Microsoft RM-586 GSM 850/1900/900/1800 Cellular Telephone with BT User Manual Manual
Microsoft Mobile Oy GSM 850/1900/900/1800 Cellular Telephone with BT Manual
Manual
Nokia 2710 User Guide
xxxxxxx
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Contents
Safety 5
Support 7
Get started 8
Insert SIM card and
battery 8
Insert a microSD card 9
Remove the microSD
card 10
Charge the battery 11
GSM antenna 12
Headset 13
Connect a USB data
cable 14
Magnets and magnetic
fields 15
Keys and parts 15
Access codes 17
Switch on and off 17
Home screen 18
Keypad lock 19
Functions without a SIM
card 19
Applications running in
background 20
Calls 20
Make and answer a
call 20
Loudspeaker 20
Dialling shortcuts 21
Write text 21
Text modes 21
Traditional text input 22
Predictive text input 23
Navigate the
menus 23
Messaging 24
Text and multimedia
messages 24
Flash messages 27
Nokia Xpress audio
messages 27
Nokia Mail 27
2Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Voice messages 30
Message settings 30
Contacts 31
Call log 33
Settings 33
Profiles 33
Tones 34
Display 34
Date and time 34
Shortcuts 35
Synchronisation and
backup 35
Connectivity 36
Call and phone 38
Accessories 39
Configuration 40
Restore factory
settings 41
Operator menu 41
Gallery 41
Applications 42
Alarm clock 42
Calendar and to-do
list 42
Extras 43
Camera and video 44
FM radio 46
Voice recorder 47
Media player 48
Maps 50
About Maps 50
Nokia Map Loader 51
About GPS 52
GPS receiver 53
Navigate to your
destination 54
Web or Internet 55
Connect to a web
service 56
SIM services 57
Green tips 57
Save energy 57
Contents 3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Recycle 58
Learn more 58
General
information 59
Accessories 60
Battery 61
Battery and charger
information 61
Nokia battery
authentication
guidelines 62
Taking care of your
device 63
Recycle 64
Additional safety
information 64
Small children 64
Operating
environment 64
Medical devices 65
Vehicles 65
Potentially explosive
environments 66
Emergency calls 66
Certification information
(SAR) 67
Index 69
4Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
Safety 5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
6Safety
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Support
When you want to learn more about how to use your
product or you are unsure how your device should
function, see the user guide or see the support pages at
www.nokia.com/support or your local Nokia website, or
with a mobile device, www.nokia.mobi/support.
If this does not resolve your issue, do one of the following:
•Restart the device: switch off the device, and remove
the battery. After about a minute, replace the battery,
and switch on the device.
•Restore the original factory settings as explained in the
user guide.
•Update your device software regularly for optimum
performance and possible new features, as explained
in the user guide.
If your issue remains unsolved, contact Nokia for repair
options. See www.nokia.com/repair, or in Latin America,
www.nokia-latinoamerica.com/centrosdeservicio. Before
sending your device for repair, always back up the data in
your device.
Support 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Get started
Insert SIM card and battery
Safe removal. Always switch the device off and disconnect
the charger before removing the battery.
The SIM card and its contacts can be easily damaged by
scratches or bending, so be careful when handling,
inserting, or removing the card.
1 Slide the back cover downwards, and remove it (1).
2 Remove the battery (2).
3 Insert the SIM card. Ensure the contact surface area is
facing down and the bevelled corner of the SIM card is
facing the bottom of the device (3, 4, 5).
4 Replace the battery and the back cover (6, 7).
8Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Insert a microSD card
Use only compatible microSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored
on the card.
Your phone supports microSD cards with a capacity of up
to 8 GB.
A compatible memory card may be supplied with the
device, and may already be inserted in the device. If not,
do the following:
Get started 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
1 Open the cover of the memory card slot.
2 Insert the card into the memory card slot with the
contact surface facing up, and press until it locks into
place.
3 Close the cover of the memory card slot.
Remove the microSD card
Important: Do not remove the memory card during an
operation when the card is being accessed. Doing so may
damage the memory card and the device, and corrupt data
stored on the card.
You can remove or replace the memory card during phone
operation without switching the device off, but you need
10 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
to ensure that no application is currently accessing the
memory card.
Charge the battery
Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
Get started 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.
GSM antenna
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
12 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
cause a higher power level during operation and may
reduce the battery life.
The figure shows the GSM antenna area marked in grey.
Headset
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it
can endanger your safety.
When connecting any external device or any headset, other
than those approved by Nokia for use with this device, to
the Nokia AV Connector, pay special attention to volume
levels.
Do not connect products that create an output signal as
this may cause damage to the device. Do not connect any
voltage source to the Nokia AV Connector.
Get started 13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Connect a USB data cable
Connect a compatible USB data cable to the USB connector.
14 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To modify the USB settings, select Menu > Settings >
Connectivity > USB data cable and the desired mode.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
Keys and parts
1Earpiece
2Display
3Selection keys
4Navi™ key (scroll key)
5Call key
Get started 15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
6Keypad
7Maps key
8End/Power key
9Microphone
10 Camera lens
11 Loudspeaker
12 Wrist strap eyelet
13 Headset connector/Nokia AV Connector (3.5 mm)
14 Charger connector
15 Capture key
16 Micro USB cable connector
17 Memory card slot
16 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Access codes
The security code helps to protect your device against
unauthorised use. The preset code is 12345. You can create
and change the code, and set the device to request the
code. Keep the code secret and in a safe place separate
from your device. If you forget the code and your device is
locked, your device will require service. Additional charges
may apply, and all the personal data in your device may be
deleted. For more information, contact a Nokia Care point
or your device dealer.
The PIN code supplied with the SIM card protects the card
against unauthorised use. The PIN2 code supplied with
some SIM cards is required to access certain services. If you
enter the PIN or PIN2 code incorrectly three times in
succession, you are asked for the PUK or PUK2 code. If you
do not have them, contact your service provider.
The module PIN is required to access the information in the
security module of your SIM card. The signing PIN may be
required for the digital signature. The barring password is
required when using the call barring service.
To set how your device uses the access codes and security
settings, select Menu > Settings > Security.
Switch on and off
Press and hold the power key.
Get started 17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Home screen
7
6
10
1Network signal strength
2Battery charge status
3Indicators
4Network name or the operator logo
5Clock
6Date (if the home screen mode is deactivated)
7Display
8Function of the left selection key
9Function of the scroll key
10 Function of the right selection key
18 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Keypad lock
Lock the keypad
Select Menu, and press * within 2.5 seconds.
