APPLICANT: MOTOROLA, INC. FCC ID: IHDP56JX2
INSTRUCTION MANUAL
A preliminary draft of the User’s Manual follows this page.
The text on the following 5 pages will be added to the user manual if not already included.
EXHIBIT 8
User’s Guide
Motorola HintTM
QA30
v559854.eps 9/5/2008 3:27:33 PM
DRAFT
DRAFT
1
HELLOMOTO
Thanks for purchasing the Motorola
Hint
TM
QA30 CDMA wireless phone! It’s an affordable phone with a sleek design
that’s sure to get attention.
Features at Your Fingertips
— More ways to keep in touch, all available directly from the home screen:
IM
;
E-mail
;
and
Conversations
, an outstanding new feature that provides a chatroom-like experience (see your Quick Start
Guide).
Multimedia on the Move
— Enjoy rich imaging and music wherever you go. Take pictures and video in a snap with
the 2 megapixel camera. Play your favorite tunes with the digital music player.
My Phone, My Way
– It’s your phone—make it that way. Customize your home screen with personal pictures,
change wallpapers, and use your favorite song as your ringtone.
DRAFT
2
Here’s a quick anatomy lesson.
Navigation Key
Left Soft Key
Send Key
Music Key
Function Key
Center Key
Right Soft Key
Power/End Key
Back Key
Camera/
Camcorder Key
Messaging
Key
Voice Record/
Speakerphone Key
Browser
Key
back
DRAFT
3
Here are more of your phone’s features:
Voice Key
Camera Lens Micro USB Port
Insert battery charger
& other accessories.
Volume Keys
Keypad Lock
Press & hold to
lock keypad.
Headset Port
DRAFT
4
back back
Main Menu
Contacts Alltel Web
IM
Conversations
E-mailFri 08/08/08 8:59 AM
Celltop
Alltel Nav
Home Screen Main Menu
Press the center
key
D
to select it.
4
Press the
navigation key
K
up/down/left/right
to scroll to a
menu feature.
3
Press & hold the
power/end key
until the display
lights up.
1
Press the left soft
key to open the
Main Menu
.
2
Messages Phonebook
Celltop
Phone Info
Recent Calls
Bluetooth
Ö©
Alltel Apps Alltel Web
EL
qj
Multimedia
Ü
Music Player
^
Em
Tools
u
Settings
Û
L
DRAFT
5
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Note:
Do not ship your phone to the above address. If you need to
return your phone for repairs, replacement, or warranty service, please
contact the Motorola Customer Support Center at:
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain
features may not be activated by your service provider, and/or the
provider’s network settings may limit the feature’s functionality. Always
contact your service provider about feature availability and functionality.
All features, functionality, and other product specifications, as well as
the information contained in this user’s guide, are based upon the latest
available information and believed to be accurate at the time of
printing. Motorola reserves the right to change or modify any
information or specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license. Yahoo! and the
Yahoo! logo are trademarks and/or registered trademarks of Yahoo!
Inc.Gmail and Google SMS
TM
mobile messaging service are trademarks
of Google Inc. The XM name is a registered trademark of XM Satellite
Radio Inc. MySpace and MySpace Mobile are trademarks of MySpace,
Inc. All other product or service names are the property of their
respective owners.
© 2008 Motorola, Inc. All rights reserved.
Caution:
Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to operate
the equipment.
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third-party software stored in semiconductor
memories or other media. Laws in the United States and other countries
preserve for Motorola and third-party software providers certain
exclusive rights for copyrighted software, such as the exclusive rights to
distribute or reproduce the copyrighted software. Accordingly, any
copyrighted software contained in the Motorola products may not be
modified, reverse-engineered, distributed, or reproduced in any manner
to the extent allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by implication,
estoppel, or otherwise, any license under the copyrights, patents, or
patent applications of Motorola or any third-party software provider,
except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Manual Number: -A
DRAFT
6
contents
contents
menu map . . . . . . . . . . . . . . . . . 8
Use and Care . . . . . . . . . . . . . . 10
get started . . . . . . . . . . . . . . . . 11
about this guide . . . . . . . . . . 11
battery . . . . . . . . . . . . . . . . . 12
battery charging . . . . . . . . . . 14
basics . . . . . . . . . . . . . . . . . . . . 16
home screen. . . . . . . . . . . . . 16
adjust volume . . . . . . . . . . . . 19
handsfree . . . . . . . . . . . . . . . 19
lock & unlock phone . . . . . . . 20
keypad lock . . . . . . . . . . . . . . 21
lock application . . . . . . . . . . . 21
codes . . . . . . . . . . . . . . . . . . 21
if you forget a code. . . . . . . . 22
manage memory . . . . . . . . . 22
TTY operation. . . . . . . . . . . . 24
airplane mode . . . . . . . . . . . 26
tips & tricks. . . . . . . . . . . . . . . 27
personalize . . . . . . . . . . . . . . . 28
home screen shortcuts . . . . 28
voice readout . . . . . . . . . . . . 28
key volumes . . . . . . . . . . . . . 29
alert reminders. . . . . . . . . . . 29
ring & vibrate . . . . . . . . . . . . 29
answer options . . . . . . . . . . 29
banner . . . . . . . . . . . . . . . . . 30
backlight. . . . . . . . . . . . . . . . 30
brightness . . . . . . . . . . . . . . 30
dial fonts . . . . . . . . . . . . . . . 30
clock format . . . . . . . . . . . . . 30
menu language . . . . . . . . . . 30
slider close. . . . . . . . . . . . . . 31
restore phone . . . . . . . . . . . 31
AGPS & your location . . . . . 31
AGPS limitations & tips . . . . 32
calls . . . . . . . . . . . . . . . . . . . . . 33
redial a number . . . . . . . . . . 33
automatic retry . . . . . . . . . . 33
turn off a call alert . . . . . . . . 33
recent calls . . . . . . . . . . . . . 34
return a missed call . . . . . . . 34
speed dial . . . . . . . . . . . . . . 35
one-touch dial . . . . . . . . . . . 35
emergency calls . . . . . . . . . 35
AGPS during an
emergency call . . . . . . . . . . 36
attach number . . . . . . . . . . . 37
insert special characters . . . 37
international calls. . . . . . . . . 37
DRAFT
7
contents
hearing aid. . . . . . . . . . . . . . 38
in-call options . . . . . . . . . . . 38
call times. . . . . . . . . . . . . . . 38
more calling features. . . . . . 40
text entry . . . . . . . . . . . . . . . . 41
entry modes . . . . . . . . . . . . 42
messages . . . . . . . . . . . . . . . . 45
send a multimedia
message . . . . . . . . . . . . . . . 45
receive a message . . . . . . . 48
conversations . . . . . . . . . . . 49
Google SMS mobile
messaging service . . . . . . . 50
email . . . . . . . . . . . . . . . . . . 51
voicemail . . . . . . . . . . . . . . . 52
more messaging features . . 53
entertainment . . . . . . . . . . . . 56
XM Radio Mobile. . . . . . . . . 56
Google Mobile. . . . . . . . . . . 56
myspace mobile . . . . . . . . . 57
camera/camcorder . . . . . . . . 57
view pictures . . . . . . . . . . . . 62
play videos . . . . . . . . . . . . . . 63
manage sounds . . . . . . . . . . 66
browser . . . . . . . . . . . . . . . . 67
tools . . . . . . . . . . . . . . . . . . . . . 68
voice recognition . . . . . . . . . 68
phonebook . . . . . . . . . . . . . . 73
network . . . . . . . . . . . . . . . . 75
personal organizer . . . . . . . . 76
connections. . . . . . . . . . . . . . . 78
cable connections. . . . . . . . . 78
Bluetooth connections . . . . . 79
service & repairs . . . . . . . . . . . 85
SAR Data . . . . . . . . . . . . . . . . . 86
Safety Information . . . . . . . . . 90
Industry Canada Notice . . . . . 93
FCC Notice. . . . . . . . . . . . . . . . 93
Warranty . . . . . . . . . . . . . . . . . 94
Hearing Aids . . . . . . . . . . . . . . 97
WHO Information . . . . . . . . . . 98
Registration . . . . . . . . . . . . . . 98
Export Law . . . . . . . . . . . . . . . 99
Recycling Information . . . . . . 99
Perchlorate Label . . . . . . . . . . 99
Privacy and Data Security . . 100
Driving Safety. . . . . . . . . . . . 100
index . . . . . . . . . . . . . . . . . . . 102
DRAFT
8
menu map
menu map
main menu
Ö
Messaging
• Create Message
• Conversations
• Inbox
• Outbox
•Drafts
•Voicemail
•E-mail
• Google SMS
©
Alltel Apps
E
Alltel Web
•Browser
• MySpace
• Google
L
Phonebook
•New
• Contact List
•Groups
• Speed Dial
q
Recent Calls
• Received Calls
• Missed Calls
• Dialed Calls
• All Calls
•Timers
j
Multimedia
• Music & Sounds
•Camera
•Pictures
• Camcorder
• Videos
• Storage Device
Ü
Music Player
^
Celltop
E
Bluetooth
m
To o l s
• Voice Commands
• Calendar
•AlarmClock
• World Clock
•Calculator
• Notepad
u
Settings
• (see next page)
Û
Phone Info
• My Number
•SW/HW Version
• Icon Glossary
This is the standard main menu layout.
Your
phone’s menu may be different.
DRAFT
9
menu map
settings menu
• Sounds
• Call Ringtone
• Message Ringtone
• Voicemail Ringtone
•Ring&Vibrate
• Alert Reminders
• Service Alerts
• Power On/Off
• Voice Readout
• Keypad Volume
• Volume Sidekeys
•Display
• Banner
• Backlight
• Brightness
• Wallpaper
• Dial Fonts
•ClockFormat
• Phone
• Airplane Mode
• Shortcuts
• Language
•Location
• Security
• Network Selection
• Active Line
•TextLearning
• Airtime Warning
• Slider Close
•Call
• Answer Options
• Auto Retry
• TTY Setup
• One Touch Dial
• Int’l Dialing
• DTMF Tones
• Hearing Aid
•Bluetooth
•AddNewDevice
•USB
• Mass Storage
• Modem/COM
• Storage Device
• Save Options *
• Phone Memory
• Memory Card *
• Phone Info
• My Number
•SW/HWVersion
• Icon Glossary
• Software Update
* available only when optional memory card
installed
DRAFT
10
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain, extreme
humidity, sweat, or other moisture. If it does get
wet, don’t try to accelerate drying with the use of
an oven or dryer, as this may damage the phone.
Don’t expose your phone to dust, dirt, sand, food,
or other inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below -10°C/14°F or
above 45°C/113°F.
To clean your phone, use only a dry soft cloth.
Don’t use alcohol or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a microwave oven. Don’t drop your phone.
DRAFT
11
get started
get started
about this guide
This guide shows how to locate a menu feature as
follows:
Find it:
Main Menu
>
qRecent Calls
>
Dialed Calls
This means that, from the home screen:
1
Press the left soft key
-
(
Main Menu
) to open the
menu.
2
Press the navigation key
K
to scroll to
qRecent Calls
, and press the center key
D
to
select it.
3
Press
K
to scroll to
Dialed Calls
, and press
D
to
select it.
CAUTION:
Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is
network/subscription dependent and may
not be available in all areas. Contact your
service provider for more information.
This means a feature requires an optional
accessory.
DRAFT
12
get started
battery
install & charge battery
See your Quick Start Guide for instructions on installing
and charging the battery.
conserve battery charge
Using certain features can quickly deplete your
battery’s charge.
These features can include
downloading music, replaying video clips, and
using Bluetooth® wireless connections.
You can conserve your battery’s charge by doing the
following:
•
Turn Bluetooth power off when not in use (see
page 79).
•
Turn off wallpaper (see your Quick Start Guide).
•
Reduce backlight display time (see page 30).
battery use & safety
IMPORTANT: HANDLE AND STORE BATTERIES
PROPERLY TO AVOID INJURY OR DAMAGE.
Most
battery issues arise from improper handling of
batteries, and particularly from the continued use of
damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred,
or otherwise attempt to change the form of
your battery.
• Don’t let the phone or battery come in
contact with water.
Water can get into the
phone’s circuits, leading to corrosion. If the
phone and/or battery get wet, have them
checked by your carrier or contact Motorola
even if they appear to be working properly.
• Don’t allow the battery to touch metal
objects.
If metal objects, such as jewelry, stay
DRAFT
13
get started
in prolonged contact with the battery contact
points, the battery could become very hot.
• Don’t place your battery near a heat source.
Excessive heat can damage the phone or the
battery. High temperatures can cause the
battery to swell, leak, or malfunction.
Therefore:
•
Do
not
dry a wet or damp battery with an
appliance or heat source, such as a hair
dryer or microwave oven.
•
Avoid leaving your phone in your car in high
temperatures.
DOs
• Do avoid dropping the battery or phone.
Dropping these items, especially on a hard
surface, can potentially cause damage.
• Do contact your service provider or
Motorola if your phone or battery has been
damaged from dropping or high
temperatures.
IMPORTANT: USE MOTOROLA ORIGINAL
PRODUCTS FOR QUALITY ASSURANCE AND
SAFEGUARDS.
