EN – 1

ENGLISH

FRANÇAIS

DEUTSCH

ITALIANO

ESPAÑOL

XL8

SL4

LCD PROJECTOR

MODEL

XL8U

SL4U

User Manual

EN – 2

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

The lightning flash with arrowhead symbol within an equilateral triangle is intended to

alert the user to the presence of uninsulated “dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the

presence of important operating and maintenance (servicing) instructions in the litera-

ture accompanying the appliance.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR

MOISTURE.

CAUTION:

TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION

CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO

PREVENT BLADE EXPOSURE.

NOTE:

SINCE THIS PROJECTOR IS PLUGGABLE EQUIPMENT, THE SOCKET-OUTLET SHALL BE

INSTALLED NEAR THE EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.

WARNING

Use the attached specified power supply cord. If you

use another power-supply cord, it may cause

interference with radio and television reception.

Use the attached RGB cable or RS-232C cable with

this equipment so as to keep interference within the

limit of a FCC Class B device.

This apparatus must be grounded.

DO NOT LOOK DIRECTLY INTO THE LENS

WHEN THE PROJECTOR IS IN THE POWER

ON MODE.

CAUTION

Not for use in a computer room as defined in the

Standard for the Protection of Electronic Computer/

Data Processing Equipment, ANSI/NFPA 75.

When using the projector in Europe:

COMPLIANCE NOTICE

This LCD Video Projector complies with the

requirements of the EC Directive 89/336/EEC “EMC

Directive” as amended by Directive 92/31/EEC and

93/68/EEC, and 73/23/EEC “Low Voltage Directive”

as amended by Directive 93/68/EEC.

The electro-magnetic susceptibility has been chosen

at a level that gains proper operation in residential

areas, on business and light industrial premises and

on small-scale enterprises, inside as well as outside

of the buildings. All places of operation are

characterised by their connection to the public low

voltage power supply system.

WARNING

Use the attached RGB cable or RS-232C cable with

this equipment so as to keep interference within the

limits of an EN55022 Class B device.

Please follow WARNING instructions.

EN – 3

ENGLISH

Contents

Trademark, Registered trademark

Macintosh is registered trademark of Apple Computer Inc.

Other brand or product names are trademarks or registered trademarks of their respective holders.

Declaration of Conformity

Model Number : XL8U / SL4U

Trade Name : MITSUBISHI ELECTRIC

Responsible party : Mitsubishi Digital Electronics America, Inc.

9351 Jeronimo Road, Irvine, CA 92618 U.S.A

Telephone number : +1-(949) 465-6000

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired

operation.

Important safeguards .......................................................................................... 4

Overview .............................................................................................................. 6

Remote control ..................................................................................................... 8

Installation ........................................................................................................... 9

Basic connections ............................................................................................... 10

Preparation ........................................................................................................ 12

Basic operation .................................................................................................. 13

Menu operation .................................................................................................. 15

Image adjustment .............................................................................................. 18

Advanced features ............................................................................................. 20

Lamp replacement ............................................................................................. 24

Maintenance ...................................................................................................... 25

Troubleshooting ................................................................................................. 26

Indicators ........................................................................................................... 29

Specifications ..................................................................................................... 30

EN – 4

Important safeguards

Please read all these instructions regarding your

LCD projector and retain them for future reference.

Follow all warnings and instructions marked on the

LCD projector.

1. Read instructions

All the safety and operating instructions should

be read before the appliance is operated.

2. Retain instructions

The safety and operating instructions should be

retained for future reference.

3. Warnings

All warnings on the appliance and in the

operating instructions should be adhered to.

4. Instructions

All operating instructions must be followed.

5. Cleaning

Unplug this projector from the wall outlet before

cleaning it. Do not use liquid aerosol cleaners.

Use a damp soft cloth for cleaning.

6. Attachments and equipment

Never add any attachments and/or equipment

without the approval of the manufacturer as

such additions may result in the risk of fire,

electric shock or other personal injury.

7. Water and moisture

Do not use this projector near water or in

contact with water.

8. Accessories

Do not place this projector on an unstable cart,

stand, tripod, bracket or table. Use only with a

cart, stand, tripod bracket, or table

recommended by the manufacturer or sold with

the projector. Any mounting of the appliance

should follow the manufacturer's instructions

and should use a mounting accessory

recommended by the manufacturer.

An appliance and cart combination should be

moved with care. Quick stops, excessive force

and uneven surfaces may cause the appliance

and cart combination to overturn.

9. Ventilation

Slots and openings in the cabinet are provided

for ventilation, ensuring reliable operation of the

projector and to protect it from overheating. Do

not block these openings or allow them to be

blocked by placing the projector on a bed, sofa,

rug, or bookcase. Ensure that there is adequate

ventilation and that the manufacturer's

instructions have been adhered to.

10. Power sources

This projector should be operated only from the

type of power source indicated on the marking

label. If you are not sure of the type of power,

please consult your appliance dealer or local

power company.

11. Power-cord protection

Power-supply cords should be routed so that

they are not likely to be walked on or pinched by

items placed upon or against them. Pay

particular attention to cords at plugs,

convenience receptacles, and points where they

exit from the appliance. Do not put the power

cord under a carpet.

12. Overloading

Do not overload wall outlets and extension cords

as this can result in a fire or electric shock.

13. Objects and liquids

Never push objects of any kind through openings

of this projector as they may touch dangerous

voltage points or short-out parts that could

result in a fire or electric shock. Never spill

liquid of any kind on the projector.

14. Servicing

Do not attempt to service this projector yourself.

Refer all servicing to qualified service personnel.

15. Damage requiring service

Unplug this projector from the wall outlet and

refer servicing to qualified service personnel

under the following conditions:

(a) If the power-supply cord or plug is damaged.

(b) If liquid has been spilled, or objects have

fallen into the projector.

after you follow the operating instructions.

Adjust only those controls that are covered

by the operating instructions. An improper

adjustment of other controls may result in

damage and may often require extensive

work by a qualified technician to restore the

projector to its normal operation.

(d) If the projector has been exposed to rain or

water.

(e) If the projector has been dropped or the

cabinet has been damaged.

(f) If the projector exhibits a distinct change in

performance - this indicates a need for

service.

16. Replacement parts

When replacement parts are required, be sure

that the service technician has used

replacement parts specified by the manufacturer

or parts having the same characteristics as the

original part. Unauthorized substitutions may

result in fire, electric shock or other hazards.

17. Safety check

Upon completion of any service or repair to this

projector, ask the service technician to perform

safety checks determining that the projector is

in a safe operating condition.

EN – 5

ENGLISH

WARNING:

Unplug immediately if there is something

wrong with your projector.

Do not operate if smoke, strange noise or odor comes

out of your projector. It may cause fire or electric

shock. In this case, unplug immediately and contact

your dealer.

Never remove the cabinet.

This projector contains high voltage circuitry. An

inadvertent contact may result in an electric shock.

Except as specifically explained in User Manual, do

not attempt to service this product by yourself.

Please contact your dealer when you want to fix,

adjust, or inspect the projector.

Do not modify the projector.

It can lead to fire or electric shock.

Do not keep using the damaged projector.

If the projector is dropped and the cabinet is dam-

aged, unplug the projector and contact your dealer

for inspection. It may lead to fire if you keep using

the damaged projector.

Do not face the projection lens to the sun.

It can lead to fire.

Use correct voltage.

If you use incorrect voltage, it can lead to fire.

Do not place the projector on uneven surface.

Place the projector on a level and stable surface only.

Do not look into the lens when the projector is

operating.

It may hurt your eyes. Never let children look into

the lens when the projector is on.

Do not unplug the power cord during

operation.

It can lead to lamp breakage, fire, electric shock or

other trouble. Wait for the fan to stop before unplug-

ging the power cord.

Do not touch the air outlet grilles and bottom

plate.

Do not touch them or put other equipment close to

the air outlet grilles because they become hot during

operation. The heated air outlet grilles and bottom

plate may cause injury or damage to other equip-

ment. Also, do not put the projector on a desk that is

easily affected by heat.

Clean the air-filter once a month.

Clean the air-filter frequently. If the filter or ventila-

tion slots become clogged with dirt or dust, the

temperature inside of the projector may rise and

cause some troubles, such as damage of inside parts,

and shortening the life of the panels.

Do not look into the air outlet grilles when

projector is operating.

Heat, dust, etc. may blow out of them and hurt your

eyes.

Place of installation

For safety’s sake, do not use the projector at any

place subjected to high temperature and high hu-

midity. Please maintain an operating temperature,

humidity, and altitude as specified below.

•Operating temperature: between +41°F (+5°C)

and +95°F (+35°C)

•Operating humidity: between 30% and 90%

•Never put any heat-producing device under the

projector to prevent the projector from being

overheated.

•Do not install the projector at a place that is

unstable or subject to vibration.

•Do not install the projector near any equipment

that produces a strong magnetic field. Also re-

frain from installing the projector near any cable

carrying a large amount of current.

•Place the projector on a solid, vibration-free

surface. Otherwise it may fall, causing serious

injury or damage.

•Do not stand the projector on its end. It may fall,

causing serious injury or damage.

•Slanting the projector more than ±10˚(right and

left) or ±30˚(front and rear) may cause trouble or

explosion of the lamp.

•Do not place the projector near air-conditioning

unit or heater to avoid the air outlet and inlet

grilles from being exposed to hot air.

COMPLIANCE NOTICE OF FCC

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter-

ference in a residential installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced Radio / TV technician for help.

Changes or modifications not expressly approved by Mitsubishi could void the user's authority to operate this

equipment.

COMPLIANCE NOTICE OF INDUSTRY CANADA

This Class B digital apparatus complies with Canadian ICES-003.

EN – 6

Overview

POWER STATUS

VIDEOKEYSTONE

ENTER

COMPUTER

AUTO POSITION

POWER STATUS

VIDEOKEYSTONE

ENTER

COMPUTER

AUTO POSITION

12 3 4 5

5431

9 8 67

1Remote control sensor (Front)

2Control panel

3Speaker

4Terminal panel

5Air outlet grille

6Kensington Security Lock Standard

connector

7Foot adjustment button

8Lens

9Air outlet grille

10 Remote control sensor (Rear)

11 Air inlet grille

Control panel

1Focus ring

2Zoom ring

3POWER indicator

4POWER button

5COMPUTER /$$

$ button

6MENU button

7}}

}}

} button

8KEYSTONE/ENTER button

9VIDEO/%%

% button

10 AUTO POSITION/{{

{{

{ button

11STATUS indicator

Important:

•While the menu or the screen for the keystone

adjustment or password entry is being displayed or

image capturing is being executed, the

COMPUTER, VIDEO, and AUTO POSITION

buttons function as the $, %, and { buttons

respectively.

•While the menu is on the screen, the KEYSTONE

button functions as the ENTER button.

Terminal panel

1USB terminal

2SERIAL terminal (8P)

3COMPUTER / COMPONENT VIDEO OUT

terminal (Mini D-SUB 15P)

4COMPUTER / COMPONENT VIDEO IN

terminal (Mini D-SUB 15P)

5VIDEO and AUDIO terminals

6Power jack

EN – 7

ENGLISH

Bottom side

POWER PAGE

VOLUME

EXPAND

SOURCE

KEYSTONE

AUTO

POSITION

STILL MUTE

ENTER

PinPMENU

UPDOWN

1 Lamp cover

2Air inlet grille / Filter cover

3Adjustment foot (Left/Right)

Caution:

Do not replace the lamp immediately after using the

projector because the lamp would be extremely hot and

it may cause burns.

