Nokia Bluetooth Headset BH-300
User Guide
9246072
Issue 1
HS-50W_en1_draft6.fm Page 1 Tuesday, April 4, 2006 12:15 PM
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product HS-50W is
in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of
the Declaration of Conformity can be found at http://www.nokia.com/phones/
declaration_of_conformity/.
The crossed-out wheeled bin means that within the European Union the product
must be taken to separate collection at the product end-of-life. Do not dispose of
these products as unsorted municipal waste.
© 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other
product and company names mentioned herein may be trademarks or tradenames of their
respective owners.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without prior
notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer
nearest to you.
Unauthorized changes or modifications to this device may void the user's authority to
operate the equipment.
Export Controls
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
9246072 / Issue 1 EN
0434
HS-50W_en1_draft6.fm Page 2 Tuesday, April 4, 2006 12:15 PM
3
Contents
1. Introduction ......................... 4
Bluetooth wireless technology .......... 4
2. Get started............................ 5
Overview .................................................. 5
Chargers and batteries......................... 5
Charge the battery................................ 6
Switch the headset on or off ............. 6
Pair the headset with
a compatible phone.............................. 7
Disconnect the headset
from the phone................................... 7
Reconnect the paired headset
to your phone...................................... 7
Troubleshooting ..................................... 8
3. Basic use ............................... 9
Place the headset on the ear ............. 9
Change the earloop............................... 9
Call handling......................................... 10
Adjust the earphone volume............ 10
Mute or unmute the
microphone ........................................... 10
Switch the call between
phone and headset.............................. 11
Use the headset with
several phones...................................... 11
Clear the settings ................................ 11
4. Battery information ........... 12
Care and maintenance ........... 13
FCC Notice .............................. 14
HS-50W_en1_draft6.fm Page 3 Tuesday, April 4, 2006 12:15 PM
Introduction
4
1. Introduction
The Nokia Bluetooth Headset BH-300 allows you freedom to make and
receive calls while on the move or in the office. You can connect the
headset to a compatible phone that supports Bluetooth wireless
technology.
Read this user guide carefully before using the headset. Read also the
user guide for your phone, which provides important safety and
maintenance information. Keep the headset out of reach of small
children.
■Bluetooth wireless technology
Bluetooth wireless technology makes it possible to connect compatible
communication devices without cables. A Bluetooth connection does
not require that the phone and the headset be in line of sight, but both
devices should be within 10 meters (30 feet) of each other. Connections
may be subject to interference from obstructions, such as walls or other
electronic devices.
The wireless headset is compliant with Bluetooth Specification 2.0 +
EDR supporting the following profiles: Headset Profile 1.1 and
Handsfree Profile 1.5. Check with the manufacturers of other devices to
determine their compatibility with this device.
There may be restrictions on using Bluetooth technology in some
locations. Check with your local authorities or service provider.
HS-50W_en1_draft6.fm Page 4 Tuesday, April 4, 2006 12:15 PM
Get started
5
2. Get started
■Keys and parts
The headset contains the following parts:
• Power key and indicator
light (1)
• Microphone (2)
• Charger connector (3)
• Answer/end key (4)
• Changeable earloop (5)
Before using the headset, you
must charge the battery and pair the headset with a compatible phone.
Note: Parts of the headset are magnetic. Metallic materials may be
attracted to the headset. Do not place credit cards or other magnetic
storage media near the headset, because information stored on them
may be erased.
■Chargers and batteries
Check the model number of any charger before using it with this device. The
headset is intended for use with the AC-3, AC-4, and DC-4 chargers.
Warning: Use only batteries and chargers approved by Nokia for use
with this particular enhancement. The use of any other types may
invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer. When
you disconnect the power cord of any enhancement, grasp and pull the plug, not
the cord.
■Charge the battery
This device has an internal, nonremovable, rechargeable battery. Do not
attempt to remove the battery from the device as you may damage the
device.
HS-50W_en1_draft6.fm Page 5 Tuesday, April 4, 2006 12:15 PM
Get started
6
1. When the back of the headset is facing you, detach the earloop from
the left of the headset (see Place the headset on the ear on page 9).
