Nokia 3710a-1 User Guide

RM-509

FCC Draft

Cyan

Magenta

Yellow

Black

Contents

Safety 4

Get started 5

Keys and parts 5

Insert the SIM card and battery 6

Insert and remove the memory

card 7

Charge the battery 8

GSM antenna 9

Accessories 9

Switch it on 11

About your device 11

Network services 11

Access codes 12

Switch the device on and off 13

Home screen 13

Navigate the menus 15

Lock the keys 16

Functions without a SIM card 16

Flight profile 17

Support and updates 18

Support 18

My Nokia 18

Download content 19

Software updates using your PC 19

Software updates over the air 19

Restore factory settings 20

Make it your device 21

Basic settings 21

Personalise your device 23

Connect 25

Network provider services 28

Stay in touch 30

Make calls 30

Text and messages 34

Mail and Instant Messaging 38

Image and video 41

Capture images 41

Record video clips 41

Camera and video settings 42

Gallery 42

Print images 43

Share images and video clips

online 44

Memory card 44

Entertainment 45

Listen to music 45

Web 50

Games and applications 52

Maps 53

2Contents

www.nokia.com/support

Cyan

Magenta

Yellow

Black

About Maps 53

Nokia Map Loader 54

About GPS 55

GPS receiver 55

Navigate to your destination 55

Organise 57

Manage contacts 57

Business cards 58

Date and time 58

Alarm clock 59

Calendar 59

To-do list 60

Notes 60

Nokia PC Suite 60

Calculator 60

Countdown timer 60

Stopwatch 61

Green tips 62

Save energy 62

Recycle 62

Learn more 62

Digital rights management 63

Accessories 63

Battery 63

Battery and charger information 63

Nokia battery authentication

guidelines 64

Taking care of your device 65

Recycle 66

Additional safety information 66

Small children 66

Operating environment 66

Medical devices 66

Vehicles 66

Potentially explosive

environments 67

Emergency calls 67

Certification information (SAR) 67

Index 69

Contents 3

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Safety

Read these simple guidelines. Not

following them may be dangerous or

illegal. Read the complete user guide for

further information.

SWITCH ON SAFELY

Do not switch the device on

when wireless phone use is

prohibited or when it may

cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always

keep your hands free to

operate the vehicle while

driving. Your first

consideration while driving

should be road safety.

INTERFERENCE

All wireless devices may be

susceptible to interference,

which could affect

performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions.

Switch the device off in

aircraft, near medical

equipment, fuel, chemicals,

or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may

install or repair this product.

ACCESSORIES AND BATTERIES

Use only approved

accessories and batteries. Do

not connect incompatible

products.

WATER-RESISTANCE

Your device is not water-

resistant. Keep it dry.

4Safety

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Get started

Get to know your device, insert the

battery, SIM card, and memory card, and

learn some important information

about your device.

Keys and parts

1Earpiece

2Display

3Navi™ key (scroll key)

4Call key

5Microphone

6Keypad

7Secondary camera

8Left and right selection keys

9End/Power key

10 Camera flash

11 Camera lens

12 Nokia AV Connector (2.5 mm)

Get started 5

www.nokia.com/support

Cyan

Magenta

Yellow

Black

13 Volume keys

14 Loudspeaker

15 Hidden display

16 Charger connector

17 Micro USB cable connector

18 Wrist strap eyelet

Insert the SIM card and battery

Note: Switch off the power and

disconnect the charger and any other

device before removing the covers.

Avoid touching electronic components

while changing the covers. Always store

and use the device with the covers

attached.

The SIM card and its contacts can be

easily damaged by scratches or

bending, so be careful when handling,

inserting, or removing the card.

1 Open the back cover, and remove it.

2 Remove the battery.

3 Open the SIM card holder. Insert the

SIM card into the holder with the

bevelled corner facing down and

the contact surface area facing

toward the contacts of the device.

The side with the bevelled corner

fits below the rim of the device.

Close the SIM card holder.

6Get started

www.nokia.com/support

Cyan

Magenta

Yellow

Black

4 Line up the battery contacts, and

insert the battery.

5 Place the battery cover on the

device, that the hooks at the upper

part of the cover are aligned with

the corresponding recesses on the

device. Slide the back cover to close

it.

Insert and remove the memory card

Use only compatible microSD cards

approved by Nokia for use with this

device. Nokia uses approved industry

standards for memory cards, but some

brands may not be fully compatible with

this device. Incompatible cards may

damage the card and the device and

corrupt data stored on the card.

Your device supports microSD cards

with a capacity of up to 8 GB. The size of

a single file must not exceed 2 GB.

Insert the memory card

Get started 7

www.nokia.com/support

Cyan

Magenta

Yellow

Black

1 Switch the device off, and remove

the back cover and battery.

2 Slide the memory card holder

inwards to unlock.

3 Open the card holder, and insert the

memory card into the holder with

the contact surface facing inwards.

4 Close the card holder, and slide it to

lock.

5 Replace the battery and back cover.

Remove the memory card

1 Remove the back cover and the

battery.

2 Open the memory card holder, and

remove the memory card. Close the

memory card holder.

3 Replace the battery and back cover.

Charge the battery

Your battery has been partially charged

at the factory. If the device indicates a

low charge, do the following:

1 Connect the charger to a wall outlet.

2 Connect the charger to the device.

3 When the device indicates a full

charge, disconnect the charger from

the device, then from the wall

outlet.

You can also charge the battery with a

USB cable, using power from a

computer.

1 Connect the USB cable to a USB port

of a computer and to your device.

2 When the battery is fully charged,

disconnect the USB cable.

If the battery is completely discharged,

USB charging may not work. Use the

charger instead.

You do not need to charge the battery

for a specific length of time, and you can

use the device while it is charging. If the

battery is completely discharged, it may

take several minutes before the

8Get started

www.nokia.com/support

Cyan

Magenta

Yellow

Black

charging indicator appears on the

display or before any calls can be made.

Charging the device while listening to

the radio may affect the quality of

reception.

GSM antenna

Your device may have internal and

external antennas. Avoid touching the

antenna area unnecessarily while the

antenna is transmitting or receiving.

Contact with antennas affects the

communication quality and may cause

a higher power level during operation

and may reduce the battery life.

The figure shows the GSM antenna area

marked in grey.

Accessories

Connect a USB cable

Headset

Warning:

When you use the headset, your ability

to hear outside sounds may be affected.

Do not use the headset where it can

endanger your safety.

When connecting any external device or

any headset, other than those approved

by Nokia for use with this device, to the

Nokia AV Connector, pay special

attention to volume levels.

Get started 9

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Do not connect products that create an

output signal as this may cause damage

to the device. Do not connect any

voltage source to the Nokia AV

Connector.

Strap

1 Open the back cover.

2 Thread the strap, and tighten it.

3 Close the back cover.

10 Get started

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Switch it on

Learn how to switch on your device, and

how to use the basic functions.

About your device

The wireless device described in this

guide is approved for use on the GSM

850, 900, 1800, 1900 and WCDMA 900,

1700-2100, 2100 MHz networks. Contact

your service provider for more

information about networks.

Your device may have preinstalled

bookmarks and links for third-party

internet sites and may allow you to

access third-party sites. These are not

affiliated with Nokia, and Nokia does

not endorse or assume liability for

them. If you access such sites, take

precautions for security or content.

Warning:

To use any features in this device, other

than the alarm clock, the device must be

switched on. Do not switch the device

on when wireless device use may cause

interference or danger.

When using this device, obey all laws

and respect local customs, privacy and

legitimate rights of others, including

copyrights. Copyright protection may

prevent some images, music, and other

content from being copied, modified, or

transferred.

Make back-up copies or keep a written

record of all important information

stored in your device.

When connecting to any other device,

read its user guide for detailed safety

instructions. Do not connect

incompatible products.

The images in this guide may differ from

your device display.

Refer to the user guide for other

important information about your

device.

Network services

To use the device you must have service

from a wireless service provider. Some

features are not available on all

networks; other features may require

that you make specific arrangements

with your service provider to use them.

Network services involve transmission

of data. Check with your service provider

for details about fees in your home

Switch it on 11

www.nokia.com/support

Cyan

Magenta

Yellow

Black

network and when roaming on other

networks. Your service provider can

explain what charges will apply.

Your service provider may have

requested that certain features be

disabled or not activated in your device.

If so, these features will not appear on

your device menu. Your device may also

have customized items such as menu

names, menu order, and icons.

Access codes

To set how your device uses the access

codes and security settings, select

Menu > Settings and Security >

Access codes.

•The security code helps to protect

your device against unauthorised

use. The preset code is 12345. You

can change the code and set the

device to request the code. Some

operations require the security

code regardless of the settings, for

example, if you want to restore the

factory settings. Keep the code

secret and in a safe place separate

from your device. If you forget the

code and your device is locked, your

device will require service and

additional charges may apply. For

more information, contact a Nokia

Care point or your device dealer.

•The PIN (UPIN) code, supplied with

the SIM (USIM) card, helps to protect

the card against unauthorised use.

•The PIN2 (UPIN2) code, supplied

with some SIM (USIM) cards, is

required to access certain services.

•PUK (UPUK) and PUK2 (UPUK2) codes

may be supplied with the SIM (USIM)

card. If you enter the PIN code

incorrectly three times in

succession, you are asked for the

PUK code. If the codes are not

supplied, contact your service

provider.

•The barring password is required

when using the call barring service

to restrict calls to and from your

device (network service).

•To view or change the security

module settings for the browser,

select Menu > Settings and

Security > Security module.

12 Switch it on

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Switch the device on and off

Switch on and off

Press and hold the power key.

Enter the PIN code

If requested , enter the PIN code

(displayed as ****).

Set the time and date

If requested, enter the time and date.

Basic setup

When you switch on your device for the

first time, a setup wizard will guide you

through basic settings.

You may be prompted to get the

configuration settings from your service

provider (network service). For more

information, contact your service

provider.

Home screen

When the device is ready for use, and

you have not entered any characters,

the device is in the home screen.

Switch it on 13

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Display

1Signal strength of the cellular

network

2Battery charge status

3Indicators

4Name of the network or the

operator logo

5Clock

6Date (only if the enhanced home

screen is deactivated)

7Display

8Function of the left selection key

9Function of the scroll key

10 Function of the right selection key

You can change the function of the left

and right selection key. See " Left and

right selection keys ", p. 24.

Enhanced home screen

With the enhanced home screen, you

can display a list of selected information

and features that you can directly

access.

Select Menu > Settings and

Display > Home screen.

Activate the enhanced home screen

Select Home screen mode > On.

Organise and personalise the

enhanced home screen

Select Personalise view.

Select the key used to activate the

enhanced home screen

Select Home screen key.

