MilDef Crete RV11 Notebook Computer User Manual RV11
MilDef Crete Inc. Notebook Computer RV11
Users Manual
NOTEBOOK COMPUTER
RV11
User’s Guide
I
Notice
The company reserves the right to revise this publication or to change its
contents without any notice. Information contained herein is for reference only
and does not constitute a commitment on the part of the manufacturer or any
subsequent vendor. They assume no responsibility or liability for any errors or
inaccuracies that may appear in this publication nor are they in anyway
responsible for any loss or damage resulting from the use (or misuse) of this
publication.
Any of the software described in this manual is sold or licensed "as is". Should
the programs prove defective following purchase, the buyer (and not the
manufacturer, its distributor, or its dealer) assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any software defects.
Brand and product names mentioned in this publication may or may not be
copyrights and/or registered trademarks of their respective companies. They
are mentioned for identification purposes only and are not intended as an
endorsement of that product or its manufacturer.
Copyright © 2014 MilDef Crete Inc.
Trademarks
All other brand and product names are trademarks or registered trademarks of
their respective companies.
II
Revision History:
Revision Date Changes Author
III
FCC (Federal Communications Commission) Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device pursuant part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and radiates radio frequency energy. If not
being installed and used in accordance with the instructions, it may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
Re-orient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
FCC Caution:
To assure continued compliance, any changes or modifications not
expressly approved by the party responsible for compliance could void
the user's authority to operate this equipment. (Example - use only
shielded interface cables when connecting to computer or peripheral
devices).
IV
Regulatory Information/ Disclaimers
Installation and use of this computer must be in strict accordance with the
instructions included in the user documentation provided with the product. Any
changes or modifications (including the antennas) made to this device that are
not expressly approved by the manufacturer may void the user’s authority to
operate the equipment.
The manufacturer is not responsible for any radio or television interference
caused by unauthorized modification of this device, or the substitution of the
connecting cables and equipment other than manufacturer specified. It is the
responsibility of the user to correct any interference caused by such
unauthorized modification, substitution or attachment. Manufacturer and its
authorized resellers or distributors will assume no liability for any damage or
violation of government regulations arising from failing to comply with these
guidelines.
V
CE
Products with the CE Marking comply with both the EMC Directive
(2004/108/EC) and the Low Voltage Directive (2006/95/EC) issued by the
Commission of the European Community.
Compliance with these directives implies conformity to the following European
Norms:
EN55022 CISPR 22 Radio Frequency Interference
EN55024 EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5,
EN61000-4-6, EN61000-4-8, EN61000-4-11, EN61000-3-2,
EN61000-3-3, Generic Immunity Standard
LV D EN 60950-1: 2006+ A11: 2009+ A1: 2010+ A12: 2011
IEC 60950-1: 2005+AM1:2009
R&TTE (CE) Manual Regulatory Requirement
WLAN - IEEE 802.11a/b/g/n
802.11a/b/g/n Restrictions:
European standards dictate maximum radiated transmit power of 100mW
EIRP and frequency range 2.400-2.4835 GHz.
VI
CE Declaration of Conformity
It is confirmed to comply with the requirements set out in the Council Directive
on the approximation of the laws of the member states relating to
Electromagnetic Compatibility (2004/108/EC), Low-voltage Directive
(2006/95/EC), the Amendment Directive (93/68/EEC), and the procedures
given in European Council Directive (99/5/EC and 2004/108/EC ).
The equipment was passed, and the equipment test was performed according
to the following European standards:
EN 300 328 V1.8.1 (2012)
EN 301 893 V1.7.1 (2012)
EN 301 489-1 V1.9.2 (2011)
EN 301 489–3 V1.6.1 (2013)
EN 301 489-17 V2.2.1 (2012)
EN62311 2008
EN300440-1 V1.6.1 2010
EN300440-2 V1.4.1 2010
UL, TÜV
AC Adapter (TÜV includes LVD EN60950)
VII
Power Conservation
This computer consumes much less power than conventional computers.
However, power consumption may be further reduced by configuring the
Power Management Setup.
It is recommended to enable power-saving functions when operating this
computer, as Power Management functions do not impact system
performance while saving power.
Power Safety
There are specific power requirements for this computer:
Only use an approved power adapter for this computer.
There is a 3-prong grounded plug of the power adapter. The third prong
serves as Ground and is an important safety feature. If a compatible outlet
is not available, consult qualified electricians for installation.
When unplugging the power cord, please be sure to unplug from the plug
head instead of pulling from the wire.
Make sure the socket and any other extension cords you use can support
the total current load of all the connected devices.
Before cleaning the computer, make sure it is disconnected from any
external power supplies.
Warning:
Before any upgrade procedures, make sure the power is turned off, and all
the cables are disconnected. Also, it is advisable to remove your battery in
prevent from turning the computer on accidentally.
VIII
Battery Precautions
Only use batteries designed for this computer. Wrong and incompatible
batteries may cause explosion, leakage or damage to the computer.
Do not remove the battery from the computer while it is powered on.
Do not continuously use a battery that has been dropped, or that appears
damaged (e.g. bent or twisted) in any way. Even if the computer is able to
continuously work with a damaged battery, the circuit damage may occur
and possibly cause fire.
Always use the notebook’s system or charger to recharge the battery.
Incorrect recharging may cause the battery to explode.
Do not try to repair a battery pack by yourself. Refer to any battery pack
repair or replacement, please contact with to your service representative
or qualified service personnel.
Please dispose damaged battery promptly and carefully. Explosion or
leakage may occur, if the battery is exposed to fire, improperly handled or
discarded.
Battery Disposal & Caution:
The product that you have purchased contains a rechargeable battery.
The battery is recyclable. At the end of its service life, under various state
and local laws, it may be illegal to dispose of this battery into the
municipal waste stream. Check with your local solid waste officials for
details in your area for recycling options or proper disposal. Danger of
explosion may possibly occur, if the battery is incorrectly replaced.
Replace only with the same or the equivalent battery recommended by
the manufacturer. Discard the used battery according to the
manufacturer’s instructions.
IX
Environmental Information, Material Safety & Recycling
All materials used in the manufacturing of this equipment are recyclable or
environmentally friendly.
Please recycle the packing materials in accordance to local regulations at the
end of the product's service life.
Notice:
The equipment may contain insignificant amount of hazardous
substances for health and environment below control level.
To avoid spreading such substances into the eco system, and to minimize
the pressure on the natural environment, you are encouraged to use the
appropriate take-back for reusing or recycling most of the materials in a
safe way after the product’s service life.
The crossed-bin symbol indicates proper disposal is required.
For more information on collection, reuse and recycling, please consult
the local or regional waste administration for more information.
You can also contact your dealer for more information on the
environmental details of the equipment.
The symbol of the crossed-out wheeled bin indicates that the
product (electrical and electronic equipment) should not be
placed in municipal waste. Please check local regulations for
disposal of electronic products.
