Nokia C2-01 User Guide
C2-01.5
5555555
Issue 1
Contents
Safety 4
About your device 5
Network services 5
Get started 7
Keys and parts 7
Insert SIM card and battery 7
Insert a memory card 9
Remove the memory card 9
Charge the battery 10
Attach the wrist strap 10
Switch the device on or off 10
GSM antenna 11
Headset 11
Basic use 12
Keypad lock 12
Access codes 12
PUK codes 12
Volume control 13
Standby mode 13
Indicators 13
Navigate the menus 14
Shortcuts 14
Operator menu 14
Use your device without a SIM card 15
Write text 15
Nokia account and Nokia's Ovi
services 16
About Ovi Store 16
Contacts 16
Calls 17
Make and answer a call 17
Loudspeaker 17
Dialling shortcuts 18
Log 18
Messaging 18
Text and multimedia messages 18
Mail 20
Chat with your friends 21
Flash messages 21
Nokia Xpress audio messages 21
Voice messages 21
Message settings 22
Organiser 22
Alarm clock 22
Calendar and to-do list 22
Web or Internet 23
About Web 23
Connect to a web service 23
Media 24
Camera and video 24
FM radio 24
Voice recorder 25
Music player 25
Gallery 26
Settings 27
Profiles 27
Tones 28
Display 28
Date and time 28
Synchronisation and backup 28
Connectivity 29
Call and phone 30
Restore factory settings 31
Find more help 31
Support 31
About device software updates 31
Update device software using your
device 32
Update device software using your
PC 33
2Contents
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when
it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
4Safety
About your device
The wireless device described in this guide is approved for use on the (E)GSM 850, 900,
1800, and 1900 MHz networks, and UMTS 850/1900/2100 MHz networks. Contact your
service provider for more information about networks.
Your device may have preinstalled bookmarks and links for third-party internet sites
and may allow you to access third-party sites. These are not affiliated with Nokia, and
Nokia does not endorse or assume liability for them. If you access such sites, take
precautions for security or content.
Warning:
To use any features in this device, other than the alarm clock, the device must be
switched on. Do not switch the device on when wireless device use may cause
interference or danger.
When using this device, obey all laws and respect local customs, privacy and legitimate
rights of others, including copyrights. Copyright protection may prevent some images,
music, and other content from being copied, modified, or transferred.
Make back-up copies or keep a written record of all important information stored in
your device.
When connecting to any other device, read its user guide for detailed safety instructions.
Do not connect incompatible products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about your device.
Network services
To use the device you must have service from a wireless service provider. Some features
are not available on all networks; other features may require that you make specific
arrangements with your service provider to use them. Network services involve
transmission of data. Check with your service provider for details about fees in your
home network and when roaming on other networks. Your service provider can explain
what charges will apply. Some networks may have limitations that affect how you can
use some features of this device requiring network support such as support for specific
technologies like WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols and
language-dependent characters.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device menu. Your
device may also have customized items such as menu names, menu order, and icons.
Safety 5
During extended operation such as a high speed data connection, the device may feel
warm. In most cases, this condition is normal. If you suspect the device is not working
properly, take it to the nearest authorised service facility.
6Safety
Get started
Keys and parts
1End/Power key
2Earpiece
3Display
4Selection keys
5Navi™ key (scroll key)
6Call key
7Keypad
8Charger connector
9Headset connector/Nokia AV Connector
(3.5 mm)
10 Camera lens
11 Micro USB connector
12 Loudspeaker
13 Microphone
14 Memory card slot
15 Wrist strap hole
Insert SIM card and battery
Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a
micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)
in this device. A micro SIM card is smaller than the standard SIM card. This device does
not support the use of micro-SIM cards and use of incompatible SIM cards may damage
the card or the device, and may corrupt data stored on the card.
Get started 7
The SIM card and its contacts can be easily damaged by scratches or bending, so be
careful when handling, inserting, or removing the card.
1 Press and slide the back cover towards the bottom of the phone, and remove it (1).
2 Remove the battery (2).
3 Open the SIM card holder (3), insert the SIM card with the contact surface facing
down (4), and close the holder (5).
4 Insert the battery (6), and replace the back cover (7).
8Get started
Insert a memory card
Use only compatible microSD cards approved by Nokia for use with this device. Nokia
uses approved industry standards for memory cards, but some brands may not be fully
compatible with this device. Incompatible cards may damage the card and the device
and corrupt data stored on the card.
Your device supports microSD memory cards with a capacity of up to 16 GB.
A compatible memory card may be supplied with the device, and may already be
inserted in the device. If not, do the following:
1 Open the cover of the memory card slot.
2 Insert the card into the memory card slot with the contact surface facing up, and
press until it locks into place.
3 Close the cover of the memory card slot.
Remove the memory card
Important: Do not remove the memory card during an operation when the card
is being accessed. Doing so may damage the memory card and the device, and corrupt
data stored on the card.
You can remove or replace the memory card during phone operation without switching
the device off, but you need to make sure that no application is currently accessing the
memory card.
Get started 9
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the charger from the device,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use the
device while it is charging. If the battery is completely discharged, it may take several
minutes before the charging indicator appears on the display or before any calls can be
made.
Attach the wrist strap
Thread the wrist strap as shown, and tighten it.
Switch the device on or off
Press and hold the power key .
You may be prompted to get the configuration settings from your service provider
(network service). For more information, contact your service provider.
10 Get started
GSM antenna
Your device may have internal and external antennas. Avoid touching the antenna area
unnecessarily while the antenna is transmitting or receiving. Contact with antennas
affects the communication quality and may cause a higher power level during operation
and may reduce the battery life.
