User guide

Nokia 6101 and Nokia 6102

User Guide

9240568

Issue 1

Issue 1te

6101_6102.ENv1_9240568_UG.fm Page 1 Tuesday, June 7, 2005 2:59 PM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the products RM-76 and

RM-77 are in conformity with the provisions of the following Council Directive:1999/5/EC.

A copy of the Declaration of Conformity can be found at

http://www.nokia.com/phones/declaration of conformity/.

LEGAL INFORMATION

Part No. 9240568, Issue No. 1

Reproduction, transfer, distribution or storage of part or all of the contents in this document

in any form without the prior written permission of Nokia is prohibited.

Nokia, Nokia Connecting People, Xpress-on, the Nokia Original Enhancements logo, and Pop-Port

are trademarks or registered trademarks of Nokia Corporation. Other product and company names

mentioned herein may be trademarks or tradenames of their respective owners.

Nokia tune is a sound mark of Nokia Corporation.

US Patent No 5818437 and other pending patents. T9 text input software Copyright (C)

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java is a trademark of Sun Microsystems, Inc.

The information contained in this user guide was written for the Nokia 6101 and Nokia 6102

products. Nokia operates a policy of ongoing development. Nokia reserves the right to make

changes to any of the products described in this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR

INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES

HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS." EXCEPT AS REQUIRED BY

APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,

BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR

CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR

WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

6101_6102.ENv1_9240568_UG.fm Page 2 Wednesday, June 8, 2005 1:36 PM

EXPORT CONTROLS

This device may contain commodities, technology, or software subject to export laws and

regulations from the U.S. and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close

proximity to receiving equipment). The FCC or Industry Canada can require you to stop using

your telephone if such interference cannot be eliminated. If you require assistance, contact

your local service facility. This device complies with part 15 of the FCC rules. Operation is

subject to the condition that this device does not cause harmful interference.

6101_6102.ENv1_9240568_UG.fm Page 3 Tuesday, June 7, 2005 2:59 PM

Contents

For your safety...................................................................................... 8

General information........................................................................... 11

Overview of functions........................................................................................................ 11

Access codes......................................................................................................................... 11

Configuration settings service ........................................................................................ 12

Download content and applications ............................................................................. 12

Nokia support on the Web ............................................................................................... 12

1. Get started.................................................................................... 13

Open the fold............................................................................................................... 13

Install the SIM card and the battery .................................................................... 13

Charge the battery..................................................................................................... 14

Switch the phone on and off.................................................................................. 14

Normal operating position ...................................................................................... 15

2. Your phone................................................................................... 16

Keys and parts............................................................................................................. 16

Standby mode ............................................................................................................. 17

Keypad lock (keyguard)............................................................................................. 19

3. Call functions............................................................................... 20

Make a call................................................................................................................... 20

Answer or reject a call.............................................................................................. 20

Options during a call................................................................................................. 21

4. Write text ..................................................................................... 22

Settings......................................................................................................................... 22

Predictive text input.................................................................................................. 22

Traditional text input................................................................................................ 23

5. Navigate the menus..................................................................... 24

6. Messages....................................................................................... 25

Text messages (SMS)................................................................................................. 25

Multimedia messages (MMS) ................................................................................. 26

Memory full ................................................................................................................. 28

Folders ........................................................................................................................... 29

Nokia Xpress audio messaging............................................................................... 29

Voice messages ........................................................................................................... 30

6101_6102.ENv1_9240568_UG.fm Page 4 Tuesday, June 7, 2005 2:59 PM

Contents

Info messages .............................................................................................................. 30

Service commands...................................................................................................... 30

Delete messages.......................................................................................................... 30

Message settings ........................................................................................................ 30

Message counter......................................................................................................... 32

7. Contacts ....................................................................................... 33

Search for a contact .................................................................................................. 33

Save names and phone numbers............................................................................ 33

Save numbers, items, or an image......................................................................... 33

Copy contacts .............................................................................................................. 34

Edit contact details.................................................................................................... 34

Delete contacts or contact details......................................................................... 34

Business cards.............................................................................................................. 34

Settings.......................................................................................................................... 34

Groups............................................................................................................................ 35

Voice dialing................................................................................................................. 35

1-touch dials................................................................................................................ 36

Info, service, and my numbers ................................................................................ 36

8. Call log......................................................................................... 37

Recent calls lists ......................................................................................................... 37

Counters and timers................................................................................................... 37

9. Settings ........................................................................................ 38

Profiles........................................................................................................................... 38

Themes........................................................................................................................... 38

Tones .............................................................................................................................. 38

My shortcuts ................................................................................................................ 39

Main display................................................................................................................. 39

Mini display.................................................................................................................. 40

Time and date .............................................................................................................. 40

Call.................................................................................................................................. 40

Phone ............................................................................................................................. 41

Connectivity ................................................................................................................. 41

Enhancements ............................................................................................................. 43

Configuration............................................................................................................... 43

Security.......................................................................................................................... 44

Restore factory settings............................................................................................ 44

10. Operator menu ............................................................................ 45

11. Gallery .......................................................................................... 46

6101_6102.ENv1_9240568_UG.fm Page 5 Tuesday, June 7, 2005 2:59 PM

Contents

12. Media............................................................................................ 47

Camera .......................................................................................................................... 47

Radio.............................................................................................................................. 47

Recorder........................................................................................................................ 48

13. Organizer ...................................................................................... 50

Alarm clock .................................................................................................................. 50

Calendar........................................................................................................................ 50

To-do list....................................................................................................................... 51

Notes.............................................................................................................................. 51

Synchronization.......................................................................................................... 52

Calculator..................................................................................................................... 53

Stopwatch .................................................................................................................... 53

Countdown timer ....................................................................................................... 54

14. Applications.................................................................................. 55

Games............................................................................................................................ 55

Collection...................................................................................................................... 55

15. Web............................................................................................... 57

Set up browsing.......................................................................................................... 57

Connect to a service.................................................................................................. 57

Browse pages............................................................................................................... 58

Appearance settings .................................................................................................. 58

Cookies.......................................................................................................................... 59

Scripts over secure connection .............................................................................. 59

Bookmarks.................................................................................................................... 59

Download files ............................................................................................................ 60

Service inbox ............................................................................................................... 60

Cache memory ............................................................................................................ 61

Positioning information............................................................................................ 61

Browser security ......................................................................................................... 61

16. SIM services.................................................................................. 64

17. PC connectivity ............................................................................ 65

PC Suite......................................................................................................................... 65

Packet data, HSCSD, and CSD ................................................................................ 65

Data communication applications ........................................................................ 65

18. Enhancements ............................................................................. 66

Power............................................................................................................................. 67

Data................................................................................................................................ 67

Audio.............................................................................................................................. 67

Car .................................................................................................................................. 67

Covers and carrying ................................................................................................... 67

6101_6102.ENv1_9240568_UG.fm Page 6 Tuesday, June 7, 2005 2:59 PM

Contents

19. Reference information ................................................................ 68

Battery information ................................................................................................... 68

Additional safety information................................................................................. 70

Emergency calls........................................................................................................... 72

Certification information (SAR).............................................................................. 73

Technical information................................................................................................ 74

Patent information..................................................................................................... 75

Care and maintenance....................................................................... 76

Index ................................................................................................... 77

6101_6102.ENv1_9240568_UG.fm Page 7 Tuesday, June 7, 2005 2:59 PM

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal.

Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the phone on when wireless phone use is prohibited

or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the

vehicle while driving. Your first consideration while driving should

be road safety.

INTERFERENCE

All wireless phones may get interference, which could

affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference

in aircraft.

SWITCH OFF WHEN REFUELLING

Don't use the phone at a refuelling point. Don't use near fuel

or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Don't use the phone where blasting is

in progress.

USE SENSIBLY

Use only in the normal position as explained in the product

documentation. Don't touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect

incompatible products.

6101_6102.ENv1_9240568_UG.fm Page 8 Tuesday, June 7, 2005 2:59 PM

For your safety

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all

important information stored in your phone.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed

safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press the end key as

many times as needed to clear the display and return to the start screen.

Enter the emergency number, then press the call key. Give your location.

Do not end the call until given permission to do so.

■About your device

The wireless device described in this guide is approved for use on the EGSM 900

and GSM 850/1800/1900 networks. Contact your service provider for more

information about networks.

When using the features in this device, obey all laws and respect the privacy and

legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock,

the device must be switched on. Do not switch the device on when

wireless device use may cause interference or danger.

■Network services

To use the phone you must have service from a wireless service provider. Many of

the features in this device depend on features in the wireless network to function.

These network services may not be available on all networks or you may have to

make specific arrangements with your service provider before you can utilize

network services. Your service provider may need to give you additional instructions

for their use and explain what charges will apply. Some networks may have

limitations that affect how you can use network services. For instance, some

networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not

activated in your device. If so, they will not appear on your device menu. Your device

may also have been specially configured for your network provider. This configuration

may include changes in menu names, menu order and icons. Contact your service

provider for more information.

6101_6102.ENv1_9240568_UG.fm Page 9 Tuesday, June 7, 2005 2:59 PM

For your safety

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols.

Some features of this device, such as text messages, multimedia messages, audio

messages, instant messaging service, e-mail, mobile Internet services, content

and application download, and synchronization with a remote Internet server,

require network support for these technologies.

■Shared memory

The following features in this device may share memory: contacts, text messages,

multimedia messages (but no attachments), instant messaging, groups, voice

commands, calendar, and to-do notes. The second shared memory is used by files

stored in Gallery, attachments of multimedia messages, e-mail, and JavaTM

applications. Use of one or more of these features may reduce the memory available

for the remaining features sharing memory. For example, saving many Java

applications may use all of the available memory. Your device may display a message

that the memory is full when you try to use a shared memory feature. In this case,

delete some of the information or entries stored in the shared memory features

before continuing. Some of the features, such as text messages, may have a certain

amount of memory specially allotted to them in addition to the memory shared

with other features.

6101_6102.ENv1_9240568_UG.fm Page 10 Tuesday, June 7, 2005 2:59 PM

General information

■Overview of functions

Your phone provides many functions that are practical for daily use, such as a

calendar, a clock, an alarm clock, a radio, and a built-in camera. Your phone also

supports the following functions:

• Enhanced data rates for GSM evolution (EDGE), see “Packet data (EGPRS),” p. 42

• Extensible hypertext markup language (XHTML), see “Web,” p. 57

• Audio messaging, see “Nokia Xpress audio messaging,” p. 29

• Java 2 Platform, Micro Edition (J2METM), see “Applications,” p. 55

■Access codes

Security code

The security code (5 to 10 digits) helps to protect your phone against unauthorized

use. The preset code is 12345. To change the code, and to set the phone to request

the code, see “Security,” p. 44.

PIN codes

The personal identification number (PIN) code and the universal personal

identification number (UPIN) code (4 to 8 digits) help to protect your SIM card

against unauthorized use. See “Security,” p. 44.

The PIN2 code (4 to 8 digits) may be supplied with the SIM card and is required

for some functions.

The module PIN is required to access the information in the security module. See

“Security module,” p. 61.

The signing PIN is required for the digital signature. See “Digital signature,” p. 63.

PUK codes

The personal unblocking key (PUK) code and the universal personal unblocking key

(UPUK) code (8 digits) is required to change a blocked PIN code and UPIN code,

respectively. The PUK2 code (8 digits) is required to change a blocked PIN2 code.

If the codes are not supplied with the SIM card, contact your local service

provider for the codes.

6101_6102.ENv1_9240568_UG.fm Page 11 Tuesday, June 7, 2005 2:59 PM

General information

Restriction password

The restriction password (4 digits) is required when using the Call restrictions.

See “Security,” p. 44.

■Configuration settings service

To use some of the network services, such as mobile Internet services, MMS,

Nokia Xpress audio messaging, or remote Internet server synchronization, your

phone needs the correct configuration settings. You may be able to receive the

settings directly as a configuration message. After receiving the settings you

need to save them on your phone. The service provider may provide a PIN that is

needed to save the settings. For more information on availability, contact your

network operator, service provider, nearest authorized Nokia dealer, or visit the

support area on the Nokia Web site, www.nokiausa.com/support.

When you have received a configuration message Configuration sett. received

is displayed.

To save the settings, select Show > Save. If the phone requests Enter settings' PIN:,

enter the PIN code for the settings, and select OK. To receive the PIN code, contact

the service provider that supplies the settings. If no settings are saved yet, these

settings are saved and set as default configuration settings. Otherwise, the phone

asks Activate saved configuration settings?.

To discard the received settings, select Exit or Show > Discard.

To edit the settings, see “Configuration,” p. 43.

■Download content and applications

You may be able to download new content (for example, themes) to the phone

(network service). Select the download function (for example, in the Gallery menu).

To access the download function, see the respective menu descriptions. For the

availability of different services, pricing, and tariffs, contact your service provider.

Important: Use only services that you trust and that offer adequate

security and protection against harmful software.

■Nokia support on the Web

Check www.nokia.comusa/support or your local Nokia Web site for the latest

version of this guide, additional information, downloads, and services related to

your Nokia product.

6101_6102.ENv1_9240568_UG.fm Page 12 Tuesday, June 7, 2005 2:59 PM

Get started

1. Get started

■Open the fold

When you open the fold of the phone, it

opens up to approximately 155 degrees.

Do not try to force the fold open more.

■Install the SIM card and the battery

Always switch the device off and disconnect the charger before removing the battery.

Keep all SIM cards out of the reach of small children. For availability and information

on using SIM card services, contact your SIM card vendor. This may be the service

provider, network operator, or other vendor.

This device is intended for use with BL-4C battery.

The SIM card and its contacts can easily be damaged by scratches or bending,

so be careful when handling, inserting, or removing the card.

To remove the back cover of the phone press the release

buttons (1), and slide the back cover to remove it from

the phone (2).

Remove the battery as shown(3).

Release the SIM card holder (4).

