Motorola Mobility P56JS1 Portable Cellular/ PCS/ AWS CDMA Transceiver with Bluetooth User Manual
Motorola Mobility LLC Portable Cellular/ PCS/ AWS CDMA Transceiver with Bluetooth
Exhibit 8 Users Manual
User’s Guide
MOTOTM
VE240
v558637.eps 7/16/2008 12:56:42 PM
1
HELLOMOTO
Thanks for purchasing the MOTO
TM
VE240 CDMA wireless phone! It’s an affordable phone with a sleek design that’s
sure to get attention.
Get Value
— This affordable, easy-to-use phone is packed with the coolest features like voice dialing, messaging,
internet browsing, and Bluetooth® wireless connectivity.
Your Music, Now
— Listen to your favorite tunes with the digital music player.
My Phone, My Way
— It’s your phone—make it that way. Customize your home screen with personal pictures,
change wallpapers, and use your favorite song as your ringtone.
2
Here’s a quick anatomy lesson.
Music Player Key
Left Soft Key
Perform function in
lower left display.
Send Key
Make & answer calls.
Clear Key
Right Soft Key
Perform function in
lower right display.
Power/End Key
Turn phone on/off,
end calls, exit menus.
4-Way Navigation Key
with Center Select
Press the center key to
open the main menu.
Headphone
Port
Mini USB Port
Insert charger
& other accessories.
3
Press and hold the
Power
Key
P for a few
seconds, or until the
display lights up, to turn
on your phone.
1
Press the Navigation
Key (
S
)
up, down, left,
or
right
to highlight a
menu feature.
3
Press the Center
Key (
s
) to select it.
4
Press the Menu Key
M
to open the
Main Menu
.
2
Home Screen Main Menu
Message
Tue 05/06/08 1:56pm
ContactsMENU
gE
Lqj
T
mu
1X 1X
Û
Recent Calls
4
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Note:
Do not ship your phone to the above address. If you need to
return your phone for repairs, replacement, or warranty service, please
contact the Motorola Customer Support Center at:
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain
features may not be activated by your service provider, and/or the
provider’s network settings may limit the feature’s functionality. Always
contact your service provider about feature availability and functionality.
All features, functionality, and other product specifications, as well as
the information contained in this user’s guide, are based upon the latest
available information and believed to be accurate at the time of
printing. Motorola reserves the right to change or modify any
information or specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license. Microsoft,
Windows and Windows Me are registered trademarks of Microsoft
Corporation; and Windows XP is a trademark of Microsoft Corporation.
iTunes
TM
is a trademark of Apple Computer, Inc. All other product or
service names are the property of their respective owners.
© 2008 Motorola, Inc. All rights reserved.
Caution:
Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to operate
the equipment.
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third-party software stored in semiconductor
memories or other media. Laws in the United States and other countries
preserve for Motorola and third-party software providers certain
exclusive rights for copyrighted software, such as the exclusive rights to
distribute or reproduce the copyrighted software. Accordingly, any
copyrighted software contained in the Motorola products may not be
modified, reverse-engineered, distributed, or reproduced in any manner
to the extent allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by implication,
estoppel, or otherwise, any license under the copyrights, patents, or
patent applications of Motorola or any third-party software provider,
except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Manual Number: 68000201589-A
5
contents
contents
menu map . . . . . . . . . . . . . . . . 7
Use and Care . . . . . . . . . . . . . . 9
get started . . . . . . . . . . . . . . . 10
about this guide . . . . . . . . . 10
memory card . . . . . . . . . . . 11
battery. . . . . . . . . . . . . . . . . 11
turn it on & off. . . . . . . . . . . 16
make & answer calls. . . . . . 16
store a phone number . . . . 16
call a stored number . . . . . . 17
view your phone number . . 17
basics . . . . . . . . . . . . . . . . . . . 18
home screen. . . . . . . . . . . . 18
adjust volume . . . . . . . . . . . 21
handsfree . . . . . . . . . . . . . . 21
codes . . . . . . . . . . . . . . . . . 22
lock & unlock phone . . . . . . 23
keypad lock. . . . . . . . . . . . . 24
if you forget a code . . . . . . 24
lock application. . . . . . . . . . 25
manage memory . . . . . . . . 25
TTY operation. . . . . . . . . . . 27
airplane mode. . . . . . . . . . . 28
tips & tricks . . . . . . . . . . . . . . 29
personalize . . . . . . . . . . . . . . 30
home screen shortcuts . . . 30
ringtones . . . . . . . . . . . . . . 30
wallpaper . . . . . . . . . . . . . . 32
skins. . . . . . . . . . . . . . . . . . 33
voice readout . . . . . . . . . . . 33
key volumes . . . . . . . . . . . . 33
alert reminders. . . . . . . . . . 34
ring & vibrate . . . . . . . . . . . 34
answer options. . . . . . . . . . 34
backlight . . . . . . . . . . . . . . . 34
brightness . . . . . . . . . . . . . . 35
banner . . . . . . . . . . . . . . . . . 35
menu language . . . . . . . . . . 35
dial fonts . . . . . . . . . . . . . . . 35
clock format. . . . . . . . . . . . . 35
restore phone . . . . . . . . . . . 36
AGPS & your location . . . . . 36
AGPS limitations & tips . . . . 37
calls . . . . . . . . . . . . . . . . . . . . . 38
redial a number . . . . . . . . . . 38
automatic retry . . . . . . . . . . 38
turn off a call alert . . . . . . . . 38
recent calls . . . . . . . . . . . . . 39
return a missed call . . . . . . . 40
speed dial . . . . . . . . . . . . . . 40
one-touch dial . . . . . . . . . . . 41
6
contents
emergency calls . . . . . . . . . 41
AGPS during an
emergency call . . . . . . . . . . 41
attach number . . . . . . . . . . 42
insert special characters. . . 42
international calls . . . . . . . . 43
voicemail . . . . . . . . . . . . . . 43
hearing aid . . . . . . . . . . . . . 43
in-call options . . . . . . . . . . . 44
call times . . . . . . . . . . . . . . 44
more calling features . . . . . 45
text entry . . . . . . . . . . . . . . . . 46
set entry modes . . . . . . . . . 47
tap mode . . . . . . . . . . . . . . 48
iTAP mode . . . . . . . . . . . . . 49
numeric mode . . . . . . . . . . 49
symbol mode . . . . . . . . . . . 50
text entry tips . . . . . . . . . . . 50
messages . . . . . . . . . . . . . . . 51
send a multimedia
message . . . . . . . . . . . . . . 51
receive a message. . . . . . . 53
more messaging features . 55
entertainment. . . . . . . . . . . . 58
music . . . . . . . . . . . . . . . . . 58
view pictures . . . . . . . . . . . 65
manage sounds . . . . . . . . . 67
music player. . . . . . . . . . . . 68
launch browser . . . . . . . . . 68
tools. . . . . . . . . . . . . . . . . . . . 69
voice recognition . . . . . . . . 69
phonebook. . . . . . . . . . . . . . 74
network . . . . . . . . . . . . . . . 78
personal organizer . . . . . . . 79
connections . . . . . . . . . . . . . 82
cable connections . . . . . . . 82
Bluetooth connections. . . . 82
service & repairs . . . . . . . . . . 89
SAR Data . . . . . . . . . . . . . . . . 90
Safety Information. . . . . . . . . 94
Industry Canada Notice . . . . 97
FCC Notice . . . . . . . . . . . . . . . 97
Warranty. . . . . . . . . . . . . . . . . 98
Hearing Aids. . . . . . . . . . . . . 101
WHO Information. . . . . . . . . 102
Registration . . . . . . . . . . . . . 102
Export Law . . . . . . . . . . . . . . 103
Recycling Information . . . . . 103
Perchlorate Label . . . . . . . . . 103
Privacy and Data Security . . 104
Driving Safety . . . . . . . . . . . 104
index . . . . . . . . . . . . . . . . . . . 106
7
menu map
menu map
main menu
g
Messaging
•Voicemail
• Create Message
• Inbox
• Outbox
•Drafts
T
BREW
E
Browser
L
Phonebook
q
Recent Calls
• Received Calls
• Missed Calls
• Dialed Calls
• All Calls
•Timers
j
Multimedia
• Music & Sounds
•Pictures
•StorageDevice
m
To o l s
• Voice Commands
• Datebook
•AlarmClock
• World Clock
•Calculator
• Notepad
u
Settings
• (see next page)
Û
Phone Info
•MyNumber
This is the standard main menu layout.
Your
phone’s menu may be different.
8
menu map
settings menu
Sounds
• Call Ringtone
• Message Ringtone
• Voicemail Ringtone
•Ring&Vibrate
• Alert Reminders
• Service Alerts
•PowerOn/Off
• Voice Readout
• Keypad Volume
• Volume Sidekeys
Display
• Banner
• Backlight
• Brightness
• Wallpaper
•Skins
• Dial Fonts
•ClockFormat
Phone
• Airplane Mode
• Shortcuts
• Language
•Location
• Security
• Network Selection
• Active Line
•TextLearning
Call
• Answer Options
• Auto Retry
• TTY Setup
• One Touch Dial
• Int’l Dialing
• DTMF Tones
• Hearing Aid
Bluetooth
•AddNewDevice
USB
• Mass Storage
• Modem/COM
Storage Device
• Save Options*
• Phone Memory
• Memory Card*
Phone Info
* available only when optional memory card
installed
9
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain, extreme
humidity, sweat, or other moisture. If it does get
wet, don’t try to accelerate drying with the use of
an oven or dryer, as this may damage the phone.
Don’t expose your phone to dust, dirt, sand, food,
or other inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below -10°C/14°F or
above 45°C/113°F.
To clean your phone, use only a dry soft cloth.
Don’t use alcohol or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a microwave oven. Don’t drop your phone.
10
get started
get started
about this guide
This guide shows how to locate a menu feature as
follows:
Find it:
s
>
qRecent Calls
>
Dialed Calls
This means that, from the home screen:
1
Press the center key
s
to open the menu.
2
Press the navigation key
S
to scroll to
qRecent Calls
, and press the center key
s
to
select it.
3
Press the navigation key
S
to scroll to
Dialed Calls
,
and press the center key
s
to select it.
CAUTION:
Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is
network/subscription dependent and may
not be available in all areas. Contact your
service provider for more information.
This means a feature requires an optional
accessory.
11
get started
memory card
Note: Optional accessory required.
Caution:
Don’t remove your memory card while your
phone is using it or writing files to it.
1
Remove the battery door from your phone (see
page 14). If necessary, remove the battery.
2
Push and hold the
rubber arm away
from the memory
card opening.
3
With the gold
contacts down,
slide the memory
card into the into
the metal slot.
4
Push the card
completely into
place.
5
Replace the battery and battery door.
To remove the memory
card
, push and hold the
rubber arm away from
the memory card
opening, then slide the
memory card out of the opening.
battery
conserve battery charge
Using certain features can quickly deplete your
battery’s charge.
These features can include
12
get started
downloading music, replaying video clips, and
using Bluetooth® wireless connections.
You can conserve your battery’s charge by doing the
following:
•
Turn Bluetooth power off when not in use (see
page 83).
•
Turn off wallpaper (see your Quick Start Guide).
•
Reduce backlight display time (see your Quick
Start Guide).
battery use & safety
IMPORTANT: HANDLE AND STORE BATTERIES
PROPERLY TO AVOID INJURY OR DAMAGE.
Most
battery issues arise from improper handling of
batteries, and particularly from the continued use of
damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred,
or otherwise attempt to change the form of
your battery.
• Don’t let the phone or battery come in
contact with water.
Water can get into the
phone’s circuits, leading to corrosion. If the
phone and/or battery get wet, have them
checked by your carrier or contact Motorola
even if they appear to be working properly.
• Don’t allow the battery to touch metal
objects.
If metal objects, such as jewelry, stay
in prolonged contact with the battery contact
points, the battery could become very hot.
• Don’t place your battery near a heat source.
Excessive heat can damage the phone or the
battery. High temperatures can cause the
battery to swell, leak, or malfunction.
Therefore:
13
get started
•
Do
not
dry a wet or damp battery with an
appliance or heat source, such as a hair
dryer or microwave oven.
•
Avoid leaving your phone in your car in high
temperatures.
DOs
• Do avoid dropping the battery or phone.
Dropping these items, especially on a hard
surface, can potentially cause damage.
• Do contact your service provider or
Motorola if your phone or battery has been
damaged from dropping or high
temperatures.
IMPORTANT: USE MOTOROLA ORIGINAL
PRODUCTS FOR QUALITY ASSURANCE AND
SAFEGUARDS.
To aid consumers in identifying
authentic Motorola batteries from non-original or
counterfeit batteries (that may not have adequate
safety protection), Motorola provides holograms on its
batteries. Consumers should confirm that any battery
they purchase has a “Motorola Original” hologram.
Motorola recommends you always use
Motorola-branded batteries and chargers.
Motorola
mobile devices are designed to work with Motorola
batteries. If you see a message on your display such as
Invalid Battery
or
Unable to Charge
, take the following steps:
•
Remove the battery and inspect it to confirm
that it has a “Motorola Original” hologram;
•
If there is no hologram, the battery is not a
Motorola battery;
•
If there is a hologram, replace the battery and
retry charging it;
•
If the message remains, contact a Motorola
Authorized Service Center.
14
get started
Important:
Motorola’s warranty does not cover
damage to the phone caused by non-Motorola batteries
and/or chargers.
Warning:
Use of a non-Motorola battery or charger may
present a risk of fire, explosion, leakage, or other
hazard.
