Monoprice MP34369 Bluetooth earphones User Manual

Monoprice, Inc. Bluetooth earphones Users Manual

User Manual

2
3
volume+/next
Multi-Function button
USB charging portvolume -/previous
456
Introduction
Bluetooth Earphone Specifications
Thanks for purchasing the Magnet-control power on/ off
bluetooth earphones from Trendwoo, please read this ma-
nual before use.
Bluetooth is a kind of wireless technology which support
short distance communications (work normally within a
distance of 10M) with it you can exchange information by
wireless between many IT digital devices like mobile
phones / wireless earphones / computers ect. Bluetooth
technology effectively and simplify to the communications
which makes device and data transmission quickly and off
effectively.
Bluetooth wireless communications Technology
introduction
Overview Of Headset
How To Use How To Use How To Use
Bluetooth Version Bluetooth V4.0
Bluetooth Protocol HFP、 HSP、 A2DP、 AVRCP
CVC
Output Power 5mw
Workable Distance 10m(Barrier-free Space)
Working Hours 12 hours for talking time, 10 hours
for playing music
Stand-by Time 240 hours
Charging Time 2 hours
Charging Voltage DC 5V
Battery Capacity 130mAh
Magnetic-T
.BHOFUDPOUSPMQPXFSPOPGGCMVFUPPUI
FBSQIPOFT6TFST.BOVBM 1
Please read suggests below in order to helping prolong the
product lifespan and clearly understand the warranty
clauses.
★Keep the product dry, do not put it in humid circumstance
to avoid short circuit.
★Do not expose it to the sun or high heat. High heating will
short lifespan of electronic components, damage battery
and deform some plastic parts.
★Do not put it in cold circumstance to avoid damage to
PCB board.
★Do not attempt to take apart the product, especially
non-professionals.
★Do not fall, vibrate strongly,strike with hard objects, to
avoid damage to inner electronic circuit.
★Do not use high chemical products,detergent to clean the
item.
★Do not scratch the surface with sharp items to avert
damaging the case and appearance.
★Do not make it charging 10 hours continuously for the
sake of lifespan.
If the product does not work properly, please send it to
Trendwoo.
Our staff will help to solve the problems for you.
Statement: In order to improve the product performance,
we will upgrade products, so the content may change
without notice.
Thank you for your understanding.
Safety And Maintenance
Shutdown state, pull open the right and left magnet, blue
LED light on, then power on;
Magnets touched, red LED light on, then power off;
(NOTE: After power on, if the device is not connected in
5 minutes, it will power off automatically)
Power On/Off
Pairing steps as below:
1.Shutdown state, pull open the magnets until the red
and blue LED light alternately flashing to the pairing
state;
2. Open Bluetooth function on the phone;
3. Search Bluetooth Devices;
4. Choose "Magnetic-T" (If require password, please
input "0000");
5.Blue LED light will flash slowly with prompt tone once
bluetooth pairing successfully;
6.Once connected one time, magnets pull open to disc-
onnect, magnets touched to re-connect automatically.
Pairing
1.According to the pairing steps to connect the first
mobile phone and turn off the Bluetooth function on the
phone to pair the second mobile phone.
2.Open Bluetooth function on first mobile phone,then
manually connect to the first mobile phone.
Pairing two mobile phones
Answer / end a call: short press the MFB to connect or
hang up the current phone.
Reject a call:Long press the MFB for 2 seconds.
Redial a call: Double click the MFB for 2 seconds.
Switching a Call: Short press the MFB to hang up the
current phone and answer the waited call when you are
calling. Double click on the MFB to answer second call, and
switch between two calls. Short press the MFB, you can
end the phone one by one.
Call
Power off: Magnetic touch
Power on: Magnetic pull
Pairing Mode: Red and blue LED light alternately flashing
Answer incoming call: click the MFB
Reject incoming call: Long press the MFB for 2 seconds
Hang up the phone: Click the MFB
Call transfer: long press the phone button 2 second
Volump up: Click V+
Volume down: Click V-
Previous song: long press V+
Next song: long press V-
Button Definition
• Waterproof IPX4
• Sweat and Splash Proof
• CVC Intelligent Noise Reduction
• Music Play time about 10h
• Call time about 12h
• Mobile Phone Battery Display
• Support Multi-Point Connection
Product Features
Bluetooth earphone protocol and description
Protocol
HSP (Earphone)
HFP (Hands-free)
A2DP
(Senior frequency dispense)
AVRCP
(Audio/Video long-distance control)
Description
Earphone mode
for mono voice call
Phone call related controls
Support stereo music playing
Control music by long-distance
Any questions, please send an email to support@trendwoo.com for inquiry or website visit.
www.trendwoo.com
MADE IN CHINA