6101_6102.ENv1_9240568_UG.fm Page 13 Tuesday, June 7, 2005 2:59 PM

Get started

Insert the SIM card (5). Make sure that the SIM card is

properly inserted, and that the golden contact area on

the card is facing downwards. Close the SIM card holder

(6) and press it until it snaps into position.

Replace the battery (7). Observe

the battery contacts. Always use

original Nokia batteries. See

“Nokia battery authentication

guidelines,” p. 68.

Slide the back cover into its

place (8, 9).

■Charge the battery

Warning: Use only batteries, chargers, and enhancements approved by

Nokia for use with this particular model. The use of any other types may

invalidate any approval or warranty, and may be dangerous.

Check the model number of any charger before use with this device. This device is

intended for use when supplied with power from an AC-3, AC-4, and DC-4 charger,

and from AC-1, ACP-7, ACP-12, and LCH-12 charger when used with the charger

adapter CA-44, which is available at your Nokia dealer or www.nokiausa.com.

For availability of approved enhancements, please check with your dealer.

1. Connect the charger to a wall socket.

2. Connect the lead from the charger to the

socket on the bottom of your phone.

If the battery is completely discharged, it may take a

few minutes before the charging indicator appears

on the display or before any calls can be made.

The charging time depends on the charger and the battery used. For example,

charging a BL-4C battery with the AC-3 charger takes approximately 2 hours and

12 minutes while the phone is in the standby mode.

■Switch the phone on and off

Press and hold the end key.

If the phone asks for a PIN or a UPIN code, enter the code (displayed as ****), and

select OK.

6101_6102.ENv1_9240568_UG.fm Page 14 Tuesday, June 7, 2005 2:59 PM

Get started

■Normal operating position

Use the phone only in its normal

operating position.

Your device has an external antenna.

Note: As with any other radio

transmitting device, do not touch the

antenna unnecessarily when the

device is switched on. Contact with

the antenna affects call quality and

may cause the device to operate at a

higher power level than otherwise

needed. Avoiding contact with the antenna area when operating the

device optimizes the antenna performance and the battery life.

6101_6102.ENv1_9240568_UG.fm Page 15 Tuesday, June 7, 2005 2:59 PM

Your phone

2. Your phone

■Keys and parts

Note: Your phone may vary slightly

in appearance, but the functionality

is the same.

• Earpiece (1)

• Main display (2)

• Left selection key (3)

Middle selection key (4)

Right selection key (5)

The function of these keys depends on

the guiding text shown on the display

above the keys.

• Volume key (6)

• 4-way navigation key (7)

Scroll up, down, left, and right.

• Call key (8)

• Camera release key (9)

• Infrared (IR) port (10)

• End key and power key (11)

• Charger connector (12)

• Pop-PortTM connector (13)

• Microphone (14)

• Loudspeaker (15)

• Camera lens (16)

• Mini display (17)

6101_6102.ENv1_9240568_UG.fm Page 16 Tuesday, June 7, 2005 2:59 PM

Your phone

■Standby mode

When the phone is ready for use, and you have not entered any characters, the

phone is in the standby mode.

Mini display

When the fold is closed, the mini display may show the following:

• The signal strength of the cellular network at your current location and the

battery charge level

• The name of the network, or if the phone is not in service, it is indicated by a

text note

• The time and date, the active profile, and the alarm clock or calendar note alerts

When you have an incoming call, the caller’s name or number is shown if it

is identified.

Main display

• Name of the network or the operator logo (1)

• Signal strength of the cellular network at your

current location (2)

• Battery charge level (3)

• Left selection key is Go to (4)

• Middle selection key is Menu (5)

• Right selection key is Names (6) or another

shortcut to a function that you selected.

See “My shortcuts,” p. 39. Operator variants may

have an operator-specific name to access an operator-specific Web site.

Personal shortcut list

The left selection key is Go to.

To view the functions in the personal shortcut list, select Go to. To activate a

function select it.

To view a list with available functions, select Go to > Options > Select options.

To add a function to the shortcut list, select Mark. To remove a function from the

list, select Unmark.

To rearrange the functions on your personal shortcut list, select Go to > Options >

Organize. Select the desired function and Move and the place where you want to

move the function.

6101_6102.ENv1_9240568_UG.fm Page 17 Tuesday, June 7, 2005 2:59 PM

Your phone

Shortcuts in the standby mode

• To access the list of dialed numbers, press the call key once. Scroll to the

number or name that you want; and to call the number, press the call key.

• To open the web browser, press and hold 0.

• To call your voice mailbox, press and hold 1.

• Use the navigation key as a shortcut. See “My shortcuts,” p. 39.

Power saving

A digital clock view overwrites the display when no function

of the phone has been used for a certain period of time.

To activate the power saver, see Power saver in “Main

display,” p. 39, and “Mini display,” p. 40. To deactivate

the screen saver, open the fold, or press any key.

Indicators

You received one or several text or picture messages. See “Read and

reply to an SMS message,” p. 26.

You received one or several multimedia messages. See “Read and reply

to a multimedia message,” p. 28.

The phone registered a missed call. See “Call log,” p. 37.

The keypad is locked. See “Keypad lock (keyguard),” p. 19.

The phone does not ring for an incoming call or text message when

Incoming call alert and Message alert tone are set to Off. See “Tones,” p. 38.

The alarm clock is set to On. See “Alarm clock,” p. 50.

When the packet data connection mode Always online is selected and

the packet data service is available, the indicator is shown. See “Packet

data (EGPRS),” p. 42.

A packet data connection is established. See “Packet data (EGPRS),” p. 42

and “Browse pages,” p. 58.

The packet data connection is suspended (on hold), for example, if there

is an incoming or outgoing call during a packet data dial-up connection.

When the infrared connection is activated, the indicator is

shown continuously.

6101_6102.ENv1_9240568_UG.fm Page 18 Tuesday, June 7, 2005 2:59 PM

Your phone

■Keypad lock (keyguard)

To prevent the keys from being accidentally pressed, select Menu, and press * within

3.5 seconds to lock the keypad.

To unlock the keypad, select Unlock, and press *. If the Security keyguard is set On,

enter the security code if requested.

To answer a call when the keyguard is on, press the call key. When you end or

reject the call, the keypad automatically locks.

For Automatic keyguard and Security keyguard, see “Phone,” p. 41.

When the keyguard is on, calls still may be possible to the official emergency

number programmed into your device.

6101_6102.ENv1_9240568_UG.fm Page 19 Tuesday, June 7, 2005 2:59 PM

Call functions

3. Call functions

■Make a call

1. Enter the phone number, including the area code.

For international calls, press * twice for the international prefix (the + character

replaces the international access code) and then enter the country code, the

area code without the leading 0, if necessary, and the phone number.

2. To call the number, press the call key.

3. To end the call or to cancel the call attempt, press the end key, or close the phone.

To make a call using names, search for a name or phone number in Contacts, see

“Search for a contact,” p. 33. Press the call key to call the number.

To access the list of up to 20 numbers you last called or attempted to call, press the

call key once in the standby mode. To call the number, select a number or name,

and press the call key.

1-touch dialing

Assign a phone number to one of the 1-touch dialing keys, 2 to 9. See “1-touch

dials,” p. 36. Call the number in either of the following ways:

• Press a 1-touch dialing key, and then press the call key.

•If 1-touch dialing is set to On, press and hold a 1-touch dialing key until the

call begins. See 1-touch dialing in “Call,” p. 40.

■Answer or reject a call

To answer an incoming call, press the call key, or open the phone. To end the call,

press the end key, or close the phone. For more options, see "Call," p. 40.

To reject an incoming call, press the end key, or if the phone is open, close the phone.

To reject an incoming call when the phone is closed, open the phone, and press

the end key within 1.5 seconds.

To mute the ringing tone, press one of the volume keys, or select Silence.

Tip: If the Forward if busy function is activated to forward the calls (for

example, to your voice mailbox) rejecting an incoming call also forwards

the call. See “Call,” p. 40.

If a compatible headset supplied with the headset key is connected to the phone,

to answer and end a call, press the headset key.

6101_6102.ENv1_9240568_UG.fm Page 20 Tuesday, June 7, 2005 2:59 PM

Call functions

Call waiting

To answer the waiting call during an active call, press the call key. The first call is

put on hold. To end the active call, press the end key.

To activate the Call waiting function, see “Call,” p. 40.

■Options during a call

Many of the options that you can use during a call are network services. For

availability, contact your network operator or service provider.

During a call, select Options and from the following options:

Call options are Mute or Unmute, Contacts, Menu, Record, Lock keypad, Audio

enhancing, Loudspeaker or Handset.

Network services options are Answer and Decline, Hold or Unhold, New call, Add

to conference, End call, End all calls, and the following:

Touch tones — to send tone strings

Swap — to switch between the active call and the call on hold

Transfer calls — to connect a call on hold to an active call and disconnect yourself

Conference — to make a conference call that allows up to five persons to take

part in a conference call

Private call — to discuss privately in a conference call

Warning: Do not hold the device near your ear when the loudspeaker is

in use, because the volume may be extremely loud.

6101_6102.ENv1_9240568_UG.fm Page 21 Tuesday, June 7, 2005 2:59 PM

Write text

4. Write text

You can enter text (for example, when writing messages) using traditional or

predictive text input. When using traditional text input, press a number key, 1 to 9,

repeatedly until the desired character appears. In predictive text input you can

enter a letter with a single keypress.

When you are writing text, predictive text input is indicated by and traditional

text input by at the top left of the display. , , or appear next

to the text input indicator, indicating the character case.

To change the character case and the text input mode, press #. indicates

number mode. To change from the letter to number mode, press and hold #,

and select Number mode.

■Settings

To set the writing language, select Options > Writing language. Predictive text

input is only available for the languages listed.

Select Options > Dictionary on to set the predictive text input or Dictionary off to

set traditional text input.

■Predictive text input

Predictive text input is based on a built-in dictionary to which you can also add

new words.

1. Start writing a word using the 2 to 9 keys. Press each key only once for a

single letter. The word changes after each keypress.

2. When you have finished writing the word and it is correct, to confirm it, press

0 to add a space, or press any of the navigation keys. Press a navigation key to

move the cursor.

If the word is not correct, press * repeatedly, or select Options > Matches.

When the word that you want appears, confirm it.

If ? is displayed after the word, the word you intended to write is not in the

dictionary. To add the word to the dictionary, select Spell. Enter the word

(traditional text input is used), and select Save.

3. Start writing the next word.

6101_6102.ENv1_9240568_UG.fm Page 22 Tuesday, June 7, 2005 2:59 PM

Write text

Write compound words

Enter the first part of the word, and press the navigation key right to confirm it.

Write the last part of the word, and confirm the word.

■Traditional text input

Press a number key, 1 to 9, repeatedly until the desired character appears. Not all

characters available under a number key are printed on the key. The characters

available depend on the writing language. See “Settings,” p. 22.

If the next letter you want is located on the same key as the present one, wait

until the cursor appears, or press any of the navigation keys and enter the letter.

The most common punctuation marks and special characters are available under

the 1 key.

6101_6102.ENv1_9240568_UG.fm Page 23 Tuesday, June 7, 2005 2:59 PM

Navigate the menus

5. Navigate the menus

The phone offers you an extensive range of functions, which are grouped into menus.

1. To access the menu, select Menu. To change the menu view, select Options >

Main menu view > List or Grid.

2. Scroll through the menu, and select a submenu (for example, Settings).

3. If the menu contains submenus, select the one that you want (for example, Call).

4. If the selected menu contains further submenus, select the one that you want

(for example, Anykey answer).

5. Select the setting of your choice.

6. To return to the previous menu level, select Back. To exit the menu, select Exit.

6101_6102.ENv1_9240568_UG.fm Page 24 Tuesday, June 7, 2005 2:59 PM

Messages

6. Messages

The message services can only be used if they are supported by

your network or your service provider.

Note: When sending messages, your phone may display the words

Message sent. This is an indication that the message has been sent by

your device to the message center number programmed into your device.

This is not an indication that the message has been received at the

intended destination. For more details about messaging services, check

with your service provider.

Only devices that have compatible features can receive and display messages.

The appearance of a message may vary depending on the receiving device.

■Text messages (SMS)

Using the short message service (SMS) you can send and receive multipart messages

made of several ordinary text messages (network service) that can contain pictures.

Before you can send any text, picture, or e-mail message, you must save your

message center number. See “Message settings,” p. 30.

To check SMS e-mail service availability and to subscribe to the service, contact

your service provider.

Your device supports the sending of text messages beyond the character limit for

a single message. Longer messages will be sent as a series of two or more messages.

Your service provider may charge accordingly. Characters that use accents or other

marks take up more space limiting the number of characters that can be sent in a

single message.

At the top of the display, you can see the message length indicator that tracks the

number of characters available. For example, 10/2 means that you can still add

10 characters for the text to be sent as two messages.

Write and send an SMS message

1. Select Menu > Messages > Create message > Text message.

2. Enter a message. See “Write text,” p. 22. To insert text templates or a picture

into the message, see “Templates,” p. 26. Each picture message comprises

several text messages. Sending one picture or multipart message may cost

more than sending one text message.

6101_6102.ENv1_9240568_UG.fm Page 25 Tuesday, June 7, 2005 2:59 PM

Messages

3. To send the message, select Send > Recently used, To phone number, To many,

or To e-mail address. To send a message using a predefined message profile,

select Via sending profile. For the message profile, see “Text and SMS e-mail,”

p. 30. Select or enter a phone number or profile.

Read and reply to an SMS message

is shown when you received an SMS message or an SMS e-mail. The blinking

indicates that the message memory is full. Before you can receive new

messages, delete some of your old messages in the Inbox folder.

1. To view a new message, select Show. To view it later, select Exit.

To read the message later, select Menu > Messages > Inbox. If more than one

message is received, select the message that you want to read. indicates

an unread message.

