GXT800 - Bill of Material Dwg.No : GXT800-BOM
Q7 BFQ67W TRANSISTOR CHIP 1
Q8 BFQ67W TRANSISTOR CHIP 1
Q10 BFQ67W TRANSISTOR CHIP 1
SPK1 DIA36 (8 ohm 0.25W) Speaker 1
C5 1PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C29 1PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C78 1.5PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C18 2PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C39 2PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C57 2PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C150 2PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C61 3.5PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C42 3PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C187C 3PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C187A 2PF (For "A" Grade 20.95MHz X-tal) CHIP CAPACITOR 0402 NPO ±0.25PF 1
C187B 3PF (For "A" or "B" Grade 20.95MHz X-tal) CHIP CAPACITOR 0402 NPO ±0.25PF 1
C62 4PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C46 5PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C79 6PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C180 6PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C49 7PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C92 7PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C51 8PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C45 9PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C77 9PF CHIP CAPACITOR 0402 NPO ±0.25PF 1
C7 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C9 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C20 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C23 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C26 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C27 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C28 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C30 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C31 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C32 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C35 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C43 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C47 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C53 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C54 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C58 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C63 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C66 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C69 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C94 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C98 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C101 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C121 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C123 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C147 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C148 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C163 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C164 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C170 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C173 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C174 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C175 100PF CHIP CAPACITOR 0402 NPO ±5% 1
