Nokia 3710 fold User Guide

5555555

Issue 1

Cyan

Magenta

Yellow

Black

Contents

Safety 4

Get started 5

Keys and parts 5

Insert the SIM card and battery 5

Insert and remove the memory card 6

Charge the battery 7

GSM antenna 8

Accessories 8

Switch it on 9

About your device 9

Network services 10

Access codes 10

Switch the device on and off 11

Home screen 11

Navigate the menus 12

Lock the keys 13

Functions without a SIM card 13

Flight profile 13

Support and updates 14

Support 14

My Nokia 14

Download content 14

Software updates using your PC 14

Software updates over the air 15

Restore factory settings 15

Make it your device 16

Basic settings 16

Personalise your device 17

Connect 19

Network provider services 21

Stay in touch 22

Make calls 22

Text and messages 25

Mail and Instant Messaging 28

Image and video 29

Capture images 29

Record video clips 30

Camera and video settings 30

Gallery 30

Print images 31

Share images and video clips online 31

Memory card 31

Entertainment 32

Listen to music 32

Web 35

Games and applications 37

Maps 38

About Maps 38

Nokia Map Loader 38

About GPS 39

GPS receiver 39

Navigate to your destination 39

Organise 40

Manage contacts 40

Business cards 41

Date and time 41

Alarm clock 41

Calendar 42

To-do list 42

Notes 42

Nokia PC Suite 42

Calculator 43

Countdown timer 43

Stopwatch 43

Green tips 44

Save energy 44

Recycle 44

Learn more 44

Digital rights management 45

Accessories 45

2Contents

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Battery 45

Battery and charger information 45

Nokia battery authentication

guidelines 46

Taking care of your device 46

Recycle 47

Additional safety information 47

Small children 47

Operating environment 47

Medical devices 47

Telecoil hearing aid 47

Vehicles 47

Potentially explosive environments 48

Emergency calls 48

Certification information (SAR) 48

Index 49

Contents 3

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Safety

Read these simple guidelines. Not

following them may be dangerous or

illegal. Read the complete user guide for

further information.

SWITCH ON SAFELY

Do not switch the device on

when wireless phone use is

prohibited or when it may

cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep

your hands free to operate the

vehicle while driving. Your first

consideration while driving

should be road safety.

INTERFERENCE

All wireless devices may be

susceptible to interference,

which could affect

performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch

the device off in aircraft, near

medical equipment, fuel,

chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may

install or repair this product.

ACCESSORIES AND BATTERIES

Use only approved accessories

and batteries. Do not connect

incompatible products.

WATER-RESISTANCE

Your device is not water-

resistant. Keep it dry.

4Safety

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Get started

Get to know your device, insert the

battery, SIM card, and memory card, and

learn some important information about

your device.

Keys and parts

1Earpiece

2Display

3Navi™ key (scroll key)

4Call key

5Microphone

6Keypad

7Secondary camera

8Left and right selection keys

9End/Power key

10 Camera flash

11 Camera lens

12 Nokia AV Connector (2.5 mm)

13 Volume keys

14 Loudspeaker

15 Hidden display

16 Charger connector

17 Micro USB cable connector

18 Wrist strap eyelet

Insert the SIM card and battery

Note: Switch off the power and

disconnect the charger and any other

device before removing the covers. Avoid

touching electronic components while

changing the covers. Always store and use

the device with the covers attached.

The SIM card and its contacts can be easily

damaged by scratches or bending, so be

careful when handling, inserting, or

removing the card.

1 Open the back cover, and remove it.

Get started 5

www.nokia.com/support

Cyan

Magenta

Yellow

Black

2 Remove the battery.

3 Open the SIM card holder. Insert the

SIM card into the holder with the

bevelled corner facing down and the

contact surface area facing toward

the contacts of the device. The side

with the bevelled corner fits below

the rim of the device. Close the SIM

card holder.

4 Line up the battery contacts, and

insert the battery.

5 Place the battery cover on the device,

that the hooks at the upper part of the

cover are aligned with the

corresponding recesses on the device.

Slide the back cover to close it.

Insert and remove the memory card

Use only compatible microSD cards

approved by Nokia for use with this

device. Nokia uses approved industry

standards for memory cards, but some

brands may not be fully compatible with

this device. Incompatible cards may

damage the card and the device and

corrupt data stored on the card.

Your device supports microSD cards with

a capacity of up to 8 GB. The size of a single

file must not exceed 2 GB.

6Get started

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Insert the memory card

1 Switch the device off, and remove the

back cover and battery.

2 Slide the memory card holder inwards

to unlock.

3 Open the card holder, and insert the

memory card into the holder with the

contact surface facing inwards.

4 Close the card holder, and slide it to

lock.

5 Replace the battery and back cover.

Remove the memory card

1 Remove the back cover and the

battery.

2 Open the memory card holder, and

remove the memory card. Close the

memory card holder.

3 Replace the battery and back cover.

Charge the battery

Your battery has been partially charged at

the factory. If the device indicates a low

charge, do the following:

1 Connect the charger to a wall outlet.

2 Connect the charger to the device.

3 When the device indicates a full

charge, disconnect the charger from

the device, then from the wall outlet.

You can also charge the battery with a USB

cable, using power from a computer.

1 Connect the USB cable to a USB port of

a computer and to your device.

2 When the battery is fully charged,

disconnect the USB cable.

If the battery is completely discharged,

USB charging may not work. Use the

charger instead.

You do not need to charge the battery for

a specific length of time, and you can use

the device while it is charging. If the

battery is completely discharged, it may

take several minutes before the charging

indicator appears on the display or before

any calls can be made.

Charging the device while listening to the

radio may affect the quality of reception.

Get started 7

www.nokia.com/support

Cyan

Magenta

Yellow

Black

GSM antenna

Your device may have internal and

external antennas. Avoid touching the

antenna area unnecessarily while the

antenna is transmitting or receiving.

Contact with antennas affects the

communication quality and may cause a

higher power level during operation and

may reduce the battery life.

The figure shows the GSM antenna area

marked in grey.

Accessories

Connect a USB cable

Headset

Warning:

When you use the headset, your ability to

hear outside sounds may be affected. Do

not use the headset where it can

endanger your safety.

When connecting any external device or

any headset, other than those approved

by Nokia for use with this device, to the

Nokia AV Connector, pay special attention

to volume levels.

Do not connect products that create an

output signal as this may cause damage

to the device. Do not connect any voltage

source to the Nokia AV Connector.

Use your T-coil hearing aid with your

device

If you have a telecoil-equipped hearing

aid, you may be able to use your hearing

aid with your device to get clearer sound

during a call.

1 Switch your telecoil-equipped

hearing aid to T mode.

2On your device, select Menu >

Settingsand Hearing aid > On.

Note that telecoil cannot be used when

your device is set to the offline profile,

when a headset or other audio accessory

8Get started

www.nokia.com/support

Cyan

Magenta

Yellow

Black

is connected to your device, or when you

are using the loudspeaker on your device.

For more information about accessibility,

go to www.nokiaaccessibility.com.

Strap

1 Open the back cover.

2 Thread the strap, and tighten it.

3 Close the back cover.

Switch it on

Learn how to switch on your device, and

how to use the basic functions.

About your device

The wireless device described in this guide

is approved for use on the GSM 850, 900,

1800, 1900 and WCDMA 900, 1700-2100,

2100 MHz networks. Contact your service

provider for more information about

networks.

Your device may have preinstalled

bookmarks and links for third-party

internet sites and may allow you to access

third-party sites. These are not affiliated

with Nokia, and Nokia does not endorse

or assume liability for them. If you access

such sites, take precautions for security or

content.

Warning:

To use any features in this device, other

than the alarm clock, the device must be

switched on. Do not switch the device on

when wireless device use may cause

interference or danger.

When using this device, obey all laws and

respect local customs, privacy and

legitimate rights of others, including

copyrights. Copyright protection may

prevent some images, music, and other

content from being copied, modified, or

transferred.

Make back-up copies or keep a written

record of all important information stored

in your device.

When connecting to any other device,

read its user guide for detailed safety

Switch it on 9

www.nokia.com/support

Cyan

Magenta

Yellow

Black

instructions. Do not connect incompatible

products.

The images in this guide may differ from

your device display.

Refer to the user guide for other

important information about your device.

Network services

To use the device you must have service

from a wireless service provider. Some

features are not available on all networks;

other features may require that you make

specific arrangements with your service

provider to use them. Network services

involve transmission of data. Check with

your service provider for details about

fees in your home network and when

roaming on other networks. Your service

provider can explain what charges will

apply.

Your service provider may have requested

that certain features be disabled or not

activated in your device. If so, these

features will not appear on your device

menu. Your device may also have

customized items such as menu names,

menu order, and icons.

Access codes

To set how your device uses the access

codes and security settings, select

Menu > Settings and Security > Access

codes.

•The security code helps to protect

your device against unauthorised use.

The preset code is 12345. You can

change the code and set the device to

request the code. Some operations

require the security code regardless of

the settings, for example, if you want

to restore the factory settings. Keep

the code secret and in a safe place

separate from your device. If you

forget the code and your device is

locked, your device will require

service and additional charges may

apply. For more information, contact

a Nokia Care point or your device

dealer.

•The PIN code, supplied with the SIM

card, helps to protect the card against

unauthorised use.

•The PIN2 code, supplied with some

SIM cards, is required to access certain

services.

•PUK and PUK2 codes may be supplied

with the SIM card. If you enter the PIN

code incorrectly three times in

succession, you are asked for the PUK

code. If the codes are not supplied,

contact your service provider.

•The barring password is required

when using the call barring service to

restrict calls to and from your device

(network service).

•To view or change the security

module settings for the browser,

select Menu > Settings and

Security > Security module.

10 Switch it on

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Switch the device on and off

Switch on and off

Press and hold the power key.

Enter the PIN code

If requested , enter the PIN code

(displayed as ****).

Set the time and date

If requested, enter the time and date.

You may be prompted to get the

configuration settings from your service

provider (network service). For more

information, contact your service

provider.

Home screen

When the device is ready for use, and you

have not entered any characters, the

device is in the home screen.

Display

1Signal strength of the cellular

network

2Battery charge status

3Indicators

4Name of the network or the operator

logo

5Clock

6Date (only if the enhanced home

screen is deactivated)

7Display

8Function of the left selection key

9Function of the scroll key

10 Function of the right selection key

You can change the function of the left and

right selection key. See " Left and right

selection keys ", p. 18.

Enhanced home screen

With the enhanced home screen, you can

display a list of selected information and

features that you can directly access.

Select Menu > Settings and Display >

Home screen.

Activate the enhanced home screen

Select Home screen mode > On.