Remote control

1POWER button

2SOURCE button

3KEYSTONE button

4STILL button

5Direction buttons

6MENU button

7EXPAND button

8VOLUME + and – buttons

9PinP button (For XL8U only)

10 ENTER button

11 MUTE button (Audio/Video)

12 AUTO POSITION button

13 PAGE UP and DOWN buttons

Important:

The VOLUME + and - buttons are used for operation

in the EXPAND mode as well as for volume control.

EN – 8

20˚

15˚

20˚

15˚

30˚30˚

Remote control

20˚ 20˚

Battery loading

First Loading:

When you use the remote control for the first time, pull out the

insulation sheet.

Replacement of the battery:

1. Turn the remote control upside down.

2. Push the lock inward and pull out the battery holder.

3. Remove the old battery.

4. Load a new battery with the positive (+) side up.

5. Push in and click the battery holder.

CAUTION

•Use of a battery of wrong type may cause explosion. Use MATSUSHITA battery, type CR2025 only.

•Dispose of used batteries according to the instructions. Batteries may explode if misused. Do not recharge,

disassemble, or dispose of in fire.

• Be sure to handle the battery according to the instructions.

• Load the battery with its positive (+) and negative (-) sides correctly oriented as indicated on the remote

control.

•Keep batteries out of reach of children and pets.

•Remove the battery, if the remote control is not used for a long time.

Operation range (of the remote control)

The maximum operation distance of the remote control is about 10 m (or about 32 feet) when the remote control

is pointed at the remote control sensor of the projector. When the remote control is pointed to the screen, the

distance from the remote control to the projector via the screen should be 6 m or less. However, the operation

distance varies depending on the type of the screen used.

Reception angle (vertical)

Reception angle (horizontal) Reception angle (vertical), ceiling mount

Important:

• Do not expose the remote control sensor to direct sunlight or fluorescent light. Keep a distance at least 2 m

(6.5 feet) between the remote control sensor and the fluorescent light to ensure correct operation of the remote

control. Inverted fluorescent light, if located near the projector, may interfere the remote control.

•When you use the remote control too close to the remote control sensor, the remote control may not work

correctly.

Remote control

Insulation sheet

Lock

Battery holder

Old battery New battery

EN – 9

ENGLISH

Installation

Layout of the projector

Image size varies depending on the distance between the screen and the projector.

Front projection

Front projection, ceiling mounting

For ceiling mounting, you need the ceiling mount kit

designed for this projector. Ask a specialist for

installation. For details, consult your dealer.

•The warranty on this projector does not cover any

damage caused by use of any non-recommended

ceiling mount kit or installation of the ceiling

mount kit in an improper location.

•When using the projector mounted on the ceiling,

set IMAGE REVERSE in the INSTALLATION

menu to MIRROR INVERT. See page 16.

• When the projector is mounted on the ceiling,

images may appear darker than those projected in

the case of tabletop mounting. This isn’t a product

malfunction.

Rear projection

Ask a specialist for installation. For details, consult

your dealer.

•For rear projection, set IMAGE REVERSE in the

INSTALLATION menu to MIRROR. See page 16.

Caution:

• Placing the projector directly on a carpet impairs

ventilation by the fans, causing damage or failure.

Put a hard board under the projector to facilitate

ventilation.

•Place the projector at least 50 cm (or 20 inch)

away from the wall to prevent the air inlet grille

and the air outlet grilles that emit hot air from

being blocked.

• Do not use the projector in the following locations

and manners, which may cause fire or electric

shock.

•In a dusty or humid place.

•In a sideways or upside-down position.

•Near a heater.

•In an oily, smoky, or damp place such as a

kitchen.

•In direct sunlight.

•Where the temperature rises high, such as in a

closed car.

•Where the temperature is lower than 41°F (or

+5˚C) or higher than 95°F (or 35˚C).

Important:

•Do not apply force to the lens, because the lens

may be damaged.

A=B

• The above figures are approximate and may be slightly different from the actual measurements.

L: Between the screen and the front edge of the projector

Hd : Height of the projected image

40 102 32 81 24 61 57 1.5 49 1.3 69 1.8 60 1.5 2.4 6.1

60 152 48 122 36 91 87 2.2 75 1.9 105 2.7 91 2.3 3.6 9.1

80 203 64 163 48 122 117 3.0 101 2.6 140 3.6 121 3.1 4.8 12.2

100 254 80 203 60 152 147 3.7 126 3.2 176 4.5 152 3.9 6.0 15.2

150 381 120 305 90 229 221 5.6 191 4.8 265 6.7 229 5.8 9.0 22.9

200 508 160 406 120 305 295 7.5 255 6.5 355 9.0 306 7.8 12.0 30.5

250 635 200 508 150 381 370 9.4 319 8.1 444 11.3 383 9.7 15.0 38.1

300 762 240 610 180 457 444 11.3 383 9.7 ––––18.0 45.7

Screen Distance from the screen : L

Diagonal size Width : W Height : H Maximum zoom (WIDE) Minimum zoom (TELE) Hd

XL8U SL4U XL8U SL4U

inch cm inch cm inch cm inch m inch m inch m inch m inch cm

EN – 10

Basic connections

This projector can be connected with various devices such as a VCR, video camera, videodisc player, and personal

computer that have analog RGB output connectors.

Important:

•Make sure that the connected device is turned off before starting connection.

•Plug in the power cords of the projector and the connected devices firmly. When unplugging, hold and pull the

plug. Do not pull the cord.

•When the projector and the connected devices are located too close to each other, the projected image may be

affected by their interference.

•See the owner’s guide of each device for details about its connections.

Projector + AV device

Important:

•Match the colors of the video and audio plugs on the AV cable with those of the terminals.

•Speaker output is mono.

•Set AUDIO MODE in the FEATURE menu to VIDEO to hear the audio only when the input source is VIDEO.

(See page 17.)

Projector + DVD player or HDTV decoder

Some DVD players have an output connector for 3-line fitting (Y, CB, CR). When connecting such DVD player with

this projector, use the COMPUTER/COMPONENT VIDEO IN terminal.

Important:

•The terminals’ names Y, PB, and PR are given as examples of when a HDTV decoder is connected.

•The terminals’ names vary depending on the connected devices.

•Use a Mini D-SUB 15P-BNC conversion cable for connection.

•Image may not be projected correctly with some DVD players.

• When connecting a HDTV decoder having RGB output terminals, set COMPUTER INPUT to RGB in the

SIGNAL menu.

•Speaker output is mono.

S-VIDEO IN

VIDEO IN

AUDIO IN

VCR, etc

to video output

to audio output

to S-video ontput

B G R

CB(PB)Y CR(PR)

HD/CS VD

AUDIO IN

COMPUTER IN

DVD player or HDTV decoder

to audio output

AUDIO cable

BNC - RCA connector (optional)

No connection

Mini D-SUB 15P-BNC

conversion cable (optional)

EN – 11

ENGLISH

Projector + Computer

Important:

•When you use a longer RGB cable instead of the provided cable, the image quality may deteriorate.

•Some computers require additional connectors or analog RGB output adapters to be connected with this

projector. Contact your dealer for further information.

•This projector uses RCA jacks for its audio input. Check the type of the audio output terminal of the connected

computer and prepare a proper cable for connection. Some computers don’t have the audio output terminal.

•Speaker output is mono.

•Set AUDIO MODE in the FEATURE menu to COMPUTER to hear the audio only when the input source is

COMPUTER. (See page 17.)

For Macintosh

• If your Macintosh has no video port, a monitor output adapter is required. Contact your dealer for further

information.

•Some Macintoshes require a MAC adapter for the RGB cable for connection with this projector. Contact your

dealer for further information.

About DDC™

The COMPUTER/COMPONENT VIDEO IN terminal of this projector complies with the DDC1/2B standard.

When a computer supporting this standard is connected to this terminal, the computer will automatically load

the information from this projector and prepare for output of appropriate images.

• After connecting a computer supporting this standard to this terminal, plug the power cord of the projector in

the wall outlet first, and then boot up the computer.

•You may need to install the DDC driver, depending on the computer you use. In this case, you need to

download the driver from our Web site. Contact your dealer or Mitsubishi sales office for further information.

AUDIO OUT

MONITOR OUTPUT

COMPUTER IN

AUDIO IN

COMPUTER

OUT

RGB cable for PC

Computer

to monitor port

PC audio cable (option)

to PC audio

output

RGB cable for PC (option)

Necessary when outputting to both a PC monitor and the projector.

EN – 12

Preparation

•Images may not be projected in a shape of a regular

rectangle or with its aspect ratio 4:3, depending on the

installation conditions of the projector and the screen.

For XL8U only

•This projector automatically corrects vertical keystone

distortion. For fine adjustment, press the KEYSTONE

button on the projector or the remote control to display

KEYSTONE, and adjust the image by pressing the %,

$ , {, or } button (or VOLUME + or - button on the

remote control).

In the following cases:

Preparation for projection

1. Attach the provided power cord to the projector.

2. Plug the power cord in the wall outlet.

3. Remove the lens cap.

Warning:

•Do not look into the lens directly when the projector is on.

•The lens cap is for protecting the lens. If you leave the

lens cap on the lens with the projector turned on, it

may be deformed because of heat build-up. Remove the

lens cap when you turn on the projector.

•The power cords for use in the U.S. and Europe are

provided with this projector. Use the appropriate cord

for your country.

•This projector uses the power plug of three-pin

grounding type. Do not remove the grounding pin from

the power plug. If the power plug doesn’t fit your wall

outlet, ask an electrician to change the wall outlet.

•The provided power cord for the U.S. is rated at 120 V.

Never connect this cord to any outlet or power supply

using other voltages or frequencies than rated. If you

want to use a power supply using other voltage than

rated, prepare an appropriate power cord separately.

•Use 100-240 V AC 50/60 Hz to prevent fire or electric

shock.

•Do not place any objects on the power cord or do not

place the projector near heat sources to prevent

damage to the power cord. If the power cord should be

damaged, contact your dealer for replacement because

it may cause fire or electric shock.

•Do not modify or alter the power cord. If the power

cord is modified or altered, it may cause fire or electric

shock.

Caution:

•Plug in the power cord firmly. When unplugging, hold

and pull the power plug, not the power cord.

•Do not plug in or out the power cord with your hand

wet. It may cause electric shock.

Adjustment of the projection angle

For the best projection, project images on a flat screen

installed at 90 degrees to the floor. If necessary, tilt the

projector using the two adjustment feet on the bottom of

the projector.

1. Tilt up the project to the appropriate angle.

2. Press the foot adjustment buttons next to the

adjustment feet, and the adjustment feet will come

out.

3. Release the buttons to lock the adjustment feet to that

position.

4. Rotate the adjustment feet for fine adjustment.

After using the projector:

5. Put the adjustment feet back into the projector by

pressing the foot adjustment buttons.

Important:

•Install the screen on a flat wall at 90 degrees to the

floor.

•Slanting the projector more than ±10˚ (horizontally) or

±30˚ (vertically) may cause trouble or explosion of the

lamp. You can tilt the projector up to 7 degrees using

the adjustment feet only.

•The automatic keystone adjustment may not be

carried out correctly because of the installation

conditions of the projector and the screen. In such

cases, correct the keystone manually.

•When the projector is projecting images where

acceleration is present, such as in a vehicle and

aircraft, the automatic keystone adjustment may not

function correctly. In such cases, set AUTO

KEYSTONE in the INSTALLATION menu to OFF

and correct the keystone manually.

•You can correct the vertical and horizontal keystones

at the same time. However, their adjustment ranges

are limited in such correction.

For SL4U only

•To correct vertical keystone distortion, press the

KEYSTONE button on the projector or the remote

control to display KEYSTONE, and adjust the image

by pressing the }, { button (or VOLUME +, - button

on the remote control).

