Nokia N8–00 User Guide
7777777
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Contents
Safety 3
About this user guide 4
Use the in-device user guide 4
Get started 4
Keys and parts 4
Volume and loudspeaker control 5
Lock or unlock the keys and screen 5
Insert or remove the SIM card 6
Insert or remove the memory card 7
Charging 8
If your device stops responding 9
Switch the device on 9
Nokia account and Ovi services 9
Copy contacts or pictures from your old
device 9
Device set-up 10
Install Ovi Suite on your PC 10
Touch screen actions 11
Interactive home screen
elements 12
Call a phone number 12
Save phone numbers and mail
addresses 13
Send a message 13
Personalisation 13
Personalise your tones 13
Change your theme 13
Switch between home screens 14
Personalise the home screen 14
Add items to the home screen 14
Social networks 14
About Communities 14
Take a picture 15
Upload a picture or video to a
service 15
View your pictures and videos on a
TV 16
Connect a USB mass storage
device 16
Back up files 16
Find more help 17
Support 17
Keep your device software and
applications up to date 17
Accessibility solutions 18
Access codes 18
Green tips 19
Save energy 19
Recycle 19
Product and safety information 19
2 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when
mobile phone use is not
allowed or when it may cause
interference or danger, for
example, in aircraft, near
medical equipment, fuel,
chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep
your hands free to operate the
vehicle while driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
BATTERIES AND OTHER ACCESSORIES
Use only chargers and other
accessories approved by Nokia
for use with this device. Do not
connect incompatible
products.
KEEP YOUR DEVICE DRY
Your device is not water-
resistant. Keep it dry.
GLASS PARTS
The front cover of the device is
made of glass. This glass can
break if the device is dropped
on a hard surface or receives a
substantial impact. If the glass
breaks, do not touch the glass
parts of the device or attempt
to remove the broken glass
from the device. Stop using the
device until the glass is
replaced by qualified service
personnel.
PROTECT YOUR HEARING
Listen to a headset at a
moderate level, and do not hold
the device near your ear when
the loudspeaker is in use.
www.nokia.com/support 3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
About this user guide
This short user guide helps you get started
with your device. With a short printed user
guide, Nokia helps save energy and paper.
Your device also has a complete user
guide, so that you can get more support
when you need it. To open the complete
user guide, select Menu >
Applications > User guide in your
device.
For even more support information, go to
www.nokia.com/support, or using a
mobile device, www.nokia.mobi/
support.
Use the in-device user guide
Select Menu > Applications > User
guide.
Open the user guide from an
application
Select Options > User guide. This is not
available for every application.
Search the user guide
When the user guide is open, select
Options > Search, and enter a letter or a
word in the search field.
Switch between the user guide and an
application
Select Options > Open applications and
the application.
Links to related topics may be at the end
of instructions. indicates a link to a
related topic, and indicates a link to a
web page.
Get started
Keys and parts
Top
1Nokia AV connector (3.5 mm)
2HDMI™ connector
3Power key
Front
1Earpiece
2Menu key
3Microphone
4Secondary camera lens
4 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Back
1Camera flash
2Camera lens
3Loudspeaker
4Microphone
Sides
1Memory card slot
2SIM card slot
3Charging indicator light
4Micro USB connector
5Volume/Zoom key
6Lock switch
7Camera key
Bottom
1Charging connector
2Wrist strap
Touch screen
To control your device, lightly touch the
screen with your fingertips. The screen
does not respond when you use your
fingernails.
If your fingertips are cold, the screen may
not respond to your touch.
To avoid scratching the touch screen,
never use a pen, pencil, or other sharp
object to write on the touch screen.
Volume and loudspeaker control
Adjust the volume of a phone call,
song, or video
Use the volume keys.
The built-in loudspeaker allows you to
speak and listen from a short distance
without having to hold the device to your
ear.
Activate or deactivate the loudspeaker
during a call
Select Loudspeaker or Activate
handset.
Lock or unlock the keys and screen
You can lock the keys and screen to avoid
accidental calls or keypresses.
Slide the lock switch.
www.nokia.com/support 5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Set the keys and screen to lock
automatically
1 Select Menu > Settings and
Phone > Display > Screen/keylock
time-out.
2 Define the length of time after which
the touch screen and keys are locked
automatically.
Insert or remove the SIM card
Do not attach any stickers to your SIM card.