PROPER AND SAFE BATTERY DISPOSAL AND
RECYCLING
Proper battery disposal is not only important for safety,
it benefits the environment. Consumers may recycle
their used batteries in many retail or service provider
locations. Additional information on proper disposal and
recycling may be found on the Web:
•
www.motorola.com/recycling
•
www.rbrc.org/call2recycle/
(in English only)
Disposal:
Promptly dispose of used batteries
in accordance with local regulations. Contact
your local recycling center or national recycling
organizations for more information on how to dispose
of batteries.
Warning:
Never dispose of batteries in a fire because
they may explode.
install the battery
1
Press down on the battery
cover, slide it up slightly, then
lift if off the phone.
2
With the gold contacts facing
down and toward the lower
end of the battery, insert the
battery, lower end first.
15
get started
3
Fit the battery cover back
onto the phone and slide it
forward into place.
charge the battery
New batteries are not fully charged. Before you can use
your phone, install and charge the battery. Some
batteries perform best after several full
charge/discharge cycles.
Using the charger:
1
Insert the charger into your
phone’s mini USB connector.
Plug the other end of the
charger into an electrical outlet.
2
When you see
Charge Complete
, unplug the charger.
When you charge the battery, the battery level indicator
at the upper right of the screen shows charging
progress. At least one segment of the indicator must
be visible to ensure full phone functionality while
charging.
Charging from your computer:
Note: Optional accessories required.
You can charge the battery by connecting a cable from
your phone’s mini USB port to a high-power USB
connector on a computer (not a low-power one, such as
the USB connector on your keyboard or bus-powered
USB hub). Typically, USB high-power connectors are
located directly on your computer.
Both your phone and your computer must be turned
on, and you must have correct software drivers
installed on your computer. Cables and software drivers
are available in Motorola Original
TM
data kits, sold
separately.
Note:
For battery use and battery safety information,
see your User’s Guide.
16
get started
Notes for charging your phone’s battery:
•
When charging your battery, keep it near room
temperature. Never expose batteries to
temperatures below 0°C (32°F) or above 45°C
(113°F) when charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long
time may take more time to charge.
•
Motorola batteries and charging systems have
circuitry that protects the battery from damage
from overcharging.
turn it on & off
To turn on your phone
, press
and hold
O
for a few
seconds or until the display
turns on. If prompted, enter
your four-digit unlock code.
To turn off your phone
, press and hold
O
for two
seconds.
make & answer calls
To make a call
, enter a
phone number and
press
N
.
To answer a call
, when your
phone rings and/or vibrates, just press
N
.
To hang up
, press
O
.
store a phone number
To store a phone number in your
Phonebook
:
1
Enter a phone number in the home screen.
2
Press
Save
.
17
get started
3
With
Create New Contact
highlighted, press the center
key
s
.
4
Set the number type (
Mobile 1
,
Mobile 2
,
Home
,
Work
, or
Fax
) and press the center key
s
.
5
Enter a name for the phone number, and enter
other information as desired. (Press
S
up or
down to highlight entry areas. To select a
highlighted entry area, press the center key
s
.)
6
Press
Save
to store the entry.
call a stored number
Find it:
s
>
LPhonebook
1
Scroll to
Contact List
and press the center key
s
.
2
Scroll to the entry you want to call.
Shortcut:
In your
Contact List
, use the keypad to enter
the first letters of an entry you want.
3
Press
N
to call the entry.
view your phone
number
Find it:
s
>
uSettings > Phone Info
>
My Number
You will see your phone number at the top of the
screen.
You can also view your number by pressing
Ò
,
then
#
.
Tip:
Want to see your phone number while you’re on a
call? Press
Options
>
Phone Info
>
My Number
.
18
basics
basics
home screen
Your phone shows the home screen when you are not
on a call or using the menu.
Note:
Your home screen might look different from the
one shown, depending on your service provider.
Soft key labels in the home screen show the current
soft key functions. See the next section for information
about status indicators.
status indicators
Indicators at the top of your phone’s display provide
important status information, such as incoming calls,
missed messages, and other conditions:
Message ContactsMENU
1X
Left Soft
Key Label
Status
Indicators
Left Soft
Key
Right Soft
Key Label
Right Soft
Key
19
basics
Here are the indicators you may see on your phone’s
display:
indicator
8
Signal Strength
—Vertical bars show the
strength of the network connection.
D
Digital
—Phone is in a CDMA digital
coverage area.
F
Analog
—Phone is in an analog coverage
area.
)
1xRTT
—Phone is in a 1xRTT coverage
area. (1xRTT offers higher voice and data
transmission than CDMA.)
í
Airplane Mode
—Phone’s features that
require voice or data transmission are
turned off (see page 28).
W
Roaming
—Phone is in a digital coverage
area and is roaming off network.
5
SSL
—Indicates phone is using Secure
Sockets Layer (SSL) secure data
transmission.
+
Data Call
—Shows during an active data
call.
ã
Dormant
—Indicates phone is dormant
and PPP session is active.
9
No Service
—Phone is in area with no
service coverage.
G
VR Active
—Indicates the phone’s Voice
Recognition feature is active (see
page 69).
æ
VR Listening
—Indicates the phone’s
Voice Recognition feature is waiting for a
voice command (see page 69).
indicator
20
basics
8
TTY
—Phone is in TTY mode (see
page 27).
è
911 Only
—
Location
is set to
Off (E911 Only)
.
ó
Location On
—
Location
is set to
On (Do Not Ask)
or
On (Always Ask)
.
0
Keypad Locked
—The keypad is locked.
A
Battery Level
—Shows battery charge
level. The more bars, the greater the
charge.
Bluetooth Active
—Your phone is paired
to another Bluetooth device.
Bluetooth On
—Your phone’s Bluetooth
power is
On
.
Bluetooth Connected
—Your phone is
connected to another Bluetooth device.
indicator
t
In Call
—Shows during an active voice
call.
]
New Message
—Phone received a new
text message.
w
New Voicemail Message
—Phone
received a new voicemail message.
U
New Text & Voicemail
Message
—Phone received a new text
and a new voicemail message.
J
All Sounds Off
—
Master Volume
is set to
All
sounds off
(see page 21).
H
Vibrate
—
Master Volume
is set to
Vibrate Only
(see page 21).
indicator
21
basics
adjust volume
With the flip open, press the
volume keys up or down to:
•
turn off an incoming
call alert
•
adjust the earpiece volume during calls
•
change sound settings (see your Quick Start
Guide)
handsfree
Note:
The use of wireless phones while driving may
cause distraction. Discontinue a call if you can’t
concentrate on driving. Additionally, the use of wireless
devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and
regulations on the use of these products.
handsfree speaker
You can use your phone’s handsfree speaker to make
calls without holding the phone to your ear.
To activate the handsfree
speaker during a call
, press and
hold the smart/speakerphone key.
á
Alarm Only
—
Master Volume
is set to
Alarm
Only
(see page 21).
=
Missed Call
—Phone received an
unanswered call.
i
Speakerphone On
—Speakerphone is
on.
h
Alarm On
—An alarm has been set.
Datebook Event
—A datebook event has
been created.
indicator
22
basics
You will hear an audible alert, and your phone will show
the speakerphone indicator
i
and
SPEAKER PHONE ON
on
the main screen.
The handsfree speaker stays on until you press and
hold the smart/speakerphone key again or turn off the
phone.
To turn off the handsfree speaker
, press and hold the
smart/speakerphone key. Your phone will show
SPEAKER
PHONE OFF
on the main screen.
To end the call
, press the power/end key
O
. You will
hear an audible alert.
Note:
The handsfree speaker won’t work when your
phone is connected to a handsfree car kit or headset.
accessory volume settings (car
kit or headset)
To adjust volume of headsets or car kit accessories that
are enabled for Bluetooth wireless connections, press
your phone’s volume keys up or down during an active
call.
codes
Your phone’s four-digit
unlock code
is originally set to
1234
or to the
last four digits of your phone number
.
The six-digit
security code
is originally set to
000000
.
Your service provider may reset these codes before you
get your phone.
If your service provider didn’t change the unlock code,
you should change it to prevent unauthorized use of
your phone. The unlock code must contain four digits.
To change the unlock code
:
Find it:
s
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
and press
Done
.
23
basics
2
With
Edit Lock Code
highlighted, press the center
key
s
.
3
Enter the new code in both entry fields and press
Done
.
lock & unlock phone
You can lock your phone manually or set it to lock
automatically whenever you turn it off.
To lock or unlock your phone, you need the four-digit
unlock code. A locked phone still rings or vibrates for
incoming calls or messages,
but you have to unlock it
to answer
.
You can make emergency calls on your phone even
when it is locked (see page 41).
manual lock
Find it:
s
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
and press
Done
.
2
Scroll to
Lock Phone Now
and press the center key
s
.
3
When prompted, enter the four-digit unlock code
and press
Done
.
To unlock your phone
:
Press
Unlock
(the right soft key). When you see
Enter Unlock
Code
, enter your four-digit unlock code and press
Done
.
automatic lock
To lock the phone whenever you turn it on:
Find it:
s
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
and press
Done
.
2
Scroll to
Phone Lock Setting
and press the center
key
s
.
3
Scroll to
On Power Up
and press the center key
s
.
24
basics
The phone will be locked whenever it is turned on. To
unlock the phone when you turn it on, enter the
four-digit lock code in the
Enter Lock Code
entry area and
press
Done
.
keypad lock
You can lock the phone’s keypad to prevent accidental
key presses.
To lock the keypad manually
:
With the flip open, press and hold
*
from the home
screen. To unlock the keypad, press
Unlock
, then press
the center key
s
.
To lock the keypad after a timer expires
:
Find it:
s
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
and press
Done
.
2
Scroll to
Keypad Lock Setting
and press the center
key
s
.
3
Scroll to
Timed
and press the center key
s
.
4
Scroll to
2 Seconds
,
4 Seconds
, or
8 Seconds
, and press the
center key
s
.
The keypad will be locked whenever it is at the home
screen and no keys are pressed for the period of time
you selected.
To unlock the phone
:
Press
Unlock
(the right soft key), then press the center
select key to select
Ok
.
if you forget a code
Your phone’s four-digit unlock code is set at the factory
to
1234
or to the last four digits of your phone number.
The six-digit security code is set to
000000
.
25
basics
If you forget your security code, contact your service
provider.
lock application
Find it:
s
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
and press
Done
.
2
Scroll to
Restrictions
and press the center key
s
.
3
Scroll to the desired application and press the
center key
s
:
Calls
,
Messages
,
Location
,
Data Modem
,
Brew
.
manage memory
Note:
The microSD memory card is an
optional
accessory
, available separately.
You can store multimedia content such as songs and
photos on your phone’s internal memory or on a
removable microSD memory card.
Note:
If you download a copyrighted file to your phone
and store it on your memory card, you can use the file
only when your memory card is inserted in your phone.
You cannot send, copy, or change copyrighted files.
See page 11 for instructions on installing a memory
card.
format memory card
Caution:
Formatting the memory card erases any data
stored on the card.
Find it:
s
>
uSettings
>
Storage Device
1
Select
Memory Card
and press the center key
s
.
2
Select
Format Memory Card
and press the center
key
s
.
set memory for multimedia content
You can download and store multimedia content in
phone memory or on the memory card.
26
basics
Find it:
s
>
uSettings
>
Storage Device
1
With
Save Options
highlighted, press the center
key
s
.
2
Scroll to
Pictures
or
Sounds
, and press the center
key
s
.
3
Select
Phone Memory
or
Memory Card
and press the
center key
s
.
view memory information
Find it:
s
>
uSettings
>
Storage Device
1
Select
Phone Memory
or
Memory Card
and press the
center key
s
.
2
If you selected
Phone Memory
in step 1, select
Phone
Memory Usage
,
My Pictures
, or
My Sounds
, and press the
center key
s
.
If you selected
Memory Card
in step 1, select
Memory Card
Usage
,
My Pictures
,
My Sounds
, or
Format Memory Card
, and
press the center key
s
.
move files from phone to memory
card
You can move files (such as photos, sounds, and music
files) to the memory card to free up phone memory.
Note:
Moving a file to the memory card deletes it from
phone memory.
Find it:
s
>
uSettings
>
Storage Device
1
Select
Phone Memory
or
Memory Card
and press the
center key
s
.
2
Scroll to
My Pictures
or
My Sounds
, and press the center
key
s
.
3
Press
Options
, then scroll to
Move
and press the
center key
s
.
27
basics
4
Scroll to each file you want to move and press the
center key
s
. Press
Mark All
if you want to move
all files.
Note:
Files that were preloaded on your phone
can’t be moved.
5
When you have selected all files that you want to
move, press
Done
.
6
When your phone asks if you want to move the
file(s), select
Yes
and press the center key
s
to
confirm that you want to move the file.
TTY operation
You can use an optional TTY device with your
phone to send and receive calls. You must plug the TTY
device into the phone’s headset jack and set the phone
to operate in one of three TTY modes.
Use a TSB-121 compliant cable (provided by the TTY
device manufacturer) to connect the TTY device to the
phone.
Set the phone volume to level 4 (middle setting) for
proper operation. If you experience a high number of
incorrect characters, adjust the volume as needed to
minimize errors.
For optimal performance, your phone should be at least
12 inches (30 centimeters) from the TTY device. Placing
the phone too close to the device may cause high error
rates.
set TTY mode
ù
When you set your phone to a TTY mode, it
operates in that mode whenever the TTY device is
connected.
Find it:
s
>
uSettings
>
Call
1
Scroll to
TTY Setup
and press the center key
s
.
