Microsoft WE02M Bluetooth Headset User Manual HS 57W en1

Microsoft Mobile Oy Bluetooth Headset HS 57W en1

Manual HS 57W

Nokia Bluetooth Headset BH-700
User Guide
9246080
Issue 1
HS-57W_en1.fm Page 1 Tuesday, June 13, 2006 6:53 PM
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product
HS-57W is in conformity with the provisions of the following Council Directive:
1999/5/EC. A copy of the Declaration of Conformity can be found at http://
www.nokia.com/phones/declaration_of_conformity/.
The crossed-out wheeled bin means that within the European Union the product
must be taken to separate collection at the product end-of-life. Do not dispose of
these products as unsorted municipal waste.
© 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other
product and company names mentioned herein may be trademarks or tradenames of their
respective owners.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without prior
notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer
nearest to you.
Unauthorized changes or modifications to this device may void the user's authority to
operate the equipment.
Export Controls
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
9246080 / Issue 1 EN
HS-57W_en1.fm Page 2 Tuesday, June 13, 2006 6:53 PM
3
Contents
1. Introduction ......................... 4
Bluetooth wireless technology .......... 4
2. Get started............................ 5
Overview .................................................. 5
Chargers ................................................... 5
Charge the battery................................ 6
Switch the headset on or off ............. 6
Pair the headset with
a compatible phone.............................. 6
Disconnect the headset
from the phone................................... 7
Reconnect the paired
headset to your phone...................... 7
Troubleshooting ..................................... 7
3. Basic use ............................... 9
Place the headset over your ear........ 9
Carry the headset in the strap......... 10
Call handling......................................... 10
Adjust the earphone volume............ 11
Mute or unmute the microphone... 11
Switch the call between
the phone and headset...................... 11
Use the headset with
several phones...................................... 11
Clear the settings ................................ 11
4. Battery information ........... 12
Care and maintenance ........... 13
FCC/Industry Canada notice .. 14
HS-57W_en1.fm Page 3 Tuesday, June 13, 2006 6:53 PM
Introduction
4
1. Introduction
The Nokia Bluetooth Headset BH-700 allows you freedom to make and
receive calls while on the move or in the office. You can connect the
headset to a compatible phone that supports Bluetooth wireless
technology.
Read this user guide carefully before using the headset. Read also the
user guide for your phone, which provides important safety and
maintenance information. Keep the headset and its accessories out of
reach of small children.
■Bluetooth wireless technology
Bluetooth wireless technology allows you to connect compatible
communication devices without cables. A Bluetooth connection does
not require that the phone and the headset be in line of sight, but both
devices should be within 10 meters (30 feet) of each other. Connections
can be subject to interference from obstructions, such as walls, or other
electronic devices.
The headset is compliant with the Bluetooth Specification 2.0 + EDR
supporting the following profiles: Headset Profile 1.1 and Handsfree
Profile 1.5. Check with the manufacturers of other devices to determine
their compatibility with this device.
There may be restrictions on using Bluetooth technology in some
locations. Check with your local authorities or service provider.
HS-57W_en1.fm Page 4 Tuesday, June 13, 2006 6:53 PM
Get started
5
2. Get started
■Overview
The headset contains the following parts:
• Indicator light (1)
• Power key (2)
• Answer/end key (3)
• Volume key (4)
• Strap catch (5)
• Charger connector (6)
• Microphone (7)
• Earloop (8)
• Earpiece (9)
Before using the headset, you must charge the battery and pair the
headset with a compatible phone.
Note: Parts of the headset are magnetic. Metallic materials may be
attracted to the headset. Do not place credit cards or other magnetic
storage media near the headset, because information stored on them
may be erased.
■Chargers
Check the model number of any charger before using it with this device. The
headset is intended for use with the AC-3, AC-4, and DC-4 chargers.
Warning: Use only chargers approved by Nokia for use with this
particular enhancement. The use of any other types may invalidate any
approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer. When
you disconnect the power cord of any enhancement, grasp and pull the plug, not
the cord.
9
HS-57W_en1.fm Page 5 Tuesday, June 13, 2006 6:53 PM
Get started
6
■Charge the battery
This device has an internal, nonremovable, rechargeable battery. Do not
attempt to remove the battery from the device as you may damage the
device.