1Memory card slot cover
2SIM card slot cover
Insert the SIM card
1 Use your fingernail to open the cover
of the memory card slot.
2 Open the cover of the SIM card slot.
3 Insert the SIM card. Push the card in,
until you hear a click.
Make sure the contact area of the card
is facing down.
6 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Remove the SIM card
1 Use your fingernail to open the cover
of the memory card slot.
2 Open the cover of the SIM card slot,
and push the card in, until you hear a
click.
3 Pull the card out.
Insert or remove the memory card
Use only compatible memory cards
approved by Nokia for use with this
device. Incompatible cards may damage
the card and the device and corrupt data
stored on the card.
Memory cards are sold separately.
Do not attach any stickers to your memory
card.
Insert the memory card
1 Use your fingernail to open the cover
of the memory card slot.
2 Make sure the contact area of the
memory card is facing down.
Push the card in, until you hear a click.
Remove the memory card
1 Use your fingernail to open the cover
of the memory card slot.
2 Push the card in, until you hear a click.
3 Pull the card out.
www.nokia.com/support 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Charging
About the battery
Your device has an internal,
nonremovable, rechargeable battery. Use
only Nokia approved chargers designated
for this device. You can also use a
compatible USB data cable to charge your
device.
Do not attempt to remove the battery
from the device. Take the device to the
nearest authorised service facility for
replacement of the battery.
Authorised retail points may also offer a
battery replacement service.
When your device is low on power, it goes
into power save mode. To deactivate
power save mode, press , and select
Deactivate power saving. When power
save mode is activated, you may not be
able to modify the settings of certain
applications.
Charge the battery
Your battery has been partially charged at
the factory, but you may need to recharge
it before you can switch on your device for
the first time.
If the device indicates a low charge, do the
following:
1
2
You do not need to charge the battery for
a specific length of time, and you can use
the device while it is charging.
If the battery is completely discharged, it
may take several minutes before the
charging indicator appears on the display
or before any calls can be made.
If the battery has not been used for a long
time, to begin charging, you may need to
connect the charger, then disconnect and
reconnect it.
Tip: You can also use a compatible USB
charger to charge your battery.
8 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Charge the battery with a USB data
cable
Battery low, but you don't have a charger
with you? To charge the battery, you can
use a USB data cable to connect your
device to a compatible device, such as a
PC.
When the battery is charging, the
charging indicator light next to the USB
connector is lit. When the battery charge
is low, the charging indicator light flashes.
It may take a while for charging to start.
Charging with the USB data cable is slower
than charging with the charger. Charging
with the USB data cable may not work if
you use a non-powered USB hub.
You can transfer data while charging.
If your device stops responding
If your device stops responding, to reset
your device, press and hold for about
8 seconds. When the device switches off,
it vibrates three times. To switch your
device on again, press .
No content, such as contacts or messages,
is deleted.
Switch the device on
Press and hold .
Switch the device off
Press and hold .
Nokia account and Ovi services
When you switch on your device for the
first time, you can create a Nokia account,
so you can access Ovi services.
With Ovi services, you can, for example:
•Download mobile games,
applications, videos, pictures,
themes, and ringing tones from Ovi
Store
•Synchronise your favourite locations
from your device to the Ovi Maps
internet service
To learn more about Ovi services, go to
www.ovi.com.
Copy contacts or pictures from your old
device
Use the Phone switch application to copy,
for example, contacts, calendar entries,
and pictures from your previous
compatible Nokia device, free of charge.
Select Menu > Applications > Tools >
Phone setup and Data transfer.
www.nokia.com/support 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
If your old Nokia device does not have the
Phone switch application, your new
device sends it in a message. Open the
message in the old device, and follow the
instructions.
1 Select the device you want to connect
to, and pair the devices. Bluetooth
needs to be activated.
2 If the other device requires a
passcode, enter the passcode. The
passcode, which you can define
yourself, must be entered in both
devices. The passcode in some devices
is fixed. For details, see the user guide
of the device.
The passcode is valid only for the
current connection.
3 Select the content and OK.
Device set-up
To define some basic settings for your
device, select the Phone set-up widget
which is on one of your home screens.
To switch between home screens, swipe
left or right. With the Phone set-up
widget, you can do the following:
•Copy contacts, pictures, and other
content from your previous Nokia
device
•Personalise your device, by changing
the ringing tone and visual theme
•Set up mail
•Update your device software
To define the settings later, you can also
select Menu > Applications > Tools >
Phone setup.