28
basics
2
Scroll to one of the following
TTY Setup
options and
press the center key
s
.
When your phone is in TTY mode, during an active call
your phone displays the international TTY mode, the
international TTY symbol, and the mode setting.
airplane mode
Note:
Consult airline staff about the use of
Airplane Mode
in flight. Turn off your phone whenever instructed to do
so by airline staff.
Use airplane mode to turn off your phone’s calling
features in locations where wireless phone use is
prohibited.
You cannot make or receive calls or use
Bluetooth wireless connections in airplane mode
,
but you can use your phone’s other non-calling
features.
Find it:
s
>
uSettings
>
Phone
>
Airplane Mode
>
On
or
Off
option
Voice
Set to standard voice mode.
TTY
Transmit and receive TTY characters.
VCO
Receive TTY characters but transmit
by speaking into phone microphone.
HCO
Transmit TTY characters but receive
by listening to phone earpiece.
29
tips & tricks
tips & tricks
From the home screen
, you can use shortcuts:
To... Do this...
redial a number
Press
N
, then scroll to the
number you want to call and
press
N
again.
lock/unlock
keypad
To
lock
the keypad,
press and hold
*
.
To
unlock
the keypad, press
Unlock
(the right soft key), then
press the center key
s
.
turn handsfree
speaker on and off
Press and hold the
smart/speakerphone key (see
page 21).
see your number
Press
Ò
, then
#
.
30
personalize
personalize
home screen shortcuts
From the home screen, you can press the navigation
key up, down, left, or right as shortcuts to your favorite
features. You can
change
the shortcuts to suit your
needs:
Find it:
s
>
uSettings
>
Phone
>
Shortcuts
Select a key direction, then choose the feature you
want to open when you press the navigation key in that
direction.
You can
show
or
hide
icons in the home screen to
indicate the shortcuts for the navigation key.
Find it:
s
>
uSettings
>
Phone
>
Shortcuts
>
Show Shortcuts
Note:
You can press
S
to select the features in the
home screen even when the icons are hidden.
ringtones
To set ringtones for incoming calls and for other events
(such as new messages):
First,
set
Master Volume
to
High
,
Med High
,
Medium
,
Low Med
,
Low
,
or
1Beep
.
Next
, select and assign ringtones.
set master volume
From the home screen, press
the volume keys up or down to
select a
Master Volume
setting:
High
,
Med High
,
Medium
,
Low Med
,
Low
—Phone rings for incoming
calls and other events, depending on the detail
settings.
31
personalize
Vibrate Only
—Phone vibrates to indicate an incoming call.
Alarm Only
—Phone plays an audible alarm to alert you to
events. You can’t change detail settings for events.
All sounds off
—Phone does not alert you to incoming calls
and events.
select ringtones
To assign ringtones for calls
:
Find it:
s
>
uSettings
>
Sounds
>
Call Ringtone
1
If necessary, press
s
to acknowledge the
message about
Shuffle Multiple
.
2
Select
Single Tone
to assign a single ringtone to
incoming calls.
or
Select
Shuffle Multiple
to set your phone to play a
random downloaded ringtone for incoming calls.
Note:
Phonebook
entries with assigned Ringer IDs
will not be affected. The
Shuffle Multiple
option works
only with downloaded ringtones and depletes your
battery’s charge more quickly than
Single Tone
.
3
If you selected
Single Tone
, scroll to the ringtone you
want and press
s
.
Note:
Your phone plays each ringtone that you
highlight.
or
If you selected
Shuffle Multiple
, scroll to each
downloaded ringtone you want and press
s
.
After you select all of the ringtones you want,
press
Done
.
4
Press
O
to return to the home screen.
32
personalize
To assign ringtones for incoming text, multimedia,
or voicemail messages
:
Find it:
s
>
uSettings
>
Sounds
1
Select
Message Ringtone
or
Voicemail Ringtone
.
2
Scroll to the ringtone you want and press the
center key
s
.
Note:
Your phone plays each ringtone that you
highlight.
3
Press
O
to return to the home screen.
buy ringtones
Find it:
s
>
uSettings
>
Sounds
1
Select
Call Ringtone
, then select
Single Tone
.
or
Select
Message Ringtone
or
Voicemail Ringtone
.
2
Select
Buy Ringtone
.
Your phone connects to the Web site with ringtone
collections. Follow the prompts on the screen to
browse ringtone lists and to purchase and
download a ringtone.
Note:
Normal airtime and/or carrier usage charges
apply.
wallpaper
Set a photo, picture, or animation as a wallpaper
(background) image in your home screen.
Find it:
s
>
uSettings
>
Display
>
Wallpaper
1
If necessary, acknowledge the message about
Shuffle Multiple
by pressing the center key
s
.
2
To assign a single picture as a wallpaper, select
Single
and press the center key
s
.
or
33
personalize
To set your phone to show a random downloaded
picture as a wallpaper, select
Shuffle Multiple
and press
the center key
s
.
3
If you selected
Single
, scroll to the desired picture
and press the center key
s
.
or
If you selected
Shuffle Multiple
, scroll to each
downloaded picture you want and press the center
key
s
. When you have selected all of the
pictures you want, press
Done
.
4
Press
O
to return to the home screen.
skins
Set the overall look and feel of your phone’s screen.
Find it:
s
>
uSettings
>
Display
>
Skins
1
Scroll to the name of a skin and press the center
key
s
.
2
Press
O
to return to the main screen.
voice readout
You can set your phone to
speak aloud
when you
press keys, receive a call with caller ID available, or
scroll through the
Phonebook
or recent calls lists.
Find it:
s
>
uSettings
>
Sounds
>
Voice Readout
key volumes
To set the volume of the tones played when you
press keypad keys
:
Find it:
s
>
uSettings
>
Sounds
>
Keypad Volume
To set whether your phone plays tones when you
press side keys
:
Find it:
s
>
uSettings
>
Sounds
>
Volume Sidekeys
34
personalize
alert reminders
Set how many times your phone plays a message alert:
Find it:
s
>
uSettings
>
Sounds
>
Alert Reminders
Select
Once
,
Every 2 Minutes
,
Every 15 Minutes
, or
Off
.
ring & vibrate
Set your phone to ring
and
vibrate when you receive an
incoming call or message.
Note:
Master Volume
must be set to
High
,
Med High
,
Medium
,
Low Med
, or
Low
(see page 21).
Find it:
s
>
uSettings
>
Sounds
>
Ring & Vibrate
answer options
You can use different methods to answer an incoming
call.
Find it:
s
>
uSettings
>
Call
>
Answer Options
backlight
Set the amount of time that the display and
keypad backlights stay on.
Find it:
s
>
uSettings
>
Display
>
Backlight
options
Any-Key
Answer by pressing any key.
Send Only
Answer only by pressing the
send key
N
.
Auto Answer with
Handsfree
Automatically answer incoming
calls when the phone is
connected to a handsfree device
such as a car kit or headset.
35
personalize
brightness
Find it:
s
>
uSettings
>
Display
>
Brightness
banner
Set a heading to display near the top of the home
screen:
Find it:
s
>
uSettings
>
Display
>
Banner
menu language
Find it:
s
>
uSettings
>
Phone
>
Language
dial fonts
Set the phone to display numbers that you enter in
large type:
Find it:
s
>
uSettings
>
Display
>
Dial Fonts
clock format
Set how your phone shows the current time:
Find it:
s
>
uSettings
>
Display
>
Clock Format
Select
Digital 12
for a 12-hour clock,
Digital 24
for a 24-hour
clock,
Analog
for a dial clock, or
Off
for no clock, and press
the center key
s
.
36
personalize
restore phone
Reset all options except unlock code, security code,
and lifetime timer:
Find it:
s
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
(see page 22) and press
Done
.
2
Scroll to
Restore Phone
and press the center key
s
.
3
Confirm that you want to reset the phone by
scrolling to
Yes
and pressing the center key
s
.
4
When prompted, enter the four-digit unlock code
(see page 22) and press
Done
.
The screen does not change while the phone
resets all options. After a few seconds, the phone
turns off and then back on.
AGPS & your location
Your phone uses the Automatic Location Information
(ALI) feature, along with AGPS satellite signals, to tell
the network where you are physically located.
When ALI is set to
Location
>
On (Do Not Ask)
or
On (Always Ask)
your phone shows the
O
(ALI on) indicator. Services
may use your known location to provide useful
information (for example, driving directions, or the
location of the nearest bank). Your phone prompts you
when the network or a service asks for your location.
You can refuse at this point.
When ALI is set to
Location
>
Off (E911 Only)
, your phone
displays the
P
(ALI off) indicator, and the phone does
not send location information unless you call the
emergency phone number (such as 911).
Find it:
s
>
uSettings
>
Phone
>
Location
37
personalize
AGPS limitations & tips
Your phone uses Assisted Global Positioning
System (AGPS) satellite signals to estimate your
location. If your phone cannot find strong satellite
signals, your AGPS might be slower, less accurate, or it
might not work at all. AGPS provides only an
approximate location, often within 150 feet (45 meters)
but sometimes much farther from your actual location.
To improve AGPS accuracy:
•
Go outside and away from underground
locations, covered vehicles, structures with
metal or concrete roofs, tall buildings, and
foliage. Indoor performance might improve if
you move closer to windows, but some
window sun shielding films can block satellite
signals.
•
Move away from radios, entertainment
equipment, and other electronic devices that
might interfere with or block AGPS satellite
signals.
•
If your phone has a retractable antenna, extend
the antenna.
•
Hold your phone away from your body, and
point the phone antenna toward the sky. Do not
cover the antenna area with your fingers.
AGPS uses satellites controlled by the U.S. government
and subject to changes implemented in accordance
with the Department of Defense AGPS user policy and
the Federal Radio Navigation Plan. These changes
might affect AGPS performance.
38
calls
calls
To make and answer calls, see your Quick Start Guide.
redial a number
1
Press the send key
N
to see the
All Calls
list.
2
Scroll to the entry you want to call.
3
Press the send key
N
to redial the number.
Note:
The
All Calls
list includes numbers that were busy
when you dialed.
automatic retry
When you receive a
busy signal
, your phone
displays
Call Failed, Number Busy
.
When you turn on automatic retry, your phone
automatically redials a busy number for four minutes.
When the call connects, your phone rings or vibrates
once, displays
Redial Successful
, and completes the call.
Find it:
s
>
uSettings
>
Call
>
Auto Retry
When automatic retry is turned off, you can manually
activate the feature to redial a phone number. When
you hear a fast busy signal and see
Call Failed
, press
N
or
RETRY
.
turn off a call alert
When you hear a call alert for an incoming call, you can
press the volume keys to turn off the alert before
answering the call.
39
calls
recent calls
Your phone keeps lists of the calls you recently
received and dialed, even if the calls didn’t connect. The
lists are sorted from newest to oldest calls. The oldest
calls are deleted as new calls are added.
Find it:
s
>
qRecent Calls
1
Scroll to
Received Calls
,
Missed Calls
,
Dialed Calls
,
All Calls
, or
Timers
, and press the center key
s
.
2
Scroll to an entry.
3
Press
N
to call the number.
or
To see call details (like time and date), press the
center key
s
.
or
Press
Options
to open the
Options
menu, which can
include:
or
To send a message to the entry, press
Send Msg
.
option
Save
Create or update a
Phonebook
entry with
the number in the
No.
field.
Lock
Prevent the selected entry from being
deleted.
Delete
Delete the selected entry (if the entry
isn’t locked).
Delete All
Delete all unlocked entries.
Timers
View call timers (see page 45).
40
calls
return a missed call
Your phone keeps a record of your unanswered calls.
When you miss a call, your phone shows the
=
(missed call) indicator and
[Number] Missed Calls
.
To view missed calls immediately
:
1
When you see the missed call indicator, select
View
Now
to see the missed calls list.
2
Scroll to an entry on the list.
3
Press
N
to call the entry.
or
To see call details (like time and date), press the
center key
s
.
or
Press
Options
to open the missed calls
Options
menu
(see page 39.
or
Press
Send Msg
to send a message to the entry.
To return a missed call later
, select
View Later
when you
see the missed calls indicator. For more information on
viewing and returning missed calls, see page 39.
speed dial
Note:
Speed dial number 1 is already assigned to your
voicemail number.
To assign a speed dial number to an entry
, see
page 77.
To see an entry’s speed dial number
:
Find it:
s
>
LPhonebook
>
Contact List
As you scroll through entries, speed dial numbers are
identified by the speed dial indicator
>
.
To activate speed dialing
, you must set
One Touch Dial
to
On
:
Find it:
s
>
uSettings
>
Call
>
One Touch Dial
41
calls
To speed dial a number
, enter the speed dial number
for the entry you want to call and press
N
.
one-touch dial
To one-touch dial a speed dial number 1 through 9,
press and hold the single-digit speed dial number (key
1
through
9
) for that entry for one second.
emergency calls
Your service provider programs one or more
emergency phone numbers, such as 911, that you can
call under any circumstances, even when your phone is
locked.
Note:
Emergency numbers vary by country. Your
phone’s preprogrammed number(s) may not work in all
locations, and sometimes an emergency call cannot be
placed due to network, environmental, or interference
issues.
1
Enter the emergency number.
2
Press
N
to call the emergency number.
AGPS during an
emergency call
When you make an emergency call, your phone
can use Assisted Global Positioning System
(AGPS) satellite signals to tell the emergency response
center your approximate location.
The AGPS feature has limitations, so always tell the
emergency response center your best knowledge of
your location. Remain on the phone for as long as the
emergency response center instructs you.
