Mikrotikls SIA RB951G-2HND MIMO BROADBAND DIGITAL TRANSMISSION SYSTEM User Manual USERS MANUAL
Mikrotikls SIA MIMO BROADBAND DIGITAL TRANSMISSION SYSTEM USERS MANUAL
USERS MANUAL
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 16-Oct-2012
RouterBOARD 951G-2HnD
Quick Setup Guide and Warranty
Information
Connecting
1. Connect your Internet cable to port 1,
and LAN computers to ports 2-5
2. Set LAN computer IP configuration to automatic (DHCP)
3. Wireless AP mode is enabled by default, you can connect to the
SSID “MikroTik”. Log into your router from your web browser
by opening 192.168.88.1 in the address bar
Powering
The device accepts powering from the power jack or from the first Ethernet port (Passive PoE):
DC power jack (5.5mm outside and 2mm inside diameter, female, pin positive plug) accepts 8-30V DC
The first Ethernet port accepts passive Power over Ethernet accepts 8-30V DC
Under maximum load, the power consumption of this device is 7W
Booting process
The device is preinstalled with MikroTik RouterOS software. It can be configured in several ways.
This device doesn't come fitted with a Serial Port connector, so initial connection has to be done via the Ethernet cable.
Connect to wireless SSID “MikroTik” and open 192.168.88.1 in your web browser. Username is admin and there is no password.
In case IP connection is not available, Winbox can be used to connect to the MAC address of the device. More information here:
http://wiki.mikrotik.com/wiki/First_time_startup
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device
when starting it until the LED light turns off, and Metal will start to look for Netinstall servers.
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device
when starting it until the LED light turns off, then release the button and the device will start looking for Netinstall servers.
By default, the device is preconfigured with a simple firewall on the WAN port, this configuration can be viewed when first
connecting to the Router via Winbox. It will ask whether to keep this configuration or clean it to use your own. LAN/WLAN
ports have DHCP server enabled.
Extension Slots and Ports
Five individual 10/100/1000 Gigabit Ethernet ports, supporting automatic cross/straight cable connection (Auto MDI/X), so you can
use either straight or cross-over cables for connecting to other network devices. The First Ethernet port accepts 8-30V DC powering
from a passive PoE injector.
One Integrated Wireless 2.4GHz 802.11b/g/n 2x2 MIMO, Onboard PIF antennas, max gain 2.5dBi
One USB 2.0 port
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 16-Oct-2012
Resetting the device
In case you wish to return the device to its original configuration, you can use the RESET button which is located to the left of
the Ethernet ports. Hold this button during boot time until LED lights start flashing, then release the button to reset RouterOS
configuration. You can use this procedure if you have forgotten the password to access the device, or simply wish to return the
unit to its default configuration state.
Buttons and Jumpers
RouterOS reset jumper hole (on the bottom of case, behind one of the rubber feet) – resets RouterOS software to defaults. Must
short circuit the metallic sides of the hole (with a screwdriver, for example) and boot the device. Hold screwdriver in place until
RouterOS configuration is cleared.
RouterBOOT reset button (RESET, front panel) has two functions:
Hold this button during boot time until LED light starts flashing,
release the button to reset RouterOS configuration (same result as with RouterOS reset hole)
Hold this button during boot time longer, until LED turns off,
then release it to make the RouterBOARD look for Netinstall servers.
Operating System Support
Currently tested operating system is MikroTik RouterOS starting from version v5.
Copyright and Trademarks.
Copyright MikroTikls SIA. This manual contains information protected by copyright law. No part of it may be reproduced or
transmitted in any form without prior written permission from the copyright holder. RouterBOARD, RouterOS, RouterBOOT
and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks appearing in this manual are the
property of their respective holders.
Hardware. MikroTik warrants all RouterBOARD series equipment for the term of twelve (12) months from the shipping date to
be free of defects in materials and workmanship under normal use and service, except in case of damage caused by mechanical,
electrical or other accidental or intended damages caused by improper use or due to wind, rain, fire or other acts of nature.
To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization) procedure. Follow
the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process.
1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all warranty and
repair issues, the following instructions apply ONLY if you purchased your equipment directly from MikroTik in Latvia.
2. We do not offer repairs for products that are not covered by warranty. Exceptions can be made for RB1000 series.
3. Out-of-warranty devices and devices not covered by warranty sent to Mikrotikls will be returned to the sender at sender's cost.
RMA Instructions are located on our webpage here: http://rma.mikrotik.com
Manual. This manual is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to, the
implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every effort to ensure
the accuracy of the contents of this manual, however, it is possible that it may contain technical inaccuracies, typographical or
other errors. No liability is assumed for any inaccuracy found in this publication, nor for direct or indirect, incidental,
consequential or other damages that may result from such an inaccuracy, including, but not limited to, loss of data or profits.
Please report any inaccuracies found to support@mikrotik.com
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 16-Oct-2012
Federal Communication Commission Interference Statement
(FCC ID: TV7RB951G-2HND)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
This device and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter.
IMPORTANT: Exposure to Radio Frequency Radiation.
To comply with CFR47 1.1307 RF exposure requirements all users must maintain a minimum distance of 30 cm between the
antenna and all users.
CE Declaration of Conformity
Hereby MikroTik declares that this product is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. The Declaration of Conformity may be obtained by contacting
sales@mikrotik.com.
