Users manual

TABLE OF CONTENTS

USING THIS GUIDE ..........2

PHONE OVERVIEW ........ 3

DISPLAY ICONS ............. 4

GETTING STARTED ......... 6

INSERTING THE SIM CARD.....6

ATTACHING THE BATTERY .... 6

CHARGING BATTERY ........... 7

BATTERY SAFETY TIPS ......... 8

BASIC PHONE

OPERATIONS .............. 9

TURNING ON THE PHONE ..... 9

STANDBY SCREEN .............. 9

MAKING A CALL ................ 9

CONVERSATION OPTIONS .. 10

ANSWERING A CALL ......... 10

ENDING A CALL ............... 11

KEYPAD LOCK ................. 11

TURNING OFF THE PHONE .. 11

NETWORK MESSAGES ....... 12

SAFETY INFORMATION .. 13

CARE AND MAINTENANCE . 18

SECURITY CODES ............. 19

GENERAL FEATURES ..... 20

DIALING STORED NUMBERS.20

SPEED DIALING ............... 21

SILENT ALERT MODE ........ 21

MUTING ........................ 22

VOLUME ADJUSTMENT ...... 22

HANDSFREE SPEAKING ...... 22

SENDING DTMF

TOUCH TONES ........... 22

HOLDING/RETRIEVING CALL 23

CALL WAITING ................ 24

CONFERENCE CALLS ......... 24

MENU SYSTEM ........... 26

MENU MAP ................... 26

ENTERING TEXT ............... 27

T9® TEXT INPUT METHOD .. 27

NETWORK SERVICES OR

DIRECT LINKS ............ 30

PHONE BOOK ................. 31

MESSAGES .................... 34

CALLS & TIMERS ............. 39

SETTINGS ...................... 43

OFFICE TOOLS ................ 60

GAMES ......................... 63

INTERNET MODE ............. 64

APPENDIX .................. 70

USING THE HEADSET ....... 70

CHANGING THE

FRONT COVER ......... 71

ACCESSORIES LIST ........... 72

GLOSSARY ..................... 73

TROUBLESHOOTING .......... 75

ERROR MESSAGES ........... 76

INDEX ....................... 78

WARRANTY ................. 82

USING THIS GUIDE

Your G320 phone operates on the GSM network which provides fraud protection, short

message service (SMS), integrated voice mail, superior voice quality and clear, static-free

sound. One of the most important GSM advantages is the removable SIM (subscriber identity

module) card, which holds your personal information such as phone numbers, missed calls,

voice mail notifications and text messages.

Your phone uses a built-in micro browser to reach the Internet and other services such as

e-mail. This micro browser uses the WAP (Wireless Application Protocol) specification, which

standarizes the way that wireless devices can access the Internet and many services. WAP uses

WML (Wireless Markup Language), a language that translates Web pages into a format that

can be viewed on wireless devices. While online, your phone can also view pictures, jump to

other links, and enter information into a Web page or service.

When available, your phone will use GPRS (General Packet Radio Service) technology.

GPRS is the fastest way yet to transmit data over mobile phone networks. With GPRS, the

information is split into separate but related "packets" before being transmitted and

reassembled at the receiving end. Packet switching means that GPRS radio resources are used

only when users are actually sending or receiving data. No dial-up modem connection is

necessary. This is why GPRS users are sometimes referred to be as being "always connected."

Certain features included in this guide called Network Services are supplied by wireless service

providers. You must order a subscription to the services from your home service provider to be

able to use them. Please ask your service provider for details of Network Services.

Key Symbols

Left softkey Right arrow on Express Key

Right softkey Left arrow on Express Key

SEND key Up arrow on Express Key

END/Power key Down arrow on Express Key

Store Press softkey below the term to perform that action. For

example, Store means press the softkey under the

word Store. Softkey actions and labels change with each

new screen.

Select ___ Use and on the Express Key to scroll to the desired

item in the menu and choose by pressing .

For example, select Phone Book means scroll to the

menu item Phone Book and choose by pressing .

G320 PHONE OVERVIEW

LED

Call and

battery charge

indicator

Headset socket

Connect the

headset here

Graphic display

screen

Phone numbers,

menus, messages,

etc. are displayed

here

Left softkey

Performs action

indicated by text

directly above it

Send, Answer

key

Dials displayed

number or name

and answers calls.

Press to see Last

dialed number list

Alphanumeric

keys

Enter telephone

numbers and text

Microphone

AC Adapter

socket

Earpiece

Right softkey

Performs action

indicated by text

directly above it

Express Key

Navigates around

the Phone book

and menus. Press

up or down during

conversation to

adjust volume

Power, End key

Press and hold to

turn the phone

on or off. Press to

end a call or

return to standby

screen

Accessories

socket

Fixed antenna

Display Icons

The display screen shows pictures, icons, numbers, text and animations.

The softkey labels are words in bold appearing on the bottom line. See

softkey descriptions on pages 2 and 3.

Display screen in standby mode

Icon Item Description

Signal strength

level Four levels indicate the strength of the

received signal from network on which

phone is currently registered. If no network

is available, the icon does not appear

Phone Book

SIM card Accessing names stored in the SIM

Phone Book

Phone card Accessing names stored in the phone

Phone Book

Roaming Phone is logged on to a network other

than its home network

Short message

service (SMS)

or Text message

SMS text message has been received and

stored. Must be offered by service

provider and subscription purchased

SMS message bank

is full SMS message bank is full and cannot

store new messages

Voice mail Voice mail message has been received

and stored by the network’s voice mail

center. Must be offered by service

provider and subscription purchased

Unanswered Call Incoming call is missed (unanswered)

Call Forwarding Incoming calls are being forwarded.

Must be offered by service provider and

subscription purchased

T9® is a registered trademark of Tegic Communications, Inc.

Line 2 Indicates Line 2 is in use. Must be offered

by service provider and subscription pur-

chased

CUG Closed User Group service is active

Alarm clock Alarm clock is set

Vibrate mode Vibrate alert set for incoming call

Ring tone off Incoming ring tone is turned off

Battery level Three levels indicate the battery charge

level; low, medium, high

Low battery Flashes when the battery is nearly empty

T9® Text Input mode Enter text with one key press per

character

Text mode

Upper case Upper case text can be entered

Text mode

Lower case Lower case text can be entered

Conversation mode Currently connected to call

Keypad lock Keypad lock is activated

Scroll arrows More menu items can be displayed if

or are pressed

WAP connection Connected to online services of your

service provider

WAP connection in

security mode Connected to online services of your

service provider in secure mode

Mute Microphone is muted

GETTING STARTED

Inserting the SIM Card

Unpack the phone and insert the SIM card into the holder.

If the SIM card has been inserted the wrong way or is damaged, Check

SIM! will display. Remove the SIM card, check this illustration and re-in-

sert it as described.

Attaching the Battery

1Open the SIM card holder as shown.

2Insert the SIM card gently as shown with the gold contacts

facing down and the bevelled corner of the card at the top

left.

3Push the SIM card holder back into position.

1Position the battery onto the phone as shown.

2Push down the opposite end of the battery onto the phone

until the battery catch 'clicks' shut.

Check that the battery is securely in place.

Charging the Battery

Note: The battery must be fully charged before using the phone for the

first time. To charge the battery, follow procedure below. For the first

three times you charge the battery, turn the phone off and charge the

battery until the Battery Full screen appears. Discharge the battery

each time by using the phone until it shuts itself off.

Connect the AC Adapter to the phone as shown.

Image not yet available.

When the phone is off, battery charging is

indicated by Charging... message. The LED

light will be red. When charging is finished,

Battery Full! displays and the LED light will

change to green.

When the phone is on, charging is indicated

by the battery icon flashing 1-2-3 bars

continuously. When charging is completed,

the battery icon will show three solid bars.

If a call is received during charging, the LED

light will flash green rapidly.

If the phone is used while charging, the charging time will be longer.

1Make sure the battery is properly installed on your phone.

2Connect the AC Adapter to the socket at the base of the

phone. Plug in the other side of the AC Adapter to a

standard 120 volt outlet.

3Make sure the proper charging indicators are showing as

stated below.

4Disconnect the AC Adapter when the Battery Full!

message displays.

Battery Charging Times

Approximate battery recharging time using the AC Rapid Charging Adapter:

Low Battery Warning

When the battery power falls to its lowest level, the message Low

Battery! displays and a low battery warning tone sounds.

If you are on a call, end the call and turn off the phone by pressing and

holding . Recharge the battery as described or replace it with a

charged one.

Battery Safety Tips

• Replace the battery when it will not hold a charge, or when operating time decreases dramat-

ically.

• Use only the Mitsubishi chargers specified for this battery. Using other chargers or batteries

will void the warranty and may cause damage.

• It is normal for batteries to become warm during charging.

• Do not leave NiMH batteries connected to a charger longer than necessary; overcharging will

shorten battery life.

• Disconnect battery chargers from the power source when not in use.

• Do not leave the phone in a closed car during hot summer or cold winter conditions or exposed

to intense sunlight. The phone may temporarily not work with a hot or cold battery.

• The recharging temperature range is 32°--104° F (0°--40° C). If you attempt to recharge

when the battery is above or below this range, acid leakage or overheating may result.

• Do not use or leave the battery near a heat source such as a stove, oven, heater or fire (170° F

= 76° C or higher).

• The battery is not waterproof. Do not immerse it in liquid or allow it to get wet.

• Avoid contact of the battery terminals with metal objects (such as keys, paper clips, coins,

chains) or excessive static electricity which may short circuit the battery.

• If the battery terminals become soiled, clean them with a soft cloth.

• Do not try to disassemble or modify the battery as injury or burns may result.

• Do not drop or subject the batteries to strong physical shocks.

• Keep batteries out of the reach of children.

• Batteries may explode if discarded into a fire or heated.

• Do not dispose of old batteries together with household waste. Starting in 2001, the Recharge-

able Battery Recycling Corporation will be collecting many types of batteries. Call 1-800-822-

8837 or visit their website at www.rbrc.org.

Battery Type Charging time

1000 mAh NiMH Standard TBD

BASIC PHONE OPERATIONS

Turning On the Phone

> See pages 19 and 48 for more details on Lock and PIN Codes.

Standby Screen

The standby screen shows the name of the network and/or service provider,

signal strength and battery level icons and Internet and SMS softkeys.

Press to go to your Phone Book (see page 31).

Press to go to the phone main menu (see page 26).

Press to go to volume control (see page 44).

Press to silence incoming ring tone (see page 43).

To set time and date, see page 51.

• Press Internet to access the Internet main menu from which you

can dial the Home Page offered by your service provider. See page 64

to learn more about this feature.

• Press SMS to access the Short Message Service menu offered by

your service provider. See page 35 to learn more about this feature.

Making a Call

The phone can only make and receive calls when it is turned on, unlocked,

has a valid SIM card inserted and is located in an area that has GSM

network service coverage. If the phone cannot find a network, the display

remains blank.

1Press and hold . A picture animation displays and a turn-

on tone sounds.

2If the phone is locked, Enter lock code will display. Enter

the 4-digit Lock Code and press OK .

3If your SIM is PIN protected, Enter PIN will display.

Enter the PIN code and press OK .

To store the dialed number in the Phone Book, press Store before

pressing to connect the call. Follow the display prompts to finish

storing.

International calls can be prefixed either with 00 or +. To enter the +

symbol before a number, press and hold until + appears in the

display.

When the call connects, the call timer displays.

•Busy Called party’s line is busy. If Auto Retry is on, the phone will

attempt to call again (see page 48 for details).

•Not allowed (fixed dialing) Number dialed is not authorized by the

FDN list (see page 34 for details).

• Line 2 icon ( ) appears when call connects (if active) indicating call

was made using this line (see page 42 for details).

Volume Adjustment During Conversation

Answering a Call

When there is an incoming call, the phone rings. The LED light on the top

of the phone flashes green and a flashing icon appears. The back-

light also lights up if the phone was set to do so or if in silent mode.

• If the ring tone volume is set to zero (off) or if the phone is in

'Silent mode' or 'Vibrate mode', no audible sound will be

heard.

1Enter the telephone number you wish to dial.

Correct any mistakes by pressing Clear . Press and hold

this key to erase the entire entry.

2Press to dial (send) the number.

Press or on the Express Key to increase or decrease the

earpiece volume through eight levels.

Press to answer the call.

Press Silence to stop incoming ring tone.

Press to send the call to voice mail.

Call Display Notes

• The caller’s number (if available) displays. If you stored this number in

the Phone Book, the person’s name displays.

• If the caller’s number is not available, Unknown number displays

first, then Call 1 displays when you answer.

• If the caller has withheld their number, Withheld number displays

first, then Call 1 displays when you answer.

• When the call connects, the call timer appears.

• Line 2 icon ( ) appears if the call is received on your Line 2 number.

See page 42 for details.

Ending a Call

After ending the call, the call timer will stop and will disappear. Wait

a few seconds or press Back softkey to return to the standby screen.

Keypad Lock

When Keypad lock is activated, it prevents accidental key presses or calls

being made when the phone is carried in a pocket, briefcase or

handbag. Keypad lock is suspended during incoming calls and resumes

when the call ends. Emergency calls can still be made.

To activate Keypad Lock,

To deactivate Keypad Lock,

Turning Off the Phone

A turn off tone will sound. During turn off, a picture animation displays,

then the phone will turn off.

Do not turn off the phone by removing the battery, as data which may

need to be saved in the SIM will be lost.