TABLE OF CONTENTS
CHAPTER ONE - GETTING STARTED ........................................1
UNPACKING ...............................................................................................1
QUICK OPERATION .....................................................................................2
APPEARANCE OVERVIEW ............................................................................3
CHAPTER TWO - OPERATING INFORMATION..........................8
WORKPLACE..............................................................................................8
RUGGEDNESS ............................................................................................8
INSTALLING OPERATING SYSTEM .................................................................8
BOOT UP AND POST..................................................................................9
SHUT DOWN...............................................................................................9
SLEEP/HIBERNATE ...................................................................................10
INTEL® RAPID START TECHNOLOGY ...........................................................11
TOUCHPAD ..............................................................................................12
KEYBOARD ..............................................................................................13
MANAGING SOLID STATIC DRIVE (SSD) .....................................................14
USING SD CARD / SIM CARD....................................................................14
RTC .......................................................................................................15
SAVE GUARD THE COMPUTER ...................................................................16
WIRELESS DEVICES (OPTION)...................................................................17
CHAPTER THREE - MANAGING POWER .................................20
AC ADAPTER ...........................................................................................20
BATTERY .................................................................................................21
POWER CONSERVATION ...........................................................................22
SUPPORTING ACPI ..................................................................................23
USB FAST CHARGING...............................................................................24
CHAPTER FOUR - BIOS SETUP................................................25
MAIN MENU .............................................................................................25
ADVANCED MENU.....................................................................................26
TRUSTED COMPUTING SUB-MENU .............................................................28
SATA CONFIGURATION SUB-MENU ...........................................................29
SATA CONFIGURATION SUB-MENU SELECTIONS........................................29
INTEL (R) RAPID START TECHNOLOGY SUB-MENU ......................................30
USB CONFIGURATION SUB-MENU .............................................................30
USB CONFIGURATION SUB-MENU SELECTIONS..........................................31
SUPER IO CONFIGURATION SUB-MENU......................................................32
RF DEVICE CONTROL CONFIGURATION SUB-MENU.....................................33
EC THERMAL CONTROL SUB-MENU ..........................................................34
AC IN BOOT SUB-MENU .........................................................................34
USB CHARGE CONTROL SUB-MENU.......................................................35
INTEL SMART CONNECT TECHNOLOGY SUB-MENU......................................35
INTEL 82579LM GIGABIT NETWORK CONNECTION SUB-MENU.....................36
CHIPSET MENU ........................................................................................37
PCH-IO CONFIGURATION SUB-MENU........................................................37
PCI EXPRESS CONFIGURATION SUB-MENU................................................38
USB CONFIGURATION SUB-MENU .............................................................38
PCH AZALIZ CONFIGURATION SUB-MENU ..................................................39
BOOT MENU ............................................................................................40
BOOT MENU SELECTIONS .........................................................................40
SECURITY MENU ......................................................................................43
SAVE & EXIT MENU ..................................................................................44
CHAPTER FIVE - DRIVERS AND APPLICATIONS ...................45
CHIPSET..................................................................................................45
VGA .......................................................................................................45
AUDIO .....................................................................................................46
INTEL ME ................................................................................................46
INTEL RAPID STORAGE TECHNOLOGY ........................................................46
WIRELESS POWER MANAGER....................................................................47
TOUCH PAD .............................................................................................47
TURBO BOOST MONITOR ..........................................................................47
GIGABIT LAN...........................................................................................48
2ND GIGABIT LAN (OPTION) .....................................................................48
WIFI (OPTION).........................................................................................48
BLUETOOTH (OPTION) ..............................................................................49
GPS (OPTION) ........................................................................................50
TPM (OPTION) ........................................................................................51
CHAPTER SIX - SPECIFICATIONS............................................52
PLATFORM...............................................................................................52
CPU .......................................................................................................52
PCH .......................................................................................................52
MEMORY .................................................................................................52
DISPLAY ..................................................................................................52
KEYBOARD ..............................................................................................52
TOUCHPAD ..............................................................................................53
SOLID STATE DRIVE (SSD).......................................................................53
I/O PORTS...............................................................................................53
POWER ...................................................................................................54
SYSTEM UNIT DIMENSIONS AND WEIGHT....................................................54
MATERIALS AND RECYCLING .....................................................................55
ENVIRONMENTAL SPECIFICATIONS .............................................................55
CERTIFICATIONS ......................................................................................55
CHAPTER SEVEN - OPTIONAL DEVICES ................................56
COMMUNICATION......................................................................................56
WEBCAM.................................................................................................56
MEMORY .................................................................................................56
MIL. FISCHER CONNECTOR .......................................................................56
TEST CABLE ............................................................................................57
TRUST PLATFORM MODULE (TPM)............................................................57
CHAPTER EIGHT - MAINTENANCE AND SERVICE.................58
CLEANING................................................................................................58
TROUBLESHOOTING..................................................................................58
RMA SERVICE .........................................................................................59
Chapter One - 1
Getting Started
Chapter One - Getting Started
Unpacking
The following components are shipped along with your computer. If any
component is missing or damaged, please notify the dealer immediately.
Computer Unit
AC Adapter
AC Power Cord
Utility DVD
Quick Guide
Chapter One - 2
Getting Started
Quick Operation
Mount the battery and tighten the battery screws. Notice that the middle
screw should be tightened first and then the other sides, as the illustration
shows below.
Tighten the middle screw
first (the circled one).
Connect the AC adapter with the computer and start charging the battery
for at least 10 minutes.
Turn ON the computer by pressing the power button.
Note:
Drivers or applications installation may be necessary for further operation.
Chapter One - 3
Getting Started
Appearance Overview
LCD Panel Open
1. Embedded Antennas (Optional):
GPS, WiFi/Bluetooth x 2
2. Optional WebCam
3. Embedded Mic
4. LED Indicators
5. Power Button
6. Touchpad
7. Touchpad Right and Left buttons
Power Indicator (Dual LED):
Green (Power)
Flashing Green (S3)
Charger/Battery low:
Orange (Charging) / Flashing
Orange (Battery low)
HDD/Heater Indicator:
Green (HDD) / Orange
(Heater)
Note:
For details, please refer to “Touchpad” section.
1
3
6
4
5
7
2
Chapter One - 4
Getting Started
Right View
1. 2.5” SATAIII 7mm SSD
2. Kensington lock slot
1 2
Chapter One - 5
Getting Started
Left View
1. GLAN RJ45
2. USB 3.0 x 1
3. USB 3.0 x 1 with Fast Charger
4. SD Card Slot x 1 + SIM Card Slot x 1
123
4
Chapter One - 6
Getting Started
Rear View
1. DC Power Jack
(Std.: DC-in 2-pin; optional: Military 3-pin)
Optional Fischer connectors:
- L1: USB2.0
- L2: VGA
- L3: RS232 or RS422
- L4: RS232 or RS422
- L5: GLAN
- L6: Audio
1 L1 L2 L3 L4 L5 L6
Chapter One - 7
Getting Started
Bottom View
1. Multi Bay port
2. Battery pack
1
2
Chapter Two - 8
Operating Information
Chapter Two - Operating Information
Workplace
A clean and moisture-free environment is preferred. Make room for air
circulation. Remember to avoid areas from:
Sudden or extreme changes in temperature.
Extreme heat.
Strong electromagnetic fields (near television set, motor rotation area,
etc.).
Dust or high humidity.
If it is necessary to work in a hostile environment, please regularly maintain
your notebook computer by cleaning dust, water, and etc. to keep it in an
optimal condition.
Ruggedness
This notebook computer is designed with rugged features such as vibration,
shock, dust, and rain/ water protection. However, it is still necessary to provide
appropriate protection while operating in harsh environments.
The notebook computer is also designed to withstand rainfall from top with
mild wind blowing only. Please keep the keyboard facing up, i.e. normal
operating direction, to maintain water resistance. NEVER immerse the unit in
water, or spray water at an upside-down system. Doing so may cause
permanent damage.
All connectors will be corroded if being exposed to water or moisture.
