Exhibit 8 Users Manual
Dummy Page - To be discarded before printing
Use this template with A7MotoQSG StructApps
Sledge GSM
Quick Start Guide
November 20, 2008
1
congratulations
The ZN300 does it all. Use the music player to listen to
the newest, hottest tracks. With a stereo wired headset
or high quality Bluetooth® stereo headset, listening has
never been easier. Or, take photos and video clips, and
share them with your friends, in a multimedia message
or by uploading them to a social networking website. All
this while you’re still connected — take or make voice or
video calls or exchange messages.
We’ve crammed all of the main features of your phone
into this handy guide, and in a matter of minutes we’ll
show you just how easy your phone is to use. So go on,
avoid those “I’m not sure how to send an MMS”
moments and check it out.
Caution:
Before using your phone for the first time,
please read the important
legal and safety
information at the back of this guide (page 59).
2
more information
Use this guide to get you going and, if you want more
information, see the User’s Guide (don’t worry, it’s easy
to use). To learn even more, go to
www.motorola.com/
consumer/support
.
this guide
symbols in this guide
This means a feature is network, SIM card, or
subscription dependent and may not be
available in all areas. Contact your service
provider for more information.
This means a feature requires an optional
accessory.
3
contents
your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
text entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
airplane mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Bluetooth® wireless. . . . . . . . . . . . . . . . . . . . . . . . . 43
cable connections. . . . . . . . . . . . . . . . . . . . . . . . . . . 48
memory card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4
synchronize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
service & repairs. . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
legal & safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
your phone
5
your phone
the important keys & connectors
Multimedia Key
Turn on/off, hang
up, exit menus.
Right Soft Key
Clear/Back Key
Open the menu
and select.
Navigate menus.
Left Soft Key
Volume Keys
Smart Key
Make & answer calls.
Charge up or
connect.
Plug in
headphones.
Insert microSD.
main menu
6
main me nu
Q
Games & Apps
e
Messages
• Create Message
•Voicemail
• Message Inbox
•Email
• Browser Msgs
• Info Services *
• Outbox
•Drafts
• Templates
t
Ring Styles
s
Recent Calls
h
Multimedia
• Music Library
•Themes
• Voice Records
•Camera
•Video Camera
•Pictures
• Sounds
•Videos
á
Web Access *
•Browser
•Web Shortcuts
• Stored Pages
•History
•Go To URL
•Browser Setup
•Web Sessions*
w
Settings
• Personalize
• Tools
• Call Forward
• In-Call Setup
•Initial Setup
• Software Update
• Phone Status
• Headset
•Car Settings
• Airplane Mode
•Network
•Security
• Java Settings
n
Phonebook
L
Connections
* optional features
This is the standard main menu layout.
Your phone’s menu may be
different.
basics
8
basics
here are some basics to get you started
turn it on & off
Press and hold
é
for a few seconds
or until the display lights up.
Caution:
If your phone asks for your SIM card PIN code
and/or unlock code, see page 56.
make & answer calls
To m a k e a c a l l
, enter a phone
number and press
è
.
To answer a call
when your phone
rings and/or vibrates, press
è
.
To ch o os e
Hold
,
Mute
,
Transfer
, or other options during a call,
press
Options
.
end calls
Press
é
.
basics
9
store contacts
1
Enter a phone number in the home screen.
2
Press
Store
.
3
Enter the contact details and press
Done
.
To manage your
Phonebook
, see page 21.
call or text contacts
1
Press
s
>
nPhonebook
.
2
Scroll to highlight the contact.
Tip:
To jump to a contact in the phonebook, enter
the first few letters of the name.
3
To
call
, press
è
.
To send a
text message
, press
Options
>
Send Message
.
To speed dial contacts, see page 14.
Note:
You can call and text contacts stored in your
phone’s memory or on your SIM card (see page 21).
home screen
10
home screen
you can always go home
The home screen appears when you turn on the phone,
or any time you press
é
. It looks similar to this:
To
open shortcuts
, press
S
up, down, left, or right. To
change shortcuts, see page 31. To open the
functions
at
the bottom of the display, press the
soft keys
(see
page 5). To open the
menu
, press
s
. To go back,
press
é
.
Status indicators
appear at the top of the home screen:
Service Provider
12/31/09
12:00
Options Main Menu
Status
Indicators
The right soft key
opens the main
menu.
The left soft key
opens quick
options.
Active Line
Message
IM
Ring Style
Battery Level
Roam
Data
EDGE/GPRS
Signal Strength
calls
11
calls
it’s good to talk
For the basics, see page 8.
recent calls & redial
1
From the home screen, press
è
to see a list of
recent calls.
To s h ow
Dialed Calls
,
Received Calls
,or
Missed Calls
,
press
*
or
#
.
2
Scroll to a call.
To see it, press
s
. To call it, press
è
.
caller ID
Calling line identification (caller ID) shows the
caller’s name when they’re stored in your
phonebook, or
Incoming Call
when caller ID
information isn’t available.
Tip:
To play a special ring for a contact, see page 21.
To show or hide
your phone number
from the next
person you call, enter their phone number,
press
Options
>
Hide ID/Show ID
, then press
è
to call.
calls
12
To show or hide
your phone number
for
all
calls you
make, press
s
>
wSettings
>
In-Call Setup
>
My Caller ID
>
All Calls
.
emergency calls
Your service provider programs one or more emergency
phone numbers, such as 911 or 112, that you can call
under any circumstances, even when your phone is
locked or the SIM card is not inserted.
Note:
Check with your service provider, as emergency
numbers vary by country. Your phone may not work in all
locations, and sometimes an emergency call cannot be
placed due to network, environmental, or interference
issues. Do not solely rely on your wireless phone for
essential communications, such as medical
emergencies.
1
Press the keypad keys to dial the emergency
number.
2
Press
è
to call the emergency number.
calls
13
handsfree
To turn on your phone’s handsfree speaker during a call,
press
Speaker
(if available), or
Options
>
Spkrphone On
.
You can use Bluetooth headsets (page 43) or wired
headsets plugged into the headset connector (page 5).
Note:
The handsfree speaker won’t work when your
phone is connected to a handsfree car kit or headset.
handsfree options
Note:
The use of wireless phones while driving may
cause distraction. Discontinue a call if you can’t
concentrate on driving. Additionally, the use of wireless
devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and
regulations on the use of these products.