Install Ovi Suite on your PC
With the Nokia Ovi Suite PC application,
you can manage content on your device,
and keep it in sync with your computer.
You can download the latest version of Ovi
Suite in www.ovi.com/suite. To install Ovi
Suite from your device, do the following:
1 Use a compatible USB data cable to
connect your device to your
computer. If you are using Windows
XP or Windows Vista, change the USB
mode of your device toMass storage.
Your device's mass memory and
memory card appear as removable
disks on your PC.
2 On your computer, select Install
Nokia Ovi Suite.
10 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To open the installation file manually,
select Open folder to view files, and
double-click
Install_Nokia_Ovi_Suite.exe.
3 Follow the instructions.
4 When you finish the installation
procedure, change the USB mode of
your device to Media transfer.
To learn more about Ovi Suite, go to
www.ovi.com.
Touch screen actions
To interact with the user interface, tap or
tap and hold the touch screen.
Open an application or other screen
element
Tap the application or element.
View item-specific options
Tap and hold the item. A pop-up menu
with available options opens. For
example, to send an image or delete an
alarm, tap and hold the image or alarm,
and from the pop-up menu, select the
appropriate option.
If you tap and hold the home screen,
editing mode is activated.
Drag an item
Tap and hold the item, and slide your
finger across the screen. The item follows
your finger.
You can drag items in the home screen or
the main menu, when you have activated
editing mode.
Swipe
Place a finger on the screen, and steadily
slide your finger in the desired direction.
www.nokia.com/support 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
For example, when you are viewing a
picture, to view the next picture, swipe
left.
Scroll in a list or menu
If the list has a scroll bar, drag the scroll
bar slider. Or place your finger on the
screen, slide it quickly up or down the
screen, then lift your finger. The content
of the screen continues scrolling with the
speed and direction it had at the moment
of release. To select an item from a
scrolling list and to stop the movement,
tap the item.
Zoom in
Place two fingers on an item, such as a
picture or web page, and slide your fingers
apart.
Zoom out
Place two fingers on the item, and slide
your fingers together.
Interactive home screen elements
The home screen elements are interactive.
For example, you can change the date and
time, set alarms, write calendar entries, or
edit the profiles directly in the home
screen.
Open the clock application
Select the time indicator (1).
Change or edit profiles
Select the profile name (2).
Open calendar
Select the date (3).
View available WLANs or missed
events
Select the top right corner (4).
Change the connectivity settings
Select the top right corner (4) and .
Call a phone number
1 In the home screen, select Call to open
the dialler, and enter the phone
number.
To enter the + character, used for
international calls, select * twice. The
+ character as a replacement for the
12 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
international access code may not
work in all regions. In this case, enter
the international access code directly.
2 To make the call, select .
3 To end the call, select .
Save phone numbers and mail
addresses
You can save your friends' phone
numbers, mail addresses, and other
information to your contacts list.
Select Menu > Contacts.
Add a contact to the contacts list
1 Select Options > New contact.
2 Select a field, and enter the details. To
close the text input, select .
Edit contact information
1 Select a contact.
2 Open the contact card tab .
3 Select a contact detail.
Add details about a contact
Select a contact and Options > Edit >
Options > Add detail.
Send a message
With text and multimedia messages, you
can quickly contact your friends and
family. In a multimedia message, you can
attach pictures, videos, and sound clips
that you want to share.
Select Menu > Messaging.
1 Select New message.
2 To select recipients from the contacts
list, select the To title. To enter the
recipient’s phone number manually,
enter the number in the To field.
3 To add an attachment, select .
4 Select .
Sending a message with an attachment
may be more expensive than sending a
normal text message. For more
information, contact your service
provider.
If the item you inserted in a multimedia
message is too large for the network, the
device may automatically reduce the size.
Only compatible devices can receive and
display multimedia messages. Messages
may look different in different devices.
Personalisation
Personalise your tones
You can personalise the ringing, key, and
warning tones for each profile.
1 In the home screen, select the profile.
2 Select Edit active profile.
3 Select Ringing tone or Key tones.
Tip: Download ringing tones from Ovi
Store. For details, go to www.ovi.com.
Change your theme
With themes, you can change the
colours and look of your display.
Select Menu > Settings > Themes.
Select General and a theme.
Some themes include background
animation effects. To save battery power,
select General > Options > Theme
effects.
www.nokia.com/support 13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Tip: Download themes from Ovi Store. To
learn more about Ovi Store, go to
www.ovi.com.