Switch it on 11

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Organise and personalise the

enhanced home screen

Select Personalise view.

Select the key used to activate the

enhanced home screen

Select Home screen key.

Navigate in the home screen

Scroll up or down to navigate the list, and

select Select, View, or Edit. The arrows

indicate that further information is

available.

Stop navigating

Select Exit.

Shortcuts

When your device is in the home screen,

you can use shortcuts.

List missed, received, and dialled calls

Press the call key. To make a call, scroll to

the number or name, and press the call

key.

Open the web browser

Press and hold 0.

Call the voice mailbox

Press and hold 1.

Use other keys as shortcuts

See "Dialling shortcuts", p. 23.

Indicators

You have unread messages.

You have unsent, cancelled, or

failed messages.

The keypad is locked.

The device does not ring for

incoming calls or text messages.

An alarm is set.

/ The device is registered to the

GPRS or EGPRS network.

/ A GPRS or EGPRS connection is

open.

/ The GPRS or EGPRS connection is

suspended (on hold).

Bluetooth connectivity is

activated.

A GPS signal is available.

No GPS signal available.

If you have two phone lines, the

second line is in use.

All incoming calls are diverted to

another number.

Calls are limited to a closed user

group.

The currently active profile is

timed.

A headset is connected to the

device.

The device is connected to

another device, using a USB cable.

Navigate the menus

The device offers a range of functions that

are grouped into menus.

1To access the menu, select Menu.

2 Scroll through the menu, and select an

option (for example, Settings).

3 If the selected menu contains further

submenus, select one (for example,

Call).

4 Select the setting of your choice.

5 To return to the previous menu level,

select Back.

To exit the menu, select Exit.

Change the menu view

Select Options > Main menu view. Scroll

right, and select from the available

options.

12 Switch it on

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Rearrange the menu

Select Options > Organise. Scroll to the

menu item to be moved, and select

Move. Scroll to where you want to move

the menu item, and select OK. To save the

change, select Done > Yes.

Lock the keys

Lock the keypad to prevent accidental

keypresses.

Lock the keypad

Select Menu, and press * within 3.5

seconds.

Unlock the keypad

Select Unlock, and press * within 1.5

seconds. If requested, enter the lock code.

Answer a call when the keypad is

locked

Press the call key. When you end or reject

a call, the keypad locks automatically.

Further features are Automatic keyguard

and Security keyguard. See "Phone

settings", p. 16.

When the device or keypad is locked, calls

may be possible to the official emergency

number programmed into your device.

Functions without a SIM card

Some functions of your device may be

used without inserting a SIM card, such as

Organiser functions and games. Some

functions appear dimmed in the menus

and cannot be used.

Flight profile

In radio sensitive environments, where

you are asked not to use your device, you

can still access your calendar, contacts list,

and offline games by activating the flight

profile.

indicates that the flight profile is

active.

Activate the flight profile

Select Menu > Settings > Profiles and

Flight > Activate or Personalise.

Deactivate the flight profile

Select any other profile.

Warning:

With the Flight profile you cannot make or

receive any calls, including emergency

calls, or use other features that require

network coverage. To make calls, you

must first activate the phone function by

changing profiles. If the device has been

locked, enter the lock code.

If you need to make an emergency call

while the device is locked and in the Flight

profile, you may be also able to enter an

official emergency number programmed

in your device in the lock code field and

select 'Call'. The device will confirm that

you are about to exit Flight profile to start

an emergency call.

Switch it on 13

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Support and updates

Nokia helps you in many ways to gain the

most benefit from your device.

Support

When you want to learn more about how

to use your product or you are unsure how

your device should function, see the user

guide or see the support pages at

www.nokia.com/support or your local

Nokia website, or with a mobile device,

www.nokia.mobi/support.

If this does not resolve your issue, do one

of the following:

•Restart the device: switch off the

device, and remove the battery. After

about a minute, replace the battery,

and switch on the device.

•Restore the original factory settings

as explained in the user guide.

•Update your device software regularly

for optimum performance and

possible new features, as explained in

the user guide.

If your issue remains unsolved, contact

Nokia for repair options. See

www.nokia.com/repair, or in Latin

America, www.nokia-latinoamerica.com/

centrosdeservicio. Before sending your

device for repair, always back up the data

in your device.

My Nokia

Select Menu > Applications > Extras >

Collection > My Nokia.

My Nokia is a free service that regularly

sends you text messages containing tips,

tricks, and support for your Nokia device.

It also allows you to browse the My Nokia

site where you can find details about

Nokia devices and download tones,

graphics, games, and applications.

To use the My Nokia service, it must be

available in your country and supported

by your service provider. You must sign up

to use the service. Call charges apply when

you send messages to sign up or

unsubscribe. For terms and conditions,

see the documentation supplied with

your device, or www.nokia.com/

mynokia.

Download content

You may be able to download new content

(for example, themes) to your device

(network service).

Important: Use only services that you

trust and that offer adequate security and

protection against harmful software.

For the availability of different services

and pricing, contact your service provider.

Software updates using your PC

Software updates may include new

features and enhanced functions that

were not available at the time of purchase

of your device. Updating the software may

also improve the device performance.

Nokia Software Updater is a PC application

that enables you to update your device

software. To update your device software,

you need a compatible PC, broadband

internet access, and a compatible USB

data cable to connect your device to the

PC.

To get more information, to check the

release notes for the latest software

versions, and to download the Nokia

Software Updater application, see

14 Support and updates

www.nokia.com/support

Cyan

Magenta

Yellow

Black

www.nokia.com/softwareupdate, or in

Latin America, www.nokia-

latinoamerica.com/nsu.

To update the device software, do the

following:

1 Download and install the Nokia

Software Updater application to your

PC.

2 Connect your device to the PC using a

USB data cable, and open the Nokia

Software Updater application. The

Nokia Software Updater application

guides you to back up your files,

update the software, and restore your

files.

Software updates over the air

Your service provider may send device

software updates over the air directly to

your device (network service). This option

may not be available, depending on your

device.

Downloading software updates may

involve the transmission of large amounts

of data (network service).

Make sure that the device battery has

enough power, or connect the charger

before starting the update.

Warning:

If you install a software update, you

cannot use the device, even to make

emergency calls, until the installation is

completed and the device is restarted. Be

sure to back up data before accepting

installation of an update.

Request a software update

1 Select Menu > Settings and

Phone > Phone updates to request

available software updates from your

service provider.

2 Select Current sw details to display

the current software version and

check whether an update is needed.

3 Select Downl. phone sw to

download and install a software

update. Follow the instructions.

4 If the installation was cancelled after

the download, select Install sw

update to start the installation.

The software update may take several

minutes. If there are problems with the

installation, contact your service provider.

Restore factory settings

To restore the device back to the factory

settings, select Menu > Settings > Rest.

fact. sett. and from the following:

Settings only — Reset all preference

settings without deleting any personal

data.

All — Reset all preference settings, and

delete all personal data, such as contacts,

messages, media files, and activation

keys.

Support and updates 15

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Make it your device

Set up your device, personalise it, and

connect it in several ways.

Basic settings

Phone settings

Select Menu > Settings and Phone.

Select from the following:

Language settings — To set the

language of your device, select Phone

language and a language. To set the

language of your device according to the

information on the SIM card, select Phone

language > Automatic.

Memory status — View the memory

consumption.

Automatic keyguard — Set the keypad

to lock automatically after a preset time

delay when the device is in the home

screen and no function has been used.

Security keyguard — Set the device to

prompt for the security code to unlock the

keypad.

Voice recognition — Set up voice

commands, or start voice recognition

training.

Flight query — Set the device to prompt

for the flight profile when you switch the

device on. In the flight profile, all radio

connections are closed.

Phone updates — Allow software

updates from your service provider

(network service). The available options

may vary.

Network mode — To use GSM and (when

available) 3G networks, select Dual

mode. This option is not available during

an active call.

Operator selection — Manually select

which network to use.

Help text activation — Set the device to

display help text.

Start-up tone — Play a tone when you

switch the device on.

Fold close handling — Select the

behaviour of the device when the fold is

closed.

Confirm SIM actions — Access additional

network services from your SIM card. This

option may not be available, depending

on your SIM card.

Security settings

Select Menu > Settings and Security.

When security features that restrict calls

are in use (such as call barring, closed user

group, and fixed dialling), calls may be

possible to the official emergency number

programmed into your device. Call barring

and call diverting cannot be active at the

same time.

Select from the following:

PIN code request or UPIN code

request — Set the device to request for

the PIN or UPIN code every time the device

is switched on. Some SIM cards do not

allow the code request to be deactivated.

Call barring service — Restrict incoming

calls to and outgoing calls from your

device (network service). A barring

password is required.

Fixed dialling — Restrict your outgoing

calls to selected phone numbers if

supported by your SIM card. When fixed

dialling is activated, GPRS connections are

not possible except while sending text

messages over a GPRS connection. In this

case, the recipient’s phone number and

the message centre number must be

included in the fixed dialling list.

16 Make it your device

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Closed user group — Define a group of

people whom you can call and who can

call you (network service).

Security level — To request the security

code whenever a new SIM card is inserted

into the device, select Phone.

Access codes — Change the security

code, PIN code, UPIN code, PIN2 code, or

barring password.

PIN2 code request — Set the device to

request the PIN2 code when using a

specific device feature protected by the

PIN2 code. Some SIM cards do not allow

the code request to be deactivated. This

option may not be available depending on

your SIM card. For details, contact your

service provider.

Code in use — Display and select the type

of PIN code to be used.

Auth. certificates or User

certificates — View the list of the

authority or user certificates available on

your device.

Security module — View Sec. module

details, activate Module PIN request, or

change the module PIN and signing PIN.

Personalise your device

Give your device a personal touch with

ringing tones, display backgrounds, and

themes. Add shortcuts for your preferred

features, and attach enhancements.

Profiles

Your device has several profiles, which you

can customise.

Select Menu > Settings and Profiles.

Select the desired profile and from the

following:

Activate — Activate the profile.

Personalise — Modify profile settings.

Timed — Set the profile to be active for

a certain period of time. When the time

set for the profile expires, the previous

profile that was not timed becomes

active.

Themes

With themes, you can personalise your

device.

Select Menu > Settings and Themes.

Select a theme

Select Select theme > Themes and a

theme.

Download more themes

Select Theme downld..

Tones

You can modify the tone settings of the

currently active profile.

Select Menu > Settings and Tones. You

can find the same settings in the Profiles

menu.

Lights

You can activate or deactivate light effects

associated with different device

functions.

Select Menu > Settings and Lights.

Display

Select Menu > Settings and Display.