To... Do this...
enable voice
dial
Press
s
>
wSettings
>
Headset
>
Voice Dial
.
calls
14
dialing options
speed dial
automatically
answer calls
Press
s
>
wSettings
>
Car Settings
or
Headset
>
Auto Answer
.
automatically
use a car kit
Press
s
>
wSettings
>
Car Settings
>
Auto Handsfree
.
To... Do this...
assign
a
speed dial
Press
s
>
nPhonebook
, scroll to the
contact, then press
Options
>
Add to Speed Dial
and pick a
speed dial key.
use a speed
dial
From your home screen, press and
hold the key (
1
calls your
voicemail).
To... Do this...
calls
15
quick dial
Dial preprogrammed phone numbers:
Find it:
sÉSettings
>
ÉTools
>
Dialing Services
>
Quick Dial
international calls
To make international calls, press and hold
0
to
insert your local international access code (indicated by
+
). Then, press the keypad keys to dial the country code
and phone number.
notepad
You can show the last number you entered (such as one
you entered during a phone call):
Find it:
s
>
sRecent Calls
, then
Options
>
Notepad
•
To call the number, press
è
.
edit your
speed dial list
Press
s
>
nPhonebook
, then press
Options
>
Setup
>
Speed Dial List
.
To... Do this...
calls
16
•
To create a contact with the number in the
Number
field, press
Store
.
•
To open the menu to attach a number or insert a
special character, press
Options
.
in-call options
During a call:
• To put a call on hold
, press
Options
>
Hold
.
•To mute a call
, press
Options
>
Mute
.
• To answer a second call
when you hear a
tone (call waiting), press
è
. Then:
•
To switch between calls, press
Switch
.
•
To connect the two calls, press
Options
>
Link
.
•
To end the call on hold, press
Options
>
End Call On Hold
.
Note:
To turn the call waiting feature on or off,
press
s
>
wSettings
>
In-Call Setup
>
Call Waiting
>
On
or
Off
.
calls
17
• To start a conference call
, dial the next
number and press
è
. When the next
number answers, press
Options
>
Link
to
create the conference call.
Tip:
Press
Options
>
New Call
before you dial the next
number, to put the first caller on hold.
• To transfer a call
, press
Options
>
Transfer
,
dial transfer number, press
è
.
Note:
If the transfer fails, your phone might put
the first call on hold and try to call the transfer
number. If that call connects, you can press
Link
to connect everyone in a conference call.
answer options
When you receive a call:
• To stop the call alert
before you answer, press
the volume keys.
• To send the call to your voicemail
, press
é
.
• To answer by pressing any key
,
press
s
>
wSettings
>
In-Call Setup
>
Answer Options
>
Multi-Key
calls
18
call forwarding
Find it:
s
>
wSettings
>
Call Forward
restrict calls & messages
block calls from unknown numbers
Find it:
s
>
wSettings
>
Security
>
Restrict Calls
, then
enter your unlock code (see page 56)
block outgoing or incoming calls
Find it:
s
>
wSettings
>
Security
>
Call Barring
your phone number
From the home screen, press
D
then
#
to see your
number.
Tip:
Want to see your phone number while you’re on a
call? Press
Options
>
My Tel. Number
.
edit your contact entry
From the home screen, press
D
then
#
, select
the contact entry, press
View
, then press
Options
>
Edit
.
calls
19
call times & costs
These features give you a rough idea of how much call
time you’ve used and the cost. Note that these figures
may not match what your service provider charges you,
as they’re not measured in the same way.
network settings
View network information and adjust network
settings:
Find it:
s
>
wSettings
>
Network
features
view call timers
s
>
sRecent Calls
, then press
Options
>
Call Times
show call time during a call
)
s
>
wSettings
>
In-Call Setup
>
In-Call Timer
show call cost
s
>
sRecent Calls
, then press
Options
>
Call Cost
calls
20
send or receive data
You can connect your phone to a computer, then
place or receive data calls from the computer.
1
Ensure that the cable is disconnected
from your
phone, then press
s
>
Connection
>
USB Settings
>
Default Connection
>
Data Connection
.
2
Connect the cable
to your phone and an available
USB port on your computer.
3
Use the computer’s software to place or answer a
data call. For more information, consult the
computer software’s documentation.
phonebook
21
phonebook
your contacts come with options
To store and call contacts, see page 9.
edit or delete contacts
Find it:
s
>
nPhonebook
Scroll to the contact or press keypad keys to enter the
first letters of a contact you want. You can also press
*
and
#
to see the entries in your categories or
entries you used recently.
To delete the contact
, press
Options
>
Delete Contact
.
To edit the contact
, press
Options
>
Edit Contact
.
Tip:
When you edit a contact, you can give it a special
Ringer ID
and
. To activate ringer IDs,
press
s
>
Ring Styles
> style
Detail
>
Ringer IDs
>
On
.
copy contacts
You can
use contacts
stored in your phone’s memory or
on your SIM card (contacts on the SIM card have fewer
details). To choose which you use,
press
s
>
nPhonebook
, then
Options
>
View
>
Phone & SIM Card
,
SIM Card
, or
Phone Contacts
.
phonebook
22
To copy one contact
to the phone or SIM card,
press
s
>
nPhonebook
, scroll to the contact, press
Options
>
Copy to SIM Card
or
Copy to Phone
.
sort your phonebook
Find it:
s
>
nPhonebook
, then
Options
>
Setup
>
Sort by
>
First Name
or
Last Name
send contacts
Find it:
s
>
nPhonebook
, scroll to the contact, press
Options
>
Send Contact
To p r i n t
a contact on a printer with a Bluetooth
wireless connection, select the contact and press
Options
>
Print
.
Note:
You cannot print a
Message List
. For more about
Bluetooth connections, see page 43.
messages
23
messages
sometimes it’s better 2 text
You can send and receive text (SMS), and
multimedia (MMS) messages with your phone.
set up email
Find it:
s
>
eMessages
, then
Options
>
Setup
>
Message Setup
Enter the information for your account, then let the
phone try to log in. If you have problems or need your
account information, contact your email provider.
Note:
To create a new account, select
[New Entry]
in the
Account Settings
list. Your display shows a folder for each
email account under
s
>
eMessages
>
Email Msgs
.
send messages
Find it:
s
>
eMessages
>
Create Message
>
New Message
or
New Email
1
Press keypad keys to enter text (see page 26).
To insert a
picture or voice note
on the page, press
Options
>
Insert
.
2
When you finish the message, press
Send To
.
messages
24
3
Scroll to a recipient and press
s
, or press
Options
>
Enter Number
or
Enter Email
.
