Manual

Nokia C6–01 User Guide

9223131

Issue DRAFT 2010-07-23

Cyan

Magenta

Yellow

Black

Contents

Safety 3

About this user guide 4

Use the in-device user guide 4

Get started 4

Keys and parts 4

Lock or unlock the keys and

screen 5

Insert the SIM card 5

Insert or remove the memory

card 6

Charging 7

Attach the wrist strap 8

Switch the device on 9

Nokia account and Nokia's Ovi

services 9

Copy contacts or pictures from your

old device 9

Device set-up 10

Touch screen actions 10

Interactive home screen

elements 11

Call a phone number 12

View your missed calls 12

Save phone numbers and mail

addresses 12

Send a message 13

Personalisation 13

Personalise your tones 13

Change your theme 13

Switch between home screens 13

Personalise the home screen 14

Add items to the home screen 14

Social networks 14

About Social 14

Take a picture 15

Upload a picture to a service 15

Upload a picture or video to the

internet 16

Connect a USB mass storage

device 16

Back up files 17

Install Nokia Ovi Suite on your

PC 17

Copy music from your PC 18

Find more help 18

Support 18

Keep your device software and

applications up to date 19

Access codes 20

Green tips 20

Save energy 20

Product and safety

information 20

2 www.nokia.com/support

Cyan

Magenta

Yellow

Black

Safety

Read these simple guidelines. Not

following them may be dangerous or

illegal. Read the complete user guide

for further information.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when

mobile phone use is not

allowed or when it may

cause interference or

danger, for example, in

aircraft, near medical

equipment, fuel, chemicals,

or blasting areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always

keep your hands free to

operate the vehicle while

driving. Your first

consideration while driving

should be road safety.

INTERFERENCE

All wireless devices may be

susceptible to interference,

which could affect

performance.

QUALIFIED SERVICE

Only qualified personnel

may install or repair this

product.

KEEP YOUR DEVICE DRY

Your device is not water-

resistant. Keep it dry.

GLASS PARTS

The front cover of the device

is made of glass. This glass

can break if the device is

dropped on a hard surface

or receives a substantial

impact. If the glass breaks,

do not touch the glass parts

of the device or attempt to

remove the broken glass

from the device. Stop using

the device until the glass is

replaced by qualified service

personnel.

PROTECT YOUR HEARING

Listen to a headset at a

moderate level, and do not

hold the device near your

ear when the loudspeaker is

in use.

www.nokia.com/support 3

Cyan

Magenta

Yellow

Black

About this user guide

This short user guide helps you get

started with your device. With a short

printed user guide, Nokia helps save

energy and paper.

Your device contains a complete in-

device user guide, which you can refer

to for additional information about

your device. To read the in-device user

guide, select Menu > Applications >

User guide.

For even more support information, go

to www.nokia.com/support, or using a

mobile device, nokia.mobi/support.

Use the in-device user guide

Select Menu > Applications > User

guide.

Open the user guide from an

application

Select Options > User guide. This is

not available for every application.

Search the user guide

When the user guide is open, select

Options > Search, and enter a letter

or a word in the search field.

Switch between the user guide and

an application

Press and hold the menu key, swipe

left or right, and select the desired

application.

Links to related topics may be at the

end of instructions. indicates a link

to a related topic, and indicates a

link to a web page.

Get started

Keys and parts

Front

1Earpiece

2Light sensor

3Proximity sensor. Automatically

disables the touch screen during

calls.

4Menu key

5Call key

6Secondary camera

7End/Power key

Do not cover the area above the touch

screen with, for example, protective

film or tape.

4 www.nokia.com/support

Cyan

Magenta

Yellow

Black

Sides, back, and bottom

8Camera flash / Flashlight

9Volume/Zoom key

10 Lock switch / Flashlight switch

11 Camera key

12 Camera

13 Loudspeaker

14 Charger connector

15 Wrist strap peg

16 Charging indicator

17 Nokia AV connector (3.5 mm)

18 Micro USB connector

19 Microphone

Touch screen

To control your device, lightly touch

the screen with your fingertips. The

screen does not respond when you use

your fingernails.

If your fingertips are cold, the screen

may not respond to your touch.

To avoid scratching the touch screen,

never use a pen, pencil, or other sharp

object to write on the touch screen.

Flashlight

The camera flash can be used as a

flashlight. To switch the flashlight on

or off, slide and hold the lock switch for

two seconds. The flashlight can only be

used when all applications are closed.

Do not shine the flashlight in anyone's

eyes.

Lock or unlock the keys and screen

To avoid accidentally making a call

when your device is in your pocket or

bag, lock the keys and screen of your

device.

Slide the lock switch.

Set the keys and screen to lock

automatically

1 Select Menu > Settings and

Phone > Display > Screen/

keylock time-out.

2 Define the length of time after

which the keys and screen are

locked automatically.

Insert the SIM card

Do not attach any stickers to your SIM

card.