In the following cases:

Important:

•When the keystone adjustment is carried out, the

adjustment value is indicated. Note that this value

doesn’t mean a projection angle.

•The allowable range of the adjustment value in the

keystone adjustment varies depending on the

installation conditions.

•When the keystone adjustment takes effect, the

resolution decreases. In addition, stripes may appear

or straight lines may bend in images with complicated

patterns. They are not due to product malfunctions.

•Noise may appear on the screen during the keystone

adjustment because of the type of the video signal

being projected and the setting values of the keystone

adjustment. In such cases, set the keystone

adjustment values in the range where the image is

displayed without noise.

•When the keystone adjustment is carried out, the

image may not be displayed correctly because of

the type of input signal.

• When the 1080i signal is input, the keystone

adjustment ranges are limited.

Screen

Adjustment feet

Press the %

button.

Press the $

button.

Press the }

(or -) button.

Press the {

(or +) button.

Press the }

(or -) button.

Press the {

(or +) button.

EN – 13

ENGLISH

Basic operation

Important:

•The projector starts warming up when the

POWER button is pressed. During the warm-up

process, images may appear dark and no

commands are accepted.

•By blinking red, the STATUS indicator indicates

that the lamp should be replaced soon. Replace

the lamp when the STATUS indicator blinks red.

(See page 26 and 29.)

• Images may not be projected with good quality in

an extremely hot or cold environment. (This is not

a product malfunction.)

4. Adjust the focus by turning the focus ring.

5. Choose your desired external input source using

the SOURCE button on the remote control or the

COMPUTER or VIDEO button on the control

panel.

• The input source is switched between VIDEO,

S-VIDEO and COMPUTER at every press of

the SOURCE button on the remote control.

•The input source is switched between VIDEO

and S-VIDEO at every press of the VIDEO

button on the control panel.

•The projector automatically selects the

appropriate signal format. The selected signal

format is displayed on the screen.

•The COMPUTER, VIDEO, and SOURCE

buttons don’t function while the menu is being

displayed.

•Images supplied from the computer may

flicker. Press the $ or % button on the remote

control to reduce flicker, if it occurs.

6. Adjust the image size by turning the zoom ring.

•If necessary, adjust the focus and zoom again.

Power-on

1. Turn on the device connected to the projector first.

2. Plug the power cord in the wall outlet.

•The POWER indicator lights up.

• If the power cord is unplugged from the wall

outlet before the projector is cooled down

completely after use, the fans may start

rotating when the power cord is plugged in

next time and the POWER button may not

function. In this case, wait for the fans to stop

and press the POWER button to light the

indicator.

3. Press the POWER button.

•It may take about one minute for the lamp to

light up.

•The lamp occasionally fails to light up. Wait a

few minutes and try to light the lamp again.

•After the POWER button is pressed or the

lamp mode is switched, the image may flicker

before the lamp becomes stable. This is not a

product malfunction.

•The STANDARD lamp mode is activated by

default whenever the projector is turned on.

When the LOW lamp mode has been chosen,

the default STANDARD lamp mode is switched

to the LOW lamp mode in 1.5 minutes.

POWER STATUS

VIDEOKEYSTONE

ENTER

COMPUTER

AUTO POSITION

POWER PAGE

VOLUME

EXPAND

SOURCE

KEYSTONE

AUTO

POSITION

STILL MUTE

ENTER

PinPMENU

UPDOWN

Condition Indicator STATUS POWER

Stand-by Red

When the lamp is on. Green Green

When the lamp is off temporarily.

-Red

EN – 14

Basic operation (continued)

VOLUME 15

Volume from the speaker

Press the VOLUME + or – button to change the

volume from the speaker.

The volume control bar will appear on the screen.

• The volume control bar will disappear about 10

seconds after the VOLUME button is released.

•The VOLUME buttons don’t function while the

menu selection bar or the menu is being

displayed.

•When a high-level audio signal, such as a DVD

audio signal, is supplied to the AUDIO IN

terminal, the output from the speaker may be

distorted.

AV mute

The video and audio signals are temporarily muted

when the MUTE button is pressed. To cancel muting,

press the MUTE button again.

•If MUTE MODE in the INSTALLATION menu is

set to IMAGE, the splash screen will appear when

the MUTE button is pressed.

•You can alter the splash screen optionally. See

page 21.

•When muting starts, the lamp mode becomes

LOW, darkening the display of IMAGE. This is

not a product malfunction.

Caution:

•After using the projector, wait one minute for the

air outlet fans to stop. Then unplug the power

cord from the wall outlet.

•The lamp can’t be lit again for one minute after

turned off for safety purpose. It will take another

one minute for the STATUS indicator to go out. If

you want to turn on the projector again, wait until

the indicator goes out, and then press the POWER

button.

• The air outlet fans rotate faster as the

temperature around the projector rises.

•When the temperature around the projector rises

high, the sign “TEMPERATURE!!” blinks red on

the screen. If the temperature stays high, the

lamp will go out automatically.

Power-off

Use the following procedure to turn off the projector.

Do not turn off the projector by unplugging the power

cord while the lamp is on. Unplugging while the lamp

is on degrades the lamp’s performance and causes

failure in the projector.

1.Press the POWER button.

•The message “POWER OFF? YES : PRESS

AGAIN” appears on the screen.

•To cancel, press any button except the POWER

button. (Some buttons on the remote control

don’t function for cancel.)

2.Press the POWER button within 10 seconds again.

•The lamp will go out and the STATUS

indicator will start blinking.

• Though the lamp goes out at this second press

of the POWER button, the air outlet fans

continue operating for one minute to cool down

the lamp and LCD panels. The STATUS

indicator will stop blinking.

3.Unplug the power cord.

•The POWER indicator will go out.

•If the power cord should be unplugged

accidentally while either the air inlet fan or the

air outlet fans are operating or the lamp is on,

allow the projector to cool down for 10 minutes

with the power off. To light the lamp again,

press the POWER button. If the lamp doesn’t

light up immediately, repeat pressing the

POWER button two or three times. If it should

still fail to light up, replace the lamp.

Important:

•When storing the projector in the provided

carrying case, the lens should face up.

AUTO POSITION button

When the image isn’t projected in the right position

with COMPUTER selected as the input source, follow

the procedure below.

1. Project a bright image such as the “Recycle Bin”

window on the full screen.

2. If the screen saver is running, turn it off.

3. Press the AUTO POSITION button.

•If the image is still not in the right position,

adjust the image position using the SIGNAL

menu.

EN – 15

ENGLISH

Menu operation


XGA60

opt.

INSTALLATION

XGA60

opt.

AUTO POWER

OFF

AUTO POWER

OFF

INSTALLATION

XGA60

opt.

AUTO POWER

OFF

AUTO POWER

OFF

AUTO POWER

30 min

AUTO POWER

OFF

Basic operation

Several settings can be adjusted using the menu.

Example : Auto power off time setting

1. Press the MENU button.

2. Press the $ or % button to select

INSTALLATION.

3. Press the ENTER button (or } button).

4. Press the { or } button to select AUTO

POWER OFF.

5. Press the $ or % button to adjust the auto

power off time.

6. Exit the menu by pressing the MENU button

several times.

Important:

•When the MENU button doesn’t function,

unplug the power cord from the wall outlet.

Wait about 10 minutes, plug the power cord in,

and try again.

•After selecting the items marked with , press

the ENTER button.

IMAGE CONTRAST ± 30

BRIGHTNESS

COLOR MATRIX

± 30

sRGB ON , OFF

STANDARD

LOW

HIGH

USER

COLOR TEMP.

COLOR ± 10

TINT ± 10

SHARPNESS ± 5

GAMMA MODE AUTO, DYNAMIC, STANDARD, THEATER

CONTRAST R ± 30

CONTRAST B ± 30

BRIGHTNESS R ± 30

BRIGHTNESS B ± 30

EXPAND MODE

EXPAND, REAL

AUDIO MODE COMPUTER, VIDEO, COMPUTER VIDEO, MUTE

INSTALLATION

AUTO KEYSTONE ON , OFF

OFF, MIRROR, INVERT, MIRROR INVERT

AUTO POWER ON ON , OFF

RESET ALL OK

AUTO POWER OFF

ON , OFF

FEATURE MENU POSITION 1 (Upper left), 2(Lower right)

IMAGE REVERSE

SPLASH SCREEN

BLACK, IMAGEMUTE MODE

BLUE, BLACK, IMAGEBACK COLOR

STANDARD, LOWLAMP MODE

OFF, CENTER, UPPER, LOWER ANAMORPHIC

DISPLAY INPUT , MENU ACCESS , SPLASH ID SCREEN

PASSWORD FUNCTION

ON , OFFSCART INPUT

VIDEO SIGNAL AUTO , NTSC , PAL , SECAM , 4.43NTSC , PAL-M , PAL-N , PAL-60

LANGUAGE , English, Español, Deutsch, Français, Italiano, , , ,

VIDEO

YELLOW ± 30

RED ± 30

BLUE ± 30

CYAN ± 30

GREEN ± 30

MAGENTA ± 30

RGB-TINT ± 20

COMPUTER

USER

OFF

SIGNAL HORIZ.POSITION

HOLD

0 - 999

VERT.POSITION 0 - 999

FINE SYNC. 0 - 31

TRACKING

USER

0 - 9999

CLAMP POSITION

0 - 63

CLAMP WIDTH 1 - 63

SHUTTER (L) 0 - 20

SHUTTER (U) 0 - 20

SHUTTER (RS) 0 - 20

SHUTTER (LS) 0 - 20

VERT. SYNC. AUTO, OFF

AUTO , OFFCINEMA MODE

*3*3

ON BEGIN 0 - 15

END 0 - 15

OFF

COMPUTER INPUT

RGB, YCBCR / YPBPR

OFF, 5, 10, 15, 30, 60 min

UNLOCK OK

LOCK

*2*1

IMAGE CAPTURE

SETUP

x1, x2, FULL

GLAY, RED, GREEN, BLUE, BLACK, WHITE, RED 50%, GREEN 50%, BLUE 50%

CAPTURE

BACK COLOR

SIZE

(Displayed only when the source is VIDEO or S-VIDEO.)

(These items are not available when the input

source is COMPUTER.)

* 1: Not available when sRGB is set to ON.

* 2: Not available with certain signals.

* 3: Not available when the source is a VIDEO

or S-VIDEO signal.

* 4: Available only when the input signal is TV60, 480i.

* 5: Setting range differs depending on the input signals.

(For XL8U only.)

EN – 16

INSTALLATION

opt.

BACK COLOR

AUTO POWER

OFF

SPLASH

SCREEN

MUTE MODE

LAMP MODE

BLUE

BLACK

OFF


CAPTURE SETUP

OFF

STANDARD

OFF

AUTO

KEYSTONE


REVERSE

XGA60

CONTRAST


BRIGHTNESS 0

STANDARD

COLOR

AUTO

XGA60

COMPUTER

OFF

TINT

0SHARPNESS

COLOR TEMP.

GAMMA MODE

COLOR MATRIX

sRGB

opt.

Menu operation (continued)

1 IMAGE

CONTRAST ......... Use to adjust the image contrast. The contrast becomes higher

as the value increases.

BRIGHTNESS ..... Use to adjust the image brightness. The image becomes

brighter as the value increases.

sRGB .................... Choose ON for projection emphasizing on the color

reproducibility.

•When sRGB is ON, COLOR MATRIX, COLOR TEMP.,

COLOR, TINT, and GAMMA MODE can't be adjusted.

COLOR MATRIX . Use to adjust the color balance in each color of the image. See

page 18.