Unlock the keypad
Select Unlock, and press * within 1.5 seconds. If requested,
enter the lock code.
Answer a call when the keypad is locked
Press the call key. When you end or reject a call, the keypad
locks automatically.
Set automatic keypad lock
Select Menu > Settings > Phone > Automatic
keyguard > On, and set the length of time, after which
the keypad locks.
When the device or keypad is locked, calls may be possible
to the official emergency number programmed into your
device.
Functions without a SIM card
Some functions of your phone may be used without
inserting a SIM card, such as Organiser functions and
games. Some functions appear dimmed in the menus and
cannot be used.
Get started 19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Applications running in background
Leaving applications running in the background increases
the demand on battery power and reduces the battery life.
Calls
Make and answer a call
Make a call
Enter the phone number, including the country and area
code if necessary, and press the call key.
Answer an incoming call
Press the call key.
Reject a call
Press the end key.
Adjust the volume
During a phone call, scroll up or down.
Loudspeaker
If available, you may select Loudsp. or Handset to use the
loudspeaker or the earpiece of the phone during a call.
20 Calls
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Warning:
Continuous exposure to high volume may damage your
hearing. Listen to music at a moderate level, and do not
hold the device near your ear when the loudspeaker is in
use.
Dialling shortcuts
Assign a phone number to a number key
Select Menu > Contacts > Speed dials, scroll to a desired
number (2-9), and select Assign. Enter the desired phone
number, or select Search and a saved contact.
Activate speed dialling
Select Menu > Settings > Call > Speed dialling > On.
Make a call using speed dialling
In the standby mode, press and hold the desired number
key.
Write text
Text modes
To enter text (for example, when writing messages) you
can use traditional or predictive text input.
Write text 21
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
When you write text, press and hold Options to switch
between traditional text input, indicated by , and
predictive text input, indicated by . Not all languages
are supported by predictive text input.
The character cases are indicated by , , and .
To change the character case, press #. To change from the
letter to number mode, indicated by , press and hold
#, and select Number mode. To change from the number
to the letter mode, press and hold #.
To set the writing language, select Options > Writing
language.
Traditional text input
Press a number key, 2-9, repeatedly until the desired
character appears. The available characters depend on the
selected writing language.
If the next letter you want is located on the same key as
the present one, wait until the cursor appears, and enter
the letter.
To access the most common punctuation marks and special
characters, press 1 repeatedly. To access the list of special
characters, press *. To insert a space, press 0.
22 Write text
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Predictive text input
Predictive text input is based on a built-in dictionary to
which you can also add new words.
1 Start writing a word, using the keys 2 to 9. Press each
key only once for one letter.
2 To confirm a word, scroll right or add a space.
•If the word is not correct, press * repeatedly, and
select the word from the list.
•If the ? character is displayed after the word, the
word you intended to write is not in the dictionary.
To add the word to the dictionary, select Spell.
Enter the word using traditional text input, and
select Save.
•To write compound words, enter the first part of
the word, and scroll right to confirm it. Write the
last part of the word, and confirm the word.
3 Start writing the next word.
Navigate the menus
The device functions are grouped into menus. Not all menu
functions or option items are described here.
In the home screen, select Menu and the desired menu and
submenu.
Navigate the menus 23
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Exit the current menu level
Select Exit or Back.
Return to the home screen
Press the end key.
Change the menu view
Select Menu > Options > Main menu view.
Messaging
Create and receive messages, such as text and multimedia,
with your device. The messaging services can only be used
if your network or service provider supports them.
Text and multimedia messages
You can create a message and optionally attach, for
example, a picture. Your phone automatically changes a
text message to a multimedia message when a file is
attached.
Text messages
Your device supports text messages beyond the limit for a
single message. Longer messages are sent as two or more
messages. Your service provider may charge accordingly.
Characters with accents, other marks, or some language
24 Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
options take more space, and limit the number of
characters that can be sent in a single message.
The total number of characters left and the number of
messages needed for sending are displayed.
To send messages, the correct message centre number
must be stored in your device. Normally, this number is set
by default through your SIM card.
To set the number manually, do the following:
1 Select Menu > Messaging > More > Msg.
settings > Text messages > Message centre.
2 Enter the name and number supplied by your service
provider.
Multimedia messages
A multimedia message can contain text, pictures, and
sound or video clips.
Only devices that have compatible features can receive and
display multimedia messages. The appearance of a
message may vary depending on the receiving device.
The wireless network may limit the size of MMS messages.
If the inserted picture exceeds this limit, the device may
make it smaller so that it can be sent by MMS.
Messaging 25
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Important: Exercise caution when opening messages.
Messages may contain malicious software or otherwise be
harmful to your device or PC.
For availability and subscription to the multimedia
messaging service (MMS), contact your service provider.
Create a message
1 Select Menu > Messaging > Create message.
2 Write your message.
To insert a special character or a smiley, select
Options > Insert symbol.
To attach an object to the message, select Options >
Insert object. The message type changes
automatically to multimedia message.
3 To add recipients, select Send to and a recipient.
To enter a phone number or mail address manually,
select Number or e-mail. Enter a phone number, or
select E-mail, and enter a mail address.
4 Select Send.
Multimedia messages are indicated with an icon at the top
of the display.
Service providers may charge differently depending on the
message type. For details, contact your service provider.
26 Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Flash messages
Flash messages are text messages that are instantly
displayed upon reception.
Select Menu > Messaging.
1 Select More > Other messages > Flash message.
2 Write your message.
3 Select Send to and a contact.
Nokia Xpress audio messages
Create and send audio messages using MMS in a convenient
way.
Select Menu > Messaging.
1 Select More > Other messages > Audio message.
The voice recorder opens.
2 To record your message, select .
3 To stop recording, select .
4 Select Send to and a contact.
Nokia Mail
Access your mail account with your device to read, write,
and send mail. This mail application is different from the
SMS mail function.
Messaging 27
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
This function is not available in all regions.
Before you can use mail, you must have an mail account
from an mail service provider. For availability and the
correct settings, contact your mail service provider. You
may receive the mail configuration settings as a
configuration message.
Mail setup wizard
The mail setup wizard opens automatically if no mail
settings are defined in the device. To add an additional
mail account, select Menu > Messaging and E-mail >
New account. Follow the instructions.
Write and send a mail
You may write your mail before connecting to the mail
service.
1 Select Menu > Messaging > More > E-mail and
Create e-mail.
