Microsoft RM-635 GSM 850/1900 Cellular Telephone with BT User Manual Manual

Microsoft Mobile Oy GSM 850/1900 Cellular Telephone with BT Manual

Manual

Nokia 2690 User Guide
xxxxxxx
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Contents
Safety 5
Get started 7
Insert SIM card and
battery 7
Remove the SIM card 8
Insert a microSD card 8
Remove the microSD
card 9
Charge the battery 10
Antenna 11
Headset 11
Magnets and magnetic
fields 12
Keys and parts 12
Switch on and off 13
Standby mode 13
Keypad lock 14
Functions without a SIM
card 15
Applications running in
background 15
General
information 16
About your device 16
Network services 17
Shared memory 18
Access codes 19
Nokia support 20
Calls 21
Make and answer a
call 21
Loudspeaker 21
Dialling shortcuts 21
Write text 22
Text modes 22
Traditional text input 23
Predictive text input 23
Navigate the
menus 24
Messaging 24
Text and multimedia
messages 24
E-mail 27
2Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Flash messages 28
Nokia Xpress audio
messages 29
Instant messaging 29
Voice messages 30
Message settings 30
Contacts 31
Call log 32
Settings 33
Profiles 33
Tones 33
Display 34
Date and time 34
Shortcuts 34
Synchronisation and
backup 35
Connectivity 35
Calls and phone 38
Voice commands and
voice dialling 39
Enhancements 40
Configuration 40
Restore factory
settings 41
Operator menu 42
Gallery 42
Media 43
Camera and video 43
FM radio 45
Voice recorder 46
Music player 46
Applications 47
Organiser 48
Alarm clock 48
Calendar and to-do
list 49
Web or Internet 49
Connect to a web
service 50
SIM services 51
Green tips 51
Contents 3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Save energy 51
Recycle 52
Learn more 52
Accessories 53
Battery 53
Battery and charger
information 53
Nokia battery
authentication
guidelines 54
Care and
maintenance 56
Recycle 57
Additional safety
information 57
Small children 57
Operating
environment 57
Medical devices 58
Vehicles 58
Potentially explosive
environments 59
Emergency calls 60
Certification information
(SAR) 60
Index 62
4Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
Safety 5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
6Safety
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Get started
Insert SIM card and battery
Safe removal. Always switch the device off and disconnect
the charger before removing the battery.
The SIM card and its contacts can be easily damaged by
scratches or bending, so be careful when handling,
inserting, or removing the card.
1 Press and slide the back cover towards the bottom of
the phone, and remove it (1).
2 Remove the battery (2).
3 Insert the SIM card into the holder with the contact
surface facing down (3).
4 Insert the battery (4), and replace the back cover (5).
Get started 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Remove the SIM card
Insert a microSD card
Use only compatible microSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored
on the card.
Your phone supports microSD cards with a capacity of up
to 8 GB.
A compatible memory card may be supplied with the
device, and may already be inserted in the device. If not,
do the following:
8Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
1 Open the cover of the memory card slot.
2 Insert the card into the memory card slot with the
contact surface facing up, and press until it locks into
place.
3 Close the cover of the memory card slot.
Remove the microSD card
Important: Do not remove the memory card during an
operation when the card is being accessed. Doing so may
damage the memory card and the device, and corrupt data
stored on the card.
Get started 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
You can remove or replace the memory card during phone
operation without switching the device off, but you need
to ensure that no application is currently accessing the
memory card.
Charge the battery
Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2
Connect the charger to the device.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
10 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
minutes before the charging indicator appears on the
display or before any calls can be made.
Antenna
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
The figure shows the antenna area marked in grey.
Headset
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it
can endanger your safety.
When connecting any external device or any headset, other
than those approved by Nokia for use with this device, to
Get started 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
the Nokia AV Connector, pay special attention to volume
levels.
Do not connect products that create an output signal as
this may cause damage to the device. Do not connect any
voltage source to the Nokia AV Connector.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
Keys and parts
1Earpiece
2Display
3Selection keys
4Navi™ key; hereafter
referred to as scroll key
5Call key
6Keypad
7End/Power key
12 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
8Charger connector
9Headset connector (3.5
mm)
10 Camera lens
11 Microphone
12 Loudspeaker
13 Memory card slot
14 Wrist strap eyelet
15 Micro USB connector
Switch on and off
Press and hold the power key.
Standby mode
When the phone is ready for use, and you have not entered
any characters, the phone is in the standby mode.
Get started 13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
1Network signal strength
2Battery charge level
3Network name or operator logo
4Functions of selection keys
The left selection key, Go to, allows you to access the
functions in your personal shortcut list. When viewing the
list, select Options > Select options to view the available
functions, or select Options > Organise to arrange the
functions in your shortcut list.
Keypad lock
To prevent accidental keypresses, select Menu, and press
* within 3.5 seconds to lock the keypad.
14 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To unlock the keypad, select Unlock, and press * within 1.5
seconds. If the security keyguard is on, enter the security
code when requested.
To set the keypad to lock automatically after a preset time
when the phone is in the standby mode, select Menu >
Settings > Phone > Automatic keyguard > On.
To answer a call when the keypad is locked, press the call
key. When you end or reject the call, the keypad locks
automatically.
When the device or keypad is locked, calls may be possible
to the official emergency number programmed into your
device.
Functions without a SIM card
Some functions of your phone may be used without
inserting a SIM card, such as Organiser functions and
games. Some functions appear dimmed in the menus and
cannot be used.
Applications running in background
Leaving applications running in the background increases
the demand on battery power and reduces the battery life.
Get started 15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
General information
About your device
The wireless device described in this guide is approved for
use on the (E)GSM 850, 900, 1800, and 1900 MHz
networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and
respect local customs, privacy and legitimate rights of
others, including copyrights.
Copyright protection may prevent some images, music,
and other content from being copied, modified, or
transferred.
Your device may have preinstalled bookmarks and links for
third-party internet sites. You may also access other third-
party sites through your device. Third-party sites are not
affiliated with Nokia, and Nokia does not endorse or
assume liability for them. If you choose to access such sites,
you should take precautions for security or content.
16 General information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Warning:
To use any features in this device, other than the alarm
clock, the device must be switched on. Do not switch the
device on when wireless device use may cause interference
or danger.