1 To remove the back cover of the

device, press the back cover with

www.nokia.com/support 5

Cyan

Magenta

Yellow

Black

your fingers, slide the cover open,

and lift the cover off.

2 Remove the battery.

3 Open the cover of the SIM card slot.

4 Insert the SIM card into the card

holder. Make sure the contact area

of the card is facing down.

5 Close the SIM card holder, and slide

the cover of the holder to lock it.

6 Replace the battery and back

cover.

Insert or remove the memory card

Use only compatible memory cards

approved by Nokia for use with this

device. Incompatible cards may

damage the card and the device and

corrupt data stored on the card.

Do not attach any stickers to your

memory card.

Insert the memory card

If a memory card is not already

inserted:

1 Remove the back cover.

2 Make sure the contact area of the

memory card is facing down.

6 www.nokia.com/support

Cyan

Magenta

Yellow

Black

Push the card in, until you hear a

click.

3 Replace the back cover.

Remove the memory card

1 Push the card in, until you hear a

click.

2 Pull the card out.

Charging

About the battery

Your device has a removable,

rechargeable battery. Use only Nokia

approved chargers designated for this

device. You can also use a compatible

USB data cable to charge your device.

When the battery charge is low, power

save mode is activated. To deactivate

power save mode, press , and select

Deactivate power saving. When

power save mode is activated, you may

not be able to modify the settings of

certain applications.

Insert the battery

1 Remove the back cover.

2 Line up the battery contacts, and

insert the battery.

3 Replace the back cover.

Charge the battery

Your battery has been partially

charged at the factory, but you may

need to recharge it before you can

switch on your device for the first time.

If the device indicates a low charge, do

the following:

www.nokia.com/support 7

Cyan

Magenta

Yellow

Black

You do not need to charge the battery

for a specific length of time, and you

can use the device while it is charging.

If the battery is completely discharged,

it may take several minutes before the

charging indicator appears on the

display or before any calls can be

made.

If the battery has not been used for a

long time, to begin charging, you may

need to connect the charger, then

disconnect and reconnect it.

Tip: You can also use a compatible USB

charger to charge your battery.

Charge the battery over USB

Battery low, but you don't have a

charger with you? You can use a

compatible USB cable to connect to a

compatible device, such as a computer.

To avoid breaking the charger

connector, be careful when connecting

or disconnecting the charger cable.

If connected to a computer, you can

synchronise your device while

charging.

Charging over USB can take longer to

start, and may not work if you connect

through a non-powered USB hub. Your

device charges more quickly when

connected to a wall outlet.

When the battery is charging, the

charging indicator light next to the USB

connector is lit. When the battery

charge is low, the charging indicator

light flashes. It may take a while for

charging to start.

Attach the wrist strap

Thread the wrist strap as shown, and

replace the back cover.

8 www.nokia.com/support

Cyan

Magenta

Yellow

Black

Switch the device on

Press and hold .

Switch the device off

Press and hold .

Nokia account and Nokia's Ovi

services

When you switch on your device for the

first time, you can create a Nokia

account, so you can access Nokia's Ovi

services.

With Ovi services, you can, for

example:

•Download mobile games,

applications, videos, pictures,

themes, and ringing tones from

Ovi Store

•Synchronise your favourite

locations from your device to the

Ovi Maps internet service

To learn more about Ovi services, go to

www.ovi.com.

To create a Nokia account later, use

your device to access an Ovi service,

and you are prompted to create an

account.

Copy contacts or pictures from your

old device

Use the Phone switch application to

copy, for example, contacts, calendar

entries, and pictures from your

previous compatible Nokia device, free

of charge.

Select Menu > Applications >

Tools > Phone setup and Data

transfer.

If your old Nokia device does not have

the Phone switch application, your

new device sends it in a message. Open

the message in the old device, and

follow the instructions.

www.nokia.com/support 9

Cyan

Magenta

Yellow

Black

1 Select the device you want to

connect to, and pair the devices.

Bluetooth needs to be activated.

2 If the other device requires a

passcode, enter the passcode. The

passcode, which you can define

yourself, must be entered in both

devices. The passcode in some

devices is fixed. For details, see the

user guide of the device.

The passcode is valid only for the

current connection.

3 Select the content and OK.

Device set-up

To define some basic settings for your

device, select the Phone setup widget

which is on one of your home

screens. To switch between home

screens, swipe left or right. With the

Phone set-up widget, you can do the

following:

•Copy contacts, pictures, and other

content from your previous Nokia

device

•Personalise your device, by

changing the ringing tone and

visual theme

•Set up mail

•Update your device software

To define the settings later, you can

also select Menu > Applications >

Tools > Phone setup.

Touch screen actions

To interact with the user interface, tap

or tap and hold the touch screen.

Open an application or other screen

element

Tap the application or element.

Access item-specific options

Tap and hold the item. A pop-up menu

with available options opens. For

example, to send an image or delete an

alarm, tap and hold the image or

alarm, and from the pop-up menu,

select the appropriate option.