Navigate in the home screen

Scroll up or down to navigate the list,

and select Select, View, or Edit. The

arrows indicate that further

information is available.

14 Switch it on

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Stop navigating

Select Exit.

Shortcuts

When your device is in the home screen,

you can use shortcuts.

List missed, received, and dialled

calls

Press the call key. To make a call, scroll

to the number or name, and press the

call key.

Open the web browser

Press and hold 0.

Call the voice mailbox

Press and hold 1.

Use other keys as shortcuts

See "Dialling shortcuts", p. 31.

Indicators

You have unread messages.

You have unsent, cancelled, or

failed messages.

The keypad is locked.

The device does not ring for

incoming calls or text

messages.

An alarm is set.

/ The device is registered to the

GPRS or EGPRS network.

/ A GPRS or EGPRS connection is

open.

/ The GPRS or EGPRS connection is

suspended (on hold).

Bluetooth connectivity is

activated.

A GPS signal is available.

No GPS signal available.

If you have two phone lines, the

second line is in use.

All incoming calls are diverted

to another number.

Calls are limited to a closed user

group.

The currently active profile is

timed.

A headset is connected to the

device.

The device is connected to

another device, using a USB

cable.

Navigate the menus

The device offers a range of functions

that are grouped into menus.

Switch it on 15

www.nokia.com/support

Cyan

Magenta

Yellow

Black

1 To access the menu, select Menu.

2 Scroll through the menu, and select

an option (for example, Settings).

3 If the selected menu contains

further submenus, select one (for

example, Call).

4 Select the setting of your choice.

5 To return to the previous menu

level, select Back.

To exit the menu, select Exit.

Change the menu view

Select Options > Main menu view.

Scroll right, and select from the

available options.

Rearrange the menu

Select Options > Organise. Scroll to the

menu item to be moved, and select

Move. Scroll to where you want to move

the menu item, and select OK. To save

the change, select Done > Yes.

Lock the keys

Lock the keypad to prevent accidental

keypresses.

Lock the keypad

Select Menu, and press * within 3.5

seconds.

Unlock the keypad

Select Unlock, and press * within 1.5

seconds. If requested, enter the lock

code.

Answer a call when the keypad is

locked

Press the call key. When you end or

reject a call, the keypad locks

automatically.

Further features are Automatic

keyguard and Security keyguard. See

"Phone settings", p. 21.

When the device or keypad is locked,

calls may be possible to the official

emergency number programmed into

your device.

Functions without a SIM card

Some functions of your device may be

used without inserting a SIM card, such

as Organiser functions and games.

Some functions appear dimmed in the

menus and cannot be used.

16 Switch it on

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Flight profile

In radio sensitive environments, where

you are asked not to use your device,

you can still access your calendar,

contacts list, and offline games by

activating the flight profile.

indicates that the flight profile is

active.

Activate the flight profile

Select Menu > Settings > Profiles

and Flight > Activate or Personalise.

Deactivate the flight profile

Select any other profile.

Warning:

With the Flight profile you cannot make

or receive any calls, including

emergency calls, or use other features

that require network coverage. To make

calls, you must first activate the phone

function by changing profiles. If the

device has been locked, enter the lock

code.

If you need to make an emergency call

while the device is locked and in the

Flight profile, you may be also able to

enter an official emergency number

programmed in your device in the lock

code field and select 'Call'. The device

will confirm that you are about to exit

Flight profile to start an emergency call.

Switch it on 17

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Support and updates

Nokia helps you in many ways to gain

the most benefit from your device.

Support

When you want to learn more about

how to use your product or you are

unsure how your device should

function, see the user guide or see the

support pages at www.nokia.com/

support or your local Nokia website, or

with a mobile device,

www.nokia.mobi/support.

If this does not resolve your issue, do

one of the following:

•Restart the device: switch off the

device, and remove the battery.

After about a minute, replace the

battery, and switch on the device.

•Restore the original factory settings

as explained in the user guide.

•Update your device software

regularly for optimum performance

and possible new features, as

explained in the user guide.

If your issue remains unsolved, contact

Nokia for repair options. See

www.nokia.com/repair, or in Latin

America, www.nokia-

latinoamerica.com/centrosdeservicio.

Before sending your device for repair,

always back up the data in your device.

My Nokia

Select Menu > Applications >

Extras > Collection > My Nokia.

My Nokia is a free service that regularly

sends you text messages containing

tips, tricks, and support for your Nokia

device. It also allows you to browse the

My Nokia site where you can find details

about Nokia devices and download

tones, graphics, games, and

applications.

To use the My Nokia service, it must be

available in your country and supported

by your service provider. You must sign

up to use the service. Call charges apply

when you send messages to sign up or

unsubscribe. For terms and conditions,

see the documentation supplied with

your device, or www.nokia.com/

mynokia.

18 Support and updates

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Download content

You may be able to download new

content (for example, themes) to your

device (network service).

Important: Use only services that you

trust and that offer adequate security

and protection against harmful

software.

For the availability of different services

and pricing, contact your service

provider.

Software updates using your PC

Software updates may include new

features and enhanced functions that

were not available at the time of

purchase of your device. Updating the

software may also improve the device

performance.

Nokia Software Updater is a PC

application that enables you to update

your device software. To update your

device software, you need a compatible

PC, broadband internet access, and a

compatible USB data cable to connect

your device to the PC.

To get more information, to check the

release notes for the latest software

versions, and to download the Nokia

Software Updater application, see

www.nokia.com/softwareupdate, or in

Latin America, www.nokia-

latinoamerica.com/nsu.

To update the device software, do the

following:

1 Download and install the Nokia

Software Updater application to

your PC.

2 Connect your device to the PC using

a USB data cable, and open the

Nokia Software Updater

application. The Nokia Software

Updater application guides you to

back up your files, update the

software, and restore your files.

Software updates over the air

Your service provider may send device

software updates over the air directly to

your device (network service). This

option may not be available, depending

on your device.

Downloading software updates may

involve the transmission of large

amounts of data (network service).

Support and updates 19

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Make sure that the device battery has

enough power, or connect the charger

before starting the update.

Warning:

If you install a software update, you

cannot use the device, even to make

emergency calls, until the installation is

completed and the device is restarted.

Be sure to back up data before accepting

installation of an update.

Request a software update

1Select Menu > Settings and

Phone > Phone updates to

request available software updates

from your service provider.

2Select Current sw details to display

the current software version and

check whether an update is needed.

3Select Downl. phone sw to

download and install a software

update. Follow the instructions.

4 If the installation was cancelled

after the download, select Install

sw update to start the installation.

The software update may take several

minutes. If there are problems with the

installation, contact your service

provider.

Restore factory settings

To restore the device back to the factory

settings, select Menu > Settings >

Rest. fact. sett. and from the following:

Settings only — Reset all preference

settings without deleting any personal

data.

All — Reset all preference settings, and

delete all personal data, such as

contacts, messages, media files, and

activation keys.

20 Support and updates

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Make it your device

Set up your device, personalise it, and

connect it in several ways.

Basic settings

Phone settings

Select Menu > Settings and Phone.

Select from the following:

Language settings — To set the

language of your device, select Phone

language and a language. To set the

language of your device according to

the information on the SIM card, select

Phone language > Automatic.

Memory status — View the memory

consumption.

Automatic keyguard — Set the

keypad to lock automatically after a

preset time delay when the device is in

the home screen and no function has

been used.

Security keyguard — Set the device to

prompt for the security code to unlock

the keypad.

Voice recognition — Set up voice

commands, or start voice recognition

training.

Flight query — Set the device to

prompt for the flight profile when you

switch the device on. In the flight

profile, all radio connections are closed.

Phone updates — Allow software

updates from your service provider

(network service). The available options

may vary.

Network mode — To use GSM and

(when available) 3G networks, select

Dual mode. This option is not available

during an active call.

Operator selection — Manually select

which network to use.

Help text activation — Set the device

to display help text.

Start-up tone — Play a tone when you

switch the device on.

Fold close handling — Select the

behaviour of the device when the fold is

closed.

Confirm SIM actions — Access

additional network services from your

SIM card. This option may not be

available, depending on your SIM card.

Security settings

Select Menu > Settings and Security.

Make it your device 21

www.nokia.com/support

Cyan

Magenta

Yellow

Black

When security features that restrict calls

are in use (such as call barring, closed

user group, and fixed dialling), calls may

be possible to the official emergency

number programmed into your device.

Call barring and call diverting cannot be

active at the same time.

Select from the following:

PIN code request or UPIN code

request — Set the device to request for

the PIN or UPIN code every time the

device is switched on. Some SIM cards

do not allow the code request to be

deactivated.

Call barring service — Restrict

incoming calls to and outgoing calls

from your device (network service). A

barring password is required.

Fixed dialling — Restrict your

outgoing calls to selected phone

numbers if supported by your SIM card.

When fixed dialling is activated, GPRS

connections are not possible except

while sending text messages over a

GPRS connection. In this case, the

recipient’s phone number and the

message centre number must be

included in the fixed dialling list.

Closed user group — Define a group of

people whom you can call and who can

call you (network service).

Security level — To request the

security code whenever a new SIM card

is inserted into the device, select

Phone.

Access codes — Change the security

code, PIN code, UPIN code, PIN2 code, or

barring password.

PIN2 code request — Set the device to

request the PIN2 code when using a

specific device feature protected by the

PIN2 code. Some SIM cards do not allow

the code request to be deactivated. This

option may not be available depending

on your SIM card. For details, contact

your service provider.

Code in use — Display and select the

type of PIN code to be used.

Auth. certificates or User

certificates — View the list of the

authority or user certificates available

on your device.

Security module — View Sec. module

details, activate Module PIN request,

or change the module PIN and signing

PIN.

22 Make it your device

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Personalise your device

Give your device a personal touch with

ringing tones, display backgrounds, and

themes. Add shortcuts for your

preferred features, and attach

enhancements.

Profiles

Your device has several profiles, which

you can customise.

Select Menu > Settings and Profiles.

Select the desired profile and from the

following:

Activate — Activate the profile.

Personalise — Modify profile settings.

Timed — Set the profile to be active for

a certain period of time. When the time

set for the profile expires, the previous

profile that was not timed becomes

active.

Themes

With themes, you can personalise your

device.

Select Menu > Settings and Themes.

Select a theme

Select Select theme > Themes and a

theme.

Download more themes

Select

Theme downld..

Tones

You can modify the tone settings of the

currently active profile.

Select Menu > Settings and Tones.

You can find the same settings in the

Profiles menu.

Lights

You can activate or deactivate light

effects associated with different device

functions.

Select Menu > Settings and Lights.

Display

Select Menu > Settings and Display.

Select from the following:

Wallpaper — Add a background image

to the home screen.

Make it your device 23

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Home screen — Activate, organise,

and personalise the home screen.

