User Manual(English)
Thank you
Thank you for purchasing the MobiFren GBH-M100 Bluetooth Headset. We hope you enjoy it!
Please read the manual before use.
About your MobiFren GBH-M100
1. LED light
- Blue indicates mode(pairing, active or standby, charged)
- Red indicates battery level(low charge,charging)
2. Volume up(+), Volume down(-)
3. Charging socket(Ultra mini USB Socket)
4. Answer/end Press 6 seconds to put headset into pairing mode
5. Answer/end button
-Press 3 seconds to turn headset on(Blue flash burst indicates success)
-Press and hold 3 seconds to turn headset off(Blue flash burst indicates success)
-Tap to answer or end a call
What your headset can do
Your MobiFren GBH-M100 lets you do all this dependent on your phone supporting the function:
-Answer calls
-End calls
-Reject calls
-Voice dialing
-Last number redialing
소유권자 : GT텔레콤 대표
사용권자 : GT텔레콤 개발실장
표준서식 GTA-003('05-01-31)
-Call waiting
-Put call on hold
Specifications
-Up to 5hours30minutes talk time/standby time up to Max 60 days.
-Rechargeable battery with charging option from AC power supply, PC via USB cable, desktop charger or car charger
(not included)
-Less than 10grams
-Operating range up to 10meters(approx.33 feet)
-Headset and handsfree Bluetooth profiles
-Bluetooth specification version 2.0
GETTING STARTED
MobiFren GBH-M100 is easy to operate. The answer/end button on the headset performs different functions depending on how long
you press it.
Instruction : Duration of press
Tap Press briefly
Press Approx:1 second
Press and hold Approx:Up to 3 second
Charge your headset
Make sure that your MobiFren GBH-M100 is fully charged before you start using it. Use the AC adaptor charge from a power
socket, or charge directly from your PC with the Ultra mini USB cable provided.
When the LED is solid red, your headset is charging. When the LED is blue, it is fully charged.
Pair it with your phone
소유권자 : GT텔레콤 대표
사용권자 : GT텔레콤 개발실장
표준서식 GTA-003('05-01-31)
Before you use your MobiFren GBH-M100, you need to pair it with your mobile phone.
1. Put the headset in pairing mode
-Press SEND/END button for about 6 seconds from power off mode.
-Check LED is continuously on with blue color.
2. Set your Bluetooth phone to 'discover' the MobiFren GBH-M100
Follow your phone's instruction guide. This usually involves going to a 'setup', 'connect' or Bluetooth' menu on your phone
and selecting the option to 'discover' or 'add' a Bluetooth device.
3. Your phone will find the MobiFren GBH-M100
Your phone then asks if you want pair with it. Accept by pressing 'Yes'
or 'OK' on the phone and confirm with the passkey or PIN=0000(4 zeros)
Your phone will confirm when pairing is complete. In case of unsuccessful pairing, repeat steps 1 to 3.
For optimal performance,wear the MobiFren GBH-M100 and your mobile phone on the same side of your body or within line of sight.
In general,you will get better performance when there are no obstructions between your headset and your mobile phone.
5. How to
Answer a call
-Tap the send/end button on your headset to answer a call
End a call
-Tap the send/end button to end an active call
Maker a call
-When you make a call from your mobile phone, the call will(subject to phone sttings) automatically transfer to your headset
If your phone does not allow this feature, trap on the MobiFren GBH-M100's send/end button to transfer the call to the headset
Reject a call
Press the answer/end button when the phone rings to reject an incoming call. Depending on your phone settings, the person who
called you will either be forwarded your voice or hear a busy signal.
소유권자 : GT텔레콤 대표
사용권자 : GT텔레콤 개발실장
표준서식 GTA-003('05-01-31)
Activate voice dialing
- Tap the send/end button more than 1 second. For the best result, record the voice-dialing tag through your headset .
Please consult your phone's user manual for information about using this feature.
Redial last number
Press the send/end button.
Adjust sound and volume
-Press the volume up or down(+ or -) to adjust the volume.
Call waiting and placing a call on hold
Call waiting and placing a call on hold
This lets you put a call on hold during a conversation and answer a incoming call.
-Press the send/end button once to put the first call on hold and answer the waiting call.
-Press the send/end button to switch the two calls.
-Tap the send/end button to end the active conversation.
What the lights mean
What you see What is the mean about your headset
Flashing blue light Flashing every second: Active on a call
Flashing blue light Flashing every second: Active on a call
Flashing blue light Running low on battery
Solid red light Charging
Solid green light Fully charged
Solid blue light In pairing mode
Troubleshooting & FAQ
I hear cracking noises.
소유권자 : GT텔레콤 대표
사용권자 : GT텔레콤 개발실장
표준서식 GTA-003('05-01-31)
For the best audio quality,always wear in your headset on the same side of the body as your mobile phone.
I cannot hear anything in my headset
-Increase the volume on the headset
-Ensure that the headset is paired with the phone.
-Make sure that the phone is connected to the headset-if it does not connect either from the phone's Bluetooth menu or by
tapping the answer/end button,follow the pairing procedure.
I have pairing problems even though my phone indicates otherwise
You may have deleted your headset pairing connection in your mobile phone.
Follow the pairing instructions in section 3
Will the MobiFren GBH-M100 work with other Bluetooth equipment?
The MobiFren GBH-M100 is designed to work with Bluetooth mobile phones. It can also work with other Bluetooth devices that are
compliant with Bluetooth version 1.1 or 1.2 and support a headset and /or handsfree profile.
Neee more help?
See the inside cover for your country's support details.
Taking care of your headset
-Always store the MobiFren GBH-M100 with the power off and protected.
-Avoid storage at extreme temperature(above 45℃//113℉-including direct sunlight-or -10℃/14℉)
This can shorten battery life and may affect operation. High temperatures may also degrade performance.
-Do not expose the MobiFren GBH-M100 to rain or other liquids.
소유권자 : GT텔레콤 대표
사용권자 : GT텔레콤 개발실장
표준서식 GTA-003('05-01-31)
Specification
Specification Remark
Radio
yChannel : 79Channel(1MHz Spacing)
yFrequency Range : 2.402GHz~2.480MHz
yPower Class : Class 2(Type -6 - +4dBm)
yRange :Max. 10m
yFrequency : ISM Band(2.4GHz)
Mechanics yDimension(H×W×D) : 60 × 19 × 14.8(mm)
Electronics
yOperating Voltage:3~4.2V
yTalk Time : Approximately 5hours 30minutes
yStandby Time : Approximately 130hours
yCharging Time : Approximately 2hours 30minutes
yCharging Voltage : 4.5V ~ 5.75V
yTemperature :
Storage :-25℃ up to +85℃
Operation :-10℃ up to +50℃
Battery : 85mA
Function
yButton 3
(Power/Talk & Volume up & Volume down)
yLED 1(2 Color(Blue/Red) LED)(operating/Battery)
yOther : Receiver/ MIC / Battery
