or move those messages from the SIM to the device memory, but not vice versa.
Configuration settings
You can configure your device with settings that are required for certain services. You
may receive these settings as a configuration message from your service provider.
Select Menu > Settings.
Select Configuration and from the following:
●Default config. sett. — View the service providers saved in the device, and set a
default service provider.
●Act. def. in all apps. — Activate the default configuration settings for supported
applications.
●Preferred access pt. — View the saved access points.
●Device mgr. settings — Allow or prevent the device from receiving software
updates. This option may not be available, depending on your device.
●Personal settings — Add manually new personal accounts for various services, and
activate or delete them. To add a new personal account, select Add or Options >
Add new. Select the service type, and enter the required parameters. To activate a
personal account, scroll to the account, and select Options > Activate.
4. Stay in touch
Learn how to make calls, write text, send messages, and use the mail functionality of
your device.
Make calls
Make a voice call
Dial a number manually — Enter the phone number, including the area code, and
press the call key. For international calls, press * twice for the international prefix (the
+ character replaces the international access code), enter the country code, the area
code without the leading 0, if necessary, and the phone number.
Redial a number — To access the list of dialled numbers, in the home screen , press
the call key. Select a number or name, and press the call key.
Stay in touch
22 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Call a contact — Select Menu > Contacts and Names. Select a contact, and press the
call key.
Handle voice calls
Answer an incoming call —
End a call —
Mute the ringing tone — Select Silence.
Reject an incoming call — Press the end key.
Adjust the volume in a call —
Dialling shortcuts
1. Select Menu > Contacts > Speed dials, and scroll to a number key.
2. Select Assign, or, if a number has already been assigned to the key, select
Options > Change.
3. Enter a number or search for a contact.
4. To activate one key dialling, select Menu > Settings and Call > Speed dialling >
On
Use a dialling shortcut — Press a number key, then the call key.
Use one key dialling — Press and hold a number key.
Voice dialling
Make a phone call by saying the name that is saved in Contacts.
As voice commands are language-dependent, before voice dialling, select Menu >
Settings and Phone > Language settings > Phone language, and your language.
Note: Using voice tags may be difficult in a noisy environment or during an
emergency, so you should not rely solely upon voice dialling in all circumstances.
1. In the home screen, press and hold the right selection key. A short tone sounds, and
Speak after the tone is displayed.
2. Say the name of the contact you want to dial. If the voice recognition is successful,
a list of proposed matches is displayed. The device plays the voice command of the
first match on the list. If it is not the correct command, scroll to another entry.
Options during a call
Many of the options that you can use during a call are network services. For availability,
contact your service provider.
Activate options during a call — Select Options.
Stay in touch
www.nokia.com/support 23
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Some of the network options are Hold, New call, Add to conference, End all calls, and
the following:
●Send DTMF — Send tone strings.
●Swap — Switch between the active call and the call on hold.
●Transfer — Connect a call on hold to an active call and disconnect yourself.
●Conference — Make a conference call.
●Private call — Start a private discussion in a conference call.
Voice messages
The voice mailbox is a network service to which you may need to subscribe. For more
information, contact your service provider.
Call your voice mailbox — Press and hold 1.
Edit your voice mailbox number — Select Menu > Messaging > More > Voice
messages and Voice mailbox no..
Call log
To view details of your calls, messages, data, and synchronisation, select Menu >
Log and the desired item.
Note: The actual invoice for calls and services from your service provider may
vary, depending on network features, rounding off for billing, taxes, and so forth.
Call settings
Select Menu > Settings and Call and from the following:
●Call divert — Divert your incoming calls (network service). You may not be able to
divert your calls if some call barring functions are active.
●Anykey answer — Answer an incoming call by briefly pressing any key, except the
power key, the left and right selection keys, or the end key.
●Automatic redial — The device redials the number automatically if a call fails. The
device tries to call the number 10 times.
●Voice clarity — Improve speech intelligibility, especially in noisy environments.
●Speed dialling — Dial the names and phone numbers assigned to the number keys
(2-9) by pressing and holding the corresponding number key.
●Call waiting — The network notifies you of an incoming call while you have a call
in progress (network service).
●Call dur. display — Display the duration of the call in progress.
●Summary after call — Briefly display the approximate duration after each call.
●Send my caller ID — Show your phone number to the person you are calling
(network service). To use the setting agreed upon with your service provider, select
Set by network.
Stay in touch
24 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Text and messages
Write text, and create messages and notes.
Write text
Text input modes
To enter text, for example, when writing messages, you can use traditional or
predictive text input.
, , and indicate the character cases. indicates number mode.
Switch between text input modes — Press and hold Options. Not all languages are
supported by predictive text input.
Switch between character cases — Press #.
Switch between letter and number modes — Press and hold #.
Set the writing language — Select Options > Writing language.
Traditional text input
Write a word — Press a number key, 2-9, repeatedly until the desired character is
displayed. The available characters depend on the selected writing language. If the next
letter you want to enter is located on the same key as the present one, wait until the
cursor is displayed, and enter the letter.
Insert common punctuation marks — Press 1 repeatedly.
Insert special characters — Press *, and select a character from the list.
Insert a space — Press 0.
Predictive text input
Predictive text input is based on a built-in dictionary to which you can also add new
words.
Write a word — Press number keys, 2-9. Press each key only once for one letter.
Confirm a word — Scroll right, or press 0 to add a space.
Select the correct word — If the proposed word is not correct, press * repeatedly, and
select the desired word from the list.