The figure shows the GSM antenna area marked in grey.
Headset
Warning:
Continuous exposure to high volume may damage your hearing. Listen to music at a
moderate level, and do not hold the device near your ear when the loudspeaker is in
use.
Warning:
When you use the headset, your ability to hear outside sounds may be affected. Do not
use the headset where it can endanger your safety.
When connecting any external device or any headset, other than those approved by
Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume
levels.
Do not connect products that create an output signal as this may cause damage to the
device. Do not connect any voltage source to the Nokia AV Connector.
Get started 11
Basic use
Keypad lock
To prevent accidental keypresses, select Menu, and press * within 3.5 seconds to lock
the keypad.
To unlock the keypad, select Unlock, and press * within 1.5 seconds. If the security
keyguard is activated, enter the security code when requested.
To set the keypad to lock automatically after a defined length of time when the device
is not being used, select Menu > Settings > Phone > Automatic keyguard > On.
To answer a call when the keypad is locked, press the call key. When you end or reject
a call, the keypad locks automatically.
When the device or keypad is locked, calls may be possible to the official emergency
number programmed into your device.
Access codes
The security code helps to protect your device against unauthorised use. The preset
code is 12345. You can create and change the code, and set the device to request the
code. Keep the code secret and in a safe place separate from your device. If you forget
the code and your device is locked, your device will require service. Additional charges
may apply, and all the personal data in your device may be deleted. For more
information, contact a Nokia Care point or your device dealer.
The PIN code supplied with the SIM card protects the card against unauthorised use.
The PIN2 code supplied with some SIM cards is required to access certain services. If you
enter the PIN or PIN2 code incorrectly three times in succession, you are asked for the
PUK or PUK2 code. If you do not have them, contact your service provider.
The module PIN is required to access the information in the security module of your SIM
card. The signing PIN may be required for the digital signature. The barring password
is required when using the call barring service.
To set how your device uses the access codes and security settings, select Menu >
Settings > Security.
PUK codes
The personal unblocking key (PUK) code and the universal personal unblocking key
(UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code,
respectively. The PUK2 code (8 digits) is required to change a blocked PIN2 code. If the
12 Basic use
codes are not supplied with the SIM card, contact your local service provider for the
codes.
Volume control
Warning:
Continuous exposure to high volume may damage your hearing. Listen to music at a
moderate level, and do not hold the device near your ear when the loudspeaker is in
use.
To adjust the earpiece or loudspeaker volume during a call or when listening to an audio
file or the FM radio, scroll up or down.
Standby mode
When the phone is ready for use, and you have not entered any characters, the phone
is in the standby mode.
1Network signal strength
2Battery charge level
3Network name or operator logo
4Functions of selection keys
The left selection key is Go to for you to view the functions in your personal shortcut
list. When viewing the list, select Options > Select options to view the available
functions, or select Options > Organise to arrange the functions in your shortcut list.
To have the phone display a list of selected features and information that you can
directly access from the standby mode, select Menu > Settings > Display > Home
screen.
Indicators
You have unread messages.
You have unsent, cancelled, or failed messages.
The keypad is locked.
The device does not ring for incoming calls or text messages.
An alarm is set.
/ The device is registered to the GPRS or EGPRS network.
/ A GPRS or EGPRS connection is open.
/ The GPRS or EGPRS connection is suspended (on hold).
Basic use 13
The device is registered to a 3G (UMTS) network.
Bluetooth is activated.
All incoming calls are diverted to another number.
Calls are limited to a closed user group.
The currently active profile is timed.
A headset is connected to the device.
The device is connected to another device, using a USB data cable.
Navigate the menus
The device functions are grouped into menus. Not all menu functions or option items
are described here.
In the home screen, select Menu and the desired menu and submenu.
Exit the current menu level
Select Exit or Back.
Return to the home screen
Press the end key.
Change the menu view
Select Menu > Options > Main menu view.
Shortcuts
With personal shortcuts, you can get quick access to frequently used phone functions.
Select Menu > Settings > My shortcuts.
Assign phone functions to the selection keys
Select Right selection key or Left selection key and a function from the list.
Select shortcut functions for the scroll key
Select Navigation key. Scroll to the desired direction, and select Change or Assign and
a function from the list.
Operator menu
Access a portal to services provided by your network operator. For more information,
contact your network operator. The operator can update this menu with a service
message.
14 Basic use
Use your device without a SIM card
Some features of your device may be used without inserting a SIM card, such as games.
Features that are unavailable when the flight profile is activated cannot be selected in
menus.
Write text
Text modes
To enter text (for example, when writing messages) you can use traditional or predictive
text input.
When you write text, press and hold Options to switch between traditional text input,
indicated by , and predictive text input, indicated by . Not all languages are
supported by predictive text input.
The character cases are indicated by , , and .
To change the character case, press #. To change from the letter to number mode,
indicated by , press and hold #, and select Number mode. To change from the
number to the letter mode, press and hold #.
To set the writing language, select Options > Writing language.
Traditional text input
Press a number key, 2-9, repeatedly until the desired character is displayed. The
available characters depend on the selected writing language.
If the next character you want is located on the same key as the present one, wait until
the cursor appears, and enter the character .
To insert common punctuation marks and special characters, press 1 repeatedly. To
access the list of special characters, press *. To insert a space, press 0.
Predictive text input
Predictive text input is based on a built-in dictionary to which you can also add new
words.
1 Start writing a word, using the keys 2 to 9. Press each key only once for one letter.
2 To confirm a word, scroll right or add a space.
•If the word is not correct, press * repeatedly, and select the word from the list.