Switch between home screens
You can have more than one home screen.
To switch to another home screen, swipe
left or right.
indicates which home screen you
are in.
Personalise the home screen
You can change wallpaper, and rearrange
home screen items.
Rearrange items in the home screen
1 Tap and hold the home screen.
2 Drag and drop items to a new
location.
Change the wallpaper
1 Tap and hold the home screen.
2 Select Options > Change
wallpaper.
3 Select the desired picture.
Tip: Download more background images
from Ovi Store. For details, go to
www.ovi.com.
Add items to the home screen
You can create shortcuts to your most
used features and add mini-applications
(widgets) that display helpful
information.
Add a shortcut to the home screen
You can add shortcuts to applications,
web bookmarks, or actions, such as
writing a message.
1 Tap and hold the home screen.
2 Select the shortcut widget and
Settings.
3 Go to the shortcut you want to define,
and select #Application or
#Bookmark and the desired item.
Add a widget to the home screen
1 Tap and hold the home screen.
2 Select and the desired widget from
the list.
Tip: To download more widgets, select
Store.
Social networks
About Communities
Select Menu > Applications >
Communities and a service, and sign in.
With the Communities application, you
can enhance your social networking
experience. When signed into a social
networking service with the Communities
application, you can do the following:
•Instantly share pictures you take with
the camera
•Call or send messages to your online
friends
•Share your location with Ovi Maps
14 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•Add events from the service calendar
to your device calendar
Only those features that are supported by
the service are available.
With the Communities widget, you can
see your online friends' latest status
updates directly in the home screen.
Using social networking services requires
network support. This may involve the
transmission of large amounts of data and
related data traffic costs. For information
about data transmission charges, contact
your service provider.
Take a picture
Press and hold .
Your device camera has the full focus
feature. With this feature, you can take
pictures where objects both in the
foreground and background are in focus.
1Press halfway down to lock the
focus on an object (not available in
landscape or sport scene modes). A
green locked focus indicator is
displayed. If the focus was not locked,
a red focus indicator is displayed.
Release , and press it halfway
down again. You can also take a
picture without locking the focus.
2 To activate the face tracking feature,
select > Face detect.. The face
tracker detects and draws white
rectangles around faces, even when
they are moving. The priority face has
a yellow rectangle drawn around it.
To focus on the priority face, press
halfway down. A green locked
focus indicator is displayed.
3 Press . Do not move the device
before the picture is saved and the
final picture displayed.
To change the default memory to save
pictures to, select Options > Settings >
Memory in use and the desired memory
location.
Upload a picture or video to a
service
With the Communities application, you
can upload pictures and videos to social
networking services.
Select Menu > Applications >
Communities and a service, and sign in.
Upload a picture or video
1 Select .
2 Select whether to upload a picture or
a video.
3 To mark the item to upload, select the
item.
4 If uploading a single picture, you can
add a caption and a tag with a
comment to a particular section of the
picture.
Take a picture and upload it
1 Select .
2 Select the option for uploading a
picture from the camera.
3 Take a picture.
4 Add a caption and a tag with a
comment to a particular section of the
picture.
www.nokia.com/support 15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To upload a picture or video, the feature
needs to be supported by the service.
View your pictures and videos on
a TV
You can use a compatible HDMI adapter
and a standard HDMI cable (cable sold
separately) to connect your device to a TV
or compatible home theatre. Pictures and
videos retain the original video and audio
quality, even supporting surround sound.
1 Connect an HDMI adapter to the HDMI
connector of your device.
HDMI adapter
2 Connect an HDMI cable to the adapter,
and then to the HDMI connector of a
TV. You may need to manually select
the HDMI input on the TV.
3 Select a picture or video to view on the
TV.
Connect a USB mass storage device
With the USB On-The-Go (OTG) adapter,
you can connect your device to a
compatible USB memory stick or hard
drive.
Connect a memory stick
1 Connect the micro USB end of the USB
OTG adapter to the USB port in your
device.
2 Connect a memory stick to the USB
OTG adapter.
The File manager application opens, and
the memory stick is displayed as a mass
memory.
Copy or move a file
In File mgr., select and hold the file you
want to copy or move, and from the pop-
up menu, select the desired option and
the target folder.
If you connect a hard drive that requires
more than 200 mA of power, use an
external power source for the hard drive.
Back up files
Want to make sure that you will not lose
any important files? You can back up the
device memory to a compatible computer
or memory card.