Add a word to the dictionary — If the ? character is displayed after the word, the
word you intended to write is not in the dictionary. To add the word to the dictionary,
select Spell. Enter the word using traditional text input, and select Save.
Write a compound word — Write the first part of the word, and scroll right to confirm
it. Write the next part of the word, and confirm again.
Stay in touch
www.nokia.com/support 25
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Text and multimedia messages
You can create a message and optionally attach, for example, a picture. Your device
automatically changes a text message to a multimedia message when a file is attached.
Text messages
Your device supports text messages beyond the limit for a single message. Longer
messages are sent as two or more messages. Your service provider may charge
accordingly. Characters with accents, other marks, or some language options take more
space, and limit the number of characters that can be sent in a single message.
The total number of characters left and the number of messages needed for sending
are displayed.
To send messages, the correct message centre number must be stored in your device.
Normally, this number is set by default through your SIM card.
1. To set the number manually, select Menu > Messaging and More > Message
settings > Text messages > Message centre.
2. Enter the name and the number supplied by the service provider.
Multimedia messages
A multimedia message can contain text, pictures, and sound or video clips.
Only devices that have compatible features can receive and display multimedia
messages. The appearance of a message may vary depending on the receiving device.
The wireless network may limit the size of MMS messages. If the inserted picture exceeds
this limit, the device may make it smaller so that it can be sent by MMS.
Important: Exercise caution when opening messages. Messages may contain
malicious software or otherwise be harmful to your device or PC.
For availability and subscription to the multimedia messaging service (MMS), contact
your service provider.
Create a message
1. Select Menu > Messaging and Create message.
2. Write your message.
To insert a special character or a smiley, select Options > Insert symbol.
To attach an object to the message, select Options > Insert object. The message
type changes automatically to multimedia message.
3. To add recipients, select Send to and a recipient.
To enter a phone number or mail address manually, select Number or e-mail. Enter
a phone number, or select E-mail and enter a mail address.
4. Select Send.
Multimedia messages are indicated with an icon at the top of the display.
Stay in touch
26 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Service providers may charge differently depending on the message type. For details,
contact your service provider.
Read a message and reply
Important: Exercise caution when opening messages. Messages may contain
malicious software or otherwise be harmful to your device or PC.
Display the message — Select View.
Create an answer message — Select Reply.
Several messages received — Select Menu > Messaging and Inbox. Select a
message and Open.
Send and organise messages
To send a message, select Send.
Note: The message sent icon or text on your device screen does not indicate that
the message is received at the intended destination.
If message sending is interrupted, the device tries to resend the message a few times.
If these attempts fail, the message is marked as failed in the Sent items folder.
The device saves received messages in the Inbox folder. Organise your messages in the
Saved items folder.
To add, rename, or delete a folder, select Menu > Messaging and More > Archive >
Options.
Nokia Xpress audio messages
Create and send audio messages using MMS in a convenient way.
1. Select Menu > Messaging.
2. Select More > Other messages > Audio message. The voice recorder opens.
3. To record your message, select .
4. To stop recording, select .
5. Select Send to and a contact.
Message settings
Select Menu > Messaging and Msg. settings.
Select from the following:
●General settings — Save copies of sent messages in your device, overwrite old
messages if the message memory becomes full, switch between the Conversations
and Inbox views, and set up other preferences related to messages.
Stay in touch
www.nokia.com/support 27
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
●Text messages — Allow delivery reports, set up message centres for SMS and SMS
mail, select the type of character support, and set up other preferences related to
text messages.
●Multimedia msgs. — Allow delivery reports, set up the appearance of multimedia
messages, allow the reception of multimedia messages and advertisements, and set
up other preferences related to multimedia messages.
●Service messages — Activate service messages, and set up preferences related to
service messages.
5. Image and video
Capture images
Activate the camera — Select Menu > Applications > Camera; or, if in video mode,
scroll left or right.
Zoom in or out —
Capture an image — Select Capture. Images are saved in Gallery.
Display images after capture — Select Options > Settings > Photo preview
time and the preview time.
End the image preview manually — Select Back.
Your device supports an image capture resolution of 2592x1944 pixels .
Record video clips
Activate video mode — Select Menu > Applications and Video recorder, or, if in
image mode, scroll left or right.
Start recording — Select Record.
Pause or resume recording — Select Pause or Continue.
Stop recording — Select Stop.
Video clips are saved in Gallery.
Camera and video settings
Select Menu > Applications > Camera.
In image or video mode, select Options and from the following:
●Self-timer — Use the self-timer.
●Effects — Apply different effects (for example, greyscale and false colour) to the
captured image.
●White balance — Adapt the camera to the current light conditions.
●Landscape format or Portrait format — Select the orientation of the camera.
●Settings — Modify other camera and video settings, and select where to save images
and video clips.
Image and video
28 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Gallery
Manage images, video clips, music files, themes, graphics, tones, recordings, and
received files. These files are stored in the phone memory or on a memory card and may
be arranged in folders.
Photos
View images and play video clips with the Photos application.
Select Menu > Gallery > Photos.
Select from the following:
●All photos — View images in a thumbnail grid. You can sort images by date, name,
or size.
●Timeline — View images in the order they were captured.
●Albums — Sort images into albums. You can create, rename and remove albums. If
you remove an album, the images inside the album are not deleted from the memory.
Rotate an image — Select Options > Landscape mode or Portrait mode.
View a slide show
A slide show uses the images of the currently selected folder or album.