AGPS
might not work
for emergency calls:
•
Your phone’s AGPS feature must be turned on
(see page 36).
42
calls
•
Your local emergency response center might
not process AGPS location information. For
details, contact your local authorities.
For best results:
•
Go outside and away from underground
locations, covered vehicles, structures with
metal or concrete roofs, tall buildings, and
foliage. Indoor performance might improve if
you move closer to windows, but some
window sun shielding films can block satellite
signals.
•
Move away from radios, entertainment
equipment, and other electronic devices that
might interfere with or block AGPS satellite
signals.
If your phone cannot find strong AGPS satellite signals,
the location of the nearest cell tower in contact with
your phone is automatically provided to the emergency
response center.
attach number
While dialing (with digits visible on the display), press
Options
, then scroll to and select
Attach Number
to attach a
number from your
Contact List
or
Recent Calls
list.
insert special
characters
While entering a number, press
Options
and select one of
these options:
•
Insert Pause (p)
—Your phone pauses for two
seconds before it dials the next digit.
•
Insert Wait (w)
—Your phone waits until the call
connects, then prompts you for confirmation
before it dials the next digit(s).
43
calls
international calls
If your phone service includes international
dialing, you can
set your phone to
automatically insert your local international access
code
:
Find it:
s
>
uSettings
>
Call
>
Int’l Dialing
>
Automatic
When
Int’l Dialing
is set to
Automatic
,
insert your local
international access code
(indicated by
+
) by pressing
and holding
0
. Then, use the keypad to dial the
country code and phone number.
voicemail
Your network stores the voicemail messages
you receive. To listen to your messages, call
your voicemail number.
Note:
Your service provider may give you additional
information about using voicemail.
When you
receive
a voicemail message, your phone
shows the voicemail message indicator
w
and
New Voicemail
. Press
Call
to listen to the message.
To
check
voicemail messages later:
Find it:
s
>
gMessaging
>
Voicemail
Press
N
(send key) to call your voicemail number.
Your phone may prompt you to store your voicemail
phone number. If you don’t know your voicemail
number, contact your service provider.
hearing aid
You can set your phone for hearing aid compatibility:
s
>
uSettings
>
Call
>
Hearing Aid
Note:
For more information about hearing aid
compatibility, see “Hearing Aid Compatibility with
Mobile Phones” on page 101.
44
calls
in-call options
During an active call, press
Options
to access these
options:
Note:
When you have a Bluetooth device connected
during a call, you may also see
Audio to Phone
and
Disconnect
Bluetooth
options. When you have
TTY Mode
on, you may
also see a
TTY Setup
option.
call times
Network connection time
is the elapsed time from
the moment you connect to your service provider’s
network to the moment you end the call by
pressing
O
. This time includes busy signals and
ringing.
The amount of network connection time you track
on your resettable timer may not equal the amount
of time for which you are billed by your service
provider. For billing information, please contact
your service provider directly.
Contacts Recent Calls
Phone Info Message Center
Bluetooth Menu Datebook
BREW TTY Setup
features
minute beep
Set your phone to beep every minute during
a call:
s
>
uSettings
>
Sounds
>
Service Alerts
>
Minute Beep
45
calls
more calling features
view call times
s
>
qRecent Calls
>
Timers
Scroll to and view the times for
Last Call
,
All Calls
,
Received
Calls
,
Dialed Calls
,
Roaming Calls
,
Transmitted Data
,
Received Data
,
Total Data
,
Last Reset
,
Lifetime Calls
, or
Lifetime Data Counter
.
reset call times or data volumes
s
>
qRecent Calls
>
Timers
To reset individual timers
: Scroll to the timer you
want to reset and press
Reset
. When prompted,
select
Yes
to confirm that you want to reset the
timer.
To reset all timers
: Press
Reset All
. When prompted,
select
Yes
to confirm that you want to reset all
timers.
features
features
DTMF Tones
Your phone can send Dual Tone Multi Frequency
(DTMF) tones for calling card calls or other
automated touch-tone calls.
Set up DTMF tones:
s
>
uSettings
>
Call
>
DTMF Tones
Select
Short
or
Long
.
conference call
During a call, dial the next number and press
N
, then press
N
again.
46
text entry
text entry
Some features require you to enter names, numbers,
and other text., such as when you add a contact to your
Contact List
or when you write and send a message.
When you add a contact to your
Contact List
, you enter a
name, number, and other information for the contact on
the
New Contact
screen:
Find it:
s
>
LPhonebook
>
New
When you compose a message, you enter the
message recipient and the message text on the
Msg
screen:
Find it:
s
>
gMessaging
>
Create Message
Your phone shows the
Msg
entry screen:
Multiple text entry modes make it easy for you to enter
information on the
New Contact
and
Msg
entry screens. See
the next section for instructions on selecting an entry
mode.
1X
Press Options to
view Options
menu.
Options Save
New Contact
First Name:
Bill
Last Name: Abc
Jone
Highlighted
entry area.
Press Save to
save changes.
1X
Press Options to
view Options
menu. Options Save
0/10 Msg 123
To:
Highlighted
entry area.
Add
47
text entry
set entry modes
The default text entry mode is
Abc
(tap mode, first
character of a sentence in uppercase).
To select an
entry mode from a text entry screen (such as the
New Contact or Msg screen)
:
1
Press
Options
(the left soft key).
2
Select
Entry Mode
.
3
Select one of the following:
When text mode is set to
ABC
or
Abc
, press
*
in any
text entry screen to toggle through these
capitalization options
:
entry modes
iTAP English
Let the phone predict each English word
as you press keys (see page 49).
iTAP
Spanish
Let the phone predict each Spanish
word as you press keys.
Abc
Enter letters and number, first character
of a sentence in uppercase.
ABC
Enter letters and numbers, all characters
in uppercase (not available when editing
a contact).
123
Enter numbers only.
Symbols
Enter symbols.
abc
no uppercase letters
Abc
first letter of a sentence in uppercase
ABC
all uppercase letters
entry modes
48
text entry
When text mode is set to
iTAP English
or
iTAP Spanish
,
press
*
in any text entry screen to toggle between
these
capitalization options
:
Note:
Your phone may not contain all of the languages
listed.
tap mode
This is the standard method for entering text on your
phone.
Regular
Tap
method cycles through the letters and
numbers of the key you press. The
Tap Extended
method
cycles through letters, numbers,
and
symbols. If
Tap
or
Tap Extended
is not available as the
Primary
or
Secondary
entry
mode, see page 47.
1
Press a key once to insert the first letter on the key,
twice for the second letter, and so on. If you pause
briefly, your phone accepts the last letter displayed
and waits for the next entry.
2
Enter the remaining characters in the same way.
Tip:
Press
#
to enter a space.
entry
mode
capitalization options
iTAP English iTAPEn
first letter of sentence in
uppercase (English)
iTAPEN
all uppercase letters (English)
iTAPen
all lowercase letters (English)
iTAP
Spanish
iTAPEs
first letter of sentence in
uppercase (Spanish)
iTAPES
all uppercase letters (Spanish)
iTAPes
all lowercase letters (Spanish)
49
text entry
iTAP® mode
iTAP software provides a predictive text entry method
that combines your key presses into common words.
When you enter three or more characters in a row, your
phone may guess the rest of the word. For example, if
you enter
prog
, you might see:
If you want a different word (such as
progress
), continue
pressing keys to enter the remaining letters.
If you enter a word your phone does not recognize,
your phone stores the word to use as a future word
option. When you run out of phone memory for
unrecognized words, your phone deletes the oldest
word to add new words.
Press
S
up or down to view other possible
combinations, and select the one you want.
Press
S
right to enter the highlighted combination
when it spells a word. A space is automatically inserted
after the word.
Press
1
to enter punctuation or other characters.
numeric mode
After selecting numeric mode, press the number keys
to enter the numbers you want.
1X
Options Send
18/960 Msg iTAPEn
To:
Press S right to
accept program. Enter
a space after prog to
keep only prog.
Insert
This is a program
Bill Miller
50
text entry
symbol mode
When you select symbol mode, your phone shows the
Symbols
screen. Scroll to the symbol you want and press
the center key
s
to select it To see more symbols,
press
Prev
or
Next
.
text entry tips
To enter a space
, press
#
.
To enter punctuation or other special character
while entering text
, press
1
repeatedly until you
see the punctuation mark or character you want.
To delete the character to the left of the cursor
,
press
Ò
.
To delete an entire word
, press and
hold
Ò
.
51
messages
messages
send a multimedia
message
A multimedia message (MMS) contains embedded
media objects such as photos, pictures, animations,
sounds, and voice records. You can also insert a vcard
for a contact or a datebook event. You can send a
multimedia message to other wireless phones with
multimedia messaging capabilities and to email
addresses.
create & send message
Find it:
s
>
gMessaging
>
Create Message
1
Enter a phone number or email address.
or
Press the center key
s
to select
Add
. On the
Add
Recipients
screen, select
Contacts
,
Recent Calls
, or
Categories
.
1X
Press Options to
view Options
menu.
Options Save
0/10 Msg 123
To:
Highlighted
entry area.
Add
Press Add to select recipient from
the Phonebook or recent calls lists.
52
messages
Press the center key to mark each entry you want
to include as a message recipient, and press
Done
when finished.
2
Scroll down to the text entry area and enter
message text.
3To insert a prewritten message
, press the center
key
s
to select
Insert
, then scroll to
Quick Text
and
press the center key
s
. Scroll to the quick text
you want to insert and press the center key
s
.
or
To insert a stored picture
, press the center
key
s
to select
Insert
, then scroll to
Pictures
and
press the center key
s
. Scroll to the desired
picture and press the center key
s
.
or
To insert a sound
, press the center key
s
to
select
Insert
, then scroll to
Audio
and press the center
key
s
. Scroll to the desired sound and press the
center key
s
.
or
To insert a vcard for a contact
in your
Phonebook
,
press the center key
s
to select
Insert
, then scroll
to
Contact Info
and press the center key
s
. Scroll to
the desired entry and press the center key
s
.
or
To insert an event from your phone’s Datebook
,
press the center key
s
to select
Insert
, then scroll
to
Datebook Event
and press the center key
s
. Scroll
to the desired event and press the center key
s
.
4
To insert a message subject, set message priority,
or set delivery options, press
Options
(see page 53).
5
Press
Send
to send the message.
Press
Options
from the
Msg
message entry screen to open
the messaging
Options
menu, which can include the
following:
53
messages
Note:
The options you see depend on the type of
message you are sending and the type of object you
insert into the message.
receive a message
When you receive a message, your phone plays
an alert and displays the
<
(new message) indicator
and a
New Message
notification.
options
Entry Mode
Specify the entry mode to use
(see page 47).
Save to Draft
Save the message, without
sending it, in the
Drafts
folder.
Insert Subject
Enter the message subject.
Insert Object
Insert quick text, picture, sound,
vcard, or datebook event.
Priority
Set to
Normal
or
High
.
Delivery
Select
Deferred Delivery
to schedule
the message to be sent at a later
time. Select
Delivery report
if you
want to receive a report on
whether or not the message was
sent successfully.
Delete Object
Delete an object you inserted into
the message.
Cancel Message
Cancel delivery of the message
and exit with or without saving
the message to the
Drafts
folder.
options
54
messages
Open the flip and select
View Now
to read the message
immediately, or select
View Later
to save it in your
Inbox
for
viewing later.
To read messages in your
Inbox
:
Find it:
s
>
gMessaging
>
Inbox
1
Scroll to the message you want to read.
2
Press the center key
s
to open the message.
Your phone displays the media object, then the
message.
3
Press
Reply
if you want to respond to the message.
or
Press
Options
to view and select from these options:
Reply with Copy
,
Forward
,
Lock/Unlock
,
Save To Contact
,
Start Slide
Show
,
Save Object
,
Message Details
,
Delete Message
,
Delete Multiple
,
Delete All
,
Sort By
,
Save Quick Text
,
Create Message
.
Note:
The options you see depend on the type of
message you receive and whether the message
contains multimedia objects.
or
Press
Ò
to return to the message
Inbox
.
Multimedia messages can contain different media
objects:
•
Photos, pictures, and animations are displayed
when you read the message.
•
A sound file begins playing when the message
text is displayed. Use the volume keys to adjust
the volume.
•
If the message includes an attached file, select
the file indicator or filename and press
VIEW
(for
an image file),
PLAY
(for a sound file), or
OPEN
(for
55
messages
an object such as a
Phonebook
or datebook entry
or an unknown file type).
more messaging
features
features
send text message
s
>
gMessaging
>
Create Message
Press
Options
to perform other actions on the
message.
create quick text
Enter and store
Quick Text
(prewritten)
messages that you can select and send later.
s
>
gMessaging
Press
Options
. then scroll to
Quick Text
and press the
center key
s
. Press
Options
, then select
New
.
send quick text
s
>
gMessaging
Press
Options
. then scroll to
Quick Text
and press the
center key
s
. Scroll to the quick text message
you want to send and press
Send
.
features
56
messages
set up messaging
s
>
gMessaging
Press
Options
. Select
Auto Cleanup
to erase messages
automatically. Select
Voicemail #
to enter the number
to call for your voicemail messages. Select
Callback #
to insert a callback number automatically into
messages that you send. Select
Signature
to create a
signature line that is inserted automatically at the
end of messages that you send. Select
Auto Receive
to
set whether received messages are automatically
downloaded to your phone.
features
view sent message
s
>
gMessaging
>
Outbox
Scroll to the message you want to view and press
the center key
s
.
