Monster 190688 MONSTER BLUETOOTH HEADPHONES User Manual

Monster, LLC MONSTER BLUETOOTH HEADPHONES

User Manual

Manual and Warranty · Manuel et Garantie · Handbuch und Garantieschein · Manual y Garantía
Important Monster®
Performance and Safety Tips
Listen Responsibly
To avoid hearing damage, make sure that the
volume on your music player is turned down
before connecting your headphones. After
placing headphones in / on your ears, gradually
turn up the volume until you reach a comfortable
listening level.
Noise levels are measured in decibels (dB), exposure
to any noise at or above 85 dB can cause gradual
hearing loss.
Monitor your use; hearing loss is a function of
loudness versus time. The louder it is, the less
time you can be exposed to it. The softer it is, the
more time you can listen to it.
This decibel (dB) table compares some common
sounds and shows how they rank in potential
harm to hearing.
SOUND NOISE LEVEL (dB) EFFECT
Whisper 30 Very quiet
Quiet Oce 50–60 Comfortable hearing levels are under 60 dB
Vacuum Cleaner, Hair Dryer 70 Intrusive; interferes with telephone conversations
Food Blender 85–90 85 dB is the level at which hearing damage (8 hrs.) begins
Garbage Truck,
Cement Mixer
100 No more than 15 minutes of unprotected exposure
recommended for sounds between 90–100 dB
Power Saw, Drill/Jackhammer 110 Regular exposure to sound over 100 dB of more than
1 minute risks permanent hearing loss
Rock Concerts (varies) 110–140 Threshold of pain begins around 125 dB
Chart information obtained from www.nidcd.nih.gov/health/education/teachers/pages/common_sounds.aspx
ENGLISH
Get the most out of your equipment and enjoy
great audio performance even at safe levels. Our
headphones will allow you to hear more details at
lower volume levels than ever before.
Learn how to establish a safe listening level and
review other important safety guidelines from the
Consumer Electronics Association at www.ce.org.
Important information on how to prevent Noise-
Induced Hearing Loss (NIHL) and a comprehensive
list of which noises can cause damage can be
found on the Deafness Research Foundations
website, www.drf.org.
Physiology of the Ear and Hearing
For additional information on what loud noises do to your ear and
chart reference www.abelard.org/hear/hear.php#loud-music
Use Responsibly
Do not use headphones when it’s unsafe to do so –
while operating a vehicle, riding a bike, crossing
streets, or during any activity or in an environment
where your full attention to your surroundings
is required.
It‘s dangerous to drive while wearing headphones,
and in many places, illegal because it decreases
your chances of hearing life-saving sounds outside
of your vehicle, such as another car’s horn and
emergency vehicle sirens.
Please avoid wearing your headphones while
driving. Use one of Monster’s FM transmitters to
listen to your mobile media devices instead.
Headphones “Break-in
Break in time for headphones? We’re kidding,
right? No we’re not. Like any high performance
product, whether it’s cars or headphones, they’re
mechanical devices that settle in after use. Your
new headphones will sound incredible out of the
box, but will “mellow” out after use and sound even
better. We recommend playing them for 8 hours.
After 20 hours of playing, they should be fully
broken in. Enjoy.
Malleus Cochlear Nerve
Stapes
Tympanic
Membrane
Auditory Canal Cochlea
Incus
Vestibule
To Nose/Throat
ENGLISH
Battery
If applicable, battery must be recycled or disposed
of properly.
Information to consumers in application
of EU WEEE Directive 96/2002
This product is subject to European Union
regulations that promote the re-use
and recycling of used electrical and electronic
equipment. This product required the extraction
and use of natural resources and may contain
hazardous substances. The symbol above, on the
product or on its packaging, indicates that this
product must not be disposed of with your other
household waste. Instead, it is your responsibility
to dispose of your waste equipment by handing
it over to a designated collection point for the
recycling of waste electrical and electronic
equipment. The separate collection and recycling
of your waste equipment at the time of disposal
will help to conserve natural resources and ensure
that it is recycled in a manner that protects human
health and the environment. For more information
about where you can drop o your waste
equipment for recycling, please contact your local
city oce, your household waste disposal service,
or the store from which you purchased the product.
For more information about Monster products,
please visit us at: www.MonsterProducts.com.
Monster® Service
Have a Problem with Your
Headphones? Our Customer
Service Team is here for you.
