Nokia C7–00 User Guide
9222032
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Contents
Safety 3
About this user guide 4
Use the in-device user guide 4
Get started 4
Keys and parts 4
Insert the SIM card and battery 5
Insert a memory card 6
Charging 7
Switch the device on or off 8
Nokia account and Nokia's Ovi
services 8
Device set-up 8
Copy contacts or pictures from your old
device 8
Lock or unlock the keys and screen 9
Change the volume of a call, song, or
video 9
Install Nokia Ovi Suite on your PC 9
Touch screen actions 10
Call a phone number 11
Answer a call 12
Mute a call 12
Save phone numbers and mail
addresses 12
Add your important contacts to the
home screen 12
Send a message 12
Personalisation 13
Personalise your tones 13
Change your theme 13
Switch between home screens 13
Personalise the home screen 13
Add items to the home screen 14
About Mail 14
Social networks 14
About Social 14
Take a picture 15
Find more help 15
Support 15
Keep your device software and
applications up to date 16
Back up files 16
Access codes 17
Green tips 17
Save energy 17
Recycle 18
Product and safety information 18
2 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when
mobile phone use is not
allowed or when it may cause
interference or danger, for
example, in aircraft, near
medical equipment, fuel,
chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep
your hands free to operate the
vehicle while driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
KEEP YOUR DEVICE DRY
Your device is not water-
resistant. Keep it dry.
GLASS PARTS
The front cover of the device is
made of glass. This glass can
break if the device is dropped
on a hard surface or receives a
substantial impact. If the glass
breaks, do not touch the glass
parts of the device or attempt
to remove the broken glass
from the device. Stop using the
device until the glass is
replaced by qualified service
personnel.
PROTECT YOUR HEARING
Listen to a headset at a
moderate level, and do not hold
the device near your ear when
the loudspeaker is in use.
www.nokia.com/support 3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
About this user guide
This short user guide helps you get started
with your device. With a short printed user
guide, Nokia helps save energy and paper.
Your device contains a complete in-device
user guide, which you can refer to for
additional information about your device.
To read the in-device user guide, select
Menu > Applications > User guide.
For even more support information, go to
www.nokia.com/support, or using a
mobile device, nokia.mobi/support.
Use the in-device user guide
Select Menu > Applications > User
guide.
Open the user guide from an
application
Select Options > User guide. This is not
available for every application.
Search the user guide
When the user guide is open, select
Options > Search, and enter a letter or a
word in the search field.
Switch between the user guide and an
application
Press and hold the menu key, swipe left or
right, and select the desired application.
Links to related topics may be at the end
of instructions. indicates a link to a
related topic, and indicates a link to a
web page.
Get started
Keys and parts
Top
1Micro USB connector
2Nokia AV connector (3.5 mm)
3Power key
Front
1Earpiece
2Call key
3Microphone
4Menu key
5End key
6Secondary camera lens
4 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Sides
1Charger connector
2Volume up/Zoom in key
3Voice key
4Volume down/Zoom out key
5Lock switch
6Camera key
Back
1Loudspeaker
2Camera lens
3Camera flash
4Secondary microphone
5Wrist strap hole
Touch screen
To control your device, lightly touch the
screen with your fingertips. The screen
does not respond when you use your
fingernails.
If your fingertips are cold, the screen may
not respond to your touch.
To avoid scratching the touch screen,
never use a pen, pencil, or other sharp
object to write on the touch screen.
Noise cancellation
If you are calling from a noisy
environment, your device filters out
background noise to make your voice
sound clearer to the person at the other
end of the line.
Noise cancellation is not available when
using the loudspeaker or a headset.
For the best noise cancellation, hold the
device with the earpiece to your ear and
the main microphone towards your
mouth. Do not cover the secondary
microphone at the back of the device.
Insert the SIM card and battery
Important: Do not use a micro-SIM or a
micro-SIM with an adapter in this device.
This device does not support use of micro-
SIM cards, and use of incompatible SIM
cards may damage the card or the device,
and may corrupt data stored on the card.
www.nokia.com/support 5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Follow the instructions carefully, to avoid
damaging the back cover.
Safe removal. Always switch the device off
and disconnect the charger before
removing the battery.
1 Unlock the back cover release latch,
and lift the back cover.
2 If the battery is inserted, lift the
battery out.
3 Insert a SIM card. Use the diagram
printed on the device to correctly
align the card.
4 Line up the contacts of the battery and
the battery compartment, and insert
the battery.
