mANTBox series
The mANTBox is a solid and waterproof outdoor device based on the RB911 wireless router series. It has high power
802.11b/g/n wireless, and one Gigabit Ethernet connector, which supports MDI-X auto detection. The device has a built in
Sectoral antenna. The device is packaged with a 24V power adapter, a PoE injector and a mounting kit.
First use
1. Unscrew the lid screw by hand, or with a hex screwdriver.
2. The device accepts 10-28V Passive PoE from a PoE injector (please compensate voltage for loss due to cable length)
or from the power jack
3. The default IP address from Ether1 is 192.168.88.1 for configuration
Username is admin and there is no password
Powering
The device comes included with a 24V 0.8A power adapter. It can be used with the included PoE injector, or the power jack.
Device accepts 8-30V for both methods. Maximum power consumption of the device is 11W at 24V. Please use the PoE
injector with the DATA+POWER end connected to the mANTBox unit, and DATA end to your switch or PC.
Booting process
Connect to wireless SSID “MikroTik” and open 192.168.88.1 in your web browser. Username is admin and there is no
password. In case IP connection is not available, Winbox can be used to connect to the MAC address of the device.
More information here: http://wiki.mikrotik.com/wiki/First_time_startup
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device
when starting it until the LED light turns off, and the device will start to look for Netinstall servers.
Mounting
The mANTbox 12s comes with a QuickMount adapter that can be attached to a wall using the included screws, or attached to
a pole, using the included metal mounting ring. The QuickMount allows the device to be adjusted horizontally and vertically.
The mANTbox 12s comes with metal pole brackets, that clamp around metal poles. More detailed instructions for assembly
are available on http://routerboard.com
Please avoid connecting a loose Ethernet cable to the Ethernet port - secure the cable to a wall or the pole, so that the cable
weight is not pulling the port. It is recommended to secure the Ethernet cable less than 2m from the device. This is to ensure
that the cable doesn't damage the port by its weight, or doesn't fall out.
It is possible to connect a grounding wire to the device, by opening the lid, a grounding screw is provided there.
Expansion Slots and Ports
Built in 2,4GHz, 802.11b/g/n wireless, 2x2 MIMO, AP/staton/bridge modes supported
One 10/100/1000 Gigabit Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X), so you can
use either straight or crossover cable for connecting to other network devices. The Ethernet port accepts 10-28V DC
powering from a passive PoE injector.
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 19-Jun-18
![](/img.php?id=3902116&img=bg2.png)
Buttons and Jumpers
The reset button is located behind the case door, to the left of the ETH port. It has following functions:
Loading the backup RouterBOOT loader: Hold this button before applying power, release after three seconds since
powering, to load backup Boot loader. This might be necessary if the device is not operation because of a failed
RouterBOOT upgrade. When you have started the device with the backup loader, you can either set RouterOS to
force backup loader in the RouterBOARD settings, or have a chance to reinstall the failed RouterBOOT from a fwf file
(total 3 seconds)
Resetting the RouterOS configuration: If you keep holding this button for 2 more seconds until LED light starts
flashing, release the button to reset RouterOS configuration (total 5 seconds)
Enabling CAPs mode: To connect this device to a wireless network managed by CAPsMAN, keep holding the button
for 5 more seconds, LED turns solid, release now to turn on CAPs mode (total 10 seconds)
Starting the RouterBOARD in Netinstall mode: Or Keep holding the button for 5 more seconds until until LED turns
off, then release it to make the RouterBOARD look for Netinstall servers. You can also simply keep the button pressed
until the device shows up in the Netinstall program on Windows (total 15 seconds)
Operating System Support
Currently tested operating system is MikroTik RouterOS (starting from version v6.24).
Copyright and Warranty information
Copyright MikroTikls SIA. This document contains information protected by copyright law. No part of it may be reproduced or
transmitted in any form without prior written permission from the copyright holder. RouterBOARD, RouterOS, RouterBOOT
and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks appearing in this document are the
property of their respective holders.
Hardware. MikroTik warrants all RouterBOARD series equipment for the term of twelve (12) months from the shipping date
to be free of defects in materials and workmanship under normal use and service, except in case of damage caused by
mechanical, electrical or other accidental or intended damages caused by improper use or due to wind, rain, fire or other acts
of nature.