•If the ? character is displayed after the word, the word you intended to write is
not in the dictionary. To add the word to the dictionary, select Spell. Enter the
word using traditional text input, and select Save.
Basic use 15
•To write compound words, enter the first part of the word, and scroll right to
confirm it. Write the last part of the word, and confirm the word.
3 Start writing the next word.
Nokia account and Nokia's Ovi services
You can create a Nokia account either on your PC or on your mobile device.
With Nokia's Ovi services and your Nokia account, you can, for example:
•Get a free Ovi Mail account
•Download games, applications, videos, and ringing tones from Ovi Store
The available services may also vary by country or region, and not all languages are
supported.
To learn more about Ovi, go to www.ovi.com.
To create a Nokia account later, use your device to access an Ovi service, and you are
prompted to create an account.
About Ovi Store
In Ovi Store, you can download mobile games, applications, videos, images, themes,
and ringing tones to your device. Some items are free of charge; others you need to pay
for with your credit card or in your phone bill. The availability of payment methods
depends on your country of residence and your network service provider. Ovi Store offers
content that is compatible with your mobile device and relevant to your tastes and
location.
Contacts
Select Menu > Contacts.
You can save names and phone numbers in the device memory or on the SIM card. In
the device memory, you can save contacts with numbers and text items. Names and
numbers saved on the SIM card are indicated with .
Add a contact
Select Add new.
Add details to a contact
Ensure that the memory in use is either Phone or Phone and SIM. Select Names, go to
the name, and select Details > Options > Add detail.
16 Contacts
Search for a contact
Select Names, and scroll through the list of contacts or enter the first letters of the name.
Copy a contact to another memory
Select Names, go to the contact, and select Details > Options > Copy number. On the
SIM card, you can save only one phone number for each name.
Select where to save contacts, how contacts are displayed, and the memory
consumption of contacts
Select Settings.
Send a business card
In the contacts list, go to a contact, and select Details > Options > Send business
card. You can send and receive business cards from devices that support the vCard
standard.
Calls
Make and answer a call
Make a call
Enter the phone number, including the country and area code if necessary, and press
the call key. For international calls, press * twice for the international prefix (the +
character replaces the international access code), enter the country code, the area code
without the leading 0, if necessary, and the phone number.
Answer an incoming call
Press the call key.
Reject a call
Press the end key.
Adjust the volume
During a phone call, scroll up or down.
Loudspeaker
If available, you may select Loudsp. or Handset to use the loudspeaker or the earpiece
of the phone during a call.
Calls 17
Warning:
Continuous exposure to high volume may damage your hearing. Listen to music at a
moderate level, and do not hold the device near your ear when the loudspeaker is in
use.
Dialling shortcuts
Assign a phone number to a number key
Select Menu > Contacts > Speed dials, scroll to a desired number (2-9), and select
Assign. Enter the desired phone number, or select Search and a saved contact.
Activate speed dialling
Select Menu > Settings > Call > Speed dialling > On.
Make a call using speed dialling
In the standby mode, press and hold the desired number key.
Log
To view information about your calls, messages, and data and synchronisation events,
select Menu > Log and the appropriate option.
Note: The actual invoice for calls and services from your service provider may
vary, depending on network features, rounding off for billing, taxes, and so forth.
Messaging
You can read, write, send, and save text, multimedia, audio, and flash messages, and e-
mail. The messaging services can only be used if your network or service provider
supports them.
Text and multimedia messages
You can create a message and optionally attach, for example, a picture. Your phone
automatically changes a text message to a multimedia message when a file is attached.
Text messages
Your device supports text messages beyond the limit for a single message. Longer
messages are sent as two or more messages. Your service provider may charge
accordingly. Characters with accents, other marks, or some language options take more
space, and limit the number of characters that can be sent in a single message.
18 Messaging
The total number of characters left and the number of messages needed for sending
are displayed.
To send messages, the correct message centre number must be stored in your device.
Normally, this number is set by default through your SIM card.
To set the number manually, do the following:
1 Select Menu > Messaging > Message settings > Text messages > Message
centres.
2 Enter the name and number supplied by your service provider.
Multimedia messages
A multimedia message can contain text, pictures, and sound clips.
Only devices that have compatible features can receive and display multimedia
messages. The appearance of a message may vary depending on the receiving device.
The wireless network may limit the size of MMS messages. If the inserted picture exceeds
this limit, the device may make it smaller so that it can be sent by MMS.
Important: Exercise caution when opening messages. Messages may contain
malicious software or otherwise be harmful to your device or PC.
For availability and subscription to the multimedia messaging service (MMS), contact
your service provider.
Create a message
1 Select Menu > Messaging > Create message and a message type.
2 In the To: field, enter the recipient's number or e-mail address (network service).
To select a recipient, select Add. You can have more than one recipient.
3 In the Text: field, write your message.
To insert a special character or a smiley, select Options > Insert symbol.
To attach content to the message, scroll to the attachment bar at the bottom of the
display, and select the desired type of content. The message type changes
automatically to multimedia message.
4 Select Send.
Note: The message sent icon or text on your device screen does not indicate
that the message is received at the intended destination.
Multimedia messages are indicated with an icon at the top of the display.
Messaging 19
Service providers may charge differently depending on the message type. For details,
contact your service provider.
Mail
Set up e-mail
Select Menu > Messaging > E-mail.
If you do not already have an e-mail account, you can create a Nokia account, which
includes the Ovi Mail service.
1 Select Get Ovi Mail.
2 Follow the instructions.
Read, write, and send an e-mail
Select Menu > Messaging > E-mail.
