Midland Radio LXT560PA GMRS / FRS User Manual LXT560 Owner s Manual Front Rev A Layout 1
Midland Radio Corporation GMRS / FRS LXT560 Owner s Manual Front Rev A Layout 1
Contents
- 1. User Manual
- 2. LXT560-Owners-Manual
User Manual
Welcome to the world of Midland electronics
Congratulations on your purchase of a high quality MIDLAND
product. Your 2-way radio represents state-of-the-art high-tech
engineering. Designed for GMRS (General Mobile Radio Service)
operation, this compact package is big on performance. It is a
quality piece of electronic equipment, skillfully constructed with the
finest components. The circuitry is all solid-state and mounted on a
rugged printed circuit board. Your two-way radio is designed for
reliable and trouble-free performance for years to come.
Features
- 36 GMRS/FRS Channels
- 121 Privacy Codes (38 CTCSS / 83 DCS)
- VOX
- Selectable Call Alert
- NOAA Weather Scan
- NOAA Weather Radio
- NOAA Weather Alert
- Scan Function
- Monitor Function
- Roger Beep Tone
- Silent Operation
- Key Pad Lock
- High / Low Power Settings
- Speaker / Microphone Jacks
- Battery Meter / Battery Low Indicator
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device does not cause
harmful interference, and (2) this radio must accept any interference
that may cause undesired operation.
To maintain compliance with FCC’s RF exposure guidelines, for
body-worn operation, this radio has been tested and meets the FCC RF
exposure guidelines when used with Midland Radio Corp. accessories
supplied or designated for this product. Use of other accessories may
not ensure compliance with FCC RF exposure guidelines.
IMPORTANT NOTICE, FCC LICENSE REQUIRED FOR GMRS OPERATION
(Only Applicable for GMRS Radio Use in the United States)
The radios operate on GMRS (General Mobile Radio Service) frequencies which
require an FCC (Federal Communications Commission) license. You must be
licensed prior to operating on channels 1 - 7 or 15 - 22, which comprise the
GMRS channels of the radios. Serious penalties could result from unlicensed use
of GMRS channels, in violation of FCC rules, as stipulated in the
Communications Acts Sections 501 and 502 (amended).
You will be issued a call sign by the FCC which should be used for station
identification when operating the radio on GMRS channels. You should also
cooperate by engaging in permissible transmissions only, avoiding channel
interference with other GMRS users, and being prudent with the length of your
transmission time.
To obtain a license or ask questions about the license application, contact the
FCC at 1-888-CALL FCC or go to the FCC's website:
http://www.fcc.gov and request form 605.
Exposure To Radio Frequency Energy
Your Midland radio is designed to comply with the following national and
international standards and guidelines regarding exposure of human beings to
radio frequency electromagnetic energy:
- United States Federal Communications Commission, Code of Federal
Regulations: 47 CFR part 2 sub-part J
- American National Standards Institute (ANSI)/Institute of Electrical &
Electronic Engineers (IEEE) C95. 1-1992
- Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition
- National Council on Radiation Protection and Measurements (NCRP) of the
United States, Report 86, 1986
- International Commission on Non-lonizing Radiation Protection (ICNIRP)
1998
To control your exposure and ensure compliance with the general population or
uncontrolled environment exposure limits, transmit no more than 50% of the
time. The radio generates measurable RF energy exposure only when
transmitting.
Body-Worn Operation
If you wear the radio on your body when transmitting always use Midland-
supplied or approved belt clip, holster, case, or body harness for this product.
Use of any accessories not supplied or approved by Midland may exceed
FCC/Health Canada RF exposure guidelines. If you do not use any accessories
supplied or approved by Midland, ensure the radio and its antenna are at least
1 inch (2.5cm) from your body when transmitting.
LCD DISPLAY
1. KEY LOCK ICON – Indicates KEY
LOCK mode is on.
2. VOX ICON – Indicates when VOX mode
is active.
3. NOAA WEATHER (WX) BAND ICON–
Indicates when the radio is in Weather
Band mode.
4. CHANNEL NUMBER – Changes from
1~36 on GMRS/FRS band (1~10 on WX
band).
5. PRIVACY CODE – Indicates Privacy
Code selected by user (oF~38/oF~83). It
can only be set in Ch 1~22.
6. BATTERY METER – Indicates the battery
level.