1. Select All photos, Timeline, or Albums.
2. Select Options > Slide show.
3. Select Start slide show.
Edit images
You can, for example, rotate, flip, crop, and adjust the brightness, contrast, and colours
of images.
1. Select an image in All photos, Timeline, or Albums.
2. Select Options > Edit photo.
3. Select an editing option, and use the scroll key to change the settings or values.
Music and videos
Your device includes a media player for playing songs and video clips. Music and video
files stored in the music folder in the device memory or on the memory card are
automatically detected and added to the video or music library.
Select Menu > Gallery and Music & videos.
Select from the following:
●Videos — List all available video clips.
●All songs — List all available songs. You can sort songs by artist, album, or genre,
for example.
Image and video
www.nokia.com/support 29
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Manage folders and files
To manage folders and files in Gallery, select Menu > Gallery.
View a list of folders — Select All content.
View a list of files in a folder — Select a folder and Open.
View the folders of the memory card when moving a file — Scroll to the memory
card, and scroll right.
Print images
Your device supports Nokia XpressPrint, allowing you to print images in the JPEG file
format.
1. Connect your device to a compatible printer, using a USB data cable, or, if supported
by the printer, Bluetooth connectivity.
2. Select an image from Gallery and Options > Print.
Memory card
Use a memory card to store your multimedia files, such as video clips, songs, sound files,
images, and messaging data.
Select Menu > Gallery > All content > Memory card.
Some of the folders in Gallery that contain content used by your device (for example,
Themes) can be stored on the memory card.
If your memory card has not been pre-formatted, you need to format it. When you
format a memory card, all data on the card is permanently deleted.
Format the memory card — Select Options > Mem. card options > Format
memory card > Yes. When formatting is complete, enter a name for the memory card.
Protect the memory card with a password — Select Options > Mem. card
options > Set password. The password is stored in your device, so you only have to
enter the password when attempting to use the memory card in another device.
Remove the memory card password — Select Options > Mem. card options >
Delete password.
Check the memory consumption — Select Options > Details. The memory
consumption of different data groups, and the amount of available memory to install
new software, is displayed.
6. Entertainment
Listen to music
Listen to music with the music player or radio, and record sounds or voice with the voice
recorder. Download music from the internet, or transfer music from your PC.
Entertainment
30 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Warning: Continuous exposure to high volume may damage your hearing. Listen
to music at a moderate level, and do not hold the device near your ear when the
loudspeaker is in use.
Media player
To open the media player, select Menu > Media > Media player.
Music menu
Access your music and video files stored in the device memory or on the memory card,
download music or video clips from the web, or view compatible video streams from a
network server (network service).
Select Menu > Media > Media player.
Play a media file — Select a file from the available folders and Play.
Download files from the web — Select Options > Downloads and a download site.
Update the music library after adding files — Select Options > Update library.
Create a playlist
1. Select Playlists > Create playlist, and enter the name of the playlist.
2. Add music or video clips from the displayed lists.
3. To store the playlist, select Done.
Configure a streaming service
You may receive the streaming settings as a configuration message from the service
provider. You can also enter the settings manually.
1. Select Options > Downloads > Streaming settings > Configuration.
2. Select a service provider, Default, or Personal config. for streaming.
3. Select Account and a streaming service account from the active configuration
settings.
Play songs
Leave the media player playing in the background — Press the end key.
Stop the media player — Press and hold the end key.
Change the media player look
Your device provides several themes to change the look of the media player.
Select Menu > Media > Media player and Go to Media pl. > Options > Settings >
Media player theme and the desired theme.
The virtual keys may change depending on the theme.
Entertainment
www.nokia.com/support 31
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Transfer music from a computer
You can transfer music to your device in the following ways:
●Use Nokia Music to transfer, rip, burn, and play new music on your PC and mobile
device. Download the PC software from www.music.nokia.com/download.
●Connect your device to your PC using Bluetooth connectivity or a compatible USB data
cable, and copy music files to the device memory. To use a USB data cable, select
Data storage as the connection mode.
●Use Windows Media Player. Connect a compatible USB data cable, and select Printing
& media as the connection mode.
Voice recorder
Record speech, sound, or an active call, and save the recordings in Gallery.
Select Menu > Media > Voice recorder.
The recorder cannot be used when a data call or GPRS connection is active.
To use the graphical keys , , or , scroll left or right.
Start recording — Select , or, during a call, select Options > Record. While recording
a call, all parties to the call hear a faint beeping.
Pause recording — Select .
Stop recording — Select . The recording is saved in the Recordings folder in Gallery.
To play or send the last recording, to access the list of recordings, or to select the memory
and the folder to store the recordings, select Options and the appropriate option.
Equaliser
Adjust the sound when using the media player.
Select Menu > Applications > Equaliser.
Activate a predefined equaliser set — Scroll to a set, and select Activate.
Create a new equaliser set
1. Select one of the last two sets in the list and Options > Edit.
2. Use the scroll key to adjust the sound controls.
3. To save the settings and enter a name for the set, select Save and Options >
Rename.
Web
You can access various internet services with your device browser (network service).
The appearance of the internet pages may vary due to screen size. You may not be able
to see all the details on the internet pages.
Entertainment
32 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Important: Use only services that you trust and that offer adequate security and
protection against harmful software.
For the availability of these services, pricing, and instructions, contact your service
provider.
You may receive the configuration settings required for browsing as a configuration
message from your service provider.
Select Menu > Internet.
To set up the service, select Web settings > Configuration sett., a configuration, and
an account.
Browse the web
Select Menu > Internet.