2. While reading a message, select Options, and delete or forward the message;

edit the message as a text message or an SMS e-mail, rename the message

you are reading, or move it to another folder; or view or extract message

details. You can also copy text from the beginning of the message to your

phone calendar as a reminder note. To save the picture in the Templates

folder when reading a picture message, select Save picture.

3. To reply as a message, select Reply > Text message, or Multimedia msg. Enter

the reply message. When replying to an e-mail, first confirm or edit the

e-mail address and subject.

4. To send the message to the displayed number, select Send > OK.

Templates

Your phone has text templates and picture templates that you can use in

texts, pictures, or SMS e-mail messages.

To access the template list, select Menu > Messages > Saved items > Text

messages > Templates.

■Multimedia messages (MMS)

Note: Only devices that offer compatible multimedia message or e-mail

features can receive and display multimedia messages. Multimedia

message objects may contain viruses or otherwise be harmful to your

device or PC. Do not open any attachment if you are not sure of the

trustworthiness of the sender.

6101_6102.ENv1_9240568_UG.fm Page 26 Tuesday, June 7, 2005 2:59 PM

Messages

A multimedia message can contain text, sound, a picture, a calendar note, a

business card, or a video clip. If the message is too large, the phone may not be

able to receive it. Some networks allow text messages that include an Internet

address where you can view the multimedia message.

You cannot receive multimedia messages during a call, a game, another Java

application, or an active browsing session over GSM data. Because delivery of

multimedia messages can fail for various reasons, do not rely solely upon them

for essential communications.

Write and send a multimedia message

To set the settings for multimedia messaging, see “Multimedia,” p. 31. To check

availability and to subscribe to the multimedia messaging service, contact your

service provider.

1. Select Menu > Messages > Create message > Multimedia msg..

2. Enter a message. See “Write text,” p. 22.

To insert a file, select Options > Insert and from the following options:

Image, Sound clip, or Video clip — to insert a file from Gallery

New image opens the Camera — to take a new image to be added to the message

New sound clip opens the Recorder — to make a new recording to be added to

the message

Business card or Calendar note — to insert a business card or a calendar note

in the message

Slide — to insert a slide to the message. Your phone supports multimedia

messages that contain several pages (slides). Each slide can contain text, one

image, a calendar note, a business card, and one sound clip. To open a desired

slide if the message contains several slides, select Options > Previous slide,

Next slide, or Slide list. To set the interval between the slides, select Options >

Slide timing. To move the text component to the top or bottom of the message,

select Options > Place text first or Place text last.

The following options may also be available: Delete to delete an image, slide,

or sound clip from the message, Clear text, Preview, or Save message. In More

options the following options may be available: Insert contact, Insert number,

Message details, and Edit subject.

3. To send the message, select Send > Recently used, To phone number, To

e-mail address, or To many.

6101_6102.ENv1_9240568_UG.fm Page 27 Tuesday, June 7, 2005 2:59 PM

Messages

4. Select the contact from the list, or enter the recipient’s phone number or

e-mail address, or search for it in Contacts. Select OK. The message is moved

to the Outbox folder for sending.

While the multimedia message is being sent, the animated indicator is

displayed and you can use other functions on the phone. If the sending fails,

the phone tries to resend it a few times. If this fails, the message remains in

the Outbox folder, and you can try to resend it later.

If you select Save sent messages > Yes, the sent message is saved in the Sent

items folder. See “Multimedia,” p. 31. When the message is sent, it is not an

indication that the message has been received at the intended destination.

from being copied, modified, transferred or forwarded.

Read and reply to a multimedia message

The default setting of the multimedia message service is generally on.

When your phone receives a multimedia message, the animated is displayed.

When the message has been received, and Multimedia message received

are shown.

1. To read the message, select Show. To view it later, select Exit.

To read the message later, select Menu > Messages > Inbox. In the list of

messages, indicates an unread message. Select the message that you

want to view.

2. The function of the middle selection key changes according to the currently

displayed attachment in the message.

To view the whole message if the received message contains a presentation, a

sound clip, or view a video clip, select Play.

To zoom in on an image, select Zoom. To view a business card or calendar

note or to open a theme object, select Open.

3. To reply to the message, select Options > Reply > Text message or

Multimedia msg.. Enter the reply message, and select Send. You can send the

reply message only to the person who sent you the original message.

Select Options to access available options.

■Memory full

When you receive a new text message, and the message memory is full, blinks

and Text msgs. memory full. Delete msgs. is shown. Select No, and delete some

messages from a folder. To discard the waiting message, select Exit > Yes.

6101_6102.ENv1_9240568_UG.fm Page 28 Tuesday, June 7, 2005 2:59 PM

Messages

When a new multimedia message is waiting, and the memory for the messages is

full, blinks and Multimedia memory full. View waiting msg. is shown. To view

the waiting message, select Show. Before you can save the waiting message, delete

old messages to free memory space. To save the message, select Save.

To discard the waiting message, select Exit > Yes. If you select No, you can view

the message.

■Folders

The phone saves received text and multimedia messages in the Inbox folder.

Multimedia messages that have not yet been sent are moved to the Outbox folder.

If you select Message settings > Text messages > Save sent messages > Yes, and

Message settings > Multimedia msgs. > Save sent messages > Yes, the sent messages

are saved in the Sent items folder.

To save the text message that you write and wish to send later in the Saved items

folder, select Options > Save message > Saved text msgs.. For multimedia messages,

select Save message. indicates unsent messages.

To organize your text messages, move some of them to My folders or add new folders

for your messages. Select Messages > Saved items > Text messages > My folders.

To add a folder, select Options > Add folder. If you have not saved any folders,

select Add.

To delete or rename a folder, scroll to the desired folder, and select Options >

Delete folder or Rename folder.

■Nokia Xpress audio messaging

With this menu, use the multimedia message service to create and send a voice

message in a convenient way. Multimedia messaging service must be activated

before this service can be used.

Create an audio message

Select Menu > Messages > Create message > Audio message. The recorder opens.

For further operation of the recorder, see “Recorder,” p. 48. When the message is

ready to send, select Options > Play (to check the message before sending), Replace

sound clip (to repeat the recording), Save message, Save sound clip (to save the

recording in Gallery), Edit subject (to insert a subject to the message), Message

details (to view the message details), or Loudspeaker or Handset.

To send the message, select Send > Recently used, To phone number, To e-mail

address, or To many. Depending on your operator, more options may be available.

6101_6102.ENv1_9240568_UG.fm Page 29 Tuesday, June 7, 2005 2:59 PM

Messages

Select the contact from the list, or enter the recipient’s phone number or e-mail

address, or search for it in Contacts. Select OK. The message is moved to the Outbox

folder for sending.

■Voice messages

The voice mailbox is a network service and you may need to subscribe to it. For

details, contact your service provider.

To call your voice mailbox, select Menu > Messages > Voice messages > Listen to

voice messages. To enter, search for, or edit your voice mailbox number, select

Voice mailbox number.

If supported by the network, indicates that there are new voice messages.

Select Listen to call your voice mailbox number.

■Info messages

Select Menu > Messages > Info messages. With the Info messages network service,

you can receive messages on various topics from your service provider. To check

availability, topics, and the relevant topic numbers, contact your service provider.

■Service commands

Select Menu > Messages > Service commands. Write and send service requests

(also known as USSD commands) to your service provider, such as activation

commands for network services.

■Delete messages

To delete all messages from a folder, select Menu > Messages > Delete messages

and the folder from which you want to delete the messages. Select Yes, and if the

folder contains unread messages, the phone asks whether you want to delete

them also. Select Yes again.

■Message settings

Text and SMS e-mail

The message settings affect the sending, receiving, and viewing of messages.

Select Menu > Messages > Message settings > Text messages, and from the

following options:

Sending profile — If more than one message profile set is supported by your SIM

card, select the set you want to change.

6101_6102.ENv1_9240568_UG.fm Page 30 Tuesday, June 7, 2005 2:59 PM

Messages

The following options may be available: Message center number (delivered from

your service provider), Messages sent via, Message validity, Default recipient

number (text messages), or E-mail server (e-mail), Delivery reports, Use packet

data, Reply via same center (network service) and Rename sending profile.

Save sent messages > Yes — Set the phone to save the sent text messages in the

Sent items folder.

Automatic resending > On — The phone automatically attempts to resend a text

message, if the sending has failed.

Multimedia

The message settings affect the sending, receiving, and viewing of

multimedia messages.

Select Menu > Messages > Message settings > Multimedia msgs. and from the

following options:

Save sent messages > Yes — to set the phone to save sent multimedia messages

in the Sent items folder

Delivery reports — to ask the network to send delivery reports about your messages

(network service)

Scale image down — to define the image size when you insert an image to a

multimedia message

Default slide timing — to define the default time between slides in

multimedia messages

Allow multimedia reception > Yes or No — to receive or to block the multimedia

message. If you select In home network, you cannot receive multimedia messages

when outside your home network.

Incoming multi-media messages > Retrieve, Retrieve manually, or Reject — to

allow the reception of multimedia messages automatically, manually after being

prompted, or to reject the reception

Configuration settings > Configuration — Only the configurations that support

multimedia messaging are shown. Select a service provider, Default, or Personal

config. for multimedia messaging. Select Account and select a multimedia messaging

service account contained in the active configuration settings.

Allow advertisements — to receive or reject advertisements. This setting is not

shown if Allow multimedia reception is set to No.

6101_6102.ENv1_9240568_UG.fm Page 31 Tuesday, June 7, 2005 2:59 PM

Messages

Other settings

To select other settings for messages, select Menu > Messages > Message

settings > Other settings. To change the font size for reading and writing

messages, select Font size. To replace character-based smileys with graphical

ones, select Graphical smileys > Yes.

■Message counter

Select Menu > Messages > Message counter for approximate information on

your recent communications.

6101_6102.ENv1_9240568_UG.fm Page 32 Tuesday, June 7, 2005 2:59 PM

Contacts

7. Contacts

You can save names and phone numbers (Contacts) in the phone

memory and in the SIM card memory.

The phone memory may save contacts with numbers and text items.

You can also save an image for a certain number of names.

Names and numbers saved in the SIM card memory are indicated by .

■Search for a contact

Select Menu > Contacts > Names > Options > Find. Scroll through the list of

contacts or enter the first letter of the name for which you are searching.

■Save names and phone numbers

Names and numbers are saved in the used memory. Select Menu > Contacts >

Names > Options > Add new contact. Enter the name and the phone number.

■Save numbers, items, or an image

In the phone memory for contacts, you can save different types of phone

numbers and short text items per name.

The first number you save is automatically set as the default number. It is indicated

with a frame around the number type indicator (for example, ). When you

select a name, the default number is used unless you select another number.

1. Make sure that the memory in use is either Phone or Phone and SIM.

2. Scroll to the name to which you want to add a new number or text item, and

select Details > Options > Add detail.

3. To add a number, select Number and one of the number types.

To add another detail, select a text type or an image from Gallery.

To change the number type, scroll to the desired number, and select

Options > Change type. To set the selected number as the default number,

select Set as default.

4. Enter the number or text item; to save it, select OK.

5. To return to the standby mode, select Back > Exit.

6101_6102.ENv1_9240568_UG.fm Page 33 Tuesday, June 7, 2005 2:59 PM

Contacts

■Copy contacts

Search for the contact you want to copy, and select Options > Copy. You can

copy names and phone numbers from the phone contact memory to the SIM card

memory, or vice versa. The SIM card memory can save names with one phone

number attached to them.

■Edit contact details

1. Search for the contact you want to edit, select Details, and scroll to the

desired name, number, text item, or image.

2. To edit a name, number, or text item, or to change an image, select Options >

Edit name, Edit number, Edit detail, or Change image.

■Delete contacts or contact details

To delete all the contacts and the details attached to them from the phone or SIM

card memory, select Menu > Contacts > Delete all contacts > From phone mem.

or From SIM card. Confirm with the security code.

To delete a contact, search for the desired contact, and select Options >

Delete contact.

To delete a number, text item, or an image attached to the contact, search for the

contact, and select Details. Scroll to the desired detail, and select Options >

Delete > Delete number, Delete detail, or Delete image. Deleting an image from

contacts does not delete it from Gallery.

■Business cards

You can send and receive a person’s contact information from a compatible

device that supports the vCard standard as a business card.

To send a business card, search for the contact whose information you want to

send, and select Options > Send bus. card > Via multimedia, Via text message, or

Via infrared.

When you have received a business card, select Show > Save to save the business

card in the phone memory. To discard the business card, select Exit > Yes.

■Settings

Select Menu > Contacts > Settings and from the following options:

Memory in use — to select SIM card or phone memory for your contacts

Contacts view — to select how the names and numbers in contacts are displayed

Memory status — to view the free and used memory capacity

6101_6102.ENv1_9240568_UG.fm Page 34 Tuesday, June 7, 2005 2:59 PM

Contacts

■Groups

Select Menu > Contacts > Groups to arrange the names and phone numbers saved

in the memory into caller groups with different ringing tones and group images.

■Voice dialing

You can make a phone call by saying a voice tag that has been added to a phone

number. Any spoken words, such as a name, can be a voice tag. The number of

voice tags you can create is limited.

Before using voice tags, note the following:

• Voice tags are not language-dependent. They are dependent on the

speaker's voice.

• You must say the name exactly as you said it when you recorded it.

• Voice tags are sensitive to background noise. Record voice tags, and use them

in a quiet environment.

• Very short names are not accepted. Use long names, and avoid similar names

for different numbers.

Note: Using voice tags may be difficult in a noisy environment or

during an emergency, so you should not rely solely upon voice dialing

in all circumstances.

Add and manage voice tags

Save or copy the contacts to the phone memory for which you want to add a voice

tag. You can also add voice tags to the names in the SIM card, but if you replace

your SIM card with a new one, you must first delete the old voice tags before you

can add new ones.

1. Search for the contact to which you want to add a voice tag.

2. Select Details, scroll to the desired phone number, and select Options >

Add voice tag.