Description Q'tyRef.No Items
Global Link Corporation Confidential Proprietary page1/ 10
GXT800 - Bill of Material Dwg.No : GXT800-BOM
Description Q'tyRef.No Items
C176 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C178 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C179 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C182 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C184 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C185 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C186 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C188 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C189 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C190 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C191 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C192 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C193 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C194 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C196 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C314 100PF CHIP CAPACITOR 0402 NPO ±5% 1
C52 10PF CHIP CAPACITOR 0402 NPO ±5% 1
C60 10PF CHIP CAPACITOR 0402 NPO ±5% 1
C93 10PF CHIP CAPACITOR 0402 NPO ±5% 1
C41 12PF CHIP CAPACITOR 0402 NPO ±5% 1
C68 150PF CHIP CAPACITOR 0402 NPO ±5% 1
C187 150PF CHIP CAPACITOR 0402 NPO ±5% 1
C55 15PF CHIP CAPACITOR 0402 NPO ±5% 1
C64 15PF CHIP CAPACITOR 0402 NPO ±5% 1
C59 18PF CHIP CAPACITOR 0402 NPO ±5% 1
C80 18PF CHIP CAPACITOR 0402 NPO ±5% 1
C13 22PF CHIP CAPACITOR 0402 NPO ±5% 1
C15 22PF CHIP CAPACITOR 0402 NPO ±5% 1
C21 22PF CHIP CAPACITOR 0402 NPO ±5% 1
C76 22PF CHIP CAPACITOR 0402 NPO ±5% 1
C140 22PF CHIP CAPACITOR 0402 NPO ±5% 1
C6 27PF CHIP CAPACITOR 0402 NPO ±5% 1
C12 33PF CHIP CAPACITOR 0402 NPO ±5% 1
C75 33PF CHIP CAPACITOR 0402 NPO ±5% 1
C128 33PF CHIP CAPACITOR 0402 NPO ±5% 1
C158 33PF CHIP CAPACITOR 0402 NPO ±5% 1
C159 33PF CHIP CAPACITOR 0402 NPO ±5% 1
C171 33PF CHIP CAPACITOR 0402 NPO ±5% 1
C11 39PF CHIP CAPACITOR 0402 NPO ±5% 1
C56 39PF CHIP CAPACITOR 0402 NPO ±5% 1
C50 56PF CHIP CAPACITOR 0402 NPO ±5% 1
C115 0.22UF CHIP CAPACITOR 0402 X5R ±10% 1
C149 0.22UF CHIP CAPACITOR 0402 X5R ±10% 1
C141 0.0012UF CHIP CAPACITOR 0402 X7R ±10% 1
C119 0.0015UF CHIP CAPACITOR 0402 X7R ±10% 1
C14 0.001UF CHIP CAPACITOR 0402 X7R ±10% 1
C17 0.001UF CHIP CAPACITOR 0402 X7R ±10% 1
C73 0.001UF CHIP CAPACITOR 0402 X7R ±10% 1
C74 0.001UF CHIP CAPACITOR 0402 X7R ±10% 1
C161 0.001UF CHIP CAPACITOR 0402 X7R ±10% 1
C169 0.001UF CHIP CAPACITOR 0402 X7R ±10% 1
C133 0.0022UF CHIP CAPACITOR 0402 X7R ±10% 1
C143 0.0022UF CHIP CAPACITOR 0402 X7R ±10% 1
C152 0.0022UF CHIP CAPACITOR 0402 X7R ±10% 1
C197 0.0022UF CHIP CAPACITOR 0402 X7R ±10% 1