Open the home page — Select Home; or in the home screen, press and hold 0.
Select a bookmark — Select Bookmarks.
Enter a web address — Select Go to address, enter the address, and select OK.
Select the last visited web address — Select Last web addr..
Search the web — If you search for the first time, select a search provider. Then
selectSearch, enter the search terms, and select Search.
Change the search provider — Select Options > Change provider.
After you connect to the service, you can start browsing its pages. The function of the
device keys may vary in different services. Follow the instructions. For more information,
contact your service provider.
Browser settings
While browsing the web, select Options > Settings and from the following:
●Display — Select the font size, whether images are displayed, and how the text is
displayed.
●General — Select the encoding type for the contents, whether web addresses are
sent as Unicode (UTF-8), and whether JavaScript is enabled.
The available options may vary.
Cache memory
A cache is a memory location that is used to store data temporarily. If you have tried to
access or have accessed confidential information requiring passwords, empty the cache
after each use. The information or services you have accessed are stored in the cache.
A cookie is data that a site saves in the cache memory of your device. Cookies are saved
until you clear the cache memory.
Clear the cache — While browsing, select Options > Tools > Clear the cache.
Entertainment
www.nokia.com/support 33
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Allow or prevent cookies — Select Menu > Internet and Web settings >
Security > Cookies.
Browser security
Security features may be required for some services, such as banking services or online
shopping. For such connections you need security certificates and possibly a security
module, which may be available on your SIM card. For more information, contact your
service provider.
To view or modify the security module settings, or to view a list of authority or user
certificates downloaded to your device, select Menu > Settings and Security >
Security module, Auth. certificates, or User certificates.
Important: Even if the use of certificates makes the risks involved in remote
connections and software installation considerably smaller, they must be used correctly
in order to benefit from increased security. The existence of a certificate does not offer
any protection by itself; the certificate manager must contain correct, authentic, or
trusted certificates for increased security to be available. Certificates have a restricted
lifetime. If "Expired certificate" or "Certificate not valid yet" is shown, even if the
certificate should be valid, check that the current date and time in your device are
correct.
Before changing any certificate settings, you must make sure that you really trust the
owner of the certificate and that the certificate really belongs to the listed owner.
Games and applications
You can manage applications and games. Your device may have some games or
applications installed. These files are stored in the device memory or an attached
memory card and may be arranged in folders.
Open an application
Select Menu > Applications.
Open a game or application — Select Games, Collection, or Memory card. Scroll to
a game or application, and select Open.
Set sounds, lights, and shakes for a game — Select Options > Application
settings.
Download an application
Your device supports J2ME™ Java applications. Ensure that the application is compatible
with your device before downloading it.
Entertainment
34 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Important: Only install and use applications and other software from trusted
sources, such as applications that are Symbian Signed or have passed the Java
Verified™ testing.
You can download new applications and games directly or using your PC.
Download directly — Select Menu > Applications and Options > Downloads >
App. downloads or Game downloads; the list of available bookmarks is shown.
Download using your PC — Download applications and games to your PC and use PC
Suite to install them on your device.
For the availability of different services and pricing, contact your service provider.
7. Maps
You can browse maps for different cities and countries, search for addresses and points
of interest, plan routes from one location to another, save locations as landmarks, and
send them to compatible devices.
Almost all digital cartography is inaccurate and incomplete to some extent. Never rely
solely on the cartography that you download for use in this device.
Note: Downloading content such as maps, satellite images, voice files, guides or
traffic information may involve transmission of large amounts of data (network service).
Content such as satellite images, guides, weather and traffic information and related
services are generated by third parties independent of Nokia. The content may be
inaccurate and incomplete to some extent and is subject to availability. Never rely solely
on the aforementioned content and related services.
Find detailed information about Maps on www.nokia.com/maps
To use the Maps application, select Menu > Applications > Maps and from the
available options.
Download maps
Your device may contain pre-installed maps on the memory card. You can download a
new set of maps through the internet using the Nokia Map Loader PC software.
Download and install Nokia Map Loader
1. To download the Nokia Map Loader on your PC and for further instructions, visit
www.maps.nokia.com.
2. Select Menu > Applications > Maps to do an initial configuration.
Download maps — Before you download new maps for the first time, ensure that you
have a memory card inserted in the device. To change the selection of maps on your
memory card, use the Nokia Map Loader to delete all maps on the memory card and
download a new selection, to ensure that all maps are from the same release.
Maps
www.nokia.com/support 35
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Download maps automatically — Select Menu > Applications > Maps and
Settings > Network settings > Allow netw. usage > Yes or In home network.
Deactivate automatic download — Select No.
Note: Downloading content such as maps, satellite images, voice files, guides or
traffic information may involve transmission of large amounts of data (network service).
Maps and GPS
Extra services
You can upgrade Maps to a full navigation system to be used by car and by foot. You
need a regional licence for the full navigation system. The car navigation is fully voice-
guided with two- and three-dimensional map views. The pedestrian navigation is
limited to a speed of 30 km/h (18.6 miles/h) and provides no voice guidance. The
navigation service is not available for all countries and regions. For details, see your
local Nokia website.
Purchase a navigation service — Select Menu > Applications > Maps and Extra
services > Purchase navigation, and follow the instructions.
To use navigation with voice guidance, you must allow the Maps application to use a
network connection.
The navigation licence is connected to your SIM card. If you insert another SIM card in
your device, you are asked to purchase a licence when starting navigation. During the
purchase procedure, you are offered to transfer the existing navigation licence to the
new SIM card without extra charge.
