Host user manual

Here is a look at a few of the exciting features of the Nintendo 2DS system!
Circle Pad
Allows precise 360˚ control
for software that includes
this feature (see page 11).
HOME Button
Allows you to access the
HOME Menu (see page 20). Sleep Switch
Touch Screen
A touch-sensitive display
screen controlled by the
stylus (see page 11).
This product is a precision electronic device that can be damaged by direct physical impact or contact with dust
or other foreign material. A protective carrying case (sold separately) may help prevent damage to your
Nintendo 2DS™ system.
Please carefully read this Operations Manual before setup or use of the Nintendo 2DS system. If, after reading all of the instructions,
you still have questions, please visit our customer service area at support.nintendo.com or call 1-800-255-3700. Also, built-in
instruction manuals are available for many software applications from the HOME Menu (see page 24).
A NOTE ABOUT COMPATIBILITY: The Nintendo 2DS system is only compatible with Nintendo 3DS™, Nintendo DSi™, and Nintendo DS™
software. Nintendo 3DS Game Cards are only compatible with the Nintendo 2DS, Nintendo 3DS, or Nintendo 3DS XL systems. Some
accessories may not be compatible with this system.
Your system includes:
Product recycling information:
Visit recycle.nintendo.com
Trademarks are property of their respective owners. Nintendo 2DS and Nintendo 3DS are trademarks of Nintendo. © 2013 Nintendo
Elements of the Nintendo 2DS system and related network services are patented or patent pending, both in the United States and internationally.
The ocial seal is your assurance that this product is licensed
or manufactured by Nintendo. Always look for this seal when
buying video game systems, accessories, games and
related products.
Nintendo 2DS system
Nintendo 2DS stylus
(inserted into the system’s
stylus holder)
SDHC Card
(inserted into the system’s
SD Card slot)
Operations Manual and other
printed enclosures
Nintendo 3DS AC adapter
AR Cards
Play Nintendo 3DS, Nintendo DS, and Nintendo DSi software in 2D (page 28).
The Nintendo 2DS system conveniently includes this fun built-in software (see page
22 for more details):
The Swapnote™ application lets you exchange hand-written messages
with your friends using StreetPass and SpotPass.
Swapnote is stored on the SD Card when it is downloaded. For more information on downloadable software, see page 30.
Push this switch to the right to enable Sleep Mode (see page 14).
NOTE: Some software may require the system to be put into Sleep Mode (closing the system on Nintendo 3DS/
Nintendo 3DS XL systems). For the Nintendo 2DS system, use the sleep switch.
This system is part of the Nintendo 3DS family. You can enjoy all Nintendo 3DS online services and use all Nintendo 3DS software
in 2D. References to Nintendo 3DS in the user agreement and throughout the system software relate to your use of Nintendo 2DS.
Nintendo DS & Nintendo DSi
Game Cards
Nintendo 3DS
Game Cards
(games will display in 2D)
6 7
Health and Safety Information
Health and Safety Information
WARNING
WARNING - SEIZURES
WARNING - REPETITIVE MOTION INJURIES
WARNING - EYESTRAIN AND MOTION SICKNESS
WARNING - BATTERY LEAKAGE
WARNING - RADIO FREQUENCY INTERFERENCE
CAUTION
Important Safety Information – Read the following warnings before setup or use of the Nintendo 2DS system.
If this product will be used by young children, this manual should be read and explained to them by an adult.
Failing to do so may cause injury. Please carefully review the instruction booklet for the game you are playing
for additional health and safety information.
Throughout this manual, you will see this symbol followed by WARNING or CAUTION, or you may see the term IMPORTANT.
These terms have dierent levels of meaning as outlined below. Please read and understand these terms and the information that
appears after them before using your Nintendo 2DS system:
Warns you about incorrect use of the Nintendo 2DS system that could result in serious personal injury.
Cautions you about incorrect use of the Nintendo 2DS system that could result in personal injury or
damage to the Nintendo 2DS system, components, games, or accessories.
Informs you about incorrect use of the Nintendo 2DS system that could result in damage to the system,
components, games, or accessories.
IMPORTANT:
• Some people (about 1 in 4000) may have seizures or blackouts triggered by light ashes or patterns, and this may occur while
they are watching TV or playing video games, even if they have never had a seizure before.
• Anyone who has had a seizure, loss of awareness, or other symptom linked to an epileptic condition should consult a doctor
before playing a video game.
• Parents should watch their children play video games. Stop playing and consult a doctor if you or your child has any of the
following symptoms:
Convulsions Eye or muscle twitching Loss of awareness
Altered vision Involuntary movements Disorientation
To reduce the likelihood of a seizure when playing video games:
1. Sit or stand as far from the screen as possible.
2. Do not play if you are tired or need sleep.
3. Play in a well-lit room.
4. Take a 10 to 15 minute break every hour.
Health and Safety Information The Nintendo 2DS system contains a rechargeable lithium ion battery pack. Leakage of ingredients contained within the battery
pack, or the combustion products of the ingredients, can cause personal injury as well as damage to your Nintendo 2DS system. If
battery leakage occurs, avoid contact with skin. If contact occurs, immediately wash thoroughly with soap and water. If liquid leak-
ing from a battery pack comes into contact with your eyes, immediately ush thoroughly with water and see a doctor.
To avoid battery leakage:
• Do not expose battery to excessive physical shock, vibration, or liquids.
• Do not disassemble, attempt to repair, or deform the battery.
• Do not dispose of battery pack in a re.
• Do not touch the terminals of the battery or cause a short between the terminals with a metal object.
• Do not peel or damage the battery label.
The Nintendo 2DS system can emit radio waves that can aect the operation of nearby electronics, including cardiac pacemakers.
• Do not operate the Nintendo 2DS system within 9 inches of a pacemaker while using the wireless feature.
• If you have a pacemaker or other implanted medical device, do not use the wireless feature of the Nintendo 2DS system without
rst consulting your doctor or the manufacturer of your medical device.
• Observe and follow all regulations and rules regarding use of wireless devices in locations such as hospitals, airports, and on
board aircraft. Operation in those locations may interfere with or cause malfunctions of equipment, with resulting injuries to
persons or damage to property.
IMPORTANT: The Nintendo 2DS system allows you to disable wireless communication from the HOME Menu. To turn
o all wireless communication, see page 25 for instructions. Make sure the wireless LED is o.
Playing video games can make your muscles, joints or skin hurt. Follow these instructions to avoid problems such as tendinitis, carpal
tunnel syndrome or skin irritation:
• Avoid excessive play. Parents should monitor their children for appropriate play.
• Take a 10 to 15 minute break every hour, even if you don’t think you need it.
• When using the stylus, you do not need to grip it tightly or press it hard against the screen. Doing so may cause fatigue
or discomfort.
• If your hands, wrists or arms become tired or sore while playing, or if you feel symptoms such as tingling, numbness, burning or
stiness, stop and rest for several hours before playing again.
• If you continue to have any of the above symptoms or other discomfort during or after play, stop playing and see a doctor.