5 To replace the back cover, direct the
top locking catches toward their slots,
and press down until the cover locks
into place.
Insert a memory card
Switch off the device before inserting a
memory card.
1 Remove the back cover of the device.
2 If the battery is inserted, lift the
battery out.
3 Insert a compatible memory card into
the slot. Make sure the contact area of
the card is facing down.
4 Push the card in, until it clicks.
6 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
5 Replace the battery and the back
cover. Make sure the cover is properly
closed.
Charging
Charge the battery
Your battery has been partially charged at
the factory, but you may need to recharge
it before you can switch on your device for
the first time.
If the device indicates a low charge, do the
following:
1
2
You do not need to charge the battery for
a specific length of time, and you can use
the device while it is charging.
If the battery is completely discharged, it
may take several minutes before the
charging indicator appears on the display
or before any calls can be made.
Tip: You can also use a compatible USB
charger to charge your battery.
Charge the battery over USB
Battery low, but you don't have a charger
with you? You can use a compatible USB
cable to connect to a compatible device,
such as a computer.
To avoid breaking the charger connector,
be careful when connecting or
disconnecting the charger cable.
If connected to a computer, you can
synchronise your device while charging.
Charging over USB can take longer to start,
and may not work if you connect through
a non-powered USB hub. Your device
charges more quickly when connected to
a wall outlet.
When the battery is charging, the
charging indicator light next to the USB
connector is lit. When the battery charge
is low, the charging indicator light flashes.
It may take a while for charging to start.
www.nokia.com/support 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Switch the device on or off
Press and hold .
Nokia account and Nokia's Ovi services
When you switch on your device for the
first time, you can create a Nokia account,
so you can access Nokia's Ovi services.
With Ovi services and your Nokia account,
you can, for example:
•See your friends' statuses in different
social networking services
•Download games, applications,
videos, pictures, themes, and ringing
tones from Ovi Store
•Get to where you want to go with free
walk and drive navigation
•Back up and manage your contacts in
the Ovi internet service
To learn more about Ovi, go to
www.ovi.com.
To create a Nokia account later, use your
device to access an Ovi service, and you are
prompted to create an account.
Device set-up
To define some basic settings for your
device, select the Phone setup shortcut
that is in one of your home screens.
To switch between home screens, swipe
left or right.
With Phone setup, you can do the
following:
• Copy contacts, pictures, and other
content from your previous Nokia
device
• Personalise your device, by
changing the ringing tone and visual
theme
• Set up mail
• Update your device software
To define the settings later, you can also
select Menu > Applications > Tools >
Phone setup.
Copy contacts or pictures from your old
device
Use the Phone switch application to copy,
for example, contacts, calendar entries,
and pictures from your previous
compatible Nokia device, free of charge.
Select Menu > Applications > Tools >
Phone setup and Data transfer.
If your old Nokia device does not have the
Phone switch application, your new
8 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
device sends it in a message. Open the
message in the old device, and follow the
instructions.
1 Select the device you want to connect
to, and pair the devices. Bluetooth
needs to be activated.
2 If the other device requires a
passcode, enter the passcode. The
passcode, which you can define
yourself, must be entered in both
devices. The passcode in some devices
is fixed. For details, see the user guide
of the device.
The passcode is valid only for the
current connection.
3 Select the content and OK.
Lock or unlock the keys and screen
To avoid accidentally making a call when
your device is in your pocket or bag, lock
the keys and screen of your device.
Slide the lock switch.
Set the keys and screen to lock
automatically
1 Select Menu > Settings and
Phone > Display > Screen/keylock
time-out.
2 Define the length of time after which
the keys and screen are locked
automatically.
Change the volume of a call, song, or
video
Use the volume keys.
The built-in loudspeaker allows you to
speak and listen from a short distance
without having to hold the device to your
ear.
Activate or deactivate the loudspeaker
during a call
Select or .
Install Nokia Ovi Suite on your PC
With the Nokia Ovi Suite PC application,
you can manage content on your device,
and keep it in sync with your computer.
Download the latest version of Nokia Ovi
Suite from www.ovi.com/suite.
If you cannot connect to the internet, to
install Ovi Suite and Nokia Ovi Player from
your device:
1 Use a compatible USB data cable to
connect your device to your
computer.
If you are using Windows XP or
Windows Vista on your computer, set
the USB mode of your device to Nokia
Ovi Suite. On your device, select the
notification area in the top right
corner, and select > USB > Mass
storage.