If you tap and hold the home screen,

editing mode is activated.

10 www.nokia.com/support

Cyan

Magenta

Yellow

Black

Drag an item

Tap and hold the item, and slide your

finger across the screen. The item

follows your finger.

You can drag items in the home screen

or the main menu, when you have

activated editing mode.

Swipe

Place a finger on the screen, and

steadily slide your finger in the desired

direction.

For example, when you are viewing a

picture, to view the next picture, swipe

left.

Scroll in a list or menu

If the list has a scroll bar, drag the scroll

bar slider. Or place your finger on the

screen, slide it quickly up or down the

screen, then lift your finger. The

content of the screen scrolls with the

speed and direction it had at the

moment of release. To select an item

from a scrolling list and to stop the

movement, tap the item.

Zoom in

Place two fingers on an item, such as a

picture or web page, and slide your

fingers apart.

Zoom out

Place two fingers on the item, and slide

your fingers together.

Interactive home screen

elements

The home screen elements are

interactive. For example, you can

change the date and time, set alarms,

write calendar entries, or edit the

profiles directly in the home screen.

www.nokia.com/support 11

Cyan

Magenta

Yellow

Black

Set an alarm

Select the clock (1).

Activate or edit profiles

Select the profile (2).

View or edit your schedule

Select the date (3).

View available WLANs or missed

events

Select the notification area (4).

Modify the connectivity settings

Select the notification area (4) and

In most other views, you can select the

notification area (4), and do the

following:

•Modify the connectivity settings.

•Open the Clock application, and

set an alarm.

•View the battery status, and

activate power saving mode.

•View notifications of missed calls

or received messages.

•Open the WLAN wizard, and

connect to a WLAN.

Call a phone number

1 In the home screen, select Call to

open the dialler, and enter the

phone number.

To enter the + character, used for

international calls, select * twice.

2 To make the call, press the call key.

3 To end the call, press the end key.

View your missed calls

In the home screen, you can see when

you have missed calls. To view the

phone number, select Show. The

caller's name is displayed if stored in

the contacts list.

Missed and received calls are logged

only if supported by the network, and

the device is switched on and within

the network service area.

Call back the contact or number

Select the contact or number.

To view the missed calls list later, in the

home screen, select Call to open the

dialler, select , and open the missed

calls tab .

Save phone numbers and mail

addresses

You can save your friends' phone

numbers, mail addresses, and other

information to your contacts list.

Select Menu > Contacts.

Add a contact to the contacts list

1 Select Options > New contact.

12 www.nokia.com/support

Cyan

Magenta

Yellow

Black

2 Select a field, and enter the details.

To close the text input, select .

Edit contact information

1 Select a contact.

2 Open the contact card tab .

3 Select a contact detail.

Add details about a contact

Select a contact and Options > Edit >

Options > Add detail.

Send a message

With text and multimedia messages,

you can quickly contact your friends

and family. In a multimedia message,

you can attach pictures, videos, and

sound clips that you want to share.

Select Menu > Messaging.

1 Select New message.

2 To select recipients from the

contacts list, select the To title. To

enter the recipient’s phone

number manually, enter the

number in the To field.

3 To add an attachment, select .

4 Select .

Sending a message with an

attachment may be more expensive

than sending a normal text message.

For more information, contact your

service provider.

If the item you inserted in a

multimedia message is too large for

the network, the device may

automatically reduce the size.

Only compatible devices can receive

and display multimedia messages.

Messages may look different in

different devices.

Personalisation

Personalise your tones

You can personalise the ringing, key,

and warning tones for each profile.

1 In the home screen, select the

profile.

2 Select Edit active profile.

3 Select Ringing tone or Key

tones.

Tip: Download ringing tones from Ovi

Store. For details, go to www.ovi.com.

Change your theme

With themes, you can change the

colours and look of your display.

Select Menu > Settings > Themes.

Select General and a theme.

Some themes include background

animation effects. To save battery

power, select General > Options >

Theme effects.

Tip: Download themes from Ovi Store.

To learn more about Ovi Store, go to

www.ovi.com.

Switch between home screens

You can have more than one home

screen.

To switch to another home screen,

swipe left or right.

www.nokia.com/support 13

Cyan

Magenta

Yellow

Black

indicates which home screen

you are in.

Personalise the home screen

You can change wallpaper, and

rearrange home screen items.

Rearrange items in the home screen

1 Tap and hold the home screen.

2 Drag and drop items to a new

location.

Change the wallpaper

1 Tap and hold the home screen.

2 Select Options > Change

wallpaper.

3 Select the desired picture.

Tip: Download more background

images from Ovi Store. For details, go

to www.ovi.com.

Add items to the home screen

You can create shortcuts to your most

used features and add mini-

applications (widgets) that display

helpful information.

Add a shortcut to the home screen

You can add shortcuts to applications,

web bookmarks, or actions, such as

writing a message.

1 Tap and hold the home screen.

2 Select the shortcut widget and

Settings.