C139 0.0033UF CHIP CAPACITOR 0402 X7R ±10% 1
C134 0.0039UF CHIP CAPACITOR 0402 X7R ±10% 1
Global Link Corporation Confidential Proprietary page2/ 10
GXT800 - Bill of Material Dwg.No : GXT800-BOM
Description Q'tyRef.No Items
C200 0.0047UF CHIP CAPACITOR 0402 X7R ±10% 1
C206 0.0056UF CHIP CAPACITOR 0402 X7R ±10% 1
C129 0.0082UF CHIP CAPACITOR 0402 X7R ±10% 1
C204 0.0082UF CHIP CAPACITOR 0402 X7R ±10% 1
C99 0.015UF CHIP CAPACITOR 0402 X7R ±10% 1
C130 0.015UF CHIP CAPACITOR 0402 X7R ±10% 1
C131 0.018UF CHIP CAPACITOR 0402 X7R ±10% 1
C137 0.018UF CHIP CAPACITOR 0402 X7R ±10% 1
C138 0.018UF CHIP CAPACITOR 0402 X7R ±10% 1
C19 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C22 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C24 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C36 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C44 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C67 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C90 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C95 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C100 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C195 0.01UF CHIP CAPACITOR 0402 X7R ±10% 1
C120 0.022UF CHIP CAPACITOR 0402 X7R ±10% 1
C153A 0.022UF CHIP CAPACITOR 0402 X7R ±10% 1
C205 0.022UF CHIP CAPACITOR 0402 X7R ±10% 1
C109 0.033UF CHIP CAPACITOR 0402 X7R ±10% 1
C157 0.033UF CHIP CAPACITOR 0402 X7R ±10% 1
C124 0.082UF CHIP CAPACITOR 0402 X7R ±10% 1
C8 270PF CHIP CAPACITOR 0402 X7R ±10% 1
C135 390PF CHIP CAPACITOR 0402 X7R ±10% 1
C65 470PF CHIP CAPACITOR 0402 X7R ±10% 1
C117 470PF CHIP CAPACITOR 0402 X7R ±10% 1
C118 470PF CHIP CAPACITOR 0402 X7R ±10% 1
C114 560PF CHIP CAPACITOR 0402 X7R ±10% 1
C10 0.1UF CHIP CAPACITOR 0402 Y5V 1
C48 0.1UF CHIP CAPACITOR 0402 Y5V 1
C81 0.1UF CHIP CAPACITOR 0402 Y5V 1
C87 0.1UF CHIP CAPACITOR 0402 Y5V 1
C88 0.1UF CHIP CAPACITOR 0402 Y5V 1
C97 0.1UF CHIP CAPACITOR 0402 Y5V 1
C102 0.1UF CHIP CAPACITOR 0402 Y5V 1
C103 0.1UF CHIP CAPACITOR 0402 Y5V 1
C104 0.1UF CHIP CAPACITOR 0402 Y5V 1
C105 0.1UF CHIP CAPACITOR 0402 Y5V 1
C106 0.1UF CHIP CAPACITOR 0402 Y5V 1
C108 0.1UF CHIP CAPACITOR 0402 Y5V 1
C110 0.1UF CHIP CAPACITOR 0402 Y5V 1
C111 0.1UF CHIP CAPACITOR 0402 Y5V 1
C112 0.1UF CHIP CAPACITOR 0402 Y5V 1
C113 0.1UF CHIP CAPACITOR 0402 Y5V 1
C116 0.1UF CHIP CAPACITOR 0402 Y5V 1
C122 0.1UF CHIP CAPACITOR 0402 Y5V 1
C126 0.1UF CHIP CAPACITOR 0402 Y5V 1
C132 0.1UF CHIP CAPACITOR 0402 Y5V 1
C136 0.1UF CHIP CAPACITOR 0402 Y5V 1
C142 0.1UF CHIP CAPACITOR 0402 Y5V 1
C145 0.1UF CHIP CAPACITOR 0402 Y5V 1
C153 0.1UF CHIP CAPACITOR 0402 Y5V 1
C154 0.1UF CHIP CAPACITOR 0402 Y5V 1
C167 0.1UF CHIP CAPACITOR 0402 Y5V 1
Global Link Corporation Confidential Proprietary page3/ 10
GXT800 - Bill of Material Dwg.No : GXT800-BOM
Description Q'tyRef.No Items
C172 0.1UF CHIP CAPACITOR 0402 Y5V 1
C177 0.1UF CHIP CAPACITOR 0402 Y5V 1
C202 0.1UF CHIP CAPACITOR 0402 Y5V 1
C208 0.1UF CHIP CAPACITOR 0402 Y5V 1
C311 0.1UF CHIP CAPACITOR 0402 Y5V 1