Home scr. font col. — Select the font

colour for the home screen.

Navigat. key icons — Display the scroll

key icons in the home screen.

Notification details — Display details

in missed call and message

notifications.

Fold animation — Display an

animation when you open or close the

fold.

Main menu view — Select the layout

of the main menu.

Font size — Set the font size for

messaging, contacts, and web pages.

Operator logo — Display the logo of

the currently selected operator.

Cell info display — Display the cell

identity, if available from the network.

My shortcuts

With personal shortcuts, you get quick

access to frequently used functions of

your device. Select Menu > Settings

and My shortcuts.

Left and right selection keys

To change the function assigned to the

left or right selection key, select Left

selection key or Right selection key,

and the desired function.

In the home screen , if the left selection

key is Go to, to add, remove, or

reorganise functions, select Go to >

Options > Select options or

Organise.

Other shortcuts

Select from the following:

Navigation key — Assign other

functions from a predefined list to the

scroll key.

Home screen key — Select the

movement of the scroll key to activate

the home screen.

Assign dialling shortcuts

Create shortcuts by assigning phone

numbers to the number keys 3-9.

1 Select Menu > Contacts > Speed

dials, and scroll to a number key.

2 Select Assign, or, if a number has

already been assigned to the key,

select Options > Change.

24 Make it your device

www.nokia.com/support

Cyan

Magenta

Yellow

Black

3 Enter a number or search for a

contact.

Voice commands

You can use voice commands to make

phone calls, launch applications, and

activate profiles. Voice commands are

language-dependent.

Select Menu > Settings and Phone.

Set the language

Select Language settings > Phone

language and the language.

Train voice recognition to your voice

Select Voice recognition > Voice

training.

Activate a voice command for a

function

Select Menu > Settings > Phone >

Voice recognition > Voice

commands, a feature, and the function.

indicates that the voice command is

activated. If is not displayed, select

Add.

Play an activated voice command

Select Play.

Use voice commands

See "Voice dialling", p. 32.

Rename or deactivate a voice

command

Scroll to a function, and select

Options > Edit or Remove.

Activate or deactivate all voice

commands

Select Options > Add all or Remove

all.

Connect

Your device provides several features to

connect to other devices to transmit and

receive data.

Bluetooth wireless technology

With Bluetooth wireless technology,

you can connect your device, using radio

waves, to a compatible Bluetooth

device within 10 metres (32 feet).

Select Menu > Settings >

Connectivity > Bluetooth.

This device is compliant with Bluetooth

Specification 2.1 + EDR supporting the

following profiles: SIM access, object

push, file transfer, headset, handsfree,

Make it your device 25

www.nokia.com/support

Cyan

Magenta

Yellow

Black

generic access, serial port, generic

object exchange, dial-up networking,

device ID, phonebook access, service

discovery application, advanced audio

distribution, audio video remote

control, and generic audio/video

distribution. To ensure interoperability

between other devices supporting

Bluetooth technology, use Nokia

approved accessories for this model.

Check with the manufacturers of other

devices to determine their compatibility

with this device.

Features using Bluetooth technology

increase the demand on battery power

and reduce the battery life.

Set up a Bluetooth connection

1Select My phone's name, and enter

a name for your device.

2 To activate Bluetooth connectivity,

select Bluetooth > On.

indicates that Bluetooth

connectivity is active.

3 To connect your device to an audio

accessory, select Conn. to audio

acc. and the accessory.

4 To pair your device with any

Bluetooth device in range, select

Paired devices > Add new

device.

5 Scroll to a found device, and select

Add.

6 Agree on a passcode (up to 16

characters) with the user of the

other device and enter the passcode

on your device. To establish the

connection, enter the passcode on

the other device, when requested.

Operating the device in hidden mode is

a safer way to avoid malicious software.

Do not accept Bluetooth connectivity

from sources you do not trust.

Alternatively, switch off the Bluetooth

function. This does not affect other

functions of the device.

Connect your PC to the internet

You can use Bluetooth technology to

connect your compatible PC to the

internet without the PC Suite software.

Your device must be able to connect to

the internet (network service), and your

PC must support Bluetooth technology.

After connecting to the network access

point (NAP) service of the device, and

pairing with your PC, your device

automatically opens a packet data

connection to the internet.

26 Make it your device

www.nokia.com/support

Cyan

Magenta

Yellow

Black

USB data cable

You can use the USB data cable to

transfer data between your device and

a compatible PC or a printer supporting

PictBridge.

Select USB mode

To activate the device for data transfer

or image printing, connect the USB data

cable, and select from the following:

PC Suite — Use Nokia PC Suite on your

PC.

Printing & media — Use your device

with a PictBridge compatible printer or

with a compatible PC.

Data storage — Connect to a PC that

does not have Nokia software, and use

your device as data storage

Change USB mode

Select Menu > Settings >

Connectivity > USB data cable and the

desired USB mode.

Connect a USB device

You can connect a USB storage device

(for example, a memory stick) to your

device and browse the file system and

transfer files.

1 Connect a compatible adapter cable

to the USB port of your device.

2 Connect the USB storage to the

adapter cable.

3 Select Menu > Gallery and the USB

device.

Not all USB storage devices are

supported, depending on their power

consumption.

Synchronisation and backup

Select Menu > Settings > Sync &

backup > Synchronisation and from

the following:

Synchronisation — Create a backup of

your personal data to a Nokia server.

Before you start a backup, you need to

set up your My Nokia account. Select

Connect, and you will be guided

through the process.

Phone switch — Synchronise or copy

selected data between your device and

another device using Bluetooth

technology.

Create backup — Create a backup of

selected data.

Restore backup — Select a stored

backup file, and restore data to the

device. Select Options > Details for

Make it your device 27

www.nokia.com/support

Cyan

Magenta

Yellow

Black

information about the selected backup

file.

Data transfer — Synchronise or copy

selected data between your device and

another device, PC, or network server

(network service).

Packet data

General packet radio service (GPRS) is a

network service that allows mobile

devices to send and receive data over an

internet protocol (IP) based network.

Select Menu > Settings and

Connectivity > Packet data > Packet

data conn..

Select from following:

When needed — Establish the packet

data connection only when an

application needs it. The connection is

closed when the application is closed.

Always online — Automatically

connect to a packet data network when

you switch the device on.

You can use your device as a modem by

connecting it to a compatible PC. For

details, see the Nokia PC Suite

documentation.

Network provider services

Your network provider provides several

additional services you may want to

use. For some of these services, charges

may apply.

Operator menu

Access a portal to services provided by

your network operator. The operator

can update this menu with a service

message. For more information, contact

your network operator.

SIM services

Your SIM card may provide additional

services. You can access this menu only

if it is supported by your SIM card. The

name and contents of the menu depend

on the available services.

Accessing these services may involve

sending messages or making a phone

call for which you may be charged.

Position log

The network may send you a position

request (network service). To subscribe

and agree upon the delivery of

positioning information, contact your

service provider.

28 Make it your device

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Accept or reject an incoming position

request

Select Accept or Reject.

View the latest position requests

Select Menu > Log > Positioning and

Position log.

If you miss the request, the device

automatically accepts or rejects it

according to what you have agreed with

your service provider.

Info messages, SIM messages, and

service commands

Select Menu > Messaging and More.

View info messages

Select Info messages. You can receive

messages on various topics from your

service provider (network service). For

more information, contact your service

provider.

Send service commands

Select Serv. commands. Service

commands allow you to write and send

service requests (USSD commands) to

your service provider, such as activation

commands for network services. For

details, contact your service provider.

View SIM messages

Select Menu > Messaging and

Options > SIM messages. SIM

messages are specific text messages

that are saved to your SIM card. You can

copy or move those messages from the

SIM to the device memory, but not vice

versa.

Configuration settings

You can configure your device with

settings that are required for certain

services. You may receive these settings

as a configuration message from your

service provider.

Select Menu > Settings.

Select Configuration and from the

following:

Default config. sett. — View the

service providers saved in the device,

and set a default service provider.

Act. def. in all apps. — Activate the

default configuration settings for

supported applications.

Make it your device 29

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Preferred access pt. — View the saved

access points.

Device mgr. settings — Allow or

prevent the device from receiving

software updates. This option may not

be available, depending on your device.

Personal settings — Add manually

new personal accounts for various

services, and activate or delete them. To

add a new personal account, select

Add or Options > Add new. Select the

service type, and enter the required

parameters. To activate a personal

account, scroll to the account, and select

Options > Activate.

Stay in touch

Learn how to make calls, write text,

send messages, and use the mail

functionality of your device.

Make calls

Make a voice call

Dial a number manually

Enter the phone number, including the

area code, and press the call key.

For international calls, press * twice for

the international prefix (the + character

replaces the international access code),

enter the country code, the area code

without the leading 0, if necessary, and

the phone number.

Redial a number

To access the list of dialled numbers, in

the home screen , press the call key.

Select a number or name, and press the

call key.

Call a contact

Select Menu > Contacts and Names.

Select a contact, and press the call key.

30 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Handle voice calls

To handle calls with the fold, select

Menu > Settings and Call > Answ. on

fold open.

Answer an incoming call

Press the call key, or open the fold.

End a call

Press the end key, or close the fold.

Mute the ringing tone

Select Silence.

When the fold is closed, press a volume

key.

Reject an incoming call

Press the end key.

When the fold is closed, press and hold

a volume key.

Adjust the volume in a call

Use the volume keys.

Make a video call

In a video call, the video recorded with

the front camera on your device is

shown to the video call recipient. To

make a video call, you must have a USIM

card and be connected to a WCDMA

network. For availability and

subscription to video call services,

contact your service provider. The video

call can be made to a compatible device

or an ISDN client between two parties.

Video calls cannot be made while

another voice, video, or data call is

active.

1 To start a video call, enter the phone

number, including the area code.

2 Press and hold the call key, or select

Options > Video call.

Starting a video call may take a

while. If the call is not successful,

you are asked to try making a voice

call or to send a message instead.

3 To end the call, press the end key.

Dialling shortcuts

You can assign phone numbers to the

number keys 3-9.

1 Select Menu > Contacts > Speed

dials, and scroll to a number key.

2 Select Assign, or, if a number has

already been assigned to the key,

select Options > Change.

3 Enter a number or search for a

contact.

Stay in touch 31

www.nokia.com/support

Cyan

Magenta

Yellow

Black

4 To activate one key dialling, select

Menu > Settings and Call >

Speed dialling > On

Use a dialling shortcut

Press a number key, then the call key.

Use one key dialling

Press and hold a number key.

Voice dialling

Make a phone call by saying the name

that is saved in Contacts.

As voice commands are language-

dependent, before voice dialling, select

Menu > Settings and Phone >

Language settings > Phone

language, and your language.