3. Select Start, and say clearly the words you want to record as a voice tag.

After recording, the phone plays the recorded tag.

appears behind the phone number with a voice tag in Contacts.

To check the voice tags, select Menu > Contacts > Voice tags. Scroll to the contact

with the voice tag that you want, and select an option to listen to, delete, or change

the recorded voice tag.

6101_6102.ENv1_9240568_UG.fm Page 35 Tuesday, June 7, 2005 2:59 PM

Contacts

Make a call with a voice tag

If the phone has an application running that is sending or receiving data using a

GPRS connection, you must end the application before voice dialing.

1. In the standby mode, press and hold the volume down key. A short tone is heard,

and Speak now is displayed.

2. Say the voice tag clearly. The phone plays the recognized voice tag, and dials

the phone number of the voice tag after 1.5 seconds.

If you are using a compatible headset with the headset key, press and hold the

headset key to start the voice dialing.

■1-touch dials

To assign a number to a 1-touch dialing key, select Menu > Contacts > 1-touch

dialing, and scroll to the 1-touch dialing number that you want.

Select Assign, or if a number has already been assigned to the key, select

Options > Change. Select Find, the name, then the number you want to assign.

If the 1-touch dialing function is off, the phone asks whether you want to activate it.

See also 1-touch dialing in “Call,” p. 40.

To make a call using the 1-touch dialing keys, see “1-touch dialing,” p. 20.

■Info, service, and my numbers

Select Menu > Contacts and from the following functions:

Info numbers — to call the information numbers of your service provider if the

numbers are included on your SIM card (network service)

Service numbers — to call the service numbers of your service provider if the

numbers are included on your SIM card (network service)

My numbers — to view the phone numbers assigned to your SIM card, if the

numbers are included on your SIM card

6101_6102.ENv1_9240568_UG.fm Page 36 Tuesday, June 7, 2005 2:59 PM

Call log

8. Call log

The phone registers the phone numbers of identified missed, received, and dialed

calls; the message recipients; and the approximate length of your calls.

The phone registers if it is switched on and within the network’s service area, and

the network supports these functions.

■Recent calls lists

When you select Options in the Missed calls, Received calls, Dialed numbers, or

Message Recipients menu, you can view the time of the call; edit, view, or call the

registered phone number; add it to the memory; or delete it from the list. You can

also send a text message. To delete the recent calls lists, select Delete recent calls.

■Counters and timers

Note: The actual invoice for calls and services from your service provider

may vary, depending upon network features, rounding-off for billing,

taxes and so forth.

Some timers, including the life timer, may be reset during service or

software upgrades.

Select Menu > Call log > Call timers, Packet data counter, or Packet data conn.

timer for approximate information on your recent communications.

6101_6102.ENv1_9240568_UG.fm Page 37 Tuesday, June 7, 2005 2:59 PM

Settings

9. Settings

■Profiles

Your phone has various setting groups, called profiles, for which you can customize

the phone tones for different events and environments.

Select Menu > Settings > Profiles, and a profile.

To activate the selected profile, select Activate.

To set the profile to be active until a certain time up to 24 hours, select Timed and

set the time the profile setting shall end. When the time set for the profile expires,

the previous profile that was not timed, becomes active.

To personalize the profile, select Customize. Select the setting you want to change,

and make the changes.

■Themes

A theme contains many elements for personalizing your phone, such as wallpaper,

screen saver, color scheme, and a ringing tone.

Select Menu > Settings > Themes and from the following options:

Select theme — to set a theme in your phone. A list of folders in Gallery opens.

Open the Themes folder, and select a theme.

Theme downloads — to open a list of links to download more themes.

See “Download files,” p. 60.

■Tones

You can change the settings of the selected active profile.

Select Menu > Settings > Tones. Select and change Incoming call alert, Ringing tone,

Ringing volume, Vibrating alert, Message alert tone, Keypad tones, and Warning

tones. You can find the same settings in the Profiles menu. See “Profiles,” p. 38.

To set the phone to ring only for calls from phone numbers that belong to a selected

caller group, select Alert for. Scroll to the caller group you want or All calls, and

select Mark.

6101_6102.ENv1_9240568_UG.fm Page 38 Tuesday, June 7, 2005 2:59 PM

Settings

■My shortcuts

With personal shortcuts, you get quick access to often used functions of the phone.

To manage the shortcuts, select Menu > Settings > My shortcuts and from the

following options:

Right selection key — to select a function from the list for the right selection key.

See also “Standby mode,” p. 17. This menu may not be shown, depending on your

service provider.

Navigation key — to select shortcut functions for the navigation key. Scroll to the

desired navigation key, select Change and a function from the list. To remove a

shortcut function from the key, select (empty). To reassign a function for the key,

select Assign. This menu may not be shown, depending on your service provider.

Voice commands — to activate phone functions by saying a voice tag. Select a

folder, scroll to a function to which you want to add a voice tag, and select Add.

indicates a voice tag. To add a voice command, see “Add and manage voice

tags,” p. 35. To activate a voice command, see “Make a call with a voice tag,” p. 36.

■Main display

Select Menu > Settings > Main display and from the following options:

Wallpaper — to add the background image to the main display in standby mode.

To select, activate, or deactivate the wallpaper, select Select wallpaper > On or Off.

Select Select slide set and a folder in the Gallery to use the images in the folder as a

slide set. To download more images for wallpaper, select Graphic downloads.

Screen saver > On — to activate the screen saver for the main display. To set the

time after which the screen saver is activated, select Time-out. To select a graphic

for the screen saver, select Image and choose an image or a graphic from the Gallery.

Select Select slide set and a folder in the Gallery to use the images in the folder as

a slide set. To download more images for the screen saver, select Graphic downloads.

Power saver > On — to save some battery power. A digital clock is displayed when

no function of the phone is used for a certain time.

Color schemes — to change the color in some display components, (for example,

menu background and signal and battery bar colors).

Idle state font color — to select the color for the texts on the display in the

standby mode.

Operator logo — to set your phone to display or hide the operator logo. The menu

is dimmed, if you have not saved the operator logo. For more information on

availability of an operator logo, contact your network operator or service provider.

6101_6102.ENv1_9240568_UG.fm Page 39 Tuesday, June 7, 2005 2:59 PM

Settings

■Mini display

Select Menu > Settings > Mini display settings. You can change the settings for

Wallpaper, Screen saver, Power saver, and Color schemes.

■Time and date

Select Menu > Settings > Time and date and from the following options:

Clock — to set the phone to show the clock in the standby mode, adjust the clock,

and select the time zone and the time format

Date — to set the phone to show the date in the standby mode, set the date, and

select the date format and date separator

Auto-update of date & time (network service) — to set the phone to automatically

update the time and date according to the current time zone

■Call

Select Menu > Settings > Call and from the following options:

Automatic volume control — to set the phone to automatically adjust the speaker

volume according to the background noise.

Call forwarding (network service) — to forward your incoming calls. You may not

be able to forward your call, if some call restriction functions are active. See Call

restrictions in “Security,” p. 44.

Anykey answer > On — to answer an incoming call, briefly press any key, except

the end key and the left and right selection keys.

Answer when fold is opened > On — to answer an incoming call, open the phone.

Automatic redial > On — to set your phone to make a maximum of 10 attempts to

connect the call after an unsuccessful call attempt.

1-touch dialing > On — to activate speed dialing. To set up speed dialing, see

“1-touch dials,” p. 36. To dial, press and hold the corresponding number key.

Call waiting > Activate — to set the network to notify you of an incoming call

while you have a call in progress (network service). See “Call waiting,” p. 21.

Summary after call > On — to briefly display the approximate duration and cost

(network service) of the call after each call.

Send my caller ID (network service) > Yes, No, or Set by network.

Line for outgoing calls (network service) — to select the phone line 1 or 2 to make

calls, if supported by your SIM card.

6101_6102.ENv1_9240568_UG.fm Page 40 Tuesday, June 7, 2005 2:59 PM

Settings

■Phone

Select Menu > Settings > Phone and from the following options:

Phone language — to set the display and writing language

Memory status — to view the free memory and the used memory in Gallery,

Messages and Applications

Automatic keyguard — to set the keypad of your phone to lock automatically

after a preset time delay when the phone is in the standby mode and no function

of the phone has been used. Select On, and you can set the time from 5 seconds

to 60 minutes.

Security keyguard — to set the phone to ask for the security code when you unlock

the keyguard. Enter the security code, and select On.

When the keyguard is on, calls still may be possible to the official emergency

number programmed into your device.

Cell info display > On — to receive information from the network operator

depending on the network cell used (network service)

Welcome note — to enter a welcome note to be shown briefly when the phone is

switched on

Operator selection > Automatic — to set the phone automatically to select one of

the cellular networks available in your area. With Manual, you can select a network

that has a roaming agreement with your home network operator.

Confirm SIM service actions — see “SIM services,” p. 64.

Help text activation — to select whether the phone shows help texts

Start-up tone — to select whether the phone plays a start-up tone when the

phone is switched on

■Connectivity

You can connect your phone to compatible devices using an IR connection. You

can also define the settings for packet data dial-up connections.

Infrared

You can set up the phone to send and receive data through its infrared (IR) port.

To use an IR connection, the device with which you want to establish a connection

must be IrDA compliant. You can send or receive data to or from a compatible phone

or data device (for example, a computer) through the IR port of your phone.

Do not point the IR beam at anyone's eyes or allow it to interfere with other IR

devices. Infrared devices are Class 1 laser products.

6101_6102.ENv1_9240568_UG.fm Page 41 Tuesday, June 7, 2005 2:59 PM

Settings

When sending or receiving data, ensure that the IR ports of the sending and

receiving devices are pointing at each other and that there are no obstructions

between the devices.

To activate the IR port of your phone to receive data using IR, select Menu >

Settings > Connectivity > Infrared.

To deactivate the IR connection, select Menu > Settings > Connectivity > Infrared.

When the phone displays Deactivate infrared?, select Yes.

If data transfer is not started within 2 minutes after the activation of the IR port,

the connection is cancelled and must be started again.

IR connection indicator

When is shown continuously, the IR connection is activated, and your

phone is ready to send or receive data through its IR port.

When blinks, your phone is trying to connect to the other device, or a

connection has been lost.

Packet data (EGPRS)

Enhanced general packet radio service (EGPRS), packet data, is a network service

which allows mobile phones to send and receive data over an Internet protocol

(IP)-based network. It enables wireless access to data networks such as the Internet.

The applications that may use packet data are MMS, browsing sessions, e-mail,

remote SyncML, Java application downloading, and the PC dial-up.

To define how to use the service, select Menu > Settings > Connectivity >

Packet data > Packet data connection.

Select When needed to set the packet data connection to be established when an

application needs it. The connection will be closed when the application is terminated.

Select Always online to set the phone to automatically connect to an packet data

network when it is switched on.

indicates a packet data connection.

Modem settings

You can connect the phone using an IR or a data cable (CA-42) connection to a

compatible PC, and use the phone as a modem to enable packet data connectivity

from the PC.

To define the settings for connections from the PC, select Menu > Settings >

Connectivity > Packet data > Packet data settings > Active access point, activate

the access point you want to use, and select Edit active access point. Select Alias

for access point, and enter a nick name for the currently selected access point.

Select Packet data access point, and enter the access point name (APN) to establish

a connection to an EGPRS network.

6101_6102.ENv1_9240568_UG.fm Page 42 Tuesday, June 7, 2005 2:59 PM

Settings

You can also set the dial-up service settings (access point name) on your PC using

the Nokia Modem Options software. See “PC Suite,” p. 65. If you have set the

settings both on the PC and on your phone, the PC settings are used.

■Enhancements

This menu is shown only if the phone is or has been connected to a compatible

mobile enhancement.

Select Menu > Settings > Enhancements. You can select an enhancement menu

if the corresponding enhancement is, or has been, connected to the phone.

Depending on the enhancement, select from the following options:

Default profile — to select the profile that you want to be automatically activated

when you connect to the selected enhancement

Automatic answer — to set the phone to answer an incoming call automatically after

5 seconds. If Incoming call alert is set to Beep once or Off, automatic answer is off.

Lights — to set the lights permanently On. Select Automatic to set the lights on

for 15 seconds after a key press

TTY/TDD > Use TTY > Yes — to use the TTY settings instead of headset or

loopset settings

■Configuration

You can configure your phone with settings that are required for certain services

to function correctly. The services are browser, multimedia messaging, and remote

Internet server synchronization. Get the settings from your SIM card, from a service

provider as a configuration message, or enter your personal settings manually.

You can store configuration settings from up to 20 service providers in the phone

and manage them within this menu.

To save the configuration settings received by a configuration message from a

service provider, see “Configuration settings service,” p. 12.

Select Menu > Settings > Configuration and from the following options:

Default configuration settings — to view the service providers saved in the phone.

Scroll to a service provider, and select Details to view the applications that the

configuration settings of this service provider support. To set the configuration

settings of the service provider as default settings, select Options > Set as default.

To delete configuration settings, select Delete.

Activate default in all applications — to activate the default configuration settings

for supported applications

Preferred access point — to view the saved access points. Scroll to an access point,

and select Options > Details to view the name of the service provider, data bearer,

and packet data access point or GSM dial-up number.

6101_6102.ENv1_9240568_UG.fm Page 43 Tuesday, June 7, 2005 2:59 PM

Settings

Connect to service provider support — to download the configuration settings

from your service provider

Personal configuration settings — to add new personal accounts for various

services manually, and to activate or delete them. To add a new personal account

if you have not added any, select Add new; otherwise, select Options > Add new.

Select the service type, and select and enter each of the required parameters. The

parameters differ according to the selected service type. To delete or activate a

personal account, scroll to it, and select Options > Delete or Activate.

■Security

When security features that restrict calls are in use (such as call restriction,

closed user group, and fixed dialing), calls still may be possible to the official

emergency number programmed into your device.

