Mobile Action Technology Inc. Bluetooth 4.0 Low Energy Wristband
User Manual
Device Overview
How to wear your Q-72 ?
User ManualQ-72 Q-Watch
EN
Wear Q-72 on your wrist
1 2
3Charge your Q-72
Fasten Q-72 with clasp
Put on the watch with the watch face facing up and wrap the
band around your wrist. Align the clasp end with the holes on
the band to measure the best fit on your wrist.
Fasten the clasp through the appropriate holes on the band. Try
it out on your wrist for best fit and adjust accordingly.
To charge your Q-72 , place it in the charging box at the
other end of the USB cable. Close the box afterwards, and
make sure the Q-72 is securely covered. Plug the USB
connector to either a PC or power adapter to start charging.
1
2
3
Wristband Clasp
Core
Button
Metallic contact for charging
Get started with Q-72
Download and Install i-gotU Life app
1 2
3 4
Start Using Q-72
Set up Q-72
Features of Q-72 & i-gotU Life App
User ManualQ-72 Q-Watch
Please download i-gotU Life app from Google Play or the App Store
and have it installed on your smartphone:
https://play.google.com/store/apps/details?id=com.mobileaction.ilife
http://appstore.com/igotulife
Apk download: http://global.mobileaction.com/download/apk
Supported device
Any Android smartphone (v4.3 and up) with built-in 4.0
Bluetooth connectivity; or
iPhone 4s and later models, iPad 2 and later models,
and iPod Touch (all with iOS version 7.0 and up).
A complete list of supported smartphone or mobile
devices can be found at:
http://ww2.voiis.com/qband/devices.html
Important Notice
Please make sure your Q-72 is fully charged when used for
the first time. It takes about 2 hours before it is fully
charged.
Please do not use under water.
Please do not use any corrosive chemical to clean the device.
1.
2.
3.
Your Q-72 can be configured directly on the i-gotU Life app.
First time setup:
Open the i-gotU Life app.
A Setup Wizard will be launched automatically.
Follow the on-screen instructions to proceed with more settings.
Set up a new device from Settings:
Open the i-gotU Life app.
Tap the app icon at the upper left corner to open function menu.
Choose Settings.
Tap Setup New Device under MORE DEVICE SETTINGS.
Follow the on-screen instructions to continue.
Note
Your personal information is used to calculate your Base Metabolic
Rate (BMR), which determines your calories burned.
1.
2.
3.
1.
2.
3.
4.
5.
1. Switch between different function modes
2. Change display information
3. Q-72 modes
1. Long-press the button on the Q-72 until you see 4 icons
on the screen for mode selection.
2. Press the button to switch mode.
3. You’ll be entering the selected mode in 3 seconds.
Information shown on the screen will vary as you press the button on
the Q-72 to toggle between screens.
Daily mode: Analyzes your daily data, including steps taken
and calories burned, and displays current UV index.
Sleep mode: Tracks your sleep pattern and quality.
Sports mode: Starts a workout and displays information
including duration, steps taken, calories burned, UV-index and
distance traveled during the workout.
Nap mode: Awakes you via vibration after a short nap.
Connection Status
Progress
Battery Status
UV – Index
1.
2.
3.
4.
Silent Alarm
Notification
Remote Display (Android only)
Online Help
Silent Alarm awakes you using gentle vibrations of the Q-72.
You can dismiss the alarm by long-pressing the button on the Q-72.
In case you miss the alarm, Q-72 will alert you again in 5 minutes.
Alarms can be set up from: i-gotU Life App Menu -> Silent Alarm.
You will be notified with incoming calls, SMS, E-Mail, or alerts from
the social apps via vibration. When notified about an incoming call
on an Android smartphone, you may reject the call by long-pressing
the button on Q-72. Notification can be set up from: i-gotU Life App
Menu -> Notification.
Please download i-gotU Sports app from Google Play
and have it installed on your Android smartphone:
After starting an activity on i-gotU Sports app, selected sports
data from i-gotU Life app will be displayed on Q-72.
Remote Display can be set up from: i-gotU Life App Menu
->Remote Display.
The screen can be rotated by changing the settings from: i-gotU
Life App Menu ->Settings -> MORE DEVICE SETTINGS -> Screen
Rotation.
Android: http://ww2.voiis.com/igotu-life/help.html?language=en
iOS: http://ww2.voiis.com/igotu-life/help.html?language=en&platform=ios
https://play.google.com/store/apps/details?id=com.mobileaction.isports
http://global.mobileaction.com/download/apk
Note on environmental protection:
After the implementation of the European Directive 2002/96/EU in the
national legal system, the following applies:
Electrical and electronic devices may not be disposed of with domestic
Waste. Consumers are obliged by law to return electrical and electronic
devices at the end of their service lives to the public collecting points set up
for this purpose or point of sale. Details to this are defined by the national
law of the respective country. This symbol on the product, the instruction
manual or the package indicates that a product is subject to these
regulations. By recycling, reusing the materials or other forms of utilizing old
devices, you are making an important contribution to protecting our
environment.
WEEE
•
•
•
4. Icon description
User ManualQ-72 Q-Watch
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by the part
responsible for compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference and
2) this device must accept any interference received, including interference that may
cause undesired operation of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating instructions
for satisfying RF exposure compliance. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
Operating temperature -10° to 65°C (14° to 149°F)
Charging temperature 0° to 45°C (32° to 113°F)
Power input type DC 5V USB cable
Battery type Rechargeable Li-Poly, 3.7 Vdc
Input Maximum DC 5V, 0.1A