8. Organise
Let your phone help you to organise your life.
Manage contacts
Save names, phone numbers, and addresses as contacts in the device and on the SIM
card.
Select Menu > Contacts.
Select the memory to use for contacts
The device memory can save contacts with additional details, such as alternative phone
numbers. You can also save an image, a tone, or a video clip for a limited number of
contacts.
The SIM card memory can save names with one phone number attached to them. The
contacts saved in the SIM card memory are indicated with .
Organise
36 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
1. Select More > Settings > Memory in use to select the SIM card, the device
memory, or both for your contacts.
2. Select Phone and SIM to recall contacts from both memories. When you save
contacts, they are saved in the device memory.
Handle contacts
Search for a contact —
Save a name and phone number — Select Menu > Contacts and Add new.
Add and edit details — Select Names, a contact, and Details > Options > Add
detail.
Delete a detail — Select Names, a contact, and Details. Select a detail and Options >
Delete.
Delete a contact — Select Names, a contact, and Options > Delete contact.
Delete all contacts — Select More > Del. all contacts > From phone mem. or From
SIM card.
Copy or move contacts between the device and SIM card memories
Copy single contacts — Select Names > Options > More > Marking options >
Mark. Mark the contacts you want to copy or move, and select Options > Copy
marked or Move marked.
Copy all contacts — Select More > Copy contacts or Move contacts.
Create a contact group
Arrange contacts into caller groups with different ringing tones and group images.
1. Select More > Groups.
2. Select Add or Options > Add new group to create a new group.
3. Enter the group name, optionally select an image and a ringing tone, and select
Save.
4. Select the group and View > Add to add contacts to the group.
Business cards
You can send and receive a person’s contact information from a compatible device that
supports the vCard standard.
Select Menu > Contacts and Names.
Send a business card — Select a contact, Details > Options > Send business
card, and the sending type.
Save a received business card — Select Show > Save.
Organise
www.nokia.com/support 37
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Date and time
Modify date and time settings — Select Menu > Settings and Date and time.
Change the time zone when travelling — Select Menu > Settings and Date and
time > Date & time settings > Time zone:, and scroll left or right to select the time
zone of your location. The time and date are set according to the time zone and enable
your device to display the correct sending time of received text or multimedia messages.
For example, GMT -5 denotes the time zone for New York (USA), 5 hours west of
Greenwich, London (UK).
Alarm clock
You can set an alarm to sound at a desired time.
Set the alarm
1. Select Menu > Applications > Alarm clock.
2. Set the alarm, and enter the alarm time.
3. To issue an alarm on selected days of the week, select Repeat: > On and the days.
4. Select the alarm tone.
5. Set the length of the snooze time-out period, and select Save.
Stop the alarm
Select Stop. If you let the alarm sound for a minute or select Snooze, the alarm stops
for the length of the snooze time-out period, then resumes.
Calendar
Select Menu > Calendar.
The current day is framed. If there are any notes set for the day, the day is in bold type.
Make a calendar note — Scroll to the date, and select Options > Make a note. Select
the note type, and fill in the fields.
View the day notes — Select View.
View a week — Select Options > Week view.
Delete all notes in the calendar — Select Options > Delete notes > All notes.
Delete old notes automatically after a specified time — Select Options >
Settings > Auto-delete notes.
Edit settings related to the date and time — Select Options > Settings.
To-do list
You can save a note for a task you must do.
Select Menu > Applications > To-do list.
Organise
38 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Add a note — If no note is added, select Add; otherwise, select Options > Add. Fill
in the fields, and select Save.
View a note — Select a note and View.
Notes
Select Menu > Applications > Notes.
Add a note — If no note is added, select Add; otherwise, select Options > Make a
note. Write the note, and select Save.
Send a note — Select Options > Send note and the sending type.
Nokia PC Suite
With Nokia PC Suite, you can manage your music and synchronise contacts, calendar
entries, notes, and to-do notes between your device and a compatible PC or a remote
internet server (network service). For more information, and to download PC Suite, visit
www.nokia.com/support.
Calculator
Your device provides a standard, a scientific, and a loan calculator.
Select Menu > Applications > Calculator.
Select Options to select the calculator type or to view the operating instructions.
This calculator has limited accuracy and is designed for simple calculations.
Countdown timer
Select Menu > Applications > Countd. timer.
Normal timer
1. Select Normal timer, enter a time, and write a note that is displayed when the time
expires.
2. Select Start.
Interval timer
To have an interval timer with up to 10 intervals started, do the following:
1. Select Interval timer.
2. Select Start timer > Start.
To select how the interval timer should start the next period, select Settings > Cont.
to next period.
Organise
www.nokia.com/support 39
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Stopwatch
You can measure time, take intermediate times, or take lap times using the stopwatch.
Select Menu > Applications > Stopwatch and from the following:
●Split timing — Take intermediate times. To reset the time without saving it, select
Options > Reset.
●Lap timing — Take lap times.
●Continue — View the timing that you have set to the background.
●Show last — View the most recently measured time if the stopwatch is not reset
●View times or Delete times — View or delete the saved times
To set the stopwatch timing to the background, press the end key.
9. Green tips
Here are tips on how you can contribute to protecting the environment.
Save energy
When you have fully charged the battery and disconnected the charger from the device,
unplug the charger from the wall outlet.
You do not need to charge your battery so often if you do the following:
●Close and disable applications, services, and connections when not in use.
●Decrease the brightness of the screen.
●Set the device to enter the power saver mode after the minimum period of inactivity,
if available in your device.