Select from the following:

Wallpaper — Add a background image

to the home screen.

Make it your device 17

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Home screen — Activate, organise, and

personalise the home screen.

Home scr. font col. — Select the font

colour for the home screen.

Navigat. key icons — Display the scroll

key icons in the home screen.

Notification details — Display details in

missed call and message notifications.

Fold animation — Display an animation

when you open or close the fold.

Main menu view — Select the layout of

the main menu.

Font size — Set the font size for

messaging, contacts, and web pages.

Operator logo — Display the logo of the

currently selected operator.

Cell info display — Display the cell

identity, if available from the network.

My shortcuts

With personal shortcuts, you get quick

access to frequently used functions of

your device. Select Menu > Settings and

My shortcuts.

Left and right selection keys

To change the function assigned to the left

or right selection key, select Left

selection key or Right selection key,

and the desired function.

In the home screen , if the left selection

key is Go to, to add, remove, or reorganise

functions, select Go to > Options >

Select options or Organise.

Other shortcuts

Select from the following:

Navigation key — Assign other functions

from a predefined list to the scroll key.

Home screen key — Select the

movement of the scroll key to activate the

home screen.

Assign dialling shortcuts

Create shortcuts by assigning phone

numbers to the number keys 3-9.

1 Select Menu > Contacts > Speed

dials, and scroll to a number key.

2 Select Assign, or, if a number has

already been assigned to the key,

select Options > Change.

3 Enter a number or search for a

contact.

Voice commands

You can use voice commands to make

phone calls, launch applications, and

activate profiles. Voice commands are

language-dependent.

Select Menu > Settings and Phone.

Set the language

Select Language settings > Phone

language and the language.

Train voice recognition to your voice

Select Voice recognition > Voice

training.

Activate a voice command for a

function

Select Menu > Settings > Phone >

Voice recognition > Voice commands,

a feature, and the function. indicates

that the voice command is activated. If

is not displayed, select Add.

Play an activated voice command

Select Play.

18 Make it your device

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Use voice commands

See "Voice dialling", p. 23.

Rename or deactivate a voice

command

Scroll to a function, and select Options >

Edit or Remove.

Activate or deactivate all voice

commands

Select Options > Add all or Remove all.

Connect

Your device provides several features to

connect to other devices to transmit and

receive data.

Bluetooth wireless technology

With Bluetooth wireless technology, you

can connect your device, using radio

waves, to a compatible Bluetooth device

within 10 metres (32 feet).

Select Menu > Settings >

Connectivity > Bluetooth.

This device is compliant with Bluetooth

Specification 2.1 + EDR supporting the

following profiles: SIM access, object

push, file transfer, headset, handsfree,

generic access, serial port, generic object

exchange, dial-up networking, device ID,

phonebook access, service discovery

application, advanced audio distribution,

audio video remote control, and generic

audio/video distribution. To ensure

interoperability between other devices

supporting Bluetooth technology, use

Nokia approved accessories for this

model. Check with the manufacturers of

other devices to determine their

compatibility with this device.

Features using Bluetooth technology

increase the demand on battery power

and reduce the battery life.

Set up a Bluetooth connection

1 Select My phone's name, and enter a

name for your device.

2 To activate Bluetooth connectivity,

select Bluetooth > On. indicates

that Bluetooth connectivity is active.

3 To connect your device to an audio

accessory, select Conn. to audio acc.

and the accessory.

4 To pair your device with any

Bluetooth device in range, select

Paired devices > Add new device.

5 Scroll to a found device, and select

Add.

6 Agree on a passcode (up to 16

characters) with the user of the other

device and enter the passcode on your

device. To establish the connection,

enter the passcode on the other

device, when requested.

Operating the device in hidden mode is a

safer way to avoid malicious software. Do

not accept Bluetooth connectivity from

sources you do not trust. Alternatively,

switch off the Bluetooth function. This

does not affect other functions of the

device.

Connect your PC to the internet

You can use Bluetooth technology to

connect your compatible PC to the

internet without the PC Suite software.

Your device must be able to connect to the

internet (network service), and your PC

must support Bluetooth technology.

1 Make sure that your device can

connect to the internet.

Make it your device 19

www.nokia.com/support

Cyan

Magenta

Yellow

Black

2 Pair your device with your PC using

Bluetooth connectivity. Your device

automatically opens a packet data

connection to the internet.

USB data cable

You can use the USB data cable to transfer

data between your device and a

compatible PC or a printer supporting

PictBridge.

Select USB mode

To activate the device for data transfer or

image printing, connect the USB data

cable, and select from the following:

PC Suite — Use Nokia PC Suite on your PC.

Printing & media — Use your device with

a PictBridge compatible printer or with a

compatible PC.

Data storage — Connect to a PC that does

not have Nokia software, and use your

device as data storage

Change USB mode

Select Menu > Settings >

Connectivity > USB data cable and the

desired USB mode.

Connect a USB device

You can connect a USB storage device (for

example, a memory stick) to your device

and browse the file system and transfer

files.

1 Connect a compatible adapter cable to

the USB port of your device.

2 Connect the USB storage to the

adapter cable.

3 Select Menu > Gallery and the USB

device.

Not all USB storage devices are supported,

depending on their power consumption.

Synchronisation and backup

Select Menu > Settings > Sync &

backup > Synchronisation and from the

following:

Phone switch — Synchronise or copy

selected data between your device and

another device using Bluetooth

technology.

Create backup — Create a backup of

selected data.

Restore backup — Select a stored

backup file, and restore data to the device.

Select Options > Details for information

about the selected backup file.

Data transfer — Synchronise or copy

selected data between your device and

another device, PC, or network server

(network service).

Packet data

General packet radio service (GPRS) is a

network service that allows mobile

devices to send and receive data over an

internet protocol (IP) based network.

Select Menu > Settings and

Connectivity > Packet data > Packet

data conn..

Select from following:

When needed — Establish the packet

data connection only when an application

needs it. The connection is closed when

the application is closed.

Always online — Automatically connect

to a packet data network when you switch

the device on.

You can use your device as a modem by

connecting it to a compatible PC. For

20 Make it your device

www.nokia.com/support

Cyan

Magenta

Yellow

Black

details, see the Nokia PC Suite

documentation.

Network provider services

Your network provider provides several

additional services you may want to use.

For some of these services, charges may

apply.

Operator menu

Access a portal to services provided by

your network operator. The operator can

update this menu with a service message.

For more information, contact your

network operator.

SIM services

Your SIM card may provide additional

services. You can access this menu only if

it is supported by your SIM card. The name

and contents of the menu depend on the

available services.

Accessing these services may involve

sending messages or making a phone call

for which you may be charged.

Position log

The network may send you a position

request (network service). To subscribe

and agree upon the delivery of

positioning information, contact your

service provider.

Accept or reject an incoming position

request

Select Accept or Reject.

View the latest position requests

Select Menu > Log > Positioning and

Position log.

If you miss the request, the device

automatically accepts or rejects it

according to what you have agreed with

your service provider.

Info messages and SIM messages

Select Menu > Messaging.

View info messages

Select More > Info messages. You can

receive messages on various topics from

your service provider (network service).

For more information, contact your

service provider.

View SIM messages

Select Options > SIM messages. SIM

messages are specific text messages that

are saved to your SIM card. You can copy

or move those messages from the SIM to

the device memory, but not vice versa.

Configuration settings

You can configure your device with

settings that are required for certain

services. You may receive these settings as

a configuration message from your

service provider.

Select Menu > Settings.

Select Configuration and from the

following:

Default config. sett. — View the service

providers saved in the device, and set a

default service provider.

Act. def. in all apps. — Activate the

default configuration settings for

supported applications.

Preferred access pt. — View the saved

access points.

Make it your device 21

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Device mgr. settings — Allow or prevent

the device from receiving software

updates. This option may not be available,

depending on your device.

Personal settings — Add manually new

personal accounts for various services,

and activate or delete them. To add a new

personal account, select Add or

Options > Add new. Select the service

type, and enter the required parameters.

To activate a personal account, scroll to

the account, and select Options >

Activate.

Stay in touch

Learn how to make calls, write text, send

messages, and use the mail functionality

of your device.

Make calls

Make a voice call

Dial a number manually

Enter the phone number, including the

area code, and press the call key.

For international calls, press * twice for

the international prefix (the + character

replaces the international access code),

enter the country code, the area code

without the leading 0, if necessary, and

the phone number.

Redial a number

To access the list of dialled numbers, in the

home screen , press the call key. Select a

number or name, and press the call key.

Call a contact

Select Menu > Contacts and Names.

Select a contact, and press the call key.

Handle voice calls

To handle calls with the fold, select

Menu > Settings and Call > Answ. on

fold open.

Answer an incoming call

Press the call key, or open the fold.

End a call

Press the end key, or close the fold.

Mute the ringing tone

Select Silence.

22 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

When the fold is closed, press a volume

key.

Reject an incoming call

Press the end key.

When the fold is closed, press and hold a

volume key.

Adjust the volume in a call

Use the volume keys.

Make a video call

In a video call, the video recorded with the

front camera on your device is shown to

the video call recipient. To make a video

call, you must have a USIM card and be

connected to a WCDMA network. For

availability and subscription to video call

services, contact your service provider.

The video call can be made to a

compatible device or an ISDN client

between two parties. Video calls cannot

be made while another voice, video, or

data call is active.

1 To start a video call, enter the phone

number, including the area code.

2 Press and hold the call key, or select

Options > Video call.

Starting a video call may take a while.

If the call is not successful, you are

asked to try making a voice call or to

send a message instead.

3 To end the call, press the end key.

Dialling shortcuts

You can assign phone numbers to the

number keys 3-9.

1 Select Menu > Contacts > Speed

dials, and scroll to a number key.

2 Select Assign, or, if a number has

already been assigned to the key,

select Options > Change.

3 Enter a number or search for a

contact.

4 To activate one key dialling, select

Menu > Settings and Call > Speed

dialling > On

Use a dialling shortcut

Press a number key, then the call key.

Use one key dialling

Press and hold a number key.

Voice dialling

Make a phone call by saying the name that

is saved in Contacts.

As voice commands are language-

dependent, before voice dialling, select

Menu > Settings and Phone >

Language settings > Phone language,

and your language.

Note: Using voice tags may be difficult in

a noisy environment or during an

emergency, so you should not rely solely

upon voice dialling in all circumstances.

1 In the home screen, press and hold

the right selection key. A short tone

sounds, and Speak after the tone is

displayed.

2 Say the name of the contact you want

to dial. If the voice recognition is

successful, a list of proposed matches

is displayed. The device plays the

voice command of the first match on

the list. If it is not the correct

command, scroll to another entry.