To aid consumers in identifying
authentic Motorola batteries from non-original or
counterfeit batteries (that may not have adequate
safety protection), Motorola provides holograms on its
batteries. Consumers should confirm that any battery
they purchase has a “Motorola Original” hologram.
Motorola recommends you always use
Motorola-branded batteries and chargers.
Motorola
mobile devices are designed to work with Motorola
batteries. If you see a message on your display such as
Invalid Battery
or
Unable to Charge
, take the following steps:
•
Remove the battery and inspect it to confirm
that it has a “Motorola Original” hologram;
•
If there is no hologram, the battery is not a
Motorola battery;
DRAFT
14
get started
•
If there is a hologram, replace the battery and
retry charging it;
•
If the message remains, contact a Motorola
Authorized Service Center.
Important:
Motorola’s warranty does not cover
damage to the phone caused by non-Motorola batteries
and/or chargers.
Warning:
Use of a non-Motorola battery or charger may
present a risk of fire, explosion, leakage, or other
hazard.
PROPER AND SAFE BATTERY DISPOSAL AND
RECYCLING
Proper battery disposal is not only important for safety,
it benefits the environment. Consumers may recycle
their used batteries in many retail or service provider
locations. Additional information on proper disposal and
recycling may be found on the Web:
•
www.motorola.com/recycling
•
www.rbrc.org/call2recycle/
(in English only)
Disposal:
Promptly dispose of used batteries
in accordance with local regulations. Contact
your local recycling center or national recycling
organizations for more information on how to dispose
of batteries.
Warning:
Never dispose of batteries in a fire because
they may explode.
battery charging
Notes for charging your phone’s battery:
•
When charging your battery, keep it near room
temperature. Never expose batteries to
temperatures below 0°C (32°F) or above 45°C
(113°F) when charging.
•
New batteries are not fully charged.
DRAFT
15
get started
•
New batteries or batteries stored for a long
time may take more time to charge.
•
Motorola batteries and charging systems have
circuitry that protects the battery from damage
from overcharging.
DRAFT
16
basics
basics
home screen
Your phone shows the home screen when you are not
on a call or using the menu.
Note:
Your home screen might look different from the
one shown.
Soft key labels in the home screen show the current
soft key functions.
Status indicators at the top of your phone’s display
provide important information about your phone, such
as incoming calls, missed messages, and other
conditions. Here are the indicators you may see:
back
Main Menu
Contacts Alltel Web
IM
Alltel Nav
Conversations
E-mailFri 08/08/08 8:59 AM
Celltop
L
Right Soft
Key Label
Right
Soft Key
Left Soft
Key Label
Left
Soft Key
Status
Indicators
indicator
8
Signal Strength
—Vertical bars show the
strength of the network connection.
C
Digital
—Phone is in a CDMA digital
coverage area.
EVDO Coverage
—Phone is in an
EVDO (fast broadband internet
service) coverage area.
DRAFT
17
basics
J
1xRTT
—Phone is in a 1xRTT coverage area.
(1xRTT offers higher voice and data
transmission than CDMA.)
ê
EVDO/ 1xRTT Coverage
—Phone is
an area with both EVDO coverage
and 1xRTT coverage.
í
Airplane Mode
—Phone’s features that
require voice or data transmission are
turned off (see page 26).
W
Roaming
—Phone is in a digital coverage
area and is roaming off network.
5
SSL
—Indicates phone is using Secure
Sockets Layer (SSL) secure data
transmission.
ì
Data Call
—Shows during an active data
call.
indicator
ã
Dormant
—Indicates phone is dormant and
PPP session is active.
9
No Service
—Phone is in area with no
service coverage.
G
VR Active
—Indicates the phone’s Voice
Recognition feature is active (see page 68).
æ
VR Listening
—Indicates the phone’s Voice
Recognition feature is waiting for a voice
command (see page 68).
8
TTY
—Phone is in TTY mode (see page 24).
è
911 Only
—
Location
is set to
Off (E911 Only)
.
ó
Location On
—
Location
is set to
On (Do Not Ask)
or
On (Always Ask)
.
0
Keypad Locked
—The keypad is locked.
A
Battery Level
—Shows battery charge level.
The more bars, the greater the charge.
indicator
DRAFT
18
basics
Bluetooth Active
—Your phone is paired to
another Bluetooth device.
Bluetooth On
—Your phone’s Bluetooth
power is
On
.
Bluetooth Connected
—Your phone is
connected to another Bluetooth device.
t
In Call
—Shows during an active voice call.
]
New Message
—Phone received a new
text message.
w
New Voicemail Message
—Phone
received a new voicemail message.
New Text & Voicemail Message
—Phone
received a new text and a new voicemail
message.
indicator
]
à
All Sounds Off
—
Master Volume
is set to
All
sounds off
(see the Quick Start Guide).
H
Vibrate Only
—
Master Volume
is set to
Vibrate
Only
(see the Quick Start Guide).
á
Alarm Only
—
Master Volume
is set to
Alarm Only
(see the Quick Start Guide).
=
Missed Call
—Phone received an
unanswered call.
i
Speakerphone On
—Speakerphone is on.
h
Alarm On
—An alarm has been set.
Calendar Event
—A calendar event has
been created.
indicator
DRAFT
19
basics
adjust volume
Press the volume keys up
or down to:
•
turn off an
incoming call alert
•
adjust the earpiece volume during calls
•
change sound settings (see the Quick Start
Guide)
handsfree
Note:
The use of wireless phones while driving may
cause distraction. Discontinue a call if you can’t
concentrate on driving. Additionally, the use of wireless
devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and
regulations on the use of these products.
handsfree speaker
To activate the handsfree
speaker during a call
, press
the voice record/speakerphone
key
u
.
You will hear an audible alert
and see the speakerphone
indicator
i
and
SPEAKER PHONE ON
.
The handsfree speaker stays on until you press and
hold the voice record/speakerphone key again or turn
off the phone.
To turn off the handsfree speaker
, press and hold the
voice record/speakerphone key. Your phone will show
SPEAKER PHONE OFF
.
To end the call
, press the power/end key
I
. You will
hear an audible alert.
Note:
The handsfree speaker won’t work when your
phone is connected to a handsfree car kit or headset.
Volume
Keys
Voice Record/-
Speakerphone Key
DRAFT
20
basics
accessory volume settings (car
kit or headset)
To adjust volume of headsets or car kit accessories that
are enabled for Bluetooth wireless connections, press
your phone’s volume keys up or down during an active
call.
lock & unlock phone
You can lock your phone manually or set it to lock
automatically whenever you turn it off.
To lock or unlock your phone, you need the four-digit
unlock code. A locked phone still rings or vibrates for
incoming calls or messages,
but you have to unlock it
to answer
.
You can make emergency calls on your phone even
when it is locked (see page 35).
manual lock
Find it:
Main Menu
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
and press
Done
.
2
Scroll to
Lock Phone Now
and press
D
.
3
When prompted, enter the four-digit unlock code
and press
Done
.
To unlock your phone
, press
Unlock
(the right soft key).
When you see
Enter Unlock Code
, enter your four-digit unlock
code and press
Done
.
automatic lock
To lock the phone whenever you turn it on:
Find it:
Main Menu
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
and press
Done
.
DRAFT
21
basics
2
Scroll to
Phone Lock Setting
and press
D
.
3
Scroll to
On Power Up
and press
D
.
The phone will be locked whenever it is turned on. To
unlock the phone when you turn it on, enter the
four-digit lock code in the
Enter Lock Code
entry area and
press
Done
.
keypad lock
You can lock the phone’s keypad to prevent accidental
key presses.
To lock the keypad
, from the home screen, press and
hold the keypad lock key at the top of the phone (see
page 3). To unlock the keypad, press and hold the
keypad lock key again.
lock application
Find it:
Main Menu
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
and press
Done
.
2
Scroll to
Restrictions
and press
D
3
Scroll to the desired application and press
D
:
Calls
,
Messages
,
Location
,
Data Modem
,
Alltel Apps
,
Browser
.
codes
Your phone’s four-digit
unlock code
is originally set to
1234
or to the
last four digits of your phone number
.
The six-digit
security code
is originally set to
000000
.
Your service provider may reset these codes before you
get your phone.
If your service provider didn’t change the unlock code,
you should change it to prevent unauthorized use of
your phone. The unlock code must contain four digits.
DRAFT
22
basics
To change the unlock code
:
Find it:
Main Menu
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
and press
Done
.
2
With
Edit Lock Code
highlighted, press
D
.
3
Enter the new code in both entry fields and press
Done
.
if you forget a code
Your phone’s four-digit unlock code is set at the factory
to
1234
or to the last four digits of your phone number.
The six-digit security code is set to
000000
.
If you forget your security code, contact your service
provider.
manage memory
Note:
The microSD memory card is an
optional
accessory
, available separately.
You can store multimedia content such as songs and
photos on your phone’s internal memory or on a
removable microSD memory card.
Your phone automatically creates folders on the
memory card named
My_Images
(for photos),
My_Videos
(for
video clips), and
My_Sounds
(for sound files). You can also
create your own folders on the memory card.
Note:
If you download a copyrighted file to your phone
and store it on your memory card, you can use the file
only when your memory card is inserted in your phone.
You cannot send, copy, or change copyrighted files.
See your Quick Start Guide for instructions on installing
a memory card.
DRAFT
23
basics
set memory for multimedia content
You can specify where multimedia content is saved—in
phone memory or in folders on the memory card.
Find it:
Main Menu
>
uSettings
>
Storage Device
1
With
Save Options
highlighted, press
D
.
2
Scroll to
Pictures
,
Videos
, or
Sounds
, and press
D
.
3 To save to phone memory
, select
Phone Memory
and
press
D
.
To save to an existing folder
on the memory
card, select the name of the folder and press
D
.
To save to a new folder that you create
on the
memory card, select
(New Folder)
and press
D
, then
enter a name for the folder and press
Save
.
view memory information
Find it:
Main Menu
>
uSettings
>
Storage Device
1
Select
Phone Memory
or
Memory Card
and press
D
.
2
If you selected
Phone Memory
in step 1, select
Phone
Memory Usage
,
My Pictures
,
My Videos
, or
My Sounds
, and
press
D
.
If you selected
Memory Card
in step 1, select
Memory Card
Usage
,
My Pictures
,
My Videos
,
My Sounds
, or
Format Memory Card
,
and press
D
.
move files
You can move files (such as photos, videos, sound, and
music files) to the memory card to free up phone
memory.
Note:
Moving a file to the memory card deletes it from
phone memory.
You can also move files from one folder to another on
your memory card.
DRAFT
24
basics
Find it:
Main Menu
>
uSettings
>
Storage Device
1
Select
Phone Memory
or
Memory Card
and press
D
.
2
Scroll to
My Pictures
,
My Videos
, or
My Sounds
, and
press
D
.
3
If necessary, scroll to the folder you want and
press
D
.
4
Press
Options
, then scroll to
Move
and press
D
.
5
Scroll to each file you want to move and press
D
.
Press
Mark All
if you want to move all files.
Note:
Files that were preloaded on your phone
can’t be moved.
6
When you have selected all files that you want to
move, press
Done
.
7 If moving the file(s) from a folder on the
memory card
, select
Phone
, the name of a folder, or
(New Folder)
, and press
D
. If you selected
(New Folder)
,
enter the folder name and press
Save
.
If moving the file(s) from phone memory
, select
the name of a folder or
(New Folder)
and press
D
. If
you selected
(New Folder)
, enter the folder name and
press
Save
.
8
When your phone asks if you want to move the
file(s), select
Yes
and press
D
to confirm that you
want to move the file(s).
TTY operation
You can use an optional TTY device with your
phone to send and receive calls. You must plug the TTY
device into the phone’s headset jack and set the phone
to operate in one of three TTY modes.
Use a TSB-121 compliant cable (provided by the TTY
device manufacturer) to connect the TTY device to the
phone.
DRAFT
25
basics
Set the phone volume to level 4 (middle setting) for
proper operation. If you experience a high number of
incorrect characters, adjust the volume as needed to
minimize errors.
For optimal performance, your phone should be at least
12 inches (30 centimeters) from the TTY device. Placing
the phone too close to the device may cause high error
rates.
set TTY mode
ù
When you set your phone to a TTY mode, it
operates in that mode whenever the TTY device is
connected.
Find it:
Main Menu
>
uSettings
>
Call
>
TTY Setup
Select one of the following
TTY Setup
options:
When your phone is in TTY mode, during an active call
your phone displays the international TTY mode, the
international TTY symbol, and the mode setting.
option
Voice
Set to standard voice mode.
TTY
Transmit and receive TTY characters.
VCO
Receive TTY characters but transmit
by speaking into phone microphone.
HCO
Transmit TTY characters but receive
by listening to phone earpiece.
DRAFT
26
basics
airplane mode
Note:
Consult airline staff about the use of
Airplane Mode
in flight. Turn off your phone whenever instructed to do
so by airline staff.
Use airplane mode to turn off your phone’s calling
features in locations where wireless phone use is
prohibited.
You cannot make or receive calls or use
Bluetooth wireless connections in airplane mode
,
but you can use your phone’s other non-calling
features.