Press
Options
to access the following options:
Resend
,
Forward
,
Lock
,
Save to Contact
,
Message Details
,
Delete Message
,
Delete Multiple
,
Delete All
,
Sort By
, or
Create Message
.
delete messages
Delete all messages or only messages from
the
Outbox
or
Drafts
folder:
s
>
gMessaging
Press
Options
, then scroll to and select
Delete
. Select
Inbox
,
Drafts
,
Outbox
, or
All
.
To delete Inbox or Outbox messages
automatically,
press
Options
, then select
Auto Cleanup
.
features
57
messages
drafts
s
>
gMessaging
>
Drafts
To complete and send
a saved draft message,
scroll to the message and press the center key
s
.
or
To view and select other options
, press
Options
to
access the following:
Send
,
Edit
,
Lock
,
Save to Contact
,
Delete
,
or
Create Message
.
Note:
The options you see depend on your service
provider.
store message objects
Go to a multimedia message slide, or
highlight an object in a letter, then press
Options
and
select
Save Object
.
features
58
entertainment
entertainment
music
Note:
You must have
an optional microSD
memory card
installed in your phone to use the music
player.
Play your music wherever and whenever you want on
your phone’s music player.
Just
load your favorite music onto your computer
.
Then,
transfer the music from the computer to your
phone
(using Windows® Media Player, or manually).
Note:
The unauthorized copying of copyrighted
materials is contrary to the provisions of the Copyright
Laws of the United States and other countries. This
device is intended solely for copying non-copyrighted
materials, materials in which you own the copyright, or
materials which you are authorized or legally permitted
to copy. If you are uncertain about your right to copy
any material, please contact your legal advisor.
load music onto your computer
To load music
onto your computer, you can
purchase
Microsoft® Windows® Media DRM-protected
music files
from supported on-line music stores (such
as Urge and Napster).
You can also
load song files from a music CD
onto
your computer:
1
Insert the music CD into your computer’s CD drive.
2
Launch Windows Media Player 11.
3
Copy the music CD to the media player library (also
called ripping the CD).
59
entertainment
If your computer is connected to the Internet, the
media player may retrieve information such as song
titles, album name, artist name, and album artwork.
This information will display in your phone’s music
player after you transfer the music to your phone.
transfer music to your phone
Before you copy files to your phone, make sure
the files are in a format that the phone recognizes. Your
phone’s music player can play the following types of
audio files: AAC, AAC+, MP3, WAV, WMA, Real Audio
G2/8/10.
Before you transfer music to your phone
:
1
Insert a memory card into your phone (see
page 11).
2
Set your phone to
Mass Storage
mode by pressing
s
>
uSettings
>
USB
>
Mass Storage
.
3
Attach a Motorola Original USB cable
to the mini USB port on your phone
and to an available USB port on your
computer. A Motorola Original USB
cable and supporting software may be included
with your phone. These tools are also sold
separately.
transfer with Windows Media Player
You can use Windows Media Player 11 to transfer
music from the computer to your phone. (If necessary,
download Windows Media Player 11 at
www.microsoft.com/windowsmedia
.)
Note:
Windows Media Player 11 requires
Windows XP
TM
or later to run. If you are using an earlier
version of Windows OS, see your user’s guide to
manually transfer music to your phone.
1
Run Windows Media Player 11.
60
entertainment
Your phone appears in the upper right corner of the
Windows Media Player 11 screen. Music files
stored on the phone’s memory card are listed on
the left side of the screen.
2
Select the “Sync” tab in Windows Media Player 11.
3
Drag and drop songs or playlists onto the “Sync
List” on the right side of the Windows Media
Player 11 screen.
4
Click “Start Sync” to copy the songs onto the
phone’s memory card.
5
When you finish, disconnect your phone from the
computer.
transfer music manually
You can manually copy or sync music files from the
computer to phone memory or to an optional microSD
memory card in the phone.
1
Find the “Removable Disk” icons for your phone
and memory card on your computer (on the “My
Computer” window on a Windows PC or on the
desktop on a Macintosh® computer).
2
Double-click the “Removable Disk” icon for your
phone or memory card.
3 To copy the desired files onto the phone or
memory card, drag and drop them onto the
appropriate removable disk icon.
4
When you finish, remove the phone safely from
your computer:
• If you are using a PC
, right-click the “Safely
Remove Hardware” icon in the system tray
at the bottom of your computer screen,
then select “USB Mass Storage Device.”
• If you are using a Mac
, select and drag the
“Removable Disk” icon to the Trash.
play music
To activate your phone’s music player
, press the
Music Player Key
[
.
61
entertainment
Your phone shows the
Music Player
menu:
The
Music Player
menu includes:
Note:
If you can’t find artist, album, or genre
information for a song in
Artists
,
Albums
, or
Genres
, the
information may not be available. All songs, with or
without this information, are listed in
All Songs
.
option
All Songs
Play a song.
Note:
All songs are listed here. Some
songs do not have
Artist
,
Album
, or
Genre
information, so that information is not
included.
Playlists
Create or play a playlist.
Artists
Play music by an artist.
Settings
1. All Songs
2. Playlists
3. Artists
4. Albums
5. Genres
Music Player
Highlighted
Selection
Press
Settings
to open
Settings
menu.
1
w
Albums
Play music from an album.
Genres
Play music by genre (type of music) such
as rock or jazz.
option
62
entertainment
While a song is playing on the music player, your
phone’s screen will look similar to the following:
During a song, the music player shows the song title,
artist, album, and artwork, if available.
Note: If you receive a call during a song
, the music
player pauses the song until the call is over.
Use these keys to control music playback:
Settings
00:27 03:13
Music
Find My Way Hc
Faith, Blind Fait
All Songs
1/2
When lit,
indicates
Shuffle
turned on.
When lit, indicates
Replay
turned on.
w
Album
artwork
shown, if
available.
Elapsed
song time.
Song length.
Bars indicate
volume level.
controls with flip open
pause/play
Press &
release center key
s
.
or
Press
Options
and select
Pause
to
pause. Press
Resume
to resume
play.
fast forward
Press &
hold
S
right
(for at
least two seconds).
next song
Press &
release
S
right
.
rewind
Press &
hold
S
left
(for at least
two seconds).
previous song
Within first two seconds of song,
press &
release
S
left
.
restart song
After first two seconds of song,
press &
release
S
left
.
scroll up/down
through list
Press
S
up or down.
63
entertainment
playlists
Personalize your music collection by creating your own
playlists.
When you name a playlist:
•
The name must be fewer than 32 characters.
•
The name cannot include these characters: / \ :
* ? < > | " !
Note:
Your music player includes a special playlist
named
ringtones
. You can’t rename this playlist. Songs
added to this playlist are not visible in other categories
(for example,
Genres
) in the music player. The
ringtones
playlist initially contains ringtones that are preloaded on
your phone. You can still edit this playlist, just like any
other playlist, to add or remove new ringtones that you
purchase.
To create
a playlist:
Find it:
s
>
—Music Player
>
Playlists
1
Press
Options
and select
Create Playlist
.
2
Enter a name for the playlist and press
Done
.
3
With the new playlist highlighted on the
Playlists
screen, press
Options
, then select
Add a Song
.Scroll to a
desired song and press the center key
s
.
Repeat this step to add more songs.
4
Press
Ò
when you finish adding songs.
To add a song
to a playlist:
Find it:
s
>
—Music Player
>
Playlists
1
Scroll to the playlist and press
Options
.
2
Scroll to
Add a Song
and press the center key
s
.
turn off music
player
Press
O
.
controls with flip open
64
entertainment
3
Scroll to the song you want to add to the playlist
and press the center key
s
.
To remove a song
from a playlist:
Find it:
s
>
—Music Player
>
Playlists
1
Scroll to the playlist and press the center key
s
.
2
Scroll to the song you want to remove from the
playlist and press the center key
s
.
3
Scroll to
Remove from Playlist
and press the center
key
s
, then scroll to
Yes
and press the center
key
s
.
To d e l e te
a playlist:
Find it:
s
>
—Music Player
>
Playlists
1
Scroll to the playlist and press
Options
.
2
Scroll to
Delete Playlist
and press the center key
s
,
then scroll to
Yes
and press the center key
s
.
wake up music player
While the music player is active, your phone may
conserve battery power by turning off the external
display and touch sensor controls (if the flip is closed)
or the inside display and keypad backlights (if the flip is
open).
To turn displays and lights back on:
customize music player
Find it:
s
>
—Music Player
Press
Settings,
then select one of the following options:
flip closed
Press any touch sensor control.
flip open
Press a number key.
options
Audio Effects
Customize music playback by selecting
Club
,
Full Bass
, or
Dance
. Select
None
to use the
player’s default playback settings.
65
entertainment
When you press
Settings
while a song is actively playing,
you will see also see
Add to Playlist
and
Background Play
.
music player tips
•
If you are navigating music player menus while
a song is playing and don’t press a key for more
than five seconds, the player returns to the
current song list screen.
•
Turn off the player before connecting the phone
to a computer. If you connect the phone to a
computer while the player is turned on, the
phone automatically turns off the player.
•
If you use a headset with the phone,
music plays through the headset. Music
plays through the phone speaker when the
headset is disconnected.
view pictures
Find it:
s
>
jMultimedia
>
Pictures
1
Scroll left and right to view pictures.
Press
Options
to open the
Options
menu (see the table
following these steps).
Visual Effects
Select custom visual effects for the music
playback screen:
Cylinder
,
Fire
,
Atlantic
,
Rain
,
Cheese
,
Rubasse
,
Emerald
.
Repeat
Replay a song (when you select a single
song for play—does not replay a playlist or
album).
Shuffle
Play songs in random order.
Help
See help information for the music player.
Note:
This option does not appear while a
song is playing.
options
66
entertainment
Press
Edit
to access editing tools that you can use
to modify the selected picture.
If you see
Slideshow
at the bottom middle of the
screen, press the center key
s
to see a
“slideshow” presentation of all pictures, shown in
sequence. Press the center key
s
to pause the
slideshow. Press
Settings
to modify slideshow
settings. Press
Ò
to end the slideshow and
return to the picture viewer screen.
If you see
Ok
at the bottom middle of the screen
and the message
Buy Wallpaper
, press the center
key
s
to purchase and download pictures.
2
Press
Ò
to return to the
Multimedia
menu.
While viewing pictures, press
Options
from the playback
screen to access these options:
Note:
You may not see all of the options listed below,
depending on your service provider.
options
Send
Send the selected picture in a
multimedia message (see page 51).
To OnLine
Album
Send the picture to an online
picture album (availability is
network/subscription dependent).
Set As
Set the picture as a picture ID (see
page 76).
Capture
Open the active camera viewfinder
screen.
Rename
Change the name of the selected
picture.
Lock/Unlock
Lock the selected picture to prevent it
from being deleted.
67
entertainment
manage sounds
You can record sounds for later playback.
create a sound
1
Press and hold the voice key on the right side of
the phone (see page 2
Tip:
You can also press
s
>
jMultimedia
>
Music & Sounds
>
Sounds
>
Record New
.
2
Press the center key
s
(
Start
) to begin recording.
3
Press the center key
s
again to stop recording.
Tip:
From the home screen and with the flip open,
press and hold the voice key on the right side of the
phone (see page 2) to go to the
Record New
screen, then
record a sound as instructed above.
play a sound
s
>
jMultimedia
>
Music & Sounds
>
Sounds
Print
Use a Bluetooth® connection with a
printer to print the selected picture.
Delete
Delete the selected picture.
Delete All
Delete all unlocked pictures.
Mark
Mark the selected picture. After you
mark one or more pictures, press
Options
to see these options:
Unmark
,
Mark
All
,
Unmark All
,
Move Marked to Memory Card
,
Move Marked to Phone
,
Delete Marked
,
Lock Marked
,
Unlock Marked
.
Mark All
Mark all pictures. After you mark all
clips, press
Options
to see these
options:
Unmark
,
Mark All
,
Unmark All
,
Move
Marked to Memory Card
,
Move Marked to Phone
,
Delete Marked
,
Lock Marked
,
Unlock Marked
.
File Info
See detailed information about the
selected picture.
options
68
entertainment
Scroll to the sound title and press the center key
s
.
Press
Options
to open a menu that can include these
options:
Send
,
Rename
,
Move
,
Lock
,
Delete
,
Delete All
,
Mark
,
Mark All
,
File Info
.
music player
To listen to music on your phone, you need to:
1
Load music on your computer.
2
Transfer music from the computer to your phone.
3
Use the music player to play and manage music
files on your phone.
See your Quick Start Guide for complete instructions
on using your music player.
launch browser
Find it:
s
>
EBrowser
69
tools—voice recognition
tools
voice recognition
Your phone’s voice recognition feature lets you make
calls and complete other actions by speaking
commands to your phone.
voice recognition tips
•
Say the names of
Contact List
entries exactly as
listed. For example, to call the mobile number
for an entry named Bill Smith, say “Call Bill
Smith mobile.” (If the entry includes only one
number for Bill Smith, say “Call Bill Smith.”)
•
Speak numbers at a normal speed and volume,
and pronounce each digit distinctly. Avoid
pausing between digits.
•
You can set your phone to play voice command
instructions through the speakerphone by
pressing the voice key, which opens the
Voice
Commands
menu. If you use the
Call
command to
place a call, the audio plays through the phone’s
earpiece when the call connects. You can turn
this feature off (see page 74).
voice commands
1
Press and
release
the voice key on the right side of
the phone.
Your phone says
Please say a command
and displays a list
of voice commands.