Note: Using voice tags may be difficult

in a noisy environment or during an

emergency, so you should not rely solely

upon voice dialling in all circumstances.

1 In the home screen, press and hold

the right selection key. A short tone

sounds, and Speak after the tone

is displayed.

2 Say the name of the contact you

want to dial. If the voice recognition

is successful, a list of proposed

matches is displayed. The device

plays the voice command of the first

match on the list. If it is not the

correct command, scroll to another

entry.

Options during a call

Many of the options that you can use

during a call are network services. For

availability, contact your service

provider.

Activate options during a call

Select Options.

Some of the network options are Hold,

New call, Add to conference, End all

calls, and the following:

Send DTMF — Send tone strings.

Swap — Switch between the active call

and the call on hold.

Transfer — Connect a call on hold to an

active call and disconnect yourself.

Conference — Make a conference call.

Private call — Start a private

discussion in a conference call.

32 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Voice messages

The voice mailbox is a network service

to which you may need to subscribe. For

more information, contact your service

provider.

Call your voice mailbox

Press and hold 1.

Edit your voice mailbox number

Select Menu > Messaging > More >

Voice messages and Voice mailbox

no..

Video messages

The video mailbox is a network service

to which you may need to subscribe. For

more information, contact your service

provider.

Call your video mailbox

Press and hold 2.

Edit your video mailbox number

Select Menu > Messaging and

More > Video messages > Video

mailbox no..

Call log

To view details of your calls, messages,

data, and synchronisation, select

Menu > Log and the desired item.

Note: The actual invoice for calls and

services from your service provider may

vary, depending on network features,

rounding off for billing, taxes, and so

forth.

Call settings

Select Menu > Settings and Call and

from the following:

Call divert — Divert your incoming calls

(network service). You may not be able

to divert your calls if some call barring

functions are active.

Anykey answer — Answer an

incoming call by briefly pressing any

key, except the power key, the left and

right selection keys, or the end key.

Automatic redial — The device redials

the number automatically if a call fails.

The device tries to call the number 10

times.

Video-voice redial — The device

automatically makes a voice call to the

same number to which a video call has

failed.

Stay in touch 33

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Voice clarity — Improve speech

intelligibility, especially in noisy

environments.

Speed dialling — Dial the names and

phone numbers assigned to the number

keys (2-9) by pressing and holding the

corresponding number key.

Call waiting — The network notifies

you of an incoming call while you have

a call in progress (network service).

Call dur. display — Display the

duration of the call in progress.

Summary after call — Briefly display

the approximate duration after each

call.

Send my caller ID — Show your phone

number to the person you are calling

(network service). To use the setting

agreed upon with your service provider,

select Set by network.

Outgoing call line — Select the phone

line for making calls, if your SIM card

supports multiple phone lines (network

service).

Answ. on fold open — Answer or end

a call by opening or closing the fold.

Text and messages

Write text, and create messages and

notes.

Write text

Text input modes

To enter text, for example, when writing

messages, you can use traditional or

predictive text input.

, , and indicate the character

cases. indicates number mode.

Switch between text input modes

Press and hold Options. Not all

languages are supported by predictive

text input.

Switch between character cases

Press #.

Switch between letter and number

modes

Press and hold #.

Set the writing language

Select Options > Writing language.

34 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Traditional text input

Write a word

Press a number key, 2-9, repeatedly

until the desired character is displayed.

The available characters depend on the

selected writing language. If the next

letter you want to enter is located on the

same key as the present one, wait until

the cursor is displayed, and enter the

letter.

Insert common punctuation marks

Press 1 repeatedly.

Insert special characters

Press *, and select a character from the

list.

Insert a space

Press 0.

Predictive text input

Predictive text input is based on a built-

in dictionary to which you can also add

new words.

Write a word

Press number keys, 2-9. Press each key

only once for one letter.

Confirm a word

Scroll right, or press 0 to add a space.

Select the correct word

If the proposed word is not correct,

press * repeatedly, and select the

desired word from the list.

Add a word to the dictionary

If the ? character is displayed after the

word, the word you intended to write is

not in the dictionary. To add the word

to the dictionary, select Spell. Enter the

word using traditional text input, and

select Save.

Write a compound word

Write the first part of the word, and

scroll right to confirm it. Write the next

part of the word, and confirm again.

Text and multimedia messages

You can create a message and optionally

attach, for example, a picture. Your

device automatically changes a text

message to a multimedia message

when a file is attached.

Stay in touch 35

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Text messages

Your device supports text messages

beyond the limit for a single message.

Longer messages are sent as two or

more messages. Your service provider

may charge accordingly. Characters

with accents, other marks, or some

language options take more space, and

limit the number of characters that can

be sent in a single message.

The total number of characters left and

the number of messages needed for

sending are displayed.

To send messages, the correct message

centre number must be stored in your

device. Normally, this number is set by

default through your SIM card.

1 To set the number manually, select

Menu > Messaging and More >

Message settings > Text

messages > Message centre.

2 Enter the name and the number

supplied by the service provider.

Multimedia messages

A multimedia message can contain text,

pictures, and sound or video clips.

Only devices that have compatible

features can receive and display

multimedia messages. The appearance

of a message may vary depending on

the receiving device.

The wireless network may limit the size

of MMS messages. If the inserted picture

exceeds this limit, the device may make

it smaller so that it can be sent by MMS.

Important: Exercise caution when

opening messages. Messages may

contain malicious software or

otherwise be harmful to your device or

PC.

For availability and subscription to the

multimedia messaging service (MMS),

contact your service provider.

Create a message

1 Select Menu > Messaging and

Create message.

2 Write your message.

To insert a special character or a

smiley, select Options > Insert

symbol.

To attach an object to the message,

select Options > Insert object. The

message type changes

36 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

automatically to multimedia

message.

3 To add recipients, select Send to

and a recipient.

To enter a phone number or mail

address manually, select Number

or e-mail. Enter a phone number,

or select E-mail and enter a mail

address.

4Select Send.

Multimedia messages are indicated

with an icon at the top of the display.

Service providers may charge differently

depending on the message type. For

details, contact your service provider.

Read a message and reply

Important: Exercise caution when

opening messages. Messages may

contain malicious software or

otherwise be harmful to your device or

PC.

Read a received message

Select View.

Reply to a message

Select Reply.

Read several received messages

Select Menu > Messaging and Inbox,

and the desired message.

Send and organise messages

To send a message, select Send.

Note: The message sent icon or text on

your device screen does not indicate

that the message is received at the

intended destination.

If message sending is interrupted, the

device tries to resend the message a few

times. If these attempts fail, the

message is marked as failed in the Sent

items folder.

The device saves received messages in

the Inbox folder. Organise your

messages in the Saved items folder.

To add, rename, or delete a folder, select

Menu > Messaging and More >

Archive > Options.

Flash messages

Flash messages are text messages that

are instantly displayed upon reception.

Select Menu > Messaging.

Stay in touch 37

www.nokia.com/support

Cyan

Magenta

Yellow

Black

1Select More > Other messages >

Flash message.

2 Write your message.

3Select Send to and a contact.

Nokia Xpress audio messages

Create and send audio messages using

MMS in a convenient way.

Select Menu > Messaging.

1Select More > Other messages >

Audio message. The voice recorder

opens.

2 To record your message, select .

3 To stop recording, select .

4Select Send to and a contact.

Message settings

Select Menu > Messaging and

More > Msg. settings.

Select from the following:

General settings — Save copies of sent

messages in your device, overwrite old

messages if the message memory

becomes full, and set up other

preferences related to messages.

Text messages — Allow delivery

reports, set up message centres for SMS

and SMS mail, select the type of

character support, and set up other

preferences related to text messages.

Multimedia msgs. — Allow delivery

reports, set up the appearance of

multimedia messages, allow the

reception of multimedia messages and

advertisements, and set up other

preferences related to multimedia

messages.

E-mail messages — Allow mail

reception, set the image size in mail,

and set up other preferences related to

mail.

Service messages — Activate service

messages, and set up preferences

related to service messages.

Mail and Instant Messaging

Set up your device to send and receive

mails from your mail account or to chat

in your instant messaging (IM)

community.

Nokia IM

With the instant messaging (IM)

network service, you can send short text

messages to online users. You must

38 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

subscribe to a service and register with

the IM service you want to use. For

availability, pricing, and instructions,

contact your service provider. The

menus may vary depending on your IM

service provider.

To connect to the service, select

Menu > I M, and follow the instructions.

Nokia Mail

Access your mail account with your

device to read, write, and send mail.

This mail application is different from

the SMS mail function.

Before you can use mail, you must have

an mail account from an mail service

provider. For availability and the correct

settings, contact your mail service

provider. You may receive the mail

configuration settings as a

configuration message.

Mail setup wizard

The mail setup wizard opens

automatically if no mail settings are

defined in the device. To open the setup

wizard, to add an additional mail

account, select Menu > Messaging

and the existing mail account. Select

Options > Add mailbox. Follow the

instructions.

Write and send a mail

You may write your mail before

connecting to the mail service.

1 Select Menu > Messaging and

Create message > E-mail

message.

2 Enter the recipient’s mail address,

the subject, and the mail message.

To attach a file, select Options >

Insert.

3 If more than one mail account is

defined, select the account from

which you want to send the mail.

4 Select Send.

Read a mail and reply

Important: Exercise caution when

opening messages. Messages may

contain malicious software or

otherwise be harmful to your device or

PC.

Select Menu > Messaging.

Download mail headers

Select your mail account.

Stay in touch 39

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Download a mail and its attachments

Select a mail and Open or Retrieve.

Reply to or forward a mail

Select Options > Reply or Forward.

Disconnect from your mail account

Select Options > Disconnect. The

connection to the mail account

automatically ends after some time

without activity.

New mail notifications

Your device can automatically check

your mail account at set intervals, and

issue a notification when new mail is

received.

Select Menu > Messaging.

1Select Msg. settings > E-mail

settings > Edit mailboxes.

2 Select your mail account,

Downloading sett., and the

following options:

Update interval — Set how often

your device checks your mail

account for new mail.

Automatic retrieval — Retrieve

new mail automatically from your

mail account.

3 To enable new mail notification,

select Msg. settings > E-mail

settings > New e-mail notif..

40 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Image and video

Capture images

Activate the camera

Select Menu > Applications >

Camera; or, if in video mode, scroll left

or right.

Zoom in or out

In image mode, scroll up and down, or

use the volume keys.

Capture an image

Select Capture.

Images are saved in Gallery.

Activate the camera flash

To set the device to use the flash

automatically if the lighting conditions

require it, select Options > Flash >

Automatic. To set the device to always

use the flash, select Flash on.

Keep a safe distance when using the

flash. Do not use the flash on people or

animals at close range. Do not cover the

flash while taking a picture.