Find it:
Main Menu
>
uSettings
>
Phone
>
Airplane Mode
>
On
or
Off
DRAFT
27
tips & tricks
tips & tricks
From the home screen
, you can use shortcuts:
To... Do this...
redial a number
Press
J
, then scroll to the
number you want to call and
press
J
again.
lock/unlock
keypad
To
lock
the keypad, press
and hold the keypad lock key
at the top of the phone (see
page 3).
To
unlock
the keypad, press
and hold the keypad lock key
again.
take photos
Press
w
.
play music
Press
[
.
See your Quick Start Guide
for more information on
using your phone’s music
player.
see your number
Press
Ò
, then
#
.
To... Do this...
DRAFT
28
personalize
personalize
home screen shortcuts
From the home screen, you can push the navigation
key up, down, left, or right to select shortcuts to your
favorite features. Your phone includes these shortcuts
on the home screen:
See your Quick Start Guide for information on these
options.
To
change
the shortcuts:
Find it:
Main Menu
>
uSettings
>
Phone
>
Shortcuts
Select a navigation key direction, then choose the
feature you want to open when you press the key in
that direction. Select
Reset All
to reset the shortcuts to
the factory defaults shown above.
voice readout
You can set your phone to
speak aloud
when you
press keys, receive a call with caller ID available, or
scroll through the
Phonebook
or recent calls lists.
Find it:
Main Menu
>
uSettings
>
Sounds
>
Voice Readout
home screen shortcuts
LContacts xAlltel Web
gConversations xIM
PE-mail xAlltel Nav
DRAFT
29
personalize
key volumes
To set the volume of the tones played
when you press
keypad keys
:
Find it:
Main Menu
>
uSettings
>
Sounds
>
Keypad Volume
To se whether your phone plays tones
when you press
side keys
:
Find it:
Main Menu
>
uSettings
>
Sounds
>
Volume Sidekeys
alert reminders
Set how many times your phone plays a message alert:
Find it:
Main Menu
>
uSettings
>
Sounds
>
Alert Reminders
Select
Once
,
Every 2 Minutes
,
Every 15 Minutes
, or
Off
.
ring & vibrate
Set your phone to ring
and
vibrate when you receive an
incoming call or message.
Note:
Master Volume
must be set to
High
,
Med High
,
Medium
,
Low Med
, or
Low
(see the Quick Start Guide).
Find it:
Main Menu
>
uSettings
>
Sounds
>
Ring & Vibrate
answer options
You can use different methods to answer an incoming
call.
Find it:
Main Menu
>
uSettings
>
Call
>
Answer Options
options
Slider Open
Answer by opening the slider.
Any Key
Answer by pressing any key.
Send Only
Answer only by pressing
J
.
Auto Answer with
Handsfree
Automatically answer incoming
calls when the phone is
connected to a handsfree device,
such as a car kit or headset.
DRAFT
30
personalize
banner
Set a heading to display near the top of the home
screen:
Find it:
Main Menu
>
uSettings
>
Display
>
Banner
backlight
Set the amount of time that the display and
keypad backlights stay on.
Find it:
Main Menu
>
uSettings
>
Display
>
Backlight
brightness
Find it:
Main Menu
>
uSettings
>
Display
>
Brightness
dial fonts
Set the phone to display numbers that you enter in
large type:
Find it:
Main Menu
>
uSettings
>
Display
>
Dial Fonts
clock format
Set how your phone shows the current time:
Find it:
Main Menu
>
uSettings
>
Display
>
Clock Format
1
Scroll to
Inside Clock
(main screen) or
Outside Clock
(external display) and press
D
.
2
Select
Digital 12
for a 12-hour clock,
Digital 24
for a
24-hour clock,
Analog
for a dial clock, or
Off
for no
clock, and press
D
.
menu language
Find it:
Main Menu
>
uSettings
>
Phone
>
Language
DRAFT
31
personalize
slider close
Set whether your phone ends a current task and
returns to the home screen when you close the slider:
Find it:
Main Menu
>
uSettings
>
Personalize
>
Slide Tone
restore phone
Reset all options except unlock code, security code,
and lifetime timer:
Find it:
Main Menu
>
uSettings
>
Phone
>
Security
1
When prompted, enter the four-digit unlock code
(see page 21) and press
Done
.
2
Scroll to
Restore Phone
and press
D
.
3
Confirm that you want to reset the phone by
scrolling to
Yes
and pressing
D
.
4
When prompted, enter the four-digit unlock code
(see page 21) and press
Done
.
The screen does not change while the phone
resets all options. After a few seconds, the phone
turns off and then back on.
AGPS & your location
Your phone uses the Automatic Location Information
(ALI) feature, along with AGPS satellite signals, to tell
the network where you are physically located.
When ALI is set to
Location
>
On (Do Not Ask)
or
On (Always Ask)
your phone shows the
O
(ALI on) indicator. Services
may use your known location to provide useful
information (for example, driving directions, or the
location of the nearest bank). Your phone prompts you
when the network or a service asks for your location.
You can refuse at this point.
DRAFT
32
personalize
When ALI is set to
Location
>
Off (E911 Only)
, your phone
displays the
P
(ALI off) indicator, and the phone does
not send location information unless you call the
emergency phone number (such as 911).
Find it:
Main Menu
>
uSettings
>
Phone
>
Location
AGPS limitations & tips
Your phone uses Assisted Global Positioning
System (AGPS) satellite signals to estimate your
location. If your phone cannot find strong satellite
signals, your AGPS might be slower, less accurate, or it
might not work at all. AGPS provides only an
approximate location, often within 150 feet (45 meters)
but sometimes much farther from your actual location.
To improve AGPS accuracy:
•
Go outside and away from underground
locations, covered vehicles, structures with
metal or concrete roofs, tall buildings, and
foliage. Indoor performance might improve if
you move closer to windows, but some
window sun shielding films can block satellite
signals.
•
Move away from radios, entertainment
equipment, and other electronic devices that
might interfere with or block AGPS satellite
signals.
•
If your phone has a retractable antenna, extend
the antenna.
•
Hold your phone away from your body, and
point the phone antenna toward the sky. Do not
cover the antenna area with your fingers.
AGPS uses satellites controlled by the U.S. government
and subject to changes implemented in accordance
with the Department of Defense AGPS user policy and
the Federal Radio Navigation Plan. These changes
might affect AGPS performance.
DRAFT
33
calls
calls
To make and answer calls, see your Quick Start Guide.
redial a number
1
Press
J
to see the
All Calls
list.
2
Scroll to the entry you want to call.
3
Press
J
to redial the number.
Note:
The
All Calls
list includes numbers that were busy
when you dialed.
automatic retry
When you receive a
busy signal
, your phone
displays
Call Failed, Number Busy
.
When you turn on automatic retry, your phone
automatically redials a busy number for four minutes.
When the call connects, your phone rings or vibrates
once, displays
Redial Successful
, and completes the call.
Find it:
Main Menu
>
uSettings
>
Call
>
Auto Retry
When automatic retry is turned off, you can manually
activate the feature to redial a phone number. When
you hear a fast busy signal and see
Call Failed
, press or
RETRY
.
turn off a call alert
When you hear a call alert for an incoming call, you can
press the volume keys to turn off the alert before
answering the call.
DRAFT
34
calls
recent calls
Your phone keeps lists of the calls you recently
received and dialed, even if the calls didn’t connect. The
lists are sorted from newest to oldest calls. The oldest
calls are deleted as new calls are added.
Find it:
Main Menu
>
qRecent Calls
1
Scroll to
Received Calls
,
Missed Calls
,
Dialed Calls
, or
All Calls
,
and press
D
.
2
Scroll to an entry.
3
Press
J
to to call the number.
To see call details (like time and date), press
D
.
Press
Options
to open the
Options
menu, which can
include
Save
,
Lock
,
Delete
,
Delete All
, and
Timers
.
To send a message to the entry, press
Send Msg
.
return a missed call
Your phone keeps a record of your unanswered calls.
When you miss a call, your phone shows the
=
(missed call) indicator and
[Number] Missed Calls
.
To view missed calls immediately
:
1
When you see the missed call indicator, select
View
Now
to see the missed calls list.
2
Scroll to an entry on the list.
3
Press
J
to call the entry.
To see call details (like time and date), press
D
.
Press
Options
to open the missed calls
Options
menu
(see page 34.
Press
Send Msg
to send a message to the entry.
To return a missed call later
, select
View Later
when you
see the missed calls indicator. For more information on
viewing and returning missed calls, see page 34.
DRAFT
35
calls
speed dial
Note:
Speed dial number 1 is already assigned to your
voicemail number.
To assign a speed dial number to an entry
:
Find it:
Main Menu
>
LPhonebook
>
Speed Dial
1
Scroll to an unassigned speed dial location entry
and press
Set
.
2
Scroll through the
Select Contact
list to the entry to be
assigned the number and press
D
.
3
When prompted, select
Yes
to confirm your
selection.
To see an entry’s speed dial number
:
Find it:
Main Menu
>
LPhonebook
>
Contact List
As you scroll through entries, speed dial numbers are
identified by the speed dial indicator
>
.
To activate speed dialing
, set
One Touch Dial
to
On
:
Find it:
Main Menu
>
uSettings
>
Call
>
One Touch Dial
To speed dial a number
, enter the speed dial number
for the entry you want to call and press
J
.
one-touch dial
To one-touch dial a speed dial number 1 through 9,
press and hold the single-digit speed dial number (keys
1
through
9
) for that entry.
emergency calls
Your service provider programs one or more
emergency phone numbers, such as 911, that you can
call under any circumstances, even when your phone is
locked.
Note:
Emergency numbers vary by country. Your
phone’s preprogrammed number(s) may not work in all
DRAFT
36
calls
locations, and sometimes an emergency call cannot be
placed due to network, environmental, or interference
issues.
1
Enter the emergency number.
2
Press
J
to call the emergency number.
AGPS during an
emergency call
When you make an emergency call, your phone
can use Assisted Global Positioning System
(AGPS) satellite signals to tell the emergency response
center your approximate location.
The AGPS feature has limitations, so always tell the
emergency response center your best knowledge of
your location. Remain on the phone for as long as the
emergency response center instructs you.
AGPS
might not work
for emergency calls:
•
Your phone’s AGPS feature must be turned on
(see page 31).
•
Your local emergency response center might
not process AGPS location information. For
details, contact your local authorities.
For best results:
•
Go outside and away from underground
locations, covered vehicles, structures with
metal or concrete roofs, tall buildings, and
foliage. Indoor performance might improve if
you move closer to windows, but some
window sun shielding films can block satellite
signals.
•
Move away from radios, entertainment
equipment, and other electronic devices that
might interfere with or block AGPS satellite
signals.
DRAFT
37
calls
If your phone cannot find strong AGPS satellite signals,
the location of the nearest cell tower in contact with
your phone is automatically provided to the emergency
response center.
attach number
While dialing (with digits visible on the display), press
Options
, then scroll to and select
Attach Number
to attach a
number from your
Contact List
or
Recent Calls
list.
insert special
characters
While entering a number, press
Options
and select one of
these options:
•
Insert Pause (p)
—Your phone pauses for two
seconds before it dials the next digit.
•
Insert Wait (w)
—Your phone waits until the call
connects, then prompts you for confirmation
before it dials the next digit(s).
international calls
If your phone service includes international
dialing, you can
set your phone to
automatically insert your local international access
code
:
Find it:
Main Menu
>
uSettings
>
Call
>
Int’l Dialing
>
Automatic
When
Int’l Dialing
is set to
Automatic
,
insert your local
international access code
(indicated by
+
) by pressing
and holding
0
. Then, use the keypad to dial the
country code and phone number.
DRAFT
38
calls
hearing aid
You can set your phone for hearing aid compatibility:
Find it:
Main Menu
>
uSettings
>
Call
>
Hearing Aid
Note:
For more information about hearing aid
compatibility, see “Hearing Aid Compatibility with
Mobile Phones” on page 97.
in-call options
During an active call, press
Options
to access these
options:
Note:
When you have a Bluetooth device connected
during a call, you may also see
Audio to Phone
and
Disconnect
Bluetooth
options. When you have
TTY Mode
on, you may
also see a
TTY Setup
option.
call times
Network connection time
is the elapsed time from
the moment you connect to your service provider’s
network to the moment you end the call by pressing
I
.
This time includes busy signals and ringing.
The amount of network connection time you track
on your resettable timer may not equal the amount
of time for which you are billed by your service
provider. For billing information, please contact
your service provider directly.
Contacts Recent Calls
Phone Info Message Center
Bluetooth Menu Datebook
BREW TTY Setup
DRAFT
39
calls
features
minute beep
Set your phone to beep every minute during
a call:
Main Menu
>
uSettings
>
Sounds
>
Service Alerts
>
Minute Beep
view call times
Main Menu
>
qRecent Calls
>
Timers
Scroll to and view the times for
Last Call
,
All Calls
,
Received
Calls
,
Dialed Calls
,
Roaming Calls
,
Transmitted Data
,
Received Data
,
Total Data
,
Last Reset
,
Lifetime Calls
, or
Lifetime Data Counter
.
reset call times or data volumes
Main Menu
>
qRecent Calls
>
Timers
To reset individual timers
: Scroll to the timer you
want to reset and press
Reset
. When prompted,
select
Yes
to confirm that you want to reset the
timer.