●Disable unnecessary sounds, such as keypad and ringing tones.
Recycle
Most of the materials in a Nokia phone are recyclable. Check how to recycle your Nokia
products at www.nokia.com/werecycle, or with a mobile device, www.nokia.mobi/
werecycle.
Recycle packaging and user guides at your local recycling scheme.
Learn more
For more information on the environmental attributes of your device, see
www.nokia.com/ecodeclaration.
Green tips
40 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Digital rights management
Content owners may use different types of digital rights management (DRM)
technologies to protect their intellectual property, including copyrights. This device uses
various types of DRM software to access DRM-protected content. With this device you
can access content protected with WMDRM 10, OMA DRM 1.0, OMA DRM 1.0 forward lock,
and OMA DRM 2.0. If certain DRM software fails to protect the content, content owners
may ask that such DRM software's ability to access new DRM-protected content be
revoked. Revocation may also prevent renewal of such DRM-protected content already
in your device. Revocation of such DRM software does not affect the use of content
protected with other types of DRM or the use of non-DRM-protected content.
Digital rights management (DRM) protected content comes with an associated licence
that defines your rights to use the content.
If your device has OMA DRM-protected content, to back up both the licence and the
content, use the backup feature of Nokia Ovi Suite.
Other transfer methods may not transfer the licence which need to be restored with the
content for you to be able to continue the use of OMA DRM-protected content after the
device memory is formatted. You may also need to restore the licence in case the files
on your device get corrupted.
If your device has WMDRM-protected content, both the licence and the content will be
lost if the device memory is formatted. You may also lose the licence and the content if
the files on your device get corrupted. Losing the licence or the content may limit your
ability to use the same content on your device again. For more information, contact
your service provider.
Some licence may be connected to a specific SIM card, and the protected content can be
accessed only if the SIM card is inserted in the device.
Third-party applications
The third-party applications provided with your device may have been created and may
be owned by persons or entities not affiliated with or related to Nokia. Nokia does not
own the copyrights or intellectual property rights to the third-party applications. As
such, Nokia does not take any responsibility for end-user support, functionality of the
applications, or the information in the applications or these materials. Nokia does not
provide any warranty for the third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED
AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR
ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY
PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
www.nokia.com/support 41
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Accessories
Warning: Use only batteries, chargers, and accessories approved by Nokia for
use with this particular model. The use of any other types may invalidate any approval
or warranty, and may be dangerous.
For availability of approved accessories, please check with your dealer. When you
disconnect the power cord of any accessory, grasp and pull the plug, not the cord.
Battery
Battery and charger information
Your device is powered by a rechargeable battery. The battery intended for use with
this device is BL-4S. Nokia may make additional battery models available for this device.
This device is intended for use when supplied with power from the following chargers:
AC-3. The exact charger model number may vary depending on the type of plug. The
plug variant is identified by one of the following: E, EB, X, AR, U, A, C, or UB.
The battery can be charged and discharged hundreds of times, but it will eventually
wear out. When the talk and standby times are noticeably shorter than normal, replace
the battery. Use only Nokia approved batteries, and recharge your battery only with
Nokia approved chargers designated for this device. Use of an unapproved battery or
charger may present a risk of fire, explosion, leakage, or other hazard.
If a battery is being used for the first time or if the battery has not been used for a
prolonged period, it may be necessary to connect the charger, then disconnect and
reconnect it to begin charging the battery. If the battery is completely discharged, it
may take several minutes before the charging indicator appears on the display or before
any calls can be made.
Always switch the device off and disconnect the charger before removing the battery.
Unplug the charger from the electrical plug and the device when not in use. Do not leave
a fully charged battery connected to a charger, since overcharging may shorten its
lifetime. If left unused, a fully charged battery will lose its charge over time.
Always try to keep the battery between 15°C and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and lifetime of the battery. A device with a hot or cold
battery may not work temporarily. Battery performance is particularly limited in
temperatures well below freezing.
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic
object such as a coin, clip, or pen causes direct connection of the positive (+) and
negative (-) terminals of the battery. (These look like metal strips on the battery.) This
might happen, for example, when you carry a spare battery in your pocket or purse.
Short-circuiting the terminals may damage the battery or the connecting object.
Accessories
42 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Do not dispose of batteries in a fire as they may explode. Batteries may also explode if
damaged. Dispose of batteries according to local regulations. Please recycle when
possible. Do not dispose as household waste.
Do not dismantle, cut, open, crush, bend, deform, puncture, or shred cells or batteries.
In the event of a battery leak, do not allow the liquid to come in contact with the skin
or eyes. In the event of such a leak, flush your skin or eyes immediately with water, or
seek medical help.
Do not modify, remanufacture, attempt to insert foreign objects into the battery, or
immerse or expose it to water or other liquids.
Improper battery use may result in a fire, explosion, or other hazard. If the device or
battery is dropped, especially on a hard surface, and you believe the battery has been
damaged, take it to a service centre for inspection before continuing to use it.
Use the battery only for its intended purpose. Never use any charger or battery that is
damaged. Keep your battery out of the reach of small children.
Nokia battery authentication guidelines
Always use original Nokia batteries for your safety. To check that you are getting an
original Nokia battery, purchase it from a Nokia authorised service centre or dealer, and
inspect the hologram label using the following steps:
Successful completion of the steps is not a total assurance of the authenticity of the
battery. If you have any reason to believe that your battery is not an authentic, original
Nokia battery, you should refrain from using it, and take it to the nearest Nokia
authorised service centre or dealer for assistance. If authenticity cannot be verified,
return the battery to the place of purchase.