Playing video games can result in eyestrain after a sustained period of time. Playing video games can also result in motion sickness in
some players. Follow these instructions to help avoid eyestrain, dizziness, or nausea:
• Avoid excessive play. It is recommended that parents monitor their children for appropriate play.
• Take a 10 to 15 minute break every hour, even if you don’t think you need it. Each person is dierent, so take more frequent and
longer breaks if you feel discomfort.
• If your eyes become tired or sore while playing, or if you feel dizzy or nauseated, stop and rest for several hours before
playing again.
• If you continue to have any of the above symptoms, stop playing and see a doctor.
NOTE: This product does not contain latex.
This product complies with applicable laws barring the use of toxic materials such as lead, mercury, cadmium, hexavalent chromium, PBB, or PBDE in
consumer products.
Health and Safety Information and
Usage Guidelines
8 9
Usage Guidelines
Usage Guidelines
IMPORTANT BATTERY GUIDELINES
1. Do not remove the battery pack from the system unless it needs to be replaced.
2. Do not use any battery other than the Nintendo 3DS rechargeable battery pack, Model No. CTR-003. A replacement battery
may be ordered through Nintendo’s website at store.nintendo.com (USA/Canada only) or by calling Customer Service at
1-800-255-3700. See page 59 for more information on replacing the battery.
3. When recharging the battery, use ONLY the included AC adapter, Model No. WAP-002(USA).
4. When disposing of the battery, follow appropriate local guidelines and regulations. For information on battery disposal
contact your local solid waste authority. See page 60 for more information on recycling the battery.
5. If liquid comes into contact with the battery, do not reuse it. Call Nintendo Customer Service at 1-800-255-3700 for further
instructions on battery replacement and possible service for your system.
IMPORTANT STYLUS AND SCREEN GUIDELINES
1. Use the stylus ONLY on the Touch Screen (lower screen).
2. Use only enough pressure to operate the game. Excessive pressure may damage the Touch Screen.
3. Do not use the stylus if it is broken.
4. Use only a Nintendo licensed stylus on the Touch Screen.
5. Replace the stylus in the stylus holder when not in use.
6. If you use a screen protector on your system, use only a Nintendo licensed screen protector.
CLEANING THE TOUCH SCREEN AND UPPER SCREEN
IMPORTANT: If the Touch Screen becomes dirty or contaminated with foreign material, do not continue to use your
system. It may not work properly and can become more damaged. Follow the cleaning procedures below. If it still
does not work after cleaning, visit support.nintendo.com for information on repair services.
If the screens on your system have visible smudges, ngerprints, or other foreign material on them, you can clean them by using a
soft clean cloth, such as a lens or eyeglass cleaning cloth.
1. Slightly dampen the cloth with water ONLY and wipe o the screens to loosen any dirt or foreign material.
2. Using a dry cloth, wipe the screens to dry them and nish the cleaning process. If needed, repeat the process.
HARDWARE PRECAUTIONS AND MAINTENANCE
1. Do not disassemble or try to repair the Nintendo 2DS system, components, or accessories. Doing so voids your warranty.
2. Only insert or remove Game Cards while the system is turned o or while the HOME Menu is displayed. Insert the Game Card
completely until it clicks into place, without forcing either the Game Card or the Nintendo 2DS system.
3. Do not store the system in a humid place, on the oor, or in any location where it may contact moisture, dirt, dust, lint, or
any other foreign material.
4. Do not drop, hit, or otherwise abuse the system, components, or accessories. Doing so may damage the LCD screens or other
precision components of the system. Do not use damaged components, accessories, Game Cards, or SD Cards with your
system.
5. Make sure all connections to the system are made carefully and inserted into the correct locations only. Hold plugs straight
when inserting them into sockets.
6. When disconnecting any plugs from the system or wall outlet, rst turn the system o. Then carefully pull by the plug itself
rather than by the cord. Do not step on, sharply pull, or bend any wires or cables.
7. Do not expose the system, Game Cards, or any of the components or accessories to extreme heat or cold. The liquid crystal dis-
plays (LCD) may become slower or may not work when the temperature is low. The LCD will deteriorate at a high temperature.
Take care not to expose the system to direct sunlight for extended periods of time.
8. The LCD screens may be damaged by sharp objects or pressure. Take care to protect the displays from scratches or stains.
9. Connect ONLY accessories designed and licensed for use with the system to any external connectors.
10. Do not spill liquids on the system, Game Cards, or other components or accessories. If the system comes into contact with
liquids, wipe clean with a soft, slightly damp cloth (use water only). Remove the battery cover and battery. If liquid came
into contact with the battery, do not reuse it. Call Nintendo Customer Service at 1-800-255-3700 for further instructions on
battery replacement and possible service for your system.
11. Do not rapidly turn the power switch ON and OFF, as this may shorten the life of the battery and cause Game Cards to lose
your stored game information.
12. To avoid dirt or dust from getting into the system, always leave a Game Card loaded (with the power o), when not in use.
13. When using an AC adapter, make sure you are using the correct model appropriate for your system. Always unplug the AC
adapter from the wall outlet when not in use.
14. Do not use the AC adapter if the cable or plug is damaged.
15. The AC adapter is intended to be correctly oriented in a vertical or oor mounted position.
GAME CARD PRECAUTIONS AND MAINTENANCE
1. Avoid touching the connectors with your ngers. Do not blow on them or allow them to get wet or dirty. Doing so may
damage the Game Card and/or the system.
2. The Game Card is a high-precision electronic device. Do not store it in places that are very hot or cold. Do not hit, drop, or
otherwise abuse it. Do not attempt to take it apart.
3. Do not clean with benzene, paint thinner, alcohol or any other solvent.
4. Always check the Game Card edge connector for foreign material before inserting the Game Card into the system.
Basic Operations
Basic Operations
10
Basic Operations
11
Nintendo 2DS Components
Nintendo 2DS Components
Nintendo 2DS Components
Notication LED
Indicates the status of the system.
Blue– You have received SpotPass data; blinks for about ve seconds (see page 37).
Green– You have received StreetPass data; blinks for about ve seconds (see page 37).
Orange– A friend has come online; blinks for about ve seconds (see page 32).
Red– Battery power is low; blinks continuously when very low (see page 17).
Microphone
Used by games and
applications that include
microphone features.
Sleep switch
Push to the right to put the system
into Sleep Mode (see page 14).
Power LED
Lights when the power is turned on (see page 17).
Power Button ( )
See page 14.
Upper screen Touch Screen (Lower screen)
Touch-sensitive screen. This screen should only be oper-
ated with a Nintendo licensed stylus.
Using the Touch Screen
Control buttons
Inner camera
Used by games or other applications that
include camera features.
NOTE: Avoid getting the camera lens
dirty. If it becomes dirty, wipe gently
with a soft cloth, being careful not to
damage the lens.
Speaker
SELECT
START
Circle Pad
For game-play control that
supports this feature. See the
instructions for the game you
are playing for specic control
information.