Your device mass memory appears as
a removable disk on your PC.
www.nokia.com/support 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2 On your computer, select Install
Nokia Ovi Suite.
If the installation window does not
open automatically, open the
installation file manually. Select Open
folder to view files, and double-click
Install_Nokia_Ovi_Suite.exe.
3 Follow the instructions.
4 When the installation is complete, if
you are using Windows XP or
Windows Vista on your computer, set
the USB mode of your device to Nokia
Ovi Suite. On your device, select the
notification area in the top right
corner, and select > USB >
Media transfer.
To learn more about Ovi Suite, go to
www.ovi.com/suite.
Touch screen actions
To interact with the user interface, tap or
tap and hold the touch screen.
Open an application or other screen
element
Tap the application or element.
Access functions quickly
Tap and hold the item. A pop-up menu
with available options opens. For
example, to send an image or delete an
alarm, tap and hold the image or alarm,
and from the pop-up menu, select the
appropriate option.
If you tap and hold the home screen,
editing mode is activated.
10 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Drag an item
Tap and hold the item, and slide your
finger across the screen. The item follows
your finger.
You can drag items in the home screen or
the main menu, when you have activated
editing mode.
Swipe
Place a finger on the screen, and steadily
slide your finger in the desired direction.
For example, when you are viewing a
picture, to view the next picture, swipe
left.
Scroll in a list or menu
Place your finger on the screen, slide it
quickly up or down the screen, then lift
your finger. The content of the screen
scrolls with the speed and direction it had
at the moment of release. To select an
item from a scrolling list and to stop the
movement, tap the item.
Zoom in
Place two fingers on an item, such as a
picture or web page, and slide your fingers
apart.
Zoom out
Place two fingers on the item, and slide
your fingers together.
Call a phone number
1 In the home screen, select Call to open
the dialler, and enter the phone
number.
To enter the + character, used for
international calls, select * twice.
www.nokia.com/support 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2 To make the call, press the call key.
3 To end the call, press the end key.
Tip: To call a contact, in the home screen,
select Call, and start entering the contact's
name.
Answer a call
When a call arrives, press the call key.
Mute a call
You can mute the microphone in your
device during a call.
Press the voice key.
The menu key light changes from white to
red when the microphone is muted.
Save phone numbers and mail
addresses
You can save your friends' phone
numbers, mail addresses, and other
information to your contacts list.
Select Menu > Contacts.
Add a contact to the contacts list
1 Select Options > New contact.
2 Select a field, and enter the details. To
close the text input, select .
Edit contact information
1 Select a contact.
2 Open the contact card tab .
3 Select a contact detail.
Add details about a contact
Select a contact and Options > Edit >
Options > Add detail.
Add your important contacts to
the home screen
Add your most important contacts to the
home screen, so you can quickly call or
send messages to them.
The contacts need to be stored in your
device memory.
1 In the Favourite contacts widget,
select .
2 To mark the contacts to add to the
home screen, select the desired
contacts. You can add up to 20
contacts to the widget.
Call or send a message to a contact
In the widget, select the contact.
Remove a contact from the home
screen
In the widget, select and the contact to
remove. The contact is deleted from the
widget, but remains in your contacts list.
Send a message
With text and multimedia messages, you
can quickly contact your friends and
family. In a multimedia message, you can
attach pictures, videos, and sound clips
that you want to share.
Select Menu > Messaging.
1 Select New message.
2 To select recipients from the contacts
list, select the To title. To enter the
recipient’s phone number manually,
enter the number in the To field.
3 To add an attachment, select .
12 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
4 Select .
Sending a message with an attachment
may be more expensive than sending a
normal text message. For more
information, contact your service
provider.
If the item you inserted in a multimedia
message is too large for the network, the
device may automatically reduce the size.
Only compatible devices can receive and
display multimedia messages. Messages
may look different in different devices.
Personalisation
Personalise your tones
You can personalise your device tones for
each profile.
Select Menu > Settings > Profiles.
1 Select the desired profile.
2 Select Personalise and the desired
option.
Tip: Download ringing tones from Ovi
Store. To learn more about Ovi Store, go
to www.ovi.com.
Change your theme
With themes, you can change the
colours and look of your display.
Select Menu > Settings > Themes.
Select General and a theme.
Some themes include background
animation effects. To save battery power,
select General > Options > Theme
effects > Off.
Tip: Download themes from Ovi Store. To
learn more about Ovi Store, go to
www.ovi.com.
Switch between home screens
You can have more than one home screen.