Remember to make back-up copies or keep a written
record of all important information stored in your device.
When connecting to any other device, read its user guide
for detailed safety instructions. Do not connect
incompatible products.
The images in this guide may differ from your device
display.
Network services
To use the device you must have service from a wireless
service provider. Many of the features require special
network features. These features are not available on all
networks; other networks may require that you make
specific arrangements with your service provider before
you can use the network services. Using network services
involves transmission of data. Check with your service
provider for details about fees in your home network and
when roaming on other networks. Your service provider
can give you instructions and explain what charges will
General information 17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
apply. Some networks may have limitations that affect
how you can use network services. For instance, some
networks may not support all language-dependent
characters and services.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have a special configuration such as
changes in menu names, menu order, and icons. Contact
your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that
run on TCP/IP protocols. Some features of this device, such
as multimedia messaging (MMS), browsing, and e-mail
application, require network support for these
technologies.
Shared memory
The following features in this device may share memory:
multimedia messaging (MMS), e-mail application, instant
messaging. Use of one or more of these features may
reduce the memory available for the remaining features
sharing memory. Your device may display a message that
the memory is full when you try to use a shared memory
feature. In this case, delete some of the information or
entries stored in the shared memory features before
continuing.
18 General information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Access codes
The security code helps to protect your device against
unauthorised use. The preset code is 12345. You can create
and change the code, and set the device to request the
code. Keep the code secret and in a safe place separate
from your device. If you forget the code and your device is
locked, your device will require service. Additional charges
may apply, and all the personal data in your device may be
deleted. For more information, contact a Nokia Care point
or your device dealer.
The PIN code supplied with the SIM card protects the card
against unauthorised use. The PIN2 code supplied with
some SIM cards is required to access certain services. If you
enter the PIN or PIN2 code incorrectly three times in
succession, you are asked for the PUK or PUK2 code. If you
do not have them, contact your service provider.
The module PIN is required to access the information in the
security module of your SIM card. The signing PIN may be
required for the digital signature. The barring password is
required when using the call barring service.
To set how your device uses the access codes and security
settings, select Menu > Settings > Security.
General information 19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Nokia support
Check www.nokia.com/support or your local Nokia
website for the latest version of this guide, additional
information, downloads, and services related to your
Nokia product.
Configuration settings service
Download free configuration settings such as MMS, GPRS,
e-mail, and other services for your phone model at
www.nokia.com/support.
Nokia PC Suite
You may find PC Suite and related information on the Nokia
website at www.nokia.com/support.
Nokia Care services
If you need to contact Nokia Care services, check the list of
local Nokia Care contact centres at www.nokia.com/
customerservice.
Maintenance
For maintenance services, check your nearest Nokia Care
point at www.nokia.com/repair.
20 General information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Calls
Make and answer a call
To make a call, enter the phone number, including the
country code and area code if necessary. Press the call key
to call the number. Scroll up to increase or down to
decrease the volume of the earpiece or headset during the
phone call.
To answer an incoming call, press the call key. To reject the
call without answering, press the end key.
Loudspeaker
If available, you may select Loudsp. or Normal to use the
loudspeaker or the earpiece of the phone during a call.
Dialling shortcuts
To assign a phone number to one of the number keys, 2 to
9, select Menu > Contacts > Speed dials, scroll to a
desired number, and select Assign. Enter the desired
phone number, or select Search and a saved contact.
Calls 21
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To switch the speed dialling function on, select Menu >
Settings > Call > Speed dialling > On.
To make a call using speed dialling, in the standby mode,
press and hold the desired number key.
Write text
Text modes
To enter text (for example, when writing messages) you
can use traditional or predictive text input.
When you write text, press and hold Options to switch
between traditional text input, indicated by , and
predictive text input, indicated by . Not all languages
are supported by predictive text input.
The character cases are indicated by , , and .
To change the character case, press #. To change from the
letter to number mode, indicated by , press and hold
#, and select Number mode. To change from the number
to the letter mode, press and hold #.
To set the writing language, select Options > Writing
language.
22 Write text
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Traditional text input
Press a number key, 2-9, repeatedly until the desired
character appears. The available characters depend on the
selected writing language.
If the next letter you want is located on the same key as
the present one, wait until the cursor appears, and enter
the letter.
To access the most common punctuation marks and special
characters, press 1 repeatedly. To access the list of special
characters, press *.
Predictive text input
Predictive text input is based on a built-in dictionary to
which you can also add new words.
1 Start writing a word, using the keys 2 to 9. Press each
key only once for one letter.
2 To confirm a word, scroll right or add a space.
If the word is not correct, press * repeatedly, and
select the word from the list.
If the ? character is displayed after the word, the
word you intended to write is not in the dictionary.
To add the word to the dictionary, select Spell.
Enter the word using traditional text input, and
select Save.
Write text 23
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To write compound words, enter the first part of
the word, and scroll right to confirm it. Write the
last part of the word, and confirm the word.
3 Start writing the next word.
Navigate the menus
The phone functions are grouped into menus. Not all menu
functions or option items are described here.
In the standby mode, select Menu and the desired menu
and submenu. Select Exit or Back to exit the current level
of menu. Press the end key to return to the standby mode
directly. To change the menu view, select Menu >
Options > Main menu view.
Messaging
You can read, write, send, and save text, multimedia,
audio, instant, and flash messages, and e-mail. The
messaging services can only be used if your network or
service provider supports them.
Text and multimedia messages
You can create a message and optionally attach, for
example, a picture. Your phone automatically changes a
24 Navigate the menus
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
text message to a multimedia message when a file is
attached.
Text messages
Your device supports text messages beyond the limit for a
single message. Longer messages are sent as two or more
messages. Your service provider may charge accordingly.
Characters with accents, other marks, or some language
options take more space, and limit the number of
characters that can be sent in a single message.
An indicator at the top of the display shows the total
number of characters left and the number of messages
needed for sending.
Before you can send messages, you must save your
message centre number. Select Menu > Messaging >
Message settings > Text messages > Message
centres > Add centre, enter a name, and the number from
the service provider.
Multimedia messages
A multimedia message can contain text, pictures, and
sound or video clips.
Only devices that have compatible features can receive and
display multimedia messages. The appearance of a
message may vary depending on the receiving device.