Stay in touch 23

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Options during a call

Many of the options that you can use

during a call are network services. For

availability, contact your service provider.

Activate options during a call

Select Options.

Some of the network options are Hold,

New call, Add to conference, End all

calls, and the following:

Send DTMF — Send tone strings.

Swap — Switch between the active call

and the call on hold.

Transfer — Connect a call on hold to an

active call and disconnect yourself.

Conference — Make a conference call.

Private call — Start a private discussion

in a conference call.

Voice messages

The voice mailbox is a network service to

which you may need to subscribe. For

more information, contact your service

provider.

Call your voice mailbox

Press and hold 1.

Edit your voice mailbox number

Select Menu > Messaging > More >

Voice messages and Voice mailbox

no..

Video messages

The video mailbox is a network service to

which you may need to subscribe. For

more information, contact your service

provider.

Call your video mailbox

Press and hold 2.

Edit your video mailbox number

Select Menu > Messaging and More >

Video messages > Video mailbox no..

Call log

To view details of your calls, messages,

data, and synchronisation, select Menu >

Log and the desired item.

Note: The actual invoice for calls and

services from your service provider may

vary, depending on network features,

rounding off for billing, taxes, and so

forth.

Call settings

Select Menu > Settings and Call and from

the following:

Call divert — Divert your incoming calls

(network service). You may not be able to

divert your calls if some call barring

functions are active.

Anykey answer — Answer an incoming

call by briefly pressing any key, except the

power key, the left and right selection

keys, or the end key.

Automatic redial — The device redials

the number automatically if a call fails.

The device tries to call the number 10

times.

Video-voice redial — The device

automatically makes a voice call to the

same number to which a video call has

failed.

Voice clarity — Improve speech

intelligibility, especially in noisy

environments.

Speed dialling — Dial the names and

phone numbers assigned to the number

24 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

keys (2-9) by pressing and holding the

corresponding number key.

Call waiting — The network notifies you

of an incoming call while you have a call

in progress (network service).

Call dur. display — Display the duration

of the call in progress.

Summary after call — Briefly display the

approximate duration after each call.

Send my caller ID — Show your phone

number to the person you are calling

(network service). To use the setting

agreed upon with your service provider,

select Set by network.

Outgoing call line — Select the phone

line for making calls, if your SIM card

supports multiple phone lines (network

service).

Answ. on fold open — Answer or end a

call by opening or closing the fold.

Text and messages

Write text, and create messages and

notes.

Write text

Text input modes

To enter text, for example, when writing

messages, you can use traditional or

predictive text input.

, , and indicate the character

cases. indicates number mode.

Switch between text input modes

Select and hold Options. Not all

languages are supported by predictive

text input.

Switch between character cases

Press #.

Switch between letter and number

modes

Press and hold #.

Set the writing language

Select Options > More > Writing

language.

Traditional text input

Write a word

Press a number key, 2-9, repeatedly until

the desired character is displayed. The

available characters depend on the

selected writing language. If the next

letter you want to enter is located on the

same key as the present one, wait until the

cursor is displayed, and enter the letter.

Insert common punctuation marks

Press 1 repeatedly.

Insert special characters

Press *, and select a character from the

list.

Insert a space

Press 0.

Predictive text input

Predictive text input is based on a built-in

dictionary to which you can also add new

words.

Write a word

Press number keys, 2-9. Press each key

only once for one letter.

Confirm a word

Scroll right, or press 0 to add a space.

Stay in touch 25

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Select the correct word

If the proposed word is not correct, press

* repeatedly, and select the desired word

from the list.

Add a word to the dictionary

If the ? character is displayed after the

word, the word you intended to write is

not in the dictionary. To add the word to

the dictionary, select Spell. Enter the word

using traditional text input, and select

Save.

Write a compound word

Write the first part of the word, and scroll

right to confirm it. Write the next part of

the word, and confirm again.

Text and multimedia messages

You can create a message and optionally

attach, for example, a picture. Your device

automatically changes a text message to

a multimedia message when a file is

attached.

Text messages

Your device supports text messages

beyond the limit for a single message.

Longer messages are sent as two or more

messages. Your service provider may

charge accordingly. Characters with

accents, other marks, or some language

options take more space, and limit the

number of characters that can be sent in

a single message.

The total number of characters left and

the number of messages needed for

sending are displayed.

To send messages, the correct message

centre number must be stored in your

device. Normally, this number is set by

default through your SIM card.

1 To set the number manually, select

Menu > Messaging and More >

Message settings > Text

messages > Message centre.

2 Enter the name and the number

supplied by the service provider.

Multimedia messages

A multimedia message can contain text,

pictures, and sound or video clips.

Only devices that have compatible

features can receive and display

multimedia messages. The appearance of

a message may vary depending on the

receiving device.

The wireless network may limit the size of

MMS messages. If the inserted picture

exceeds this limit, the device may make it

smaller so that it can be sent by MMS.

Important: Exercise caution when

opening messages. Messages may contain

malicious software or otherwise be

harmful to your device or PC.

For availability and subscription to the

multimedia messaging service (MMS),

contact your service provider.

Create a message

1 Select Menu > Messaging and

Create message.

2 Write your message.

To insert a special character or a

smiley, select Options > Insert

symbol.

To attach an object to the message,

select Options > Insert object. The

message type changes automatically

to multimedia message.

3To add recipients, select Send to and

a recipient.

26 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

To enter a phone number or mail

address manually, select Number or

e-mail. Enter a phone number, or

select E-mail and enter a mail

address.

4 Select Send.

Multimedia messages are indicated with

an icon at the top of the display.

Service providers may charge differently

depending on the message type. For

details, contact your service provider.

Read a message and reply

Important: Exercise caution when

opening messages. Messages may contain

malicious software or otherwise be

harmful to your device or PC.

Read a received message

Select View.

Reply to a message

Select Reply.

Read several received messages

Select Menu > Messaging and Inbox,

and the desired message.

Send and organise messages

To send a message, select Send.

Note: The message sent icon or text on

your device screen does not indicate that

the message is received at the intended

destination.

If message sending is interrupted, the

device tries to resend the message a few

times. If these attempts fail, the message

is marked as failed in the Sent items

folder.

The device saves received messages in the

Inbox folder. Organise your messages in

the Saved items folder.

To add, rename, or delete a folder, select

Menu > Messaging and More >

Archive > Options.

Flash messages

Flash messages are text messages that are

instantly displayed upon reception.

Select Menu > Messaging.

1 Select More > Other messages >

Flash message.

2 Write your message.

3 Select Send to and a contact.

Nokia Xpress audio messages

Create and send audio messages using

MMS in a convenient way.

Select Menu > Messaging.

1 Select More > Other messages >

Audio message. The voice recorder

opens.

2 To record your message, select .

3 To stop recording, select .

4 Select Send to and a contact.

Message settings

Select Menu > Messaging and More >

Msg. settings.

Select from the following:

General settings — Save copies of sent

messages in your device, overwrite old

messages if the message memory

becomes full, and set up other preferences

related to messages.

Stay in touch 27

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Text messages — Allow delivery reports,

set up message centres for SMS and SMS

mail, select the type of character support,

and set up other preferences related to

text messages.

Multimedia msgs. — Allow delivery

reports, set up the appearance of

multimedia messages, allow the

reception of multimedia messages and

advertisements, and set up other

preferences related to multimedia

messages.

E-mail messages — Allow mail

reception, set the image size in mail, and

set up other preferences related to mail.

Service messages — Activate service

messages, and set up preferences related

to service messages.

Mail and Instant Messaging

Set up your device to send and receive

mails from your mail account or to chat in

your instant messaging (IM) community.

Nokia Mail

Access your mail account with your device

to read, write, and send mail. This mail

application is different from the SMS mail

function.

Before you can use mail, you must have an

mail account from an mail service

provider. For availability and the correct

settings, contact your mail service

provider. You may receive the mail

configuration settings as a configuration

message.

Mail setup wizard

The mail setup wizard opens

automatically if no mail settings are

defined in the device. To open the setup

wizard, to add an additional mail account,

select Menu > Messaging and the

existing mail account. Select Options >

Add mailbox. You can also create a new

mail account on Ovi for free. Follow the

instructions.

Write and send a mail

You may write your mail before

connecting to the mail service.

1 Select Menu > Messaging and

Create message > E-mail message.

2 Enter the recipient’s mail address, the

subject, and the mail message. To

attach a file, select Options > Insert.

3 If more than one mail account is

defined, select the account from

which you want to send the mail.

4 Select Send.

Read a mail and reply

Important: Exercise caution when

opening messages. Messages may contain

malicious software or otherwise be

harmful to your device or PC.

Select Menu > Messaging.

Download mail headers

Select your mail account.

Download a mail and its attachments

Select a mail and Open or Retrieve.

Reply to or forward a mail

Select Options > Reply or Forward.

Disconnect from your mail account

Select Options > Disconnect. The

connection to the mail account

automatically ends after some time

without activity.

28 Stay in touch

www.nokia.com/support

Cyan

Magenta

Yellow

Black

New mail notifications

Your device can automatically check your

mail account at set intervals, and issue a

notification when new mail is received.

Select Menu > Messaging and More.

1 Select Msg. settings > E-mail

settings > Edit mailboxes.

2 Select your mail account,

Downloading sett., and the

following options:

Update interval — Set how often

your device checks your mail account

for new mail.

Automatic retrieval — Retrieve new

mail automatically from your mail

account.

3 To enable new mail notification,

select Msg. settings > E-mail

settings > New e-mail notif..

Nokia IM

With the instant messaging (IM) network

service, you can send short text messages

to online users. You must subscribe to a

service and register with the IM service

you want to use. For availability, pricing,

and instructions, contact your service

provider. The menus may vary depending

on your IM service provider.

To connect to the service, select Menu >

I M, and follow the instructions.

Image and video

Capture images

Activate the camera

Select Menu > Applications > Camera;

or, if in video mode, scroll left or right.

Zoom in or out

In image mode, scroll up and down, or use

the volume keys.

Capture an image

Select Capture.

Images are saved in Gallery.

Activate the camera flash

To set the device to use the flash

automatically if the lighting conditions

require it, select Options > Flash >

Automatic. To set the device to always

use the flash, select Flash on.

Keep a safe distance when using the flash.

Do not use the flash on people or animals

at close range. Do not cover the flash while

taking a picture.

Display images after capture

Select Options > Settings > Photo

preview time and the preview time.

End the image preview manually

Select Back.

Your device supports an image capture

resolution of up to 1536x2048 pixels.

Image and video 29

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Record video clips

Activate video mode

Select Menu > Applications and Video

camera, or, if in image mode, scroll left or

right.