To switch to another home screen, swipe
left or right.
indicates which home screen you
are in.
Personalise the home screen
You can change wallpaper, and rearrange
home screen items.
Rearrange items in the home screen
1 Tap and hold the home screen.
2 Drag and drop items to a new
location.
Change the wallpaper
1 Tap and hold the home screen.
2 Select Options > Change
wallpaper.
3 Select the desired picture.
Tip: Download more background images
from Ovi Store. For details, go to
www.ovi.com.
www.nokia.com/support 13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Add items to the home screen
You can create shortcuts to your most
used features and add mini-applications
(widgets) that display helpful
information.
Add a shortcut to the home screen
You can add shortcuts to applications,
web bookmarks, or actions, such as
writing a message.
1 Tap and hold the home screen.
2 Select the shortcut widget and
Settings.
3 Select the shortcut you want to
define, and select Application or
Bookmark and the desired item.
Tip: To remove a shortcut, replace it with
another one.
Add a widget to the home screen
1 Tap and hold the home screen.
2 Select and the desired widget from
the list.
Tip: To download more widgets, select
Store.
Remove a widget from the home
screen
1 Tap and hold the home screen.
2 Select the widget, and from the pop-
up menu, select Remove.
About Mail
Select Menu > Applications > Mail.
With Mail, you can add several mailboxes
and access them directly from your home
screen. In the main mail view, you can
switch from one mailbox to another.
If you do not have a mail account, you can
create one at www.ovi.com.
1Write a mail.
2Switch between your mailboxes.
3Sort your mail by, for example, date.
4Mail in current mailbox.
Mail contains interactive elements. Select
and hold, for example, a mail to view a
pop-up menu.
Social networks
About Social
Select Menu > Social, sign in to Ovi by
Nokia, and then sign in to your relevant
social networking services.
With the Social application, you can
enhance your social networking
experience. When signed in to social
networking services through Ovi by Nokia,
you can do the following:
•See your friends' status updates from
multiple services in one view
14 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•Post your own status update to
multiple services at the same time
•Instantly share pictures you take with
the camera
•Link your online friends' profiles to
their contact information in your
device
•Add your location information to your
status update
•Add events from the service calendar
to your device calendar
Only those features that are supported by
the social networking service are
available.
Using social networking services requires
network support. This may involve the
transmission of large amounts of data and
related data traffic costs. For information
about data transmission charges, contact
your service provider.
The social networking services are third
party services and not provided by Nokia.
Check the privacy settings of the social
networking service you are using as you
may share information with a large group
of people. The terms of use of the social
networking service apply to sharing
information on that service. Familiarise
yourself with the terms of use and the
privacy practices of that service.
Take a picture
Press and hold the camera key.
Your device camera has the full focus
feature. With this feature, you can take
pictures where objects both in the
foreground and background are in focus.
1 To activate the face tracking feature,
select > Face detect.. The face
tracker detects and draws rectangles
around faces, even when they are
moving.
2 Press the camera key. Do not move the
device before the picture is saved and
the final picture displayed.
Find more help
Support
When you want to learn more about how
to use your product or you are unsure how
your device should function, go to
www.nokia.com/support, or using a
mobile device, nokia.mobi/support. You
can also select Menu > Applications >
User guide in your device.
If this does not resolve your issue, do one
of the following:
•Reboot your device. Switch off the
device, and remove the battery. After
about a minute, replace the battery,
and switch on the device.
•Restore the original factory settings.
•Update your device software.
If your issue remains unsolved, contact
Nokia for repair options. Go to
www.nokia.com/repair. Before sending
your device for repair, always back up the
data in your device.
www.nokia.com/support 15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Keep your device software and
applications up to date
About device software and application
updates
With device software updates and
application updates, you can get new
features and enhanced functions for your
device. Updating the software may also
improve your device performance.
It is recommended that you back up your
personal data before updating your
device software.
Warning:
If you install a software update, you
cannot use the device, even to make
emergency calls, until the installation is
completed and the device is restarted.
After you update your device software or
applications, the instructions in the user
guide may no longer be up to date.
Update device software and
applications using your device
You can check if there are updates
available for your device software or for
individual applications, and then
download and install them to your device
(network service). You can also set your
device to automatically check for updates
and notify you when important or
recommended updates are available.
Select Menu > Applications > Tools >
SW update.
If there are available updates, select
which updates to download and install,
and select .
Set your device to automatically check
for updates
Select Options > Settings > Auto-check
for updates.