Messaging 25
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
The wireless network may limit the size of MMS messages.
If the inserted picture exceeds this limit, the device may
make it smaller so that it can be sent by MMS.
Important: Exercise caution when opening messages.
Messages may contain malicious software or otherwise be
harmful to your device or PC.
For availability and subscription to the multimedia
messaging service (MMS), contact your service provider.
You may also download the configuration settings. See
"Nokia support", p. 20.
Create a text or multimedia message
1 Select Menu > Messaging > Create message >
Message.
2 To add recipients, scroll to the To: field, and enter the
recipient’s number or e-mail address, or select Add to
select recipients from the available options. Select
Options to add recipients and subjects and to set
sending options.
3 Scroll to the Text: field, and enter the message text.
4 To attach content to the message, scroll to the
attachment bar at the bottom of the display and select
the desired type of content.
5 To send the message, press Send.
26 Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
The message type is indicated at the top of the display and
changes automatically depending on the content of the
message.
Service providers may charge differently depending on the
message type. Check with your service provider for details.
E-mail
Access your POP3 or IMAP4 e-mail account with your phone
to read, write, and send e-mail. This e-mail application is
different from the SMS e-mail function.
Before you can use e-mail, you must have an e-mail
account and the correct settings. To check the availability
and the settings of your e-mail account, contact your e-
mail service provider. You may receive the e-mail
configuration settings as a configuration message.
E-mail setup wizard
The e-mail setup wizard starts automatically if no e-mail
settings are defined in the phone. To start the setup wizard
for an additional e-mail account, select Menu >
Messaging and the existing e-mail account. Select
Options > Add mailbox to start the e-mail setup wizard.
Follow the instructions on the display.
Messaging 27
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Write and send an e-mail
To write an e-mail, select Menu > Messaging > Create
message > E-mail message. To attach a file to the e-mail,
select Options > Insert. To send the e-mail, press the call
key. Select the desired account if necessary.
Download e-mail
Important: Exercise caution when opening messages.
Messages may contain malicious software or otherwise be
harmful to your device or PC.
To select the retrieve mode, select Menu > Messaging >
Message settings > E-mail messages > Edit
mailboxes and the desired mailbox, and Downloading
settings > Retrieve mode.
To download e-mail, select Menu > Messaging and the
desired mailbox; confirm the query for connection if
necessary.
Flash messages
Flash messages are text messages that are instantly
displayed upon reception.
1 To write a flash message, select Menu >
Messaging > Create message > Flash message.
28 Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2 Enter the recipient’s phone number, write your
message (maximum 70 characters), and select Send.
Nokia Xpress audio messages
Create and send an audio message using MMS in a
convenient way.
1 Select Menu > Messaging > Create message >
Audio message. The voice recorder opens.
2 Record your message.
3 Enter one or more phone numbers in the To: field, or
select Add to retrieve a number.
4 To send the message, select Send.
Instant messaging
With instant messaging (IM, network service) you can send
short text messages to online users. You must subscribe to
a service and register with the IM service you want to use.
Check the availability of this service, pricing, and
instructions with your service provider. The menus may
vary depending on your IM provider.
To connect to the service, select Menu > Messaging >
Instant messages and follow the instructions on the
display.
Messaging 29
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Voice messages
The voice mailbox is a network service to which you may
need to subscribe. For more information, contact your
service provider.
Call your voice mailbox
In the standby mode, press and hold 1.
Edit voice mailbox number
Select Menu > Messaging > Voice messages > Voice
mailbox number.
Message settings
Select Menu > Messaging > Message settings and from
the following:
General settings — to save copies of sent messages in
your phone, to overwrite old messages if the message
memory becomes full, and to set up other preferences
related to messages
Text messages — to allow delivery reports, to set up
message centres for SMS and SMS e-mail, to select the type
of character support, and to set up other preferences
related to text messages
Multimedia msgs. — to allow delivery reports, to set up
the appearance of multimedia messages, to allow the
30 Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
reception of multimedia messages and advertisements,
and to set up other preferences related to multimedia
messages
E-mail messages — to allow e-mail reception, to set the
image size in e-mail, and to set up other preferences
related to e-mail
Service messages — to activate service messages and to
set up preferences related to service messages
Contacts
Select Menu > Contacts.
You can save names and phone numbers in the phone
memory and SIM card memory. In the phone memory, you
can save contacts with numbers and text items. Names and
numbers saved in the SIM card memory are indicated by
.
To add a contact, select Names > Options > Add new
contact. To add details to a contact, ensure that the
memory in use is either Phone or Phone and SIM. Select
Names, scroll to the name, and select Details >
Options > Add detail.
Contacts 31
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To search for a contact, select Names, and scroll through
the list of contacts or enter the first letters of the name.
To copy a contact between the phone memory and SIM card
memory, select Names, scroll to the contact, and select
Options > Copy contact. In the SIM card memory, you can
save only one phone number for each name.
To select the SIM card or phone memory for your contacts,
to select how the names and numbers in contacts are
displayed, and to view the memory capacity for contacts,
select Settings.
You can send and receive a person's contact information
as a business card from a compatible device that supports
the vCard standard. To send a business card, select
Names, search for the contact whose information you
want to send, and select Details > Options > Send bus.
card.
Call log
To view the information on your calls, messages, data, and
synchronisation, select Menu > Log and from the
available options.
32 Call log
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Note: The actual invoice for calls and services from your
service provider may vary, depending on network features,
rounding off for billing, taxes, and so forth.
Settings
Profiles
Your phone has various setting groups called profiles,
which you can customise with ringing tones for different
events and environments.
Select Menu > Settings > Profiles, the desired profile,
and from the following options:
Activate — to activate the selected profile
Personalise — to change the profile settings
Timed — to set the profile to be active for a certain time.
When the time set for the profile expires, the previous
profile that was not timed becomes active.
Tones
You can change the tone settings of the selected active
profile.
Select Menu > Settings > Tones. You can find the same
settings in the Profiles menu.
Settings 33
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Display
To view or adjust the wallpaper, font size, or other features
related to the phone display, select Menu > Settings >
Display.
Date and time
Select Menu > Settings > Date and time.
To set the date and time, select Date and time settings.
To set the formats for date and time, select Date and time
format settings.