2. Connect the charger to a wall outlet.
3. Connect the charger cable to the
headset.
The red indicator light is displayed
during charging. If charging does
not start, disconnect the charger,
plug it in again, and retry. Charging
the battery fully may take up to 2
hours.
4. When the battery is fully charged, the red indicator light turns off.
Disconnect the charger from the wall outlet and the headset.
The fully charged battery has power for up to 5 hours and 30 minutes of
talk-time or up to 150 hours of standby time. However, the talk and
standby times may vary when used with different mobile phones or
other compatible Bluetooth devices, usage settings, usage styles, and
environments.
When the battery is running out of power, the headset beeps, and the
red indicator light starts to flash.
■Switch the headset on or off
To switch on, press and hold the power key. The headset beeps, and the
green indicator light starts to flash quickly. When the headset is
connected to a paired phone and is ready for use, the green indicator
light flashes slowly.
To switch off, press and hold the power key. The headset beeps, and the
red indicator light is displayed briefly.
■Pair the headset with a compatible phone
Before you can use the headset with your phone, you need to pair and
connect the headset with it.
1. Switch on your phone and the headset.
HS-50W_en1_draft6.fm Page 6 Tuesday, April 4, 2006 12:15 PM
Get started
7
2. Activate the Bluetooth feature on the phone, and set the phone to
search for Bluetooth devices. See the user guide of your phone for
instructions.
3. Select the headset (Nokia BH-300) from the list of found devices.
4. Enter the Bluetooth passcode 0000 to pair and connect the headset
to your phone. In some phones you may need to make the connection
separately after pairing. See the user guide of your phone for details.
You only need to pair the headset with your phone once.
If the pairing is successful, the headset beeps and appears in the phone
menu where you can view the currently paired Bluetooth devices.
Disconnect the headset from the phone
To disconnect the headset from your phone (for example, to connect the
phone to another Bluetooth device), do one of the following:
• Switch off the headset.
• Disconnect the headset in the Bluetooth menu of your phone.
• Move the headset more than 10 meters (30 feet) away from the
phone.
You do not need to delete the pairing with the headset to disconnect it.
Reconnect the paired headset to your phone
To connect the headset to your phone, switch on the headset, make the
connection in the Bluetooth menu of your phone, or press and hold the
answer/end key.
You can set your phone to connect with the headset automatically
when the headset is switched on. To do this in Nokia phones, change
your paired device settings in the Bluetooth menu. See the user guide of
your phone for details.
■Troubleshooting
If you cannot connect the headset to your phone, do as follows:
HS-50W_en1_draft6.fm Page 7 Tuesday, April 4, 2006 12:15 PM
Get started
8
• Ensure that the headset is charged, switched on, and paired with
your phone.
• Ensure that the Bluetooth feature is activated on your phone.
• Check that the headset is within 10 meters (30 feet) of your phone
and that there are no obstructions between the headset and the
phone, such as walls or other electronic devices.
• To reset the headset if it stops functioning, although it is charged,
plug the headset into a charger, and briefly press the power key and
the answer/end key at the same time. This reset does not clear your
settings (for example, pairing settings).
HS-50W_en1_draft6.fm Page 8 Tuesday, April 4, 2006 12:15 PM
Basic use
9
3. Basic use
■Place the headset on the ear
The headset has an earloop that is attached around it.
To use the headset without placing the earloop over the ear, plug the
earpiece into your ear.
To use the headset with the earloop over the right ear, with the back of
the headset facing you, detach the earloop from the right side of the
headset (1) by lifting it. To use the headset on the left ear, detach the
earloop from the left side of the headset. Slide the earloop behind your
ear (2), and plug the earpiece into your ear (3).
The headset is supplied with earloops in different colors. To change the
earloop, detach the earloop from both sides of the headset, and attach
the new earloop by inserting the catches at the ends of the earloop into
the corresponding slots in the headset.
■Call handling
To make a call, use your phone in the normal way when the headset is
connected to your phone.
If your phone supports last number redialing with this device, press the
answer/end key twice briefly while no call is in progress.