3 Select the shortcut you want to

define, and select Application or

Bookmark and the desired item.

Tip: To remove a shortcut, replace it

with another one.

Add a widget to the home screen

1 Tap and hold the home screen.

2 Select and the desired widget

from the list.

Tip: To download more widgets, select

Store.

Remove a widget from the home

screen

1 Tap and hold the home screen.

2 Select the widget, and from the

pop-up menu, select Remove.

Social networks

About Social

Select Menu > Social netw. > Social,

in to your relevant social networking

services.

With the Social application, you can

enhance your social networking

experience. When signed in to social

networking services through Ovi by

Nokia, you can do the following:

14 www.nokia.com/support

Cyan

Magenta

Yellow

Black

•See your friends' status updates

from multiple services in one view

•Post your own status update to

multiple services at the same time

•Instantly share pictures you take

with the camera

•Link your online friends' profiles to

their contact information in your

device

•Add your location information to

your status update

•Add events from the service

calendar to your device calendar

Only those features that are supported

by the social networking service are

available.

Using social networking services

requires network support. This may

involve the transmission of large

amounts of data and related data

traffic costs. For information about

data transmission charges, contact

your service provider.

The social networking services are

third party services and not provided

by Nokia. Check the privacy settings of

the social networking service you are

using as you may share information

with a large group of people. The

service apply to sharing information

on that service. Familiarise yourself

with the terms of use and the privacy

practices of that service.

Take a picture

Press and hold the camera key.

Your device camera has the full focus

feature. With this feature, you can take

pictures where objects both in the

foreground and background are in

focus.

1 To activate the face tracking

feature, select > Face detect..

The face tracker detects and draws

white rectangles around faces,

even when they are moving. The

priority face has a yellow rectangle

drawn around it.

2 Press the camera key. Do not move

the device before the picture is

saved and the final picture

displayed.

You need a memory card to use the

camera. Pictures and videos are saved

to the memory card.

Upload a picture to a service

With the Social application, you can

upload pictures to social networking

services.

Select Menu > Social netw. > Social.

1 Select .

2 Select to upload a picture.

3 To mark the items to upload, select

the items.

4 If uploading a single picture, you

can add a caption and a tag with a

comment to a particular section of

the picture.

Take a picture and upload it

1 Select .

www.nokia.com/support 15

Cyan

Magenta

Yellow

Black

2 Select the option for uploading a

picture from the camera.

3 Take a picture.

4 Add a caption and a tag with a

comment to a particular section of

the picture.

To upload a picture, the feature needs

to be supported by the social

networking service.

Upload a picture or video to the

internet

After taking a picture or recording a

video, you can upload your picture or

video to an online sharing service, such

as Flickr or YouTube.

Press and hold the camera key.

After taking a picture or recording a

video, select , and follow the

instructions on the display.

The first time you try to upload a

picture or video to a sharing service,

you are guided through the service

activation procedure. The service you

add is set as the default sharing

service.

Not all sharing services support all file

formats or videos recorded in high

quality.

Connect a USB mass storage

device

You can use a USB On-The-Go (OTG)

adapter to connect your device to a

compatible USB memory stick or hard

drive.

Connect a memory stick

1 Connect the micro USB end of the

USB OTG adapter (sold separately)

to the USB port in your device.

2 Connect a memory stick to the USB

OTG adapter.

The File manager application opens,

and the memory stick is displayed as a

mass memory.

Copy or move a file

In File mgr., select and hold the file you

want to copy or move, and from the

pop-up menu, select the desired

option and the target folder.

16 www.nokia.com/support

Cyan

Magenta

Yellow

Black

If you connect a hard drive that

requires more than 200 mA of power,

use an external power source for the

hard drive.

Back up files

Want to make sure that you will not

lose any important files? You can back

up the device memory to a compatible

computer or memory card.

Select Menu > Applications >

Office > File mgr. and Backup.

It is recommended that you back up

the device memory regularly to a

compatible computer or memory card.

Tip: If you have DRM-protected

content, use Nokia Ovi Suite to back up

both the licences and the content to

your computer.

Install Nokia Ovi Suite on your

With the Nokia Ovi Suite PC application,

you can manage content on your

device, and keep it in sync with your

computer.

Download the latest version of Nokia

Ovi Suite from www.ovi.com/suite.

If you cannot connect to the internet,

to install Ovi Suite and Nokia Ovi Player

from your device:

1 Use a compatible USB data cable to

connect your device to your

computer.

If you are using Windows XP or

Windows Vista on your computer,

set the USB mode of your device to

Mass storage. On your device,

select the notification area in the

top right corner, and select >

USB > Mass storage.

Your memory card appears as a

removable disk on your PC.

2 On your computer, select Install

Nokia Ovi Suite.

If the installation window does

not open automatically, open the

installation file manually. Select

Open folder to view files, and

www.nokia.com/support 17

Cyan

Magenta

Yellow

Black

double-click

Install_Nokia_Ovi_Suite.exe.

