See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 16-Oct-2012
RouterBOARD+SXT+5nD+r2+
Quick&Setup&Guide&and&Warranty&Information&
The$RouterBOARD$SXT$5nD$r2$comes$as$a$complete$set,$and$includes$a$
built$in$802.11n$dual$chain$wireless$device,$and$a$dual$polarization$
16dBi$antenna.$It$has$one$BASEGT$10/100$ethernet$connector$which$
supports$MDIGX$auto$detection.$
First&use&
1. Connect$an$Ethernet$cable$to$the$port$behind$the$small$plastic$door$
2. The$SXT$accepts$24V$Passive$PoE$from$a$PoE$injector$
3. The$default$IP$address$from$LAN$is$192.168.88.1$for$configuration$
4. Username$is$admin$and$there$is$no$password$
Powering&
The$board$accepts$powering$from$the$Ethernet$port$(Passive$PoE)$8G30V$DC.$Package$contains$a$24V$adapter.$
Maximum$power$consumption$of$the$device$is$7W.$
Booting&process&
Initial$connection$has$to$be$done$via$the$Ethernet$cable.$Open$192.168.88.1+in$your$web$browser,$and$choose$
“Webfig”$for$browser$based$configuration$or$“Winbox”$for$a$Windows$utility$with$the$same$functions.+Username$
is$admin$and$there$is$no$password.$In$case$IP$connection$is$not$available,$Winbox$can$be$used$to$connect$to$the$
MAC$address$of$the$device.$More$information$here:$http://wiki.mikrotik.com/wiki/First_time_startup$
In$case$you$wish$to$boot$the$device$from$network,$for$example$to$use$MikroTik$Netinstall,$hold$the$RESET$button$
of$the$device$when$starting$it$until$the$LED$light$turns$off,$and$Metal$will$start$to$look$for$Netinstall$servers.$
Mounting&
With$the$clip$pointed$forward,$slide$the$mounting$bracket$into$the$rail$on$the$bottom$of$the$case,$until$the$clip$
clicks$into$place.$The$SXT$comes$bundled$with$a$hose$clamp$G$guide$the$clamp$through$the$opening$in$the$bracket$
and$around$the$pole$where$it$will$be$mounted.$Tighten$the$hose$clamp$screw$when$alignment$is$complete.$Two$
screw$holes$are$provided$as$additional$security$against$accidental$bracket$movement.$
The$SXT$device$has$a$sliding$door,$behind$which$the$Ethernet$port,$and$the$reset$jumpers$are$located.$This$door$
can$be$also$secured$shut$with$a$screw$in$the$provided$screw$hole.&
&
$&
![](/img.php?id=1894048&img=bg2.png)
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 16-Oct-2012
Buttons&and&Jumpers&
• RouterOS$reset$jumper$hole$(access$through$the$plastic$door)$–$resets$RouterOS$software$to$defaults.$Must$short$cirG
cuit$the$metallic$sides$of$the$hole$(with$a$screwdriver,$for$example)$and$boot$the$device.$Hold$screwdriver$in$place$
until$RouterOS$configuration$is$cleared.$$$
• RouterBOOT$reset$button$(access$through$the$plastic$door)$has$two$functions:$
! Hold$this$button$during$boot$time$until$LED$light$starts$flashing,$$
release$the$button$to$reset+RouterOS+configuration+(same$result$as$with$reset$hole)$
! Hold$this$button$during$boot$time$longer,$until$LED$turns$off,$$
and$then$release$it$to$make$the$device$look+for+Netinstall+servers.$
Operating&System&Support&
Currently$tested$operating$system$is$MikroTik$RouterOS$(starting$from$version$v5.20).$
Copyright&and&Warranty&Information&
Copyright+and+Trademarks.$Copyright$MikroTikls$SIA.$This$manual$contains$information$protected$by$copyright$
law.$No$part$of$it$may$be$reproduced$or$transmitted$in$any$form$without$prior$written$permission$from$the$copyG
right$holder.$RouterBOARD,$RouterOS,$RouterBOOT$and$MikroTik$are$trademarks$of$MikroTikls$SIA.$All$trademarks$
and$registered$trademarks$appearing$in$this$manual$are$the$property$of$their$respective$holders.$
Hardware.$MikroTikls$SIA$warrants$all$RouterBOARD$series$equipment$for$the$term$of$fifteen$(15)$months$from$
the$shipping$date$to$be$free$of$defects$in$materials$and$workmanship$under$normal$use$and$service,$except$in$
case$of$damage$caused$by$mechanical,$electrical$or$other$accidental$or$intended$damages$caused$by$improper$use$
or$due$to$wind,$rain,$fire$or$other$acts$of$nature.$
If$you$have$purchased$your$product$from$a$MikroTik$Reseller,$please$contact$the$Reseller$company$regarding$all$
warranty$and$repair$issues,$the$following$instructions$apply$ONLY$if$you$purchased$your$equipment$directly$from$
MikroTik$Latvia$
