Mikrotikls SIA DYNADISHGAC Digital Transmission System User Manual
Mikrotikls SIA Digital Transmission System
User Manual
![](/img.php?id=2643302&img=bg1.png)
DynaDish series
Quick Setup Guide and Warranty Information
The Dynadish is a outdoor wireless system with a built in antenna. It can be used as a CPE or for Point to Point
links.
Connecting
1. Unscrew the Ethernet protector and connect your PC or LAN cable to the Ethernet port, connect the other
end of the Ethernet cable to a PoE injector, or a powered Switch
2. Set LAN computer IP configuration to automatic (DHCP)
3. Default IP address of the unit is 192.168.88.1, open this address in your web browser to start configuration.
The username is admin and there is no password
Powering
The device accepts powering only from Passive PoE injectors or 802.3af PoE devices.
Booting process
Initial connection has to be done via the Ethernet cable. Open 192.168.88.1 in your web browser. Username is
admin and there is no password. In case IP connection is not available, Winbox can be used to connect to the
MAC address of the device. More information here: http://wiki.mikrotik.com/wiki/First_time_startup
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of
the device when starting it until the LED light turns off, and device will start to look for Netinstall servers.
Extension Slots and Ports
One 10/100/1000 Gigabit Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X),
so you can use either straight or cross-over cables for connecting to other network devices.
One Integrated Wireless 5GHz 802.11a/n/ac, 2x2 MIMO with built in parabolic dish antenna, max gain
24dBi
Buttons and Jumpers
RouterBOOT reset button (RESET, front panel) has three functions:
•Hold this button during boot time until LED light starts flashing, release the button to reset
RouterOS configuration (total 5 seconds)
•Keep holding for 5 more seconds, LED turns solid, release now to turn on CAPs mode (total 10
seconds)
•Or Keep holding the button for 5 more seconds until until LED turns off, then release it to make the
RouterBOARD look for Netinstall servers (total 15 seconds)
Operating System Support
Currently tested operating system is MikroTik RouterOS starting from version v6.20
Copyright and Warranty information
Copyright MikroTikls SIA. This document contains information protected by copyright law. No part of it may be
reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD,
RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks
appearing in this document are the property of their respective holders.
See www.routerboard.com for more information. Contact support@mikrotik.com 30-Oct-14
![](/img.php?id=2643302&img=bg2.png)
Hardware. MikroTik warrants all RouterBOARD series equipment for the term of twelve (12) months from the
shipping date to be free of defects in materials and workmanship under normal use and service, except in case of
damage caused by mechanical, electrical or other accidental or intended damages caused by improper use or due
to wind, rain, fire or other acts of nature.
To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization)
procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA
process.
1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company
regarding all warranty and repair issues, the following instructions apply ONLY if you purchased your
equipment directly from MikroTik in Latvia.
2. MikroTik does not offer repairs for products that are not covered by warranty. Exceptions can be made for:
CCR1016-12G, CCR1016-12G-BU, CCR1036-12G-4S, RB1100, RB1100AH, RB1100AHx2, RB1200,
RB600, RB600A and RB800 as a paid service (fees apply).
3. Out-of-warranty devices and devices not covered by warranty sent to Mikrotik will be returned to the sender
at sender's cost. If the customer has not organized return of such rejected devices within 12 months from
the day of arrival, MikroTik has the right to discard them.
RMA Instructions are located on our webpage here: http://rma.mikrotik.com
This document is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to,
the implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every
effort to ensure the accuracy of the contents of this document, however, it is possible that it may contain technical
inaccuracies, typographical or other errors. No liability is assumed for any inaccuracy found in this publication, nor
for direct or indirect, incidental, consequential or other damages that may result from such an inaccuracy, including,
but not limited to, loss of data or profits. Please report any inaccuracies found to support@mikrotik.com
See www.routerboard.com for more information. Contact support@mikrotik.com 30-Oct-14
Federal Communication Commission Interference Statement
(FCC ID: TV7DYNADISHGAC)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This device and its antenna must not be co-located or operation in conjunction with any other
antenna or transmitter.
IMPORTANT: Exposure to Radio Frequency Radiation.
27 cm minimum distance has to be maintained between the antenna and the occupational user
and 60 cm to general public. Under such configuration, the FCC radiation exposure limits set
forth for an population/uncontrolled environment can be satisfied.
Antenna Installation. WARNING: It is installer's responsibility to ensure that when using
the authorized antennas in the United States (or where FCC rules apply); only those antennas
certified with the product are used. The use of any antenna other than those certified with the
product is expressly forbidden in accordance to FCC rules CFR47 part 15.204. The installer
should configure the output power level of antennas, according to country regulations and per
antenna type. Professional installation is required of equipment with connectors to ensure
compliance with health and safety issues.
Industry Canada (IC:7442A-DYNADISHGAC)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