3 Follow the instructions.

4 When the installation is complete,

if you are using Windows XP or

Windows Vista on your computer,

set the USB mode of your device to

Media transfer. On your device,

select the notification area in the

top right corner, and select >

USB > Media transfer.

To learn more about Ovi Suite, go to

www.ovi.com.

Copy music from your PC

Do you have music on your PC that you

want to listen on your device? Nokia

Ovi Player is the fastest way to transfer

music on your device, and you can use

it to manage and synchronise your

music collection.

1 Use a compatible USB data cable to

connect your device to your

computer. Make sure a compatible

memory card is inserted in your

device.

2On your device, select the

notification area in the top right

corner, and select > USB >

Media transfer.

3 On your computer, open Nokia Ovi

Player. For more information, see

the Ovi Player help.

Download the latest version of Ovi

player from www.ovi.com.

Some music files can be protected by

digital rights management (DRM) and

cannot be played on more than one

device.

Find more help

Support

When you want to learn more about

how to use your product or you are

unsure how your device should

function, go to www.nokia.com/

support, or using a mobile device,

nokia.mobi/support. You can also

select Menu > Applications > User

guide in your device.

If this does not resolve your issue, do

one of the following:

•Switch off the device, and remove

the battery. After about a minute,

replace the battery, and switch on

the device.

•Restore the original factory

settings.

•Update your device software.

If your issue remains unsolved, contact

Nokia for repair options. Go to

www.nokia.com/repair. Before

18 www.nokia.com/support

Cyan

Magenta

Yellow

Black

sending your device for repair, always

back up the data in your device.

Keep your device software and

applications up to date

About device software and

application updates

With device software updates and

application updates, you can get new

features and enhanced functions for

your device. Updating the software

may also improve your device

performance.

It is recommended that you back up

your personal data before updating

your device software.

Warning:

If you install a software update, you

cannot use the device, even to make

emergency calls, until the installation

is completed and the device is

restarted.

After you update your device software

or applications, the instructions in the

user guide may no longer be up to

date.

Update device software and

applications using your device

You can check if there are updates

available for your device software or

for individual applications, and then

download and install them to your

device (network service). You can also

set your device to automatically check

for updates and notify you when

important or recommended updates

are available.

Select Menu > Applications >

Tools > SW update.

If there are available updates, select

which updates to download and

install, and select .

Set your device to automatically

check for updates

Select Options > Settings > Auto-

check for updates.

Update device software using your

You can use the Nokia Software

Updater PC application to update your

device software. To update your device

software, you need a compatible PC, a

high-speed internet connection, and a

compatible USB data cable to connect

your device to the PC.

To get more information and to

download the Nokia Software Updater

application, go to www.nokia.com/

softwareupdate.

www.nokia.com/support 19

Cyan

Magenta

Yellow

Black

Access codes

PIN code — This code protects your SIM

card against unauthorised use. The PIN

code (4 - 8 digits) is usually supplied

with the SIM card.

PIN2 code — This code (4 - 8 digits) is

supplied with some SIM cards, and is

required to access some functions in

your device.

If you forget an access code, contact

the network service provider whose

SIM card is in your device. After three

consecutive incorrect PIN or PIN2 code

entries, the code is blocked, and you

need the PUK code to unblock it.

PUK code and PUK2 code — These

codes (8 digits) are required to change

a blocked PIN code or PIN2 code,

respectively. If the codes are not

supplied with the SIM card, contact the

network service provider whose SIM

card is in your device.

IMEI number — This number (15 or 17

digits) is used to identify valid devices

in the GSM network. Devices that are,

for example, stolen, can be blocked

from accessing the network. The IMEI

number for your device can be found

under the battery.

Lock code (also known as security

code) — The lock code helps you to

protect your device against

unauthorised use. You can create and

change the code, and set the device to

request the code. Keep the new code

secret and in a safe place separate

from your device. If you forget the code

and your device is locked, your device

will require service. Additional charges

may apply, and all the personal data in

your device may be deleted. For more

information, contact a Nokia Care

Point or your device dealer.

Green tips

Save energy

You do not need to charge your battery

so often if you do the following (if

available for your device):

•Close applications and data

connections, for example, your

Bluetooth connection, when not in

use.

•Decrease the brightness of the

screen.

•Set your device to enter power

saver mode after the minimum

period of inactivity, if available in

your device.

•Deactivate unnecessary sounds,

such as key tones.

Product and safety information

Network services and costs

Your device is approved for use on the WCDMA 850, 900,

1700–2100, 1900, 2100 and GSM/EDGE 850, 900, 1800,

1900 MHz networks. To use the device, you need a

subscription with a service provider.

Using network services and downloading content to

your device may result in data traffic costs. Some product

features require support from the network, and you may

need to subscribe to them.

Take care of your device

Handle your device, battery, charger and accessories

with care. The following suggestions help you protect

your warranty coverage.