Read an e-mail
Select an e-mail and Open.
Important: Exercise caution when opening messages. Messages may contain
malicious software or otherwise be harmful to your device or PC.
E-mails with attachments, for example, images, are marked with a paperclip icon. Some
attachments may not be compatible with your device, and cannot be displayed on your
device.
View attachments
Select an attachment and View.
Write an e-mail
Select Options > Compose New.
Attach a file to the e-mail
Select Options > Attach file.
Send the e-mail
Select Send.
Close the e-mail application
Select Sign Out.
20 Messaging
Chat with your friends
You can chat with other online users using your device.
You can use an existing account for an IM community that is supported by your device.
If you are not registered to an IM service, you can create an account for a supported IM
service, using your computer or your device. The menus may vary, depending on the IM
service.
To connect to the service, select Menu > Messaging > IMs, and follow the displayed
instructions.
Flash messages
Flash messages are text messages that are instantly displayed upon reception.
Select Menu > Messaging.
1 Select Create message > Flash message.
2In the To: field, enter the recipient's number. To select a recipient, select Add. You
can have more than one recipient.
3In the Message: field, write your message.
To insert a special character or a smiley, select Options > Insert symbol.
4 Select Send.
Nokia Xpress audio messages
Create and send audio messages as multimedia messages in a convenient way.
Select Menu > Messaging.
1 Select Create message > Audio message. The voice recorder opens.
2 To record your message, select .
3 To stop recording, select .
4In the To: field, enter the recipient's number. To select a recipient, select Add. You
can have more than one recipient.
5 Select Send.
Voice messages
The voice mailbox is a network service to which you may need to subscribe. For more
information, contact your service provider.
Call your voice mailbox
Press and hold 1.
Messaging 21
Edit your voice mailbox number
Select Menu > Messaging > Voice messages and Voice mailbox no..
Message settings
Select Menu > Messaging and Message settings.
Select from the following:
General settings — Set the font size for messages, and activate graphical smileys.
Text messages — Set up message centres for text messages and activate delivery
reports.
Multimedia msgs. — Allow delivery reports and the reception of multimedia messages
and advertisements, and set up other preferences related to multimedia messages.
Service messages — Activate service messages, and set up preferences related to
service messages.
Organiser
Alarm clock
You can set an alarm to sound at a desired time.
Set the alarm
1 Select Menu > Organiser > Alarm clock.
2 Set the alarm, and enter the alarm time.
3 To issue an alarm on selected days of the week, select Repeat: > On and the days.
4 Select the alarm tone. If you select the radio as the alarm tone, connect the headset
to the device.
5 Set the length of the snooze time-out period, and select Save.
Stop the alarm
Select Stop. If you let the alarm sound for a minute or select Snooze, the alarm stops
for the length of the snooze time-out period, then resumes.
Calendar and to-do list
Select Menu > Organiser > Calendar. The current day is framed. If there are any notes
set for the day, the day is in bold.
Add a calendar note
Scroll to the date, and select Options > Make a note.
22 Organiser
View the details of a note
Scroll to a note, and select View.
Delete all notes from the calendar
Select Options > Delete notes > All notes.
View the to-do list
Select Menu > Organiser > To-do list.
The to-do list is displayed and sorted by priority. To add, delete, or send a note, to mark
the note as done, or to sort the to-do list by deadline, select Options.
Web or Internet
About Web
Select Menu > Internet.
Depending on your device, the web browsing function may be displayed as Web or
Internet in the menu, hereafter referred to as Web.
You can access various internet services with your device browser. The appearance of
the web pages may vary due to screen size. You may not be able to see all the details
on the web pages.
The security icon does not indicate that the data transmission between the gateway
and the content server (where the data is stored) is secure. The service provider secures
the data transmission between the gateway and the content server.
For the availability of these services, pricing, and instructions, contact your service
provider.
You may receive the configuration settings required for browsing as a configuration
message from your service provider.
Connect to a web service
Select Menu > Internet > Home. Or, in the standby mode, press and hold 0.
After you make a connection to the service, you can start browsing its pages. The
function of the phone keys may vary in different services. Follow the text guides on the
phone display. For more information, contact your service provider.
Web or Internet 23
Media
Camera and video
Your device supports an image capture resolution of 2048x1536 pixels.
Camera mode
Use the still image function
Select Menu > Media > Camera.
Zoom in or out
Scroll up or down.
Capture an image
Select Capture.
Set the preview mode and time
Select Options > Settings > Photo preview time.
To activate the self-timer, select Options and the desired option.
Video mode
Use the video function
Select Menu > Media > Video camera.
Start recording a video clip
Select Record.
Switch between camera and video mode
In camera or video mode, scroll left or right.
FM radio
The FM radio depends on an antenna other than the wireless device antenna. A
compatible headset or accessory needs to be attached to the device for the FM radio to
function properly.
Warning:
Continuous exposure to high volume may damage your hearing. Listen to music at a
moderate level, and do not hold the device near your ear when the loudspeaker is in
use.
24 Media
Select Menu > Media > Radio.
Search for a neighbouring station
Press and hold the scroll key to the left or right.
Save a station
Tune to the desired station, and select Options > Save station.
Switch between saved stations
Scroll left or right to switch between stations, or press the corresponding number key
of the memory location of a desired station.
Adjust the volume
Scroll up or down.
Leave the radio playing in the background
Press the end key.
Close the radio
Press and hold the end key.
Voice recorder
Select Menu > Media > Voice recorder.
The recorder cannot be used when a data call or GPRS connection is active.
Start recording
Select the record icon.