Update device software using your PC
You can use the Nokia Software Updater
PC application to update your device
software. To update your device software,
you need a compatible PC, a high-speed
internet connection, and a compatible
USB data cable to connect your device to
the PC.
To get more information and to download
the Nokia Software Updater application,
go to www.nokia.com/softwareupdate.
Back up files
Want to make sure that you will not lose
any important files? You can back up the
device memory to a compatible computer
or memory card.
16 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Select Menu > Applications > Office >
File mgr. and Backup.
It is recommended that you back up the
device memory regularly to a compatible
computer or memory card.
Tip: If you have DRM-protected content,
use Nokia Ovi Suite to back up both the
licences and the content to your
computer.
Access codes
PIN code — This code protects your SIM
card against unauthorised use. The PIN
code (4 - 8 digits) is usually supplied with
the SIM card.
PIN2 code — This code (4 - 8 digits) is
supplied with some SIM cards, and is
required to access some functions in your
device.
If you forget an access code, contact the
network service provider whose SIM card
is in your device. After three consecutive
incorrect PIN or PIN2 code entries, the
code is blocked, and you need the PUK
code to unblock it.
PUK code and PUK2 code — These codes (8
digits) are required to change a blocked
PIN code or PIN2 code, respectively. If the
codes are not supplied with the SIM card,
contact the network service provider
whose SIM card is in your device.
IMEI number — This number (15 or 17
digits) is used to identify valid devices in
the GSM network. Devices that are, for
example, stolen, can be blocked from
accessing the network. The IMEI number
for your device can be found under the
battery.
Lock code (also known as security
code) — The lock code helps you to protect
your device against unauthorised use. You
can create and change the code, and set
the device to request the code. Keep the
new code secret and in a safe place
separate from your device. If you forget
the code and your device is locked, your
device will require service. Additional
charges may apply, and all the personal
data in your device may be deleted. For
more information, contact a Nokia Care
Point or your device dealer.
Green tips
Save energy
You do not need to charge your battery so
often if you do the following (if available
for your device):
•Close applications and data
connections, for example, your
Bluetooth connection, when not in
use.
•Decrease the brightness of the screen.
•Set your device to enter power saver
mode after the minimum period of
inactivity, if available in your device.
www.nokia.com/support 17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•Deactivate unnecessary sounds, such
as key tones.
Recycle
All materials of this device can be
recovered as materials and energy. For
information on how to recycle your old
Nokia products, go to www.nokia.com/
werecycle, or using a mobile device,
nokia.mobi/werecycle.
Recycle packaging and user guides at your
local recycling scheme.
The crossed-out wheeled-bin symbol on
your product, battery, literature, or
packaging reminds you that all electrical
and electronic products, batteries, and
accumulators must be taken to separate
collection at the end of their working life.
This requirement applies in the European
Union. Do not dispose of these products as
unsorted municipal waste. For more
information on the environmental
attributes of your device, see
www.nokia.com/ecodeclaration.
Product and safety information
Network services and costs
Your device is approved for use on the GSM 850, 900, 1800,
1900 MHz networks, and WCDMA 850, 900, 1700, 1900, 2100
MHz networks. To use the device, you need a subscription
with a service provider.
Using network services and downloading content to your
device may result in data traffic costs. Some product features
require support from the network, and you may need to
subscribe to them.
Take care of your device
Handle your device, battery, charger and accessories with
care. The following suggestions help you protect your
warranty coverage.
•Keep the device dry. Precipitation, humidity, and all
types of liquids or moisture can contain minerals that
corrode electronic circuits. If your device gets wet,
remove the battery, and allow the device to dry.
•Do not use or store the device in dusty or dirty areas.
Moving parts and electronic components can be
damaged.
•Do not store the device in high temperatures. High
temperatures can shorten the life of the device,
damage the battery, and warp or melt plastics.
•Do not store the device in cold temperatures. When the
device warms to its normal temperature, moisture can
form inside the device and damage electronic circuits.
•Do not attempt to open the device other than as
instructed in the user guide.
•Unauthorised modifications may damage the device
and violate regulations governing radio devices.
•Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and
mechanics.
•Only use a soft, clean, dry cloth to clean the surface of
the device.
•Do not paint the device. Paint can clog the moving parts
and prevent proper operation.
•Switch off the device and remove the battery from time
to time for optimum performance.
•Keep your device away from magnets or magnetic
fields.
•To keep your important data safe, store it in at least
two separate places, such as your device, memory card,
or computer, or write down important information.