Volume control
Slide to adjust the volume.
NOTE: The camera shutter sound always plays
at a xed volume and is not aected by the
volume control.
HOME
Displays the HOME Menu during a game.
+
Control Pad
Recharge LED ( )
Lights when the battery is being charged (see page 13).
Audio jack
For connection of stereo headphones (sold
separately). If headphones are connected,
no sound will play through the speaker. (This
system is not compatible with the Nintendo
DS Headset.)
When using headphones, set
the volume at a safe level. Setting the volume
too high may harm your hearing or damage the
headphones.
The lower LCD screen, or Touch Screen, is touch-
sensitive. For games that include this game control
feature, operate the screen by using the included stylus.
Lightly touch or slide the stylus across the Touch Screen
as shown.
SD Card slot
For inserting an SD or SDHC Card
(see page 18).
Wireless LED ( )
Lights when wireless com-
munication is turned on, turns
o when communication is
turned o, and blinks while
data is being sent or received
or when the system is in Sleep
Mode (dimly).
NOTE: Wireless communica-
tion can be turned on or o
from the HOME Menu (see
page 25).
Volume
+ –
Basic Operations
12
Basic Operations
13
Nintendo 2DS Components
Stylus holder
Always replace the stylus into
the stylus holder after use.
NOTE: To prevent damage to
the Nintendo 2DS system, do
not insert anything other than
a Nintendo 2DS licensed stylus
into the stylus holder.
Battery cover
Remove cover to replace the battery.
NOTE: Do not remove the cover unless you need to
replace the battery or check battery installation.
Infrared transceiver
Sends and receives information when
using infrared communication.
L Button
R Button
Outer cameras
Used by games or other applications
that include camera features. Two cameras
allow you to take 3D photographs or videos
that can be viewed on a Nintendo 3DS or
Nintendo 3DS XL system (see page 22).
NOTE: Avoid getting the camera lenses dirty. If
they become dirty, wipe gently with a soft cloth,
being careful not to damage the lenses.
Game Card slot
For loading Nintendo 3DS Game Cards. Also compatible
with Nintendo DS and Nintendo DSi Game Cards.
Wrist strap attachment
For attachment of a licensed wrist strap
(sold separately).
AC adapter connector
Allows connection of the
Nintendo 3DS AC adapter
(included), for recharging the bat-
tery or operation using household
current (see page 13).
WARNING Do not use the Nintendo 3DS AC adapter during a lightning storm. There may be a risk of
electric shock from lightning.
IMPORTANT: Do not use the AC adapter with voltage transformers, dimmer switches, or any other equipment. It is
only for use in a standard 120-volt AC wall outlet.
2
１
２
1
Logo faces up
Swing prongs out
Recharge LED will
light up
Insert the DC plug from the AC adapter into the AC adapter connector on the back of the Nintendo 2DS. Be sure to insert
it straight into the connector.
IMPORTANT: Be sure the DC connector plug is facing in the correct direction before inserting into the
connector to avoid damaging either the plug or connector.
Swing the prongs out of the AC adapter and insert into a standard 120-volt AC wall outlet . The recharge LED will
light, indicating the system is charging. When fully charged, the recharge LED will go out. When charging is complete,
remove the AC adapter from the wall outlet and fold the prongs back into the housing.
IMPORTANT: The AC adapter should be correctly oriented in a vertical or oor-mounted position. The cord
should always face downward.
NOTE: If you play a game while recharging, the recharge LED may not always turn o once charging has completed.
• Battery recharge time is approximately 3 1/2 hours, depending on remaining charge when you start and whether or not you
are using your system during recharging.
• Optimal charging temperature is between 40º and 95º Fahrenheit (5-35º Celsius). Temperatures above or below this may
decrease the life of the battery and adversely aect the ability of the battery to charge.
• The battery pack can be recharged approximately 500 times, after which battery life may be 70% of a new battery.
• Battery packs become worn with repeated charge/discharge cycles. If usage time gets very short, replace the battery pack
(see page 59).
1
2
Charging the Battery Pack
Charging the Battery Pack
Basic Operations
Basic Operations
1514
Press the POWER Button to turn the system on. The Power LED will light up and
after a few seconds the HOME Menu will appear.
The rst time you turn the system on, you will need to select a language
and then congure the System Settings.
For more information on the Power LED and battery life, see page 17.
Sleep Mode and turning your system o
Putting the system into Sleep Mode
Moving the Sleep switch to the right while the system is turned on will suspend your game and put the
system into Sleep Mode. In this mode, the screens will turn o and the controls will become inoperable.
Sleep Mode will reduce power consumption while still using features such as StreetPass and SpotPass
(see page 2 and page 3 for more information on these features).
Depending on the software you are using, pressing the Sleep switch may not place it in Sleep Mode. (For example, when listen-
ing to music with Nintendo 3DS Sound.)
Turning the system o
To turn the system o, either press the POWER Button to display the Power menu and tap
Power O, or press and hold the POWER Button until the power LED turns o.
NOTE: If the system is in Sleep Mode, you will need to wake it before turning the
power o.
Conguring System Settings for the rst time
First select a language. Then you will need to congure the basic system settings. Using the stylus on the lower screen, follow the
on-screen instructions. If a child will be using the Nintendo 2DS, an adult should assist with these settings.
NOTE: At the beginning, system information will be displayed. Touch OK after reading to proceed.
Set the date and time.
Tap to adjust the settings, then tap
OK to conrm and move to the next option.
Use the keyboard to enter a nickname (or user name). You can enter up
to 10 characters.
Remember that other Nintendo 2DS, Nintendo 3DS, or Nintendo 3DS XL users
will see your nickname when interacting with them, so do not use your real
name or otherwise share any personal information in your nickname.
Power LED
will light up
Press the
POWER Button
1
2
Power On/O and Basic Conguration
Power On/O and Basic Conguration
Power On/O and Basic Conguration Set your birthday.
Tap to adjust the month and day, then tap OK to conrm and move to
the next option.
Set the country and state or province where you live.
Read the Nintendo 3DS Service User Agreement, and after reading, tap I Accept.
To continue without agreeing, tap Later. If you tap Later, you cannot connect to the
Internet until you agree to the Nintendo 3DS Service User Agreement.
Congure the Internet Settings.
If you connect to the Internet, you can use SpotPass, Nintendo Wi-Fi Connection, and
other features to enjoy more ways of playing and interacting. See page 42 for more
information on setting up an Internet connection. To congure these settings later, tap
Wait Till Later.
Congure the Parental Controls.
Parental Controls allow you to restrict the use or download of games and some features
by children. See page 48 for more information.
If you don’t need to congure these settings, tap Wait Till Later.
Read the system introduction.
You can tap OK to start the introduction. If you tap Later, you can view the introduction
at any time by going to Other Setting in System Settings.
You have now completed the basic system conguration. Press the HOME Button to display the
HOME Menu (see page 20) and explore the many features of the Nintendo 2DS.