1. Connect the charger to a wall outlet.
2. Connect the charger cable to the headset.
The red indicator light is displayed during
charging. If charging does not start,
disconnect the charger, plug it in again,
and retry. Charging the battery fully may
take up to 2 hours.
3. When the battery is fully charged, the red indicator light turns off.
Disconnect the charger from the headset and the wall outlet.
The fully charged battery has power for up to 6 hours of talk-time or up
to 160 hours of standby time. However, the talk and standby times may
vary when used with different mobile phones or other compatible
Bluetooth devices, usage settings, usage styles, and environments.
When battery power is low, the headset beeps, and the red indicator
light starts to flash.
■Switch the headset on or off
To switch on, press and hold the power key. The headset beeps, and the
green indicator light is displayed briefly. When the headset is connected
to a paired phone and is ready for use, the blue indicator light flashes
slowly. If the headset is not connected to a phone, the green indicator
light flashes slowly.
To switch off, press and hold the power key. The headset beeps, and the
red indicator light is displayed briefly.
■Pair the headset with a compatible phone
1. Switch on your phone and the headset.
HS-57W_en1.fm Page 6 Tuesday, June 13, 2006 6:53 PM
Get started
7
2. Activate the Bluetooth feature on the phone, and set the phone to
search for Bluetooth devices. See the user guide of your phone for
instructions.
3. Select the headset (Nokia BH-700) from the list of found devices.
4. Enter the Bluetooth passcode 0000 to pair and connect the headset
to your phone. In some phones you may need to make the connection
separately after pairing. See the user guide of your phone for details.
You only need to pair the headset with your phone once.
If the pairing is successful, the headset beeps and appears in the phone
menu where you can view the currently paired Bluetooth devices.
Disconnect the headset from the phone
To disconnect the headset from your phone (for example, to connect the
phone to another Bluetooth device), do one of the following:
• Switch off the headset.
• Disconnect the headset in the Bluetooth menu of your phone.
• Move the headset more than 10 meters (30 feet) away from the
phone.
You do not need to delete the pairing with the headset to disconnect it.
Reconnect the paired headset to your phone
To connect the headset to your phone, switch on the headset, make the
connection in the Bluetooth menu of your phone, or press and hold the
answer/end key.
You can set your phone to connect with the headset automatically
when the headset is switched on. To do this in Nokia phones, change
your paired device settings in the Bluetooth menu.
■Troubleshooting
If you cannot connect the headset to your phone, do as follows:
• Ensure that the headset is charged, switched on, and paired with
your phone.
HS-57W_en1.fm Page 7 Tuesday, June 13, 2006 6:53 PM
Get started
8
• Ensure that the Bluetooth feature is activated on your phone.
• Check that the headset is within 10 meters (30 feet) of your phone
and that there are no obstructions between the headset and the
phone, such as walls or other electronic devices.
• To reset the headset if it stops functioning, although it is charged,
plug the headset into a charger, and briefly press the power key and
the middle of the volume key. This reset does not clear your settings
(for example, pairing settings).
HS-57W_en1.fm Page 8 Tuesday, June 13, 2006 6:53 PM
Basic use
9
3. Basic use
■Place the headset over your ear
The headset is provided with an earloop that you can use for a better fit
on your ear.
To use the headset without the earloop, plug the earpiece into your ear
(1), and point the headset toward your mouth.
To use the headset with the earloop, insert the earloop into the small
opening at the back of the headset (2). To wear the headset on the right
ear, rotate the earloop so that the loop is to the right of the "Nokia" text.
Slide the earloop over your ear (3), and push or pull the earloop to set its
length (4). Set the headset so that it points toward your mouth.
To use the headset on the left ear, rotate the earloop so that the loop is
to the left of the text (5).
To detach the earloop (for example, to clean it), gently pull it from the
headset.
HS-57W_en1.fm Page 9 Tuesday, June 13, 2006 6:53 PM
Basic use
10
■Carry the headset in the strap
The headset is supplied with a strap. When you do not keep the headset
on your ear, you can wear it on your neck using the strap. To fix the
headset to the strap, insert the headset into the catch (1), and gently
push it downwards (2) until it locks into place. To detach the headset,
slide it out through the catch (3).
■Call handling
To make a call, use your phone in the normal way when the headset is
connected to your phone. The blue indicator light flashes slowly during
the call.
If your phone supports redialing with this device, briefly press the
answer/end key twice when no call is in progress.