Select Menu > Settings > Security and from the following options:

PIN code request — to set the phone to ask for your PIN or UPIN code every time

the phone is switched on. Some SIM cards do not allow the code request to be

turned off.

Call restrictions (network service) — to restrict incoming calls to and outgoing

calls from your phone. A restriction password is required.

Fixed dialing — to restrict your outgoing calls to selected phone numbers if this

function is supported by your SIM card

Closed user group (network service) — to specify a group of people whom you can

call and who can call you

Security level > Phone — the phone asks for the security code whenever a new SIM

card is inserted into the phone. Select Memory and the phone asks for the security

code when SIM card memory is selected and you want to change the memory in use.

Access codes — to set the PIN code or UPIN code in use, or to change the security

code, PIN code, UPIN code, PIN2 code, and restriction password

Code in use — to select whether the PIN code or UPIN code should be active

Pin2 code request — to select whether PIN2 code is required when using a specific

phone feature which is covered by the PIN2 code

■Restore factory settings

To reset some of the menu settings to their original values, select Menu > Settings >

Restore settings. Enter the security code. The data you have entered or downloaded

are not deleted (for example, the names and phone numbers saved in Contacts).

6101_6102.ENv1_9240568_UG.fm Page 44 Tuesday, June 7, 2005 2:59 PM

Operator menu

10. Operator menu

This menu lets you access a portal to services provided by your network operator.

The name and the icon depend on the operator. For more information contact

your network operator. If this menu is not shown the following menu numbers

change accordingly.

The operator can update this menu with a service message. For more information,

see “Service inbox,” p. 60.

6101_6102.ENv1_9240568_UG.fm Page 45 Tuesday, June 7, 2005 2:59 PM

Gallery

11. Ga llery

In this menu you can manage graphics, images, recordings, video

clips, themes, and tones. These files are arranged in folders.

Your phone supports an activation key system to protect acquired content. Always

check the delivery terms of any content and activation key before acquiring them,

as they may be subject to a fee.

from being copied, modified, transferred, or forwarded.

The files stored in Gallery use a memory that may have a capacity of approximately

3MB.

1. Select Menu > Gallery.

2. Scroll to the desired folder. To view a list of files in the folder, select Open >

Options and one of the available options.

3. Scroll to the file you want to view, and select Open > Options and one of the

following functions:

Send — to send the selected file using MMS or IR

Delete all — to delete all the files and folders in the selected folder

Edit image — to insert text, a frame or clip-art into the selected picture,

or to crop the image

Open in sequence — to view the files in the folder one by one

Zoom — to increase the size of the image

Mute audio or Unmute audio — to mute or unmute the sound file

Set contrast — to adjust the contrast level of the image

Activate content — to update the activation key of the selected file. The option

is only shown if the activation key updating is supported by the file.

Activation key list — to view the list of all available activation keys. You can

delete the activation keys (for example, delete the expired ones).

6101_6102.ENv1_9240568_UG.fm Page 46 Tuesday, June 7, 2005 2:59 PM

Media

12. Media

and other content from being copied, modified, transferred, or forwarded.

■Camera

You can take photos or record video clips with the built-in camera. The camera

produces pictures in JPEG format and video clips in 3GP format.

When taking and using images or video clips, obey all laws and respect local

customs as well as privacy and legitimate rights of others.

Take a photo

Select Menu > Media > Camera > Capture, or press the camera release key.

The phone saves the photo in Gallery > Images. To take another photo, select

Back; to send the photo as a multimedia message, select Send. To view the

options, select Options.

To take a self-portrait, close the fold and use the mini display as a view finder.

Press the camera release key.

Record a video clip

Select Menu > Media > Camera. To select the video mode, scroll left or right, or

select Options > Video; select Record, or press the camera release key. To pause

the recording, select Pause; to resume the recording, select Continue. To stop the

recording, select Stop. The phone saves the recording in Gallery > Video clips.

To view the options, select Options.

■Radio

The FM radio depends on an antenna other than the wireless devices antenna.

A compatible headset or enhancement needs to be attached to the device for the

FM radio to function properly.

Warning: Listen to music at a moderate level. Continuous exposure to high

volume may damage your hearing. Do not hold the device near your ear

when the loudspeaker is in use, because the volume may be extremely loud.

Select Menu > Media > Radio. To use the graphical keys , , , or

on the display, scroll left or right to the desired key, and select it.

To change the volume, press the volume keys.

6101_6102.ENv1_9240568_UG.fm Page 47 Tuesday, June 7, 2005 2:59 PM

Media

Save radio channels

1. To start the channel search, select and hold or . To change the radio

frequency in 0.05 MHz steps, briefly press or .

2. To save the channel to a memory location, 1 to 9, press and hold the

corresponding number key. To save the channel in the memory location from

10 to 20, press briefly 1 or 2, and press and hold the desired number key, 0 to 9.

3. Enter the name of the channel, and select OK.

Listen to the radio

Select Menu > Media > Radio. To scroll to the desired channel, select or ,

or press the headset key. To select a radio channel location, briefly press the

corresponding number keys.

Select Options and from the following options:

Turn off — to turn off the radio

Save channel — to save a new channel, and enter the channels name

Channels — to select the list of saved channels. To delete or rename a channel,

scroll to the desired channel, and select Options > Delete channel or Rename.

Mono output or Stereo output — to listen to the radio in monophonic sound

or in stereo

Loudspeaker or Headset — to listen to the radio using the loudspeaker or headset.

Keep the headset connected to the phone. The lead of the headset functions as

the radio antenna.

Set frequency — to enter the frequency of the desired radio channel

You can normally make a call or answer an incoming call while listening to the

radio. During the call, the volume of the radio is muted.

When an application using a packet data or HSCSD connection is sending or

receiving data, it may interfere with the radio.

■Recorder

You can record pieces of speech, sound, or an active call for 5 minutes.

The recorder cannot be used when a data call or packet data connection is active.

6101_6102.ENv1_9240568_UG.fm Page 48 Tuesday, June 7, 2005 2:59 PM

Media

Record sound

1. Select Menu > Media > Recorder.

To use the graphical keys, , , or , on the display, scroll left or right

to the desired key, and select it.

2. To start the recording, select . To start the recording during a call, select

Options > Record. While recording a call, all parties to the call hear a faint

beeping sound about every 5 seconds. When recording a call, hold the phone

in the normal position near to your ear.

3. To end the recording, select . The recording is saved in Gallery > Recordings.

4. To listen to the latest recording, select Options > Play last recorded.

5. To send the last recording using a multimedia message or IR, select Options >

Send last recorded.

List of recordings

Select Menu > Media > Recorder > Options > Recordings list. The list of folders

in the Gallery is shown. Open Recordings to see the list with recordings. Select

Options to select options for files in the Gallery. See “Gallery,” p. 46.

6101_6102.ENv1_9240568_UG.fm Page 49 Tuesday, June 7, 2005 2:59 PM

Organizer

13. Organizer

■Alarm clock

You can set the phone to alarm at a desired time. Select Menu > Organizer >

Alarm clock.

To set the alarm, select Alarm time, and enter the alarm time. To change the alarm

time when the alarm time is set, select On. To set the phone to alert you on selected

days of the week, select Repeat alarm.

To select the alarm tone or set a radio channel as the alarm tone, select Alarm

tone. If you select the radio as an alarm tone, connect the headset to the phone.

The phone uses the last channel you listened to as the alarm, and the alarm plays

through the loudspeaker. If you remove the headset or switch off the phone, the

default alarm tone replaces the radio.

To set a snooze time-out, select Snooze time-out.

Stop the alarm

The phone sounds an alert tone, and flashes Alarm! and the current time on the

display, even if the phone was switched off. To stop the alarm, select Stop or open

the phone. If you let the phone continue to sound the alarm for a minute or select

Snooze, the alarm stops for the selected snooze time-out and then resumes.

If the alarm time is reached while the device is switched off, the device switches

itself on and starts sounding the alarm tone. If you select Stop, the device asks

whether you want to activate the device for calls. Select No to switch off the

device or Yes to make and receive calls. Do not select Yes when wireless phone

use may cause interference or danger.

■Calendar

Select Menu >Organizer > Calendar.

The current day is indicated by a frame. If there are any notes set for the day, the

day is in bold type. To view the day notes, select View. To view a week, select

Options > Week view. To delete all notes in the calendar, select the month or

week view, and select Options > Delete all notes.

Other options for the day view may be Make a note, Delete, Edit, Move, or Repeat

a note; Copy a note to another day; Send note as text message or multimedia

message, with IR, or to the calendar of another compatible phone. In Settings you

can set the date and time settings. In Auto-delete notes you can set the phone to

delete old notes automatically after a specified time.

6101_6102.ENv1_9240568_UG.fm Page 50 Tuesday, June 7, 2005 2:59 PM

Organizer

Make a calendar note

Select Menu > Organizer > Calendar. Scroll to the date you want, and select

Options > Make a note and one of the following note types:

Meeting, Call, Birthday, Memo, or Reminder.

A note alarm

The phone beeps and displays the note. With a call note on the display, to call

the displayed number, press the call key. To stop the alarm and to view the note,

select View. To stop the alarm for approximately 10 minutes, select Snooze. To

stop the alarm without viewing the note, select Exit.

■To-do list

To save notes for tasks that you must do, select Menu > Organizer > To-do list.

To create a note if no note is added, select Add note; otherwise, select Options >

Add. Write the note, and select Save. Select the priority, the deadline, and the

alarm type for the note.

To view a note, scroll to it, and select View.

You can also select an option to delete the selected note and delete all the notes

that you have marked as done. You can sort the notes by priority or by deadline,

send a note to another phone as a text message or a multimedia message, save a

note as a calendar note, or access the calendar.

While viewing a note, you can also select an option to edit the deadline or priority

for the note or mark the note as done.

■Notes

To use this application for writing and sending notes, select Menu > Organizer >

Notes. To create a note if no note is added, select Add note; otherwise, select

Options > Make a note. Write a note, and select Save.

Other options for notes include deleting and editing a note. While editing a note,

you can also exit the text editor without saving the changes. You can send the

note to compatible devices using a text message, a multimedia message, or IR. If

the note is too long to send as a text message, the phone asks you to delete the

appropriate number of characters from your note.

6101_6102.ENv1_9240568_UG.fm Page 51 Tuesday, June 7, 2005 2:59 PM

Organizer

■Synchronization

Synchronization allows you to save your calendar and Contacts data on a remote

Internet server (network service) or on a compatible PC. If you have saved data on

the remote Internet server, to synchronize your phone, start the synchronization

from your phone. To synchronize the data in the phone contacts, calendar, and

notes to correspond with the data of your compatible PC, start the synchronization

from the PC. The contact data in your SIM card is not synchronized.

Answering an incoming call during synchronization ends the synchronization,

and you must restart it.

Synchronize from your phone

Before synchronizing from your phone, you must do the following:

• Subscribe to a synchronization service. For details, contact your service provider.

• Retrieve the synchronization settings from your service provider.

See “Synchronization settings,” p. 52.

To start the synchronization from your phone, do the following:

1. Select the configuration settings you need for the synchronization. See

“Synchronization settings,” p. 52.

2. Select Menu > Organizer > Sync > Server sync > Data to be synchronized.

Mark the data to be synchronized.

3. Select Menu > Organizer > Sync > Server sync > Synchronize. The marked

data of the active set is synchronized after confirmation.

Synchronizing for the first time or after an interrupted synchronization may take

up to 30 minutes to complete, if the contacts or calendar are full.

Synchronization settings

You may receive the configuration settings required for synchronization as a

configuration message from the network operator or service provider. To manage

the configuration settings, see “Configuration,” p. 43.

1. Select Menu > Organizer > Sync > Server sync > Sync settings and from the

following options:

Configuration — Only the configurations that support the synchronization are

shown. Select a service provider, Default, or Personal config. for synchronization.

Account — Select a synchronization service account contained in the active

configuration settings.

2. Select PC sync settings to enter the settings for server alerted

synchronization. Set the User name and Password.

The user name and password must be the same in the phone and in the PC.

6101_6102.ENv1_9240568_UG.fm Page 52 Tuesday, June 7, 2005 2:59 PM

Organizer

Synchronize from a compatible PC

To synchronize Contacts, Calendar, and Notes from a compatible PC, use an IR, or

data cable connection. You also need Nokia PC Suite software of your phone

installed on the PC. Start the synchronization from the PC using Nokia PC Suite.

■Calculator

The calculator in your phone adds, subtracts, multiplies, divides, calculates the

square and the square root and converts currency values.

Note: This calculator has limited accuracy and is designed for

simple calculations.

Select Menu > Organizer > Calculator. When 0 is displayed on the screen, enter

the first number in the calculation. Press # for a decimal point. Select Options >

Add, Subtract, Multiply, Divide, Square, Square root, or Change sign. Enter the

second number. For a total, select Equals. Repeat this sequence as many times as

it is necessary. To start a new calculation, first select and hold Clear.

To perform a currency conversion, select Menu > Organizer > Calculator. To save

the exchange rate, select Options > Exchange rate. Select either of the displayed

options. Enter the exchange rate, press # for a decimal point, and select OK. The

exchange rate remains in the memory until you replace it with another one. To

perform the currency conversion, enter the amount to be converted, and select

Options > To home or To foreign.

Note: When you change base currency, you must enter the new rates

because all previously set exchange rates are set to zero.

■Stopwatch

To measure time, take intermediate times, or take lap times, use the stopwatch.

During timing, the other functions of the phone can be used. To set the stopwatch

timing in the background, press the end key.

Using the stopwatch or allowing it to run in the background when using other

features increases the demand on battery power and reduces the battery life.

Select Menu > Organizer > Stopwatch and from the following options:

Split timing — to take intermediate times. To start the time observation, select

Start. Select Split every time that you want to take an intermediate time. To stop

the time observation, select Stop. To save the measured time, select Save. To start

the time observation again, select Options > Start. The new time is added to the

previous time. To reset the time without saving it, select Reset. To set the stopwatch

timing in the background, press the end key.