Corrosion is accelerated if the power is ON. Please take proper water-resistant
measures for cable connections. The DC jack and cables are sealed and may
be operated with water splashing while attached. All port covers should be in
place when no cable is attached.
Installing Operating System
Your computer is designed to operate with Microsoft Windows 7 / 8 32 / 64-bit
Operating System. Please connect your computer with an external
USB-interface drive, such as an ODD or a USB thumb drive, and start the OS
installation.
Chapter Two - 9
Operating Information
Boot Up and POST
Boot up
The computer turns ON and loads the operating system (such as Windows)
into the system memory. This start-up procedure is called “boot up”.
The ROM BIOS Power on Self-Test (POST)
Each time when the computer powers on, it automatically performs a self-test
of its memory and hardware devices.
Shut down
Directly click “Shut down” from your OS to turn OFF the power of your
computer. Before shutting down, please do remember to save any unfinished
works and close your applications to prevent your SSD from suffering possible
data loss or damage. “Shut down” will turn OFF power of your computer. If you
want to start your computer again, you need to turn it ON again by pressing the
power button.
Force Shut Down
In the event that your notebook computer hangs or stops responding, you can
perform a force shut down by pressing and holding the power button for 4~5
seconds. Please note that any unsaved work or data will be lost this way.
Chapter Two - 10
Operating Information
Sleep/Hibernate
Sleep
Under “Sleep” mode, the system will temporarily save your work into the
computer’s RAM. If you want to start your computer again, please press the
power button to resume. Under Windows 8, you can enter this mode by directly
clicking:
Move your mouse to the upper-right or lower-right corner of the screen,
and then click “Settings” => Click “Power” => Click “Sleep”.
Hibernate
Under “Hibernate” mode, the system will save your work into SSD. If you want
to start your notebook computer again, you need to press the power button.
Under Windows 8, you can enter “Hibernate” mode by directly clicking:
Move your mouse to the upper-right or lower-right corner of the screen,
and then click “Settings” => Click “Power” => Click “Hibernate”.
Chapter Two - 11
Operating Information
Intel® Rapid Start Technology
Your notebook computer can operate Intel® Rapid Start Technology when SSD
is installed. This technology enables your system resume time not only to be
as fast as wake-up time from S3 (Sleep) mode, but also to be more energy
saving.
Before using Intel® Rapid Storage Technology, please check the following
system requirements:
System Requirement:
Intel QM77 Express Chipset-based desktop board
Intel Ivy Bridge i7-3517UE
Solid State Drive (SSD)
Operating system
- Microsoft Windows 7 or 8 (32- or 64-bit edition) in Legacy mode
- Microsoft Windows 7 or 8 (64-bit edition) in UEFI mode
Note:
Intel® Rapid Storage Technology Driver should be installed and can be
found in Utility DVD.
Please refer to the User Guide from Intel official website for setting up the
function. There are two kinds of User Guide, “Intel® Rapid Start
Technology User Guide for UEFI Mode” and “Intel® Rapid Start
Technology User Guide.” The former is for UEFI mode, while the latter is
for legacy mode.
Please remember to enable Rapid Start Technology from BIOS Advanced
Menu.
To cancel the Rapid Start Technology, please disable the function from
Chapter Two - 12
Operating Information
Touchpad
The touchpad features large-area, multi-touch, and Windows 8 supported. For
usage details, please see the following table.
No. Item Description
1. Touchpad Multi-touchpad features in click, scroll,
swipe, rotate, and pinch.
2. Left-click button Similar to left button of mouse
3. Right-click button Similar to right button of mouse
Note:
You can press Fn+F12 to enable/disable touchpad function.
1
2 3
Chapter Two - 13
Operating Information
Keyboard
The keyboard is functionally equivalent to a full size desktop keyboard. A
sample layout is shown as below.
Function Key Combinations
Key Description
[Fn] + [F3] Decrease LCD brightness
[Fn] + [F4] Increase LCD brightness
[Fn] + [F5] Mute
[Fn] + [F6] Volume down
[Fn] + [F7] Volume up
[Fn] + [F9] Decrease keyboard backlight
[Fn] + [F10] Increase keyboard backlight
[Fn] + [F12] Touchpad lock
Chapter Two - 14
Operating Information
Managing Solid Static Drive (SSD)
The Solid Static Drive (SSD) is a 2.5” type/ 7mm height standard SATAII/III
interface data storage device. Some functions, such as Rapid Start
Technology, are required to use SSD for operation.
Using SD Card / SIM Card
The card slots are located at the bottom-right side of your notebook computer.
To remove the card slot cover, please use an appropriate screwdriver and turn
counterclockwise to unlock.
The SIM card slot occupies the top side of the expansion cards compartment.
The SD card slot is located at the bottom.
Please take note of the card slot differences to prevent insertion of
incompatible card types, and do not attempt to force the cards into wrong card
slots to prevent from damaging your computer.
The design of SIM card and SD card slots are foolproof; if you encounter
difficulty in inserting the cards, please turn/reverse the cards and try again.
When inserting SIM card and SD card, the connector pins of your cards should
be facing down, as the following illustration shows.
Note:
Please always turn off the computer before inserting or rejecting SIM
Card.
SIM Card
SD Card
Chapter Two - 15
Operating Information
Insert SIM Card:
Insert SD card:
RTC
Battery backed up RTC (Real Time Clock/Calendar) is built in an on-board
CMOS (Complementary Metal Oxide Semiconductor) chip. The RTC keeps
track of the time and date while the computer is off. The CMOS chip also
stores system setup information.
RTC battery is also recharged when AC adapter is attached. Recharge the
computer approximately once per month to ensure RTC operation.
Insert SD Card into the
bottom card slot with pins
facing down.
Insert SIM card into the top
card slot with pins facing
down.
Chapter Two - 16
Operating Information
Save Guard the Computer
The Kensington lock slot is on the right side of the computer. Plug the
Kensington lock into the slot and lock it. Both the computer and SSD are
secured.
Note:
Kensington lock is a widely available 3rd party product.
Chapter Two - 17
Operating Information
Wireless Devices (Option)
For your ease of operations, you can turn on/off your wireless devices through
the proprietary software application - “Device Power Manager”.
Wireless LAN
1. Driver & Application Installation
a. Install the Chipset Driver first. Read from the Utility DVD and find the
directory listed in the readme file to finish installation.
b. Then, install the Device Power Manager application. Read from the
Utility DVD and find the directory listed in the readme file to finish
installation.
2. Launch the Device Power Manager
After launching the utility, please click “Wireless LAN” for enabling the
Wireless LAN function (click again to disable).
Once the Wireless LAN function starts up, the wireless device LED indicator
will turn on (color blue) and the Wireless LAN icon will appear in the OS
accordingly.
Note:
Depending on the configuration of your notebook computer, your Device
Power Manager menu may appear differently from the screenshots provided
in this section.
When you adjust User Account Control (UAC), a security feature in Windows,
the setting value of Device Power Manager will be affected. So, once there is
any adjustment in UAC, please uninstall Device Power Manager and reinstall
it again.
Chapter Two - 18
Operating Information
Bluetooth
1. Driver & Application Installation
a. Install the Bluetooth driver first. Read from the Utility DVD and find
the directory listed in the readme file to finish installation.
b. Install the Device Power Manager application. Read from the Utility
DVD and find the directory listed in the readme file to finish
installation.
2. Launch the Device Power Manager
After launching the utility, please click “Bluetooth” to enable the Bluetooth
function (click again to disable). Once the Bluetooth function starts up, the
wireless LED indicator (color blue) will turn on and the Bluetooth icon will
show up in the operating system accordingly.
