Mobile Action Technology 16H66R1 Bluetooth 4.0 Low Energy Wristband User Manual
Mobile Action Technology Inc. Bluetooth 4.0 Low Energy Wristband
User Manual
![](/img.php?id=3045402&img=bg1.png)
Device Overview
How to wear your Q-66HR?
User ManualQ-66HR Q-Band
EN
Wear Q-66HR on your wrist
1 2
3 4
Charge your Q-66HR
Fasten Q-66HR with clasp
Change the wristband
Put on the wristband with the screen facing up and the band
wrapped around your wrist. Align the clasp along the band to
find the holes where best fit the clasps.
Squeeze both clasps into the holes on the wristband until you
hear a click, indicating the band is securely fastened.
Spread open both bands with the screen facing up, and press down the screen
with your thumb until the core comes off the wristband.
Insert the core with screen facing up into the notch from below the wristband.
Make sure the two tenons on each side of the core are securely fixed into the
corresponding slots in the bands.
Button up the clasp on the side of the band with 2 holes. Please note that the
charging contact should be near the clasp.
Important Notice:
Failure to follow the instructions above might cause damage to the device.
1.
2.
3.
1
1
2
32
Wristband
Clasp
Core
Touch Button
Metallic contact for charging
Optical Sensor
To charge your Q-66HR, place it in the charging box at the
other end of the USB cable. Close the box afterwards, and
make sure the Q-66HR is securely covered. Plug the USB
connector to either a PC or power adapter to start charging.
![](/img.php?id=3045402&img=bg2.png)
Get started with Q-66HR
Download and Install i-gotU Life app
1 2
3 4
Start Using Q-66HR
Set up Q-66HR
Features of Q-66HR & i-gotU Life App
User ManualQ-66HR Q-Band
Please download i-gotU Life app from Google Play or the App Store
and have it installed on your smartphone:
https://play.google.com/store/apps/details?id=com.mobileaction.ilife
http://appstore.com/igotulife
Apk download: http://global.mobileaction.com/download/apk
Supported device
Any Android smartphone (v4.3 and up) with built-in 4.0
Bluetooth connectivity; or
iPhone 4s and later models, iPad 2 and later models,
and iPod Touch (all with iOS version 7.0 and up).
A complete list of supported smartphone or mobile
devices can be found at:
http://ww2.voiis.com/qband/devices.html
Your Q-66HR can be configured directly on the i-gotU Life app.
First time setup:
Open the i-gotU Life app.
A Setup Wizard will be launched automatically.
Follow the on-screen instructions to proceed with more settings.
Set up a new device from Settings:
Open the i-gotU Life app.
Tap the app icon at the upper left corner to open function menu.
Choose Settings.
Tap Setup New Device under MORE DEVICE SETTINGS.
Follow the on-screen instructions to continue.
Note
Your personal information is used to calculate your Base Metabolic
Rate (BMR), which determines your calories burned.
1.
2.
3.
1.
2.
3.
4.
5.
1. Switch between different function modes
2. Change display information
3. Q-66HR modes
1. Tap the button twice to wake up the device screen.
2. Long-press the button on the Q-66HR until you see 4 icons
on the screen for mode selection.
3. Tap the button twice to switch mode.
4. You’ll be entering the selected mode in 3 seconds.
Information shown on the screen will vary as you press the
button on the Q-66HR to toggle between screens.
Daily mode: Analyzes your daily data, including steps taken
and calories burned, and displays current UV index.
Sleep mode: Tracks your sleep pattern and quality.
Sports mode: Starts a workout and displays information
including duration, steps taken, calories burned, UV-index and
distance traveled during the workout.
Nap mode: Awakes you via vibration after a short nap.
Date
Connection Status
Current Mode
Overall Progress (the average of Calories + Steps)
Battery Status
Heart Rate
Silent Alarm
Notification
Online Help
Manual download
Silent Alarm awakes you using gentle vibrations of the Q-66HR.
You can dismiss the alarm by long-pressing the button on the
Q-66HR. In case you miss the alarm, Q-66HR will alert you again in
5 minutes. Alarms can be set up from: i-gotU Life App Menu ->
Silent Alarm.
You will be notified with incoming calls, SMS, E-Mail, or alerts from
the social apps via vibration. When notified about an incoming call
on an Android smartphone, you may reject the call by
long-pressing the button on Q-66HR. Notification can be set up
from: i-gotU Life App Menu -> Notification.
Android: http://ww2.voiis.com/igotu-life/help.html?language=en
iOS: http://ww2.voiis.com/igotu-life/help.html?language=en&platform=ios
Note on environmental protection:
After the implementation of the European Directive 2002/96/EU in the
national legal system, the following applies:
Electrical and electronic devices may not be disposed of with domestic
Waste. Consumers are obliged by law to return electrical and electronic
devices at the end of their service lives to the public collecting points set up
for this purpose or point of sale. Details to this are defined by the national
law of the respective country. This symbol on the product, the instruction
manual or the package indicates that a product is subject to these
regulations. By recycling, reusing the materials or other forms of utilizing old
devices, you are making an important contribution to protecting our
environment.
WEEE
•
•
•
4. Icon description
Important Notice
Please make sure your Q-66HR is fully charged when used for the first
time. It takes about 2 hours before it is fully charged.
Please do not use under water.
Please do not use any corrosive chemical to clean the device.
The built-in Li-Polymer Battery might be damaged if it remains low
voltage for a long time. It is suggested that you charge the battery once
every three months to prolong the battery's lifetime, even though you
don't use the device very often or do not plan to use it for a while.
1.
2
3.
4.
http://www.mobileaction.com/download/Q-Band_download.jsp
![](/img.php?id=3045402&img=bg3.png)
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved
by the part responsible for compliance could void the user’s authority to
operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference and
2) this device must accept any interference received, including interfer-
ence that may cause undesired operation of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. End users must follow the specific
operating instructions for satisfying RF exposure compliance. This
transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Operating temperature: -10° to 65°C (14° to 149°F)
Charging temperature: 0° to 45°C (32° to 113°F)
Power input type: DC 5V USB cable
Battery type: Rechargeable Li-Poly, 3.7 Vdc
Input: Maximum DC 5V, 0.1A
User ManualQ-66HR Q-Band
