Nokia Lumia 1320
Welcome to the
Nokia Lumia 1320
Issue 1.0 EN 1320.1
Keys and parts
1 Connector for headphones and
loudspeakers (3.5 mm)
2Earpiece
3 Front camera
4Volume keys
5 Power/Lock key
6 Camera key
7 Back key
8Start key
9Search key
10 Microphone
11 Micro-USB connector. Also used to charge
the battery.
Do not attempt to remove the battery from the
device. To replace the battery, take the device to
your nearest authorised service facility.
Some of the accessories mentioned in this user
guide may be sold separately.
2
Get started
Before you start using your phone, remove the
back cover to insert the micro-SIM card.
Remove the back cover
Make sure your phone is switched off.
At the bottom corner of the phone, put your
fingernail in the seam between the screen frame
and the back cover. Bend the back cover open,
and remove it. Only use your fingers to open the
cover.
3
Insert the SIM and memory card
Important: Your device uses a mini-UICC SIM
card, also known as a micro-SIM card. Use of
incompatible SIM cards, or use of SIM card
adapters, may damage the card or the device, and
may corrupt data stored on the card.
1. Push the SIM card into the SIM card slot, contact
area face down.
2. If you have a microSD card, push the card into
the memory card slot until it locks into place.
4
Close the back cover
Press the top edge of the back cover against the
top edge of your phone, and snap the back cover
into place.
Charge the battery
Connect the USB cable to the charger, plug the
charger into a wall outlet, and connect the micro-
USB end to your phone. You can also charge the
phone from a computer with the USB cable.
If the battery is completely discharged, it may
need to charge for up to 20 minutes before you
can use your phone. The charging indicator may
not be displayed in this time.
5
Help and tips
There's a user guide in your phone – it's always
with you, available when needed. On the start
screen, swipe left, and tap Nokia Care.
For the online user guide, even more info, and
troubleshooting help, go to www.nokia.com/
support, or press , and tap . Point the camera
at the code below, and tap the result.
Check out the videos at www.youtube.com/
NokiaSupportVideos.
If your phone freezes
Press and hold the power key for about 10
seconds. The phone vibrates and restarts.
6
Product and safety information
Important: For important info on the safe use of your device and
battery, read “Safety” and “Product and safety info” in the device
user guide at www.nokia.com/support and in the in-device user guide
before you take your device into use. Select Nokia Care.
For info on Nokia Service terms and Privacy policy, go to
www.nokia.com/privacy.
You can only use your device on the LTE 700, 850, 1700–2100, 1900
MHz networks, WCDMA 850, 1900, 1700–2100, 2100 MHz networks,
and GSM 850, 900, 1800, 1900 MHz networks.
Use your device only with an original BV-4BWA rechargeable
battery. To replace the battery, take the device to the nearest
authorised service facility. Do not dispose batteries as household
waste. Charge your device with AC-60U charger. Charger plug type
may vary. Nokia may make additional battery or charger models
available for this device.
Third-party chargers that comply with the IEC/EN 62684 standard,
and that can connect to your device micro USB connector, may also
be compatible.
To prevent possible hearing damage, do not listen at high volume
levels for long periods. Exercise caution when holding your device
near your ear while the loudspeaker is in use.
Additional safety information
Accessibility solutions
Nokia is committed to making mobile phones easy to use for all
individuals, including those with disabilities. For more information,
visit the Nokia website at www.nokiaaccessibility.com.
Hearing
Warning: When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it can
endanger your safety.
Some wireless devices may interfere with some hearing aids.
Information on health
The U.S. Food and Drug Administration (FDA) and the U.S. Federal
Communications Commission (FCC) published statements and
questions and answers concerning cellular telephones and health.
Nokia encourages you to visit these websites for updated
information. You can access the FDA website at www.fda.gov/
Radiation-EmittingProducts/
RadiationEmittingProductsandProcedures/
HomeBusinessandEntertainment/CellPhones/default.htm and the
FCC website at transition.fcc.gov/oet/rfsafety/rf-faqs.html.