Authenticate hologram
1. When you look at the hologram on the label, you should see the
Nokia connecting hands symbol from one angle and the Nokia
Original Enhancements logo when looking from another angle.
2. When you angle the hologram left, right, down and up, you
should see 1, 2, 3 and 4 dots on each side respectively.
Battery
www.nokia.com/support 43
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
What if your battery is not authentic?
If you cannot confirm that your Nokia battery with the hologram on the label is an
authentic Nokia battery, please do not use the battery. Take it to the nearest Nokia
authorised service centre or dealer for assistance. The use of a battery that is not
approved by Nokia may be dangerous and may result in poor performance and damage
to your device and its accessories. It may also invalidate any approval or warranty
applying to the device.
To find out more about original Nokia batteries, see www.nokia.com/battery.
Care and maintenance
Your device is a product of superior design and craftsmanship and should be treated
with care. The following suggestions will help you protect your warranty coverage.
●Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can
contain minerals that will corrode electronic circuits. If your device does get wet,
remove the battery, and allow the device to dry completely before replacing it.
●Do not use or store the device in dusty, dirty areas. Its moving parts and electronic
components can be damaged.
●Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
●Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic circuit
boards.
●Do not attempt to open the device other than as instructed in this guide.
●Do not drop, knock, or shake the device. Rough handling can break internal circuit
boards and fine mechanics.
●Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the
device.
●Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
●Use only the supplied or an approved replacement antenna. Unauthorised antennas,
modifications, or attachments could damage the device and may violate regulations
governing radio devices.
●Use chargers indoors.
●Always create a backup of data you want to keep, such as contacts and calendar notes.
●To reset the device from time to time for optimum performance, power off the device
and remove the battery.
These suggestions apply equally to your device, battery, charger, or any accessory. If
any device is not working properly, take it to the nearest authorised service facility for
service.
Care and maintenance
44 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Recycle
Always return your used electronic products, batteries, and packaging materials to a
dedicated collection point. This way you help prevent uncontrolled waste disposal and
promote the recycling of materials. More detailed information is available from the
product retailer, local waste authorities, national producer responsibility organisations,
or your local Nokia representative. Check how to recycle your Nokia products at
www.nokia.com/werecycle, or if browsing on a mobile device, www.nokia.mobi/
werecycle.
The crossed-out wheeled-bin symbol on your product, battery, literature, or
packaging reminds you that all electrical and electronic products, batteries, and
accumulators must be taken to separate collection at the end of their working life.
This requirement applies in the European Union. Do not dispose of these products
as unsorted municipal waste. For more environmental information, see the product Eco-
Declarations at www.nokia.com/environment.
Additional safety information
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
Small children
Your device and its accessories may contain small parts. Keep them out of the reach of
small children.
Operating environment
This device meets RF exposure guidelines in the normal use position at the ear or at
least 1.5 centimetre (5/8 inch)away from the body. Any carry case, belt clip, or holder
for body-worn operation should not contain metal and should position the device the
above-stated distance from your body.
To send data files or messages requires a quality connection to the network. Data files
or messages may be delayed until such a connection is available. Follow the separation
distance instructions until the transmission is completed.
Medical devices
Operation of any radio transmitting equipment, including wireless phones, may
interfere with the functionality of inadequately protected medical devices. Consult a
physician or the manufacturer of the medical device to determine if they are adequately
shielded from external RF energy or if you have any questions. Switch off your device
in health care facilities when any regulations posted in these areas instruct you to do
so. Hospitals or health care facilities may be using equipment that could be sensitive to
external RF energy.
Additional safety information
www.nokia.com/support 45
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Implanted medical devices
Manufacturers of medical devices recommend that a minimum separation of 15.3
centimetres (6 inches) should be maintained between a wireless device and an
implanted medical device, such as a pacemaker or implanted cardioverter defibrillator,
to avoid potential interference with the medical device. Persons who have such devices
should:
●Always keep the wireless device more than 15.3 centimetres (6 inches) from the
medical device when the wireless device is turned on.
●Not carry the wireless device in a breast pocket.
●Hold the wireless device to the ear opposite the medical device to minimise the
potential for interference.
●Turn the wireless device off immediately if there is any reason to suspect that
interference is taking place.
●Read and follow the directions from the manufacturer of their implanted medical
device.
If you have any questions about using your wireless device with an implanted medical
device, consult your health care provider.
Hearing aids
Some digital wireless devices may interfere with some hearing aids. If interference
occurs, consult your service provider.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems
in motor vehicles such as electronic fuel injection systems, electronic antiskid (antilock)
braking systems, electronic speed control systems, and air bag systems. For more
information, check with the manufacturer, or its representative, of your vehicle or any
equipment that has been added.
Only qualified personnel should service the device or install the device in a vehicle. Faulty
installation or service may be dangerous and may invalidate any warranty that may
apply to the device. Check regularly that all wireless device equipment in your vehicle
is mounted and operating properly. Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the device, its parts, or accessories.
For vehicles equipped with an air bag, remember that air bags inflate with great force.
Do not place objects, including installed or portable wireless equipment in the area over
the air bag or in the air bag deployment area. If in-vehicle wireless equipment is
improperly installed and the air bag inflates, serious injury could result.
Using your device while flying in aircraft is prohibited. Switch off your device before
boarding an aircraft. The use of wireless teledevices in an aircraft may be dangerous to
the operation of the aircraft, disrupt the wireless telephone network, and may be illegal.