Press to end a call.

Press and hold . The screen will show .

Press Unlock , then press .

Press and hold .

Network Messages

A Network Message icon will appear when you have missed an incoming

call, received a voice message, or received an SMS message. An alert tone

will also sound for voice and SMS messages.

The display shows the message type icon and number of messages.

Follow these actions to pick up your messages.

1Press Read to view the message.

2If there is more than one type of message, pressing Read

will display a list of the message types. Scroll to the desired

message and press Select or to view the message.

Icon Item Action

Unanswered Call Press Read . The caller’s number appears.

Press to call the number, or press

Options . Unanswered call numbers are

stored in the Unanswered Call Log. See page

39 for details.

Voice Mail Press or Call to speed dial your voice

mail message center. See page 52 for details.

SMS Message Press Read to view the SMS Inbox

messages. See SMS Messages on page 35.

SMS Message

bank is full Delete at least one old received message to

be able to receive new messages.

See Managing SMS Messages on page 35.

SAFETY INFORMATION

STATEMENT OF COMPLIANCE

This device complies with part 15 of the

FCC Rules. Operation is subject to the

following two conditions: 1) This device

may not cause harmful interference, and

2) this device must accept any interfer-

ence that may cause undesired operation.

CAUTION: Changes or modifications not

expressly approved by Mitsubishi Wireless

Communications, Inc. could void your

authority from the FCC to operate the

equipment.

EXPOSURE TO RADIO

FREQUENCY SIGNALS

Your wireless handheld portable tele-

phone is a low power radio transmitter

and receiver. When it is ON, it receives

and also sends out radio frequency (RF)

signals.

In August 1996, the Federal Communica-

tions Commissions (FCC) adopted RF

exposure guidelines with safety levels for

hand-held wireless phones. These guide-

lines are consistent with the safety stan-

dards previously set by both U.S. and

international standards bodies:

*ANSI C95.1 (1992)

*NCRP Report 86 (1986)

*ICNIRP (1996)

*American National Standards Institute;

National Council on Radiation Protection and

Measurements; International Commission on

Non-Ionizing Radiation Protection

Those standards were based on compre-

hensive and periodic evaluations of the

relevant scientific literature. For example,

over 120 scientists, engineers, and physi-

cians from universities, government

health agencies, and industry reviewed

the available body of research to develop

the ANSI Standard (C95.1).

The design of your phone complies with

the FCC guidelines (and those standards).

THIS MODEL PHONE MEETS THE

GOVERNMENT’S REQUIREMENTS

FOR EXPOSURE TO RADIO

WAVES.

Your wireless phone is a radio transmitter

and receiver. It is designed and manufac-

tured not to exceed the emission limits

for exposure to radiofrequency (RF)

energy set by the Federal Communica-

tions Commission of the U.S. Govern-

ment. These limits are part of

comprehensive guidelines and establish

permitted levels of RF energy for the

general population. The guidelines are

based on standards that were developed

by independent scientific organizations

through periodic and thorough evalua-

tion of scientific studies. The standards

include a substantial safety margin

designed to assure the safety of all

persons, regardless of age and health.

The exposure standard for wireless mobile

phones employs a unit of measurement

known as the Specific Absorption Rate, or

SAR. The SAR limit set by the FCC is 1.6 W/

kg.* Tests for SAR are conducted using

standard operating positions specified by

the FCC with the phone transmitting at its

highest certified power level in all tested

frequency bands. Although the SAR is

determined at the highest certified power

level, the actual SAR level of the phone

while operating can be well below the

maximum value. This is because the

phone is designed to operate at multiple

power levels so as to use only the power

required to reach the network. In general,

the closer you are to a wireless base

station antenna, the lower the power

output.

Before a phone model is available for sale

to the public, it must be tested and certi-

fied to the FCC that it does not exceed the

limit established by the government-

adopted requirement for safe exposure.

The tests are performed in positions and

locations (e.g., at the ear and worn on the

body) as required by the FCC for each

model. The highest SAR value for this

model phone when tested for use at the

ear is ____ and when worn on the body, as

described in this user guide, is ___. (Body-

worn measurements differ among phone

models, depending upon available acces-

sories and FCC requirements.) While there

may be differences between the SAR levels

of various phones and at various positions,

they all meet the government requirement

for safe exposure.

The FCC has granted an Equipment

Authorization for this model phone with

all reported SAR levels evaluated as in

compliance with the FCC RF emission

guidelines. SAR information on this model

phone is on file with the FCC and can be

found under the Display Grant section of

http://www.fcc.gov/oet/fccid after search-

ing on FCC ID BGB MT289.

Additional information on Specific Absorp-

tion Rates (SAR) can be found on the

Cellular Telecommunications Industry

Association (CTIA) website at http://

www.phonefacts.net.

* In the United States and Canada, the SAR

limit for mobile phones used by the public is

1.6 watts/kilogram (W/kg) averaged over

one gram of tissue. The standard incorpo-

rates a substantial margin of safety to give

additional protection for the public and to

account for any variations in measurements.

Your phone has been tested and meets

the limits for radio frequency (RF)

exposure set by the FCC for normal

handheld use next to the ear or worn on

the body using a Mitsubishi brand belt

clip accessory specified for this phone,

and used as intended. Operation of the

phone in other situations such as in shirt

pockets or non-Mitsubishi brand belt clips

or holsters have not been tested. There-

fore operation of the phone in non-tested

situations may not meet the limits for RF

exposure set by the FCC and must be

avoided.

ANTENNA CARE

Use only the supplied or an approved

replacement antenna. Unauthorized

antennas, modifications, or attachments

could damage the phone and may violate

FCC regulations.

PHONE OPERATION

Hold the phone as you would any other

telephone with the antenna pointed up

and over your shoulder.

For your phone to operate most effi-

ciently, extend the antenna fully (if appli-

cable) and do not touch the antenna

unnecessarily when the phone is in use.

Contact with the antenna affects call

quality and may cause the phone to

operate at a higher power level than oth-

erwise needed.

DRIVING

Check the laws and regulations on the

use of wireless telephones in the areas

where you drive. Always obey them. Also,

if using your phone while driving, please:

• Give full attention to driving - driving

safely is your first responsibility.

• Use hands-free operation, if available.

• Pull off the road and park before mak-

ing or answering a call if driving condi-

tions so require.

ELECTRONIC DEVICES

Most modern electronic equipment is

shielded from RF signals. However, certain

electronic equipment may not be shielded

against the RF signals from your wireless

phone.

Pacemakers

The Health Industry Manufacturers Asso-

ciation recommends that a minimum sep-

aration of six (6”) inches be maintained

between a handheld wireless phone and

a pacemaker to avoid potential interfer-

ence with the pacemaker. These recom-

mendations are consistent with the

independent research by and recommen-

dations of Wireless Technology Research.

Persons with pacemakers:

• Should ALWAYS keep the phone more

than six inches from their pacemaker

when the phone is turned ON

• Should not carry the phone in a breast

pocket

• Should use the ear opposite the pace-

maker to minimize the potential for

interference

• If you have any reason to suspect that

interference is taking place, turn your

phone OFF immediately

Hearing Aids

Some digital wireless phones may interfere

with some hearing aids. In the event of

such interference, you may want to consult

your service provider (or call the customer

service line to discuss alternatives).

Other Medical Devices

If you use any other personal medical

device, consult the manufacturer of your

device to determine if they are adequately

shielded from external RF energy. Your

physician may be able to help you obtain

this information.

Turn your phone OFF in health care facili-

ties when any regulations posted in these

areas instruct you to do so. Hospitals or

health care facilities may be using equip-

ment that could be sensitive to external RF

energy.

Vehicles

RF signals may affect improperly installed

or inadequately shielded electronic

systems in motor vehicles. Check with the

manufacturer or its representative regard-

ing your vehicle. You should also consult

the manufacturer of any equipment that

has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where

posted notices so require.

AIRCRAFT

FCC regulations prohibit using your phone

while in the air.

Switch OFF your phone before boarding

an aircraft.

BLASTING AREAS

To avoid interfering with blasting opera-

tions, turn your phone OFF when in a

“blasting area” or in areas posted “Turn

off two-way radio.” Obey all signs and

instructions.

POTENTIALLY EXPLOSIVE AREAS

Turn your phone OFF when in any area

with a potentially explosive atmosphere

and obey all signs and instructions. Sparks

in such areas could cause an explosion or

fire resulting in bodily injury or even

death. Areas with a potentially explosive

atmosphere are often but not always

clearly marked. They include fueling areas

such as gasoline stations; below deck on

boats; fuel or chemical transfer or storage

facilities; vehicles using liquefied petro-

leum gas (such as propane or butane);

areas where the air contains chemicals or

particles, such as grain, dust, or metal

powders; and any other area where you

would normally be advised to turn off

your vehicle engine.

FOR VEHICLES EQUIPPED WITH

AIR BAGS

An air bag inflates with great force. DO

NOT place objects, including both installed

or portable wireless equipment, in the area

over the air bag or in the air bag deploy-

ment area. If in-vehicle wireless equipment

is improperly installed and the air bag in-

flates, serious injury could result.

The U.S. Food and Drug Admin-

istration’s Center for Devices

and Radiological Health

Consumer Update on

Mobile Phones

FDA has been receiving inquiries about the

safety of mobile phones, including cellular

phones and PCS phones. The following

summarizes what is known--and what

remains unknown--about whether these

products can pose a hazard to health, and

what can be done to minimize any poten-

tial risk.

Why the concern?

Mobile phones emit low levels of radio

frequency energy (i.e., radio frequency

radiation) in the microwave range while

being used. They also emit very low levels

of radio frequency energy (RF), considered

non-significant, when in the stand-by

mode. It is well known that high levels of

RF can produce biological damage

through heating effects (this is how your

microwave oven is able to cook food).

However, it is not known whether, to what

extent, or through what mechanism,

lower levels of RF might cause adverse

health effects as well. Although some

research has been done to address these

questions, no clear picture of the biologi-

cal effects of this type of radiation has

emerged to date. Thus, the available

science does not allow us to conclude that

mobile phones are absolutely safe, or that

they are unsafe. However, the available

scientific evidence does not demonstrate

any adverse health effects associated with

the use of mobile phones.

What kinds of phones are in

question?

Questions have been raised about hand-

held mobile phones, the kind that have a

built-in antenna that is positioned close to

the user’s head during normal telephone

conversation. These types of mobile

phones are of concern because of the

short distance between the phone’s

antenna--the primary source of the RF--

and the person’s head. The exposure to RF

from mobile phones in which the antenna

is located at greater distances from the

user (on the outside of a car, for example)

is drastically lower than that from hand-

held phones, because a person’s RF

exposure decreases rapidly with distance

from the source. The safety of so-called

”cordless phones,” which have a base unit

connected to the telephone wiring in a

house and which operate at far lower

power levels and frequencies, has not

been questioned.

How much evidence is there that

hand-held mobile phones might be

harmful?

Briefly, there is not enough evidence to

know for sure, either way; however,

research efforts are on-going.

The existing scientific evidence is conflict-

ing and many of the studies that have

been done to date have suffered from

flaws in their research methods. Animal

experiments investigating the effects of RF

exposures characteristic of mobile phones

have yielded conflicting results. A few

animal studies, however, have suggested

that low levels of RF could accelerate the

development of cancer in laboratory ani-

mals. In one study, mice genetically

altered to be predisposed to developing

one type of cancer developed more than

twice as many such cancers when they

were exposed to RF energy compared to

controls. There is much uncertainty

among scientists about whether results

obtained from animal studies apply to the

use of mobile phones. First, it is uncertain

how to apply the results obtained in rats

and mice to humans. Second, many of the

studies that showed increased tumor

development used animals that had

already been treated with cancer-causing

chemicals, and other studies exposed the

animals to the RF virtually continuously--

up to 22 hours per day.

For the past five years in the United States,

the mobile phone industry has supported

research into the safety of mobile phones.

This research has resulted in two findings

in particular that merit additional study:

1. In a hospital-based, case-control study, researchers looked for

an association between mobile phone use and either glioma

(a type of brain cancer) or acoustic neuroma (a benign tumor

of the nerve sheath). No statistically significant association

was found between mobile phone use and acoustic neuroma.

There was also no association between mobile phone use and

gliomas when all types of types of gliomas were considered

together. It should be noted that the average length of mobile

phone exposure in this study was less than three years.

When 20 types of glioma were considered separately, how-

ever, an association was found between mobile phone use and

one rare type of glioma, neuroepithelliomatous tumors. It is

possible with multiple comparisons of the same sample that

this association occurred by chance. Moreover, the risk did not

increase with how often the mobile phone was used, or the

length of the calls. In fact, the risk actually decreased with

cumulative hours of mobile phone use. Most cancer causing

agents increase risk with increased exposure. An ongoing study

of brain cancers by the National Cancer Institute is expected to

bear on the accuracy and repeatability of these results.1

2. Researchers conducted a large battery of laboratory tests to

assess the effects of exposure to mobile phone RF on genetic

material. These included tests for several kinds of abnormali-

ties, including mutations, chromosomal aberrations, DNA

strand breaks, and structural changes in the genetic material

of blood cells called lymphocytes. None of the tests showed

any effect of the RF except for the micronucleus assay, which

detects structural effects on the genetic material. The cells in

this assay showed changes after exposure to simulated cell

phone radiation, but only after 24 hours of exposure. It is pos-

sible that exposing the test cells to radiation for this long

resulted in heating. Since this assay is known to be sensitive to

heating, heat alone could have caused the abnormalities to

occur. The data already in the literature on the response of the

micronucleus assay to RF are conflicting. Thus, follow-up

research is necessary.2

FDA is currently working with govern-

ment, industry, and academic groups to

ensure the proper follow-up to these

industry-funded research findings. Collab-

oration with the Cellular Telecommunica-

tions Industry Association (CTIA) in

particular is expected to lead to FDA pro-

viding research recommendations and sci-

entific oversight of new CTIA-funded

research based on such recommendations.

