DIGITAL TELEVISIONS '_
MFSUBISHI
i,VillWPOinl
Owner Information:
Use this space to record the serial number of your HD=6000.
This information is on the back of your receiver/controller.
Serial number
visit our bs_te
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
)liance.
Portions of the advanced circuitry of this Receiver/Controller must continue to operate even when
the Receiver/Controller is turned off. Some of these circuits therefore need to be cooled at all
times. A low power standby fan may be heard in a quiet environment. This is normal operation.
Warning: To avoid permanently imprinting a fixed image onto your projection television or plasma
monitor screen, please do not display the same stationary images on the screen for more than 15% of
your total TV viewing in one week. Examples of stationary images are letterbox top/bottom bars from
DVD disc or other video sources, side bars when showing standard TV pictures on widescreen TV's,
stock market reports, video game patterns, black or bright Closed Caption backgrounds, station Iogos,
web sites or stationary computer images. Such patterns can unevenly age the picture tubes or plasma
display panels, causing permanent damage to the display. Please see page 35 for a detailed explanation.
Note that not all high definition television sets are fully compatible with this product and may cause
artifacts to be displayed in the picture. In the case of 525 progressive scan picture problems, it is
recommended that the user switch the connection to the standard definition output. If there are
questions regarding your TV set compatibility with this receiver/controller at 525p, please contact our
customer service center.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
NOTE TO CATV SYSTEM INSTALLER: THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM INSTALLER'S
ATTENTION TO ARTICLE 820-40 OF THE NEC THAT PROVIDES GUIDELINES FOR THE PROPER GROUNDING AND,
IN PARTICULAR, SPECIFIES THAT THE CABLE GROUND SHALL BE CONNECTED TO THE GROUNDING SYSTEM
OF THE BUILDING, AS CLOSE TO THE POINT OF CABLE ENTRY AS PRACTICAL.
FCC DecMaration of Conformity
Product: High Definition Receiver/Controller
Models: HD=6000
Responsible Party: Mitsubishi Digital Electronics America, hc.
9851 Jeronimo Road
Rrvine, CA 92618=1904
Telephone: 949=465=6000
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference wiii not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
o Reorient or relocate the receiving antenna.
o Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
o Consult the dealer or an experienced radioiTV technician for help.
Changes or modifications not expressly approved by Mitsubishi could cause harmful interference and would
void the user's authority to operate this equipment.
Contents
Chapter I HDo6000 Receiver/Controller Overview
Accessories ................................................................................................................ 10
SpecialFeatures ......................................................................................................... 11
Front Control Panei .................................................................................................... 12
Back Panel .................................................................................................................. 13
Chapter 2 Connecting
External Devices & NetCommand® Setup .............................................................. 16
Wail Outlet Cable ........................................................................................................ 17
Cable £ox .................................................................................................................... 17
CabieCARD TM Technology ......................................................................................... 18
Single Lead Antenna .................................................................................................. 19
Separate UHF and VHF Antennas ........................................................................... 19
Antenna or Wail Outlet Cable to a VCR (Audio & Video) ........................................ 20
Cable Box to a VCR (Audio & Video) ........................................................................ 21
A/V Receiver or Stereo System ................................................................................ 22
Satellite Receiver or Other Device with SoVideo .................................................... 22
MoLink Control ............................................................................................................ 23
Computer with a PC Monitor Output ....................................................................... 23
DTV Receiver
with Component Video ........................................................................................... 24
with RGB, HV Video ................................................................................................ 25
DVD Player with Component Video .......................................................................... 26
Display Monitor with Component Video .................................................................. 26
Display Monitor with an HDMm mnput ........................................................................ 27
HDMm Source Device .................................................................................................. 27
DVi Device ................................................................................................................... 28
To the Mitsubishi L%4260 LCD TV ........................................................................... 29
mREmitter NetCommand® ........................................................................................ 30
mRSensor mnput ........................................................................................................... 31
Compatible (EEE 1394 Devices ................................................................................. 32
Helpful Hints ............................................................................................................... 34
mmportant Notes ......................................................................................................... 35
Chapter 3 NetCommand ® Setup and Editing
Using the Remote Control with NetCommand® .................................................... 38
Remote Control Functions: Overview ...................................................................... 39
Remote Control Functions:
Battery mnstallation ............................................................................................... 40
Care ........................................................................................................................ 40
Sleep Timer ............................................................................................................ 40
NetCommand® OnScreen Buttons .......................................................................... 41
3D Graphical Viewpoint® Menu System ................................................................. 42
NetCommand® mnitiai Setup ..................................................................................... 43
Edit NetCommand®
Add an A/V Receiver ............................................................................................. 45
Add Devices ........................................................................................................... 48
Change ...................................................................................................................52
DemeteDevices.......................................................................................................52
Finish Screen.........................................................................................................52
Chapter 4 mEEE 1394 Devices and NetCommand® Controlled Recordings
mEEE 1394 Devices and NetCommand® Controm .................................................... 54
Adding mEEE 1394 Devices Automatically ................................................................ 55
Device Semection Menu .............................................................................................. 57
Using the DEVICE MENU Button to Display Menus ............................................... 58
Using the Guide Button to Display ChannelView TM and Menus ............................ 5g
NetCommand® Controlled
Recordings .......................................................................................................... 60
Record List .......................................................................................................... 61
Peer-to-Peer Connections ................................................................................ 62
Using TV Disc & A/V Disc ......................................................................................... 58
Direct VCR Recording from an Antenna or Cabme Source ..................................... 63
PC Viewing .................................................................................................................. 64
MediaCommand TM and Media Card Pmayback with the Mitsubishi LTo4260 ....... 65
Chapter 5 Tv Menu Screen Operations
Main Menu Choices ................................................................................................... 68
Setup Menu ................................................................................................................. 69
NetCommand® Menu ................................................................................................ 71
Antenna Menu ............................................................................................................. 72
Time Menu .................................................................................................................. 74
Captions Menu ........................................................................................................... 75
V-Chip Rating Guidelines .......................................................................................... 77
V-Chip Lock Menu ...................................................................................................... 78
AudioVideo Menu ....................................................................................................... 80
A/V Settings Descriptions ......................................................................................... 81
Chapter 6 Speciam Features
Operation of Propand POP ......................................................................................... 84
Display Formats ........................................................................................................ 85
Device Control with NetCommand® ........................................................................ 87
Appendix A: Bypassing the V-Chip Lock ................................................................. 89
Appendix B: mnput Connection Compatibility ......................................................... 91
Appendix C: Remote Control Programming Codes ............................................... 94
Appendix D: On-Screen Information Displays ........................................................ g7
Appendix E: NetCommand® Specialized Device Keys ......................................... 98
Appendix F: Cleaning and Service ........................................................................... 99
Troubleshooting ....................................................................................................... 102
Additional mnformation .............................................................................................. 107
mndex ........................................................................................................................... 108
Warranty ..................................................................................................................... 110
IM PORTANT SAFEG UAR DS
PUease read the following safeguards for your HDTV receiver/controller and retain for future reference.
AUways follow aH warnings and instructions marked on the tebvision.
1.
2.
3.
.
.
Read, Retain and Follow All instructions
Read aHsafety and operating instructions before operating the HDTV receiver/controller. Retain the safety and
operating instructions for future reference. Follow aH operating and use instructions.
Heed Warnings
Adhere to aH warnings on the appiiance and in the operating instructions.
Cleaning
Unpiug the HDTV receiver/controller from the wall outlet before charting. Do not use iiquid, abrasive or aerosoi
cleaners. Use a lightly dampened cloth for cleaning.
Attachments and Equipment
Never add any attachments and/or equipment without approval of the manufacturer as such additions may result
in the risk of fire, electric shock or other personal injury.
Water and Moisture
Do not use the HDTV receiver/controlbr where contact with or immersion in water is possibb. Do not use near
bath tubs, wash bowls, kitchen sinks, laundry tubs, swimming pools, etc.
6
6. Accessories
.
.
g.
10.
11.
Do not place the HDTV receivericontrolbr on an unstable cart, stand, tripod, or tabb. The
HDTV receivericontrolbr may fall, causing serious injury to a child or adult and serious
damage to the HDTV receiver/controlbr. Use only with a cart, stand, tripod, bracket or table
recommended by the manufacturer, or sold with the HDTV receivericontrolbr. Any mounting
of the HDTV receivericontrolbr should follow the manufacturer's instructions, and should use
mounting accessories recommended by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops, excessive force,
and uneven surfaces may cause the appliance and cart combination to overturn.
Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the HDTV
receiver/controller and to protect it from overheating. Do not block these openings or allow them to be
obstructed by placing the HDTV receiver/controller on a bed, sofa, rug, or other similar surface. Nor should it
be placed over a radiator or heat register. If the HDTV Receiver/controller is to be placed in a rack or bookcase,
ensure that there is adequate ventilation and that the manufacturer's instructions have been adhered to.
Power Source
This HDTV Receiver/controller should be operated only from the type of power source indicated on the mark-
ing label. If you are not sure of the type of power supplied to your home, consult your appliance dealer or local
power company.
Grounding or Polarization
This HDTV Receiver/controlbr is equipped with a polarized alternating current line plug having one blade wider
than the other. This plug will fit into the power outlet only one way. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete
outbt. Do not defeat the safety purpose of the polarized plug.
Power-Cord Protection
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point
where they exit from the HDTV Receiver/controller.
Lightning
For added protection for this HDTV Receiver/controlbr during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the HDTV Receiver/controller due to lightning and power-line surges.
IMPORTANT SAFEGUARDS, continued
12.
13.
14.
15.
16.
17.
18.
19.
20.
Power Lines
An outside antenna system shouid not be ]oeated in the vbirfity of overhead power Hinesor other ebctrb Hightor
power circuits, or where it can fan into such power Hinesor circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be
fatal.
Overloading
Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
Object and Liquid Entry
Never push objects of any kind into this HDTV Receiver/Controlbr through openings as they may touch dangerous
voltage points or short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or into
the HDTV ReceiveriControlbr.
Outdoor Antenna Grounding
if an outside antenna or cable system is connected to the HDTV
Receiver/Controller, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up
static charges.
Article 810 of the National Electric Code, ANS[/NFPA No. 70-2002,
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead in wire to an antenna
discharge unit, size of grounding conductors, location of antenna
discharge unit, connection to grounding electrodes, and requirements
for the grounding electrode.
Servicing
EXAMPLE OF ANTENNA GROUNDING
LEAD iN WiRE
GROUND CLAMP
ANTENNA
DISCHARGE UNIT
(NEC ARTICLE slo 20)
GROUNDING
CONDUCTORS
(NEC ARTICLE 810 21)
_POWER SERVICE GROUNDING
ELECTRODE SYSTEM
NEC NATIONAL ELECTRICAL CODE (NEC AR] 250, PART N)
Do not attempt to service this HDTV Receiver/Controller yourself as opening or removing covers may expose you
to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Damage Requiring Service
Unplug the HDTV Receiver/Controller from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
(a) When the power-supply cord or plug is damaged.
(b) if liquid has been spilled, or objects have fallen into the HDTV Receiver/Controller.
(c) if the HDTV Receiver/Controller has been exposed to rain or water.
(d) if the HDTV Receiver/Controller does not operate normally by following the operating instructions, adjust only
those controls that are covered by the operating instructions as an improper adjustment of other controls may
result in damage and will often require extensive work by a qualified technician to restore the HDTV Receiver,,"
Controller to its normal operation.
(e) If the HDTV Receiver/Controller has been dropped or the cabinet has been damaged.
(f) When the HDTV Receiver/Controller exhibits a distinct change in performance - this indicates a need for
service.
Replacement Parts
When replacement parts are required, be sure the service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock or other hazards.
Safety Check
Upon completion of any service or repair to the HDTV Receiver/Controlbr, ask the service technician to perform
safety checks to determine that the HDTV Receiver/Controlbr is in safe operating condition.
Heat
The product should be situated away from heat sources such as radiators, heat registers, stoves or other products
(including amplifiers) that produce heat.
7
Thanks...
We are honored that you chose Mitsubishi as your path to upgrading your high
definition monitor dLsplay to a furl HDTV. The HD-6000 Lsdesigned to become
the cornerstone of your home entertainment system, offering the flexibility of
using both digital sources and analog sources in an advanced, but simple to use
single control system. It provides advanced user interface connections such as
CableCARD TM, IEEE 1394 and HDML You have the ability to record to an internal
120GB TV DLsc Internal Digital Video Recorder (DVR). The HD-6000 Lsready to
provide for your enjoyment for the next several years.
Whether thLs is part of a Mitsubishi LT-4260 HDTV package, an upgrade to your
MitsubLshi HD-upgradeable TV or dLsplay monitor or the HD-6000 Lsused to
upgrade dLsp/ays from other manufacturers, we hope this will bring you many
hours of enjoymenL
Mitsubishi DigitaJ EJectronics America, inc.
8
HDo6000 Receiver/Controm_er Overview
Accessories ................................................................................ 10
SpeciaU Features ........................................................................ 11
Front Control Panel .................................................................... 12
Back Panel .................................................................................. 13
HD=6000 Accessories
PUease take a moment to review the following
Uistof items to ensure that you have received
everything incUuding:
5, One Quadruple IR Emitter Cable (allows NetCommand to
control other devices)
1. Remote Control
2. Two AA Batteries
6. One HDMf to HDMI cable
3, One Digital Audio Cable (sends the audio of digitaf
channels to a digital audio video receiver).
7. One MonitorLink TMControt/RS-232C Cable
8, Product Registration Card (not pictured)
9. Owner's Guide (not pictured)
!0. Quick Reference Card (not pictured)
4. One wired IR sensor
10
SpeciaJ Features
Your new HD-6000 High Definition teJevision receiver/controJJer has many speciaJ features
that turn your high definition dispJay monitor into a fuJJy integrated HDTV. This makes it
the perfect controJ center for your high definition dispJay monitor and home entertainment
system. These speciaJ features include:
MuJtipJe Connection CapabiJity
On the compact HD-6000 back panei you will find a full compbment of the connections
needed for the most sophisticated home theater system, hcluded are standard Audio/Video/
S-Video, wideband component video, FireWire®, EEE 1394, CabbCARD and both an HDMI
Input and an HDMI Output.
TV Disc JnternaJ DigitaJ Video Recorder (DVR)
TV Disc is an internal 120GB high definition hard disk drive recorder (also called a digital video
recorder or DVR). This exciting feature may record as much as 12 hours of high definition TV
programming and includes live TV pause with instant replay. Please note that some of the disk
drive space is used by TV Pause, so not all 120GB is available for recording.
It is able to record digital and analog programs received from CabbCARD TMchannels, Antenna
1, Antenna 2, devices connected to Input 1, 2 or IEEE 1394 devices. Now you can record
a high definition program and watch it later without any picture quality loss and without a
VCR. Recordings on the TV Disc can be sent by IEEE 1394 to D-VHS VCRs or to other JEEE
1394 compatible TVs. When recording analog programs, TV Disc will even use Dolby Digital
Record to convert the analog stereo to high quality digital stereo compatible with Dolby Digital
decoding surround receivers.
DigitaJ CabJe Ready (CabJeOARD TM)
Your widescreen Mitsubishi HDTV receiver/controlbr is "Plug-and-Play" ready. It can
descrambb a cable provider's one-way digital signals with the use of a CabbCARD security
module+ The CabbCARD is used in place of a traditional cable box to access digital cable
programming (including high definition). Contact your local cable provider for availability
information and service details.
NetOommand ® Home Network ControJ System
Your Mitsubishi HDTV receiver/controlbr offers a new level of networking to combine selected
older products with new and future digital products. NetCommand supports JEEE 1394
connections, Audio Video Control system (AViC), 5C copy protection and JRcontrol of selected
older products such as VCRs, DVD players, cable boxes or satellite receivers. NetCommand
includes the ability to learn remote control signals directly from the remote control of many
devices, allowing you to customize the NetCommand system in a way that works best for your
viewing+
LT-4260 CompatibiJity
The HD-6000 is designed to work with all of the features of the Mitsubishi LT-4260 LCD HDTV
display. The HD-6000 has the correction connection to work with the authorized card reader
that is in the LT-4260.
11
Front ControJ PaneJ
MITSUBJSHJ
HD-6000 HDTV Receive_lControimer
Except for SYSTEM RESET, the buttons on the Front Control Panel duplicated on the remote control. The top row of
labels show the control functions when there are no TV menus displayed on the screen. The bottom row of labels
show the control functions when the TV menus are displayed on the screen or when a special function has been
activated. See Remote Control Overview, for further details on the functions of these buttons.
System Reset
If the HDTV receiver/controller wiii not respond to either the remote control or the front panel controls and/or wiii
not power Off, press the SYSTEM RESET button with a pointed item like the end point of a paperclip. The HDTV
receiver/controller wiii turn Off and the front panel Power Indicator Light wiii flash quickly for about one minute.
When the light stops flashing, you may again turn on the HDTV receiver/controller. The changes you made the last
time the HDTV receiver/controller was on before you used the SYSTEM RESET button may be lost, however, the
changes that were previously saved are not IosL
Power indicator Light
The diamond shaped indicator in the center of the HD-6000 is multi-functional. Each time the HDTV receiver,,"
controller is plugged into a wall electrical outlet, or when power is restored after a power failure, or after using the
SYSTEM RESET button, a blue light wiii flash rapidly for about one minute. Do not attempt to turn on the HDTV
Receiver during this period, wait for the flashing to stop. While the HDTV Receiver is powered on, the blue light
illuminates steadily.
A/V Reset
There may be times when you wish to reset the AiV (Audio and Video) settings back to the factory defaults. To return
all of the settings at once, press GUIDE and FORMAT on the front panel at the same time. To reset the defaults for
individual devices, use the AiV Memory Reset selection on the AudioVideo menu.
12
Back Panel
1. 2. 3. 4. 5. 6. 7. 8.
1. IR Emitter°NetCommand ®
Two jacks are provided for connecting IR emitters. JR
Emitters connected to these jacks are used by the
NetCommand system of the HDTV receiver/controller
to control external analog devices such as VCRs, DVDs,
cable boxes, sateiJite receivers and audio receivers.
2. Input-l, -2
Input 1 and 2 can be used for the connection of a VCR,
Super VHS (S-VHS) VCR, DVD player, standard satellite
receiver or other A/V device to the HDTV receiver/controller.
When connecting the video, you must choose to connect to
either S=VIDEO or VIDEO. They cannot both be connected
at the same time.
3. MonitorLink/TM HDMP M Output
The HDMI (High Definition Multimedia Interface) supports
uncompressed standard and high definition digital video
formats and existing digitaJ multi-channel audio formats.
The HDMI output supports both video and audio using a
single cabJe. HDMI is the preferred connection type. If
you need to send analog audio to an A/V receiver, see
aJso item 7, "Output to Display."
Use this output to connect to an HDMI monitor such as
the LT=4260 fiat panel LCD TV.
4. HDMI Input
Use this input to connect to EIA/CEA-861 compliant
devices such as a high definition cable box, sateilite
receiver or DVD piayer. This input supports 480i, 480p,
720p and 1080i video formats. It is not intended for use
with personal computers or devices outputting video
signals with computer resoJutions.
This input can also be used as a DVl connection with
separate analog audio inputs (see item 6). An optional
HDMI=to-DVI adaptor or cabJe wilI be necessary to make
this connection and may be available from your IocaJ
eJectronics retailer. When using the optional HDMI-to-
DVl adapter, the DVI analog audio inputs on your HDTV
receiver/controiler allow you to receive left and right
audio from your DVI device.
This input is HDCP (High-Bandwidth DigitaI Copy
Protection) compliant.
5. IR Input
This HDTV receiver/controiler has a remote control IR
sensor on the front panel. In some situations it wilI not
be convenient to point the remote controJ at the HDTV
receiver/controilen In this situation, you may place the
included wired IR sensor in a more accessible Jocation.
6. VGA(PC) Input and Audio/DVl Audio
This input can be used for the connection of a 640 x 480
VGA(PC) computer. PJease see Appendix B for signal
compatibility. Stereo audio inputs are atso provided.
Unlike HDMI, DVl does not carry audio information on
the same cable. Use these analog stereo audio inputs
when using the HDMI input with a device that outputs
DVl instead of HDMI. When used with the LT-4260 LCD
HDTV display, this PC input is deactivated and the PC
input on the display is avaiJabJe instead.
7, Output to DispJay (YPrPb with
Use the HD-6000 OUTPUT to Display under the following
circumstances:
No HDMJ input available for your display monitor°
These jacks provide a substitute output if an HDMI
input is unavailable on your monitor. Use them to
send component video to the display monitor and left
13
Back PaneJ, continued
and right audio outputs to speakers that are either
buiHt into the monitor or connected to it.
HDMi input used in conjunction with an A/V
receiver. If you are using an HDMI input to your
dispHay monitor and want to send anaHog audio to an
AiV receiver, connect the OUTPUT to DispHay Heft and
right audio outputs to the AiV receiver. Note that in
addition to these anaHog audio connections, you must
aHso connect the HD-6000 DigitaH Audio Output to the
AiV receiver digitaH audio input.
8. Componentol, o2 inputs
YPbPr (480i/480p/720p/1080i)
These inputs can be used for the connection of devices
with component video outputs, such as a high definition
cable box, satellite receiver, DVD player or compatible
video game system. Please see Appendix B for signal
compatibility.
9. Antenna (ANT-I MAIN, ANT-2 AUX)
ANT-1 MAIN and ANT-2 AUX can each receive both
digital and analog over-the-air channels from a VHF/UHF
antenna or non-scrambled digital/analog cable channels.
Your primary viewing signat source should be connected
to ANT-1 MAIN. ANT-1 MAIN must be used to view
premium subscription cable TV service authorized
by the CabIeCARD TM access card. The CabIeCARD
access card is provided by your local cable company.
ANT-2 AUX can continue to receive over-the-air or non-
scrambled cable signals.
10, Jnput-DTV YPbPr/RGB HV
(480ii480p/720pi1080i)
This input is used to connect an external DTV receiver,
and can be configured for YPbPr or RGB plus H&V signal
types. Please see Appendix B for signal compatibility.
11. MonitorLinkTM/RSo2320 ControJ
When used with a Mitsubishi HD upgradeabIe TV or fiat
panel display this digital control interface wilI work in
conjunction with HDMJ. While HDMI provides the digital
video signal, the RS-232C control provides enhanced
functioning such as automatic power ON/OFF and input
selection for the compatible Mitsubishi TV or display
panel.
12. CabJeCARD TM SJot
The CableCARD access card provided by your cable TV
service provider is inserted into this slot. The top of the
card should face upwards.
CableCARD is a nationwide standard system that allows
your local cable TV provider to supply you with an
14
access card customized to your account. This card
allows the TV to receive, decode and unscramble the
premium digital channels included in your cable TV
subscription without the use of a cable box. See page
18 for additiona! CabJeCARD information and activation
instructions.
If your cable company is not currently offering
CabIeCARD access cards, you will need to use a
cable box provided and authorized by your local cable
company to view scrambled channels.
13. JEEE 1394
These jacks allow the HDTV receiver/controller to
connect to external JEEE 1394 digital products by
means of a single cable. Three jacks are provided for
this purpose, which allow for a high degree of flexibility
for connecting your NetCommand controlled system.
Detailed information regarding EEE 1394 connection
requirements are in Chapter 4.
14. DigitaJ Audio Output
This output will automatically send Dolby® Digital audio
from digital channels and iEEE 1394 devices to a digital
Audio/Video receiver. Connect this output to the A/V
receiver's coaxial digital audio input. The output will
automatically turn off when viewing an analog channel or
device, except when using the TV Disc, which converts
analog audio to digital. Use Output to Display to send
analog sound to your A/V receiver.
Some digital cable channels send MPEG-1 digital audio
instead of DoJby Digital, however, not all A/V receivers
can decode MPEG-1 digital audio. This can cause the
A/V receivers to produce a loud noise that can damage
speakers. For this reason, the HDTV receivericontrolIer
will automatically turn off the digital audio output when
tuned to a channel or device that has MPEG-1 digital
audio and send it to the A/V receiver as analog left and
right audio from Monitor Output.
15. Monitor Output
The Monitor Output sends the HDTV receiver/controller's
audio and video signals from the antennas or inputs to a
VCR. This output is for recording only. Do not connect
to an A/V receiver.
16, LT-4260 Authorized Card Reader
This port connects to the Mitsubishi LT-4260 flat
panel LCD TV, to enable using an authorized media
card reader built into the display panel. This reader
supports MultiMediaCard TM, SD Media Card,
SmartMedia TM. CompactFlash® and/or MEMORY
STICK TM. Cards up to 128mb, may have a file format of
FAT 16 (block size = 1024 or 2048).
Connecting
E×ternaU Devices & NetCommand® Setup .................................. 16
WaN Outlet CabUe ........................................................................... 17
Cable Box ........................................................................................ 17
CableCARD TMTechnoUogy ............................................................. 18
Single Lead Antenna ...................................................................... lg
Separate UHF and VHF Antennas ............................................... 19
Antenna or WaUl OutUet CabUe to a VCR (Audio & Video} ............ 20
CabUe Box to a VCR (Audio & Video} ............................................ 2i
A/V Receiver or Stereo System .................................................... 22
Satellite Receiver or Other Device with S-Video ........................ 22
MonitorLink TMControl ................................................................... 23
Computer with aPC Monitor Output ........................................... 23
DTV Receiver
with Component Video ............................................................... 24
with RGB, HV Video ................................................................... 25
DVD PUayer with Component Video .............................................. 26
DispJay Monitor with Component Video ...................................... 26
DispJay Monitor with an NDMJ input ............................................ 27
HDMJ Source Device ...................................................................... 27
DVJ Device ....................................................................................... 28
To the Mitsubishi LTo4260 LCD TV ............................................... 29
JR Emitter NetCommand® ............................................................ 30
JR Sensor input .............................................................................. 31
CompatibJe JEEE 1394 Devices ..................................................... 32
HeJpfuJ Hints ................................................................................... 34
important Notes ............................................................................. 35
Connecting E×temai Devices & NetCommand ® Setup
NetCommand is able to control many current audio and video devices by sending remote control signals from
the HDTV receiver/controller to each device through IR emitters, Additionally, it is also able to barn the remote
control signals used by most audio video devices not already in the HDTV receiver's memory, NetCommand can
automatically switch the HDTV receiver and compatible or learned Audio/Video (A/V) Receivers to the correct input
used with each device, It is important that the inputs on the HDTV receiver and AiV receiver back panels match the
NetOommand setup that is displayed on-screen,
To simplify the installation of NetCommand, there is a step-by-step on-screen NetCommand Setup procedure in this
chapter, which details the type and brands of devices you are connecting to the HDTV receiver, The NetCommand
Setup also assigns preset HDTV receiver and AiV receiver inputs for each device, You should connect each device
to the TV input (both audio and video) and to the AiV receiver (audio) as shown in the figure below,
Display monitor & connected speakers
Audio & Video output of device
AV RECEIVER
IR Emitters
_MonitorLink Control Cable is used only with Miteubishi display monitors
The following charts show which preset inputs you should use on the HDTV receiver and AiV receiver,
Chart 1 shows HDTV receiver inputs,
Chart 2 shows the AiV receiver inputs used by AiV receiver models already known by NetCommand,
Chart i
Device Audio and Video Outputs to HDTV R/C mnputs
Cable for CableOARD TM Service ANT-I
Antenna/Oabme (digital/anamog} ANT-I if primary viewing source,
ANT-2 if secondary viewing source
Cabmebox ANT-2
VCR lnput-f
Satellite Receiver (DBS) Input-2
DVD Player Component-i
Chart 2 Bose I DenenI I.tegra IKenweedIMarantzlPieneeriI pieneer21 ReteuI sew IYamahai_
After setting up NetCommand, you may go to the NetCommand menu at any time to change the inputs you used for
connecting each device, custom name devices, add devices not included in the presets above or delete devices no
longer used. See Helpfu! Hints, at the end of this chapter for additional information on device setup.
16
Connecting aWall Out et Cable or Cable Box
Wall OutJet CabJe
(can be used with aCabmeCARDTM)
Figure 1
It is very important to connect the incoming cable for your primary viewing source to ANT=l, especially for
CaBIeCARD TM use.
1. Connect the primary incoming coaxiaH HeadcabHeto ANT-1 MAiN on the HDTV receiver/controller back panel
2. For an optionaH secondary antenna source, connect an antenna (or cabHe)to ANT-2 AUX.
3. If you have subscribed to a CaMeCARD TMservice, the CaMeCARD can now be inserted into the CaMeCARD
SLOT. The top of the card shouHd face upwards. Additional CableCARD information is on page 18.
3.
CableCARD"
SLOT L 1" CablePri_r_arYWallOlltlet
Figure 1, Wall Outlet Cable
Cable Box
Figure 2
3 coaxial cables and one two-way RFsplitter are required. Theseare not included with the HDTVreceiver/controfle,c
it is very important to connect the incoming cable for your primary viewing source to ANT=l, especially for
CableOARD TM use.
1. Connect the incoming cable to IN on an RF splitter.
2. Connect one coaxial cable from OUT on the RF splitter to ANT-1 MAIN on the HDTV receiver/controller back
panel.
3. Connect one coaxial cable from OUT on the RF splitter to IN on the cable box.
4. Connect one coaxial cable from OUT on the cable box to ANT-2 AUX on the HDTV receiver/controller back panel.
Figure 2. Connecting a Cable Box
IMPORTANT
Additional connection cables
are not provided with the NDTV
receiver/controller. They are
available at most electronic stores.
Note: Net Command® will assume that your Cable Box is connected as shown here. Also, that Channel 3 is
the default output channel for the cable box. If either the connections or output channel are different, use the
Change option of Edit NetCommand to apply the changes.
17
Cab eCARD TM Technology
CabJeCARD TechnoJogy
CabbCARD is a nationwide system standard that
allows your local cabb TV provider to supply you with
an access card customized to your account. This
card allows your HDTV receivericontroibr to receive,
decode and unscrambb the premium digital channels
included in your cabb TV subscription, without the use
of a cabb box. It also allows your cabb provider to
automatically update and change your subscription.
