Mossloo MSLW198Q Wireless Charging Power Bank User Manual LEEDS W198Q

Shenzhen Mossloo Industrial Co.,Ltd Wireless Charging Power Bank LEEDS W198Q

Contents

User Manual

Instruction Manual
MSL-W198Q
1 x 6000 mAh Power Bank
1 x 2-in-1 Charging Cable
1 x Instruction Manual
Micro Input: DC 5V 2A
Lightning Input: DC 5V 1A
USB Output 1/2: DC 5V 2A(MAX)
Wireless Input: 5V 0.8A
Wireless Output: 5V 1A
ON/OFF Button: Press once to to view the
remaining power capacity. LED indicator
will show Green once the Power bank is on
wireless charging standby mode.
Charging the power bank:
Charge the power bank fully before usage.
Using the built-in 2-in-1 charging cable,
AC adapter or USB port of a computer,
insert the 2-in-1 tip (the side with pins
upwards) into power bank micro input.
charging, and will stop once fully charged.
To Wireless Charge the power bank, place
power bank(6) on a wireless charging surface,
Charging mobile phones and other
electronic devices:
Connect the 2-in-1 cable to your mobile
phone.
Android device: The tip with pins upwards;
iOS device: The tip without pins upwards.
Connect the other end to the power bank it
will begin to charge automatically.
Remove the USB cable from your mobile
device when it is fully charged.
Charging Mobile phones and other
electronic devices with wireless output.
Place wireless charging enable device on
Wireless Charging Output Pad(7). The device
begins to charge with LED indicator will turn
RED.
You can fasten your phone on the power bank
via silicone wrap of the power bank(8) during
wireless charging.
Note: In order to charge devices, use only
the accessory cable or the cable included
with your own device by the manufacturer.
1.
a.
b.
c.
d.
2.
a.
b.
3.
a.
b.
*
•
•
•
•
•
•
What’s included:
Features:
LED Indicators:
Instructions:
1.
2.
3.
4.
5.
6.
7.
8.
LED Indicator
ON/OFF button
Micro Input
Lightning Input
USB port
Wireless Input Pad
Wireless Output Pad
Silicone Wraps
MADE IN CHINA
1
2
76
534
can impede the effectiveness of the
wireless charger, and lead to overheating.
Please remove attachments from the phone
before charging on this device.
WARNING-When using this product, basic
precautions should always be followed:
Read all the instructions before use.
Never store or use this product in
temperatures below 32°F (0°C) or above
115°F (45°C).
Do not overcharge your phone. The
unit may become hot under excessive
use. Remove your phone once it is fully
charged. Never charge your phone for
more than 7 hours at a time.
The unit will only achieve full performance
after 2 or 3 completed charge and
discharge cycles.
To reduce the risk of injury, close
supervision is required when the product is
used near children.
Do not expose the device to moisture.
Do not use the device in excess of its
output rating. Overload outputs above the
Do not use the device if damaged or
explosion or risk of injury.
Do not disassemble the device. For
professional. Incorrect reassembly may
or temperatures above 104°F (40°C) may
result in explosion.
To ensure product safety, ensure that
identical replacement parts.
Attachments on the back of your phone
•
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
SAFETY PRECAUTIONS:
FCC WARNING
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.However, there is no guarantee that interference
will not occur in a particular installation.If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one
or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
To maintain compliance with FCC’s RF Exposure guidelines,
This equipment should be installed and operated with minimum
20cm distance between the radiator your body: Use only the
supplied antenna
Wireless Charging Power Bank