During extended operation, the device may feel warm. In
most cases, this condition is normal. If you suspect the device
is not working properly, take it to the nearest authorised
service facility.
Recycle
Always return your used electronic products, batteries, and
packaging materials to dedicated collection points. This way
you help prevent uncontrolled waste disposal and promote
the recycling of materials. Check product environmental
information and how to recycle your Nokia products at
www.nokia.com/werecycle, or with a mobile device, http://
nokia.mobi/werecycle.
Batteries and chargers
Nokia battery authentication guidelines
Always use original Nokia batteries for your safety. To help
ensure that you are getting an original Nokia battery,
purchase it from a Nokia authorised service centre or dealer,
and check the hologram label.
18 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Authenticate hologram
1 Look at the hologram. You should see the Nokia
connecting hands symbol from one angle and the Nokia
Original Accessories logo from the other angle.
2 Angle the hologram left, right, down, and up. You
should see 1, 2, 3 and 4 dots on each side respectively.
However, this is not a total assurance of the authenticity of
the battery. If you cannot confirm authenticity or if you have
any reason to believe that your Nokia battery with the
hologram on the label is not an authentic Nokia battery, stop
using the battery and take it to the nearest Nokia authorised
service centre or dealer.
To find out more about original Nokia batteries, go to
www.nokia.com/battery.
Battery and charger information
This device is intended for use with a BL-5K rechargeable
battery. Nokia may make additional battery models available
for this device. Always use original Nokia batteries.
This device is intended for use when supplied with power
from the following chargers: AC-15. The exact charger model
number may vary depending on the type of plug. The plug
variant is identified by one of the following: E, X, AR, U, A, C,
K, or B.
The battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, you need
to replace the battery.
Battery safety
Always switch the device off and disconnect the charger
before removing the battery. When you unplug a charger or
an accessory, hold and pull the plug, not the cord.
When your charger is not in use, unplug it from the electrical
plug and the device. Do not leave a fully charged battery
connected to a charger, as overcharging may shorten the
battery’s lifetime. If left unused, a fully charged battery will
lose its charge over time.
Always keep the battery between 15°C and 25°C (59°F and
77°F). Extreme temperatures reduce the capacity and lifetime
of the battery. A device with a hot or cold battery may not
work temporarily.
Accidental short-circuiting can happen when a metallic object
touches the metal strips on the battery, for example, if you
carry a spare battery in your pocket. Short-circuiting may
damage the battery or the connecting object.
Do not dispose of batteries in a fire as they may explode.
Dispose of batteries according to local regulations. Recycle
when possible. Do not dispose as household waste.
Do not dismantle, cut, open, crush, bend, puncture, or shred
cells or batteries. If a battery leaks, do not let battery liquid
touch skin or eyes. If this happens, immediately flush the
affected areas with water, or seek medical help.
Do not modify, remanufacture, attempt to insert foreign
objects into the battery, or immerse or expose it to water or
other liquids. Batteries may explode if damaged.
Use the battery and charger for their intended purposes only.
Improper use, or use of unapproved batteries or chargers may
present a risk of fire, explosion, or other hazard, and may
invalidate any approval or warranty. If you believe the battery
or charger is damaged, take it to a service centre for
inspection before continuing to use it. Never use a damaged
battery or charger. Only use the charger indoors.
Additional safety information
Emergency calls
Make an emergency call
1 Ensure the device is switched on.
2 Check for adequate signal strength. You may also need
to do the following:
•Insert a SIM card.
•Remove call restrictions you have activated for
your device, such as call barring, fixed dialling, or
closed user group.
•Ensure your device is not in an offline or flight
profile.
www.nokia.com/support 19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•If the device screen and keys are locked, unlock
them.
3 To clear the display, press the end key as many times
as needed.
4 Select Call.
5 Enter the official emergency number for your present
location. Emergency call numbers vary by location.
6Press the call key.
7 Give the necessary information as accurately as
possible. Do not end the call until given permission to
do so.
Important: Activate both cellular and internet calls, if your
device supports internet calls. The device may attempt to
make emergency calls both through cellular networks and
through your internet call service provider. Connections in all
conditions cannot be guaranteed. Never rely solely on any
wireless device for essential communications like medical
emergencies.
Small children
Your device, its battery and accessories are not toys. They may
contain small parts. Keep them out of the reach of small
children.