Chapter Two - 19
Operating Information
GPS
1. Driver & Application Installation
a. Install the Device Power Manager application:
Read from the Utility DVD and find the directory listed in the readme
file to finish installation.
b. Install the GPS driver:
GPS (Driver): Read from the Utility DVD and find the directory listed
in the readme file to finish installation.
Chapter Three - 20
Managing Power
Chapter Three - Managing Power
AC Adapter
The AC adapter performs two functions:
It powers the computer from an external AC source.
It charges the computer battery.
The adapter automatically detects the AC line voltage (100V or 240V) and
adjusts accordingly.
The following are recommended when using the AC adapter:
Use a properly grounded AC outlet.
Use one AC outlet exclusively for the computer. Having other appliances
on the same line may cause interference.
Use a power strip with built-in surge protection.
Connecting the AC adapter:
Plug the AC cord to the adapter.
Plug the other end of the AC cord into the wall outlet. Make sure the green
LED on the adapter turns on.
Attach the DC plug into the power jack of the computer; turn the lock ring
clockwise to secure it.
AC Adapter Indicator:
The green LED indicates that AC power is ready.
Note:
To ensure system stability, please connect your computer to an
external power source when operating at -20
°
C ambient
temperature.
Chapter Three - 21
Managing Power
Battery
The power source will automatically switch to battery when the external power
source (AC adapter or optional vehicle adapter) is disconnected.
Battery Low
When the battery is nearly exhausted, the computer gives the following
“Battery Low” warnings:
Windows battery low warning (when operating system is Windows).
The battery charger LED flashes.
Once the Battery Low warning occurs, please:
Save and close the files you are currently working on.
Plug in the AC adapter to recharge the battery.
Charging the Battery
Plug in the AC adapter or vehicle adapter to start the battery charging. If the
battery is already full, the sense circuitry will stop high current charge within
several minutes.
The LED Indicator turns ON when the battery is charging and turns OFF when
the battery charge is completed.
Battery Gauge
You may check battery status from battery gauge in Windows. Click the
power/battery icon to reveal the battery gauge window.
Chapter Three - 22
Managing Power
Battery Power Saving Tips
The computer comes with an intelligent power-saving feature. You may extend
the battery life by:
Setup power saving functions in Operating System Power Management
options (e.g. Windows Power Options).
Lower the intensity of the display by brightness control.
Use standby option when computer is temporarily not in use.
Shut down the computer when it will not be for a long-time use.
Replacing Battery
When the battery is nearly exhausted, there are two ways to keep your
computer working. Connect the AC adapter and the power cord designed for
this notebook computer to start charging is one method; directly replace a
charged battery designed for this notebook computer may be the other one.
Power Conservation
This computer consumes much less power than conventional computers.
However, power consumption may be reduced by configuring the Power
Management Setup properly.
It is recommended the power saving functions to be enabled even when not
running on battery power. Power Management will not degrade performance
while saving power.
Note:
Always remember to turn OFF the power before replacing the
battery.
Chapter Three - 23
Managing Power
Supporting ACPI
Your notebook computer supports ACPI (Advanced Configuration and Power
Interface) for power management. With ACPI and an ACPI-compliant
operating system such as Windows, the feature will allow you to reduce the
power consumption for energy saving. By supporting ACPI, the AC adapter
LED and the Power indicator LED will show in different ways. The followings
are the detailed description.
Sleep:
AC adapter LED is ON (while connecting with power)
Power LED indicator is flashing; other LED indicators are OFF
Under Hibernation:
AC adapter LED is ON (while connecting with power)
Power LED indicator is OFF; other LED indicators are OFF
Shutdown:
AC adapter LED is ON (while connecting with power)
Power LED indicator is OFF; other LED indicators are OFF
Chapter Three - 24
Managing Power
USB Fast charging
Your computer supports USB fast charging feature, enabling to quickly charge
your fast-charging compatible devices. But note, fast charging is not supported
for all power modes. The following table shows details for USB Charging
information:
Mode USB3.0 Charging Features
AC Fast charging supports
Power off Battery No charging
AC Normal charging
Power on Battery Normal charging
AC Fast charging supports
S3 Battery Fast charging supports
Note:
When enable USB fast charging from USB CHARGE control in BIOS, please
cold boot your computer to enable the function.
Chapter Four - 25
BIOS Setup
Chapter Four - BIOS Setup
Press [F2] at boot up to enter BIOS setup. Use arrow keys to select options
and [+/-] to modify them. When finished, move to “Exit” and press [Enter] then
confirm save by pressing [Y].
Main Menu
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
Choose the system
default language
BIOS Information
BIOS Vendor
Core Version
Compliancy
Project Version
Build Date and Time
EC Version
System Language [English]
System Date [Mon 05/20/2013]
System Time [16:19:20]
Access Level Administrator
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Main Menu Selections
You can make the following selections on the Main Menu. Use the sub-menus
for other selections.
Feature Options Description
System Date MM/DD/YYYY Set the Date. Use Tab to switch
between Date elements
System Time HH:MM:SS Set the Time. Use Tab to switch
between Time elements.
Note:
The contents may vary depending on computer configurations.
You can check your BIOS/EC Version on the main menu.
Incorrect settings may cause system malfunction. To correct it, restore the
Optimized Defaults with F3.
Chapter Four - 26
BIOS Setup
Advanced Menu
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
Trusted Computing
Setting
► Trusted Computing
► SATA Configuration
► Intel (R) Rapid Start Technology
► USB Configuration
► Super IO Configuration
► RF Device Control
► EC Thermal Control
► AC IN BOOT Control
► USB CHARGE Control
► Intel (R) Smart Connect Technology
► Intel (R) 82579LM Gigabit Network Connection
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Chapter Four - 27
BIOS Setup
Advanced Menu Selections
You can make the following selections on the Advanced Menu.
Feature Options Description
Trusted
Computing
Disabled
Enabled
TPM Support
SATA
Configuration
SATA Mode
Selection
SATA Test Mode
Aggressive LPM
Support
SATA Controller
Speed
SATA Mode Selection:
IDE/AHCI/RAID
SATA Test Mode:
Enabled/Disabled
Aggressive LPM Support:
Enabled/Disabled
SATA Controller Speed:
Gen1/Gen2/Gen3
Intel (R) Rapid
Start
Technology
Disabled
Enabled
Allows the system to skip certain
tests while booting. This will
decrease the time needed to boot
the system.
USB
Configuration
Disabled
Enabled
Legacy USB Support
USB3.0 Support
XHCI Hand-off
EHCI Hand-off
Generic Storage Device 0.00
Super IO
Configuration
Serial Port 0
Configuration
Serial Port 1
Configuration
Serial Port 2
Configuration
Serial Port 3
Configuration
Set Parameters of Serial Port o
(COMA)
RF Device
Control
Disabled
Enabled
GPS/BLUETOOTH/WLAN
EC Thermal
Control
Thermal cooling trip point
AC IN BOOT
Control
Disabled
Enabled
USB CHARGE
Control
Disabled
Enabled
Chapter Four - 28
BIOS Setup
Feature Options Description
Intel Smart
Connect
Technology
Disabled
Enabled
Intel Smart Connect Technology
Settings
Intel 82579LM
Gigabit
Network
Connection
NIC Configuration
Blink LEDs (range
0/15 seconds)
Link Status
Configure Gigabit Ethernet device
parameters
Trusted Computing Sub-Menu
Aptio Setup Utility
Advanced
Enables or Disables
BIOS support for
security device. O.S.
will not show Security
Device. TCG EFI
protocol and INT1A
interface will not be
available.