2 Enter the recipient’s mail address, the subject, and the
mail message. To attach a file, select Options >
Insert.
3 If more than one mail account is defined, select the
account from which you want to send the mail.
4 Select Send.
28 Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Read a mail and reply
Important: Exercise caution when opening messages.
Messages may contain malicious software or otherwise be
harmful to your device or PC.
Select Menu > Messaging.
Download mail headers
Select your mail account.
Download a mail and its attachments
Select a mail and Open or Retrieve.
Reply to or forward a mail
Select Options > Reply or Forward.
Disconnect from your mail account
Select Options > Disconnect. The connection to the mail
account automatically ends after some time without
activity.
New mail notifications
Your device can automatically check your mail account at
set intervals, and issue a notification when new mail is
received.
Select Menu > Messaging > More > E-mail.
Messaging 29
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
1 Select E-mail settings > Edit mailboxes.
2 Select your mail account, Downloading sett., and the
following options:
Update interval — Set how often your device checks
your mail account for new mail.
Automatic retrieval — Retrieve new mail
automatically from your mail account.
3 To enable new mail notification, select E-mail
settings > New e-mail notif..
Voice messages
The voice mailbox is a network service to which you may
need to subscribe. For more information, contact your
service provider.
Call your voice mailbox
Press and hold 1.
Edit your voice mailbox number
Select Menu > Messaging > More > Voice messages
and Voice mailbox no..
Message settings
Select Menu > Messaging and More > Msg. settings.
30 Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Select from the following:
General settings — Save copies of sent messages in your
device, overwrite old messages if the message memory
becomes full, and set up other preferences related to
messages.
Text messages — Allow delivery reports, set up message
centres for SMS and SMS mail, select the type of character
support, and set up other preferences related to text
messages.
Multimedia msgs. — Allow delivery reports, set up the
appearance of multimedia messages, allow the reception
of multimedia messages and advertisements, and set up
other preferences related to multimedia messages.
Service messages — Activate service messages, and set
up preferences related to service messages.
Contacts
You can save names and phone numbers in the device
memory and on the SIM card. In the device memory, you
can save contacts with numbers and text items. Names and
numbers saved on the SIM card are indicated with .
Select Menu > Contacts > Names.
Contacts 31
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Add a contact
Select Options > Add new contact.
Add details to a contact
Ensure that the memory in use is either Phone or Phone
and SIM. Scroll to a contact, and select Details >
Options > Add detail.
Search for a contact
Select Names. Scroll through the list of contacts, or enter
the first characters of the contact's name.
Copy a contact between the device memory and SIM
card
Select Names, scroll to the contact, and select Options >
More > Copy contact. On the SIM card, you can save only
one phone number for each name.
To select the SIM card or device memory for your contacts,
to select how the names and numbers in the contacts list
are displayed, and to view the memory capacity for
contacts, select Settings and the appropriate option.
You can send and receive a person's contact information
as a business card from a compatible device that supports
the vCard standard.
32 Contacts
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Send a business card
Select a contact, Options > More > Business card, and
the sending type.
Call log
To view the information on your calls, messages, data, and
synchronisation, select Menu > Log and from the
available options.
Note: The actual invoice for calls and services from your
service provider may vary, depending on network features,
rounding off for billing, taxes, and so forth.
Settings
Profiles
Waiting for a call, but can’t let your device ring? There are
various settings groups called profiles, which you can
customise with ringing tones for different events and
environments.
Select Menu > Settings > Profiles.
Select the desired profile and from the following:
Activate — Activate the profile.
Call log 33
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Personalise — Modify the profile settings.
Timed — Set the profile to be active until a certain time.
When the time set for the profile expires, the previous
profile that was not timed becomes active.
Tones
You can change the tone settings of the selected active
profile.
Select Menu > Settings > Tones. You can find the same
settings in the Profiles menu.
Display
To view or adjust the wallpaper, font size, or other features
related to the device display, select Menu > Settings >
Display.
Date and time
Select Menu > Settings > Date and time.
Set the date and time
Select Date & time settings.
Set the date and time format
Select Date & time format.
34 Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Update the time automatically according to the
current time zone
Select Auto-update of time (network service).
Shortcuts
With personal shortcuts, you can get quick access to
frequently used phone functions.
Select Menu > Settings > My shortcuts.
Assign phone functions to the selection keys
Select Right selection key or Left selection key and a
function from the list.
Select shortcut functions for the scroll key
Select Navigation key. Scroll to the desired direction, and
select Change or Assign and a function from the list.
Synchronisation and backup
Select Menu > Settings > Sync & backup.
Select from the following:
Synchronisation — Create a backup of your personal data
to a Nokia server. Before you start backing up data, you
need to set up your My Nokia account. Select Connect, and
you are guided through the process of backing up data.
Settings 35
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Phone switch — Synchronise or copy selected data, such
as your contacts, calendar entries, notes, or messages,
between your device and another device.
Create backup — Back up selected data.
Restore backup — Restore data from a backup. To view
the details of a backup file, select Options > Details.
Data transfer — Synchronise or copy selected data
between your device and a network server (network
service).
Connectivity
Your phone has several features that allow you to connect
to other devices to transmit and receive data.
Bluetooth wireless technology
Bluetooth technology allows you to connect your device,
using radio waves, to a compatible Bluetooth device or
accessory that is within 10 metres (32 feet).
Select Menu > Settings > Connectivity > Bluetooth.
Set up a Bluetooth connection
1 Select My phone's name, and enter a name for your
device.
2 Select Bluetooth > On. indicates that Bluetooth
connectivity is active.
36 Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
3 To connect your device to an audio accessory, select
Conn. to audio acc. and the device that you want to
connect to.
4 To pair your device with any Bluetooth device in range,
select Paired devices > Add new device.
Scroll to a found device, and select Add.
Enter a passcode (up to 16 characters) on your device,
and allow the connection on the other Bluetooth
device.
If you are concerned about security, deactivate the
Bluetooth function, or set Phone visibility to Hidden.
Accept Bluetooth communication only from those you
trust.
Connect your PC to the internet
You can use Bluetooth technology to connect your
compatible PC to the internet without the PC Suite
software. Your device must be able to connect to the
internet (network service), and your PC must support
Bluetooth technology. After connecting to the network
access point (NAP) service of the device, and pairing with
your PC, your device automatically opens a packet data
connection to the internet.