4
Before you send a message, you can press
Options
to
choose
Save to Drafts
,
Cancel Message
, or open
Sending Options
(such as message
Subject
or
CC
addresses).
5
To
send
the message, press
Send
.
To use message templates
with preloaded
animations, press
s
>
eMessages
>
Templates
>
Text Templates
or
Multimedia Templates
.
To send voice messages
, press
s
>
eMessages
>
Create Message
>
New Voice Msg
. Your phone starts
recording the voice message. To stop recording,
press
Stop
. Your phone inserts the voice recording into a
message and lets you enter email addresses or phone
numbers of the recipients.
receive messages
When you receive a message, your phone plays
an alert and shows a new message indicator
É
.
Press
Read
to open the message.
To see all of your messages:
messages
25
Find it:
s
>
eMessages
>
Message Inbox
or
Email
Press
Options
to use or To store any phone numbers,
email addresses, Web sites, or files in the message,
scroll to the message and press
Options
.
To... Do this...
open a
message
Press
s
. To
Reply
,
Forward
,
Lock
,
or
Delete
a message, open it
and press
Options
.
open browser
messages
Press
s
>
eMessages
>
Browser Msgs
.
store
messages
Press
s
>
eMessages
, then
Options
>
Setup
>
Message Setup
>
Text Msg Setup
>
Default Storage
>
SIM Card
.
print
messages
(using
Bluetooth®)
Press
s
>
eMessages
>
Message Inbox
,
Email
,
Outbox
, or
Drafts
.
Open the message you want
to print and press
Options
>
Print
.
text entry
26
text entry
how fast can u text?
When you need to enter text, your phone changes to a
text entry mode, indicated by an icon at the top of your
screen.
To change modes
when you are entering text,
press
#
:
entry modes
Û
or
Ú
iTAP™
predicts the word you want, with just
one keypress per letter. For example, to enter
home
, press
4663
. If the prediction is
not correct, press
S
to show other options.
Ô
or
Õ
Ta p
lets you press a key one or more times to
cycle through the letters and numbers of that
key. When you see the character you want,
just press another key or wait a second or
two to move on. For example, to enter
h
,
press
4
two times quickly.
text entry
27
To s e t
your primary and secondary text entry modes,
press
Options
>
Text Setup
in a text entry view and select
Primary Text
or
Secondary Text
.
To change capitalization
, press
0
to switch to all
capital letters (
á
), no capitals (
Á
), or next letter
capital (
Â
).
To accept
a word completion that appears after the
letters you entered, press
S
right.
To enter a space
, press
*
.
To enter punctuation
or symbols, press
1
.
To delete a character
, press
D
(to delete a whole
word, hold
D
).
ÃNumeric
mode enters numbers only.
Shortcut:
Press and hold a number key to
temporarily switch to numeric mode.
ÄSymbol
mode enters symbols only. To exit this
mode, press
#
again.
entry modes
tips & tricks
28
tips & tricks
make your phone even faster
To... Do this...
change ring
style
From the home screen, press the volume
keys up or down. Hold
#
to switch to
Silent
and back.
check your
voicemail
In the home screen, press and hold
1
to check your voicemail.
return to the
home
screen
In a menu, message, or other screen,
press
é
to cancel and return to the
home screen.
update
phone
software
To check for updates,
press
s
>
wSettings
>
Software Update
>
Check for Updates
Note:
These software updates are safe
for your phone, and do not affect your
contacts or other personal entries.
personalize
29
personalize
add your personal touch
ring style
choose styles
Find it:
s
>
Ring Styles
>
Style:
style name
Shortcut:
To change your ring style profile from the
home screen
, just press the volume keys up or down.
edit ring styles
After you choose a ring style, you can change its alerts,
reminders, and volume.
Find it:
s
>
Ring Styles
> style
Detail
Note:
Style represents the current ring style. You can’t
set an alert for the
Silent
ring style setting.
themes
A theme is a group settings (such as a wallpaper,
screen saver, display skin, and ringtone) that you
can apply at the same time.
personalize
30
To
apply
a theme, press
s
>
hMultimedia
>
Themes
>theme.
To
delete themes you downloaded
, press
s
>
hMultimedia
>
Themes
, scroll to the theme, and
press
Options
>
Delete
or
Delete All
.
display settings
To... Do this...
choose
wallpaper
Press
s
>
wSettings
>
Personalize
>
Wallpaper
.
choose a
skin
Press
s
>
wSettings
>
Personalize
>
Skin
.
set the
scroll bar
Set to
Up/Down
or
Wrap Around
in menu
lists. Press
s
>
wSettings
>
Initial Setup
>
Scroll
.
set display
brightness
Press
s
>
wSettings
>
Initial Setup
>
Brightness
.
personalize
31
home screen shortcuts
You can set the features that open when you
press the navigation key, soft keys, or smart key in
your home screen (for key locations, see page 5).
Find it:
s
>
wSettings
>
Personalize
>
Home Screen
>
Home Keys
main menu appearance
To show your main menu as
icons or a list
,
press
s
>
wSettings
>
Personalize
>
Main Menu
>
View
>
Icons
or
List
.
To change your main menu
order
, press
s
>
wSettings
>
Personalize
>
Main Menu
>
Reorder
.
save battery
life
Yo u r ke y p a d
backlight
and
display
turns off when you’re not pressing any
keys. To set the delay time for this,
press
s
>
wSettings
>
Initial Setup
>
Backlight
.
To... Do this...
personalize
32
time & date
Your phone can use the network to automatically update
your time zone, time, and date.
Find it:
s
>
wSettings
>
Initial Setup
>
Time and Date
>
Autoupdate
>
Time & Time Zone
To
manually
set the time zone, time, and date, turn off
Autoupdate
, then: Press
s
>
wSettings
>
Initial Setup
>
Time and Date
>
Time Zone
,time or date.
To choose an
analog or digital
clock for your home
screen, press
s
>
wSettings
>
Personalize
>
Home Screen
>
Clock
.
language
Set menu language:
Find it:
s
>
wSettings
>
Initial Setup
>
Language
photos
33
photos
see it...take it...send it!
take & send photos
To get the clearest pictures, wipe the lens clean with
a dry cloth before you take a picture.
Find it:
Slide the multimedia key to
j
.
To change camera settings, press
Options
before you take
the photo.
232
Press
s
to take
the picture.
Press
S
up or
down to view
camera settings.
Press left or right
to change.