When you move to a new cabb provider's area, you
simply return the CabbCARD to the original cable
provider and get a new card from your new cable
provider.
Please note that CabbCARD is a new technology and
your local cable provider may not currently be offering
this service. As time passes, this system will become
broadly supported by most cable providers.
The CabbCARD system is "unidirectional" which
means your cable provider can send updates to the
access card and HDTV receivericontrolbr, however,
the HDTV receiver/controlbr cannot send back signals
such as requests for Video-On-Demand or Pay-per-
View by remote control.
Digital cable channels authorized by the CabbCARD
will be available on the Firewire® IEEE 1394 network
and can be shared by other products on the network.
Some digital channels or programs may not be copied
or recorded because of copy restriction limits set by
the content owners or copyright holders.
The HDTV receiver/controlbr is capable of receiving
analog basic, digital basic and digital premium
cable television programming by direct connection
to a cable system providing such programming.
A security card (CabbCARD) provided by your
cable operator is required to view encrypted digital
programming. Certain advanced and interactive
digital cable services such as video-on-demand, a
cable operator's enhanced program guide and data-
enhanced television services may require the use of a
set-top box. For more information call your local cable
operator.
Please see page 17 for instructions on how to insert
the CableCARD.
Using a CabJeCARD
After inserting a CableCARD into the HDTV receiver/
controller back panel CableCARD slot and powering
On the HDTV receiver/controller, the initialization
process begins. An initial screen will automatically
display for a few minutes, with information that your
Cable Provider will need in order to start service.
Please write down this information before calling your
cable provider.
Please call XYZ Cable
at xxx-xxx-xxxx to
acttva-[e cable service.
They will need these numbers:
Host ID X-XXX-XXX-XXX-XXX
CableCARD TMID: X-XXX-XXX-XXX-XXX
See on nets manual for
further" information
An example of an initial screen is shown here. Your
screen wiii display specific information from your
cable provider and may not look like this screen.
If you were unable to record the information, you can
press TV MENU on the remote and then enter the
number 999 and the screen will re-display. You can
also press DEVICE MENU when the CableCARD is
the selected source and you will be able to select the
startup application.
iMPORTANT
e a CableOARD, the primary incoming
18
Connecting a Lead Antenna or Separate UHF and VHF
Antenna
Lead Antenna motfor use with CabJeCARD TM}
Figure 3
For antennas with twin flat lead
A 300-Ohm to 75-Ohm transformer is required, This is not included with the HDTVreceiver/controlle_ but is available at most
electronics stores,
1. For antenna with twin fiat leads, connect the 300-Ohm twin leads to the 300-Ohm to 75-Ohm transformer.
2. Push the 75-Ohm side of the transformer onto ANT-1 MAiN on the HDTV receiver/controller back panel.
For cable or antenna with coaxial lead
3. Connect the coaxial lead directly to ANT-1 MAiN on the HDTV receiver/controller back panel.
\
Mitsubishi strongly recommends against
using antennas with twin flat leads, Twin
flat lead antenna wires are subject to
interference which may adversely affect
the performance of the TV, We recommend
using coaxial antenna cable.
Figure 3. Connecting a Single Antenna
Separate UHF and VHF Antenna
Figure 4
A UHF/VHF combiner is required, This is not included with the HDTV receiver/controlle,c
1. Connect the UHF and VHF antenna leads to the UHF/VHF combiner.
2. Push the combiner onto ANT-1 MAIN on the HDTV receiver/controller back panel.
VHF _/t ennc_
[Chc_nneP 2 13)
Figure 4. Connecting separate UHF and VHF Antennas
19
Connecting an Antenna or Wai Out et Cable to a VCF{ (Audio &
Video)
Antenna or Wal OutJet CabJe to a VCR (Audio & Video)
Figure 5
A two-way RF splitter, 3 coaxial cables, right and left audio cables and a S-Video or Video cables are required, These are not
included with the HDTV receiver/controller,
1. Connect the incoming cabb or Antenna to IN on the RF spltter.
2. Connect one coaxial cabb from OUT on the RF spltter to ANTENNA IN on the VCR back panel.
3. Connect one coaxial cabb from OUT on the RF spltter to ANT-1 MAIN on the HDTV receiver/controler back panel.
4. To use the TV speakers with the VCR, connect a set of audio cabbs from AUDIO OUT on the VCR back panel to
INPUT-1 AUDIO-LEFT (MONO) and AUDIO-RIGHT on the HDTV receivericontroler back panel. The red cable
connects to the R (right) channel and the white cable connects to the L (left) channel. If your VCR is mono (non-
stereo), connect only the white (left) cabb.
5. Connect either an S-Video or Video cable from VIDEO OUT on the VCR back panel to INPUT-1 VIDEO on the HDTV
receiver/controlerback panel Only one type of video cable should be connected. S-Video is recommended, if
avalable.
6. For NetCommand® controlled recordings, connect a set of audio cables from AUDIO IN on the VCR back panel
to MONITOR OUTPUT AUDIO-LEFT (MONO) and AUDIO-RIGHT on the HDTV receivericontroler back panel. The
red cable connects to the R (right) channel and the white cable connects to the L (left) channel.
7. Complete the NetCommand controlled recordings connections by connecting a Video cable from VIDEO IN on the
VCR back panel to MONITOR OUTPUT VIDEO on the HDTV receiver/controler back panel.
Figure 5. Connecting a VCR to an Antenna or Waft Outlet Cab/e
Note: NetCommand® will assume your VCR is connected to inputs as shown on this page. If you use any
other inputs for your VCR or add a second VCR, this change must match in the NetCommand system. See Edit
NetCommand... in Chapter 3 for more information.
2O
Connecting a Cable Box to a VCR (Audio & Video)
Cable Box to a VCR (Audio & Video)
Figure 6
A two-way RF splitter, 4 coaxial cables, right and Ieft audio cables and an S-Video or Video cable are required. Theseare not
included with the HDTV rece/ver/controller.
1. Connect the incoming cable to IN on the RF splitter.
2. Connect one coaxial cable from OUT on the RF splitter to IN on the cable box back panel.
3. Connect one coaxial cable from OUT on the RF splitter to ANT-1 MAIN on the HDTV receiver/controller, back
panel
4. Connect one coaxial cable from OUT on the cable box to ANTENNA IN on the VCR back panel
5. Connect one coaxial cable from ANTENNA OUT on the VCR back panel to ANT-2 AUX on the HDTV receiver/
controller back panel (optional).
6. To use the TV speakers with the VCR, connect a set of audio cables from AUDIO OUT on the VCR back panel to
INPUT-1 AUDIO-LEFT (MONO) and AUDIO-RIGHT on the HDTV receiver/controller back panel. The red cable
connects to the R (right) channel and the white cable connects to the L (left) channel. If your VCR is mono (non-
stereo), connect only the white (left) cable.
7. Connect either an S-Video or Video cable from VIDEO OUT on the VCR back panel to INPUT 1 VIDEO on the HDTV
receiver/controller back panel. Only one type of video cable should be connected. S-Video is recommended, if
available.
8. For NetCommand@ controlled recordings, connect a set of audio cables from AUDIO IN on the VCR back panel to
MONITOR OUTPUT AUDIO-LEFT (MONO) and AUDIO-RIGHT on the HDTV receiver/controller back panel. The
red cable connects to the R (right) channel and the white cable connects to the L (left) channel.
9. Complete the NetCommand controlled recordings connections by connecting a Video cable from VIDEO IN on the
VCR back panel to MONITOR OUTPUT VIDEO on the HDTV receiver/controller back panel.
L I
or REON/OFF_itch _t itto OFF
L ....
{ ........
Figure 6. Connecting a VCR to a CaMe Box
Note: NetCommand® wiii assume your VCR is connected to inputs as shown on this page. If you use any
other inputs for your VCR or add a second VCR, this change must match in the NetCommand system. See Edit
NetCommand... in Chapter 3 for more information.
21
Connecting an A/V Receiver or Stereo System or
aSatellite Receiver or Other Device with S-Video
A/V Receiver or Stereo System
Figure 7
A digital audio cable and stereo audio cables are required. The digital audio cable is provided. The stereo audio cables are not
included with the HDTV receiver/controller. "Y" splitter cables may also be required.
1_ Connect a set of stereo audio cables from OUTPUT to Display on the HDTV receiver/controller back panel to the
TV AUDIO INPUT on the back of the AiV receiver. The red cable connects to the R (right) channel and the white
cable connects to the L (left) channel.
Note: If you use OUTPUT to Display to provide audio signals to the speakers associated with your monitor, then
the audio output must be shared with the AiV receiver. Use RCA "Y" splitter cables to send analog audio to
both the AiV receiver and the monitor speakers.
To connect a digital A/V receiver with Dolby® Digital surround sound:
2_ Connect one end of the digital audio cable supplied with the HDTV receiver/controller to DIGITAL AUDIO on the
back of the HDTV receivericontroller. Connect the other end to the COAXIAL DIGITAL INPUT on the back of the
AiV receiver.
Check AiV receiver's Owner's Guide for information concerning the use of the digital input and switching
Figure ZConnecting an A/V receiver
Satellite Receiver or Other Device with S-Video
Figure 8
An S-Video cable and audio cables are required. These are not included with the TV.
1_ Connect an S-Video cable from VIDEO OUT on the satellite receiver back panel to INPUT-2 VIDEO on the HDTV
receiver/controller back panel
2_Connect a set of audio cables from AUDIO OUT on the satellite receiver back panel to INPUT-2 AUDIO, on
the HDTV receiver/controller back panel. The red cable connects to the R (right) channel and the white cable
connects to the L (left) channel.
Note: Refer to the Satellite Receiver Owner's Guide for Dish Antenna connections.
Figure 8. Connecting a Sate!rite Receiver with S-Video
Note: NetCommand® will asssume you connected your Satellite Receiver to Input-2. If you add a
second Satellite Receiver or use any other inputs for your Satellite Receiver, this change must match in the
NetCommand system. See Editing NetCommand Setup in Chapter 3 for more information.
Connecting MonitorLink TM Contro or
aComputer with a PC Monitor Output
MonitorLink ControJ (For Use onJy with Mitsubishi DispJay Monitor with
MonitorLink ControJ Connection}
Figure 9
A MonitorLink control cable is required and is provided,
This connection allows the HD-6000 to automatically turn on or off the compaflMe MitsubisM dispHay monitor, When
used wth the Mitsubishi 4260 LCD TV, the connections allow the HD-6000 to use the remote control sensor in front
of the TV, Connect the MonitorLink control cable from the MonitorLink control on the HD-6000 back panel to the
M-Link control on the TV back panel (MonitorLink is also called MonLink or M-Link, depending on the Mitsubishi
display monitor),
You will also want to connect the MonitorLink HDMI Output to the Mitsubishi monitor, as shown on page 27 or 28_
Section detail of
Mitsubishi
]_/back pallel
Figure 9. Connecting M-Link Control
Computer with a PC Monitor Output (Not for use when connected to the LT-4260 LCD TV)
Figure 10
A !5 pin PC monitor cable and an audio video cable is required, These are not included with the TV.
1_ Connect PC Monitor Out from the computer to PC Input on the HDTV receiver/controller back panel using a PC
compatible monitor cable, See Appendix B for PC signal compatibility,
2_Connect the L (left) and R (right) audio cables from the computer to PC AUDIO on the HDTV receiver/controller
back panel, If the computer's audio output is a single mini-jack, a splitter is needed to complete this connection,
Note: The HD-6000 PC input is only compatible with VGA resolution (640 x480, 60hz), If your display monitor
is capable of a higher resolution then you should connect the PC directly to the monitor,
Note: To utilize the benefits of a digital A/V receiver, connect your computer's digital audio out, if available, to a
digital input on your digital AiV receiver,
Figure 10. Connecting aComputer with a PC Monitor
23
DTV Connectors and Adaptors Connecting a DTV Receiver with
Component Video
DTV Connectors and Adaptors
Figure 1!
The HDTV receiver/controlbr back panel has 5 RCA-type connectors for the Input-DTV. The back panel of your
external DTV receiver may use RCA-type connectors or BNC-type connectors. If your DTV receiver comes with BNC
type connections, you will need to purchase BNC to RCA adaptors to connect the HDTV receivericontrolbr to the
DTV receiver. These adaptors should be available at most electronic supply stores.
BNCto
RCA BNC Fitted to
Adaptor Connector Connection
Figure 11.
or
RCA
Connector
DTV Connectors and Adaptors
IMPORTANT
See Appendix B for component video
signal compatibility information.
gital audio connections, see your
: DTV Receiver and A/V receiver Owner's
DTV Receiver with Component Video
Figure 12
A coaxial splitter, RCA component video cables and audio cables are required. These are not included with the HDTVreceiver/
controller.
1. Connect the outside antenna, cable or satellite to ANT or SATELLITE IN on the DTV receiver (see your DTV
receiver's owner's guide for instructions and cable compatibility).
2. Connect the incoming terrestrial antenna or cable (not satellite) to ANT-1 on the HDTV receiver/controller back
panel (a coaxial splitter, available at most electronic supply stores, may be required to complete this installation).
3. Connect RCA-type cables from the YPrPb outputs on the DTV receiver to Input-DTV on the HDTV receiver/
controller back panel, matching the correct connections:
DTV Receiver to HD-6000 back panel
YtoY
Pr to Pr
Pb to Pb
4. Connect the L (left) and R (right) audio cables from the DTV receiver to Input-DTV AUDIO on the HDTV receiver/
controller back panel.
Note: To utilize the benefits of a digital AiV receiver, connect your DTV receiver's digital audio out to a digital
input on your digital AiV receiver.
• 3. _o ,_ White
to antenna,
cable or satellit e
Figure !2, Connecting an External DTV Receiver with Component Video Connections
Connecting a DTV Receiver with RGB, HV Video
DTV Receiver with RGB, HV Video
Figure 13
A coaxial splitte_ RGB, HV and audio cables are required. Theseare not included with the HDTV receiver/controller.
1. Connect the outside antenna, came or sateHke to ANT or SATELLITE IN on the DTV receiver (see your DTV receiver
owner's guide for instructions and cabHecompafibiHRy).
2. Connect the incoming terrestdaH antenna or cabHe (not sateHRe)to ANT-1 on the HDTV receiver/controller back
paneH(a coaxiaH spHRter,avaiHabHeat most eHectronic suppHy stores, may be required to compHete this installation).
3. Connect RGB cables from the DTV receiver to Input-DTV on the HDTV receiver/controller back panel.
DTV Receiver to the BDTV receiver/controJJer Back Pane)
G (green) to Y/G
R (red) to Pr/R
B (blue)to Pb/B
4. Connect the H & V sync signals as shown below:
H (horizontal sync) to H
V (vertical sync) to V
All 5 cabies (G,R,B,H and V) must be connected. 3 cables or Sync on green connections are incomplete or not compatible and wiJJ
not work
5. Connect the L (left) and R (right) audio cables from the DTV Receiver to Input-DTV AUDIO on the HDTV receiver/
controller back panel.
DTV Receiver
(with RGB connections)
to antenns
2_ .1,
Figure !3. Connecting an External DTV Receiver with RGB Video Connections
it may be necessary to obtain a VGA to RGB, HV adaptor cable. These are available at most computer
stores and many electronic stores. Some of the adaptor cables have RCA type connector ends, others
have BNC type ends and will require adaptors as shown on p_ge 24.
Connecting a DVD Player with Component Video or a
Display Monitor with Component Video
DV[::) PJayer with Component Video
Figure 14
Component video cabtes and audio cables are required. Theseare not included with the HDTV receiveffcontrotler.
1_Connect the Component Video cabHes from _1Pr/Pb VIDEO OUT on the back of the DVD pHayerto COMPONENT-
1 on the HDTV receiver/controller back paneH,matching the correct connection:
Y to Y (Green), Pr to Pr (Red), Pb to Pb (Btue)
2_ Connect a set of audio caMes from AUDIO OUT on the back of the DVD pHayerto COMPONENT-1 AUDIO Input
on the HDTV receiver/controller back panel The red cabHeconnects to the R (right) channeH, and the white cabHe
connects to the L (left) channel
IMPORTANT
ppendix B for component
signal compatibility
For digital audio connections, see
your DVD Owner's Guides.
Figure 14. Connecting a DVD Player with Component Video
Note: NetCommand® will assume you connected your DVD pHayerto Component-1. If you add a second
DVD or use any other inputs for your DVD, this change must match in the NetCommand system. See Edit
NetCommand... in Chapter 3 for more information_
DispJay Monitor with Component Video
Figure 15
Component video cables and audio cables are required. These are not included with the HDTV receiver/controller.
1_ Connect the Component Video cables from Y/Pr/Pb VIDEO INPUT on the back of the Display Monitor to OUTPUT
to Display (Y/PbiPR) on the HDTV receiver/controller back panel, matching the correct connection:
Y to Y (Green), Pb to Pb (Blue), Pr to Pr (Red)
2_OPTIONAL: To use the speakers built in or connected to the display monitor, connect a set of audio cables from
OUTPUT to Display on the back of the HDTV receiver/controller to AUDIO INPUT on the back of the display
monitor. The red cable connects to the R (right) channel, and the white cable connects to the L (left) channel. If
you are also using the OUTPUT to Display to connect to your AV Receiver as shown on page 22, then use RCA
"Y" splitter cables_
Figure 15. Connecting a Monitor with Component Video
26
Connecting HDMI Devices
DispJay Monitor with an HDMI or DVi Input
Figure !6
An HDMI to HDMI or HDMf to DV/ cable is required. An HDMI to HDMI cable isprovided,
1. To connect to an HDMI monitor, connect an HDMI cabHefrom the HDMI output on the HDTV receiver/controller
back paneHto the HDMI input on the monitor. HDMI devices provide video and audio through this cabHe.
2a. To connect to a DVI monitor, connect the DVI-to-HDMI came (recommended) (or DVI/HDMI adaptor with an
HDMI came) from the DVI monitor's back paneHto the HDTV receiver/controller's back panel
b. Connect a set of audio caMes from AUDIO OUT on the the DVI device back paneHto the DVI AnaHog Audio input
on the HDTV receiver/controller back panel. The red cable connects to the R (right) channel, and the white
cable connects to the L (left) channel.
NOTE: If you are using a DVIiHDMI adaptor, it is important to connect the adaptor to the DVI side for best performance.
,' i HD u_ ad_ble
Figure 16. Connecting HD-6OOO's HDMI Device Output
HDMI Source Device (CabJe Box, Satellite Receiver, DVD PJayer, Etc.}
Figure !7
An HDM! to HDMI cable is required and one is provided.
Connect an HDMI cable from the HDMI input on the HDTV receiver/controller back panel to the HDMI output on the
source device output. HDMI devices provide video and audio through this cable.
DVD Prayer w_thHDMI output
Figure IZ Connecting the HD-6OOO's HDMI Device Input
27
Connecting a DV[ Device
DV[ Device
Figure 18
A DV/-to-HDM/cable or DVt/HDMI adaptor and HDMI cable and audio cables are required, Theseare not included with the HDTV
receiver/controlle,c Theymay be available at your local electronics retailer.
1. Connect the DVPto-HDM[ cable (recommended) (or DV[/HDM[ adaptor with an HDM[ cable) from the DV[ device's
back panel to the HDTV receiver/controller's back panel.
NOTE: If you are using a DV[iHDM[ adaptor, it is important to connect the adaptor to the DV[ side for best
performance.
2. Connect a set of audio cables from AUDIO OUT on the the DV[ device back panel to the DV[ Analog Audio input
on the HDTV receiver/controller back panel. The red cable connects to the R (right) channel, and the white cable
connects to the L (left) channel.
NOTE: The HDM[ connection supports copy protection (HDCP). Some devices require connecting to an analog
input first, in order to view on-screen menus and select DV[ as the oupuL Please review your equipment
instructions for DV[ connectivity and compatibility.
Figure 18. Connecting a DW Device
28
Connecting to the Mitsubish LT=4260 LCD TV
Power Connection
Figure 19
TheAC Power cord is provided with the LT-4260,
Connect the AC power cord from the back of the HD-6000 to the back of the LT-4260. Make this connection before
connecting any devices. If you connect new devices after the power is connected, you will need to un@ug and
reconnect the AC power cord.
Figure 19. Power Connection to LT-4260
HDMJ Connection
Figure 20
An HDMI to HDM! cable is required and one is provided,
Connect an HDMJ cane from the HDMI output on the HDTV receiver/controller back paneHto the HDMI/MonitorLink TM
Input on the LT-4260. HDMI devices provide video and audio through this cane.
f
__
@@e ........
Figure 20. HDMI Connection to LT-4260
Authorized Card Reader Connection
Figure 21
A USB A to USBB cable to connect the authorized card readers is provided with the LT-4260,
The USB A connects to the Authorized Card Reader port on the HD-6000. The USB B connects to the Authorized Card
Reader for the HD-6000 port on the LT-4260. You can then use the media card slots on the front of the LT-4260 with
authorized media cards.
USB B
Figure 21. HDM! Connection to LT-4260
29
Connecting the Emitter NetCommand ®
IR Emitter NetCommand®
Figure 22
A quadruple/R Emitter cable is included with the HDTV receiver/controller,
The emitters connected to these jacks are used by the NetCommand system to controi other devices such as VCRs,
DVD phyers, Cabb boxes and Satellite receivers.
1_ Connect the phg end of the suppibd quadrupb BREmitter Cabb to one of the IR Output NetCommand jacks on
the HDTV receiver/controller back panel
2_ Run the cabb for each of the emitter ends under, abng side or over the top of each device to be controlled to the
area of the front where the remote controi sensor is bcated.
3_ Phce the emitter end in front of the remote controi sensor of the device to be controHed. The emitter buib
shouid face the remote controi sensor. This bub emits infrared light in a cone shaped pattern. The bulb needs
to be placed far enough from the remote control sensor to allow the cone pattern to include the sensor.
The remote control sensor is usually behind the plastic window of the front display panel. It is sometimes visible
when you look through the display plastic using a flashlight and is normally a round or square cutout behind the
phstic. If you cannot see the sensor and the device's Owner's Guide does not specify the location, you can find
it by using the device's remote control Hold the remote about 1/2 inch from the front of the device. Starting from
one end of the display window plastic, press the POWER button.
If the device does not respond, move the remote control 1 inch toward the center and try again. Repeat this until
the device responds. Note this location then start over from the other end of the display window plastic, repeating
until the device responds again. The remote control sensor wiii be somewhere between these two positions. This
is usually enough accuracy for the placement of the IR emitters.
4. With some devices, the emitter wiii work better facing downward from the top of the device. Some
experimentation may be needed.
5. The emitter end being used can be secured in place using double stick tape.
6. If you are not going to be using all emitter ends, place the unused ends behind the devices so that they cannot
send signals to the remote control sensors.
Other A/V device
===_
-'70therA!V device
3.
3. A/V Receiver
Figure 2£ Connecting/R Emitter NetCommand
3O
too emitters or remote controls not respond at all.
Connecting the IF{ Sensor Input Connection
IR Emitter PJacement
Figure 23
IR Emitter Placement
Recommendations
(see instructions, page 30}
Figure 23, /R Emitter Placement Recommendations
IR Sensor Input Connection
(Figures 24, 25)
This connection allows you to piace the IR sensor
in another part of the room, in situations where it is
inconvenient to point the HD-6000 remote controi at
the HD-6000,
1. Connect the IR sensor into the IR Sensor Input on
the back panel of the HD-6000.
2. Place the IR sensor end in a convenient place. The
sensor can be secured in place using doublestick
place.
Note: When the IR sensor Input is connected the
IR sensor on the front panel wiii not function. This
connection is not required when the HD-6000 is
connected to the Mitsubishi LT-4260 LCD TV,
Figure 25, IR Sensor Placement Recommendation
31
Connecting Compatible IEEE 1394 Devices
CompatibJe IEEE 1394 Devices
It is possible to connect devices to the HDTV receiver that
have EEE 1394 connectors but are not compatible with the
HDTV receiver or with the NetCommand ® control system.
Areas of compatibility to consider are:
1. Digital Video Signals
The HDTV receiver is able to decode MPEG2 video.
Other types of digital video, such as DV video provided
by some camcorders, must be decoded by the source
device and sent to the HDTV receiver as analog video
or S+Video. If the camcorder uses a compatible digital
control system, the IEEE 1394 cable can still provide
control for the camcorder while the TV is viewing the
analog video or S+Video signals.
2. Digital Audio Signals
When received with video signals, the HDTV receiver is
able to decode Dolby Digitat signals and MPEG audio
signals. Other types of digital audio as provided by some
digita! recording devices, such as MP3 audio and DTS
audio, cannot be decoded by the HDTV receiver when
received over EEE 1394.
The HDTV receiver may not be able to pass incompatible
digital audio signals on the coaxial digital audio output,
however these signals may pass on the EEE 1394 cable
to other devices+
3. Digital Control Signal
The HDTV receiver is able to act as the control center for
IEEE 1394 audio/video devices, such as VCRs, A/V Discs,
tuners, cable boxes and amplifiers that are compatible
with the following EEE 1394 control standards.
EIAW75 is designed for tuning devices such as cable
boxes allowing the device to send simple graphics.
However, this standard does not allow the HDTV
receiver to control the cable box by EEE 1394.
+ AV/C {Audio Video Control} is designed to provide
basic controls such as play, stop, channei selection
and volume, as appropriate for the device+
Some devices may be a combination of two or more
types of devices. For example, there may be a
recording device that is also a tuning device. Each
portion of the device is called a sub-uniL When you
select a device on the Device Selection menu that
has sub-units, a pop-up menu will appear so you can
select which sub-unit section you wish to use+
When Connecting IEEE 1394 Devices
Do not place an IEEE 1394 device between the
HDTV receiver/controller and the TV or display
monitor+
Do not make a loop with the last device in the
chain. When the device chain is looped, the
HDTV receiver/controller may not be able to
work with the other devices+
Place devices that have only a mechanical (two-
position) power switch at the end of the chain
or leave the power switch in the On position.
When turned Off, IEEE 1394 signals may not
be able to pass through the device to other
devices+
Place devices with the slowest communication
speed at the end of the chain+ Sometimes
the communication speed will be marked
near the IEEE 1394 connector with an "S"
number+ The higher the number, the faster the
communication speed+ This HDTV receiver
has a communication speed of $400+ Devices
with slow communication speed can interfere
with IEEE 1394 signals from faster devices+
When using NetCommand to set up a digital
recording between a faster and slower device,
the slower device should be the source and the
faster device should be the recorder+
Do not use an IEEE 1394 cable longer than 15
feet between each device+
This HDTV receiver is an IEEE 1394a Device+
IEEE 1394b is currently under development.
This system will provide for longer distances
and multi-room applications+ Included in the
IEEE 1394b systems are IEEE 1394a to IEEE
1394b converters to maintain compatibility
with this HDTV receiver and other IEEE 1394a
devices+
32
Connecting Compatible IEEE 1394 Devices, continued
Connection StyJes
There are two different connection sues that can be
used when connecting IEEE 1394 devices. Use the
sue that fits your network of audio/video products.
Direct Device-TooDevice StyJe
The IEEE 1394 offers you the capabiiity to chain
devices, uniike previous audio and video connections
where you had to individually connect each device
directly to the HDTV receiver/controller. For exampb,
you can connect a D-VHS to a 1394 DVD Hayer
and then to the HD-6000. The resuiflng IEEE 1394
chain will allow you to add more devices to the
chain. You will be able to see each video device
on the HDTV receivers Device Selection Menu and
send information from any IEEE 1394 device to other
compatible devices.
HDMI, MonitorLink TM,Out to Display
or Component Video
TV
Dig Digital
VCR DVD
Hub Connection StyJe
The IEEE 1394 also offers you the capability to
connect your devices using the HD-6000 as a hub
within the audio/video network. Each device can
send information, which may include audio and video,
to any other device in the network.
Digital
Digital
DVD
HDMI, MonitorLink M
Out to Display or
1394
Monitor
Other
1394 Device #1
Digita_
VCR #3
Digita_ DVD #2
Digita_ VCR #2
TV
4oPin Styme vs. 6-Pin Styme Connectors
There are two different types of connectors used for
IEEE 1394 terminals and cables, a 4-pin and a 6-pin
style.
4 pin connector
The 4-pin connector sends
digital audio signals, digital video
signals and digital control signals
back and forth between devices.
Your HDTV receiver has three
4-pin type connection jacks
available on the back panel.
The 6-pin connector is capable
....., of sending the same digital audio,
video and control signals as the
4-pin connector, but the 6-pin
connector is also able to send
low voltage electrical power. This
6 pin connector HDTV receiver does not have 6
pin connectors.
The purpose of this low voltage electrical power is
to provide the needed operating power to a device
that is not connected directly to the household AC
power such as a camcorder. A device with a 6-pin
connector can send this electrical power to another
device, or receive electrical power from another
device, or simply use a 6-pin connector without using
the two additional pins.
6 pin to 4 pin adaptor
A 6-pin connector cannot
be connected directly to a
4-pin jack, and vice versa. To
connect a 6-pin device to a
4-pin device, you wiii need to
obtain a 6-pin to 4-pin adaptor
or adaptor cable. These cables
are available from electronic
and computer stores.
When connecting a 6-pin device (such as a
camcorder) to the HDTV, (if it is designed to receive
electrical power from another 6-pin device) you
will need to connect the camcorder directly to the
household AC, or use the camcorder's battery for
power. If this is not possible, then the camcorder wiii
need to be connected directly to another 6-pin device
in the network that can provide the electrical power.
Other 1394 Device #2
83
Connecting: Helpful Hints
Q My VCR (or other device} does not have two sets of stereo audio outputs. How can I connect this
device's audio to both the HDTV receiver and the A/V Receiver?
A. There are two solutions:
,Connect the single set of stereo audio outputs to the HDTV receiver only. Use Edit NetCommand@ to
change the setup of this device, in the Connection screen of "Change" make sure both audio and video
for the HDTV receiver input are check marked and neither the audio or the video for the AVR input are
check marked. This will allow the NetCommand system to use the HDTV receiver outputs to transfer the
device's audio to the A/V Receiver. See Edit NetCommand in the next chapter for details.