C1 2PF(03) CHIP CAPACITOR 0603 NPO ±0.25PF 1
C3 4PF(03) CHIP CAPACITOR 0603 NPO ±0.25PF 1
C2 5PF(03) CHIP CAPACITOR 0603 NPO ±0.25PF 1
C34 8PF(03) CHIP CAPACITOR 0603 NPO ±0.25PF 1
C4 100PF(03) CHIP CAPACITOR 0603 NPO ±5% 1
C33 12PF(03) CHIP CAPACITOR 0603 NPO ±5% 1
C37 1UF CHIP CAPACITOR 0603 Y5V 1
C40 1UF CHIP CAPACITOR 0603 Y5V 1
C72 1UF CHIP CAPACITOR 0603 Y5V 1
C83 1UF CHIP CAPACITOR 0603 Y5V 1
C84 1UF CHIP CAPACITOR 0603 Y5V 1
C85 1UF CHIP CAPACITOR 0603 Y5V 1
C86 1UF CHIP CAPACITOR 0603 Y5V 1
C89 1UF CHIP CAPACITOR 0603 Y5V 1
C96 1UF CHIP CAPACITOR 0603 Y5V 1
C144 1UF CHIP CAPACITOR 0603 Y5V 1
C155 1UF CHIP CAPACITOR 0603 Y5V 1
C156 1UF CHIP CAPACITOR 0603 Y5V 1
C181 1UF CHIP CAPACITOR 0603 Y5V 1
L25 100NH INDUCTOR CHIP 100NH 1005 1
L4 27NH INDUCTOR CHIP 27NH 1005 1
L8 33NH INDUCTOR CHIP 33NH 1005 1
L5 47NH INDUCTOR CHIP 47NH 1005 1
L9 47NH INDUCTOR CHIP 47NH 1005 1
L20 5.6NH INDUCTOR CHIP 5.6NH 1005 1
L21 5.6NH INDUCTOR CHIP 5.6NH 1005 1
L22 5.6NH INDUCTOR CHIP 5.6NH 1005 1
R57 Thermistor 100 NCP18XF101J03RB 1
R173 Thermistor 10K NCP18XH103J03RB 1
IC4 AT24C02BN-10SU-1.8, 8Pin SOIC IC EEPROM 1
IC3 AZ358MTR-E1 IC LINEAR OP AMP 1
PCB1 PCB GXT800 PCB Ver.ACA / 4 layer 1
L6 270NH(03) INDUCTOR CHIP 270NH 1608 1
L24 56NH(03) INDUCTOR CHIP 56NH 1608 5% 1
L17 0.3*1.0*3T R Inductor Air 1
L23 0.3*1.3*3T R Inductor Air 1
L3 0.3*1.4*6T R Inductor Air 1
L1 0.35*1.7*5T R Inductor Air 1
L2 0.35*1.7*5T R Inductor Air 1
L15 0.4*1.1*2T R Inductor Air 1
L16 0.4*1.5*5T L Inductor Air 1
ZD1 6.8V ZENER DIODE ZMM6.8V 0.5W SMD Type 1
SF1 SAW Filter 465MHz SAW FILTER (12F-465BS) 1
CF1 FT21M07B X-tal filter 21.4MHz +/-3.75KHz UM5 1
Q5 NE5510279A FET PA NE5510279A 1
IC1 JT5BU8-XXXX / Flash No. - JT5BL9 IC CPU 1
CT1 10PF (Trimmer) 3 dia STC3M10-T1 1
Q1 2SC4226 ( R25 ) TRANSISTOR CHIP 1
Q3 2SC4226 ( R25 ) TRANSISTOR CHIP 1
Q11 2SC4226 ( R25 ) TRANSISTOR CHIP 1
Q12 2SC4226 ( R25 ) TRANSISTOR CHIP 1
Q24 2SC4226 ( R25 ) TRANSISTOR CHIP 1
Global Link Corporation Confidential Proprietary page4/ 10
GXT800 - Bill of Material Dwg.No : GXT800-BOM
Description Q'tyRef.No Items
LED1 12-21SYGC/TR8 Chip LED 1
MIC1 F9745AP342-34 Condensor Mic 1
D1 KDS114E Chip Diode Switching 1
D2 KDS114E Chip Diode Switching 1
D6 KDS114E Chip Diode Switching 1
D8 KDS114E Chip Diode Switching 1
D9 KDS114E Chip Diode Switching 1
D7 KDS121 Chip Diode Switching 1
D5 KDV154B Chip Diode Vari-cap 1
D3 KDV358-TRK/P Chip Diode Vari-cap 1
D4 KDV358-TRK/P Chip Diode Vari-cap 1
Q13 KRA306E CHIP TRANSISTOR BRT 1
Q15 KRA306E CHIP TRANSISTOR BRT 1
Q17 KRA306E CHIP TRANSISTOR BRT 1
Q19 KRA306E CHIP TRANSISTOR BRT 1
Q25 KRA306E CHIP TRANSISTOR BRT 1
Q21 KRC246S CHIP TRANSISTOR BRT 1
Q18 KRC401E CHIP TRANSISTOR BRT 1
Q22 KRC404E CHIP TRANSISTOR BRT 1
Q201 KRC404E CHIP TRANSISTOR BRT 1
Q6 KRC405E CHIP TRANSISTOR BRT 1
Q9 KRC405E CHIP TRANSISTOR BRT 1
Q20 KRC405E CHIP TRANSISTOR BRT 1
Q16 KTC4075E CHIP TRANSISTOR BRT 1
Q23 KTC4075E CHIP TRANSISTOR BRT 1