Start recording

Select Record.

Pause or resume recording

Select Pause or Continue.

Stop recording

Select Stop.

Video clips are saved in Gallery.

Camera and video settings

Select Menu > Applications > Camera.

In image or video mode, select Options

and from the following:

Self-timer — Use the self-timer.

Effects — Apply different effects (for

example, greyscale and false colour) to

the captured image.

White balance — Adapt the camera to

the current light conditions.

Landscape format or Portrait

format — Select the orientation of the

camera.

Settings — Modify other camera and

video settings, and select where to save

images and video clips.

Gallery

Manage images, video clips, music files,

themes, graphics, tones, recordings, and

received files. These files are stored in the

device memory or on a memory card and

may be arranged in folders.

Photos

View images and play video clips with the

Photos application.

Select Menu > Gallery > Photos.

Select from the following:

My photos — View images in a thumbnail

grid. You can sort images by date, name,

or size.

Timeline — View images in the order

they were captured.

My albums — Sort images into albums.

You can create, rename and remove

albums. If you remove an album, the

images inside the album are not deleted

from the memory.

Rotate an image

Select Options > Landscape mode or

Portrait mode.

View a slide show

A slide show uses the images of the

currently selected folder or album.

1 Select My photos, Timeline, or My

albums.

2 Select Options > Slide show.

3 Select Start slide show.

Edit images

You can, for example, rotate, flip, crop,

and adjust the brightness, contrast, and

colours of images.

1 Select an image in My photos,

Timeline, or My albums.

2 Select Options > Edit photo.

3 Select an editing option, and use the

scroll key to change the settings or

values.

30 Image and video

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Music and videos

Your device includes a media player for

playing songs and video clips. Music and

video files stored in the music folder in the

device memory or on the memory card are

automatically detected and added to the

video or music library.

Select Menu > Gallery and Music &

videos.

Select from the following:

Videos — List all available video clips.

All songs — List all available songs. You

can sort songs by artist, album, or genre,

for example.

Manage folders and files

To manage folders and files in Gallery,

select Menu > Gallery.

View a list of folders

Select All content.

View a list of files in a folder

Select a folder and Open.

View the folders of the memory card

when moving a file

Scroll to the memory card, and scroll right.

Print images

Your device supports Nokia XpressPrint,

allowing you to print images in the JPEG

file format.

1 Connect your device to a compatible

printer, using a USB data cable, or, if

supported by the printer, Bluetooth

connectivity.

2 Select an image from Gallery and

Options > Print.

Share images and video clips online

Share images and video clips in

compatible online sharing services on the

web.

To use online sharing, you must subscribe

to an online sharing service (network

service).

1 Select Menu > Gallery > Photos and

a file.

2 Select Options > Send > Upload to

web.

3 Select an online sharing service, and

follow the instructions on the display.

You may also mark several images or

video clips and upload them together to

the online sharing service.

You can view uploads on the internet

pages of the online sharing service on

your device.

For more information on online sharing

and compatible service providers, see the

Nokia product support pages or your local

Nokia website.

Memory card

Use a memory card to store your

multimedia files, such as video clips,

songs, sound files, images, and messaging

data.

Select Menu > Gallery > All content >

Memory card.

Some of the folders in Gallery that contain

content used by your device (for example,

Themes) can be stored on the memory

card.

If your memory card has not been pre-

formatted, you need to format it. When

Image and video 31

www.nokia.com/support

Cyan

Magenta

Yellow

Black

you format a memory card, all data on the

card is permanently deleted.

Format the memory card

Select Options > Mem. card options >

Format memory card > Yes. When

formatting is complete, enter a name for

the memory card.

Protect the memory card with a

password

Select Options > Mem. card options >

Set password. The password is stored in

your device, so you only have to enter the

password when attempting to use the

memory card in another device.

Remove the memory card password

Select Options > Mem. card options >

Delete password.

Check the memory consumption

Select Options > Details. The memory

consumption of different data groups,

and the amount of available memory to

install new software, is displayed.

Entertainment

Listen to music

Listen to music with the music player or

radio, and record sounds or voice with the

voice recorder. Download music from the

internet, or transfer music from your PC.

Warning:

Continuous exposure to high volume may

damage your hearing. Listen to music at a

moderate level, and do not hold the device

near your ear when the loudspeaker is in

use.

Media player

To open the media player, select Menu >

Applications > Media player.

Music menu

Access your music and video files stored in

the device memory or on the memory

card, download music or video clips from

the web, or view compatible video

streams from a network server (network

service).

Select Menu > Applications > Media

player.

Play a media file

Select a file from the available folders and

Play.

Download files from the web

Select Options > Downloads and a

download site.

Update the music library after adding

files

Select Options > Update library.

32 Entertainment

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Create a playlist

1 Select Playlists > Create playlist,

and enter the name of the playlist.

2 Add music or video clips from the

displayed lists.

3 To store the playlist, select Done.

Configure a streaming service

You may receive the streaming settings as

a configuration message from the service

provider. You can also enter the settings

manually.

1 Select Options > Downloads >

Streaming settings >

Configuration.

2 Select a service provider, Default, or

Personal config. for streaming.

3 Select Account and a streaming

service account from the active

configuration settings.

Play songs

Operate the media player

Use the scroll key according to the virtual

keys on the display.

Adjust the volume

Use the volume keys.

Start playing

Select .

Pause playing

Select .

Skip to the next song

Select .

Skip to the previous song

Select twice.

Fast-forward the current song

Select and hold .

Rewind the current song

Select and hold .

Switch to the music menu

Select .

Switch to the current playlist

Select .

Leave the media player playing in the

background

Press the end key.

Stop the media player

Press and hold the end key.

Change the media player look

Your device provides several themes to

change the look of the media player.

Select Menu > Applications > Media

player and Go to Media pl. > Options >

Settings > Media player theme and the

desired theme.

The virtual keys may change depending

on the theme.

Transfer music from a computer

You can transfer music to your device in

the following ways:

•Use Nokia Music to transfer, rip, burn,

and play new music on your PC and

mobile device. Download the PC

software from

www.music.nokia.com/download.

•Use PC Suite to connect your device to

your PC using Bluetooth connectivity

or a compatible USB data cable, and

Entertainment 33

www.nokia.com/support

Cyan

Magenta

Yellow

Black

use the Nokia Music Manager. To use

a USB data cable, select PC Suite as the

connection mode.

•Connect your device to your PC using

Bluetooth connectivity or a

compatible USB data cable, and copy

music files to the device memory. To

use a USB data cable, select Data

storage as the connection mode.

•Use Windows Media Player. Connect a

compatible USB data cable, and select

Printing & media as the connection

mode.

Radio

The FM radio depends on an antenna other

than the wireless device antenna. A

compatible headset or accessory needs to

be attached to the device for the FM radio

to function properly.

Select Menu > Applications > Radio.

Tune in to radio stations

1 To start the search, press and hold the

scroll key left or right. To change the

radio frequency in 0.05 MHz steps,

briefly press the scroll key left or right.

2 To save a station to a memory

location, select Options > Save

station.

3 To enter the name of the radio

station, select Options > Stations >

Options > Rename.

Select Options and from the following:

Search all stations — Search

automatically for the available stations at

your location.

Set frequency — Enter the frequency of

a radio station.

Station directory — Access a website

with a list of radio stations.

Stations — List, rename, or delete saved

stations.

Use the virtual keys on the display

Use the scroll key.

Change stations

Scroll up or down, or press the number key

that corresponds to the number of the

station in the station list.

Adjust the volume

Use the volume keys.

Set the radio to play in the background

Briefly press the end key.

Close the radio

Press and hold the end key.

Radio settings

Select Menu > Applications > Radio.

Select Options > Settings and from the

following:

RDS — Display information from the radio

data system, such as the name of the

station.

Auto-frequency — Allow the device to

automatically switch to a frequency with

better reception (available when RDS is

activated).

Play via — Listen using the headset or

the loudspeaker.

Output — Switch between stereo and

mono output.

Radio theme — Select the look of the

radio.

Voice recorder

Record speech, sound, or an active call,

and save the recordings in Gallery.

34 Entertainment

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Select Menu > Applications > Voice

recorder.

The recorder cannot be used when a data

call or GPRS connection is active.

To use the graphical keys , , or , scroll

left or right.

Start recording

Select , or, during a call, select

Options > Record. While recording a call,

all parties to the call hear a faint beeping.

Pause recording

Select .

Stop recording

Select . The recording is saved in the

Recordings folder in Gallery.

To play or send the last recording, to

access the list of recordings, or to select

the memory and the folder to store the

recordings, select Options and the

appropriate option.

Equaliser

Adjust the sound when using the media

player.

Select Menu > Applications >

Equaliser.

Activate a predefined equaliser set

Scroll to a set, and select Activate.

Create a new equaliser set

1 Select one of the last two sets in the

list and Options > Edit.

2 Use the scroll key to adjust the sound

controls.

3 To save the settings and enter a name

for the set, select Save and

Options > Rename.

Web

You can access various internet services

with your device browser (network

service). The appearance of the internet

pages may vary due to screen size. You

may not be able to see all the details on

the internet pages.

Important: Use only services that you

trust and that offer adequate security and

protection against harmful software.

For the availability of these services,

pricing, and instructions, contact your

service provider.

You may receive the configuration

settings required for browsing as a

configuration message from your service

provider.

Select Menu > Internet.

To set up the service, select Web

settings > Configuration sett., a

configuration, and an account.

Browse the web

Select Menu > Internet.

Open the home page

Select Home; or in the home screen, press

and hold 0.

Select a bookmark

Select Bookmarks.

Enter a web address

Select Go to address, enter the address,

and select OK.

Entertainment 35

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Select the last visited web address

Select Last web addr..

Search the web

If you search for the first time, select a

search provider. Then select Search, enter

the search terms, and select Search.

Change the search provider

Select Options > Change provider.

After you connect to the service, you can

start browsing its pages. The function of

the device keys may vary in different

services. Follow the instructions. For more

information, contact your service

provider.

Web uploads

On the web page of your online sharing

service, you can view uploaded images

and video clips and modify settings

(network service).

Select Menu > Internet and Web

uploads.

Open an online sharing service

Select an online sharing service and a link

offered by the service.

Modify settings

When an online sharing service is open,

select Options > Settings.

Browser settings

While browsing the web, select

Options > Settings and from the

following:

Display — Select the font size, whether

images are displayed, and how the text is

displayed.

General — Select the encoding type for

the contents, whether web addresses are

sent as Unicode (UTF-8), and whether

JavaScript™ is enabled.

The available options may vary.