20 www.nokia.com/support

Cyan

Magenta

Yellow

Black

•Keep the device dry. Precipitation, humidity, and

all types of liquids or moisture can contain

minerals that corrode electronic circuits. If your

device gets wet, remove the battery, and allow the

device to dry.

•Do not use or store the device in dusty or dirty

areas. Moving parts and electronic components

can be damaged.

•Do not store the device in high temperatures. High

temperatures can shorten the life of the device,

damage the battery, and warp or melt plastics.

•Do not store the device in cold temperatures.

When the device warms to its normal

temperature, moisture can form inside the device

and damage electronic circuits.

•Do not attempt to open the device other than as

instructed in the user guide.

•Unauthorised modifications may damage the

device and violate regulations governing radio

devices.

•Do not drop, knock, or shake the device. Rough

handling can break internal circuit boards and

mechanics.

•Only use a soft, clean, dry cloth to clean the surface

of the device.

•Do not paint the device. Paint can clog the moving

parts and prevent proper operation.

•Switch off the device and remove the battery from

time to time for optimum performance.

•Keep your device away from magnets or magnetic

fields.

•To keep your important data safe, store it in at

least two separate places, such as your device,

memory card, or computer, or write down

important information.

During extended operation, the device may feel warm.

In most cases, this condition is normal. If you suspect the

device is not working properly, take it to the nearest

authorised service facility.

Recycle

Always return your used electronic products, batteries,

and packaging materials to dedicated collection points.

This way you help prevent uncontrolled waste disposal

and promote the recycling of materials. Check product

environmental information and how to recycle your

Nokia products at www.nokia.com/werecycle, or with a

mobile device, http://nokia.mobi/werecycle.

About Digital Rights Management

When using this device, obey all laws and respect local

customs, privacy and legitimate rights of others,

including copyrights. Copyright protection may prevent

you from copying, modifying, or transferring images,

music, and other content.

Content owners may use different types of digital rights

management (DRM) technologies to protect their

intellectual property, including copyrights. This device

uses various types of DRM software to access DRM-

protected content. With this device you can access

content protected with WM DRM 10, and OMA DRM 2.0. If

certain DRM software fails to protect the content,

content owners may ask that such DRM software's ability

to access new DRM-protected content be revoked.

Revocation may also prevent renewal of such DRM-

protected content already in your device. Revocation of

such DRM software does not affect the use of content

protected with other types of DRM or the use of non-DRM-

protected content.

Digital rights management (DRM) protected content

comes with an associated licence that defines your rights

to use the content.

If your device has OMA DRM-protected content, to back

up both the licences and the content, use the backup

feature of Nokia Ovi Suite.

Other transfer methods may not transfer the licences

which need to be restored with the content for you to

be able to continue the use of OMA DRM-protected

content after the device memory is formatted. You may

also need to restore the licences in case the files on your

device get corrupted.

If your device has WMDRM-protected content, both the

licences and the content will be lost if the device memory

is formatted. You may also lose the licences and the

content if the files on your device get corrupted. Losing

the licences or the content may limit your ability to use

the same content on your device again. For more

information, contact your service provider.

Some licences may be connected to a specific SIM card,

and the protected content can be accessed only if the SIM

card is inserted in the device.

Batteries and chargers

Battery and charger information

This device is intended for use with a BL-5CT

rechargeable battery. Nokia may make additional

battery models available for this device. Always use

original Nokia batteries.

This device is intended for use when supplied with

power from the following chargers:AC-15. The exact

charger model number may vary depending on the type

www.nokia.com/support 21

Cyan

Magenta

Yellow

Black

of plug. The plug variant is identified by one of the

following: E, X, AR, U, A, C, K, or B.

The battery can be charged and discharged hundreds of

times, but it will eventually wear out. When the talk and

standby times are noticeably shorter than normal, you

need to replace the battery.

Battery safety

Always switch the device off and disconnect the charger

before removing the battery. When you unplug a charger

or an accessory, hold and pull the plug, not the cord.

When your charger is not in use, unplug it from the

electrical plug and the device. Do not leave a fully

charged battery connected to a charger, as overcharging

may shorten the battery’s lifetime. If left unused, a fully

charged battery will lose its charge over time.

Always keep the battery between 15°C and 25°C (59°F

and 77°F). Extreme temperatures reduce the capacity

and lifetime of the battery. A device with a hot or cold

battery may not work temporarily.

Accidental short-circuiting can happen when a metallic

object touches the metal strips on the battery, for

example, if you carry a spare battery in your pocket.

Short-circuiting may damage the battery or the

connecting object.

Do not dispose of batteries in a fire as they may explode.

Dispose of batteries according to local regulations.

Recycle when possible. Do not dispose as household

waste.

Do not dismantle, cut, open, crush, bend, puncture, or

shred cells or batteries. If a battery leaks, do not let

battery liquid touch skin or eyes. If this happens,

immediately flush the affected areas with water, or seek

medical help.

Do not modify, remanufacture, attempt to insert foreign

objects into the battery, or immerse or expose it to water

or other liquids. Batteries may explode if damaged.