Display images after capture

Select Options > Settings > Photo

preview time and the preview time.

End the image preview manually

Select Back.

Your device supports an image capture

resolution of up to 1536x2048 pixels.

Record video clips

Activate video mode

Select Menu > Applications and

Video camera, or, if in image mode,

scroll left or right.

Start recording

Select Record.

Pause or resume recording

Select Pause or Continue.

Stop recording

Select Stop.

Video clips are saved in Gallery.

Image and video 41

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Camera and video settings

Select Menu > Applications >

Camera.

In image or video mode, select

Options and from the following:

Self-timer — Use the self-timer.

Effects — Apply different effects (for

example, greyscale and false colour) to

the captured image.

White balance — Adapt the camera to

the current light conditions.

Landscape format or Portrait

format — Select the orientation of the

camera.

Settings — Modify other camera and

video settings, and select where to save

images and video clips.

Gallery

Manage images, video clips, music files,

themes, graphics, tones, recordings,

and received files. These files are stored

in the device memory or on a memory

card and may be arranged in folders.

Photos

View images and play video clips with

the Photos application.

Select Menu > Gallery > Photos.

Select from the following:

All photos — View images in a

thumbnail grid. You can sort images by

date, name, or size.

Timeline — View images in the order

they were captured.

Albums — Sort images into albums.

You can create, rename and remove

albums. If you remove an album, the

images inside the album are not deleted

from the memory.

Rotate an image

Select Options > Landscape mode or

Portrait mode.

View a slide show

A slide show uses the images of the

currently selected folder or album.

1 Select All photos, Timeline, or

Albums.

2 Select Options > Slide show.

3 Select Start slide show.

42 Image and video

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Edit images

You can, for example, rotate, flip, crop,

and adjust the brightness, contrast, and

colours of images.

1 Select an image in All photos,

Timeline, or Albums.

2Select Options > Edit photo.

3 Select an editing option, and use

the scroll key to change the settings

or values.

Music and videos

Your device includes a media player for

playing songs and video clips. Music and

video files stored in the music folder in

the device memory or on the memory

card are automatically detected and

added to the video or music library.

Select Menu > Gallery and Music &

videos.

Select from the following:

Videos — List all available video clips.

All songs — List all available songs. You

can sort songs by artist, album, or genre,

for example.

Manage folders and files

To manage folders and files in Gallery,

select Menu > Gallery.

View a list of folders

Select All content.

View a list of files in a folder

Select a folder and Open.

View the folders of the memory card

when moving a file

Scroll to the memory card, and scroll

right.

Print images

Your device supports Nokia XpressPrint,

allowing you to print images in the JPEG

file format.

1 Connect your device to a compatible

printer, using a USB data cable, or,

if supported by the printer,

Bluetooth connectivity.

2 Select an image from Gallery and

Options > Print.

Image and video 43

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Share images and video clips online

Share images and video clips in

compatible online sharing services on

the web.

To use online sharing, you must

subscribe to an online sharing service

(network service).

1Select Menu > Gallery > Photos

and a file.

2Select Options > Send > Upload

to web.

3Select an online sharing service, and

follow the instructions on the

display.

You may also mark several images or

video clips and upload them together to

the online sharing service.

You can view uploads on the internet

pages of the online sharing service on

your device.

For more information on online sharing

and compatible service providers, see

the Nokia product support pages or your

local Nokia website.

Memory card

Use a memory card to store your

multimedia files, such as video clips,

songs, sound files, images, and

messaging data.

Select Menu > Gallery > All

content > Memory card.

Some of the folders in Gallery that

contain content used by your device (for

example, Themes) can be stored on the

memory card.

If your memory card has not been pre-

formatted, you need to format it. When

you format a memory card, all data on

the card is permanently deleted.

Format the memory card

Select Options > Mem. card

options > Format memory card >

Yes. When formatting is complete,

enter a name for the memory card.

Protect the memory card with a

password

Select Options > Mem. card

options > Set password. The

password is stored in your device, so

you only have to enter the password

44 Image and video

www.nokia.com/support

Cyan

Magenta

Yellow

Black

when attempting to use the memory

card in another device.

Remove the memory card password

Select Options > Mem. card

options > Delete password.

Check the memory consumption

Select Options > Details. The memory

consumption of different data groups,

and the amount of available memory to

install new software, is displayed.

Entertainment

Listen to music

Listen to music with the music player or

radio, and record sounds or voice with

the voice recorder. Download music

from the internet, or transfer music

from your PC.

Warning:

Continuous exposure to high volume

may damage your hearing. Listen to

music at a moderate level, and do not

hold the device near your ear when the

loudspeaker is in use.

Media player

To open the media player, select

Menu > Applications > Media

player.

Music menu

Access your music and video files stored

in the device memory or on the memory

card, download music or video clips

from the web, or view compatible video

streams from a network server

(network service).

Entertainment 45

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Select Menu > Applications > Media

player.

Play a media file

Select a file from the available folders

and Play.

Download files from the web

Select Options > Downloads and a

download site.

Update the music library after

adding files

Select Options > Update library.

Create a playlist

1Select Playlists > Create playlist,

and enter the name of the playlist.

2 Add music or video clips from the

displayed lists.

3 To store the playlist, select Done.

Configure a streaming service

You may receive the streaming settings

as a configuration message from the

service provider. You can also enter the

settings manually.

1 Select Options > Downloads >

Streaming settings >

Configuration.

2 Select a service provider, Default,

or Personal config. for streaming.

3 Select Account and a streaming

service account from the active

configuration settings.

Play songs

Operate the media player

Use the scroll key according to the

virtual keys on the display.

Adjust the volume

Use the volume keys.

Start playing

Select .

Pause playing

Select .

Skip to the next song

Select .

Skip to the previous song

Select twice.

46 Entertainment

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Fast-forward the current song

Select and hold .

Rewind the current song

Select and hold .

Switch to the music menu

Select .

Switch to the current playlist

Select .

Leave the media player playing in

the background

Press the end key.

Stop the media player

Press and hold the end key.

Change the media player look

Your device provides several themes to

change the look of the media player.

Select Menu > Applications > Media

player and Go to Media pl. >

Options > Settings > Media player

theme and the desired theme.

The virtual keys may change depending

on the theme.

Transfer music from a computer

You can transfer music to your device in

the following ways:

•Use Nokia Music to transfer, rip,

burn, and play new music on your

PC and mobile device. Download the

PC software from

www.music.nokia.com/download.

•Use PC Suite to connect your device

to your PC using Bluetooth

connectivity or a compatible USB

data cable, and use the Nokia Music

Manager. To use a USB data cable,

select PC Suite as the connection

mode.

•Connect your device to your PC

using Bluetooth connectivity or a

compatible USB data cable, and

copy music files to the device

memory. To use a USB data cable,

select Data storage as the

connection mode.

•Use Windows Media Player. Connect

a compatible USB data cable, and

select Printing & media as the

connection mode.

Radio

The FM radio depends on an antenna

other than the wireless device antenna.

Entertainment 47

www.nokia.com/support

Cyan

Magenta

Yellow

Black

A compatible headset or accessory

needs to be attached to the device for

the FM radio to function properly.

Select Menu > Applications >

Radio.

Tune in to radio stations

1 To start the search, press and hold

the scroll key left or right. To change

the radio frequency in 0.05 MHz

steps, briefly press the scroll key left

or right.

2 To save a station to a memory

location, select Options > Save

station.

3 To enter the name of the radio

station, select Options >

Stations > Options > Rename.

Select Options and from the following:

Search all stations — Search

automatically for the available stations

at your location.

Set frequency — Enter the frequency

of a radio station.

Station directory — Access a website

with a list of radio stations.

Stations — List, rename, or delete

saved stations.

Use the virtual keys on the display

Use the scroll key.

Change stations

Scroll up or down, or press the number

key that corresponds to the number of

the station in the station list.

Adjust the volume

Use the volume keys.

Set the radio to play in the

background

Briefly press the end key.

Close the radio

Press and hold the end key.

Radio settings

Select Menu > Applications >

Radio.

Select Options > Settings and from the

following:

RDS — Display information from the

radio data system, such as the name of

the station.

Auto-frequency — Allow the device to

automatically switch to a frequency

48 Entertainment

www.nokia.com/support

Cyan

Magenta

Yellow

Black

with better reception (available when

RDS is activated).

Play via — Listen using the headset or

the loudspeaker.

Output — Switch between stereo and

mono output.

Radio theme — Select the look of the

radio.

Voice recorder

Record speech, sound, or an active call,

and save the recordings in Gallery.

Select Menu > Applications > Voice

recorder.

The recorder cannot be used when a

data call or GPRS connection is active.

To use the graphical keys , , or ,

scroll left or right.

Start recording

Select , or, during a call, select

Options > Record. While recording a

call, all parties to the call hear a faint

beeping.

Pause recording

Select .

Stop recording

Select . The recording is saved in the

Recordings folder in Gallery.

To play or send the last recording, to

access the list of recordings, or to select

the memory and the folder to store the

recordings, select Options and the

appropriate option.

Equaliser

Adjust the sound when using the media

player.

Select Menu > Applications >

Equaliser.

Activate a predefined equaliser set

Scroll to a set, and select Activate.

Create a new equaliser set

1 Select one of the last two sets in the

list and Options > Edit.

2 Use the scroll key to adjust the

sound controls.

3 To save the settings and enter a

name for the set, select Save and

Options > Rename.

Entertainment 49

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Web

You can access various internet services

with your device browser (network

service). The appearance of the internet

pages may vary due to screen size. You

may not be able to see all the details on

the internet pages.

Important: Use only services that you

trust and that offer adequate security

and protection against harmful

software.

For the availability of these services,

pricing, and instructions, contact your

service provider.

You may receive the configuration

settings required for browsing as a

configuration message from your

service provider.

Select Menu > Internet.

To set up the service, select Web

settings > Configuration sett., a

configuration, and an account.

Browse the web

Select Menu > Internet.

Open the home page

Select Home; or in the home screen,

press and hold 0.

Select a bookmark

Select Bookmarks.

Enter a web address

Select Go to address, enter the address,

and select OK.

Select the last visited web address

Select Last web addr..

Search the web

If you search for the first time, select a

search provider. Then select Search,

enter the search terms, and select

Search.

Change the search provider

Select Options > Change provider.

After you connect to the service, you can

start browsing its pages. The function of

the device keys may vary in different

services. Follow the instructions. For

more information, contact your service

provider.

50 Entertainment

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Web uploads

On the web page of your online sharing

service, you can view uploaded images

and video clips and modify settings

(network service).

Select Menu > Internet and Web

uploads.

Open an online sharing service

Select an online sharing service and a

link offered by the service.

Modify settings

When an online sharing service is open,

select Options > Settings.