Two other studies of interest have been

reported recently in the literature:

1. Two groups of 18 people were exposed to simulated mobile

phone signals under laboratory conditions while they

performed cognitive function tests. There were no changes in

the subjects’ ability to recall words, numbers, or pictures, or in

their spatial memory, but they were able to make choices

more quickly in one visual test when they were exposed to

simulated mobile phone signals. This was the only change

noted among more than 20 variables compared.3

2. In a study of 209 brain tumor cases and 425 matched

controls, there was no increased risk of brain tumors

associated with mobile phone use. When tumors did exist in

certain locations, however, they were more likely to be on the

side of the head where the mobile phone was used. Because

this occurred in only a small number of cases, the increased

likelihood was too small to be statistically significant.4

In summary, we do not have enough

information at this point to assure the

public that there are, or are not, any low

incident health problems associated with

use of mobile phones. FDA continues to

work with all parties, including other

federal agencies and industry, to assure

that research is undertaken to provide the

necessary answers to the outstanding

questions about the safety of mobile

phones.

What is known about cases of

human cancer that have been

reported in users of hand-held

mobile phones?

Some people who have used mobile

phones have been diagnosed with brain

cancer. But it is important to understand

that this type of cancer also occurs among

people who have not used mobile phones.

In fact, brain cancer occurs in the U.S.

population at a rate of about 6 new cases

per 100,000 people each year. At that

rate, assuming 80 million users of mobile

phones (a number increasing at a rate of

about 1 million per month), about 4800

cases of brain cancer would be expected

each year among those 80 million people,

whether or not they used their phones.

Thus it is not possible to tell whether any

individual’s cancer arose because of the

phone, or whether it would have

happened anyway.

A key question is whether the risk of

getting a particular form of cancer is

greater among people who use mobile

phones than among the rest of the popu-

lation. One way to answer that question is

to compare the usage of mobile phones

among people with brain cancer with the

use of mobile phones among appropri-

ately matched people without brain

cancer. This is called a case-control study.

The current case-control study of brain

cancers by the National Cancer Institute,

as well as the follow-up research to be

See also Conference Calls on page 24.

1Press Options and select Auto DTMF.

2Enter the DTMF numbers by using the keypad or from a

number stored in the Phone Book (under Names ).

3Press OK to send the tones. After the tones have been

sent the normal conversation screen displays.

Press and hold . The symbol * appears first, then the symbol +,

then the letter p will appear on the screen.

Press to put a call on hold during conversation.

Press or Unhold to retrieve a call.

1After putting the call on hold, enter a number, press and

establish the call.

2Press to swap between the two calls.

3To end either the current call or the held call, select End

active or End held call in the Options menu. The remaining

call is automatically retrieved.

4Press to end the remaining call.

Call Waiting

Call waiting is a network service that allows you to put an existing call

'on hold' while you answer or make a second call.

To activate or cancel call waiting,

USING CALL WAITING

When a second call comes in, you will hear a 'double beep'; and an

animated phone icon and the phone number (if available) will display.

• Either press to answer the call and put the first call on hold or press

Reject to send the incoming call to voice mail.

• Press to swap between the two calls.

• Press Replace to end the first call and take the incoming call.

• See Step 3 in Holding and Retrieving a Call to end one or both calls.

Example of a multiparty call screen.

The signal strength, time of day, Line 2 in use,

and battery level icons appear on the top line.

The active call type is in bold, displaying

name and call time elapsed.

If possible, the time elapsed from the start of

the multiparty call may display.

Conference Calls

This feature allows you to make or receive between 2 to 5 calls at the

same time with all parties being able to hear and talk with each other.

1Press . Select Settings. Select Services.

2Select Call waiting.

3To check the current setting, select Status. The network will

send a display stating whether Call Waiting is active or not.

4To change the setting, select Activate or Cancel.

Requesting displays. The network will confirm your request.

1Enter a number, press and establish the call.

2Enter another number and press . The first call will be put

on hold while the second call becomes active.

3Press Options for these options:

Throughout the call, the screen confirms the actions you have selected.

• For alternate line service (ALS) subscribers, conference calls cannot be

made between Line 1 and Line 2. For details, see Alternate Line Service

on page 42.

Option Confer-

ence Non-

confer-

ence

Description

Auto-DTMF •Allows a DTMF string to be

entered to the active call only

Swap •Swaps between active and call

on hold

Join •Joins active and call on hold to

make a conference call

Mute/Unmute • • Turns on or off the microphone

Hold/Retrieve • • Holds or retrieves the call

Private with •Allows you to select and have a

private conversation with one of

the conference callers while

putting all the other calls on

hold

End held •Ends the call on hold

End active •Ends active call and connects

with call on hold

End one •Allows you to select and end

one of the conference call

participants

End all • • Ends all the calls

MENU SYSTEM

Use the Express Key to access the easy to use menu system, where all of the

phone’s features and function settings are stored. The menu is also used for

features you have requested from your service provider. Your SIM card

presents these features through the menu system.

• Press (labeled MEM) to go to all stored telephone numbers in the

Phone Book.

• Press (labeled MENU) to enter the main menu from the standby

screen.

• To navigate through the main menu items, press or .

• All other functions and features are then selected by pressing or

Select .

• To return to a previous menu, press or Back .

• To exit the menus, press and hold Clear ; or if no call is in

progress.

Menu Map

* Appears if offered by service provider and subscription is purchased.

Network Serv. * Calls & Timers Internet

Direct Links * Call log Home page *

Applications * Call timers Bookmarks *

Services * Call costs * Other site *

Information * Line selection * Profile list *

Settings *

Phone Book Settings

Recall Phone settings

Store Voice mail

Remaining Services

Own numbers Broadcast

Fixed dialing * Office Tools

Messages Scratchpad

Inbox * Currency converter

Outbox * Alarm clock

Write new

Settings * Games *

Draft texts * Reshape *

Alert * Push *

Storage * Options *

ENTERING TEXT

To store names and email addresses in the Phone Book, write SMS text

messages, use the Scratchpad or use the Internet services, you will enter

and edit text in the display.

In the text input screen, select from two modes:

• Alpha -- to enter alpha characters

• T9 -- to enter alpha characters using quick T9 Text Input

Press and hold to switch between the modes.

These icons appear in the text input screen:

> The upper and lower case icons appear both in Alpha mode and T9

mode.

T9® Text Input Method

There are two methods for entering characters and numbers. In the con-

ventional alpha method, you keep pressing each key until the desired letter

appears. This can be cumbersome when entering a lot of text. For a quick

text entry method, use T9 Text Input to press each key just once to allow

the T9 software to assemble the word for you. The T9 database ranks

words by common usage so one entry gives the choice of several words.

To use T9 Text Input mode:

Alpha mode

Upper case Upper case text can be entered

Alpha mode

Lower case Lower case text can be entered

T9® Text Input mode Enter text with one key press per

character

1To enter a word, press each key containing the desired letters

only once.

Be sure to type the entire word first before editing.

2Check to see if the desired word appears. If it does, press

to enter a space and continue entering text.

3If the desired word is not displayed, press to cycle to other

word choices.

4If the desired word doesn’t appear, press to change to

the alpha mode to enter the word.

5Use the arrow keys to move the cursor to insert characters or

make corrections.

T9® Text Input Example

T9 Text Input mode is ready when the icon displays.

Press keys corresponding to the letters you need, just as if the phone

keypad were a typewriter. Type for space and for period.

For example:

h e l l o w o r l d .

T9 Text Input key actions

Adding words to T9 Text Input database

Words that do not appear in T9 Text Input database can be added easily

using the alpha mode. In alpha mode, type the desired word into the text

of your message. The unknown word is automatically added to the

database so you can type it using T9 Text Input in the future.

For example, to enter ‘Jenna’ to the T9 database,

1. Press to go to alpha mode.

2. Press to capitalize, then press 5 key once to enter ‘J.’ Press 3

key twice to enter ‘e.’ Press 6 key twice to enter ‘n.’ Wait for

cursor to move then press 6 key twice to enter another ‘n.’

Press 2 key once to enter ‘a.’

Key Action

Press to shift - upper/lower case

Press briefly to automatically capitalize the

current letter

Clear Clear character or backspace

Press and hold to clear entire entry

Press to enter space

Press and hold to view symbols

Scroll to other word choices

Enters a period, --, or ... Press 1 key, then press

zero key repeatedly to scroll to , - ‘ @ : ?

To type contractions such as you’re, type y-o-u-1-

r-e. The period will change to an apostrophe.

number keys Press and hold to enter numbers

Press to switch between T9 Text Input and alpha

modes

Press to move cursor between words

3. Press to go to T9 Text Input mode to complete the message.

4. The name Jenna is automatically stored in the T9 database.

T9® is a registered trademark of Tegic Communications, Inc.

Alpha Text Entry Method

Alpha method key actions

For example, to enter ‘Card’ in the Scratchpad,

1. Press , then press three times to select Office Tools.

2. Select Scratchpad, then select Write.

3. Press briefly to go to upper case mode, icon is displayed.

Press briefly three times to enter C in the screen.

4. Wait for the cursor to move or press to move to the next position,

notice that is displayed. Press briefly once to enter a.

5. Press briefly three times to enter r.

6. Press once to enter d. The word Card will now be in the screen.

7. Press to exit from this example.

1To type each letter of a word, press the desired key

one, two, three or four times, corresponding to the letter’s

position on the key.

2See chart below:

Key Action

Press to shift - upper/lower case

Press briefly to automatically capitalize the current

letter

Press and hold to shift lock upper/lower case

Clear Clear character or backspace

Press and hold to clear entire entry

Press to enter space

Press and hold to view symbols

Press to enter 1 . , - @ : ?

number keys Press and hold to enter numbers

Press to switch between T9 Text Input and alpha

modes

Press to move cursor between letters or words

Entering Symbols

Shortcut for entering punctuation marks in alpha mode,

To select and insert a symbol into the text,

Symbol page 1

NETWORK SERVICES OR DIRECT LINKS

The menu item Network Serv. or Direct Links may appear at the

beginning of the menu if your network provider elects to offer certain

value added services and contact phone numbers. These services and

phone numbers will be stored in your SIM. Contact your network

provider for details on these services. A service provider may present

these in one of three ways:

SIM application tool kit

An automatic way to provide services related to your network and not

to your phone. These services are SIM dependent.

SDN numbers stored in the SIM

Up to 32 Service Dialing Numbers may be stored in the SIM which

cannot be changed.

Information numbers

A list or a menu to enable you to call network or information services

offered by your network.

Some providers can offer two of the above services on the same SIM, in

which case the Network Serv. or Direct Links item in the main menu will

present two menu items, Applications and Services or Information.

Press from one to eight times to enter 1 . , - ' @ : ?

1Press and hold to view symbols. Press to scroll to

additional symbols on pages 2 and 3.

2The symbols are arranged as the 1 - 9 keys are arranged on

the keypad. To select and enter a symbol into your text,

press the number key corresponding to the desired symbol’s

location on the screen. For example, press to select ( and

insert it directly into the text.

3You will be returned to the text entry screen and the symbol

will be in place.

PHONE BOOK

The SIM and the phone have areas of memory used for storing names

and telephone numbers known as the Phone Book.

The phone can store up to 100 “extended” vCards (called Phone Cards).

These cards store first and last names; home, work, and cell phone

numbers; and note. The phone also supports SIM Cards with up to 255

entries but the actual number and capacity is dependent upon the SIM

itself. The SIM Cards store name and number.

The phone and SIM memory locations are interconnected, and both are

searched when you recall a name or number.

Storing Names and Telephone Numbers

Names and numbers can be stored directly in the Phone Book or moved

from other stored areas such as from SMS messages, scratchpad

(numbers only) or last dialed number list, etc.

If you travel abroad, it is best to store numbers in international format

using the '+' prefix before the country code followed by the telephone

number. To enter +, press and hold until + appears on the screen.

See page 27 for instructions on entering text.

To store Phone Card entries,

1Enter the number. Press Store . Another way is to

press , select Phone Book, and select Store.

2Select Phone names.

3Select the category of the number you entered. Choices are

Home, Work, or Cellular.

4Enter last name and press OK .

5Enter first name and press OK .

6Enter information into any of these categories.

Press OK after each entry.

Home phone number

Work phone number

Cellular phone number

Notes

7Stored displays and the remaining number of open entries.

To store SIM Card entries,

Numbers stored in the last dialed, received, unanswered, scratchpad

(numbers only) and SMS message locations can all be stored in the Phone

Book.

To enter a Phone or SIM Card from other stored locations,

> During number and name entry, press Clear to erase the last

character. Press and hold Clear to erase the entire entry.

• The characters *, +, P (pause), # and _ can be stored together with

numbers.

• If the SIM or Phone Book is full, a warning message will display when

selecting the Phone Book.

Free Space in the Phone Book

To see how many empty Phone Book spaces remain in the SIM or the

phone,

> If available, the free memories in the FDN list will also be shown.