COLOR TEMP. .... Use to adjust the color temperature. See page 18.

COLOR ................ Use to adjust the color intensity of the image.

TINT .................... Use to adjust the color balance of the image. The color balance

shifts to green as the value increases and shifts to purple as

the value decreases. (Available only when VIDEO is chosen as

the source.)

•When the TV50 (PAL, SECAM) signal is input, TINT can't be adjusted.

SHARPNESS ....... Use to adjust the image sharpness. The image becomes sharp as the value increases. (Available only

when VIDEO is chosen as the source.)

GAMMA MODE ... When AUTO is selected, the appropriate gamma mode is automatically selected depending on the

input signal. For normal use, select AUTO. Select DYNAMIC for computer sources. Select

STANDARD for sport scenes and video sources. Select THEATER for film sources.

2 INSTALLATION

AUTO POWER ON ......

When ON is chosen, the lamp is automatically lit when the

power cord is plugged in the wall outlet. Choose ON when

using the projector mounted on the ceiling.

•The projector is in the stand-by mode when the lamp

is off. Use the remote control to turn on the lamp.

AUTO POWER OFF Use to set the time elapsed before the projector enters the

stand-by mode when there is no signal input from the source.

IMAGE CAPTURE Use to capture the screen for the splash screen. See page 21.

SPLASH SCREEN Choose ON to display the splash screen when the power is

turned on.

•The splash screen can be changed. See page 21.

BACK COLOR ...... Use to select the background from among BLUE, BLACK and

IMAGE, which will be displayed when there is no signal input

from the source. When IMAGE is selected, the splash screen will be displayed.

MUTE MODE ...... Use to choose the background, either BLACK, or IMAGE, which will be displayed when the MUTE

button is pressed. When IMAGE is chosen, the splash screen will be displayed.

LAMP MODE ....... Use to change the brightness of the lamp. When LOW is chosen, the lamp brightness is kept low

and the volume of the operation sound is reduced, resulting in a longer lamp replacement interval.

• The STANDARD lamp mode is activated by default whenever the projector is turned on.

When the LOW lamp mode has been chosen, the default STANDARD lamp mode is

switched to the LOW lamp mode in 1.5 minutes.

•When the lamp mode is switched, the projected image may flicker. This is not a product

malfunction.

AUTO KEYSTONE .....

Choose ON to adjust the vertical keystone distortion automatically. (For XL8U only.)

IMAGE REVERSE ..

Use to reverse the projected image. Select MIRROR for rear projection with the tabletop-mounted

projector. Select MIRROR INVERT for rear projection with the ceiling-mounted projector.

• When you continue projection for a long time with BACK COLOR or MUTE MODE set to IMAGE, an after-

image may persist on the screen.

•Do not change the setting of LAMP MODE frequently.

•You can’t set IMAGE CAPTURE or SPLASH SCREEN when PASSWORD FUNCTION in the FEATURE

menu has been set to SPLASH ID SCREEN to enable the password lock.

EN – 17

ENGLISH

3 FEATURE

MENU POSITION ...

Use to select the position of the menu on the screen, 1.

(upper left) or 2. (lower right).

EXPAND MODE .. Choose the mode for enlarging the image. See page 20.

AUDIO MODE ..... Select COMPUTER to output the audio that is input to the

AUDIO IN terminal when COMPUTER is chosen as the

source. Select VIDEO to output the audio that is input to that

terminal when VIDEO is chosen as the source. Select

COMPUTER VIDEO mode to always output the audio that is

input to that terminal. Select MUTE not to output the audio at

all.

CINEMA MODE .. When AUTO is selected, the film mode will be automatically

activated when a film source signal is inputted. When OFF is

selected, the film mode will not be activated.

VIDEO SIGNAL ... When AUTO is selected, the appropriate video format is

automatically selected depending on the input signal. If the

image isn’t displayed correctly, select the desired video format manually.

SCART INPUT ..... Choose ON when connecting the projector with a device equipped with the SCART terminal that

can output RGB signal. SCART terminal is used mainly in Europe. Choose OFF normally.

ANAMORPHIC .... Select the desired position from among UPPER, CENTER, and LOWER when playing DVD discs

containing data of letterboxed images.

PASSWORD FUNCTION .

Use to change the mode of the password lock or to enable or cancel the password lock. See page 23

for details.

LANGUAGE ........ Use to select the language used in the menu. ( / English / Español / Deutsch / Français /

Italiano / / / / )

RESET ALL ......... Use to reset the menu settings (except IMAGE CAPTURE, PASSWORD, and LANGUAGE ).

•CINEMA MODE can be adjusted only when a TV60,480i signal is being displayed.

•When SCART INPUT is set to ON, nothing is output to the external monitor.

•When SCART INPUT is set to ON, normal computer signals aren’t projected.

•Use a SCART-BNC (or SCART-Mini D-SUB 15P) cable (option) when connecting this projector with an AV

device equipped with the SCART terminal.

•Some AV devices equipped with the SCART terminal aren’t compatible with this projector.

•When VIDEO SIGNAL is set to AUTO, the image may not be projected with correct colors. Change the

setting of VIDEO SIGNAL depending on the input signal in such cases.

•When ANAMORPHIC is set to except OFF, the keystone adjustment ranges are limited.

4 SIGNAL

HORIZ. POSITION ...

Use to adjust the horizontal position of the image.

VERT. POSITION ...

Use to adjust the vertical position of the image.

FINE SYNC. ......... Use to synchronize the projector with the PC input signal so

that the image is not blurred.

TRACKING .......... Use to eliminate image noise such as wide stripes.

COMPUTER INPUT ...

The projector adjusts its settings automatically when

connected to a DVD player equipped with a component video

output (Y, CB, CR). When the projector is connected with a

device having an RGB terminal, choose RGB manually.

HOLD .................. Use to adjust the image when flagging occurs near the top of

the screen.

5 SIGNAL - USER (No need to adjust in normal use.)

CLAMP POSITION/

CLAMP WIDTH ... Use to correct solid white or solid black in the projected image.

VERT.SYNC. ........ Use to adjust the image when its motion doesn’t run smoothly.

Select AUTO for normal use.

SHUTTER (U) ...... Use to adjust the image when noise appears on the top part of the

image.

SHUTTER (L) ...... Use to adjust the image when noise appears on the bottom part of

the image.

SHUTTER (LS) .... Use to adjust the image when noise appears on the left half of the

image.

SHUTTER (RS) .... Use to adjust the image when noise appears on the right half of

the image.

•If any setting of the SIGNAL-USER menu is changed, the image maynot be displayed correctly. In this

case, press the AUTO POSITION button.

Important:

•You can set the IMAGE, SIGNAL, and SIGNAL-USER menus only when the signal is supplied.

•TV60 and TV50 are equivalent to 480i and 576i respectively. Settings made for one of them apply

automatically when its counterpart is supplied.

FEATURE

OFF

XGA60

AUTO

EXPAND

opt.

MENU POSITION

EXPAND MODE

VIDEO SIGNAL

ANAMORPHIC

RESET ALL

English

LANGUAGE

SCART INPUT

DISPLAY

INPUT

PASSWORD

FUNCTION

CINEMA MODE AUTO

AUDIO MODE COMPUTER

VIDEO

CLAMP

POSITION

SIGNAL-USER

CLAMP WIDTH 1

SHUTTER (U) 0

SHUTTER (L) 0

SHUTTER (LS) 0

SHUTTER (RS) 0

VERT. SYNC. AUTO

R G B

SIGNAL

HORIZ. POSITION 0

VERT. POSITION 0

TRACKING 0

COMPUTER

INPUT RGB

FINE SYNC. 0

USER

XGA60

opt.

HOLD

EN – 18

Image adjustment

CONTRAST R

COLOR TEMP.-USER

CONTRAST B 0

BRIGHTNESS R 0

BRIGHTNESS B 0

CONTRAST


BRIGHTNESS 0

STANDARD

COLOR

AUTO

XGA60

COMPUTER

OFF

TINT

0SHARPNESS

COLOR TEMP.

GAMMA MODE

COLOR MATRIX

sRGB

opt.

4. Press the { or } button to select the desired

color.

•If you want to adjust the all color balance of

the image, select RGB-TINT.

5. Press the $ or % button to adjust the color

balance of the selected color.

6. Repeat steps 4 and 5 for optimum adjustment

results.

7. Exit the menu by pressing the MENU button

several times.

•When the input source is VIDEO or COMPUTER,

the setting items in the color matrix adjustment

are automatically set to the predetermined values.

You can change these settings manually.

•To cancel the color matrix adjustment, select OFF

in step 2.

•When the color matrix adjustment is carried out,

the colors in the menu will also vary. This isn’t a

product malfunction.

Color temperature

1. Select COLOR TEMP. in the IMAGE menu.

2. Press the $ or % button to select USER .

3. Press the ENTER button.

4. Press the { or } button to select the desired

item.

5. Press the $ or % button to adjust the selected

item.

6. Repeat steps 4 and 5 for optimum adjustment

results.

7. Exit the menu by pressing the MENU button

several times.

COLOR MATRIX

RED

RGB-TINT

GREEN

BLUE

YELLOW

CYAN

MAGENTA

About color temperature

There are different kinds of white color. Color

temperature is a way to show the differences in

white. White of which temperature is low appears

reddish. When the color temperature rises, white

appears bluish. This projector adjusts this color

temperature by changing the values of contrast

blue and red.

To rise the color temperature:

Increase the CONTRAST B (blue) and decrease the

CONTRAST R (red).

To reduce the color temperature:

Decrease the CONTRAST B (blue) and increase

the CONTRAST R (red).

Image adjustment

You can adjust the image using the IMAGE menu.

To control the white-to-black level of the image :

Adjust CONTRAST in the IMAGE menu. Press the

% button to increase the contrast and the $ button

to reduce it.

To control the light level of the image :

Adjust BRIGHTNESS in the IMAGE menu. Press

the % button to lighten the image and the $ button

to darken it.

To determine the intensity of the color :

Adjust COLOR in the IMAGE menu. Press the %

button to increase the amount of color in the image

and the $ button to decrease it.

To adjust the red-green color balance of the

image :

Adjust TINT in the IMAGE menu. Press the %

button to increase the amount of green in the image

and the $ button to increase the amount of red in

the image.

To adjust the detail and clarity of the image :

Adjust SHARPNESS in the IMAGE menu. Press the

% button to sharpen the image and the $ button to

soften the image.

Color matrix

This projector adjusts the color balance in each color

of RGB (red, green, and blue), and their neutral

colors (yellow, cyan, and magenta) by the color

correction adjustment. Use the color correct

adjustment when you want to emphasize color or

when only a certain color balance is not correctly

adjusted.

1. Select COLOR MATRIX in the IMAGE menu.

2. Press the $ or % button to select USER .

3. Press the ENTER button.

EN – 19

ENGLISH

Adjustment of the image from the

computer

This projector adjusts the format of the video signal

supplied from the computer. However, sometimes

images are not projected correctly owing to the type

of the computer used. When the image from the

computer isn’t projected correctly, press the AUTO

POSITION button. (See page 14.) If the image isn’t

projected correctly yet, adjust the image from the

computer using the menu.

To move the image horizontally :

Adjust HORIZ. POSITION in the SIGNAL menu.

Press the % button to move the image to the left.

Press the $ button to move the image to the right.

To move the image vertically :

Adjust VERT. POSITION in the SIGNAL menu.

Press the % button to move the image upward.

Press the $ button to move the image downward.

When the image flickers or the image is out of

focus :

Adjust FINE SYNC. in the SIGNAL menu.

When the top part of the image flags :

Change the setting of HOLD in the SIGNAL menu.

