(Short-term Confidential)User Manual
User’s manual
Product: Wireless LAN Module
Model: DW092
FCC ID: EW4DW092
IC: 4634A-3149EC
For OEM integration only – device cannot be sold to general public.
Therefore we will not supply the User’s manual, the installation manual is the official for OEM.
(Note)
OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host
device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna
of this device must not be co-located or used in conjunction with any other antenna or transmitter. OEM integrators must be provided with
antenna installation instructions. Only those antennas tested with the device or similar antennas with equal or lesser gain may be used
with this transmitter.
We will ask OEM to include the following Notices required by FCC/ IC on the product and in the User’s
manual.
■Requirement of Labeling
(For FCC)
Please describe the following item on the host device of the this module:
Contains Transmitter Module FCC ID: EW4DW092 or Contains FCC ID: EW4DW092
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
(For IC)
Please describe the following item on the host device of the this module:
Contains Transmitter Module IC: 4634A-3149EC or Contains IC: 4634A-3149EC
■Requirement of User’s Manual Statement
(For FCC)
User’s manual shall contain following sentence
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
When installing in Mobile device
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio
frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment has very low levels of RF energy that it deemed to
comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated keeping
the radiator at least 20cm or more away from person’s body (excluding extremities: hands, wrists, feet and ankles).
When installing in Portable device
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio
frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment has very low levels of RF energy that are deemed
to comply without testing of specific absorption ratio (SAR).
* Portable device: Distance between the person's body and the antenna is 20cm or less.
* Mobile device: Distance between the person's body and the antenna is more than 20cm.
(For IC)
Indicate the following information.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
* It can be also indicated on the equipment in place of the manual
When installing in Mobile device
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive
exposure evaluation (MPE). But it is desirable that it should be installed and operated keeping the radiator at least 20cm or more away
from person’s body (excluding extremities: hands, wrists, feet and ankles).
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les
règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet une énergie RF très faible qui est
considérée conforme sans évaluation de l’exposition maximale autorisée. Cependant, cet équipement doit être installé et utilisé en
gardant une distance de 20 cm ou plus entre le dispositif rayonnant et le corps (à l’exception des extrémités : mains, poignets, pieds et
chevilles).
When installing in Portable device
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment has very low levels of RF energy that are deemed to comply without testing of specific
absorption ratio (SAR).
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les
règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet une énergie RF très faible qui est
considérée conforme sans évaluation du débit d’absorption spécifique (DAS).