Cache memory

A cache is a memory location that is used

to store data temporarily. If you have tried

to access or have accessed confidential

information requiring passwords, empty

the cache after each use. The information

or services you have accessed are stored

in the cache.

A cookie is data that a site saves in the

cache memory of your device. Cookies are

saved until you clear the cache memory.

Clear the cache

While browsing, select Options >

Tools > Clear the cache.

Allow or prevent cookies

Select Menu > Internet and Web

settings > Security > Cookies.

Browser security

Security features may be required for

some services, such as banking services or

online shopping. For such connections

you need security certificates and possibly

a security module, which may be available

on your SIM card. For more information,

contact your service provider.

To view or modify the security module

settings, or to view a list of authority or

user certificates downloaded to your

device, select Menu > Settings and

Security > Security module, Auth.

certificates, or User certificates.

36 Entertainment

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Important: Even if the use of certificates

makes the risks involved in remote

connections and software installation

considerably smaller, they must be used

correctly in order to benefit from

increased security. The existence of a

certificate does not offer any protection

by itself; the certificate manager must

contain correct, authentic, or trusted

certificates for increased security to be

available. Certificates have a restricted

lifetime. If "Expired certificate" or

"Certificate not valid yet" is shown, even if

the certificate should be valid, check that

the current date and time in your device

are correct.

Before changing any certificate settings,

you must make sure that you really trust

the owner of the certificate and that the

certificate really belongs to the listed

owner.

Games and applications

You can manage applications and games.

Your device may have some games or

applications installed. These files are

stored in the device memory or an

attached memory card and may be

arranged in folders.

Open an application

Select Menu > Applications > Extras.

Open a game or application

Select Games, Collection, or Memory

card.

Scroll to a game or application, and select

Open.

Set sounds, lights, and shakes for a

game

Select Options > Application settings.

Download an application

Your device supports J2ME™ Java

applications. Ensure that the application

is compatible with your device before

downloading it.

Important: Only install and use

applications and other software from

trusted sources, such as applications that

are Symbian Signed or have passed the

Java Verified™ testing.

You can download new applications and

games directly or using your PC.

Download directly

Select Menu > Applications > Extras

and Options > Downloads > App.

downloads or Game downloads; the list

of available bookmarks is shown.

Download using your PC

Download applications and games to your

PC and use PC Suite to install them on your

device.

For the availability of different services

and pricing, contact your service provider.

Entertainment 37

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Maps

With Maps, you can browse maps for

different cities and countries, search for

addresses and different points of interest,

plan routes from one location to another,

see your current location on the map if you

have a GPS connection, and save locations

and send them to compatible devices. You

can also purchase a licence for a

navigation service with voice guidance.

This service is not available for all

countries or regions.

About Maps

If there are maps available in your device

or on an inserted memory card, you can

browse them without an internet

connection. When you browse to an area

which is not covered by the maps already

downloaded in your device, a map for the

area is automatically downloaded

through the internet. You may be

prompted to select an access point to use

with the internet connection.

Downloading maps may involve the

transmission of large amounts of data

through your service provider's network.

Contact your service provider for

information about data transmission

charges.

You can also use the Nokia Map Loader PC

software to download maps to your

device. To install Nokia Map Loader on a

compatible PC, see www.nokia.com/

maps.

Select Menu > Applications > Maps and

from the following:

Last map — Open the map that was

displayed last.

Find address — Search for a specific

address.

Saved locations — Find a location you

have saved on your device.

Rec. locations — View the locations you

have browsed.

Current position — View your current

location, if a GPS connection is available.

Plan route — Plan a route.

Extra services — Purchase a license for

navigation.

Settings — Define the settings.

Almost all digital cartography is

inaccurate and incomplete to some

extent. Never rely solely on the

cartography that you download for use in

this device.

Nokia Map Loader

With the Nokia Map Loader application for

PC, you can download maps and voice

guidance files from the internet. A

memory card with sufficient space must

be inserted in your device. You must use

the Maps application and browse maps at

least once before using Nokia Map Loader,

as Nokia Map Loader uses the Maps history

information to check which version of the

maps to download.

To install Nokia Map loader, visit

www.nokia.com/maps, and follow the

instructions.

Download maps with Nokia Map

Loader

1 Connect your device to the computer

with a compatible USB data cable or

Bluetooth connection. If you use a

data cable, select PC Suite as the USB

connection method.

38 Maps

www.nokia.com/support

Cyan

Magenta

Yellow

Black

2 Open Nokia Map Loader on the

computer.

3 Select a continent and a country or

region.

4 Select the maps or services, and

download and install them to your

device.

On the Service tab of Nokia Map Loader,

you can purchase navigation and traffic

information licences, travel guides, and

download maps.

About GPS

The Global Positioning System (GPS) is

operated by the government of the United

States, which is solely responsible for its

accuracy and maintenance. The accuracy

of location data can be affected by

adjustments to GPS satellites made by the

United States government and is subject

to change with the United States

Department of Defense civil GPS policy and

the Federal Radionavigation Plan.

Accuracy can also be affected by poor

satellite geometry. Availability and

quality of GPS signals may be affected by

your location, buildings, natural

obstacles, and weather conditions. GPS

signals may not be available inside

buildings or underground and may be

impaired by materials such as concrete

and metal.

GPS should not be used for precise

location measurement, and you should

never rely solely on location data from the

GPS receiver and cellular radio networks

for positioning or navigation.

The trip meter has limited accuracy, and

rounding errors may occur. Accuracy can

also be affected by availability and quality

of GPS signals.

GPS receiver

Your device has an internal GPS receiver.

For the best signal from the satellites,

place your device in a position with an

unobstructed view to the sky.

You can use GPS to support the Maps

application. Find out your location, or

measure distances and plot coordinates.

Navigate to your destination

You can upgrade Maps to a full navigation

system to be used by car and by foot. You

need a regional licence for the full

navigation system. The car navigation is

fully voice-guided with two and three-

dimensional map views. Pedestrian

navigation is limited to a speed of 30 km/

h (18.6 miles/h) and provides no voice

guidance. The navigation service is not

available for all countries and regions. For

details, see your local Nokia website.

Purchase a licence for navigation

Select Extra services. The licence is

region-specific and can be used only in the

selected area.

Navigate to the destination

1 Select Plan route, and create a route.

2 Select Options > Show route >

Options > Start navigation.

3 Accept the displayed disclaimer.

Maps 39

www.nokia.com/support

Cyan

Magenta

Yellow

Black

4 Select the language for voice

guidance, if prompted.

If you deviate from the set route, the

device automatically plans a new route.

Repeat the voice guidance

Select Repeat.

Silence the voice guidance

Select Options > Mute audio.

Stop navigating

Select Stop.

Navigate on foot

Select Settings > Routing settings >

Route selection > On foot. This

optimises the routes you create for

navigation on foot.

Organise

Let your phone help you to organise your

life.

Manage contacts

Save names, phone numbers, and

addresses as contacts in the device and on

the SIM card.

Select Menu > Contacts.

Select the memory to use for contacts

The device memory can save contacts with

additional details, such as alternative

phone numbers. You can also save an

image, a tone, or a video clip for a limited

number of contacts.

The SIM card memory can save names with

one phone number attached to them. The

contacts saved in the SIM card memory are

indicated with .

1 Select More > Settings > Memory in

use to select the SIM card, the device

memory, or both for your contacts.

2 Select Phone and SIM to recall

contacts from both memories. When

you save contacts, they are saved in

the device memory.

Handle contacts

Search for a contact

Select Names.

Scroll through the list of contacts, or enter

the first characters of the contact's name.

Save a name and phone number

Select Menu > Contacts and Add new.

40 Organise

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Add and edit details

Select Names, a contact, and Details >

Options > Add detail.

Delete a detail

Select Names, a contact, and Details.

Select a detail and Options > Delete.

Delete a contact

Select Names, a contact, and Options >

Delete contact.

Delete all contacts

Select More > Del. all contacts > From

phone mem. or From SIM card.

Copy or move contacts between the

device and SIM card memories

Copy single contacts

Select Names > Options > More >

Marking options > Mark. Mark the

contacts you want to copy or move, and

select Options > Copy marked or Move

marked.

Copy all contacts

Select More > Copy contacts or Move

contacts.

Create a contact group

Arrange contacts into caller groups with

different ringing tones and group images.

1 Select More > Groups.

2 Select Add or Options > Add new

group to create a new group.

3 Enter the group name, optionally

select an image and a ringing tone,

and select Save.

4 Select the group and View > Add to

add contacts to the group.

Business cards

You can send and receive a person’s

contact information from a compatible

device that supports the vCard standard.

Select Menu > Contacts and Names.

Send a business card

Select a contact, Options > More > Send

business card, and the sending type.

Save a received business card

Select Show > Save.

Date and time

Modify date and time settings

Select Menu > Settings and Date and

time.

Change the time zone when travelling

Select Menu > Settings and Date and

time > Date & time settings > Time

zone:, and scroll left or right to select the

time zone of your location.

The time and date are set according to the

time zone and enable your device to

display the correct sending time of

received text or multimedia messages.

For example, GMT -5 denotes the time

zone for New York (USA), 5 hours west of

Greenwich, London (UK).

Alarm clock

You can set an alarm to sound at a desired

time.

Set the alarm

1 Select Menu > Applications >

Alarm clock.

Organise 41

www.nokia.com/support

Cyan

Magenta

Yellow

Black

2 Set the alarm, and enter the alarm

time.

3 To issue an alarm on selected days of

the week, select Repeat: > On and

the days.

4 Select the alarm tone. If you select the

radio as the alarm tone, connect the

headset to the device.

5 Set the length of the snooze time-out

period, and select Save.

Stop the alarm

Select Stop. If you let the alarm sound for

a minute or select Snooze, the alarm

stops for the length of the snooze time-

out period, then resumes.

Calendar

Select Menu > Calendar.

The current day is framed. If there are any

notes set for the day, the day is in bold

type.

Make a calendar note

Scroll to the date, and select Options >

Make a note. Select the note type, and fill

in the fields.

View the day notes

Select View.

View a week

Select Options > Week view.

Delete all notes in the calendar

Select Options > Delete notes > All

notes.

Delete old notes automatically after a

specified time

Select Options > Settings > Auto-

delete notes.

Edit settings related to the date and

time

Select Options > Settings.

To-do list

You can save a note for a task you must do.

Select Menu > Applications > To-do

list.

Add a note

If no note is added, select Add; otherwise,

select Options > Add. Fill in the fields,

and select Save.

View a note

Select a note and View.

Notes

Select Menu > Applications > Notes.

Add a note

If no note is added, select Add; otherwise,

select Options > Make a note. Write the

note, and select Save.

Send a note

Select Options > Send note and the

sending type.