7
Additional health-related information is available from the World
Health Organization (WHO) at www.who.int/mediacentre/
factsheets/fs193/en/ and The National Cancer Institute ("NCI")
www.cancer.gov/ncicancerbulletin/NCI_Cancer_Bulletin_092308/
page7. In the event that you are concerned about possible health
effects, the FDA suggests that you limit your own or your children’s
radio frequency (RF) exposure by limiting the length of calls or by
using handsfree devices.
Safety and texting while driving
Safety should be every driver’s first priority. Drivers must obey all
local laws that may include restrictions on the use of cellular
telephones or accessories while driving. If use is legal, always keep
your hands free to operate the vehicle while driving and use a
handsfree device whenever possible. Suspend calls in heavy traffic or
hazardous weather. Get to know your cellular phone and its features
and make any necessary information inputs prior to driving. Do not
input data or engage in text messaging while driving. Cellular
telephones should not be used when use may be a distraction to the
driver.
The Cellular Telecommunications & Internet Association (CTIA) has
published further info and tips on safe use of cellular telephones at
www.ctia.org/consumer_info/safety, which we encourage you to
review.
Certification information (SAR)
This mobile device meets international guidelines for exposure to
radio waves.
Your mobile device is a radio transmitter and receiver. It is designed
not to exceed the limits for exposure to radio waves (radio frequency
electromagnetic fields), recommended by international guidelines
from the independent scientific organization ICNIRP. These
guidelines incorporate substantial safety margins that are intended
to assure the protection of all persons regardless of age and health.
The exposure guidelines are based on the Specific Absorption Rate
(SAR), which is an expression of the amount of radio frequency (RF)
power deposited in the head or body when the device is transmitting.
The ICNIRP SAR limit for mobile devices is 2.0 W/kg averaged over 10
grams of tissue.
SAR tests are carried out with the device in standard operating
positions, transmitting at its highest certified power level, in all its
frequency bands. The maximum recorded SAR values for this device
are:
Maximum SAR value Frequency bands
used when
Maximum SAR value
was recorded
8
When held against
the head
0.56 W/kg over 10g WCDMA 1900 and
WLAN 2450
When operated at a
separation distance
of 1.5 centimetres
(5/8 inch) from the
body
0.40 W/kg over 10g WCDMA 1900 and
WLAN 2450
Your mobile device is also designed to meet the United States Federal
Communications Commission (FCC) and Industry Canada SAR (IC)
guidelines. FCC ratings for your device and more information on SAR
can be found at transition.fcc.gov/oet/rfsafety/sar.html.
Information on IC SAR can be found at www.ic.gc.ca.
This device meets RF exposure guidelines when used against the head
or when positioned at least 1.5 centimetres (5/8 inch) away from the
body. When a carry case, belt clip or other form of device holder is
used for body-worn operation, it should not contain metal and should
provide at least the above stated separation distance from the body.
To send data or messages, a good connection to the network is
needed. Sending may be delayed until such a connection is available.
Follow the separation distance instructions until the sending is
finished.
During general use, the SAR values are usually well below the values
stated above. This is because, for purposes of system efficiency and
to minimise interference on the network, the operating power of your
mobile is automatically decreased when full power is not needed for
the call. The lower the power output, the lower the SAR value.
Device models may have different versions and more than one value.
Component and design changes may occur over time and some
changes could affect SAR values. The latest available SAR information
for this and other Nokia device models can be found at
www.nokia.com/sar.
For more info, go to www.sar-tick.com. Note that mobile devices may
be transmitting even if you are not making a voice call.
The World Health Organization (WHO) has stated that current
scientific information does not indicate the need for any special
precautions when using mobile devices. If you are interested in
reducing your exposure, they recommend you limit your usage or use
a hands-free kit to keep the device away from your head and body.
For more information and explanations and discussions on RF
exposure, go to the WHO website at www.who.int/peh-emf/en.
Nokia Care
For questions regarding your plans, billing or network please contact
your operator. For questions regarding your Nokia product and
9
warranty, please visit the support pages for your country at
www.nokia.com/support.
Copyrights and other notices
The availability of products, features, apps and services may vary by
region. For more info, contact your Nokia dealer or your service
provider. This device may contain commodities, technology or
software subject to export laws and regulations from the US and other
countries. Diversion contrary to law is prohibited.