To$return$failed$unit$or$units$to$MikroTikls$you$must$perform$the$following$RMA$(Return$Material$Authorization)$
procedure.$Follow$the$instructions$below$to$save$time,$efforts,$avoid$costs,$and$improve$the$speed$of$the$RMA$
process.$Take$into$account$that$all$goods$have$one$year$warranty.$
Instructions$are$located$on$our$webpage$here:$http://rma.mikrotik.com$
Manual.$This$manual$is$provided$“as$is”$without$a$warranty$of$any$kind,$expressed$or$implied,$including,$but$not$
limited$to,$the$implied$warranty$of$merchantability$and$fitness$for$a$particular$purpose.$The$manufacturer$has$
made$every$effort$to$ensure$the$accuracy$of$the$contents$of$this$manual;$however,$it$is$possible$that$it$may$conG
tain$technical$inaccuracies,$typographical$or$other$errors.$No$liability$is$assumed$for$any$inaccuracy$found$in$this$
publication,$nor$for$direct$or$indirect,$incidental,$consequential$or$other$damages$that$may$result$from$such$an$
inaccuracy,$including,$but$not$limited$to,$loss$of$data$or$profits.$Please$report$any$inaccuracies$found$to$supG
port@mikrotik.com$
$&
![](/img.php?id=1894048&img=bg3.png)
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 16-Oct-2012
Federal&Communication&Commission&Interference&Statement&&
(FCC&ID:&TV7SXT-5ND)&
This$equipment$has$been$tested$and$found$to$comply$with$the$limits$for$a$Class$B$digital$device,$purG
suant$to$Part$15$of$the$FCC$Rules.$These$limits$are$designed$to$provide$reasonable$protection$against$
harmful$interference$in$a$residential$installation.$
This$equipment$generates,$uses$and$can$radiate$radio$frequency$energy$and,$if$not$installed$and$used$in$accordG
ance$with$the$instructions,$may$cause$harmful$interference$to$radio$communications.$However,$there$is$no$guarG
antee$that$interference$will$not$occur$in$a$particular$installation.$If$this$equipment$does$cause$harmful$interferG
ence$to$radio$or$television$reception,$which$can$be$determined$by$turning$the$equipment$off$and$on,$the$user$is$
encouraged$to$try$to$correct$the$interference$by$one$of$the$following$measures:$
• Reorient$or$relocate$the$receiving$antenna.$
• Increase$the$separation$between$the$equipment$and$receiver.$
• Connect$the$equipment$into$an$outlet$on$a$circuit$different$from$that$to$which$the$receiver$is$connected.$
• Consult$the$dealer$or$an$experienced$radio/TV$technician$for$help.$
FCC+Caution:$Any$changes$or$modifications$not$expressly$approved$by$the$party$responsible$for$compliance$could$
void$the$user’s$authority$to$operate$this$equipment.$
This$device$complies$with$Part$15$of$the$FCC$Rules.$Operation$is$subject$to$the$following$two$conditions:$(1)$This$
device$may$not$cause$harmful$interference,$and$(2)$this$device$must$accept$any$interference$received,$including$
interference$that$may$cause$undesired$operation.$
This$device$and$its$antenna$must$not$be$coGlocated$or$operation$in$conjunction$with$any$other$antenna$or$transG
mitter.$$
IMPORTANT:+Exposure+to+Radio+Frequency+Radiation.$
13$cm$minimum$distance$has$to$be$maintained$between$the$antenna$and$the$occupational$user$and$28$cm$to$
general$public.$Under$such$configuration,$the$FCC$radiation$exposure$limits$set$forth$for$an$populaG
tion/uncontrolled$environment$can$be$satisfied.$
Antenna+Installation.+WARNING:$It$is$installer's$responsibility$to$ensure$that$when$using$the$authorized$antennas$
in$the$United$States$(or$where$FCC$rules$apply);$only$those$antennas$certified$with$the$product$are$used.$The$use$
of$any$antenna$other$than$those$certified$with$the$product$is$expressly$forbidden$in$accordance$to$FCC$rules$
CFR47$part$15.204.$The$installer$should$configure$the$output$power$level$of$antennas,$according$to$country$
regulations$and$per$antenna$type.$Professional$installation$is$required$of$equipment$with$connectors$to$ensure$
compliance$with$health$and$safety$issues.$$
CE&Declaration&of&Conformity&
Hereby$MikroTik$declares$that$this$product$is$in$compliance$with$the$essential$requirements$and$
other$relevant$provisions$of$Directive$1999/5/EC.$The$Declaration$of$Conformity$may$be$obtained$
by$contacting$sales@mikrotik.com.$$
$