To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization) procedure.
Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process.
1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all warranty
and repair issues, the following instructions apply ONLY if you purchased your equipment directly from MikroTik in Latvia.
2. MikroTik does not offer repairs for products that are not covered by warranty. Exceptions can be made for: CCR1016-12G,
CCR1016-12G-BU, CCR1036-12G-4S, RB1100, RB1100AH, RB1100AHx2, RB1200, RB600, RB600A and RB800 as a paid
service (fees apply).
3. Out-of-warranty devices and devices not covered by warranty sent to Mikrotik will be returned to the sender at
sender's cost. If the customer has not organized return of such rejected devices within 12 months from the day of arrival,
MikroTik has the right to discard them.
RMA Instructions are located on our webpage here: http://rma.mikrotik.com
This document is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to, the
implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every effort to ensure
the accuracy of the contents of this document, however, it is possible that it may contain technical inaccuracies, typographical
or other errors. No liability is assumed for any inaccuracy found in this publication, nor for direct or indirect, incidental,
consequential or other damages that may result from such an inaccuracy, including, but not limited to, loss of data or profits.
Please report any inaccuracies found to support@mikrotik.com
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 19-Jun-18
![](/img.php?id=3902116&img=bg3.png)
Federal Communication Commission Interference Statement
FCC ID: TV7RB911G-2HPND
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation. This device and its antenna must not be co-located or operation in conjunction with any other
antenna or transmitter.
IMPORTANT: Exposure to Radio Frequency Radiation.
20 cm minimum distance has to be maintained between the antenna and the occupational user and 20 cm to general public.
Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be
satisfied.
List of additional approved antennas:
Sectoral 120 degree antenna, 12dBi
Antenna Installation. WARNING: It is installer's responsibility to ensure that when using the authorized antennas in the United
States (or where FCC rules apply); only those antennas certified with the product are used. The use of any antenna other than
those certified with the product is expressly forbidden in accordance to FCC rules CFR47 part 15.204. The installer should
configure the output power level of antennas, according to country regulations and per antenna type. Professional installation
is required of equipment with connectors to ensure compliance with health and safety issues.
Industry Canada (IC:7442A-911G2HPND)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 19-Jun-18
![](/img.php?id=3902116&img=bg4.png)
CE Declaration of Conformity
Full Declaration of Conformity (DoC) may be obtained by visiting this web page: http://routerboard.com/doc/
Manufacturer: Mikrotikls SIA, Pernavas street 46, Riga, Latvia, LV1009.
Maximum Output Power (EIRP) in the frequency range 2412-2472 MHz is 20 dBm.
[EN] English Hereby, MIKROTĪKLS SIA declares that this ROUTERBOARD is in compliance with the essential requirements and other relevant provisions of
Directive 2014/53/eu.
[BG] Bulgarian С настоящето, MIKROTĪKLS SIA декларира, че ROUTERBOARD е в съответствие със съществените изисквания и другитеприложими
разпоредби на Директива 2014/53/eu.
[CZ] Czech MIKROTĪKLS SIA tímto prohlašuje, že ROUTERBOARD splňuje základní požadavky a všechna příslušná ustanoveni Směrnice 2014/53/eu.
[DK] Danish Undertegnede MIKROTĪKLS SIA erklærer herved, at følgende udstyr ROUTERBOARD overholder de væsentlige krav og øvrige relevante krav i
direktiv 2014/53/eu.
[DE] German Hiermit erklärt MIKROTĪKLS SIA dass sich das Gerät ROUTERBOARD in Übereinstimmung mit den grundlegenden Anforderungen und den
übrigen einschlägigen Bestimmungen der Richtlinie 2014/53/EG befindet.
[EE] Estonian Käesolevaga kinnitab MIKROTĪKLS SIA seadme ROUTERBOARD vastavust direktiivi 2014/53/EÜ põhinõuetele ja nimetatud direktiivist
tulenevatele teistele asjakohastele sätetele.