2. Use RCA type "Y" splitter cables to split the device's audio output to be connected to both the TV and
the A/V Receiver.
Q. 1have both the HDTV receiver/OUT To Display stereo audio output and HDTV receiver digital audio
output connected to the same input designation on my A/V Receiver. How do I switch between
analog audio and digital audio?
A. This depends on the individual A/V Receiver. Some A/V Receivers will switch automatically to digital when
a digital audio signal is supplied. Other A/V Receivers can be manually switched by remote control. For
these types of A/V Receivers, see Edit NetCommand in the next chapter for NetCommand control of these
features. Some A/V Receivers will require that you make this change on the front panel of the A!V Receiver.
Q. The front panem of my A/V Receiver is too tammor too convex for the IF{ emitter signam to reach the
remote control sensor of the A/V Receiver. What can I do?
A. There are several possible solutions.
1. Mount the IR Emitter on the top, front edge of the A/V Receiver over the remote control sensor. Use tape
to secure it in place.
2. Mount the IR Emitter on the underside of the shelf above the A/V Receiver (if the A/V Receiver is in a
cabinet). Use double sided tape to secure it in place.
3. Some small stick-on emitters from other manufacturers may be compatible with this HDTV receiver's IR
Emitter jacks. These may be used instead of the supplied IR Emitters.
Q. I occasionally need to see the menu from my A/V Receiver. How can Iconnect it to the HDTV
receiver for this purpose?
A. You can connect the video output of the A/V Receiver to an unused input on the HDTV receiver. Then use
Edit NetCommand to "Add" this as an "Other" device, not an A/V Receiver. On the "Connection" screen,
indicate which HDTV receiver input was used and check mark the video box. Make sure the HDTV receiver
input audio box and both the audio and video boxes for the AVR input are not check marked. You should
also name this device so you can easily identify it on the Device Selection Menu. You can also use input 3
(Camcorder) on the front panel.
Q. 1have a separate high definition receiver I woumd miketo connect and it amso has an S-video output and
would like to be able use it as well. Is there any way to connect this receiver both ways?
A. Yes, this item will appear twice in the Device Selection Menu. Just add this unit once using the Input=bTV
receiver and once using one of the S-video inputs. Make sure you barn the remote control twice, on for
each input. We suggest that you connect stereo audio outputs with the S-video to the HDTV receiver so that
you do not need to use two inputs on the A/V Receiver. if this is a NetOommand compatible HDTV receiver
that HD or SD outputs can be switched by remote control, see Edit NetCommand in the next chapter for
NetCommand control of this feature.
84
FOR PLASMA DUSPLAY MONUTORS AND PUCTURE TUBE REAR PROJECTUON DUSPLAY
When using the VGA input, do not leave stationary, toombar, or partiam images on-screen for
extended periods of time. Mix the types of pictures shown. Uneven pmasma dispmay or picture
tube aging is NOT covered by your warranty.
The normai use of a TV or piasma dispiay monitor
shouid inciude a mixture of TV picture types. The most
frequently used picture types shouid fiH the screen
with constantly moving images rather than stationary
images or patterns. Dispiaying the same stationary
patterns over extended periods of time, or dispiaying
the same stationary pattern frequently can Heavea
subtle but permanent ghost image. To avoid this, mix
your viewing pattern. Do not show the same stationary
image for more than 15% of your total viewing in any
one week. Display constantly moving and changing
images that fill the screen whenever possible.
Most plasma display monitors and rear projection TV's
are not meant to be used as a work station or to view
static or odd-shaped images for an extended period
of time. Any device connected to your system via
the VGA port, including, but not limited to, personal
computer, game system, or digital set-top box, must
have its screen saver function activated to prevent
damage to the television. We DO NOT recommend the
use of any external device that does not have a screen
saver function with a television.
the whole screen. Stationary images or images that
only partially fiii the screen (leaving black or colored
bars to fiii the screen), when used over extended
periods of time or when viewed repeatedly, can cause
uneven aging of the phosphors and leave subtle
ghosts of the stationary images in the picture.
Setting the video setting of contrast to a medium
position can help slow phosphor aging.
Still or stationary images may be received from
broadcasters, cable channels, satellite channels, DVD
discs, video tapes, laser discs, onqine services, web/
internet searching devices, video games, and digital
TV tuner/converter boxes. Examples of these types of
images can be, but are not limited to the following:
Letterbox top/bottom black bars: shown at the
top and bottom of the TV screen when you watch a
widescreen (16:9) movie on a standard (4:3) TV.
Side bar images: solid bars shown on each side of
an image when watching a standard (4:3) program
on a widescreen (16:9) TV.
We recommend that screen saver activation time
be set to less than five minutes when using a
device through the VGA port. You should also use
lower brightness and contrast settings. If your
computer programs allow, toolbars should be set
to hidden mode.
Please remember most computer programs and video
game systems display static images, such as boxes,
buttons, tool bars, and game scores that can damage
the television if used for extended periods of time,
repeatedly, or frequently.
CRT TV's and plasma display monitors use phosphors
or phosphor picture tubes to create the image on
the screen. All phosphor picture tubes or plasma
display monitors age with use, As they age, their
light output is gradually reduced. Normal pictures fill
the screen with constantly changing images. Under
these conditions, picture tubes or plasma display
monitors age at an even rate across the entire screen.
This maintains a TV picture that is evenly bright over
@
o
Stock-market report bars: ticker running at the
bottom of the TV screen.
Shopping channel iogos & pricing displays:
bright graphics that are shown constantly or
repeatedly in the same location.
Video game patterns and scoreboards
Bright station logos: moving or low-contrast
graphics are less likely to cause uneven aging.
On=line (hternet) web sites: or any other
stationary or repetitive computer sue images.
Closed Caption Backgrounds: When set to
black or bright color, if Close Caption wiii be used
frequently, Mitsubishi suggests the use of the gray
or translucent background.
35
36
NetCommand ® Setup and Editing
Using the Remote ControU with NetCommand® ........................ 38
Remote Control Functions: Overview .......................................... 39
Remote ControU Functions:
Battery installation ................................................................... 40
Care ............................................................................................ 40
NetCommand® OnScreen Buttons .............................................. 41
3D GraphicaU Viewpoint® Menu System ..................................... 42
NetCommand® lnitiaU Setup ......................................................... 43
Edit NetCommand®
Add an A/V Receiver ................................................................. 45
Add Devices ............................................................................... 48
Change ....................................................................................... 52
DeUete Devices .......................................................................... 52
Finish Screen ............................................................................. 52
Using the Remote Contro with NetCommand ®
Below is a tist of several manufacturers devices tested and shown to be compatible with NetCommand. These devices
can be controlled without changing the setting of the remote control from the HDTV receiver to another product.
NetCommand may be abte to operate additiona! models since many manufacturers use the same control signals to
operate some or all of the models they offer. This chart lists only the models that have been tested with NetCommand.
The NetCommand Learning feature is able to learn the remote control signals of most Audio Video devices. For devices
not listed in the table, or if your device does not operate using the same remote control as the models listed below, use the
learning feature by selecting "Other" as the Manufacturer at the [Device] screen. See the Edit NetCommand section of this
Guide.
NOTE: There are many different types of remotes and not alI of them may be compatible with the learning feature. Bright
light near the front of the HDTV receiver/controller can also adversely affect the learning feature. If it is not possible to
learn a device, you will need to use the original remote control of the device, or program the HDTV receiver remote to
operate these devices in the traditiona! manner.
NetOommand PreBMemorized Devices
DEVICE
A/V receiver CableBox DBSSatellite DVDPlayer VCR
Receiver
M Mitsubishi MA/R800, SR-HD5 DD_6000, HS_U795,
M-VR900 DD-8020 HS_U778
A Bose Lifestyle@28 Lifestyle@28
N Denon AVR_2700
Echostar 6000
UFunai F260LA
F General OFT2200
Instruments
AHitachi DV-P415U VT-FX665A
C Hughes HIRD-E45,
HIRD-E86
T Integra DTR_9.1 DPS-9.1
U JVC XWS65GD HR_VP650U
Kenwood VR2OS0
RMarantz SR8200
E Microsoft XBoxT"_(requirestheDVDkit from
R Microsoft)
Motorola DOT2244
Panasonic TU_HDS20 DVD-A310 PV_8662
Philips VR620OAT
Pioneer VSX-D557, DV-414
VSX-49TX
RCA DRD480RE,
DTC-100
Rotel RSX-1065
ScientificAtlanta 8600
Sharp VC_H810U
Sony STR_DE825 SAT-A55 DVP_S500D,PlayStation®2 SLW778HF
(Playstation®2 requiresthe DVD
RemoteControllerkitfromSony;
DVDPlayersoftwarediscversion
2,10)
Toshiba DTS_300O SD-9200, W_717
SD_5109
Yamaha RX_V2095, DVD_S520,
RX_V2200 DVD_C996
Zenith DTVI080
38
Remote Contro Functions: Overview
Overview
F/gure !, foi/owing page
lm S_ide Switch: Selects A/V product to be controlled
by the remote control. When in the TV position, will
operate Mitsubishi TVs and plasma display monitors.
Select Cable/DBS/DTV for NetCommand® device
control. Media card functions are available only when
the HD-6000 is connected to the LT-4260 LCD TV.
2m
IMPORTANT: To program the remote control to
operate the HD-6000, slide to the CabIe/DBS/DTV
position then press and hold the POWER while
entering the numbers 1,9,7 in sequence, then release
the POWER key.
Numbers: Individually selects channels or enters
information into menus.
3. POWER: Turns power on and off for HDTV receiver
and other A/V products.
4. SQV (SuperQuickViewTM}: Scans through
memorized lists of favorite channels.
5. QV (QuickViewTM}: Switches between the current
channel and last channel viewed.
6m
7m
SUB/CANCEL: Clears SQV and some menu entries
and cancels recordings. For digital channels, adds
separator between major and sub channel numbers.
DEVICE: Displays the Device Selection menu to
select the device to view (Ant-1 and Ant-2, TV Disc
or devices connected to the HDTV receiver's inputs
including IEEE 1394 devices).
8, CHANNEL: Scan up or down through memorized
channels. Performs chapter skip function for
NetCommand® controlled DVD's.
9. VOLUME: Changes sound level.
10. MUTE: Turns sound on or off.
11. TV MENU: Displays _ViSWP0J_Ion-screen menu system.
12. ADJUST: Press ,_, I_, A and • to navigate menus,
change settings, and move the PIP on-screen
location. Operates many NetCommand® functions.
Performs skip forward and backwards function of TV
Pause.
13. ENTER: Selects a channel number or menu item.
14, GUIDE: Displays ChannelView TMfor Ant-1 and 2.
Displays Track List for TV Disc and IEEE 1394 A/V
Discs. Displays program guide for satellite receiver,
some cable boxes or DVD Disc menu. Displays
thumbnails or playlists for media card files.
15. Light: Located on the right side of the remote control,
this feature illuminates buttons or labels.
16. DEVICE MENU: Displays menus for devices
connected to the HDTV receiver, including
CableCARD TM.
17, HOME: Exits the HDTV receiver's on-screen menus
and returns to TV viewing.
18, V-CHIP: Turns On or Off the V-Chip Lock
19. INFO: Displays on-screen summary of the current
device used and any broadcast information available
(including current V-Chip information). See Appendix
D for details.
20. AUDIO: Selects and adjusts individua! audio settings.
21. VIDEO: Selects and adjusts individual video settings.
22. PiP CH: Scrolls up or down through memorized
channels for PIP.
23. PIP/POP: Cycles through PIP and POP choices.
24. EXCH: Exchanges PIP or POP and main TV picture.
25. SLEEP: Sets the HD-6000 to turn off within 2 hours.
See next page for setup instructions.
26, PiP DEVICE: Displays PIP Selection menu to select
the PIP or POP image source device
27. FORMAT: Changes the shape and size of the main TV
picture.
28. CONNECT: Initiates IEEE 1394 peer-to-peer
connections.
29. RED (Record}: Records with a VCR, sets up
recordings for DVCR or while in ChanneiView.
30. PAUSE: Pause a live TV picture when no PIP or POP
image is displayed (when TV Pause is set to Always
or On Request). When PIP or POP image is visible,
pauses that image (default TV Pause set to Off or On
Request). Pauses a VCR, DVD or A/V Disc, media
card file. Returns to TV viewing from TV Pause.
31. REW/REV: Rewinds or reverses search in TV Pause,
while watching the TV Disc or with a VCR. Reverses
scan with a DVD, A/V Disc or media card file.
32. PLAY: Plays the TV Disc or VCR, DVD, A/V Disc or
media card file.
33. STOP: Stops the TV Disc, VCR, DVD, A/V Disc or
media card file.
34. FF/FWD: Fast forward or forward search in TV Pause,
while watching the TV Disc, with a VCR or media card
file, or fast play a DVD.
39
Remote ControJ Functions:Operation and Care, SJeep Timer
CAB__/DBS/D_ VCR _VO
Iw _ _ i _AUDIO
RM-6000
PAUSE (
Figure 1. Remote Control Overview
Battery installation
Figure 2
installing the Batteries:
1. Remove the remote control's back cover by gently
pressing the ribbed tab in the direction of the arrow
and sliding off the cover.
2. Load the batteries, making sure the polarities (+) and
(-) are correcL For best results, insert the negative
(-) side firsL
AA (alkaline)
b_tterie_
Care
For Best Results from the Remote Control:
• Be within 20 feet of the equipment.
• Do not press two or more buttons at the same
time unless instructe&
Do not allow unit to get wet or become heated.
Avoid dropping on hard surfaces.
Do not use harsh chemicais to clean. Use only
a soft, lightJymoistened cloth.
Do not mix new and old batteries.
Do not heat, take apart orthrow batteries into
fire.
Use onlyAA aIkaIine batteries.
Hint: /f the remote is in the Cab/e/DBS/DTV
layer and will not operate the HD-6000, press
and hold POWER and enter 1,9,7 to reset the
remote.
SJeep Timer
Setting the Sleep Timer:
1. Press SLEEP on the remote control.
2. Each press of SLEEP increases the time displayed
by 30 minutes, until the maximum value of 120
minutes is reached.
3. After 5 seconds of inactivity, the message will
disappear.
4, Press SLEEP to view the remaining time before the
timer turns the TV off.
Canceling the Sleep Timer:
1. Press SLEEP to display the on-screen message.
2. Press SLEEP repeatedly until OFF is displayed.
Note: After 5 seconds of inactivity, the message
box disappears.
Figure 2. Operation: Installing the Batteries
4O
NetCommand® On Screen Buttons
To use the HDTV receiver's NetCommand feature, you need to provide some detaibd information during the setup.
You must define the manufacturer of the devices that are connected to the HDTV receiver, or barn the IR code
remote controi signais for the device connected. For each device, the input to the HDTV receiver and AiV receiver,
and the names for the device are pre-set during Bnitiai NetCommand setup. You may change those inputs or names
using the Edit NetCommand or Learn screens. The buttons described bellow will heip you navigate the screens.
On your remote controi, the ADJUST _ and • buttons
allow you to navigate Heftand right to different
sebcfions on the screen. The ADJUST • and V
buttons allow you to:
Change the radio button
Change current text box sebction
Navigate up and down on the screen
The ENTER button allows you to:
Confirm the selected character when naming a
device
Add or delete check marks in check boxes
o Select on-screen buttons to change screens
Text Box
Control Buttons
Much like the software on your computer, you will use
graphic buttons to navigate through the NetCommand
Setup screen. Highlight the button and press ENTER
to select the function.
<Back Button
Use the <Back button to navigate back to the previous
screen.
Next> Button
Use the Next> button to navigate forward to the next
screen.
CanceJ Button
Press ADJUST • or • to make a selection.
Check Box
Check marks indicate the item or input is added or
turned On. Press ENTER when the check box is
highlighted to add or delete a check mark. When
viewing the Review screen, a check box reflects which
devices are turned On or Off, or connected to the
HDTV receiver.
Radio Buttons
The Cancel button wiii cancel out any changes you
are currently making without saving them into memory.
When you select the Cancel key, NetCommand
wiii prompt you to confirm that you want to cancel
the changes you are currently making. If you
select Cancel during Initial Setup, you can setup
NetCommand later by selecting the NetCommand
menu, then choosing Initial.
The setting changes when one of the choices is
41
3D Graphical )ViewPoiil[Menu System
Your HDTV receiver also has MitsubisM's exclusive 3D GrapMca[ Vi6WPOifllon-screen operating system, which
provides on-screen information for menu choices and changes, using the HDTV receiver's remote control
V[SWPS[I][Menu Screens Remote Contro[ Buttons
A picture (icon) wiN[be highlighted on the
menu screen when selected with the ADJUST
arrows. You may then make changes within
the menu or access sub-menus, if available.
You can also access sub-menus from a button.
Sometimes when you select a button, an
automatic function begins.
The VlewPoln[system ir/ciudes the following special
features:
• The currently selected icon or button is
highlighted with a yellow outline; the text color is
yellow.
On-screen instructions, shown in the message
line at the bottom of the menu, provide feature
selection and adjustment information.
Some on-screen menu options must be set
before other options are available.
Main Menu: This screen will always be the first screen that
appears when you press the remote's TV MENU button,
The following buttons on your remote control help you
navigate within the _V[SWP0ilI[system :
1. ADJUST • or_to select the menu item you want
to change.
2. ADJUST • or V to change the settings.
3. ENTER to enter into a menu, start an automatic
function or select a checkbox.
4. CANCEL to clear a setting or stop an automatic
function.
5. TV MENU to display the TV's main menu or move
back one menu screen at a time.
6. HOME to exit aii menus and return to TV viewing.
%B/OAN6_
TVMENU @
Press ADJUST • or V to change text boxes_ Some
text boxes have preset labels. Other boxes allow you
to select letters, numbers or characters to customize
names.
NetCommand ® lnitia Setup
When you first power On your new MitsubisM HDTV
receiver, the initiaHsetup screens appear. Most IR
remote controH signaHformats can be Hearned by
NetCommand.
IMPORTANT: To program the remote control to
operate the HD-6000, slide to the CabIe/DBS/DTV
position then press and hold the POWER while
entering the numbers 1,9,7 in sequence, then release
the POWER key.
WeJcome Screen
Figure 1
When you first turn on your HDTV receiver, the
WeHcome screen dispHays and asks you to seHect
either EngHishor Spanish as the Hanguage for the on-
screen menus. The default Hanguage is EngHish. To
change Language Hater,seHect Setup in the Main Menu.
SeHecting Oancel at this screen will cause the defauHt
Hanguage (EngHish)to be seHected.
Figure 1. We/come screen
NetCommand (Information} Screen
Figure 2
The NetCommand (Information) Screen describes
how to start or delay the initial NetCommand Setup.
This screen displays automatically the first time you
power On your new HDTV receiver, after the Welcome
screen. To setup NetCommand, select Next> and
Figure 2, information screen
If the NetCommand Setup is cancelled before it's
completed, you can restart the NetCommand setup
by:
1. A press of TV MENU on the remote control to
display the TV Main menu.
2. Select NetCommand. The available options will
be: Add, Review and Initial. Change and Delete
will be grayed out.
3. Press ADJUST ,&, _V',_ or _ to select Initial.
4. Press ENTER. The Device Setup screen displays.
Device Setup Screen
Figure 3
If the devices connected to the HDTV receiver/
controller are already in NetCommand memory,
you can quickly select them at this screen. Press
ADJUST _ or _ to move to each device type.
Press ADJUST A or 'V to select the manufacturer.
Select "Other" if the manufacturer is not listed.
Later, you can use the Change setting in the Edit
NetCommand menu to learn the remote control
signals for this device. Select "None" for device
types that are not connected.
For the AiV Receiver, if the manufacturer is not
listed, you cannot select "Other". Instead, select
"None". Later, you can use the "Add" feature in the
NetCommand menu to have the HDTV receiver add
and learn the remote control signals for this device.
After completing your choices, select Next> and
Figure 3, Device Setup screen
43
NetCommand ® Initial Setup, continued
Note: if you selected "Other" for any of the
device names, the HDTV receiver/controller
can "Learn" the connected device by following
the Edit NetCommand instructions. For many
device types, nonqisted models will operate in
the same way as the listed models and you can
still use the pre-loaded setting.
Review Screen
Figure 4
After you have made your device choices the Review
Screen will display, it is important to review the
settings to ensure that they are correct, if necessary,
you can use <Back to return to the Device Setup
screen to make changes.
Finish Screen
Figure 5
To compiete the NetCommand setup, seiect Finish
from the Finish screen.
if you wish to change any of the pre-configured
inputs or names for the devices, or add devices not
in the pre-configured setup, seiect Edit to dispiay
Edit NetCommand menu.
if your A/V receiver was not listed, select Edit to
add the AVR and then assign all devices to new AVR
inputs.
Figure 5, Finish screen
Figure 4. Review screen
Note: The Review screen lists the HDTV received
controller input and A/V receiver input used with
each device. You must correctly identify the
inputs you used when you connected the devices.
If you have not connected your devices, write
down these inputs as a guide. If you cannot use
these inputs, or if you would like to change the
name of a device, use the instructions in Edit
NetCommand to make necessary changes.
Note: if you select Next> on the Review screen,
ai[ selections made are finaiized.
On the Review screen, adding or deleting check marks
wiii turn the adjacent devices, media cards or inputs
On or Off. 1394 device names only appear on the
Review screen when the devices are connected to the
TV.
Note: If TV Disc is not checked, TV Pause wiii
not be avaiiabie.
it is still necessary to memorize the available
channels for Antenna-1 (and Antenna-2, if used).
You may do that by going to the TV Main menu
and selecting Antenna. instructions to memorize
channels are found in the Antenna menu section.
Edit NetCommand®, Add an AiV Receiver
A/V Receiver Screen
Figure 6
If your AiV Receiver manufacturer was not Histed,and
you seHected "None" during the initiaH NetCommand
Setup you may add the AiV Receiver and have
NetCommand Heamits remote controHs functions.
Either seHect Edit from the Finish screen or if you
have finished the initiaHsetup, go to the Main menu,
seHect NetCommand, then press ENTER. The Edit
NetCommmand screen will dispHay, seHect Add.
Figure 6. A/V receiver screen
NetCommand to switch inputs to use this device.
However, NetCommand will not be aMe to controH
this device. Later you may use the "Change" option
in the NetCommand menu to Heamthe remote
controH signaHs.
After seHecfing Next>, the screens that follow are:
the AiV Receiver Input screen (Figure 7), Name
screen (Figure 10), Monitor Out to AVR screen
(Figure 11), ending with the Finish screen (Figure
12).
Choose ONE of these options:
Select a recognized manufacturer. The model
number optimized for NetCommand will display at
the bottom of the screen. If a number follows the
manufacturer's name, (example: Mitsubishi 1), this
indicates additional models are optimized for that
manufacturer. For many device types, non-listed
models will operate in the same way as the listed
models and you can still use the preqoaded setting.
After selecting Next>, the screens that follow are:
the Name Screen (Figure 10), Monitor Out to AVR
screen (Figure 11), ending with the Finish screen
(Figure 12).
Select "Other", then highlight "Learn" and press
ENTER. This will allow you to have NetCommand
learn the remote control signals of this new device.
After selecting "Learn" and pressing ENTER, the
screens that follow are: the AiV receiver Inputs
screen (Figure 7), AiV Receiver Input Learn screen
(Figure 8), AiV Receiver Learn screen (Figure
9), Name screen (Figure 10), Monitor Out to AVR
screen (Figure 11), ending with the Finish screen
(Figure 12).
Select "Other", skip Learn and select Next>. This
will allow the device to appear and will allow
A/V Receiver Inputs
Figure 7
If you select "Other" as the manufacturer, you will see
the AiV Receiver Input screen after selecting "Learn"
and pressing ENTER. After selecting the number of
inputs, this screen will not appear again.
Depending on your AiV Receiver's capability, you
may connect up to to seven (7) AiV inputs. Select the
number of inputs by pressing ADJUST A or V.
If the number of connected inputs changes, you
will need to delete the AiV receiver through Edit
NetCommand and add it again, as described above.
Figure 7, A/V receiver Input screen
45
Edit NetCommand ®, Add an AiV Receiver, continued
A/V Receiver input Learn Screen
Figure 8
NetCommand can now barn the remote controi
signais used to sebct each input on the AiV receiver.
1. Press ADJUST _ or _ on the HDTV receiver/
controller remote to sebct the check box for each
function to be bamed.
2. Press ENTER and the function name will begin to
flash to confirm the ready-toqeam status.
3. Point the AiV receiver's remote controi at the TV
screen. Press the button on the remote controi that
corresponds to the sebcted function. A check
mark will appear and the function name will stop
flasMng. This confirms the signai bamed status.
4. To test the bamed command, whiie the function
is sebcted, press ENTER on the HDTV receiver, /
controller remote. The A/V receiver will perform the
sebcted function. The AiV receiver needs to be
turned on and the IR emitters properly placed for
the test to be successful (see page 30 for IR emitter
placement).
5. To customize the input names, press ADJUST _ to
move to the Input Name text box and then press
ADJUST A or • and ENTER to select each letter of
the name. These names will appear on the Review
screen as the AiV receiver's input names.
6. To erase the learned input signal, highlight the
check box for that input and press CANCEL
7. Repeat for each connected inpuL
8. When the input selection signals have been learned
and the inputs named, press ADJUST _ to select
Next> and move to the A/V receiver Learn screen.
Figure 8, A/V receiver Input Learn screen
A/V Receiver Learn Screen
Figure 9
1. Press ADJUST _ or _ on the HDTV receiver/
controller remote to select the check box for each
function to be learned.
2. Press ENTER and the function name wiii begin to
flash to confirm the ready-to-learn status.
3. Press the button on the AiV receiver's remote
control that corresponds to the selected function,
A check mark will appear and the function name
will stop flashing. This confirms the signal learned
status.
4_ To test the learned command, press ENTER on the
HDTV receiver/controller remote. The AiV receiver
wiii perform the selected function. The AiV receiver
needs to be turned on and the IR emitters properly
placed for the test to be successful (see page 30 for
5. Repeat for each function to be learned.
6. To erase a learned function, highlight the check box
for that function and press CANCEL
7. When the function signals have been learned, press
ADJUST _ to select Next> and move to the Name
screen.
Figure 9. A/V receiver Learn screen
Hint: If your A/V receiver remote control uses a single
button for both Power On and Power Off, don't learn
the Power Off function, if your A/V receiver uses a
single button to toggle between digital and analog
sound, then learn only Analog to Digital. if your A/V
receiver automaticafly switches between analog and
digital audio, then you don't need to learn either
Analog to Digital or Digital to Analog functions.
46
Edit NetCommand ®, Add an AiM Receiver, continued
Name Screen
Figure 10
The Name screen allows you to change the default
name for the AiV receiver to a custom name of up to
eight characters (incHuding a bHankspace), seHecting
from Hetters, numbers, and nine different characters.
Using the HDTV receiver/controller's remote, press
ADJUST • or • to seHecteach Hetter,then press
ENTER to move to the next position. Press CANCEL to
delete the current Hetter and move back one character
position. When in the first position, the CANCEL
button will return the name to the default name.
Figure !0. Name screen
Finish Screen
Figure 12
To finaHize your seHections and compHete the A/V
receiver setup, seHect Finish from the Finish screen.
Note: Hfyou connected the audio output of
any device dkectHy to the A/V Receiver, you
must use the "Change" function of the Edit
NetCommand menu and select the device to
assign the correct A/V Receiver input to be
used with each device.
Audio Output to AVR Screen
Figure 11
If you connected the HD-6000 Output to Display to an
AiV receiver, use this screen to select the name of the
analog input you're using on the AiV receiver.
If the AIV receiver also has a digital audio input, then
connect the HD-6000 Digital Audio Output to the AiV
receiver digital audio input.
Note that the HD-6000 Monitor Ouput connection is
only for VCR recording and is not synchronized with
the video display.
Figure 1!, Audio Output to AVR screen
Figure 12, Finish screen
47
Edit NetCommand ®, Add Devices
MitsubishVs NetCommand allows you to edit your home theater configuration. You can add new devices, change
device settings and connections, debte devices and barn remote controi IR signais not akeady in NetCommand
memory.
Edit NetCommand Screen
Figure !3
If you sebcted Edit when you were at the Finish screen,
the Edit NetCommand screen dispiays. The choices
are:
time by pressing TV MENU, then sebcting
NetCommand. See page 69 for detaiis.
Use these settings to change the NetCommand setup
to reflect a change in your home theater system. To
barn the remote controi IR signais of a device that
is not akeady in the NetCommand memory, add this
device as manufacturer of "Other". The barning
screens will then automatically be included in the
series of screens used for adding the device.
Figure 13. NetCommand Menu, Edit NetCommand Option
Add Screen
Figure 14
Select "Add" from the Edit NetCommand screen, and
the New Device screen will display. Select the Device
type that you would like to add. You may add your
AiV receiver (if not added in Initial setup) Cable Box,
Camcorder, DBS, DVD, Laser Disc, PC and VCR.
Add:
Add a new device to the NetCommand setup. See
Figure 14for more information.
Change the brand/model or input connections of a
device already listed in the configuration. Learn the
remote control signals of devices listed as "Other"
brands. See Figure 23 for more information.
Review:
View a list of all devices and input connections in the
NetCommand home theater configuration. This is also
where you can turn On or Off unused HDTV receiver, /
controller inputs or devices. See Figure, 4 for more
information.
Delete:
Remove a device or erase the complete NetCommand
home theater configuration. The learned remote
control signals are erased when the associated device
is deleted. See Figure 25 for more information.
At the next screen, choose the manufacturer. If you
choose "Other" for the manufacturer, the device (AiV
receiver, Cable, DBS, DVD or VCR) can be learned.
For device types Laser Disc, Camcorder, Game
and PC, the "Learn" screen is skipped. There is no
NetCommand support or learning for these devices.