To set the phone to update the time and date automatically
according to the current time zone, select Auto-update of
date & time (network service).
Shortcuts
With personal shortcuts, you can get quick access to
frequently used phone functions. Select Menu >
Settings > My shortcuts.
To allocate one phone function to the right or left selection
key, select Right selection key or Left selection key.
34 Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To select shortcut functions for the scroll key, select
Navigation key. Scroll to the desired direction, and select
Change or Assign and a function from the list.
Synchronisation and backup
Select Menu > Settings > Sync and backup and from the
following:
Phone switch — Synchronise or copy selected data
between your phone and another phone using Bluetooth
technology.
Create backup — Create a backup of selected data to the
memory card or to an external device.
Restore from backup — Select a backup file stored on the
memory card or on an external device and restore it to the
phone. Select Options > Details for information about the
selected backup file.
Data transfer — Synchronise or copy selected data
between your phone and another device, PC, or network
server (network service).
Connectivity
Your phone has several features that allow you to connect
to other devices to transmit and receive data.
Settings 35
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Bluetooth wireless technology
Bluetooth technology allows you to connect your phone,
using radio waves, to a compatible Bluetooth device within
10 metres (32 feet).
This device is compliant with Bluetooth Specification 2.0 +
EDR supporting the following profiles: generic access,
hands-free, headset, object push, file transfer, dial-up
networking, serial port, SIM access, generic object
exchange, advanced audio distribution, audio video
remote control, and generic audio video distribution. To
ensure interoperability between other devices supporting
Bluetooth technology, use Nokia approved accessories for
this model. Check with the manufacturers of other devices
to determine their compatibility with this device.
Features using Bluetooth technology increase the demand
on battery power and reduce the battery life.
Set up a Bluetooth connection
Select Menu > Settings > Connectivity > Bluetooth and
take the following steps:
1 Select My phone's name and enter a name for your
phone.
2 To activate Bluetooth connectivity select Bluetooth >
On. indicates that Bluetooth is active.
36 Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
3 To connect your phone with an audio enhancement,
select Connect to audio enhancements and the
device that you want to connect to.
4 To pair your phone with any Bluetooth device in range,
select Paired devices > Add new device.
Scroll to a found device, and select Add.
Enter a passcode (up to 16 characters) on your phone
and allow the connection on the other Bluetooth
device.
If you are concerned about security, turn off the Bluetooth
function, or set My phone's visibility to Hidden. Accept
Bluetooth communication only from those you trust.
Packet data
General packet radio service (GPRS) is a network service
that allows mobile phones to send and receive data over
an internet protocol (IP)-based network.
To define how to use the service, select Menu >
Settings > Connectivity > Packet data > Packet data
connection and from the following options:
When needed — to establish the packet data connection
when an application needs it. The connection is closed
when the application is terminated.
Always online — to automatically connect to a packet
data network when you switch the phone on
Settings 37
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
You can use your phone as a modem by connecting it to a
compatible PC using Bluetooth technology. For details, see
the Nokia PC Suite documentation.
Calls and phone
Select Menu > Settings > Call.
To divert your incoming calls, select Call divert (network
service). For details, contact your service provider.
To make ten attempts to connect the call after an
unsuccessful attempt, select Automatic redial > On.
To have the network notify you of an incoming call while
you are in a call, select Call waiting > Activate (network
service).
To set whether to show your number to the person you are
calling, select Send my caller ID (network service).
To set the display language of your phone, select Menu >
Settings > Phone > Language settings > Phone
language.
38 Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Voice commands and voice dialling
Use your phone by saying a voice command, and make a
phone call by saying a name saved in Contacts.
Voice commands and voice dialling are language-
dependent. Voice recognition is not supported in all
languages. To see which languages are supported, select
Menu > Settings > Phone > Language settings >
Voice recognition language. To set the recognition
language, select the desired language.
Note: Using voice tags may be difficult in a noisy
environment or during an emergency, so you should not
rely solely upon voice dialling in all circumstances.
To train the voice recognition of your phone to your voice,
select Menu > Settings > Phone > Voice recognition >
Voice recognition training.
To activate a voice command for a function, select
Menu > Settings > Phone > Voice recognition > Voice
commands, a feature, and the function. indicates that
the voice command is activated.
To activate the voice command, select Add. To play the
activated voice command, select Playback.
To manage the voice commands, scroll to a function, and
select Options.
Settings 39
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To use voice commands or voice dialling, in the standby
mode, press and hold the right selection key. A short tone
sounds, and Speak now is displayed. Speak the command
or the name of the contact you want to dial. If the voice
recognition is successful, a list of proposed matches is
displayed. The phone plays the voice command of the first
match on the list. If it is not the correct command, scroll to
another entry.
Enhancements
This menu and its various options are shown only if the
phone is or has been connected to a compatible mobile
enhancement.
Select Menu > Settings > Enhancements. Select an
enhancement, and an option depending on the
enhancement.
Configuration
You can configure your phone with settings that are
required for certain services. Your service provider may
also send you these settings.
Select Menu > Settings > Configuration and from the
following options:
40 Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Default configu- ration settings — to view the service
providers saved in the phone and set a default service
provider
Activate default in all applications — to activate the
default configuration settings for supported applications
Preferred access point — to view the saved access points
Device manager settings — to allow or prevent the
phone from receiving software updates. This option may
not be available, depending on your phone.
Personal configu- ration settings to manually add
new personal accounts for various services and to activate
or delete them. To add a new personal account, select Add
new or Options > Add new. Select the service type, and
enter the required parameters. To activate a personal
account, scroll to it, and select Options > Activate.
Restore factory settings
To restore the phone back to factory conditions, select
Menu > Settings > Restore factory sett. and from the
following options:
Restore settings only — to reset all preference settings
without deleting any personal data
Restore all — to reset all preference settings and delete
all personal data, such as contacts, messages, media files
and activation keys
Settings 41
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Operator menu
Access a portal to services provided by your network
operator. For more information, contact your network
operator. The operator can update this menu with a service
message.
Gallery
Your phone supports a digital rights management (DRM)
system to protect acquired content. Always check the
delivery terms of any content and activation key before
acquiring them, as they may be subject to a fee.