Viewing and Dialing Numbers in the Phone Book

Phone Book entries can be recalled into the screen to be edited, deleted,

copied, moved or dialed from either the phone or SIM.

To go to a Phone Book entry,

1Enter the number. Press Store . Another way is to

press , select Phone Book, and select Store.

2Select SIM names.

3Confirm the number and press OK .

4Enter the name and press OK . Stored displays and the

remaining number of open entries.

1Display a number from one of the above, press Options .

2Select Store, then select Phone names or SIM names.

Follow directions above for storing Phone Cards or SIM

Cards, starting at step 3.

1Press . Select Phone Book.

2Select Remaining and use or to display the remaining

available spaces in the phone or SIM.

1Press to view the Phone Book or press and select

Phone Book.

2Select Recall.

If no initial is entered, the screen will show the first alphabet

ical entry in the Phone Book. The list of Phone Book entries

will be displayed in alphabetical order. An icon indicates

whether the entry is stored in the SIM or the phone memory.

To go directly to an entry, press the corresponding alphabet

key. For example, to go directly to entries starting with 'N'

press twice.

press Options to display the following menu:

Own Number Display

You can view your own PCS number, and if you have a subscription, your

Line 2 PCS number (Alternate Line Service), data and fax numbers. All of

these numbers are stored in the SIM by your service provider.

To view your own number(s),

3Either press OK or enter up to the first 3 initials of the

name desired and then press OK .

4Press or to scroll to the desired phone entry.

5Press to dial the number, or

Item Action

Edit Edits the entry

Delete Deletes the entry

Copy Copies the entry to the SIM or the phone or vice

versa. Editing allowed before copying

Move Moves the entry to another position.

Editing allowed before moving

Call Calls the number displayed. If there are multiple

numbers, a list will display from which you can

choose the desired number to dial.

1Press . Select Phone Book.

2Select Own numbers. Your PCS number displays.

3Use or to view Line 2, data and fax numbers

(if you have a subscription for them).

Fixed Dialing Numbers (FDN)

Fixed dialing restricts outgoing calls to 'fixed' numbers or 'prefixes' con-

tained in SIMs that support this feature. It prevents dialing numbers, call

forwarding and sending SMS messages to numbers that are not in the FDN

list. The amount of FDN numbers that can be stored depends on the SIM

capacity. PIN 2 code is required to turn on FDN or enter numbers into the

FDN list.

To turn on or off FDN operation,

To view the numbers in the list,

To enter, edit or delete numbers in the FDN list,

> Wild card spaces can be used with the numbers stored in the FDN

list. For example, the number 727 8_ _ 9 allows calls to all numbers

between 727 8009 to 727 8999 to be dialed. When recalled to the

standby screen, the number can be edited and dialed.

MESSAGES

SMS message service enables you to send or receive short text messages

of up to 160 characters to or from other digital cellular phones with the

same capability. The messages are not sent directly to the other mobile

phone but go via your service provider’s message center. Store, edit and

forward text messages, as well as saving any of the numbers they may

contain. You can also use the Outbox to store, edit, and forward

messages as well as saving any of the numbers they contain.

1Press . Select Phone Book.

2Select Fixed dialing. Select Status.

3Select On or Off. If selecting On, enter the PIN2 code.

4Press OK to confirm the setting.

1Press . Select Phone Book.

2Select Fixed dialing.

3Select View and use or to view all the entries. Press

Options to edit, delete or copy numbers to phone or SIM.

1Press . Select Phone Book.

2Select Fixed dialing.

3Select Add new. Enter the PIN2 code if not entered yet. It is

now possible to add new numbers as well as edit, delete and

copy numbers to the phone or SIM.

Reading a New SMS or Email Message

When the phone receives an SMS message, an SMS message alert tone

sounds and displays. The message is automatically stored in the SIM.

READING STORED SMS MESSAGES

• Each message header displays the sender’s call-back number, date/

time stamp, first line of message, message state icon, and number of

messages in the Inbox.

• Message state icons: Unread (new) message Read message

• Use and to scroll between pages or between messages.

• If appears, the SMS message storage is full. Delete old messages to

be able to receive new messages.

Managing SMS Messages

After reading the text message, press Options for these options:

> The items of this menu may vary and are dependent upon

the type of message received.

Press Read to read all new received messages (Inbox).

1Press . Select Messages.

2Select Inbox to display the first message header.

3Press or select Options , then select Read text to

read the message text.

Item Action

Read text Displays remainder of text

Delete Deletes the message

Reply Replies to sender of the message

Reply (+ text) Replies to sender of the message with the

initial text

Forward Forwards the message to another phone

Forward to n Forwards a set of several messages

(5 maximum) to 5 different addresses

Numbers Stores or calls the number(s) contained in

the SMS header or text

Set up to Send SMS Messages

Before writing a new SMS message, check to see that the network’s SMS

message center number is stored in the phone.

If desired, you can select and change the following options.

The default settings are in place unless you change them.

The phone is now ready to send SMS messages.

Creating a Draft Message

A set of 10 message texts or templates, initially empty, may be used as

text templates when entering message text. Each of these texts can be

up to 50 characters in length. These draft messages are stored in the

phone draft text memory.

To create a draft text,

To edit an existing draft text,

1Press . Select Messages.

2Select Settings.

3Select Message center.

If a number already appears, your service provider supplied

the number. Press OK . If empty, call your service provider.

Option Description Default

Validity Time held at message center. 12 hrs,

1 day, 2 days or Maximum (defined by

service provider) Maximum

Format Selects format of message; Text, Voice,

Fax or Pager Text

Paid reply

to You may pay for the reply to a mes-

sage, if a reply is sent by the addressee Off

Status

report to Requests a status report. Must be

supported by your service provider Off

1Press . Select Messages.

2Select Draft texts.

3Choose a blank template [...] and press Edit .

4Enter the message text. See Entering Text on page 27.

When finished, press OK .

1Press . Select Messages.

2Select Draft texts.

3Select the draft text to modify and press Edit .

4Edit the text. When finished, press OK .

Sending a New SMS Message to One Addressee

Sending a New SMS Message to Many Addressees

Outbox Messages

The Outbox contains unsent draft messages and stored sent messages,

identified by their headers. These messages can be selected from the

Outbox menu and can be modified and resent as new SMS messages.

To select an Outbox message,

1Press . Select Messages.

2Select Write new.

3Choose a draft text or enter the message text. See Entering

Text on page 27. When finished, press OK .

4Select Send.

5Enter the destination number or select Names to choose a

number from a Phone Book entry and press to select.

Press OK . Sent confirmation will display.

6If you select Store, the message will store in the Outbox.

1Press . Select Messages.

2Select Write new.

3Choose a draft text or enter the message text. See Entering

Text on page 27. When finished, press OK .

4Select Multicast.

5Enter up to 5 destination numbers or select Names to

choose up to 5 numbers from the Phone Book and press to

select. Press OK . Sent confirmation will display.

6If you select Store, the message will store in the Outbox.

1Press . Select Messages.

2Select Outbox.

3Use or to scroll to the desired message header.

Each message header displays whether the message has

already been “sent” or “not sent” , the first line of

message, and number of messages.

4Press Options for the following menu:

SMS Alert Tone

To hear a tone each time an SMS message arrives,

Default = On

Storage Available in SMS Memory

To view the amount of available memory in the Inbox and Outbox,

Message Templates

If your SIM can store message templates, then Msg templates will ap-

pear in the Messages - Settings menu. Each of these templates can be

named, then selected and used whenever needed.

• Default settings for Reply and Status are set to ‘No’ unless you change

them to ‘Yes.’

• If only one template is set, it is automatically used by default.

• If more than one is set, any one can be selected to write a new message.

Item Action

Read Display the remainder of the text

Delete Delete the message

Status Available only for sent messages.

Requests a status report. Must be sup-

ported by your service provider

Send Send (or resend) to one addressee

Edit Edit the message

Send to many Send (or resend) to many addressees

5Use or to select and follow the screen prompts.

1Press . Select Messages.

Select

Alert

. Select

Off

1Press . Select Messages.

2Select Storage.

3Scroll to view total SMS storage, SMS outbox and

SMS inbox.

1Press . Select Messages. Select Settings.

2Select Msg templates. Choose any blank [...] template and

press Edit .

3Enter the template Name, Msg Center number, Validity

period and Format.

CALLS & TIMERS

Details of incoming and outgoing calls, duration of the last call, and

accumulated total of all calls made are stored in Calls & Timers menu.

Call Log

The Call log stores details of the last 10 numbers dialed, the last 5

unanswered calls, and the last 5 received (answered) calls. The call logs

are common for both Line 1 and Line 2.

To view or dial a number from the call log,

• The most recent number dialed or received is displayed first.

• For unanswered and received calls, if the caller’s number is in your

Phone Book, the name is shown. If not, ‘Unknown number’ displays.

To edit or delete call log entries,

> Press in the standby screen for one touch access to the 10 last

dialed calls.

1Press . Select Calls & Timers.

2Select Call log.

3Select Last dial, Unanswered or Received.

4Use or to scroll through the call lists.

5Press at a highlighted number to dial that number.

1Press . Select Calls & Timers.

2Select Call log.

3Select Last dial, Unanswered or Received.

4Select the desired entry.

5Press Options to go to the following menu:

Item Action

Store Store number in Phone Book

Delete Delete the entry

Delete all Delete all the entries

Edit Edit the displayed number

Details View the name, number, date, time, and call

length of the highlighted number.

Call Dial the number

6Use or to select and follow the screen prompts.

Call Timers

The length of the last call, total accumulated time of all calls, and total

time of calls for Line 1 and Line 2 are stored.

Times for calls made and received through the home subscription net-

work and through other networks are displayed in Details .

To view call timers,

Balance Information (subscription service only)

This subscription service provided by some networks enables you to ask for

your remaining airtime balance. Contact your service provider for details.

•If Call is selected and the balance information number is

entered, the balance information center is dialed.

• If a number has not been entered, select Set number and

enter the number. Press OK to store your number or to

store and dial the information center number.

1Press . Select Calls & Timers.

2Select Call timers.

3Select Show.

4Use or to view Last call, All calls, Calls L1, and Calls

L2. The top time (>>) indicates time of outgoing calls and

the bottom time (<<) indicates time of incoming calls.

5Press Details for call times on My network, National

roaming, and International roaming calls.

1Press . Select Calls & Timers.

2Select Call timers.

3Select Balance information.

4Select Call or Set number.

5Press when the call is ended.

Reminder - Call Duration

A call duration reminder beeps to remind you of how long you have

been on a call. It can be set in 1 minute increments (1 - 59 mins).

Default = Off

Reset Call Timer

To reset all the call timers,

Call Costs - Management (subscription service)

Some networks offer an Advice of Charge (AoC) subscription service to

see the cost of the last call made, the accumulated total cost of all calls,

and the remaining balance in units or currency of any 'cost limit' set.

To display these costs in the currency of your choice, first select the

currency and cost per unit. If not selected, call costs in units will display.

To set currency and cost per unit,

To set call cost type to units,

> When the cost type is set to units, the credit limit and the remaining

credit are shown in units.

1Press . Select Calls & Timers.

2Select Call timers.

3Select Reminder. Select On (or Off to turn off).

4Enter 2 digits (to signify 1 to 59 mins). Press OK .

1Press . Select Calls & Timers.

2Select Call timers.

3Select Reset.

4Select Yes (or No to exit).

5Enter your 4-digit phone lock code and press OK .

A confirm message will appear.

1Press . Select Calls & Timers.

2Select Call costs. Select Display cost type.

3Select Currency. The present currency settings display.

4Press Edit . Enter the PIN 2 code and press OK .

5Enter the abbreviated letters of the currency. Press OK .

6Enter the cost per unit in the selected currency.

Press OK to confirm. The screen will confirm your selection.

1Press . Select Calls & Timers.

2Select Call costs. Select Display cost type.

3Select Units.

Setting the Credit Limit

After setting the currency and cost per unit, if desired and available in

your subscription, you can also set a credit limit. When the credit limit is

reached, the phone cannot make or receive any chargeable calls. This

does not prevent the phone from making emergency calls.

> When a credit limit is entered, the 'Credit Limit' selection will be Edit

or Set No Limit.

Show Costs

If offered by your service provider, you can view the cost of your last call,

all calls, and your remaining credits.

> The remaining credit is shown in either units or currency as set by

Cost Type menu above.

Reset Call Costs

To reset all the call costs to zero,

Alternate Line Service - Line 2 (subscription service)

Some GSM 1900 operators offer the use of a second line. This is normally

a subscription service and allows, for example, separating calls for

business or private use. Line 2 has a separate PCS number.

1Press . Select Calls & Timers. Select Call costs.

2Select Credit limit. Screen shows the present credit limit.

3Press Edit . Enter the PIN 2 code and press OK .

4Enter the credit limit (use to enter a decimal point). Press

OK to confirm.

1Press . Select Calls & Timers. Select Call costs.

2Select Show.

3Scroll to display the cost of the Last Call, All Calls and the

Remaining credits.

1Press . Select Calls & Timers. Select Call costs.

2Select Reset.

3Select Yes to reset the costs or No to exit.

If Yes is selected, enter the PIN 2 number and press OK .

All Costs Reset will briefly display.

1Press . Select Calls & Timers.

2Select Line selection. The current line selection displays.

3Scroll to the desired line. Press Select or .