Select ON , press the ENTER button, and adjust

BEGIN or END to minimize the flagging.

When wide strips appear :

Adjust CLAMP POSITION or CLAMP WIDTH in the

SIGNAL - USER menu.

When the motion doesn't run smoothly :

Adjust VERT. SYNC. in the SIGNAL - USER menu.

Select AUTO for normal use.

When noise appears on the right or left half of

the image :

Adjust SHUTTER (LS) or SHUTTER (RS) in the

SIGNAL - USER menu.

When noise appears on the top or bottom part

of the image :

Adjust SHUTTER (U) or SHUTTER (L) in the

SIGNAL - USER menu.

R G B

SIGNAL

HORIZ. POSITION 0

VERT. POSITION 0

TRACKING 0

COMPUTER

INPUT RGB

FINE SYNC. 0

USER

XGA60

opt.

HOLD

CLAMP

POSITION

SIGNAL-USER

CLAMP WIDTH 1

SHUTTER (U) 0

SHUTTER (L) 0

SHUTTER (LS) 0

SHUTTER (RS) 0

VERT. SYNC. AUTO

Important:

Do not change any of the settings in the SIGNAL-

USER menu for normal use.

Simple adjustment method

1. Select HORIZ. POSITION in the SIGNAL menu.

2. Press the $ or % button to adjust the horizontal

start position (or the left side of the image).

3. Select TRACKING in the SIGNAL menu.

4. Press the $ or % button to adjust the horizontal

end position (or the right edge of the image).

5. Repeat steps 1 to 4 for optimum adjustment

results.

6. Select VERT. POSITION in the SIGNAL menu.

7. Press the $ or % button to adjust the vertical

start position (or the upper edge of the image).

EN – 20

Advanced features

Expand

By pressing the EXPAND button on the remote

control, you can magnify the image to view the

details. You can view the image in its original size in

the REAL mode.

•The EXPAND mode doesn't work with video

or S-video signal.

•The EXPAND mode doesn't function with some

input signals. For details, see page 32 or 33.

Still

To stop the motion in the image temporarily (or

to display a still image):

Press the STILL button on the remote control.

•The image will freeze temporarily.

To resume the motion in the image:

Press the STILL button on the remote control again.

For XL8U only

Picture in Picture (PinP)

One of the special features of this projector is the

picture-in-picture (PinP) mode. The PinP mode

allows you to view the images from different sources

at the same time.

To use the PinP mode

1. Press the PinP button on the remote control.

•When you press the PinP button with the

image from the COMPUTER/COMPONENT

VIDEO IN terminal displayed on the screen,

the image from the VIDEO IN or S-VIDEO IN

terminal is displayed as the sub image.

•When the image from the VIDEO IN or S-

VIDEO IN terminal is displayed, the PinP

mode isn’t activated.

2. If necessary, select the desired external input

source of the sub image by using the SOURCE

button on the remote control or the VIDEO button

on the control panel.

To change the position of the sub image:

1. Press the $ or % buttons on the remote control.

2. Press the PinP button on the remote control.

•The sub image will disappear.

Important:

•The motion may not run smoothly in the PinP

mode.

•The PinP mode isn’t available with some input

signals. For further information, see page 32.

To choose the EXPAND or REAL mode:

1. Press the MENU button.

2. Press the $ or % to select the FEATURE menu.

3. Press the ENTER button.

4. Press the { or } button to select EXPAND MODE.

5. Press the $ or % to choose EXPAND or REAL.

6. Press the MENU button twice to exit the menu.

To use the EXPAND mode:

1. Press the EXPAND button.

•You can select the area to be magnified by

pressing the {, }, $, or % button on the

remote control.

•You can change the magnification of the se-

lected area by pressing the + or - button.

2. Press the EXPAND button again to the exit the

EXPAND mode.

•The regular operation screen will appear.

Important:

•In the EXPAND mode, you can't adjust the vol-

ume.

To use the REAL mode:

1. Press the EXPAND button.

•In the REAL mode, press the $ or % button on

the remote control for fine adjustment.

•In the REAL mode, the AUTO POSITION button

doesn't function. When this button is pressed, the

prohibition mark ( ) appears on the screen.

2. Press the EXPAND button again to the exit the

REAL mode.

•The regular operation screen will appear.

EXPAND REAL

Magnified image Native resolution display

EN – 21

ENGLISH

XL8U

CAPTURE : ENTER X2

CANCEL : MENU

CAPTURE : ENTER + ENTER

CANCEL : MENU

XL8U

CAPTURE : ENTER X2

CANCEL : MENU

Setting of the image displayed during

startup or muting

You can display your desired image as the startup

screen (or splash screen). Using the menu, you can also

use such image as a background that is displayed

while the video is muted or no signal is supplied.

Important:

•You can't set IMAGE CAPTURE when PASS-

WORD FUNCTION in the FEATURE menu has

been set to SPLASH ID SCREEN to enable the

password lock.

Setting procedure

1. Press the COMPUTER button to select the image

supplied to the COMPUTER/COMPONENT

VIDEO IN terminal.

2. Display your desired image.

3. Display the INSTALLATION menu.

4. Select IMAGE CAPTURE by pressing the { or }

button.

5. Press the ENTER button.

• The setting menu will be displayed.

opt.

INSTALLATION

CUSTOM IMAGE CAPTURE

XGA60

BACK COLOR

SIZE

GRAY

CAPTURE GO

Set the background color

(Set the background color only when you set the

image size to x1 or x2.)

6. Select BACK COLOR by pressing the { or }

button.

7. Select your desired color for the background

(GRAY, RED, GREEN, BLUE, BLACK, WHITE,

RED50%, GREEN50%, or BLUE50%) by pressing

the $ or % button.

Set the image size

8. Select SIZE by pressing the { or } button.

9. Select x1, x2, or FULL by pressing the $ or %

button.

Capture the image

10.Select CAPTURE by pressing the { or } button.

11.Press the ENTER button.

•A red frame appears. (The size of the red

frame is 295x222 pixels.)

12. Adjust the size of the image to be captured so that

such image stays within the red frame.

•Press the {, }, $, or % button to move the

red frame.

•You can’t move the red frame outside the

screen.

13.Press the ENTER button twice.

•Image capture will start.

• Press the MENU button to cancel the proce-

dure.

•When the image capture completes, the cap-

tured image will be displayed for three sec-

onds.

Important:

•You can’t change the new startup screen back to

the original startup screen. (Even when you

select RESET ALL in the FEATURE menu, the

factory default screen isn’t available any longer.)

When you want to change the startup screen

again, capture another image.

•The captured image will be displayed from the

next startup. If the captured image isn’t dis-

played, make sure that the setting of SPLASH

SCREEN in the INSTALLATION menu isn’t OFF.

(See page 16.)

•To display the captured image while the video is

muted, set MUTE MODE in the INSTALLATION

menu to IMAGE. (See page 16.)

•When BACK COLOR in the INSTALLATION

menu is set to IMAGE, the captured image will be

displayed while no signal is supplied.

•Some images can’t be captured correctly because

of their signal type.

LVP-XD300

Capturing Logo !

x1 x2 FULL

EN – 22

Advanced features (continued)

USB

Page-up and page-down

You can control the computer to page-up and page-down the presentation data using the remote control.

Switch the pages using the PAGE UP or DOWN button on the remote control.

Connection

To control the computer using the remote control, connect the projector with the computer as shown below.

•Only the computers equipped with a USB port are supported.

•Wait for the lamp to light up before connecting the USB cable.

PAGE UP or DOWN button

to USB port

USB 4P

(type B)

USB 4P

(type A)

EN – 23

ENGLISH

FEATURE

PASSWORD FUNCTION

XGA60

opt.

LOCK

UNLOCK

PASSWORD

CONFIRM

O K CANCEL

FEATURE

PASSWORD FUNCTION

XGA60

opt.

LOCK

UNLOCK

PASSWORD

O K CANCEL

Password function

This projector is equipped with the password func-

tion that is designed for prevention of theft and

wrong operation by children and restriction on

operation by other than specified users. The pass-

word function has three modes as follows.

DISPLAY INPUT .......... When the projector is turned

on, the startup screen (or splash screen) will

appear and stay on the screen until the password

is entered. When the password is entered, the

startup screen will switch to the regular operation

screen.

MENU ACCESS ............ All the buttons except for

the POWER button on the projector are disabled.

(The buttons on the remote control are enabled.)

You can use this mode as a measure of prevention

of wrong operation by children and restriction on

operation by other than specified users.

SPLASH ID SCREEN .. IMAGE CAPTURE and

SPLASH SCREEN in the menu become

unavailable. SPLASH SCREEN will be set to ON

automatically.

To enable the password function:

1. Display the FEATURE menu.

2. Press the { or } button to select PASSWORD

FUNCTION.

3. Press the % button to change the mode among

DISPLAY INPUT, MENU ACCESS, and SPLASH

ID SCREEN.

•When the password has already been set, the mode

won’t be changed. In such cases, press the ENTER

button to cancel the password function and try

again.

4. Press the ENTER button.

• The screen for setting the password function

will appear.

5. Press the ENTER button.

•The screen for entering a password will appear.

6. Press the { or } button to select a number from

0 to 9.

7. Press the % button.

•You can set the next digit.

8. Repeat steps 6 and 7 to set a four-digit password.

9. Enter the password again for confirmation using

the same steps.

10.Select OK, and press the ENTER button.

•If the entered passwords don’t match, an error

message will appear.

•To cancel the procedure, select CANCEL, and

press the ENTER button.

•You can cancel the procedure by pressing the

MENU button alternatively.

To cancel the password function:

1. Display the FEATURE menu.

2. Press the { or } button to select PASSWORD

FUNCTION.

3. Press the ENTER button.

• The screen for canceling the password function

will appear.

4. Press the ENTER button.

•The screen for entering the password will

appear.

5. Press the { or } button to select a number from

0 to 9.

6. Press the % button.

•You can set the next digit.

7. Repeat steps 5 and 6 to enter the four-digit pass-

word.

8. Press the % button, select OK, and press the

ENTER button.

•If you enter a wrong password, an error mes-

sage will appear.

•To cancel the procedure, press the % button,

select CANCEL, and press the ENTER button.

•You can cancel the procedure by pressing the

MENU button alternatively.

EN – 24

Lamp replacement

8. Tighten up the screws (c) using a

Phillips screwdriver (+).

9. Tighten up the screw (a) using a

Phillips screwdriver (+) to secure the

lamp cover.

Reset of the lamp operation time

Plug in the power cord, turn on the

lamp, and reset the lamp operation time by keep

pressing the $, %, and POWER buttons on the

control panel at the same time about three seconds.

Important:

•Unless these three buttons are pressed at the

same time, the lamp operation time isn’t reset.

•Make sure that the STATUS indicator is lit about

two seconds and the lamp operation time is reset

successfully.

•The projector doesn’t turn on if the lamp cover

isn’t attached securely.

• Be sure to reset the lamp operation time when-

ever you replace the lamp.

•Do not reset the lamp operation time unless you

replace the lamp.

Caution:

• The lamp is fragile. If it is broken, be careful not

to cut yourself with glass fragments.

• Contact your dealer for a new lamp.

Interval of lamp replacement

The recommended interval of lamp replacement is

about 2,000 hours of consecutive use. Such interval

differs depending on the operating environment and

may be shorter than 2,000 hours. Decrease in lumi-

nescence and/or color brightness indicates that the

lamp needs to be replaced. When the lamp operation

time exceeds 1,500 hours*1, the indicator will blink

alternately between green and red (while the lamp is

lit; when the lamp is not lit, the indicator will be lit

red only) and the lamp replacement message will

appear on the screen for one minute everytime the

lamp is turned on. When the lamp has been used for

about 1,900 hours*1, the replacement message

(LAMP:>1900H) will appear on the screen for one

minute every 10 hours thereafter.