Start recording during a call
Select Options > Record. When recording a call, hold the phone in the normal position
near to your ear. The recording is saved in the Recordings folder in Gallery.
Listen to the latest recording
Select Options > Play last recorded.
Send the last recording in a multimedia message
Select Options > Send last recorded.
Music player
Your device includes a music player for listening to songs or other MP3 or AAC sound
files.
Media 25
Warning:
Continuous exposure to high volume may damage your hearing. Listen to music at a
moderate level, and do not hold the device near your ear when the loudspeaker is in
use.
Select Menu > Media > Media player.
Start or pause playing
Press the scroll key.
Skip to the beginning of the current song
Scroll left.
Skip to the previous song
Scroll left twice.
Skip to the next song
Scroll right.
Rewind the current song
Press and hold the scroll key to the left.
Fast-forward the current song
Press and hold the scroll key to the right.
Adjust the volume
Scroll up or down.
Mute or unmute the music player
Press #.
Leave the music player playing in the background
Press the end key.
Close the music player
Press and hold the end key.
Gallery
Your phone supports a digital rights management (DRM) system to protect acquired
content. Always check the delivery terms of any content and activation key before
acquiring them, as they may be subject to a fee.
26 Gallery
Digital rights management
Content owners may use different types of digital rights management (DRM)
technologies to protect their intellectual property, including copyrights. This device uses
various types of DRM software to access DRM-protected content. With this device you
can access content protected with WMDRM 10, OMA DRM 1.0, OMA DRM 1.0 forward lock,
and OMA DRM 2.0. If certain DRM software fails to protect the content, content owners
may ask that such DRM software's ability to access new DRM-protected content be
revoked. Revocation may also prevent renewal of such DRM-protected content already
in your device. Revocation of such DRM software does not affect the use of content
protected with other types of DRM or the use of non-DRM-protected content.
Digital rights management (DRM) protected content comes with an associated
activation key that defines your rights to use the content.
If your device has OMA DRM-protected content, to back up both the activation keys and
the content, use the backup feature of Nokia Ovi Suite.
Other transfer methods may not transfer the activation keys which need to be restored
with the content for you to be able to continue the use of OMA DRM-protected content
after the device memory is formatted. You may also need to restore the activation keys
in case the files on your device get corrupted.
If your device has WMDRM-protected content, both the activation keys and the content
will be lost if the device memory is formatted. You may also lose the activation keys and
the content if the files on your device get corrupted. Losing the activation keys or the
content may limit your ability to use the same content on your device again. For more
information, contact your service provider.
View the Gallery contents
Select Menu > Gallery.
Settings
Profiles
Waiting for a call, but can’t let your device ring? There are various settings groups called
profiles, which you can customise with ringtones for different events and environments.
Select Menu > Settings > Profiles.
Select the desired profile and from the following:
Activate — Activate the profile.
Personalise — Modify the profile settings.
Settings 27
Timed — Set the profile to be active until a certain time. When the time set for the
profile expires, the previous profile that was not timed becomes active.
The available options may vary.
Warning:
With the Flight profile you cannot make or receive any calls, including emergency calls,
or use other features that require network coverage. To make calls, you must first
activate the phone function by changing profiles. If the device has been locked, enter
the lock code.
If you need to make an emergency call while the device is locked and in the Flight profile,
you may be also able to enter an official emergency number programmed in your device
in the lock code field and select 'Call'. The device will confirm that you are about to exit
Flight profile to start an emergency call.
Tones
You can modify the tone settings of the selected active profile.
Select Menu > Settings > Tones. You can find the same settings in the Profiles menu.
Display
Select Menu > Settings > Display.
You can view or adjust the wallpaper, font size, or other features related to the device
display.
Date and time
Select Menu > Settings > Date and time.
Set the date and time
Select Date & time settings.
Set the date and time format
Select Date & time format.
Update the time automatically according to the current time zone
Select Auto-update of time (network service).
Synchronisation and backup
Select Menu > Settings > Sync and backup.
28 Settings
Select from the following:
Phone switch — Synchronise or copy selected data, such as your contacts, calendar
entries, notes, or messages, between your device and another device.
Create backup — Back up selected data to a connected external storage device.
Restore backup — Restore data from a backup on a connected external storage device.
To view the details of a backup file, select Options > Details.
Data transfer — Synchronise or copy selected data between your device and a network
server (network service).
Connectivity
Your phone has several features that allow you to connect to other devices to transmit
and receive data.
Bluetooth wireless technology
Bluetooth technology allows you to connect your device, using radio waves, to a
compatible Bluetooth device within 10 metres (32 feet).
This device is compliant with Bluetooth Specification 2.1 + EDR supporting the following
profiles: generic access, hands-free, headset, object push, file transfer, dial-up
networking, serial port, SIM access, generic object exchange, advanced audio
distribution, audio video remote control, and generic audio video distribution. To
ensure interoperability between other devices supporting Bluetooth technology, use
Nokia approved accessories for this model. Check with the manufacturers of other
devices to determine their compatibility with this device.
Features using Bluetooth technology increase the demand on battery power and reduce
the battery life.
When the wireless device is in the remote SIM mode, you can only use a compatible
connected accessory, such as a car kit, to make or receive calls.
Your wireless device will not make any calls, except to the emergency numbers
programmed into your device, while in this mode.
To make calls, you must first leave the remote SIM mode. If the device has been locked,
enter the lock code to unlock it first.
Open a Bluetooth connection
1 Select Menu > Settings > Connectivity > Bluetooth.
2 Select My phone's name, and enter a name for your device.
3 To activate Bluetooth connectivity, select Bluetooth > On. indicates that
Bluetooth connectivity is active.