SETTINGS

Phone Settings

KEYPAD LOCK

When keypad lock is activated, it prevents accidental key presses and

menu access. The key tones are also silenced.

Keypad lock is suspended during incoming calls and resumed when the

call ends. Emergency calls can still be made.

> Keypad lock is cancelled when connected to the handsfree car kit.

To activate or deactivate keypad lock from the menu,

LANGUAGE SELECTION

If offered by your service provider, all the screen messages can be shown

in one of three languages: English, French, or Spanish.

To select the language of your choice,

> To reset the phone to the language of the SIM, enter *#0000#.

To reset the phone language to English, enter *#0044#.

Default = English

TONES - ALERT MODE

There are two ways to turn off the incoming ring tone, key tones and all alert

tones and alarm tones. If either 'Vibrate' or 'Vibrate then ring' options are

chosen, all alert and alarm tones are replaced by the vibrating action.

Shortcut to turn alert tones on or off,

1Press and hold to activate keypad lock. displays.

2Press Unlock plus to deactivate keypad lock.

1Press . Select Settings. Select Phone settings.

2Select Keypad lock to activate keypad lock.

3Press Unlock plus to deactivate keypad lock.

1Press . Select Settings. Select Phone settings.

2Select Language.

3Use or to select a language from the list. Press .

1Press to display Ring, Silent, Vibrate, Vibrate & ring,

or Vibrate then ring.

2Scroll to desired setting. Press to select. If any of the

vibrate options are selected, the phone will vibrate briefly.

To turn alert tones on or off from the menu,

Default = Ring

•If any Vibrate options are selected, the icon appears. It takes prece-

dence over the icon.

•If Ring is selected but the ring tone volume is set to Off, the icon

appears.

• When the phone is connected to either the Desktop Charger, Handsfree

Headset, Cigarette Lighter Adapter, or AC Adapter, the vibrator mode can-

not work so the phone will ring instead.

RING TONE SELECTION

Choose the sound of the incoming ring tone from a stored selection.

To hear your chosen ring tone or melody, wait several seconds before

confirming your choice. The tone or the melody will play.

Default = Trium

VOLUME ADJUSTMENTS

Shortcut to adjust volume of the ring tone, key tones and incoming audio,

To adjust volumes from the menu,

1Press . Select Settings. Select Phone settings.

2Select Tones.

3Select Alert tones.

4Select Ring, Vibrate, Vibrate & ring, or Vibrate then

ring.

1Press . Select Settings. Select Phone settings.

2Select Tones. Select Melodies.

3To help you identify incoming calls, you can give different

ring tones to Standard/Line 1, Phone names, SIM

names, Line 2 and Alarm.

3Use or to scroll to the different ring tones. Wait several

seconds to hear the tone. After choosing a tone, press to

select the tone.

During a call, you can adjust the volume by using or .

1Press . Continue with step 4 below.

1Press . Select Settings. Select Phone settings.

2Select Tones.

> The ring tone volume off setting is not saved when the phone is turned off.

Default = mid-levels

RAMPING

Ramping causes the incoming ring tone to gradually increase to maxi-

mum volume level if the call is not answered after the first ring.

Default = Off

BACKLIGHT - SETTING

This option controls the backlight during key entry or incoming ring tone.

Choose from two settings:

•On for 10 sec.: Screen and key backlight stay on for

10 seconds after the last key press or incoming call.

•Off: Backlight stays off.

Default = Off

• The backlight setting will be On for 10 sec. when the phone is con-

nected to the Desktop Charger, Handsfree Headset, Cigarette Lighter

Adapter or AC Adapter.

3Select Volume.

4Select Ring, Keys, Conversation or Alarm.

The screen will name the volume type to be adjusted.

5Use or to adjust the setting. Press OK to confirm.

1Press . Select Settings. Select Phone settings.

2Select Tones.

3Select Volume.

4Select Ramping.

5Select On or Off. Press OK to confirm.

1Press . Select Settings. Select Phone settings.

2Select Display.

3Select Backlight.

4Select On for 10 sec. or Off. Press OK to confirm.

DISPLAY CONTRAST

To modify the screen contrast,

Default = mid-level

MENU GRAPHICS

Choose a preferred set of menu graphics. Selecting a set immediately

changes the phone graphics: main menu images, sprites and icons.

Default = TBD

ANY KEY ANSWER

This feature enables any key (except and Silence ) to be pressed

to answer an incoming call.

Default = Off

SOFTKEYS FUNCTIONS

The right and left softkey shortcut can be changed so your standby

screen can have a shortcut to the menus of your choice. The options

available are shown in the menu during selection.

Shortcut to softkeys functions:

To change softkey functions from the menu:

1Press . Select Settings. Select Phone settings.

2Select Display.

3Select Contrast.

4Adjust the contrast using or . Press OK to confirm.

1Press . Select Settings. Select Phone settings.

2Select Menu graphics.

3Use or to scroll to the sets of menu graphics.

Press Select or .

1Press . Select Settings. Select Phone settings.

2Select Keys. Select Any key answer.

3Select On or Off.

1Press and hold or . Continue with Step 5 below.

1Press . Select Settings. Select Phone settings.

2Select Keys.

3Select Softkey functions.

4Select Left softkey or Right softkey.

5Use or to scroll through the softkey option choices.

> If (......) appears, it means the softkey has no function. Either you chose No

function in the menu option or a previously SIM dependent or subscription

service assigned to that softkey is no longer available, for example, Line 2

selection. Defaults: Left softkey = Internet

Right softkey = Messages

SPEED DIALING

Phone Book numbers can be assigned to Keys 2 - 9 which when held

down will dial those numbers. Key 1 is reserved for the voice mail center

number. Numbers stored in the SIM and in the phone (except fixed

dialing numbers) can be selected.

To assign Phone Book numbers to the speed dialing keys,

> If a number which was assigned to a speed dial key is deleted from the Phone

Book, the same number is automatically deleted from the speed dial key.

If you choose a Phone Card with multiple numbers, then when you speed dial

that Key, you will have to select one of the numbers to dial (for example, Work

or Cellular).

To change or delete assigned speed dial keys,

> Key 1 cannot be changed or deleted.

6Press Select to select an option.

7Press Back or to return to the standby screen, which

shows your new softkey function.

1Press . Select Settings. Select Phone settings.

2Select Keys.

3Select Speed dial.

4Use or to scroll to the next Empty Key number.

5Select Names to go to the Phone Book and scroll to the

desired entry.

6Press Select . The Phone Book name will appear with the

assigned Key number.

1Press . Select Settings. Select Phone settings.

2Select Keys. Select Speed dial.

3Use or to scroll to the desired Key number.

4Select Options . Select Names to go to the Phone Book to

replace current phone number. Scroll to desired Phone Book

entry and press Select to replace with new Phone Book

entry. The Phone Book name will appear with the assigned

Key number.

5Select Delete to delete the current Phone Book Entry. The

Key screen will display ‘Empty.’

AUTO ANSWER

When the phone is connected to a handsfree car kit or headset, the

phone will automatically answer an incoming call after approximately 5

seconds without having to press any keys.

Default = Off

AUTO RETRY

The phone will automatically redial the number of a failed call up to 10

times, due to a busy system or unavailable signal from the network.

Default = Off

When activated, Auto-retry and a countdown timer to the next call

attempt appears. A warning tone sounds each time a new call attempt

is made. If it is successful, proceed with the call. Press Back or any

key during Auto-retry to end dialing for that call.

SECURITY FEATURES

The following security features protect your phone from unauthorized use.

Tips on using security codes:

• When requested, enter the code, which appear as asterisks (*), and

press OK .

• If you make a mistake, press Clear then enter the correct digit(s).

• Do not use codes such as emergency 911 to prevent accidently dialing

these numbers.

Change your default codes at once, write them down and

store them in a separate place.

PHONE LOCK CODE

When Phone lock is turned on, the phone lock code must be entered

each time the phone is turned on. The phone lock code is also required

to reset the call timers.

The factory setting is 0000. In order for the security system to work

properly, reset this code, write it down and keep it in a safe place,

separate from the phone.

1Press . Select Settings. Select Phone settings.

2Select Auto features. Select Auto-answer.

3Select On or Off.

1Press . Select Settings. Select Phone settings.

2Select Auto features. Select Auto-retry.

3Select On or Off.

To change the phone lock code,

Default = 0000

To turn Phone lock on or off,

> Emergency calls can still be made when Phone lock is turned on.

Default = Off

PIN CODE

Your SIM is provided with a 4 to 8-digit PIN code to protect it from

unauthorized use. When PIN code lock is enabled, the PIN code must be

entered each time the phone is turned on. If you enter the wrong PIN

code three times in a row, your SIM card is blocked and you must enter

the 8-digit PUK code supplied from your service provider (see page 19).

To enable or disable the PIN code lock,

To change the PIN code (PIN lock must first be enabled),

1Press . Select Settings. Select Phone settings.

2Select Security. Select Phone lock.

3Select Change code and follow the screen prompts.

4Press OK to confirm the new code.

1Press . Select Settings. Select Phone settings.

2Select Security. Select Phone lock.

3Select On or Off.

4Enter the phone lock code to confirm your selection.

1Press . Select Settings. Select Phone settings.

2Select Security.

If already off, PIN enable will show.

If already on, PIN disable and PIN change will show.

3Press Select and follow the screen prompts.

4Press OK to confirm. PIN enabled or PIN disabled

briefly displayed will confirm your action.

1Press . Select Settings. Select Phone settings.

2Select Security.

3Select PIN change and follow the screen prompts.

4Press OK to confirm your new PIN. Confirmation will display.

PIN2 CODE

The PIN2 code prevents access to some features such as turning on or

off FDN operations, modifying the FDN Phone Book, setting calls costs

to zero, or modifying the costs display. It can be changed but not turned

on or off.

To change the PIN2 code,

PUK AND PUK2 CODES

See page 19 for details of PUK and PUK2 codes.

CALL BARRING PASSWORD

The call barring password, supplied by your service provider, selects the call

barring levels listed in the Services - Call Barring menu (see page 57).

To change the call barring password,

Code/Password Entry Summary Chart

1Press . Select Settings. Select Phone settings.

2Select Security.

3Select PIN2 change and follow the screen prompts.

4Press OK to confirm your new PIN2 code.

1Press . Select Settings. Select Services.

2Select Call barring.

3Select Change password and follow the screen prompts.

4Press OK to confirm.

Password Length Number of

tries allowed If blocked or

forgotten

Unlock code 4 digits Unlimited Return phone to

manufacturer

PIN 4-8 digits 3PUK code unblocks

PIN2 4-8 digits 3PUK2 code unblocks

PUK 8 digits 10 Call service provider

PUK2 8 digits 10 Call service provider

Call barring

password 4 digits Network

determined Call service provider

TIME & DATE SETTING

To set the current time,

To set the current date,

• Time and date appear only while the phone is turned on. The time, the day

of the week and the date appear on the standby screen.

• An internal battery maintains the date and time setting for up to 3 hours

when the phone is turned off and without a battery, or with a completely

discharged battery attached. After this 3 hour period, you may need to

reset the clock when the phone is turned on again.

• An error message appears if you make an incorrect entry.

DEFAULT (FACTORY) SETTINGS

Use Default settings to return the phone settings back to the factory

settings. The Phone Book entries, phone lock code, or voice mail and SMS

message alert tones will not change. Only the features named below will

be affected.

1Press . Select Settings. Select Phone settings.

2Select Time & date.

3Select Set time.

4Enter the time using the number keys. Enter 0 (zero) first for

single digit hours and minutes. In the standby screen, the

zero before the hour digit will not appear. Use and to

move the cursor. Press OK to set.

5Select am or pm. Press OK to set.

1Press . Select Settings. Select Phone settings.

2Select Time & date.

3Select Set date.

4Enter the date using the number keys. When entering date,

format is month/day/year. Enter 0 (zero) first for single digit

months and days. Enter all four digits of the year. Use and

to move the cursor. In the standby screen, the day of the

week and the date will appear.

5Press OK to set.

1Press . Select Settings. Select Phone settings.

2Select Default settings.

3Select Yes or No.

Factory Default Settings Summary

Voice Mail

You can receive voice mail messages if offered by your service provider.

Your voice mail box must first be set up with your service provider

before receiving voice mail messages.

CALLING THE VOICE MAIL CENTER TO CHECK FOR MESSAGES

To dial the voice mail center directly after receiving a message,

To dial the voice mail center using the menu,

VIEWING YOUR VOICE MAIL CENTER NUMBER

To view your voice mail center number,

> If you subscribe to 'Line 2' service, you can view the voice mail center number

the same way.

The voice mail number is automatically assigned to speed dial location Key 1.

See Speed Dialing on page 47.

Feature Factory setting

Alert Tones Ring

Ring Tones Trium

Volume, Ring, Key, Conversation, Alarm Mid-levels

Backlight

Contrast On for 10 sec.

Mid-level

Any key answer, Auto-retry and

Auto-answer features Off

Ramping Off

Menu graphics Trium

Press and hold .

1Press . Select Settings. Select Voice mail.

2Select Call.

1Press . Select Settings. Select Voice mail.

2Select Number. The phone number of your voice mail center

appears.

VOICE MAIL ALERT TONE

To hear a tone each time that a voice mail message arrives,

Default = On

Services

CALL FORWARDING (NETWORK SERVICE)

Call forwarding service forwards incoming calls, whether voice, fax or

data, to another number.

To set up call forwarding,

1Press . Select Settings. Select Voice mail.

