User manual 2 of 2

11
2. Multi point setting
※ It's possible to connect and use 2 devices simultaneously
3. Call
※Depending on mobile phone models, the above functions may be different.
Please refer to mobile phone manual.
1) Answering a call
- Press button to answer a call.
2) Ending a call
- Press button shortly to end a call.
5) Volume control
3) Rejecting a call
- During an incoming call, press button for about 1 second.
4) Converting a call
During call with mobile, press button to convert to headphone.
(To call with mobile again, use your mobile phone menu.)
- During call, if you press or button for about 1 second, the microphone
becomes mute.
-
During mute, it will be released, if you press or button for about 1 second.
6) Microphone Mute
/
- With button, you can control volume.
1) Setting Multi point
- Please pair Bluetooth earphone to the first device according to the pairing
process.(Refer to pairing process.)
- Turn off Bluetooth headphone.
- Press button for around 4 seconds till blue LED is continuously on.
-
Please pair Bluetooth earphone to 2nd device according to pairing process.
-
Then, turn off Bluetooth headphone and turn on again, it will be connected 2 devices.
2) To use multi point
- At the status of connecting two devices, press button to answer a call if
there's incoming call.
- At the status of connecting two devices, press button to listen the music
that was played lately.
※ During multi point status, please refer that App related functions are not workable.
12
6. Changing EQ
- While playing music, if you press MFB button and ( ) button
at the same time for 1 second, the EQ changes.
- MSTS™ Tuning technology together with lossless compression apt-X codec)
c
odec enables you to enjoy not only MobiFren sound but similar sound quality
of various kinds of famous high end wired headphones and you can select
EQ for your preference. Now you can enjoy music with the optimum sound
quality like as CD in wireless.
or +
※ There are several kinds of bit rate even though it's the same MP3 file.
If the file source is higher bit rate(320K) for listening, you can feel the real
worth for our Bluetooth headphone. And, if the speaker is not good even
with good source, the sound quality will not be good, and if the speaker is
good with inferior source, the sound quality can't touch to the listener.
The MobiFren headphone of optimized tuning supplies you high quality
sound, but, we also recommend you to use high resolution source file
(320K) to enjoy touching sound.
MobiFren Mode (Normal) : MobiFren's pursing tune
Bass Boost Mode : for those who like deep bass
Cinema Mode : for those who want to enjoy 3D surround sound
Special EQ modes supplied by MobiFren
5. Playing music
4. Factory Reset
※ To enjoy the best audio quality, please set 70~80% from the max
volume in your device.
- On first purchasing, the volume sets in level 10 of all 15 levels.
(Please adjust with button for volume. )
Play / Pause : button shortly Press
Stop : Give a button long press
Volume up : Press button shortly
Next song : Give a button long press
Volume down : Press button shortly
Previous song : Give a button long press
Press buttons in order,
then, purple LED glitters and headset will be initialized.
Pair the headset again to use after factory reset.
+ + + +
13
- Last Call (Direct call to the latest number)
It's for direct call to the latest number that you used.
- Hot call (Prompt call)
It's for prompt call to the frequent number.
- Find mobile phone
If you can't remember well where you placed your mobile phone,
press and buttons
at the same time for about 1 second to find out your mobile phone.
Then, the mobile phone will ring.
- Camera Remote control
Press or button shortly to take a picture after running application.
(It needs additional MobiFren camera application.)
Last Call /Hot Call
●
Press button shortly for 2 times.
7. Using Android App.
- SMS/SNS message TTS
- TTS caller ID
If you press or button shortly when there's an incoming call,
you can listen the caller's name via mobile phone speaker.
For more convenient and easy use of the headphone, please download
"MobiFren_GT" at Google play store
- After setting Message TTS, in automatic mode, it reads you message
after the setting time, and in manual mode, you can hear message by
using headset button.
(When you set this function, it goes to mobile phone's accessibility
menu automatically, then, select MobiFren_GT in accessibility service.)
Stop while playing TTS : TTS playing stop.
Manual mode : It reads you message by pressing headset button.
While reading TTS message, press , + button to stop playing.
Press MFB button and , + at the same time to hear message manually.
4. What does LED color mean?
14
Status LED indication
Standby
Battery is running low
Charging
Fully charged
Pairing mode
Blinks red light
Red light ON
Blue light ON
Blue light ON
LED OFF
(If press button, blue LED blinks once.)
5. FAQ & Troubleshooting
15
※I hear crackling noises
- For the best audio quality, always locate your headphone close to
mobile phone.