3
4
5
66
7
8
Consumer Information
Consumer Information
7170
Warranty and Service Information
Regulations for Equipment Use
You may need only simple instructions to correct a problem with your product. Try our website at support.nintendo.com or call our
Consumer Assistance Hotline at 1-800-255-3700, rather than going to your retailer. Hours of operation are 6 a.m. to 7 p.m., Pacic Time,
Monday - Sunday (times subject to change). If the problem cannot be solved with the troubleshooting information available online or over the
telephone, you will be oered express factory service through Nintendo. Please do not send any products to Nintendo without contacting us rst.
HARDWARE WARRANTY
Nintendo of America Inc. (“Nintendo”) warrants to the original purchaser that the hardware product shall be free from defects in material and
workmanship for twelve (12) months from the date of purchase. If a defect covered by this warranty occurs during this warranty period, Nintendo
will repair or replace the defective hardware product or component, free of charge.* The original purchaser is entitled to this warranty only if the
date of purchase is registered at point of sale or the consumer can demonstrate, to Nintendo’s satisfaction, that the product was purchased within
the last 12 months.
GAME & ACCESSORY WARRANTY
Nintendo warrants to the original purchaser that the product (games and accessories) shall be free from defects in material and workmanship for
a period of three (3) months from the date of purchase. If a defect covered by this warranty occurs during this three (3) month warranty period,
Nintendo will repair or replace the defective product, free of charge.*
SERVICE AFTER EXPIRATION OF WARRANTY
Please try our website at support.nintendo.com or call the Consumer Assistance Hotline at 1-800-255-3700 for troubleshooting information and
repair or replacement options and pricing.*
* In some instances, it may be necessary for you to ship the complete product, FREIGHT PREPAID AND INSURED FOR LOSS OR DAMAGE, to Nintendo.
Please do not send any products to Nintendo without contacting us rst.
WARRANTY LIMITATIONS
THIS WARRANTY SHALL NOT APPLY IF THIS PRODUCT: (a) IS USED WITH PRODUCTS NOT SOLD OR LICENSED BY NINTENDO (INCLUDING, BUT NOT LIM-
ITED TO, NON-LICENSED GAME ENHANCEMENT AND COPIER DEVICES, ADAPTERS, SOFTWARE, AND POWER SUPPLIES); (b) IS USED FOR COMMERCIAL
PURPOSES (INCLUDING RENTAL); (c) IS MODIFIED OR TAMPERED WITH; (d) IS DAMAGED BY NEGLIGENCE, ACCIDENT, UNREASONABLE USE, OR BY OTHER
CAUSES UNRELATED TO DEFECTIVE MATERIALS OR WORKMANSHIP; OR (e) HAS HAD THE SERIAL NUMBER ALTERED, DEFACED OR REMOVED.
ANY APPLICABLE IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY
LIMITED IN DURATION TO THE WARRANTY PERIODS DESCRIBED ABOVE (12 MONTHS OR 3 MONTHS, AS APPLICABLE). IN NO EVENT SHALL NINTENDO BE
LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES RESULTING FROM THE BREACH OF ANY IMPLIED OR EXPRESS WARRANTIES. SOME STATES DO
NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR EXCLUSION OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU.
This warranty gives you specic legal rights. You may also have other rights which vary from state to state or province to province.
Nintendo’s address is: Nintendo of America Inc., P.O. Box 957, Redmond, WA 98073-0957 U.S.A.
This warranty is only valid in the United States and Canada.
Revision R1
Warranty and Service Information
FCC and Industry Canada Information
In order to comply with FCC radio-frequency radiation exposure guidelines for an uncontrolled exposure, this device and its antenna must not be
co-located or operating in conjunction with any other antenna or transmitter.
This device complies with Part 15 of the FCC Rules and RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept interference received, including interference that may cause
undesired operation.
Changes or modications not expressly approved by the manufacturer could void the user’s authority to operate this device.
This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician or call Nintendo Consumer Service at 1-800-255-3700 for assistance.
The user may nd the following booklet prepared by the Federal Communications Commission helpful: How to Identify and Resolve Radio-TV
Interference Problems. This booklet is available from the U.S. Government Printing Oce, Washington, D.C., 20402, Stock No. 004-000-00345-4.
Regulations for Equipment Use
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Consumer Information
Consumer Information
7372
Nintendo 3DS System Privacy Policy
Nintendo 3DS System Privacy Policy
Last Updated: November 1, 2011
Nintendo is dedicated to protecting your privacy and handling any personal information we obtain from you with care and respect. By accepting
the Nintendo 3DS Service User Agreement, you consent to and accept this Nintendo 3DS System Privacy Policy (“Privacy Policy”). This Privacy Policy
describes, among other things, the types of information collected about you by Nintendo when you use the Nintendo 3DS System, the Nintendo 3DS
Service, Software, and Content; how your information may be used; when it may be disclosed; how you can control the use and disclosure of your
information; and how your information is protected. This Privacy Policy applies only to information collected from your Nintendo 3DS System by
Nintendo of America Inc. or its parent company, Nintendo Co., Ltd. (individually and collectively, “Nintendo”). Information that you may submit to
Nintendo through any of its Web sites or any other Nintendo product or service is subject to the applicable privacy policy posted at support.nintendo.
com. This Privacy Policy should be read in conjunction with the Nintendo 3DS Service User Agreement and Code of Conduct. All capitalized terms not
dened in this Privacy Policy will have the meaning set forth in the Nintendo 3DS Service User Agreement.
CHANGES TO THIS PRIVACY POLICY
We may revise and update this Privacy Policy from time to time. Please review the most recent version of this policy frequently by going to support.
nintendo.com or contacting us at 1-888-977-7627 or e-mailing us at privacypolicy@noa.nintendo.com . When we update this Privacy Policy, we will
revise the “Last Updated” date above.
INFORMATION COLLECTED
Personally Identiable Information. “Personally Identiable Information” or “PII” is information that identies you as an individual, such as your
full name, address, telephone number, or email address. We only collect PII that you provide to us. For example, the Nintendo 3DS System, Nintendo
3DS Service, Software, and Content may enable you to provide User Content that may contain PII. If you choose not to provide us with certain PII,
you will be able to continue using your Nintendo 3DS System, Nintendo 3DS Service, Software, and Content, except that your use of features or
applications that require the disclosure of certain PII may be limited or unavailable.
We may add to or update the PII you provide through the Nintendo 3DS System, Nintendo 3DS Service, Software, or Content with data collected from
other sources, including oine sources (e.g., consumer service transactions such as repairs, part orders or purchases). If we combine information
collected oine with information collected through the Nintendo 3DS System, Nintendo 3DS Service, Software, or Content the combined PII will be
treated in accordance with this Privacy Policy.
Non-Personally Identiable Information. In addition to the PII you provide to us, we may collect Non-Personally Identiable Information from
you. “Non-Personally Identiable Information” or “Non-PII” is information that does not identify you as an individual. This includes information such
as your Mii prole information, age, gender, geographic area, game play data, online status, Nintendo 3DS System serial number and device ID,
device certicate information, cookies, Friend Codes, wireless access point information, Internet Protocol (“IP”) address, and Media Access Control
(“MAC”) address. We may link your PII with Non-PII or Aggregate Information that we collect from you. Some of the ways in which we collect
Non-PII are described in more detail below.