2Select Alert. Select On or Off.

1Press . Select Settings. Select Services.

2Select Call forwarding for the following menu:

Forward options Action

All Voice calls Forwards all incoming voice calls before

call is sent to your phone

When not reachable Forwards all voice calls only when the

phone cannot be reached (out of service)

On no reply Forwards all voice calls only when the

phone does not answer

When busy Forwards all voice calls only when the

phone is busy

All conditions

Forwards all voice calls only during 3

conditions; When not reachable, On no

reply and When busy. Your phone will ring

first before call is forwarded

Cancel all Cancels all Forwards

All FAX calls Forwards all incoming fax calls before call

is sent to your phone

All DATA calls Forwards all incoming data calls before call

is sent to your phone

3Scroll to select the desired forwarding condition and select.

4Select Activate.

5Select Names or Number.

6If Names was selected, choose the number to forward your

incoming calls to from the Phone Book. If Number was

selected, enter a phone number. Press Select or OK .

Requesting displays. The network will confirm your request.

CALL FORWARDING NOTES

• If the ‘On no reply’ option is selected, you must enter a delay period of 5,

15, or 30 seconds.

• Call forwards for Line 1 and 2 must be set for each line. During call forward

set up, only the line currently selected is affected. To choose a call forward

for the other line, you must select this other line first (see Alternate Line

Service on page 42).

To cancel or check the status of individual call forwards,

To cancel all (multiple) call forwards,

> This action cancels all voice forwards (for voice, faxes and data calls) for the line

currently in use. To cancel call forwards for the other line, first select this other

line (see Alternate Line Service on page 42).

CALLER LINE IDENTITY - SHOWING/HIDING YOUR PCS NUMBER

Most networks allow the Caller Line Identity feature (CLI) which shows

the incoming number (ID) while receiving a call. Select Receiving caller

ID to check if this is available from your network.

RECEIVING CALLER ID

To check if a network presents the caller ID of incoming calls,

To disable sending your own number on a call by call basis,

If your service provider has disabled sending your PCS number, then to show

your number on a call by call basis,

1Press . Select Settings. Select Services.

2Select Call forwarding.

3Select the desired forward option and press .

4Select Cancel or Status. Requesting displays.

The network will respond with current status.

1Press . Select Settings. Select Services.

2Select Call forwarding.

3Select Cancel all.

4Select Cancel. Requesting displays. The network will

confirm your request.

1Press . Select Settings. Select Services.

2Select Receiving caller ID. Requesting displays.

The network will return either Calling user ID

presentation available or presentation unavailable.

1Enter #31# before the number you are calling.

1Enter *31# before the number you are calling.

SENDING CALLER ID

To check if your PCS phone number is sent to other phones,

To show or hide your PCS phone number to other phones,

To reset to the standard network setting for sending your PCS number,

NETWORK SEARCH

When the phone is turned on, it automatically searches for the last net-

work it was registered on (usually the home network). If this is not avail-

able, the phone will automatically search and select a network from the

preferred network list contained in the SIM.

PREFERRED NETWORK LIST

The phone contains a list of networks which can be selected and

transferred to the preferred networks list stored in the SIM. When

traveling, you may wish to choose a particular network to use.

To edit or change the order and name of the networks in the preferred

networks list,

1Press . Select Settings. Select Services.

2Select Sending my ID.

3Select Status. Requesting displays. The network will

respond with your current setting.

1Press . Select Settings. Select Services.

2Select Sending my ID.

3Select My settings.

4Select Hide my ID or Show my ID. Requesting displays.

The network will respond with an appropriate message.

1Press . Select Settings. Select Services.

2Select Sending my ID.

3Select My settings.

4Select Preset. Requesting displays. The phone resets to the

network setting agreed to with your service provider.

1Press . Select Settings. Select Services.

2Select Network.

3Select Preferred list. A Preferred list screen appears with

several [...] signifying empty lines.

4The highlighted [...] will be filled with your choice.

5Press Options to select:

FORBIDDEN NETWORK LIST AND HOME NETWORK NAME

Your SIM may contain a forbidden list of networks which cannot be

used. The SIM also stores the home network name.

To view the forbidden list or show the home network name,

AUTOMATIC NETWORK SEARCH (NORMAL DEFAULT SETTING)

To perform an automatic search from the preferred list,

MANUAL NETWORK SEARCH

When you wish to select a specific network which has better coverage in

your current location, choose manual network search.

Option Description

Modify by list Displays a list of all known networks con-

tained in the phone in alphabetical order

Modify by code Edits or enters a network number

(MCC MNC) if you know this information

Delete Deletes an entry (appears only when net-

work name is already listed)

6A list of networks displays. Scroll to your preferred network

and highlight it. Press Select to place your selection in the

preferred list.

7To add more to the list, scroll to the next empty line [...] and

continue with step 4. To replace or delete an entry on your

preferred list, highlight the entry, press Options and

continue with step 5.

1Press . Select Settings. Select Services.

2Select Network.

3Select either Forbidden or Home network.

A list of forbidden networks or the home network displays.

1Press . Select Settings. Select Services.

2Select Network.

3Select Search.

4Select Automatic. An automatic search is performed.

1Press . Select Settings. Select Services.

2Select Network.

3Select Search.

> You cannot delete a network from the forbidden list. This list

automatically updates when the manual network selection is performed.

CALL BARRING (NETWORK SERVICE)

Call barring stops certain types of calls from being made or received. You

must use a Call barring password available only from your service provider.

To put on a call bar,

To remove or check the status of a Call bar,

4Select Manual. Scanning for Networks displays, followed

by a list of the networks found.

5Choose a network and press .

6Requesting displays. The network will send a confirmation.

1Press . Select Settings. Select Services.

2Select Call barring.

3Select Outgoing calls or Incoming calls. Choose from:

Options Description

Outgoing - All outgoing All outgoing calls are barred

- Int'nal calls Only outgoing international

calls are barred

- Int'nal excl.

- home

All outgoing international calls

except to other subscribers

within your home network

Incoming - All incoming All incoming calls are barred

- Roaming

- only All incoming calls when not on

the home network

4Select the desired option. Press Select .

5Select Activate. Enter the Call barring password and press

Select .

The network will respond with a confirm message.

1Press . Select Settings. Select Services.

2Select Call barring.

3Continue with step 3 above, then select Cancel to remove a

Call bar or select Status and press .

If removing a Call bar, the password is required.

To change the Call bar password,

CLOSED USER GROUP -- CUG (SUBSCRIPTION SERVICE)

This network service allows the phone to make or receive calls only from

selected groups of people. The groups, level of access, and if one of the

groups has preferential calling access is set up at the time of subscrip-

tion. This is mainly for businesses wishing to use closed, internal commu-

nications. This feature is not available for personal use.

Up to 10 groups may be set up. Unauthorized calls made or received

from numbers outside the group are not permitted.

To turn on and off CUG and select type of CUG service,

Default = No CUG

Broadcast - Cell Broadcast (CB) Messages

These are messages broadcast by the networks to all GSM customers. They

provide general information about local area dialing codes, weather reports

and traffic news, etc.

Choose up to 3 message types to receive from the 16 standard message

types stored. Contact your service provider for details on the types and

quantity of CB broadcast messages available. Before you can turn on the

broadcast service, enter at least one message type in the Message types list.

1Press . Select Settings. Select Services.

2Select Call barring.

3Select Change password.

Enter the old password. Enter the new password, then enter

it again to confirm. The network will confirm.

1Press . Select Settings. Select Services.

2Select CUG. The current CUG status displays.

3Press Set

to display these options:

Options Description

No CUG CUG is off. No groups active. Calls can be

made outside the group

Partial CUG Limited calls to and from users outside the

group and from users within the group

CUG Only Only able to make and receive calls from

users within the group

4Select an option. Press . Follow the screen prompts.

ENTER A CB MESSAGE TYPE

CHANGE OR DELETE A CB MESSAGE TYPE

Standard Message Type Codes Chart

TURN ON OR OFF CB BROADCAST SERVICE

> When the broadcast service is turned on continuously, the battery

standby time is reduced. Default = Off

READING CB BROADCAST MESSAGES

Broadcast messages are shown in the standby screen only. A message can

be up to 93 characters in length and cover several pages. Pages will scroll

automatically approximately every five seconds or press to scroll.

1Press . Select Settings. Select Broadcast.

2Select Message types. Press Options .

3Select Modify by list or Modify by code (if known).

4Scroll to the desired message type. Press Select to add

the message type. The screen confirms your choice.

5To add more message types, press to highlight an empty

row [...]. Press Options and continue at Step 3.

1Press . Select Settings. Select Broadcast.

2Select Message types.

3Scroll to the desired message type and press Options .

4To change a message type, select Modify by list or Modify

by code and continue with Step 4 in Enter a CB Message.

5To delete a message type, select Delete.

Code No. Description Code No. Description

000 Index 052 Network

Information

022 Doctors 054 Operator services

030 National road report 056 Phone directory

032 Local road report 057 Int’l directory

034 Taxis 058 Customer care

040 Weather reports 059 Int’l customer care

1Press . Select Settings. Select Broadcast.

2Select On/Off.

3Select On or Off.

Options during message display:

Press Clear

to clear the message currently displayed.

Press to dial the number shown within the message.

Press Options

for these options:

BROADCAST MESSAGE ALERT TONE

Default = On

BROADCAST LANGUAGE

If offered by your service provider, all the CB Broadcast messages can be

shown in one of three languages: English, French, or Spanish.

To select a language,

Default = English

OFFICE TOOLS

Office Tools menu contains a scratchpad, currency converter, and Alarm clock.

Scratchpad

Scratchpad can store up to 5 separate entries of 20 characters each.

Option Action

Delete Delete the current message

Delete All Deletes all stored messages

Numbers Displays all phone numbers in message

text. Option to dial or store in scratchpad

Broadcast Off Turns off cell broadcast service

1Press . Select Settings. Select Broadcast.

2Select Alert.

3Select On or Off.

1Press . Select Settings. Select Broadcast.

2Select Language.

3Use or to select a language from the list. Press .

1Press . Select Office Tools.

2Select Scratchpad.

3Select Read. Use or to scroll through the entries.

Select Write to make a new scratchpad entry. See Entering

text on page 27. Press and hold desired key to enter a num-

ber. When entering phone numbers, do not enter spaces or

dashes. The entry will be date and time stamped.

Press Options for these options while in Read mode:

* These items appear only if the scratchpad entry is a telephone number.

Currency Converter

To use the currency converter, you must first set up the currencies and

the exchange rate. The conversion is calculated on the per unit exchange

rate of the second currency selected.

To select the currencies and the exchange rate,

> If you wish to use your Currency converter as a Euro converter for participating

currencies to the European Monetary Union ("Euroland currencies"), please

enter the complete Euro exchange rate with at least three significant figures.

For example: 1 Euro = £ 1.52.

To calculate the conversion between the chosen currencies,

> Conversion from one Euroland currency to another, or to non-Euroland

currencies, should normally follow "triangulation" rules (i.e. conversion of local

currency to Euro and then Euro to other local currency). Your Currency

converter cannot do this. Your result will be only a close approximation

Item Action

Store * To save a number to the phonebook

Edit Modifies an entry

Delete Deletes an entry

Delete all Deletes all entries

Call * Calls the number displayed in the entry

1Press . Select Office Tools.

2Select Currency converter.

3Select Settings.

4Enter the first currency name (e.g. Dollar). Press OK .

Enter the second currency name (e.g. Yen). Press OK .

5Enter the exchange rate using to enter a decimal point.

Press OK to confirm the entry.

1Press . Select Office Tools.

2Select Currency converter.

3Select one of the two first options.

In our example: either Dollar->Yen or Yen->Dollar.

4Enter the amount to be converted. Press to insert a decimal

point, if needed. Press OK . The converted amount displays.

Alarm Clock

You can set a daily 'Power On' or a daily 'Reminder alarm.'

To set a time and turn on the alarm,

Standby screen with alarm icon

When alarm time arrives, an alarm sounds for up to to 1 minute. Alarm

clock! and vibrating bell icon appear and the LED light flashes red.

Silence turns off the alarm tone only. Valid. validates the alarm

(that is, turns off the alarm until the next day). To clear (turn off) the

alarm permanently, you must select Off in the Alarm clock menu. See

next page.

If the phone is off at alarm time, the phone will automatically turn on

and the alarm tone sounds and screen messages appear.

To use as a Reminder or Snooze Alarm,

Caution - Please remember to turn off the alarm feature in places

where cellular phone use is not permitted. You can also remove

the battery after turning off the phone. See the Safety warnings

on page 13.

1Press . Select Office Tools.

2Select Alarm clock (If a previous alarm time was entered,

then that time displays).

3Select On. Enter the alarm time using 0 (zero) for single digit

hours or minutes. Press OK .

4Select am or pm and press Select . Stored displays

briefly.

5Press Back or to return to the standby screen.

icon appears on the top line of the screen.

Press Silence , or any other key (except Valid. ) to stop the

alarm tone. The alarm icon and Alarm clock! warning remain on

screen. The alarm rings again 3 minutes later.

Press Valid. to validate the alarm (that is, turn it off until the

next day).

ALARM CLOCK NOTES

• If the phone is turned off and is locked or the PIN lock is set, the alarm

will turn on the phone. However, the phone remains blocked until you

enter the phone lock code or PIN code.