Configuration
Security Device Support [Disabled]
Current Status Information
SUPPORT TURNED OFF
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Chapter Four - 29
BIOS Setup
SATA Configuration Sub-Menu
Aptio Setup Utility
Advanced
Determine how SATA
controller(s) operate.
SATA Mode Selection [AHCI]
SATA Test Mode [Disabled]
Aggressive LPM Support [Enabled]
SATA Controller Speed [Gen3]
Serial ATA Port 0 HGST HTS725050 (500.1GB)
Software Preserve SUPPORTED
Serial ATA Port 0 Empty
Software Preserve Unknown
Serial ATA Port 0 Empty
Software Preserve Unknown
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
SATA Configuration Sub-Menu Selections
You can make the following selections on the SATA configuration sub-menu.
Feature Options Description
SATA Mode
Selection
IDE
AHCI
RAID
SATA Test
Mode
Disabled
Enabled
Enable or Disable Test Mode
Aggressive
LPM Support
Disabled
Enabled
Enable PCH to aggressively enter
link power state.
SATA
Controller
Speed
Gen1
Gen2
Gen3
Indicate the maximum speed the
SATA controller can support.
Chapter Four - 30
BIOS Setup
Intel (R) Rapid Start Technology Sub-Menu
Aptio Setup Utility
Advanced
Enable or disable Intel
(R) Rapid Start
Technology
Intel (R) Rapis Start Technology [Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
USB Configuration Sub-Menu
Aptio Setup Utility
Advanced
Enables Legacy USB
support.
AUTO option disables
legacy support if no USB
devices are connected.
Disable option will keep
USB devices available
only for EFI applications
USB Configuration
USB Devices:
2 Hubs
Legacy USB Support [Enabled]
USB3.0 Support [Enabled]
XHCI Hand-off [Enabled]
EHCI Hand-off [Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Chapter Four - 31
BIOS Setup
USB Configuration Sub-Menu Selections
You can make the following selections on the USB configuration sub-menu.
Feature Options Description
Legacy USB
enabled
Disabled
Enabled
Auto
Enables Legacy USB support.
AUTO option disables legacy
support if no USB devices are
connected. DISABLE option will
keep USB devices available only
for EFI applications.
USB3.0
Support
Disabled
Enabled
Enable/Disable USB3.0 (XHCI)
Controller support.
XHCI Hand-off Disabled
Enabled
This is a workaround for OSes
without XHCI hand-off support.
This XHCI ownership change
should be claimed by XHCI
driver.
EHCI Hand-off Disabled
Enabled
This is a workaround for OSes
without EHCI hand-off support.
This EHCI ownership change
should be claimed by EHCI
driver.
Chapter Four - 32
BIOS Setup
Super IO Configuration Sub-Menu
Aptio Setup Utility
Advanced
Set Parameters of Serial
Port 0 (COMA)
Super IO configuration
Super IO Chip IT8760
►Serial Port 0 Configuration
►Serial Port 1 Configuration
►Serial Port 2 Configuration
►Serial Port 3 Configuration →←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Super IO Configuration Sub-Menu Selections
You can make the following selections on the IT8783F super IO configuration
sub-menu.
Feature Options Description
Serial Port Disabled
Enabled
Enable or Disable Serial
Port (COM)
Change
Settings
Auto
IO=3F8h; IRQ=4;
IO=3F8h;
IRQ=3,4,5,6,7,10,11,12;
IO=2F8h;
IRQ=3,4,5,6,7,10,11,12;
IO=3E8h;
IRQ=3,4,5,6,7,10,11,12;
IO=2E8h;
IRQ=3,4,5,6,7,10,11,12;
Select an optimal setting
for Super IO device.
Chapter Four - 33
BIOS Setup
RF Device Control Configuration Sub-Menu
Aptio Setup Utility
Advanced
RF Device Control Setting
RF Device Control
GPS STATUS Present
GPS [Enabled]
BT STATUS Present
BLUETOOTH [Enabled]
WLAN STATUS Present
WLAN [Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
RF Device Control Configuration Sub-Menu Selections
You can make the following selections on the RF Security Control sub-menu.
Feature Options Description
GPS Disabled
Enabled
RF Device Control Setting
BLUETOOTH Disabled
Enabled
RF Device Control Setting
WLAN Disabled
Enabled
RF Device Control Setting
Chapter Four - 34
BIOS Setup
EC Thermal Control Sub-Menu
Aptio Setup Utility
Advanced
EC Thermal Control
Setting
EC Thermal Control
Thermal cooling trip point [87 C]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
AC IN BOOT Sub-Menu
Aptio Setup Utility
Advanced
AC IN BOOT Setting
AC IN BOOT Control
AC IN BOOT Control [Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Chapter Four - 35
BIOS Setup
USB CHARGE Control Sub-Menu
Aptio Setup Utility
Advanced
USB CHARGE Setting
USB CHARGE Control
USB CHARGE Control [Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Intel Smart Connect Technology Sub-Menu
Aptio Setup Utility
Advanced
Enable/Disable ISCT
Configuration
ISCT Configuration [Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Note:
After enabling USB fast charge function, please cold boot your
computer.
Chapter Four - 36
BIOS Setup
Intel 82579LM Gigabit Network Connection Sub-Menu
Aptio Setup Utility
Advanced
Click to configure the
network device port
PORT CONFIGURATION MENU
NIC Configuration
Blink LEDs (range 0-15 seconds) 0
PORT CONFIGURATION INFORMATION
UEFI Driver: Intel PRO/1000 5.0.12
Adapter PBA: FFFFFF-OFF
Chip Type: Intel PCH2
PCI Device ID 1502
PCI Bus:Device:Function: 0:25:0
Link Status [Disconnected]
Factory MAC Address: 88:88:88:88:87:88
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
INTEL 82579LM Gigabit Network Connection Sub-Menu Selections
You can make the following selections on the RF Security Control sub-menu.
Feature Options Description
NIC Configuration
LINK Speed
Wake on LAN
Change link speed and duplex
for current port.
Enable this option to wake the
system with a magic packet
Blink LEDs (range
0-15 seconds) Blink LEDs for the specified
duration (up to 15 seconds).
Chapter Four - 37
BIOS Setup
Chipset Menu
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
PCH Parameter
► PCH-IO Configuration
► System Agent (SA) Configuration
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
PCH-IO Configuration Sub-Menu
Aptio Setup Utility
Chipset
PCI Express
Configuration settings
Intel PCH RC Version 1.6.0.0
Intel PCH SKU Name QM77
Intel PCH Rev ID 04/C1
► PCI Express Configuration
► USB Configuration
► PCH Azalia Configuration
PCH LAN Controller [Enabled]
Wake on LAN [Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Chapter Four - 38
BIOS Setup
PCI Express Configuration Sub-Menu
Aptio Setup Utility
Advanced
Enable or disable PCI
Express Clock Gating
for each root port
PCI Express Configuration
PCI Express Clock Gating [Enabled]
DMI Link ASPM Control [Enabled]
DMIO Link Extended Synch Control [Disabled]
PCIe-USB Glitch W/A [Disabled]
Subtractive Decode [Disabled]
► PCI Express Root Port 1
► PCI Express Root Port 2
► PCI Express Root Port 3
► PCI Express Root Port 4
► PCI Express Root Port 5
PCIE Port 6 is assigned to LAN
► PCI Express Root Port 7
► PCI Express Root Port 8
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
USB Configuration Sub-Menu
Aptio Setup Utility
Advanced
Enable or disable
XHCI Pre-Boot Driver
support
USB Configuration
XHCI Pre-Boot Driver [Enabled]
xHCI Mode [Smart Auto]
HS Port #1 Switchable [Enabled]
HS Port #2 Switchable [Enabled]
HS Port #3 Switchable [Enabled]
HS Port #4 Switchable [Enabled]
xHCI Streams [Enabled]
EHCI1 [Enabled]
EHCI2 [Enabled]
USB Ports Per-Port Disable Control [Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Chapter Four - 39
BIOS Setup
PCH Azaliz Configuration Sub-Menu
Aptio Setup Utility
Advanced
Control Detection of
the Azalia device.