Nokia PC Suite

With Nokia PC Suite, you can manage your

music and synchronise contacts, calendar

entries, notes, and to-do notes between

your device and a compatible PC or a

remote internet server (network service).

For more information, and to download PC

Suite, visit www.nokia.com/support.

42 Organise

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Calculator

Your device provides a standard, a

scientific, and a loan calculator.

Select Menu > Applications >

Calculator.

Select Options to select the calculator

type or to view the operating instructions.

This calculator has limited accuracy and is

designed for simple calculations.

Countdown timer

Select Menu > Applications > Countd.

timer.

Normal timer

1 Select Normal timer, enter a time,

and write a note that is displayed

when the time expires.

2 Select Start.

Interval timer

To have an interval timer with up to 10

intervals started, do the following:

1 Select Interval timer.

2 Select Start timer > Start.

To select how the interval timer should

start the next period, select Settings >

Cont. to next period.

Stopwatch

You can measure time, take intermediate

times, or take lap times using the

stopwatch.

Select Menu > Applications >

Stopwatch and from the following:

Split timing — Take intermediate times.

To reset the time without saving it, select

Options > Reset.

Lap timing — Take lap times.

Continue — View the timing that you

have set to the background.

Show last — View the most recently

measured time if the stopwatch is not

reset

View times or Delete times — View or

delete the saved times

To set the stopwatch timing to the

background, press the end key.

Organise 43

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Green tips

Here are tips on how you can contribute

to protecting the environment.

Save energy

When you have fully charged the battery

and disconnected the charger from the

device, unplug the charger from the wall

outlet.

You do not need to charge your battery so

often if you do the following:

•Close and disable applications,

services, and connections when not in

use.

•Decrease the brightness of the screen.

•Set the device to enter the power

saver mode after the minimum period

of inactivity, if available in your

device.

•Disable unnecessary sounds, such as

keypad and ringing tones.

Recycle

Most of the materials in a Nokia phone are

recyclable. Check how to recycle your

Nokia products at www.nokia.com/

werecycle, or with a mobile device,

www.nokia.mobi/werecycle.

Recycle packaging and user guides at your

local recycling scheme.

Learn more

For more information on the

environmental attributes of your device,

see www.nokia.com/ecodeclaration.

44 Green tips

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Digital rights management

Content owners may use different types of digital rights

management (DRM) technologies to protect their intellectual

property, including copyrights. This device uses various types

of DRM software to access DRM-protected content. With this

device you can access content protected with WMDRM 10,

OMA DRM 1.0, OMA DRM 1.0 forward lock, and OMA DRM 2.0. If

certain DRM software fails to protect the content, content

owners may ask that such DRM software's ability to access

new DRM-protected content be revoked. Revocation may also

prevent renewal of such DRM-protected content already in

your device. Revocation of such DRM software does not affect

the use of content protected with other types of DRM or the

use of non-DRM-protected content.

Digital rights management (DRM) protected content comes

with an associated licence that defines your rights to use the

content.

If your device has OMA DRM-protected content, to back up

both the licence and the content, use the backup feature of

Nokia PC Suite.

Other transfer methods may not transfer the licence which

need to be restored with the content for you to be able to

continue the use of OMA DRM-protected content after the

device memory is formatted. You may also need to restore

the licence in case the files on your device get corrupted.

If your device has WMDRM-protected content, both the licence

and the content will be lost if the device memory is formatted.

You may also lose the licence and the content if the files on

your device get corrupted. Losing the licence or the content

may limit your ability to use the same content on your device

again. For more information, contact your service provider.

Some licence may be connected to a specific SIM card, and the

protected content can be accessed only if the SIM card is

inserted in the device.

Accessories

Warning:

Use only batteries, chargers, and accessories approved by

Nokia for use with this particular model. The use of any other

types may invalidate any approval or warranty, and may be

dangerous. In particular, use of unapproved chargers or

batteries may present a risk of fire, explosion, leakage, or

other hazard.

For availability of approved accessories, please check with

your dealer. When you disconnect the power cord of any

accessory, grasp and pull the plug, not the cord.

Battery

Battery and charger information

Your device is powered by a rechargeable battery. The battery

intended for use with this device is BL-4S. Nokia may make

additional battery models available for this device. This

device is intended for use when supplied with power from

the following chargers: AC-8/AC-15. The exact charger model

number may vary depending on the type of plug. The plug

variant is identified by one of the following: E, EB, X, AR, U, A,

C, K, or UB.

The battery can be charged and discharged hundreds of

times, but it will eventually wear out. When the talk and

standby times are noticeably shorter than normal, replace the

battery. Use only Nokia approved batteries, and recharge

your battery only with Nokia approved chargers designated

for this device.

If a battery is being used for the first time or if the battery has

not been used for a prolonged period, it may be necessary to

connect the charger, then disconnect and reconnect it to

begin charging the battery. If the battery is completely

discharged, it may take several minutes before the charging

indicator appears on the display or before any calls can be

made.

Safe removal. Always switch the device off and disconnect the

charger before removing the battery.

Proper charging. Unplug the charger from the electrical plug

and the device when not in use. Do not leave a fully charged

battery connected to a charger, since overcharging may

shorten its lifetime. If left unused, a fully charged battery will

lose its charge over time.

Avoid extreme temperatures. Always try to keep the battery

between 15°C and 25°C (59°F and 77°F). Extreme

temperatures reduce the capacity and lifetime of the battery.

A device with a hot or cold battery may not work temporarily.

Battery performance is particularly limited in temperatures

well below freezing.

Do not short-circuit. Accidental short-circuiting can occur

when a metallic object such as a coin, clip, or pen causes direct

connection of the positive (+) and negative (-) terminals of

the battery. (These look like metal strips on the battery.) This

might happen, for example, when you carry a spare battery

in your pocket or purse. Short-circuiting the terminals may

damage the battery or the connecting object.

Disposal. Do not dispose of batteries in a fire as they may

explode. Dispose of batteries according to local regulations.

Please recycle when possible. Do not dispose as household

waste.

Digital rights management 45

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Leak. Do not dismantle, cut, open, crush, bend, puncture, or

shred cells or batteries. In the event of a battery leak, prevent

battery liquid contact with skin or eyes. If this happens, flush

the affected areas immediately with water, or seek medical

help.

Damage. Do not modify, remanufacture, attempt to insert

foreign objects into the battery, or immerse or expose it to

water or other liquids. Batteries may explode if damaged.

Correct use. Use the battery only for its intended purpose.

Improper battery use may result in a fire, explosion, or other

hazard. If the device or battery is dropped, especially on a

hard surface, and you believe the battery has been damaged,

take it to a service centre for inspection before continuing to

use it. Never use any charger or battery that is damaged. Keep

your battery out of the reach of small children.

Nokia battery authentication guidelines

Always use original Nokia batteries for your safety. To check

that you are getting an original Nokia battery, purchase it

from a Nokia authorised service centre or dealer, and inspect

the hologram label using the following steps:

Authenticate hologram

1 When you look at the hologram on the label, you should

see the Nokia connecting hands symbol from one angle

and the Nokia Original Enhancements logo when

looking from another angle.

2 When you angle the hologram left, right, down and up,

you should see 1, 2, 3 and 4 dots on each side

respectively.

Successful completion of the steps is not a total assurance of

the authenticity of the battery. If you cannot confirm

authenticity or if you have any reason to believe that your

Nokia battery with the hologram on the label is not an

authentic Nokia battery, you should refrain from using it, and

take it to the nearest Nokia authorised service centre or

dealer for assistance.

For additional information, refer to the warranty and

reference leaflet included with your Nokia device.

Taking care of your device

Your device is a product of superior design and craftsmanship

and should be treated with care. The following suggestions

will help you protect your warranty coverage.

•Keep the device dry. Precipitation, humidity, and all

types of liquids or moisture can contain minerals that

will corrode electronic circuits. If your device does get

wet, remove the battery, and allow the device to dry

completely before replacing it.

•Do not use or store the device in dusty, dirty areas. Its

moving parts and electronic components can be

damaged.

•Do not store the device in high or cold temperature.

High temperatures can shorten the life of electronic

devices, damage batteries, and warp or melt certain

plastics. When the device warms to its normal

temperature from a cold temperature, moisture can

form inside the device and damage electronic circuit

boards.

•Do not attempt to open the device other than as

instructed in this guide.

•Do not drop, knock, or shake the device. Rough

handling can break internal circuit boards and fine

mechanics.

•Do not use harsh chemicals, cleaning solvents, or strong

detergents to clean the device. Only use a soft, clean,

dry cloth to clean the surface of the device.

•Do not paint the device. Paint can clog the moving parts

and prevent proper operation.

•Use only the supplied or an approved replacement

antenna. Unauthorised antennas, modifications, or

attachments could damage the device and may violate

regulations governing radio devices.

•Use chargers indoors.

•Backup all data you want to keep, such as contacts and

calendar notes.

•To reset the device from time to time for optimum

performance, power off the device and remove the

battery.

46 Taking care of your device

www.nokia.com/support

Cyan

Magenta

Yellow

Black

These suggestions apply equally to your device, battery,

charger, or any accessory.

Recycle

Always return your used electronic products, batteries, and

packaging materials to dedicated collection points. This way

you help prevent uncontrolled waste disposal and promote

the recycling of materials. Check product environmental

information and how to recycle your Nokia products at

www.nokia.com/werecycle, or nokia.mobi/werecycle.

Additional safety information

The surface of this device is nickel-free.

Small children

Your device and its accessories are not toys. They may contain

small parts. Keep them out of the reach of small children.

Operating environment

This device meets RF exposure guidelines in the normal use

position at the ear or at least 1.5 centimetres (5/8 inch)away

from the body. Any carry case, belt clip, or holder for body-

worn operation should not contain metal and should position

the device the above-stated distance from your body.

To send data files or messages requires a quality connection

to the network. Data files or messages may be delayed until

such a connection is available. Follow the separation distance

instructions until the transmission is completed.

Medical devices

Operation of radio transmitting equipment, including

wireless phones, may interfere with the function of

inadequately protected medical devices. Consult a physician

or the manufacturer of the medical device to determine

whether they are adequately shielded from external RF

energy. Switch off your device when regulations posted

instruct you to do so. Hospitals or health care facilities may

use equipment sensitive to external RF energy.

Implanted medical devices

Manufacturers of medical devices recommend a minimum

separation of 15.3 centimetres (6 inches) between a wireless

device and an implanted medical device, such as a pacemaker

or implanted cardioverter defibrillator, to avoid potential

interference with the medical device. Persons who have such

devices should:

•Always keep the wireless device more than 15.3

centimetres (6 inches) from the medical device.