Digital rights management
Content owners may use different types of digital rights
management (DRM) technologies to protect their
intellectual property, including copyrights. This device
uses various types of DRM software to access DRM-
protected content. With this device you can access content
protected with WMDRM 10, OMA DRM 1.0, OMA DRM 1.0
forward lock, and OMA DRM 2.0. If certain DRM software
fails to protect the content, content owners may ask that
such DRM software's ability to access new DRM-protected
content be revoked. Revocation may also prevent renewal
of such DRM-protected content already in your device.
Revocation of such DRM software does not affect the use
42 Operator menu
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
of content protected with other types of DRM or the use of
non-DRM-protected content.
Digital rights management (DRM) protected content comes
with an associated activation key that defines your rights
to use the content.
If your device has OMA DRM-protected content, to back up
both the activation keys and the content, use the backup
feature of Nokia PC Suite.
If your device has WMDRM-protected content, both the
activation keys and the content will be lost if the device
memory is formatted. You may also lose the activation keys
and the content if the files on your device get corrupted.
Losing the activation keys or the content may limit your
ability to use the same content on your device again. For
more information, contact your service provider.
To view the folders, select Menu > Gallery.
Media
Camera and video
Your device supports an image capture resolution of
480x640 pixels .
Media 43
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
For faster operation when capturing an image, set the
camera to use a lower resolution when a memory card is
not inserted.
Capture an image
To use the still image function, select Menu > Media >
Camera, or if the video function is activated, scroll left or
right. To capture an image, select Capture.
To zoom in or out in camera mode, scroll up or down.
To activate the self-timer, or to capture images in a fast
sequence, select Options and the appropriate option.
To set the image quality, image resolution, or preview
time, select Options > Settings.
Record a video clip
To use the video function, select Menu > Media > Video.
To start recording a video clip, select Record.
When recording, lower quality video can be recorded for a
greater length of time. To change the quality settings, and
to set the maximum length of the video clip, select
44 Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Menu > Media > Camera > Options > Settings > Video
clip quality, or Video clip length.
FM radio
Select Menu > Media > Radio or, in the standby mode,
press and hold *.
If you have already saved radio stations, scroll left or right
to switch between stations, or press the corresponding
number key of the memory location of a desired station.
To search for a neighbouring station, press and hold the
scroll key left or right.
To save the station to which you are tuned, select
Options > Save station.
To adjust the volume, scroll up or down.
To leave the radio playing in the background, press the end
key. To close the radio, press and hold the end key.
Media 45
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Voice recorder
To start recording, select Menu > Media > Recorder and
the virtual record button on the display.
To listen to the latest recording, select Options > Play last
recorded. To send the last recording using a multimedia
message, select Options > Send last recorded.
Music player
Your phone includes a music player for listening to songs
or other MP3 or AAC sound files.
Select Menu > Media > Music player.
To start or pause playing, press the middle selection key.
To skip to the beginning of the current song, scroll left.
To skip to the previous song, scroll left twice.
To skip to the next song, scroll right.
To rewind, press and hold the scroll key to the left.
To fast-forward, press and hold the scroll key to the right.
46 Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To adjust the volume, scroll up or down.
To mute or unmute the music player, press #.
To leave the music player playing in the background, press
the end key. To close the music player, press and hold the
end key.
Applications
Your phone software may include some games and Java
applications specially designed for this Nokia phone.
Select Menu > Applications.
To launch a game or application, select Games or
Collection. Scroll to a game or application, and select
Open.
To view the amount of memory available for game and
application installations, select Options > Memory
status.
To download a game or application, select Options >
Downloads > Game downloads or App. downloads.
Your phone supports J2ME™ Java applications. Ensure that
Applications 47
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
the application is compatible with your phone before
downloading it.
Important: Only install and use applications and other
software from trusted sources, such as applications that
are Symbian Signed or have passed the Java Verified™
testing.
Downloaded applications may be saved in Gallery instead
of Applications.
Organiser
Alarm clock
Select Menu > Organiser > Alarm clock.
To set the alarm on or off, select Alarm:.
To set the time for the alarm, select Alarm time:.
To set the phone to alert you on selected days of the week,
select Repeat:.
To select or personalise the alarm tone, select Alarm
tone:.
To set the time out for the snooze alert, select Snooze
timeout:.
48 Organiser
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
To stop the alarm, select Stop. If you let the phone continue
to sound the alarm for a minute or select Snooze, the alarm
stops for the snooze time-out, then resumes.
Calendar and to-do list
Select Menu > Organiser > Calendar. The current day is
framed. If there are any notes set for the day, the day is in
bold.
To make a calendar note, scroll to the date, and select
Options > Make a note.
To view the day notes, select View. To delete all notes in
the calendar, select Options > Delete notes > All notes.
To view the to-do list, select Menu > Organiser > To-do
list. The to-do list is displayed and sorted by priority. To
add, delete, or send a note, to mark the note as done, or
to sort the to-do list by deadline, select Options.
Web or Internet
You can access various internet services with your phone
browser. The appearance of the web pages may vary due
to screen size. You may not be able to see all the details on
the web pages.
Web or Internet 49
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Depending on your phone, the web browsing function may
be displayed as Web or Internet in the menu, hereafter
referred to as Web.
Important: Use only services that you trust and that offer
adequate security and protection against harmful
software.
For the availability of these services, pricing, and
instructions, contact your service provider.
You may receive the configuration settings required for
browsing as a configuration message from your service
provider.
Connect to a web service
To make a connection to the service, select Menu >
Web > Home; or in the standby mode, press and hold 0.
After you make a connection to the service, you can start
browsing its pages. The function of the phone keys may
vary in different services. Follow the text guides on the
phone display. For more information, contact your service
provider.
50 Web or Internet
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
SIM services
Your SIM card may provide additional services. You can
access this menu only if it is supported by your SIM card.
The name and contents of the menu depend on the
available services.
Green tips
Here are tips on how you can contribute to protecting the
environment.
Save energy
When you have fully charged the battery and disconnected
the charger from the device, remember to also unplug the
charger from the wall outlet.
You do not need to charge your battery so often if you do
the following:
Close and disable applications, services, and
connections when you are not using them.
SIM services 51
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Decrease the brightness of the screen.
Set the device to enter the power saver mode after the
minimum period of inactivity, if available in your
device.