This device is compliant with Bluetooth Specification 2.0 +
EDR supporting the following profiles: generic access,
Settings 37
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
hands-free, headset, object push, file transfer, dial-up
networking, serial port, SIM access, and generic object
exchange. To ensure interoperability between other
devices supporting Bluetooth technology, use Nokia
approved accessories for this model. Check with the
manufacturers of other devices to determine their
compatibility with this device.
Features using Bluetooth technology increase the demand
on battery power and reduce the battery life.
Packet data
General packet radio service (GPRS) is a network service
that allows mobile phones to send and receive data over
an internet protocol (IP)-based network.
To define how to use the service, select Menu >
Settings > Connectivity > Packet data > Packet data
conn. and from the following options:
When needed — to establish the packet data connection
when an application needs it. The connection is closed
when the application is terminated.
Always online — to automatically connect to a packet
data network when you switch the phone on
Call and phone
Select Menu > Settings > Call.
38 Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Divert incoming calls
Select Call divert (network service). For details, contact
your service provider.
Automatically redial ten times after an unsuccessful
attempt
Select Automatic redial > On.
Get a notification of incoming calls while you are in a
call
Select Call waiting > Activate (network service).
Display or hide your number to the person you are
calling
Select Send my caller ID (network service).
Select Menu > Settings > Phone.
Set the display language
Select Language settings > Phone language.
Accessories
This menu is only available if the device is or has been
connected to a compatible accessory.
Settings 39
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Select Menu > Settings > Accessories. Select an
accessory and an option, depending on the accessory.
Configuration
You can configure your phone with settings that are
required for certain services. Your service provider may
also send you these settings.
Select Menu > Settings > Configuration and from the
following options:
Default config. sett. — to view the service providers
saved in the phone and set a default service provider
Act. def. in all apps. — to activate the default
configuration settings for supported applications
Preferred access pt. — to view the saved access points
Device mgr. settings — to allow or prevent the phone
from receiving software updates. This option may not be
available, depending on your phone.
Personal settings — to manually add new personal
accounts for various services and to activate or delete
them. To add a new personal account, select Add or
Options > Add new. Select the service type, and enter the
required parameters. To activate a personal account, scroll
to it, and select Options > Activate.
40 Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Restore factory settings
To restore the phone back to factory conditions, select
Menu > Settings > Rest. fact. sett. and from the
following:
Settings only — Reset all preference settings without
deleting any personal data.
All — Reset all preference settings and delete all personal
data, such as contacts, messages, media files, and
activation keys.
Operator menu
Access a portal to services provided by your network
operator. For more information, contact your network
operator. The operator can update this menu with a service
message.
Gallery
In Gallery, you can manage images, video clips, and music
files.
View the Gallery contents
Select Menu > Gallery.
Operator menu 41
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Applications
Alarm clock
You can set an alarm to sound at a desired time.
Set the alarm
1 Select Menu > Applications > Alarm clock.
2 Set the alarm, and enter the alarm time.
3 To issue an alarm on selected days of the week, select
Repeat: > On and the days.
4 Select the alarm tone. If you select the radio as the
alarm tone, connect the headset to the device.
5 Set the length of the snooze time-out period, and
select Save.
Stop the alarm
Select Stop. If you let the alarm sound for a minute or select
Snooze, the alarm stops for the length of the snooze time-
out period, then resumes.
Calendar and to-do list
Select Menu > Calendar. The current day is framed. If
there are any notes set for the day, the day is in bold.
42 Applications
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Add a calendar note
Scroll to the date, and select Options > Make a note.
View the details of a note
Scroll to a note, and select View.
Delete all notes from the calendar
Select Options > Delete notes > All notes.
View the to-do list
Select Menu > Applications > To-do list.
The to-do list is displayed and sorted by priority. To add,
delete, or send a note, to mark the note as done, or to sort
the to-do list by deadline, select Options.
Extras
Your device may include some games and Java™
applications specially designed for your device.
Select Menu > Applications > Extras.
Open a game or application
Select Games, Collection, or Memory card, and a game or
an application.
Applications 43
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
View the amount of memory available for game and
application installations
Select Options > Memory status.
Download a game or application
Select Options > Downloads > Game downloads or
App. downloads.
Your device supports J2ME™ Java applications. Ensure that
the application is compatible with your device before
downloading it.
Important: Only install and use applications and other
software from trusted sources, such as applications that
are Symbian Signed or have passed the Java Verified™
testing.
The downloaded applications may be saved in Gallery
instead of Applications.
Camera and video
Your device supports an image capture resolution of
1200x1600 pixels.
44 Applications
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Camera mode
Use the still image function
In the home screen, press the capture key.
Zoom in or out
Scroll up or down.
Capture an image
Press the capture key.
Set the preview mode and time
Select Options > Settings > Photo preview time.
To activate the self-timer, or to capture images in a fast
sequence, select Options and the desired option.
Video mode
Use the video function
Press and hold the capture key.
Start recording a video clip
Press the capture key.
Applications 45
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Switch between camera and video mode
In camera or video mode, scroll left or right.
FM radio
The FM radio depends on an antenna other than the
wireless device antenna. A compatible headset or
accessory needs to be attached to the device for the FM
radio to function properly.
Warning:
Continuous exposure to high volume may damage your
hearing. Listen to music at a moderate level, and do not
hold the device near your ear when the loudspeaker is in
use.
Select Menu > Applications > Radio, or, in the home
screen, press and hold *.
Search for a neighbouring station
Press and hold the scroll key to the left or right.
Save a station
Tune to the desired station, and select Options > Save
station.
46 Applications
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Switch between saved stations
Scroll left or right to switch between stations, or press the
corresponding number key of the memory location of a
desired station.
Adjust the volume
Scroll up or down.
Leave the radio playing in the background
Press the end key.
Close the radio
Press and hold the end key.
Voice recorder
Select Menu > Applications > Voice recorder.
Start recording
Select the record icon.
Start recording during a call
Select Options > Record. When recording a call, hold the
phone in the normal position near to your ear. The
recording is saved in the Recordings folder in Gallery.
Applications 47
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Listen to the latest recording
Select Options > Play last recorded.
Send the last recording in a multimedia message
Select Options > Send last recorded.
Media player
Your device includes a media player for listening to songs
or other MP3 or AAC sound files.
Warning:
Continuous exposure to high volume may damage your
hearing. Listen to music at a moderate level, and do not
hold the device near your ear when the loudspeaker is in
use.
Select Menu > Applications > Media player.
Start or pause playing
Press the scroll key.
Skip to the beginning of the current song
Scroll left.
48 Applications
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Skip to the previous song
Scroll left twice.