Please don’t return headphones to your retailer,
CALL our customer service center, 1-877-800-8989
for United States or Latin America, or email us at
www.MonsterProducts.com/service/. For Canadian,
European, and Asian Pacic customer service
numbers, please see the “Telephone Numbers”
section in the following “Limited Warranty for
Consumers”. Our team of experts will assist you
with all questions and technical diculties.
We stand behind our products. Monster
headphones deliver the best in sound, quality,
and design.
Thank you for your purchase.
Download the complete manual at:
www.MonsterProducts.com
ENGLISHENGLISH
Product Overview
1. Microphone
2. Charge jack
3. Indicator light
4. Volume + / Track Forward
5. Multifunction button
(Power On/O, Pairing,
Activate Voice Dialing)
6. Volume - / Track Backward
INDICATOR LIGHT DESCRIPTION VOICE PROMPTS
Power on Stays blue 1 second Power on
Power o Stays red 2 seconds Power o
Standby (connected) Blink blue once every 5 seconds /
Pairing Flashes Red and Blue alternately Pairing
Incoming call Flashes blue continuous /
Charging Stays on blue while charging /
Guide to Indicator Lights
2
1
36
5
4
ENGLISH
Basic operation
Charge the Battery
Your ISport Wireless initially has enough power
to complete the pairing and a few calls. When
battery is low, you will hear warning tone and
indicator light changes to red. The headphone
includes a Micro USB cable that can be connected
to your computer or other device made for USB
charging. Plug the Micro USB end of the included
USB cable into the USB micro port on the control
talk box. Plug the other end into a USB port on
your computer or other devices made for USB
charging. The indicator light will be blue while
charging. Once fully charged, the indicator light
will be o. Charge time is approximately 1.5 hours
on an empty battery.
Note: The lifetime of the battery will be signicantly
reduced if your headphone is left uncharged for a
long period. We recommend that you recharge your
headphone at least once a month.
Power On/ Power O
Press the Multifunction button for about 1 second
to power on the headphone. To power o the
headphone, press the Multifunction button for
about 3 seconds.
Volume Control
Press the Volume “+” or “-” to turn volume up
or down, you hear beep once you reach the
maximum volume or minimum volume.
Pairing
Pair One Phone
1. Press and hold the Multifunction button for
about 5 seconds until indicator light ashes
blue and red alternately, you hear “Power
on” and “Pairing. Now
headphone
is in
pairing mode.
2. Activate Bluetooth® on your phone and set it
to search for new devices.
3. Select “ISport Wireless. If your phone
asks,
enter 0000 (four zeros) for the passcode or
accept the connection. The indicator light
stops ashing red and blue once successfully
paired, you hear “Paired, phone 1 connected”.
Some phone list an option to “Play through
earphone”, select to use the
headphone
.
Note: When you unbox the headphone and power
it on for the rst time, it will enter to pairing mode
automatically.
ENGLISH
Pair Another Phone
Multipoint technology enables you to pair another
phone and take a call from either.
To pair with another mobile phone, power o
the headphone, then follow the steps for “Pair
one phone”. After pairing successfully, restart the
headphone
to connect to 2 paired mobile phone
automatically and manually.
Note: You may need to connect the second
phone manually.
Call
Answer a Call: Press the Multifunction button once.
Reject a Call: Press and hold the Multifunction
button for about 1 second.
End a Call: Press the Multifunction button once.
Redial the Last Call: Press Volume”+” and “-” for
about 3 seconds in standby mode. The mobile
phone will redial the last call number.
Mute On/O: Press the Volume “-” for about
3 seconds to mute on/o.
Switch Between the Headphone and Phone:
Press the Multifunction button for about 1 second
during a call, the call will be switched to the mobile
phone, redo this operation again, the call will be
switched to the headphone.
End Current Call and Answer New Call: When a
new call rings during a call, press the Multifunction
button once to answer new call and end current
call simultaneously.
On Hold Current Call and Answer New Call:
When a new call rings during a call, double press
the Multifunction button to hold current call and
answer new call. To switch between held call and
active call, double press the Multifunction button.
Activate Voice Dialing: Double press the
Multifunction button to trigger the voice dialer,
this function varies with user’s smartphone.
Music
Play / Pause Music: Press Multifunction button
once to play / pause music. (Some phones may
require you to start a media player rst).
Track Back / Forward: Press the Volume “-” for
1 second once to skip track backward, press Volume
“+” for 1 second once to skip track forward.