Settings 29
4 To connect your device to an audio accessory, select Conn. to audio acc. and the
accessory.
5 To pair your device with any Bluetooth device in range, select Paired devices >
Add new device.
6 Scroll to a found device, and select Add.
7 Enter a passcode (up to 16 characters) on your device, and allow the connection on
the other Bluetooth device.
Operating the device in hidden mode is a safer way to avoid malicious software. Do not
accept Bluetooth connectivity from sources you do not trust. Alternatively, switch off
the Bluetooth function. This does not affect other functions of the device.
Connect your PC to the internet
You can use Bluetooth technology to connect your compatible PC to the internet. Your
device must be able to connect to the internet (network service), and your PC must
support Bluetooth technology. After connecting to the network access point (NAP)
service of the device and pairing with your PC, your device automatically opens a packet
data connection to the internet.
Packet data
General packet radio service (GPRS) is a network service that allows mobile phones to
send and receive data over an internet protocol (IP) based network.
To define how to use the service, select Menu > Settings > Connectivity > Packet
data > Packet data conn. and from the following:
When needed — Establish a packet data connection when needed by an application.
The connection is closed when the application is closed.
Always online — Automatically connect to a packet data network when you switch
the device on.
You can use your device as a modem by connecting it to a compatible PC using Bluetooth
technology. For details, see the Nokia Ovi Suite documentation.
Call and phone
Select Menu > Settings > Call.
Divert incoming calls
Select Call divert (network service). For details, contact your service provider.
Automatically redial ten times after an unsuccessful attempt
Select Automatic redial > On.
30 Settings
Get a notification of incoming calls while you are in a call
Select Call waiting > Activate (network service).
Display or hide your number to the person you are calling
Select Send my caller ID (network service).
Set the display language
Select Menu > Settings > Phone > Language settings > Phone language.
Restore factory settings
To restore the device back to the default settings, select Menu > Settings > Rest.
factory sett..
To reset all preference settings without deleting any personal data, select Settings
only.
To reset all preference settings and delete all personal data, such as contacts, messages,
media files, and activation keys, select All.
Find more help
For local services and warranty information, please refer to the separate booklet.
Support
When you want to learn more about how to use your product or you are unsure how
your device should function, go to www.nokia.com/support, or using a mobile device,
nokia.mobi/support.
If this does not resolve your issue, do one of the following:
•Reboot your device. Switch off the device, and remove the battery. After about a
minute, replace the battery, and switch on the device.
•Restore the original factory settings.
•Update your device software.
If your issue remains unsolved, contact Nokia for repair options. Go to www.nokia.com/
repair, or in Latin America, www.nokia-latinoamerica.com/centrosdeservicio. Before
sending your device for repair, always back up the data in your device.
About device software updates
With device software updates, you can get new features and enhanced functions for
your device. Updating the software may also improve your device performance.
Find more help 31
It is recommended that you back up your personal data before updating your device
software.
Warning:
If you install a software update, you cannot use the device, even to make emergency
calls, until the installation is completed and the device is restarted.
Downloading software updates may involve the transmission of large amounts of data
(network service).
Make sure that the device battery has enough power, or connect the charger before
starting the update.
After you update your device software, the instructions in the user guide may no longer
be up to date.
Update device software using your device
Want to improve the performance of your device and get application updates and great
new features? Update the software regularly to get the most out of your device. You
can also set your device to automatically check for updates.
Select Menu > Settings.
1 Select Phone > Phone updates.
2 To display the current software version and check whether an update is available,
select Current sw details.
32 Find more help
3 To download and install a software update, select Downl. phone sw. Follow the
instructions.
4 If the installation was cancelled after the download, select Install sw update.
The software update may take several minutes. If there are problems with the
installation, contact your service provider.
Check for software updates automatically
Select Auto sw update, and define how often to check for new software updates.
Your service provider may send device software updates over the air directly to your
device (network service).
Update device software using your PC
You can use the Nokia Ovi Suite PC application to update your device software. You need
a compatible PC, a high-speed internet connection, and a compatible USB data cable to
connect your device to the PC.
To get more information and to download the Nokia Ovi Suite application, go to
www.ovi.com/suite.
Protect the environment
Save energy
You do not need to charge your battery so often if you do the following:
•Close applications and data connections, for example, your Bluetooth connection,
when not in use.
•Deactivate unnecessary sounds, such as key tones.
Recycle
When this device has reached the end of its working life, all of its materials can be
recovered as materials and energy. To guarantee the correct disposal and reuse, Nokia
co-operates with its partners through a program called We:recycle. For information on
how to recycle your old Nokia products and where to find collection sites, go to
www.nokia.com/werecycle, or using a mobile device, nokia.mobi/werecycle, or call the
Nokia Contact Center.
Recycle packaging and user guides at your local recycling scheme.
Protect the environment 33
For more information on the environmental attributes of your device, go to
www.nokia.com/ecodeclaration.
Product and safety information
Accessories
Warning:
Use only batteries, chargers, and accessories approved by Nokia for use with this particular model. The use of any other types
may invalidate any approval or warranty, and may be dangerous. In particular, use of unapproved chargers or batteries may
present a risk of fire, explosion, leakage, or other hazard.
For availability of approved accessories, please check with your dealer. When you disconnect the power cord of any accessory,
grasp and pull the plug, not the cord.
Battery
Battery and charger information
Your device is powered by a rechargeable battery. The battery intended for use with this device is BL-5C. Nokia may make
additional battery models available for this device. This device is intended for use when supplied with power from the following
chargers: AC-3. The exact charger model number may vary depending on the type of plug. The plug variant is identified by one
of the following: E, X, AR, U, A, C, K, or B.