16 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Select Menu > Applications > Office >
File mgr. and Backup.
It is recommended that you back up the
device memory regularly to a compatible
computer or memory card.
Tip: If you have DRM-protected content,
use Nokia Ovi Suite to back up both the
licences and the content to your
computer.
Find more help
For local services and warranty
information, please refer to the separate
booklet.
Support
When you want to learn more about how
to use your product or you are unsure how
your device should function, go to
www.nokia.com/support, or using a
mobile device, nokia.mobi/support. You
can also select Menu > Applications >
User guide in your device.
If this does not resolve your issue, do one
of the following:
•Press and hold for about 8 seconds.
The device switches off. To switch the
device on again, press .
•Restore the original factory settings.
•Update your device software.
If your issue remains unsolved, contact
Nokia for repair options. Go to
www.nokia.com/repair, or in Latin
America, www.nokia-latinoamerica.com/
centrosdeservicio. Before sending your
device for repair, always back up the data
in your device.
Keep your device software and
applications up to date
About device software and application
updates
With device software updates and
application updates, you can get new
features and enhanced functions for your
device. Updating the software may also
improve your device performance.
It is recommended that you back up your
personal data before updating your
device software.
www.nokia.com/support 17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Warning:
If you install a software update, you
cannot use the device, even to make
emergency calls, until the installation is
completed and the device is restarted.
After you update your device software or
applications, the instructions in the user
guide may no longer be up to date.
Update device software and
applications using your device
You can check if there are updates
available for your device software or for
individual applications, and then
download and install them to your device
(network service). You can also set your
device to automatically check for updates
and notify you when important or
recommended updates are available.
Select Menu > Applications > Tools >
SW update.
If there are available updates, select
which updates to download and install,
and select .
Set your device to automatically check
for updates
Select Options > Settings > Auto-check
for updates.
Update device software using your PC
You can use the Nokia Software Updater
PC application to update your device
software. To update your device software,
you need a compatible PC, a high-speed
internet connection, and a compatible
USB data cable to connect your device to
the PC.
To get more information and to download
the Nokia Software Updater application,
go to www.nokia.com/softwareupdate,
or in Latin America, www.nokia-
latinoamerica.com/nsu.
Accessibility solutions
Nokia is committed to making mobile
phones easy to use for all individuals,
including those with disabilities. For more
information, visit the Nokia website at
www.nokiaaccessibility.com.
Access codes
PIN code — This code protects your SIM
card against unauthorised use. The PIN
code (4 - 8 digits) is usually supplied with
the SIM card.
PIN2 code — This code (4 - 8 digits) is
supplied with some SIM cards, and is
required to access some functions in your
device.
If you forget an access code, contact the
network service provider whose SIM card
is in your device. After three consecutive
incorrect PIN or PIN2 code entries, the
code is blocked, and you need the PUK
code to unblock it.
PUK code and PUK2 code — These codes (8
digits) are required to change a blocked
PIN code or PIN2 code, respectively. If the
codes are not supplied with the SIM card,
contact the network service provider
whose SIM card is in your device.
IMEI number — This number (15 or 17
digits) is used to identify valid devices in
the GSM network. Devices that are, for
example, stolen, can be blocked from
accessing the network.
Lock code (also known as security
code) — The lock code helps you to protect
18 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
your device against unauthorised use. You
can create and change the code, and set
the device to request the code. Keep the
new code secret and in a safe place
separate from your device. If you forget
the code and your device is locked, your
device will require service. Additional
charges may apply, and all the personal
data in your device may be deleted. For
more information, contact a Nokia Care
Point or your device dealer.
Green tips
Save energy
You do not need to charge your battery so
often if you do the following (if available
for your device):
•Close applications and data
connections, for example, your
Bluetooth connection, when not in
use.
•Decrease the brightness of the screen.
•Set your device to enter power saver
mode after the minimum period of
inactivity, if available in your device.
•Deactivate unnecessary sounds, such
as key tones.
Recycle
All materials of this device can be
recovered as materials and energy. For
information on how to recycle your old
Nokia products, go to www.nokia.com/
werecycle, or using a mobile device,
nokia.mobi/werecycle.
Recycle packaging and user guides at your
local recycling scheme.
For more information on the
environmental attributes of your device,
go to www.nokia.com/ecodeclaration.
Product and safety information
Network services and costs
Your device is approved for use on the WCDMA 850, 900, 1700,
1900, 2100 MHz networks. To use the device, you need a
subscription with a service provider.