Q26 KTC4075E CHIP TRANSISTOR BRT 1
Q27 KTC4075E CHIP TRANSISTOR BRT 1
J2 EXT MIC EXT MIC JACK DUAL LT2510C 1
C162 10UF/10V ELECT CAPACITOR (3*5) 1
C160 22UF/6.3V ELECT CAPACITOR (3*5) 1
C146 100UF/10V ELECT CAPACITOR (5*7) 1
C198 100UF/10V ELECT CAPACITOR (5*7) 1
VR1 47K(B) 47KB Semi-fixed resistor 3dia 1
VR3 47K(B) 47KB Semi-fixed resistor 3dia 1
VR4 500 ohm (B) 500 ohm B Semi-fixed resistor 3dia 1
IC2 AN29160 IC AN29160 (One Chip) 1
R135 47K CHIP RESISTOR 0402 1% 1/16W 1
R134 68K CHIP RESISTOR 0402 1% 1/16W 1
R3 0 ohm CHIP RESISTOR 0402 5% 1/16W 1
R103 0 ohm CHIP RESISTOR 0402 5% 1/16W 1
R160 0 ohm CHIP RESISTOR 0402 5% 1/16W 1
R163 0 ohm CHIP RESISTOR 0402 5% 1/16W 1
R38 1.2K CHIP RESISTOR 0402 5% 1/16W 1
R98 1.2K CHIP RESISTOR 0402 5% 1/16W 1
R146 1.2K CHIP RESISTOR 0402 5% 1/16W 1
R105 1.5M CHIP RESISTOR 0402 5% 1/16W 1
R11 1.8K CHIP RESISTOR 0402 5% 1/16W 1
R59 1.8K CHIP RESISTOR 0402 5% 1/16W 1
R111 1.8K CHIP RESISTOR 0402 5% 1/16W 1
R148 1.8K CHIP RESISTOR 0402 5% 1/16W 1
R26 10 ohm CHIP RESISTOR 0402 5% 1/16W 1
R14 100 ohm CHIP RESISTOR 0402 5% 1/16W 1
R37 100 ohm CHIP RESISTOR 0402 5% 1/16W 1
R42 100 ohm CHIP RESISTOR 0402 5% 1/16W 1
R54 100 ohm CHIP RESISTOR 0402 5% 1/16W 1
R72 100 ohm CHIP RESISTOR 0402 5% 1/16W 1
R126 100 ohm CHIP RESISTOR 0402 5% 1/16W 1
Global Link Corporation Confidential Proprietary page5/ 10
GXT800 - Bill of Material Dwg.No : GXT800-BOM
Description Q'tyRef.No Items
R127 100 ohm CHIP RESISTOR 0402 5% 1/16W 1
R152 100 ohm CHIP RESISTOR 0402 5% 1/16W 1
R56 100K CHIP RESISTOR 0402 5% 1/16W 1
R58 100K CHIP RESISTOR 0402 5% 1/16W 1
R79 100K CHIP RESISTOR 0402 5% 1/16W 1
R88 100K CHIP RESISTOR 0402 5% 1/16W 1
R89 100K CHIP RESISTOR 0402 5% 1/16W 1
R93 100K CHIP RESISTOR 0402 5% 1/16W 1
R100 100K CHIP RESISTOR 0402 5% 1/16W 1
R115 100K CHIP RESISTOR 0402 5% 1/16W 1
R129 100K CHIP RESISTOR 0402 5% 1/16W 1
R138 100K CHIP RESISTOR 0402 5% 1/16W 1
R153 100K CHIP RESISTOR 0402 5% 1/16W 1
R154 100K CHIP RESISTOR 0402 5% 1/16W 1
R155 100K CHIP RESISTOR 0402 5% 1/16W 1
R156 100K CHIP RESISTOR 0402 5% 1/16W 1
R157 100K CHIP RESISTOR 0402 5% 1/16W 1
R167 100K CHIP RESISTOR 0402 5% 1/16W 1
R170 100K CHIP RESISTOR 0402 5% 1/16W 1
R175 100K CHIP RESISTOR 0402 5% 1/16W 1
R176 100K CHIP RESISTOR 0402 5% 1/16W 1
R177 100K CHIP RESISTOR 0402 5% 1/16W 1
R47 10K CHIP RESISTOR 0402 5% 1/16W 1
R50 10K CHIP RESISTOR 0402 5% 1/16W 1
R95 10K CHIP RESISTOR 0402 5% 1/16W 1
R101 10K CHIP RESISTOR 0402 5% 1/16W 1
R112 10K CHIP RESISTOR 0402 5% 1/16W 1
R136 10K CHIP RESISTOR 0402 5% 1/16W 1
R149 10K CHIP RESISTOR 0402 5% 1/16W 1
R150 10K CHIP RESISTOR 0402 5% 1/16W 1
R173A 10K CHIP RESISTOR 0402 5% 1/16W 1
R71 120K CHIP RESISTOR 0402 5% 1/16W 1
R116 120K CHIP RESISTOR 0402 5% 1/16W 1
R2 15 ohm CHIP RESISTOR 0402 5% 1/16W 1
R147 150 ohm CHIP RESISTOR 0402 5% 1/16W 1
R91 150K CHIP RESISTOR 0402 5% 1/16W 1
R169 150K CHIP RESISTOR 0402 5% 1/16W 1
R27 15K CHIP RESISTOR 0402 5% 1/16W 1
R75 15K CHIP RESISTOR 0402 5% 1/16W 1