To reset all timers
: Press
Reset All
. When prompted,
select
Yes
to confirm that you want to reset all
timers.
features
DRAFT
40
calls
more calling features
features
DTMF Tones
Your phone can send Dual Tone Multi Frequency
(DTMF) tones for calling card calls or other
automated touch-tone calls.
Set up DTMF tones:
Main Menu
>
uSettings
>
Call
>
DTMF Tones
Select
Short
or
Long
.
conference call
During a call, dial the next number and
press
J
, then press
J
again.
DRAFT
41
text entry
text entry
Some features require you to enter names, numbers,
and other text, such as when you add a contact to your
Contact List
or when you write and send a message.
Your phone’s full
qwerty keypad
makes text entry
quick and easy:
While you enter text, an indicator at the top right of the
screen shows the current entry mode.
See the next section for instructions on selecting an
entry mode.
Options Add Send
To:
0/10 MsgFN
0/160
Flashing cursor shows
where you are typing.
Entry Mode
Indicator
DRAFT
42
text entry
entry modes
Multiple entry modes make it easy for you to enter
information on text entry screens.
iTAP® & QWERTY modes
To select an iTAP or QWERTY entry mode
:
1
Press
Options
(the left soft key).
2
Select
Entry Mode
.
3
Select one of the following:
Note:
Your phone may not contain all of the languages
listed.
iTAP software provides a predictive text entry method
that combines your key presses into common words.
When you enter three or more characters in a row, your
phone may guess the rest of the word. For example, if
you enter
prog
, you might see:
If you want a different word (such as
progress
), continue
pressing keys to enter the remaining letters.
If you enter a word your phone does not recognize,
your phone stores the word to use as a future word
entry modes
iTAP English
Let the phone predict each English word
as you press keys (see page 42).
iTAP
Spanish
Let the phone predict each Spanish
word as you press keys.
QWERTY
Enter letters and number, first character
of a sentence in uppercase.
Options Send
29/160
Insert
MsgiTAPEn
This is a program
Alvin MillerTo:
Press K right to
accept program.
Enter a space
after prog to
keep only prog.
DRAFT
43
text entry
option. When you run out of phone memory for
unrecognized words, your phone deletes the oldest
word to add new words.
Press
K
up or down to view other possible
combinations, and select the one you want.
Press
K
right to enter the highlighted combination
when it spells a word. A space is automatically inserted
after the word.
Press
1
to enter punctuation or other characters.
function key mode
Press the function key
N
to
switch to
FN
mode:
•
Press
N
once
to enter
the upper symbol or
number on the next key
pressed (such as
!
), then
return to the previous
entry mode.
•
Press
N
twice
to enter the upper symbols
and numbers on the keys until you press
N
again or move the cursor to a different field.
special keys
Several special keys let you modify text or change entry
options:
Press to enter
upper character
on key.
Press with
function key
to select symbol mode.
Press to delete
last character.
Press to enter
a line break.
Press to change
capitalization
DRAFT
44
text entry
capitalization options
Press
s
in any text entry screen to toggle between
these
capitalization options
:
Note:
When you enter a phone number from the home
screen, your phone automatically uses
FN
mode for
keys with numbers and for the
*
and
#
keys.
entry
mode indicator description
iTAP
English
iTAPEn
first letter of sentence in
uppercase (English)
iTAPEN
all uppercase letters (English)
iTAPen
all lowercase letters (English)
iTAP
Spanish
iTAPEs
first letter of sentence in
uppercase (Spanish)
iTAPES
all uppercase letters (Spanish)
iTAPes
all lowercase letters (Spanish)
QWERTY Abc
first character of a sentence in
uppercase
abc
all lowercase letters
ABC
all uppercase letters
entry
mode indicator description
DRAFT
45
messages
messages
send a multimedia
message
A multimedia message (MMS) contains embedded
media objects, such as photos, pictures, animations,
sounds, and voice records. You can also insert a Vcard
for a contact or a calendar event. You can send a
multimedia message to other wireless phones with
multimedia messaging capabilities and to email
addresses.
create & send message
1
From the home screen, press
v
, then scroll to
Create Message
and press
D
.
Tip:
You can also go to
Create Message
by pressing
Main Menu
>
ÖMessaging
>
Create Message
.
Options Add Send
To:
0/10 MsgFN
0/160
Press the function key to
switch the entry mode.
Highlighted
Entry Area
Press Options
to view Options
menu.
Press Add to select recipient
from the Phonebook or recent
calls lists.
DRAFT
46
messages
2
Enter a phone number or email address.
Press
D
to select
Add
. On the
Add Recipients
screen,
select
Contacts
,
Recent Calls
, or
Groups
. Press to mark
each entry you want to include as a message
recipient, and press
Done
when finished.
3
Scroll down to the text entry area and enter
message text.
To insert a prewritten message
, press
D
to
select
Insert
, then scroll to
Quick Text
and press
D
.
Scroll to the quick text you want to insert and
press
D
.
To insert a sound
, press
D
to select
Insert
, then
scroll to
Audio
and press
D
. Scroll to the desired
sound and press
D
.
To insert a stored picture or video clip
, press
D
to select
Insert
, then scroll to
Pictures
or
Video
and
press
D
. Scroll to the desired object and
press
D
.
To insert a Vcard for a contact
in your
Phonebook
,
press
D
to select
Insert
, then scroll to
Contact Info
and
press
D
. Scroll to the desired entry and
press
D
.
To insert an event from your phone’s Calendar
,
press
D
to select
Insert
, then scroll to
Calendar Event
and press
D
. Scroll to the desired event and
press
D
.
4
To insert a message subject, set message priority,
or set delivery options, press
Options
(see page 47).
5
Press
Send
to send the message.
When you press
Options
from the
Msg
message entry
screen, you see the messaging
Options
menu, which can
include the following:
DRAFT
47
messages
Note:
The options you see depend on the type of
message you are sending and the type of object you
insert into the message.
options
Entry Mode
Specify the entry mode to use
(see page 42).
Save to Draft
Save the message, without
sending it, in the
Drafts
folder.
Insert Subject
Enter the message subject.
Insert Object
Insert quick text, picture, video,
sound, vcard, or calendar event.
Add Recipients
Enter message recipients from
the
Phonebook
or recent calls lists.
Priority
Set to
Normal
or
High
.
Delivery
Select
Deferred Delivery
to schedule
the message to be sent at a later
time. Select
Delivery report
if you
want to receive a report on
whether or not the message was
sent successfully.
Delete Object
Delete an object you inserted into
the message.
Cancel Message
Cancel delivery of the message
and exit with or without saving
the message to the
Drafts
folder.
options
DRAFT
48
messages
receive a message
When you receive a message, your phone plays
an alert and displays the
<
(new message) indicator
and a
New Message
notification.
Select
View Now
to read the message immediately, or
select
View Later
to save it in your
Inbox
for viewing later.
To read messages in your
Inbox
:
1
From the home screen, press
v
, then scroll to
Inbox
and press
D
.
Tip:
You can also go to
Inbox
by pressing
Main Menu
>
ÖMessaging
>
Inbox
.
2
Scroll to the message you want to read.
3
Press
D
to open the message. Your phone
displays the media object, then the message.
4
Press
Reply
if you want to respond to the message.
Press
Options
to view and select from these options:
Reply with Copy
,
Forward
,
Lock/Unlock
,
Save To Contact
,
Start Slide
Show
,
Save Object
,
Message Details
,
Delete Message
,
Delete Multiple
,
Delete All
,
Sort By
,
Save Quick Text
,
Create Message
.
Note:
The options you see depend on the type of
message you receive and whether the message
contains multimedia objects.
Press
Ò
to return to the message
Inbox
.
Multimedia messages can contain different media
objects:
•
Photos, pictures, and animations are displayed
when you read the message.
•
A sound file begins playing when the message
text is displayed. Use the volume keys to adjust
the volume.
•
If the message includes an attached file, select
the file indicator or filename and press
VIEW
(for
an image file),
PLAY
(for a sound file), or
OPEN
(for
DRAFT
49
messages
an object such as a
Phonebook
or calendar entry or
an unknown file type).
conversations
If you get a lot of messages from many different
senders, you need a way to keep track of all of these
messages and your responses.
Conversations
organizes your messages into conversation
strings that you can follow quickly and easily.
1
From the home screen, scroll to
gConversations
and
press
D
.
Tip:
You can also go to
Conversations
by pressing
v
and selecting
Conversations
, or by pressing
Main Menu
>
ÖMessaging
>
Conversations
.
Your phone shows a list of contacts and/or
numbers who have sent you messages.
The list is ordered by how recently you received
messages from the senders. The most recent
message sender appears at the top of the list.
2
Scroll to the message sender you want.
When a message sender is highlighted, you see
the date, time, and subject of the last message
you received from the sender.
Press
Options
to view these options:
Reply
,
Delete
Conversation
,
Delete All Conversations
,
Save to Contacts
,
Go to
Messaging
.
3
Press
D
to select the highlighted sender.
Options
Conversations
Nick 10/15/08
What Time Is the Meeting? 8:15 AM
Liz 10/14/08
Martin
Jameson
Jason
Ken
™
DRAFT
50
messages
You see a partial view of the last message you
received from the sender. Above that is a partial
view of the previous message.
4
Press
K
to
scroll back to earlier messages
.
Press
D
to open and view a highlighted
message
.
Scroll down to the entry area at the bottom of the
screen
to enter a reply
. Press
Send
to send the
reply.
Press
Options
to view and select
:
Reply
,
Lock/Unlock
,
Save
to Contacts
,
Message Details
,
Delete Message
,
Call
,
Go to Messaging
.
5
Press
I
to return to the home screen.
Google SMSTM
mobile
messaging service
With Google SMS mobile messaging service, you can
send a text message with your search query to Google.
Google will then send a text message to your phone
with the results of your query. You can inquire about
local movie listings, driving directions, weather, stock
quotes, translations, currency conversion, sports
scores, and more.
1
From the home screen, press
v
, then scroll to
Google SMS
and press
D
.
Options
Nick (5)
Me 4:33 PM 10/14/08
Are you coming to the mtg? We will discuss
Nick 8:15 AM 10/15/08
What time is the meeting? I have to
finish this design and then run it down
to the shop first, then stop by ...
™
=
=
Previous
Message
Press Options to open
the Options menu.
Most Recent
Message in
Conversation
Scroll down to this area to
enter a message reply.
Scroll up to see
earlier messages.
Press the center
key D to open a
highlighted message.
DRAFT
51
messages
Tip:
You can also go to
Google SMS
by pressing
Main Menu
>
ÖMessaging
>
Google SMS
.
2
Enter your search term and send it to Google.
email
You can send and receive email messages with (such
as Gmail
TM
or AOL or with another account that you set
up.
set up personal email with
automaticsettings
Most of the settings for Gmail and AOL email accounts
are already configured for you on your phone.
After you know your email user names and passwords
for these accounts:
1
From the home screen, select
PE-mail
.
2
Scroll to and select
G-mail
or
AOL Mail
.
3
Enter your email user name and password, and
press
D
.
Your phone connects to the appropriate email
server.
4
Press
I
to return to the home screen.
set up personal email
manually
If you want to use an email provider other than the
ones already set up on your phone, you must manually
enter the following:
•
account type (POP3 or IMAP4)
•
the incoming server address, and whether the
server requires an SSL connection
•
the outgoing server address, and whether the
outgoing server requires authentication
•
for a small number of POP3 and IMAP4 email
providers, a domain name
DRAFT
52
messages
1
From the home screen, select
PE-mail
.
2
Scroll to and select
Other
.
3
Complete the
Username
,
Password
,
Email Address
, and the
incoming server information, and press
Next
.
4
Enter the outgoing server information, and press
Done
to complete the setup and check your email.
5
Press
I
to return to the home screen.
read email
When you receive a new email message, your phone
plays an alert and shows
V
.
1
From the home screen, select
PE-mail
.
2
Scroll to and select an email account.
3
Log into your email account by entering your user
name and password.
4
Select and read the email messages you want.
send email
1
From the home screen, select
PE-mail
.
2
Scroll to and select an email account.
3
Log into your email account by entering your user
name and password.
4
Select and “New”, then type and send an email
message just like on your PC.
voicemail
Your network stores the voicemail messages
you receive. To listen to your messages, call
your voicemail number.
Note:
Your service provider may give you additional
information about using voicemail.
When you
receive
a voicemail message, your phone
shows the voicemail message indicator
w
and
New Voicemail
. Press
Call
to listen to the message.
DRAFT
53
messages
To
check
voicemail messages later:
1
From the home screen, scroll to
àVoicemail
and
press
D
.
Tip:
You can also press
v
and select
Voicemail
, or
press
Main Menu
>
ÖMessaging
>
Voicemail
.
2
Press
J
to call your voicemail number.
Your phone may prompt you to store your voicemail
phone number. If you don’t know your voicemail
number, contact your service provider.
more messaging
features
features
send text message
Main Menu
>
ÖMessaging
>
Create Message
Press
Options
to perform other actions on the
message.
create quick text
Enter and store
Quick Text
(prewritten)
messages that you can select and send later.
Main Menu
>
ÖMessaging
Press
Options
. then scroll to
Quick Text
and press
D
.
Press
Options
, then select
New
.
DRAFT
54
messages
send quick text
Main Menu
>
ÖMessaging
Press
Options
. then scroll to
Quick Text
and press
D
.