Camera Mode
(photo or video)
Timer Remaining
Photos
Storage (phone
or memory card)
Resolution
Focus Point
Options Exit
Exit the camera.Open the camera
menu.
Zoom
1x
photos
34
To take the photo, press
s
or
j
. Then:
•
To
store
the photo, press
Options
>
Store Only
.
•
To
send
the photo in a message, press
Send
.
•
To
discard
the photo and return to the active
viewfinder, press
D
.
see stored photos
Find it:
s
>
hMultimedia
>
Media
Finder
>
Pictures
>picture name
To
copy, move
or
delete
a picture, open it and
press
Options
>
Manage
>
Copy
,
Move
or
Delete
.
videos
35
videos
capture moments you want to remember
record & send videos
To get the clearest videos, wipe the lens clean with a
dry cloth before you record a video.
Find it:
Slide the multimedia key to
c
.
To change video settings, press
Options
.
51
Press
s
to start
the video.
Press
S
up or
down to view
camera settings.
Press left or right
to change.
Camera Mode
(photo or video)
Minutes
Remaining
Storage (phone
or memory card)
Resolution
Options Exit
Exit the camera.Open the video
menu.
Zoom
1x
videos
36
Tip:
If you want to send your video in a message, set the
video length to
MMS
: Press
Options
>
Video Camera Setup
>
Video Length
>
MMS
.
To r e c o r d
the video, press
s
.
To s t o p
the video, press
Stop
.
•
To
preview, store, or discard
the video, press
Options
.
•
To
send
the video in a message, press
Send
. Enter text and press
Send To
, then
select a recipient.
•
To
discard
the video, press
D
.
play video clips
Find it:
s
>
hMultimedia
>
Videos
> video
Tip:
While a video is playing, you can press
Options
>
Play Full Screen
to see the video at the full display
size (press any key to return to the regular view).
music
37
music
when you need music, all you need is your phone
load music
To
download
songs from the Internet, use your phone’s
micro-browser (press
s
>
TWeb Access
and go to the
page with the file).
To
copy
files between your phone and a
computer, you will need:
•
a USB cable (see page 48) or a computer that
supports Bluetooth® connections (see page 43).
•
a microSD memory card (see page 51).
•
a computer with music files in one of these
formats:
music file formats bit rate
AAC, AAC+,
Enhanced AAC+, or M4A
up to 128 kbps
MP3 or MP4 up to 320 kbps
music
38
play music
Find it:
s
>
hMultimedia
>
Music Library
You can open a list of
All Songs
,
Recently Played
songs, or the
Playlists
you created. You can also choose songs by
Albums
,
Artists
, or
Genres
.
Shortcut:
In a song list, press a number key to jump to
songs that begin with the letters on the key.
When you select a song:
• Play or pause—
Press
s
.
Artist
Album
Song
00:09 03:00
Options Back
Press
S
left or
right to skip
songs, or hold it
to scan.
Album Image
(if available)
Press the center
key
s
to pause
or play.
The right soft key
hides the player.
The left soft key
opens player
options.
music
39
• Rewind or fast-forward—Hold
S
left or right
(
hold
for at least 2 seconds).
• Skip to another song—Press
S
left or right.
• Change volume—
Press the volume keys.
• Hide the player—
Press
Options
>
Hide
. This lets
you use other phone features while the song
plays. To end the hidden audio player, press
é
in the home screen.
FM radio
40
FM radio
listen to news and music anywhere, for free
play stations
Find it:
s
>
hMultimedia
>
Radio
• Volume
: Press
S
up or down. To mute the
radio, press
Options
>
Mute
.
•Tuning
: Press
Options
>
Scan
.
use radio presets
To s t o r e
the current station as a preset, just press and
hold a number key.
To g o t o
a preset station, press the number key.
To m a n a g e
presets, press
Options
>
Station Presets
.
Web
41
Web
surf the Web from your phone
browser
To
launch
the browser, press
s
>
TWeb Access
.
To
go to a Web page
, press
Options
>
Open
>
Web Address
,
enter the Web address (URL), then press
OK
.
To
enter text
, select a text entry field and press
s
to
open it. Then, enter text.
To
choose a storage location
for downloaded files,
press
s
>
wSettings
>
Phone Status
>
Download Location
>
Memory Card
or
Phone
To
clear the micro-browser history, cache, or cookies
,
press
s
>
áWeb Access
>
Browser Setup
>
Clear History
,
Reset Cache
, or
Clear Cookies
To
exit
the browser, press
Options
>
Exit
.
airplane mode
42
airplane mode
long flights don’t have to be dull
You can switch your phone to airplane mode to prevent it
from communicating with the network. This lets you use
games or other applications while you are on an airplane,
without interfering with airplane communications.
Note:
Your phone cannot make Bluetooth® connections
when
Airplane Mode
is on.
Find it:
s
>
wSettings
>
Airplane Mode
>
Airplane Mode
>
On
You can make the airplane mode option appear whenever
you turn on your phone:
Find it:
s
>
wSettings
>
Airplane Mode
>
Prompt At Power Up
>
On
Bluetooth® wireless
43
Bluetooth® wireless
don’t let wires tie you down
connect new devices
Note:
The use of wireless phones while driving
may cause distraction. Discontinue a call if you can’t
concentrate on driving. Additionally, the use of wireless
devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and
regulations on the use of these products.
Before you try to connect your phone with a
handsfree device
, make sure the device is
on
and
ready
in pairing or bonding mode (see the user’s guide for the
device). You can connect your phone with only one
device at a time.
Find it:
s
>
Connection
>
Bluetooth Link
>
Audio Devices
>
[Look For Devices]
Your phone lists the devices it finds within range.
Scroll to one of the Bluetooth devices your phone found
and press
s
.
If necessary, press
Yes
,
OK
or enter the device passkey
(such as
0000
) to connect to the device. When the device
Bluetooth® wireless
44
is connected, the Bluetooth indicator
O
appears in the
home screen.
Tip:
Do you have questions about a device? For specific
information about a device, check the instructions that
came with it.
For maximum Bluetooth security
, you should always
connect Bluetooth devices in a safe, private
environment.
reconnect devices
Find it:
s
>
wSettings
>
Connection
>
Bluetooth Link
>
Audio Devices
> device name
Shortcut:
When your phone’s Bluetooth power is on,
your phone can automatically connect to a handsfree
device you have used before. Just turn on the device, or
move it near the phone. If the device doesn’t connect,
turn it off and back on. To turn your phone’s Bluetooth
power on, press
s
>
wSettings
>
Connection
>
Bluetooth Link
>
Setup
>
Power
>
On
.