At the next screen, you can keep the default Name or
select a custom Name for the device, using ADJUST
A or V to select letters A-Z, numbers 0-9, and/or
symbols (!.&'/:*- and blank) for each character of the
name you would like for the selected channel.
The next screen displays the Connection screen (RF
Connection for Cable, Figure 21). Select the HDTV
receiver/controller and A/V receiver inputs that the
device is connected to. Only audio can be connected
to the AiV receiver. The AiV receiver may need
configuring for digital audio.
initial:
Start the setup at the beginning. This button
only becomes available after deleting the entire
configuration, or if NetCommand was not set up when
the HDTV receiver/controller was first powered On.
If you select Initial, the first screen that wiii display
is the Device Setup Screen. See Figure 3 for more
information.
Note: If you have completed the NetCommand
setup, you can access the Edit menu at any
48
Figure 14. Add screen
Edit NetCommand ® Add Devices, continued
[Device] Screen
Figure 15
If you sebcted "None", during initiai setup, then you
can add a device. If you have added a new device, use
this screen to start baming.
Our exampbs show the choices for adding a VCR,
however, the same type of screens will appear for any
DBS (Direct Broadcast Satellite), DVD piayer or Cabb
Bo-4.
Figure 15. [Device] screen
Choose ONE of these options:
this devbe. Later you may use the "Change" option
in the Setup menu to barn the remote controi
signais.
After sebcfing Next>, the screens that follow are:
the Name Screen (Figure 18), Connection screen
(Figure 19) and speciaiized device screens (Figures
20-23), ending with the Finish screen (Figure 26).
[Device] Learn Screen
Figure 16
Shown only if "Learn" was selected
Sebct a recognized manufacturer. The model
number optimized for NetCommand will display at
the bottom of the screen. If a number follows the
manufacturer's name, (example: Mitsubishi 1), this
indicates additional models are optimized for that
manufacturer. For many device types, non-listed
models will operate in the same way as the listed
models and you can still use the preqoaded setting.
After selecting Next>, the screens that follow are:
the Name Screen (Figure 18), Connection screen
(Figure 19) and specialized device screens (Figures
20-23), ending with the Finish screen (Figure 26).
Select "Other", then highlight "Learn" and press
ENTER. This will allow you to have NetCommand
learn the remote control signals of this new device.
After selecting "Learn" and pressing ENTER, the
screens that follow are: [Device] Learn screen
(Figure 16), [Device] Advanced Learn screen (Figure
17), Name screen (Figure 18), Connection screen,
(Figure 19) and specialized device screens (Figures
20-23), ending with the Finish screen (Figure 26)_
Select "Other", skip Learn and select Next>. This
will allow the device to appear and will allow
NetCommand to switch inputs to use this device.
However, NetCommand will not be able to control
Figure 16. [Device] Learn screen
.
2.
.
.
Press ADJUST A, V, _ or _ to select the check
box for each function to be learned.
Press ENTER and the function name wiii begin to
flash to confirm the ready-to-learn status.
Press the button on the device's remote control
that corresponds to the selected function. A check
mark will appear and the function name will stop
flashing. This confirms the signal learned status.
To test the learned command, press the ENTER
button on the HDTV receiver/controller remote while
the learned function is still highlighted. The device
should perform the selected function. The device
needs to be turned on and the IR emitters properly
placed for the test to be successful (see page 30
for IR emitter placement). If the functions are not
learned the first time, try Learn again.
5. Repeat for each function to be learned.
49
Edit NetCommand®, Add Devices, continued
6. To erase a barned function, highiight the check box
for that function and press CANCEL.
7. When the function signais have been barned,
press ADJUST _ to sebct Next> and move to the
[Device] Advanced Learn screen. NOTE: When
barning the device's remote controi signais, point
the device's remote controi at the HD-6000.
Hint; if the device's remote control uses a single button
for both Power On and Power Off, don't learn the
Power Off function,
Name Screen
Figure 18
The Name screen allows you to change the defauit
name for each device to a custom name of up to eight
characters (inciuding a biank space), sebcfing from
btters, numbers and nine different characters. Press
ADJUST • or • to sebct each ]etter, then press
ENTER to move to the next position. Press CANCEL
on the remote to debte the current btter and move
back one character position. When in the first position,
the CANCEL button will return the name to the defauit
name.
[Device] Advanced Learn Screen
Figure !7
After learning the basic device keys, the [Device]
Advanced Learn screen allows you to learn any special
keys for your device. Most common IR remote control
signal formats can be learned by NetCommand.
A table of specialized device keys is shown in
Appendix E. You only need to barn the functions your
devices respond to and can ignore the functions that
do not apply to your device.
Figure 17 [Device] Advanced Learn screen
Figure 18. Name screen
Connection for [Device] Screen
Figure 19
This screen allows the HDTV receivericontrolbr to
learn the connection between device(s) and input(s).
Inputs 1 & 2, Components 1 & 2, Input-DTV, VGA
and/or the inputs for the AiV Receiver all need to be
checked, if connected. Add or remove check marks
to indicate what type of connections (Audio, Video or
both) are used with each HDTV receivericontrolbr and
AiV Receiver input.
Figure 19, Connection for [Device] screen
5O
Edit NetCommand ®, Add Devices, continued
The screens described bemow may not be necessary for your device setup. If they do not dispmay
automatically on-screen, they are not required.
VCR for Recordings Screen
Figure 20
If more than one anaHog VCR is connected to the HDTV
receiver/controller, you need to seHectthe one to be
used for recording. You may aHsoseHect whether you
want the recorded 16:9 signaHsfrom digitaH channeHs
or EEE-1394 devices to be cropped (sides are cut off)
or AnamorpMc (full screen). If Anamorphic is seHected
for viewing, choose the Standard format for the best
quaHity pHayback.
lnputoDTV Connection Screen
Figure 22
This screen dispHays only if the device seHected k_the
Connection screen (Figure 19) is connected to hput-
DTV_ This is usually DBS, but can be Cable Box_ The
Input-DTV Connection screen allows you to select the
connection type, RGB (HV) or Component YPbPr you
are using to connect your cable box or DBS.
Figure 20. VCRfor Recordings screen
RF Connection for CabJe Screen
Figure 21
The RF Connection screen displays only when
adding or changing a Cable Box. if your Cable Box
is connected to a HDTV receiver/controller antenna
input, check the RF checkbox. Select the antenna
input that is used with the Cable Box. Select the
channel number used for output by your cable box.
The default channel is 003. if the Cable Box is also
connected to a VCR for recording, select that VCR.
If your Cable box is connected using Audio/Video
cables, make sure the RF checkbox is unchecked.
Then the next screen will be Connection (Figure 19),
to allow the selection of the HDTV receiver/controller
input used with the Cable Box.
Figure 2!. RF Connection for Cab/e screen
Figure 22./nput-DTV Connection screen
IR Code for [Device] Screen
Figure 23
This screen only displays if an added device has the
same IR code as a previously added device of the same
type and manufacturer. You can specify the IR setting for
the new device. For example, for the second Mitsubishi
VCR you can specify the IR Code setting to VCR-B, if the
primary Mitsubishi VCR is using the VCR-A IR code.
Figure 23./R Code for [Device] screen
51
Edit NetCommand ®, Change or Delete Devices, Finish Screen
Change Device Screen
Figure 24
SeHecflng Change from the Setup menu screen,
dispHays the Change screen. To change a device,
seHect the device by name, not type. You can change
the name or input connections to the HDTV receiver/
controller and AiV receiver. If "Other" is seHected for
the manufacturer then you can aHso"Learn". The rest
of the screens that follow are the same as when you
Add a device.
Figure 24, Change screen
Finish Screen
Figure 26
To finaHize your seHecfions and compHete the
NetCommand setup, seHect Finish from the Finish
screen.
Note: To change any of the inputs or names
for the devices, or add devices not included in
the initial settings, select Edit to display the Edit
NetCommand menu.
DeJete Device Screen
Figure 25
Selecting DeHetefrom the Setup menu, dispHays the
Delete screen. You can choose to delete a single
device by selecting the device you would like to
delete, or you can delete the entire NetCommand
configuration. After you have chosen the device, or
the entire configuration, you will be prompted to
confirm your choice to delete. If you select the Entire
Configuration, the Initial button becomes available on
the Edit NetCommand screen. If you delete a device
that you learned the remote control signals for the
learned signals are erased.
Figure 25. Delete screen
Figure 26, Finish screen
IMPORTANT
NetOommand does not allow you to delete
a device or change the connections for a
device (like a VCR or a DVD player} if the
device (input} is currently being displayed by
the TV.
Switch the ND-6000 to a different device
from the one you are changing or deleting.
To change the A/V receiver, you need to be
listening to the TV speakers.
52
JEEE 1394 Devices and
NetCommand® ControJJed Recordings
JEEE 1394 Devices and NetCommand® Control ........................ 54
Adding JEEE 1394 Devices Automatically .................................... 55
Device Selection Menu .................................................................. 57
Using the DEVICE MENU Button to E)ispUayMenus ................... 58
Using the Guide Button to Display ChannelView TM and Menus..5@
NetCommand® Controlled
Recordings ............................................................................. 60
Record List ............................................................................. 61
Peer-to- Peer Connectio ns .................................................... G2
Using TV Disc & A/V Disc ............................................................. 58
Direct VCR Recording from an Antenna or CabUe Source ......... 63
PC Viewing ...................................................................................... 64
MediaCommand TM and Media Card PJayback with the
Mitsubishi LT-4260 ......................................................................... 65
IEEE 1394 Devices and NetCommand® Contro
See pages 31-32 for information regarding compatible IEEE 1394 devices and connection styles. The HDTV receiver/
controller is not able to control IEEE 1394 devices that use other types of control protocols. Incompatible digital audio,
video and/or control information wilI stiII be able to pass from one device through the HDTV receiver/controlIe to another
device on the network. These incompatible devices may not appear on the Device Selection menu or in the Review
screen of the Edit NetCommand menu.
NetOommand ControJ of DigitaJ Devices Using the "Learn" Feature.
Some IEEE 1394 devices such as cable boxes or satellite receivers will not have compatible digitat control signals
or require the use of the device's own remote control. Some of these IEEE 1394 devices will not display on-screen
information through the IEEE 1394 connection and will require using an analog connection for on-screen displays. In
many cases, to control these digita! devices, the Learning feature of NetCommand can be used.
1. Place an IR Emitter for NetCommand in front of the device's remote control sensor (see IR Emitters, page 30,31).
2. On the Name for 1394 Device screen (Figure 2, page 55) use ADJUST and ENTER to check mark the Analog
Connection box.
3. Select the device type on the IEEE 1394 Device Type screen (Figure 3, page 56) of DBS or similar tuning device.
4. If desired, using the ADJUST buttons enter a custom Name on the Name screen (Figure 18, page 50).
5. At the Device Screen, Select "Other" as a manufacturer and then highlight "Learn" and press ENTER (Figure 4, page
56).
6. Follow the device learning instructions found on the screen(s) or in the Edk NetCommand section of Chapter 3.
7. The Connection screen (Figure 5, page 56) follows the learning screens. If analog connections are used, select the
correct inputs.
8. Proceed wkh the Finish screen.
This will allow NetCommand to use the learned remote control signal to control these IEEE 1394 devices.
Note: When using the NetCommand learning feature for IEEE 1394 devices that do not have analog connections,
the GUIDE function will require pressing GUIDE twice. The first press of GUIDE will display the HDTV receiver/"
controller's digital channel guide. The second press will display the program guide for the device if an IEEE 1394
Guide is available.
54
Adding IEEE 1394 Devices Automatically
Adding IEEE 1394 Devices
When an JEEE 1394 device is connected into the HDTV
receiver/controller network and is powered On, the new
device will automatically announce its presence. This
process is called device discovery and can take up to
1 minute. Some non-audio/video or non-compaflbHe
IEEE 1394 devices, such as PersonaH Computers
(PCs), may not announce their presence to the HDTV
receiver/controller. The HDTV receiver/controller
will not be aMe to show these devices in the Device
SeHecflon menu, however, they can coexist and will still
be available to other devices on the IEEE 1394 network
that are compatible with these non-audio/video
devices.
IEEE 1394 cable boxes and satellite receivers may
require that you use the remote control that came with
those devices. For some compatible devices, the other
slide switch positions of the HDTV receiver/controller
remote control may be able to control operation.
Name for 1394 Device Screen
Figure 2
If you choose to add the discovered IEEE 1394 device,
the Name for 1394 Device screen will appear. Name
the device or use the default name that appears
Some IEEE 1394 digital devices, such as some DVCRs,
can also operate as analog devices. For example,
some DVCRs can record and play as VHS or S-VHS,
in addition to D-VHS. This allows you to play analog
rental tapes or analog tapes from your established
library or make analog recordings from antenna or
cable systems. To use the analog capability, check the
Analog Connection box.
New 1394 Device Screen
Figure 1
When your HDTV receiver/controller discovers a new IEEE
1394 device, the New 1394 Device screen will appear.
Selecting "Add" will include the device in the Device
Selection menu. Selecting "Do Not Add" will not add the
device to the Device Selection menu. If the IEEE 1394
device does not provide audio and video, you may not
want to add that device to the HDTV receiver/controller's
Device Selection menu. Devices that were discovered but
not added to the Device Selection menu will still be listed
in the Review screen of the Edit NetCommand® menu.
Figure !. New 1394 Device screen
Figure 2, Name for !394 Device screen
55
Adding IEEE 1394 Devices Automatically, continued
IEEE 1394 Device Type Screen
Figures 3 and 4
If the new IEEE 1394 device is aHsoconnected using
anaHog inputs, you will need to define the device type.
SeHect the type of device, such as a VCR.
Figure 3. fEEE I394 Device Type screen
Once the device type is seHected, then the Device
screen is dispHayed so the manufacturer can be
seHected. If the manufacturer is Histed,then you may
be aMe to controH this device whiHeit is operating as
an anaHog VCR. For exampHe, if the IEEE 1394 device
you have added is a Mitsubishi DVCR, and you have
seHected an anaHog connection as a second connection,
then you will select Mitsubishi for the manufacturer. If
the manufacturer is not listed, select "Other" and use
the Learn screens.
Be sure to place an IR Emitter in front of the remote
control sensor, just as you have done for other
NetCommand® devices. It is necessary to use the
IR Emitter only when the DVCR is being used as an
S-VHS or VHS VCR. When the DVCR is playing or
recording digital signals in D-VHS, the HDTV receiver/
controller will control the VCR through the IEEE 1394
cable.
Figure 4, Device screen
Connection Screen
Figure 5
Select the HDTV receiver/controller input that you used
when you connected the video or S-Video cables. You
may also select the HDTV receiver/controller or AiV
receiver input you used when you connected the stereo
audio cables. The HDTV receiver/controfler will learn the
input names for the HDTV receiver/controller Input and
AiV Receiver Input selections. If your AiV receiver has
other inputs than those listed in the menu, those other
inputs are not available for NetCommand.
The playback and record control of some DV camcorders
may still operate by the IEEE 1394 cable automatically,
even though you must use the video or S-video cable
for the picture. In this case, when you select the
Camcorder, be sure to select analog (not digital) from the
pop up when a camcorder is selected from the Device
Selection menu. Then the picture is shown via the analog
connection but control is from IEEE 1394.
Figure 5, Connection screen
Finish Screen
Figure 6
To finalize your selections and complete the
NetCommand setup, select Finish from the Finish
screen.
56
Figure 6. Finish screen
Device Selection Menu
When you press DEVICE on the HDTV receiver/controller's remote control, the Device Selection menu (Figure 7)
displays. If NetCommand@ has not been set up, the Device Selection menu allows you to select an input for viewing.
If NetCommand is set up, the Device Selection menu allows you to select the device for viewing, select audio from
the TV speakers or AiV receiver, power compatible devices On or Off, and verify the destination of signals. On the
Device Selection menu, the device or input currently displayed appears as a gold-colored icon.
Device
Section
Video Connection Audio
Section Section Section Audio Section
When a NetCommand pre-memorized or learned IR
controlled AiV receiver has been connected to the
HDTV receiver/controller and added to NetCommand
Setup, an AVR icon wiii appear in the audio section.
Press AUDIO to change navigation to the audio
section. Then press ADJUST 4, •, • or • to select
the TV speakers icon or the AiV receiver icon. Press
ENTER to change the audio selection. Press DEVICE
to return the navigation to the Device Section.
Figure 7. Device Selection Menu with NetCommand
Power On/Off Devices
Devices that have separate On and Off remote control
buttons wiii power On automatically when you select
the device and wiii power Off when you turn off the
HDTV receiver/controller. For devices that do not
power On or Off automatically, display the Device
Selection menu, press ADJUST _ or • to highlight
the device icon and press POWER on the remote
control. For the A/V receiver, press AUDIO to move
the navigation to the Audio Section. Highlight the AiV
receiver icon and press POWER. If you press POWER
on the remote control when the Device Selection menu
is not displayed, the HDTV receiver/controller wiii turn
Off.
Device Section
To select another device or input, press ADJUST
4, •, • or • on the HD-6OOO's remote to move the
highlight. Press ENTER to select the device to view
and hear. The HDTV receiver/controller inputs are
automatically changed. If NetCommand is set up, the
inputs on compatible AiV receivers are automatically
changed at the same time.
If you're using a display with built-in or connected
speakers, use the display's remote control to mute
sound from the display's speakers. If you're using
the HD-6000 with the LT-4260 dispaly, muting occurs
automatically when the AiV receiver is selected
through NetCommand.
PIP Device SeJection Menu
Figure 8
The PIP Selection menu displays when you press the
PIP DEVICE button on the remote control. This menu
has the same general format as the Device Selection
menu. The source for the Video Section is the sub
picture and the Audio and Connection Sections are not
available.
Use ADJUST 4, •, • or • to move the highlight to
the device to show in the PIP or POP screen, then
press ENTER. Device icons that are grayed out are
not available for use as PIP/POP sources or with the
current source.
Video
Video Section
The TV icon shows the destination for the device
highlighted in the Device Section. Device
Section
Connection Section
The Connection Section shows the other devices
currently connected to the device highlighted in
the Device Section. For example, if the Digital VCR
(D-VCR) is currently recording, when you move the
highlight to the Ant-1 icon, the D-VCR icon will appear
in the Connection Section. This icon will disappear
when you move the highlight to another icon, Press
CANCEL to stop recording.
Figure 8, PIP Device Selection Menu
has not _rovided that for the device.
57
Using the Device Menu Button to Display Menus
Device Menu
If NetCommand is setup, pressing the remote control's
DEVICE MENU button displays the transport menu
if the input is a VCR or DVD. Another press of the
DEVICE MENU button wiii display menu for the current
device source, if available.
Figure 9, Transport menu
IR Controlled Devices
For a NetCommand compatible traditional IR
controlled device, pressing DEVICE MENU once or
twice will display the menu for that device. While the
menu for the device is displayed, press ADJUST
_, b', • or • and ENTER to navigate the screen. For
some NetCommand traditional devices you will also be
able to use the number buttons and other additional
buttons on the HDTV receiver/controller remote.
For traditional DVD players, DEVICE MENU is also
known as the setup menu.
CableCARD TM Menu
FigurelO
When using a CabieCARD, pressing DEVICE MENU
wiUldisplay a list of up to 8 links to applications that
contain basic CableCARD information made available
from your cable provider. Press ADJUST • or • to
move through the application links. To select a link
(blue text) to an application, press ADJUST • or •
to highlight the link, then press ENTER to access the
linked page. Pressing DEVICE MENU will return to
the CableCARD menu screen and pressing HOME will
If there are technical problems with the CableCARD,
an error screen wiii automatically display with
information that may be needed by your Cable
provider when you call them for assistance.The screen
shown below is an example of the type of screen that
may display. Specific screen menus are sent by your
cable provider.
Moving Through Other CableOARD Screens
In addition to CableCARD menus, other CableCARD
application screens may display and require you
to make additional selections. While CableCARD
application screens are customized in each area, some
general rubs apply in using these screens with your
Mitsubishi HDTV receiver/controller.
Blue text denotes a link to another screen. Press
ENTER to move to the next application. When
screens do not have blue text, there are no more
links.
2. You cannot move backward through the links. If you
want to exit the CableOARD system, press HOME
to exit and return to TV viewing. CANCEL may not
apply to some CableCARD screens.
All information on these application screens is provided
by your iocai cable company. Please contact your
cable provider if you have any problems with the
application screen displays.
IMPORTANT
screens are status or
nostic in nature and do not allow you to
make changes. These screens are meaningful
_ly to your local cable provider.
i_i_! _!! i i_:_iiii! i_x! TM io _3(!i
Figure !0. Possible Device Menu for CableCARD
58
Using the GUIDE Button to Display Channe View TM and Menus
GUIDE and Devices (1394 or mRControlled)
For NetCommand compafibie satellite receivers and
some cable boxes, GUIDE wiii display the on-screen
programming guide for the receiver or cable box. Press
ADJUST 4, _', • or • and ENTER to navigate the
displayed Guide. For NetCommand compatible satellite
receivers, you may also be able to use the number or
other additional buttons.
For NetCommand compatible DVD players, GUIDE wiii
display the DVD disc "top" menu (not the setup menu).
For AiV Discs, pressing GUIDE wiii display the Track List
screen. For IEEE 1394 devices with digital connections,
press GUIDE twice to display the device's Guide.
GUIDE and the Device SeJection Menu
For compatible traditional VCRs, pressing GUIDE when
the VCR is highlighted on the Device Selection menu
wiii change the VCR's inpuL
When the AiV Receiver icon is highlighted in the Audio
Section, pressing GUIDE switches the AiV Receiver
from analog audio to digital audio and vice versa.
GUIDE and the Record To Menu
When in the Record To menu, pressing GUIDE wiii
display the current list of programmed recordings.
Please see Record List, page 61 for more infomation.
GUIDE and ChanneJView
Figures 11 and !2
Press GUIDE while viewing Ant-1 or Ant-2 to display
a list of available memorized digital channels (D) and
analog (A) channel information (if available from the
broadcaster). This list is called ChannelViewTM.
ChannelView for digital channels wiii show the major
and sub-channels (or bitstreams). Analog channel
information wiii display as sent. Press ADJUST • or •
to scan through the all the channels in memory one by
one. To cycle through the choices quickly, press CH
•or•.
For detailed program information, press ADJUST I_,
to return to basic information press ADJUST 4. This
information is sent by the broadcaster. If limited data
is shown or no program data appears, it is because the
broadcaster is not sending the information. This is not
a defect of your HDTV receiver/contro//er.
Recording a Current Program
To record a current program, press REC (record) when
your program choice is highlighted on the program
list in ChannelView. A red "R" will be added after the
input name. The HD receiver/controller will immediately
switch to the selected channel and start recording.
Figure 11.ChannetView screen, current programs
Recording Future Programs
To record a future program, press ADJUST • or •
to select the channel you want to record from. For
detailed program information, press ADJUST I_',to
return to basic information press ADJUST 4. Press
REC (record) when your choice is highlighted. A red
"R" will be added after the input name. The message,
The recording has been added to the Record List will
display. To view, change or cancel a recording, use
the Record List (page 61). if a program title was not
sent by the broadcaster, you will be unable to set up a
recording and a message will display.
Figure !2. ChannelYiew screen, future programs
IMPORTANT
For complete ChannelView information to be
daily, the HDTV receiver/controller
powered Off between 5 to 15 minutes
depending on the number of channels in
memory, ff the HDTV receiver/controller loses
power, the program listings will be temporarily
most.
59
NetCommand ® Controlled Recordings
Setting up Recordings
Figure !3
Through NetCommand, you can automatbaHy start
and stop recordings and send signais from one
piayback device to a recording device. Recordings
can be made on recordabb devices connected to the
HDTV receiver/controller or to the intemai TV Disc.
TheTV Disc is an JEEE 1394 hard disk drive, with 120
GB of memory and is avaiiabb for CabbCARD TM, Ant
1, Ant 2, JEEE 1394 or tuning devices (cabb boxes or
satellite receivers) connected to inputs 1 or 2 when a
PBPor POP is not dispiayed.
The HDTV receiver/controller can convert digital
channels and IEEE 1394 device signals to analog
signals that can be recorded on NetCommand
compatible analog VHS and S-VHS VCRs.
You can schedule the recording to take place at a
later time and program the recording duration for a
minimum of 30 minutes and a maximum of 6 hours
(in 30 minute increments). The default is 1 hour.
During the recording, the HDTV receivericontrolbr
can be powered Off. If the HDTV receivericontrolbr
is powered On, it must be tuned to the source that is
being recorded.
Figure 13 Record to screen
6O
Recording Now
Can be used when viewing Antenna 1 or 2, an IEEE
1394 device including TV Disc, or a non-recording
traditional device.
To initiate recording now:
1. Press REC (record) on the HDTV receiver/controller
remote.
2. Press DEVICE on the remote control to move to the
Source Device section.
3. Press ADJUST _ or _ to select the source device
you wiii record from. If a source is not displayed, it
is not available as a recording source.
4. Press ENTER to confirm selection and return to the
"Record to" section.
5. In the "Record to" section, review the destination
device and duration. Use ADJUST • or V to
change if necessary.
6. Press REC a second time to initiate recording.
Time-DeJayed Recording
To initiate a time-delayed recording:
1. Press REC (record) on the HDTV receiver/controller
remote.
2. Press DEVICE on the remote control to move to the
Source Device section.
3. Press ADJUST •, V, _ or _, to select the source
device you wiii record from.
4. Press ENTER to confirm your source device
selection and move to the Record to section.
5_ Press ADJUST _ or _ to select the Record to
device, duration time, start time (press ENTER
after selecting hour, minutes and AM or PM to set
the time) and day. For devices that can select
channels, select the channel.
6_ Select Add and press ENTER to add the recording
to the record lisL If your selection is successful, a
confirmation message wiii be displayed. If you pick
overlapping times, day(s), or destination devices,
you will see a message stating there is a conflict.
7. To exit, press HOME on the HDTV receiver/
controiier remote after aii recordings have been
added.
Record List, Peer=to=Peer Connections
Record List
Figure 14
Press GUIDE while viewing the Record To screen to see a
list of all currently programmed recordings. A maximum of
32 recordings can be scheduled.
@_
Figure 14. Record List screen
OanceJ Current Recordings
To cancei a recording in progress, press DEVICE
to display the Device Selection menu and highlight
the source of the recording. Confirm that the icon
for VCR (or recording device) is in the Connection
Section next to the TV icon. Press the CANCEL
button. The icon for the VCR (or recording device) wiii
disappear from the Connection Section to confirm the
cancellation.
To cancel a recording on the Record List, press ADJUST
• or V to select the recording, then press CANCEL. To
page through the list, press CH • or V.
Peer-to-Peer Connections
A peer-to-peer connection allows the IEEE 1394 devices
in your HDTV receiver/controller network to talk to
each other without the further need of HDTV receiver/
controller intervention once the peer-to-peer connection
is established. For example, the HDTV receiver/controller
can set up a connection for an A/V Disc or DVCR that
sends a recorded program to an IEEE 1394 monitor in
another room. NetCommand will establish the connection
between the two devices. Once the connection has been
established, the HD-6000 can be turned off or be used
to display another device on the moniton Recording
from digital channels to a DVCR is also a peer-to-peer
connection. In this case, the HD-6000 is one of the
devices in the peer-to peer connection.
Setting up a Peer-to-Peer Connection
To establish a peer-to-peer connection:
1_ Press CONNECT on the HDTV receiver/controller
remote_
2. Press DEVICE on the remote control to move to the
Source Device section.
3. Press ADJUST _ or _ to select the source device
you wiii record from.
4. Press ENTER to confirm selection and return to the
"Record to" section_
5_ In the "Record to" section, review the destination
device (example: DVCR) and duration. Change if
necessary.
6_ Press CONNECT a second time to initiate
recording.
CanceJing a Peer-tooPeer Connection
After a peer-to-peer connection has been established,
you can cancel it by highlighting the source device
in the Device Selection menu. Confirm that the on-
screen icon for the peer-to-peer connection is in the
Connection Section next to the TV icon, then press
CANCEL The connection will end and the destination
icon will be removed. If there is more than one peer-
to-peer connection for the same device, all of the
connections will all be canceled.
NOTE: Multiple peer-to-peer connections can
occur simultaneously, sometimes with the same
source device.
61
Using TV Disc & AiV Discs
TV Disc & A/V Disc Track List Screen
Figure !5
When viewing the TV Disc or an A/V Disc, press GUIDE
to display its Track List. The Channel, Station, Date,
Time, Program name and whether it has been Watched
(Y=yes, N=no) will be displayed. Tracks will be listed in
date and time order and will vary in size.
Press ADJUST • or • to navigate through the Track
List. Press INFO to see the recording's length and
the amount of memory it will use. Free disc space is
displayed in the upper right. If the broadcaster has
sent detailed information regarding the program, it will
also display when you press INFO. To play a track,
select it on the list, then press ENTER. To change
pages, press CH • or •. To delete a track, select it
on the list and press CANCEL. Press CANCEL again to
confirm.
Figure 15, Track List screen for TV Disc
2. Press ADJUST • or • to select a track. Then press
ENTER to start playing.
3. Press PAUSE to pause the playback.
4. Press REC (record) on the HD-6000 remote. The
Record To screen will display.
5. In the "Record to" section, review the destination
device (DVCR, VCR). Change if necessary.
6. Press REC a second time to initiate recording.
7. The TV Disc and destination device cannot be
viewed or used while recording. To view a different
device, press DEVICE and select.
IMPORTANT
gprograms cannot be transferred from
TV Disc and the TV Disc is not intended to
as permanent storage of digital recordings.
recommends you transfer important
ital recordings to an external device such as
a D-VHS VCR. Recordings stored on TV Disc
are lost and cannot be recovered if the TV Disc
requires replacement or repair. Mitsubishi is
not liable for lost recordings.
TV Disc or A/V Disc Search
NetCommand is able to search to a specific time in a
recording on the TV Disc or an IEEE 1394 AiV Disc.
1. Start the desired track's playback on the AiV disc.
2. Use the number buttons to enter the time code
position of hours followed by minutes. For example,
to enter one hour and twenty-two minutes (1:22)
into the track, enter 1, 2, 2.