Using network services and downloading content to your
device may result in data traffic costs. Some product features
require support from the network, and you may need to
subscribe to them.
Take care of your device
Handle your device, battery, charger and accessories with
care. The following suggestions help you protect your
warranty coverage.
•Keep the device dry. Precipitation, humidity, and all
types of liquids or moisture can contain minerals that
corrode electronic circuits.
•Do not use or store the device in dusty or dirty areas.
Moving parts and electronic components can be
damaged.
•Do not store the device in high temperatures. High
temperatures can shorten the life of the device,
damage the battery, and warp or melt plastics.
•Do not store the device in cold temperatures. When the
device warms to its normal temperature, moisture can
form inside the device and damage electronic circuits.
•Do not attempt to open the device other than as
instructed in the user guide.
•Unauthorised modifications may damage the device
and violate regulations governing radio devices.
•Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and
mechanics.
•Only use a soft, clean, dry cloth to clean the surface of
the device.
•Do not paint the device. Paint can clog the moving parts
and prevent proper operation.
•Keep your device away from magnets or magnetic
fields.
www.nokia.com/support 19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•To keep your important data safe, store it in at least
two separate places, such as your device, memory card,
or computer, or write down important information.
During extended operation, the device may feel warm. In
most cases, this condition is normal. If you suspect the device
is not working properly, take it to the nearest authorised
service facility.
Recycle
Always return your used electronic products, batteries, and
packaging materials to dedicated collection points. This way
you help prevent uncontrolled waste disposal and promote
the recycling of materials. Check product environmental
information and how to recycle your Nokia products at
www.nokia.com/werecycle, or with a mobile device, http://
nokia.mobi/werecycle.
About Digital Rights Management
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent you from
copying, modifying, or transferring images, music, and other
content.
Content owners may use different types of digital rights
management (DRM) technologies to protect their intellectual
property, including copyrights. This device uses various types
of DRM software to access DRM-protected content. With this
device you can access content protected with WM DRM 10 and
OMA DRM 2.0. If certain DRM software fails to protect the
content, content owners may ask that such DRM software's
ability to access new DRM-protected content be revoked.
Revocation may also prevent renewal of such DRM-protected
content already in your device. Revocation of such DRM
software does not affect the use of content protected with
other types of DRM or the use of non-DRM-protected content.
Digital rights management (DRM) protected content comes
with an associated licence that defines your rights to use the
content.
If your device has OMA DRM-protected content, to back up
both the licences and the content, use the backup feature of
Nokia Ovi Suite.
Other transfer methods may not transfer the licences which
need to be restored with the content for you to be able to
continue the use of OMA DRM-protected content after the
device memory is formatted. You may also need to restore
the licences in case the files on your device get corrupted.
If your device has WMDRM-protected content, both the
licences and the content will be lost if the device memory is
formatted. You may also lose the licences and the content if
the files on your device get corrupted. Losing the licences or
the content may limit your ability to use the same content on
your device again. For more information, contact your service
provider.
Some licences may be connected to a specific SIM card, and
the protected content can be accessed only if the SIM card is
inserted in the device.
Batteries and chargers
Battery and charger information
This device has an internal, nonremovable, rechargeable
battery. Do not attempt to remove the battery from the device
as you may damage the device. Take the device to the nearest
authorised service facility for replacement of the battery.
This device is intended for use when supplied with power
from the following chargers:AC-15. The exact charger model
number may vary depending on the type of plug. The plug
variant is identified by one of the following: E, X, AR, U, A, C,
K, or B.
The battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, take the
device to the nearest authorised service facility for battery
replacement.
Battery safety
Note: The battery in your device cannot be removed, so refer
only to the battery-related statements that apply to your
device.
When you unplug a charger or an accessory, hold and pull the
plug, not the cord.
When your charger is not in use, unplug it from the electrical
plug and the device. Do not leave a fully charged battery
connected to a charger, as overcharging may shorten the
battery’s lifetime. If left unused, a fully charged battery will
lose its charge over time.
Always keep the battery between 15°C and 25°C (59°F and
77°F). Extreme temperatures reduce the capacity and lifetime
of the battery. A device with a hot or cold battery may not
work temporarily.
Accidental short-circuiting can happen when a metallic object
touches the metal strips on the battery. Short-circuiting may
damage the battery or the connecting object.