The battery can be charged and discharged hundreds of times, but it will eventually wear out. When the talk and standby times
are noticeably shorter than normal, replace the battery. Use only Nokia approved batteries, and recharge your battery only with
Nokia approved chargers designated for this device.
If a battery is being used for the first time or if the battery has not been used for a prolonged period, it may be necessary to
connect the charger, then disconnect and reconnect it to begin charging the battery. If the battery is completely discharged, it
may take several minutes before the charging indicator appears on the display or before any calls can be made.
Safe removal. Always switch the device off and disconnect the charger before removing the battery.
Proper charging. Unplug the charger from the electrical plug and the device when not in use. Do not leave a fully charged battery
connected to a charger, since overcharging may shorten its lifetime. If left unused, a fully charged battery will lose its charge
over time.
Avoid extreme temperatures. Always try to keep the battery between 15°C and 25°C (59°F and 77°F). Extreme temperatures
reduce the capacity and lifetime of the battery. A device with a hot or cold battery may not work temporarily. Battery
performance is particularly limited in temperatures well below freezing.
Do not short-circuit. Accidental short-circuiting can occur when a metallic object such as a coin, clip, or pen causes direct
connection of the positive (+) and negative (-) terminals of the battery. (These look like metal strips on the battery.) This might
happen, for example, when you carry a spare battery in your pocket or purse. Short-circuiting the terminals may damage the
battery or the connecting object.
Disposal. Do not dispose of batteries in a fire as they may explode. Dispose of batteries according to local regulations. Please
recycle when possible. Do not dispose as household waste.
Leak. Do not dismantle, cut, open, crush, bend, puncture, or shred cells or batteries. In the event of a battery leak, prevent
battery liquid contact with skin or eyes. If this happens, flush the affected areas immediately with water, or seek medical help.
34 Product and safety information
Damage. Do not modify, remanufacture, attempt to insert foreign objects into the battery, or immerse or expose it to water or
other liquids. Batteries may explode if damaged.
Correct use. Use the battery only for its intended purpose. Improper battery use may result in a fire, explosion, or other hazard.
If the device or battery is dropped, especially on a hard surface, and you believe the battery has been damaged, take it to a
service centre for inspection before continuing to use it. Never use any charger or battery that is damaged. Keep your battery
out of the reach of small children.
Nokia battery authentication guidelines
Always use original Nokia batteries for your safety. To check that you are getting an original Nokia battery, purchase it from a
Nokia authorised service centre or dealer, and inspect the hologram label using the following steps:
Authenticate hologram
1 When you look at the hologram on the label, you should see the Nokia connecting hands symbol from one angle and the
Nokia Original Enhancements logo when looking from another angle.
2 When you angle the hologram left, right, down and up, you should see 1, 2, 3 and 4 dots on each side respectively.
Successful completion of the steps is not a total assurance of the authenticity of the battery. If you cannot confirm authenticity
or if you have any reason to believe that your Nokia battery with the hologram on the label is not an authentic Nokia battery,
you should refrain from using it, and take it to the nearest Nokia authorised service centre or dealer for assistance.
For additional information, refer to the warranty and reference leaflet included with your Nokia device.
Taking care of your device
Your device is a product of superior design and craftsmanship and should be treated with care. The following suggestions will
help you protect your warranty coverage.
•Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that will corrode
electronic circuits. If your device does get wet, remove the battery, and allow the device to dry completely before replacing
it.
•Do not use or store the device in dusty, dirty areas. Its moving parts and electronic components can be damaged.
Product and safety information 35
•Do not store the device in high or cold temperature. High temperatures can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics. When the device warms to its normal temperature from a cold temperature,
moisture can form inside the device and damage electronic circuit boards.
•Do not attempt to open the device other than as instructed in this guide.
•Do not drop, knock, or shake the device. Rough handling can break internal circuit boards and fine mechanics.
•Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device. Only use a soft, clean, dry cloth
to clean the surface of the device.
•Do not paint the device. Paint can clog the moving parts and prevent proper operation.
•Use only the supplied or an approved replacement antenna. Unauthorised antennas, modifications, or attachments could
damage the device and may violate regulations governing radio devices.
•Use chargers indoors.
•Backup all data you want to keep, such as contacts and calendar notes.
•To reset the device from time to time for optimum performance, power off the device and remove the battery.
These suggestions apply equally to your device, battery, charger, or any accessory.
Recycle
Always return your used electronic products, batteries, and packaging materials to dedicated collection points. This way you
help prevent uncontrolled waste disposal and promote the recycling of materials. Check product environmental information
and how to recycle your Nokia products at www.nokia.com/werecycle, or with a mobile device, nokia.mobi/werecycle.
Additional safety information
The surface of this device is nickel-free.
Small children
Your device and its accessories are not toys. They may contain small parts. Keep them out of the reach of small children.
Operating environment
This device meets RF exposure guidelines in the normal use position at the ear or at least 1.5 centimetres (5/8 inch) away from
the body. Any carry case, belt clip, or holder for body-worn operation should not contain metal and should position the device
the above-stated distance from your body.
To send data files or messages requires a quality connection to the network. Data files or messages may be delayed until such
a connection is available. Follow the separation distance instructions until the transmission is completed.
Parts of the device are magnetic. Metallic materials may be attracted to the device. Do not place credit cards or other magnetic
storage media near the device, because information stored on them may be erased.