3. Press ENTER to skip to the time code position.
4. To cancel the request or to start over, press
CANCEL instead of ENTER.
Archiving TV Disc Digital Recordings
To permanently store a COPY FREE digital recording
from the TV Disc on D-VHS or other IEEE 1394 device:
1. Press DEVICE on the remote control and select TV
Disc by pressing ADJUST 4, I_, • or • and then
ENTER.
62
Using the Remote Control with TV Disc or A/V Disc
after selecting from the Device Selection menu:
GUIDE:
PLAY:
PAUSE:
FF/FWD:
REWiREV:
displays the Track List of recorded pro_rams.
resumes playback of paused pro_gram.
pauses or resumes playback of program.
forward picture search, multiple presses
increase the speed.
reversepicture search, multiple presses
ADJUST _:
ADJUST •:
ADJUST •:
REC:
skip backward 12seconds per press.
skip forward 30 seconds per press.
skip to the end of the track.
skip to the beginning of the track.
Display the Record Menu to schedule
recordings
If the TV Disc is the default digital record device
(NetCommand menu), you can also schedule
recordings from ChannelView.
Direct VCR Recording from an Antenna or Cable Source,
Copy=Protected Material and Restricitons for Traditional VCRs
Direct VCR Recording from an
Antenna or Cable Source:
Pressing REC (record) on the HDTV receiver/
controller's remote control will function the same way
as pressing the record button on the VCR's remote
control or front panel.
To record directly from antenna or cable:
1. Press DEVICE on the HDTV receiver/controller's
remote to display the Device Selection menu.
Highlight the traditional VCR and press POWER
to turn on the VCR. If necessary, press GUIDE to
select the input the VCR is on, such as Antenna
input (or line input).
2. Press ENTER to switch the HDTV receiver/
controller to the VCR.
3. Select the correct channel for recording on the
VCR and then press REC to start recording. You
wiii need to manually stop the recording at the end
of the program.
om_
4. Press the DEVICE MENU button to display the
VCR's menu to schedule a delayed recording
directly from antenna or cable.
To record from Ant-l, Ant-2 or other devices, see
NetCommand Controlled Recordings.
Copy-Protected Material
When attempting to record copy-protected material,
the Record functions of the NetCommand and IEEE
1394 systems may be prevented or stopped. If you
have a recording that is tagged "Record Once",
NetCommand will not allow the recording to be moved.
Restrictions for Traditional VORs
If turned On, the HDTV receiver/controller must be
tuned to the source device.
Your VCRshould be connected directly to Monitor Audio
Video OutpuL
The VCR must be set manually to "Line input".
Display the Device Selection menu, highlight the VCR
and press GUIDE to change VCR inputs.
The HDTV receiver/controller can select channels on
compatible cable boxes for recordings, Leave the cable
box turned on,
Ifthe source device or recording device does not have
separate power On and Off features, then leave that
device powered On.
63
PC Viewing
PC Input
Figure 16
Display
1. Connect the PC to the HDTV receivericontroHHer's
back paneHas shown in the connection chapter of
this guide. If you are connecting to a LT-4260 LCD
TV, foHHowthose specific instructions.
2. Add the device in the NetCommand menu.
3. SeHect the PC through the Device SeHection menu.
Resolution
For the correct screen resoHution (pixeHs),whiHethe PC
is dispHayed on-screen, use the PC's ControH PaneH
settings, as shown bellow (for most PC's). Your TV can
dispHay onHystandard VGA (640 x 480) 60Hz refresh rates
onHy.
1. In the PC's "Start" menu, seHect "Settings".
2. SeHect "ControH PaneH'.
3. SeHect "DispHay'.
4. Choose the "Settings" tab.
5. Depending on your PC, either:
Use the screen area sHideror use the Screen
ResoHution sHiderto adjust the resoHution.
You may need to restart the PC for this change to take
effect.
IMPORTANT
I_ you are using the HD=6000 with the LT-4260
LCD HDTV display, you cannot use the PC input
on the HD=6000. Use the PC input on the TV's
display panel.
7{'_ I
Figure 16, Selecting VGA resolution for a PC
(}4
MediaComrnand TM and Media Card Playback with the
Mitsubishi LT-4260 LCD TV Display Only
Warning: Some media cards avaimabie on the market are not properly certified to fommow the card type
specifications noted below and cannot be used by the Card Reader. if you experience problems with the
reading of your file, please transfer your flies to a properly certified card.
Media Card S Jots Remote Control Buttons for Controlling the
Inserting a media card Playback
Insert a card into a matching card shot on the frame For JPEG
of the LT-4260. Be sure to use the correct card shot. PLAY:
Card 1 will accept MuHfiMediaCard TMand SD Media PAUSE:
Card. Card 2 will accept SmartMedia TM. Card 3
will accept CompactHash®. Card 4 will accept FF:
MEMORYSTICKTM, Cards up to 128mb, with a flHe REW:
format of FAT 16 (bHock size = 1024 or 2048) are FORMAT:
supported.
Normally the label side should be up, but if the card
does not fit, try turning the card over and insert
again. When properly inserted, the light next to the
slot will light up.
2_ Press DEVICE on the remote control to display the
Device Selection Menu and then select the correct
card slot from the list, using ADJUST 4, _', • orV.
3_ The Media Dialog box (figure 17) will automatically
display. Use the AUDIO button to switch from
JPEG Picture Slideshow setup to MP3 or WMA7
Audio Haylist setup or use the VIDEO button on
the remote to switch from the MP3 or WMA Audio
Haylist setup to JPEG Picture Slideshow setup.
Don't pummthe media card out whime it is pmaying.
STOP:
Pictures Slideshow:
begins or resumes slideshow playback
pauses or resumes playback while in the
automatic advance mode.
skips to the next slide.
returns to the previous slide.
single press rotates the slide 90 °.Multiple
press continues to rotate the slide.
Stop slideshow, return to media card
screen.
For MP3 or WMA Audio Playback
PLAY:
PAUSE:
FF:
REW:
STOP:
begins or resumes playlist playback.
pauses or resumes playback.
skips to the next track/song.
skips to the previous track/song.
Stop playback and returns to media card
screen_
Using the Picture Thumbnaim Menu or Audio
PmaylistMenu
For JPEG Picture Thumbnail Menu:
Figure 18
1_ Press GUIDE on the remote to display the JPEG
picture Thumbnail menu.
2_Press ADJUST 4, I_ • or V to move the highlight
to different images (CH up/down will change pages
of the Thumbnail menu). Use REW to go to the first
slide and FF to go to the last slide on the page.
3_Press FORMAT to rotate the selected image 90°
(pressing FORMAT four times will rotate the image
completely around to the original position).
Figure 17. Media Dialog Box
4_ On the remote control, press:
4_Press PLAY to begin playback of the Slideshow from
the selected image. The Thumbnail menu will be
taken down.
PLAY: to start the slideshow or play audio.
GUIDE: to display the JPEG Thumbnail menu
(Figure 18) or Audio track playlist (Figure 19) i
DEVICE
MENU: to display the Media Setup menu (Figure 20)_
Figure !8, JPEG Thumbnails
65
MediaCommand TM and Media Card Playback with the
Mitsubishi LT-4260 LCD TV Display Only, continued
For MP3 or WMA7 Playlist Menu:
Figure 19
1. Press GUIDE to display the Playlist menu.
2. Using ADJUST • or V to move the highlight to
different tracks (CH up/down wiii change pages of
the Piayiist).
3. Press PLAY to begin playback. The Playlist menu
wiii be taken down. An asterisk (*) wiii be next to the
song currently playing.
Figure 19, Audio Playlist
COMPATIBLE PICTURE OR AUDIO FILES:
For JPEG Pictures up to 128MB:
1. Stiii images recorded on digital cameras using the
Exchangable image File Format, version 2.1 (EXIF
2.1) standard for digital still cameras and Design
Rules for Camera File Systems version 1.0 (DCF 1.0).
Some images opened and resaved on a computer
may not playback or may not be able to display a
picture in the thumbnail list because the computer
program that opened and resaved the images
changed the fib to an incompatible formal
2. Standard digital images with a maximum size of
5-megapixels for each image, or 2560 x 1920 pixels.
Pictures will be scaled to the TV display. Some
pictures may be cropped to fiL
3. Full path fib names can be no longer than 50
characters and must end in a jpg extension. Not all
50 characters wiii display.
For MP3 or WMA7 Audio files:
1. Fibs recorded with sampling rates of 32 kHz, 44.1
kHz or 48 kHz.
2. Fibs recorded with fixed bit rates
3. Fib names with .mp3 or .wma extensions
66
NOTE: During MP3 or WMA7 audio playback,
audio from the cards wiii be sent to the AiV
receiver as analog audio. Digital out is not
available.
Media Setup Menu
Figure 20
Press DEVICE MENU at any time to display the Media
Setup screen, where you can adjust the Slideshow
Display, Frequency, Interval or Playlist Frequency.
For JPEG Picture Slideshow Setup
For JPEG picture Slideshow playback, select
Automatic or Manual advance. For manual
operation, press PLAY or ENTER on the remote
control to advance each slide.
For automatic advance, select the frequency
or number of times to show the complete slide
show, Once, Twice or Continuously.
For automatic advance, select the interval time
each slide is shown, for example, 5 seconds, or
30 seconds.
For MP3 or WMA7 Audio Playlist Setup
Select the frequency or number of times to
play the complete playlisL Once, Twice or
Continuously.
To exit, press DEVICE MENU on the remote control
to redisplay the media card screen or press HOME to
return to TV viewing.
Figure 20. Media Setup Menu
E d ed thr _ghth!1Tvor
__anges should be made
n,oo o,oovo, ,,o,ooos.
TV Menu Screen Operations
Main Menu Choices ....................................................................... 68
Setup Menu .................................................................................... 69
NetOommand® Menu .................................................................... 71
Antenna Menu ................................................................................ 72
Time Menu ...................................................................................... 74
Captions Menu ............................................................................... 75
V-Chip Rating Guidelines .............................................................. 77
V-Chip Lock Menu ......................................................................... 78
AudioVideo Menu ........................................................................... 80
A/V Settings Descriptions ............................................................. 81
Main Menu Choices
Setup Menu
Figure 1
Use the Setup menu to seHect EngHishor Spanish as
the Hanguage for the menus and on-screen dispHays.
Adjust CoHor BaHanceAutomatically or manually
(PerfectCoHorTM). CoHor BaHance uses six coHors,
Magenta, Red, Yellow, Green, Cyan and BHueto obtain
coHor baHance. Reset the CoHor BaHanceto the factory
defauHt setfings.
SeHect the setting for the TV Pause feature. Choose
Side Bar CoHorof bHack or gray. View the HD-6OOO's
software version on this screen.
Figure 1, Main menu, Setup selected
Time Menu
Figure 4
Manually set the time for the HD-6000, or seHect Auto
and the HD-6000 will automatically set the time based
upon Extended Data Service (XDS) time data. This
time data is usually broadcast by your local PBS
station. This menu is also used to set the TV timer.
Figure 4. Main menu, Time selected
Captions Menu
Figure 5
Display Closed Captions if sent by the broadcaster,
select settings for analog or digital captions.
NetOommand® Menu
Figure 2
Add, change, review or delete NetCommand® settings
and devices. If you have more than one digital
recording device connected, use this menu to change
the default digital Record To device. Turn the transport
menu off and change the order of the icons in the
Device Selection menu.
Figure 2. Main menu, NetCommand selected
Figure 5. Main menu, Captions selected
VoChip Lock Menu
Figure 6
Block or allow programing based upon rating signals
sent by the broadcast station or lock by time.
Antenna Menu
Figure 3
Memorize available analog and digital channels for
both Ant-1 and Ant-2. After memorization, if a channel
displays as digital and analog, you can choose to
see the channel digitally every time it is selected.
Manually add or delete channels from memory, name
channels or add your favorite channels to a SQV
(SuperQuickView TM) list.
Figure 3, Main menu, Antenna selected
Figure 6, Main menu, V-Chip Lock selected
AudioVideo Menu
Figure 7
Reset the AiV Memory to return to the original factory
AiV settings for a selected device. Customize the
individual audio and video settings.Display a blue
screen when viewing a device with no signal, enhance
the darker parts of bright pictures or adjust the analog
audio output.
68
Figure 7. Main menu, Audio/Video selected
Setup Menu
Setup Menu
Figure 8
Press ADJUST A or T to navigate between cobrs
and ADJUST _ or _ to change the cobr siider
settings.
Figure 8. Setup Menu, NetCommand Option
Language
Dispiay the on-screen menus in either Engiish or
Spanish (Espa_oi). The first time you powered On your
HDTV receiver/controller, you were requested to sebct
an on-screen menu ianguage. If you choose to change
the sebction, aH menu text will immedbteiy switch to
the ianguage of your choice.
Program titles and other information sent by a
broadcaster wiii be shown in the originai language.
CoJor Balance
Your HD-6000 uses six coiors (Magenta, Red, Yellow,
Green, Cyan and Biue) to create coior baiance. You may
adjust the intensity of the colors automatically or manually
(PerfectColor TM)or reset them to the default settings.
Each input or device has a memory for PerfectColor.
Auto (Color Balance}
If the Auto box is checked, your HD-6000 will optimize
color automatically and continuously. Both PerfectColor
and Reset options for Color Balance are grayed out and
unavailable.
PerfectComor TM (Manuam Comor Bamance}
Figure 9
The PerfectColor (manual) option is only available when
Auto (Color Balance) is not checked. Select PerfectColor
and press ENTER to display the menu. Individual sliders
for Magenta, Red, Yellow, Green, Cyan and Blue will be
displayed. The sliders have a numeric value, where 63
is the maximum. The default setting for each color is 31
(center). Highlighted text will show which slider you are
adjusting. Each active input can be individually adjusted.
Figure 9. PerfectColor Menu, Manual Color Correction
Reset
Select to reset the Color Balance settings. Each active
input can be individually reset, if Auto is not checked.
TV Pause
TV Pause is a special feature of the internal TV Disc
digital video recorder (DVR). TV Pause is available
for CabbCARD TM,Ant-l, Ant-2, IEEE 1394 input and
tuning devices (cable boxes or satellite receivers
connected to Inputs 1 or 2).
This feature allows you to press PAUSE to "pause"
live TV. You can then search backwards or forwards
through the current TV program. When you pause
the TV program, an on-screen slider will show
approximately how far and in which direction(s) you
can search.
TV Pause has three settings:
On Request: This is the default setting. TV Pause
is in the standby mode until you press PAUSE
for the first time after turning on the TV, or after
a channel or device change. There will be a few
seconds delay before a paused picture appears.
During this pause, you will not be able to scan or
skip backwards in the TV Program. Later uses of
TV Pause while in the same program, will allow
reverse scan or skip of the available TV program
as shown on the slider. The TV Pause will return to
the standby mode automatically when you change
the channel or device. The PIP/POP features are
available only when TV Pause is in the standby
mode and not enabled.
Always: Press PAUSE, REW, FF or any ADJUST
button to pause the program and scan or skip
within the program. You can also scan or skip
69
Setup Menu, continued
forward to catch up to the Hivebroadcast. In the
AHwayssetting, the PIP/POP features are not
avaiHaMe and channeH changing will be shower. To
use the PPiPOP features, seHectthe Off or On
Request setting for TV Pause.
Off: This mode prevents the TV Pause function,
however, full screen picture freeze is avaiHabHe.If
you do not expect to use the TV Pause features,
we recommend the Off or On Request mode. This
mode allows PIP/POP features to be used.
Figure !0, TV Pause slider
Side Bar CoJor
For some TV formats sidebars are visibHe (see TV
DispHay Formats, pages 85-86). You can choose to
dispHay these sidebars in gray or bHack. When used
with an LCD, DLP or LCOS TV, Mack is recommended.
When used with a CRT or pHasma dispHay, gray is
recommended to avoid burn in.
Software Version
For some service related issues, it may be necessary
to know which software version is in your TV. This
information is displayed on the Setup menu screen.
Controlling the TV Pause Features:
NOTE: You cannot reverse search further back
than the beginning of the filled space as shown on
the slider. You cannot forward search past the live
broadcast point.
Press PAUSE to pause the current TV program.
Press PLAY to resume watching the TV program
from the pause point.
Press FF to forward picture scan. Press up to
4 times to increase the scan speed. If pressed
when TV is paused, then will forward scan, not
fast forward.
Press REW to reverse picture scan. Press up
to 4 times to increase the scan speed, pressed
when TV is paused, then will reverse at half
speed.
Press ADJUST 4 to skip backwards 12 seconds
(for each press).
Press ADJUST _ to skip forward 30 seconds (for
each press).
Press ADJUST A to skip all the way to live
broadcast.
Press ADJUST V to skip back to the earliest
available part of the TV program as shown on
the slider.
If you wish to save this program press REC to display
the record menu and begin a formal recording. You
can use ChannelView to setup a formal recording by
pressing GUIDE.
7O
NetCommand® Menu
NetCommand Menu
Figure 11
Figure 11, NetCommand Menu
DetaiHed information regarding setting up and editing
the NetCommand menu is found in Chapter3. The Edit
NetCommand screens allow you to add new devices,
change or edit tradifionaH and IEEE 1394 devices, turn
devices and unused inputs On or Off, deHetea singHe
device or deHetethe entire setup configuration. If you
choose to deHetethe entire configuration, or if the
NetCommand setup was cancelled, deHeted or not
compHeted, you can start at the JnitiaHNetCommand
screen. The Review screen shows aH devices
connected to the HDTV receiver/controller.
Transport Menu
Figure 12
Note: Transport buttons (rewind, play forward, stop,
pause and record) on the remote control are located in
the bottom section of the remote control
DefauJt DigitaJ Record Device
If multiple digital recording devices are available in
NetCommand, this setting allows you to choose the
device to use when recording digital programs. A
digital recording can be made on either a digital or
analog device although the quality will not be as good
if recorded on an analog device. For best playback
quality, record digital programs on a digital recording
device.
If multiple devices were not connected and then
added in the NetCommand setup, this setting will
be unavailable (grayed out). Analog recordings can
only be made on the one analog device connected to
Monitor Out (usually a VCR) and are not affected by
this setting. This feature is most usdul when recording
from ChanneIView TM(page 59)_
icon Order
Figure !3
The Icon Order screen allows you to arrange the device
icon order on the Device Selection menu to a different
sequence, for ease of selection and operation. To change
the order, press ADJUST A ,V ,•, or • to highlight the
icon to be moved and then press ENTER. Press ADJUST
A,V" ,• or • to move the icon to the desired position and
then press ENTER to release the icon.
Figure 12. Transport Menu
NetCommand uses the Transport menu to control the
TV Disc, VCRs, DVDs, IEEE 1394 AV Discs, digital VCRs,
and similar devices. If you choose to turn off this
menu when viewing the devices, the transport buttons
(rewind, play forward, stop, pause and record) on the
HDTV receiver/controller's remote control will continue
to operate these devices. In the Device Selection menu
selecting a VCR or DVD Hayer will automatically display
the Transport menu. You can re-display this menu by
pressing DEVICE MENU.
Select Transport menu functions by pressing ADJUST •
or • and then ENTER. For example, to pause playback,
press ADJUST • or • to move to PAUSE, then press
ENTER. If a function is not possible, such as record for a
DVD Hayer, the Transport menu button will be grayed ouL
Figure 13 Icon Order Menu
71
Antenna Menu
Antenna Menu
Figure 14
Figure 14. Antenna Menu
The Antenna Menu options are avaiiabb for use with
anabg and digitai channeis on Antenna-1 and Antenna-
2. You can memorize channeis, add or debte channeis,
name channeis and add channeis to an SQV (Super
Quick View TM)bank.
For Antenna 1 (Main} or Antenna 2 (Au×}
Seiect either Air (when used with an indoor/outdoor
antenna) or CaMe (when used with direct came)
then press ENTER to start the automatic channei
memorization process. If a CabHeCARDTMis being
used, memorized channeis are provided by your cabb
provider through the CabbCARD.
To stop the automatic channei memorization process,
press CANCEL. Channeis memorized before you
pressed CANCEL are retained in memory.
After memorizing channels, the channels in the memory
can be accessed in ascending or descending order by
pressing CH • or •.
The memorization will occur twice, as the HDTV
receivericontrolbr memorizes analog and digital
Prefer Digital
When a memorized channel is available as both analog
and digital, a check mark in the Prefer Digital box will
allow digital channels to display and analog channels to
be hidden (when using CH). Removing the checkmark
will show both analog and digital choices.
Channels can be changed in 3 ways:
1. By pressing ADJUST • or • to select the channel.
2. By pressing CH • or • for channels already in
memory.
3_ Directly entering the number. With so many current
and potential channels, the number range is greatly
expanded. Channels can be one part, analog or
digital (up to the number 16888) or two part, for
digital channels (these use a separator). For a
two part digital channel, you may press SUB/
CANCEL on the remote to enter a separator after
the first, second or third number, depending on the
broadcaster's channel information.
For digital channels, when the broadcaster has
sent a virtual channel number, the virtual channel
number is shown in the text box and as a reference,
the original digital channel is shown below the text
box_
After the available channels have been memorized
with Memorize, weaker channels can be added.
Unwanted channels can also be deleted. Press CH
• or • on the remote control to see the channels
in memory. Press ADJUST • or • to select Added
or Deleted for the channel shown in the Channel
number box.
Analog channels shown on Antenna-1 or Antenna-2
can be named (up to four characters). After you enter
a name, it will appear on the TV screen, next to the
channel number.
1. Press ADJUST • or • to select each letter.
2. Press ENTER to set the letter and move to the
next letter position.
3. Press CANCEL to move back one position.
Digital channels are automatically named if the
broadcaster sends the information.
72
Antenna Menu, continued: SuperQuickView TM (SQV)
SQV (SuperQuickView TM)
Using The Menu Screen
Figure 15
SQV (SuperQuickView TM)allows you to put together
banks of your favorite channeb from Antenna 1 and
Antenna 2_You can store channeis in any of the 9
different SQV memory banks. You can aiso store the
same channei in muifipb memory banks. Once you
have added a channei to an SQV memory, "SQV" and
the memory bank number will appear under the tuned
channei number on the TV screen.
Adding SQV Channels
1_ Sebct the channei using the "ChanneP option box
or press CH • or V.
2_Highiight the bank (SQV1-SQV9).
3_ Press ENTER to check mark the selected SQV
memory bank.
4. Repeat for additional channels or banks.
Removing SQV Channems
1. Highlight the box for the SQV bank number.
2_Press ENTER to remove the check mark.
Figure !5. Antenna Menu, SQV (SuperQuickView)
SQV (SuperQuickView TM)
Using The Remote Control
Viewing and changing SQV banks using the remote
control:
1. Press the SQV button.
2_ To change memory banks, press a number
button within 5 seconds of pressing the SQV
button.
3. Press the SQV button repeatedly to cycle through
the channels available in that bank.
Adding SQV channels using the remote control:
1_Press CH •, • or number buttons to select the
channel you want to add to the current SQV memory
bank.
2. Press and hold the SQV button for about 2 seconds.
When "SQV" and the memory bank number
appear under the channel number, the channel has
successfully been added.
Removing SQV channems using the remote controm:
1. Press the SQV button and then the memory bank
number.
2. Press the SQV button repeatedly until you see the
desired channel.
3_ While the channel number and SQV indicator (with
correct bank number) are still displayed on the
screen, press the CANCEL button. If the CANCEL
button is not pressed before the SQV indicator
disappears automatically, the channel wiii not be
removed.
4. When the SQV indicator disappears, the channel
has successfully been removed only from that bank.
"Other" banks remain unchanged.
73
Time Menu
Setting the CJock
You may choose to manually or automatically set the
chock that your HDTV receiver/controller will use for
recording or timer functions. You cannot schedub
recordings if the chock is not properiy set.
Figure 16
To manually set the chock, you need to sebct the
current time, inciuding AM or PM, current date, time
zone for your area and the Dayiight Savings time
setting.
Figure 16. Time Menu, Manual Clock Setting
Set Time
Press ADJUST • or V repeatedly to slowly select
the hour or press and hold to quickly select the hour.
Press ENTER to move to the minutes options. Press
ADJUST • or • to select minutes, then press ENTER
to select AM or PM.
Set Date
Press ADJUST • or • to sebct the correct date.
Time Zone
Sebct your correct time zone. Press ADJUST • or • to
sebct the time zone (Afiantb, Eastern, Centrai, Mountain,
Pacific, Alaska or Hawaii) for your area. Then press
ADJUST _' to move to the Daylight Savings time option.
Daylight Savings Time
Select the Daylight Savings time (DST) option that your
state uses. Press ADJUST • or • to select Applies if
your state or area uses DST, or Ignore if DST does not
apply.
Auto
Select the Time Zone and Daylight Savings time setting,
as noted above. You may then tune to a channel
(on Ant-1 or Ant-2) that uses Extended Data Service
(XDS) time data, typically a PBS channel. The Auto
selection will automatically retrieve the correct time
and date information from this channel. Be aware that
74
if a channel displays incorrect time information, it is
because of information sent from the broadcaster and
is not a defect of the HDTV receiver/controller.
Timer On/Off
Figure 16
The timer can be turned to On or Off. When On, you
need to select the time and day to turn the TV On and
the device and channel to display. At your presebcted
time, the timer will turn the HDTV receivericontrolbr
On, and this message will be displayed: "Press a
button for the HD-6000 to stay on". Press any button
on the remote control within 5 minutes or the HD-6000
will turn itself Off.
Set Time
Press ADJUST • or • repeatedly to slowly select
the hour or press and hold to quickly select the hour.
Press ENTER to move to the minutes options. Press
ADJUST • or • to select minutes, then press ENTER
to select AM or PM.
Set Day
Select the day or days that the HDTV receiver/
controller will turn on automatically. Press ADJUST
• or • to select Everyday, Mon-Fri (Monday through
Friday), or the individual days of the week.
Figure 17. Timer Menu (Timer On/Off)
Press ADJUST • or • to select the device to use
when the timer turns on the HD-6000. If the HD-6000
is already on, the timer wiii turn the TV to this selected
device.
When an antenna _sthe selected device, you may
select any memorized channel. Press ADJUST • or •
to select the channel and the HDTV receiver/controller
wiii tune to this channel in memory when the timer turns
it on. This includes sub-channels for digital choices.
Captions Menu: AnaJog and DigitaJ Captions
Captions Menu
Figure 18
For anaiog channeis broadcasters can send either
Standard or Text ciosed captioning. Standard Ciosed
Captions follows the diaiogue of the characters on-
screen and dispiays in a small section of the screen.
Text Ciosed Captions often contain information such as
weather or news and covers a iarge portion of the screen.
On digitai channeis, broadcasters can send up to 6
different captioning sebcfions. Each TV station may
broadcast oniy one or two types of captions or none
at all. The HDTV receiver/controller cannot decode
Ciosed Captions received on Component 1, 2 or Input-
DTV.
To make the anaiog dosed captions easier to read, you
can choose to dispiay the background cobr as either
biack or gray behind the captions.
DigitaJ Captions
The HDTV receiver/controlbr can display one of the
following Captions for Digital sources:
Captions 1_6. Sent by broadcaster.
On if Mute. Closed captions when mute.
When selected, the captioning signal (Caption 1)
wiii turn on/off by pressing MUTE on the HDTV
receiver/controller remote control
Off. No closed captions.
Note: If the broadcaster is only sending analog
captions converted to digital, then the analog
captions settings apply.
Figure !8, Captions Menu
Aria Jog Captions
The HDTV receiver/controller can display one of the
following captions for Analog sources:
CC1,002, CC3, or 004. (Standard closed
captioning signals).
Text1, Text2, Text3, or Text4. (Text closed
captioning signals).
On if mute. Closed captions when mute.
When selected, the standard closed captioning
signal (CC1)will turn on/off by pressing MUTE
on the HD-6000 remote control.
Off. No closed captions.
The Default options shows what the closed caption
provider intended to send. You may select the Custom
option to override and customize Closed Captions
appearance. These settings do not apply to analog
Closed Captioning converted to digital
DigitaJ Settings
Figures 18and 19
Digital Settings are available only when Custom was
selected from Appearance (Figure 17) and do not
apply to analog closed captions converted to digital.
Select Digital Settings by moving the ADJUST buttons
and pressing ENTER. You can select Font, Size,
Color, Background, Opacity (Font) and Background
Opacity.
Figure !9. Closed Captions Menu Digital Settings
75
Captions Menu, continued: Customizing Digita Settings
Fonts
You can customize the text of digitaH captions by
selecting the font of your choice, The avaiHabHeFont
options are as follows:
Default -
provider
Font 1 -
Font 2 -
Font 3 -
Font 4 -
Font 5 -
Font 6 -
Font 7 -
Selected by the Closed Captions
Monospaced font with Serifs
Proportional spaced font with Serifs
Monospaced font without Serifs
Proportionally spaced without Serif
Casual font
Cursive font
Small Capitals font
Size
You can also customize the text of digital captions
by selecting your desired size of font. Large is the
recommended font size.
Color
You can customize the text of digital captions by
selecting the color of fonL The available font colors
are as follows:
White • Yellow
Black • Green
Magenta * Cyan
Red * Blue
Opaque - Solid color text; blocks the TV program
Flashing - Text flashes in intervals
iMPORTANT
We recommend you use contrasting colors
between captions and background. In
particular, Black background with translucent
opacity and White font are best.
Care must be exercised when selecting
customized colors. "four choice may change
the legibility or readability of captions.
Background Opacity
You can customize the background for digital captions
using the following categories:
Transparent - See-through background to the TV
program
Translucent - TV program is visible behind the
background
Opaque - Solid background; blocks TV program
Flashing - Background flashing in intervals
To make the digital closed captions easier to read,
you can choose the background color. The available
background colors are as follows:
White • Yellow
Black * Green
Magenta * Cyan
Red * Blue
NOTE: If you choose the same color for the fonts
and background, Closed Captions will not be
visible.
