Mobile Action Technology Inc. Bluetooth 4.0 Low Energy Wristband
User Manual
Device Overview
How to wear your Q-77?
User ManualQ-77 Q-Watch
EN
3 4
Charge your Q-77 Change the watch band
Put on the watch with the watch face facing up and wrap the band
around your wrist. Snap the metal fastening buttons into two of the
holes on the other strap to adjust the fit on your wrist.
Slide the end of the strap through the loop, and slide the loop anywhere you
like alongside the strap. The two metal fastening buttons are removable and
can be relocated to any other holes on the strap as you prefer.
To charge your Q-77, place it in the charging box at the
other end of the USB cable. Close the box afterwards, and
make sure the Q-77 is securely covered. Plug the USB
connector to either a PC or power adapter to start charging.
To change the watch band, please consult a watch dealer for assistance
on choosing the right size of watch band for a change. Make sure the
replacement band comes with the following measurements:
Width: ≤ 20 mm
Thickness: ≤ 4 mm
Wear Q-77 on your wrist
1 2 Fasten Q-77 with clasp
Wristband ClaspCore
Button
20 mm
4 mm
1
2
3
Metallic contact for charging
Get started with Q-77
Download and Install i-gotU Life app
1 2
3 4
Start Using Q-77
Set up Q-77
Features of Q-77 & i-gotU Life App
User ManualQ-77 Q-Watch
Please download i-gotU Life app from Google Play or the App Store
and have it installed on your smartphone:
https://play.google.com/store/apps/details?id=com.mobileaction.ilife
http://appstore.com/igotulife
Apk download: http://global.mobileaction.com/download/apk
Supported device
Any Android smartphone (v4.3 and up) with built-in 4.0
Bluetooth connectivity; or
iPhone 4s and later models, iPad 2 and later models,
and iPod Touch (all with iOS version 7.0 and up).
A complete list of supported smartphone or mobile
devices can be found at:
http://ww2.voiis.com/qband/devices.html
Important Notice
Please make sure your Q-77 is fully charged when used for the first
time. It takes about 2 hours before it is fully charged.
Please do not use under water.
Please do not use any corrosive chemical to clean the device.
The built-in Li-Polymer Battery might be damaged if it remains low
voltage for a long time. It is suggested that you charge the battery
once every three months to prolong the battery's lifetime, even though
you don't use the device very often or do not plan to use it for a while.
1.
2.
3.
4.
Your Q-77 can be configured directly on the i-gotU Life app.
First time setup:
Open the i-gotU Life app.
A Setup Wizard will be launched automatically.
Follow the on-screen instructions to proceed with more settings.
Set up a new device from Settings:
Open the i-gotU Life app.
Tap the app icon at the upper left corner to open function menu.
Choose Settings.
Tap Setup New Device under MORE DEVICE SETTINGS.
Follow the on-screen instructions to continue.
Note
Your personal information is used to calculate your Base Metabolic
Rate (BMR), which determines your calories burned.
1.
2.
3.
1.
2.
3.
4.
5.
1. Switch between different function modes
2. Change display information
3. Q-77 modes
1. Long-press the button on the Q-77 until you see 4 icons
on the screen for mode selection.
2. Press the button to switch mode.
3. You’ll be entering the selected mode in 3 seconds.
Information shown on the screen will vary as you press the button on
the Q-77 to toggle between screens.
Daily mode: Analyzes your daily data, including steps taken
and calories burned, and displays current UV index.
Sleep mode: Tracks your sleep pattern and quality.
Sports mode: Starts a workout and displays information
including duration, steps taken, calories burned, UV-index and
distance traveled during the workout.
Nap mode: Awakes you via vibration after a short nap.
Connection Status
Progress
Battery Status
UV – Index
Silent Alarm
Notification
Online Help
Silent Alarm awakes you using gentle vibrations of the Q-77.
You can dismiss the alarm by long-pressing the button on the Q-77.
In case you miss the alarm, Q-77 will alert you again in 5 minutes.
Alarms can be set up from: i-gotU Life App Menu -> Silent Alarm.
You will be notified with incoming calls, SMS, E-Mail, or alerts from
the social apps via vibration. When notified about an incoming call
on an Android smartphone, you may reject the call by long-pressing
the button on Q-77. Notification can be set up from: i-gotU Life App
Menu -> Notification.
Android: http://ww2.voiis.com/igotu-life/help.html?language=en
iOS: http://ww2.voiis.com/igotu-life/help.html?language=en&platform=ios
Note on environmental protection:
After the implementation of the European Directive 2002/96/EU in the
national legal system, the following applies:
Electrical and electronic devices may not be disposed of with domestic
Waste. Consumers are obliged by law to return electrical and electronic
devices at the end of their service lives to the public collecting points set up
for this purpose or point of sale. Details to this are defined by the national
law of the respective country. This symbol on the product, the instruction
manual or the package indicates that a product is subject to these
regulations. By recycling, reusing the materials or other forms of utilizing old
devices, you are making an important contribution to protecting our
environment.
WEEE
•
•
•
4. Icon description
User ManualQ-77 Q-Watch
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by the part
responsible for compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
1) this device may not cause harmful interference and
2) this device must accept any interference received, including interference that may
cause undesired operation of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF
exposure compliance. This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
Operating temperature:-10° to 65°C (14° to 149°F)
Charging temperature:0° to 45°C (32° to 113°F)
Power input type:DC 5V USB cable
Battery type:Rechargeable Li-Poly, 3.7 Vdc
Input:Maximum DC 5V, 0.1A