During a call
, press
Options
>
Use Bluetooth
to switch to a
recognized headset or car kit.
Bluetooth® wireless
45
transfer files
You can use a Bluetooth connection to transfer a
media file, contact, datebook event, or Web shortcut
from your phone to a computer or other device.
Note:
The unauthorized copying of copyrighted materials
is contrary to the provisions of the Copyright Laws of the
United States and other countries. This device is
intended solely for copying non-copyrighted materials,
materials in which you own the copyright, or materials
which you are authorized or legally permitted to copy. If
you are uncertain about your right to copy any material,
please contact your legal advisor.
1
On your phone, scroll to the object that you want to
transfer.
2
For media files
, press
Options
>
Manage
>
Copy
or
Move
Caution:
Moving an object
deletes
the original
object from your phone.
For contacts
, press
Options
>
Share
For datebook events
, press
Options
>
Send
Bluetooth® wireless
46
3
Select a recognized device name, or
[Look For Devices]
to
search for the device where you want to transfer the
file.
If your phone could not transfer the file to the other
device
, make sure the device is
on
and
ready
in
discoverable mode (see the user’s guide for the device).
Also, make sure the device is not busy with another
similar Bluetooth connection.
Note:
Once you connect your phone to a Bluetooth
device, that device can start similar Bluetooth
connections with your phone. Your display shows the
Bluetooth indicator
O
at the top when there is a
Bluetooth connection.
receive files
If you do not see the Bluetooth indicator
O
at the
top of your phone display, turn on your phone’s Bluetooth
feature by pressing
s
>
wSettings
>
Connection
>
Bluetooth Link
>
Setup
>
Power
>
On
.
1
Place your phone near the device, and send the file
from the device.
Bluetooth® wireless
47
If your phone and the sending device don’t recognize
each other, place your phone in discoverable mode
so the sending device can locate it:
press
s
>
wSettings
>
Connection
>
Bluetooth Link
>
Find Me
.
2
Press
Accept
on your phone to accept the file from the
other device.
Your phone notifies you when file transfer is complete. If
necessary, press
Store
to save the file.
cable connections
48
cable connections
your computer wants a friend
Your phone has a mini USB
port so you can connect it to
a computer to transfer data.
Before you connect a cable,
tell your phone what type of
USB connection you want to use by
pressing
s
>
Connection
>
USB Settings
>
Default Connection
.
Note:
Motorola Original USB data cables
and supporting software are sold separately.
Check your computer or hand-held device to
determine the type of cable you need. To
transfer data
between your phone and
computer, you might need to install the software
included with the Motorola Original data kit. See the data
kit user’s guide for more information.
connect your memory card to
aPC
Note:
Memory cards are optional. To insert a
memory card, see page 7.
4H
cable connections
49
You can use a cable connection to access your phone’s
memory card with a computer. When your phone is
connected to a computer, you can only access the
memory card through the computer.
Note:
When your phone is plugged into a computer and
is being used for mass storage, it cannot be used for
anything else, including making emergency calls. To
restore the phone to normal use, disconnect it from the
PC.
Note:
The unauthorized copying of copyrighted materials
is contrary to the provisions of the Copyright Laws of the
United States and other countries. This device is
intended solely for copying non-copyrighted materials,
materials in which you own the copyright, or materials
which you are authorized or legally permitted to copy. If
you are uncertain about your right to copy any material,
please contact your legal advisor.
On your phone:
On your Phone
1
Disconnect the cable
from your phone, if it is
connected, then press
s
>
wSettings
>
Connection
>
USB Settings
>
Default Connection
>
Memory Card
.
cable connections
50
2
Connect the cable
to your phone (see page 48) and
to an available USB port on your computer.
On your computer:
1
Open your “My Computer” window, then click on
the “Removable Disk” icon to see the files on your
memory card.
2
Drop files into these folders on the memory card
(create the folders if necessary):
mobile\audio
,
mobile\picture
(wallpapers or screen savers), or
mobile\video
.
3
When you finish, select the “Safely Remove
Hardware” icon in the system tray at the bottom of
your computer screen, then disconnect the “USB
Mass Storage Device” (your memory card).
4
Disconnect the cable.
memory card
51
memor y card
store more
show & manage files
Note:
Memory cards are optional. To insert a
memory card, see page 7.
Do not remove your memory card while your phone is
using it or writing files on it.
To
see memory card files
, open a file list, such as
hMultimedia
>
Media Finder
>
Pictures
.
To copy or move a file
from your phone to your
memory card
, highlight it in the list and press
Options
>
Manage
>
Copy
or
Move
>
Memory Card
.
To see your card’s
available memory
and other
information:
s
>
wSettings
>
Phone Status
>
Storage Devices
.
Note:
If you download a copyrighted file and store it on
your memory card, you can use the file only while your
memory card is inserted in your phone. You cannot send,
copy, or change copyrighted files.
synchronize
52
synchronize
keep up-to-date
ActiveSync
You can use the Internet to synchronize your
phone’s phonebook and datebook entries with an email
account on a Microsoft® Exchange 2003 Server.
You need to know the email account’s
user name
and
password
, the Microsoft® Exchange
server name
, and
the
user domain name
. Confirm that the
Mobility
option is enabled on the email account, and that
data
service
is activated with your phone service provider.
To schedule
automatic synchronization with an
ActiveSync partner you set up, press
s
>
wSettings
>
Connection
>
MOTOSYNC
>
Exchange
, then press
Options
>
Auto Sync Setup
. Enter the time and days you want your
phone to synchronize.
tools
53
tools
keep up with life
calendar
add new events
Find it:
s
>
wSettings
>
Tools
>
Calendar
, scroll to the day,
press
s
, scroll to
Create New Event
, and press
s
When you see an
event reminder
, press
View
to open
event details or press
Exit
to close the reminder.
Tip:
To change your reminder sound, see page 29.
see or edit events
Find it:
s
>
wSettings
>
Tools
>
Calendar
, scroll to the day,
and press
s
Scroll to the event and press
s
. To edit the details,
press
Options
>
Edit
.
Tip:
Keeping up with life can be tough work. To see a list
of your upcoming events, open the calendar and press
Options
>
View
>
Organized Events
.
tools
54
send events to other devices
Find it:
s
>
wSettings
>
Tools
>
Calendar
, scroll to the day,
press
s
, scroll to the event, press
Options
>
Send
>
with Bluetooth
print events
You can use a Bluetooth wireless connection to
send a datebook month, week, or day from your phone
to a printer.