7. RECEIVE (RX) ICON – Indicates radio is
receiving a transmission.
8. TRANSMIT (TX) ICON – Indicates radio
is transmitting a signal.
9. TRANSMIT POWER LEVEL ICON –
Indicates TX Power setting (H/L).
10. PRIVACY CODE ICON – Indicates
Privacy Code setting (CTCSS/DCS).
1
CONTROLS
11. PTT Button – Press and hold to
transmit voice communication.
12. CALL/LOCK Button – Press to send a
CALL ALERT signal. Press and hold to
turn KEY LOCK on/off.
13. MIC – Built-in microphone.
14. SPEAKER – Built-in speaker.
15. ANTENNA
16. EXTERNAL SPEAKER/MIC/CHG.
JACK
17. POWER / MENU Button – Press and
hold for at least 3 seconds to turn the
radio on/off. Press momentarily to
access Menu mode.
18. MONITOR/SCAN Button – Press to
enter SCAN mode. Press and hold to
enter MONITOR mode.
19. UP/WX SCAN sand DOWN t
Buttons – Make adjustments in MENU
mode. Press and hold the UP button for
5 seconds to activate the NOAA
Weather Scan function.
18
17
16
14
13
12
11
7
6
3
2
15
19
4
5
8
9
10
BATTERY INSTALLATION
Your radio operates with either a NiMH battery pack or optional 4 AAA
alkaline batteries. The belt clip should be removed (see below) to
ease installation or removal of the batteries.
To install the batteries:
1. With the back of the radio facing you, remove the belt clip (see
diagram below) for easy access, then remove the Battery Cover by
pressing down on the top center and sliding it down from the radio.
2. Insert 4 AAA batteries observing the polarity as shown. Installing
the batteries incorrectly will prevent the unit from operating or may
damage the unit.
3. Return the Battery Cover by sliding it up on the radio. Replace the
belt clip, making sure it locks into place.
BATTERY
COMPARTMENT
BATTERY
COMPARTMENT
COVER
Press here and
push down to open
BELT CLIP
LOCK TAB
BELT CLIP
LATCH
INSTALLING THE BELT CLIP
To install the BELT CLIP, slide the clip up into the slot on the back of
the radio until the BELT CLIP LATCH clicks. To remove the BELT
CLIP, press the LOCK TAB up, then gently pull the belt clip down
toward the bottom of the radio.
MIDLAND RADIO CORPORATION
5900 Parretta Drive
Kansas City, MO 64120
Call 816.241.8500
We’d love to hear from you! Let us know what you
think of your new Midland product at
or by visiting us at
midlandusa.com
Note: Features & Specifications are subject to change without
notice. MIDLAND is not responsible for unintentional errors or
omissions on its packaging.
Your radio is equipped for using a rechargeable NiMH battery pack
which can be recharged by inserting the AC adapter into the radio
charge jack, or with optional desktop charger (as described below).
Initial charge time is 24 hours. Charge time is about 12 hours
thereafter. For maximum battery life, we recommend charging the
battery pack when the low battery icon comes on. Remove the radios
from the charger when the charge time expires.
To charge using a Desktop Charger:
1. Place the rechargeable battery packs in the radios.
2. Connect the AC adapter into an AC wall outlet.
3. Insert the AC adapter plug (or DC Cigarette Lighter adapter if
charging in vehicle) into the desktop charger jack.
4. Place the units into the desktop charger slot and note that the LED
indicator with RED color will light up, indicating charging function.
In order to ensure that the battery pack is fully charged, it is
recommended that the battery pack be charged for at least 12
hours with the radio turned OFF.
1. Only use our NiMH battery pack and AC adapter.
2. Do not attempt to charge alkaline batteries or any batteries
or battery packs other than the one indicated in the
manual. This may cause leakage and damage to the radio.
3. For long term storage of the radio, turn the radio OFF and
remove the batteries from the radio.
BATTERY LEVEL INDICATOR
Your radio has a BATTERY LEVEL METER that shows the
battery power level. The greater the number of bars visible, the
stronger the battery level. When the battery level is low, the Battery
Shell icon will flash in the display indicating your batteries
should be replaced or recharged if using a rechargeable battery pack.
CHARGING THE BATTERY PACK
!