Do not dispose of batteries in a fire as they may explode.
Dispose of batteries according to local regulations. Recycle
when possible. Do not dispose as household waste.
Do not dismantle, cut, open, crush, bend, puncture, or shred
cells or batteries. If a battery leaks, do not let battery liquid
20 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
touch skin or eyes. If this happens, immediately flush the
affected areas with water, or seek medical help.
Do not modify, remanufacture, attempt to insert foreign
objects into the battery, or immerse or expose it to water or
other liquids. Batteries may explode if damaged.
Use the battery and charger for their intended purposes only.
Improper use, or use of unapproved batteries or chargers may
present a risk of fire, explosion, or other hazard, and may
invalidate any approval or warranty. If you believe the battery
or charger is damaged, take it to a service centre for
inspection before continuing to use it. Never use a damaged
battery or charger. Only use the charger indoors.
Additional safety information
Emergency calls
Make an emergency call
1 Ensure the device is switched on.
2 Check for adequate signal strength. You may also need
to do the following:
•Insert a SIM card.
•Remove call restrictions you have activated for
your device, such as call barring, fixed dialling, or
closed user group.
•Ensure your device is not in an offline or flight
profile.
•If the device screen and keys are locked, unlock
them.
3 To clear the display, press the menu key as many times
as needed.
4Select Call.
5 Enter the official emergency number for your present
location.
6Select
.
7 Give the necessary information as accurately as
possible. Do not end the call until given permission to
do so.
Important: Activate both cellular and internet calls, if your
device supports internet calls. The device may attempt to
make emergency calls both through cellular networks and
through your internet call service provider. Connections in all
conditions cannot be guaranteed. Never rely solely on any
wireless device for essential communications like medical
emergencies.
Small children
Your device and its accessories are not toys. They may contain
small parts. Keep them out of the reach of small children.
Medical devices
Operation of radio transmitting equipment, including
wireless phones, may interfere with the function of
inadequately protected medical devices. Consult a physician
or the manufacturer of the medical device to determine
whether they are adequately shielded from external RF
energy. Switch off your device when regulations posted
instruct you to do so, for example, in hospitals.
Implanted medical devices
Manufacturers of medical devices recommend a minimum
separation of 15.3 centimetres (6 inches) between a wireless
device and an implanted medical device, such as a pacemaker
or implanted cardioverter defibrillator, to avoid potential
interference with the medical device. Persons who have such
devices should:
•Always keep the wireless device more than 15.3
centimetres (6 inches) from the medical device.
•Not carry the wireless device in a breast pocket.
•Hold the wireless device to the ear opposite the medical
device.
•Turn the wireless device off if there is any reason to
suspect that interference is taking place.
•Follow the manufacturer directions for the implanted
medical device.
If you have any questions about using your wireless device
with an implanted medical device, consult your health care
provider.
Hearing
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it can
endanger your safety.
Some wireless devices may interfere with some hearing aids.
Operating environment
This device meets RF exposure guidelines in the normal use
position at the ear or at least 1.5 centimetres (5/8 inch) away
from the body. Any carry case, belt clip, or holder for body-
worn operation should not contain metal and should position
the device the above-stated distance from your body.
To send data files or messages requires a quality connection
to the network. Data files or messages may be delayed until
such a connection is available. Follow the separation distance
instructions until the transmission is completed.
www.nokia.com/support 21
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Vehicles
Radio signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles such as
electronic fuel injection, electronic antilock braking,
electronic speed control, and air bag systems. For more
information, check with the manufacturer of your vehicle or
its equipment.
Only qualified personnel should install the device in a vehicle.
Faulty installation or service may be dangerous and may
invalidate your warranty. Check regularly that all wireless
device equipment in your vehicle is mounted and operating
properly. Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the device,
its parts, or accessories. Remember that air bags inflate with
great force. Do not place your device or accessories in the air
bag deployment area.
Switch off your device before boarding an aircraft. The use of
wireless devices in an aircraft may be dangerous to the
operation of the aircraft and may be illegal.
Potentially explosive environments
Switch off your device in any area with a potentially explosive
atmosphere. Obey all posted instructions. Sparks in such
areas could cause an explosion or fire resulting in bodily
injury or death. Switch off the device at refuelling points such
as near gas pumps at service stations. Observe restrictions in
fuel depots, storage, and distribution areas; chemical plants;
or where blasting operations are in progress. Areas with a
potentially explosive atmosphere are often, but not always,
clearly marked. They include areas where you would be
advised to turn off your vehicle engine, below deck on boats,
chemical transfer or storage facilities and where the air
contains chemicals or particles such as grain, dust, or metal
powders. You should check with the manufacturers of
vehicles using liquefied petroleum gas (such as propane or
butane) to determine if this device can be safely used in their
vicinity.