Browser settings

While browsing the web, select

Options > Settings and from the

following:

Display — Select the font size, whether

images are displayed, and how the text

is displayed.

General — Select the encoding type for

the contents, whether web addresses

are sent as Unicode (UTF-8), and

whether JavaScript™ is enabled.

The available options may vary.

Cache memory

A cache is a memory location that is

used to store data temporarily. If you

have tried to access or have accessed

confidential information requiring

passwords, empty the cache after each

use. The information or services you

have accessed are stored in the cache.

A cookie is data that a site saves in the

cache memory of your device. Cookies

are saved until you clear the cache

memory.

Clear the cache

While browsing, select Options >

Tools > Clear the cache.

Allow or prevent cookies

Select Menu > Internet and Web

settings > Security > Cookies.

Browser security

Security features may be required for

some services, such as banking services

or online shopping. For such

connections you need security

certificates and possibly a security

module, which may be available on your

SIM card. For more information, contact

your service provider.

Entertainment 51

www.nokia.com/support

Cyan

Magenta

Yellow

Black

To view or modify the security module

settings, or to view a list of authority or

user certificates downloaded to your

device, select Menu > Settings and

Security > Security module, Auth.

certificates, or User certificates.

Important: Even if the use of

certificates makes the risks involved in

remote connections and software

installation considerably smaller, they

must be used correctly in order to

benefit from increased security. The

existence of a certificate does not offer

any protection by itself; the certificate

manager must contain correct,

authentic, or trusted certificates for

increased security to be available.

Certificates have a restricted lifetime. If

"Expired certificate" or "Certificate not

valid yet" is shown, even if the

certificate should be valid, check that

the current date and time in your device

are correct.

Before changing any certificate settings,

you must make sure that you really trust

the owner of the certificate and that the

certificate really belongs to the listed

owner.

Games and applications

You can manage applications and

games. Your device may have some

games or applications installed. These

files are stored in the device memory or

an attached memory card and may be

arranged in folders.

Open an application

Select Menu > Applications >

Extras.

Open a game or application

Select Games, Collection, or Memory

card.

Scroll to a game or application, and

select Open.

Set sounds, lights, and shakes for a

game

Select Options > Application

settings.

Download an application

Your device supports J2ME™ Java

applications. Ensure that the

application is compatible with your

device before downloading it.

52 Entertainment

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Important: Only install and use

applications and other software from

trusted sources, such as applications

that are Symbian Signed or have passed

the Java Verified™ testing.

You can download new applications and

games directly or using your PC.

Download directly

Select Menu > Applications >

Extras and Options > Downloads >

App. downloads or Game

downloads; the list of available

bookmarks is shown.

Download using your PC

Download applications and games to

your PC and use PC Suite to install them

on your device.

For the availability of different services

and pricing, contact your service

provider.

Maps

With Maps, you can browse maps for

different cities and countries, search for

addresses and different points of

interest, plan routes from one location

to another, see your current location on

the map if you have a GPS connection,

and save locations and send them to

compatible devices. You can also

purchase a licence for a navigation

service with voice guidance. This service

is not available for all countries or

regions.

About Maps

If there are maps available in your

device or on an inserted memory card,

you can browse them without an

internet connection. When you browse

to an area which is not covered by the

maps already downloaded in your

device, a map for the area is

automatically downloaded through the

internet. You may be prompted to select

an access point to use with the internet

connection.

Downloading maps may involve the

transmission of large amounts of data

through your service provider's

Maps 53

www.nokia.com/support

Cyan

Magenta

Yellow

Black

network. Contact your service provider

for information about data

transmission charges.

You can also use the Nokia Map Loader

PC software to download maps to your

device. To install Nokia Map Loader on a

compatible PC, see www.nokia.com/

maps.

Select Menu > Applications > Maps

and from the following:

Last map — Open the map that was

displayed last.

Find address — Search for a specific

address.

Saved locations — Find a location you

have saved on your device.

Rec. locations — View the locations

you have browsed.

Current position — View your current

location, if a GPS connection is available.

Plan route — Plan a route.

Extra services — Purchase a license for

navigation.

Settings — Define the settings.

Almost all digital cartography is

inaccurate and incomplete to some

extent. Never rely solely on the

cartography that you download for use

in this device.

Nokia Map Loader

With the Nokia Map Loader application

for PC, you can download maps and

voice guidance files from the internet. A

memory card with sufficient space must

be inserted in your device. You must use

the Maps application and browse maps

at least once before using Nokia Map

Loader, as Nokia Map Loader uses the

Maps history information to check

which version of the maps to download.

To install Nokia Map loader, visit

www.nokia.com/maps, and follow the

instructions.

Download maps with Nokia Map

Loader

1 Connect your device to the

computer with a compatible USB

data cable or Bluetooth connection.

If you use a data cable, select PC

Suite as the USB connection

method.

2 Open Nokia Map Loader on the

computer.

3 Select a continent and a country or

region.

54 Maps

www.nokia.com/support

Cyan

Magenta

Yellow

Black

4 Select the maps or services, and

download and install them to your

device.

On the Service tab of Nokia Map Loader,

you can purchase navigation and traffic

information licences, travel guides, and

download maps.

About GPS

The Global Positioning System (GPS) is

operated by the government of the

United States, which is solely

responsible for its accuracy and

maintenance. The accuracy of location

data can be affected by adjustments to

GPS satellites made by the United States

government and is subject to change

with the United States Department of

Defense civil GPS policy and the Federal

Radionavigation Plan. Accuracy can also

be affected by poor satellite geometry.

Availability and quality of GPS signals

may be affected by your location,

buildings, natural obstacles, and

weather conditions. GPS signals may

not be available inside buildings or

underground and may be impaired by

materials such as concrete and metal.

GPS should not be used for precise

location measurement, and you should

never rely solely on location data from

the GPS receiver and cellular radio

networks for positioning or navigation.

The trip meter has limited accuracy, and

rounding errors may occur. Accuracy can

also be affected by availability and

quality of GPS signals.

GPS receiver

Your device has an internal GPS receiver.

For the best signal from the satellites,

place your device in a position with an

unobstructed view to the sky.

You can use GPS to support the Maps

application. Find out your location, or

measure distances and plot

coordinates.

Navigate to your destination

Maps 55

www.nokia.com/support

Cyan

Magenta

Yellow

Black

You can upgrade Maps to a full

navigation system to be used by car and

by foot. You need a regional licence for

the full navigation system. The car

navigation is fully voice-guided with

two and three-dimensional map views.

Pedestrian navigation is limited to a

speed of 30 km/h (18.6 miles/h) and

provides no voice guidance. The

navigation service is not available for all

countries and regions. For details, see

your local Nokia website.

Purchase a licence for navigation

Select Extra services. The licence is

region-specific and can be used only in

the selected area.

Navigate to the destination

1Select Plan route, and create a

route.

2Select Options > Show route >

Options > Start navigation.

3 Accept the displayed disclaimer.

4 Select the language for voice

guidance, if prompted.

If you deviate from the set route, the

device automatically plans a new route.

Repeat the voice guidance

Select Repeat.

Silence the voice guidance

Select Options > Mute audio.

Stop navigating

Select Stop.

Navigate on foot

Select Settings > Routing settings >

Route selection > On foot. This

optimises the routes you create for

navigation on foot.

56 Maps

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Organise

Let your phone help you to organise

your life.

Manage contacts

Save names, phone numbers, and

addresses as contacts in the device and

on the SIM card.

Select Menu > Contacts.

Select the memory to use for contacts

The device memory can save contacts

with additional details, such as

alternative phone numbers. You can

also save an image, a tone, or a video

clip for a limited number of contacts.

The SIM card memory can save names

with one phone number attached to

them. The contacts saved in the SIM card

memory are indicated with .

1Select More > Settings > Memory

in use to select the SIM card, the

device memory, or both for your

contacts.

2Select Phone and SIM to recall

contacts from both memories.

When you save contacts, they are

saved in the device memory.

Handle contacts

Search for a contact

Select Names.

Scroll through the list of contacts, or

enter the first characters of the contact's

name.

Save a name and phone number

Select Menu > Contacts and Add

new.

Add and edit details

Select Names, a contact, and Details >

Options > Add detail.

Delete a detail

Select Names, a contact, and Details.

Select a detail and Options > Delete.

Delete a contact

Select Names, a contact, and

Options > Delete contact.

Delete all contacts

Select More > Del. all contacts > From

phone mem. or From SIM card.

Organise 57

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Copy or move contacts between the

device and SIM card memories

Copy single contacts

Select Names > Options > More >

Marking options > Mark. Mark the

contacts you want to copy or move, and

select Options > Copy marked or

Move marked.

Copy all contacts

Select More > Copy contacts or Move

contacts.

Create a contact group

Arrange contacts into caller groups with

different ringing tones and group

images.

1Select More > Groups.

2Select Add or Options > Add new

group to create a new group.

3 Enter the group name, optionally

select an image and a ringing tone,

and select Save.

4 Select the group and View > Add to

add contacts to the group.

Business cards

You can send and receive a person’s

contact information from a compatible

device that supports the vCard standard.

Select Menu > Contacts and Names.

Send a business card

Select a contact, Details > Options >

Send business card, and the sending

type.

Save a received business card

Select Show > Save.

Date and time

Modify date and time settings

Select Menu > Settings and Date and

time.

Change the time zone when

travelling

Select Menu > Settings and Date and

time > Date & time settings > Time

zone:, and scroll left or right to select

the time zone of your location.

The time and date are set according to

the time zone and enable your device to

58 Organise

www.nokia.com/support

Cyan

Magenta

Yellow

Black

display the correct sending time of

received text or multimedia messages.

For example, GMT -5 denotes the time

zone for New York (USA), 5 hours west

of Greenwich, London (UK).

Alarm clock

You can set an alarm to sound at a

desired time.

Set the alarm

1Select Menu > Applications >

Alarm clock.

2 Set the alarm, and enter the alarm

time.

3 To issue an alarm on selected days

of the week, select Repeat: > On

and the days.

4 Select the alarm tone. If you select

the radio as the alarm tone, connect

the headset to the device.

5 Set the length of the snooze time-

out period, and select Save.

Stop the alarm

Select Stop. If you let the alarm sound

for a minute or select Snooze, the alarm

stops for the length of the snooze time-

out period, then resumes.

Calendar

Select Menu > Calendar.

The current day is framed. If there are

any notes set for the day, the day is in

bold type.

Make a calendar note

Scroll to the date, and select Options >

Make a note. Select the note type, and

fill in the fields.

View the day notes

Select View.

View a week

Select Options > Week view.

Delete all notes in the calendar

Select Options > Delete notes > All

notes.

Delete old notes automatically after

a specified time

Select Options > Settings > Auto-

delete notes.