PCH Azalia Configuration
Azalia [Auto]
Azalia Docking Support [Disabled]
Azalia PME [Disabled]
Azalia Interbal HDMI Codec [Enabled]
Azalia HDMI codec Port B [Enabled]
Azalia HDMI codec Port C [Enabled]
Azalia HDMI codec Port D [Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Chapter Four - 40
BIOS Setup
Boot Menu
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
Select boot mode
LEGACY/UEFI
Boot mode select [UEFI]
FIXED Boot ORDER Priorities
Boot Option #1 [Hard Disk: Windows B…]
Boot Option #2 [CD/DVD]
Boot Option #3 [USB Hard Disk]
Boot Option #4 USB CD/DVD]
Boot Option #5 [USB Key]
Boot Option #6 [USB Floppy]
Boot Option #7 [Network]
►CSM parameters
►UEFI Hard Disk Drive BBS Priorities
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
The system will try to boot from device on top then the 2nd and so on. If there
is more than one device in each category, only the device on top of
sub-menu can boot up.
Boot Menu Selections
You can make the following selections on the Boot menu.
Feature Options Description
Boot mode
select
LEGACY
UEFI
Select boot
mode
LEGACY/UEFI
Boot Option #1 Hard Disk: Windows Boot Manager
CD/DVD
USB Hard Disk
USB CD/DVD
USB Key
USB Floppy
Network
Disabled
Sets the system
boot order
Chapter Four - 41
BIOS Setup
Boot Option #2 Hard Disk: Windows Boot Manager
CD/DVD
USB Hard Disk
USB CD/DVD
USB Key
USB Floppy
Network
Disabled
Sets the system
boot order
Boot Option #3 Hard Disk: Windows Boot Manager
CD/DVD
USB Hard Disk
USB CD/DVD
USB Key
USB Floppy
Network
Disabled
Boot Option #4 Hard Disk: Windows Boot Manager
CD/DVD
USB Hard Disk
USB CD/DVD
USB Key
USB Floppy
Network
Disabled
Boot Option #5 Hard Disk: Windows Boot Manager
CD/DVD
USB Hard Disk
USB CD/DVD
USB Key
USB Floppy
Network
Disabled
Boot Option #6 Hard Disk: Windows Boot Manager
CD/DVD
USB Hard Disk
USB CD/DVD
USB Key
USB Floppy
Network
Disabled
Chapter Four - 42
BIOS Setup
Boot Option #7 Hard Disk: Windows Boot Manager
CD/DVD
USB Hard Disk
USB CD/DVD
USB Key
USB Floppy
Network
Disabled
CSM
parameters
Launch CSM
Boot option filter
Launch PXE OpROM policy
Launch Storage OpROM policy
Launch Video OpROM policy
Other PCI device ROM priority
OpROM
execution, boot
options filter,
etc
UEFI Hard
Disk Drive
BBS Priorities
Boot Option #1 Specifies the
Boot Device
Priority
sequence from
available UEFI
Hard Disk
Devices.
Chapter Four - 43
BIOS Setup
Security Menu
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
Set Administrator
Password
Password Description
If ONLY the Administrator’s password is set, then this
only limits access to Setup and is only asked for when
entering Setup.
If ONLY the User’s password is set, then this is a
power on password and must be entered to boot or
enter Setup. In Setup the User will have Administrator
rights.
The password length must be in the following range;
Minimum length 3
Maximum length 20
Administrator Password
User Password
Secure Boot menu
HDD Security Configuration:
PO: INTEL SSDSC2
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Chapter Four - 44
BIOS Setup
Save & Exit Menu
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
Exit system setup after
saving the changes
Save Changes and Exit
Discard Changes and Exit
Save Changes and Reset
Discard Changes and Reset
Save Options
Save Changes
Discard Changes
Restore Defaults
Save as User Defaults
Restore User Defaults
Boot Override
Windows Boot Manager
→←: Select Screen
↑↓: Select Item
Enter: Select
–/+: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Chapter Five - 45
Drivers and Applications
Chapter Five - Drivers and Applications
The Utility DVD includes all the drivers for the installed devices in your
notebook computer. Please consult the dealer if there is any driver missing.
Also, through Device Manager in Windows, you are able to perform “Driver
Update” or check if there are still drivers for the devices needed to be installed.
Please check the readme file on Utility DVD to get the latest information before
installing device drivers.
Chipset
Windows 8/Ultimate 32/ 64-bit:
Run "infinst_autol.exe" in the directory of "\Drivers\Chipset\Windows 8 (32-bit
∕64-bit)", and then follow the instructions to install.
Windows7/Ultimate 32/64-bit:
Run "Setup.exe" in the directory of "\Drivers\Chipset\Windows 7 (32-bit∕
64-bit)", and then follow the instructions to install.
VGA
Windows 8/Ultimate 64-bit:
Run "Setup.exe" in the directory of "\Drivers\VGA(Intel_HD4000)\Windows 8
(64-bit)\Win64_15313", and then follow the instructions to install.
Windows 8/Ultimate 32-bit:
Run "Setup.exe" in the directory of "\Drivers\VGA(Intel_HD4000)\Windows 8
(32-bit)\Win32_15313", and then follow the instructions to install.
Note:
Please install the chipset driver first.
If the system requests for reboot after installing drivers, please
reboot your notebook computer first before installing other drivers.
Chapter Five - 46
Drivers and Applications
Windows 7/Ultimate 64-bit:
Run "Setup.exe" in the directory of "\Drivers\VGA(Intel_HD4000)\Windows 7
(64-bit)\Win64_15319", and then follow the instructions to install.
Windows 7/Ultimate 32-bit:
Run "Setup.exe" in the directory of "\Drivers\VGA(Intel_HD4000)\Windows 7
(32-bit)\Win32_15319", and then follow the instructions to install.
Audio
Windows 8/Ultimate 32/64-bit:
Run "Setup.exe" in the directory of "\Drivers\Audio\Windows 7∕8 (32-bit∕
64-bit)\6777_PG360_Win8_Win7_Vista_XP", and then follow the instructions
to install.
Windows 7/Ultimate 32/64-bit:
Run "Setup.exe" in the directory of "\Drivers\Audio\Windows 7∕8 (32-bit∕
64-bit)\6777_PG360_Win8_Win7_Vista_XP", and then follow the instructions
to install.
Intel ME
Windows 8/Ultimate 32/64-bit:
Run "Setup.exe" in the directory of "\Drivers\Intel_ME_8.1\Windows 7∕8
(32-bit∕64-bit)", and then follow the instructions to install.
Windows 7/Ultimate 32/64-bit:
Run "Setup.exe" in the directory of "\Drivers\Intel_ME_8.1\Windows 7∕8
(32-bit∕64-bit)", and then follow the instructions to install.