Scroll to the quick text message you want to send
and press
Send
.
set up messaging
Main Menu
>
ÖMessaging
Press
Options
. Select
Auto Cleanup
to erase messages
automatically. Select
Voicemail #
to enter the number
to call for your voicemail messages. Select
Callback #
to insert a callback number automatically into
messages that you send. Select
Signature
to create a
signature line that is inserted automatically at the
end of messages that you send. Select
Auto Receive
to
set whether received messages are automatically
downloaded to your phone.
features
view sent message
Main Menu
>
ÖMessaging
>
Outbox
Scroll to the message you want to view and
press
D
.
Press
Options
to access the following options:
Resend
,
Forward
,
Lock
,
Save to Contact
,
Message Details
,
Delete Message
,
Delete Multiple
,
Delete All
,
Sort By
, or
Create Message
.
delete messages
Delete all messages or only messages from
the
Outbox
or
Drafts
folder:
Main Menu
>
ÖMessaging
Press
Options
, then scroll to and select
Delete
. Select
Inbox
,
Drafts
,
Outbox
, or
All
.
To delete Inbox or Outbox messages
automatically,
press
Options
, then select
Auto Cleanup
.
features
DRAFT
55
messages
drafts
Main Menu
>
ÖMessaging
>
Drafts
To complete and send
a saved draft message,
scroll to the message and press
D
.
or
To view and select other options
, press
Options
to
access the following:
Send
,
Edit
,
Lock
,
Save to Contact
,
Delete
,
or
Create Message
.
Note:
The options you see depend on your service
provider.
store message objects
Go to a multimedia message slide, or
highlight an object in a letter, then press
Options
and
select
Save Object
.
features
DRAFT
56
entertainment
entertainment
XM Radio Mobile
XM Radio Mobile gives you access to
twenty-five of XM Radio’s top satellite channels right
from your mobile phone.
Find it:
Main Menu
>
ÜMultimedia
>
Music & Sounds
>
XM Radio
When XM Radio Mobile is activated, scroll left or right
to the station you want, and press
D
to select it.
Note:
Your service provider may give you additional
information about using XM Radio Mobile on your
phone.
GoogleTM
Mobile
Stay connected on the go with Google Search, Maps,
YouTube
TM
, News, Blogger, and many other popular
Google products.
To use Google Mobile
:
Find it:
Main Menu
>
EAlltel Web
>
Google
When you connect to Google, select the Google
product you want to use.
Note:
Normal airtime connection charges apply.
DRAFT
57
entertainment
myspace mobileTM
MySpace Mobile allows you to:
•
view and send messages
•
read and send bulletins
•
add friend comments
•
read and post blogs
•
approve friend requests
•
view friend profiles
•
view photos and more
You’ll need a MySpace account to use MySpace
Mobile. If you already have an existing account, you can
log in right away. If not, sign up by going to
http://www.myspace.com
and clicking on the “Sign Up”
tab.
To use MySpace Mobile:
Find it:
Main Menu
>
EAlltel Web
>
Google
When you connect to Google, select the Google
product you want to use.
Note:
Normal airtime connection charges apply.
camera/camcorder
take photos
The camera lens is on the back of the phone.
To ge t
the sharpest photos, wipe the lens clean with a dry
cloth before you take a photo.
With the phone powered on:
1
Press the camera/camcorder key
w
.
2
With
Camera
highlighted, press
D
.
Tip:
You can also activate your phone’s camera by
pressing
Main Menu
>
jMultimedia
>
Camera
.
DRAFT
58
entertainment
Your phone shows the active camera viewfinder
screen:
Tip:
Press the camera/camcorder key
w
to
toggle between the camera and camcorder.
3
Point the camera lens at the subject.
Press
K
right and left to zoom in and out.
To view other options,
press
Options
(see page 58).
4
Press
D
to take the photo.
5
Press
Send
to send the photo in a message,
to an online album (if
Online Album Reminder
is
On
—see page 59), or to another device via a
Bluetooth® connection (see page 82).
Press
D
(
Save
) to save the photo and return to the
active viewfinder.
Press
Delete
to delete the photo and return to the
active photo viewfinder.
6
Press
O
to return to the main screen.
When the camera is active, press
Options
to view and
select these options:
Options Capture Pictures
455 1600x1200
Press K right
& left to zoom
in & out.
Remaining
Shots
Resolution
Press D to
take photo.
Press left soft
key to view
Options menu.
option
Resolution
Set resolution to
1600x1200
,
1280x960
,
640x480
,
320x240
, or
Picture ID
.
DRAFT
59
entertainment
Tip:
You can skip the
Options
menu and quickly adjust
camera settings. Just press
K
up and down to scroll
to
Color Effects
,
White Balance
, or
Brightness
, then press
K
left
and right to scroll through the settings for that option.
Self Timer
Set the camera to take a photo
after a specific interval:
3 seconds
,
5 seconds,
or
10 seconds
. Or turn it off.
Add Picture Frame
Select a custom frame for your
photo.
Brightness
Adjust image brightness by
scrolling left or right from
-2
to
2
.
White Balance
Adjust for different lighting
conditions by scrolling left or right
to choose from
Auto
,
Sunny
,
Cloudy
,
Tungsten
,
Fluorescent
, or
Darkness
.
Color Effects
Scroll left or right to select
Normal
,
Antique
,
Black & White
, or
Negative
.
option
Online Album
Reminder
Set whether your phone
to asks if you want to
send photos to an online photo
album (availability is
network/subscription
dependent).
Shutter Tone
Activate a sound that plays when
you take a photo:
Shutter
,
Silent
,
Quack
,
Boing
, or
Apple Bite
.
Storage Location
Specify where you want
to save photos (
Phone
or
Memory Card
). This option is available
only if you have a memory card
inserted.
option
DRAFT
60
entertainment
record videos
1
Press and
hold
the camera/camcorder key
w
to
activate the camera.
Tip:
You can also activate your phone’s camcorder
by pressing
Main Menu jMultimedia
>
Camcorder
.
Your phone shows the active camcorder
viewfinder screen:
Tip:
Press the camera/camcorder key
w
to
toggle between the camera and camcorder.
2
Point the camera lens at the subject.
Press
K
right and left to zoom in and out.
To view other options,
press
Options
(see the table
following these steps).
3
Press
D
to begin video recording.
4
Press
Stop
to stop video recording.
5
Press
Send
to send the video clip in a
message, to an online album (if
Online Album
Reminder
is
On
—see page 59), or to another device via
a Bluetooth® connection (see page 82).
Press
D
(
Save
) to save the video clip and return to
the active viewfinder.
Press
Delete
to delete the video clip and return to
the active viewfinder.
6
Press
I
to return to the main screen.
Options Rec Videos
176x144REC 00:00:00
Press D to
take photo.
Press left soft
key to view
Options menu.
Camera Mode
(Photo or Video)
Recording
Time
DRAFT
61
entertainment
When the camcorder viewfinder is active, press
Options
to set video recording options:
option
Resolution
Set resolution to
Large (320 x 240)
or
Small (176 x 144)
.
Video Length
Set the maximum length of
video clips to
2 Minutes
,
5Minutes
,
Fit
to Memory
, or
Fit to MMS
.
Tip:
To send your video clip in a
multimedia message, the video
length must be set to
Fit to MMS
.
Self Timer
Set the camcorder to begin
recording after a specific
interval:
3 seconds
,
5 seconds,
or
10
seconds
. Or turn it off.
Brightness
Adjust image brightness by
scrolling left or right from
-2
to
2
.
White Balance
Adjust for different lighting
conditions by scrolling left or
right to choose from
Auto
,
Sunny
,
Cloudy
,
Tungsten
,
Fluorescent
, or
Darkness
.
Color Effects
Scroll left or right to select
Normal
,
Antique
,
Black & White
, or
Negative
.
Online Album Reminder
Set whether your phone
to asks if you want to
send photos to an online photo
album.
Storage Location
Specify where you want
to save video clips (
Phone
or
Memory Card
). This option is
available only if you have a
memory card inserted.
option
DRAFT
62
entertainment
view pictures
Find it:
Main Menu
>
jMultimedia
>
Pictures
1
Scroll left and right to view pictures.
Press
Options
to open the
Options
menu (see the table
following these steps).
Press
Edit
to access editing tools that you can use
to modify the selected picture.
If you see
Slideshow
at the bottom middle of the
screen, press
D
to see a “slideshow”
presentation of all pictures, shown in sequence.
Press
D
to pause the slideshow. Press
Settings
to
modify slideshow settings. Press
Ò
to end the
slideshow and return to the picture viewer screen.
If you see
Ok
at the bottom middle of the screen
and the message
Buy Wallpaper
, press
D
to
purchase and download pictures.
2
Press
Ò
to return to the
Multimedia
menu.
While viewing pictures, press
Options
from the playback
screen to access these options:
Note:
You may not see all of the options listed below,
depending on your service provider.
options
Send
Send the selected picture in a
multimedia message (see page 45) or
to another device via a Bluetooth®
connection (see page 82).
To OnLine
Album
Send the picture to an online
picture album (availability is
network/subscription dependent).
Capture
Open the active camera viewfinder
screen.
Rename
Change the name of the selected
picture.
DRAFT
63
entertainment
play videos
To play video clips that you have recorded or received in
multimedia messages:
Find it:
Main Menu
>
jMultimedia
>
Videos
Move
Move the selected picture
from phone memory to an
installed memory card, or from
memory card to phone memory (see
page 23).
Print
Use a Bluetooth® connection with a
printer to print the selected picture.
Delete
Delete the selected picture (if it is not
locked (see
Mark
and
Mark All
below).
Delete All
Delete all unlocked pictures (see
Mark
and
Mark All
below).
Mark
Mark the selected picture. After you
mark one or more pictures, press
Options
to see these options:
Unmark
,
Mark
All
,
Unmark All
,
Move Marked
,
Delete Marked
,
Lock
Marked
,
Unlock Marked
.
options
Mark All
Mark all pictures. After you mark all
pictures, press
Options
to see these
options:
Unmark
,
Mark All
,
Unmark All
,
Move
Marked
,
Delete Marked
,
Lock Marked
,
Unlock
Marked
.
File Info
See detailed information about the
selected picture.
options
DRAFT
64
entertainment
Your phone shows the video clip playback screen:
1
Scroll left or right to highlight a video clip.
Press
Options
to open the
Options
menu (see the table
following these steps).
2
Press
D
to play a highlighted video clip.
Use these keys to control video playback:
Options Play Record
5/5
0811081219a.3g2
Press D to
play selected
video clip.
Press left soft
key to view
Options menu.
video playback controls
pause/play
Press
D
.
fast forward
Press &
hold
K
right
.
Options Mute
5/5
00:01 00:05
0811081219a
Press left soft key
to freeze video clip
at current frame
& open the
Options menu.
Press right soft
key to mute &
unmute video
clip sound.
DRAFT
65
entertainment
During video clip playback
, press
Options
to view
these options:
Extract Current Frame
,
Videos
,
File Info
.
3
When the video clip is finished playing, press
Ò
to return to the playback screen.
When a video clip is not playing, press
Options
from the
playback screen to access these options:
next video
clip
Press
K
right
.
rewind
Press &
hold
K
left
).
previous
video clip
Within first two seconds of video
clip playback, press
K
left
.
restart video
clip
After first two seconds of video clip
playback, press
K
left
.
switch
portrait &
landscape
orientation
Press
K
down.
video playback controls
options
Send
Send the selected clip in a multimedia
message (see page 45) or to another
device via a Bluetooth® connection (see
page 82).
To OnLine
Album
Send the video clip to an online
album (availability is
network/subscription dependent).
Rename
Change the name of the selected video
clip.
Move
Move the selected video clip
from phone memory to memory
card, or from memory card to phone
memory (see page 23).
Delete
Delete the selected video clip.
DRAFT
66
entertainment
Note:
Your phone’s options may vary. Most options
apply only to user-recorded videos, and are not available
for pre-installed videos.
manage sounds
You can record sounds for later playback.
create a sound
1
Press and hold the voice record/speakerphone
key
u
(see page 2).
Tip:
You can also press
Main Menu
>
jMultimedia
>
Music & Sounds
>
Sounds
>
Record New
.
2
Press
D
(
Start
) to begin recording.
3
Press
D
again to stop recording.
play a sound
Find it:
Main Menu
>
jMultimedia
>
Music & Sounds
>
Sounds
Scroll to the sound title and press
D
. Press
Options
to
open a menu that can include these options:
Send
,
Rename
,
Move
,
Lock
,
Delete
,
Delete All
,
Mark
,
Mark All
,
File Info
.
Delete All
Delete all unlocked video clips.
Trim
Edit the length of the video clip.
Mark
Mark the selected clip. After you mark
one or more clips, press
Options
to see
these options:
Unmark
,
Mark All
,
Unmark All
,
Move Marked
,
Delete Marked
,
Lock Marked
,
Unlock
Marked
.
Mark All
Mark all video clips. After you mark all
clips, press
Options
to see these options:
Unmark
,
Mark All
,
Unmark All
,
Move Marked
,
Delete
Marked
,
Lock Marked
,
Unlock Marked
File Info
See detailed information about the
selected video clip.
options
DRAFT
67
entertainment
browser
Use your phone’s browser to surf to your
favorite Web sites, upload videos to a video blog, and
download files and applications to your phone. Log
onto your Internet-based email account to check your
email on the go.
