Monster >
user manual
iCarPlay
™
Wireless 200
Car Stereo FM Transmitter/Charger
iCarPlay
™
Wireless 200 Features
• High-quality stereo audio
• Full range of FM stations, from 88.1
to 107.9 (U.S. mode)
• 3 “favorite station” programmable presets
• iPod
®
screen display of FM frequency
® screen display of FM frequency
®
• AutoScan automatically fi nds best FM frequency
• 30-ft. maximum range**
• Micro-processor controlled
• Built-in antenna
• Powered by 12V car cigarette lighter adapter
• International FM tuning for U.S., Europe,
and Japan
• Auto-reset fuse to protect unit and iPod
• Charges iPod while in use
INSTRUCTIONS
Connecting to the iPod
1. Plug the iCarPlay Wireless 200 power adapter
into your car’s 12V accessory outlet (cigarette
lighter socket) and turn your iPod on.
2. Plug the iCarPlay Wireless 200 dock unit into
your iPod docking connector. The iPod screen
will fl ash the check symbol and the words
“OK to disconnect,” and then iPod will revert
back to the regular iPod menu.
Selecting the 3 FM Station
Memory Presets
iCarPlay Wireless 200
features 3 FM Station Memory
Presets to make it easy for you to quickly select
commonly used channels that you can set (see next
section). You may fi nd, for example, that one frequency
works best in one part of town and another works
better elsewhere.
1. Press the “S” button twice. (This will stop music
playback on the iPod.)
2. Press Right or Left button to select the desired
preset frequency.
3. Press the “S” button to select.
4. Tune your FM radio to the same channel
as indicated on the iPod display screen.
AutoScan FM Frequency Selection
(recommended)
The iCarPlay Wireless 200 features AutoScan
to automatically fi nd the best, clearest FM channel
in your local area. The process takes about a minute.
Remember that as you drive through different areas
the FM signal conditions change, so when driving
long distances, you can repeat the AutoScan selection
whenever FM interference occurs.
1. Press TWICE on the “S” button. (This will also stop
music playback on the iPod.)
2. Press the Right or Left button to highlight AutoScan.
3. Press and hold the “S” button for two seconds.
4. AutoScan will begin searching through the entire
FM range to fi nd the best frequency. This may take
up to 1 minute. Then iCarPlay Wireless 200 will
automatically select the best frequency and display
it on the iPod screen. NOTE: After a few seconds
the iPod will return to its regular menu, so it’s
important to note the AutoScan selected frequency
while it’s shown.
6. Tune your FM radio to the same channel.
Manual FM Frequency Selection
1. Press the iCarPlay Wireless 200 “S” button
once. (This will stop music playback
on the iPod.)
2. Press Right or Left button to select
FM frequency.
3. Press the “S” button again. The iPod will return
to its regular menu.
4. Tune your FM radio to the same channel.
Setting Memory Presets
You can program the 3 FM Station Memory Presets
to any frequencies in the FM range. iCarPlay Wireless
200 will continue to remember these presets even
when both power and the iPod are disconnected,
so they’ll always be ready to use the next time
you need them.
1. Press the “S” button twice. (This will stop music
playback on the iPod.)
2. Press the Right or Left button to highlight the FM
Station Memory Preset that you’d like to change.
3. Press and hold the “S” button for two seconds
to enter Preset tuning.
4. Press Right or Left to scroll tune the desired FM
frequency displayed on the iPod screen.
5. Press the “S” button again. The FM Station Memory
Preset will be set, selected, and the iPod will return
to its regular menu.
International FM Tuning Selection
iCarPlay Wireless 200 works with FM radio systems
worldwide. To select a different tuning system:
1. Press the “S” button THREE TIMES. (This will
stop music playback on the iPod.)
2. Press the Right or Left to select the desired
International Mode.
US: 88.1 - 107.9 MHz (with 0.2 intervals)
Europe: 87.8 - 108.1 MHz, (with 0.1 intervals)
Japan: 76 - 90 MHz (with 0.1 intervals)
4. Press the “S” button again. The International
Mode will be set, and the iPod will return
to its regular menu.
•
•
•
User Guide & Warranty Information
**Range determined by product specifi cations and other environmental variables
5. Press the ‘Play’ button on your iPod.
6. Use your car radio’s volume knob to adjust
sound level.
Note: iPod Backlight Timer Setting
Depending on your settings, your iPod’s screen
light may go out before you’re fi nished making
adjustments to the iCarPlay Wireless 200.
To ensure uninterrupted iPod screen viewing
during setup and FM frequency selection,
please set the backlight timer properties
on the iPod settings menu.