Switch Music and Call: When a call rings during a
music playing, the music automatically pauses to
allow you to answer or ignore the call. Once the call
is ignored or ends, the music is resumed.
ENGLISH
More Features
Battery Indicator
When the headphone is connected to a device with
iOS system, a battery indicator will appear at the
upper right of the system, indicating battery status
of the headphone.
Auto Power-O
When the distance between the headphone and
the mobile phone is beyond eective range, a
warning tone will be alerted and headphone will try
to reconnect with the mobile phone for 10 minutes.
If no phone is reconnected within 10 minutes, the
headphone will go to connectable mode and wait
for 5 more minutes before automatically power o.
Automatic Connection After
Powering On
When the headphone and phone have been
paired once, they will automatically connect when
the headphone is on and Bluetooth is activated
on the phone.
Connection Standby
After successful pairing and connection, you will
hear the voice prompt “Phone 1 connected”. The
headphone will be in turning on mode or standby
mode automatically and the blue LED will ash
once every 5 seconds. When the phone disconnects
the headphone, you will hear the disconnect tone.
Reset Paired Device(s)
Go to the Pairing mode (hold the Multifunction
button for 5 seconds from Power o state), then
hold the Volume “-” to reset the paired device(s),
indicator light ashes blue and red alternatively
and rapidly few times, you will also hear the tone.
Hardware Reset
Plug the Micro USB cable into the USB micro port
of headphone to connect it to the computer or
other device made for USB charging to have the
hardware reset.
Certication
FCC ID: RJE190688
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any
interference received, including interference
that may cause undesired operation. Changes or
modication not expressly approved by the party
responsible for Compliance could void the users
authority to operate the equipment. Connecting of
peripherals requires the use of grounded shielded
ENGLISH
signal cables. The socket-outlet shall be installed
near the equipment and shall be easily accessible.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment o and on, the user is encouraged
to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
CAUTION: Changes or modications not expressly
approved by the party responsible for compliance
could void the user’s (or your) authority to operate
the equipment. Avoid storage in extreme heat
or cold. Avoid exposure to liquids, temperature
extremes and high humidity. The product’s
working temperature range is 0–45°C (32–113°F).
This device complies with FCC/IC radiation
exposure limits set forth for an uncontrolled
environment.
Canada Notice — IC ID: 5153A-
190688
This Class B digital apparatus complies with
Canadian ICES-003.
This device complies with RSS 210 of Industry
Canada. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference and (2) this device must accept any
interference,including interference that may cause
undesired operation of the device.
Canadian Class B Statement
This digital device does not exceed the Class
B limits for radio noise emissions from digital
apparatus as set out in the interference causing
equipment standard entitled “Digital Apparatus,
ICES-003 of the Department of Communications.
CAN ICES-3 (B)/NMB-3(B)
Modication
Any changes or modications not expressly
approved by the grantee of this device could void
ENGLISH
Canada Notice — IC: 5153A-
190688
This device complies with Industry Canada's licence-exempt RSSs. Operation is
subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada . Son
fonctionnement est soumis aux deux conditions suivantes :
( 1 ) Ce dispositif ne peut causer d'interférences ; et
( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences
qui peuvent causer un mauvais fonctionnement de l'appareil.
the user’s authority to operate the device.
Europe—EU Declaration of
Conformity
The equipment complies according to the Radio
Equipment and Telecommunications Terminal
Equipment Directive 1999/5/EC.
This equipment meets the following conformance
standards:
Safety EN 60950-1/A 12:2011
Health EN 62479:2010
EMC EN 301489-1 V1.9.2
EN 301489-17 V2.2.1
EN 55022:2010/AC:2011
EN 55024:2010
Radio EN 300 328 V1.8.1
CAUTION: Risk of explosion if battery is replaced
by an incorrect type. Dispose of used batteries
according to the instructions.
Certication Model Number:
190688
Import: Monster, LLC
Address: 7251 West Lake Mead Blvd.,
Las Vegas, NV 89128
Import: Monster Technology International, Ltd.
Address: Ballymaley Business Park,
Gort Rd., Ennis, Co. Clare, Ireland
N2001
LIMITED WARRANTY
FOR CONSUMERS
Monster, LLC, 7251 West Lake Mead Blvd., Las Vegas,
NV 89128, USA, [PLEASE NOTE THAT MONSTER
DOES NOT ACCEPT PRODUCTS SHIPPED TO THIS
ADDRESS – FOLLOW INSTRUCTIONS IN “HOW
TO MAKE A CLAIM” BELOW] (415) 840-2000
(“Monster”) extends You this Limited Warranty.
