RouterBOARD953GS-5HnT
QuickSetupGuideandWarrantyInformation
TheRB953isequippedwiththreeGigabitEthernetports,twoSFPcagesandtwominiPCIslots.Italsohasabuilt-
in5GHzwirelessdevicewiththree-chainsupport(threeantennaconnectors).
AssemblingtheHardware
Firstuseoftheboard:
1. InserttheminiPCIcards
2. Installtheboardinacaseandconnectantennacables
3. Connectotherperipheralsandcables
4. PluginPoEpoweredEthernettoturnontheboard
Thedevicecomeswithathermalpad,whichislocatedinsideasmallbag.Thisthermalpadwillensureheattrans-
ferbetweenthebacksideofRB953wirelessdeviceheatsink,andtheindoororoutdoorcase,whereitwillbe
mounted.ThethermalpadshouldbeputontherectangularareaoftheRB953heatsink,sothatitispressing
againstthedevicecase,whenitismounted.
Powering
It’spossibletopowerthedevicewiththefollowingmethods:
• ThefirstEthernetport(Ether1)accepts8-30VDCinput(attheboard;highervoltageneededtocompensate
forpowerlossonlongcables;atleast18Vsuggested)fromnon-standard(passive)PoweroverEthernetin-
jectors.ThisdevicedoesnotworkwithIEEE802.3afcompliant48Vpowerinjectors.
• DCpowerjackwhichaccepts8-30V(5.5mmoutsideand2mminsidediameter,female,pinpositiveplug)
Bootingprocess
RouterOSistheoperatingsystemofallRouterBOARDrouters.Pleaseseedetailedconfigurationguidehere:
http://wiki.mikrotik.com/wiki/Category:Manual
Thisdevicedoesn'tcomefittedwithaSerialPortconnector,soinitialconnectionhastobedoneviatheEthernet
cable,usingtheMikroTikWinboxutility.WinboxshouldbeusedtoconnecttothedefaultIPaddressof
192.168.88.1withtheusernameadminandnopassword.
Incaseyouwishtobootthedevicefromnetwork,forexampletouseMikroTikNetinstall,holdtheRESETbutton
ofthedevicewhenstartingituntiltheLEDlightturnsoff,andGroovewillstarttolookforNetinstallservers.
IncaseIPconnectionisnotavailable,WinboxcanalsobeusedtoconnecttotheMACaddressofthedevice.More
informationhere:http://wiki.mikrotik.com/wiki/First_time_startup
ExtensionSlotsandPorts
• Three10/100/1000GigabitEthernetports,supportingautomaticcross/straightcablecorrection(Auto
MDI/X),soyoucanuseeitherstraightorcross-overcablesforconnectingtoothernetworkdevices.The
firstEthernetportaccepts8-30VDCpoweringfromapassivePoEinjector.TheothertwoEthernetports
donotsupportPoEpowering.
![](/img.php?id=2312239&img=bg2.png)
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 19/05/14
• TwoMiniPCITypeIIIA/IIIBportswith3.3Vpowersignaling
• TwoSFPcages(Supports1.25GSFPmodules,supportsDDMI)
• OnepoweredUSB2.0port(5V)
• One8-30VDCpowerjack
• Onefanheader,forconnectinganoptionalcoolingfan(5V)
Buttons
• Bootloaderbackupbutton(Reset1).Holdingthebuttonwhilebootingwillcausethebackupbootloader
tobeused
• RouterOSresethole(Whilebooting,andholdingametalobjectinthishole(forexampleascrewdriver)
willcauseRouterOSsoftwaretoberesettodefaults
OperatingSystemSupport
CurrentlytestedoperatingsystemisMikroTikRouterOS(startingfromv6).
CopyrightandWarrantyinformation
CopyrightMikroTiklsSIA.Thisdocumentcontainsinformationprotectedbycopyrightlaw.Nopartofitmaybereproducedor
transmittedinanyformwithoutpriorwrittenpermissionfromthecopyrightholder.RouterBOARD,RouterOS,RouterBOOT
andMikroTikaretrademarksofMikroTiklsSIA.Alltrademarksandregisteredtrademarksappearinginthisdocumentarethe
propertyoftheirrespectiveholders.
Hardware.MikroTikwarrantsallRouterBOARDseriesequipmentforthetermoftwelve(12)monthsfromtheshippingdate
tobefreeofdefectsinmaterialsandworkmanshipundernormaluseandservice,exceptincaseofdamagecausedbyme-
chanical,electricalorotheraccidentalorintendeddamagescausedbyimproperuseorduetowind,rain,fireorotheractsof
nature.
ToreturnfailedunitstoMikroTik,youmustperformthefollowingRMA(ReturnMerchandiseAuthorization)procedure.Fol-
lowtheinstructionsbelowtosavetime,efforts,avoidcosts,andimprovethespeedoftheRMAprocess.
1. IfyouhavepurchasedyourproductfromaMikroTikReseller,pleasecontacttheResellercompanyregard-
ingallwarrantyandrepairissues,thefollowinginstructionsapplyONLYifyoupurchasedyourequipmentdirectly
fromMikroTikinLatvia.
2. MikroTikdoesnotofferrepairsforproductsthatarenotcoveredbywarranty.Exceptionscanbemadefor:
CCR1016-12G,CCR1016-12G-BU,CCR1036-12G-4S,RB1100,RB1100AH,RB1100AHx2,RB1200,RB600,RB600Aand
RB800asapaidservice(feesapply).
3. Out-of-warrantydevicesanddevicesnotcoveredbywarrantysenttoMikrotikwillbereturnedtothesend-
eratsender'scost.Ifthecustomerhasnotorganizedreturnofsuchrejecteddeviceswithin12monthsfromtheday
ofarrival,MikroTikhastherighttodiscardthem.
RMAInstructionsarelocatedonourwebpagehere:http://rma.mikrotik.com
Thisdocumentisprovided“asis”withoutawarrantyofanykind,expressedorimplied,including,butnotlimitedto,theim-
pliedwarrantyofmerchantabilityandfitnessforaparticularpurpose.Themanufacturerhasmadeeveryefforttoensurethe
accuracyofthecontentsofthisdocument,however,itispossiblethatitmaycontaintechnicalinaccuracies,typographicalor
othererrors.Noliabilityisassumedforanyinaccuracyfoundinthispublication,norfordirectorindirect,incidental,conse-
quentialorotherdamagesthatmayresultfromsuchaninaccuracy,including,butnotlimitedto,lossofdataorprofits.