POWER ON/OFF AND VOLUME
Press the POWER/MENU button for at least 3 seconds to turn the
radio on/off. During Power On, the radio will beep 2 times with
different tones, the LCD will display all icons for 1 second and the
LCD display will indicate the last channel selected.
To increase/decrease the volume level, press the s\tbuttons
during RX or STANDBY mode.
TRANSMITTING AND RECEIVING A CALL
To communicate, all radios in your group must be set to the same
channel and/or Privacy Code.
1. For maximum clarity, hold the radio 2 to 3 inches from your
mouth.
2. Press and hold the PTT button and speak in a normal voice
into the microphone. The TX icon will appear continuously
on the LCD display while transmitting.
3. To receive a call, release the PTT button. The RX icon will
appear on the display when your radio is receiving a transmision.
ABOUT RANGE
Your LXT Series radios are designed to give you maximum range
under optimum conditions.
Optimum Conditions are:
lOver water
lOpen rural areas without obstructions
lFlat areas where you can see the other person
To ensure you get maximum range:
lBe sure to use fresh or fully charged batteries - low batteries will
cause low power conditions.
lBe sure you are on a GMRS channel - FRS channels are
restricted by the FCC to low power.
lBe sure to set your radio to use Hi power.
OPERATING YOUR RADIO LXT560 SERIES QUICK REFERENCE CHART
MONITOR
Pressing and holding the MONITOR button for 3 seconds will let you
hear noise so you can adjust the volume level of the radio when not
receiving a signal. This could also be used to check any activity on
your current channel before transmitting.
Press and hold the MONITOR button for 3 seconds again to get out
of MONITOR mode.
SCAN
Your radio can scan all 36 channels for activity. To enter, quickly
press the SCAN button. Repeat the same procedure to exit. Your
radio will rapidly scan each of the 36 channels and stop on any active
channel for 4 seconds before resuming scan.
When you press the PTT button to transmit on an active channel, the
scanning function will stop and remain on the active channel. To
resume scanning, quickly press the SCAN button.
CALL ALERT
Your radio can transmit a call alert for a fixed length of time. To send
a call alert, press the CALL button. The TX icon will appear while
transmitting a call alert and a tone can be heard on the speaker for
confirmation.
KEYPAD LOCK
To avoid accidentally changing the radio setting, press the LOCK
button for 4 seconds. The KEY LOCK icon will appear on the display.
PTT and CALL will still be active. Repeat the same procedure to
unlock the keypad.
CHANNEL SELECTION (GMRS/FRS BAND)
Press the MENU button once, and then the s\tbuttons to select
one of the 36 GMRS/FRS channels. To confirm the selection, press
the PTT button or press the MENU button again to move to the next
feature setting.
MENU Channel VOX
1~36
Privacy
Roger Beep
On/Off
Power
H/L
Call Alert
1~5
WX Channel
1~10
Silent Operation
On/Off
oF/1/2/3
CTCSS
DCS
oF~38
oF~83
WX Alert
On/Off
WX Scan
1~10
Press and hold UP/WX
button for 5 seconds
!
SETTING PRIVACY CODES
Your radio has 121 Privacy Codes available to use in channels
1~22. You may select a different Privacy Code for each channel. To
select a Privacy Code for the current channel press the MENU
button twice, and then the s\tbuttons to select one of the 38
CTCSS Privacy Codes. Press the MENU button again and then the
s\t buttons to select one of the 83 DCS Privacy Code. The Privacy
Code icon on the display will indicate whether you set your Privacy
Code in CTCSS or DCS mode. To confirm the selection, press the
PTT button or press the MENU button again to move to the next
feature setting.
Note : If you select a CTCSS Privacy Code, any pre-selected
DCS Privacy Code will be cancelled and vice-versa.
Selecting a Privacy Code of "oF"will disable the Privacy feature.
To communicate between two radios, all radios in your group
must be set to the same channel and/or Privacy Code selections.
The Privacy Code can only be set in channels 1~22.
TRANSMIT (TX) POWER LEVEL SELECTION
Your radio has 2 power level settings. To select the power level on
channels 1~7 and 15~36, press the MENU button until a “Pr” icon will
appear blinking on the display. Then press the s\tbuttons to select
TRANSMIT POWER LEVEL icon (H: Hi/L: Lo). To confirm, press the
PTT button or press the MENU button again to move to the next
feature setting. When the PTT button is pressed during Low
Battery Level condition, the TX Power will automatically switch
from Hi(H) to Lo(L) level.