Statutory or common law may provide You with
additional rights or remedies, which shall not be
aected by this Limited Warranty.
DEFINITIONS
Adequate Use” means personal use of the Product
(i) for private (as opposed to commercial) purposes,
(ii) in conformance with all applicable law, code
or regulations (including without limitation
building and/or electrical codes), (iii) in accordance
with manufacturer recommendations and/or
instructions in the materials and documentation
that accompany the Product, and (iv) if applicable,
with proper electrical grounding.
Authorized Dealer” means any distributor,
ENGLISH
reseller or retailer that (i) was duly authorized
to do business and permitted to sell You the
Product under the laws of the jurisdiction where
You bought the Product, (ii) purchased the
Product directly from Monster or from a party
with a contractual relationship with Monster and
in accordance with the authorized terms and
conditions of such agreement, and (iii) sold You
the Product new and in its original packaging.
“Formal Warranty Claim” means a claim made
in accordance with the section “Formal Warranty
Claims” herein.
“Product” means a Product (i) that is listed in the
Specications Table below, (ii) that You bought
from an Authorized Dealer new and in its original
packaging, and (iii) whose serial number, if any, has
not been removed, altered, or defaced.
“Product Defect” or “Defective Product” means
an inadequacy of the Product that existed at the
time when You received the Product from an
Authorized Dealer and that causes a failure of the
Product to perform in accordance with Monster’s
documentation accompanying the Product,
unless such failure has been caused completely
or partly by (a) any use other than Adequate
Use, (b) transportation, neglect, misuse or abuse
by anyone other than Monster’s employees;
(c) alteration, tampering or modication of
the product by anyone other than a Monster
employee; (d) accident (other than a malfunction
that would otherwise qualify as a Product Defect);
(e) maintenance or service of the Product by
anyone other than a Monster employee; (f)
exposure of the Product to heat, bright light, sun,
liquids, sand or other contaminants; or (g) acts
outside the control of Monster, including without
limitation acts of God, re, storms, earthquake
or ood.
“Warranty Period” means the time period during
which Monster must have received Your Formal
Warranty Claim. The dierent Warranty Periods
related to Product Defects are dened in the
Specications Table below. The Warranty Period
commences on the date when You purchased
or received (whichever occurs later) the Product
from an Authorized Dealer as evidenced by
the Authorized Dealer’s invoice, sales receipt or
packing slip. If You do not have written proof
of the date of purchase or receipt, then the
Warranty Period commences three (3) months
after the date when the Product left Monster
or its factory as evidenced by Monster’s records.
The Warranty Period ends after the time dened
in the Specications Table has expired or after
You have transferred ownership of the Product,
whichever occurs earlier. Also, You must call
Monster and obtain a Return Authorization
Number (as described under “How to Make a
Claim”) within two (2) months after You discover
a Product Defect (or should have discovered it, if
such Product Defect was obvious).
“ Yo u ” means the rst individual person that
ENGLISH
purchased the Product in its original packaging
from an Authorized Dealer. This Limited Warranty
does not apply to persons or entities that bought
the Product (i) in used or unpackaged form, (ii) for
resale, lease or other commercial use, or (iii) from
someone other than an Authorized Dealer.
SCOPE OF THIS LIMITED WARRANTY
PRODUCTS. If a Product contained a Product
Defect when You bought it from an Authorized
Dealer, and Monster receives a Formal Warranty
Claim from You (i) within two (2) months after
You discover such Product Defect (or should have
discovered it, if such Product Defect was obvious)
and (ii) before the end of the Warranty Period
for Product Defects applicable to the Defective
Product, then Monster will provide You with one of
the following remedies: Monster will (1) repair or,
at Monster’s sole discretion, replace the Defective
Product, or (2) refund to You the purchase price
You paid to Monster or the Authorized Dealer for
the Defective Product if repair or replacement
is not commercially practicable or cannot be
timely made. NOTE: TO THE FULLEST EXTENT
PERMITTED BY APPLICABLE LAW, MONSTER DOES
NOT ASSUME ANY LIABILITY FOR ANY INCIDENTAL,
CONSEQUENTIAL OR INDIRECT DAMAGES UNDER
THIS LIMITED WARRANTY.