• Web Beacons: The Nintendo 3DS System, Nintendo 3DS Service, Software, or Content may use a common Internet technology called “Web
Beacons” which are small graphic images placed on a Web page, on a Web-based document, or in an email message, designed to collect certain
information and monitor user activity online. We may use Web Beacons to collect information such as IP address, MAC address, the URL of the
page the Web user comes from, and the time the Web Beacon is activated (such as when you view the Web page, advertisement, or email con-
taining the Web Beacon). We may use the information collected through Web Beacons, for example, to determine how to improve the Nintendo
3DS System, Nintendo 3DS Service, Software, or Content by seeing which areas, features, and products are most popular; to personalize the
Nintendo 3DS System, Nintendo 3DS Service, Software, or Content and make recommendations based on downloaded products; and to complete
transactions you have requested.
• Cookies: Certain Nintendo 3DS System online applications may use cookies, which are small text les that a Web site places on your Nintendo
3DS System. These les identify your Nintendo 3DS System and record data about your visit so that when you return to a Web site, the site
recognizes your Nintendo 3DS System and can personalize your visit. Cookies may be linked to your transaction history, online game play or other
information. We may use information collected by cookies, as well as other tools such as log les and Web Beacons, for example, to determine
how to improve the Nintendo 3DS System applications by seeing which areas, features, and products are most popular; to personalize the
Nintendo 3DS System services; make recommendations based on downloaded products; and to complete transactions you have requested.
• Nintendo Wireless Communications: Your Nintendo 3DS System is automatically assigned an IP address by your Internet Provider when you
connect to Nintendo via wireless communications. Nintendo receives a log le of your activities that may include, for example, your IP address,
MAC address, cookie information, transaction data, settings and download activity. We may use these log les, for example, to monitor trac
on our Web sites, to facilitate your use of the Nintendo 3DS System, Nintendo 3DS Service, Software, or Content, and to troubleshoot technical
problems. If you do not want Nintendo to collect this information, you should turn o wireless communications on your Nintendo 3DS System.
Aggregate Information. We also may collect and aggregate certain information about our users’ game play, age, gender, search terms,
clickstreams, and purchases for the purposes of advertising and improving the Nintendo 3DS System, Nintendo 3DS Service, Software, and Content.
“Aggregate Information” is Non-PII that is combined with the Non-PII of other users.
HOW INFORMATION IS USED
We may collect PII, Non-PII, and Aggregate Information from you through your Nintendo 3DS System in order to: (i) fulll your requests for products,
services, and information, including to send you commercial and non-commercial messages and to process orders you have placed through your
Nintendo 3DS System; (ii) contact you in connection with games, contests, sweepstakes, surveys, promotional materials, and product changes; (iii)
facilitate your use of the Nintendo 3DS System, Nintendo 3DS Service, Software, and Content, such as StreetPass Communications and communica-
tions with other users; (iv) customize the content, features, and advertising available through the Nintendo 3DS System, Nintendo 3DS Service,
Software, and Content such as your Nintendo 3DS Shop catalog and other catalogs; (v) set up repair orders and respond to other consumer service
inquiries; (vi) provide you back-end services, such as system updates, system messages, and free games, applications, trials, and content; (vii)
analyze the use of the Nintendo 3DS Service, Software, Content, and information about our users for demographic studies, quality assurance and to
understand and improve our service oerings; (viii) facilitate demographic studies and quality assurance; (ix) prevent potentially illegal or oensive
activities or to enforce our rights or the rights of our users; and (x) for any other purposes disclosed to you at the time we collect your information or
pursuant to your consent.
DISCLOSURE OF INFORMATION
We may facilitate the disclosure of PII, Non-PII and Aggregate Information when you use the Nintendo 3DS System, Nintendo 3DS Service, Software,
or Content. For example, information such as your Mii name, Mii prole information, online status, Mii greeting, and other User Content or game
play information may be displayed to other users when you use the online features of the Nintendo 3DS System, Nintendo 3DS Service, Software,
or Content.
• Third Parties. We may share PII, Non-PII, and Aggregate Information with our vendors to help us perform various functions necessary to
operate our business or fulll your requests (for example, completing downloads or purchases, developing and executing marketing campaigns,
etc.). We also may share such information and any User Content you create with third parties. We may share your PII, Non-PII, and Aggregate
Information with third parties to complete your transactions and provide you with advertising and other promotional materials through your
Nintendo 3DS System, Nintendo 3DS Service, Software, or Content.
• StreetPass Communications. Certain Nintendo 3DS Service, Software, and Content allow other Nintendo 3DS System users to automatically
contact and interact with you. The StreetPass Communications feature allows PII, Non-PII and User Content that you have provided or that is
stored on your Nintendo 3DS System to be shared automatically with other Nintendo 3DS System users via a wireless connection, the Nintendo
Zone or a StreetPass Communication Point. You understand that you have no expectation of privacy in the information or User Content shared
via StreetPass Communications. When StreetPass Communications are enabled on your Nintendo 3DS System, you may not only receive User
Content from other users but advertising or other promotional materials from Nintendo and third parties. You may disable this feature at any
time through the Nintendo 3DS System settings.
• Friends. In addition, you may add Friends to your Nintendo 3DS Friend list by exchanging friend codes or friend cards. Through the Nintendo
3DS Friend list and Friend messaging features, certain information that you have provided or that is stored on your Nintendo 3DS System, such
as your Mii name, Mii prole information, Mii greeting, online status, rankings, and other User Content or game play information, may be shared
with your Nintendo 3DS Friends.
• Legal and Business Purposes. We may disclose PII in order to comply with legal process, to respond to claims or inquiries, or to protect the
rights, property or personal safety of Nintendo, our users, or the public. Information about our users, including PII, may be disclosed as part of
any sale or transfer of company assets, if permitted by and done in accordance with applicable laws. We also may disclose your PII for any other
purposes pursuant to your consent.
You are responsible for any User Content or PII that you share through the Nintendo 3DS System, Nintendo 3DS Service, Software,
or Content. Please be aware that other Nintendo 3DS System users may be able to store, modify, or share with third parties
information that you provide them through your Nintendo 3DS System.
Nintendo 3DS System Privacy Policy
Consumer Information
Consumer Information
7574
Nintendo 3DS System Privacy Policy
Nintendo 3DS System Privacy Policy
MARKETING AND ADVERTISING
We may collect and use your PII, Non-PII, or Aggregate Information for marketing purposes, including the delivery of advertising and other promo-
tional materials to you through the Nintendo 3DS System, Nintendo 3DS Service, Software, or Content. For example, we might deliver messages to
your Nintendo 3DS System that oer discounts on Nintendo games or products. You may be able to opt-out of receiving these messages through the
Nintendo 3DS System settings or as otherwise described to you in the marketing message.