Medical devices
Operation of radio transmitting equipment, including
wireless phones, may interfere with the function of
inadequately protected medical devices. Consult a physician
or the manufacturer of the medical device to determine
whether they are adequately shielded from external RF
energy. Switch off your device when regulations posted
instruct you to do so, for example, in hospitals.
Implanted medical devices
Manufacturers of medical devices recommend a minimum
separation of 15.3 centimetres (6 inches) between a wireless
device and an implanted medical device, such as a pacemaker
or implanted cardioverter defibrillator, to avoid potential
interference with the medical device. Persons who have such
devices should:
•Always keep the wireless device more than 15.3
centimetres (6 inches) from the medical device.
•Not carry the wireless device in a breast pocket.
•Hold the wireless device to the ear opposite the medical
device.
•Turn the wireless device off if there is any reason to
suspect that interference is taking place.
•Follow the manufacturer directions for the implanted
medical device.
If you have any questions about using your wireless device
with an implanted medical device, consult your health care
provider.
Hearing
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it can
endanger your safety.
Some wireless devices may interfere with some hearing aids.
Protect your device from harmful content
Your device may be exposed to viruses and other harmful
content. Take the following precautions:
•Be cautious when opening messages. They may contain
malicious software or otherwise be harmful to your
device or computer.
•Be cautious when accepting connectivity requests,
browsing the internet, or downloading content. Do not
accept Bluetooth connections from sources you do not
trust.
•Only install and use services and software from sources
that you trust and that offer adequate security and
protection.
•Install antivirus and other security software on your
device and any connected computer. Only use one
antivirus application at a time. Using more may affect
performance and operation of the device and/or
computer.
•If you access preinstalled bookmarks and links to third
party internet sites, take the appropriate precautions.
Nokia does not endorse or assume liability for such
sites.
Operating environment
This device meets RF exposure guidelines in the normal use
position at the ear or at least 1.5 centimetres (5/8 inch) away
from the body. Any carry case, belt clip, or holder for body-
worn operation should not contain metal and should position
the device the above-stated distance from your body.
To send data files or messages requires a quality connection
to the network. Data files or messages may be delayed until
such a connection is available. Follow the separation distance
instructions until the transmission is completed.
Vehicles
Radio signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles such as
electronic fuel injection, electronic antilock braking,
electronic speed control, and air bag systems. For more
20 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
information, check with the manufacturer of your vehicle or
its equipment.
Only qualified personnel should install the device in a vehicle.
Faulty installation or service may be dangerous and may
invalidate your warranty. Check regularly that all wireless
device equipment in your vehicle is mounted and operating
properly. Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the device,
its parts, or accessories. Remember that air bags inflate with
great force. Do not place your device or accessories in the air
bag deployment area.
Switch off your device before boarding an aircraft. The use of
wireless devices in an aircraft may be dangerous to the
operation of the aircraft and may be illegal.
Potentially explosive environments
Switch off your device in any area with a potentially explosive
atmosphere. Obey all posted instructions. Sparks in such
areas could cause an explosion or fire resulting in bodily
injury or death. Switch off the device at refuelling points such
as near gas pumps at service stations. Observe restrictions in
fuel depots, storage, and distribution areas; chemical plants;
or where blasting operations are in progress. Areas with a
potentially explosive atmosphere are often, but not always,
clearly marked. They include areas where you would be
advised to turn off your vehicle engine, below deck on boats,
chemical transfer or storage facilities and where the air
contains chemicals or particles such as grain, dust, or metal
powders. You should check with the manufacturers of
vehicles using liquefied petroleum gas (such as propane or
butane) to determine if this device can be safely used in their
vicinity.
Wet or dusty conditions
Important: Accessories for use with this device are not as
durable or water-resistant as the device. For example,
chargers should only be used in dry conditions, never when
damp or wet.
•Water-resistance means resistance against cold, clean
fresh water only. Do not expose the device to any other
type of liquid, such as sea water.
•Do not submerge your device in water.
•If the device has been exposed to water, wipe it off with
a dry cloth. If it has been exposed to any other liquid,
immediately splash some clean fresh water onto the
device. Wipe the device carefully dry.
•Do not charge the device or connect anything to the
connectors if they are dusty, wet, or damp.
•If the connectors are dusty, open the connector cover
of the device and splash clean freshwater onto the
connectors to remove the dust. Wipe the device and
connector area dry carefully, and let the inside of the
connectors dry.
•Only open the back cover in dry and clean conditions,
and wipe the device dry and clean before opening the
back cover to prevent water or dust from reaching the
interior of the device. Make sure the interior of your
device and the back cover seals are dry, clean, and free
of any foreign objects, as they may damage the seals
against water.