Opacity (Font}
You can customize the visibility of your fonts using the
following categories:
Transparent - See-through text to the TV program
Translucent - TV program is visible behind the
text
76
V-Chip Rating Guidelines
V-Chip Signal Information
When provided by the broadcaster, V-Chip ratings can be used to control which programs can be viewed or will be blocked.
When V-Chip ratings are sent, you will see the ratings when you change the channel or when you press the INFO button on the
remote control. Both TV and Movie ratings will display. TV ratings apply to programs and movies developed for TV and may
have supplemental blocking by content categories. Movie ratings use MPAA ratings for movies released in theaters.
TV Ratings:
Used with TV programs and Made-for-TV movies.
TV-Y Youth, for children under the age of 7.
TWY7 Youth, 7 years old and older. For children 7 years old and older.
TWG General Audience. For the entire family to view.
TWPG Parental Guidance. Parental Guidance is recommended, may not
be suitable for some children.
TW14 Adolescent 14 years old and older. Not recommended for children
under the age of 14.
TWMA Mature Audience. For adults only.
TVRating FV D L S V
TV=Y
TV-Y7 X
TV-PG X X X X
TV-14 X X X X
TV-MA X X X
Content Categories:
Used in association with the TV ratings above.
FV Fantasy Violence- applies to TV-Y7 only.
D Sexual Dialog- applies in different degrees to TV-PG and TV-14.
L Adult Language-applies in different degrees to TV-PG, TV-14, and TV-MA.
S Sexual Situations- applies in different degrees to TV-PG, TV-14, and TV-MA
V Violence (graphic or realistic)- applies in different degrees to TV-PG, TV-14, and TV-MA.
When you select a TV rating, you are selecting the least=restricted program level that can be viewed. As an
example, if you select TV=PG, you are allowing programs rated TV=Y, TV=Y7, TV=G and TV-PG to be seen and
blocking programs rated TV-14 and TV-MA. When you select a TV Content category, you wimmblock atomTV
programs that have the same content category misting. As an example, if you select to block V (Violence) at
the TV-14 level, you wm also block any program that has the V category listing at the TV-PG rating level as
well.
Movie Ratings:
Used with theater released movies and direct-to-video movies.
G General Audience- Designed for the entire family to view.
PG Parental Guidance- Parental Guidance is recommended, may not be suitable for some children.
PG-13 Parental Guidance 13 years old and older- Not recommended for children under the age of 13_
R Restricted- Restricted in the theater to 17 years old and older unless accompanied by an adult.
NC-17 No Children- Restricted in the theater to 18 years old and older.
X Adult- Designed for and restricted in the theater to adult audiences only.
When you select a Movie rating, you are selecting the least restricted program level that can be viewed. As
an example, if you select a movie rating of PG-13, you are allowing movies rated G, PG and PG-13 to be seen
and blocking movies rated R, N0-17, and X.
Programs Not Rated: Used for programs that are
not rated like news, sports, weather, emergency
bulletins, or movies such as those prior to or without
MPAA Ratings.
This does not include programs without V-Chip signals.
77
V=Chip Lock Menu
V-Chip Lock Menu Overview
The V-Chip Lock menu allows you to Mock or allow
programs based upon rating signaHs sent by the
broadcaster, or bHock TV viewing during specific
times. You can turn the V-Chip Lock On or Off using
the V-Chip menu or the V-CHIP button on the remote
control The TV comes from the factory with the V-
Chip Lock in the Off setting.
When On, the factory preset is TV-PG for TV ratings
or PG for movie ratings, allowing onHyprograms rated
TV-PGiPG or Hower. Use the V-Chip Menu to change
the aHHowabHerating HeveHs.After changing channeHs
or devices, there may be up to a 5 second deHay
before the V-Chip Hocktakes effect.before the V-Chip
Hocktakes effect.
VoChip Lock Menu
Figure 21
The V-Chip Lock menu can be used in several ways. If
you want to lock the HD-6000 during specific hours,
select Lock by Time from the V-Chip Lock menu. To
set the lock, press ADJUST • or • to select On or Off
for Lock by Time. If you select On, then press ADJUST
• to move to the Lock Time box. Press ADJUST • or
• to select Lock Time.
Press ADJUST • or • repeatedly to slowly select
the hour or press and hold to quickly select the hour.
Press ENTER to move to the minutes options. Press
ADJUST • or • to select minutes, then press ENTER
to select AM or PM. Repeat these choices to select
the Unlock Time.
Setting the Lock Time and Unlock Time to the same
time will make the Lock by Time active 24 hours a day.
During the Lock Time, you must use your passcode to
view the TV.
SeJecting a Passcode from the VoOhip
Lock Menu
Figure 20
The V-CHIP PARENT LOCK screen shown below
displays when you select the V-Chip Lock menu from
the Main menu. To access the V-Chip Lock menu,
input a four-digit passcode with the number buttons
on the remote control, then press ENTER. You
can delete a number and move back one space by
pressing CANCEL or you can exit without inputting
a passcode by pressing MENU or HOME before
pressing ENTER. The next time you select V-Chip
Lock you will see "...enter your passcode" instead of
"__enter a new passcode'_
Figure 20. V-Chip Entry screen from Menu
78
Figure 2!. V:Chip Lock Menu
V Chip Lock Menu, continued
Using VoChip with Program Ratings
Figure 22
You can choose the program ratings that you want
to allow during specific times of the day by using the
ADJUST buttons to higHight V-Chip from the V-Chip
Lock menu and press ENTER. When you seHect V-
Chip the screen in Figure 22 will dispHay.
Press ADJUST A or • to seHect On or Off. If you
seHected On then press ADJUST • to move to the TV
Rating box. Press ADJUST • or • to seHectthe TV
Rating HeveHyou want to allow. Press ADJUST • to
move to the TV Content Categories and press ADJUST
• or • to seHect. Press ENTER to add a check mark
to the TV Content Categories you want to bHock.
Press ADJUST • to move to the Programs Not rated
box and press ADJUST • or • to seHecta program.
Press ENTER to add a check mark to programs that
are not aHowed.
NOTE: If you select to block programs that carry the V-
Chip rating Programs Not rated, you may block News
or Emergency Bulletins, when "None" or "NR" Not
Rated V-Chip rating is included. Care should be used
when blocking programming that is not rated.
Press ADJUST • to move to the Movie Rating box.
Press ADJUST • or • to select the Movie Rating
level you want to allow. See the next page for detailed
information on rating guidelines.
To set the times when these guidelines will be active,
press ADJUST • or • to slowly select the time,
starting with the hours. Press and hold ADJUST •
or • to quickly select the hours, press ADJUST • to
select the minutes.
By setting the V-Chip Start Time and V-Chip Stop
Time to the same time, the V-Chip will be active 24
hours a day.
Figure 22. V-Chip Menu
Using the Passcode from the VoOhip
Lock Menu
When a channel or the HD-6000 is locked, figure 23
will display. To view a V-Chip blocked program or
to watch the program during a scheduled lock time,
you must enter your 4-digit passcode or change to
an unlocked channel or allowed program. Once you
have entered the passcode, the V-Chip Lock or Lock
by Time will remain released until the HD-6000 is
powered Off and then On again.
Figure 23. V-Chip Passcode screen
Using the VoChip from the Remote
Figure 24
You will see the screen shown below when you first
press V-CHIP on the remote control. To quickly turn
on or off the V-Chip Lock, input a four-digit passcode
with the number buttons on the remote control, then
press ENTER. To change any V-Chip settings, you
must use the V-Chip Lock Menu.
Figure 24, V-Chip Ent_v screen from Remote Control
79
AudioVideo Menu
Figure 25
Figure 25. Audio/Video Menu, Settings
A/V Memory Reset
AiV Memory Reset allows you to seHectthe device
which will have the AiV Settings returned to the
odginaH factory settings. To return a device's memory
to the odginaH factory settings, seHectthe device and
then press ENTER.
Settings
Each device has its own AiV memory. SeHect the
device in A/V Memory Reset, then seHectAudio or
Video to adjust the device's individuaH settings. Press
ENTER, the menu is removed, and the individuaH
settings are dispHayed.
If using the HDTV receiver/controller with the LT-4260
dispHay, use the AUDIO and VIDEO buttons on the
remote controH to change settings, as these options
are not accessibHe from this screen.
Figure 26. Scan Rate Output
Figure 2Z Scan Rate Confirmation screen
Use ADJUST • or • to select the individual settings
for adjustment. Use ADJUST • or _"to adjust. For
descriptions of the individual AiV settings see AiV
Setting Descriptions, pages 81 and 82.
Scan Rate Ouput
Figures 26 and 27
Allows you to adjust the scan rate output from the
HD-6000 to the TV, display, or LCD. If you choose
Automatic, the HD-6000 will select the scan rate, or
you can select 1080i, 720p or 480p for the output
format. When you select Test, the main screen will
change to the selected Output Format and a small
screen will display, allowing you to select OK to make
Video Mute
Video Mute lets you display a blue background when
no signal is being received on Inputs 1-3, MonLink, PC,
Components 1-2 and Input DTV.
AnaJog Audio Output
If speakers are connected to the TV or monitor or you
are using the internal TV speakers, select Variable.
This allows you to control the volume with the HD-
6000 remote control, if speakers are connected to
the AiV receiver, select Fixed. When NetCommand ®
is enabled, selecting the AiV receiver icon from the
Device Selection menu automatically turns Off the TV
speakers.
Note: To prevent damage from a sudden increase
in volume, make sure the volume is set to low before
setting speakers to ON.
8O
AiV Setting Descriptions: Audio
NOTE: The effects of the Audio Settings of Bass, Trebb, Baiance and Surround affect the sound heard through the
TV speakers oniy.
Using the AUDIO Button on the Remote Control
To adjust individuai Audio settings directly with the
remote controk
1. Press AUDIO to cycb through the avaiiabb settings.
2. Press ADJUST '4 or _ to adjust the setting. After
5 seconds of inactivity, the setting dispiay will
disappear.
AnaJog and DigitaJ Audio Setting
A siider will dispiay on-screen for most settings.
When the siider is dispiayed it has a numeric vaiue,
where 63 is the maximum, 31 is the mid-point and 0 us
the minimum.
0Bass
Enhances or reduces low-pitch sound.
0Treble
Enhances or reduces high-pitch sound.
0Balance
Adjusts the level of sound between the left and right
speakers.
0Surround
Creates simulated stereo and surround effects
through the TV speakers. Your choices are:
Off: No surround effects.
Surround Sound: Will create a simulated surround
effect when watching a stereo program.
Simulated Stereo: Will create a simulated stereo effect
when watching a non-stereo program.
AnaJogoOrfly Audio Settings
0Listen to
Determines how your HD-6000 will receive a
broadcast audio signal and play back the sound
you hear.
Your choices are:
Stereo: Default setting. Will play stereo
broadcasts in stereo and mono broadcasts in
mono. The word "Stereo" will be displayed
when you tune to a channel broadcasting
stereo.
SAP (Second Audio Program): Additional
monaural soundtrack that you cannot hear
during normal TV viewing. The SAP signal
might be related to the program you are
watching, such as a soundtrack in a foreign
language, or unrelated to the program you are
watching, such as a weather report. If an SAP
signal is broadcast, the letters "SAP" will be
displayed when you tune to the channel.
Mono: Reduces background noise and should
be used when receiving a weak stereo audio
signal. All audio will be played mono with this
setting.
Listen to is not availabb for devices connected
to the video inputs, component inputs or 1394
devices.
0Level Sound
Turn On or Off to automatically equalize the
volume level of programs containing significant
level differences from one segment to another (for
example, regular programming to commercials). To
receive the best fidelity with music programs, you
can turn this setting to Off.
OigitaJoOrfly Audio Settings
0Language
Determines what possible language you will hear.
Your choices are:
English
French
o German
kalian
Portuguese
Spanish
"Other"
0Level Sound
Automatically reduces loud passages and boosts
soft passages to a more uniform loudness. When
connecting to an AiV receiver, set level sound
to OFF and turn the TV speakers off to send full
dynamics to the AiV receiver.
This feature only works with Dolby Digital sources.
Other digital audio formats do not offer this
dynamic range control. In these cases, no effect
wiii be heard when changing the level sound
setting.
81
AiV Setting Descriptions: Video
Using the VIDEO Sutton on the Remote Control
To adjust individuaH Video settings directly with the
remote controH:
1. Press VIDEO to cycHethrough the avaihbHe settings.
2. Press ADJUST • or • to adjust the setting. After
5 seconds of inactivity, the setting disphy will
disappear.
Video Settings
0 Contrast
Provides a sHiderto adjust the white-to-Mack HeveL
Low contrast shows a variety of shades in darker
images, whiHehigh contrast shows darker images
more uniformHy bhck and makes coHors appear
more vibrant. In most home Highting situations, a
medium contrast looks best. High contrast is good
for brightly lit environments.
0 Brightness
Provides a slider to adjust the overall brightness of
the picture.
0 Sharpness
Provides a slider to adjust the detail and clarity.
0 Color
Provides a slider to adjust the color intensity.
0Tint
Provides a slider to adjust the proportion of red to
green.
0 Video Noise
Use to reduce minor noise (graininess) in the
broadcast received on Ant-1 and Ant-2, Inputs 1
and 2, Component 1 and 2, and Input-DTV. Use
standard with good quality signals.
0 Film Mode {Auto} -On or Off
On is the automatic setting and will automatically
detect and apply film decoding correction for
signals that originated on 24 frames per second film
cameras and then were converted for broadcast to
30 frames per second video.
When the original signals originated on 30 frames
per second video cameras, the On setting will
automatically apply video decoding, the same as
used with the Off setting. Try the Off setting when
the TV seems to have difficulties and adds too many
jagged edges to the images.
Film Mode is not effective for progressive scan (480p)
devices, and high definition signals.
NOTE: A slider will display on-screen for most
settings. When the slider is displayed it has a
numeric value, where 63 is the maximum, 31 is
the mid-point and 0 is the minimum.
82
Special Features
Operation of PiP and POP ............................................................. 84
Display Formats ............................................................................ 85
Device Control with NetCommand® ........................................... 87
Appendix A: Bypassing the V-Chip Lock ..................................... 89
Appendix B: input Connection CompatibiUity ............................. 91
Appendix C: Remote Control Programming Codes ................... 94
Appendix D: On-Screen information Displays ............................ 97
Appendix E: NetCommand® SpeciaUized Device Keys ............. 98
Appendix F: Cleanincj and Service ............................................... 99
Appendix G: input Sources and Scan Rates ............................... 100
TroubUeshooting ............................................................................. 102
AdditionaU information ................................................................... 107
index ................................................................................................ 108
Wa rra nty ........................................................................................ 110
Operation of PIP and POP
You can display programs from analog channels, analog inputs or devices as Pictureqn-Picture (PIP) and Picture-
Outside-Picture (POP). The HDTV receiver/controller has a second analog tuner for non-scrambled analog channels
received on Ant-1 and will display them as the PIP/POP sub-pictures. Digital channels and devices can be shown as
the main picture but cannot be the sub-picture. PC screens can be viewed in the side-by-side mode.
Press HPiPOP to activate the HPiPOP option. With
each press of the HP/POP button on the HD-6000
remote control (within seconds of each other), the PIP/
POP will cycle through the following display options:
.POP
side-by-side
MAIN pictures
PICTURE Side-by-Side
POP 1
MAIN
PICTURE POP 2
POP 3
• 3 POP
POP 1 POP 2 POP 3
MAtN POP 4 POP 5 POP 6
POP 7 POP8 POP 9
• 9 POP
Ar_t-I 2 XYO0(
StAndard
Stereo SAP
TV-PG DLSV
SQVI •PiP large
Ant-12 XX_SK
Slandard
Ster_> SAP
TWPG DLSV
SQV1
PIP Ant-1 17
• PiP small
Ant-12 XXXX
Standard
Stereo SAP
TV-PG DLSV
SQVl • PIP/POP off
84
To turn PIP/POP off, wait at least 10 seconds, and
press PIP/POP. The next time you activate PIP/POP,
the last used PIP/POP option will be displayed
Changing PIP/POP Device
Press PIP DEVICE to change the PIP or POP picture
source device. A menu similar to the Device Selection
menu will be displayed.
Changing PIP/Side-by-Side CharmeJs
Press PIP CH to scroll up and down through
memorized channels on Ant-1 and Ant-2.
Exchanging Program images
Press EXCH to exchange the main picture and the PIP/
POP picture. Pictures from digital channels can only
be shown as the main picture.
Moving PiP image
If no menus are onscreen, press ADJUST A V, 4or_
to move the PIP display anywhere on the main screen.
Automatic POP Switching
When automatic POP switching is active, the TV will
cycle through memorized analog channels on Ant-1 or
Ant-2 or strobe pictures from other AiV components
in the POP display. Press PAUSE to pause or restart
automatic POP switching.
SeJecting POP "Live" Image
Press ADJUST A, V, _ or _" to select a different POP
"live" image (automatic POP switching must be paused.)
Freezing the ProPand Side-By-Side Picture
Press PAUSE to freeze the PIP and side-by-side
images. Press PAUSE again to return to a "live" image.
IMPORTANT
Side-by-Side cannot show the same channem or
device on both sides,
If Ant-1 or Ant=2 is the main picture, Ant-2 is not
availabme as a PiP, POP or Side-by-Side.
PIP/POP is not compatibme with signams from
media cards.
if TV Pause is set to "Always" PIP/POP and Side-
-Side are not available.
Display Formats
The HD-6000 is designed to work with widescreen TVs (also known as a 16:9 TVs). This shape reflects the new
types of images available from HDTV and many DVDs. There are still many cider style narrow screen images (called
4:3 aspect ratio) you wiii encounter. While there wiii never be a perfect solution for displaying a narrow image on a
wide screen, Mitsubishi offers several display formats to choose from.
Press FORMAT on the HDTV receiver/controller remote
control to cycle through the available display formats.
The last used format for each device wiii be used when
you return to that device.
Note: Not all formats are available for
PIP/POP. Side-by-Side, 3 POP and 9 POP are
only available in Standard and Expand formats.
PC formats vary depending on PC signal.
Signals and Formats Definitions:
480i Signals: Traditional analog interlaced signals from
or through AntH & 2, Inputs 1 & 2, Component 1 & 2,
Input-DTV and HDMI.
480p Signals: Progressive scan analog DVD signals on
Antq & 2, Componentq & 2, Input-DTV and HDMI.
720p & 1080i Signals: High definition analog signals
received through ComponentH & 2, Input-DTV and HDMI.
These signals are always 16:9 (widescreen).
SD 4:3: Standard definition narrow screen format
signals from digital channels and IEEE 1394 devices.
SD 16:9: Standard definition wide screen format signals
from digital channels and IEEE 1394 devices.
HD: High definition wide screen format signals from
digital channels and EEEH394 devices. These signals
are always 16:9 (widescreen).
Zoom: This wiii enlarge the picture, cropping off some
of the image at each side and top and bottom. This is
useful to remove or reduce the black top and bottom
bars on anamorphic DVDs with a 2.35:1 aspect ratio.
Available for analog 480i and 480p and SD 4:3 signals
oniy.
Stretch: This format wiii stretch a narrow (4:3) image
across the screen, however, there is less stretch in the
center than the sides. This will allow the entire narrow
image to be displayed across the screen with less
distortion than seen in the Standard formal Available
for analog 480i and 480p and SD 4:3 signals only.
Stretch Plus: Similar to stretch mode, however
to minimize distortions on the side, the picture is
expanded to crop off portions of the top and bottom.
Useful when no important information is shown at the
top and/or bottom of the screen. Available for analog
480i and 480p and SD 4:3 signals only.
Narrow: This format wiii display narrow (4:3) images in
their original shape, and add stationary black or gray
side bars to fill the screen. Available for 480i, 480p
and digital SD 4:3 signals only.
Wide Expand: Enlarges the picture, cropping some of
the image on both sides. This Expand format is useful
to remove or reduce black side bars added to narrow
images that are converted to 16:9 signals for digital
broadcasL Available for analog 1080i, 720p, digital SD
16:9 and digital HD signals.
DVD Definitions:
Standard: This is the full screen formal HDTV
signals use this formal This format is useful to display
Anamorphic DVDs that have 1.78:1 or 1.85:1 aspect
ratios. Anamorphic DVDs that have a 2.35:1 aspect
ratio wiii still display black bars at the top and bottom
but wiii show the entire image correctly. Narrow (4:
3) images wiii be stretched evenly from side to side.
Available for aii signals.
Expand: This wiii enlarge the picture to fiii the screen
cropping off some of the image at the top and bottom.
This is useful to reduce the letterbox top and bottom
bars of non-anamorphic DVD. Available for analog
480i, 480p and digital SD 4:3 signals only.
Anamorphic (or Enhanced for Widescreen TV's}:
These DVDs are recorded in a special way to properly
show widescreen images on 16:9 TV sets in the
Standard format mode. This is the recommended
choice.
Non=Anamorphic (or 4:3, 1:33:1, Letterbox or Full
Screen}:
These DVDs are recorded for use with traditional
shaped TVs. They may be full screen (4:3 or 1:
33:1) which crops movies to fit the narrow TV, or
Letterboxed which adds black top and bottom bars.
This information may or may not be listed on the DVD
case. Some DVDs support both types of recordings.
85
TV Display Formats
ORIGINAL SIGNAL
Non-anamorphic or SD 4:3
Standard
TV Display
(not recommended, distorted)
Expand
f_O _ not available for
HD, SD 16:9 or
analog 720p, 1080i
(recommended for letterboxed)
Zoom
__) (_ not available for
HD, SD 16:9 or
analog 720p, 1080i
(not recommended, distorted)
Stretch not ai,a ,e,o
HD, SD 16:9 or
analog 720p, 1080i
(recommended for standard broadcast)
Stretch Plus
_O not available for
HD, SD 16:9 or
analog 720p, 1080i
(recommended for standard broadcast)
Narrow
D
I
G
I
T
A
L
(with side bars in broadcast)
Original HD or SD
16:9, 720p or 1080i
86
ORIGINAL SIGNAL
Anamorphic DVD
TV Display
(recommended)
Standard
Expand
__O__O__ not available for
HD, SD 16:9 or
analog 72gp, 1080i
(not recommended, distorted)
IO_ O 1 not available for
Zoom HD, SD 16:9 or
analog 720p, 1080i
(recom mended for anamorphic 2.35:1)
Stretch
(not recommended, distorted)
not available for
HD, SD 16:9 or
analog 720p, 1080i
Stretch Plus
(not recommended, distorted)
not available for
HD, SD 16:9 or
analog 720p, 1080i
Narrow not available for
HD, SD 16:9 or
analog 720p, 1080i
(not recommended, distorted)
Oavailable only for
Wide Expand (_ digital SD 16:9, HD,
oanalog 1O8Oi or 720p
(recommended to remove side bars)
Device Contro with Net Command °
NetCommand Compatibme Traditionam Devices (Anamog)
When Device Semection Menu is Dispmayed and the Device is Highlighted (Yellow Outline)
e
POWER
GUIDE
FORMAT
A/V RECEmVER
Power On/Off
(toggle)
Changes
between digital
and analog
audio
n/a
VCR
Power On/Off
(toggle)
Changes VCR inputs
n/a
DVD
Power On/Off
(toggle)
n/a
Changes output between inter-
laced and progressive
CABLE BOX/DRS
Power On/Off
(toggle)
Changes antenna inputs (RCA
model DTC-100 only)
Changes output between HD and
SD select models
When Net Command@ Compatible Traditional Device is Viewed or Played
OH up/down
VOL up/down
MUTE
0-9 (digits)
QV
DEVICE Menu
HOME
ENTER
CANCEL
GUIDE
ADJUST
PLAY
STOP
RECORD
REW/REV
FF/FWD
A/V RECEIVER
Volume
Up/Down
Mute On/Off
VCR
Channel up/down
number functions
1st press Transport Menu,
2rid press Setup Menu display
Counter Reset
Play
Stop
Record
Rewind/Reverse
Fast Forward or Fast Play
DVD
Skip Forward/Backwards
Chapter or Track
number functions
1st press Transport Menu,
2nd press Setup Menu display
Enter or select
Exit or return
Disc menu display
up/down left/right
Play
Stop
Reverse
Fast Play
CARLE/DRS
Channel up/down Page up/down
when guide showing
number functions
Last Channel Recall
Setup menu display or Action
function
Enter or select
Exit or return
Channel Guide
up/down left/right
87
Device Contro with Net Command O, continued
(EEE 1394 Devices
When Device Semection Menu is Dispmayed and the Device is Highlighted (Yellow Outline)
eTUNER/ A/V DmSC DVCR AMPLIFIER
CABLE BOX/
DBS
Remote _
Controm Butto_-_
POWER
GUIDE
FORMAT
Power On/Off
(toggle)
n/a
n/a
Power On/Off
(toggle)
n/a
n/a
Power On/Off
(toggle)
n/a
n/a
Power On/Off
(toggle)
n/a
n/a
CH up/down
VOL up/down
MUTE
0-9 (digits}
QV
DEVICE Menu
HOME
ENTER
CANCEL
GUIDE
ADJUST
PLAY
STOP
RECORD
REW/REV
FF/FWD
When an mEEE 1394 Device is Viewed or Pmayed
CABLE/DBS TV Disc or A/V DISC DVCR AMPUFmER
Channel up/down
number functions
Last Channel Recall
n/a
Exit menus/displays
Enter or select
Cancel function
Digital Channel
Guide
up/down left/right
Page up/down
(when track list is displayed)
Search by time
(when followed by ENTER)
Transport Menu redisplay
Exit menus/displays
Enter or select
Cancel function
Track or program list display
Skip Forward 30 seconds
(during playback)
Skip Backwards 12 seconds
(during playback)
Skip to end or beginning of program
Page up/down in track list
Play
Stop
Record
Reverse picture scan or Slow Play
Fast picture scan or Fast Play
index search forward/reverse
(if supported by DVCR)
Transport Menu redisplay
Exit menus/displays
Enter or select
Cancel function or Counter
Reset
Digital Channel Guide
up/down left/right
Play
Stop
Record
Reverse or Slow Play
Fast Play
Volume Up/Down
Mute On/Off
Device Menu
Exit menus/displays
Enter or select
Cancel function
up/down left/right
88
Appendix A:
Bypassing the V=Chip Lock:
0
® gg
cn
m
0 {n
0
mm
0
g_
<
g_
t#
t#
mm
l
t#
0
Bypassing the V-Chip Lock
After you set the Hock,you need your passcode to view
a V-Chip Hocked program, view the Hocked TV, canceH
the Hock,or enter the V-Chip Lock menus.
If you forget your passcode, you can view the Hocked
HD-6000 without entering your passcode. This is
done by pressing the number 9 and QV buttons on the
HDTV receiver/controHHer remote controH at the same
time, when your passcode is requested. This process
temporariHy unHocks the HDTV receiver/controHHer.
When entering the V-Chip Lock menu, this process
deHetes your oHdpasscode and prompts you to enter a
new passcode. Press HOME to exit the menu.
Bypassing Front Button Lock
If you have mispHaced the remote controH, you can
bypass the front button Hockby pressing and homing
the MENU button on the front paneHfor more than 8
seconds.
iMPORTANT
Cut among the dotted mineand lime
bypass instructions in a safe place for
:: future reference,
[
iMPORTANT
iiiili
control included with this HDTV
receiver/controller, You cannot use a
tvlitsubishi remote controm from another
component or a "universal" remote,
89
This page intentionally bJank
gO
Appendix B: input Connection Compatibility
Component°l and Component 2inputs
These inputs are compatible wkh component video signals from standard DVD players and other equipment _y
sending a standard NTSC component video signal (480i). These inputs are also compatible with newer DVD
players sending a progressive NTSC component video signal (480p). These inputs are also compatible with most
standard DTV and satellke receivers with component video outputs (YPbP0. Compatible DTV signals are SDTV
480i, 480p, 720p and HDTV 1080i.
VGA Input
This input will accommodate most computers capable of supporting a VGA monitor. The only compatible display
resolution is 640x480. The sync rate is 60 Hz. SVGA and higher resolutions are not supported.
NetOommand® IEEE 1394 System CompatibiJity=
This HDTV Receiver is designed to conform to EEE 1394 AV/C software standards in effect at the time of
development. This exciting new networking and control technology is designed to provide high=performance
digital connections and product control, making products easier to use.
As other manufacturers produce products that use IEEE 1394 AV/C, they will be responsible for the development
of their products to meet the standards of the technology, as well as compatibility testing with other products.
Mitsubishi cannot be responsible for their efforts, and therefore cannot promise compatibility with these other
products. Any compatibility problems with other manufacturers products should be brought to the attention of
those manufacturers.
DTV YPbPr RGBHV Input
This input is compatible with most standard DTV and satellite receivers with component video outputs (YPbPr).
Compatible DTV signals are SDTV 480i, 480p, 720p and HDTV 1080i. This input is also compatible with some DTV
receivers using RGB with "sync on green" or with "separate H and V sync." Compatible DTV signals are SDTV
480i, 480p, 720p and HDTV 1080i. All other DTV signals need to be converted by the DTV receiver to one of the
compatible signal types. Industry standards for DTV RGB signals (systems, synchronization, timing, and signal
strengths) are not currently established. These inputs will not be compatible with all DTV receivers that offer RGB.
If your DTV receiver offers both DTV component video signals and DTV RGB signals, Mitsubishi suggests you use
the DTV component video signals. Please check the DTV receiver specifications before connecting.