※ I cannot hear anything
- Increase the volume on the headphone.
- Ensure that the headphone is paired with the phone.
- Make sure that the phone is connected to the headphone.
- If the headphone fails to connect when you pressed MFB,
try to connect again following the pairing procedure.
※I have problems with pairing even though my phone indicates otherwise.
- Please delete the headphone paired in your mobile and pair the
headphone again.
Please refer to set up “Pairing mode”.
※ Will the MobiFren GBH-S3000 series work with other Bluetooth equipment?
-
The MobiFren GBH-S3000 series is designed to work with Bluetooth mobile,
computer or portable audio devices which are built in. It can also work
with other Bluetooth devices that are compliant with Bluetooth version
1.1/ 1.2/ 2.0/2.1+EDR/3.0 and that support HSP, HFP, A2DP and AVRCP.
※Is the enclosed charging cable for only specified device?
- It’s compatible with all standardized micro USB charger, and in general,
compatible with Android mobile phone charger.
※When you use the headphone in the car, the handsfree can be affected
by the internal noise.
6. Handle MobiFren with care
16
Always store the MobiFren ear
phone with the power off and
protect safely when it’s not in use.
can affect the MobiFren’s battery
life and may be the cause of
malfunction.
High temperature may also degrade
performance.
Do not expose the MobiFren
earphone to rain or other liquids
Prevent baby, children or pets to
bite or suck this headset
Please do not disassemble at
user’s option
Please make sure to use certif ied
charger. (Rated Voltage : 5V)
5V, 140mA
7. Certification and safety approvals
17
FCC ID : UZCGBH-S3100
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules.
These limits are designed to pro-vide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not in-stalled
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is encou
raged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different
from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION : Changes or modifications not expressly approved
by the manufacturer responsible for compliance
could void the user’s authority to operate the equipment.
This device comply with part15 of FCC rules.
Operation is subject to the following two conditions:
•This device may not cause harmful interference.
•This device must accept any interference received, including
interference that may cause undesired operation.
8. Specifications
18
•Model
GBH-S3000 Series
•
Talk time
•Music play time
•
Standby time
•Charging time
•
Size
About 9 hrs
About 7.5 hrs
About 10 days
about 1.5 hours
9.8mm(W) X 58mm(L) X 6.2mm(T)
570mm(cable length)
•Battery
•Operation range
•
Bluetooth profile
•
Weight
•
Bluetooth profile
Rechargeable Lithium Polymer(DC 3.7 V)
Within 10m
about 13g
Headset profile
Headset profile
A2DP
AVRCP
SPP
Ver. 3.0
※Operation time may be variable, depending on connected device or setting status.
Made in Korea
In accordance with the R & TTE Directive 1999 / 5 / EC of 09. March 1999
9. Warranty
19
※ The conditions and our responsibilities under this warranty are
as follows :
•The warranty is limited to the original purchaser.
•A copy of your receipt or other proof of purchase is required.
•
The warranty is void if the serial number, date code
label or
product label is removed, or if the product
has been subject
to physical abuse, improper installation, modification, or repair by
unautho rized third parties.
•The responsibility of MobiFren products shall be limited to
the repair or replacement of the product at its sole discretion.
•
Any implied warranty on MobiFren products is limited
to one year
from the date of purchase on all parts, including any cord and connector.
But, battery warranty is limited to 6 months.
•
Specifically exempt from any warranty are limited-life consumable
components subject to normal wear and tear, such as microphone
windscreens, ear cushions, decorative finishes, batteries, and other
accessories.
•
MobiFren is not liable for any incidental or consequential
damages
arising from the use or misuse of any MobiFren product.
•
This warranty gives you specific rights and you may have other rights
which vary from area to area.
•
Unless otherwise instructed in the User Manual, the user may not,
under any circumstances, attempt to perform service, adjustm
ents or repairs on this unit, whether in or out of warranty.
It must be returned to the purchase point, factory or authorized service
agency for all such work.
•MobiFren will not take any responsibility for any loss or damage
incurred in shipping.
Any repair work on MobiFren products by unauthorized third parties
voids any warranty.
" Contribute to our communities
with good technology and good product "
MADE IN KOREA
ISO 9001 Quality Management System
Certified Company
MSIP-CRM-GTT-GBH-S3100
www.mobifren.com
(Gupyeong Dong A & B dong), 88, Indong 52 Gil,
Gumi City, Gyeongbuk, Korea 730-300
TEL : 82-54-474-2220 FAX : 82-54-474-2251
GT Telecom Co., Ltd.
3.7V
,