Use the battery and charger for their intended purposes

only. Improper use, or use of unapproved batteries or

chargers may present a risk of fire, explosion, or other

hazard, and may invalidate any approval or warranty. If

you believe the battery or charger is damaged, take it to

a service centre for inspection before continuing to use

it. Never use a damaged battery or charger. Only use the

charger indoors.

Additional safety information

Emergency calls

Make an emergency call

1 Ensure the device is switched on.

2 Check for adequate signal strength. You may also

need to do the following:

•Insert a SIM card.

•Remove call restrictions you have activated

for your device, such as call barring, fixed

dialling, or closed user group.

•Ensure your device is not in an offline or

flight profile.

•If the device screen and keys are locked,

unlock them.

3 To clear the display, press the menu key as many

times as needed.

4Select Call.

5 Enter the official emergency number for your

present location.

6Select

7 Give the necessary information as accurately as

possible. Do not end the call until given permission

to do so.

Important: Activate both cellular and internet calls, if

your device supports internet calls. The device may

attempt to make emergency calls both through cellular

networks and through your internet call service

provider. Connections in all conditions cannot be

guaranteed. Never rely solely on any wireless device for

essential communications like medical emergencies.

Small children

Your device, its battery and accessories are not toys. They

may contain small parts. Keep them out of the reach of

small children.

Medical devices

Operation of radio transmitting equipment, including

wireless phones, may interfere with the function of

inadequately protected medical devices. Consult a

physician or the manufacturer of the medical device to

determine whether they are adequately shielded from

external RF energy. Switch off your device when

regulations posted instruct you to do so, for example, in

hospitals.

Implanted medical devices

Manufacturers of medical devices recommend a

minimum separation of 15.3 centimetres (6 inches)

between a wireless device and an implanted medical

22 www.nokia.com/support

Cyan

Magenta

Yellow

Black

device, such as a pacemaker or implanted cardioverter

defibrillator, to avoid potential interference with the

medical device. Persons who have such devices should:

•Always keep the wireless device more than 15.3

centimetres (6 inches) from the medical device.

•Not carry the wireless device in a breast pocket.

•Hold the wireless device to the ear opposite the

medical device.

•Turn the wireless device off if there is any reason

to suspect that interference is taking place.

•Follow the manufacturer directions for the

implanted medical device.

If you have any questions about using your wireless

device with an implanted medical device, consult your

health care provider.

Hearing

Warning:

When you use the headset, your ability to hear outside

sounds may be affected. Do not use the headset where

it can endanger your safety.

Some wireless devices may interfere with some hearing

aids.

Operating environment

This device meets RF exposure guidelines in the normal

use position at the ear or at least 1.5 centimetres (5/8

inch) away from the body. Any carry case, belt clip, or

holder for body-worn operation should not contain

metal and should position the device the above-stated

distance from your body.

To send data files or messages requires a quality

connection to the network. Data files or messages may

be delayed until such a connection is available. Follow

the separation distance instructions until the

transmission is completed.

Vehicles

Radio signals may affect improperly installed or

inadequately shielded electronic systems in motor

vehicles such as electronic fuel injection, electronic

antilock braking, electronic speed control, and air bag

systems. For more information, check with the

manufacturer of your vehicle or its equipment.

Only qualified personnel should install the device in a

vehicle. Faulty installation or service may be dangerous

and may invalidate your warranty. Check regularly that

all wireless device equipment in your vehicle is mounted

and operating properly. Do not store or carry flammable

liquids, gases, or explosive materials in the same

compartment as the device, its parts, or accessories.

Remember that air bags inflate with great force. Do not

place your device or accessories in the air bag

deployment area.

Switch off your device before boarding an aircraft. The

use of wireless devices in an aircraft may be dangerous

to the operation of the aircraft and may be illegal.

Potentially explosive environments

Switch off your device in any area with a potentially

explosive atmosphere. Obey all posted instructions.

Sparks in such areas could cause an explosion or fire

resulting in bodily injury or death. Switch off the device

at refuelling points such as near gas pumps at service

stations. Observe restrictions in fuel depots, storage, and

distribution areas; chemical plants; or where blasting

operations are in progress. Areas with a potentially

explosive atmosphere are often, but not always, clearly

marked. They include areas where you would be advised

to turn off your vehicle engine, below deck on boats,

chemical transfer or storage facilities and where the air

contains chemicals or particles such as grain, dust, or

metal powders. You should check with the

manufacturers of vehicles using liquefied petroleum gas

(such as propane or butane) to determine if this device

can be safely used in their vicinity.

Certification information (SAR)

This mobile device meets guidelines for exposure to

radio waves.

Your mobile device is a radio transmitter and receiver. It

is designed not to exceed the limits for exposure to radio

waves recommended by international guidelines. These

guidelines were developed by the independent scientific

organisation ICNIRP and include safety margins

designed to assure the protection of all persons,

regardless of age and health.