Injput Levels and Timing with Component 1 and 2
Video
EIA = 770.1
Pb
Pr
and EIA = 770.2 Standard Levels & Timing
= 1.0Vp-p (includes sync) 75ohm
= 700mVp-p, 75ohm (can also receive signals
from outputs labeled B-Y and Cb)
= 700mVp-p, 75ohm (can also receive signals
from outputs labeled R-Y and CO
DTV input Levels Used With HD Component Video
_nals
EIA - 770.3 Standard Levels & Timing
Y = 1.0Vp-p (includes sync) 75ohm
Pb = 700mVp-p, 75ohm
Pr = 700mVp-p, 75ohm
H = Not Used
V = Not Used
DTV Input Levels when Used With HD=RGB Video
_nals
E_. G = 700mVp-p (no sync), 1Vp-p (with sync) 75ohm
B = 700mVp-p, 75ohm
R = 700mVp-p, 75ohm
H= 4Vp-p+i-1.0% 75ohm (when using separate
H and V sync)
V = 4Vp-p+/-1.0% 75ohm (when using separate
H and V sync)
HDlVii input LeveLs
NTSC 480i only
Y = 1.0Vp-p (includes sync) 75ohm
C = 0_286 Vp-p (burst signal), 75 ohm
91
Appendix B: Specifications
From time to time, Mitsubishi may offer software updates to expand the features or operation of this HDTV receiver, /
controller. When these updates are avaHabHethey win be announced on our web site, Mitsubishi-tv.com. If you
return your Owner's registration card, with your modeH and sedan number, you may receive written notification of
avaHabHesoftware updates.
HDo6000 HDTV Receiver/Controller Specifications
Channe_ Frequency Reception Over-the-Air: VNF 2 - 13, UNF 14 - 69
Analog Cable: i - 125
Digital Cabme: i - 135
Channel Type Over the Air: Analog NTSC, Digital ATSC with sub-channels
(aB118video formats)
Cable: Anamog NTSC (non-scrambled)
DigitaB QAM 64 and 256 w{th sub-channems (non-scrambled)
CableOARDTM: Authorized scrambmed and non-scrambled digitaB channels
Note for Digitam Channels: The channeB numbers displayed on-screen are determined by the broadcaster or cable
company and can vary from the standard frequency number. If there is no channel number information included from
the broadcaster or cable company, then the TV win create a channel number based on the frequency number as the
main channel number and the program number as the sub-channem number. When using an authorized CabmeCARD, the
channel numbers are determined by the cable company.
mnputs
Antenna/Oabme input Qty 2 F connector, 75ohm
NDMm (digital video/audio}, Qty 1 NDMm standard connector
Signam Type NDMm standards for digitam audio and video. Not intended for use with
Video/S-Video, Qty 2 each
Signam Type
Component Video (Y/Pr/Pb) Qty 2 sets
Signam Type
lnput-DTV (Y/Pr/Pb or RGBH&V) Oty I set
Signam Type
PC mnput (RGB) Qty i
Signam Type
Audio mnputs: Qty 6 pair
personal computers
Video: RCA Pin P_ug, t,0 V p_p, 75 ohm
S-Video: Four Pin Din PBug
Y: i,0 Vp-p 75 ohm
C: 0,286 Vp-p (burst signat), 75 ohm
NTSC 480i onmy
RCA Pin Plug (EIAW70.3 Standard Levemsand Timing)
Y: i.0 Vp-p (incmudes sync), 75 ohm
Pr: 700 mVp-p, 75 ohm
Pb: 700 mVp-p, 75 ohm
EIA-770.i & EIA 770.2 480i, 480p, EIA 770.3 720p and i080i (video
standards)
RCA Pin Plug,
When used as Y/Pr/Pb same as component inputs shown above
When used as RGBN&V:
R {red): 700 mVp_p, 75 ohm
G (green - no sync): 700 mVp-p 75 ohm
B (b_ue): 700 mVp_p, 75 ohm
H (horizontam sync): 3 Vp-p +/-i,0v, 2,2k-ohm
V (vertical sync): 3 Vp_p, +/- 1,0% 2,2k-ohm
EIA-770,1 & EIA 770,2 480i, 480p, EIA 770,3 720p and 1080i (video
standards)
Mini_D Sub, 15 pin
VGA (640 x 480), 60Nz
RCA Pin Plug 500mY (fun scale), 43kohm
92
Appendix B: Specifications, continued
Outputs
Video
Video Monitor Output, Qty f
Signal Type
Component Video (Y/Pr/Pb) Qty f set
"OUTPUT to Display"
Video: RCA Pin Pmug f.0 Vp_p, 75 ohm
NTSC 480i onmy for recording onmy
RCA Pin Plug (EIA-770.3 Standard Levels and Timing)
Y: f.0 Vp-p 0ncludes sync), 75 ohm
Pr: 700 mVp-p, 75 ohm
Pb: 700 mVp-p, 75 ohm
EIA-770.f & EIA 770.2, 480p, EIA 770.3 720p and f080i {video standards)
Signal Type
Audio
Monitor Output, Oty f pair RCA Pin Plug, 500 mV rms +_200 mV (full scame) for analog sources.
1.5 V +_0.5 V (full scale) for digital sources.
OUTPUT to Dispmay Qty 2 pair RCA Pin Plug, 500 mV rms +_200 mV (full scame) for analog sources.
f.5 V +_0.5 V (full scale) for digital sources.
Fixed audio ouput when connected to A/V Receiver.
Variabme audio output when connected to monitor.
Video and Audio
HDMI (digital video/audio), Qty f HDMI standard connector
Signal Type HDMI standards for digital audio and video. Not intended for use with
personal computers
Digitam interfaces
Digital Audio Output, Qty i RCA Pin Plug, Signal Type, Domby Digital
IEEE 1394, Qty 3 IEEE 1394 Four Pin type Terminam, S400
Dimensions H 3.4" x W 17' x D f6.8", 27 Ibs.
Power Consumption 82 watts
Net command® IEEE f394 System Compatibimity:
This teBevision is designed to conform to IEEE f394 AV/C Software standards in effect at the time of devemopment. This
exciting new networking and controB technomogy is des{gned to prov{de high-performance digitam connections and
3roduct controm, making the product easier to use.
Mitsubishi D-VHS VCRs are fully compatible with this HDTV receiver/controller in audio, video and control. Many
DV camcorders that have IEEE 1394 connections will be compatibme with the controm features of this HDTV receiver/
controlmer, but not compatible with the audio or video decoder.
As other manufacturers distribute products that use the IEEE f394 AV/C standards, they will be responsibme for
devemoping products that meet the standards of the technomogy, as well as compatibility testing with other products.
Mitsubishi cannot be responsibme for their efforts, and therefore cannot promise compatibility with these other
3roducts. Any compatibimity probmems with other manufacturers products shouM be brought to the attention of those
manufacturers.
The HDMI input is compBiant with EIA=86f£ standards for standard, extended and high definition video, digitat audio
and HDCP copy protection. However, this input is not intended for use with personal computers or devices outputting
video signams with computer resomutions.
93
Appendix C:Remote Contro Programming Codes
Programming the Remote to ControJ
NetCommand A/V Products
1+ Move the siide switch at the top of the HD-6000
remote to the CabHe/DBSiDTV position+
2+ Press and hold POWER on the remote control+
3+ Enter the three digit code of 197, and then release
POWER+
4+ When the remote control is in the CABLEiDBSi
DTV position, it is now programmed to send
NetCommand signals to the HD-6000 so that
it can control the BEEE1394 devices and older
NetCommand supported or learned IR devices+
(This is the default setting for the remote controL)
Programming the Remote to ControJ
Other Brands of Audio and Video
Products
1+ Move the slide switch at the top of the remote to the
product you want to control
2+ Press and hold POWER on the remote control+
3. Enter the first three digit code listed for your
equipment, and then release the POWER button on
the remote control+
4+Point the remote control at the equipment and press
the POWER button+ If the equipment responds, the
remote control is properly programmed to operate
the equipment+ If the equipment does not respond,
repeat steps 2-4 with the next three digit code listed
in step 3 for your equipment+
A/V Receivers
A/V Receiver Brand
MITSUBISHI
AIWA
BOSE
B&K
DENON
FISHER
GARRARD
HARMAN KARDON
JENSEN
JVC
KENWOOD
KLH
KOSS
MAGNAVOX
MARANTZ
MCINTOSH
NAKAMICHI
ONKYO
OPTIMUS
PANASONIC
PARASOUND
PHILIPS
PIONEER
POLK AUDIO
QUASAR
RCA
ROTEL
SANSUI
SHARP
SHERWOOD
SONY
TEAC
TECHNICS
VICTOR
YAMAHA
Code
010, 011,012, 013, 014
225,226,241
351
352
234,235,236,245,246,359,361
2O4
213
215,223,242,362
223_229
232,233
200,208
363
357
227,228
224,350,360
216
206,217
209,214,240, 247
203,227,231,230
219,218,221
356
223,248
205,207
353
219,218,221
203,205,227,231,230
366
203,211,239
234,237
354,355
222,249,364,365
212, 213,211,210
221,218,219
232,233
201,202,243,244
CabMe Boxes
Cabme Brand
ABC
ARCHER
CABLEVEW
CITIZEN
COLOR VOICE
COMTRONICS
CURTIS
DIAMOND
EAGLE
GCBRAND
GE
GEMINI
GENERAL INSTRUMENT/
JERROLD
HAMLIN
HITACHI
MACOM
M AG NAVOX
MOTOROLA
MEMOREX
MOVlETIME
PANASONIC
PARAGON
PHILIPS
PIONEER
PULSAR
RCA
REGAL
REMBRANDT
SAMSUNG
SONY
ZENITH/DRAKE SATELLITE
Code
124
125
105,
122,105
128,129,130,106,107
128,129,130,106,107
112,113
124,125
129
105
112,113
122
121,122
112
103,124
103,104,105,108
128,129,130,106,107,133,138
123,146
130
105,
114
117
138
101,106,116
105
115
112
105,138
105
147,177
100
94
Appendix C: Remote Control Programming Codes,
continued
Cable Boxes, continued
SCiENTiFiC ATLANTA
SIGNATURE
SLMARK
SPRUCER
STARCQM
STARGATE
TELEVlEW
TOCQM
TOSHIBA
UNIKA
UNITED CABLE
UNIVERSAL
VIDEOWAY
VIEWSTAR
ZENITH
112, 113, 194
119,124,125,126,127,120,121,122
105,101
105
119,124,125,126,127,120,121,122
105
101,105
135,136
104
125
119,124,125,126,127,120,121,122
122
106
129,130
117,100
DVD Brand
MITSUBISHI
AIWA
APEX
BOSE
DENON
FERGUSON
HARMAN KARDON
HiTACHi
JVC
KENWOOD
MINTEK
NORDMENDE
ONKYO
ORITRON
PANASONIC
PHILIPS/MAGNAVOX
PIONEER
RCA/GE/PROSCAN
ROTEL
SABA
SAMSUNG
SAMPO
SHARP
SYLVANIA
SONY
THOMSON
TOSHIBA
V iNC. (BRAVO D1)
YAMAHA
ZENITH
Code
003
261,274
266,283
286
250,273
251
282_288
27O
257
271,289
285
251
267,280
263,268
250
258 263 272,290
252
251,266
292
251
261
263
260
264
264,278,279
251
253
291
250,272, 276,287
269
Satellite Receivers/DBS/DTV
DBS Brand
MITSUBISHI
ECHOSTAR/DISH NETWORK
EXPRESS VU
G.E.
HiTACHi
HNS(Huqhes}
JVC (ECHOSTAR}
MAGNAVOX
PANASONIC
PHILIPS
PROSCAN
RCA
SAMSUNG - TERRESTRIAL
SONY
STAR CHOICE
TOSHIBA
UNIDEN
WEBTV
ZENITH/LG
Code
006(same as 173)
175,182,183,188
175
176
173,181,184
173
175
171,172
174
171,172
176,179,180,185
176,179,180,185
192
177
173
170,189,190,191
171,172
187
193
VCRs
VCR Brand
MITSUBISHI
AKAI
AUDIO DYNAMIC
BELL&HOWELL
BROKSONIC
CANON
CiTiZEN
CRAIG
Code
[001,060,
049_ 034,
031
025,
040, 046
043, 046
026
025,049,
067,068,061,062,002
035,036
026
CURTIS MATHES 065,
DAEWOO 063,
DBX 030,
DIMENSIA 065
EMERSON 063,
FISHER 025,
EUNAI 047,
GE 053,
GO VIDEO 057,
GOLDSTAR 026
HiTACHi 043,
iNSTANT REPLAY 044,
JVC 030,
KENWOOD 030,
LXl 047,
MAGNAVOX 051,
MARANTZ 030,
MARTA 026
044,047
021,044,078
031
046,038,039,023,045,062,040
028,029,027
046,040
065,044,079
069,070,071
065,020,047
O43
031,076,077
026,031
026,020,027,028,025,029
043,044
031
MEMOREX
MGA
MINOLTA
MULTITECH
NEC
OLYMPIC
OPTIMUS
ORION
PANASONIC
PENNEY
PENTAX
PHILCO
PHILIPS
PIONEER
PROSCAN
QUASAR
RADIO SHACK
RCA
REALiSTiC
SAMSUNG
SANSUI
SANYO
SCOTT
SEARS
[044,029
[060,067,068,061,062
[020,065
[067,047
[030,031
[044,043
[048,041,055,026
[046,040
[043,044,041,042
[044,020,065,025,030,031
[020,031,065
[051,044,047,043,046,040,063
[051,043,044
043
[
[022,058
[04!,042,043,044
[
i065,066
[044,026,056_029,060,047
[057,022,053
[046,040
[025,029
[021,022,029,060,067,068,046,040
[025,026,027,028,020
SHARP [055,
SIGNATURE 2000 047,
SONY [048,
SV2000
SYLVANIA
SYMPHONIC
TASHIRO
TATUNG
TEAC
TECHNICS
TEKNIKA
TOSHIBA
TQTEVISION
VECTOR RESEARCH
WARDS
YAMAHA
ZENITH
[047
061,
047
026
030,
030,
041,
044,
021,
026
031
055,
025,
064,
O56
O55
049, 050, 073, 074,075
043,044,047
031
047,031
042,043,044
O47
066
056,029,064,026
030,031
026
95
Appendix C: Remote Control Programming Codes,
continued
/MPORTANT
Some manufacturers may change their
products, or they may use more than one
remote controm system. If this is the case,
the HDTV receiver/contommer remote controm
may not be abmeto operate your VCR, DVD,
cabme box, satemmitereceiver, or A/V receiver.
After entering the correct codes in each position of
the remote control, use the slide switch to select
which product will respond when an operational
button is pressed. Only one of the below devices is
allowed for each slide switch position.
TV position:
Mitsubishi TVs
Cable/DBSiDTV position:
HD-6000 HDTV receiver/controller
NetCommand® controlled devices
DVD position:
DVD player
LD player
VCR position:
VCR
o
Audio position:
AiV receiver
DVD player
Cable box
If you have a Mitsubishi AiV receiver, the audio
position may be used in conjunction with select
Mitsubishi CD players. Your audio position must be
programmed to 010.
When your remote control has been programmed to
operate another manufacturer's product, the function
performed on each layer can vary. The most common
functions are:
VCRPOWER
CHANNEL up/down
PLAY
REC
PAUSE
STOP
FFiFWD
REWiREV
Mitsubishi VCRs will be compatible with some
additional buttons
Cabme Boxes and Satellite Receivers
POWER
CHANNEL up/down
0-9 number buttons (on some models)
ENTER (on some models)
CANCEL (on some models)
ADJUST up/down/left/right (on some models)
o GUIDE (on some models)
A/V Receivers
*POWER
VOLUME
MUTE
Mitsubishi A/V Receivers
Direct Input Selection buttons:
numbers, SQV and QV (on some models)
Mitsubishi CD Players
(not aimfunctions for aimmodels}
PLAY
FFiFWD
REWiREV
PAUSE
STOP
DVD and Laser Disc Players
(net all functions for all models)
POWER
MENU
0-9 number buttons (on some models)
PLAY
STOP
ARROW up/down/left/right (on some models)
FF/FWD
REWiREV
PAUSE
CANCEL (on some models)
ENTER
CHANNEL (on some models)
96
Appendix D: On Screen Information Displays
When you turn on the HD-6000, change Devices, change Channels or when you press the INFO
button on the remote control the HD-6000 will display the current status. Below are the most
common displays; please note that seldom or never do all of the different status indicators appear
at the same time.
Analog Program
1. Antenna or Device being viewed
2. Analog channel being received: If antenna being
viewed
3. Channel name (if manually programmed)
4. Signal Type being received
Possible:
Ant-l, Ant-2 or Input 1, 2- 480i
Component 1, 2 - 480i, 480p, 720p or 1080i
Inp-DTV- 480i, 480p, 720p or 1080i
5. Screen format being used
Possible:
Analog 480i/480p signals - Standard, Expand,
Zoom, Stretch, Stretch Plus, Narrow
720p/1080i signals - Standard, Wide Expand
6. Stereo and/or SAP being broadcast
7. V-Chip Ratings
8. Channel in SuperQuickView bank 2
9. Day and Time
10. Sleep Timer remaining time
11. PiP source and channel
12. Special Message Line
(shows only when a special message is
needed)
Digital
1=
2=
3=
Program
Digital Major and Sub channel number
Digital Channel Name (only if broadcast)
Signal Type being broadcast/received
Possible: SD 4:3, SD 16:9 or HD
4. Screen format being used
Possible:
SD 4:3 - Standard, Expand, Zoom, Stretch,
Stretch Plus, Narrow
SD 16:9 or HD- Standard, Wide Expand
5. Language(s) being broadcast
6. Program Name (if broadcast)
7. Special Message Line
(shows only when a special message is
needed)
G
G"
-Ant-1 3 XXXX
.480i Standard -_.__.._ f-.
,Stereo SAP _f 5 )
TV-PG DLSV_
SQV2
,Monday 11:00 AM
Sleep Timer: 30 -----4_
Special Message Line
- t,
Ant=l XXXX=XX
•HD Standard --@
TV-PG DLSV
SQV2
XXXXXXXXXXXXXX
Monday 11:00 AM
Sleep Timer: 30
- Special Message Line
Digital IEEE 1394 Device
1. Status of D-VHS VCR or IEEE 1394 device
2. Counter of D-VHS VCR
3. Media type in D-VHS VCR
4. Special message line
(shows only when a special message is needed;
may be seen with Analog signals)
(_
DVCR
HD Standard
TV-PG DLSV
"Play 01:20:15"
: DVHS
Monday 11:00 AM
Sleep Timer: 30
•Special Message Line
97
Appendix E: NetCommand® Specialized Device Keys
AiV
RECEBVER
X
X
X
X
X
X
X
X
CABLE VCR DVD
or DBS
X X X
X X X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
LEARNING SCREEN
CHECKBOX NAME
Power*
Power (Off)*
Volume Up
Volume Down
Mute
Analog to Digital*
Digital to Analog*
input (1-7)
X
X
Channel Up
Channel Down
Recall
Guide
Adjust Up
Adjust Down
Adjust Left
Adjust Right
Enter
Menu
Cancel
Info
Page Up
Page Down
Play
Stop
Forward
Rewind
Pause
Record
Enter (digits)t
Low Speed Out*
Nigh Speed Out*
1,2,3,4,5,6,7,8,9,0
input
Sub channel separators
Chapter +
Chapter -
FUNCTION
Power On or Power On/Off
Power Off
Volume Up
Volume Down
Mute
Analog/Digita! Switch
Digital/Analog Switch
AVR input Select
Channel Scan Up
Channel Scan Down
Last Channel RecalI
Guide
Arrow/move Up
Arrow/move Down
Arrow/move Left
Arrow/move Right
Enter/Select
Device Menu or Setup Menu
Cancel or Exit
Status information Display
Guide Page Up
Guide Page Down
Play
Stop
Fast Forward/Fwd Search
Rewind/Reverse Search
Pause
Record
Enter for channel numbers
LowSpeed 480i out
Hi Speed 480p/1080i out
1,2,3,4,5,6,7,8,9,0
input Change
Digital Sub channel
Chapter Skip Forward
Chapter Skip Reverse
NAME ON TV
REMOTE
POWER**
POWER**
VOL A
VOL •
MUTE
GUIDE**
GUIDE**
Automatic (when
device is selected)
CHAN •
CHAN •
QV
GUIDE
ADJUST •
ADJUST •
ADJUST
ADJUST _,
ENT
DEVICE MENU
CANCEL
INFO
CHAN • ***
CHAN • ....
PLAY
STOP
FF
REW
PAUSE
REC
ENT
FORMAT**
FORMAT**
1,2,3,4,5,6,7,8,9,0
GUIDE**
CANCEL
CHAN •
CHAN •
* These are paired functions (e.g. Power and Power Off). When the original remote control uses a single button for both functions, learn only the
first of the paired functions.
If there are two Enter keys, learn the Enter key used for channel selection here. The ENT button on the remote sends the correct IR code
when digits are entered.
$Learn the subchannel separator ira special key is used to add a separator (dash or dot) in a digital channel. Press the CANCEL button on the
remote to add the separator
** This function is performed only when the Device Selection Menu is displayed and the device icon is highlighted.
*** Channel Up/Down as Guide Page Up/Down happens only after pressing GUIDE and returns to channel functions after pressing ENTERor
CANCEL.
98
Appendix F: C eaning and Service
Service
Normally, light dusting with a dry, non-scratching
duster wiii keep your HDTV Receiver clean. If cleaning
beyond this is needed, please use the following
guidelines:
First, turn off the HDTV Receiver and unplug the
power cord from the power outlet.
Front, Top and Sides of the HDTV Receiver:
Gently wipe down your HDTV Receiver with a
soft, non-abrasive cloth such as cotton flannel
or a clean cloth diaper, lightly moistened with
water. Dry with a second dry, soft, non-abrasive
cloth.
For oily dirt, add a few drops of mild liquid
detergent, such as dishwashing detergent to
the water used to moisten the cloth. Rinse with
a second cloth moistened only with water. Dry
with a third dry, soft, non-abrasive cloth.
If you are unable to correct a problem with your HDTV
Receiver, consult your Mitsubishi dealer or a Mitsubishi
Authorized Warranty Service Center.
DO NOT adjust any controls other than
those described in this Owner's Guide.
o DO NOT remove the protective cover of your
HDTV Receiver.
Menus not described and shown in this owner's
guide are designed for Factory use and for
Authorized Service Personnel, Damage caused to
the HDTV Receiver by non=authorized changes or
changes to these menus made by non-authorized
persons are not covered under warranty.
General Cleaning Warnings:
DO NOT allow liquid to enter the HDTV
Receiver through the ventilation slots or any
crevice.
DO NOT use any strong or abrasive
cleaners as these can scratch the surfaces.
DO NOT use any cleaners with ammonia,
bleach, alcohol, benzine, or thinners as
these can dull the surfaces.
DO NOT spray liquids or cleaners directly
on the HDTV Receiver's surfaces.
DO NOT scrub or rub the HDTV Receiver
harshly. Wipe it gently.
IMPORTANT
For further information, call Consumer
Relations (800} 332=2119.
99
Appendix G: Input Sources and Scan Rates
HDMI/DVJ Monitor
Output Scan Rate
ANALOG
480i signals from
Ant-l, Ant-2, hput- 1, 2
480i signals from
Ant-l, Ant-2, hput- 1, 2
480i, 480p signals from
Component 1 & 2
480i, 480p signals from
Component 1 & 2
480i, !080p component
signals from hput DTV
480i, 480p component
signals from hput DTV
480i, 480p, 1080i, 720p
RGBHV signals from
hput DTV
1080i, 720p component
signals from hput DTV or
Component 1, 2
DIGITAL
Copy
Protection
none
yes
Done
yes
Done
yes
none
does not
apply
HDCP
1080i
Monitor
1080i
1080i
1080i
1080i
1080i
1080i
1080i
1080i
480i or 480p signals none 1080i
from Ant-1 or EEE 1394
480i or 480p signals from yes 1080i
Ant-l, Ant-2 or IEEE 1394
720p signats from none 1080i
Ant-l, Ant-2 or EEE 1394
720p signals from yes 1080i
Ant-l, Ant-2 or EEE 1394
1080i signals from none 1080i
Ant-l, Ant-2 or EEE 1394
1080i signals from yes 1080i
Ant-l, Ant-2 or EEE 1394
HDMI input yes or none 1080i
Non =
HDCP
1080i
Monitor
1080i
none
1080i
none
1080i
none
1080i
1080i
1080i
none
1080i
none
1080i
none
none
HDCP
720p
Monitor
720p
720p
720p
720p
720p
720p
720p
720p
720p
720p
720p
720p
720p
720p
720p
Non-
HDCP
720p
Monitor
720p
none
720p
none
720p
none
720p
720p
720p
none
720p
none
720p
RODe
none
HDCP
480p
Monitor
480p
480p
480p
480p
480p
480p
480p
480p
480p
480p
480p
480p
480p
480p
480p
Non =
HDCP
480p
Monitor
480p
none
480p
none
480p
none
480p
480p
480p
none
480p
none
480p
none
none
100
Appendix G: Input Sources and Scan Rates
Scan Rate
YPbPR or HD Monitor
Output Scan Rate
mnput Signam Source copy
Protection
1080i
Monitor
720p
Monitor
480p
Monitor
ANALOG
480i signais from Ant-l, Ant-2, Input- 1, 2 none 1080i 720p 480p
480i signals from Ant-l, Ant-2, Input- 1, 2 yes none none 480p
480i, 480p signals from Component 1 & 2 none 1080i 720p 480p
480i, 480p signals from Component 1 & 2 yes none none 480p
480i, 1080p component signals from Input DTV none 1080i 720p 480p
480i, 480p component signals from Input DTV yes none none 480p
480i, 480p, 1080i, 720p RGBHV signals from none 1080i 720p 480p
Input DTV
1080i, 720p component signals from Input DTV or Component 1, 2 does not apply 1080i 720p 480p
DIGITAL
480i or 480p signals from Ant-1 or EEE 1394 none 1080i 720p 480p
480i or 480p signals from Ant-l, Ant-2 or IEEE 1394 yes none none 480p
720p signals from Ant-l, Ant-2 or IEEE 1394 none 1080i 720p 480p
720p signals from Ant-l, Ant-2 or IEEE 1394 yes none none 480p
1080i signais from Ant-l, Ant-2 or IEEE 1394 none 1080i 720p 480p
1080i signals from Ant-l, Ant-2 or IEEE 1394 yes none none 480p
HDMI input yes or none 480p 480p 480p
Video Output
VCR or Non-HD Monitor
Output Scan Rate
mnput Signal Source copy
Protection
Scan Rate
ANALOG
480i signals from Ant-l, Ant-2, Input- 1, 2
480p signals from Component 1 & 2
480i or 480p RGBHV signals from Input DTV
1080i component signals from Input DTV
1080i RGBHV signals from Input DTV
DIGITAL
yes or none
yes or none
yes or none
does not apply
does not apply
Video Output VCR or Non-HD
Monitor
480i
none
none
none
none
480i or 480p signals from Ant-l, Ant 2 or EEE 1394
480i or 480p signals from Ant-l, Ant 2 or IEEE 1394
720p signals from Ant-l, Ant 2 or EEE 1394
720p signals from Ant-l, Ant 2 or EEE 1394
1080i signals from Ant-l, Ant 2 or EEE 1394
1080i signals from Ant-l, Ant 2 or EEE 1394
none
yes
DOne
yes
node
yes
480i
480i
480i
480i
480i
480i
101
Troubleshooting
1. The HD-6000 remote control does not work.
2. The HD-6000 takes several seconds to respond.
3. Cable provider needs information to start
CableCARD TMservice.
4. You cannot access a channel.
5. On-screen displays appear each time you
change a function.
6. You cannot program the HD-6000 to turn on
automatically (timer function)
7. There is no sound even when the volume is
turned up.
8. NetCommand unable to learn specific device
keys.
9. You have forgotten your V-Chip passcode.
10. PIP does not display a picture.
11. Digital channels do not appear in PIP.
12. Not all channels appear in multiple PIP/POR
13. The sound does not match the screen picture.
14. There is a large black or gray rectangle on the
screen,
1E You cannot see a picture when playing a VHS
tape.
16. V-Chip is not working.
17. The HD-6000 will not turn on after being
plugged in.
PossibJe Solution
Check that the batteries are installed correctly.
Check that the selected switch is set to CABLE/DBS/DTV.
Be within 20 feet of the HD-6000 when using the remote control.
Program the remote control to operate the HD-6000 (Appendix C).
®It is normal for digital channels to take longer to tune in.
®Press ENTER after a channel number to avoid delays.
Use a 4 digit number for an over-the-air digital channel
®Use a 6 digit number for cable digital channels
® On the remote control, press TV MENU and then enter the numbers
999 to display the Host ID and CabbCARD TMID information.
®Use number key's instead of CHANNEL up/down.
®Be sure the channel you want to view is in memory. See page 72.
®Check that the HD-6000 is turned to the correct device or antenna for
that channel, by pressing the DEVICE button.
®Make sure the V-Chip lock is off.
®if tuned to digital channels, have physical channel in memory.
®This is part of normal the HD-6000's operation.
®The HD-6000 may be locked.
®The clock may not be set.
®Check audio source in Device Menu.
®Check to see if the MUTE button is on.
®The HD-6000's "Listen to:" setting may be set to SAP.
if you are listening through a DVl device, check that the analog audio
has been connected to the HD-6000 and your DVl device.
®Device does not use IR format for remote control signal. ITT and
RF formats cannot be learned.
®Room lighting may affect the signal. Have the remotes very close
(6 inches or less) to the HD-6000 during Learning.
®if using a Mitsubishi remote control, make sure the slide switch is not
set to the CABLE/DBS/DTV position.
®Some but not all device key' functions can be learned by
NetCommand. For example, POWER and PLAY may be learned,
but other functions may not.
®The signal from the remote control may not be strong
enough, insert fresh batteries and try Learning again.
®See Appendix A, Bypassing the V-Chip Lock.
®Make sure the V-Chip lock is off.
®Not all inputs can be displayed as a PIP.
® Normal PiP operation.
® Digital channels do not display in PIP/POR
®NetCommand@ is setup incorrectly.
The HD-6000's "Listen to:" setting may be set to SAP.
®if using stereo or A/V receiver speakers, check their input selection.
®if using stereo or A/V receiver, check that AUDIO 2 of MONITOR
OUTPUT on HD-6000's back panel is connected to the A/V receiver.
®The HD-6000's analog closed captioning has been set to "text" mode
in the Captions menu. Turn off because there is no text information
being broadcast.
Display the Device Selection menu and select the correct VCR.
®Check your VCRs owner's guide for further trouble shooting.
