Mikrotikls SIA R52 MPCI WIRELESS MODULE User Manual R52 Quick Install Guide

Mikrotikls SIA MPCI WIRELESS MODULE R52 Quick Install Guide

Contents

users manual

Quick Install Guide
Mikrotik
Wireless
Mini PCI Adapter
RouterBOARD R52
Version 1.0
1. Introduction
This mini PCI adapter, RouterBOARD R52 contains a dual-mode
single chip MAC/BB/Radio for IEEE 802.11a, 11g and 11b Wireless
LAN. It can support high-speed data transmission of up to 54 Mbps
in the 2.4GHz and 5GHz frequency bands based on 802.11b/g and
802.11a respectively.
Based on the latest industry standard Wi-Fi Certified IEEE 802.11a/g
specification, the RouterBOARD R52 offers maximum channel
speeds of up to 54 Mbps. It supports key security features like Wi-Fi
Protected Access (WPA), WPA2, WEP and 802.1x.
You can find this adapter that is seated inside the wireless products
such as the notebook computers or any other devices containing Mini
PCI socket. R52 can be removed from or inserted on the PCBA of the
RouterBOARD® products.
2. Package Content
RouterBOARD R52 retail package contains the following items:
• 1 x RouterBOARD R52 Wireless Mini PCI adapter
3. Application of Mini PCI
1. Align the R52 adapter to the Mini PCI socket.
2. Adjust and push down the R52 adapter gently until the metal-
locking levers aside from the Mini PCI socket is fastened.
Take note that R52 adapter can only fit in one direction due
to the keyed notch. Wrong orientation will cause improper
installation and may damage the Mini PCI socket.
3. Connect antenna/s on R52 adapter.
RouterBoard
Disclaimer: Mikrotikls, SIA provides this guide without warranty of any kind, either expressed or implied,
including but not limited to the implied warranties of merchantability and fitness for a particular purpose.
Mikrotikls, SIA may make improvements and/or changes to the product and/or specifications of the product
described in this guide, without prior notice. Mikrotikls, SIA will not be liable for any technical inaccuracies or
typographical errors found in this guide. Changes are periodically made to the information contained herein and
will be incorporated into later versions of the guide. The information contained is subject to change without
prior notice.
Trademark Information: Mikrotik® and RouterBOARD® are registered trademarks of Mikrotikls, SIA. All
other brand and product names are trademarks or registered trademarks of their respective owners.
Notice: Copyrights © 2004 by Mikrotikls, SIA. All rights reserved. Reproduction, adaptation, or translation
without prior permission of Mikrotikls, SIA is prohibited, except as allowed under the copyright laws.
Manual Revision by Aris
Manual Number: M-R52-1.0A Version 1.0, January 2006
FCC NOTICE: This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This device generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful interference to radio or television reception, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Connect the computer into an outlet on a
circuit different from that to which the
receiver is connected.
! Increase the separation between the computer and
receiver.
Consult the dealer or an experienced radio / TV
technician for help.
Caution: Any changes or modifications not expressly approved by the grantee of this device could void the
user's authority to operate the equipment.
FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
(2)
This device may not cause harmful interference, and
This device must accept any interference received, including interference that may cause undesired
operation.
Products that contain a radio transmitter are labeled with FCC ID and may also carry the FCC logo.
Caution: Exposure to Radio Frequency Radiation.
To comply with the FCC RF exposure compliance requirements, the following antenna installation and device
operating configurations must be satisfied:
a.
b.
For configurations using the integral antenna, the separation distance between the antenna(s) and any
person’s body (including hands, wrists, feet and ankles) must be at least 2.5cm (1 inch).
For configurations using an approved external antenna, the separation distance between the antenna and
any person’s body (including hands, wrists, feet and ankles) must be at least 20cm (8 inch).
The transmitter shall not be collocated with other transmitters or antennas.
ICES 003 Statement
This Class B digital apparatus complies with Canadian ICES-003.
DECLARATION OF CONFORMITY: Mikrotik SIA declares that the product:
Product Name: Mikrotik RouterBoard R52 Wireless Mini PCI Adapter
Model No.: R52 conforms to the following Product Standards:
Radiated Emission Standards: ETSI EN 300 328-2: July 2000; FCC: 47 CFR Part 15, Subpart B, ANSI
C63.4-1992; 47 CFR Part 15, Subpart C (Section 15.247), ANSI C63.4-1992.
Conducted Emission Standards: ETS 300 826: Nov. 1997.
Immunity Standards: IEC 801-2; IEC 801-3; IEC 801-4
Low Voltage Directive: EN 60 950:1992+A1: 1993+A2: 1993+A3; 1995+A4; 1996+A11: 1997
Therefore, this product is in conformity with the following regional standards: FCC Class B – following the
provisions of FCC Part 15 directive; CE Mark – following the provisions of the EC directive.
Manufacturer’s Name: Mikrotik, SIA
Address: 46 Pernavas street ,
Riga, LV-1009, Latvia