[GR] Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Ο ΚΑΤΑΣΚΕΥΑΣΤΗΣ MIKROTĪKLS SIA ΔΗΛΩΝΕΙ ΟΤΙ ROUTERBOARD ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ
ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 2014/53/ΕΚ
[ES] Spanish Por la presente, MIKROTĪKLS SIA declara que este ROUTERBOARD cumple con los requisitos esenciales y otras exigencias relevantes de la
Directiva 2014/53/EC.
[IT] Italian Con la presente MIKROTĪKLS SIA dichiara che questo ROUTERBOARD è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti
stabilite dalla direttiva2014/53 /CE.
[LV] Latvian Ar šo MIKROTĪKLS SIA deklarē, ka ROUTERBOARD atbilst Direktīvas2014/53 /EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
[LT] Lithuanian Šiuo MIKROTĪKLS SIA deklaruoja, kad šis ROUTERBOARD atitinka esminius reikalavimus ir kitas 2014/53/EB Direktyvos nuostatas
[HU] Hungarian A MIKROTĪKLS SIA ezzennel kijelenti, hogy a ROUTERBOARD típusú beren-dezés teljesíti az alapvető követelményeket és más 2014/53/EK
irányelvben meghatározott vonatkozó rendelkezéseket.
[NL] Dutch Hierbij verklaart MIKROTĪKLS SIA dat het toestel l ROUTERBOARD in overeenstemming is met de essentiële eisen en de andere relevante
bepalin-gen van richtlijn2014/53 /EG.
[PL] Polish Niniejszym MIKROTĪKLS SIA deklaruje że ROUTERBOARD jest zgodny z zasadniczymi wymaganiami i innymi właściwymi postanowieniami
Dyrektywy 2014/53/EC.
[PT] Portuguese Eu, MIKROTĪKLS SIA declaro que o ROUTERBOARD cumpre os requisitos essenciais e outras provisões relevantes da Directiva 2014/53/EC.
[RO] Romanian Prin prezenta, MIKROTĪKLS SIA declară că aparatul ROUTERBOARD este în conformitate cu cerinţele esenţiale şi cu alte prevederi pertinente ale
Directivei 2014/53/CE..
[SK] Slovak MIKROTĪKLS SIA týmto vyhlasuje, že ROUTERBOARD spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 2014/53/ES.
[SI] Slovenian MIKROTĪKLS SIA izjavlja, da je ta ROUTERBOARD v skladu z bistvenimi zahtevami in drugimi relevantnimi določili direktive 2014/53/ES.
[FI] Finish MIKROTĪKLS SIA vakuuttaa täten että ROUTERBOARD tyyppinen laite on direktiivin 2014/53/EY oleellisten vaatimusten ja sitä koskevien
direktiivin muiden ehtojen mukainen.
[SE] Swedish Härmed intygar MIKROTĪKLS SIA att denna RouterBOARD är i överensstämmelse med de väsentliga egenskapskrav och övriga relevanta
bestämmelser som framgår av direktiv 2014/53/EG.
[NO] Norwegian MIKROTĪKLS SIA Erklærer herved at ROUTERBOARD er i samsvar med de grunnleggende krav og øvrige relevante krav i direktiv 2014/53/EF.
EN. Instruction manual: Connect the power adapter to turn on the device. Open 192.168.88.1 in your web browser, to configure it. More information on http://wiki.mikrotik.com
BG. Инструкция: Свържете адаптера на захранване, за да включите устройството. Отворете 192.168.88.1 в уеб браузър, за да настроите продукта. Повече информация в
http://wiki.mikrotik.com CZ. Návod k použití: Připojte napájecí adaptér k zapnutí přístroje. Otevřete 192.168.88.1 ve webovém prohlížeči pro konfiguraci produktu. Více informací
najdete v http://wiki.mikrotik.com DK. Instruktionsbog: Tilslut strømadapteren for at tænde for enheden. Åbn 192.168.88.1 i en webbrowser til at konfigurere produktet. Mere
information i http://wiki.mikrotik.com FR. Mode d'emploi: Connectez l'adaptateur d'alimentation pour allumer l'appareil. Ouvrez 192.168.88.1 dans un navigateur Web pour
configurer le produit. Plus d'informations dans http://wiki.mikrotik.com DE. Bedienungsanleitung: Verbinden Sie das Netzteil, um das Gerät einzuschalten. Öffnen Sie 192.168.88.1
in einem Web-Browser, um das Produkt zu konfigurieren. Weitere Informationen im http://wiki.mikrotik.com EE. Kasutusjuhend: Ühendage toiteadapter seadme sisselülitamiseks.