•Not carry the wireless device in a breast pocket.

•Hold the wireless device to the ear opposite the medical

device.

•Turn the wireless device off if there is any reason to

suspect that interference is taking place.

•Follow the manufacturer directions for the implanted

medical device.

If you have any questions about using your wireless device

with an implanted medical device, consult your health care

provider.

Hearing aids

Some digital wireless devices may interfere with some

hearing aids.

Your mobile device model complies with FCC rules governing

hearing aid compatibility. These require a M3 microphone or

higher value. Your device M-value is shown on the box. A

higher M-value generally indicates that a device model has a

lower RF emissions level, which may improve the likelihood

that the device will operate with certain hearing aids. Some

hearing aids are more immune than others to interference.

Please consult your hearing health professional to determine

whether your hearing aid will work with this device. More

information on accessibility can be found at

www.nokiaaccessibility.com.

Telecoil hearing aid

Setting for telecoil hearing aid users.

This device includes a setting for direct connection to telecoil-

equipped hearing aids. When both the telecoil hearing aid (T

switch) and the phone telecoil are activated, using the device

with the aided ear will provide a direct connection for audio

through your hearing aid. The quality of sound depends on

the type of hearing aid used. You should test the device with

the telecoil setting activated to determine whether your

audio performance improves. Using the telecoil hearing-aid

setting consumes additional battery power.

Vehicles

RF signals may affect improperly installed or inadequately

shielded electronic systems in motor vehicles such as

electronic fuel injection, electronic antilock braking,

electronic speed control, and air bag systems. For more

information, check with the manufacturer of your vehicle or

its equipment.

Only qualified personnel should service the device or install

the device in a vehicle. Faulty installation or service may be

dangerous and may invalidate your warranty. Check regularly

that all wireless device equipment in your vehicle is mounted

and operating properly. Do not store or carry flammable

liquids, gases, or explosive materials in the same

compartment as the device, its parts, or accessories.

Remember that air bags inflate with great force. Do not place

your device or accessories in the air bag deployment area.

Additional safety information 47

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Switch off your device before boarding an aircraft. The use of

wireless teledevices in an aircraft may be dangerous to the

operation of the aircraft and may be illegal.

Potentially explosive environments

Switch off your device in any area with a potentially explosive

atmosphere. Obey all posted instructions. Sparks in such

areas could cause an explosion or fire resulting in bodily

injury or death. Switch off the device at refuelling points such

as near gas pumps at service stations. Observe restrictions in

fuel depots, storage, and distribution areas; chemical plants;

or where blasting operations are in progress. Areas with a

potentially explosive atmosphere are often, but not always,

clearly marked. They include areas where you would be

advised to turn off your vehicle engine, below deck on boats,

chemical transfer or storage facilities and where the air

contains chemicals or particles such as grain, dust, or metal

powders. You should check with the manufacturers of

vehicles using liquefied petroleum gas (such as propane or

butane) to determine if this device can be safely used in their

vicinity.

Emergency calls

Important: This device operates using radio signals,

wireless networks, landline networks, and user-programmed

functions. If your device supports voice calls over the internet

(internet calls), activate both the internet calls and the

cellular phone. The device may attempt to make emergency

calls over both the cellular networks and through your

internet call provider if both are activated. Connections in all

conditions cannot be guaranteed. You should never rely

solely on any wireless device for essential communications

like medical emergencies.

To make an emergency call:

1 If the device is not on, switch it on. Check for adequate

signal strength. Depending on your device, you may

also need to complete the following:

•Insert a SIM card if your device uses one.

•Remove certain call restrictions you have

activated in your device.

•Change your profile from Offline or Flight profile

to an active profile.

2 Press the end key as many times as needed to clear the

display and ready the device for calls.

3 Enter the official emergency number for your present

location. Emergency numbers vary by location.

4Press the call key.

When making an emergency call, give all the necessary

information as accurately as possible. Your wireless device

may be the only means of communication at the scene of an

accident. Do not end the call until given permission to do so.

Certification information (SAR)

This mobile device meets guidelines for exposure to

radio waves.

Your mobile device is a radio transmitter and receiver. It is

designed not to exceed the limits for exposure to radio waves

recommended by international guidelines. These guidelines

were developed by the independent scientific organisation

ICNIRP and include safety margins designed to assure the

protection of all persons, regardless of age and health.

The exposure guidelines for mobile devices employ a unit of

measurement known as the Specific Absorption Rate or SAR.

The SAR limit stated in the ICNIRP guidelines is 2.0 watts/

kilogram (W/kg) averaged over 10 grams of tissue. Tests for

SAR are conducted using standard operating positions with

the device transmitting at its highest certified power level in

all tested frequency bands. The actual SAR level of an

operating device can be below the maximum value because

the device is designed to use only the power required to reach

the network. That amount changes depending on a number

of factors such as how close you are to a network base station.

The highest SAR value under the ICNIRP guidelines for use of

the device at the ear is 0.95 W/kg.

Use of device accessories may result in different SAR values.

SAR values may vary depending on national reporting and

testing requirements and the network band. Additional SAR

information may be provided under product information at

www.nokia.com.

Your mobile device is also designed to meet the requirements

for exposure to radio waves established by the Federal

Communications Commission (USA) and Industry Canada.

These requirements set a SAR limit of 1.6 W/kg averaged over

one gram of tissue. The highest SAR value reported under this

standard during product certification for use at the ear is 0.96

W/kg and when properly worn on the body is 0.49 W/kg.

48 Additional safety information

www.nokia.com/support

Cyan

Magenta

Yellow

Black

Index

Symbols/Numerics

3G 16

access codes 10

accessories 8

answering calls 22

anykey answer 24

applications 37

audio messages 27

backing up data 20

barring password 10

battery 5, 7

battery charge level indicator 11

Bluetooth 19

browser 35

browser security 36

browser settings 36

business cards 41

cable connection 20

cache memory 36

calculator 43

calendar 42

call 22

call divert 24

call log 24

call waiting 25

caller id 25

camera 29

camera settings 30

chat services (IM) 29

configuration 21

contacts 40

cookies 36

date and time 41

dial 22

dialling 23

dialling shortcuts 18, 23

digital rights 45

display settings 17, 36

downloads 14

e-mail 28

equaliser 35

factory settings, restoring 15

file management 31

flash messages 27

flight profile 13, 16

games 37

GPRS (general packet radio service) 20

GPS (global positioning system) 39

handsfree 24

headset 8

hearing aids 8

help application 16

home screen 11, 18

IM (instant messaging) 29

images 29, 30

in-call timer 25

indicators 12

info messages 21

internet 35

keyguard 13, 16

keypad lock 13

Index 49

www.nokia.com/support

Cyan

Magenta

Yellow

Black

keys 5, 18

language settings 16

lights 17

location information 21

loudspeaker 24

mail 28, 29

Maps 38

maps 38, 39

media player 31, 32, 33

memory 31

memory card 6

message centre number 26

message sending 27

message settings 27

messages 26, 27

modem 20

music 33

music player 32, 33

My Nokia 14

navigation 12

Nokia Map Loader 38

Nokia support information 14

notes 42

offline profile 13

online sharing service 36

operator menu 21

packet data connection 20

PC Suite 42

phonebook 40

photographs 29

PictBridge 20

PIN 10

position log 21

printing 31

profiles 17

PUK 10

radio 34

redial 22, 24

rejecting calls 22

restoring data 20

restoring settings 15

screen settings 17

scrolling 12

security code 10

security module 10

security settings 16

settings

— accessories 8

sharing, online 31, 36

shortcuts 12, 18

signal strength indicator 11

SIM card 5, 13, 21

SIM messages 21

software updates 14, 15, 16

speed dialling 18, 23, 25

status indicators 11

stopwatch 43

strap 9

support resources 14

switching device on/off 11

synchronisation 20

text input 25

text messages 26

themes 17

time and date 41

to-do list 42

tones 16, 17

transferring, files 33

50 Index

www.nokia.com/support

Cyan

Magenta

Yellow

Black

updates

— device software 14

USB cable connection 8, 20

USB connection 20

video 30

video call 23

video messages 24

voice clarity 24

voice commands 18

voice dialling 23

voice messages 24

voice recorder 34

wallpaper 17

web 35

write text 25

Index 51

www.nokia.com/support

Cyan

Magenta

Yellow

Black

DECLARATION OF CONFORMITY

0434

Hereby, NOKIA CORPORATION declares that this RM-509

product is in compliance with the essential requirements and

other relevant provisions of Directive 1999/5/EC. A copy of the

Declaration of Conformity can be found at www.nokia.com/

phones/declaration_of_conformity/.

Nokia, Nokia Connecting People, Ovi, Nokia Xpress print,

Nokia Xpress audio messaging, and Navi are trademarks or

registered trademarks of Nokia Corporation. Nokia tune is a

sound mark of Nokia Corporation. Other product and

company names mentioned herein may be trademarks or

tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all

of the contents in this document in any form without the prior

written permission of Nokia is prohibited. Nokia operates a

policy of continuous development. Nokia reserves the right

to make changes and improvements to any of the products

described in this document without prior notice.

Includes RSA BSAFE cryptographic or security protocol

software from RSA Security.

Java and all Java-based marks are trademarks or registered

trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent

Portfolio License (i) for personal and noncommercial use in

connection with information which has been encoded in

compliance with the MPEG-4 Visual Standard by a consumer

engaged in a personal and noncommercial activity and (ii) for

use in connection with MPEG-4 video provided by a licensed

video provider. No license is granted or shall be implied for

any other use. Additional information, including that related

to promotional, internal, and commercial uses, may be

obtained from MPEG LA, LLC. See http://www.mpegla.com.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,

UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS

LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME

OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT

DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS".

EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF

ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT

LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN

RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS

DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS

DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR

NOTICE.

The availability of particular products and applications and

services for these products may vary by region. Please check

with your Nokia dealer for details and availability of language

options. This device may contain commodities, technology or

software subject to export laws and regulations from the US

and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example,

when using a telephone in close proximity to receiving

equipment). The FCC or Industry Canada can require you to

stop using your telephone if such interference cannot be

eliminated. If you require assistance, contact your local

service facility. This device complies with part 15 of the FCC

rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including

interference that may cause undesired operation. Any

changes or modifications not expressly approved by Nokia

could void the user's authority to operate this equipment.

Model number: 3710h

5555555/Issue 1 EN

Cyan

Magenta

Yellow

Black

Microsoft RM-509H GSM/WCDMA cellular phone w/BT User Manual Manual

Microsoft Mobile Oy GSM/WCDMA cellular phone w/BT Manual

Manual

Navigation menu

Namespaces

Views

Navigation