Edit settings related to the date and

time

Select Options > Settings.

Organise 59

www.nokia.com/support

Cyan

Magenta

Yellow

Black

To-do list

You can save a note for a task you must

do.

Select Menu > Applications > To-do

list.

Add a note

If no note is added, select Add;

otherwise, select Options > Add. Fill in

the fields, and select Save.

View a note

Select a note and View.

Notes

Select Menu > Applications >

Notes.

Add a note

If no note is added, select Add;

otherwise, select Options > Make a

note. Write the note, and select Save.

Send a note

Select Options > Send note and the

sending type.

Nokia PC Suite

With Nokia PC Suite, you can manage

your music and synchronise contacts,

calendar entries, notes, and to-do notes

between your device and a compatible

PC or a remote internet server (network

service). For more information, and to

download PC Suite, visit

www.nokia.com/support.

Calculator

Your device provides a standard, a

scientific, and a loan calculator.

Select Menu > Applications >

Calculator.

Select Options to select the calculator

type or to view the operating

instructions.

This calculator has limited accuracy and

is designed for simple calculations.

Countdown timer

Select Menu > Applications >

Countd. timer.

Normal timer

1 Select Normal timer, enter a time,

and write a note that is displayed

when the time expires.

60 Organise

www.nokia.com/support

Cyan

Magenta

Yellow

Black

2Select Start.

Interval timer

To have an interval timer with up to 10

intervals started, do the following:

1Select Interval timer.

2Select Start timer > Start.

To select how the interval timer should

start the next period, select Settings >

Cont. to next period.

Stopwatch

You can measure time, take

intermediate times, or take lap times

using the stopwatch.

Select Menu > Applications >

Stopwatch and from the following:

Split timing — Take intermediate

times. To reset the time without saving

it, select Options > Reset.

Lap timing — Take lap times.

Continue — View the timing that you

have set to the background.

Show last — View the most recently

measured time if the stopwatch is not

reset

View times or Delete times — View or

delete the saved times

To set the stopwatch timing to the

background, press the end key.

Organise 61

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Green tips

Here are tips on how you can contribute

to protecting the environment.

Save energy

When you have fully charged the battery

and disconnected the charger from the

device, unplug the charger from the wall

outlet.

You do not need to charge your battery

so often if you do the following:

•Close and disable applications,

services, and connections when not

in use.

•Decrease the brightness of the

screen.

•Set the device to enter the power

saver mode after the minimum

period of inactivity, if available in

your device.

•Disable unnecessary sounds, such

as keypad and ringing tones.

Recycle

Most of the materials in a Nokia phone

are recyclable. Check how to recycle

your Nokia products at

www.nokia.com/werecycle, or with a

mobile device, www.nokia.mobi/

werecycle.

Recycle packaging and user guides at

your local recycling scheme.

Learn more

For more information on the

environmental attributes of your

device, see www.nokia.com/

ecodeclaration.

62 Green tips

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Digital rights management

Content owners may use different types of digital rights

management (DRM) technologies to protect their

intellectual property, including copyrights. This device

uses various types of DRM software to access DRM-

protected content. With this device you can access content

protected with WMDRM 10, OMA DRM 1.0, OMA DRM 1.0

forward lock, and OMA DRM 2.0. If certain DRM software

fails to protect the content, content owners may ask that

such DRM software's ability to access new DRM-protected

content be revoked. Revocation may also prevent renewal

of such DRM-protected content already in your device.

Revocation of such DRM software does not affect the use

of content protected with other types of DRM or the use of

non-DRM-protected content.

Digital rights management (DRM) protected content

comes with an associated licence that defines your rights

to use the content.

If your device has OMA DRM-protected content, to back up

both the licence and the content, use the backup feature

of Nokia PC Suite.

Other transfer methods may not transfer the licence which

need to be restored with the content for you to be able to

continue the use of OMA DRM-protected content after the

device memory is formatted. You may also need to restore

the licence in case the files on your device get corrupted.

If your device has WMDRM-protected content, both the

licence and the content will be lost if the device memory

is formatted. You may also lose the licence and the content

if the files on your device get corrupted. Losing the licence

or the content may limit your ability to use the same

content on your device again. For more information,

contact your service provider.

Some licence may be connected to a specific SIM card, and

the protected content can be accessed only if the SIM card

is inserted in the device.

Accessories

Warning:

Use only batteries, chargers, and accessories approved by

Nokia for use with this particular model. The use of any

other types may invalidate any approval or warranty, and

may be dangerous. In particular, use of unapproved

chargers or batteries may present a risk of fire, explosion,

leakage, or other hazard.

For availability of approved accessories, please check with

your dealer. When you disconnect the power cord of any

accessory, grasp and pull the plug, not the cord.

Battery

Battery and charger information

Your device is powered by a rechargeable battery. The

battery intended for use with this device is BL-4S. Nokia

may make additional battery models available for this

device. This device is intended for use when supplied with

power from the following chargers: AC-8. The exact

charger model number may vary depending on the type

of plug. The plug variant is identified by one of the

following: E, EB, X, AR, U, A, C, K, or UB.

The battery can be charged and discharged hundreds of

times, but it will eventually wear out. When the talk and

standby times are noticeably shorter than normal, replace

the battery. Use only Nokia approved batteries, and

recharge your battery only with Nokia approved chargers

designated for this device.

If a battery is being used for the first time or if the battery

has not been used for a prolonged period, it may be

necessary to connect the charger, then disconnect and

Digital rights management 63

www.nokia.com/support

Cyan

Magenta

Yellow

Black

reconnect it to begin charging the battery. If the battery

is completely discharged, it may take several minutes

before the charging indicator appears on the display or

before any calls can be made.

Safe removal. Always switch the device off and disconnect

the charger before removing the battery.

Proper charging. Unplug the charger from the electrical

plug and the device when not in use. Do not leave a fully

charged battery connected to a charger, since

overcharging may shorten its lifetime. If left unused, a fully

charged battery will lose its charge over time.

Avoid extreme temperatures. Always try to keep the

battery between 15°C and 25°C (59°F and 77°F). Extreme

temperatures reduce the capacity and lifetime of the

battery. A device with a hot or cold battery may not work

temporarily. Battery performance is particularly limited in

temperatures well below freezing.

Do not short-circuit. Accidental short-circuiting can occur

when a metallic object such as a coin, clip, or pen causes

direct connection of the positive (+) and negative (-)

terminals of the battery. (These look like metal strips on

the battery.) This might happen, for example, when you

carry a spare battery in your pocket or purse. Short-

circuiting the terminals may damage the battery or the

connecting object.

Disposal. Do not dispose of batteries in a fire as they may

explode. Dispose of batteries according to local

regulations. Please recycle when possible. Do not dispose

as household waste.

Leak. Do not dismantle, cut, open, crush, bend, puncture,

or shred cells or batteries. In the event of a battery leak,

prevent battery liquid contact with skin or eyes. If this

happens, flush the affected areas immediately with water,

or seek medical help.

Damage. Do not modify, remanufacture, attempt to insert

foreign objects into the battery, or immerse or expose it

to water or other liquids. Batteries may explode if

damaged.

Correct use. Use the battery only for its intended purpose.

Improper battery use may result in a fire, explosion, or

other hazard. If the device or battery is dropped, especially

on a hard surface, and you believe the battery has been

damaged, take it to a service centre for inspection before

continuing to use it. Never use any charger or battery that

is damaged. Keep your battery out of the reach of small

children.

Nokia battery authentication guidelines

Always use original Nokia batteries for your safety. To

check that you are getting an original Nokia battery,

purchase it from a Nokia authorised service centre or

dealer, and inspect the hologram label using the following

steps:

Authenticate hologram

1 When you look at the hologram on the label, you

should see the Nokia connecting hands symbol from

one angle and the Nokia Original Enhancements

logo when looking from another angle.

64 Battery

www.nokia.com/support

Cyan

Magenta

Yellow

Black

2 When you angle the hologram left, right, down and

up, you should see 1, 2, 3 and 4 dots on each side

respectively.

Successful completion of the steps is not a total assurance

of the authenticity of the battery. If you cannot confirm

authenticity or if you have any reason to believe that your

Nokia battery with the hologram on the label is not an

authentic Nokia battery, you should refrain from using it,

and take it to the nearest Nokia authorised service centre

or dealer for assistance.

For additional information, refer to the warranty and

reference leaflet included with your Nokia device.

Taking care of your device

Your device is a product of superior design and

craftsmanship and should be treated with care. The

following suggestions will help you protect your warranty

coverage.

•Keep the device dry. Precipitation, humidity, and all

types of liquids or moisture can contain minerals

that will corrode electronic circuits. If your device

does get wet, remove the battery, and allow the

device to dry completely before replacing it.

•Do not use or store the device in dusty, dirty areas.

Its moving parts and electronic components can be

damaged.

•Do not store the device in high or cold temperature.

High temperatures can shorten the life of electronic

devices, damage batteries, and warp or melt certain

plastics. When the device warms to its normal

temperature from a cold temperature, moisture can

form inside the device and damage electronic circuit

boards.

•Do not attempt to open the device other than as

instructed in this guide.

•Do not drop, knock, or shake the device. Rough

handling can break internal circuit boards and fine

mechanics.

•Do not use harsh chemicals, cleaning solvents, or

strong detergents to clean the device. Only use a

soft, clean, dry cloth to clean the surface of the

device.

•Do not paint the device. Paint can clog the moving

parts and prevent proper operation.

•Use only the supplied or an approved replacement

antenna. Unauthorised antennas, modifications, or

attachments could damage the device and may

violate regulations governing radio devices.

•Use chargers indoors.

•Backup all data you want to keep, such as contacts

and calendar notes.

•To reset the device from time to time for optimum

performance, power off the device and remove the

battery.

These suggestions apply equally to your device, battery,

charger, or any accessory.

Taking care of your device 65

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Recycle

Always return your used electronic products, batteries,

and packaging materials to dedicated collection points.

This way you help prevent uncontrolled waste disposal

and promote the recycling of materials. Check product

environmental information and how to recycle your Nokia

products at www.nokia.com/werecycle, or nokia.mobi/

werecycle.

Additional safety information

The surface of this device is nickel-free.

Small children

Your device and its accessories are not toys. They may

contain small parts. Keep them out of the reach of small

children.

Operating environment

This device meets RF exposure guidelines in the normal

use position at the ear or at least 1.5 centimetres (5/8

inch)away from the body. Any carry case, belt clip, or

holder for body-worn operation should not contain metal

and should position the device the above-stated distance

from your body.

To send data files or messages requires a quality

connection to the network. Data files or messages may be

delayed until such a connection is available. Follow the

separation distance instructions until the transmission is

completed.