Disable unnecessary sounds, such as keypad tones. Set
the volume of your device to an average level.
Recycle
Did you remember to recycle your old device? 65-80% of
the materials in a Nokia mobile phone can be recycled.
Always return your used electronic products, batteries, and
packaging materials to a dedicated collection point. By
doing this, you help prevent uncontrolled waste disposal
and promote the recycling of materials. Check how to
recycle your Nokia products at www.nokia.com/
werecycle or www.nokia.mobi/werecycle.
You may recycle the packaging and user guides at your
local recycling scheme.
Learn more
For more information on the environmental attributes of
your device, see www.nokia.com/ecodeclaration.
52 Green tips
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Accessories
Warning:
Use only batteries, chargers, and
accessories approved by Nokia for use
with this particular model. The use of
any other types may invalidate any
approval or warranty, and may be
dangerous.
For availability of approved accessories,
please check with your dealer. When
you disconnect the power cord of any
accessory, grasp and pull the plug, not
the cord.
Battery
Battery and charger information
Your device is powered by a
rechargeable battery. The battery
intended for use with this device is
BL-4C. Nokia may make additional
battery models available for this device.
This device is intended for use when
supplied with power from the following
chargers: AC-3. The exact charger model
number may vary depending on the type
of plug. The plug variant is identified by
one of the following: E, EB, X, AR, U, A, C,
or UB.
The battery can be charged and
discharged hundreds of times, but it will
eventually wear out. When the talk and
standby times are noticeably shorter
than normal, replace the battery. Use
only Nokia approved batteries, and
recharge your battery only with Nokia
approved chargers designated for this
device. Use of an unapproved battery or
charger may present a risk of fire,
explosion, leakage, or other hazard.
If a battery is being used for the first
time or if the battery has not been used
for a prolonged period, it may be
necessary to connect the charger, then
disconnect and reconnect it to begin
charging the battery. If the battery is
completely discharged, it may take
several minutes before the charging
indicator appears on the display or
before any calls can be made.
Always switch the device off and
disconnect the charger before removing
the battery.
Unplug the charger from the electrical
plug and the device when not in use. Do
not leave a fully charged battery
connected to a charger, since
overcharging may shorten its lifetime. If
left unused, a fully charged battery will
lose its charge over time.
Always try to keep the battery between
15°C and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and
Accessories 53
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
lifetime of the battery. A device with a
hot or cold battery may not work
temporarily. Battery performance is
particularly limited in temperatures
well below freezing.
Do not short-circuit the battery.
Accidental short-circuiting can occur
when a metallic object such as a coin,
clip, or pen causes direct connection of
the positive (+) and negative (-)
terminals of the battery. (These look like
metal strips on the battery.) This might
happen, for example, when you carry a
spare battery in your pocket or purse.
Short-circuiting the terminals may
damage the battery or the connecting
object.
Do not dispose of batteries in a fire as
they may explode. Batteries may also
explode if damaged. Dispose of
batteries according to local regulations.
Please recycle when possible. Do not
dispose as household waste.
Do not dismantle, cut, open, crush,
bend, deform, puncture, or shred cells or
batteries. In the event of a battery leak,
do not allow the liquid to come in
contact with the skin or eyes. In the
event of such a leak, flush your skin or
eyes immediately with water, or seek
medical help.
Do not modify, remanufacture, attempt
to insert foreign objects into the
battery, or immerse or expose it to
water or other liquids.
Improper battery use may result in a
fire, explosion, or other hazard. If the
device or battery is dropped, especially
on a hard surface, and you believe the
battery has been damaged, take it to a
service centre for inspection before
continuing to use it.
Use the battery only for its intended
purpose. Never use any charger or
battery that is damaged. Keep your
battery out of the reach of small
children.
Nokia battery authentication
guidelines
Always use original Nokia batteries for
your safety. To check that you are
getting an original Nokia battery,
purchase it from a Nokia authorised
service centre or dealer, and inspect the
hologram label using the following
steps:
Successful completion of the steps is not
a total assurance of the authenticity of
the battery. If you have any reason to
believe that your battery is not an
authentic, original Nokia battery, you
should refrain from using it, and take it
54 Battery
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
to the nearest Nokia authorised service
centre or dealer for assistance. If
authenticity cannot be verified, return
the battery to the place of purchase.
Authenticate hologram
1 When you look at the hologram on
the label, you should see the
Nokia connecting hands symbol
from one angle and the Nokia
Original Enhancements logo when
looking from another angle.
2 When you angle the hologram
left, right, down and up, you
should see 1, 2, 3 and 4 dots on
each side respectively.
What if your battery is not authentic?
If you cannot confirm that your Nokia
battery with the hologram on the label
is an authentic Nokia battery, please do
not use the battery. Take it to the
nearest Nokia authorised service centre
or dealer for assistance. The use of a
battery that is not approved by Nokia
may be dangerous and may result in
poor performance and damage to your
device and its accessories. It may also
invalidate any approval or warranty
applying to the device.
To find out more about original Nokia
batteries, see www.nokia.com/battery.
Battery 55
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Care and maintenance
Your device is a product of superior
design and craftsmanship and should be
treated with care. The following
suggestions will help you protect your
warranty coverage.
Keep the device dry. Precipitation,
humidity, and all types of liquids
or moisture can contain minerals
that will corrode electronic
circuits. If your device does get
wet, remove the battery, and
allow the device to dry completely
before replacing it.
Use a soft, clean, dry cloth to clean
any lenses, such as camera,
proximity sensor, and light sensor
lenses.
Do not use or store the device in
dusty, dirty areas. Its moving
parts and electronic components
can be damaged.
Do not store the device in hot
areas. High temperatures can
shorten the life of electronic
devices, damage batteries, and
warp or melt certain plastics.
Do not store the device in cold
areas. When the device returns to
its normal temperature, moisture
can form inside the device and
damage electronic circuit boards.
Do not attempt to open the device
other than as instructed in this
guide.
Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
Do not use harsh chemicals,
cleaning solvents, or strong
detergents to clean the device.
Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
Use only the supplied or an
approved replacement antenna.
Unauthorised antennas,
modifications, or attachments
could damage the device and may
violate regulations governing
radio devices.
Use chargers indoors.
Always create a backup of data
you want to keep, such as contacts
and calendar notes.