6101_6102.ENv1_9240568_UG.fm Page 53 Tuesday, June 7, 2005 2:59 PM

Organizer

Lap timing — to take lap times. To set the stopwatch timing in the background,

press the end key.

Continue — to view the timing that you have set in the background

Show last time — to view the most recently measured time if the stopwatch

is not reset

View times or Delete times — to view or delete the saved times

■Countdown timer

Select Menu > Organizer > Timer. Enter the alarm time in hours, minutes, and

seconds, and select OK. If you wish, write your own note text that is displayed

when the time expires. To start the countdown timer, select Start. To change the

countdown time, select Change time. To stop the timer, select Stop timer.

If the alarm time is reached when the phone is in the standby mode, the phone

sounds a tone and flashes the note text if it is set or Countdown completed. To stop

the alarm, press any key. If no key is pressed, the alarm automatically stops within

30 seconds. To stop the alarm and to delete the note text, select Exit. To restart the

countdown timer, select Restart.

6101_6102.ENv1_9240568_UG.fm Page 54 Tuesday, June 7, 2005 2:59 PM

Applications

14. Applications

■Games

Your phone software includes some games.

Launch a game

Select Menu > Applications > Games. Scroll to the desired game, and select Open.

For options related to a game, see “Other application options,” p. 55.

Game downloads

Select Menu > Applications > Options > Downloads > Game downloads. The list

of available bookmarks is shown. Select More bookmarks to access the list of

bookmarks in the Web menu. See “Bookmarks,” p. 59.

Important: Only install and use applications and other software

from sources that offer adequate security and protection against

harmful software.

Game settings

To set sounds, lights, and shakes for the game, select Menu > Applications >

Options > App. settings.

■Collection

Your phone software may include some Java applications specially designed for

this Nokia phone.

Launch an application

Select Menu > Applications > Collection. Scroll to an application, and select

Open; or press the call key.

Other application options

Delete — to delete the application or application set from the phone

Details — to view additional information about the application

Update version — to check if a new version of the application is available for

download from Web (network service)

6101_6102.ENv1_9240568_UG.fm Page 55 Tuesday, June 7, 2005 2:59 PM

Applications

Web page — to provide further information or additional data for the application

from an Internet page. This feature must be supported by the network. It is only

shown if an Internet address has been provided with the application.

App. access — to restrict the application from accessing security relevant functions

like network access or access to user data. Different categories are shown. Select

in each category, if available, one of the following permission: Ask every time to

set the phone to always ask for network access, Ask first time only to set the phone

to ask for network access only on the first attempt, Always allowed to allow the

network access, or Not allowed to not allow the network access.

Download an application

Your phone supports J2ME Java applications. Make sure that the application is

compatible with your phone before downloading it.

Important: Only install and use applications and other software

from sources that offer adequate security and protection against

harmful software.

You can download new Java applications in different ways.

Select Menu > Applications > Options > Downloads > App. downloads. The list

of available bookmarks is shown. Select More bookmarks to access the list of

bookmarks in the Web menu. Select the appropriate bookmark to connect to the

desired page. For the availability of different services, pricing, and tariffs, contact

your service provider.

Select Menu > Web > Downloads. Download an appropriate application or game.

See “Download files,” p. 60.

Use the game download function. See “Game downloads,” p. 55.

Use the Nokia Application Installer in PC Suite to download the applications to

your phone.

Your device may have some bookmarks loaded for sites not affiliated with Nokia.

Nokia does not warrant or endorse these sites. If you choose to access them, you

should take the same precautions, for security or content, as you would with any

Internet site.

6101_6102.ENv1_9240568_UG.fm Page 56 Tuesday, June 7, 2005 2:59 PM

Web

15. Web

You can access various mobile Internet services with your phone browser.

Important: Use only services that you trust and that offer adequate

security and protection against harmful software.

Check the availability of these services, pricing, tariffs, and instructions with your

service provider.

With the phone browser you can view the services that use wireless markup

language (WML) or extensible hypertext markup language (XHTML) on their pages.

Appearance may vary due to screen size. You may not be able to view all details

of the Internet pages.

■Set up browsing

You may receive the configuration settings required for browsing as a configuration

message from the network operator or service provider that offers the service that

you want to use. See “Configuration settings service,” p. 12. You can also enter

all the configuration settings manually. See “Configuration,” p. 43.

■Connect to a service

Verify that the correct configuration settings of the service that you want to use

are activated.

1. To select the settings for connecting to the service, select Menu > Web >

Settings > Configuration settings.

2. Select Configuration. Only the configurations that support browsing service

are shown. Select a service provider, Default, or Personal config. for browsing.

See “Set up browsing,” p. 57.

Select Account and a browsing service account contained in the active

configuration settings.

Select Display terminal window > Yes to perform manual user authentication

for intranet connections.

Make a connection to the service in one of the following ways:

• Select Menu > Web > Home; or in the standby mode, press and hold 0.

• To select a bookmark of the service, select Menu > Web > Bookmarks.

• To select the last URL, select Menu > Web > Last web address.

• To enter the address of the service, select Menu > Web > Go to address, enter

the address of the service, and select OK.

6101_6102.ENv1_9240568_UG.fm Page 57 Tuesday, June 7, 2005 2:59 PM

Web

■Browse pages

After you make a connection to the service, you can start browsing its pages.

The function of the phone keys may vary in different services. Follow the text

guides on the phone display. For more information, contact your service provider.

If packet data is selected as the data bearer, is shown on the top left of the

display during browsing. If you receive a call or a text message, or make a call

during a packet data connection, is shown on the top right of the display to

indicate that the packet data connection is suspended (on hold). After a call the

phone tries to reconnect the packet data connection.

Browse with phone keys

Use the navigation keys to browse through the page.

To select a highlighted item, press the call key, or select Select.

To enter letters and numbers, press the keys, 0 to 9. To enter special characters,

press *.

Options while browsing

Nokia.com, Home, Shortcuts, Add bookmark, Bookmarks, Page options, History,

Downloads, Other options, Reload, and Quit may be available. The service provider

may also offer other options.

A cache is a memory location that is used to store data temporarily. If you have

tried to access or have accessed confidential information requiring passwords,

empty the cache after each use. The information or services you have accessed is

stored in the cache.

To empty the cache, see “Cache memory,” p. 61.

Direct calling

The browser supports functions that you can access while browsing. You can make

a phone call, send touch tones while a voice call is in progress, and save a name

and a phone number from a page.

■Appearance settings

While browsing, select Options > Other options > Appear. settings; or in the

standby mode, select Menu > Web > Settings > Appearance settings and from

the following options:

Text wrapping > On — to set the text to continue on the next line on the display.

If you select Off, the text is abbreviated.

6101_6102.ENv1_9240568_UG.fm Page 58 Tuesday, June 7, 2005 2:59 PM

Web

Font size > Extra small, Small, or Medium — to set the font size

Show images > No — to hide pictures on the page. This can speed up the browsing

of pages that contain a lot of pictures.

Alerts > Alert for unsecure connection > Yes — to set the phone to alert when an

encrypted connection changes to unencrypted during browsing.

Alerts > Alert for unsecure items > Yes — to set the phone to alert when an encrypted

page contains an unsecure item. These alerts do not guarantee a secure connection.

For more information, see “Browser security,” p. 61.

Character encoding > Content encoding — to select the encoding for the browser

page content

Character encoding > Unicode (UTF-8) web addresses > On — to set the phone to

send a URL as a UTF-8 encoding. You may need this setting when you access a

Web page created in foreign language.

■Cookies

A cookie is data that a site saves in the cache memory of your phone. Cookies are

saved until you clear the cache memory. See “Cache memory,” p. 61.

While browsing, select Options > Other options > Security > Cookie settings; or

in the standby mode, select Menu > Web > Settings > Security settings > Cookies.

To allow or prevent the phone from receiving cookies, select Allow or Reject.

■Scripts over secure connection

You can select whether to allow the running of scripts from a secure page. The

phone supports WML scripts.

1. While browsing, select Options > Other options > Security settings > Script

settings; or in the standby mode, select Menu > Web > Settings > Security

settings > Scripts over secure connection.

2. To allow the scripts, select Allow.

■Bookmarks

You can save page addresses as bookmarks in the phone memory.

1. While browsing, select Options > Bookmarks; or in the standby mode, select

Menu > Web > Bookmarks.

2. Scroll to a bookmark, and select it; or press the call key to make a connection

to the page associated with the bookmark.

3. Select Options to view, edit, delete, or send the bookmark; create a new

bookmark; or save the bookmark to a folder.

6101_6102.ENv1_9240568_UG.fm Page 59 Tuesday, June 7, 2005 2:59 PM

Web

Your device may have some bookmarks loaded for sites not affiliated with Nokia.

Nokia does not warrant or endorse these sites. If you choose to access them, you

should take the same precautions, for security or content, as you would with any

Internet site.

Receive a bookmark

When you have received a bookmark that is sent as a bookmark, 1 bookmark received

is displayed. To save the bookmark, select Show > Save. To view or delete the

bookmark, select Options > View or Delete. To discard the bookmark directly

after you have received the bookmark, select Exit > OK.

■Download files

To download more tones, images, games, or applications to your phone (network

service), select Menu > Web > Downloads > Tone downloads, Graphic downloads,

Game downloads, Video downloads, Theme downloads, or App. downloads.

Important: Only install and use applications and other software

from sources that offer adequate security and protection against

harmful software.

To save all downloaded files automatically in Gallery, select Menu > Web >

Settings > Downloading settings > Automatic saving > On.

■Service inbox

The phone is able to receive service messages (pushed messages) sent by your service

provider (network service). Service messages are notifications of, for example,

news headlines, and they may contain a text message or an address of a service.

To access the Service inbox in the standby mode, when you have received a service

message, select Show. If you select Exit, the message is moved to the Service inbox.

To access the Service inbox later, select Menu > Web > Service inbox.

To access the Service inbox while browsing, select Options > Other options >

Service inbox. Scroll to the message you want, and to activate the browser and

download the marked content, select Retrieve. To display detailed information on

the service notification or to delete the message, select Options > Details or Delete.

Service inbox settings

Select Menu > Web > Settings > Service inbox settings.

To set whether you want to receive service message, select Service messages >

On or Off.

6101_6102.ENv1_9240568_UG.fm Page 60 Tuesday, June 7, 2005 2:59 PM

Web

To set the phone to receive service messages only from content authors approved

by the service provider, select Message filter > On. To view the list of the approved

content authors, select Trusted channels.

To set the phone to automatically activate the browser from the standby mode when

the phone has received a service message, select Automatic connection > On. If you

select Off, the phone activates the browser only after you select Retrieve when

the phone has received a service message.

■Cache memory

A cache is a memory location that is used to store data temporarily. If you have

tried to access or have accessed confidential information requiring passwords,

empty the cache after each use. The information or services you have accessed is

stored in the cache.

To empty the cache, while browsing, select Options > Other options > Clear the

cache; in the standby mode, select Menu > Web > Clear the cache.

■Positioning information

The network may send you a location request. You can ensure that the network

delivers location information of your phone only if you approve it (network service).

Contact your network operator or service provider to subscribe and to agree upon

the delivery of location information.

To accept or reject the location request, select Accept or Reject. If you miss the

request, the phone automatically accepts or rejects it according to what you have

agreed with your network operator or service provider. The phone displays 1 missed

position request. To view the missed location request, select Show.

To view the information on the 10 most recent privacy notifications and requests

or to delete them, select Menu > Web > Positioning > Position log > Open folder

or Delete all.

■Browser security

Security features may be required for some services, such as online banking or

shopping. For such connections you need security certificates and possibly a

security module, which may be available on your SIM card. For more information,

contact your service provider.

Security module

The security module improves security services for applications requiring a browser

connection, and allows you to use a digital signature. The security module may

contain certificates as well as private and public keys. The certificates are saved

in the security module by the service provider.

6101_6102.ENv1_9240568_UG.fm Page 61 Tuesday, June 7, 2005 2:59 PM

Web

Select Menu > Web > Settings > Security settings > Security module settings

and from the following options:

Security module details — to show the security module title, status, manufacturer,

and serial number

Module PIN request — to set the phone to ask for the module PIN when using services

provided by the security module. Enter the code, and select On. To disable the

module PIN request, select Off.

Change module PIN — to change the module PIN, if allowed by the security module.

Enter the current module PIN code, then the new code twice.

Change signing PIN — to change the signing PIN code for the digital signature.

Select the signing PIN you want to change. Enter the current PIN code, then the

new code twice.

See also “Access codes,” p. 11.

Certificates

Important: Note that even if the use of certificates makes the risks

involved in remote connections and software installation considerably

smaller, they must be used correctly in order to benefit from increased

security. The existence of a certificate does not offer any protection by

itself; the certificate manager must contain correct, authentic, or trusted

certificates for increased security to be available. Certificates have a

restricted lifetime. If Expired certificate or Certificate not valid yet is

shown even if the certificate should be valid, check that the current date

and time in your device are correct.

Before changing any certificate settings, you must make sure that you

really trust the owner of the certificate and that the certificate really

belongs to the listed owner.

There are three kinds of certificates: server certificates, authority certificates, and

user certificates. You may receive these certificates from your service provider.

Authority certificates and user certificates may also be saved in the security

module by the service provider.

To view the list of the authority or user certificates downloaded into your phone,

select Menu > Web > Settings > Security settings > Authority certificates or

User certificates.

The security indicator is displayed during a connection, if the data transmission

between the phone and the content server is encrypted.

6101_6102.ENv1_9240568_UG.fm Page 62 Tuesday, June 7, 2005 2:59 PM

Web

The security icon does not indicate that the data transmission between the gateway

and the content server (or place where the requested resource is stored) is secure.

The service provider secures the data transmission between the gateway and the

content server.

