SEXTANT

The SEXTANT is a 18dBi 5GHz antenna with a built in RB711

router. It has two polarizations to give you all benefits of 2x2 MIMO

in 802.11n.

The new SEXTANT is very similar to the popular SXT unit, just

slightly bigger.

Inside is the brand new RB711-5HnD dual chain wireless device,

with high performance, high output power, and low power

requirements.

Easy to use and quick to deploy, SEXTANT is ideal for point to

point links.

Outdoor point to point solution

Frequencies 5.17 - 5.825 GHz

Gain 18dBi

VSWR 1.6:1

3 dB Beam-Width, H-Plane 16.8 °

3 dB Beam-Width, E-Plane, typ. 22.8 °

Polarization Linear, Vertical and Horizontal

Port to Port Isolation - 35 dB

RX sensitivity 802.11a: –96 dBm @ 6Mbps to -80 dBm @ 54 Mbps

802.11n: –96 dBm @ MCS0 to –77 dBm @ MCS7

TX power 802.11a: 26dBm @ 6Mbps to 22dBm @ 54 Mbps

802.11n: 25dBm @ MCS0 to 19dBm @ MCS7

CPU Atheros AR7241 400MHz network processor

Memory 32MB DDR SDRAM onboard memory

Data storage 128MB onboard NAND memory chip

Ethernet One 10/100 Mbit/s Fast Ethernet port with Auto-MDI/X

Wireless 5GHz AR9280 802.11a/n, 2x2 MIMO, 2x MMCX

LEDs Power, NAND activity, 5 user LEDs

Power Power over Ethernet: 10..28V DC (except power over

datalines). No power jack. Up to 4.5W consumption.

OS MikroTik RouterOS v4, Level3 license
