Mossloo >
User Manual
Wireless Charger Clock
Instruction Manual
1071-29
ON/OFF
UP
MEAU
OFF
Micro USB Input
Time Display
Temperature Display
Wireless Charging Pad
What’s included:
1 x Wireless Charger Clock
1 x USB to Micro-USB charging cable
1 x Instruction Manual
Tech Specifications:
Input power: 5V/1.5A
Wireless Output: 5V/1A 5W
INSTRUCTIONS:
1. Multiple Display: Convenient LED display, showing Time,
Date and Temperature.
A. Time: Display Hour, Minute. switch between 12/24-hour
system.
B. Date: Display Month, Day and Year (from 2000 to 2099).
C. Temperature: Display temperature and switch between
Fahrenheit/Celsius. Normal measurement range is from
0 ℃ to 50 ℃ (32 ℉ - 122 ℉).
2. Mode option: There are 3 optional modes dP-1,dP-2
and dP-3 by pressing the“UP”button.
A. Dp-1 mode: Display on the LED screen automatically
switches between time and date continuously, time stays
for 10 seconds while date stays for 2 seconds.
Temperature will always stay on the screen with solid light.
And when the setting’s done, it will go back to time
mode directly.
B. Dp-2 mode: The LED screen displays time as standard,
and will always display a mode after you switch to it. When
the setting’s done, it will exit to this mode and display it
all the time. Temperature will always stay on the screen
with solid light.
C. The LED screen displays time as standard. When the
setting of all modes is done, it will exit to this mode firstly
and go back to time mode after 15 seconds. Temperature
will always stay on the screen with solid light.
3. Power-saving function: Turn on/off the power-saving
function by pressing the “DOWN”button. (ON with
display oNSd: and OFF shows --Sd:)
4. External power-off protection function:If you unplug the
external power, there would be no display on LED screen
and no use for any pressing on any button, but the time
function will still be on.
5. Real-time Temperature can be displayed by pressing
DOWN in 2S to switch ℃ / ℉
SAFETY PRECAUTIONS:
WARNING–When using this product, basic precautions
should always be followed, including the following:
1. Do not use on an aircraft or in a hospital.
2. To reduce the risk of injury, close supervision is
necessary when the product is used near children.
3. Do not expose the device to any moisture.
4. Do not use the device in excess of its output rating.
Overloaded outputs above rating may result in a risk of
fire or injury.
5. Do not use the device if damaged or modified.
Damaged or modified device may exhibit unpredictable
behavior resulting in fire, explosion or risk of injury.
6. Do not disassemble the device. Take it to a qualified
service person when service or repair is required. Incorrect
reassembly may result in a risk of fire or injury.
7. Do not expose the device to fire or excessive
temperature. Exposure to extreme heat may cause
explosion.
8. Have servicing performed by a qualified repair person
using only identical replacement parts. This will ensure
that the safety of the product is maintained.
9. This device is not a toy.
10. Do not overcharge Phone. Unit may get hot with
excessive use. Remove Phone when it is fully charged.
Never charge for more than 7 hours at a time.
***KEEP OUT OF REACH OF CHILDREN***
FCC STATEMENT
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation. Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate the equipment.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
‐Reorient or relocate the receiving antenna.
‐Increase the separation between the equipment and
receiver.
‐Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
‐Consult the dealer or an experienced radio/ TV technician
for help.
WARNING
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