NINTENDO ZONE
We may collect and use your PII and Non-PII to notify you when you are close to a Nintendo Zone. If you choose to access a Nintendo Zone, we may
use your PII and Non-PII, for example, to facilitate your access to Software and Content. In addition, third parties may collect PII that you provide to
them and Non-PII through the Nintendo Zone.
LINKING ACCOUNTS
You may link your Nintendo 3DS Shop Account to your Club Nintendo account to receive personalized content and to participate in a variety of
activities, promotions and programs. By linking your Club Nintendo account to your Nintendo 3DS Shop Account, you consent to having any PII
you enter on your Club Nintendo account linked to your Nintendo 3DS Shop Account. You may unlink these accounts in the Settings section of the
Nintendo 3DS Shop.
THIRD-PARTY WEB BEACONS AND COOKIES
In the event you visit a third party’s Web site through the Internet browser on the Nintendo 3DS System, or you choose to view an ad delivered by a
third party, such as those made available through the Nintendo Zone, those Web sites or ads may also contain tools such as cookies and Web Beacons
which may be accessible to such third party to collect information about your online browsing. These third parties also may use ad networks, ad serv-
ers, ad exchanges, or other third parties that may collect information when you view or interact with advertisements or Web sites across the Internet
in an eort to understand your interests and deliver you advertisements tailored to your interests. Nintendo does not have access to the information
these third parties may collect about your interests to deliver relevant advertising to you, and the information practices of these third parties are not
covered by this Privacy Policy. We strongly recommend that you refer to the privacy policies of these third parties to learn more about how they may
collect, use, and disclose your information.
GAMES, APPLICATIONS, ADVERTISING, AND CONTENT PROVIDED BY THIRD PARTIES
You may disclose PII and Non-PII to third parties when you use the Nintendo 3DS System to play third-party games, use third-party applications,
view third-party advertisements, or visit third-party Web sites. We are not responsible for the privacy practices of these third parties, and we recom-
mend that you review their privacy policies before submitting any information.
ATTENTION PARENTS OR LEGAL GUARDIANS: PROTECTING CHILDREN’S PRIVACY
Nintendo is committed to protecting your child’s privacy. The Nintendo 3DS System is directed to a general audience, but where Nintendo has actual
knowledge that a user is under the age of 13, Nintendo complies with the U.S. Children’s Online Privacy Protection Act (“COPPA”), which governs how
operators of websites and online services collect, use, and disclose PII from children under the age of 13 on the Internet.
You can nd information about how we collect, use, and disclose PII from users, including children under 13 years of age, in the sections above titled
INFORMATION COLLECTED, HOW INFORMATION IS USED, DISCLOSURE OF INFORMATION, MARKETING AND ADVERTISING, and NINTENDO ZONE. You
have the option of consenting to Nintendo’s collection and use of your child’s PII without consenting to the disclosure of that information with third
parties. In addition, Nintendo is prohibited from conditioning your child’s participation in an activity on the child’s disclosing more personal informa-
tion than is reasonably necessary to participate in such activity.
You may review and have deleted your child’s PII, and refuse to permit further collection or use of your child’s PII, by contacting the Nintendo 3DS
Privacy Policy Administrator via email at privacypolicy@noa.nintendo.com, by phone at 1-888-977-7627, or by regular mail at Nintendo of America
Inc., Attn: Online Privacy Policy Administrator, 4600 150th Avenue NE, Redmond, WA 98052, U.S.A. Before responding to your request to review PII
collected from your child, Nintendo may require that you follow reasonable procedures to help verify your identity as the child’s parent and may deny
any request that fails to follow these procedures. If you choose to have your child’s PII deleted or refuse to permit further collection or use of your
child’s PII, your child will be able to continue using the Nintendo 3DS System, except your child’s use of certain features of the Nintendo 3DS Service,
Software, and Content that require the disclosure of certain PII may be limited or unavailable.
Please note that third-party game publishers, application providers, and content providers may collect, use, and disclose your child’s personal
information through the Nintendo 3DS System when your child uses the third-party’s Software or Content. Nintendo is not responsible for the
privacy practices of these third parties, and we recommend that you review their privacy notices before your child provides or exchanges any PII
through third-party Software or Content.
We strongly recommend that you supervise your children’s use of the Nintendo 3DS System, Nintendo 3DS Service, Software, and Content at all
times. You can restrict your children’s use of certain features of the Nintendo 3DS System by setting up the Nintendo 3DS Parental Controls. For a
detailed description of the Nintendo 3DS System wireless communication features and Parental Controls, please see the Nintendo 3DS System Opera-
tions Manual included with your Nintendo 3DS System. This Operations Manual is also available at support.nintendo.com.
SECURITY
We have established reasonable safeguards to help ensure the security, integrity and privacy of the PII submitted or collected from the Nintendo 3DS
System, Nintendo 3DS Service, Software, or Content. We also have implemented reasonable security measures to help protect information under our
control against loss, misuse or alteration. While we strive to safeguard your PII, no data storage system or transmission of data over the Internet or
any other public network can be guaranteed to be 100% secure.
Please note that information collected by third parties, including a Third Party Content Provider, may not have the same security protections as
information you submit to us, and we are not responsible for protecting the security of such information.
If you install unauthorized applications or content on your Nintendo 3DS System or make unauthorized modications to the Nintendo 3DS System,
your PII may be compromised. Nintendo is not responsible for any data collection, use or disclosure from any Nintendo 3DS System with unauthor-
ized applications or applications installed.
OPTING-OUT OF INFORMATION COLLECTION
You may use the Nintendo 3DS System without disclosing PII; however, some features and applications may not be available to you. You can opt-out
of the collection of PII by turning o wireless communications on your Nintendo 3DS System. You also may be able to opt-out of some types of
information collection through the Nintendo 3DS System settings and Parental Controls.
DISABLING AND REMOVING INFORMATION STORED ON YOUR NINTENDO 3DS SYSTEM
Certain PII about you that you disclose when communicating with third parties or using your Nintendo 3DS System may be stored on your Nintendo
3DS System. For your protection, before selling or otherwise transferring your Nintendo 3DS System, please be sure to remove all stored information
on your Nintendo 3DS System. For instructions on how to remove this information, please see the Internet Setup section of your Nintendo 3DS
System Operations Manual or contact a Nintendo consumer service representative.
If you transfer data to a Nintendo 3DS System using the System Transfer or Nintendo 3DS Transfer Tool features, any PII or Non-PII included in such
data will be transferred as part of this process.
INTERNATIONAL USERS
Any information you provide or that is collected through the Nintendo 3DS System, Nintendo 3DS Service, Software, or Content may be stored and
processed in the United States or any other country in which we or our aliated companies, vendors or agents maintain facilities. As such, PII may be
accessed by foreign governmental authorities and otherwise in accordance with applicable laws. By using the Nintendo 3DS System, Nintendo 3DS
Service, Software, or Content you consent to such storage and processing. We abide by the safe harbor framework as set forth by the U.S. Department
of Commerce regarding the collection, use, and retention of data from the European Union. However, this Privacy Policy is intended to meet the laws
and requirements of the United States and those of Canada and Latin America, which may not be the same as the laws and regulations of your home
country. If you are not located in the United States, Canada or Latin America please go back to the country selection screen and select an appropriate
country so that you will be aware of the policies that apply to you.