HS-50W_en1_draft6.fm Page 9 Tuesday, April 4, 2006 12:15 PM
Basic use
10
To answer a call, press the answer/end key, or use the phone keys. If the
automatic answer function is set on, the phone automatically answers
the incoming call after one ring.
To reject an incoming call, briefly press the answer/end key twice.
To end a call, press the answer/end key, or use the phone keys.
■Adjust the earphone volume
To increase or decrease the earphone volume, use the volume keys on
your phone.
■Mute or unmute the microphone
To mute or unmute the microphone during a call, use the respective
function in your phone.
■Switch the call between the phone and headset
To switch the call between the headset and a compatible Nokia phone,
press and hold the answer/end key, or use the respective function in
your phone.
■Use the headset with several phones
You can pair the headset with up to eight phones but connect it to only
one phone at a time.
The phone that was first paired with the headset is the default phone. If
the headset is switched on within 10 meters (30 feet) of several paired
phones, the headset tries to connect to the default phone.
If the headset cannot connect to the default phone, the headset tries to
connect to the last used phone. If the headset cannot connect to this
phone either, one of the other six paired phones can be connected to the
headset. To make the connection, see the user guide of your phone.
HS-50W_en1_draft6.fm Page 10 Tuesday, April 4, 2006 12:15 PM
Basic use
11
■Clear the settings
If you want to clear all the settings from the headset (for example, the
list of paired devices if you cannot pair the headset with your phone),
press and hold the power key and the answer/end key over 10 seconds.
After the settings are cleared, the headset beeps twice, and the red and
green indicator lights alternate for several seconds.
HS-50W_en1_draft6.fm Page 11 Tuesday, April 4, 2006 12:15 PM
Battery information
12
4. Battery information
Your device is powered by a rechargeable battery. The full performance of a new
battery is achieved only after two or three complete charge and discharge cycles.
The battery can be charged and discharged hundreds of times, but it will
eventually wear out. Recharge your battery only with Nokia approved chargers
designated for this device.
Unplug the charger from the electrical plug and the device when not in use. Do
not leave a fully charged battery connected to a charger, since overcharging may
shorten its lifetime. If left unused, a fully charged battery will lose its charge over
time.
Never use any charger that is damaged.
Leaving the device in hot or cold places, such as in a closed car in summer or
winter conditions, will reduce the capacity and lifetime of the battery. Always try
to keep the battery between 15°C and 25°C (59°F and 77°F). A device with a hot
or cold battery may not work temporarily, even when the battery is fully charged.
Battery performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also
explode if damaged. Dispose of batteries according to local regulations. Please
recycle when possible. Do not dispose as household waste.
HS-50W_en1_draft6.fm Page 12 Tuesday, April 4, 2006 12:15 PM
Care and maintenance
13
Care and maintenance
Your device is a product of superior design and craftsmanship and should be
treated with care. The suggestions below will help you protect your warranty
coverage.
• Keep all accessories and enhancements out of the reach of small children.
• Keep the device dry. Precipitation, humidity, and all types of liquids or
moisture can contain minerals that will corrode electronic circuits. If your
device does get wet, allow it to dry completely.
• Do not use or store the device in dusty, dirty areas. Its moving parts and
electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic
circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the device. Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
All of the above suggestions apply equally to your device, battery, charger, or any
enhancement. If any device is not working properly, take it to the nearest
authorized service facility.
HS-50W_en1_draft6.fm Page 13 Tuesday, April 4, 2006 12:15 PM
FCC notice
14
FCC notice
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: 1. This device may not cause harmful
interference; and 2. This device must accept any interference received,
including interference that may cause undesired operation. This
equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures: Reorient or relocate the receiving antenna. Increase the
separation between the equipment and receiver. Connect the
equipment into an outlet on a circuit different from that to which the
receiver is connected. Consult the dealer or an experienced radio/TV
technician for help. NOTE: FCC Radiation Exposure Statement: This
equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter. NOTE:
Modifications not expressly approved by Nokia could void the user's
authority to operate the equipment.
HS-50W_en1_draft6.fm Page 14 Tuesday, April 4, 2006 12:15 PM