2
Say one of the commands listed in the following
table. Your phone performs the corresponding
action.
70
tools—voice recognition
feature
Call <Name or #>
Place a call to:
•
a
Contact List
entry whose name you speak
or
•
a phone number you speak
or
•
your voicemail number
or
•
the last number you called
For example, you could say “Call Bill Smith mobile,”
“Call 8475551212,” “Call voicemail,” or Call last
number.”
Send Msg <Name or #>
Send a message to:
•
a
Contact List
entry whose name you speak
or
•
a phone number you speak
or
•
all the members of a
Group
whose name you
speak
For example, when prompted to say a command,
you could say “Send message to Bill Smith mobile,”
“Send message to 8475551212,” or “Send
message to Family.” Your phone would open the
Msg
entry screen, with Bill Smith’s mobile number, the
number
8475551212
, or the group named
Family
in the
To
field. For instructions on sending a message, see
pages 51.
feature
71
tools—voice recognition
Go To <Shortcut>
Access the menu or perform the action you specify:
Contacts
—Open the
Contact List
.
Recent Calls
—Open the
Recent Calls
menu.
Messaging
—Open the
Messaging
menu.
Settings
—Open the
Settings
menu.
Camera
—Open the active camera viewfinder.
Music Player
—Open the
Music Player
menu.
Redial
—Call the last number you dialed.
Note:
If you don’t have any content (music, recent
calls, and so on), the phone returns to the home
screen.
feature
Check <Item>
View the item on the screen that you say aloud:
Status
—coverage, signal strength, and battery
charge
Voice mai l
—new voicemail messages
Messages
—newly received messages
Missed Calls
—unanswered incoming calls
Time
—time and date
Signal Strength
—network connection strength
Battery
—battery charge
Volume
—ringer volume
feature
72
tools—voice recognition
voice recognition settings
To modify voice recognition settings:
1
Press and release the voice key on the right side of
the phone.
Note:
With the phone closed, press and hold the
voice key.
2
Press
Settings
.
3
Scroll to the desired option and press the center
key
s
.
Contact <Name>
Look up an entry from the
Contact List
by saying the
contact’s name.
Play <Playlist>
Play a playlist with the music player by saying the
name of one of your playlists.
Note:
If you don’t have any music, the phone
returns to the home screen.
Help
Access help information for the voice recognition
feature.
feature
voice recognition settings
Digit Dial Readout
Set your phone to say numbers aloud as you press
them on the keypad.
73
tools—voice recognition
Confirmation
If your phone is not sure that it has correctly
identified a name or number that you speak, it can
display up to three choices and prompt you to
confirm the correct one.
You can control when choice lists appear:
Automatic
—Display a list of choices from multiple
alternatives.
Always Confirm
—Always display a list of choices when
there are multiple alternatives.
Never Confirm
—Never display a choice list. The phone
chooses from the best alternatives.
voice recognition settings
Sensitivity
You can fine tune your phone’s ability to recognize
voice commands. Select
Most Sensitive
,
Recommended
, or
Least Sensitive
.
If sensitivity is too strict
, your phone often rejects
voice commands and displays “Please repeat ...” or
“No match found.” Select Most Sensitive.
If sensitivity is too forgiving
, you experience false
activations (indicating that the phone detects a
wrong match). Select
Least Sensitive
.
Adaptation
Follow the prompts on your screen to improve
recognition of spoken words. Adaptation takes
about sixty seconds and requires you to be in a
quiet place (no background noise).
voice recognition settings
74
tools—phonebook
To access in-device help for a setting you speak,
press
Info
.
phonebook
create entry
Find it:
s
>
LPhonebook
>
New
Enter contact information and press
Save
. You must
complete at least one of the following entry areas:
Mobile1
,
Home
,
Work
,
Email1
,
Mobile2
,
Fax
,
Email2
, or
URL
.
For more information on creating a new entry, see
page 16.
view entry
Find it:
s
>
LPhonebook
>
Contact List
To view details for an entry
, scroll to the entry and
press the center key
s
.
To perform other actions on an entry
, scroll to the
entry and press
Options
.
Prompts
Mode
—Set whether your phone says
Prompts
,
Readout
(to
read every word on the screen), or
Tones Only
.
Audio Playback
—Set how you want to hear prompts:
Automatic
detection
, Speakerphone,
or through your
Earpiece
.
Call Alert
For an incoming call, set whether you hear a
Ring Only
,
Caller ID then Ring
, or
Caller ID Repeat
(repeat the name until
you answer or the call goes to voicemail).
voice recognition settings
75
tools—phonebook
call entry
Find it:
s
>
LPhonebook
>
Contact List
Scroll to the entry you want to call and press
N
.
edit entry
To modify an entry
:
Find it:
s
>
LPhonebook
>
Contact List
Scroll to the entry and press
Options
, then scroll to
Edit
Contact
and press the center key
s
.
To edit an entry before calling it
:
Find it:
s
>
LPhonebook
>
Contact List
1
Scroll to the entry.
2
If the entry has more than one number, press
S
left or right to scroll to the number you want to
change.
3
Press
Options
, then scroll to
Edit Before Call
and press
the center key
s
.
Your phone shows the number to be changed.
4
Change the number as desired, then press
Save
.
5
Select
Create New Contact
, then enter contact
information and press
Save
.
or
Select
Update Existing
, then scroll to the entry to be
updated and press the center key
s
. Select the
number to be updated and press the center
key
s
.
To delete an entry
:
Find it:
s
>
LPhonebook
>
Contact List
Scroll to the entry and press
Options
, then scroll to
Delete
and press the center key
s
.
To delete all entries
:
Find it:
s
>
LPhonebook
>
Contact List
1
Press
Options
, then select
Delete All
.
76
tools—phonebook
2
When you see
Delete All Contacts?
, scroll to
Yes
and
press the center key
s
.
3
Enter your four-digit security code (see page 22)
and press
Done
.
To add more numbers or email addresses to an
entry
:
Find it:
s
>
LPhonebook
>
Contact List
1
Scroll to the entry and press
Options
, then select
Edit
Contact
.
2
Scroll down to the appropriate entry area (see
page 74) and enter the required information.
3
Press
Save
to save the modified entry.
ringer IDs
When you assign a ringtone to an entry, your phone
plays that ringtone when you receive a call from that
entry.
Find it:
s
>
LPhonebook
1
Scroll to the entry and press
Options
, then select
Edit
Contact
.
2
Scroll to
Ringer ID
and press the center key
s
.
3
Scroll to the desired ringtone.
Note:
As you scroll through settings, your phone
plays a sample of each setting you highlight.
4
Press the center key
s
to select the highlighted
ringtone.
picture IDs
Assign a photo or picture to show when you receive a
call from an entry:
Find it:
s
>
LPhonebook
>
Contact List
1
Scroll to the entry and press
Options
, then select
Edit
Contact
.
2
Scroll to
and press the center key
s
.
77
tools—phonebook
3
Scroll left or right to the desired picture and press
the center key
s
.
Press
Options
and select
Capture
to take a new photo
(see your Quick Start Guide) to use as a picture ID.
set speed dial number
Note:
To use speed dial to call an entry, see page 40.
Find it:
s
>
LPhonebook
>
Speed Dial
1
Scroll to an unassigned speed dial location entry
and press
Set
.
2
Scroll through the
Contact List
to the entry to be
assigned the number and press the center
key
s
.
3
When prompted, select
Yes
to confirm your
selection.
set default number
Set the primary number for an entry with multiple
numbers. This will be the number your phone shows
when listing
Contact List
entries.
Find it:
s
>
LPhonebook
>
Contact List
1
Scroll to the entry and press
Options
, then select
Edit
Contact
.
2
Scroll to the number to be set as the default
number and press
Options
, then select
Set as Default
.
sort entries
Set whether
Contact List
entries are listed in alphabetical
order by first or last name:
Find it:
s
>
LPhonebook
>
Contact List
1
Press
Options
, then select
Sort Name
.
2
Scroll to
First Name
or
Last Name
and press the center
key
s
.
78
tools—network
groups
To send a text message to many people at once, you
can add
Contact List
entries to
Groups
. Then, when you enter
a group’s name as a message recipient, the message is
sent to all members of that group.
Yo u r
Phonebook
comes with several groups already, and
you can create your own additional groups.
To add entries to a group
:
Find it:
s
>
LPhonebook
>
Groups
1
Scroll to the group name and press
Options
, then
select
Add Contacts
.
2
Scroll to each entry you want to add to the group
and press the center key
s
.
A check mark appears in the box beside an entry
when you select it. To deselect an entry, scroll to
the entry and press the center key
s
to remove
the check mark.
3
When you finish selecting entries, press
Done
to
save your selections.
To create a new group
:
Find it:
s
>
LPhonebook
>
Groups
1
Press
New
.
2
Enter the new group name and press
Save
.
network
features
network settings
View network information and adjust
network settings:
s
>
uSettings
>
Phone
>
Network Selection
Scroll to the desired network setting and press the
center key
s
.
79
tools—personal organizer
personal organizer
call connect tones
Set phone to play a tone when a call
connects:
s
>
uSettings
>
Sounds
>
Service Alerts
>
Call Connect
call drop tone
Set phone to play an alert tone whenever
the network drops a call. (Because digital networks
are so quiet, a call drop alert may be your only
indication that a call was dropped.)
s
>
uSettings
>
Sounds
>
Service Alerts
>
Voice Call Drop
features
features
add datebook event
s
>
ÉTools
>
Datebook
Scroll to the desired day and press
Add
, then enter
event information and press
Done
.
view datebook event
View or edit event details:
s
>
ÉTools
>
Datebook
Scroll to the desired day and press the center
key
s
, then scroll to the event and press the
center key
s
.
To edit the event, press
Edit
.
80
tools—personal organizer
event reminder
Press
View
to view an event reminder.
Press
Exit
to dismiss an event reminder.
set alarm
s
>
ÉTools
>
Alarm Clock
Select
Alarm 1,
Alarm 2
, or
Alarm 3
, then turn on the
alarm, specify the alarm time, recurrence, and alert
type.
turn off alarm
To turn off an alarm, press
Off
or
O
.
calculator
s
>
ÉTools
>
Calculator
features
view world clock
To view the current time in cities around the world:
s
>
ÉTools
>
World Clock
Scroll left or right to see the time in a desired city.
Or, press
Cities
, then scroll to a city and press the
center key
s
. Press
Set DST
to set Daylight Savings
Time for a city.
features
81
tools—personal organizer
notepad
Your phone stores the most recent digits you
entered in the
Notepad
. These digits can be a number
that you called or a number that you entered and
want to save for later. You can also create notes
with information that you want to save for later.
s
>
ÉTools
>
Notepad
Your phone shows a list of notes. To view the
contents of a note, scroll to the note and press the
center key
s
. To create a new note, press
New
.
features
82
connections—cable connections
connections
cable connections
Your phone has a micro USB port that allows
you to connect it to a computer.
Note:
Motorola Original
TM
data cables and supporting
software are sold separately. Check your computer to
determine the type of cable you need.
If you use a USB cable connection:
•
Make sure both your phone and the computer
are turned on.
•
Make sure to connect the phone to a
high-power USB port on your computer (not a
low-power one such as the USB port on your
keyboard or bus-powered USB hub). Typically,
USB high-power ports are located directly on
your computer.
Note:
If you connect your phone to a
low-power USB port, the computer may not
recognize your phone.
Specify the correct USB setting on your phone:
Find it:
s
>
uSettings
>
USB
Scroll to
Modem/COM
and press the center key
s
.
Bluetooth®
connections
Your phone supports Bluetooth wireless connections.
You can connect your phone to a Bluetooth headset or
car kit, or connect to another device to transfer files.
To view a list of Bluetooth profiles supported by your
phone:
83
connections—Bluetooth® connections
Find it:
s
>
uSettings
>
Bluetooth
1
Press
Options
, then scroll to
Supported Profiles
and press
the center key
s
.
2
To see more information about a profile, scroll to
the profile name and press the center key
s
.
For more Bluetooth wireless connections support
information, go to
www.motorola.com/Bluetoothsupport
.
Note:
All multimedia (audio player, shutter tones) will
play from the speakerphone when your phone is
connected to another Bluetooth device.
For maximum Bluetooth security
, always connect
Bluetooth devices in a safe, private environment, away
from other devices with Bluetooth connection
capabilities.
turn Bluetooth power on/off
Set Bluetooth power to be on whenever your phone
is on.
Find it:
s
>
u
Settings
>
Bluetooth
Press
Turn On
(the right soft key).
Note:
To extend battery life when you are not actively
using a Bluetooth connection, turn Bluetooth power off
by using this procedure and pressing
Turn Off
. If you turn
off Bluetooth power, your phone will not connect to
other Bluetooth devices until you turn on Bluetooth
power and then reconnect.
place phone in discovery mode
Allow an unknown Bluetooth device to discover your
phone:
Find it:
s
>
uSettings
>
Bluetooth
1
Press
Options
.
2
Scroll to
Discovery Mode
and press the center key
s
.
3
Scroll to
On
and press the center key
s
.
84
connections—Bluetooth® connections
The following message appears:
Discovery on: For one
minute other devices can find you
.
If the device requests permission to bond with your
phone, press
YES
and enter the device PIN code to
create a secure connection with the device. (The PIN
code is typically set to
0000
.)
Note:
See the instructions that came with your device
for the device’s PIN code and other information about
the device.
pair with headset, handsfree
device, or computer
Note: If you want to use your Motorola Bluetooth
headset with both an audio device and your phone,
use your phone’s Bluetooth menus to connect the
phone with the headset.