Note : You cannot adjust the power setting on the FRS
channels (8~14). They are set to Low power per FCC
regulations.
VOX
Your radio has 3 VOX level settings: (oF/1/2/3).
To set VOX, press the MENU button until the display shows “VOX”
blinking while on the right of the CHANNEL NUMBER display, an
“oF” icon appears. Select “1”,“2” or “3” by pressing the s\tbuttons
and push the PTT key, or press the MENU button again to move to
the next feature setting.
!
Rev A
VOX will be more sensitive on the “1”setting than on the “3”setting.
To turn VOX off, press the MENU button until the display shows
“VOX” blinking while on the right of the CHANNEL NUMBER display,
a “1”,“2” or “3” icon appears. Select “oF” by pressing the s\t
buttons and push the PTT key, or press the MENU button again to
move to the next feature setting.
ROGER BEEP (end of transmission) TONE
When the PTT button is released, the radio will beep to confirm to
other users that your transmission has finished.
To turn the ROGER BEEP tone on, press the MENU button until the
display shows a “rb” icon while on the right of the “rb” display, an “oF”
icon appears. Select “on” by pressing the s\tbuttons and push the
PTT key, or press the MENU button to move to the next feature
setting.
To turn the ROGER BEEP tone off, press the MENU button until the
display shows a “rb” icon while on the right of the “rb” display, an “on”
icon appears. Select “oF” by pressing the s\tbuttons and push the
PTT key, or press the MENU button to move to the next feature
setting.
CALL ALERT SELECTION
Your radio has 5 selectable CALL ALERTS.
To select, press the MENU button until a “CA” icon appears and to
the right of the “CA” icon the current CALL ALERT setting is
displayed. Then press the s\tbuttons to make the CALL ALERT
selections - the radio will emit a corresponding tone for each
selection. To confirm, press the PTT button or press the MENU
button to move to the next feature setting.
SILENT OPERATION
Your radio has a SILENT OPERATION mode. In this mode, all
“beeps” and “tones” are disabled.
To turn the SILENT OPERATION mode on, press the MENU button
until the display shows a “bP” icon while on the right of the “bP”
display, an “on” icon appears. Select “oF” by pressing the s\t
buttons and push the PTT key or MENU button.
To turn the SILENT OPERATION mode off, press the MENU button
until the display shows a “bP” icon while on the right of the “bP”
display, an “oF” icon appears. Select “on” by pressing the s\t
buttons and push the PTT key or MENU button.
NOAA WEATHER RADIO/SCAN
Your radio has a NOAA WEATHER RADIO function, to enable the
user to receive weather reports from designated NOAA stations.
Your radio also has a NOAA WEATHER SCAN function to enable the
user to scan all 10 channels of the NOAA WEATHER RADIO. To turn
the NOAA WEATHER SCAN on, press and hold the UP/WX s
button for 5 seconds while in GMRS mode. The radio will go to WX
Band mode and start scanning all 10 channels and stop on any
active channel. When the channel becomes inactive for 10 seconds
the radio will resume scanning.
To stop the NOAA WEATHER (WX) SCAN and set the channel
manually on the WX Band, press the MENU button during NOAA
WEATHER (WX) SCAN. The radio will stop scanning and the display
will show the current WX Band channel setting and the WX Band
icon. While on WX Band mode press the s\tbuttons to select one
of the 10 NOAA WEATHER (WX) BAND channels. To confirm, press
the PTT button or press the MENU button to move to the next feature
setting.
To turn the NOAA WEATHER RADIO off, press the PTT button. The
current GMRS/FRS radio setting will be displayed and the WX BAND
icon will go off.
NOAA WEATHER ALERT
Your radio has a NOAA WEATHER ALERT function, to enable you
to automatically receive weather alerts from designated NOAA
stations.
The NOAA WEATHER (WX) ALERT is automatically on during
NOAA WEATHER SCAN mode.
To turn the NOAA WEATHER (WX) ALERT on during normal NOAA
WEATHER RADIO mode, press the MENU button twice while in
NOAA WEATHER SCAN mode. The display shows "AL,"while on
the right an "oF" icon appears blinking. Select "on" by pressing the
s\t buttons.