Digital signature

You can make digital signatures with your phone if your SIM card has a security

module. Using the digital signature can be the same as signing your name to a

paper bill, contract, or other document.

To make a digital signature, select a link on a page (for example, the title of the

book you want to buy and its price). The text to sign, which may include the

amount and date, is shown.

Check that the header text is Read and that the digital signature icon is shown.

If the digital signature icon does not appear, there is a security breach, and you

should not enter any personal data such as your signing PIN.

To sign the text, read all of the text first, and select Sign.

The text may not fit within a single screen. Therefore, make sure to scroll through

and read all of the text before signing.

Select the user certificate you want to use. Enter the signing PIN (see “Access

codes,” p. 11), and select OK. The digital signature icon disappears, and the

service may display a confirmation of your purchase.

6101_6102.ENv1_9240568_UG.fm Page 63 Tuesday, June 7, 2005 2:59 PM

SIM services

16. SIM services

Your SIM card may provide additional services that you can access. This menu is

shown only if it is supported by your SIM card. The name and contents of the

menu depend on the SIM card.

For availability and information on using SIM card services, contact your SIM

card vendor. This may be the service provider, network operator, or other vendor.

To set the phone to show you the confirmation messages sent between your phone

and the network when you are using the SIM services, select Menu > Settings >

Phone > Confirm SIM service actions > Yes.

Accessing these services may involve sending messages or making a phone call

for which you may be charged.

6101_6102.ENv1_9240568_UG.fm Page 64 Tuesday, June 7, 2005 2:59 PM

PC connectivity

17. PC connectivity

You can send and receive e-mail, and access the Internet when your phone is

connected to a compatible PC through an IR or data cable (CA-42) connection.

You can use your phone with a variety of PC connectivity and data

communications applications.

■PC Suite

With PC Suite you can synchronize Contacts, calendar and to-do notes, and notes

between your phone, and the compatible PC, or a remote Internet server (network

service). You may find more information about PC suite (for example,

downloadable files in the support area) on the Nokia Web site at

www.nokia.com/support.

■Packet data, HSCSD, and CSD

With your phone you can use the packet data, high-speed circuit switched data

(HSCSD), and circuit switched data (CSD, GSM data).

For availability and subscription to data services, contact your network operator

or service provider.

The use of HSCSD services consumes the phone battery faster than normal voice

or data calls. You may need to connect the phone to a charger for the duration of

data transfer.

See “Packet data (EGPRS),” p. 42.

■Data communication applications

For information on using a data communication application, refer to the

documentation provided with it. Making or answering phone calls during a computer

connection is not recommended, as it might disrupt the operation. For better

performance during data calls, place the phone on a stationary surface with the

keypad facing down. Do not move the phone by holding it in your hand during a

data call.

6101_6102.ENv1_9240568_UG.fm Page 65 Tuesday, June 7, 2005 2:59 PM

Enhancements

18. Enhancements

If you want to enhance device functionality, a range

of enhancements is available for you. You can select

any of these items to help accommodate your

specific communication needs. For availability of

these and other enhancements, contact your dealer.

Wrist straps for your Nokia 6101 or Nokia 6102

mobile device are available for purchase at your

Nokia dealer or www.nokiausa.com.

Check the model number of any charger before use with this device. This device is

intended for use when supplied with power from an AC-3, AC-4, and DC-4 charger,

and from AC-1, ACP-7, ACP-12, and LCH-12 charger when used with the charger

adapter CA-44, which is available at your Nokia dealer or www.nokiausa.com.

Warning: Use only batteries, chargers and enhancements approved by

Nokia for use with this particular model. The use of any other types may

invalidate any approval or warranty, and may be dangerous. For availability

of approved enhancements, please check with your dealer.

Your device and its enhancements may contain small parts. Keep them out of

reach of small children.

A few practical rules about accessories and enhancements:

• Keep all accessories and enhancements out of the reach of small children.

• When you disconnect the power cord of any accessory or enhancement, grasp

and pull the plug, not the cord.

• Check regularly that enhancements installed in a vehicle are mounted and

are operating properly.

• Installation of any complex car enhancements must be made by qualified

personnel only.

6101_6102.ENv1_9240568_UG.fm Page 66 Tuesday, June 7, 2005 2:59 PM

Enhancements

■Power

• Battery, 760 mAh, Li-Ion (BL-4C)

• Compact charger (AC-3)

• Travel charger (AC-4)

• Charger adapter (CA-44)

■Data

• Connectivity Adapter Cable (CA-42)

■Audio

• Stereo headset (HS-23)

• Display headset (HS-6)

■Car

• Mobile holder (CR-34)

•Car kit (CK-10)

■Covers and carrying

• Carrying case

6101_6102.ENv1_9240568_UG.fm Page 67 Tuesday, June 7, 2005 2:59 PM

Reference information

19. Reference information

■Battery information

Charging and discharging

Your device is powered by a rechargeable battery. The full performance of a new

battery is achieved only after two or three complete charge and discharge cycles.

The battery can be charged and discharged hundreds of times but it will eventually

wear out. When the talk and standby times are noticeably shorter than normal,

replace the battery. Use only Nokia approved batteries, and recharge your battery

only with Nokia approved chargers designated for this device.

Unplug the charger from the electrical plug and the device when not in use. Do not

leave a fully charged battery connected to a charger, since overcharging may shorten

its lifetime. If left unused, a fully charged battery will lose its charge over time.

Use the battery only for its intended purpose. Never use any charger or battery

that is damaged.

Do not short-circuit the battery. Accidental short-circuiting can occur when a

metallic object such as a coin, clip, or pen causes direct connection of the

positive (+) and negative (-) terminals of the battery. (These look like metal strips

on the battery.) This might happen, for example, when you carry a spare battery

in your pocket or purse. Short-circuiting the terminals may damage the battery

or the connecting object.

Leaving the battery in hot or cold places, such as in a closed car in summer or winter

conditions, will reduce the capacity and lifetime of the battery and its ability to

charge. Always try to keep the battery between 59°F and 77°F (15°C and 25°C). A

device with a hot or cold battery may not work temporarily, even when the battery

is fully charged. Battery performance is particularly limited in temperatures well

below freezing.

Do not dispose of batteries in a fire, as they may explode. Batteries may also explode

if damaged. Dispose of batteries according to local regulations. Please recycle

when possible. Do not dispose as household waste.

Nokia battery authentication guidelines

Always use original Nokia batteries for your safety. To check that you are getting an

original Nokia battery, purchase it from an authorized Nokia dealer, look for the

Nokia Original Enhancements logo on the packaging, and inspect the hologram

label using the following steps.

6101_6102.ENv1_9240568_UG.fm Page 68 Tuesday, June 7, 2005 2:59 PM

Reference information

Successful completion of the four steps is not a total assurance of the authenticity

of the battery. If you have any reason to believe that your battery is not an authentic

original Nokia battery, you should refrain from using it and take it to the nearest

authorized Nokia service point or dealer for assistance. Your authorized Nokia

service point or dealer will inspect the battery for authenticity. If authenticity

cannot be verified, return the battery to the place of purchase.

How do you check the security features on batteries with hologram labels?

1. When looking at the hologram label, you should

see the Nokia connecting hands symbol from one

angle and the Nokia Original Enhancements logo

when looking from another angle.

2. When you angle the hologram to the left, right,

down, and up sides of the logo, you should see

1, 2, 3, and 4 dots on each side, respectively.

3. Scratch the side of the label to reveal a 20-digit

code, for example, 12345678919876543210.

Turn the battery so that the numbers are facing

upwards. The 20-digit code reads starting from the

number at the top row followed by the bottom row.

4. Confirm that the 20-digit code is valid by following

the instructions at www.nokia.com/batterycheck.

What if your battery is not verified as authentic?

If you cannot confirm that your Nokia battery with the hologram label is an

authentic Nokia battery, please do not use the battery. Take it to the nearest

authorized Nokia service point or dealer for assistance. The use of a battery that

is not approved by the manufacturer may be dangerous and may result in poor

performance and damage to your device and its enhancements. It may also

invalidate any approval or warranty applying to the device.

To find out more about original Nokia batteries visit www.nokia.com/battery.

6101_6102.ENv1_9240568_UG.fm Page 69 Tuesday, June 7, 2005 2:59 PM

Reference information

■Additional safety information

Operating environment

Remember to follow any special regulations in force in any area and always switch

off your device when its use is prohibited or when it may cause interference or

danger. Use the device only in its normal operating positions. This device meets RF

exposure guidelines when used either in the normal use position against the ear or

when positioned at least 7/8 inch (2.2 cm) away from the body. When a carry case,

belt clip, or holder is used for body-worn operation, it should not contain metal

and should position the device at least 7/8 inch (2.2 cm) away from your body.

In order to transmit data files or messages, this device requires a quality connection

to the network. In some cases, transmission of data files or messages may be delayed

until such a connection is available. Ensure the above separation distance instructions

are followed until the transmission is completed.

Parts of the device are magnetic. Metallic materials may be attracted to the device.

Your device and its enhancements may contain small parts. Keep them out of

reach of small children.

Medical devices

Operation of any radio transmitting equipment, including wireless devices, may

interfere with the functionality of inadequately protected medical devices. Consult

a physician or the manufacturer of the medical device to determine if they are

adequately shielded from external RF energy or if you have any questions. Switch

off your device in health care facilities when any regulations posted in these areas

instruct you to do so. Hospitals or health care facilities may be using equipment

that could be sensitive to external RF energy.

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 6 inches

(15.3 cm) be maintained between a wireless device and a pacemaker to avoid

potential interference with the pacemaker. These recommendations are consistent

with the independent research by and recommendations of Wireless Technology

Research. To minimize the potential for interference, persons with pacemakers should

• Always keep the device more than 6 inches (15.3 cm) from their pacemaker

when the device is switched on

• Not carry the device in a breast pocket

• Hold the device to the ear opposite the pacemaker

If you have any reason to suspect that interference is taking place, switch off

your device immediately.

6101_6102.ENv1_9240568_UG.fm Page 70 Tuesday, June 7, 2005 2:59 PM

Reference information

Hearing aids

Some digital wireless devices may interfere with some hearing aids. If interference

occurs, consult your hearing aid provider.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic

systems in motor vehicles such as electronic fuel injection systems, electronic

antiskid (antilock) braking systems, electronic speed control systems, air bag

systems. For more information, check with the manufacturer or its representative

of your vehicle or any equipment that has been added.

Only qualified personnel should service the device, or install the device in a vehicle.

Faulty installation or service may be dangerous and may invalidate any warranty

that may apply to the device. Check regularly that all wireless device equipment

in your vehicle is mounted and operating properly. Do not store or carry flammable

liquids, gases, or explosive materials in the same compartment as the device, its

parts, or enhancements. For vehicles equipped with an air bag, remember that an

air bags inflate with great force. Do not place objects, including installed or portable

wireless equipment in the area over the air bag or in the air bag deployment area.

If in-vehicle wireless equipment is improperly installed and the air bag inflates,

serious injury could result.

Airplanes

Using your device while flying may be prohibited. Switch off your device before

boarding an aircraft. The use of wireless teledevices in an aircraft may be dangerous

to the operation of the aircraft, may disrupt the wireless teledevice network, and

may be illegal.

Failure to observe these instructions may lead to suspension or denial of teledevice

services to the offender, legal action, or both.

Potentially explosive environments

Switch off your device when in any area with a potentially explosive atmosphere

and obey all signs and instructions. Potentially explosive atmospheres include areas

where you would normally be advised to turn off your vehicle engine. Sparks in

such areas could cause an explosion or fire resulting in bodily injury or even death.

Switch off the device at refuelling points such as near gas pumps at service stations.

Observe restrictions on the use of radio equipment in fuel depots, storage, and

distribution areas, chemical plants or where blasting operations are in progress.

Areas with a potentially explosive atmosphere are often but not always clearly

marked. They include below deck on boats, chemical transfer or storage facilities,

vehicles using liquefied petroleum gas (such as propane or butane), and areas

where the air contains chemicals or particles such as grain, dust or metal powders.

6101_6102.ENv1_9240568_UG.fm Page 71 Tuesday, June 7, 2005 2:59 PM

Reference information

■Emergency calls

Important: Wireless devices, including this device, operate using radio

signals, wireless networks, landline networks, and user-programmed

functions. Because of this, connections in all conditions cannot be

guaranteed. You should never rely solely on any wireless device for

essential communications like medical emergencies.

To make an emergency call, do the following:

1. If the device is not on, switch it on. Check for adequate signal strength. For

SIM card devices, add Some networks may require that a valid SIM card is

properly inserted in the device.

2. Press the end key as many times as needed to clear the display and ready the

device for calls.

3. Enter the official emergency number for your present location. Emergency

numbers vary by location.

4. Press the call key.

If certain features are in use, you may first need to turn those features off before

you can make an emergency call. Consult this guide or your service provider.

When making an emergency call, give all the necessary information as accurately

as possible. Your wireless device may be the only means of communication at the

scene of an accident. Do not end the call until given permission to do so.

6101_6102.ENv1_9240568_UG.fm Page 72 Tuesday, June 7, 2005 2:59 PM

Reference information

■Certification information (SAR)

THE NOKIA 6101 and 6102 DEVICES MEET GUIDELINES FOR EXPOSURE TO RADIO WAVES.

Your mobile device is a radio transmitter and receiver. It is designed and

manufactured not to exceed the limits for exposure to radio frequency (RF) energy

recommended by international guidelines (ICNIRP). These limits establish permitted

levels of RF energy for the general population. The guidelines are based on standards

that were developed by independent scientific organizations through periodic

and thorough evaluation of scientific studies. The standards and guidelines

include a substantial safety margin designed to assure the safety of the public,

regardless of age and health and to account for any variations in measurements.