If you establish the
connection by pressing a button on the headset, or if
you allow the headset to connect automatically by
turning it on, you may experience unexpected results.
Before you try to connect to another Bluetooth
device
, make sure your phone’s Bluetooth power is
On
and the device is in pairing or bonding mode (see the
user guide for the device you are attempting to pair
with). You can connect your phone with only one device
at a time.
Find it:
s
>
uSettings
>
Bluetooth
1
Press the center key
s
to select
Add New Device
.
Note:
If your Bluetooth power is not turned on,
your phone will prompt you to turn it on.
2
When you see
Place the device you are connecting to in
discoverable mode
, press the center key
s
.
Your phone lists the devices it finds within its
range. If your phone is already connected to a
device, your phone lists that device and identifies it
with a
%
(in-use indicator).
3
Scroll to a device in the list and press
Pair
to
connect to the device.
85
connections—Bluetooth® connections
4
If the device requests permission to bond with
your phone, press
YES
and enter the device PIN
code to create a secure connection with the
device. (The PIN code is typically set to
0000
.)
Note:
See the instructions that came with your
device for the device’s PIN code and other
information about the device.
When the connection is made, the
à
(Bluetooth)
indicator or a
Bluetooth
message displays in the home
screen.
connect to handsfree device
during a call
1
During a call, press
Options
, then select
Connect Bluetooth
.
2
Scroll to
Add New Device
, or select the name of a
device if you have paired with it previously, and
press the center key
s
.
3
If connecting to a new device, place the new
device in discoverable mode and press the center
key
s
on your phone.
4
When your phone finds the device, press
Pair
.
5
If prompted, enter the default PIN code
0000
.
Note:
You can’t switch to a headset or car kit if you are
already connected to a Bluetooth device.
copy files to another device
You can use a Bluetooth connection to transfer
a contact or file to another Bluetooth device.
To transfer a contact
:
Note:
Make sure the device receiving the entry has
Bluetooth power on and is in discoverable mode.
Find it:
s
>
LPhonebook
>
Contact List
1
Scroll to the entry you want to transfer and press
Options
.
86
connections—Bluetooth® connections
2
Scroll to
Send Contact Info
and press the center key
s
.
3
Press the center key
s
to select
via Bluetooth
.
4
To add more entries, scroll to each entry and press
the center key
s
.
5
Press
Done
, then press
Send
.
6
Scroll to
Add New Device
, or scroll to the device that
you want, and press the center key
s
.
Note:
If your phone does not already have
Bluetooth power turned on, it prompts you to turn
it on.
7
If connecting to a new device, place the new
device in discoverable mode and press the center
key
s
on your phone.
8
When the phone shows the list of devices, scroll
to the device you want and press
OK
.
9
If prompted, enter the default PIN code
0000
.
When the connection is made, the receiving device is
prompted to accept the transfer. When the receiving
device accepts, the your phone transfers the entry to
the device.
To transfer a file to another device
:
Note:
Make sure the device receiving the file has
Bluetooth power on and is in discoverable mode. The
receiving phone must be capable of receiving the file
type.
1
On your phone, select the file (such as a picture or
sound) you want to transfer and press
Options
.
2
Press the center key
s
to select
Send
.
3
Scroll to
via Bluetooth
and press the center key
s
.
4
Scroll to
Add New Device
, or scroll to the device that
you want, and press the center key
s
.
Note:
If your phone does not already have
Bluetooth power turned on, it prompts you to turn
it on.
87
connections—Bluetooth® connections
5
If connecting to a new device, place the new
device in discoverable mode and press the center
key
s
on your phone.
6
When the phone shows the list of devices, scroll
to the device you want and press
OK
.
7
If prompted, enter the default PIN code
0000
.
8
When your phone prompts you to confirm that you
want to send the file, press
Yes
.
When the connection is made, the receiving device is
prompted to accept the transfer. When the receiving
device accepts, the your phone transfers the entry to
the device.
receive files from another
device
Note:
If you do not see the Bluetooth indicator
O
at
the top of your phone’s display,
turn on your phone’s
Bluetooth power
(see page 83).
1
Pair your phone with the other device (see
page 84).
2
Send the file from the other device. (If necessary,
refer to the user’s manual for the device for
instructions.)
3
When prompted to accept the sent object, scroll to
Yes
and press the center key
s
.
Your phone notifies you when the transfer is complete.
If necessary, press
Save
to save the file.
disconnect from a device
To disconnect from a device
while the phone
is idle
:
Find it:
s
>
u
Settings
>
Bluetooth
1
Scroll to the name of the device from which you
want to disconnect and press
Options
.
88
connections—Bluetooth® connections
2
When your phone prompts
Disconnect from
devicename
?
, scroll to
Yes
and press the center
key
s
.
To disconnect from a device
during an active call
:
1
Press
Options
.
2
Scroll to
Disconnect Bluetooth
and press the center
key
s
.
89
service & repairs
service & repairs
If you have questions or need assistance, we're here to
help.
Go to
www.motorola.com/support
, where you can select
from a number of customer care options. You can also
contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456
(TTY/TDD United States for hearing impaired), or
1-800-461-4575 (Canada).
90
SAR Data
Specific Absorption Rate Data
SAR Data
This model wireless phone meets the government’s
requirements for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed limits for exposure to radio frequency
(RF) energy set by the Federal Communications Commission (FCC) of the
U.S. Government and by the Canadian regulatory authorities. These
limits are part of comprehensive guidelines and establish permitted
levels of RF energy for the general population. The guidelines are based
on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to
assure the safety of all persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC and by the Canadian regulatory authorities is
1.6 W/kg.
1
Tests for SAR are conducted using standard operating
positions accepted by the FCC and by Industry Canada with the phone
transmitting at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest certified power
level, the actual SAR level of the phone while operating can be well
below the maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a wireless base
station, the lower the power output.
Before a phone model is available for sale to the public in the U.S. and
Canada, it must be tested and certified to the FCC and Industry Canada
that it does not exceed the limit established by each government for
safe exposure. The tests are performed in positions and locations (e.g.,
at the ear and worn on the body) reported to the FCC and available for
review by Industry Canada. The highest SAR value for this model phone
when tested for use at the ear is 1.52 W/kg, and when worn on the body,
as described in this user guide, is 0.90 W/kg. (Body-worn measurements
differ among phone models, depending upon available accessories and
regulatory requirements).
2
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the governmental
requirements for safe exposure. Please note that improvements to this
product model could cause differences in the SAR value for later
products; in all cases, products are designed to be within the guidelines.
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications & Internet Association (CTIA) Web
site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web
site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile phones used by the
public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard
91
SAR Data
incorporates a substantial margin of safety to give additional protection for
the public and to account for any variations in measurements.
2. The SAR information includes the Motorola testing protocol, assessment
procedure, and measurement uncertainty range for this product.
92
SAR Data
93
Important Safety and
LegalInformation
94
Safety Information
Safety and General Information
Safety Information
This section contains important information on the safe and
efficient operation of your mobile device. Read this information
before using your mobile device.
Exposure to Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON, it
receives and transmits RF energy. When you communicate with your
mobile device, the system handling your call controls the power level at
which your mobile device transmits.
Your Motorola mobile device is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to
RF energy.
Operational Precautions
For optimal mobile device performance, and to be sure that human
exposure to RF energy does not exceed the guidelines set forth in the
relevant standards, always follow these instructions and precautions.
Product Operation
When placing or receiving a phone call, hold your mobile device just like
you would a landline phone.
If you wear the mobile device on your body, always place the mobile
device in a Motorola-supplied or approved clip, holder, holster, case, or
body harness. If you do not use a body-worn accessory supplied or
approved by Motorola, keep the mobile device and its antenna at least
2.5 centimeters (1 inch) from your body when transmitting.
Using accessories not supplied or approved by Motorola may cause your
mobile device to exceed RF energy exposure guidelines. For a list of
Motorola-supplied or approved accessories, visit our Web site at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from
external sources if inadequately shielded, designed, or otherwise
configured for RF energy compatibility. In some circumstances your
mobile device may cause interference with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices
instruct you to do so.
In an aircraft, turn off your mobile device whenever instructed to do so
by airline staff. If your mobile device offers an airplane mode or similar
feature, consult airline staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or
defibrillator, consult your physician before using this mobile device.
Persons with implantable medical devices should observe the following
precautions:
95
Safety Information
•
ALWAYS keep the mobile device more than 20 centimeters
(8 inches) from the implantable medical device when the
mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to
minimize the potential for interference.
•
Turn OFF the mobile device immediately if you have any
reason to suspect that interference is taking place.
Read and follow the directions from the manufacturer of your
implantable medical device. If you have any questions about using your
mobile device with your implantable medical device, consult your
healthcare provider.
Driving Precautions
The use of wireless phones while driving may cause distraction.
Discontinue a call if you can’t concentrate on driving.
Additionally, the use of wireless devices and their accessories may be
prohibited or restricted in certain areas. Always obey the laws and
regulations on the use of these products.
Responsible driving practices can be found in the “Smart Practices
While Driving” section in this guide (or separate guide).
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always,
posted and can include fueling areas, such as below decks on boats,
fuel or chemical transfer or storage facilities, or areas where the air
contains chemicals or particles, such as grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not
remove, install, or charge batteries. In such areas, sparks can occur and
cause an explosion or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as
follows:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a
fire.
Your battery or mobile device may require recycling
in accordance with local laws. Contact your local
regulatory authorities for more information.
Do not throw your battery or mobile device in the
trash.
032374o
032376o
032375o
96
Safety Information
Batteries & Chargers
Caution: Improper treatment or use of batteries may present a
danger of fire, explosion, leakage, or other hazard. For more
information, see the “battery use & safety” section in the user’s
guide.
Keep Your Mobile Device and Its
Accessories Away From Small Children
These products are not toys and may be hazardous to children. For
example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing
hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Glass Parts
Some parts of your mobile device may be made of glass. This glass
could break if the product is dropped on a hard surface or receives a
substantial impact. If glass breaks, do not touch or attempt to remove.
Stop using your mobile device until the glass is replaced by a qualified
service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when playing video games. These
may occur even if a person has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult with your physician before
playing video games or enabling a flashing-lights feature (if available)
on your mobile device.
Discontinue use and consult a physician if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of
awareness, involuntary movements, or disorientation. It is always a
good idea to hold the screen away from your eyes, leave the lights on in
the room, take a 15-minute break every hour, and stop use if you are
tired.
Caution About High Volume Usage
Warning:
Exposure to loud noise from any source for
extended periods of time may affect your hearing. The
louder the volume sound level, the less time is required
before your hearing could be affected. To protect your
hearing:
•
Limit the amount of time you use headsets or headphones at
high volume.
Do not let your battery, charger, or mobile device
get wet.
Listening at full volume to music or voice through a
headset may damage your hearing.
Symbol Definition
97
Industry Canada Notice
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near
you.
If you experience hearing discomfort, including the sensation of
pressure or fullness in your ears, ringing in your ears, or muffled speech,
you should stop listening to the device through your headset or
headphones and have your hearing checked.
For more information about hearing, see our Web site at
www.motorola.com/hearingsafety
(in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in
your hands, arms, shoulders, neck, or other parts of your body. If you
continue to have discomfort during or after such use, stop use and see a
physician.
[Mar0108]
Industry Canada Notice to Users
Indust ry Cana da Notice
Operation is subject to the following two conditions: (1) This device may
not cause interference and (2) This device must accept any interference,
including interference that may cause undesired operation of the
device. See RSS-GEN 7.1.5.
FCC Notice to Users
FCC Notice
The following statement applies to all products that have
received FCC approval. Applicable products bear the FCC logo,
and/or an FCC ID in the format FCC-ID:xxxxxx on the product
label.
Motorola has not approved any changes or modifications to this device
by the user. Any changes or modifications could void the user’s authority
to operate the equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. See 47 CFR
Sec. 15.19(3).
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
98
Warranty
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the
receiver.
•
Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for
help.
Motorola Limited Warranty for the United States and Canada
Wa rr a n t y
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its
telephones, pagers, messaging devices, and consumer and professional
two-way radios (excluding commercial, government or industrial radios)
that operate via Family Radio Service or General Mobile Radio Service,
Motorola-branded or certified accessories sold for use with these
Products (“Accessories”) and Motorola software contained on
CD-ROMs or other tangible media and sold for use with these Products
(“Software”) to be free from defects in materials and workmanship
under normal consumer usage for the period(s) outlined below. This
limited warranty is a consumer's exclusive remedy, and applies as
follows to new Motorola Products, Accessories and Software purchased
by consumers in the United States or Canada, which are accompanied
by this written warranty:
Products and Accessories
Products Covered Length of Coverage
Products and
Accessories
as defined
above, unless otherwise
provided for below.
One (1) year
from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Decorative
Accessories and
Cases.
Decorative
covers, bezels,
PhoneWrap™ covers and
cases.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
99
Warranty
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and replacement
of parts due to normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80%
of their rated capacity and batteries that leak are covered by this limited
warranty.
Abuse & Misuse.
Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as
physical damage (cracks, scratches, etc.) to the surface of the product
resulting from misuse; (b) contact with liquid, water, rain, extreme
humidity or heavy perspiration, sand, dirt or the like, extreme heat, or
food; (c) use of the Products or Accessories for commercial purposes or
subjecting the Product or Accessory to abnormal usage or conditions; or
(d) other acts which are not the fault of Motorola, are excluded from
coverage.
Use of Non-Motorola Products and Accessories.
