V

ersion Information

Product Name Microsoft® O

p

tical Deskto

p

Elite for Bluetooth®

Product Version Microsoft Optical Desktop Elite for Bluetooth 1.0

Keyboard Version Microsoft Keyboard Elite for Bluetooth 2.0

Mouse Version Microsoft IntelliMouse®Ex

p

lorer for Bluetooth 2.0

Transceiver Version Microsoft Wireless Transceiver for Bluetooth 2.0

Product Dimensions

Keyboard Length 19.4 inches (494 millimeters)

Keyboard Width 10.5 inches (266 millimeters) includes palm rest

Keyboard Depth/Height 1.55 inches (39.4 millimeters) with tilt legs folded

Ke

y

board Wei

g

ht 46.0 ounces

(

1301

g

rams

)

includes 3 AA alkaline batteries

;

t

yp

ical batter

y

wei

g

ht ma

y

var

y

Mouse Length 4.97 inches (126 millimeters)

Mouse Width 3.14 inches (79.6 millimeters)

Mouse Depth/Height 1.72 inches (43.6 millimeters)

Mouse Weight 5.48 ounces (155 grams) includes 2 AA alkaline batteries; typical battery weight may vary

Transceiver Length 1.81 inches (46.0 millimeters)

Transceiver Width 0.88 inches (22.3 millimeters)

Transceiver Depth/Height 0.30 inches (7.69 millimeters)

Transceiver Weight 0.27 ounces (7.62 grams)

Com

p

atibilit

y

and Localization

Interface USB Compatible

Operating Systems Microsoft Windows® XP with SP2 or higher

Top-line System Requirements • Microsoft Windows XP with Service Pack 2 or higher

• Pentium 233 MHz or higher processor

• 128 MB of RAM

• 60 MB of available hard disk space

• USB port

• CD drive

• A wired mouse or keyboard may be required for installation

Compatibility Logos • Designed for Microsoft Windows XP

• Bluetooth Compatible Product

• Certified USB logo

Software Version Microsoft IntelliPoint software, version 5.2 or higher, is required in order to enjoy full product

functionality (including Tilt Wheel Technology, Smart Receiver Technology, and button

programmability features). Microsoft IntelliType Pro software, version 5.2 or higher, is required in

order to enjoy full product functionality (including all Hot Key and Media Key features).

Internet Hot Keys are supported for use with: Microsoft Internet Explorer version 5.0 or later;

MSN® Explorer 7.0 or 8.0; Netscape Navigator versions 6.1, 6.2, or 7.0; and AOL versions 7.0, 8.0,

or 9.0

Multimedia Hot Keys are supported for use with: Versions of Microsoft CD Player, Microsoft

Deluxe CD, Microsoft Windows Media Player, and certain versions of other popular media players

and browsers

Software Localization Microsoft IntelliPoint and IntelliType Pro software may be installed in Simplified Chinese, Traditional

Chinese, English, French, German, Italian, Japanese, Korean, Brazilian Portuguese, Iberian

Portuguese, or Spanish. If available, standard setup will install the software in the default OS

language. Otherwise, the English language version will be installed.

Keyboard Localization Available language sets will vary by product and sales channel.

104 key configuration: English (North America), International English (EURO), and International

English (ROW)

105 key configuration: Danish, English (UK), Finnish/Swedish, French (France), German

(Germany), German (Switzerland/Belgium), Italian, Norwegian, Portuguese (Portugal), and Spanish

(EURO)

109 key configuration: Japanese

Trackin

g

Technolo

gy

Mouse Tracking System Microsoft-proprietary optical technology

Imaging Rate Dynamically adaptable to 6000 frames per second

X-Y Resolution 400 points per inch (15.75 points per millimeter)

Tracking Speed Up to 20 inches (508 millimeters) per second

Rev. 0602A Microsoft® Optical Desktop Elite for Bluetooth®Page 1 of 2

Power Requirements

Battery Type and Quantity • Keyboard: 3 AA alkaline batteries (included)

• Mouse: 2 AA alkaline batteries (included)

Battery Life • Keyboard: 6 months typical

• Mouse: 3 months typical

Wireless Technolo

gy

Wireless Platform Bluetooth 1.2

Wireless Frequency 2.4 GHz frequency range

Wireless Range 32.8 feet (10 meters) typical

Bluetooth Profile Support • Serial Port (SPP)

• Object Push (OPP)

• Personal Area Networking (PANU)

• Human Interface Device (HID)