Find it:
s
>
wSettings
>
Tools
>
Calendar
Go to the month, week, or day view and press
Options
>
Print
.
For more about Bluetooth connections, see page 43.
alarms
To set an alarm
, press
s
>
wSettings
>
Tools
>
Alarm Clock
When an alarm happens
: To turn off the alarm, press
Disable
or
é
. To set a delay, press
Snooze
.
tools
55
voice records
create voice records
Find it:
s
>
hMultimedia
>
Voice Record
When you are ready, press
s
and speak into the phone.
play voice records
Find it:
s
>
hMultimedia
>
Media Finder
>
Voice Notes
, scroll
to the voice record, and press
s
calculator & currency converter
calculator
Find it:
s
>
wSettings
>
Tools
>
Calculator
currency converter
Find it:
s
>
wSettings
>
Tools
>
Calculator
, then press
Options
>
Exchange Rate
Enter the exchange rate, press
OK
, enter the amount,
then press
Options
>
Convert Currency
.
security
56
security
keep your phone safe
codes & passwords
Your phone’s four-digit
unlock code
is originally set to
1234
. The six-digit
security code
is originally set to
000000
. If your service provider didn’t change these
codes, you should change them:
Find it:
s
>
wSettings
>
Security
>
New Passwords
You can also change your
SIM PIN
password.
If you forget your unlock code:
At the
Enter Unlock Code
prompt, try entering 1234 or the last four digits of your
phone number. If that doesn’t work, press
s
and enter
your six-digit security code instead.
If you forget other codes:
If you forget your security
code, SIM PIN code, PIN2 code, or call barring password,
contact your service provider.
lock & unlock phone
You can lock your phone to keep others from using it. To
lock or unlock your phone, you need the four-digit unlock
code.
security
57
To
manually lock
your phone:
Press
s
>
wSettings
>
Security
>
Phone Lock
>
Lock Now
, then
enter your four-digit unlock code.
To
automatically lock
your phone whenever you turn it
off: Press
s
>
wSettings
>
Security
>
Phone Lock
>
Automatic Lock
>
On
, then enter your four-digit unlock code.
Note:
You can make emergency calls on a locked phone
(see page 12). A locked phone still rings or vibrates for
incoming calls or messages,
but you need to unlock it
to answer
.
lock your SIM card or applications
To lock or unlock your
SIM card
, press
s
>
wSettings
>
Security
>
SIM PIN
.
Caution:
If you enter an incorrect PIN code three times
before the correct code, your SIM card is disabled and
your display shows
SIM Blocked
.
To
lock an application
(such as
Messaging
),
press
s
>
wSettings
>
Security
>
Lock Application
.
Enter your unlock code to open a list of applications.
Select an application and choose
Locked
to lock it.
service & repairs
58
servi ce & repai rs
we’re here to help
If you have questions or need assistance, we're here to
help.
Go to
www.motorola.com/support
, where you can select
from a number of customer care options. You can also
contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456 (TTY/
TDD United States for hearing impaired), or
1-800-461-4575 (Canada).
59
legal & safety
battery use & safety
IMPORTANT: HANDLE AND STORE BATTERIES PROPERLY TO AVOID
INJURY OR DAMAGE.
Most battery issues arise from improper handling of
batteries, and particularly from the continued use of damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or otherwise attempt to
change the form of your battery.
• Don’t let the phone or battery come in contact with water.
Water can get
into the phone’s circuits, leading to corrosion. If the phone and/or battery get
wet, have them checked by your carrier or contact Motorola, even if they appear
to be working properly.
• Don’t allow the battery to touch metal objects.
If metal objects, such as
jewelry, stay in prolonged contact with the battery contact points, the battery
could become very hot.
• Don’t place your battery near a heat source.
Excessive heat can damage the
phone or the battery. High temperatures can cause the battery to swell, leak, or
malfunction. Therefore:
•
Do
not
dry a wet or damp battery with an appliance or heat source, such as a
hair dryer or microwave oven.
•
Avoid leaving your phone in your car in high temperatures.
DOs
• Do avoid dropping the battery or phone.
Dropping these items, especially on
a hard surface, can potentially cause damage.
• Do contact your service provider or Motorola if your phone or battery
has been damaged from dropping or high temperatures.
IMPORTANT: USE MOTOROLA ORIGINAL PRODUCTS FOR QUALITY
ASSURANCE AND SAFEGUARDS.
To aid consumers in identifying authentic
Motorola batteries from non-original or counterfeit batteries (that may not have
adequate safety protection), Motorola provides holograms on its batteries.
60
Consumers should confirm that any battery they purchase has a “Motorola Original”
hologram.
Motorola recommends you always use Motorola-branded batteries and
chargers.
Motorola mobile devices are designed to work with Motorola batteries.
If you see a message on your display such as
Invalid Battery
or
Unable to Charge
, take
the following steps:
•
Remove the battery and inspect it to confirm that it has a “Motorola Original”
hologram;
•
If there is no hologram, the battery is not a Motorola battery;
•
If there is a hologram, replace the battery and retry charging it;
•
If the message remains, contact a Motorola Authorized Service Center.
Important:
Motorola’s warranty does not cover damage to the phone caused by
non-Motorola batteries and/or chargers.
Warning:
Use of a non-Motorola battery or charger may present a risk of fire,
explosion, leakage, or other hazard.
PROPER AND SAFE BATTERY DISPOSAL AND RECYCLING
Proper battery disposal is not only important for safety, it benefits the environment.
Consumers may recycle their used batteries in many retail or service provider
locations. Additional information on proper disposal and recycling may be found on
the Web:
•
www.motorola.com/recycling
•
www.rbrc.org/call2recycle/
(in English only)
Disposal:
Promptly dispose of used batteries in accordance with local
regulations. Contact your local recycling center or national recycling
organizations for more information on how to dispose of batteries.
Warning:
Never dispose of batteries in a fire because they may
explode.
battery charging
Notes for charging your phone’s battery:
•
When charging your battery, keep it near room temperature. Never expose
batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when
charging.
61
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time may take more time to charge.
•
Motorola batteries and charging systems have circuitry that protects the battery
from damage from overcharging.
61a
Specific Absorption Rate Data
The model wireless phone meets the government’s requirements
for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission (FCC) of the U.S.