Intel Rapid Storage Technology
Windows 8/Ultimate 32/64-bit:
Run "SetupRST.exe" in the directory of "Drivers\Intel Rapid Storage
Technology\Windows 7∕8 (32-bit∕64-bit)", and then follow the instructions to
install.
Windows 7/Ultimate 32/64-bit:
Run "SetupRST.exe" in the directory of "Drivers\Intel Rapid Storage
Technology\Windows 7∕8 (32-bit∕64-bit)", and then follow the instructions to
install.
Chapter Five - 47
Drivers and Applications
Wireless Power Manager
Windows 8/Ultimate 32/64-bit:
Run "setup.exe" in the directory of "\Utilities\0620\", and then follow the
instructions to install.
Windows 7/Ultimate 32/64-bit:
Run "setup.exe" in the directory of "\Utilities\0620\", and then follow the
instructions to install.
Touch Pad
Windows 8/Ultimate 32/64-bit:
Run "Setup.exe" in the directory of "\Drivers\Touch Pad (ETD)\Windows 7∕8
(32-bit ∕64-bit)\ETD11.10.7.5_ps2drv_WHQL", and then follow the
instructions to install.
Windows 7/Ultimate 32/64-bit:
Run "Setup.exe" in the directory of "\Drivers\Touch Pad (ETD)\Windows 7∕8
(32-bit ∕64-bit)\ETD11.10.7.5_ps2drv_WHQL", and then follow the
instructions to install.
Turbo Boost Monitor
Windows 8/Ultimate 32/64-bit:
Run "Setup.exe" in the directory of "\Drivers\Turbo Boost Monitor\Windows 7∕
8 (32-bit∕64-bit)", and then follow the instructions to install.
Windows 7/Ultimate 32/64-bit:
Run "Setup.exe" in the directory of "\Drivers\Turbo Boost Monitor\Windows 7∕
8 (32-bit∕64-bit)", and then follow the instructions to install.
Chapter Five - 48
Drivers and Applications
Gigabit LAN
Windows 8/Ultimate 64-bit:
Run "PROWinx64.exe" in the directory of "\Drivers\Intel_82579LM\Windows 8
(64-bit)", and then follow the instructions to install.
Windows 8/Ultimate 32-bit:
Run "PROWinx32.exe" in the directory of "\Drivers\Intel_82579LM\Windows 8
(32-bit)", and then follow the instructions to install.
Windows 7/Ultimate 64-bit:
Run "PROWinx64.exe" in the directory of "\Drivers\Intel_82579LM\Windows 7
(64-bit)", and then follow the instructions to install.
Windows 7/Ultimate 32-bit:
Run "PROWin32.exe" in the directory of "\Drivers\Intel_82579LM\Windows 7
(32-bit)", and then follow the instructions to install.
2nd Gigabit LAN (Option)
Windows 8/Ultimate 32/64-bit:
Run "setup.exe" in the directory of "\Drivers\Mini PCI-E 1G RTL8111E
LAN\Windows 7∕8 (32-bit∕64-bit)\Install_Win7_7046_07202011", and then
follow the instructions to install.
Windows 7/Ultimate 32/64-bit:
Run "setup.exe" in the directory of "\Drivers\Mini PCI-E 1G RTL8111E
LAN\Windows 7∕8 (32-bit∕64-bit)\Install_Win7_7046_07202011", and then
follow the instructions to install.
WiFi (Option)
Windows 8/Ultimate 64-bit:
Run "Wireless_15.6_De64.exe" in the directory of "\Drivers\Mini PCI-E WiFi
6235\Windows 8 (64-bit)", and then follow the instructions to install.
*: Then into the“Wireless Power Manager”to turn on the WLAN device.
Windows 8/Ultimate 32-bit:
Run "Wireless_15.6_De32.exe" in the directory of "\Drivers\Mini PCI-E WiFi
6235\Windows 8 (32-bit)", and then follow the instructions to install.
*: Then into the“Wireless Power Manager”to turn on the WLAN device.
Chapter Five - 49
Drivers and Applications
Windows 7/Ultimate 64-bit:
Run "Wireless_15.3.1_Ds64.exe" in the directory of "\Drivers\Mini PCI-E WiFi
6235\Windows 7 (64-bit)", and then follow the instructions to install.
*: Then into the“Wireless Power Manager”to turn on the WLAN device.
Windows 7/Ultimate 32-bit:
Run "Wireless_15.3.1_Ds32.exe" in the directory of "\Drivers\Mini PCI-E WiFi
6235\Windows 7 (32-bit)", and then follow the instructions to install.
*: Then into the“Wireless Power Manager”to turn on the WLAN device.
Bluetooth (Option)
Windows 8/Ultimate 64-bit:
*: First into the "Wireless Power Manager" to turn on the Bluetooth device.
Run "BT_2.6.1211_e64.exe" in the directory of
"\Drivers\Bluetooth\Windows 8 (64-bit)", and then follow the instructions to
install.
Windows 8/Ultimate 32-bit:
*: First into the "Wireless Power Manager" to turn on the Bluetooth device.
Run "BT_2.6.1211_e32.exe" in the directory of
"\Drivers\Bluetooth\Windows 8 (32-bit)", and then follow the instructions to
install.
Windows 7/Ultimate 64-bit:
*: First into the "Wireless Power Manager" to turn on the Bluetooth device.
Run "BT_2.2_s64.exe" in the directory of "\Drivers\Bluetooth\Windows 7
(64-bit)", and then follow the instructions to install.
Windows 7/Ultimate 32-bit:
*: First into the "Wireless Power Manager" to turn on the Bluetooth device.
Run "BT_2.2_s32.exe" in the directory of "\Drivers\Bluetooth\Windows 7
(32-bit)", and then follow the instructions to install.
Chapter Five - 50
Drivers and Applications
GPS (Option)
Windows 8/Ultimate 32/64-bit:
*: First into the "Wireless Power Manager" to turn on the GPS device.
Run "ublox_A4_U5_USB_drv3264_install_UI.exe" in the directory of
"\Drivers\GPS(u-blox 6H)\Windows 7∕8 (32-bit∕64-bit)", and then follow the
instructions to install.
Windows 7/Ultimate 32/64-bit:
*: First into the "Wireless Power Manager" to turn on the GPS device.
Run "ublox_A4_U5_USB_drv3264_install_UI.exe" in the directory of
"\Drivers\GPS(u-blox 6H)\Windows 7∕8 (32-bit∕64-bit)", and then follow the
instructions to install.
Chapter Five - 51
Drivers and Applications
TPM (Option)
Windows 8/Ultimate 32/64-bit:
*: First into the "BIOS" to turn on the TPM device.
Run "Setup.exe" in the directory of "\Drivers\TPM\Windows 7∕8 (32-bit
∕64-bit)", and then follow the instructions to install.
Windows 7/Ultimate 32/64-bit:
*: First into the "BIOS" to turn on the TPM device.
Run "Setup.exe" in the directory of "\Drivers\TPM\Windows 7∕8 (32-bit
∕64-bit)", and then follow the instructions to install.
Chapter Six - 52
Specifications
Chapter Six - Specifications
Platform
Intel® Chief River Platform
CPU
Intel® Ivy Bridge i7-3517UE
(4MB Intel® Smart Cache Memory)
CPU runs at multiple speeds depending on the CPU type and operating
system. Also, CPU speed switches automatically by detecting AC adapter/
battery operation and busy state.