Certification information (SAR)
This mobile device meets guidelines for exposure to
radio waves.
Your mobile device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines
were developed by the independent scientific organisation
ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The exposure guidelines for mobile devices employ a unit of
measurement known as the Specific Absorption Rate or SAR.
The SAR limit stated in the ICNIRP guidelines is 2.0 watts/
kilogram (W/kg) averaged over 10 grams of tissue. Tests for
SAR are conducted using standard operating positions with
the device transmitting at its highest certified power level in
all tested frequency bands. The actual SAR level of an
operating device can be below the maximum value because
the device is designed to use only the power required to reach
the network. That amount changes depending on a number
of factors such as how close you are to a network base station.
The highest SAR value under the ICNIRP guidelines for use of
the device at the ear is 1.02 W/kg.
Use of device accessories may result in different SAR values.
SAR values may vary depending on national reporting and
testing requirements and the network band. Additional SAR
information may be provided under product information at
www.nokia.com.
Your mobile device is also designed to meet the requirements
for exposure to radio waves established by the Federal
Communications Commission (USA) and Industry Canada.
These requirements set a SAR limit of 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported under this
standard during product certification for use at the ear is 1.09
W/kg and when properly worn on the body is 0.85 W/kg.
Feature-specific information
Use of the Mail for Exchange is limited to over-the-air
synchronisation of PIM information between the Nokia device
and the authorised Microsoft Exchange server.
Note: Using WLAN may be restricted in some countries. For
example, in France, you are only allowed to use WLAN
indoors. For more information, contact your local authorities.
Note: Using FM transmitter may be restricted in some
countries. For more information, contact your local
authorities and go to www.nokia.com/fmtransmitter.
Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-596
product is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC. A copy of the
Declaration of Conformity can be found at www.nokia.com/
phones/declaration_of_conformity/.
© 2010 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nseries, Nokia Original
Accessories logo, and Ovi are trademarks or registered
trademarks of Nokia Corporation. Nokia tune is a sound mark
22 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
of Nokia Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or storage of part or all
of the contents in this document in any form without the prior
written permission of Nokia is prohibited. Nokia operates a
policy of continuous development. Nokia reserves the right
to make changes and improvements to any of the products
described in this document without prior notice.
HDMI and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Java and all Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent
Portfolio License (i) for personal and noncommercial use in
connection with information which has been encoded in
compliance with the MPEG-4 Visual Standard by a consumer
engaged in a personal and noncommercial activity and (ii) for
use in connection with MPEG-4 video provided by a licensed
video provider. No license is granted or shall be implied for
any other use. Additional information, including that related
to promotional, internal, and commercial uses, may be
obtained from MPEG LA, LLC. See http://www.mpegla.com.
To the maximum extent permitted by applicable law, under
no circumstances shall Nokia or any of its licensors be
responsible for any loss of data or income or any special,
incidental, consequential or indirect damages howsoever
caused.
The contents of this document are provided "as is". Except as
required by applicable law, no warranties of any kind, either
express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular
purpose, are made in relation to the accuracy, reliability or
contents of this document. Nokia reserves the right to revise
this document or withdraw it at any time without prior
notice.
Reverse engineering of software in the device is prohibited
to the extent permitted by applicable law. Insofar as this user
guide contains any limitations on Nokia's representations,
warranties, damages and liabilities, such limitations shall
likewise limit any representations, warranties, damages and
liabilities of Nokia's licensors.
The availability of products, features, applications and
services may vary by region. For more information, contact
your Nokia dealer or your service provider. This device may
contain commodities, technology or software subject to
export laws and regulations from the US and other countries.
Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example,
when using a telephone in close proximity to receiving
equipment). The FCC or Industry Canada can require you to
stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local
service facility. This device complies with part 15 of the FCC
rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation. Any
changes or modifications not expressly approved by Nokia
could void the user's authority to operate this equipment.
Some operations and features are SIM card and/or network
dependent, MMS dependent, or dependent on the
compatibility of devices and the content formats supported.
Some services are subject to a separate charge.
7777777/Issue 1 EN
www.nokia.com/support 23
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