CONTACT US WITH YOUR PRIVACY QUESTIONS, COMMENTS OR CONCERNS
If you have any questions, complaints or comments regarding this Privacy Policy, the data collected from you or our practices, please contact the Nin-
tendo 3DS Privacy Policy Administrator via email at privacypolicy@noa.nintendo.com, by phone at 1-888-977-7627, or by regular mail at Nintendo
of America Inc., Attn: Online Privacy Policy Administrator, 4600 150th Avenue NE, Redmond, WA 98052, U.S.A.
For U.S. and Canada residents only: Nintendo is a licensee of the Entertainment Software Rating Board’s Privacy Online Program. If you believe that
we have not responded to your inquiry or your inquiry has not been satisfactorily addressed, please contact ESRB at http://www.esrb.org/privacy/
contact.jsp, ESRB Attn: Privacy Online Program, 317 Madison Avenue, 22nd Floor New York, NY 10017, U.S.A. or privacy@esrb.org.
Consumer Information
Consumer Information
7776
Nintendo 3DS Code of Conduct
Legal Notices
Nintendo 3DS Code of Conduct
This Nintendo 3DS Code of Conduct outlines the rules that you must follow to participate in the Nintendo 3DS Service. These rules are designed to
keep the Nintendo 3DS Service a friendly and safe environment.
The Nintendo 3DS Code of Conduct may be found at http://support.nintendo.com and may be revised by us at anytime. If you do not have Internet
access, please contact Nintendo Consumer Service by (i) sending a letter to Nintendo of America Inc., Attn: Nintendo 3DS Code of Conduct, 4600
150th Ave NE, Redmond, WA 98052 USA; or (ii) calling, toll free, 1-888-977-7627, and they will mail you a current version of the Nintendo 3DS Code
of Conduct, free of charge. All capitalized terms not dened in this Nintendo 3DS Code of Conduct will have the meaning set forth in the Nintendo
3DS Service User Agreement.
1. Your use of the Nintendo 3DS is subject to this Nintendo 3DS Code of Conduct, which prohibits all harmful, illegal or otherwise oensive conduct,
including, but not limited to the following:
• Misrepresenting, impersonating, abusing, stalking, threatening or harassing any person or company, including, but not limited to other
users, Nintendo, and/or its employees, moderators, or sta.
• Doing anything illegal, discriminatory, defamatory, hateful, harassing, abusive, obscene, threatening, physically dangerous or otherwise
objectionable in connection with the Nintendo 3DS System or Nintendo 3DS Service.
• Making, disseminating, sharing or playing unauthorized copies of games, music or images on the Nintendo 3DS System. This activity is
illegal!
• Making new versions of existing Content or Products.
• Trying to modify or gain access to another person’s Nintendo 3DS System or Nintendo 3DS Service without permission or trying to modify or
gain access to any of Nintendo’s computers, hardware or networks used to provide the Nintendo 3DS Service or any feature of the Nintendo
3DS System.
• Cheating in a game, unless such cheats have been deliberately enabled.
• Hosting, intercepting, emulating, reverse engineering or redirecting the communication protocols used by Nintendo as part of the Nintendo
3DS System or Nintendo 3DS Service, regardless of the method used to do so.
• Engaging in any commercial activity using the Nintendo 3DS System or any other activity that disrupts, diminishes the quality of, interferes
with the performance of, or impairs the functionality of a Nintendo 3DS System, including the Nintendo 3DS Service or networks connected
to the Nintendo 3DS Service.
• Accessing or attempting to access another person’s Nintendo 3DS System, including, but not limited to a person’s Nintendo 3DS Shop
Account without permission or trying to modify, destroy or lose information from, copy or access any third party’s, including, but not limited
to Nintendo’s computers, hardware or networks.
• Uploading, posting, emailing, transmitting or otherwise making available: (a) any content that you do not have a legal right to make
available; (b) any content that infringes any patent, trademark, trade secret, copyright or other intellectual property or proprietary rights of
any party; (c) any unsolicited or unauthorized advertising or promotional materials (e.g. “spam”); (d) information which personally identi-
es you or any third party; (e) content to which you have disguised the origin; or (f) content that is obscene, unlawful or prohibited from
publication in your jurisdiction, including but not limited to publishing news, stories or pictures associated with a third party.
2. Nintendo is not responsible for, and to the fullest extent permitted by law, will not accept liability for, anything you say or anything that happens
on the Nintendo 3DS System and Nintendo 3DS Service or as a result of your use of the Nintendo 3DS System and Nintendo 3DS Service; you
alone are responsible.
3. Virtual Property. Some games or other content may have certain features that may be traded with other Nintendo 3DS users. For example, a
game might give you the ability to create a character that gathers objects (like a car or gold coins) and has certain characteristics (like a special
ability or appearance). These features are sometimes called “virtual property.” Nintendo (or its licensors) own this virtual property, and you may
not sell, trade, assign, license, or otherwise convey virtual property for real money.
4. Nintendo reserves the right to immediately terminate, block or suspend, in whole or in part, your use of the Nintendo 3DS Service or any feature
of the Nintendo 3DS System for, in Nintendo’s sole discretion, any violation of this Nintendo 3DS Code of Conduct. Nintendo reserves the right
to contact and cooperate with any law enforcement agencies, government ocials or Internet Service Providers, as Nintendo believes in its sole
discretion, is necessary or appropriate to investigate or resolve possible problems or inquiries, or as otherwise required by law.
This product includes RSA BSAFE® Cryptographic software of EMC Corporation. RSA and
BSAFE are registered trademarks or trademarks of EMC Corporation in the United States
and other countries. ©2005 EMC Corporation. All rights reserved.
SDHC Logo is a trademark of SD-3C, LLC.
This product uses certain fonts provided by Fontworks Inc.
This product includes speech rate conversion software developed by Toshiba corporation.
Copyright ©2008 TOSHIBA CORPORATION
“QR code reader” includes software deliverables of Information System Products Co., Ltd.
and Institute of Super Compression Technologies, Inc. QR Code is a registered trademark of
DENSO WAVE INCORPORATED in JAPAN and other countries.
“ “ and AOSS™ are the trademarks of BUFFALO INC.
“Yahoo!” and the Yahoo! logo are registered trademarks of Yahoo! Inc.
Google™ search is a trademark of Google Inc.
This product contains NetFront Browser NX of ACCESS CO., LTD.
ACCESS, ACCESS logo and NetFront are registered trademarks or trademarks of ACCESS
CO., LTD. in the United States, Japan and/or other countries. © 2011 ACCESS CO., LTD. All
rights reserved.