PCH
Intel® Panther Point QM77
Memory
4/8GB System Memory
DDR3 SO-DIMM 1600MHz x 1
Display
Type: 15.6” Widescreen (LED Backlight)
Resolution: 1920 x 1080
Brightness: 230~270 nits
Keyboard
Number of keys: 87 Keys (standard 87-key with backlight)
Key Travel: 1.4 ± 0.2 (mm)
Caps Lock LED (Green)
Chapter Six - 53
Specifications
Touchpad
Type: Capacitive Touchpad with Multi-touch
Interface: PS/2
Solid State Drive (SSD)
Type: 2.5” (Removable)
Height: 7mm
Interface: SATA II/III SSD
I/O Ports
Left:
SD Card Slot x 1*
SIM Card Slot x 1
Std.
GLAN RJ45 (on board Intel GLAN)
USB 3.0
USB 3.0**
Bottom:
Multi Bay port x 1***
Rear:
DC-in Connector x 1 (Standard 2-pin; optional Military 3-pin)
Optional DC-in 12~32V with Surge Protector
Optional Fischer connectors x 6
- L1: USB2.0
- L2: VGA
- L3: RS232 or RS422
- L4: RS232 or RS422
- L5: GLAN
- L6: Audio
Note:
*SD card slot supports SDHC/SDXC format.
**1 x USB3.0 with USB-IF BC V1.2 for 1.5A fast charger
***The Multi Bay will be installed under the base. Signals include:
PCI-e x 1, USB3.0 x 1, USB2.0 x 1, Power (VBTA/1A & 5V/1A)
Chapter Six - 54
Specifications
Power
Battery:
Type: Removable Li-ion Polymer Battery Pack
Capacity: 11.1V 6040mAh
Dimension: 327.4 mm (W) x 90.7 mm (D) x 15.2 mm (H)
Weight: 448g
AC Adapter:
AC Input: 100 - 240V
Frequency: 50/60Hz
DC Output: 19V
Maximum Power: 90 Watts
DC-in 19V:
Standard: DC-in 2 pin
Optional: Military 3 pin
Optional DC-in 12~32V with Surge Protector:
Need to choose the optional BVA & Surge Protector Module
System Unit Dimensions and Weight
Dimensions (mm):
386 (L) x 299 (W) x 32 (H) (with Bumper)
382 (L) x 295 (W) x 25 (H) (without Bumper)
Weight: 3.7kg (with Battery)
Chapter Six - 55
Specifications
Materials and Recycling
Materials of the computer are as follows:
Plastic Case: Recyclable UL grade PC + ABS GE C2800 or
C6200
Aluminum Case: AL6061T6
Bracket: Aluminum 5052, Steel with nickel plating, stainless
steel S304
Cushion Pad/Button: Natural Rubber
PCB: FR-4, UL 94V0
Battery: Rechargeable Li-polymer
Packing: Carton- Recycled/Recyclable Paper (unbleached)
Cushion- Recyclable EPE
Quick Guide- Recycled/Recyclable Paper
Please recycle the parts according to the local regulations.
Environmental Specifications
Temperature: Std. -20 ~ +60ºC (-4 ~ +140ºF) operating
Opt. -40 ~ +60ºC (-40 ~ +140ºF)* operating
-40 ~ +70ºC (-40 ~ +158ºF) storage
Humidity: 5~95% Non-condensing operating
95% maximum storage
Altitude: 0 ~ 4,572 meters (0 ~ 15,000 feet) operating
Certifications
CE, FCC, WEEE, REACH, IP65 (Open Port), MIL-STD-810G,
MIL-STD-461F (Optional)
Note:
*LCD adds heater for optional operating temperature.
Chapter Seven - 56
Optional Devices
Chapter Seven - Optional Devices
Communication
WiFi/Bluetooth:
- Intel® Centrino® Advanced-N 6235, Dual Band
- Board Form Factor: PCIe Half Mini Card
- Wi-Fi Certified: 802.11 a/b/g/n
- Bluetooth: Supports BT 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE)
- Interface: PCIe (WiFi)/USB (BT)
GPS: u-blox LEA-6H (USB interface)
2nd Gigabit LAN: 1Gbps (internal Mini PCIe Card)
WebCam
An optional WebCam featuring in 1MP, HD 720p can be equipped for camera
functions, such as recording videos or shooting images.
Memory
The memory card will expand your memory to facilitate better system
performance. Industrial grade DDR3 SO-DIMM x 1 is available, supporting
4GB or 8GB DDR3 1600 memory cards.
Mil. Fischer Connector
Optional Fischer connectors provide solutions for users to operate the device
in harsh environment. Signals designed for usage include USB2.0, VGA,
RS232, RS422, GLAN, and Audio.
Chapter Seven - 57
Optional Devices
Test Cable
The following shows optional test cables available for usage:
Optional 1M VGA Test Cable (Fischer 9p to DB15)
Optional 1M RS232 Test Cable (Fischer 9p to DB9)
Optional 1M RS422 Test Cable (Fischer 9p to DB9)
Optional 1M GLAN Test Cable (Fischer 9p to RJ45)
Optional 20cm USB Test Cable (Fischer 5p to USB)
Optional 10cm Audio Test Cable (Fischer 5p to Audio Jack 3.5Φ)
Trust Platform Module (TPM)
There is an optional Trust Platform Module (TPM) equipped with this notebook
computer for users to strengthen the security.
With TPM, users are able to encrypt the folders and files directly and make the
important file be more secure and be with an additional protection. In other
words, your TPM-encrypted files are basically protected with two layers. Even
if your TPM-encrypted files are hacked, the files can not to be read without
passwords and TPM chipset.
Chapter Eight - 58
Maintenance and Service
Chapter Eight - Maintenance and Service
Cleaning
ALWAYS turn OFF the power, unplug the power cord and remove the battery
before cleaning.
The exterior of the system and display may be wiped with a clean, soft, and
lint-free cloth. If there is difficulty removing dirt, apply non-ammonia,
non-alcohol based glass cleaner to the cloth and wipe.
An air gun is recommended for cleaning water and dust. For salty water please
clean with fresh water then blow-dry with an air gun. Be sure not to turn the
computer upside-down while there is water being applied.
Troubleshooting
Should the computer fail to function properly, the troubleshooting steps below
may be followed.
Check AC/vehicle adapter, battery, and the power source.
Minimize the configuration, i.e. remove extra peripherals and devices.
Remove the software suspected.
Set BIOS fail-safe default.
Re-install operating system and application software.
Chapter Eight - 59
Maintenance and Service
RMA Service
If troubleshooting steps are unsuccessful, consult your dealer for RMA.
Shipping instructions:
1. Remove any personal disks or other media.
2. Use the original shipping container and packing materials, if possible.
3. If the original packing materials are not available, wrap the equipment with
soft material (e.g. PU/PE form) then put the wrapped equipment into a
hard cardboard shipping box.
4. Include a sheet with the following information: (Note: Please keep a copy
of this sheet for your records)
Name
Address
Unit serial number
Place and date of purchase or the original invoice number
Date of failure
A DETAILED Description of the problems you have encountered
A list of the hardware/software configuration, if applicable.
5. Clearly mark the outside of the shipping box with the RMA #. If RMA # is
not present on the shipping box, receiving will be unable to identify it and it
might be returned.
6. Unless prior arrangements have been made, the customer is responsible
for all shipping costs. Unauthorized use of the company’s shipping
accounts is not permitted.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The antennas used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