Certification information (SAR)
This mobile device meets guidelines for exposure to
radio waves.
Your mobile device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines
were developed by the independent scientific organisation
ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The exposure guidelines for mobile devices employ a unit of
measurement known as the Specific Absorption Rate or SAR.
The SAR limit stated in the ICNIRP guidelines is 2.0 watts/
kilogram (W/kg) averaged over 10 grams of tissue. Tests for
SAR are conducted using standard operating positions with
the device transmitting at its highest certified power level in
all tested frequency bands. The actual SAR level of an
operating device can be below the maximum value because
the device is designed to use only the power required to reach
the network. That amount changes depending on a number
of factors such as how close you are to a network base station.
The highest SAR value under the ICNIRP guidelines for use of
the device at the ear is 0.73 W/kg.
Use of device accessories may result in different SAR values.
SAR values may vary depending on national reporting and
testing requirements and the network band. Additional SAR
information may be provided under product information at
www.nokia.com.
Your mobile device is also designed to meet the requirements
for exposure to radio waves established by the Federal
Communications Commission (USA) and Industry Canada.
These requirements set a SAR limit of 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported under this
standard during product certification for use at the ear is 1.03
W/kg and when properly worn on the body is 0.83 W/kg.
Feature-specific information
Use of the Mail for Exchange is limited to over-the-air
synchronisation of PIM information between the Nokia device
and the authorised Microsoft Exchange server.
www.nokia.com/support 21
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Note: Using WLAN may be restricted in some countries. For
example, in France, you are only allowed to use WLAN
indoors. For more information, contact your local authorities.
Note: FM transmitter can not be used in Greece. For more
information, contact you local operator and go to
www.nokia.com/fmtransmitter.
Do not connect products that create an output signal as this
may cause damage to the device. Do not connect any voltage
source to the Nokia AV connector. If you connect an external
device or headset, other than those approved by Nokia for
use with this device, to the Nokia AV connector, pay special
attention to volume levels.
Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-675
product is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC. A copy of the
Declaration of Conformity can be found at www.nokia.com/
phones/declaration_of_conformity/.
© 2010 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Original Accessories
logo, and Ovi by Nokia are trademarks or registered
trademarks of Nokia Corporation. Nokia tune is a sound mark
of Nokia Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or storage of part or all
of the contents in this document in any form without the prior
written permission of Nokia is prohibited. Nokia operates a
policy of continuous development. Nokia reserves the right
to make changes and improvements to any of the products
described in this document without prior notice.
Java and all Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent
Portfolio License (i) for personal and noncommercial use in
connection with information which has been encoded in
compliance with the MPEG-4 Visual Standard by a consumer
engaged in a personal and noncommercial activity and (ii) for
use in connection with MPEG-4 video provided by a licensed
video provider. No license is granted or shall be implied for
any other use. Additional information, including that related
to promotional, internal, and commercial uses, may be
obtained from MPEG LA, LLC. See http://www.mpegla.com.
To the maximum extent permitted by applicable law, under
no circumstances shall Nokia or any of its licensors be
responsible for any loss of data or income or any special,
incidental, consequential or indirect damages howsoever
caused.
The contents of this document are provided "as is". Except as
required by applicable law, no warranties of any kind, either
express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular
purpose, are made in relation to the accuracy, reliability or
contents of this document. Nokia reserves the right to revise
this document or withdraw it at any time without prior
notice.
Reverse engineering of software in the device is prohibited
to the extent permitted by applicable law. Insofar as this user
guide contains any limitations on Nokia's representations,
warranties, damages and liabilities, such limitations shall
likewise limit any representations, warranties, damages and
liabilities of Nokia's licensors.
The availability of products, features, applications and
services may vary by region. For more information, contact
your Nokia dealer or your service provider. This device may
contain commodities, technology or software subject to
export laws and regulations from the US and other countries.
Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example,
when using a telephone in close proximity to receiving
equipment). The FCC or Industry Canada can require you to
stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local
service facility. This device complies with part 15 of the FCC
rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation. Any
changes or modifications not expressly approved by Nokia
could void the user's authority to operate this equipment.
Some operations and features are SIM card and/or network
dependent, MMS dependent, or dependent on the
22 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
compatibility of devices and the content formats supported.
Some services are subject to a separate charge.
9222032/Issue 1 EN
www.nokia.com/support 23
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