Defects or
damage that result from the use of non-Motorola branded or certified
Products, Accessories, Software or other peripheral equipment are
excluded from coverage.
Unauthorized Service or Modification.
Defects or damages
resulting from service, testing, adjustment, installation, maintenance,
alteration, or modification in any way by someone other than Motorola,
or its authorized service centers, are excluded from coverage.
Altered Products.
Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken
seals or that show evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-Motorola housings, or parts, are
excluded from coverage.
Communication Services.
Defects, damages, or the failure of
Products, Accessories or Software due to any communication service or
signal you may subscribe to or use with the Products Accessories or
Software is excluded from coverage.
Monaural Headsets.
Ear buds and boom
headsets that transmit
mono sound through a
wired connection.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
Consumer and
Professional Two-Way
Radio Accessories.
Ninety (90) days
from the date of
purchase by the first consumer
purchaser of the product.
Products and
Accessories that are
Repaired or Replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Products Covered Length of Coverage
100
Warranty
Software
Exclusions
Software Embodied in Physical Media.
No warranty is made that
the software will meet your requirements or will work in combination
with any hardware or software applications provided by third parties,
that the operation of the software products will be uninterrupted or
error free, or that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media.
Software that is not
embodied in physical media (e.g. software that is downloaded from the
internet), is provided “as is” and without warranty.
Who Is Covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the
purchase price of any Products, Accessories or Software that does not
conform to this warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products, Accessories or
parts. No data, software or applications added to your Product,
Accessory or Software, including but not limited to personal contacts,
games and ringer tones, will be reinstalled. To avoid losing such data,
software and applications please create a back up prior to requesting
service.
How to Obtain Warranty Service or Other
Information
You will receive instructions on how to ship the Products, Accessories or
Software, at your expense, to a Motorola Authorized Repair Center. To
obtain service, you must include: (a) a copy of your receipt, bill of sale or
other comparable proof of purchase; (b) a written description of the
problem; (c) the name of your service provider, if applicable; (d) the
name and location of the installation facility (if applicable) and, most
importantly; (e) your address and telephone number.
Products Covered Length of Coverage
Software.
Applies only to physical
defects in the media that embodies
the copy of the software (e.g.
CD-ROM, or floppy disk).
Ninety (90) days
from
the date of purchase.
USA Phones:
1-800-331-6456
Pagers:
1-800-548-9954
Two-Way Radios and Messaging Devices:
1-800-353-2729
Canada All Products:
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone number
designated above for the product with which they are used.
101
Hearing Aids
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR
REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS
THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT
SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR
FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF
BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR
APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO USE THE
PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE
DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation
on the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that
vary from state to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola
certain exclusive rights for copyrighted Motorola software such as the
exclusive rights to reproduce and distribute copies of the Motorola
software. Motorola software may only be copied into, used in, and
redistributed with, the Products associated with such Motorola
software. No other use, including without limitation disassembly of
such Motorola software or exercise of the exclusive rights reserved for
Motorola, is permitted.
Hearing Aid Compatibility with Mobile Phones
Heari ng Aids
Some Motorola phones are measured for compatibility with hearing
aids. If the box for your particular model has “Rated for Hearing Aids”
printed on it, the following explanation applies.
When some mobile phones are used near some hearing devices
(hearing aids and cochlear implants), users may detect a buzzing,
humming, or whining noise. Some hearing devices are more immune
than others to this interference noise, and phones also vary in the
amount of interference they generate.
The wireless telephone industry has developed ratings for some of their
mobile phones, to assist hearing device users in finding phones that
may be compatible with their hearing devices. Not all phones have been
rated. Phones that are rated have the rating on their box or a label on
the box.
The ratings are not guarantees. Results will vary depending on the
user’s hearing device and hearing loss. If your hearing device happens to
be vulnerable to interference, you may not be able to use a rated phone
102
WHO Information
successfully. Trying out the phone with your hearing device is the best
way to evaluate it for your personal needs.
M-Ratings:
Phones rated M3 or M4 meet FCC requirements and are
likely to generate less interference to hearing devices than phones that
are not labeled. M4 is the better/higher of the two ratings.
T-Ratings:
Phones rated T3 or T4 meet FCC requirements and are likely
to be more usable with a hearing device’s telecoil (“T Switch” or
“Telephone Switch”) than unrated phones. T4 is the better/higher of the
two ratings. (Note that not all hearing devices have telecoils in them.)
Hearing devices may also be measured for immunity to this type of
interference. Your hearing device manufacturer or hearing health
professional may help you find results for your hearing device. The more
immune your hearing aid is, the less likely you are to experience
interference noise from mobile phones.
Information from the World Health Organization
WHO Information
Present scientific information does not indicate the need for any special
precautions for the use of mobile phones. If you are concerned, you may
want to limit your own or your children’s RF exposure by limiting the
length of calls or by using handsfree devices to keep mobile phones
away from your head and body.
Source: WHO Fact Sheet 193
Further information:
http://www.who.int./peh-emf
Product Registration
Registration
Online Product Registration:
www.motorola.com/us/productregistration
Product registration is an important step toward enjoying your new
Motorola product. Registering permits us to contact you for product or
software updates and allows you to subscribe to updates on new
products or special promotions. Registration is not required for warranty
coverage.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola Personal Communications Product
you will need to provide a copy of your dated sales receipt to confirm
warranty status.
Thank you for choosing a Motorola product.
103
Export Law
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United
States of America and Canada. The Governments of the United States
of America and Canada may restrict the exportation or re-exportation of
this product to certain destinations. For further information contact the
U.S. Department of Commerce or the Canadian Department of Foreign
Affairs and International Trade.
Caring for the Environment by Recycling
Recycling Informa tion
This symbol on a Motorola product means the product should
not be disposed of with household waste.
Disposal of your Mobile Device and
Accessories
Please do not dispose of mobile devices or electrical accessories (such
as chargers, headsets, or batteries) with your household waste. These
items should be disposed of in accordance with the national collection
and recycling schemes operated by your local or regional authority.
Alternatively, you may return unwanted mobile devices and electrical
accessories to any Motorola Approved Service Center in your region.
Details of Motorola approved national recycling schemes, and further
information on Motorola recycling activities can be found at:
www.motorola.com/recycling
Disposal of your Mobile Device Packaging
and User’s Guide
Product packaging and user’s guides should only be disposed of in
accordance with national collection and recycling requirements. Please
contact your regional authorities for more details.
California Perchlorate Label
Perchlorat e Label
Some mobile phones use an internal, permanent backup battery on the
printed circuit board that may contain very small amounts of
perchlorate. In such cases, California law requires the following label:
“Perchlorate Material – special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
.”
There is no special handling required by consumers.
104
Privacy and Data Security
Privacy and Data Security
Priva cy and Data Security
Motorola understands that privacy and data security are important to
everyone. Because some features of your mobile device may affect your
privacy or data security, please follow these recommendations to
enhance protection of your information:
• Monitor access
—Keep your mobile device with you and do
not leave it where others may have unmonitored access. Lock
your device’s keypad where this feature is available.
• Keep software up to date
—If Motorola or a
software/application vendor releases a patch or software fix
for your mobile device that updates the device’s security,
install it as soon as possible.
• Erase before recycling
—Delete personal information or
data from your mobile device prior to disposing of it or turning
it in for recycling. For step-by-step instructions on how to
delete all personal information from your device, see the
section entitled “master clear” or “delete data” in the user’s
guide.
Note:
For information on backing up your mobile device data
before erasing it, go to
www.motorola.com
and then navigate
to the “downloads” section of the consumer Web page for
“Motorola Backup” or “Motorola Phone Tools.”
• Understanding AGPS
—To provide location information for
emergency calls, certain Motorola mobile devices incorporate
Assisted Global Positioning System (AGPS) technology. AGPS
technology also can be used in non-emergency applications to
track and monitor a user’s location—for example, to provide
driving directions. Users who prefer not to permit such
tracking and monitoring should avoid using such applications.
If you have further questions regarding how the use of your mobile
device may impact your privacy or data security, please contact
Motorola at
privacy@motorola.com
, or contact your service provider.
Smart Practices While Driving
Drivi ng Safety
Drive Safe, Call Smart
Check the laws and regulations on the use of mobile devices
and their accessories in the areas where you drive. Always obey
them. The use of these devices may be prohibited or restricted in
certain areas -- for example, handsfree use only. Go to
www.motorola.com/callsmart
(in English only) for more
information.
Your mobile device lets you communicate by voice and data—almost
anywhere, anytime, wherever wireless service is available and safe
conditions allow. When driving a car, driving is your first responsibility.
105
Driving Safety
If you choose to use your mobile device while driving, remember the
following tips:
• Get to know your Motorola mobile device and its
features such as speed dial and redial.
If available, these
features help you to place your call without taking your
attention off the road.
• When available, use a handsfree device.
If possible, add an additional layer of
convenience to your mobile device with one
of the many Motorola Original handsfree
accessories available today.
• Position your mobile device within easy reach.
Be able
to access your mobile device without removing your eyes from
the road. If you receive an incoming call at an inconvenient
time, if possible, let your voicemail answer it for you.
• Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic
or hazardous weather conditions.
Rain, sleet, snow, ice,
and even heavy traffic can be hazardous.
• Do not take notes or look up phone numbers while
driving.
Jotting down a “to do” list or going through your
address book takes attention away from your primary
responsibility—driving safely.
• Dial sensibly and assess the traffic; if possible, place
calls when your car is not moving or before pulling into
traffic.
If you must make a call while moving, dial only a few
numbers, check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations
that may be distracting.
Make people you are talking with
aware you are driving and suspend conversations that can
divert your attention away from the road.
• Use your mobile device to call for help.
Dial 911 or other
local emergency number in the case of fire, traffic accident, or
medical emergencies.*
• Use your mobile device to help others in emergencies.
If you see an auto accident, crime in progress, or other serious
emergency where lives are in danger, call 911 or other local
emergency number, as you would want others to do for you.*
• Call roadside assistance or a special non-emergency
wireless assistance number when necessary.
If you see
a broken-down vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless number.*
* Wherever wireless phone service is available.
106
index
index
1X indicator 19
911 indicator 20
A
accessories 10, 21
airplane mode indicator 19
alarm clock 80
alarm indicator 21
alert,turn off 38
analog indicator 19
answer a call 16, 34
attach a number 42
audio file formats 59
B
backlight 34
banner 35
battery 14
battery level indicator 20
battery life, extend 12
battery,conserving 11
Bluetooth connections
connect during call 85
brightness 35
browser 68
C
cables 82
calculator 80
call
answer 16, 34
end 16
make 16
call ringtone 31
call times 45
minute beep 44
reset 45
car kit 21
center select key 2
clock 35
world 80
codes 22, 23
conference call 45
conserve battery 11
contacts 74
add entries to group 78
add number 76
call entry 75
create group 78
delete entry 75
edit entry 75
edit entry before call 75
picture ID 76
primary number 77
107
index
ringer ID 76
set speed dial 77
sort entries 77
view entry 74
D
data call indicator 19
data volumes
reset 45
dial a phone number 16
dialed calls 39
digital indicator 19
display
brightness 35
display themes 33
dormant indicator 19
drafts folder 57
DTMF tones 45
E
emergency number 41
end a call 16
end key 2, 16
export regulations 103
F
flip 16
G
group
add entries 78
create 78
H
handsfree speaker 21
headset 21
hearing aid 43
hearing aids 101
home screen
banner 35
I
indicators
1X 19
911 20
airplane mode 19
alarm 21
analog 19
battery level 20
data call 19
digital 19
dormant 19
location on 20
message 20
no service 19
roaming 19
signal strength 19
sounds off (silent) 20
sounds soft 21
speakerphone 21
SSL 19
108
index
indicators (continued)
TTY 20
uanswered call 21
vibrate on 20
voice call 20
international access code 43
iTAP text entry mode 49
K
key volume 33
keypad lock 24
L
location on indicator 20
lock
keypad 24
phone 23
M
make a call 16
menu
language 35
message
delete 56
drafts 57
quick text 55
store message objects 56, 57
text message 55
view sent message 56
message alert 32
message indicator 20, 30
message ringtone 32
messages
alerts 34
minute beep 44
missed Calls message 40
MP3 music player
songs 61
wake up 64
music player
albums 61
artists 61
controls, flip open 60
genres 61
My Music menu 61
playlist 61, 63
N
navigation key 2, 10
network
adjust settings 78
call connect tones 79
call drop tone 79
no service indicator 19
notepad 81
number. See phone number
numeric entry mode 49
O
optional accessory 10
optional feature 10
109
index
P
phone
network settings, adjust 78
network, call connect tones 79
network, call drop tone 79
talking phone 33
phone number 17
phonebook 42
add entries to group 78
add number 76
call entry 75
create group 78
delete entry 75
edit entry 75
picture ID 76
primary number 77
ringer ID 76
set speed dial 77
view entry 74
picture ID 76
playlist 61, 63
power key 2, 16
Q
quick text 55
R
received calls 39
recent calls 39
redial 29, 38
return a call 40
ringer ID 76
ringtone
buy 32
call 31
message 32
roaming indicator 19
S
safety information 94
safety tips 104
security code 22
send key 2, 16
signal strength indicator 19
sounds off (silent) indicator 20
sounds soft indicator 21
speakerphone 21
speakerphone indicator 21
SSL indicator 19
store your number 17
symbol entry mode 50
T
tap text entry mode 48
telephone number. See phone
number
text entry 46
TTY indicator 20
turn on/off 16
U
unanswered call indicator 21