Government and by the Canadian regulatory authorities. These limits are
part of comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC and by the Canadian regulatory authorities is 1.6 W/
kg
1
Tests for SAR are conducted using standard operating positions
accepted by the FCC and by Industry Canada with the phone transmitting
at its highest certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the maximum value.
This is because the phone is designed to operate at multiple power levels
so as to use only the power required to reach the network. In general, the
closer you are to a wireless base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S. and
Canada, it must be tested and certified to the FCC and Industry Canada
that it does not exceed the limit established by each government for safe
exposure. The tests are performed in positions and locations (e.g., at the
ear and worn on the body) reported to the FCC and available for review by
Industry Canada. The highest SAR value for this model phone when
tested for use at the ear is 1.09 W/kg, and when worn on the body, as
61b
described in this user guide, is 0.77 W/kg. (Body-worn measurements
differ among phone models, depending upon available accessories and
regulatory requirements).
2
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the governmental requirements for
safe exposure. Please note that improvements to this product model
could cause differences in the SAR value for later products; in all cases,
products are designed to be within the guidelines.
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications & Internet Association (CTIA) Web
site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web
site:
http://www.cwta.ca
1.
In the United States and Canada, the SAR limit for mobile phones used by
the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The
standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
2. A
The SAR information includes the Motorola testing protocol, assessment
procedure, and measurement uncertainty range for this product.
62
Additional Information can be found on the websites of the World Health
Organization (
http://www.who.int/emf
) or Motorola, Inc. (
http://
www.motorola.com/rfhealth
).
1. The tests are carried out in accordance with international guidelines for testing.
The limit incorporates a substantial margin for safety to give additional
protection for the public and to account for any variations in measurements.
Additional related information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty range for this product.
2. Please see the Safety and General Information section about body worn
operation.
European Union Directives
Conformance Statement
EU Conformance
Hereby, Motorola declares that this product is in compliance
with:
•
The essential requirements and other relevant provisions of
Directive 1999/5/EC
•
All other relevant EU Directives
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC
(to R&TTE Directive) at
www.motorola.com/rtte
. To find your DoC, enter the
0168
Product
Approval
Number
63
Product Approval Number from your product’s label in the “Search” bar on the Web
site.
Safety and General Information
Safety I nformation
This section contains important information on the safe and efficient
operation of your mobile device. Read this information before using your
mobile device.
Exposure to Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives
and transmits RF energy. When you communicate with your mobile device, the
system handling your call controls the power level at which your mobile device
transmits.
Your Motorola mobile device is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to RF energy.
Operational Precautions
For optimal mobile device performance, and to be sure that human exposure to RF
energy does not exceed the guidelines set forth in the relevant standards, always
follow these instructions and precautions.
Product Operation
When placing or receiving a phone call, hold your mobile device just like you would
a landline phone.
If you wear the mobile device on your body, always place the mobile device in a
Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do
not use a body-worn accessory supplied or approved by Motorola, keep the mobile
device and its antenna at least 2.5 centimeters (1 inch) from your body when
transmitting.
Using accessories not supplied or approved by Motorola may cause your mobile
device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or
approved accessories, visit our Web site at:
www.motorola.com
.
64
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external
sources if inadequately shielded, designed, or otherwise configured for RF energy
compatibility. In some circumstances your mobile device may cause interference
with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to do
so.
In an aircraft, turn off your mobile device whenever instructed to do so by airline
staff. If your mobile device offers an airplane mode or similar feature, consult airline
staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or defibrillator,
consult your physician before using this mobile device.
Persons with implantable medical devices should observe the following precautions:
•
ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the
implantable medical device when the mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to minimize the potential
for interference.
•
Turn OFF the mobile device immediately if you have any reason to suspect that
interference is taking place.
Read and follow the directions from the manufacturer of your implantable medical
device. If you have any questions about using your mobile device with your
implantable medical device, consult your healthcare provider.
Driving Precautions
The use of wireless phones while driving may cause distraction. Discontinue a call if
you can’t concentrate on driving.
Additionally, the use of wireless devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and regulations on the use of
these products.
65
Responsible driving practices can be found in the “Smart Practices While Driving”
section in this guide (or separate guide).
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always, posted and
can include fueling areas, such as below decks on boats, fuel or chemical transfer or
storage facilities, or areas where the air contains chemicals or particles, such as
grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not remove,
install, or charge batteries. In such areas, sparks can occur and cause an explosion
or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as follows:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a fire.
Your battery or mobile device may require recycling in
accordance with local laws. Contact your local regulatory
authorities for more information.
Do not throw your battery or mobile device in the trash.
032374o
032376o
032375o
66
Batteries & Chargers
Caution: Improper treatment or use of batteries may present a danger of
fire, explosion, leakage, or other hazard. For more information, see the
“battery use & safety” section in the user’s guide.
Keep Your Mobile Device and Its Accessories
Away From Small Children
These products are not toys and may be hazardous to children. For example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could break if
the product is dropped on a hard surface or receives a substantial impact. If glass
breaks, do not touch or attempt to remove. Stop using your mobile device until the
glass is replaced by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when exposed to
flashing lights, such as when playing video games. These may occur even if a person
has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult with your physician before playing video games or
enabling a flashing-lights feature (if available) on your mobile device.
Do not let your battery, charger, or mobile device get wet.
Listening at full volume to music or voice through a headset
may damage your hearing.
Symbol Definition
67
Discontinue use and consult a physician if any of the following symptoms occur:
convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or
disorientation. It is always a good idea to hold the screen away from your eyes,
leave the lights on in the room, take a 15-minute break every hour, and stop use if
you are tired.
Caution About High Volume Usage
Warning:
Exposure to loud noise from any source for extended
periods of time may affect your hearing. The louder the volume
sound level, the less time is required before your hearing could be
affected. To protect your hearing:
•
Limit the amount of time you use headsets or headphones at high volume.
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness
in your ears, ringing in your ears, or muffled speech, you should stop listening to the
device through your headset or headphones and have your hearing checked.
For more information about hearing, see our Web site at
www.motorola.com/
hearingsafety
(in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in your hands,
arms, shoulders, neck, or other parts of your body. If you continue to have discomfort
during or after such use, stop use and see a physician.
[Mar0108]
FCC Notice to Users
FCC Notice
The following statement applies to all products that have received FCC
approval. Applicable products bear the FCC logo, and/or an FCC ID in the
format FCC-ID:xxxxxx on the product label.