R81 15K CHIP RESISTOR 0402 5% 1/16W 1
R113 15K CHIP RESISTOR 0402 5% 1/16W 1
R108 180K CHIP RESISTOR 0402 5% 1/16W 1
R61 18K CHIP RESISTOR 0402 5% 1/16W 1
R128 18K CHIP RESISTOR 0402 5% 1/16W 1
R131 18K CHIP RESISTOR 0402 5% 1/16W 1
R7 1K CHIP RESISTOR 0402 5% 1/16W 1
R70 1K CHIP RESISTOR 0402 5% 1/16W 1
R301 1K CHIP RESISTOR 0402 5% 1/16W 1
R12 1M CHIP RESISTOR 0402 5% 1/16W 1
R110 1M CHIP RESISTOR 0402 5% 1/16W 1
R118 1M CHIP RESISTOR 0402 5% 1/16W 1
R139 1M CHIP RESISTOR 0402 5% 1/16W 1
R180 1M CHIP RESISTOR 0402 5% 1/16W 1
R13 2.2K CHIP RESISTOR 0402 5% 1/16W 1
R44 2.2K CHIP RESISTOR 0402 5% 1/16W 1
R109 2.2K CHIP RESISTOR 0402 5% 1/16W 1
R145 2.2K CHIP RESISTOR 0402 5% 1/16W 1
Global Link Corporation Confidential Proprietary page6/ 10
GXT800 - Bill of Material Dwg.No : GXT800-BOM
Description Q'tyRef.No Items
R94 2.2M CHIP RESISTOR 0402 5% 1/16W 1
R17 2.7K CHIP RESISTOR 0402 5% 1/16W 1
R22 2.7K CHIP RESISTOR 0402 5% 1/16W 1
R82 2.7K CHIP RESISTOR 0402 5% 1/16W 1
R29 22 ohm CHIP RESISTOR 0402 5% 1/16W 1
R5 220 ohm CHIP RESISTOR 0402 5% 1/16W 1
R10 220 ohm CHIP RESISTOR 0402 5% 1/16W 1
R15 220 ohm CHIP RESISTOR 0402 5% 1/16W 1
R28 220 ohm CHIP RESISTOR 0402 5% 1/16W 1
R30 220 ohm CHIP RESISTOR 0402 5% 1/16W 1
R31 220 ohm CHIP RESISTOR 0402 5% 1/16W 1
R45 220 ohm CHIP RESISTOR 0402 5% 1/16W 1
R66 220K CHIP RESISTOR 0402 5% 1/16W 1
R77 220K CHIP RESISTOR 0402 5% 1/16W 1
R151 220K CHIP RESISTOR 0402 5% 1/16W 1
R171 220K CHIP RESISTOR 0402 5% 1/16W 1
R184 220K CHIP RESISTOR 0402 5% 1/16W 1
R125 22K CHIP RESISTOR 0402 5% 1/16W 1
R142 22K CHIP RESISTOR 0402 5% 1/16W 1
R166 22K CHIP RESISTOR 0402 5% 1/16W 1
R53 270K CHIP RESISTOR 0402 5% 1/16W 1
R92 270K CHIP RESISTOR 0402 5% 1/16W 1
R34 27K CHIP RESISTOR 0402 5% 1/16W 1
R87 27K CHIP RESISTOR 0402 5% 1/16W 1
R121 27K CHIP RESISTOR 0402 5% 1/16W 1
R120 3 K CHIP RESISTOR 0402 5% 1/16W 1
R36 3.3K CHIP RESISTOR 0402 5% 1/16W 1
R46 3.3K CHIP RESISTOR 0402 5% 1/16W 1
R68 3.3K CHIP RESISTOR 0402 5% 1/16W 1
R60 3.9K CHIP RESISTOR 0402 5% 1/16W 1
R106 3.9K CHIP RESISTOR 0402 5% 1/16W 1
R9 330K CHIP RESISTOR 0402 5% 1/16W 1
R74 330K CHIP RESISTOR 0402 5% 1/16W 1
R80 330K CHIP RESISTOR 0402 5% 1/16W 1
R40 33K CHIP RESISTOR 0402 5% 1/16W 1
R76 33K CHIP RESISTOR 0402 5% 1/16W 1
R97 33K CHIP RESISTOR 0402 5% 1/16W 1
R137 33K CHIP RESISTOR 0402 5% 1/16W 1
R20 390 ohm CHIP RESISTOR 0402 5% 1/16W 1
R86 390K CHIP RESISTOR 0402 5% 1/16W 1
R107 39K CHIP RESISTOR 0402 5% 1/16W 1
R132 39K CHIP RESISTOR 0402 5% 1/16W 1
R55 4.7K CHIP RESISTOR 0402 5% 1/16W 1
R69 4.7K CHIP RESISTOR 0402 5% 1/16W 1
R178 4.7K CHIP RESISTOR 0402 5% 1/16W 1
R32 47 ohm CHIP RESISTOR 0402 5% 1/16W 1
R33 47 ohm CHIP RESISTOR 0402 5% 1/16W 1
R4 470K CHIP RESISTOR 0402 5% 1/16W 1
R143 470K CHIP RESISTOR 0402 5% 1/16W 1
R144 470K CHIP RESISTOR 0402 5% 1/16W 1
R321 470K CHIP RESISTOR 0402 5% 1/16W 1
R41 47K CHIP RESISTOR 0402 5% 1/16W 1
R48 47K CHIP RESISTOR 0402 5% 1/16W 1
R49 47K CHIP RESISTOR 0402 5% 1/16W 1