The words “OK to disconnect” will always appear
when in FM Transmitter mode, this is normal.
When selecting your FM station, in all instances,
the music will stop transmitting.
•
•
•
iPod
OK to disconnect.
Press S to Confirm
89.1
iPod
OK to disconnect.
Tap S to Select
Hold S to Set
89.1
FCC Notice:
This device complies with Part 15 of the FCC
rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
Caution:
Changes or modifi cations not expressly approved
by Monster Cable Products, Inc. may void the users authority
to operate this device.
Note:
This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to Part
15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by tuning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment
and receiver
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician
for help
FCC ID : RJE169202-00
LIMITED WARRANTY FOR CONSUMERS
United States
Monster Cable Products, Inc., 455 Valley Drive Brisbane,
CA 94005 (415) 840-2000. (“Monster”) extends You
this Limited Warranty. Statutory or common law may
provide You with additional rights or remedies, which
shall not be affected by this Limited Warranty.
DEFINITIONS
“Adequate Use”
means use of the Product (i) within a
home or dwelling, (ii) for private (as opposed to commercial)
purposes, (iii) in conformance with all applicable local,
state or federal law, code or regulations (including
without limitation building and/or electrical codes), (iv) in
accordance with manufacturer recommendations and/or
instructions in the materials and documentation that
accompany the Product, (v) with proper electrical grounding.
“Authorized Dealer”
means any distributor, re-seller
or retailer that (i) was duly authorized to do business in
the jurisdiction where it sold the Product to You, (ii) was
permitted to sell You the Product under the laws of the
jurisdiction where You bought the Product, and (iii) sold
You the Product new and in its original packaging.
“Formal Warranty Claim”
means a claim made
in accordance with the section “Formal Warranty
Claims” herein.
“Product”
means a Product listed in the Specifi cations Table
below, and (iii) You bought from new from an Authorized
Dealer new and in its original packaging.
“Product Defect”
means an inadequacy of the Product
that existed at the time when You received the Product from
an Authorized Dealer and that causes a failure of the Product
to perform in accordance with Monster’s documentation
accompanying the Product, unless such failure has been
caused completely or partly by (a) any use other than
Adequate Use, (b) transportation, neglect, misuse or abuse
by anyone other than Monster’s employees; (c) alteration,
tampering or modifi cation of the product by anyone; (e)
accident; (f) maintenance or service of the Product by
anyone other than a Monster employee or authorized service
technician; (g) exposure of the Product to heat, bright light,
sun, liquids, sand or other contaminants; or (h) acts outside
the control of Monster, including without limitation acts
of God, fi re, storms, earthquake or fl ood.
“Warranty Period”
means the time period during which
Monster must have received Your Formal Warranty Claim.
The different Warranty Periods related to Product Defects are
defi ned in the Specifi cations Table below. The Warranty Period
commences on the date when You purchased or received
(whichever occurs later) the Product from an Authorized
Dealer as evidenced by the Authorized Dealer’s invoice, sales
receipt, or packing slip. If You do not have written proof
of the date of purchase or receipt, then the Warranty Period
commences three (3) months after the date when the Product
left Monster’s or its factory as evidenced by Monster’s records.
The Warranty Period ends after the time defi ned in the
Specifi cations Table has expired or after You have transferred
ownership of the Product, whichever occurs earlier.
“You”
means the fi rst individual person that purchased
the Product in its original packaging from an Authorized
Dealer. This Limited Warranty does not apply to persons or
entities that bought the Product (i) in used or unpackaged
form, (ii) for resale, lease or other commercial use, or (iii)
from someone other than an Authorized Dealer.
SCOPE OF THIS LIMITED WARRANTY
Products.
If a Product contained a Product Defect when
You bought it from an Authorized Dealer and Monster
receives a Formal Warranty Claim from You before the end
of the Warranty Period for Product Defects applicable to
the affected Product, then Monster will provide You with
one of the following remedies: Monster will (1) repair or,
at Monster’s sole discretion, replace the Product, or
(2) refund to You the purchase price paid for the affected
Product from an Authorized Dealer if repair or replacement
is not commercially practicable or cannot be timely made.
NOTE: MONSTER does not assume any liability for ANY
INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES.
GENERAL PROVISIONS
Choice of Law/Jurisdiction.
This Limited Warranty and
any disputes arising out of or in connection with this Limited
Warranty (“Disputes”) shall be governed by the laws of the
State of California, USA, excluding confl icts of law principles
and excluding the Convention for the International Sale of
Goods. The courts located in the State of California, USA shall
have exclusive jurisdiction over any Disputes.
Serial number.
If this Product contains a serial number, this
Limited Warranty is void if the label on the Product bearing
the serial number has been removed, altered, or defaced.