GENERAL PROVISIONS
CHOICE OF LAW/JURISDICTION. This Limited
Warranty and any disputes arising out of or in
connection with this Limited Warranty (“Disputes”)
shall be governed by the laws of the jurisdiction
where You bought the Product.
OTHER RIGHTS. THIS LIMITED WARRANTY GIVES
YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS, WHICH VARY FROM
JURISDICTION TO JURISDICTION, AND WHICH
SHALL NOT BE AFFECTED BY THIS LIMITED
WARRANTY.* THIS WARRANTY EXTENDS ONLY
TO YOU AND CANNOT BE TRANSFERRED OR
ASSIGNED. If any provision of this Limited Warranty
is unlawful, void or unenforceable, that provision
shall be deemed severable and shall not aect any
remaining provisions. In case of any inconsistency
between the English and other versions of this
Limited Warranty, the English version shall prevail.
REGISTRATION. Please register Your Product at
www.MonsterProducts.com. Failure to register will
not diminish Your warranty rights.
SPECIFICATIONS TABLE
Product Model Warranty Period
for headphone
Product that
accompanies
this warranty
statement
One (1) year for product sold
in North America, South
America and Asia Pacic
Two (2) years for product sold
in Europe
ENGLISH
FORMAL WARRANTY CLAIM
HOW TO MAKE A CLAIM. In the event of a Product
Defect, You must follow these instructions: (1) Call
Monster within two (2) months after You discover
a Product Defect (or should have discovered it,
if such Product Defect was obvious); (2) Give a
detailed explanation of how the damage occurred;
(3) Obtain a Return Authorization Number; (4)
Return the Product, shipping prepaid by You (to
be refunded if You are entitled to a remedy under
the Scope of this Limited Warranty), to Monster
for verication of damage, along with a copy of
Your original sales receipt or proof of purchase
(invoice or packing slip) for such Product, the
completed claim form, and printed Return
Authorization Number on the outside of the
return package (the claim form will include
instructions for return).
TELEPHONE NUMBERS. If You bought the Product
in the United States (1-877-800-8989), Latin
America (Mexico 011-882-800-8989), or Asia
Pacic (China 400-820-8973), contact Monster, LLC
via postal service at 455 Valley Drive, Brisbane, CA
94005 (PLEASE NOTE THAT MONSTER DOES NOT
ACCEPT PRODUCTS SHIPPED TO THIS ADDRESS –
FOLLOW INSTRUCTIONS IN “HOW TO MAKE
A CLAIM” ABOVE). If You bought the Product
in Australia, contact Monster’s agent, Convoy
International Pty Ltd (02 9700 0111), Unit 7,
1801 Botany Rd, Banksmeadow, NSW 2019
Australia. If You bought the Product anywhere
else, contact Monster Technology International
Ltd., Ballymaley Business Park, Gort Road, Ennis,
Co. Clare, Ireland. You can use one of the following
telephone numbers:
United States 1-877-800-8989
Canada 866-348-4171
Mexico 011-882-800-8989
China 400-820-8973
Ireland 353 65 68 69 354
Austria 0800296482
Belgium 0800-79201
Denmark 8088-2128
Finland 800-112768
France 0800-918201
Germany 0800-1819388
Greece 00800-353-12008
Italy 800-871-479
Netherlands 0800-0228919
Norway 800-10906
Russia 810-800-20051353
Spain 900-982-909
Sweden 020-792650
Switzerland 0800834659
Czech Republic 800-142471
United Kingdom 0800-0569520
FURTHER PROCEEDINGS. Monster will determine
ENGLISH
whether a Product Defect existed. Monster may,
at its discretion, direct You to obtain a repair
estimate at a service center. If a repair estimate is
required, You will be instructed on how to properly
submit the estimate and the resulting invoice to
Monster for payment. Any fees for repairs may be
negotiated by Monster.
TIMING. If You bring a Formal Warranty Claim and
fully comply with all terms and conditions of this
Limited Warranty, Monster will use its best eorts
to provide You with a remedy within thirty (30)
days after receipt of Your Formal Warranty Claim
(if You reside in the United States – forty-ve (45)
days if You reside elsewhere), unless obstacles
outside Monster’s control delay the process.
* Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major
failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does
not amount to a major failure.
Ver.121912 – GLOBAL
©2003–2016 Monster, LLC
ENGLISH

Navigation menu