Medical devices
Operation of radio transmitting equipment, including wireless phones, may interfere with the function of inadequately
protected medical devices. Consult a physician or the manufacturer of the medical device to determine whether they are
adequately shielded from external RF energy. Switch off your device when regulations posted instruct you to do so. Hospitals
or health care facilities may use equipment sensitive to external RF energy.
Implanted medical devices
Manufacturers of medical devices recommend a minimum separation of 15.3 centimetres (6 inches) between a wireless device
and an implanted medical device, such as a pacemaker or implanted cardioverter defibrillator, to avoid potential interference
with the medical device. Persons who have such devices should:
•Always keep the wireless device more than 15.3 centimetres (6 inches) from the medical device.
•Not carry the wireless device in a breast pocket.
•Hold the wireless device to the ear opposite the medical device.
36 Product and safety information
•Turn the wireless device off if there is any reason to suspect that interference is taking place.
•Follow the manufacturer directions for the implanted medical device.
If you have any questions about using your wireless device with an implanted medical device, consult your health care provider.
Hearing aids
Some digital wireless devices may interfere with some hearing aids.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles such as electronic fuel
injection, electronic antilock braking, electronic speed control, and air bag systems. For more information, check with the
manufacturer of your vehicle or its equipment.
Only qualified personnel should service the device or install the device in a vehicle. Faulty installation or service may be
dangerous and may invalidate your warranty. Check regularly that all wireless device equipment in your vehicle is mounted
and operating properly. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the
device, its parts, or accessories. Remember that air bags inflate with great force. Do not place your device or accessories in the
air bag deployment area.
Switch off your device before boarding an aircraft. The use of wireless teledevices in an aircraft may be dangerous to the
operation of the aircraft and may be illegal.
Potentially explosive environments
Switch off your device in any area with a potentially explosive atmosphere. Obey all posted instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or death. Switch off the device at refuelling points such as near gas
pumps at service stations. Observe restrictions in fuel depots, storage, and distribution areas; chemical plants; or where blasting
operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include
areas where you would be advised to turn off your vehicle engine, below deck on boats, chemical transfer or storage facilities
and where the air contains chemicals or particles such as grain, dust, or metal powders. You should check with the manufacturers
of vehicles using liquefied petroleum gas (such as propane or butane) to determine if this device can be safely used in their
vicinity.
Emergency calls
Important: This device operates using radio signals, wireless networks, landline networks, and user-programmed
functions. If your device supports voice calls over the internet (internet calls), activate both the internet calls and the cellular
phone. The device may attempt to make emergency calls over both the cellular networks and through your internet call provider
if both are activated. Connections in all conditions cannot be guaranteed. You should never rely solely on any wireless device
for essential communications like medical emergencies.
To make an emergency call:
1 If the device is not on, switch it on. Check for adequate signal strength. Depending on your device, you may also need to
complete the following:
•Insert a SIM card if your device uses one.
•Remove certain call restrictions you have activated in your device.
•Change your profile from Offline or Flight profile to an active profile.
2 Press the end key as many times as needed to clear the display and ready the device for calls.
3 Enter the official emergency number for your present location. Emergency numbers vary by location.
4Press the call key.
Product and safety information 37
When making an emergency call, give all the necessary information as accurately as possible. Your wireless device may be the
only means of communication at the scene of an accident. Do not end the call until given permission to do so.
Certification information (SAR)
This mobile device meets guidelines for exposure to radio waves.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines were developed by the independent scientific organisation ICNIRP
and include safety margins designed to assure the protection of all persons, regardless of age and health.
The exposure guidelines for mobile devices employ a unit of measurement known as the Specific Absorption Rate or SAR. The
SAR limit stated in the ICNIRP guidelines is 2.0 watts/kilogram (W/kg) averaged over 10 grams of tissue. Tests for SAR are
conducted using standard operating positions with the device transmitting at its highest certified power level in all tested
frequency bands. The actual SAR level of an operating device can be below the maximum value because the device is designed
to use only the power required to reach the network. That amount changes depending on a number of factors such as how
close you are to a network base station.
The highest SAR value under the ICNIRP guidelines for use of the device at the ear is 1.20 W/kg.
Use of device accessories may result in different SAR values. SAR values may vary depending on national reporting and testing
requirements and the network band. Additional SAR information may be provided under product information at
www.nokia.com.
Your mobile device is also designed to meet the requirements for exposure to radio waves established by the Federal
Communications Commission (USA) and Industry Canada. These requirements set a SAR limit of 1.6 W/kg averaged over one
gram of tissue. The highest SAR value reported under this standard during product certification for use at the ear is 1.33 W/
kg and when properly worn on the body is 0.83 W/kg.
Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-722 product is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/
phones/declaration_of_conformity/.
© 2010 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Messaging and Nokia Original Enhancements logo are trademarks or registered
trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior
written permission of Nokia is prohibited. Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without prior notice.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
38 Copyright and other notices
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection
with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal
and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license
is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and
commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE
RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER
CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES
THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
The availability of particular products and applications and services for these products may vary by region. Please check with
your Nokia dealer for details and availability of language options. This device may contain commodities, technology or software
subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.
The third-party applications provided with your device may have been created and may be owned by persons or entities not
affiliated with or related to Nokia. Nokia does not own the copyrights or intellectual property rights to the third-party
applications. As such, Nokia does not take any responsibility for end-user support, functionality of the applications, or the
information in the applications or these materials. Nokia does not provide any warranty for the third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA
NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE
ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment).
The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require
assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by
Nokia could void the user's authority to operate this equipment.
5555555/Issue 1 EN
Copyright and other notices 39