Additional safety information
46 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere, and
obey all signs and instructions. Potentially explosive atmospheres include areas where
you would normally be advised to turn off your vehicle engine. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even death. Switch off the
device at refuelling points such as near gas pumps at service stations. Observe
restrictions on the use of radio equipment in fuel depots, storage, and distribution
areas; chemical plants; or where blasting operations are in progress. Areas with a
potentially explosive atmosphere are often, but not always, clearly marked. They include
below deck on boats, chemical transfer or storage facilities and areas where the air
contains chemicals or particles such as grain, dust, or metal powders. You should check
with the manufacturers of vehicles using liquefied petroleum gas (such as propane or
butane) to determine if this device can be safely used in their vicinity.
Emergency calls
Important: This device operates using radio signals, wireless networks, landline
networks, and user-programmed functions. If your device supports voice calls over the
internet (internet calls), activate both the internet calls and the cellular phone. The
device will attempt to make emergency calls over both the cellular networks and
through your internet call provider if both are activated. Connections in all conditions
cannot be guaranteed. You should never rely solely on any wireless device for essential
communications like medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for adequate signal strength. Depending
on your device, you may also need to complete the following:
●Insert a SIM card if your device uses one.
●Remove certain call restrictions you have activated in your device.
●Change your profile from offline or flight profile mode to an active profile.
2. Press the end key as many times as needed to clear the display and ready the device
for calls.
3. Enter the official emergency number for your present location. Emergency numbers
vary by location.
4. Press the call key.
When making an emergency call, give all the necessary information as accurately as
possible. Your wireless device may be the only means of communication at the scene
of an accident. Do not end the call until given permission to do so.
Certification information (SAR)
This mobile device meets guidelines for exposure to radio waves.
Additional safety information
www.nokia.com/support 47
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the
limits for exposure to radio waves recommended by international guidelines. These
guidelines were developed by the independent scientific organisation ICNIRP and
include safety margins designed to assure the protection of all persons, regardless of
age and health.
The exposure guidelines for mobile devices employ a unit of measurement known as
the Specific Absorption Rate or SAR. The SAR limit stated in the ICNIRP guidelines is 2.0
watts/kilogram (W/kg) averaged over 10 grams of tissue. Tests for SAR are conducted
using standard operating positions with the device transmitting at its highest certified
power level in all tested frequency bands. The actual SAR level of an operating device
can be below the maximum value because the device is designed to use only the power
required to reach the network. That amount changes depending on a number of factors
such as how close you are to a network base station. The highest SAR value under the
ICNIRP guidelines for use of the device at the ear is 0.59 W/kg.
Use of device accessories may result in different SAR values. SAR values may vary
depending on national reporting and testing requirements and the network band.
Additional SAR information may be provided under product information at
www.nokia.com.
Your mobile device is also designed to meet the requirements for exposure to radio
waves established by the Federal Communications Commission (USA) and Industry
Canada. These requirements set a SAR limit of 1.6 W/kg averaged over one gram of
tissue. The highest SAR value reported under this standard during product certification
for use at the ear is 0.64 W/kg and when properly worn on the body is 0.72 W/kg.
Additional safety information
48 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
Index
A
access codes 11
answering calls 23
anykey answer 24
applications 34
audio messages 27
B
backing up data 21
barring password 11
battery 9
battery charge level indicator 13
Bluetooth 19
browser 32, 33
browser security 34
browser settings 33
business cards 37
C
cable connection 20
cache memory 33
calculator 39
call 22
call divert 24
call log 24
call waiting 24
caller id 24
camera
capturing images 28
camera settings 28
configuration 22
contacts 36
cookies 33
D
date and time 38
device
software updates 16
dial 22
dialling shortcuts 18, 23
digital rights 41
display settings 18, 33
E
equaliser 32
F
file management 30
Flight profile 16
flight profile 15
G
games 34
GPRS (general packet radio
service) 20
GPS (global positioning system) 36
H
handsfree 23
headset 10
help text 16
home screen 13, 18
I
images 28, 29
See also
camera
in-call timer 24
indicators 14
info messages 21
insert battery 9
internet 32
K
keyguard 16
keys 7, 18
L
language 16
loudspeaker 23
M
Maps 35, 36
media player 29, 31
memory 30
www.nokia.com/support 49
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
memory card 9
message centre number 26
message sending 27
message settings 27
messages 26
microSD card 9
modem 20
music 32
music player 31
N
navigation 14
navigation tools 36
notes 39
O
offline profile 15
operator menu 21
P
packet data connection 20
parts 7
PC Suite 39
phonebook 36
photographs 28
See also
camera
PictBridge 20
PIN 11
printing 30
profiles 17
PUK 11
R
redial 22, 24
rejecting calls 23
remove battery 8
restoring data 21
S
screen settings 18
scrolling 14
security
settings 16
security code 11
security module 11
service commands 21
shortcuts 14, 18
signal strength indicator 13
SIM card 8, 15, 21
SIM messages 21
speed dialling 18, 23, 24
status indicators 13
stopwatch 40
strap 10
synchronisation 21
T
text input 25
text messages 26
themes 17
time and date 38
to-do list 38
tones 16, 17
transferring, files 32
U
UPIN 11
USB cable connection 10, 20
USB connection 21
V
video 28, 29
voice clarity 24
voice commands 18
voice dialling 23
voice messages 24
voice recorder 32
W
wallpaper 18
web 32
write text 25
Index
50 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-07-07 13:43:57 RM497 User guide publication 2