Skip to the next song
Scroll right.
Rewind the current song
Press and hold the scroll key to the left.
Fast-forward the current song
Press and hold the scroll key to the right.
Adjust the volume
Scroll up or down.
Mute or unmute the media player
Press #.
Leave the media player playing in the background
Press the end key.
Close the media player
Press and hold the end key.
Applications 49
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Maps
With Maps, you can browse maps for different cities and
countries, search for addresses and different points of
interest, plan routes from one location to another, see your
current location on the map if you have a GPS connection,
and save locations and send them to compatible devices.
You may need to purchase a licence for a navigation service
with voice guidance. This service is not available for all
countries or regions.
About Maps
If there are maps available in your device or on an inserted
memory card, you can browse them without an internet
connection. When you browse to an area which is not
covered by the maps already downloaded in your device,
a map for the area is automatically downloaded through
the internet. You may be prompted to select an access
point to use with the internet connection.
Downloading maps may involve the transmission of large
amounts of data through your service provider's network.
Contact your service provider for information about data
transmission charges.
You can also use the Nokia Map Loader PC software to
download maps to your device. To install Nokia Map Loader
on a compatible PC, see www.nokia.com/maps.
50 Maps
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Select Menu > Applications > Maps and from the
following:
Last map — Open the map that was displayed last.
Find address — Search for a specific address.
Saved locations — Find a location you have saved on your
device.
Rec. locations — View the locations you have browsed.
Current position — View your current location, if a GPS
connection is available.
Plan route — Plan a route.
Extra services — Purchase a license for navigation.
Settings — Define the settings.
Almost all digital cartography is inaccurate and incomplete
to some extent. Never rely solely on the cartography that
you download for use in this device.
Nokia Map Loader
With the Nokia Map Loader application for PC, you can
download maps and voice guidance files from the internet.
A memory card with sufficient space must be inserted in
your device. You must use the Maps application and browse
maps at least once before using Nokia Map Loader, as Nokia
Map Loader uses the Maps history information to check
which version of the maps to download.
Maps 51
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To install Nokia Map loader, visit www.nokia.com/maps,
and follow the instructions.
Download maps with Nokia Map Loader
1 Connect your device to the computer with a
compatible USB data cable or Bluetooth connection. If
you use a data cable, select PC Suite as the USB
connection method.
2 Open Nokia Map Loader on the computer.
3 Select a continent and a country or region.
4 Select the maps or services, and download and install
them to your device.
On the Service tab of Nokia Map Loader, you can purchase
navigation and traffic information licences, travel guides,
and download maps.
About GPS
The Global Positioning System (GPS) is operated by the
government of the United States, which is solely
responsible for its accuracy and maintenance. The accuracy
of location data can be affected by adjustments to GPS
satellites made by the United States government and is
subject to change with the United States Department of
Defense civil GPS policy and the Federal Radionavigation
Plan. Accuracy can also be affected by poor satellite
geometry. Availability and quality of GPS signals may be
52 Maps
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
affected by your location, buildings, natural obstacles, and
weather conditions. GPS signals may not be available
inside buildings or underground and may be impaired by
materials such as concrete and metal.
GPS should not be used for precise location measurement,
and you should never rely solely on location data from the
GPS receiver and cellular radio networks for positioning or
navigation.
The trip meter has limited accuracy, and rounding errors
may occur. Accuracy can also be affected by availability and
quality of GPS signals.
GPS receiver
Your device has an internal GPS receiver. For the best signal
from the satellites, place your device in a position with an
unobstructed view to the sky.
You can use GPS to support the Maps application. Find out
your location or measure distances.
Maps 53
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Navigate to your destination
You can upgrade Maps to a full navigation system to be
used by car and on foot. You need a regional licence for the
full navigation system. The car navigation is fully voice-
guided. Pedestrian navigation is limited to a speed of 30
km/h (18.6 miles/h) and provides no voice guidance. The
navigation service is not available for all countries and
regions. For details, see your local Nokia website.
Purchase a licence for navigation
Select Extra services. The licence is region-specific and can
be used only in the selected area.
Navigate to the destination
1 Select Plan route, and create a route.
2 Select Options > Show route > Options > Start
navigation.
54 Maps
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
3 Accept the displayed disclaimer.
4 Select the language for voice guidance, if prompted.
If you deviate from the set route, the device automatically
plans a new route.
Repeat the voice guidance
Select Repeat.
Silence the voice guidance
Select Options > Mute audio.
Stop navigating
Select Stop.
Navigate on foot
Select Settings > Routing settings > Route selection >
On foot. This optimises the routes you create for
navigation on foot.
Web or Internet
You can access various internet services with your phone
browser. The appearance of the web pages may vary due
to screen size. You may not be able to see all the details on
the web pages.
Web or Internet 55
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Depending on your phone, the web browsing function may
be displayed as Web or Internet in the menu, hereafter
referred to as Web.
Important: Use only services that you trust and that offer
adequate security and protection against harmful
software.
For the availability of these services, pricing, and
instructions, contact your service provider.
You may receive the configuration settings required for
browsing as a configuration message from your service
provider.
Connect to a web service
Select Menu > Internet > Home. Or, in the standby mode,
press and hold 0.
After you make a connection to the service, you can start
browsing its pages. The function of the phone keys may
vary in different services. Follow the text guides on the
phone display. For more information, contact your service
provider.
56 Web or Internet
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
SIM services
Your SIM card may provide additional services. You can
access this menu only if it is supported by your SIM card.
The name and contents of the menu depend on the
available services.
Green tips
Here are tips on how you can contribute to protecting the
environment.
Save energy
When you have fully charged the battery and disconnected
the charger from the device, unplug the charger from the
wall outlet.
You do not need to charge your battery so often if you do
the following:
•Close and disable applications, services, and
connections when not in use.
SIM services 57
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•Decrease the brightness of the screen.
•Set the device to enter the power saver mode after the
minimum period of inactivity, if available in your
device.
•Disable unnecessary sounds, such as keypad and
ringing tones.
Recycle
Most of the materials in a Nokia phone are recyclable. Check
how to recycle your Nokia products at www.nokia.com/
werecycle, or with a mobile device, www.nokia.mobi/
werecycle.
Recycle packaging and user guides at your local recycling
scheme.
Learn more
For more information on the environmental attributes of
your device, see www.nokia.com/ecodeclaration.
58 Green tips
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
General information
About your device
The wireless device described in this
guide is approved for use on the (E)GSM
850, 900, 1800, and 1900 MHz
networks. Contact your service provider
for more information about networks.