R64 47K CHIP RESISTOR 0402 5% 1/16W 1
R65 47K CHIP RESISTOR 0402 5% 1/16W 1
R83 47K CHIP RESISTOR 0402 5% 1/16W 1
Global Link Corporation Confidential Proprietary page7/ 10
GXT800 - Bill of Material Dwg.No : GXT800-BOM
Description Q'tyRef.No Items
R84 47K CHIP RESISTOR 0402 5% 1/16W 1
R114 47K CHIP RESISTOR 0402 5% 1/16W 1
R117 47K CHIP RESISTOR 0402 5% 1/16W 1
R119 47K CHIP RESISTOR 0402 5% 1/16W 1
R123 47K CHIP RESISTOR 0402 5% 1/16W 1
R140 47K CHIP RESISTOR 0402 5% 1/16W 1
R141 47K CHIP RESISTOR 0402 5% 1/16W 1
R165 47K CHIP RESISTOR 0402 5% 1/16W 1
R172 47K CHIP RESISTOR 0402 5% 1/16W 1
R181 47K CHIP RESISTOR 0402 5% 1/16W 1
R317 47K CHIP RESISTOR 0402 5% 1/16W 1
R319 47K CHIP RESISTOR 0402 5% 1/16W 1
R320 47K CHIP RESISTOR 0402 5% 1/16W 1
R8 5.6 ohm CHIP RESISTOR 0402 5% 1/16W 1
R35 5.6 ohm CHIP RESISTOR 0402 5% 1/16W 1
R23 5.6K CHIP RESISTOR 0402 5% 1/16W 1
R39 5.6K CHIP RESISTOR 0402 5% 1/16W 1
R62 5.6K CHIP RESISTOR 0402 5% 1/16W 1
R73 5.6K CHIP RESISTOR 0402 5% 1/16W 1
R43 56 ohm CHIP RESISTOR 0402 5% 1/16W 1
R16 560 ohm CHIP RESISTOR 0402 5% 1/16W 1
R90 560K CHIP RESISTOR 0402 5% 1/16W 1
R124 560K CHIP RESISTOR 0402 5% 1/16W 1
R1 56K CHIP RESISTOR 0402 5% 1/16W 1
R96 56K CHIP RESISTOR 0402 5% 1/16W 1
R122 56K CHIP RESISTOR 0402 5% 1/16W 1
R133 56K CHIP RESISTOR 0402 5% 1/16W 1
R78 6.8K CHIP RESISTOR 0402 5% 1/16W 1
R6 680 ohm CHIP RESISTOR 0402 5% 1/16W 1
R63 680K CHIP RESISTOR 0402 5% 1/16W 1
R168 680K CHIP RESISTOR 0402 5% 1/16W 1
R130 8.2K CHIP RESISTOR 0402 5% 1/16W 1
R104 82K CHIP RESISTOR 0402 5% 1/16W 1
R18 1K (03) CHIP RESISTOR 0603 5% 1/16W 1
R21 2.2 ohm (03) CHIP RESISTOR 0603 5% 1/16W 1
R19 750 ohm (03) CHIP RESISTOR 0603 5% 1/16W 1
VIB1 VIBRATION MOTOR VIBRATION MOTOR: OTL-6SL ( 3V ) 1
VR2 F-09115S-19 Volume Switch 1
Q2 2SC4083 CHIP TRANSISTOR 1
Q4 2SC4083 CHIP TRANSISTOR 1
Q14 2SC4083 CHIP TRANSISTOR 1
LCD1 LCD (GXT800) 16pin LCD 1
L27 0.33UH(03) INDUCTOR CHIP 0.33UH 1608 1
L26 1.2UH(03) INDUCTOR CHIP 1.2UH 1608 1
L10 1.8UH(05) INDUCTOR CHIP 1.8UH 2012 1
L18 18NH(03) INDUCTOR CHIP 18NH 1608 5% 1
L19 18NH(03) INDUCTOR CHIP 18NH 1608 5% 1
L7 2.7UH(03) INDUCTOR CHIP 2.7UH 1608 1
L11 5.6UH(05) INDUCTOR CHIP 5.6UH 2012 1
CF3 LTM450HTU Ceramic filter 1
CF2 CDB450C3-L DIP DISCRIMINATOR 450KHz 1
Wire1 Lead Wire Blk 2-50-2 AWG#30/1571 1
Wire2 Lead Wire Red 2-50-2 AWG#30/1571 1
X2 4 MHz X-tal R49SDA-004000-FA-16-30A 1
X1 20.95MHZ X-tal R49SDA-020950-FA-16, HC-49/S, 15PPM 1
Mechanical parts for GXT800
Global Link Corporation Confidential Proprietary page8/ 10
GXT800 - Bill of Material Dwg.No : GXT800-BOM
Description Q'tyRef.No Items
φ1.5 E-ring 1
GXT300-022 SPCC Shaft (Pin) for belt Clip 1
SPTE, 0.2t Shield Plate 1
GXT300-021 SUS 304, φ1.0 Spring for belt clip 1
G223-017 SPTE, 0.2t VCO can 1
Bonso no. 0098-100631-000 EVA Sponge 1.5Diax1.5T on Speaker 2
Screw (2.6 x 8) Screw 5
Screw (2.6 x 8) SUS Natural Screw 1
GXT800-034 PORON t2.0(SR-S-32P)+Nitto #500 MIC CUSHION 1
Antenna Coil (GXT800) 1
