Ver.1.0
Jan 11, 2012
MIWA LOCK CO., LTD.
User Manual
Product Name Contactless Smart Card Reader
Model RDFL-B03
![](/img.php?id=1641971&img=bg2.png)
User Manual
MIWA LOCK CO., LTD. 2
1
11
1.
..
.APPLICATIONS
These manual describe the contactless smart card reader “RDFL-B03” which is a reading device for
exclusive use of the card key for Hotel Card Lock `ALV2” and manage the guest Room and the facilities
of the Hotel.
2
22
2.
..
.SUMMARY
2-1.Contactless Smart Card Reader
(1) This is card reader for exclusive use of the entrance of the Hotel Card Lock “ALV2” , which
reads key data of the card key and output the signal.
(2) When a contactless smart card issued by card issuing machine installed in the front desk is
used, it collates the various information such as a Hotel code and room number with stored data.
If the card is confirmed valid, it output the signal to the external system.
3
33
3.
..
.GENERAL SPECIFICATIONS
Specifications
Model RDFL-B03
Dimensions
Panel
116(W) , 120(H) , 7(D)
Main body
90(W) , 70(H) , 35(D)
Weight 250g approximately
Materials Panel : Acrylic
Main body : ABS resin
Power supply supplied from a controller
Operation temperature -10~50℃
Safekeeping temperature
-10~60℃
Operation humidity 20~90%RH Without condensation
Target card ISO14443 TYPE-A, TYPE-B, FeliCa
™
![](/img.php?id=1641971&img=bg3.png)
User Manual
MIWA LOCK CO., LTD. 3
4
44
4.
..
.Detail of function
(1) Bring a card key close to the contactless smart card reader.
(2) The contactless smart card reader reads the key data and if the data accords with the database,
signal is sent the external system.
Collation data:
1) Hotel code
2) Validity of the card key. (from check-in time to check-out time)
3) Room number of the key.
(3)If the card key is valid, the LED lights blue. In case of invalid card key, the LED lights red.
![](/img.php?id=1641971&img=bg4.png)
User Manual
MIWA LOCK CO., LTD. 4
5. Regulatory Compliance
5-1. USA-Federal Communications Commission (FCC)
This unit has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This unit generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this unit does cause harmful interference to radio or television reception,
which can be determined by turning the unit off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the unit and receiver.
- Connect the unit into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This unit complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This unit may not cause harmful interference, and (2) This unit must accept any interference
received, including interference that may cause undesired operation.
Caution:
Any changes or modifications not expressly approved by the party responsible for product compliance
could void the user's authority to operate the unit.
Labelling
MIWA LOCK contactless smart card reader is labelled as below.
FCC ID: VBU-RDFL-B03