• Hard Copy Cable Replacement (HCRP)

• Dial-Up Networkng (DUN)

Product Feature Performance

QWERTY Key Life 1,000,000 actuations per key

Hot Key Features Mail, Web/Home, Messenger, My Documents, My Pictures, My Music, Show My Favorites, My

Favorites 1, My Favorites 2, My Favorites 3, My Favorites 4, My Favorites 5, Calculator, Log Off,

Slee

p,

Back

,

and Forward

Hot Key Life 500,000 actuations per key

Media Key Features Mute, Volume -, Volume +, Play/Pause, Stop (Media), Previous Track, and Next Track

Media Key Life 500,000 actuations per key

Enhanced Function Key Features Help, Undo, Redo, New, Open, Close, Reply, Forward, Send, Spell, Save, and Print

Typing Speed 1000 characters per minute

Keyboard Wheel Scrolling Features Tilt wheel enables vertical and horizontal scrolling

Keyboard Wheel Vertical Scrolling Life • 50,000 revolutions (away from user) at no more than 60 rotations per minute

• 100,000 revolutions (toward user) at no more than 60 rotations per minute

Ke

y

board Wheel Horizontal Scrollin

g

Life 250

,

000 actuations

p

er side at no more than 4 actuations

p

er second

Mouse Button Features 5 buttons including scroll wheel button

Mouse Right & Left Button Life 1,000,000 actuations at no more than 4 actuations per second

Back/Forward Button Life 500,000 actuations at no more than 4 actuations per second

Mouse Wheel Button Life 150,000 actuations at no more than 4 actuations per second

Mouse Scrolling Features Tilt wheel enables vertical and horizontal scrolling

Mouse Wheel Vertical Scrolling Life • 85,000 revolutions (away from user) at no more than 60 rotations per minute

• 100,000 revolutions (toward user) at no more than 60 rotations per minute

Mouse Wheel Horizontal Scrollin

g

Life 250

,

000 actuations

p

er side at no more than 4 actuations

p

er second

Transceiver Features Supports up to seven devices equipped with Bluetooth technology

Storage Temperature & Humidity -40 °F (-40 °C) to 140 °F (60 °C) at < 5% to 65% relative humidity (non-condensing)

Operating Temperature & Humidity 14 °F (-10 °C) to 104 °F (40 °C) at <5% to 80% relative humidity (non-condensing)

Certification Information

Country of Manufacture People's Republic of China (PRC)

ISO 9002 Qualified Manufacturer Yes

FCC ID This device complies with part 15 of the FCC Rules and Industry Canada RSS-210. Operation is

subject to the following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may cause undesired

operation. Tested to comply with FCC standards. For home and office use. Model numbers: 1002,

Keyboard Elite for Bluetooth 2.0; 1001, IntelliMouse Explorer for Bluetooth 2.0; and 1003, Wireless

Transceiver for Bluetooth 2.0. FCC IDs C3K1002, C3K1001, and C3K1003.

Agency and Regulatory Approvals • FCC Declaration of Conformity (USA)

• UL and cUL Notice of Approval (USA and Canada)

• RSS-210 and ICES-003 data on file (Canada)

• R&TTE Declaration of Conformity, Safety and EMC (European Union)

• TUV GS Certificate (Germany)

• VCCI and Telec Certificates (Japan)

• ACA/MED Declaration of Conformity (Australia and New Zealand)

• CITC Certificate (Saudi Arabia)

• NTRA Certificate (Egypt)

• CE Declaration (Hungary)

• NOM Certificates (Mexico)

• CB Scheme Certificate (International)

• WHQL (International) IDs: 850313 (Keyboard 104/105), 850318 (Keyboard 109),

851258 (Mouse), 848441 (Transceiver)

Results stated herein are based on internal Microsoft testing. Individual results and performance may vary. Any device images shown are not actual size. This document is

provided for informational purposes only and is subject to change without notice. Microsoft makes no warranty, express or implied, with this document or the information contained

herein. Review any public use or publications of any data herein with your local legal counsel.

©2006 Microsoft Corporation. All rights reserved. Microsoft, the IntelliEye logo, IntelliMouse, MSN, the Laser Technology logo, the Optical Technology logo, Natural, Windows, and

Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Mac and the Mac logo are trademarks of Apple Computer,

Inc., registered in the U.S. and/or other countries. The names of actual companies and products mentioned herein may be trademarks of their respective owners.

Rev. 0602A Microsoft® Optical Desktop Elite for Bluetooth®Page 2 of 2