The contents of this document are provided "as is". Except as
required by applicable law, no warranties of any kind, either express
or implied, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose, are made in
relation to the accuracy, reliability or contents of this document.
Nokia reserves the right to revise this document or withdraw it at any
time without prior notice.
To the maximum extent permitted by applicable law, under no
circumstances shall Nokia or any of its licensors be responsible for
any loss of data or income or any special, incidental, consequential or
indirect damages howsoever caused.
Reproduction, transfer or distribution of part or all of the contents in
this document in any form without the prior written permission of
Nokia is prohibited. Nokia operates a policy of continuous
development. Nokia reserves the right to make changes and
improvements to any of the products described in this document
without prior notice.
Nokia does not provide a warranty for or take any responsibility for
the functionality, content, or end-user support of third-party apps
provided with your device. By using an app, you acknowledge that the
app is provided as is. Nokia does not make any representations,
provide a warranty, or take any responsibility for the functionality,
content, or end-user support of third-party apps provided with your
device.
The software in this device includes software licensed by Nokia from
Microsoft Corporation or its affiliates. To access the Windows Phone
software license terms, select Settings > about. Please read the
terms. Please note that by using the software, you accept the terms.
If you do not accept the terms, do not use the device or software.
Instead contact Nokia or the party from which you purchased the
device to determine its return policy.
FCC/INDUSTRY CANADA/MEXICO NOTICE
This device complies with part 15 of the FCC rules and Industry Canada
licence-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation. Any changes or
modifications not expressly approved by Nokia could void the user's
authority to operate this equipment.
10
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
TM & © 2013 Nokia. All rights reserved. Third party products/names
may be TMs of their respective owners.
© 2013 Microsoft Corporation. All rights reserved. Microsoft, Windows
and the Windows logo are trademarks of the Microsoft group of
companies.
The Bluetooth word mark and logos are owned by the Bluetooth SIG,
Inc. and any use of such marks by Nokia is under license.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Dolby Laboratories.
This product is licensed under the MPEG-4 Visual Patent Portfolio
License (i) for personal and noncommercial use in connection with
information which has been encoded in compliance with the MPEG-4
Visual Standard by a consumer engaged in a personal and
noncommercial activity and (ii) for use in connection with MPEG-4
video provided by a licensed video provider. No license is granted or
shall be implied for any other use. Additional information, including
that related to promotional, internal, and commercial uses, may be
obtained from MPEG LA, LLC. See www.mpegla.com.
NOKIA — MANUFACTURER’S LIMITED
WARRANTY
1. GENERAL
Nokia Inc. (“Nokia”) provides this Manufacturer's Limited Warranty
(“Warranty”) for genuine Nokia product (the “Product”), which Nokia
has released for sale in the United States of America and Canada
(“Covered Countries”) since 1 November 2013.
11
This Warranty is distinct from any statutory rights under any
mandatory consumer protection laws of your country or state
applicable to you. It is intended to grant you specific, and as the case
may be, additional rights, within the limits of what is permissible under
such law, and does not limit the rights you may have under applicable
statutory product warrantee provisions. You may have other rights
based on local laws during or after the Warranty period. These rights
are not excluded by this Warranty.
2. WARRANTY
From the date the Product is sold to an end-user for the first time, as
evidenced by the original proof of purchase, Nokia warrants the
Product is free from defects in materials and workmanship (“Defect”)
as follows:
(i) Twelve (12) months for the main device;
(ii) Twelve (12) months for accessories sold separately or included in
the sales pack of the main device excluding batteries, covers, cables
and chargers; and
(iii) Six (6) months for all batteries, covers, cables and chargers,
unless otherwise specified in the Product user guide.
During the warranty period, Nokia will, in a reasonable time, remedy
the Defect free of charge by either repairing or replacing the
defective Product or the defective part of it at its option provided that
you have informed Nokia of the Defect before the warranty period
expires. When repairing or replacing your Product, Nokia may use new
or re-conditioned parts or products.
To the fullest extent permitted by applicable law, no repair or
replacement will renew or extend the warranty period. Original or
replacement parts or replacement Products provided under this
Warranty will be covered by this Warranty for the remainder of the
original warranty period or for sixty (60) days from the date of repair
or replacement, whichever is longer.
The Product or all parts of your Product that Nokia has replaced shall
become Nokia’s property.