To launch the browser, from the home screen,
press
t
.
DRAFT
68
tools—voice recognition
tools
voice recognition
Your phone’s voice recognition feature lets you make
calls and complete other actions by speaking
commands to your phone.
voice recognition tips
•
Say the names of
Contact List
entries exactly as
listed. For example, to call the mobile number
for an entry named Bill Smith, say “Call Bill
Smith mobile.” (If the entry includes only one
number for Bill Smith, say “Call Bill Smith.”)
•
Speak numbers at a normal speed and volume,
and pronounce each digit distinctly. Avoid
pausing between digits.
•
You can set your phone to play voice command
instructions through the speakerphone by
pressing the voice key, which opens the
Voice
Commands
menu. If you use the
Call
command to
place a call, the audio plays through the phone’s
earpiece when the call connects. You can turn
this feature off (see page 72).
voice commands
1
Press and
release
the voice key on the right side of
the phone.
Your phone says
Please say a command
and shows a list
of voice commands.
DRAFT
69
tools—voice recognition
2
Say one of the following commands:
feature
Call <Name or #>
Place a call to:
•
a
Contact List
entry whose name you speak
•
a phone number you speak
•
your voicemail number
•
the last number you called
For example, you could say “Call Bill Smith mobile,”
“Call 8475551212,” “Call voicemail,” or Call last
number.”
Send Msg <Name or #>
Send a message to:
•
a
Contact List
entry whose name you speak
•
a phone number you speak
•
all the members of a
Group
whose name you
speak
For example, when prompted to say a command,
you could say “Send message to Bill Smith mobile,”
“Send message to 8475551212,” or “Send
message to Family.” Your phone would open the
Msg
entry screen, with Bill Smith’s mobile number, the
number
8475551212
, or the group named
Family
in the
To
field. For instructions on sending a message, see
pages 45.
feature
DRAFT
70
tools—voice recognition
Go To <Shortcut>
Go to the menu or perform the action you specify:
Contacts
,
Recent Calls
,
Messaging
,
Settings
,
Music Player
, or
Redial
.
Note:
If you don’t have any content (music, recent
calls, and so on), the phone returns to the home
screen.
Check <Item>
View the item on the screen that you say aloud:
Status
,
Voicemail
,
Messages
,
Missed Calls
,
Time
,
Signal Strength
,
Battery
, or
Vol ume
.
feature
Contact <Name>
Look up an entry from the
Contact List
by saying the
contact’s name.
Play <Playlist>
Play a playlist with the music player by saying the
name of one of your playlists.
Note:
If you don’t have any music, the phone
returns to the home screen.
Help
See help information for the voice recognition
feature.
feature
DRAFT
71
tools—voice recognition
voice recognition settings
To modify voice recognition settings:
1
Press and release the voice key on the right side of
the phone.
2
Press
Settings
.
3
Scroll to the desired option and press
D
.
voice recognition settings
Digit Dial Readout
Set your phone to say numbers aloud as you press
them on the keypad.
Confirmation
If your phone is not sure that it has correctly
identified a name or number that you speak, it can
display up to three choices and prompt you to
confirm the correct one.
You can control when choice lists appear:
Automatic
—Display a list of choices from multiple
alternatives.
Always Confirm
—Always display a list of choices when
there are multiple alternatives.
Never Confirm
—Never display a choice list. The phone
chooses from the best alternatives.
voice recognition settings
DRAFT
72
tools—voice recognition
To access in-device help for a setting you speak,
press
Info
.
Sensitivity
You can fine tune your phone’s ability to recognize
voice commands. Select
Most Sensitive
,
Recommended
, or
Least Sensitive
.
If sensitivity is too strict
, your phone often rejects
voice commands and displays “Please repeat ...” or
“No match found.” Select Most Sensitive.
If sensitivity is too forgiving
, you experience false
activations (indicating that the phone detects a
wrong match). Select
Least Sensitive
.
Adaptation
Follow the prompts on your screen to improve
recognition of spoken words. Adaptation takes
about sixty seconds and requires you to be in a
quiet place (no background noise).
voice recognition settings
Prompts
Mode
—Set whether your phone says
Prompts
,
Readout
(to
read every word on the screen), or
Tones Only
.
Audio Playback
—Set how you want to hear prompts:
Automatic
detection,
Speakerphone
, or through your
Earpiece
.
Call Alert
For an incoming call, set whether you hear a
Ring Only
,
Caller ID + Ring
, or
Name Repeat
(repeat the name until you
answer or the call goes to voicemail).
voice recognition settings
DRAFT
73
tools—phonebook
phonebook
create entry
For information on creating a new entry, see your Quick
Start Guide.
view entry
Find it:
Main Menu
>
LPhonebook
>
Contact List
To view details
for an entry, scroll to the entry and
press
D
.
For
other options
, scroll to the entry and press
Options
.
call entry
Find it:
Main Menu
>
LPhonebook
>
Contact List
Scroll to the entry you want to call and press
J
.
edit entry
To modify or delete
an entry:
Find it:
Main Menu
>
LPhonebook
>
Contact List
Scroll to the entry and press
Options
, then scroll to the
option you want and press
D
.
ringer IDs
When you assign a ringtone to an entry, your phone
plays that ringtone when you receive a call from that
entry.
Find it:
Main Menu
>
LPhonebook
1
Scroll to the entry and press
Options
, then select
Edit
Contact
.
2
Scroll to
Ringer ID
and press
D
.
DRAFT
74
tools—phonebook
3
Scroll to the desired ringtone.
Note:
As you scroll through settings, your phone
plays a sample of each setting you highlight.
4
Press
D
to select the highlighted ringtone.
picture IDs
Assign a photo or picture to show when you receive a
call from an entry:
Find it:
Main Menu
>
LPhonebook
>
Contact List
1
Scroll to the entry and press
Options
, then select
Edit
Contact
.
2
Scroll to
and press
D
.
3
Scroll left or right to the desired picture and
press
D
.
Press
Options
and select
Capture
to take a new photo
(see your Quick Start Guide) to use as a picture ID.
set default number
Set the primary number for an entry with multiple
numbers. This will be the number your phone shows
when listing
Contact List
entries.
Find it:
Main Menu
>
LPhonebook
>
Contact List
1
Scroll to the entry and press
Options
, then select
Edit
Contact
.
2
Scroll to the number to be set as the default
number and press
Options
, then select
Set as Default
.
sort entries
Set whether
Contact List
entries are listed in alphabetical
order by first or last name:
Find it:
Main Menu
>
LPhonebook
>
Contact List
1
Press
Options
, then select
Sort Name
.
2
Scroll to
First Name
or
Last Name
and press
D
.
DRAFT
75
tools—network
groups
To send a text message to many people at once, you
can add
Contact List
entries to
Groups
. Then, when you enter
a group’s name as a message recipient, the message is
sent to all members of that group.
Yo u r
Phonebook
comes with several groups already, and
you can create your own additional groups.
To add entries to a group
:
Find it:
Main Menu
>
LPhonebook
>
Groups
1
Scroll to the group name and press
Options
, then
select
Add Contacts
.
2
Scroll to each entry you want to add to the group
and press
D
.
A check mark appears in the box beside an entry
when you select it. To deselect an entry, scroll to
the entry and press
D
to remove the check mark.
3
When you finish selecting entries, press
Done
to
save your selections.
To create a new group
:
Find it:
Main Menu
>
LPhonebook
>
Groups
1
Press
New
.
2
Enter the new group name and press
Save
.
network
features
network settings
View network information and adjust
network settings:
Main Menu
>
uSettings
>
Phone
>
Network Selection
Scroll to the desired network setting and press
D
.
DRAFT
76
tools—personal organizer
personal organizer
call connect tones
Set phone to play a tone when a call
connects:
Main Menu
>
uSettings
>
Sounds
>
Service Alerts
>
Call Connect
call drop tone
Set phone to play an alert tone whenever
the network drops a call. (Because digital networks
are so quiet, a call drop alert may be your only
indication that a call was dropped.)
Main Menu
>
uSettings
>
Sounds
>
Service Alerts
>
Voice Call Drop
features
features
add datebook event
Main Menu
>
ÉTools
>
Datebook
Scroll to the desired day and press
Add
, then enter
event information and press
Done
.
view datebook event
View or edit event details:
Main Menu
>
ÉTools
>
Datebook
Scroll to the desired day and press
D
, then scroll
to the event and press
D
.
To edit the event, press
Edit
.
DRAFT
77
tools—personal organizer
event reminder
Press
View
to view an event reminder.
Press
Exit
to dismiss an event reminder.
set alarm
Main Menu
>
ÉTools
>
Alarm Clock
Select
Alarm 1,
Alarm 2
, or
Alarm 3
, then turn on the
alarm, specify the alarm time, recurrence, and alert
type.
turn off alarm
To turn off an alarm, press
Off
or
I
.
calculator
Main Menu
>
ÉTools
>
Calculator
features
view world clock
To view the current time in cities around the world:
Main Menu
>
ÉTools
>
World Clock
Scroll left or right to see the time in a desired city.
Or, press
Cities
, then scroll to a city and press
D
.
Press
Set DST
to set Daylight Savings Time for a city.
notepad
Your phone stores the most recent digits you
entered in the
Notepad
. These digits can be a number
that you called or a number that you entered and
want to save for later. You can also create notes
with information that you want to save for later.
Main Menu
>
ÉTools
>
Notepad
Your phone shows a list of notes. To view the
contents of a note, scroll to the note and press
D
.
To create a new note, press
New
.
features
DRAFT
78
connections—cable connections
connections
cable connections
Your phone has a micro USB port that allows
you to connect it to a computer.
Note:
Motorola Original
TM
data cables and supporting
software are sold separately. Check your computer to
determine the type of cable you need.
If you use a USB cable connection:
•
Make sure both your phone and the computer
are turned on.
•
Make sure to connect the phone to a
high-power USB port on your computer (not a
low-power one such as the USB port on your
keyboard or bus-powered USB hub). Typically,
USB high-power ports are located directly on
your computer.
Note:
If you connect your phone to a
low-power USB port, the computer may not
recognize your phone.
Specify the correct USB setting on your phone:
Find it:
Main Menu
>
uSettings
>
USB
Scroll to
Modem/COM
and press
D
.
DRAFT
79
connections—Bluetooth® connections
Bluetooth®
connections
Your phone supports Bluetooth wireless connections.
You can connect your phone to a Bluetooth headset or
car kit, or connect to another device to transfer files.
To view a list of Bluetooth profiles supported by your
phone:
Find it:
Main Menu
>
uSettings
>
Bluetooth
1
Press
Options
, then scroll to
Supported Profiles
and
press
D
.
2
To see more information about a profile, scroll to
the profile name and press
D
.
For more Bluetooth wireless connections support
information, go to
www.motorola.com/Bluetoothsupport
.
Note:
All multimedia (video player, audio player, shutter
tones) will play from the speakerphone when your
phone is connected to another Bluetooth device.
For maximum Bluetooth security
, always connect
Bluetooth devices in a safe, private environment, away
from other devices with Bluetooth connection
capabilities.
turn Bluetooth power on/off
Set Bluetooth power to be on whenever your phone
is on.
Find it:
Main Menu
>
u
Settings
>
Bluetooth
Press
Turn On
(the right soft key).
Note:
To extend battery life when you are not actively
using a Bluetooth connection, turn Bluetooth power off
by using this procedure and pressing
Turn Off
. If you turn
off Bluetooth power, your phone will not connect to
other Bluetooth devices until you turn on Bluetooth
power and then reconnect.
DRAFT
80
connections—Bluetooth® connections
place phone in discovery mode
Allow an unknown Bluetooth device to discover your
phone:
Find it:
Main Menu
>
uSettings
>
Bluetooth
1
Press
Options
.
2
Scroll to
Discovery Mode
and press
D
.
3
Scroll to
On
and press
D
.
The following message appears:
Discovery on: For one
minute other devices can find you
.
If the device requests permission to bond with your
phone, press
YES
and enter the device PIN code to
create a secure connection with the device. (The PIN
code is typically set to
0000
.)
Note:
See the instructions that came with your device
for the device’s PIN code and other information about
the device.
pair with headset, handsfree
device, or computer
Note: If you want to use your Motorola Bluetooth
headset with both an audio device and your phone,
use your phone’s Bluetooth menus to connect the
phone with the headset.
If you establish the
connection by pressing a button on the headset, or if
you allow the headset to connect automatically by
turning it on, you may experience unexpected results.
Before you try to connect to another Bluetooth
device
, make sure your phone’s Bluetooth power is
On
and the device is in pairing or bonding mode (see the
user guide for the device you are attempting to pair
with). You can connect your phone with only one device
at a time.
Find it:
Main Menu
>
uSettings
>
Bluetooth
DRAFT
81
connections—Bluetooth® connections
1
Press
D
to select
Add New Device
.
Note:
If your Bluetooth power is not turned on,
your phone will prompt you to turn it on.
2
When you see
Place the device you are connecting to in
discoverable mode
, press
D
.
Your phone lists the devices it finds within its
range. If your phone is already connected to a
device, your phone lists that device and identifies it
with a
%
(in-use indicator).