To confirm, press the PTT button or press MENU. The radio will
return to WX BAND and the WX BAND icon will continue blinking. If
the radio receives a WX ALERT signal from a designated NOAA
station while on GMRS/FRS Radio mode, the radio will beep for 10
seconds while an "AL" and "In" icon appear on the display, after
which it will automatically go to WX BAND.
If any button is pressed during beeping while on GMRS/FRS Radio
mode, the radio will automatically go to WX BAND.
To turn the NOAA WEATHER (WX) ALERT off, press the MENU
button twice while in WX Band. The display shows "AL,"while on the
right an "on" icon appears blinking. Select "oF" by pressing the
s\t buttons. To confirm, press the PTT button or press MENU.
Note : The WX Alert is automatically ON during WX SCAN
mode.
EXTERNAL SPEAKER/MICROPHONE JACK
Your radio can be used with an optional external speaker/
microphone or headset, freeing your hands for other tasks. To use an
optional speaker/microphone or headset:
lInsert the plug(s) into the SPK/MIC jacks.
lPlace the earbud into your ear, and adjust the
mic into your desired position.
Note : You can charge a rechargeable NiMH
battery pack thru the CHG Jack.
!
PROBLEM SOLUTION
No Power - Check battery installation and/or replace batteries.
Cannot Receive
Messages
- Confirm the radios have the same channel
settings.
- Make sure that you are within range of the other
transceivers.
- Buildings and other structures may interfere with
your communication.
Radio is not responding
to button presses
- Make sure key lock is not on (See Keypad Lock).
- Radio might need to be reset. Turn radio off then
on.
Display is dim - Recharge or replace batteries.
Charger not functioning - Contacts on the bottom of the radio may require
cleaning.
- Ensure the outlet where the charger is plugged
in is functioning properly.
- Check that the battery pack is installed in the radio
properly.
USE AND CARE
1. Use a soft damp cloth to clean the radio.
2. Do not use alcohol or cleaning solutions to clean the radio.
3. Do not immerse the radio in water.
4. Dry the radio with a dry lint-free cloth should it get wet.
5. Turn off the radio and remove the batteries during long-term
storage.
If you have a problem which you believe requires
service, please call first and speak with a service
technician at 816-241-8500. Many problems can be
remedied over the phone without returning the unit for
service.
TROUBLESHOOTING GUIDE SPECIFICATIONS
Channels 36 GMRS/FRS Channels +121 Privacy Codes
10 NOAA Weather (WX) Band Channels
Operating Frequency UHF 462.5500 ~ 467.7125 MHz
Power Source 4 AAA Alkaline or 4.8V Rechargeable NiMH
battery pack
GMRS/FRS FREQUENCY CHART (MHz)
CH. No CH. Freq. CH. No CH. Freq. CH. No CH. Freq.
1462.5625
2462.5875
3462.6125
11 467.6375
4462.6375
12 467.6625
5462.6625
13 467.6875
21 462.7000
6462.6875
14 467.7125
22 462.7250
7462.7125
15 462.5500
8467.5625
16 462.5750
9467.5875
10 467.6125
17 462.6000
18 462.6250
23
24
25
26
27
28
19 462.6500
20 462.6750
29
30
31
32
33
34
35
36
NOAA WEATHER (WX) RADIO FREQUENCY CHART (MHz)
CH. No CH. Freq. CH. No CH. Freq.
1 162.550 6 162.500
2 162.400 7 162.525
3 162.475 8 161.650
4 162.425 9 161.775
5 162.450 10 163.275
PRIVACY CODES FREQUENCY CHART (Hz)
Code Freq. Code Freq. Code Freq. Code Freq. Code Freq.
1 67.0 9 91.5 17 118.8 25 156.7 33 210.7
2 71.9 10 94.8 18 123.0 26 162.2 34 218.1
3 74.4 11 97.4 19 127.3 27 167.9 35 225.7
4 77.0 12 100.0 20 131.8 28 173.8 36 233.6
5 79.7 13 103.5 21 136.5 29 179.9 37 241.8
6 82.5 14 107.2 22 141.3 30 186.2 38 250.3
7 85.4 15 110.9 23 146.2 31 192.8
8 88.5 16 114.8 24 151.4 32 203.5
* Channel 8,9 and 10 are designated Canadian Marine Frequencies
* Channels 8~14 are low-power FRS license free channels
Note: Privacy codes can be programmed for use on Channels 1~22 only
DCS PRIVACY CODE CHART
No.