THIS PRODUCT IS LICENSED UNDER THE MPEG-4 SYSTEMS PATENT PORTFOLIO LICENSE
FOR ENCODING IN COMPLIANCE WITH THE MPEG-4 SYSTEMS STANDARD. EXCEPT THAT
AN ADDITIONAL LICENSE AND PAYMENT OF ROYALTIES ARE NECESSARY FOR ENCODING IN
CONNECTION WITH (i) DATA STORED OR REPLICATED IN PHYSICAL MEDIA WHICH IS PAID FOR
ON A TITLE BY TITLE BASIS AND/OR (ii) DATA WHICH IS PAID FOR ON A TITLE BY TITLE BASIS
AND IS TRANSMITTED TO AN END USER FOR PERMANENT STORAGE AND/OR USE. SUCH
ADDITIONAL LICENSE MAY BE OBTAINED FROM MPEG LA, LLC. SEE <HTTP://WWW.MPEGLA.
COM> FOR ADDITIONAL DETAILS.
Ubiquitous TCP/IP+SSL Copyright ©2001-2010 Ubiquitous Corp.
Powered by Devicescape Software. Portions of this products are © 2003-2010 Devicescape
Software, Inc. All rights reserved.
Copyright ©2003-2010, Jouni Malinen <j@w1.> and contributors All Rights Reserved.
WPA Supplicant licensed pursuant to BSD License.
Redistribution and use in source and binary forms, with or without modication, are
permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
3. Neither the name(s) of the above-listed copyright holder(s) nor the names of its contribu-
tors may be used to endorse or promote products derived from this software without
specic prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS ”AS IS” AND
ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR
ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON
ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE,
EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
This product includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit. (http://www.openssl.org/). Copyright ©1998-2007 The OpenSSL Project. All
rights reserved.
Redistribution and use in source and binary forms, with or without modication, are
permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
3. All advertising materials mentioning features or use of this software must display the
following acknowledgment: ”This product includes software developed by the OpenSSL
Project for use in the OpenSSL Toolkit. (http://www.openssl.org/)”
4. The names ”OpenSSL Toolkit” and ”OpenSSL Project” must not be used to endorse or
promote products derived from this software without prior written permission. For
written permission, please contact openssl-core@openssl.org.
5. Products derived from this software may not be called ”OpenSSL” nor may ”OpenSSL”
appear in their names without prior written permission of the OpenSSL Project.
6. Redistributions of any form whatsoever must retain the following acknowledgment:
This product includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit (http://www.openssl.org/)
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS” AND ANY EXPRESS OR
IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO
EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING,
BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE,
DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR
OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGE.
This product includes cryptographic software written by Eric Young. Copyright ©1995-1998
Eric Young (eay@cryptsoft.com). All rights reserved.
This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The
implementation was written so as to conform with Netscapes SSL.
This library is free for commercial and non-commercial use as long as the following condi-
tions are adhered to. The following conditions apply to all code found in this distribution,
be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code. The SSL documentation
included with this distribution is covered by the same copyright terms except that the holder
is Tim Hudson (tjh@cryptsoft.com).
Copyright remains Eric Young’s, and as such any Copyright notices in the code are not to
be removed. If this package is used in a product, Eric Young should be given attribution as
the author of the parts of the library used. This can be in the form of a textual message at
program startup or in documentation (online or textual) provided with the package.
Redistribution and use in source and binary forms, with or without modication, are
permitted provided that the following conditions are met:
1. Redistributions of source code must retain the copyright notice, this list of conditions
and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
3. All advertising materials mentioning features or use of this software must display the
following acknowledgement: ”This product includes cryptographic software written by
Eric Young (eay@cryptsoft.com)” The word ‘cryptographic’ can be left out if the routines
from the library being used are not cryptographic related :-).
4. If you include any Windows specic code (or a derivative thereof) from the apps direc-
tory (application code) you must include an acknowledgement: This product includes
software written by Tim Hudson (tjh@cryptsoft.com).
THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ”AS IS” AND ANY EXPRESS OR IMPLIED
WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANT-
ABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL
THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR
BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER
IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING
IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGE.
The licence and distribution terms for any publicly available version or derivative of this
code cannot be changed. i.e. this code cannot simply be copied and put under another
distribution licence [including the GNU Public Licence.]
This product uses the LC Font by Sharp Corporation. LCFONT, LC Font and the LC logo mark
are trademarks of Sharp Corporation.
The Wi-Fi CERTIFIED logo, Wi-Fi Protected Access® (WPA and WPA2), and the Wi-Fi
Protected Setup icon are registered trademarks of the Wi-Fi Alliance.
Legal Notices
Consumer Information
Consumer Information
7978
Specications
Specications
Specications
Nintendo 2DS system
FTR-001
Upper Screen: Widescreen LCD display, capable of displaying approximately 16.77 mil-
lion colors. 3.53-inch display (76.8 mm horizontal x 46.08 mm vertical) with 400x240
pixel resolution.
Lower Screen: LCD Touch Screen, capable of displaying approximately 16.77 million
colors. 3.02-inch display (61.44 mm horizontal x 46.08 mm vertical) with 320x240
pixel resolution.
AC adapter (WAP-002 (USA)), Battery pack (CTR-003)
2.4GHz band
IEEE802.11b/g
Within 98’ (30 m). Depending on surrounding conditions, this distance may be less.
Lens: Single focus. Capture element: CMOS. Active pixel count: Approx. 300,000 pixels.
Maximum daily variance: ± 4 seconds
Monaural
Game Card slot, SD Card slot, AC adapter connector, and stereo headphone output jack
Motion sensor, gyro sensor
Within 8” (20 cm). Depending on surrounding conditions, this distance may be less.
Approximately 4.1W (while charging)
Temperature, 41˚F – 95˚F (5˚C – 35˚C) / humidity, 20-80 percent
Height: 127 mm / width: 144 mm / thickness: 20.3 mm
Approximately 260 g (including battery pack, stylus , and SD Card)
Approx. 3 hours and 30 minutes
Please see page 17.
Model name:
LCD screens
(Screen size/pixel count):
Power source:
Wireless frequency:
Wireless standards:
Recommended wireless distance:
Camera functions:
Clock features:
Speaker:
Input/output:
Sensors:
Infrared communications:
Maximum power consumption:
Operating environment:
Dimensions:
Weight:
Charge time:
Battery endurance:
Model name: CTR-003
Battery type: Lithium-Ion
Power capacity: 5Wh
Nintendo 3DS battery pack
Nintendo 3DS AC adapter
Model name: WAP-002 (USA)
Input: 120V 60Hz 7W
Output: DC 4.6V 900mA
Dimensions: Height: 67.5 mm / width: 47.7 mm / thickness:23.0 mm
Weight: Approximately 80 g
Cord length: Approximately 1.9 m
Compatible products: Nintendo 2DS, Nintendo 3DS XL, Nintendo 3DS, Nintendo DSi XL, Nintendo DSi

Navigation menu