To reset the device from time to
time for optimum performance,
power off the device and remove
the battery.
These suggestions apply equally to your
device, battery, charger, or any
accessory. If any device is not working
56 Care and maintenance
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
properly, take it to the nearest
authorised service facility for service.
Recycle
Always return your used electronic
products, batteries, and packaging
materials to a dedicated collection
point. This way you help prevent
uncontrolled waste disposal and
promote the recycling of materials.
More detailed information is available
from the product retailer, local waste
authorities, national producer
responsibility organisations, or your
local Nokia representative. Check how to
recycle your Nokia products at
www.nokia.com/werecycle, or if
browsing on a mobile device,
www.nokia.mobi/werecycle.
The crossed-out wheeled-bin symbol on
your product, battery, literature, or
packaging reminds you that all electrical
and electronic products, batteries, and
accumulators must be taken to separate
collection at the end of their working
life. This requirement applies in the
European Union. Do not dispose of these
products as unsorted municipal waste.
For more environmental information,
see the product Eco-Declarations at
www.nokia.com/environment.
Additional safety information
The surface of this device is nickel-free.
Small children
Your device and its accessories may
contain small parts. Keep them out of
the reach of small children.
Operating environment
This device meets RF exposure
guidelines when used either in the
normal use position against the ear or
when positioned at least 1.5
centimetres (5/8 inch) away from the
body. When a carry case, belt clip, or
holder is used for body-worn operation,
it should not contain metal and should
position the device the above-stated
distance from your body.
To transmit data files or messages, this
device requires a quality connection to
the network. In some cases,
transmission of data files or messages
may be delayed until such a connection
is available. Ensure the above
separation distance instructions are
followed until the transmission is
completed.
Parts of the device are magnetic.
Metallic materials may be attracted to
Additional safety information 57
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
the device. Do not place credit cards or
other magnetic storage media near the
device, because information stored on
them may be erased.
Medical devices
Operation of any radio transmitting
equipment, including wireless phones,
may interfere with the functionality of
inadequately protected medical
devices. Consult a physician or the
manufacturer of the medical device to
determine if they are adequately
shielded from external RF energy or if
you have any questions. Switch off your
device in health care facilities when any
regulations posted in these areas
instruct you to do so. Hospitals or health
care facilities may be using equipment
that could be sensitive to external RF
energy.
Implanted medical devices
Manufacturers of medical devices
recommend that a minimum separation
of 15.3 centimetres (6 inches) should be
maintained between a wireless device
and an implanted medical device, such
as a pacemaker or implanted
cardioverter defibrillator, to avoid
potential interference with the medical
device. Persons who have such devices
should:
Always keep the wireless device
more than 15.3 centimetres (6
inches) from the medical device
when the wireless device is turned
on.
Not carry the wireless device in a
breast pocket.
Hold the wireless device to the ear
opposite the medical device to
minimise the potential for
interference.
Turn the wireless device off
immediately if there is any reason
to suspect that interference is
taking place.
Read and follow the directions
from the manufacturer of their
implanted medical device.
If you have any questions about using
your wireless device with an implanted
medical device, consult your health care
provider.
Hearing aids
Some digital wireless devices may
interfere with some hearing aids. If
interference occurs, consult your service
provider.
Vehicles
RF signals may affect improperly
installed or inadequately shielded
electronic systems in motor vehicles
58 Additional safety information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
such as electronic fuel injection systems,
electronic antiskid (antilock) braking
systems, electronic speed control
systems, and air bag systems. For more
information, check with the
manufacturer, or its representative, of
your vehicle or any equipment that has
been added.
Only qualified personnel should service
the device or install the device in a
vehicle. Faulty installation or service
may be dangerous and may invalidate
any warranty that may apply to the
device. Check regularly that all wireless
device equipment in your vehicle is
mounted and operating properly. Do
not store or carry flammable liquids,
gases, or explosive materials in the
same compartment as the device, its
parts, or accessories. For vehicles
equipped with an air bag, remember
that air bags inflate with great force. Do
not place objects, including installed or
portable wireless equipment in the area
over the air bag or in the air bag
deployment area. If in-vehicle wireless
equipment is improperly installed and
the air bag inflates, serious injury could
result.
Using your device while flying in aircraft
is prohibited. Switch off your device
before boarding an aircraft. The use of
wireless teledevices in an aircraft may
be dangerous to the operation of the
aircraft, disrupt the wireless telephone
network, and may be illegal.
Potentially explosive environments
Switch off your device when in any area
with a potentially explosive
atmosphere, and obey all signs and
instructions. Potentially explosive
atmospheres include areas where you
would normally be advised to turn off
your vehicle engine. Sparks in such areas
could cause an explosion or fire
resulting in bodily injury or even death.
Switch off the device at refuelling points
such as near gas pumps at service
stations. Observe restrictions on the use
of radio equipment in fuel depots,
storage, and distribution areas;
chemical plants; or where blasting
operations are in progress. Areas with a
potentially explosive atmosphere are
often, but not always, clearly marked.
They include below deck on boats,
chemical transfer or storage facilities
and areas where the air contains
chemicals or particles such as grain,
dust, or metal powders. You should
check with the manufacturers of
vehicles using liquefied petroleum gas
(such as propane or butane) to
determine if this device can be safely
used in their vicinity.
Additional safety information 59
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Emergency calls
Important: This device operates using
radio signals, wireless networks,
landline networks, and user-
programmed functions. If your device
supports voice calls over the internet
(internet calls), activate both the
internet calls and the cellular phone. The
device will attempt to make emergency
calls over both the cellular networks and
through your internet call provider if
both are activated. Connections in all
conditions cannot be guaranteed. You
should never rely solely on any wireless
device for essential communications
like medical emergencies.
To make an emergency call:
1 If the device is not on, switch it on.
Check for adequate signal
strength. Depending on your
device, you may also need to
complete the following:
Insert a SIM card if your
device uses one.
Remove certain call
restrictions you have
activated in your device.
Change your profile from
offline or flight profile mode
to an active profile.
2 Press the end key as many times
as needed to clear the display and
ready the device for calls.
3 Enter the official emergency
number for your present location.
Emergency numbers vary by
location.