Motorola has not approved any changes or modifications to this device by the user.
Any changes or modifications could void the user’s authority to operate the
equipment. See 47 CFR Sec. 15.21.
68
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation. See 47 CFR Sec. 15.19(3).
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Use and Care
Use an d Care
To care for your Motorola phone, please keep it away from:
liquids of any kind
Don’t expose your phone to water, rain, extreme humidity,
sweat, or other moisture. If it does get wet, don’t try to
accelerate drying with the use of an oven or dryer, as this may
damage the phone.
dust and dirt
Don’t expose your phone to dust, dirt, sand, food, or other
inappropriate materials.
69
extreme heat or cold
Avoid temperatures below 0°C/32°F or above 45°C/113°F.
cleaning solutions
To clean your phone, use only a dry soft cloth. Don’t use alcohol
or other cleaning solutions.
microwaves
Don’t try to dry your phone in a microwave oven.
the ground
Don’t drop your phone.
Information from the World Health
Organization
WHO Informat ion
Present scientific information does not indicate the need for any special precautions
for the use of mobile phones. If you are concerned, you may want to limit your own
or your children’s RF exposure by limiting the length of calls or by using handsfree
devices to keep mobile phones away from your head and body.
Source: WHO Fact Sheet 193
Further information:
http://www.who.int./peh-emf
Caring for the Environment by
Recycling
Recycling Information
70
This symbol on a Motorola product means the product
should not be disposed of with household waste.
Disposal of your Mobile Device and
Accessories
Please do not dispose of mobile devices or electrical accessories (such as chargers,
headsets, or batteries) with your household waste. These items should be disposed
of in accordance with the national collection and recycling schemes operated by
your local or regional authority. Alternatively, you may return unwanted mobile
devices and electrical accessories to any Motorola Approved Service Center in your
region. Details of Motorola approved national recycling schemes, and further
information on Motorola recycling activities can be found at:
www.motorola.com/
recycling
Disposal of your Mobile Device Packaging and
User’s Guide
Product packaging and user’s guides should only be disposed of in accordance with
national collection and recycling requirements. Please contact your regional
authorities for more details.
Privacy and Data Security
Privacy and Data Security
Motorola understands that privacy and data security are important to everyone.
Because some features of your mobile device may affect your privacy or data
security, please follow these recommendations to enhance protection of your
information:
• Monitor access
—Keep your mobile device with you and do not leave it where
others may have unmonitored access. Lock your device’s keypad where this
feature is available.
• Keep software up to date
—If Motorola or a software/application vendor
releases a patch or software fix for your mobile device which updates the
device’s security, install it as soon as possible.
• Erase before recycling
—Delete personal information or data from your
mobile device prior to disposing of it or turning it in for recycling. For step-by-step
71
instructions on how to delete all personal information from your device, see the
section entitled “master clear” or “delete data” in this user’s guide.
Note:
For information on backing up your mobile device data before erasing it,
go to
www.motorola.com
and then navigate to the “downloads” section of the
consumer Web page for “Motorola Backup” or “Motorola Phone Tools.”
• Understanding AGPS
—In order to comply with emergency caller location
requirements of the FCC, certain Motorola mobile devices incorporate Assisted
Global Positioning System (AGPS) technology. AGPS technology also can be used
in non-emergency applications to track and monitor a user’s location—for
example, to provide driving directions. Users who prefer not to permit such
tracking and monitoring should avoid using such applications.
If you have further questions regarding how use of your mobile device may impact
your privacy or data security, please contact Motorola at
privacy@motorola.com
, or
contact your service provider.
Smart Practices While Driving
Driving Safety
Drive Safe, Call Smart
Check the laws and regulations on the use of mobile devices and their
accessories in the areas where you drive. Always obey them. The use of
these devices may be prohibited or restricted in certain areas -- for
example, handsfree use only. Go to
www.motorola.com/callsmart
(in English
only) for more information.
Your mobile device lets you communicate by voice and data—almost anywhere,
anytime, wherever wireless service is available and safe conditions allow. When
driving a car, driving is your first responsibility. If you choose to use your mobile
device while driving, remember the following tips:
• Get to know your Motorola mobile device and its features such as speed
dial and redial.
If available, these features help you to place your call without
taking your attention off the road.
72
• When available, use a handsfree device.
If possible, add
an additional layer of convenience to your mobile device with
one of the many Motorola Original handsfree accessories
available today.
• Position your mobile device within easy reach.
Be able
to access your mobile device without removing your eyes from
the road. If you receive an incoming call at an inconvenient time, if possible, let
your voicemail answer it for you.
• Let the person you are speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather conditions.
Rain,
sleet, snow, ice, and even heavy traffic can be hazardous.
• Do not take notes or look up phone numbers while driving.
Jotting down a
“to do” list or going through your address book takes attention away from your
primary responsibility—driving safely.
• Dial sensibly and assess the traffic; if possible, place calls when your
car is not moving or before pulling into traffic.
If you must make a call while
moving, dial only a few numbers, check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations that may be
distracting.
Make people you are talking with aware you are driving and
suspend conversations that can divert your attention away from the road.
• Use your mobile device to call for help.
Dial 911 or other local emergency
number in the case of fire, traffic accident, or medical emergencies.*
• Use your mobile device to help others in emergencies.
If you see an auto
accident, crime in progress, or other serious emergency where lives are in
danger, call 911 or other local emergency number, as you would want others to
do for you.*
• Call roadside assistance or a special non-emergency wireless
assistance number when necessary.
If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a minor traffic accident where
no one appears injured, or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless number.*
73
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the capabilities and settings of
your service provider’s network. Additionally, certain features may not be activated
by your service provider, and/or the provider’s network settings may limit the
feature’s functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other product
specifications, as well as the information contained in this user’s guide are based
upon the latest available information and are believed to be accurate at the time of
printing. Motorola reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark
Office. All other product or service names are the property of their respective
owners. The Bluetooth trademarks are owned by their proprietor and used by
Motorola, Inc. under license. Java and all other Java-based marks are trademarks or
registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.
Microsoft, Windows and Windows Me are registered trademarks of Microsoft
Corporation; and Windows XP is a trademark of Microsoft Corporation.
© 2008 Motorola, Inc. All rights reserved.
Caution:
Changes or modifications made in the radio phone, not expressly approved
by Motorola, will void the user’s authority to operate the equipment.
Manual Number: 68XXXXX359___
U.S. patent Re. 34,976
* Wherever wireless phone service is available.