If your phone supports voice dialing with this device, press and hold the
answer/end key when no call is in progress, and proceed as described in
the user guide of your phone.
When you receive a call, the blue indicator light flashes quickly, and you
hear a ringing tone through the headset. To answer the call, press the
answer/end key, or use the phone keys. If the automatic answer function
is set to on in your phone, the phone automatically answers the
incoming call after one ring.
To reject an incoming call, briefly press the answer/end key twice, or use
the phone keys.
To end a call, press the answer/end key, or use the phone keys.
HS-57W_en1.fm Page 10 Tuesday, June 13, 2006 6:53 PM
Basic use
11
■Adjust the earphone volume
Press the volume key up to increase or down to decrease the volume
during a call. To adjust the volume quickly, press and hold the key in the
desired direction.
■Mute or unmute the microphone
To mute or unmute the microphone during a call, briefly press the
middle of the volume key. A long tone sounds, and the headset beeps at
regular intervals until you unmute the microphone.
■Switch the call between the phone and headset
To switch the call between the headset and a compatible phone, press
and hold the answer/end key, or use the respective function in your
phone.
■Use the headset with several phones
You can pair the headset with up to eight phones but connect it to only
one phone at a time.
The phone that was first paired with the headset is the default phone. If
the headset is switched on within 10 meters (30 feet) of several paired
phones, the headset tries to connect to the default phone.
If the headset cannot connect to the default phone, the headset tries to
connect to the last used phone. If the headset cannot connect to this
phone either, one of the other six paired phones can be connected to the
headset. To make the connection, see the user guide of your phone.
■Clear the settings
If you want to clear all the settings from the headset (for example, the
list of paired devices), press and hold the power key and the volume key
up for 10 seconds. After the settings are cleared, the headset beeps
twice, and the indicator lights alternate for several seconds.
HS-57W_en1.fm Page 11 Tuesday, June 13, 2006 6:53 PM
Battery information
12
4. Battery information
Your device is powered by a rechargeable battery. The full performance of a new
battery is achieved only after two or three complete charge and discharge cycles.
The battery can be charged and discharged hundreds of times, but it will
eventually wear out. Recharge your battery only with Nokia approved chargers
designated for this device.
Unplug the charger from the electrical plug and the device when not in use. Do
not leave a fully charged battery connected to a charger, since overcharging may
shorten its lifetime. If left unused, a fully charged battery will lose its charge over
time.
Never use any charger that is damaged.
Leaving the device in hot or cold places, such as in a closed car in summer or
winter conditions, will reduce the capacity and lifetime of the battery. Always try
to keep the battery between 15°C and 25°C (59°F and 77°F). A device with a hot
or cold battery may not work temporarily, even when the battery is fully charged.
Battery performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also
explode if damaged. Dispose of batteries according to local regulations. Please
recycle when possible. Do not dispose as household waste.
HS-57W_en1.fm Page 12 Tuesday, June 13, 2006 6:53 PM
Care and maintenance
13
Care and maintenance
Your device is a product of superior design and craftsmanship and should be
treated with care. The suggestions below will help you protect your warranty
coverage.
• Keep all accessories and enhancements out of the reach of small children.
• Keep the device dry. Precipitation, humidity, and all types of liquids or
moisture can contain minerals that will corrode electronic circuits. If your
device does get wet, allow it to dry completely.
• Do not use or store the device in dusty, dirty areas. Its moving parts and
electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic
circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the device. Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
All of the above suggestions apply equally to your device, battery, charger, or any
enhancement. If any device is not working properly, take it to the nearest
authorized service facility for service.
HS-57W_en1.fm Page 13 Tuesday, June 13, 2006 6:53 PM
FCC/Industry Canada notice
14
FCC/Industry Canada notice
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: 1. This device may not cause harmful
interference; and 2. This device must accept any interference received,
including interference that may cause undesired operation. This
equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures: Reorient or relocate the receiving antenna. Increase the
separation between the equipment and receiver. Connect the
equipment into an outlet on a circuit different from that to which the
receiver is connected. Consult the dealer or an experienced radio/TV
technician for help. NOTE: FCC Radiation Exposure Statement: This
equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter. NOTE:
Modifications not expressly approved by Nokia could void the user's
authority to operate the equipment.
HS-57W_en1.fm Page 14 Tuesday, June 13, 2006 6:53 PM

Navigation menu