The exposure guidelines for mobile devices employ a unit of measurement known

as the Specific Absorption Rate or SAR. The SAR limit stated in the international

guidelines is 2.0 watts/kilogram (W/kg) averaged over ten grams of tissue. Tests for

SAR are conducted using standard operating positions with the device transmitting

at its highest certified power level in all tested frequency bands. The actual SAR

level of an operating device can be well below the maximum value because the

device is designed to use only the power required to reach the network. That amount

changes depending on a number of factors such as how close you are to a network

base station. The highest SAR value when tested according to international testing

procedures for use at the ear for device type RM-76 is 0.82 W/kg and for device

type RM-77 is 0.68 W/kg. Your device’s type is listed on the label located under

the battery.

SAR values may vary depending on national reporting and testing requirements

and the network band. Use of device accessories and enhancements may result in

different SAR values. Additional SAR information may be provided under product

information at www.nokia.com.

USA and Canada: The SAR limit of USA (FCC) and Canada (IC) is 1.6 W/kg averaged

over one gram of tissue. Device types RM-76 and RM-77 have also been tested

against this SAR limit. The highest SAR values reported under this standard during

product certification for use at the ear and when properly worn on the body are:

Information about these devices can be found on the FCC’s website at http://

www.fcc.gov/oet/fccid by searching the equipment authorization system using

FCC ID: PPIRM-76, PPIRM-77, or PPIRM-77X.

Your device’s IC and FCC ID are listed on the label located under the battery.

Device type IC FCC ID SAR at the ear SAR on the body

RM-76 661U-RM76 PPIRM-76 0.79 W/kg 0.59 W/kg

RM-77 661U-RM77 PPIRM-77 0.95 W/kg 0.59 W/kg

PPIRM-77X 0.97 W/kg 0.91 W/kg

6101_6102.ENv1_9240568_UG.fm Page 73 Tuesday, June 7, 2005 2:59 PM

Reference information

■Technical information

Feature Specification

Weight 3.4 oz (97 g) with BL-4C Li-Ion mAh battery

Size Volume: 4.7 in3 (77cm3)

Length: 3.3 in (85 mm)

Width: 1.8 in (45 mm)

Thickness: 0.9 in (24 mm)

Frequency range GSM 850

824–894 MHz (TX)

869–894 MHz (RX)

GSM 900

880–915 MHz (TX)

925–960 MHz (RX)

GSM 1800

1710–1785 MHz (TX)

1805–1865 MHz (RX)

GSM 1900

1850–1910 MHz (TX)

1930–1990 MHz (RX)

Transmitter output power Up to 2 W

Battery voltage 3.7 V dc

Number of channels 299

Memory size Up to 16 MB flash memory

Up to 4.6 MB shared memory

Operating temperature 59°F to + 77°F

(15°C to + 25°C)

6101_6102.ENv1_9240568_UG.fm Page 74 Tuesday, June 7, 2005 2:59 PM

Reference information

■Patent information

Manufactured or sold under one or more following US Patents:

4868846 5568545 5806003 5966374 6118775 6240079 6366659 6466033 6582147 6675012 6834181

4945633 5570369 5809018 5896369 6119002 6243455 6369635 6466585 6584089 6678361

4969192 5574985 5809115 5898775 6119003 6243582 6370362 6469673 6584161 6678368

5012208 5577024 5812835 5898925 6119180 6249584 6370367 6470313 6584164 6678527

5016851 5581244 5819165 5901353 6121846 6253089 6370389 6222924 6584314 6678531

5045973 5590160 5821735 5905235 6122498 6259312 6370390 6473016 6587680 6680913

5059131 5590415 5826191 5907480 6125267 6259323 6370391 6473594 6587695 6680955

5127844 5594948 5827082 5907796 6128322 6259676 6370591 6473611 6587817 6681099

5128965 5596571 5832381 5907796 6128509 6262735 6374083 6473622 6591116 6681253

5168982 5597102 5832524 5987406 6130650 6265928 6374118 6477151 6593914 6683860

5173927 5598125 5835858 5987639 6134439 6266321 6377803 6480485 6594472 6687499

5200997 5603103 5835862 6026161 6137789 6266330 6377817 6480715 6594486 6690307

5218270 5606548 5835889 6028567 6141410 6266516 6381453 6483051 6597319 6691085

5229701 5613235 5838672 6029128 6144243 6269126 6381468 6487288 6597914 6693892

5230091 5621367 5839059 6031827 6144660 6269331 6385054 6487397 6597917 6694135

5241583 5625274 5841774 6035189 6144676 6271794 6385446 6487424 6600663 6694141

5267234 5633913 5842141 6035194 6144709 6274825 6385451 6493564 6603773 6697347

5270666 5634197 5845219 6035201 6145095 6275708 6392503 6497364 6606508 6697604

5271056 5638034 5850607 6038238 6148103 6278688 6392605 6498785 6606593 6697624

5289059 5640395 5857151 6038695 6148209 6282436 6393008 6501957 6611507 6707428

5292259 5652748 5859843 6041120 6151485 6285884 6393121 6501967 6611693 6708028

5293139 5664004 5862178 6041234 6151507 6285888 6393260 6504595 6614860 6711211

5307371 5664053 5862489 6041235 6154455 6285889 6393518 6507590 6614905 6711689

5311179 5669069 5870683 6043760 6154457 6286122 6396878 6510148 6615044 6714091

5313661 5678192 5884103 6044264 6163546 6292669 6397074 6512756 6615169 6714784

5317283 5678224 5884176 6047181 6163708 6295286 6397081 6516193 6621910 6717925

5319525 5692032 5884190 6047196 6164547 6298035 6400958 6519241 6622011 6717928

5331638 5692105 5887266 6047196 6167038 6300887 6407532 6522670 6625452 6718179

5350956 5697074 5889770 6049796 6167248 6301338 6408063 6522877 6625458 6721304

5351235 5699482 5890005 6050415 6167256 6304652 6415163 6526290 6628731 6721374

5357222 5701392 5892475 6052385 6167273 6307512 6415410 6529561 6629130 6721700

5361459 5706110 5893060 6055439 6170073 6308066 6417817 6529717 6633536 6721867

5365119 5706285 5895884 6058317 6171127 6308084 6418326 6532226 6633618 6721871

5378935 5712845 5912885 6060193 6172673 6314683 6427078 6532227 6633768 6724892

5396653 5715522 5914690 6072787 6173301 6317083 6424829 6532257 6636491 6724944

5400949 5722074 5915440 6073001 6173302 6317588 6429746 6535979 6639905 6728241

5408504 5726593 5917907 6075789 6175623 6320330 6430163 6538449 6639950 6728548

5410733 5726981 5918049 6076181 6178535 6321083 6430189 6538613 6643513 6728555

5416435 5729534 5920619 6078570 6184592 6321257 6430721 6539236 6646841 6735249

5420552 5729541 5920812 6081534 6185302 6324074 6434133 6542170 6646998 6738370

5428602 5732831 5920826 6081732 6188909 6324281 6437711 6542606 6647006 6741860

5430740 5734683 5924026 6084868 6192055 6324389 6438229 6542931 6647248 6744742

5432473 5737323 5924038 6084920 6192238 6327153 6438370 6546251 6647249 6748076

5437056 5737410 5926138 6085605 6195338 6327256 6439905 6549773 6650905 6748219

5444816 5740129 5926147 6088342 6198928 6333716 6441591 6550927 6654589 6751227

5446364 5748720 5930233 6088746 6199035 6341220 6441689 6553065 6658064 6751472

5450487 5752165 5936979 6091440 6201818 6341221 6442386 6553107 6658256 6760317

5471655 5752172 5940790 6091955 6201876 6343131 6445924 6556550 6661404 6763011

5473284 5754595 5941978 6094426 6201974 6347138 6445928 6556824 6661780 6763019

5479476 5754976 5944844 6094587 6202109 6347218 6445932 6560458 6662155 6763035

5479481 5758278 5945952 6094661 6202163 6347945 6449264 6560460 6662986 6766159

5485635 5760568 5946326 6097961 6204727 6350133 6449473 6563801 6664844 6771619

5487084 5761245 5946634 6097964 6204830 6351470 6449480 6567389 6665289 6771631

5490235 5779115 5946651 6098194 6205172 6351647 6452914 6570596 6665309 6771964

5491718 5786703 5953665 6105784 6208961 6351842 6453179 6570860 6665692 6775228

5493255 5787341 5956323 6107743 6209050 6356468 6455188 6570909 6667963 6775259

5493701 5787357 5956332 6107986 6209173 6356759 6456237 6571095 6668162 6813503

5524288 5793744 5956625 6108323 6222730 6356766 6456826 6574336 6671286 6813638

5534878 5796757 5956633 6109972 6222924 6359865 6461193 6574473 6671287 6816719

5537557 5797102 5960354 6111944 6223037 6359904 6463262 6577204 6671495 6816729

5564074 5802465 5960389 6112078 6223059 6363252 6463278 6577619 6671511 6816832

5565821 5805084 5963634 6112099 6229996 6363259 6463502 6580920 6674733 6819923

5566201 5805301 5963901 6115617 6240076 6365854 6465896 6580932 6674860 6822585

6101_6102.ENv1_9240568_UG.fm Page 75 Tuesday, June 7, 2005 2:59 PM

Care and maintenance

Your device is a product of superior design and craftsmanship and should be treated

with care. The suggestions below will help you protect your warranty coverage

and enjoy your device for many years.

• Keep the device dry. Precipitation, humidity, and all types of liquids or moisture

can contain minerals that will corrode electronic circuits.

• Do not use or store the device in dusty, dirty areas. Its moving parts and

electronic components can be damaged.

• Do not store the device in hot areas. High temperatures can shorten the life of

electronic devices, damage batteries, and warp or melt certain plastics.

• Do not store the device in cold areas. When the device returns to its normal

temperature, moisture can form inside the device and damage electronic

circuit boards.

• Do not attempt to open the device other than as instructed in this guide.

• Do not drop, knock, or shake the device. Rough handling can break internal

circuit boards and fine mechanics.

• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean

the device.

• Do not paint the device. Paint can clog the moving parts and prevent

proper operation.

• Use a soft, clean, dry cloth to clean any lenses (such as camera, proximity

sensor, and light sensor lenses).

• Use chargers indoors.

• Always create a backup of data you want to keep (such as contacts and

calendar notes) before sending your device to a service facility.

All of the above suggestions apply equally to your device, battery, charger, or any

enhancement. If any device is not working properly, take it to the nearest authorized

service facility for service.

6101_6102.ENv1_9240568_UG.fm Page 76 Tuesday, June 7, 2005 2:59 PM

Index

NUMERICS

1-touch dialing 20, 36

access code

PIN 11, 44

PUK 11

restriction 11, 44

security 11, 44

alarm 50

alerts 59

applications 55, 56

battery

authenticate 68

charge 14, 68

information 68

install 13

browsing 57

bookmarks 59

certificates 62

download files 60

options 58

scripts 59

security 61

business cards 34

cache memory 61

calculator 53

calendar 50

call

1-touch dialing 40

answer 20, 40

dial 20

forward 40

options 21

outgoing line 40

redial 40

reject 20

summary 40

volume control 40

waiting 21, 40

call register

recent calls list 37

timers 37

caller ID 40

camera 47

clock

alarm 50

set 40

configuration settings 12

contacts 33

1-touch dialing 36

delete 34

edit 34

groups 35

search 33

settings 34

synchronization 52

countdown timer 54

date 40

default settings 44

digital signature 63

download

applications 56

files 60

games 55

EGPRS 42

enhancements 43, 66

factory settings 44

file download 60

FM radio 47

functions overview 11

games 55

graphics 46

6101_6102.ENv1_9240568_UG.fm Page 77 Tuesday, June 7, 2005 2:59 PM

Index

images 46, 47

save 33

show or hide 59

infrared (IR) 41

Internet (See web) 57

keypad

lock 19, 41

unlock 19, 41

language 41

lock keypad 19, 41

main display 17, 39

memory

cache 61

full 28

shared 10

messages 25

counter 32

delete 30

folders 29

multimedia 26

Nokia Xpress audio 29

reply 25

send 25

settings 30

text 25

voice 30

mini display 17, 40

modem 42

multimedia messages 26

reply 28

save 27

send 27

settings 31

notes 51

packet data 42, 65

PC Suite 65

personal shortcut list 17

photographs 47

PIN code 11, 44

predictive text input 22

profiles 38

PUK code 11

radio 47

record

list of recordings 48

sound 48

save

configuration settings 12

images 33

multimedia messages 27

names 33

phone numbers 33

text messages 29

scripts 59

security 44

browsing 61

digital signature 63

service inbox 60

shortcut 39

in standby mode 18

list 17

SIM card 13, 64

sound 48

stopwatch 53

synchronize

calendar 52

configuration settings 52

contacts 52

notes 53

PC 53

6101_6102.ENv1_9240568_UG.fm Page 78 Tuesday, June 7, 2005 2:59 PM

Index

text

predictive text input 22

traditional input 23

wrapping 58

write 22

text messages 25

themes 38, 46

time 40

timer 54

to-do list 51

tones 38, 46

traditional text input 23

TTY/TTD 43

unlock keypad 19

video clips 46, 47

voice dialing 35

voice tags

add 35

making a call 36

WAP services 10

security module in SIM 61

signing documents 63

web

bookmarks 59

browsing 57

browsing options 58

certificates 62

connect 57

download files 60

scripts 59

write text 22

6101_6102.ENv1_9240568_UG.fm Page 79 Tuesday, June 7, 2005 2:59 PM

Notes

6101_6102.ENv1_9240568_UG.fm Page 80 Tuesday, June 7, 2005 2:59 PM

Microsoft RM-77XH GSM 850/1800/1900 Cellular Telephone User Manual 6101 6102 ENv1 9240568 UG

Microsoft Mobile Oy GSM 850/1800/1900 Cellular Telephone 6101 6102 ENv1 9240568 UG

Contents

User guide

Navigation menu

Namespaces

Views

Navigation