GXT800-009 Urethane Antenna Housing (GXT800) 1
GXT300-012 SK-5 D-spring 1
G4-003 1 Point, 8.0 x 8.0 with Dia 5.0 dome. Metal Dome 1
GXT800-M007 Wood Free Paper Manual (GXT800) 0.5
G223-028 PP, 200 x 150 x 0.05t Ploy Bag 0.5
GXT800-018 SUS 304, 0.3t BRACKET PTT 1
GXT800-017 SUS 304, 0.3t BRACKET SPK/MIC JACK 1
GXT800-021 SPTE, 0.3t LCD bracket (GXT800) 1
GXT800-024 SUS 304, DIA 1.0 x L 21.7 PIN LOCKER 1
GXT800-022 SUS 304 0.3t (1H) Terminal -F 1
GXT800-023 SUS 304 0.3t (1H) Terminal -G 1
GXT800-019 SUS 304, 1H, 0.2t Terminal-A 1
7N-013 SUS 304, 1H, 0.2t Terminal-B 1
GXT800-020 SUS 304, 1H, 0.2t Terminal-C 1
GXT800-025 BsBM Terminal-Chage 2
7N-015 SUS 304, 1H, 0.2t Terminal-D (Dual) 1
7N-016 NICO SUS 304 (φ0.8) Terminal-E 1
GXT800-002 ABS Back Cover (GXT800) 1
GXT800-007 Acryl Back Light Lens (GXT800) 1
GXT800-003 ABS Battery Cover (GXT800) 1
GXT800-008 ABS, Battery HOUSING 1
GXT300-019 PC Belt Clip 1
GXT800-001 ABS, 1 spray(SLATE), 1silk (black) Front Cover (GXT800) 1
GXT300-020 PC Hinge for belt clip 1
GXT800-005 Acryl LCD window (GXT800) 1
GXT800-004 PC LOCKER KNOB (GXT800) 1
GXT800-006 ABS Volume Knob (GXT800) 1
450-023 VOLUME NUT BsBM (Ni PLATE) 1
FW13-029 Cushion, Battery EVA 0.7t w/double side tape(ANT' COIL) 1
GXT800-026 PE, white, 0.1t (38.55 x 23.2) Reflective Sheet (GXT800) 1
GXT800-030 Felt, 0.1t, Black Felt(GXT800) 1
GXT800-010 Silicone FUNCTION BUTTON (GXT800) 1
GXT800-014 Silicone GASKET ANTENNA 1
GXT800-015 Silicone GASKET BATTERY COVER 1
GXT800-012 Silicone GASKET SPK/MIC JACK 1
GXT800-011 Silicone HEADSET JACK CAP 1
GXT800-013 Silicone PTT button (GXT800) 1
450-020 GASKET VOLUME Silicone Rubber / Pantone 164C(RED) 1
LXT420-059 EVA Sponge for VCO van EVA 4.0t, 8x8 w/double side tape, Black 1
Stranded Wire AWG#22 52mm BATT WIRE 1
GXT500-016 Zebra 14.7 x 3.8 x 1.0t Zebra (GXT500) 1
GXT800-033 Waterproof Cloth + 3M #AD163(t0.2) GASKET MIC 1
GXT800-028 PC t0.3 BLACK + NITTO #500 GASKET SHEET "A" 2
GXT800-029 PC t0.3 BLACK + NITTO #500 GASKET SHEET "B" 2
GXT800-031 DIA1.2 x L 295mm(SILICONE) GASKET TUBE 1
Polybag270 400 Polybag PE 270 x 400 x 0.05t Ploy Bag (for clamshell) 0.5
GXT800-032 3M, #4187 clear Pop Label (GXT800) 1
Global Link Corporation Confidential Proprietary page9/ 10
GXT800 - Bill of Material Dwg.No : GXT800-BOM
Description Q'tyRef.No Items
GXT800-031 Polyester, 0.1t Product Label (GXT800) 1
GXT800-027 Nitto, No 5713 (t0.33) Tape LCD window 1
Art Paper with sticker Warrenty Sticker 0.5
LETTER W/MIDLAND BOX TAPE 1
Accessory card (Midland USA) 0.5
GXT300-029 Hi Power instruction 1
Sensormatic Consigend parts 0.5
GXT800-092 Wood Free Paper, 0.4t Card Board (GXT800) 0.5
GXT800-040 DW Out Carton (GXT800) 0.125
GXT800-031 Polyester, 0.1t Product Label (GXT800) 1
GXT500-041 SW Partition Pad (GXT500) 0.125
Art Paper with sticker H2O Label 0.5
GXT300-026 PVC, 0.5t Clam Shell Back 0.5
GXT800-090 PVC, 0.5t Clam Shell Front (GXT800) 0.5
Global Link Corporation Confidential Proprietary page10/ 10