3
Scroll to a device in the list and press
Pair
to
connect to the device.
4
If the device requests permission to bond with
your phone, press
YES
and enter the device PIN
code to create a secure connection with the
device. (The PIN code is typically set to
0000
.)
Note:
See the instructions that came with your
device for the device’s PIN code and other
information about the device.
When the connection is made, the
à
(Bluetooth)
indicator or a
Bluetooth
message displays in the home
screen.
connect to handsfree device
during a call
1
During a call, press
Options
, then select
Connect Bluetooth
.
2
Scroll to
Add New Device
, or select the name of a
device if you have paired with it previously, and
press
D
.
3
If connecting to a new device, place the new
device in discoverable mode and press
D
on your
phone.
4
When your phone finds the device, press
Pair
.
5
If prompted, enter the default PIN code
0000
.
Note:
You can’t switch to a headset or car kit if you are
already connected to a Bluetooth device.
DRAFT
82
connections—Bluetooth® connections
copy files to another device
You can use a Bluetooth connection to transfer
a contact or file to another Bluetooth device.
To transfer a contact
:
Note:
Make sure the device receiving the entry has
Bluetooth power on and is in discoverable mode.
Find it:
Main Menu
>
LPhonebook
>
Contact List
1
Scroll to the entry you want to transfer and press
Options
.
2
Scroll to
Send Contact Info
and press
D
.
3
Press
D
to select
via Bluetooth
.
4
To add more entries, scroll to each entry and
press
D
.
5
Press
Done
, then press
Send
.
6
Scroll to
Add New Device
, or scroll to the device that
you want, and press v.
Note:
If your phone does not already have
Bluetooth power turned on, it prompts you to turn
it on.
7
If connecting to a new device, place the new
device in discoverable mode and press
D
on your
phone.
8
When the phone shows the list of devices, scroll
to the device you want and press
OK
.
9
If prompted, enter the default PIN code
0000
.
When the connection is made, the receiving device is
prompted to accept the transfer. When the receiving
device accepts, the your phone transfers the entry to
the device.
To transfer a file to another device
:
Note:
Make sure the device receiving the file has
Bluetooth power on and is in discoverable mode. The
DRAFT
83
connections—Bluetooth® connections
receiving phone must be capable of receiving the file
type.
1
On your phone, select the file (such as a picture,
video, or sound) you want to transfer and press
Options
.
2
Press
D
to select
Send
.
3
Scroll to
via Bluetooth
and press
D
.
4
Scroll to
Add New Device
, or scroll to the device that
you want, and press
D
.
Note:
If your phone does not already have
Bluetooth power turned on, it prompts you to turn
it on.
5
If connecting to a new device, place the new
device in discoverable mode and press
D
on your
phone.
6
When the phone shows the list of devices, scroll
to the device you want and press
OK
.
7
If prompted, enter the default PIN code
0000
.
8
When your phone prompts you to confirm that you
want to send the file, press
Yes
.
When the connection is made, the receiving device is
prompted to accept the transfer. When the receiving
device accepts, the your phone transfers the entry to
the device.
receive files from another
device
Note:
If you do not see the Bluetooth indicator
O
at
the top of your phone’s display,
turn on your phone’s
Bluetooth power
(see page 79).
1
Pair your phone with the other device (see
page 80).
2
Send the file from the other device. (If necessary,
refer to the user’s manual for the device for
instructions.)
DRAFT
84
connections—Bluetooth® connections
3
When prompted to accept the sent object, scroll to
Yes
and press
D
.
Your phone notifies you when the transfer is complete.
If necessary, press
Save
to save the file.
disconnect from a device
To disconnect from a device
while the phone
is idle
:
Find it:
Main Menu
>
u
Settings
>
Bluetooth
1
Scroll to the name of the device from which you
want to disconnect and press
Options
.
2
When your phone prompts
Disconnect from
devicename
?
, scroll to
Yes
and press
D
.
To disconnect from a device
during an active call
:
1
Press
Options
.
2
Scroll to
Disconnect Bluetooth
and press
D
.
DRAFT
85
service & repairs
service & repairs
If you have questions or need assistance, we're here to
help.
Go to
www.motorola.com/support
, where you can select
from a number of customer care options. You can also
contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456
(TTY/TDD United States for hearing impaired), or
1-800-461-4575 (Canada).
DRAFT
86
service & repairs
Specific Absorption Rate Data
SAR Data
This model wireless phone meets the
government’s requirements for exposure to radio
waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission (FCC) of the U.S. Government and by the Canadian
regulatory authorities. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the
general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure
the safety of all persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit
of measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC and by the Canadian regulatory
authorities is 1.6 W/kg.
1
Tests for SAR are conducted using
standard operating positions accepted by the FCC and by Industry
Canada with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate
at multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a wireless
base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S.
and Canada, it must be tested and certified to the FCC and Industry
Canada that it does not exceed the limit established by each
government for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body)
reported to the FCC and available for review by Industry Canada.
The highest SAR value for this model phone when tested for use at
the ear is 1.14W/kg, and when worn on the body, as described in
this user guide, is 1.40 W/kg. (Body-worn measurements differ
among phone models, depending upon available accessories and
regulatory requirements).
2
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the governmental
requirements for safe exposure. Please note that improvements to
this product model could cause differences in the SAR value for
later products; in all cases, products are designed to be within the
guidelines.
SAR Data
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications & Internet Association
(CTIA) Web site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA)
Web site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
2. The SAR information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty range for this
product.
DRAFT
FCC Notice
FCC Notice To Users
FCC Notice
Motorola has not approved any changes or modifications to this
device by the user. Any changes or modifications could void the
user’s authority to operate the equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. See 47 CFR Sec. 15.19(3).
If your mobile device or accessory has a USB connector, or is
otherwise considered a computer peripheral device whereby it can
be connected to a computer for purposes of transferring data, then
it is considered a Class B device and the following statement
applies:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the
receiver.
•
Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician
for help.
DRAFT
89
Important Safety and
Legal Information
DRAFT
90
Safety Information
Safety and General Information
Safety Information
This section contains important information on the safe and
efficient operation of your mobile device. Read this information
before using your mobile device.
Exposure to Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON, it
receives and transmits RF energy. When you communicate with your
mobile device, the system handling your call controls the power level at
which your mobile device transmits.
Your Motorola mobile device is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to
RF energy.
Operational Precautions
For optimal mobile device performance, and to be sure that human
exposure to RF energy does not exceed the guidelines set forth in the
relevant standards, always follow these instructions and precautions.
Product Operation
When placing or receiving a phone call, hold your mobile device just like
you would a landline phone.
If you wear the mobile device on your body, always place the mobile
device in a Motorola-supplied or approved clip, holder, holster, case, or
body harness. If you do not use a body-worn accessory supplied or
approved by Motorola, keep the mobile device and its antenna at least
2.5 centimeters (1 inch) from your body when transmitting.
Using accessories not supplied or approved by Motorola may cause your
mobile device to exceed RF energy exposure guidelines. For a list of
Motorola-supplied or approved accessories, visit our Web site at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from
external sources if inadequately shielded, designed, or otherwise
configured for RF energy compatibility. In some circumstances your
mobile device may cause interference with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices
instruct you to do so.
In an aircraft, turn off your mobile device whenever instructed to do so
by airline staff. If your mobile device offers an airplane mode or similar
feature, consult airline staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or
defibrillator, consult your physician before using this mobile device.
Persons with implantable medical devices should observe the following
precautions:
DRAFT
91
Safety Information
•
ALWAYS keep the mobile device more than 20 centimeters
(8 inches) from the implantable medical device when the
mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to
minimize the potential for interference.
•
Turn OFF the mobile device immediately if you have any
reason to suspect that interference is taking place.
Read and follow the directions from the manufacturer of your
implantable medical device. If you have any questions about using your
mobile device with your implantable medical device, consult your
healthcare provider.
Driving Precautions
The use of wireless phones while driving may cause distraction.
Discontinue a call if you can’t concentrate on driving.
Additionally, the use of wireless devices and their accessories may be
prohibited or restricted in certain areas. Always obey the laws and
regulations on the use of these products.
Responsible driving practices can be found in the “Smart Practices
While Driving” section in this guide (or separate guide).
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always,
posted and can include fueling areas, such as below decks on boats,
fuel or chemical transfer or storage facilities, or areas where the air
contains chemicals or particles, such as grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not
remove, install, or charge batteries. In such areas, sparks can occur and
cause an explosion or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as
follows:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a
fire.
Your battery or mobile device may require recycling
in accordance with local laws. Contact your local
regulatory authorities for more information.
Do not throw your battery or mobile device in the
trash.
032374o
032376o
032375o
DRAFT
92
Safety Information
Batteries & Chargers
Caution: Improper treatment or use of batteries may present a
danger of fire, explosion, leakage, or other hazard. For more
information, see the “battery use & safety” section in the user’s
guide.
Keep Your Mobile Device and Its
Accessories Away From Small Children
These products are not toys and may be hazardous to children. For
example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing
hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Glass Parts
Some parts of your mobile device may be made of glass. This glass
could break if the product is dropped on a hard surface or receives a
substantial impact. If glass breaks, do not touch or attempt to remove.
Stop using your mobile device until the glass is replaced by a qualified
service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when playing video games. These
may occur even if a person has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult with your physician before
playing video games or enabling a flashing-lights feature (if available)
on your mobile device.
Discontinue use and consult a physician if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of
awareness, involuntary movements, or disorientation. It is always a
good idea to hold the screen away from your eyes, leave the lights on in
the room, take a 15-minute break every hour, and stop use if you are
tired.
Caution About High Volume Usage
Warning:
Exposure to loud noise from any source for
extended periods of time may affect your hearing. The
louder the volume sound level, the less time is required
before your hearing could be affected. To protect your
hearing:
•
Limit the amount of time you use headsets or headphones at
high volume.
Do not let your battery, charger, or mobile device
get wet.
Listening at full volume to music or voice through a
headset may damage your hearing.
Symbol Definition
DRAFT
93
Industry Canada Notice
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near
you.
If you experience hearing discomfort, including the sensation of
pressure or fullness in your ears, ringing in your ears, or muffled speech,
you should stop listening to the device through your headset or
headphones and have your hearing checked.
For more information about hearing, see our Web site at
www.motorola.com/hearingsafety
(in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in
your hands, arms, shoulders, neck, or other parts of your body. If you
continue to have discomfort during or after such use, stop use and see a
physician.
[Mar0108]
Industry Canada Notice to Users
Indust ry Cana da Notice
Operation is subject to the following two conditions: (1) This device may
not cause interference and (2) This device must accept any interference,
including interference that may cause undesired operation of the
device. See RSS-GEN 7.1.5.
FCC Notice to Users
FCC Notice
The following statement applies to all products that have
received FCC approval. Applicable products bear the FCC logo,
and/or an FCC ID in the format FCC-ID:xxxxxx on the product
label.
Motorola has not approved any changes or modifications to this device
by the user. Any changes or modifications could void the user’s authority
to operate the equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. See 47 CFR
Sec. 15.19(3).
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
DRAFT
94
Warranty
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the
receiver.
•
Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for
help.
Motorola Limited Warranty for the United States and Canada
Wa rr a n t y
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its
telephones, pagers, messaging devices, and consumer and professional
two-way radios (excluding commercial, government or industrial radios)
that operate via Family Radio Service or General Mobile Radio Service,
Motorola-branded or certified accessories sold for use with these
Products (“Accessories”) and Motorola software contained on
CD-ROMs or other tangible media and sold for use with these Products
(“Software”) to be free from defects in materials and workmanship
under normal consumer usage for the period(s) outlined below. This
limited warranty is a consumer's exclusive remedy, and applies as
follows to new Motorola Products, Accessories and Software purchased
by consumers in the United States or Canada, which are accompanied
by this written warranty:
Products and Accessories
Products Covered Length of Coverage
Products and
Accessories
as defined
above, unless otherwise
provided for below.
One (1) year
from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Decorative
Accessories and
Cases.
Decorative
covers, bezels,
PhoneWrap™ covers and
cases.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
DRAFT
95
Warranty
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and replacement
of parts due to normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80%
of their rated capacity and batteries that leak are covered by this limited
warranty.
Abuse & Misuse.
Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as
physical damage (cracks, scratches, etc.) to the surface of the product
resulting from misuse; (b) contact with liquid, water, rain, extreme
humidity or heavy perspiration, sand, dirt or the like, extreme heat, or
food; (c) use of the Products or Accessories for commercial purposes or
subjecting the Product or Accessory to abnormal usage or conditions; or
(d) other acts which are not the fault of Motorola, are excluded from
coverage.
Use of Non-Motorola Products and Accessories.
Defects or
damage that result from the use of non-Motorola branded or certified
Products, Accessories, Software or other peripheral equipment are
excluded from coverage.
Unauthorized Service or Modification.
Defects or damages
resulting from service, testing, adjustment, installation, maintenance,
alteration, or modification in any way by someone other than Motorola,
or its authorized service centers, are excluded from coverage.
Altered Products.
Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken
seals or that show evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-Motorola housings, or parts, are
excluded from coverage.
Communication Services.