• The alarm rings for 1 minute until any key (except Valid. softkey) is

pressed to stop the alarm tone. The alarm is still active, and it repeats

3 minutes later. If Valid. softkey is not pressed after the third alarm

tone, the alarm is not repeated but the phone remains turned on and

alarm indicators remain for up to 15 minutes. Then it reverts back to

the standby screen.

• If the alarm time arrives during a call, an 'In Call' alert beep sounds

every 20 seconds. Press Valid. softkey to turn off alarm.

• If the alarm time arrives while dialing or receiving a call, the alarm is

suspended until the call connects. An 'In Call' alert beep sounds every

20 seconds.

• If the phone is turned off when alarm time arrives, the phone will turn

on. If the alarm is not validated, the phone remains on for 15 minutes,

then turns off.

To turn off the alarm permanently,

GAMES

If available from your service provider, two games are available in the

phone, Reshape and Push.

Choose from 3 sound effects options - Music, electronic sound effects

(Sfx), or No sound in the Options item in the menu.

To select a game,

1Press . Select Office Tools.

2Select Alarm clock.

3Select Off. Confirmation displays.

1Press . Select Games.

2Choose the desired game and press Select .

3Select Help for instructions on how to play the game and the

controls to be used.

4Select Play to start the game.

5Select Code to enter and play the game at your skill level.

•Reshape is a game with 250 skill levels in which you reorder shapes

on the right side to be the same as the left side. Push is a game with

50 skill levels in which you move blocks of ice to their final place. As

each level is successfully played within the allotted time, you will play

at the next higher skill level.

• After successfully playing 'X' amount of levels, you are given a code to

re-enter the game at your previously attained skill level.

• The player’s name can be entered with final scores.

• If a call is received while a game is being played, the game is sus-

pended and you may answer the call normally. When the call is ended,

the game will resume.

• To exit from the games menu, press Back or press to return to

the standby screen.

INTERNET MODE

Your G320 phone has an Internet browser allowing you access to

services such as News, Sports, Weather and Stock quotes.

The types of service and content offered while in Internet Mode

are supplied entirely by your service/Internet provider.

To access Internet Mode, your service provider must first set up and

purchase a data subscription from your service provider.

Set Up Connection Settings

Before starting, check with your service provider as to whether the

connection settings have been already set up or if you must enter the

settings yourself. If your service provider has already completed these

connection settings, these options may not appear or they may be

locked.

If you have not already done so, set the current time and date as de-

scribed on page 51.

PROFILES

To create a new profile,

SELECT A PROFILE

If your service provider offers multiple WAP profiles, you may select a

WAP profile to connect to at start-up, or edit or delete profiles.

INTERNET SETTINGS

Select if you want to clear cache memory, turn off downloading pictures

to speed up data transmission, allow scripting, and set the auto-

disconnect time period.

1Press . Select Internet.

2Select Profile list.

3Select an empty profile [...] and press Options .

4Select Edit. Enter the 4 digit lock code (default code 0000).

Press OK .

5Enter a Proxy name,

a Phone number (to access data services),

an Analog or Numeric connection type,

the speed if required (9600 or 14400),

a Login name,

a Login password (each character will change to an * asterisk),

an IP address,

a Home Page address

Select On or Off to activate security.

Enter the Port number if required.

Press OK after each entry.

The new profile will appear in the profiles list.

1Press . Select Internet.

2Select Profile list.

3Use or to scroll to the desired profile and press

Options to choose Select, Edit or Delete. Follow screen

prompts.

1Press . Select Internet.

2Select Settings.

3Scroll to these options:

Connecting to the Internet

To connect to the Internet services offered by your service provider,

Once your phone displays your service provider’s Home page, you can

access the online services presented on the Home page. Check with your

service provider for information on the content of their online services.

The Internet icon on the bottom of the screen indicates that you are

connected to the online services of your service provider.

SECURE CONNECTION

While online, you can request a secure connection via “Security on” (see

page 65). This closes the current non-secure session and allows you to

navigate within the cache pages. When an Internet connection is

needed again, a secure connection will be requested. When the secure

connection is established, the icon appears to confirm it. In some

cases the secure connection procedure may not work properly because

of server restrictions. In this case, you may need to start a new Internet

session.

Option Action

Clear cache

While you are online, some of the services

and web pages you have accessed are

stored in a memory area called the cache.

Select Yes to delete this cache memory.

Download

pictures

Some Internet pages may have

pictures which take time to download to

the phone. Select Off to stop picture

downloads.

Scripting Many Internet pages use scripts to run a

sequence of commands. Select Off to

turn off scripting.

Auto-disconnect

Set a time period that your phone will

disconnect from the Internet if there is no

activity. Enter the period (0-60 minutes)

and press OK .

0 deactivates the auto-disconnect.

1Press Internet from the standby screen or

press and select Internet.

2Select Start.

3Connecting to... then your profile name will display while

the phone is connecting to the data network.

Then Loading... will display while the Home page is loading.

Interactive Web browsing

PICTURES

You may view pictures on screen. If the picture is wider than the screen,

press View to see the complete picture. Navigate within the picture

by using , , , and keys as in a map.

LINKS

To go to an underlined link of another web page,

ENTER INFORMATION

You may wish to enter information into a Web page. For example, a

people search website usually has a box in which you begin by entering

the last name of a person that you want to find.

Options Menu

While online, press Options or to access these options:

1Use and to move line-by-line through the page.

2If a page contains an interactive line; for example, a link to

another web page, press or to highlight the interactive

phrase or picture.

3To select it, either press the right softkey (labeled Link,

Edit, Enter, Expand, Reduce, View) or press . For

Options menu, press . See Options menu chart below.

To return to the previous page, either press Back softkey (when

displayed), or press left softkey or and select Back.

1Use or to highlight the link.

2Press Link to go to the linked address.

1Use or to highlight the box.

2Press Edit to type the name into the box. See Entering

Text on page 27. Follow screen prompts.

Item Action

Back Returns to previous page

Zoom +/- Increases or decreases text size

* The appearance of these items in the options menu depends on the

service provider and/or the settings in the Settings menu.

Ending Connection

Other site

This Internet menu option allows you to type in a known website

address and go directly to that website. If the phone cannot link to that

website, it’s possible that the website may not be able to be translated

into Wireless Markup Language (WML) which is the language your

phone uses to present Internet information. Also, just as when you surf

the Internet from your computer, web server traffic may be too heavy to

allow a connection.

To store a favorite website address, see Bookmarks.

Bookmarks

Most likely, you will want to use some services and websites frequently.

These services or pages can be stored as Bookmarks which take you directly

Disconnect Disconnects the browser from the network

but leaves the current page locally active

within the phone browser

Clear cache * Clears the browser’s cache, which contains

the most recent Web files you downloaded

Add bookmark * Adds a current card or page to the list of

bookmarks

Go to bookmark * Goes to a previously stored bookmark

Home page Reloads and returns to the Home page

Reload Reloads the current page

Close session Disconnects the phone from the Internet

Press to end the Internet connection.

You can also select Close session under the Options menu.

1Press Internet from the standby screen or

press and select Internet.

2Select Other site.

3Enter the desired website address. For example, enter

www.yahoo.com. Press OK .

Internet connection will begin.

to that web address. Your phone can store up to 5 Bookmarks, if they are

available on the current connection settings of your service provider.

CREATE A BOOKMARK

Shortcut to create a bookmark while currently viewing a Web site,

To create a bookmark from the standby screen,

Bookmarks can only be edited or deleted while offline.

Go to a Bookmark

Shortcut to go to a bookmark while online,

To go to a bookmark from the standby screen,

1Press to display the Options menu.

2Select Add bookmark, enter a shortcut name and

press OK .

1Press Internet from the standby screen or

press and select Internet.

2Select Bookmarks.

3Press Options and select Modify.

4In the Alias screen, type in the name you wish to give your

bookmark. Press OK .

5Type in the Internet address of the desired bookmark in the

Go to screen. Press OK .

1Press Internet from the standby screen or

press and select Internet.

2Select Bookmarks and scroll to the desired bookmark.

3Press Options to choose from Go here, Modify,

Remove or Clear list.

1Press to display the Options menu.

2Select Go to bookmark.

3Select the desired Bookmark.

1Press Internet from the standby screen or

press and select Internet.

2Select Bookmarks.

3Scroll to the desired bookmark and press .

4The phone will connect to the Internet and go to your Book-

mark web address.

ACCESSORIES

Using the Headset

Insert the headset plug in the phone headset connector as shown. TBD

Place the headset earpiece

in your ear. The headset

microphone is then at a

convenient level for

speaking.

You can answer calls by

pressing and end calls

by pressing .

Adjust the earpiece

volume using and .

Disconnect the headset plug as shown. TBD

Changing the Front Cover

Before changing the front cover, always turn off the phone and disconnect

from any charging device or car kit.

Removing the Front Cover

Replacing the Front Cover

• Do not use excessive force when changing the front cover.

• Avoid bending the front cover.

• Do not leave in direct sunlight.

• Always use the phone with the front cover attached.

• Do not clean the phone with alcohol, strong chemicals or solvents.

Wipe it only with a soft, slightly dampened cloth. Read the Care and Mainte-

nance instructions on page 18.

1To be determined.

Accessories List

To purchase accessories, contact your service provider or shop online at

www.mitsubishiwireless.com.

Do you have questions about accessories or would you like to place an

order by phone? Please call toll free 1-877-581-8776

M-F 5:00 am - 9:00 pm PT • Sat 6:00 am - 8:00 pm PT • Sun 8:00 am - 5:00 pm PT

Handsfree kits Part numbers

Headset (earphone + microphone)

Simple Holder with bracket (mounts in car to hold

phone)

Batteries and Chargers Part numbers

Standard battery (Nickel Metal Hydride)

Desktop Battery Charger (for phone + spare

battery)

AC Rapid Charging Adapter 120V (for battery

charging using wall outlet)

Cigarette Lighter Adapter - plug one end into car

cigarette lighter, other end into phone jack to use

and charge phone in your car

Miscellaneous Part number

Belt Clip w/Button

Data Connector Part number

PC cable (RS232C)

Contact Data Kit (Software + PC cable)

To use data and fax numbers, refer to the instruc-

tions in the Contact Data kit and/or contact your

service provider for details.

Also allows you to create and download melodies,

manage abbreviated dial numbers, and perform

SMS functions on your PC.

GLOSSARY

Term Description

AC adapter Alternating Current adapter

Active call The call currently in conversation

ALS Alternate Line Service (Line 2)

AoC Advice of Charge. Cost of calls made

CB Cell Broadcast. General messages broadcast to GSM

customers

CLI Caller Line Identity. Displays caller’s telephone number

Conversation mode When the phone is making or receiving a call

CUG Closed User Group. Preset group of user phone num-

bers

DTMF Dual tone multifrequency tones or touch tones

FDN Fixed Dialing Number. Outgoing calls restricted to fixed

phone numbers

Forwarding Forwards incoming calls to another number

GPRS General Packet Radio Service. Packet-switched data

transmission in which the wireless phone sends and re-

ceives bursts, or packets, of data. A radio channel is oc-

cupied only for the duration of the data transmission

instead of continuously as in circuit-switched.

GSM Global System for Mobile communications. One of

three American digital cellular phone technologies in

the 1900 MHz band. Allows roaming between North

America and Europe by removing SIM card from Amer-

ican phone and placing in European network’s phone

or vice-versa

LCD Liquid Crystal Display

LED Light Emitting Diode

PIN/PIN2 Personal Identification Number. Supplied by your

network/service provider

PUK/PUK2 PIN Unblocking Key. Used to unlock PIN and PIN2.

Supplied by your network/service provider

Roaming (Rm) Make and receive calls on networks other than your

home network at home or abroad

SDN Service Dialing Number of your service provider

SIM Subscriber Identity Module card. Supplied by your net-

work/service provider, holds phone numbers and other

network information

SMS Short Message Service. Text messages can be sent and

received to your phone via the service provider’s mes-

sage center.

Standby mode When the phone is on, registered onto a network but

not making or receiving a call

Standby time Amount of time a fully charged wireless phone can be

on before the phone’s battery will lose power

URL Uniform Resource Locator. Address of a file (resource)

accessible on the Internet

WAP Wireless Application Protocol. Specification that

standarizes the way that wireless devices can be used

for Internet access

WML Wireless Markup Language. Language derived from

HTML that translates Web pages into a format that can

be viewed on wireless devices. Formerly called HDML

(Handheld Devices Markup Language)

TROUBLESHOOTING

Problem Possible cause and solution

Phone will not turn

on • Remove and replace battery assuring that the bat-

tery is charged and correctly attached to the phone

Charging LED not lit

red and no flashing

battery Icon

• Check wall outlet. Power may be out

• The AC/DC charger may be defective. Return it to

your dealer, try another Mitsubishi adapter

Short standby and

talk times • Cell broadcast is permanently on, using more bat-

tery power

• Phone is in a poor signal area and therefore always

on full power

• Incorrect charging and discharging. Always charge

and discharge your battery fully

• The battery is wearing out. Replace the battery

Calls cannot be

made or received • Check that you have at least one signal strength bar

(). Try in a stronger signal strength area

• If the name of a network is not displayed, check that

your SIM is OK, check registration with your service

provider

• Call barring option is turned on. Turn it off (see

page 57)

• Call cost limit is reached (see page 42)

Stored telephone

numbers cannot be

recalled

• Fixed Dialed Number or Call Barring features are

turned on. Turn off the features (see pages 34

and 57)

Numbers cannot be

entered in the

screen

• Keypad lock is on ( is displayed). Press Unlock

and to turn Keypad lock off

• Remove and replace battery assuring that the bat-

tery is charged and correctly attached to the phone

Phone turns on but

there is no display • Display contrast is turned down to low. Reset

contrast (see page 46)

Battery icon not

flashing 1-2-3 dur-

ing charging

• Indicates a charging or battery problem. Turn off

and disconnect the adapter. Reconnect and try

again. If the problem persists, contact your dealer.