CODE No. CODE No. CODE
1 023 29 174 57 445
2 025 30 205 58 464
3 026 31 223 59 465
4 031 32 226 60 466
5 032 33 243 61 503
6 043 34 244 62 506
7 047 35 245 63 516
8 051 36 251 64 532
9 054 37 261 65 546
10 065 38 263 66 565
11 071 39 265 67 606
12 072 40 271 68 612
13 073 41 306 69 624
14 074 42 311 70 627
15 114 43 315 71 631
16 115 44 331 72 632
17 116 45 343 73 654
18 125 46 346 74 662
19 131 47 351 75 664
20 132 48 364 76 703
21 134 49 365 77 712
22 143 50 371 78 723
23 152 51 411 79 731
24 155 52 412 80 732
25 156 53 413 81 734
26 162 54 423
82 743
27 165 55 431 83 754
28 172 56 432 - -
Note: Privacy codes can be programmed for use on Channels 1~22 only
LIMITED WARRANTY (United States and Canada)
Subject to the exclusions set forth below, Midland Radio Corporation will repair or
replace, at its option without charge, any Midland FRS/GMRS transceiver which fails
due to a defect in material or workmanship within Three Years following the initial
consumer purchase.
This warranty does not apply to water damage, battery leak, abuse or misuse of
unauthorized accessories, unauthorized service or modification or altered products.
Accessories have a 90 day warranty from date of purchase, including any chargers,
microphones, and cables.
This warranty does not include the cost of labor for removal or re-installation of the
product in a vehicle or other mounting.
ANY IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, SHALL BE LIMITED AS SET FORTH HEREIN AND TO THE DURATION
OF THE LIMITED WARRANTY, OTHERWISE THE REPAIR OR REPLACEMENT AS
PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL MIDLAND BE
LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING BUT NOT LIMITED TO
NEGLIGENCE, GROSS NEGLIGENCE, BODILY INJURY, PROPERTY DAMAGE
AND DEATH) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR
PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA OR OTHER
FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR
INABILITY TO USE THE PRODUCTS OR ACCESSORIES TO THE FULL EXTENT
THESE DAMAGES MAY BE DISCLAIMED BY LAW.
For Product Purchased in the USA:
Performance of any obligation under this warranty may be obtained by returning the
warranted product, prepaid freight, along with proof of purchase to:
Midland Radio Corporation
Warranty Service Department
5900 Parretta Drive
Kansas City, MO 64120
This warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
Note: The above warranty applies only to merchandise purchased in the United
States of America or any of the territories or possessions thereof, or from a U.S.
Military exchange.
For Product Purchased in Canada:
Performance of any obligation under this warranty may be obtained by returning the
warranted product, along with proof of purchase, to your place of purchase in
Canada.
This warranty gives you specified legal rights. Additional warranty rights may be
provided by law in some areas within Canada.
AVPH2
- Closed Face
Helmet
Headset Kit
AVP1
- Over the Ear
Headsets
ACCESSORIES
Accessories can be purchased at midlandusa.com.
AVPH3
- Surveillance
Headsets
AVPH5
- Behind the
Head Headsets
AVPH4
- Wrap Around
the Ear
Headsets
AVPH7
- Camo
Headsets with
Boom Mic
AVP-H8
- Acoustic Throat
Mic
TH2
- Tactical Action
Boom Mic
with PTT
AVP6
- Chargers and
Batteries
IMPORTANT: This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired
operation of the device.
IMPORTANT: Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi même si le brouillage est susceptible d'en
compromettre le fonctionnement.
IMPORTANT: Changes or modifications to this unit not expressly
approved by MIDLAND RADIO CORP. could void your right to operate
this unit. Your radio is set up to transmit a regulated signal on an assigned
frequency. It is against the law to alter or adjust the settings inside the
COMMUNICATOR to exceed those limitations. Any adjustment to your
radio must be made by qualified technicians.
FVIN Information : 8d , to verify FVIN, press button
“down key” on the dead LXT560PA and turn volume key to
turn on. Then you will see FVIN on screen for 2 sec.