When the lamp operation time exceeds 2,000

hours*1 *2, the projector automatically shuts off

and can’t be used until the lamp is replaced

and the lamp operation time is reset.

*1When LAMP MODE of the INSTALLATION menu

is set to STANDARD.

*2When LAMP MODE is set to LOW, this duration

will be extended up to 3,000 hours.

Caution:

•This projector uses a lamp that contains mercury.

Disposal of the lamp or the projector with the

lamp may be regulated due to environmental

considerations. For disposal or recycling informa-

tion, please contact your local authorities or the

Electronic Industries Alliance: www.eiae.org. (For

US only).

(b)

(a)

(c)

(d)

(c)

The lamp is designed to project the image on the LCD

panels. When the lamp no longer functions, replace it

with a new one.

Caution:

•Do not remove the lamp immediately after using

the projector. You may get burned because the

lamp is very hot after use.

• Before replacing the lamp, press the POWER

button to turn off the lamp and wait for two

minutes for the lamp and LCD panels to cool

down. Unplug the power cord from the wall outlet

and wait one hour for the lamp to cool down

completely.

• Do not remove the lamp except for replacement.

Careless handling can cause injury or fire.

•Do not touch the lamp directly. It may break and

cause injury or burn.

• Be sure not to drop the lamp lid screw into the

projector. Also be sure not to put metal or any

flammable objects inside because it may cause fire

or electric shock. If any objects should fall inside,

unplug and contact your dealer.

• Install the lamp securely to prevent failure and

fire.

• If the lamp should break, small glass fragments

may fall out through the grilles and some may

remain inside of the projector or the lamp box.

When taking the lamp box out, be sure to turn

over the projector and hold the handle of the lamp

box to avoid injury due to the glass fragments.

•If the lamp should break, never shake the lamp

box or hold it in front of your face after removing

it. The glass fragments may fall out and cause

injury to your eyes.

1. Reverse the projector gently.

2. Loosen the screw (a) using a

Phillips screwdriver (+), and

remove the lamp cover (b).

3. Remove the screws (c) using a

Phillips screwdriver (+).

4. Pull up the handle.

5. Pull out the lamp box by the handle

while holding the projector.

•Pull the lamp box out of the

projector slowly. If it is pulled out

quickly, the lamp may break

scattering glass fragments.

• Do not spill liquid on the re-

moved lamp box or do not place it

near any flammable object or

where children can reach to

prevent injury or fire.

•Do not remove the screws (d). If

they are removed, the lamp may fall

in the cource of removal of the box,

resulting in lamp breakage.

6. Load a new lamp box securely

into the projector in the right

orientation.

7. Put the handle back to the

original position.

•Make sure that the handle is

locked.

EN – 25

ENGLISH

Maintenance

Cleaning of the projector and the

ventilation slots

Use a soft cloth to clean the projector and the ventila-

tion grilles. When the grilles become dirty, wipe them

with a soft cloth dampened with diluted mild deter-

gent, and then wipe them with a dry cloth.

To protect the surface of the projector from fading or

deteriorating:

•Do not spray insecticide on or inside the projector.

•Do not use benzine or thinner to clean it.

• Do not let rubber or plastic materials contact with

projector.

Cleaning of the lens

Use a standard lens-cleaning brush or a piece of lens

tissue dampened with lens cleaning fluid. The lens

surface is fragile. Use only recommended, nonabra-

sive lens-cleaning materials. Do not touch the lens

with your fingers.

Caution:

Be sure to turn off the lamp and unplug the power

cord from the wall outlet before you perform any

maintenance on the projector.

Cleaning of the air-filter

Clean the air-filter fre-

quently (about once a

month). If the filter or

ventilation grilles become

clogged with dirt or dust,

the temperature inside

the projector may rise and

cause troubles, such as

damage to the inside

parts and shortening the

life of the panels.

•When the temperature

inside the projector rises, the STATUS indicator

will blink orange and the lamp will be turned off.

1. Put the projector upside

down and raise the lock of

the filter cover in the

direction of the arrow.

2. Remove the air-filter.

3. Wash the air-filter or

change it with a new filter.

•Use water or diluted

mild detergent to clean

the filter. Rinse the filter

thoroughly and let it dry

completely.

4. Attach the air-filter.

5. Attach the filter cover to the projector.

•Make sure that the air-filter is attached

correctly without displacement.

Important:

• If the filter is damaged or becomes extremely

dirty, change it with a new filter. Contact your

dealer for a new filter.

•The projector will not turn on if the air-filter

cover is attached improperly .

Caution:

Be sure to use the projector with an air-filter. If not,

dust may get inside the projector causing fire and

failure.

Filter cover

Lock

Air-filter

EN – 26

Troubleshooting

The following offers solutions to some of the common problems you may encounter. We suggest that you consult

this chart before contacting your dealer.

Images aren't projected on the screen.

Problem

Power isn't turned on.

Images aren't projected

on the screen.

Images suddenly

disappear.

"NO SIGNAL" is

displayed.

The screen for entering

the password appears.

Cause and solution

• Check the states of the indicators.

POWER

Off

Steady red

Blinking

red / green

STATUS

Off

Blinking

orange

Blinking

green

Steady red

Off

Steady

Blinking

Solution

• Connect the power cord to the projector.

• Plug the power cord into a wall outlet.

• If any objects are blocking the air inlet or outlet grille, remove them and carry

out the following.

1. Unplug the power cord from the wall outlet.

2. Make sure that the projector has cooled off.

3. Plug the power cord into the wall outlet.

4. Press the POWER button.

• If any objects are blocking the air inlet or outlet grille, remove them.

• Don't expose the air outlet grilles to hot air emitted from a heating appliance.

• Check whether the filter is clogged with dirt or dust.

➔Clean the filter, if clogged. (See page 25.)

• After the STATUS indicator stops blinking, press the POWER button.

• If you unplug the power cord while the fan is rotating, the lamp may not turn on about one minute

when you plug the power cord next time.

• The lamp can't turn on again for one minute after it goes out.

• Press the POWER button several times.

• Replace the lamp. (The lamp is at the end of its life.)

• Attach the lamp cover on the bottom.

• Unplug the power cord from the wall outlet and contact your dealer.

•Cancel the AV mute by pressing the MUTE button.

•The lamp sometimes takes about one minute to light up.

• On rare occasion, the lamp fails to light up. In such cases, wait a few minutes and try to

light the lamp again.

•If the projector was turned off before the lamp cooled down completely, the fans may

start rotating and the POWER button may not function when you plug the power cord

into the wall outlet next time. Wait for the fans to stop and press the POWER button to

turn on the lamp again.

•Set SCART INPUT in the FEATURE menu to OFF. (See page 17.)

•Check that the filter is clean. (See page 25.)

•Check that the lamp cover are closed.

•Check that the cable connected to the external device isn't broken.

•When an extension cord is being used, replace it with the supplied cable and check

whether images are projected correctly. If images are projected correctly, use an RGB

signal amplifier along with the extension cord.

•The air inlet or outlet grille may be blocked. (In such cases, the STATUS indicator blinks

green.)

➔Remove the objects blocking the air inlet or outlet grille and carry out the following.

1. Wait for the air inlet or outlet fan to stop (or wait for the STATUS indicator to go out.)

2. Unplug the power cord from the wall outlet.

3. Wait about 10 minutes.

4. Plug the power cord into the wall outlet.

5. Press the POWER button.

•When the STATUS indicator is blinking red, it is indicating that the lamp should be

replaced. Replace the lamp in this case.

•Turn on the power of the connected device, or check whether there is something wrong

with the connected device.

• Check whether the external device outputs signals. (Check this especially when the

external device is a notebook computer.)

• Check that the cable connected to the external device isn't defective.

•Check that the projector is connected to the external device using the correct terminals.

•Check that the connected device is correctly selected as the input source.

•When an extension cord is being used, replace it with the supplied cable and check

whether images are projected correctly. If images are projected correctly, use an RGB

signal amplifier along with the extension cord.

•PASSWORD FUNCTION in the FEATURE menu has been set to DISPLAY INPUT to

enable the password lock.

➔Enter the password or contact the person in charge of management of the projector.

(See page 23.)

EN – 27

ENGLISH

Images aren't projected correctly.

Problem

Projected images are

shaking.

Projected images are

displaced.

Projected images are

distorted.

Projected images are

dark.

Projected images are

blurred.

Afterimages persist on

the screen.

Red, blue, and green

dots appear in projected

images.

Black dots appear in

projected images.

Fine streak pattern

appears in projected

images.

Projected images (and/

or audio) appear wavy

and distorted.

Tint in projected images

is incorrect.

Only the motion areas

in the images supplied

from the computer

aren't displayed.

Projected images are

obscured.

Cause and solution

• Check that the cable connected to the external device isn't intermittent.

•Connect the cable's plug with the external device's connector firmly.

•Press the AUTO POSITION button.

•Some computers output out-of-spec signals on rare occasion. Adjust the SIGNAL menu. (See

page 19.)

•Adjust the projector and the screen so that they are perpendicular to each other. (See page

12.)

•Adjust BRIGHTNESS in the IMAGE menu. (See page 18.)

•Replace the lamp. (See page 24.)

•Adjust the focus. (See page 13.)

•Remove the lens cap.

•Clean the lens.

•Press the $ or % button on the remote control to eliminate flicker.

• Adjust BRIGHTNESS and CONTRAST in the IMAGE menu. (See page 18.)

•Adjust the projector and the screen so that they are perpendicular to each other. (See page

12.)

• This phenomenon is improved by keeping projecting an evenly bright image. (Such "image

burn-in" phenomenon where afterimages persist on the screen may occur if a stationary

image is kept displayed on the screen for a long time.)

• This phenomenon is unique to LCD projector and isn't a product malfunction.

(A small number of pixels always stay on or off, which are not malfunctions. More than

99.99% of the pixels are effective.)

•It occurs because of interference with the screen and isn't a product malfunction. Change

the screen or readjust the focus of the projector.

•Connect the cable's plug with the external device's connector firmly.

•Keep the projector away from equipment generating interfering radio waves.

• When the keystone adjustment is carried out, the image may not be displayed correctly

because of the type of input signal. This isn’t a product malfunction. In this case, readjust

the keystone so that the amount of keystone correction is as small as possible.

•Check that COMPUTER INPUT in the SIGNAL menu is correctly set. (See page 17.)

•Check that the cable connected to the external device isn't broken.

•This is caused by the computer being used. Contact the manufacturer of your computer.

•Match the output resolution of your computer with the resolution of the projector. For the

method to change the output resolution of the computer, contact the manufacturer of your

computer. (See page 32.)

• Some images and texts appear obscured during the keystone adjustment. In such cases, use

the projector without applying the keystone adjustment. (See page 12.)

EN – 28

Troubleshooting (continued)

Others

Cause and solution

•This air comes out as a result of cooling the inside of the projector. This isn't a product

malfunction.

•Check that the volume isn't set to low.

•The microcomputers inside the projector may be wrongly operating because of noise.

➔Press the POWER button to turn off the lamp and unplug the power cord from the wall

outlet. Wait about 10 minutes, plug the power cord in, and try again.

• This indication appears when the ambient temperature rises high. When the ambient

temperature stays high, the lamp goes out.

➔Eliminate any causes of the rise in the ambient temperature.

• This indication appears when the air inlet or outlet grille is blocked. When they are kept

blocked, the lamp goes out.