The exposure guidelines for mobile devices employ a

unit of measurement known as the Specific Absorption

Rate or SAR. The SAR limit stated in the ICNIRP guidelines

is 2.0 watts/kilogram (W/kg) averaged over 10 grams of

tissue. Tests for SAR are conducted using standard

operating positions with the device transmitting at its

highest certified power level in all tested frequency

bands. The actual SAR level of an operating device can

be below the maximum value because the device is

designed to use only the power required to reach the

network. That amount changes depending on a number

of factors such as how close you are to a network base

station.

www.nokia.com/support 23

Cyan

Magenta

Yellow

Black

The highest SAR value under the ICNIRP guidelines for

use of the device at the ear is 1.00 W/kg.

Use of device accessories may result in different SAR

values. SAR values may vary depending on national

reporting and testing requirements and the network

band. Additional SAR information may be provided

under product information at www.nokia.com.

Your mobile device is also designed to meet the

requirements for exposure to radio waves established

by the Federal Communications Commission (USA) and

Industry Canada. These requirements set a SAR limit of

1.6 W/kg averaged over one gram of tissue. The highest

SAR value reported under this standard during product

certification for use at the ear is 1.10 W/kg and when

properly worn on the body is 1.25 W/kg.

Feature-specific information

Use of the Mail for Exchange is limited to over-the-air

synchronisation of PIM information between the Nokia

device and the authorised Microsoft Exchange server.

Note: Using WLAN may be restricted in some countries.

For example, in France, you are only allowed to use WLAN

indoors. For more information, contact your local

authorities.

Do not connect products that create an output signal as

this may cause damage to the device. Do not connect any

voltage source to the Nokia AV connector. If you connect

an external device or headset, other than those

approved by Nokia for use with this device, to the Nokia

AV connector, pay special attention to volume levels.

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that this RM-601

product is in compliance with the essential requirements

and other relevant provisions of Directive 1999/5/EC. A

copy of the Declaration of Conformity can be found at

www.nokia.com/phones/declaration_of_conformity/.

Nokia, Nokia Connecting People, and Ovi are trademarks

or registered trademarks of Nokia Corporation. Nokia

tune is a sound mark of Nokia Corporation. Other product

and company names mentioned herein may be

trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part

or all of the contents in this document in any form

without the prior written permission of Nokia is

prohibited. Nokia operates a policy of continuous

development. Nokia reserves the right to make changes

and improvements to any of the products described in

this document without prior notice.

Java and all Java-based marks are trademarks or

registered trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent

Portfolio License (i) for personal and noncommercial use

in connection with information which has been encoded

in compliance with the MPEG-4 Visual Standard by a

consumer engaged in a personal and noncommercial

activity and (ii) for use in connection with MPEG-4 video

provided by a licensed video provider. No license is

granted or shall be implied for any other use. Additional

information, including that related to promotional,

internal, and commercial uses, may be obtained from

MPEG LA, LLC. See http://www.mpegla.com.

To the maximum extent permitted by applicable law,

under no circumstances shall Nokia or any of its licensors

be responsible for any loss of data or income or any

special, incidental, consequential or indirect damages

howsoever caused.

The contents of this document are provided "as is".

Except as required by applicable law, no warranties of

any kind, either express or implied, including, but not

limited to, the implied warranties of merchantability

and fitness for a particular purpose, are made in relation

to the accuracy, reliability or contents of this document.

Nokia reserves the right to revise this document or

withdraw it at any time without prior notice.

Reverse engineering of software in the device is

prohibited to the extent permitted by applicable law.

Insofar as this user guide contains any limitations on

Nokia's representations, warranties, damages and

liabilities, such limitations shall likewise limit any

representations, warranties, damages and liabilities of

Nokia's licensors.

The availability of products, features, applications and

services may vary by region. For more information,

24 www.nokia.com/support

Cyan

Magenta

Yellow

Black

contact your Nokia dealer or your service provider. This

device may contain commodities, technology or

software subject to export laws and regulations from the

US and other countries. Diversion contrary to law is

prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for

example, when using a telephone in close proximity to

receiving equipment). The FCC or Industry Canada can

require you to stop using your telephone if such

interference cannot be eliminated. If you require

assistance, contact your local service facility. This device

complies with part 15 of the FCC rules. Operation is

subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) this device

must accept any interference received, including

interference that may cause undesired operation. Any

changes or modifications not expressly approved by

Nokia could void the user's authority to operate this

equipment.

Some operations and features are SIM card and/or

network dependent, MMS dependent, or dependent on

the compatibility of devices and the content formats

supported. Some services are subject to a separate

charge.

9223131/Issue DRAFT 2010-07-23 EN

www.nokia.com/support 25

Cyan

Magenta

Yellow

Black

Microsoft RM-601 GSM/WCDMA cellular telephone phone with Bluetooth and WLAN User Manual Manual

Microsoft Mobile Oy GSM/WCDMA cellular telephone phone with Bluetooth and WLAN Manual

Manual

Navigation menu

Namespaces

Views

Navigation