Your device may have preinstalled
bookmarks and links for third-party
internet sites and may allow you to
access third-party sites. These are not
affiliated with Nokia, and Nokia does
not endorse or assume liability for them.
If you access such sites, take precautions
for security or content.
Warning:
To use any features in this device, other
than the alarm clock, the device must be
switched on. Do not switch the device on
when wireless device use may cause
interference or danger.
When using this device, obey all laws
and respect local customs, privacy and
legitimate rights of others, including
copyrights. Copyright protection may
prevent some images, music, and other
content from being copied, modified, or
transferred.
Make back-up copies or keep a written
record of all important information
stored in your device.
When connecting to any other device,
read its user guide for detailed safety
instructions. Do not connect
incompatible products.
The images in this guide may differ from
your device display.
Refer to the user guide for other
important information about your
device.
Network services
To use the device you must have service
from a wireless service provider. Some
features are not available on all
networks; other features may require
that you make specific arrangements
with your service provider to use them.
Network services involve transmission
of data. Check with your service provider
for details about fees in your home
network and when roaming on other
networks. Your service provider can
explain what charges will apply. Some
networks may have limitations that
affect how you can use some features of
this device requiring network support
such as support for specific technologies
like WAP 2.0 protocols (HTTP and SSL)
General information 59
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
that run on TCP/IP protocols and
language-dependent characters.
Your service provider may have
requested that certain features be
disabled or not activated in your device.
If so, these features will not appear on
your device menu. Your device may also
have customized items such as menu
names, menu order, and icons.
Shared memory
The following features in this device
may share memory: multimedia
messaging (MMS), e-mail application,
instant messaging. Use of one or more
of these features may reduce the
memory available for the remaining
features. If your device displays a
message that the memory is full, delete
some of the information stored in the
shared memory.
Digital rights management
Content owners may use different types
of digital rights management (DRM)
technologies to protect their
intellectual property, including
copyrights. This device uses various
types of DRM software to access DRM-
protected content. With this device you
can access content protected with
WMDRM 10, OMA DRM 1.0, OMA DRM 1.0
forward lock, and OMA DRM 2.0. If certain
DRM software fails to protect the
content, content owners may ask that
such DRM software's ability to access
new DRM-protected content be revoked.
Revocation may also prevent renewal of
such DRM-protected content already in
your device. Revocation of such DRM
software does not affect the use of
content protected with other types of
DRM or the use of non-DRM-protected
content.
Accessories
Warning:
Use only batteries, chargers, and
accessories approved by Nokia for use
with this particular model. The use of
any other types may invalidate any
approval or warranty, and may be
dangerous. In particular, use of
unapproved chargers or batteries may
present a risk of fire, explosion, leakage,
or other hazard.
For availability of approved accessories,
please check with your dealer. When
you disconnect the power cord of any
accessory, grasp and pull the plug, not
the cord.
60 Accessories
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Battery
Battery and charger information
Your device is powered by a
rechargeable battery. The battery
intended for use with this device is
BL-5C. Nokia may make additional
battery models available for this device.
This device is intended for use when
supplied with power from the following
chargers: AC-3. The exact charger model
number may vary depending on the type
of plug. The plug variant is identified by
one of the following: E, EB, X, AR, U, A, C,
K, or UB.
The battery can be charged and
discharged hundreds of times, but it will
eventually wear out. When the talk and
standby times are noticeably shorter
than normal, replace the battery. Use
only Nokia approved batteries, and
recharge your battery only with Nokia
approved chargers designated for this
device.
If a battery is being used for the first
time or if the battery has not been used
for a prolonged period, it may be
necessary to connect the charger, then
disconnect and reconnect it to begin
charging the battery. If the battery is
completely discharged, it may take
several minutes before the charging
indicator appears on the display or
before any calls can be made.
Safe removal. Always switch the device
off and disconnect the charger before
removing the battery.
Proper charging. Unplug the charger
from the electrical plug and the device
when not in use. Do not leave a fully
charged battery connected to a charger,
since overcharging may shorten its
lifetime. If left unused, a fully charged
battery will lose its charge over time.
Avoid extreme temperatures. Always try
to keep the battery between 15°C and
25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and
lifetime of the battery. A device with a
hot or cold battery may not work
temporarily. Battery performance is
particularly limited in temperatures
well below freezing.
Do not short-circuit. Accidental short-
circuiting can occur when a metallic
object such as a coin, clip, or pen causes
direct connection of the positive (+) and
negative (-) terminals of the battery.
(These look like metal strips on the
battery.) This might happen, for
example, when you carry a spare battery
in your pocket or purse. Short-circuiting
the terminals may damage the battery
or the connecting object.
Battery 61
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Disposal. Do not dispose of batteries in
a fire as they may explode. Dispose of
batteries according to local regulations.
Please recycle when possible. Do not
dispose as household waste.
Leak. Do not dismantle, cut, open, crush,
bend, puncture, or shred cells or
batteries. In the event of a battery leak,
prevent battery liquid contact with skin
or eyes. If this happens, flush the
affected areas immediately with water,
or seek medical help.
Damage. Do not modify, remanufacture,
attempt to insert foreign objects into
the battery, or immerse or expose it to
water or other liquids. Batteries may
explode if damaged.
Correct use. Use the battery only for its
intended purpose. Improper battery use
may result in a fire, explosion, or other
hazard. If the device or battery is
dropped, especially on a hard surface,
and you believe the battery has been
damaged, take it to a service centre for
inspection before continuing to use it.
Never use any charger or battery that is
damaged. Keep your battery out of the
reach of small children.
Nokia battery authentication
guidelines
Always use original Nokia batteries for
your safety. To check that you are
getting an original Nokia battery,
purchase it from a Nokia authorised
service centre or dealer, and inspect the
hologram label using the following
steps:
Authenticate hologram
1 When you look at the hologram on
the label, you should see the
Nokia connecting hands symbol
from one angle and the Nokia
Original Enhancements logo when
looking from another angle.
62 Battery
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2 When you angle the hologram
left, right, down and up, you
should see 1, 2, 3 and 4 dots on
each side respectively.
Successful completion of the steps is not
a total assurance of the authenticity of
the battery. If you cannot confirm
authenticity or if you have any reason to
believe that your Nokia battery with the
hologram on the label is not an
authentic Nokia battery, you should
refrain from using it, and take it to the
nearest Nokia authorised service centre
or dealer for assistance.