Avatud 192.168.88.1 in veebilehitseja seadistada toodet. Rohkem teavet http://wiki.mikrotik.com ES. Manual de instrucciones: Conecte el adaptador de alimentación para
encender la unidad. Abra 192.168.88.1 en un navegador web para configurar el producto. Más información en http://wiki.mikrotik.com IT. Manuale di istruzioni: Collegare
l'adattatore di alimentazione per accendere l'unità. Aprire 192.168.88.1 in un browser Web per configurare il prodotto. Maggiori informazioni in http://wiki.mikrotik.com LV.
Lietošanas instrukcija: Pievienojiet Strāvas adapteri, lai ieslēgtu ierīci. Atvērt 192.168.88.1 ar interneta pārlūku, lai konfigurētu produktu. Plašāka informācija
http://wiki.mikrotik.com LT. Naudojimosi instrukcija: Prijunkite maitinimo adapterį įjunkite įrenginį. Į interneto naršyklę 192.168.88.1 Atidarykite galite konfigūruoti gaminį.
Daugiau informacijos rasite http://wiki.mikrotik.com HU. Használati utasítás: Csatlakoztassa a hálózati adaptert a készülék bekapcsolásához. Megnyitása 192.168.88.1 egy
webböngészőben beállítani a terméket. Több információ http://wiki.mikrotik.com NL. Handleiding: Sluit voedingsadapter aan op het apparaat in te schakelen. Open 192.168.88.1
in een webbrowser om het product te configureren. Meer informatie in http://wiki.mikrotik.com PL. Instrukcja obsługi: Podłącz adapter zasilania, aby włączyć urządzenie. Otwórz
192.168.88.1 w przeglądarce internetowej, aby skonfigurować urządzenie. Więcej informacji w http://wiki.mikrotik.com PT. Manual de instruções: Conecte o adaptador de
alimentação para ligar o aparelho. Abra 192.168.88.1 em um navegador da web para configurar o produto. Mais informações em http://wiki.mikrotik.com RO. Instrucțiuni de
utilizare : Conectați adaptorul de alimentare pentru a porni aparatul. Deschide 192.168.88.1 într-un browser web pentru a configura produsul. Mai multe informații în
http://wiki.mikrotik.com SK. Návod na použitie: Pripojte napájací adaptér k zapnutiu prístroja. Otvorte 192.168.88.1 vo webovom prehliadači pre konfiguráciu produktu. Viac
informácií nájdete v http://wiki.mikrotik.com SI. Navodila: Priključite napajalnik za vklop naprave. Odprite 192.168.88.1 v spletnem brskalniku nastaviti izdelek. Več informacij v
http://wiki.mikrotik.com FI. Käyttöohje: Kytke virtalähde päälle laitteen. Avaa 192.168.88.1 in selaimen määrittää tuotteen. Lisää tietoa http://wiki.mikrotik.com SE.
Instruktionsmanual: Anslut nätadaptern för att slå på enheten. Öppna 192.168.88.1 i en webbläsare för att konfigurera produkten. Mer information på http://wiki.mikrotik.com
NO. Bruksanvisningen: Koble strømadapteren for å slå på enheten. Åpne 192.168.88.1 i en nettleser for å konfigurere produktet. Mer informasjon på http://wiki.mikrotik.com GR.
εγχειρίδιο οδηγιών: Συνδέστε τον προσαρμογέα τροφοδοσίας για να ενεργοποιήσετε τη μονάδα. Ανοίξτε 192.168.88.1 σε ένα πρόγραμμα περιήγησης στο Web για να
διαμορφώσετε το προϊόν. Περισσότερες πληροφορίες στο http://wiki.mikrotik.com
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 19-Jun-18