No Liability for Advice.
Any technical or other advice
offered before or after delivery with respect to the use
and application of the Product is furnished without charge
and subject to the understanding that such advice is issued
at the purchaser’s sole risk without any limitation
or modifi cations of any disclaimer or other provision
contained herein.
Other Rights.
THIS LIMITED WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE AND WHICH
SHALL NOT BE AFFECTED BY THIS LIMITED WARRANTY.
THIS WARRANTY EXTENDS ONLY TO YOU AND CANNOT
BE TRANSFERRED OR ASSIGNED.
Registration.
Please register Your Product at
www.MonsterCable.com/Warranty. Failure to register
will not diminish Your warranty rights.
SPECIFICATIONS TABLE
Product Model No. Warranty Period for Product
Monster
®
iCarPlay
™
Wireless 200 One (1) Year
FORMAL WARRANTY CLAIM
How To Make A Claim.
In the event of a Product Defect,
You must follow these instructions: (1) Call 1-877-800-8989;
(2) Give a detailed explanation of the Product Defect;
(3) Obtain a Return Authorization Number; (4) Return
the Products, shipping prepaid by You, to Monster for
verifi cation of Product Defect, along with a copy of Your
original sales receipts and proof of purchase (UPC label)
for such Products, and printed Return Authorization
Number on the outside of the return package (the claim
form will include instructions for return). IMPORTANT: IN
ORDER TO EXERCISE YOUR RIGHTS UNDER THIS LIMITED
WARRANTY YOU MUST SUBMIT YOUR ORIGINAL SALES
RECEIPTS AND A PROOF OF PURCHASE (UPC LABEL
OR PACKING SLIP FOR THE PRODUCTS).
Further Proceedings.
Monster will reimburse You for any
shipping costs that You incurred in accordance with Monster’s
instructions and, at its discretion, either (a) direct You to
obtain a repair estimate at a service center for the Product;
or, (b) make a payment to You in accordance with the scope
of this Limited Warranty.
Timing.
If You bring a Formal Warranty Claim and fully
comply with all terms and conditions of this Limited
Warranty, Monster will use its best efforts to provide
You with a remedy within thirty (30) days after receipt
of Your Formal Warranty Claim (if You reside in the United
States - forty-fi ve (45) days if You reside elsewhere), unless
obstacles outside Monster’s control delay the process.
Ver.112003 – US/iCarPlay Wireless 200 ©2004 Monster
Cable Products, Inc.
MONSTER SAFETY TIP
Connecting and/or setting iCarPlay Wireless 200 while driving
may cause serious injury and/or death. Drive responsibly—
connect and set iCarPlay Wireless 200 BEFORE operating your
vehicle and pay attention to the road while driving.
Performance & Safety Tips:
• Connect iCarPlay Wireless 200 and select
channels BEFORE operating your vehicle;
never while driving.
• For best performance, select an iCarPlay
Wireless 200 channel that is not occupied
by a strong local FM radio station.
• Select the channel that offers clearest sound
with the least interference. AutoScan can fi nd
this channel automatically. Remember that
signal conditions change as your car moves,
and re-scanning may be necessary.
• The iCarPlay Wireless 200 transmitter
strength is regulated and limited by the FCC.
iCarPlay Wireless 200 transmits at the power
allowable by law.
• iCarPlay Wireless 200 is designed
to transmit within your car’s perimeter
while not interfering with the surrounding
public airwaves.
• Certain cars radios may experience more
diffi culty receiving clear signals than others.
Location of the antenna can affect signal
strength. Some vehicles have a metallic fi lm
in the windows that can also make it harder
to receive clear signals from the iCarPlay
Wireless 200.
• In dense metropolitan areas, there are cases
where all iCarPlay Wireless 200 pre-set
stations are occupied by local radio stations.
Sometimes a station setting next to a local
station may be strong enough to ‘bleed’ over
to the adjacent frequencies. Use manual
tuning to eliminate interference.
• Radio frequencies from local stations can
‘bounce’ from hills and buildings and may
cause momentary interference.
• A steel bridge or parking garage may act like
an antenna, strengthening local and distant
radio station signals. You may need to wait
until you are “over the bridge” or “out
of the structure” for clearest reception.
Note: Illustrations may vary in appearance from actual product.
Get All the Performance You Paid Fo
r
™
We invite you to visit the Monsters at:
MonsterCable.com
Engineered in the USA and manufactured for Monster
to its quality specifications.
Made in China.
© 2006 Monster Cable Products, Inc
455 Valley Drive
Brisbane, CA 94005, USA
1-877-800-8989
rm 181357
rm 181357