4 Press the call key.
When making an emergency call, give all
the necessary information as accurately
as possible. Your wireless device may be
the only means of communication at the
scene of an accident. Do not end the call
until given permission to do so.
Certification information (SAR)
This mobile device meets guidelines
for exposure to radio waves.
Your mobile device is a radio transmitter
and receiver. It is designed not to exceed
the limits for exposure to radio waves
recommended by international
guidelines. These guidelines were
developed by the independent scientific
organisation ICNIRP and include safety
margins designed to assure the
protection of all persons, regardless of
age and health.
The exposure guidelines for mobile
devices employ a unit of measurement
known as the Specific Absorption Rate
60 Additional safety information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
or SAR. The SAR limit stated in the ICNIRP
guidelines is 2.0 watts/kilogram (W/kg)
averaged over 10 grams of tissue. Tests
for SAR are conducted using standard
operating positions with the device
transmitting at its highest certified
power level in all tested frequency
bands. The actual SAR level of an
operating device can be below the
maximum value because the device is
designed to use only the power required
to reach the network. That amount
changes depending on a number of
factors such as how close you are to a
network base station. The highest SAR
value under the ICNIRP guidelines for
use of the device at the ear is 0.66 W/
kg.
Use of device accessories may result in
different SAR values. SAR values may
vary depending on national reporting
and testing requirements and the
network band. Additional SAR
information may be provided under
product information at
www.nokia.com.
Your mobile device is also designed to
meet the requirements for exposure to
radio waves established by the Federal
Communications Commission (USA) and
Industry Canada. These requirements
set a SAR limit of 1.6 W/kg averaged over
one gram of tissue. The highest SAR
value reported under this standard
during product certification for use at
the ear is 0.78 W/kg and when properly
worn on the body is 0.81 W/kg.
Additional safety information 61
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Index
A
access codes 19
applications 47
audio messages 29
B
battery
charging 10
browser 49
C
call log 32
calls 21
configuration 40
D
display 34
E
e-mail 27
enhancements 40
F
flash messages 28
G
games 47
H
headset 11
I
IM 29
instant messaging 29
internet 49
K
keyguard 14
keypad lock 14
keys 12
M
memory card 8
message centre
number 25
messaging 24
audio messages 29
microSD card 8
62 Index
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
N
Nokia Care 20
number mode 22
O
offline mode 15
operator menu 42
organiser 48
P
passwords 19
PIN code 19
predictive text input 23
profiles 33
S
security code 19
settings 33
configuration 40
date 34
display 34
factory 41
phone 38
time 34
tones 33
shortcuts 34
SIM card 7, 15
SIM card, removing 8
speed dialling 21
T
text modes 22
tones 33
traditional text input 23
V
voice commands 39
voice dialling 39
voice recognition 39
voice recorder 46
W
web 49
write text 22
Index 63
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
DECLARATION OF CONFORMITY
0434
Hereby, NOKIA CORPORATION declares
that this RM-635 product is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC. A copy
of the Declaration of Conformity can be
found at www.nokia.com/phones/
declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and
Navi are trademarks or registered
trademarks of Nokia Corporation. Nokia
tune is a sound mark of Nokia
Corporation. Other product and
company names mentioned herein may
be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in
this document in any form without the
prior written permission of Nokia is
prohibited. Nokia operates a policy of
continuous development. Nokia
reserves the right to make changes and
improvements to any of the products
described in this document without
prior notice.
Includes RSA BSAFE cryptographic or
security protocol software from RSA
Security.
Java is a trademark of Sun Microsystems,
Inc.
This product is licensed under the
MPEG-4 Visual Patent Portfolio License
(i) for personal and noncommercial use
in connection with information which
has been encoded in compliance with
the MPEG-4 Visual Standard by a
consumer engaged in a personal and
noncommercial activity and (ii) for use
in connection with MPEG-4 video
provided by a licensed video provider.
No license is granted or shall be implied
for any other use. Additional
information, including that related to
promotional, internal, and commercial
uses, may be obtained from MPEG LA,
LLC. See http://www.mpegla.com.
TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, UNDER NO
64
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
CIRCUMSTANCES SHALL NOKIA OR ANY OF
ITS LICENSORS BE RESPONSIBLE FOR ANY
LOSS OF DATA OR INCOME OR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR
INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE
PROVIDED "AS IS". EXCEPT AS REQUIRED
BY APPLICABLE LAW, NO WARRANTIES OF
ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY
OR CONTENTS OF THIS DOCUMENT. NOKIA
RESERVES THE RIGHT TO REVISE THIS
DOCUMENT OR WITHDRAW IT AT ANY TIME
WITHOUT PRIOR NOTICE.
The availability of particular products
and applications and services for these
products may vary by region. Please
check with your Nokia dealer for details
and availability of language options.
This device may contain commodities,
technology or software subject to
export laws and regulations from the US
and other countries. Diversion contrary
to law is prohibited.
The third-party applications provided
with your device may have been created
and may be owned by persons or
entities not affiliated with or related to
Nokia. Nokia does not own the
copyrights or intellectual property
rights to the third-party applications. As
such, Nokia does not take any
responsibility for end-user support,
functionality of the applications, or the
information in the applications or these
materials. Nokia does not provide any
warranty for the third-party
applications. BY USING THE
APPLICATIONS YOU ACKNOWLEDGE THAT
THE APPLICATIONS ARE PROVIDED AS IS
WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED, TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW.
YOU FURTHER ACKNOWLEDGE THAT
NEITHER NOKIA NOR ITS AFFILIATES MAKE
ANY REPRESENTATIONS OR WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO WARRANTIES OF TITLE,
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, OR THAT THE
APPLICATIONS WILL NOT INFRINGE ANY
THIRD-PARTY PATENTS, COPYRIGHTS,
TRADEMARKS, OR OTHER RIGHTS.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio
interference (for example, when using a
telephone in close proximity to
receiving equipment). The FCC or
Industry Canada can require you to stop
using your telephone if such
interference cannot be eliminated. If
you require assistance, contact your
local service facility. This device
complies with part 15 of the FCC rules.
65
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Operation is subject to the following
two conditions: (1) This device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that
may cause undesired operation. Any
changes or modifications not expressly
approved by Nokia could void the user's
authority to operate this equipment.
xxxxxxx/Issue 1 EN
66
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Navigation menu