Nokia does not warrant that software preinstalled by or on behalf of
Nokia in the Product (or subsequent updates and upgrades) (together
“Nokia software”) will meet your requirements, work in combination
with any hardware or software not provided by Nokia, is uninterrupted
or error free or that errors are correctable or will be corrected. For
Nokia software related errors, Nokia will make available the latest
version of the Nokia software for reinstallation on your Product or, if
that would not be possible, another remedy, which in Nokia’s
reasonable discretion, satisfactorily addresses the error. Some Nokia
software may be subject to separate license terms that are available
with the software or your local section of www.nokia.com.
Please always back up all data and content stored on your Product
before taking your Product in for service since service activities will
erase all data from your Product.
3. WHAT THIS WARRANTY DOES NOT COVER
Nokia does not provide any warranty for the following:
12
1 User guides;
2 Any (i) third party software, settings, content, data, or links installed
or downloaded onto your Product at any time, or (ii) Nokia and third
party services or enabling clients even if preinstalled by Nokia (please
read the terms and conditions that may accompany the services as
those will define your rights and obligations);
3 Any (i) normal wear and tear, (ii) reduced charging capacity of the
battery resulting from its natural end of product life, or (iii) pixel
defects in your Product’s display that are within the scope of industry
standards;
4 SIM card and/or any cellular or other networks or system on which
your Product operates; or
5 Errors or damage caused by: (a) misuse or not using your Product in
accordance with the user guide, such as if the Product has been
exposed to moisture, to dampness or to extreme thermal or
environmental conditions or to rapid changes in such conditions, to
corrosion, to oxidation, to spillage of food or liquid or to influence
from chemical products, (b) using your Product with, or connecting it
to, any product, accessory, software, or service not manufactured or
supplied by Nokia, (c) any products combined with your Product by a
third party, (d) damage or errors caused by hacking, cracking, viruses,
or other malware, or by unauthorised access to services, accounts,
computer systems or networks; or (e) other acts beyond Nokia’s
reasonable control.
This Warranty is not valid:
1 Outside of the Covered Countries;
2 If your Product, or the software it runs on, has been (a) opened,
modified, or repaired without Nokia’s authorisation, or (b) repaired
with unauthorised spare parts;
3 If your Product's serial number, the mobile accessory date code, or
the IMEI number has been removed, erased, defaced, altered or if
these are illegible in any way;
4 If you have not installed the latest software updates that are publicly
available for your Product within a reasonable time of their release;
or
5 If you refuse to give possession of the Product to Nokia for repair
and investigation.
If this Warranty does not cover your Product or the issue based on
which it requires service, Nokia reserves the right to charge for the
repair or replacement of your Product, as well as a handling fee.
4. LIMITATION OF NOKIA'S LIABILITY
To the extent permitted by applicable law(s), Nokia shall not under
any circumstances be liable, either expressly or implicitly, for any
1 Damages or losses of any kind whatsoever resulting from or relating
to loss of, damage to, or corruption of, content or data or the
recreation or transfer thereof even if such loss, damage, or
corruption was a result of a Defect in your Product; and/or
13
2 Loss of profit, products or functionality, business, contracts,
revenues or anticipated savings, increased costs or expenses, or for
any indirect, consequential or special loss or damage.
To the extent permitted by applicable law, Nokia’s liability shall be
limited to the purchase value of your Product.
The limitations in this clause 4 shall not apply in case of Nokia’s
negligence or intentional misconduct or in case of death or personal
injury resulting from Nokia’s proven negligence.
5. OTHER IMPORTANT NOTICES
For further information on your Warranty, as well as information
needed to process your warranty queries, please visit
www.nokia.com.
Please ensure your operator has removed any SIM-locks (or other
equivalent mechanisms that may lock your Product to a specific
network or operator) prior to delivering your Product for repair.
Your Product may contain country specific elements, including
software. The warranty services available in a particular country may
be limited to the Products and country specific elements available in
that country. Also, if your Product has been re-exported from its
original destination to another country, your Product may contain
country specific elements that are not considered a defect under this
Warranty even if it would not be operational.
United States: Nokia Inc., 200 South Mathilda, Sunnyvale, California
94086
14
