Users Manual
Federal Communication Commission Interference
Statement (FCC ID: TV7R52HND)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This device and its antenna must not be co-located or operation in conjunction with any other
antenna or transmitter.
IMPORTANT: Exposure to Radio Frequency Radiation.
1.65 m minimum distance has to be maintained between the antenna and user. Under such
configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment
can be satisfied.
OEM statement. This module is intended for OEM installations only. As such the OEM
integrator is responsible for ensuring that the end-user has no manual instructions to remove install
or modify the module. This module is limited to installations in mobile or fixed applications. OEM
integrators may utilize antennas of like an equal or lesser gain as appearing in the list in this
document (reference 47 CFR, paragraph 15.204(c)(4) for further information on this topic. The
MikroTik OEM RF Module complies with Part 15 of the FCC rules and regulations.
OEM Modules have been certified by the FCC for use with other products without any further
certification (as per FCC section 2.1091). Separate approval is required for other operating
configurations including portable configurations with respect to 47CFR paragraph 2.1093 and
different antenna configurations. The OEM is required to comply with all 47CFR labeling instructions
and requirements for the finished products.
Changes or modifications not expressly approved by MikroTik could void the OEM authority to install
or operate the equipment. OEMs must test their final product to comply with unintentional radiators
(FCC section 15.107 and 15.109) before declaring compliance of their final product to Part 15 of the
FCC Rules.
See www.routerboard.com for more information. Contact support@mikrotik.com 25-Aug-16
WARNING: the OEM must ensure that the FCC labeling requirements are met. This includes a
clearly visible label on the outside of the OEM enclosure specifying the appropriate MikroTik OEM RF
Module FCC identifier for this product as well as any other required FCC notices as presented below.
Contains FCC ID: TV7R52HND
This enclosed device complies with 47CFR paragraph 15 C of the FCC rules and regulations.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Labeling and text information should be of a size of type large enough to be readily legible,
consistent with the dimensions of the equipment and the label.
WARNING: This device has been tested with a MMCX connector and antennas as listed in the table
below. When integrated into the OEM products, these fixed antennas require professional
installation. Preventing end users from replacing them with non-compliant antennas.
List of approved antennas for 2.4GHz:
Omni Directional, 130K-D-1131-150K(WS), 2dBi;
Omni Directional, WLO-2450-15, 15 dBi;
Omni Directional HP, ODH 24-13, 13dBi;
Panel, WLP-2450-20, 20 dBi;
Sector, SA-24-90-17-WB, 17 dBi;
Dish, DC 24-HD-PFIP, 24 dBi;
List of approved antennas for 5GHz:
Omni Directional, MT-482016/N/A, 8.5dBi;
Panel, PA58-24-ANT, 24dBi;
Dish, HDDA5W-32-DP2, 32dBi.
Antennas of same type and lower gain than those listed above may be used in compliance with
certification.
Antenna Installation. WARNING: It is installer's responsibility to ensure that when using the
authorized antennas in the United States (or where FCC rules apply); only those antennas certified
with the product are used. The use of any antenna other than those certified with the product is
expressly forbidden in accordance to FCC rules CFR47 part 15.204. The installer should configure the
output power level of antennas, according to country regulations and per antenna type. Professional
installation is required of equipment with connectors to ensure compliance with health and safety
issues.
Industry Canada (IC:7442A-R52HND)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
See www.routerboard.com for more information. Contact support@mikrotik.com 25-Aug-16
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
LE-LAN device restriction:
The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems;
Users should also be advised that high-power radars are allocated as primary users (i.e.
priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars
could cause interference and/or damage to LE-LAN devices.
les dispositifs fonctionnant dans la bande de 5 150 à 5 250 MHz sont réservés uniquement
pour une utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux
systèmes de satellites mobiles utilisant les mêmes canaux
Les utilisateurs devraient aussi être avisés, d’une part, que les utilisateurs de radars de
haute puissance sont désignés utilisateurs principaux (c.-à-d., qu'ils ont la priorité) des
bandes de 5 250 à 5 350 MHz et de 5 650 à 5 850 MHz et, d’autre part, que ces radars
pourraient causer du brouillage et/ou des dommages aux dispositifs de RL-EL