➔Remove the objects blocking the air inlet or outlet grille. Clean the filter. (See page 25.)

•This mark appears when ineffective operation is carried out. This isn't a product malfunc-

tion.

• Check that the battery is loaded in the remote control or the battery isn't weak. (See page

8.)

• Check that the remote control sensor isn't exposed to direct sunlight or fluorescent light.

(See page 8.)

•Use the remote control within its operation range. (See page 8.)

•Use the remote control at least 10 cm away from the projector.

•PASSWORD FUNCTION in the FEATURE menu has been set to MENU ACCESS to enable

the password lock.

➔Cancel the password lock or contact the person in charge of management of the projector.

(See page 23.)

When the problems below occur after the lamp is replaced, check the following.

Problem

The power isn't

turned on.

The STATUS indicator

blinks.

Problem

Hot air is emitted from

the air outlet grilles.

No audio is output.

The menu can't be used.

“TEMPERATURE!!” is

displayed.

The mark appears.

The remote control

doesn't function easily

or at all.

The buttons on the

control panel (except for

the POWER button)

don’t function.

Cause and solution

•Attach the lamp cover on the bottom correctly.

•Reset the lamp operation time. (See page 24.)

EN – 29

ENGLISH

Indicators

POWER STATUS

VIDEOKEYSTONECOMPUTER

AUTO POSITION

POWER

Steady

red

Steady

green

Steady

green

STATUS

Off

Blinking

green

Steady

green

CONDITION

Stand-by

Lamp stand-by (about 1 minute)

The power is on. (Normal condition)

NOTE

The POWER button cannot be used to

switch between on and off.

POWER

Steady

green

Steady red

Steady

green

Steady red

Blinking

green/red

Blinking

green/red

STATUS

Blinking orange

Blinking green

Blinking green/red

Blinking red

Steady red

Off

Steady

Blinking

CONDITION

Abnormal temperature

• The ventilation grilles or air filter is clogged with

dust or dirt.

• The room temperature is high.

The protection circuit is working or the lamp is in an

abnormal condition.

Lamp operation time warning. (Total lamp operation

time reached 1,500 hours* while the power was on.)

Lamp operation time warning. (Total lamp operation

time reached 1,500 hours* while the power was off.)

Lamp operation time warning. (Total lamp operation

time reached 2,000 hours* while the power was off.)

The lamp cover isn’t closed.

Abnormal.

POSSIBLE SOLUTION

• Clean the ventilation grilles or air filter.

• Relocate the projector to a cooler place.

•Wait until the STATUS indicator goes out,

then press the POWER button.

• If the above solution is not effective,

replace the lamp.

Replace the lamp.

Change with a new lamp if this problem

recurs.

Close the cover correctly.

Contact your dealer.

* When LAMP MODE of the INSTALLATION menu is set to STANDARD.When it is set to LOW, the duration will be extended.

This projector has two indicators, each of which shows the operation condition of the projector.

The following offer solutions to possible problems. If these problem persist, turn the projector off and consult your

dealer.

Normal condition

Abnormal condition

POWER indicator

STATUS indicator

EN – 30

Specifications

Type

Model

Rated power supply

Rated input

LCD panels

Colors

Projection lens

Light source lamp

Picture size

PC compatibility

Video compatibility

Audio output

Speaker

S-video input

Video input

Audio inputs

Analog RGB input

Control connector

Outside dimensions

Weight

Length of power cord

Temperature, humidity

(performance guaranteed)

LCD projector

XL8U / SL4U

100 - 240 V AC, 50 / 60 Hz

2.6 A

0.7-inch LCD panel: 3 pieces (for R, G, B)

Pixels 1,024 x 768 = 786,432 pixels Total 2,359,296 pixels (XL8U)

Pixels 800 x 600 = 480,000 pixels Total 1,440,000 pixels (SL4U)

Active pixel rate: 99.99% or more (each panel)

16,770,000 colors

F 1.8 - 2.1 f = 27 - 32 mm (XL8U)

F 2.0 - 2.3 f = 23 - 27 mm (SL4U)

180 W NSH

40 - 300 inch (aspect ratio 4:3)

Resolution :

640 x 400 (Expand) - 1024 x 768 (Real) - 1280 x 1024 (Compress) (XL8U)

640 x 400 (Expand) - 800 x 600 (Real) - 1024 x 768 (Compress) (SL4U)

Sync on Green available

NTSC / NTSC 4.43 / PAL (including PAL-M, N) / SECAM, PAL-60

Component Video (DVD/HDTV) (480i, 576i, 480p, 576p, 1080i, 720p)

2 W Mono

Round type (16 Ω 2 W) × 1

Luminance signal: 1.0 Vp-p 75 Ω (negative sync.)

Chroma signal: 0.286 Vp-p 75 Ω (burst signal)

1.0 Vp-p 75 Ω (negative sync.)

300 mVrms, 10 kΩ or more

RGB: 0.7 Vp-p 75 Ω (negative sync.)

YPBPR(YCBCR): Y:1.0 Vp-p (negative sync.) PBPR(CBCR):0.7 Vp-p

HD/CS : TTL level (positive or negative)

VD : TTL level (positive or negative)

Serial (8-pin connector) RS-232C standards

USB terminal

275 × 70 × 261 mm (width × height × depth) Feet and lens are not included.

Approx. 2.7 kg

114 inch (2.9 m)

+41°F (+5°C) - +95°F (+35°C), 30~90%

Kensington Lock

This projector has a Kensington Security Standard connector for use with Kensington MicroSaver Security

System. Refer to the information that came with the Kensington System for instructions on how to use it to

secure the projector. Please contact Kensington Technology Group below.

Kensington Technology Group

2855 Campus Drive

San Mateo, CA 94403, U.S.A.

Phone : +1- (650)572-2700 Fax : +1- (650)572-9675

EN – 31

ENGLISH

Connectors

1R(RED)/CR

G(GREEN)/Y

B(BLUE)/CB

4GND

5GND

6GND

7GND

8GND

9–

10 GND

11 GND

12 DDC Data

13 HD/CS

14 VD

15 DDC Clock

1TXD IN

2––

3––

4GND –

5CTS / 5V IN/OUT

6CLOCK OUT

7RXD OUT

8RI / DATA OUT

267

48.7

267

281

275 261

RS-232C (8P)

Pin No. Name I/O

COMPUTER / COMPONENT VIDEO IN/OUT

(Mini D-SUB 15P)

Pin No. Spec.

Dimensional drawings (unit : mm)

What’s included in the box

2 AC power cord 246C483-10

246C383-20

1Audio/Video cable 246C381-10

1RGB cable for PC 246C448-10

1RS-232C cable 246C447-10

1USB cable 246C450-10

1Remote control (with battery) 939P961-10

1Quick reference card 857D055-10

1Safety manual 871D393-10

1CD-ROM 919C133-10

1Carrying case 772P043-10

Replacement part

(Option / Not included in the box)

Spare lamp 499B037-10

(VLT-XL8LP)

1R(RED)/CR

G(GREEN)/Y

B(BLUE)/CB

4–

5GND

6GND

7GND

8GND

9–

10 GND

11 –

12 –

13 HD/CS

14 VD

15 –

Pin No. Spec.

OUT

EN – 32

TV60, 480i(525i) – 15.73 59.94 1024 x 768 – *1

TV50, 576i(625i) – 15.63 50.00 1024 x 768 – *1

1080i 60 (1125i 60) – 33.75 60.00 1024 x 576 – *1

1080i 50 (1125i 50) – 28.13 50.00 1024 x 576 – *1

1080i 50a (1250i 50) – 31.25 50.00 1024 x 576 – *1

480p (525p) – 31.47 59.94 1024 x 768 – *1

576p (625p) – 31.25 50.00 1024 x 768 – *1

720p 60 (750p 60) – 45.00 60.00 1024 x 576 – *1

720p 50 (750p 50) – 37.50 50.00 1024 x 576 – *1

PC98 640 x 400 24.82 56.42 1024 x 640 640 x 400 *2

CGA70 640 x 400 31.47 70.09 1024 x 640 640 x 400 *2

CGA84 640 x 400 37.86 84.13 1024 x 640 640 x 400 *2

CGA85 640 x 400 37.86 85.08 1024 x 640 640 x 400 *2

VGA60 640 x 480 31.47 59.94 1024 x 768 640 x 480 *2

VGA72 640 x 480 37.86 72.81 1024 x 768 640 x 480 *2

VGA75 640 x 480 37.50 75.00 1024 x 768 640 x 480 *2

VGA85 640 x 480 43.27 85.01 1024 x 768 640 x 480 *2

VGA120 640 x 480 61.89 120.17 1024 x 768 640 x 480 *2

SVGA56 800 x 600 35.16 56.25 1024 x 768 800 x 600

SVGA60 800 x 600 37.88 60.32 1024 x 768 800 x 600

SVGA72 800 x 600 48.08 72.19 1024 x 768 800 x 600

SVGA75 800 x 600 46.88 75.00 1024 x 768 800 x 600

SVGA85 800 x 600 53.67 85.06 1024 x 768 800 x 600

SVGA95 800 x 600 59.97 94.89 1024 x 768 800 x 600

SVGA120 800 x 600 77.11 119.93 1024 x 768 800 x 600

XGA43i 1024 x 768 35.52 86.96 1024 x 768 1024 x 768 *2

XGA60 1024 x 768 48.36 60.00 1024 x 768 1024 x 768

XGA70 1024 x 768 56.48 70.07 1024 x 768 1024 x 768

XGA75 1024 x 768 60.02 75.03 1024 x 768 1024 x 768

XGA85 1024 x 768 68.68 85.00 1024 x 768 1024 x 768

XGA120 1024 x 768 98.58 119.78 1024 x 768 1024 x 768

SXGA70a 1152 x 864 63.85 70.01 1024 x 768 1024 x 768 *2

SXGA75a 1152 x 864 67.50 75.00 1024 x 768 1024 x 768 *2

SXGA85a 1152 x 864 77.49 85.06 1024 x 768 1024 x 768 *2

SXGA60b 1280 x 960 60.00 60.00 1024 x 768 1024 x 768 *2

SXGA75b 1280 x 960 75.00 75.00 1024 x 768 1024 x 768 *2

SXGA43i 1280 x 1024 46.43 86.87 960 x 768 1024 x 768 *2

SXGA60 1280 x 1024 63.98 60.02 960 x 768 1024 x 768 *2

SXGA75 1280 x 1024 79.98 75.02 960 x 768 1024 x 768 *2

MAC13 640 x 480 35.00 66.67 1024 x 768 640 x 480 *2

MAC16 832 x 624 49.72 74.55 1024 x 768 832 x 624 *2

MAC19 1024 x 768 60.24 75.02 1024 x 768 1024 x 768 *2

MAC21 1152 x 870 68.59 74.96 1016 x 768 1024 x 768 *2

HP75 1024 x 768 62.94 74.92 1024 x 768 1024 x 768 *2

HP72 1280 x 1024 78.13 72.00 960 x 768 1024 x 768 *2

SUN66a 1152 x 900 61.85 66.00 984 x 768 1024 x 768 *2

SUN76a 1152 x 900 71.81 76.64 984 x 768 1024 x 768 *2

SUN66 1280 x 1024 71.68 66.68 960 x 768 1024 x 768 *2

SUN76 1280 x 1024 81.13 76.11 960 x 768 1024 x 768 *2

SGI72 1280 x 1024 76.92 72.30 960 x 768 1024 x 768 *2

SGI76 1280 x 1024 82.01 76.00 960 x 768 1024 x 768 *2

IBM60 1280 x 1024 63.42 60.00 960 x 768 1024 x 768 *2

Specifications (continued)

Specification of RGB signals in each computer mode of the projector (For XL8U)

Signal mode resolution horizontal Vertical Normal mode Real mode

(H x V) frequency (kHz) frequency (Hz) (H x V) (H x V)

*1 : The Expand mode and the PinP mode don’t

function with this signal.