For additional information, refer to the
warranty and reference leaflet included
with your Nokia device.
Taking care of your device
Your device is a product of superior
design and craftsmanship and should be
treated with care. The following
suggestions will help you protect your
warranty coverage.
•Keep the device dry. Precipitation,
humidity, and all types of liquids
or moisture can contain minerals
that will corrode electronic
circuits. If your device does get
wet, remove the battery, and
allow the device to dry completely
before replacing it.
•Do not use or store the device in
dusty, dirty areas. Its moving
parts and electronic components
can be damaged.
•Do not store the device in high or
cold temperature. High
temperatures can shorten the life
of electronic devices, damage
batteries, and warp or melt
certain plastics. When the device
warms to its normal temperature
from a cold temperature,
moisture can form inside the
device and damage electronic
circuit boards.
•Do not attempt to open the device
other than as instructed in this
guide.
•Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
Taking care of your device 63
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•Do not use harsh chemicals,
cleaning solvents, or strong
detergents to clean the device.
Only use a soft, clean, dry cloth to
clean the surface of the device.
•Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
•Use only the supplied or an
approved replacement antenna.
Unauthorised antennas,
modifications, or attachments
could damage the device and may
violate regulations governing
radio devices.
•Use chargers indoors.
•Backup all data you want to keep,
such as contacts and calendar
notes.
•To reset the device from time to
time for optimum performance,
power off the device and remove
the battery.
These suggestions apply equally to your
device, battery, charger, or any
accessory.
Recycle
Always return your used electronic
products, batteries, and packaging
materials to dedicated collection points.
This way you help prevent uncontrolled
waste disposal and promote the
recycling of materials. Check product
environmental information and how to
recycle your Nokia products at
www.nokia.com/werecycle, or
nokia.mobi/werecycle.
Additional safety information
The surface of this device is nickel-free.
Small children
Your device and its accessories are not
toys. They may contain small parts. Keep
them out of the reach of small children.
Operating environment
This device meets RF exposure
guidelines in the normal use position at
the ear or at least 1.5 centimetres (5/8
inch) away from the body. Any carry
case, belt clip, or holder for body-worn
operation should not contain metal and
should position the device the above-
stated distance from your body.
To send data files or messages requires
a quality connection to the network.
Data files or messages may be delayed
until such a connection is available.
Follow the separation distance
instructions until the transmission is
completed.
Parts of the device are magnetic.
Metallic materials may be attracted to
64 Additional safety information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
the device. Do not place credit cards or
other magnetic storage media near the
device, because information stored on
them may be erased.
Medical devices
Operation of radio transmitting
equipment, including wireless phones,
may interfere with the function of
inadequately protected medical
devices. Consult a physician or the
manufacturer of the medical device to
determine whether they are adequately
shielded from external RF energy.
Switch off your device when regulations
posted instruct you to do so. Hospitals
or health care facilities may use
equipment sensitive to external RF
energy.
Implanted medical devices
Manufacturers of medical devices
recommend a minimum separation of
15.3 centimetres (6 inches) between a
wireless device and an implanted
medical device, such as a pacemaker or
implanted cardioverter defibrillator, to
avoid potential interference with the
medical device. Persons who have such
devices should:
•Always keep the wireless device
more than 15.3 centimetres (6
inches) from the medical device.
•Not carry the wireless device in a
breast pocket.
•Hold the wireless device to the ear
opposite the medical device.
•Turn the wireless device off if
there is any reason to suspect that
interference is taking place.
•Follow the manufacturer
directions for the implanted
medical device.
If you have any questions about using
your wireless device with an implanted
medical device, consult your health care
provider.
Hearing aids
Some digital wireless devices may
interfere with some hearing aids.
Vehicles
RF signals may affect improperly
installed or inadequately shielded
electronic systems in motor vehicles
such as electronic fuel injection,
electronic antilock braking, electronic
speed control, and air bag systems. For
more information, check with the
manufacturer of your vehicle or its
equipment.
Only qualified personnel should service
the device or install the device in a
vehicle. Faulty installation or service
Additional safety information 65
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
may be dangerous and may invalidate
your warranty. Check regularly that all
wireless device equipment in your
vehicle is mounted and operating
properly. Do not store or carry
flammable liquids, gases, or explosive
materials in the same compartment as
the device, its parts, or accessories.
Remember that air bags inflate with
great force. Do not place your device or
accessories in the air bag deployment
area.
Switch off your device before boarding
an aircraft. The use of wireless
teledevices in an aircraft may be
dangerous to the operation of the
aircraft and may be illegal.
Potentially explosive environments
Switch off your device in any area with
a potentially explosive atmosphere.
Obey all posted instructions. Sparks in
such areas could cause an explosion or
fire resulting in bodily injury or death.
Switch off the device at refuelling points
such as near gas pumps at service
stations. Observe restrictions in fuel
depots, storage, and distribution areas;
chemical plants; or where blasting
operations are in progress. Areas with a
potentially explosive atmosphere are
often, but not always, clearly marked.
They include areas where you would be
advised to turn off your vehicle engine,
below deck on boats, chemical transfer
or storage facilities and where the air
contains chemicals or particles such as
grain, dust, or metal powders. You
should check with the manufacturers of
vehicles using liquefied petroleum gas
(such as propane or butane) to
determine if this device can be safely
used in their vicinity.
Emergency calls
Important: This device operates using
radio signals, wireless networks,
landline networks, and user-
programmed functions. If your device
supports voice calls over the internet
(internet calls), activate both the
internet calls and the cellular phone. The
device may attempt to make emergency
calls over both the cellular networks and
through your internet call provider if
both are activated. Connections in all
conditions cannot be guaranteed. You
should never rely solely on any wireless
device for essential communications
like medical emergencies.
To make an emergency call:
1 If the device is not on, switch it on.
Check for adequate signal
strength. Depending on your
device, you may also need to
complete the following:
66 Additional safety information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•Insert a SIM card if your
device uses one.
•Remove certain call
restrictions you have
activated in your device.
•Change your profile from
Offline or Flight profile to an
active profile.
2 Press the end key as many times
as needed to clear the display and
ready the device for calls.
3 Enter the official emergency
number for your present location.
Emergency numbers vary by
location.
4 Press the call key.
When making an emergency call, give all
the necessary information as accurately
as possible. Your wireless device may be
the only means of communication at the
scene of an accident. Do not end the call
until given permission to do so.
Certification information (SAR)
This mobile device meets guidelines
for exposure to radio waves.
