Mission Electronic BTCAN Bluetooth Speaker User Manual

Shenzhen Mission Electronic Limited Bluetooth Speaker Users Manual

User manual

BT5 Instruction Manual
I.NOTES
Please use and store the device under normal temperature.
Please against rain or humidity.
Please do not throw or drop.
Please do not disassemble, amend or alter device alone.
II.Technic data
1.Bluetooth: V3.0+EDR Version
2.Transmission distance: 10M or so
3.Frequency coverage: 180HZ-18KHZ
4.SNR: 80dB
5.Charging voltage: 5V
6.Charging time: 3.5 hours
7.Continuous broadcasting: 1 hours (under maximum sound)
8.Li-ion battery: 3.7V/250mA
9.LED signal lamp: working with Blue, charging with Red, off once charging full
10.Unit size: Ø45*H56MM
11.Unit weight: 63g
III.Function
1.Bluetooth: V3.0+EDR (support A2DP V1.2 or AVRCP V1.4 profiles) 10M transmission distance.
2.available to play music by Bluetooth devices, also available to be connected by 3.5M line with other sound
equipments to broadcast music.
3.Set-in Li-ion chargeable battery, charge by USB cable, multiple circuit protection.
4.aluminum drum shape design, cute, specific, portable, good for party, trip, sports to enjoy music anywhere.
IV.Function button and cable
1.ON/OFF: switch the button, three function step, OFF/Minimum sound/Maximum sound, blue LED flash once
the device opening.
2.USB Port: Only power charge
3.Audio input port: 3.5M line audio input
V.Function specification
1. Bluetooth speaker pair with cell phone
Open the device, blue LED flash, and shall seek "MYLEGO" on your Bluetooth pairing, confirm the pairing
device ( the password of Bluetooth match is "0000" if the Bluetooth device under 2.0 version.)the speaker will
pairing the device at once if the device had ever paired the speaker shile the device Bluetooth is opening.
2. playing music by Bluetooth function
Play music directly once the speaker paired with the sound equipment, signal transmission distance is 10M or
so.
3. Audio input broadcasting
Use USB Cable to connect the PC, and 3.5MM set-into the device to enjoy good music. Playing music and
power charging available to be at the same time.
4. Charging
USB Line to connect with PC or other USB cable, Red LED flash. The LED power off once the power charging
enough.
5. Low power caution
Means power is not enough once the speaker sound as DONG, DONGwhile broadcasting.
VI.accessories
1. Drum Speaker 1PC
2. USB Cable 1PC
3. Instruction manual 1PC
Audio
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
The device complies with industry Canada license-exempt RSS standard(s). Operation of this device
is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of
the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement."
This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numrique de la classe [B] est conforme la norme NMB-003 du Canada.
FCC ID: R5B- BTCAN
IC: 11474A-BTCAN
Shenzhen Mission Electronic Limited
Model name: Bluetooth Speaker Model No.: BTCAN
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
R5B-BTCAN