Flashing • There is not enough memory to store another SMS

message. You must delete one or more of the

existing stored messages.

ERROR MESSAGES

Message Possible cause and solution

Allowed credit

reached! • Allowed credit limit has already been reached

• Allowed credit limit is reached during an outgoing

call (the call is then cancelled).

Busy • Destination number is being used

Call failed • Caller’s phone is turned off

• Number is out of order or unreachable

• Network system is busy or does not answer

• Option to hide your phone number when calling is

not supported by the network

• CUG is in use and the call is not allowed or not

recognized by the network

• Control and verification of CUG parameters not

confirmed, or CUG availability on network

Cancelled. No type

selected • Cell broadcast activation has been requested but no

message type is selected

Cannot execute

command • Cannot perform request in the current call situation

Can't display

message • Characters not recognized, incorrect format of

short message text

Check SIM! • No SIM is present or the SIM is incorrectly inserted.

See page 6 for more details

Check your password • Call barring password was changed

• Call barring service status was changed

• Entered password is incorrect

Check your request • Your request for a service cannot be fulfilled

Check your

subscription • You have no subscription for requested network

service. Check your subscription regarding the

related service use rights or access

CUG call failed • CUG (Closed user group) call is rejected because the

network does not recognize the CUG parameters

• Dialed number is not in the same CUG

• Dialed number has no CUG association

Error! • Network cannot perform your request

Failed • An SMS message cannot be sent

Incorrect entry • Character string has a syntax error

Invalid number • Network does not recognize the phone number

• Phone number is too long to be stored or moved to

the selected location

Locked! Press (Un-

lock)(#) to unlock • A key was pressed while keypad is locked

Low battery! • Battery is too low and phone will soon turn off

automatically

Network busy • Call is rejected by the network due to overload

Network not allowed • When selecting network manual search, you have

selected a network that rejects the connection

New PIN1 incorrect.

Try again • Second new PIN code entry is different than first

New PIN2 incorrect.

Try again • Second new PIN2 code entry is different than first

No response • Call was made to a remote phone with no response

Not allowed • Number or character entry is not allowed

Not allowed (fixed

dialing) • Number dialed does not match any of the fixed

dialing numbers in memory

Not Available • No more SIM storage available

Number changed • Called number has changed

PIN blocked • Wrong PIN code entered 3 times. Enter PUK code

PIN2 blocked • Wrong PIN2 code entered 3 times. Enter PUK2 code

PUK2 blocked • Wong PUK2 code has been entered 10 times.

The SIM services protected by the PIN2 code have

now been permanently disabled

Reaching allowed

credit! • Cost limit is about to be reached. Connected call will

end automatically when limit is reached.

Ring volume Off • Ring volume is set to 0 (no volume)

Service not available • You have requested some services that are not

available on the network

SIM blocked. Contact

provider • Wrong PUK has been entered 10 times. The SIM

card has been permanently disabled and must be

replaced by a new one.

SIM fixed full

SIM names full

Phone names full

• Corresponding phone book memory is full

SMS memory locations

are full • New message storage is full while writing a new

SMS

Wrong code. Try

again • Wrong phone lock code has been entered

Wrong PIN/PIN2, or

Wrong PUK/PUK2,

try again

• Wrong code has been entered

INDEX

Accessories 70

Adjusting volume 22

Alarm clock 62

Alert mode 43

Alert tone

Broadcast 60

SMS message 38

Voice mail 53

Alternate line service 42

Auto answer 48

Auto retry 48

AutoDTMF, sending 23

Automatic search 56

Backlight 45

Balance information 40

Basic phone operations 9

Battery

Attaching 6

Charging 7

Safety Tips 8

Bookmarks 68

Broadcast

Alert tone 60

Language 60

Message types 59

Messages 58

On/Off 59

Call Answering 10

Ending 11

Holding 23

Making 9

Retrieving 23

Call barring 57

Call barring password 19, 50

Call costs 41

Call duration reminder 41

Call forwarding 53

Call log 20, 39

Call timers 40

Call waiting 24

Caller line identity (Caller ID) 54

Calls & Timers 39

Call costs 41, 42

Call log 39

Call timers 41

Dialing from 20

Line selection 42

Care and Maintenance 18

CB messages 58

Alert tone 60

Language 60

Message types 59

On/Off 59

Reading 59

Cell broadcast messages 58

Changing front cover 71

Charging battery 7

Clear cache 68

Closed user group 58

Conference calls 24

Consumer Update on

Mobile Phones 15

Contrast 46

Creating a draft message 36

Credit limit 42

CUG 58

Currency converter 61

Date & time setting 51

Default settings 51

Dialing a number 9

Dialing stored numbers 20

Direct Links 30

Display contrast 46

Display icons 4

Draft texts 36

DTMF tones, send 22, 23

Edit online 67

End key 2, 3

Ending a call 11

Ending Internet connection 68

Entering symbols 30

Entering text 27

Error messages 76

Express Key 2, 3

Fixed dialing numbers (FDN) 34

Forwarding, call 53

Front cover, changing 71

Games 63

Getting started 6

Glossary 73

GPRS 2

GSM network 2

Headset, using 70

Holding a call 23

Icons, display 4

Inbox 20, 35

Information numbers 30

Interactive Web browsing 67

Internet

Bookmarks 68

Clear cache 68

Connecting to 66

Edit online 67

Ending connection 68

Links 67

Mode 64

Options menu 67

Other site 68

Profile list 65

Secure connection 66

Set up connection 64

Settings 65

Keypad lock 11, 43

Language

Broadcast 60

Menus 43

Last dial 20, 39

LED light 3, 7, 10

Line selection 42

Links, Internet 67

Lock keypad 11, 43

Lock phone 48

Making a call 9

Managing SMS Messages 35

Melodies, ring tone 44

Graphics 46

Language 43

Map 26

System 26

Messages

Error 76

Network 12

Messages (SMS) 34

Alert tone 38

Draft texts 36

Indicator 12

Managing 35

Reading 35

Settings 36

Storage 38

Templates 38

Write new 37

Messages, broadcast 58

Multicast 37

Mute/Unmute 22

Network messages 12

Network search 55

Network Services 30

Office Tools 60

Alarm clock 62

Currency converter 61

Scratchpad 60

On/off key 2, 3

Other site 68

Outbox messages 37

Overview 3

Own number, showing/hiding 54

Own numbers 33

Pause feature 23

Phone Book 31

Dialing numbers 32

Fixed dialing 34

Own numbers 33

Recall 32

Remaining 32

Storing in Phone memory 31

Storing in SIM memory 32

Storing numbers 31

Viewing numbers 32

Phone lock 48

Phone lock code 19, 48

Phone names, storing

numbers in 31

Phone overview 3

Phone settings 43

Auto features 48

Default 51

Display 45, 46

Keypad lock 43

Keys 46, 47

Language 43

Security 49

Time & date 51

Tones 44, 45

Pictures, view 67

PIN/PIN2 codes 19, 49, 50

Power key 2, 3

Problems 75, 76

Profile list, Internet 65

PUK/PUK2 codes 19

Push (game) 63

Ramping 45

Reading a new SMS message 35

Received call 20, 39

Receiving Caller ID 54

Reset call costs 42

Reset call timer 41

Reshape (game) 63

Retrieving a call 23

Ring tone 43

Ring tone selection 44

Safety information 13

Scratchpad 21, 60

SDN numbers 30

Security codes 19

Security features 48

Send key 2, 3

Sending a new SMS message

to many addressees 37

Sending a new SMS message

to one addressee 37

Sending my ID 55

Services 53

Call barring 50, 57

Call forwarding 53

CUG 58

Network search 56

Receiving ID 54

Sending ID 55

Settings

Broadcast 58

Phone settings 43

Services 53

Voice mail 52

Show costs 42

Silent alert mode 21, 43

SIM application tool kit 30

SIM card 6

SIM names, storing

numbers in 32

SMS messages 34

Softkeys 2, 3

Softkeys functions 46

Solutions 75, 76

Speed dialing 21, 47

Standby screen 9

Storage -- available

SMS memory 38

Storing names/numbers 31

Symbols, entering 30

T9 text entry 27

Text entering

Alpha method 29

T9 Text Input 27

Time & date setting 51

Touch tones (DTMF) 22

Troubleshooting 75

Turning off the phone 11

Turning on the phone 9

Unanswered call 12, 20, 39

Unlock keypad 11

Using this guide 4

vCards 31

Vibrate mode 43

View pictures 67

Voice mail 52

Alert tone 53

Call 52

Indicator 12

Number 52

Volume

Alarm 44, 45

Conversation 10, 22, 44, 45

Keys 44, 45

Ring 44, 45

WAP 2

WAP connection 5, 66

WAP connection, secure 5, 66

Web browsing 67

Write new SMS message 37

ONE YEAR LIMITED WARRANTY

MODEL G320

Mitsubishi Wireless Communications Inc.

800-888-9879

Mitsubishi Electric Sales Canada Inc.

Corporate Service Division

4299 14th Avenue, Markham, Ont. L3R OJ2

(905) 475-7728

Mitsubishi Wireless Communications, Inc. (MWCI) warrants this product

to the original purchaser (Purchaser) against defects in materials and

workmanship as set forth below. If ownership of the product is

transferred, this warranty is terminated. This warranty applies only to

product purchased or repaired in the United States or Canada.

For the period of time specified below from the date of first retail

purchase, MWCI shall at its sole and absolute opinion either repair or

replace the defective product or part with a new or comparable

refurbished product or part. Mitsubishi brand accessories are covered

under this warranty for one year. Batteries are covered under this

warranty for 90 days. Carrying cases are covered under this warranty for

one year.

To obtain warranty service in the US, please contact MWCI at 1-800-888-

9879 to obtain the nearest location of the MWCI authorized service

center so as to make arrangements for repair or replacement. To obtain

warranty service in Canada, please contact Mitsubishi Electric Sales

Canada, Inc. (MESCA) at (905) 475-7728 or at the Canadian address

above. Purchaser must present proof of purchase in the form of a retail

bill of sale, invoice or other document that will show that the product is

within the applicable warranty period. No charge will be made for parts

or labor directly related to the repair or replacement of the defective

product or part. The repaired or replaced product will be warranted for

90 days from the date of return shipment or for the balance of the

original warranty, whichever is longer.

Repair or replacement, as provided under this warranty, is the only

remedy provided to the purchaser. MWCI SHALL NOT BE LIABLE FOR ANY

INCIDENTAL OR CONSEQUENTIAL DAMAGES INCURRED BY PURCHASER

such as, but not limited to, interruption of service, loss of anticipated

benefits or profits, or damage to any other equipment resulting from the

use or operation of the product, or arising from breach of express or

implied warranties on this product. MWCI SHALL NOT BE LIABLE FOR

DAMAGE TO TELEPHONE EQUIPMENT, VEHICLES, AND/OR PERSONAL

PROPERTY CAUSED BY IMPROPER INSTALLATION OR USAGE.

THIS WARRANTY DOES NOT COVER FUSES OR CLAIMS OF DAMAGE DUE

TO ALTERATION, ACCIDENT, MISUSE, ABUSE, NEGLECT, IMPROPER

INSTALLATION OR MAINTENANCE, CONNECTION TO AN IMPROPER

VOLTAGE SUPPLY, RECEPTION PROBLEMS CAUSED BY INADEQUATE

SIGNALS, LIQUID SPILLS, OR DAMAGE THAT IS ATTRIBUTABLE TO ACTS OF

GOD. REMOVAL AND INSTALLATION COSTS ARE NOT COVERED BY THIS

WARRANTY. COSMETIC DAMAGE, SUCH AS MARS, SCRATCHES, CRACKS,

BLEMISHES, AND THE WEARING OF PRINTED LOGOS OR KEYS, IS NOT

COVERED BY THIS WARRANTY. DAMAGE RESULTING FROM THE USE OF

ACCESSORIES THAT ARE NOT MITSUBISHI BRAND ACCESSORIES IS NOT

COVERED.

LOSS AND DAMAGE OCCURRING DURING TRANSIT ARE NOT COVERED BY

THIS WARRANTY. Products repaired or replaced under warranty will be

returned to the Purchaser transportation prepaid. Return shipping costs

for out-of-warranty repairs shall be paid by the Purchaser.

ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE IS EXCLUDED EXCEPT WHERE PROHIBITED BY

LAW, AND WHERE PROHIBITED, IS LIMITED TO THE MINIMUM PERIOD

PERMITTED BY SUCH LAW.

Some States or Provinces do not allow the exclusion or limitation of

incidental or consequential damages, or limitations on an implied

warranty, so the above limitations or exclusions may not apply to you.

This warranty gives you specific legal rights, and you may also have other

rights which vary from State to State, or Province to Province.

Mitsubishi Electric MT289XG01A Hand Held Cellular Telephone User Manual G420man

Mitsubishi Electric Corp Hand Held Cellular Telephone G420man

Contents

Users manual

Navigation menu

Namespaces

Views

Navigation
