Mikrotikls SIA R11E5HND DIGITAL TRANSMISSION SYSTEM MODULE (5745-5825 MHz) User Manual
Mikrotikls SIA DIGITAL TRANSMISSION SYSTEM MODULE (5745-5825 MHz)
User Manual
Federal Communication Commission Interference Statement
(FCC ID: TV7R11E5HND)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT: Exposure to Radio Frequency Radiation.
The maximum permissible exposure report has been created for this module, which shows the
minimum distances for public use as 300 cm when using a 32-dBi gain antenna. Under such
configuration, the FCC radiation exposure limits set forth for a general population/uncontrolled
environment can be satisfied.
List of approved antennas:
Omni Directional, MT-482016NA, 9 dBi;
Panel, PA 58-24, 24 dBi;
Dish, HDDA 5W-32-DP2, 32 dBi ;
Antennas of same type and lower gain than those listed above may be used in compliance with
certification.
Antenna Installation. WARNING: It is installer's responsibility to ensure that when using the
authorized antennas in the United States (or where FCC rules apply); only those antennas
certified with the product are used. The use of any antenna other than those certified with the
product is expressly forbidden in accordance to FCC rules CFR47 part 15.204. The installer
should configure the output power level of antennas, according to country regulations and per
antenna type. Professional installation is required of equipment with connectors to ensure
compliance with health and safety issues.
OEM statement. This module is intended for OEM installations only. As such the OEM
integrator is responsible for ensuring that the end-user has no manual instructions to remove
install or modify the module. This module is limited to installations in mobile or fixed
applications. OEM integrators may utilize antennas of like an equal or lesser gain as appearing
in the table above (reference 47 CFR, paragraph 15.204(c)(4) for further information on this
topic. The MikroTik OEM RF Module complies with Part 15 of the FCC rules and regulations.
OEM Modules have been certified by the FCC for use with other products without any further
certification (as per FCC section 2.1091). Separate approval is required for other operating
configurations including portable configurations with respect to 47CFR paragraph 2.1093 and
different antenna configurations. The OEM is required to comply with all 47CFR labeling
instructions and requirements for the finished products. Changes or modifications not
expressly approved by MikroTik could void the OEM authority to install or operate the
equipment. OEMs must test their final product to comply with unintentional radiators (FCC
section 15.107 and 15.109) before declaring compliance of their final product to Part 15 of the
FCC Rules.
WARNING: the OEM must ensure that the FCC labeling requirements are met. This includes a
clearly visible label on the outside of the OEM enclosure specifying the appropriate MikroTik
OEM RF Module FCC identifier for this product as well as any other required FCC notices as
presented below.
Labeling and text information should be of a size of type large enough to be readily legible,
consistent with the dimensions of the equipment and the label.
WARNING: This device has been tested with a U.FL connector and antennas as listed in the
table above. When integrated into the OEM products, these fixed antennas require
professional installation. Preventing end users from replacing them with non-compliant
antennas.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This device and its antenna must not be co-located or operation in conjunction with any other
antenna or transmitter.
Contains FCC ID: TV7R11E5HND
This enclosed device complies with 47CFR paragraph 15 C of the FCC rules and regulations.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