®Make sure that V-Chip is On.
®if V-Chip Hours are currently set to disable the V-Chip lock, the
V-Chip will not block programming.
if blue light on front panel is blinking, wait for at least one
minute for the light to turn off, then press Power again.
102
TroubJeshooting, continued
PossibJe SoJution
18. HD-6000 functions do not respond to the ®Use the System Reset button as explained at the end of this
remote control or to front panel control and will section.
not Power Off.
19. Name options not available for some channels _ Only memorized analog channels can be named.
20. When viewing a stopped VCR, white lines are
rolling on the screen.
21. HD-6000 turned itself Off and the Jight on the
front paneJ started to blJnk.
22n
23n
24n
When a Device is selected from the Device
Selection menu, the screen is blue
(no signal source).
The Device does not respond to button presses
from the remote.
The A/V Receiver is the selected audio source
but there is no sound.
25. The TV Speaker icon or A/V Receiver icon is
grayed out and not selectable.
26. Devices are grayed out in the Device Selection
menu or the PIP Selection menu.
27. Cannot see the A/V Receiver menu.
28. Screen is black when trying to view digital
channels or IEEE 1394 device.
®Turn off video mute for the VCR.
Begin playing the tape.
®Change the VCR input to the antenna input.
Momentary power fluctuation caused theHD-6000 to turn off to
prevent damage. Wait for the blue light to stop flashing and turn On
again.
If the HD-6000 does not stay turned On, use the System Reset
button. If this happens frequently, obtain an AC line power
conditioner/surge protecton
®Make sure the selected device is turned on.
®From the Edit NetCommand® menu select Review. Verify that
the inputs are actually connected to the HD-6000. If they are not,
either change the physical connections on the back panel, or select
the Change on the Edit NetCommand menu to change the
HD-6000 NetCommand's settings for the connection or connection
screen for each device.
Remote has not been setup for NetCommand ® use.
®The incorrect manufacturer was selected during setup.
Select the Change setting from the Setup menu and then the device
to display the manufacturer selection. Change if necessary.
®The device is not supported and keys have not been learned.
The requested function is not supported by NetCommand.
Verify that the function is supported or keys are learned.
®The IR emitter is incorrectly placed. Make sure the IR emitter is
facing the IR sensor in the device.
®The IR emitter is not plugged into the IR emitter Output
NetCommand.
®The IR emitter is facing the HD-6000, causing double signals. Be
sure that the IR emitter cannot send to the HD-6000.
®Check to see if the A/V Receiver power is turned on. After the power
is turned on, redisplay the Device Selection menu and press ENTER
to al!ow NetCommand to correctly select the A/V Receiver input.
®From the NetCommand Menu select Review. Check the Review
screen to see if the A/V Receiver inputs and device correspond to the
actual connections on the A/V Receiver. If they do not match, either
change the actual connections, or select Change on the Edit
NetCommand menu to change the input on the Connection screen.
®Select the Change setting from the Edit NetCommand menu, and
then select the device (for example VCR). Once the Connection
screen is displayed, check if the audio checkbox is selected for the
TV input and/or AVR input.
A recording is in progress requiring the use of Monitor Out. Cancel
the recording to select the device.
®Digital channels and media cards cannot display in the PIP or POR
The A/V Receiver is not connected to any input of the HD-6000. To
check the A/V Receiver menu temporarily plug into an unused input
of the HD-6000. Then select Review from the NetCommand Menu,
turn the input On to view the A/V Receiver menu.
® The PerfectColor rM color balance has been incorrectly set. Use the
Setup menu to reset the color balance.
103
TroubJeshooting, continued
PossibJe SoJution
29n The REC button is not working, or, on the
Transport menu the record key is grayed out and
not availabJe.
30. A program recorded on your HD-6000 is
distorted when played on a 4:3 TV.
31. Excessive digital artifacts.
32. DVCR analog/digital problems.
33. D-VHS recordings for digital cable have drop-
outs (loss of picture or sound), or no playback.
34. There is no audio and video from the HEEE1394
device.
35n The EEE 1394 Device is not listed in the Device
SeJection menu.
36. The HEEE1394 device cannot be selected.
37. DEVHCE MENU button does not display a menu.
38. AIJ HEEE1394 devices disappear.
39. Cannot rediscover a deleted HEEE1394 device
The device does not support recording, such as a DVD player.
®Recordings can not be initiated from the Transport menu when
using an IEEE 1394 device. Press REC instead. The Record
menu displays allowing setup of a recording.
®HD-6000 was set to Anamorphic when program was recorded.
Record programs in Cropped mode if playing back on a 4:3 TV.
®The EEE 1394 cable is too long (15 feet between devices is the
maximum length).
®There may be a slow device in the middle of the EEE 1394 network.
Move the slow devices to the end so that connections for faster
devices do not pass through them.
® If the tape is currently playing but no picture displays, there may be a
mismatch of the media with the display. Press DEVICE to
display the Device Selection menu. Press ENTER for the DVCR
device. If dJgitaI is selected, try analog, or if analog Jsselected, try
digital.
®DigitaJ cable signals on EEE 1394 can exceed the data rate
standards supported by DVCR.
®The device is not turned on - turn the device power on.
No media (tape or disc) is inserted into the device.
®The media is blank (has no recording).
®The play command failed - Try pressing play again on the device's
remote control or front panel.
®The device is already in use (for example: the device is currently
recording).
®The source is copy-protected or violates copy protection.
, The device's digital video signal is not supported by the TV, such as
DV video, common with camcorders. Use analog connections
instead, if available.
The device is not an audio/video device.
®Too many other devices are already communicating over EEE 1394.
Remove or stop some devices and try again.
®The device is unchecked in the Review screen. Select the
NetCommand menu. Through Review, verify the device is checked.
The EEE 1394 plug is disconnected or loose.
®The EEE 1394 Device has not been powered On. Turn on.
®The device has not been discovered.
The device is not an Audio/Video device
®The device may be busy, either recording or a peer-to-peer
connection has been established. Cancel the recording or
peer-to-peer connection.
®The IEEE 1394 device does not provide a menu.
® The TV cannot support EEE 1394 menus. See page 46.
®The connected devices must not be in a loop that returns to the
HD-6000. Make sure a device is connected at the end.
®Disconnect all the cables and devices from the TV. Replace them one
by one to locate the problem device or cable.
®Use System Reset (front controJ panel).
®The device has been disconnected. Plug it in.
The device ls unchecked in the Review screen. Select NetCommand
from the Main menu, then select Review. Check the device.
®Remove EEE 1394 plug. Go to the Edit NetCommand menu. Delete
the EEE 1394 device. Plug the device in again so it can be
discovered again.
104
Troubleshooting, continued
PossibJe SoJution
40,
41,
An IEEE 1394 device has been plugged in but
does not appear in the Device Selection menu
(not discovered).
Cannot record to or from the IEEE 1394 device,
including Dub recordings.
42. Cannot control the IEEE 1394 device from the
Transport Menu.
43. When ChannelView rM list is displayed,
information appears incomplete
44. Program to be recorded was correctly selected ® The broadcaster supplied program information that was incorrect
from ChannelView, however, incorrect program and/or was changed after a recording was added to the Record List.
was recorded.
45. incomplete ChannelView program recorded.
46. ChannelView program recording failed.
®The IEEE 1394 connection to the HD-6000 or another device is not
secure or is loose.
The IEEE 1394 device is not powered on.
®A device in the IEEE 1394 chain is not powered on - turn on all the
devices.
The device discovery can take as long as a minute to initiate.
® IEEE 1394 cable is too long (maximum of !5 feet between devices).
®The IEEE 1394 device uses an incompatible protocol and will not be
discovered
®To initiate a recording to IEEE 1394 device press the REC key.
The Record menu displays allowing setup of the recording.
®The source device for the recording is not powered on.
®When dubbing, the destination device for the recording
is not powered on.
®The wrong media, (analog tape for digital recording, or
digital tape for the analog recording) is in the device.
®Either the program is copy protected, or if there are multiple
subchannels and one of the programs (not necessarily the
program requested) is copy protected.
®The program has already been recorded once and the copy
protection only allows one recording.
Unapproved source device for copy protected material.
®The recording device can not decode the copyright signal
included in the signal source (try another device if available).
®The playing device (for dubbing) does not support
copyrighted material.
Source for recording is copyrighted.
®Too many IEEE 1394 devices in network, insufficient
bandwith available. Disconnect unused devices.
®Source Device has higher speed (S 400) than record device, if
possible, reverse devices, play in the slower device and record
in the faster device.
®Device may not support the command.
Selected function is gray (such as Record for a DVD, which does not
support the Record function).
® Available information is sent from the broadcaster or cable provider.
No other data is available.
47. HD-6000 is not responding, after pulling out a
Memory card during playback with the LT-4260.
48. Can't see a thumbnail picture in the JPEG ® File does not meet file standards for playback.
menu, or can't see a track/song name in the
Playlist menu.
49. See on screen message "TV Disc is full..." ®Some recording(s) on the Track List need to be deleted. Press
DEVICE to display the Device Selection menu, then select TV
Disc. Press GUIDE to display the track list. Highlight program(s) to
delete and press CANCEL twice to confirm.
Recording device may have lack of space availability and there is not
enough blank space to make a full recording.
Connection and compatibility issues with IEEE 1394 (FireWire@)
digital devices. This may include too many Firewire devices in use at
one time, or the recording device not understanding the record
command.
®HD-6000 lost power long enough to lose current clock time.
®Analog VCR power was left Off.
® Press STOP or wait until playback is complete before removing
media card.
105
Troubleshooting, continued
PossibJe SoJution
50. TV PAUSE does not start when the PAUSE key
is pressed.
If there is a fulI screen pause without a slider appearing, then TV
Pause is off. Go to the Setup menu and change the TV Pause
setting from Off to Always or On Request. Press Pause.
TV Pause needs to be restarted. Press DEVICE to display the
Device Selection menu and press ENTER. Press Pause.
Power the HD-6000 off and then on. Press Pause.
Can't use TV Pause while recording an analog program.
See Reset Menu instructions at the end of the Troubleshooting
guide.
, _ TV Pause is not available when PIP/POP is displayed.
51. When viewing a PC screen on the LT-4260 with _ Turn the PC Power Saver to Off, to prevent the LT-4260 and HD-6000
PC Power Saver turned On, the LT-4260 and turning off.
HD-6000 turn off.
Using The System Reset Button
If the HD-6000 doesn't respond to either the
remote controi or the front panei controis or wiii
not power off, press the SYSTEM RESET button
on the front panei with a pointed item such as the
point of a bah point pen or end tip of a paperciip.
The HD-6000 wiii turn off and the blue led wiii flash
quickly for about one minute. When the blue led
stops flashing, you may turn on the HD-6000 again.
The changes you made whiHethe HD-6000 was
most recently on, before you used the SYSTEM
RESET button may lost, however, the changes you
made previously are not IosL Only those changes
since the last power On may be lost when the
system reset button is pressed. Aii other settings
are retained.
Using the Reset Menu for Reset
of the HD-6000 or TV Disc
Press TV menu followed by 1,2,3 to see the RESET
SERVICE MENU to reset the HD-6000 or TV Disc.
Select a device other than TV Disc before using this
menu.
Read on-screen warnings before
proceeding, as some user data or
settings may be erased.
Your choices are:
OP
2.
Reset System Defaults (CAUTmON: All settings,
except V-Chip, wiii be reset to the original
factory defaults).
Erase TV Disc (CAUTION: Track List wiii be
cleared).
3. Reformat TV Disc (CAUTION: Track List wiii be
cleared).
4. Reset TV Disc (Track List wiii not be affected).
106
Additional Information
UCENSOR'S SUPPLIERS DO NOT MAKE OR PASS ON TO END USER OR ANY OTHER THIRD PARTY,
ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY OR REPRESENTATION ON BEHALF OF SUCH
SUPPMERS, INCLUDING, BUT NOT LIMITED TO THE IMPLIED WARRANTES OF NONqNFRINGEMENT, TITLE,
MERCHANTABIMTY OR FITNESS FOR A PARTICULAR PURPOSE
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for
home and other limited pay-per-view uses only unless otherwise authorized by Macrovision. Reverse engineering or
CableCARD TMis a trademark of Cable Television Laboratories, Bnc.
HDMF Mthe HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
Manufactured under license from Dolby Laboratories. Dolby@ and the double-D symbol are registered trademarks
of Dolby Laboratories.
Lifestyle@ 28 is a trademark of the Bose Corporation.
XBox TMis a trademark of the Microsoft Corporation.
Playstation@ 2 is a trademark of the Sony Corporation.
This product includes technology owned by Microsoft Corporation and cannot be used or distributed without a
license from Microsoft Licensing, Inc.
MultiMediaCard TMis trademark of Infineon Technologies and licensed to the MultiMediaCard Association.
SmartMedia TMis a trademark of Toshiba Corp.
CompactFlash@ and CF are trademarks of the CompactFlash Association.
MEMORYSTICKTMis a trademark of Sony Corp.
DTVUNK TMCertification Logo is a trademark of the Consumer Electronics Association.
DCR TMCertification Logo is a trademark of the Consumer Electronics Association.
Firewire@ is a trademark of Apple Computer, Inc. registered in the U.S. and other countries.
MonitorLink TM,NetOommand@, ViewPoint@, QuickView TM,SuperQuickView TM,PerfectColor TM, MediaCommand TM
and ChanneIView TM are trademarks of Mitsubishi Digital Electronics America, Inc.
WARNING: This product contains chemicals known to the State of California to cause cancer and/or birth defects
or other reproductive harm.
107
A
AN
Add
Disc Search 62
Memory Reset 80
Receiver, add 45-47
Reset 12
Setting Descriptions 81-82
Audio 81
Video 82
A/V Receiver 45-47
Devices 48-51
Audio Settings 81
Antenna 14
Menu 68, 72
AudioVideo Menu 68, 80
B
Back Panel Inputs 13-14
Bypassing the V-Chip Lock 89
C
Cab[eCARD TM 14
Inserting 17
TechnoHogy 18
Captions Menu 68, 75-76
Change Device 52
Channel 72, 74
Memorize 72
Name 72
ChannelView 59
Cleaning and Service 99
Color Balance, Setting 69
Connecting
A/V Receiver 22
CabHeBox 17, 21
Component 1, and 2 Inputs with YPbPr 14, 26
Computer with a PC Monitor Output 23
DigitaHAudio Output 14
DispHayMonitor with Component Video 26
DTV Receiver with
Component Video 24
RGB, HV Video 25
DVD Hayer with Component Video 26
DV[ Device with AnaHogAudio 13, 28
ExternaH Devices & NetCommand 16
HeHpfuHHints 34
HDM[ Device 13, 27
[EEE 1394 Devices 14, 32-33
[R
Emitters 30
Sensor 3I
108
Lead Antenna 19
LT-4260 LCD TV 29
M(onitor)-Link ControH 23
S-Video 22
SateHHiteReceiver 22
Separate UHF and VHF Antenna 19
Stereo System 22
VCR 20, 21
VVaHHOutlet CaMe 17, 20
Copy-Protected Materia[ 63
Current Recordings, canceHHing 61
D
Daylight Savings Time, setting 74
Device
Add 48-51
Advanced Learn Screen 50
Change 52
Connection for, Screen 50
ControH with Net Command® 87-88
DeHete 52
[R ControHHed 59
Learn Screen 49
Menu 58
Name Screen 50
Screen 49
Setup 43
Device Menu Button to DispHay Menus 58
Device SeHection Menu 57, 59
Audio 81
Output 14
Record Device 71
Prefer, Setting 72
DispHay Formats 85-86
DispHay Monitor with Component Video 26
DTV Connectors and Adaptors 24
DVD Format Definitions 85
DV[ AnaHog Audio 13, 28
Finish Screen 44, 47, 52, 56
Front Button Lock 78
Front Centre[ Pane Indicators 12
G
GUIDE Button to DispHayChanne[View TM and Menus 59
H
HDM[ 15
Connecting to
Display Monitor 27
DV[ Device 28
Source Device 27
iconOrder,Viewing,Changing71
IEEE1394
AddingAutomatically55-56
andNetCommand®Control54
CompatibleDevices32
DeviceTypeScreen56
Name53
importantSafeguards6-7
indicators,frontpanel 12
informationDisplays,On-Screen97
inputConnectionCompatibility91
DTV14,51
SourcesandScanRates100,101
IREmittePNetCommand@13,30,31
JPEG Picture Thumbnail Menu 65
L
Language selection 43, 69, 81
LT-4260 LCD W
Connecting 29
Media Card Playback 65-66
M
M(onitor)-Link 14, 23
Media Card use with LT-4260 13
Playback 65-66
USB Port 14
Memorize Channels 72
Monitor Output 14, 23,
MP3 Playlist Menu 66
N
NetCommand@ 11
Edit 45-52
InformationScreen 43
Initial Setup 43-44
Menu 68, 71
On Screen Buttons 41
Peer-to-Peer Connections 61
Specialized Device Keys 98
Time-Delayed Recording 60
P
PC 13, 23, 64
PerfectColor TM (Manual Color Balance ) 69
PiP/POP
Device Selection Menu 57
Operation 84
Power indicator Light 12
R
Recording Now 60
Record To
List 61
Setup 60
Remote Control
Battery Installation 40
Buttons 39, 40
Care 40
Functions 39-40
with NetCommand@ 38
Programming to Control A/V Products 94-96
Transport Buttons 71
Reset
Coior 69
Menu 106
Review Screen 44
RF Connection for Cable Screen 51
S
Setting the Clock 74
Setup Menu 68, 69-70
Sleep Timer 40
Software version 70
Specifications 92-93
SQV (SuperQuickView TM) 73
Stationary Picture Warning 36
System Reset Button 12, 106
T
Time Menu 68, 74
Time Zone Selection 74
Timer On/Off setting 74
Track List Screen 62
Transport Menu 71
Troubleshooting 102-106
TV Disc 11
Archiving 62
TV Pause 69-70
V
V-Chip Lock Menu 68, 77-79
Exceptions 77
Passcode 78, 79, 89
Ratings Guideline 77
VCR
Video
Video
W
Connecting 20, 21
Recording 63
Restrictions for Traditional 63
Mute 80
Settings 82
Welcome Screen 43
WMA7 Playlist Menu 66
109
MITSUBISHI HDTV Receiver!Controller SOFTWARE
END-USER LICENSE AGREEMENT FOR EMBEDDED SOFTWARE
IMPORTANT - READ CAREFULLY: This License Agreement is a legal agreement between you (either an individual or an entity) and
Mitsubishi Digital Electronics America, Inc. (MDEA) for all software preinstalled and/or provided along with this HDTV Receiver/Controller
("Software"). By utilizing this receiver and Software, you agree to be bound by the terms of this License Agreement.
The Software is protected by United States copyright laws and international treaty provisions, as well as other intellectual property laws and
treaties. The Software is licensed, not sold.
1. UCENSE GRANT. MDEA grants you a non-exclusive, non-transferable, limited right and license to use one copy of the Software only
with the Mitsubishi HDTV Receiver/Controller model that included this owner's guide and owned by you.
2. RIGHTS AND LIMITATIONS.
Software Not for Resale. You may not resell or otherwise transfer for value the Software, except in conjunction with a sale of the HDTV
Receiver/Controller that Software has been preinstalled.
Prohibition on Reverse Enqineering, Decompilation and Disassembly. The Software contains trade secrets or other proprietary material in its
human perceivable form and to protect them, you may not reverse engineer, decompile, or disassemble, or otherwise reduce the Software to
any human perceivable form, except to the extent that the foregoing restriction is expressly prohibited by applicable law.
Separation of Components. The Software is licensed as a single product. Its component parts may not be separated for use on more than
one HDTV Receiver/Controller.
No Rental. You may not rent, lease, lend, or sublicense the Software.
Trademarks. This License Agreement does not grant you any rights to any trademarks of MDEA.
3. VIOLATIONS. You understand that any use, copying or transfer of the Software, except as permitted pursuant to this License, may
subject you to serious criminal and civil penalties including damages and an award to MDEA of attorneys' fees in connection with any
violation of this License. You further understand that you may be held legally responsible for any copyright infringement or other violation
of intellectual property rights that is caused, encouraged, or induced by your failure to abide by the terms of the License. This license
is effective until terminated, and will terminate immediately without notice from MDEA or judicial resolution if you fail to comply with any
provision of this License.
4. COPYRmGHT. All title and intellectual property rights in and to the Software (including but not limited to any images, photographs,
animations, video, audio, music, text, and "applets" incorporated into the Software), and any accompanying printed materials are owned by
or licensed to MDEA. All title and intellectual property rights in and to the content which may be accessed through use of the Software is the
property of the respective content owner and may be protected by applicable copyright or other intellectual property laws and treaties. This
License Agreement grants you no rights to use such content, except that you own the media on which the Software is recorded, but MDEA
and its licensors retain ownership of the Software itself. All rights not expressly granted are reserved by MDEA.
5. EXPORT RESTRICTIONS. MDEA is licensing the Software for use within the United States. You agree that you will not export or
re-export the Software. You specifically agree not to export or re-export the Software: (i) to any country to which the U.S. has embargoed
or restricted the export of goods or services, which currently include, but are not necessarily limited to Cuba, Iran, Iraq, Libya, North
Korea, Sudan, and Syria, or to any national of any such country, wherever located, who intends to transmit or transport the Software back
to such country; (ii) to any person or entity who you know or have reason to know will utilize the Software in the design, development, or
production of nuclear, chemical, or biological weapons; or (iii) to any person or entity who has been prohibited from participating in U.S.
export transactions by any federal agency of the U.B. government. You warrant and represent that neither the RXA nor any other U.S. federal
agency has suspended, revoked, or denied your export privileges.
6. DISCLAIMER OF WARRANTY. EXCEPT AS OTHERWISE PROWDED IN THIS UCENSE OR IN THE UMITED WARRANTY
APPLICABLE TO THE HDTV RECEIVER/CONTROLLER, MDEA MAKES NO OTHER WARRANTIES OF ANY KIND WHATSOEVER
REGARDmNG THE SOFTWARE AND HEREBY EXPRESSLY DISCLAIMS ALL WARRANTIES OF ANY KIND WHATSOEVER, EXPRESS
OR iMPLIED, WITH RESPECT TO THE SOFTWARE. ALL IMPUED WARRANTIES, mNCLUDING, WITHOUT UMITATION, THE IMPLIED
WARRANTIES OF MERCBANTABlUTY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXPRESSLY DISCLAIMED BY
MDEA. mNNO EVENT SHALL MDEA BE LIABLE TO YOU OR ANY THIRD PARTIES, IN CONTRACT, iN TORT OR OTHERWISE, FOR
ANY DIRECT, INDIRECT, SPECIAL, iNCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KiND OR NATURE. BECAUSE SOME
JURISDmONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES, THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
7. UMITATiON OF UARlUTY. MDEA SHALL NOT, UNDER ANY CIRCUMSTANCES BE LIABLE TO YOU OR ANY THIRD PARTIES
FOR ANY DAMAGES OF ANY NATURE, WHETHER INDIRECT, SPECIAL, INCmDENTAL, CONSEQUENTIAL OR OTHERWISE,
INCLUDmNG, BUT NOT LIMITED TO, ANY CLAIMS FOR LOST PROFITS, LOSS OF GOOD WILL OR EXPENDITURES MADE OR
COMMITTED FOR IN REUANCE ON THE CONTINUATION OF THinS UCENSE. YOU AGREE THAT NEITHER MDEA'S BREACH OF
THS UCENSE NOR ITS FAILURE TO REPAIR A DEFECT, ERROR OR BUG SHALL CONSTmTUTE A FAILURE OF THE ESSENTIAL
PURPOSE OF THinS UCENSE. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR UMITATION OF LIABlUTY
FOR CONSEQUENTIAL OR INCIDENT_AL DAMAGES, THE ABOVE UM_TAT_ONS MAY NOT APPLY TO YOU. MDEA's HabiHty to you
for direct damages for any cause whatsoever and regardless of the form of the action, will be limited to the money paid by you for
the HDTV Receiver/Controller (based on fair market value of the HDTV Receiver/Controller} that caused the damages.
8. GENERAL. This License Agreement will be governed by the laws of the State of California.
110
MITSUBgSHI HDTV RECEIVER/CONTROLLER LiMiTED WARRANTY
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. ("MDEA') warrants to the original purchaser of this HDTV receiver/controller that if purchased
from an authorized MITSUBISHI Audio/Video Dealer, should it prove defective by reason of improper worknTanship and/or material:
a. Parts. All parts (except any software incorporated into this HDTV receiver/controller) are warranted for a period of one year from the date
of the original purchase at retail. We will repair or replace, at our option, any defective part without charge for the part. Parts used for replacement
may be replaced with those of like kind and quality and may be new or remanufactured. Parts used for replacement are warranted for the remainder
of the original warranty period.
b. Embedded Software. MDEA warrants that all software incorporated into this HDTV receiver/controller (the "Embedded Software") will
perform in accordance with the functional description of Embedded Software in all material respects, but MDEA does not warrant that the Embedded
Software is error-free. MDEA also does not warrant that the Embedded Software will be compatible under EEE 1394 AV/C and HAVi software
standards with products produced by any other manufacturer. The warranty contained in this section shall continue for a period of one year, from the
date of the original purchase from the dealer. If, after prompt notice within the warranty period, MDEA determines that the Embedded Software has
failed to perform in accordance with such functional description in all material respects and if such failure is not due to accident, misuse, modification
or misapplication of the Embedded Software, then MDEA shall modify or replace the nonconforming Embedded Software at no charge to you,
which at MDEA's sole discretion may be fulfilled by means of modification or replacement software contained on a replacement memory card for
Customer installation. The foregoing shall be MDEA's sole obligation to you under this limited warranty. All rights under this limited warranty on the
Embedded Software also subject to your compliance with the terms of the Software License Agreement applicable to this HDTV receiver/controller,
and this limited warranty on the Embedded Software shall be null and void if the Embedded Software is modified or changed in any manner except
as specifically authorized by MDEA.
c. Labor. For certain items that are designed to be replaced by the consumer, including (but not limited to) some Embedded Software,
the consumer is solely responsible for any replacement labor. For all other parts, we will provide the labor for a warranty repair by an authorized
MITSUBISHI service center without charge for one year from the original date of purchase at retail.
d. Notice. To obtain warranty service, you must notify an authorized MITSUBISHI service center of any defect within the applicable
warranty time period.
BEFORE REQUESTING SERVICE, pmease review the instruction booklet to insure proper installation and correct customer
controm adjustment, If the problem persists please arrange for warranty service,
1. TO OBTAIN WARRANTY SERVICE:
a. Return your HDTV receiver/controller to your nearest authorized MITSUBISHI service center whose name and address can be obtained
from your MITSUBISHI dealer, by writing at the address provided below, calling MDEA at the 800-332-2119, or by using the support feature of our
website at www.mitsubishi-tv.com.
b. Proof of purchase date from an authorized MITSUBISHI dealer is required when requesting warranty service. Present your sales receipt
or other document which establishes proof and date of purchase. THE RETURN OF THE OWNER REGISTRATION CARD IS NOT A CONDITION OF
WARRANTY COVERAGE. However, please return the Owner Registration Card so that we can contact you should a question of safety arise which
could affect you.
2. THIS WARRANTY DOES NOT COVER cosmetic damage or damage to any other prod uct where such damage is caused by unauthorized modification,
alteration, repairs to or service of the product by anyone other than an authorized MITSUBISHI service center; physical abuse to or misuse of the
product (including any failure to carry out any maintenance as described in the Owner's Guide or any product damaged by excessive physical or
electrical stress); any products that have had a serial number or any part thereof altered, defaced or removed; product use in any manner contrary to
the Owner's Guide (including uneven picture tube aging and imprinted images on the viewing screen of connected display monitors); freight damage;
or any damage caused by acts of God or other factors beyond the reasonable control of MDEA, such as power surge damage caused by electrical
system or lightning. This warranty also excludes service where no defect in the product covered under this warranty is found, service related to
unsatisfactory audio or visual reception or signal unless caused a defect in the product that is covered under this warranty, all costs, expenses or any
other damages arising from product installation, or set-ups, any adjustments of user controls (including contrast, brightness, color, tint, fine tuning,
sharpness), other adjustment necessary to prepare the unit for display or use, connection with any external audio receiver, antenna, cable or satellite
systems, or service of products purchased or serviced outside the U.S.A. Please consult the operating instructions contained in the Owner's Guide
furnished with the product for information regarding user controls.
3. ANY EXPRESS WARRANTY NOT PROVIDED HEREIN, AND ANY REMEDY WHICH, BUT FOR THIS PROVISION, MIGHT ARISE BY IMPLICATION
OR OPERATION OF LAW, IS HEREBY EXCLUDED AND DISCLAIMED. THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR ANY
PARTICULAR PURPOSE ARE EXPRESSLY LIMITED TO A TERM OF ONE YEAR.
4. UNDER NO CIRCUMSTANCES SHALL MDEA BE LIABLE TO PURCHASER OR ANY OTHER PERSON FOR ANY INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES, WHETHER ARISING OUT OF BREACH OF WARRANTY, BREACH OF CONTRACT, OR OTHERWISE.
5. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental, special or consequential
damages, so the above limitations or exclusions may not apply to you.
6. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
In no event shall Mitsubishi have any liability, including without limitation, for general, consequential, incidental, or special damages for loss,
destruction, damage or corruption of recorded data, media or software resulting from use of this television, or cost of recovery of lost data, media or
software therefore.
MmTSUBISHI DIGITAL ELECTRONmCS AMERICA, INC. 9351 Jeronimo Road Irvine, CA 92618-1904 111
,l_ MiTSUBiSHi
ELECTRIC
DiGiTAL TELEVJSJDNB '_
Website:
www. rnitsubishi-tv.com
M DEAservice@mdea.corn
To order repMacement or
additionaU remote controUs or
Owner's Guides, call
800 -553-7278
For questions, call Consumer
ReMations at
© 2004 Mitsubishi Digital Electronics America, hc. Written and Printed in the U.S.A
871D410A10