Defects, damages, or the failure of
Products, Accessories or Software due to any communication service or
signal you may subscribe to or use with the Products Accessories or
Software is excluded from coverage.
Monaural Headsets.
Ear buds and boom
headsets that transmit
mono sound through a
wired connection.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
Consumer and
Professional Two-Way
Radio Accessories.
Ninety (90) days
from the date of
purchase by the first consumer
purchaser of the product.
Products and
Accessories that are
Repaired or Replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Products Covered Length of Coverage
DRAFT
96
Warranty
Software
Exclusions
Software Embodied in Physical Media.
No warranty is made that
the software will meet your requirements or will work in combination
with any hardware or software applications provided by third parties,
that the operation of the software products will be uninterrupted or
error free, or that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media.
Software that is not
embodied in physical media (e.g. software that is downloaded from the
internet), is provided “as is” and without warranty.
Who Is Covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the
purchase price of any Products, Accessories or Software that does not
conform to this warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products, Accessories or
parts. No data, software or applications added to your Product,
Accessory or Software, including but not limited to personal contacts,
games and ringer tones, will be reinstalled. To avoid losing such data,
software and applications please create a back up prior to requesting
service.
How to Obtain Warranty Service or Other
Information
You will receive instructions on how to ship the Products, Accessories or
Software, at your expense, to a Motorola Authorized Repair Center. To
obtain service, you must include: (a) a copy of your receipt, bill of sale or
other comparable proof of purchase; (b) a written description of the
problem; (c) the name of your service provider, if applicable; (d) the
name and location of the installation facility (if applicable) and, most
importantly; (e) your address and telephone number.
Products Covered Length of Coverage
Software.
Applies only to physical
defects in the media that embodies
the copy of the software (e.g.
CD-ROM, or floppy disk).
Ninety (90) days
from
the date of purchase.
USA Phones:
1-800-331-6456
Pagers:
1-800-548-9954
Two-Way Radios and Messaging Devices:
1-800-353-2729
Canada All Products:
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone number
designated above for the product with which they are used.
DRAFT
97
Hearing Aids
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR
REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS
THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT
SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR
FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF
BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR
APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO USE THE
PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE
DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation
on the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that
vary from state to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola
certain exclusive rights for copyrighted Motorola software such as the
exclusive rights to reproduce and distribute copies of the Motorola
software. Motorola software may only be copied into, used in, and
redistributed with, the Products associated with such Motorola
software. No other use, including without limitation disassembly of
such Motorola software or exercise of the exclusive rights reserved for
Motorola, is permitted.
Hearing Aid Compatibility with Mobile Phones
Heari ng Aids
Some Motorola phones are measured for compatibility with hearing
aids. If the box for your particular model has “Rated for Hearing Aids”
printed on it, the following explanation applies.
When some mobile phones are used near some hearing devices
(hearing aids and cochlear implants), users may detect a buzzing,
humming, or whining noise. Some hearing devices are more immune
than others to this interference noise, and phones also vary in the
amount of interference they generate.
The wireless telephone industry has developed ratings for some of their
mobile phones, to assist hearing device users in finding phones that
may be compatible with their hearing devices. Not all phones have been
rated. Phones that are rated have the rating on their box or a label on
the box.
The ratings are not guarantees. Results will vary depending on the
user’s hearing device and hearing loss. If your hearing device happens to
be vulnerable to interference, you may not be able to use a rated phone
DRAFT
98
WHO Information
successfully. Trying out the phone with your hearing device is the best
way to evaluate it for your personal needs.
M-Ratings:
Phones rated M3 or M4 meet FCC requirements and are
likely to generate less interference to hearing devices than phones that
are not labeled. M4 is the better/higher of the two ratings.
T-Ratings:
Phones rated T3 or T4 meet FCC requirements and are likely
to be more usable with a hearing device’s telecoil (“T Switch” or
“Telephone Switch”) than unrated phones. T4 is the better/higher of the
two ratings. (Note that not all hearing devices have telecoils in them.)
Hearing devices may also be measured for immunity to this type of
interference. Your hearing device manufacturer or hearing health
professional may help you find results for your hearing device. The more
immune your hearing aid is, the less likely you are to experience
interference noise from mobile phones.
Information from the World Health Organization
WHO Information
Present scientific information does not indicate the need for any special
precautions for the use of mobile phones. If you are concerned, you may
want to limit your own or your children’s RF exposure by limiting the
length of calls or by using handsfree devices to keep mobile phones
away from your head and body.
Source: WHO Fact Sheet 193
Further information:
http://www.who.int./peh-emf
Product Registration
Registration
Online Product Registration:
www.motorola.com/us/productregistration
Product registration is an important step toward enjoying your new
Motorola product. Registering permits us to contact you for product or
software updates and allows you to subscribe to updates on new
products or special promotions. Registration is not required for warranty
coverage.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola Personal Communications Product
you will need to provide a copy of your dated sales receipt to confirm
warranty status.
Thank you for choosing a Motorola product.
DRAFT
99
Export Law
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United
States of America and Canada. The Governments of the United States
of America and Canada may restrict the exportation or re-exportation of
this product to certain destinations. For further information contact the
U.S. Department of Commerce or the Canadian Department of Foreign
Affairs and International Trade.
Caring for the Environment by Recycling
Recycl ing Information
This symbol on a Motorola product means the product should
not be disposed of with household waste.
Disposal of your Mobile Device and
Accessories
Please do not dispose of mobile devices or electrical accessories (such
as chargers, headsets, or batteries) with your household waste. These
items should be disposed of in accordance with the national collection
and recycling schemes operated by your local or regional authority.
Alternatively, you may return unwanted mobile devices and electrical
accessories to any Motorola Approved Service Center in your region.
Details of Motorola approved national recycling schemes, and further
information on Motorola recycling activities can be found at:
www.motorola.com/recycling
Disposal of your Mobile Device Packaging
and User’s Guide
Product packaging and user’s guides should only be disposed of in
accordance with national collection and recycling requirements. Please
contact your regional authorities for more details.
California Perchlorate Label
Perchlorat e Label
Some mobile phones use an internal, permanent backup battery on the
printed circuit board that may contain very small amounts of
perchlorate. In such cases, California law requires the following label:
“Perchlorate Material – special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
.”
There is no special handling required by consumers.
DRAFT
100
Privacy and Data Security
Privacy and Data Security
Priva cy and Data Security
Motorola understands that privacy and data security are important to
everyone. Because some features of your mobile device may affect your
privacy or data security, please follow these recommendations to
enhance protection of your information:
• Monitor access
—Keep your mobile device with you and do
not leave it where others may have unmonitored access. Lock
your device’s keypad where this feature is available.
• Keep software up to date
—If Motorola or a
software/application vendor releases a patch or software fix
for your mobile device that updates the device’s security,
install it as soon as possible.
• Erase before recycling
—Delete personal information or
data from your mobile device prior to disposing of it or turning
it in for recycling. For step-by-step instructions on how to
delete all personal information from your device, see the
section entitled “master clear” or “delete data” in the user’s
guide.
Note:
For information on backing up your mobile device data
before erasing it, go to
www.motorola.com
and then navigate
to the “downloads” section of the consumer Web page for
“Motorola Backup” or “Motorola Phone Tools.”
• Understanding AGPS
—To provide location information for
emergency calls, certain Motorola mobile devices incorporate
Assisted Global Positioning System (AGPS) technology. AGPS
technology also can be used in non-emergency applications to
track and monitor a user’s location—for example, to provide
driving directions. Users who prefer not to permit such
tracking and monitoring should avoid using such applications.
If you have further questions regarding how the use of your mobile
device may impact your privacy or data security, please contact
Motorola at
privacy@motorola.com
, or contact your service provider.
Smart Practices While Driving
Drivi ng Safety
Drive Safe, Call Smart
Check the laws and regulations on the use of mobile devices
and their accessories in the areas where you drive. Always obey
them. The use of these devices may be prohibited or restricted in
certain areas -- for example, handsfree use only. Go to
www.motorola.com/callsmart
(in English only) for more
information.
Your mobile device lets you communicate by voice and data—almost
anywhere, anytime, wherever wireless service is available and safe
conditions allow. When driving a car, driving is your first responsibility.
DRAFT
101
Driving Safety
If you choose to use your mobile device while driving, remember the
following tips:
• Get to know your Motorola mobile device and its
features such as speed dial and redial.
If available, these
features help you to place your call without taking your
attention off the road.
• When available, use a handsfree device.
If possible, add an additional layer of
convenience to your mobile device with one
of the many Motorola Original handsfree
accessories available today.
• Position your mobile device within easy reach.
Be able
to access your mobile device without removing your eyes from
the road. If you receive an incoming call at an inconvenient
time, if possible, let your voicemail answer it for you.
• Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic
or hazardous weather conditions.
Rain, sleet, snow, ice,
and even heavy traffic can be hazardous.
• Do not take notes or look up phone numbers while
driving.
Jotting down a “to do” list or going through your
address book takes attention away from your primary
responsibility—driving safely.
• Dial sensibly and assess the traffic; if possible, place
calls when your car is not moving or before pulling into
traffic.
If you must make a call while moving, dial only a few
numbers, check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations
that may be distracting.
Make people you are talking with
aware you are driving and suspend conversations that can
divert your attention away from the road.
• Use your mobile device to call for help.
Dial 911 or other
local emergency number in the case of fire, traffic accident, or
medical emergencies.*
• Use your mobile device to help others in emergencies.
If you see an auto accident, crime in progress, or other serious
emergency where lives are in danger, call 911 or other local
emergency number, as you would want others to do for you.*
• Call roadside assistance or a special non-emergency
wireless assistance number when necessary.
If you see
a broken-down vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless number.*
* Wherever wireless phone service is available.
DRAFT
102
index
index
1X indicator 16, 17
911 indicator 17
A
accessories 11, 19
airplane mode indicator 17
alarm clock 77
alarm indicator 18
alarm only indicator 18
alert,turn off 33
answer options 29
attach a number 37
automatic e-mail setup 51
B
back key 2
backlight 30
banner 30
battery level indicator 17
battery life, extend 12
battery,conserving 12
Bluetooth active indicator 18
Bluetooth connected indicator 18
Bluetooth connections
connect during call 81
Bluetooth on indicator 18
brightness 30
browser 67
browser key 2
C
cables 78
calculator 77
calendar event indicator 18
call
answer 29
conference 40
DTMF tones 40
call times 39
minute beep 39
reset 39
camera 60
camera lens 3
camera/camcorder key 2
capitalization 44
car kit 19
center key 2
clock 30
world 77
codes 20, 21
conference call 40
conserve battery 12
contacts 73
add entries to group 75
DRAFT
103
index
call entry 73
create group 75
edit entry 73
picture ID 74
primary number 74
ringer ID 73
sort entries 74
view entry 73
D
data call indicator 17
data volumes
reset 39
dialed calls 34
digital indicator 16
display
brightness 30
dormant indicator 17
drafts folder 55
DTMF tones 40
E
e-mail
automatic setup 51
read 52
send 52
set up manually 51
emergency number 35
end key 2
entry mode
capitalization 44
function key 43
iTAP 42
QWERTY 42
EVDO indicator 17
export regulations 99
F
function key 2
function key entry mode 43
G
group
add entries 75
create 75
H
handsfree speaker 19
headset 19
headset port 3
hearing aid 38
hearing aids 97
home screen
banner 30
I
indicators 16
speakerphone 18
international access code 37
iTAP text entry mode 42
DRAFT
104
index
K
key
function key 43
special 43
key volume 29
keypad lock 3, 21
keypad locked indicator 17
L
language 30
location on indicator 17
lock
keypad 21
phone 20
M
menu language 30
message
alerts 29
delete 54
drafts 55
quick text 53, 54
send text message 53
set up 54
store message objects 55
text message 53
view sent message 54
message indicator 18
messaging key 2
micro USB port 3
minute beep 39
missed call indicator 18
Missed Calls message 34
N
navigation key 2, 11
network
adjust settings 75
call connect tones 76
call drop tone 76
no service indicator 17
notepad 77
O
operator hosted e-mail 51
optional accessory 11
optional feature 11
P
phone
network settings, adjust 75
network, call connect tones 76
network, call drop tone 76
talking phone 28
phonebook 37
add entries to group 75
call entry 73
create group 75
edit entry 73
picture ID 74
primary number 74
DRAFT
105
index
ringer ID 73
view entry 73
picture ID 74
power key 2
Q
quick text 53, 54
QWERTY text entry mode 42
R
received calls 34
recent calls 34
redial 27, 33
return a call 34
ringer ID 73
roaming indicator 17
S
security code 21
send key 2
set up e-mail 51
signal strength indicator 16
sounds off (silent) indicator 18
speakerphone 19
speakerphone indicator 18
special keys 43
SSL indicator 17
status indicators 16
T
text entry 41
TTY indicator 17
U
unanswered call indicator 18
unlock code 20, 21
unlock, phone 20
USB cables 78
V
vibrate on indicator 18
video 60
voice call indicator 18
voice key 3
voice note 66
play 66
voice recognition 68
voice recognition active indicator
17
voice recogntion listening indicator
17
voicemail 52
voicemail message indicator 18,
52
volume keys 3
W
world clock 77
U.S. patent Re. 34,976
DRAFT
106
index
DRAFT