Medical devices

Operation of radio transmitting equipment, including

wireless phones, may interfere with the function of

inadequately protected medical devices. Consult a

physician or the manufacturer of the medical device to

determine whether they are adequately shielded from

external RF energy. Switch off your device when

regulations posted instruct you to do so. Hospitals or

health care facilities may use equipment sensitive to

external RF energy.

Implanted medical devices

Manufacturers of medical devices recommend a minimum

separation of 15.3 centimetres (6 inches) between a

wireless device and an implanted medical device, such as

a pacemaker or implanted cardioverter defibrillator, to

avoid potential interference with the medical device.

Persons who have such devices should:

•Always keep the wireless device more than 15.3

centimetres (6 inches) from the medical device.

•Not carry the wireless device in a breast pocket.

•Hold the wireless device to the ear opposite the

medical device.

•Turn the wireless device off if there is any reason to

suspect that interference is taking place.

•Follow the manufacturer directions for the

implanted medical device.

If you have any questions about using your wireless device

with an implanted medical device, consult your health

care provider.

Hearing aids

Some digital wireless devices may interfere with some

hearing aids.

Vehicles

RF signals may affect improperly installed or inadequately

shielded electronic systems in motor vehicles such as

electronic fuel injection, electronic antilock braking,

electronic speed control, and air bag systems. For more

information, check with the manufacturer of your vehicle

or its equipment.

66 Additional safety information

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Only qualified personnel should service the device or

install the device in a vehicle. Faulty installation or service

may be dangerous and may invalidate your warranty.

Check regularly that all wireless device equipment in your

vehicle is mounted and operating properly. Do not store

or carry flammable liquids, gases, or explosive materials

in the same compartment as the device, its parts, or

accessories. Remember that air bags inflate with great

force. Do no t place your device or accessories in the air bag

deployment area.

Switch off your device before boarding an aircraft. The use

of wireless teledevices in an aircraft may be dangerous to

the operation of the aircraft and may be illegal.

Potentially explosive environments

Switch off your device in any area with a potentially

explosive atmosphere. Obey all posted instructions. Sparks

in such areas could cause an explosion or fire resulting in

bodily injury or death. Switch off the device at refuelling

points such as near gas pumps at service stations. Observe

restrictions in fuel depots, storage, and distribution areas;

chemical plants; or where blasting operations are in

progress. Areas with a potentially explosive atmosphere

are often, but not always, clearly marked. They include

areas where you would be advised to turn off your vehicle

engine, below deck on boats, chemical transfer or storage

facilities and where the air contains chemicals or particles

such as grain, dust, or metal powders. You should check

with the manufacturers of vehicles using liquefied

petroleum gas (such as propane or butane) to determine

if this device can be safely used in their vicinity.

Emergency calls

Important: This device operates using radio signals,

wireless networks, landline networks, and user-

programmed functions. If your device supports voice calls

over the internet (internet calls), activate both the internet

calls and the cellular phone. The device may attempt to

make emergency calls over both the cellular networks and

through your internet call provider if both are activated.

Connections in all conditions cannot be guaranteed. You

should never rely solely on any wireless device for

essential communications like medical emergencies.

To make an emergency call:

1 If the device is not on, switch it on. Check for

adequate signal strength. Depending on your

device, you may also need to complete the

following:

•Insert a SIM card if your device uses one.

•Remove certain call restrictions you have

activated in your device.

•Change your profile from Offline or Flight

profile to an active profile.

2 Press the end key as many times as needed to clear

the display and ready the device for calls.

3 Enter the official emergency number for your

present location. Emergency numbers vary by

location.

4 Press the call key.

When making an emergency call, give all the necessary

information as accurately as possible. Your wireless device

may be the only means of communication at the scene of

an accident. Do not end the call until given permission to

do so.

Certification information (SAR)

This mobile device meets guidelines for exposure to

radio waves.

Your mobile device is a radio transmitter and receiver. It

is designed not to exceed the limits for exposure to radio

waves recommended by international guidelines. These

guidelines were developed by the independent scientific

Additional safety information 67

www.nokia.com/support

Cyan

Magenta

Yellow

Black

organisation ICNIRP and include safety margins designed

to assure the protection of all persons, regardless of age

and health.

The exposure guidelines for mobile devices employ a unit

of measurement known as the Specific Absorption Rate or

SAR. The SAR limit stated in the ICNIRP guidelines is 2.0

watts/kilogram (W/kg) averaged over 10 grams of tissue.

Tests for SAR are conducted using standard operating

positions with the device transmitting at its highest

certified power level in all tested frequency bands. The

actual SAR level of an operating device can be below the

maximum value because the device is designed to use only

the power required to reach the network. That amount

changes depending on a number of factors such as how

close you are to a network base station.

The highest SAR value under the ICNIRP guidelines for use

of the device at the ear is 0.95 W/kg.

Use of device accessories may result in different SAR

values. SAR values may vary depending on national

reporting and testing requirements and the network

band. Additional SAR information may be provided under

product information at www.nokia.com.

Your mobile device is also designed to meet the

requirements for exposure to radio waves established by

the Federal Communications Commission (USA) and

Industry Canada. These requirements set a SAR limit of 1.6

W/kg averaged over one gram of tissue. The highest SAR

value reported under this standard during product

certification for use at the ear is 1.28 W/kg and when

properly worn on the body is 0.57 W/kg.

68 Additional safety information

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Index

Symbols/Numerics

3G 21

access codes 12

answering calls 31

anykey answer 33

applications 52

audio messages 38

backing up data 27

barring password 12

battery 6, 8

battery charge level indicator 14

Bluetooth 25

browser 50

browser security 51

browser settings 51

business cards 58

cable connection 27

cache memory 51

calculator 60

call 30

call divert 33

call log 33

call waiting 34

caller id 34

camera 41

camera settings 42

chat services (IM) 38

configuration 29

contacts 57

cookies 51

date and time 58

dial 30

dialling 31

dialling shortcuts 24, 31

digital rights 63

display settings 23, 51

downloads 19

e-mail 39

equaliser 49

factory settings, restoring 20

file management 43

flash messages 37

flight profile 17, 21

Index 69

www.nokia.com/support

Cyan

Magenta

Yellow

Black

games 52

GPRS (general packet radio

service) 28

GPS (global positioning system) 55

handsfree 32

headset 9

help application 21

home screen 14, 24

IM (instant messaging) 38

images 41, 42

in-call timer 34

indicators 15

info messages 29

internet 50

keyguard 16, 21

keypad lock 16

keys 5, 24

language settings 21

lights 23

location information 28

loudspeaker 32

mail 39, 40

Maps 53

maps 53, 54, 55

media player 43, 45, 46, 47

memory 44

memory card 7

message centre number 36

message sending 37

message settings 38

messages 36, 37

modem 28

music 47

music player 45, 46, 47

My Nokia 18

navigation 15

Nokia Map Loader 54

Nokia support information 18

notes 60

offline profile 16

online sharing service 51

operator menu 28

70 Index

www.nokia.com/support

Cyan

Magenta

Yellow

Black

packet data connection 28

PC Suite 60

phonebook 57

photographs 41

PictBridge 27

PIN 12

position log 28

printing 43

profiles 23

PUK 12

radio 47, 48

redial 30, 33

rejecting calls 31

restoring data 27

restoring settings 20

screen settings 23

scrolling 15

security code 12

security module 12

security settings 21

service commands 29

sharing, online 44, 51

shortcuts 15, 24

signal strength indicator 14

SIM card 6, 16, 28

SIM messages 29

software updates 19, 21

speed dialling 24, 31, 34

status indicators 14

stopwatch 61

strap 10

support resources 18

switching device on/off 13

synchronisation 27

text input 34, 35

text messages 36

themes 23

time and date 58

to-do list 60

tones 21, 23

transferring, files 47

updates

— device software 19

UPIN 12

USB cable connection 9, 27

USB connection 27

video 41, 42

Index 71

www.nokia.com/support

Cyan

Magenta

Yellow

Black

video call 31

video messages 33

voice clarity 34

voice commands 25

voice dialling 32

voice messages 33

voice recorder 49

wallpaper 23

web 50

write text 34

72 Index

www.nokia.com/support

Cyan

Magenta

Yellow

Black

DECLARATION OF CONFORMITY

0434

Hereby, NOKIA CORPORATION declares that this RM-509

product is in compliance with the essential requirements

and other relevant provisions of Directive 1999/5/EC. A

copy of the Declaration of Conformity can be found at

www.nokia.com/phones/declaration_of_conformity/.

Nokia, Nokia Connecting People, Ovi, Nokia Xpress print,

Nokia Xpress audio messaging, and Navi are trademarks

or registered trademarks of Nokia Corporation. Nokia tune

is a sound mark of Nokia Corporation. Other product and

company names mentioned herein may be trademarks or

tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or

all of the contents in this document in any form without

the prior written permission of Nokia is prohibited. Nokia

operates a policy of continuous development. Nokia

reserves the right to make changes and improvements to

any of the products described in this document without

prior notice.

Includes RSA BSAFE cryptographic or security protocol

software from RSA Security.

Java and all Java-based marks are trademarks or registered

trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent

Portfolio License (i) for personal and noncommercial use

in connection with information which has been encoded

in compliance with the MPEG-4 Visual Standard by a

consumer engaged in a personal and noncommercial

activity and (ii) for use in connection with MPEG-4 video

provided by a licensed video provider. No license is

granted or shall be implied for any other use. Additional

information, including that related to promotional,

internal, and commercial uses, may be obtained from

MPEG LA, LLC. See http://www.mpegla.com.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,

UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS

LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR

INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR

INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS".

EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES

OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT

NOT LIMITED TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY,

RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA

RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR

WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

The availability of particular products and applications

and services for these products may vary by region. Please

check with your Nokia dealer for details and availability of

Cyan

Magenta

Yellow

Black

language options. This device may contain commodities,

technology or software subject to export laws and

regulations from the US and other countries. Diversion

contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for

example, when using a telephone in close proximity to

receiving equipment). The FCC or Industry Canada can

require you to stop using your telephone if such

interference cannot be eliminated. If you require

assistance, contact your local service facility. This device

complies with part 15 of the FCC rules. Operation is subject

to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must

accept any interference received, including interference

that may cause undesired operation. Any changes or

modifications not expressly approved by Nokia could void

the user's authority to operate this equipment.

Model number: 3710a-1

5555555/Issue 1 EN

Cyan

Magenta

Yellow

Black

Microsoft RM-509 GSM 850/900/1800/1900 and WCDMA FDD I/IV/VIII Cellular Phone w/BT User Manual Manual

Microsoft Mobile Oy GSM 850/900/1800/1900 and WCDMA FDD I/IV/VIII Cellular Phone w/BT Manual

Manual

Navigation menu

Namespaces

Views

Navigation