Your mobile device is a radio transmitter
and receiver. It is designed not to exceed
the limits for exposure to radio waves
recommended by international
guidelines. These guidelines were
developed by the independent scientific
organisation ICNIRP and include safety
margins designed to assure the
protection of all persons, regardless of
age and health.
The exposure guidelines for mobile
devices employ a unit of measurement
known as the Specific Absorption Rate
or SAR. The SAR limit stated in the ICNIRP
guidelines is 2.0 watts/kilogram (W/kg)
averaged over 10 grams of tissue. Tests
for SAR are conducted using standard
operating positions with the device
transmitting at its highest certified
power level in all tested frequency
bands. The actual SAR level of an
operating device can be below the
maximum value because the device is
designed to use only the power required
to reach the network. That amount
changes depending on a number of
factors such as how close you are to a
network base station.
The highest SAR value under the ICNIRP
guidelines for use of the device at the
ear is 0.73 W/kg.
Use of device accessories may result in
different SAR values. SAR values may
vary depending on national reporting
and testing requirements and the
network band. Additional SAR
information may be provided under
Additional safety information 67
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
product information at
www.nokia.com.
Your mobile device is also designed to
meet the requirements for exposure to
radio waves established by the Federal
Communications Commission (USA) and
Industry Canada. These requirements
set a SAR limit of 1.6 W/kg averaged over
one gram of tissue. The highest SAR
value reported under this standard
during product certification for use at
the ear is 0.97 W/kg and when properly
worn on the body is 0.79 W/kg.
68 Additional safety information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Index
A
access codes 17
accessories 39
applications 42
audio messages 27
B
backing up data 35
battery 8
— charging 11
battery charge level
indicator 18
Bluetooth 36
browser 55
business cards 31
C
cable connection 14
calendar 42
call log 33
calls 20
camera 44
configuration 40
contacts 31
D
date and time 34
display settings 34
E
e-mail 27
extras 43
F
factory settings 41
flash messages 27
G
Gallery 41
games 43
GPS (global positioning
system) 52, 53
H
headset 13
I
image mode 44
indicators 18
Index 69
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
internet 55
K
keyguard 19
keypad lock 19
keys 15
M
mail 27, 28, 29
Maps 50
maps 50, 51, 54
media player 48
memory card 9
menus 23
message centre
number 24
message settings 30
messages 26
microSD card 9
N
Nokia Map Loader 51
Nokia support
information 7
number mode 21
O
offline mode 19
operator menu 41
P
passwords 17
PIN code 17
predictive text input 23
profiles 33
S
security code 17
settings 33
— configuration 40
— phone 38
settings, display 34
shortcuts 35
signal strength
indicator 18
SIM card 8, 19
speed dialling 21
support resources 7
synchronisation 35
T
text messages 24
70 Index
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
DECLARATION OF CONFORMITY
0434
Hereby, NOKIA CORPORATION declares
that this RM-586 product is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC. A copy
of the Declaration of Conformity can be
found at www.nokia.com/phones/
declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and
Navi are trademarks or registered
trademarks of Nokia Corporation. Nokia
tune is a sound mark of Nokia
Corporation. Other product and
company names mentioned herein may
be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in
this document in any form without the
prior written permission of Nokia is
prohibited. Nokia operates a policy of
continuous development. Nokia
reserves the right to make changes and
improvements to any of the products
described in this document without
prior notice.
Includes RSA BSAFE cryptographic or
security protocol software from RSA
Security.
Java and all Java-based marks are
trademarks or registered trademarks of
Sun Microsystems, Inc.
This product is licensed under the
MPEG-4 Visual Patent Portfolio License
(i) for personal and noncommercial use
in connection with information which
has been encoded in compliance with
the MPEG-4 Visual Standard by a
consumer engaged in a personal and
noncommercial activity and (ii) for use
in connection with MPEG-4 video
provided by a licensed video provider.
No license is granted or shall be implied
for any other use. Additional
information, including that related to
promotional, internal, and commercial
uses, may be obtained from MPEG LA,
LLC. See http://www.mpegla.com.
72
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, UNDER NO
CIRCUMSTANCES SHALL NOKIA OR ANY OF
ITS LICENSORS BE RESPONSIBLE FOR ANY
LOSS OF DATA OR INCOME OR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR
INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE
PROVIDED "AS IS". EXCEPT AS REQUIRED
BY APPLICABLE LAW, NO WARRANTIES OF
ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY
OR CONTENTS OF THIS DOCUMENT. NOKIA
RESERVES THE RIGHT TO REVISE THIS
DOCUMENT OR WITHDRAW IT AT ANY TIME
WITHOUT PRIOR NOTICE.
The availability of some features may
vary by region. Please contact your
operator for more details.
The availability of particular products
and applications and services for these
products may vary by region. Please
check with your Nokia dealer for details
and availability of language options.
This device may contain commodities,
technology or software subject to
export laws and regulations from the US
and other countries. Diversion contrary
to law is prohibited.
The third-party applications provided
with your device may have been created
and may be owned by persons or
entities not affiliated with or related to
Nokia. Nokia does not own the
copyrights or intellectual property
rights to the third-party applications. As
such, Nokia does not take any
responsibility for end-user support,
functionality of the applications, or the
information in the applications or these
materials. Nokia does not provide any
warranty for the third-party
applications.
BY USING THE APPLICATIONS YOU
ACKNOWLEDGE THAT THE APPLICATIONS
ARE PROVIDED AS IS WITHOUT WARRANTY
OF ANY KIND, EXPRESS OR IMPLIED, TO THE
MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW. YOU FURTHER
ACKNOWLEDGE THAT NEITHER NOKIA NOR
ITS AFFILIATES MAKE ANY
REPRESENTATIONS OR WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO WARRANTIES OF TITLE,
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, OR THAT THE
APPLICATIONS WILL NOT INFRINGE ANY
THIRD-PARTY PATENTS, COPYRIGHTS,
TRADEMARKS, OR OTHER RIGHTS.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio
interference (for example, when using a
73
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
telephone in close proximity to
receiving equipment). The FCC or
Industry Canada can require you to stop
using your telephone if such
interference cannot be eliminated. If
you require assistance, contact your
local service facility. This device
complies with part 15 of the FCC rules.
Operation is subject to the following
two conditions: (1) This device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that
may cause undesired operation. Any
changes or modifications not expressly
approved by Nokia could void the user's
authority to operate this equipment.
xxxxxxx/Issue 1 EN
74
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