*2 : The PinP mode don’t function with this signal.

•When the EXPAND button on the remote control

is pressed with EXPAND MODE in the FEATURE

menu set to REAL, images are displayed in their

original size. In the REAL mode, images are

black-framed when the image resolution is lower

than 1,024 x 768.

Important:

•Some computers aren’t compatible with the

projector.

•The projector's maximum resolution is 1,024 x 768

pixels. It may not display images of higher resolu-

tions than 1,024 x 768 correctly.

•Images with SYNC on G (Green) signal may jitter.

•Images with SYNC on G (Green) signal may be

tinged with green.

•If the resolution and frequency of your computer

aren't shown on the table, find the compatible

resolution and frequency by changing the resolu-

tion of your computer.

•Set COMPUTER INPUT in the SIGNAL menu to

RGB when inputting the HDTV signal as RGB

signal.

• In the case of SXGA, the right side of the image

may not appear. In this case, adjust TRACKING

in the SIGNAL menu.

• TV60 and TV50 are equivalent to 480i and 576i

respectively. When these signals are supplied to

the VIDEO or S-VIDEO signal, the signal mode is

indicated as TV60 or TV50. When they are

supplied to the COMPONENT terminal, the

signal mode is indicated as 480i or 576i.

EN – 33

ENGLISH

TV60, 480i(525i) – 15.73 59.94 800 x 600 – *1

TV50, 576i(625i) – 15.63 50.00 800 x 600 – *1

1080i 60 (1125i 60) – 33.75 60.00 800 x 450 – *1

1080i 50 (1125i 50) – 28.13 50.00 800 x 450 – *1

1080i 50a (1250i 50) – 31.25 50.00 800 x 450 – *1

480p (525p) – 31.47 59.94 800 x 600 – *1

576p (625p) – 31.25 50.00 800 x 600 – *1

720p 60 (750p 60) – 45.00 60.00 800 x 450 – *1

720p 50 (750p 50) – 37.50 50.00 800 x 450 – *1

PC98 640 x 400 24.82 56.42 800 x 500 640 x 400

CGA70 640 x 400 31.47 70.09 800 x 500 640 x 400

CGA84 640 x 400 37.86 84.13 800 x 500 640 x 400

CGA85 640 x 400 37.86 85.08 800 x 500 640 x 400

VGA60 640 x 480 31.47 59.94 800 x 600 640 x 480

VGA72 640 x 480 37.86 72.81 800 x 600 640 x 480

VGA75 640 x 480 37.50 75.00 800 x 600 640 x 480

VGA85 640 x 480 43.27 85.01 800 x 600 640 x 480

VGA120 640 x 480 61.89 120.17 800 x 600 640 x 480

SVGA56 800 x 600 35.16 56.25 800 x 600 800 x 600

SVGA60 800 x 600 37.88 60.32 800 x 600 800 x 600

SVGA72 800 x 600 48.08 72.19 800 x 600 800 x 600

SVGA75 800 x 600 46.88 75.00 800 x 600 800 x 600

SVGA85 800 x 600 53.67 85.06 800 x 600 800 x 600

SVGA95 800 x 600 59.97 94.89 800 x 600 800 x 600

SVGA120 800 x 600 77.11 119.93 800 x 600 800 x 600

XGA43i 1024 x 768 35.52 86.96 800 x 600 800 x 600

XGA60 1024 x 768 48.36 60.00 800 x 600 800 x 600

XGA70 1024 x 768 56.48 70.07 800 x 600 800 x 600

XGA75 1024 x 768 60.02 75.03 800 x 600 800 x 600

XGA85 1024 x 768 68.68 85.00 800 x 600 800 x 600

MAC13 640 x 480 35.00 66.67 800 x 600 640 x 480

MAC16 832 x 624 49.72 74.55 800 x 600 800 x 600

MAC19 1024 x 768 60.24 75.02 800 x 600 800 x 600

HP75 1024 x 768 62.94 74.92 800 x 600 800 x 600

Specification of RGB signals in each computer mode of the projector (For SL4U)

Signal mode resolution horizontal Vertical Normal mode Real mode

(H x V) frequency (kHz) frequency (Hz) (H x V) (H x V)

*1 : The Expand mode don’t function with this

signal.

•When the EXPAND button on the remote control

is pressed with EXPAND MODE in the FEATURE

menu set to REAL, images are displayed in their

original size. In the REAL mode, images are

black-framed when the image resolution is lower

than 800 x 600.

Important:

•Some computers aren’t compatible with the

projector.

•The projector's maximum resolution is 800 x 600

pixels. It may not display images of higher resolu-

tions than 800 x 600 correctly.

•Images with SYNC on G (Green) signal may jitter.

•Images with SYNC on G (Green) signal may be

tinged with green.

•If the resolution and frequency of your computer

aren't shown on the table, find the compatible

resolution and frequency by changing the resolu-

tion of your computer.

•Set COMPUTER INPUT in the SIGNAL menu to

RGB when inputting the HDTV signal as RGB

signal.

• In the case of XGA, the right side of the image

may not appear. In this case, adjust TRACKING

in the SIGNAL menu.

• TV60 and TV50 are equivalent to 480i and 576i

respectively. When these signals are supplied to

the VIDEO or S-VIDEO signal, the signal mode is

indicated as TV60 or TV50. When they are

supplied to the COMPONENT terminal, the

signal mode is indicated as 480i or 576i.

North America

MESCA (Mitsubishi Electric Sales Canada Inc.)

http://www.mitsubishielectric.ca

Information Technologies Group, 4299 14th Avenue, Markham, Ontario L3R

0J2, Canada

Sales Phone :+1-(905) 475-7728

Fax :+1-(905) 475-7958

E-mail :projectors@mitsubishielectric.ca

Technical Phone :+1-(905) 475-7728

Fax :+1-(905) 475-7958

Customer Care

E-mail :support@mitsubishielectric.ca

MDEA (Mitsubishi Digital Electronics America, Inc.)

(Warranty Registration)

http://www.mitsubishi-presentations.com/

Presentation Products Division, 9351 Jeronimo Road, Irvine, CA 92618 U.S.A

Phone Main Line :+1-(949) 465-6000

Technical :+1-(888) 307-0309

Product Information :+1-(888) 307-0312

Technical Support

E-mail :tsupport@mdea.mea.com

Europe

MEU-FRA (Mitsubishi Electric Europe B.V French Branch)

25, Boulevard des Bouvets 92 741, Nanterre CEDEX, France

Sales Phone :+33 (0)1 55-68-55-07

Fax :+33 (0)1 55-68-57-31

Technical Phone :+33 (0)1 41-02-83-24

Fax :+33 (0)1 49-01-07-23

MEU-GER (Mitsubishi Electric Europe B.V. German Branch)

http://www.mitsubishi-evs.de/

Gothaer Strasse 8, 40880 Ratingen, Germany

MEU-IR (Mitsubishi Electric Europe B.V. Irish Branch)

http://www.mitsubishi.ie/

Westgate Business Park, Ballymount, Dublin 24, Ireland

Sales Phone :+353-(0)1- 4198844

Fax :+353-(0)1-4564422

Technical Phone :+353-(0)1-4198807

Fax :+353-(0)1-4198895

MEU-IT (Mitsubishi Electric Europe B.V. Italian Branch)

Centro Direzionale Colleoni, Palazzo Persero-Ingresso 2, Via Paracelso 12, 20041

Agrate Brianza, Italy

Sales Phone :+39-(0)39-60531

Fax :+39-(0)39-6053214

E-mail :info.projector@it.mee.com

MEU-NL (Mitsubishi Electric Europe B.V. Benelux Branch)

http://www.mitsubishi.nl/LCD/ProdFrame.html

Nijverheidsweg 23a, 3641 RP Mijdrecht, The Netherlands

Sales Phone :+31-297-282461

Fax :+31-297-283936

E-mail :info.lcd@nl.mee.com

Technical Phone :+31-297-282461

Fax :+31-297-283936

E-mail :info.lcd@nl.mee.com

MEU (MITSUBISHI ELECTRIC EUROPE B.V.)

http://www.mitsubishi-projector.ru/

Moscow Representative Office, 12/1 Goncharnaya St. 109240, Moscow, Russia

Sales Phone :+7 (095) 915 8602

Fax :+7 (095) 915 8603

MEU-SP (Mitsubishi Electric Europe B.V. Spanish Branch)

http://www.mitsubishielectric.es/

Ctra. de Rubi, 76-80, 08190 Sant Cugat del Valles, Barcelona, Spain

Sales Phone :+34-93.565.31.54

Fax :+34-93.589.43.88

E-mail :mitsubishi.profesional@sp.mee.com

Technical Phone :+34-93.586.27.51

Fax :+34-93.699.74.45

E-mail :mitsubishi.profesional@sp.mee.com

MEU-SWE (Mitsubishi Electric Europe B.V Scandinavian Branch)

Hammarbacken 14, Box 750, S-19127, Sollentuna, Sweden

Sales Phone :+46-(0)8-6251070

Fax :+46-(0)8-6251036

Technical Phone :+46-(0)8-6251052

Fax :+46-(0)8-6251036

MEU-UK (Mitsubishi Electric Europe)

http://www.mitsubishi.co.uk/evs/

Visual Information Systems Division, Travellers Lane, Hatfield, Hertfordshire,

AL10 8XB

Sales Phone :+44 (1707) 278684

Fax :+44 (1707) 278541

E-mail :projector.info@meuk.mee.com

Technical Phone :+44 (870) 606 5008

Fax :+44 (1506) 431927

E-mail :projector.info@meuk.mee.com

Russia (Mitsubishi Electric Europe B.V Moscow Representative Office)

52, bldg.5, Kosmodamianskaya Nab, 113054, Moscow, Russian Federation

Sales Phone :+7 (095) 721 2070

Fax :+7 (095) 721 2071

Technical Phone :+7 (095) 721 2070

Fax :+7 (095) 721 2071

MITSUBISHI Projector Contact Information

Asia

RIL (Ryoden (Holdings) Ltd. )

http://www.ryoden.com.hk

•Hong Kong Office

15/F, Manulife Tower, 169 Electric Road, North Point, Hong Kong, China

Technical Support

Phone :+852 6510 1750

Fax :+852 2887 8027

•Beijing Office

9/F, Office Tower 1, Henderson Centre, 18 Jianguomennei Dajie, Dongcheng

District, Beijing, 100005, China

Sales & Technical Support

Phone :+86 (10) 6518 2930

Fax :+86 (10) 6518 2530

•Shanghai Office

10/F, Shanghai Square Office Tower, 138 Huai Hai Zhong Road, Lu Wan

District, Shanghai, 200021, China

Sales & Technical Support

Phone :+86 (21) 6327 2228

Fax :+86 (21) 6327 4918

•Shenzhen Office

Unit 01-04, 13/F, Building A, Tian An International Building, Renmin Road

South, Shenzhen, 518005, China

Sales & Technical Support

Phone :+86 (755) 518 6386

Fax :+86 (755) 218 4775

•Chengdu Office

Block B-1, 23/F., Chuan Xin Mansion, 18 Section 2, Renmin Road South,

Chengdu, 610016, China

Sales & Technical Support

Phone :+86 (28) 619 9730

Fax :+86 (28) 619 9801

REMECO (Ryoden Merchandising Co., Ltd.)

http://www.mitsubishi-ryoden.com.hk
